Movement Types MM-IM Task Force Logistics
SAP AG Page 1
Movement Types MM-IM
This document was created in the context of the Retail Task Force Logistics. Its aim is to help con-
sultants solve concrete problems in customer projects.
You can find more documents on the Task Force Logistics under the Expert Knowledge Corner in
http://service.sap.com/retail.
Movement Types MM-IM Task Force Logistics
SAP AG Page 2
Description
The following questions are dealt with in the presentation:
• What are movement types?
• What influences them and how are they influenced (possible configurations)?
• How are movement types classified?
• Which are the most important tables/transactions?
The configurations are also explained by numerous examples.
Important terms that are used in this environment include:
• Value and quantity update
• Movement indicator
• Special stock indicator
• Receipt indicator
• Consumption indicator
among many others.
(Comment: Read the notes in the presentation.)
MovementTypes_MM
-IM.ppt
®
� SAP AG 2000 BWART 05/2000
SAP AG
Movement Types in MM-IM
®
� SAP AG 2000 BWART 05/2000
Contents
� Introduction
� Table T156SY with value strings/quantity strings
� Other movement type tables
®
� SAP AG 2000 BWART 05/2000
What is a Movement Type?
� Key for a specific goods movement (incomplete)
� Quantity update (stock tables)
� Value update (FI document, account determination)
� Screen layout (dialog only)
� GR/GI slip print
� Checks (min. shelf life, dynamic availability, etc.)
� Link to WM, QM, serial numbers
®
� SAP AG 2000 BWART 05/2000
Stock Tables Overview
Vendor
Plant
Customer
GR-
blocked
stock
Returns
MARD-
RETME
Subcontractor
MSSL/MSLB
(Sobkz = O)
unrestricted/Q
Consignment
MSKU
(Sobkz = V)
unrestricted/Q
Returnable
packaging
MSKU
(Sobkz = W)
unrestricted/Q
Customer order
MSSA/MSKA
(Sobkz = E)
unrestricted
Q/S
Project stock
MSSQ/MSPR
(Sobkz = Q)
unrestricted
Q/S
Vendor consignment/RTP
MKOL (Sobkz = K, M)
unrestricted Q/S
Storage location
MARD
unrestricted/Q/S
+ transfer (313/5)
Batches
(MCHB)
Plant level MARC
transfer (MARC-UMLMC - 303/5)
transit (MARC-TRAME - 641)
101 601
103 105 453 651
Consumption
201
®
� SAP AG 2000 BWART 05/2000
Classification of Movement Types
� 1xx GR from purchasing/production + returns
� 2xx GI for consumption
� 3xx, 4xx Transfers
� 5xx GR without reference to PO or PP order
� 6xx LE-SHP movement types
� 7xx Physical inventory (MM-IM: 70x / WM: 71x)
� 8xx Brazil
� Customer range: 9xx, Xxx, Yxx, Zxx
� Complete list and description: see IMG MM-IM
®
� SAP AG 2000 BWART 05/2000
Movement Type Tables: Customizable
� T156 Definition (key: Bwart)
� T156B Screen layout (46C: MIGO_CUST_FIELDS) (Bwart + Sobkz)
Batch determination
� T156SC WM mvt, availability check (complete key) (< 4.6: T156S)
� T156Q QM inspection lot origin, HU
� T156X Account modifier (KOMOK)
� T156T Short text
� T158B Allowed movement types per transaction
� T157H Longer text per transaction / special stock
� T157D Reason for movement
� T156N Subsequent movement types
� TMCA LIS statistic group
®
� SAP AG 2000 BWART 05/2000
Customizing Movement Type: OMJJ
� All customizable movement type tables can be
maintained with OMJJ (Customizing MM-IM)
� View-Cluster MB_156
� No new entries possible, only copy
� Do not create own movement types only to change a
customizing field!
� To copy a movement type do not forget to select the
whole range because you want to copy to 9xx range
®
� SAP AG 2000 BWART 05/2000
Movement Type Tables: System Tables
� T156SY Quantity / value strings (< 4.6: T156S)
� T156W Value strings (Key: BUSTW)
� T156M Quantity strings (Key: BUSTM)
� T156F Field segments
� T156C Stock types for LIS
®
� SAP AG 2000 BWART 05/2000
Table T156SY,
Value Strings, Quantity Strings
®
� SAP AG 2000 BWART 05/2000
Movement Type 101 Overview
Vendor
Plant
Subcontractor
MSSL/MSLB
(Sobkz = O)
Unrestricted/Q
Customer order
MSSA/MSKA
(Sobkz = E)
Unrestricted
Q/S
Project stock
MSSQ/MSPR
(Sobkz = Q)
Unrestricted
Q/S
Vendor consignment/RTP
MKOL (Sobkz = K, M)
Unrestricted Q/S
Storage location
MARD
Unrestricted
Quality inspection
Blocked stock
Batches
(MCHB)
Transit stock
(MARC-TRAME)
101 FProduction
101 B
Insmk _, 2, 3
101 B + Kzzug X101 B
K / M
Sobkz O
E
Q
Consumption
Kzvbr V
®
� SAP AG 2000 BWART 05/2000
Central Table T156S (T156SY + T156SC)
� Contains the complete key for a specific movement
� T156S was split in 4.6A into
� T156SY: client-independent, system table BUSTW/BUSTM,...
� T156SC: client-dependent, customizable WM mvt types, ...
� Key field BUSTR for T156SY derived from T156
� Old customer mvt types have their own BUSTR
� New customer mvt type: BUSTR for T156SY is copied
from standard mvt type
®
� SAP AG 2000 BWART 05/2000
Key for T156SY and T156SC
BWART
101
901
BUSTR
101
101
T156
BUSTR ...
101 ...
BUSTW
WE01T156SY
BWART ...
101 ...
901 ...
Avail. check
01
02
T156SC
®
� SAP AG 2000 BWART 05/2000
From Movement Type to Value/Quantity String
User enters data
Movement type 201
Transaction MB1A
No special stock
Plant 0001
Material XYZ
Program reads T156SY (old: T156S)
Value string ref. BUSTR 201
Mvt indicator KZBEW space
Special stock SOBKZ space
Value update WERTU X
Quantity update MENGU X
Receipt indicator KZZUG space
Consumption indic. KZVBR space
and finds…
Value string BUSTW WA01
Quantity string BUSTM MA01
T158-KZBEW (transaction)
T134M (material type)
T156-BUSTR (mvt type)
®
� SAP AG 2000 BWART 05/2000
®
� SAP AG 2000 BWART 05/2000
Movement Indicator KZBEW
� Needed to differentiate between
� GR for purchase order (101 B)
� GR for production order (101 F)
� Depends on transaction (T158) for MB transactions
� Filled by MB_CREATE callers in IMSEG
(variable in VL02 / VL32)
� Possible values:
� B = purchase order
� F = production order (not repetitive manufacturing)
� L = LE-SHP delivery
� Space= movement without purchase/production order
� L/Space: will probably merge together in next releases
®
� SAP AG 2000 BWART 05/2000
Receipt Indicator KZZUG
� Filled only in case of transport orders
� Movement types 351/641/643 (GI) and 101 (GR)
� MB_CREATE: filled for T156-KZBWA 1,3,4,5
(set in MB_CREATE_GOODS_ISSUE_ITEM_TRA)
� MB11/MB01: is not set by purchase order interface
(EBEFU/BBEFU). It is set internally by SAPMM07M
®
� SAP AG 2000 BWART 05/2000
Consumption Indicator KZVBR (1)
� GR for PO: depends on assignment category in T163K
(OME9). Table T163K also sets special stock SOBKZ.
� SD and PP also work with table T163K
� Values:
� space normal goods issue with MB1A
� V account assignment K (normal consumption)
� A account assignment A (assets)
� E/P used for non-valuated special stocks E/Q
� Valuated special stock E/Q (KZBWS not initial):
T156SY is read with KZVBR space
� Used by SD and QM to determine if an assignment to
CO object is necessary
®
� SAP AG 2000 BWART 05/2000
Consumption Indicator KZVBR (2)
� Set externally by LE-SHP, MM-PUR, PP
� Database checks with SE16:
� LIPS-KZVBR inbound/outbound delivery
� EKPO-KZVBR purchase order
� AFPO-KZVBR production order
� Debugging: check incoming interfaces
� MB_CREATE_GOODS_MOVEMENT: internal table IMSEG
� MM07MFB7, call ME_READ_ITEM_GOODS_RECEIPT: XEBEFU
� MM07MPPS,call CO_SF_ITEM_GOODS_RECEIPT: XFBEFU
®
� SAP AG 2000 BWART 05/2000
From Value String to Processing Key
T156SY
bustr 201
wertu X
mengu X
sobkz space
kzbew space
kzzug space
kzvbr space
Valuation
program
SAPLMBGB
Form WA01
Table XACCIT
BSX 300000 -20
GBB 400000 +20
Accounting
interface
Table XZCXCM
(1) BSX H - 20
(2) GBB S +20
(3) PRD 0
(4) BSX 0
(5) UMB 0
Customer account table T030
BSX 300000
GBB VBR 400000
MR_ACCOUNT_
ASSIGNMENT
Table T156W: WA01
(1) BSX
(2) GBB
(3) PRD
(4) BSX
(5) UMB
Loop at X156W
T156X:
account modifier
(2) VBR
®
� SAP AG 2000 BWART 05/2000
®
� SAP AG 2000 BWART 05/2000
T156X: Account Modifier (KOMOK)
� Counter CNT02 in T156X refers to counter in T156W
(= identifier for processing key)
� Only possible for GBB, PRD, KON, AUM, (WRX?)
� SD/QM: KZVBR leads to different account modifiers
depending on KZVBR (set if CO object needed):
� SD uses VAX and VAY (CO object for VAY) (movement type 601)
� QM uses VQP and VQY (CO object for VQY) (movement type 331)
� In case of valuated special stock E/Q (KZBWS set), we read
� Table T156SY w/o KZVBR
� Table T156X with KZVBR (E/P/V)
®
� SAP AG 2000 BWART 05/2000
T156X: Indicator XPKON (1)
� XPKON = X means account assignment data (CO object) will
be copied to XACCIT of that processing key (usually GBB)
� Copying of CO object also depends on field selection in
T156B (OMBW). See note 117596 for special stock E/Q.
= possible solution to message KI235 for GBB line
� Manual account is also be copied to that line
� Can also be set for PRD/AUM if customer wants the
same CO object for price differences
(possible for AUM since 30F, note 13984)
= possible solution to message KI235 for PRD/AUM line
®
� SAP AG 2000 BWART 05/2000
T156X: Indicator XPKON (2)
� Entry 101 is necessary for GR for PO with account
assignment (value string WE06 processing key KBS)
� KBS means we copy the account from the PO, so no
account determination is necessary (already done)
®
� SAP AG 2000 BWART 05/2000
Check Strings in Material Documents
� SE16 MSEG contains
� All T156SY fields (Bwart, Mengu, Wertu, Kzbew, Kzvbr, Kzzug)
� Value string BUSTW
� Quantity string BUSTM
®
� SAP AG 2000 BWART 05/2000
T156M: Quantity Strings for Simple Movements
BWART +
SOBKZ
T156
SHKZG
T156SY
BUSTM
T156B
UMSOK
T156M T156F
501 S (+) MA01 MA01 – 1 = L01 MARD-LABST
201 H (-) MA01 MA01 – 1 = L01 MARD-LABST
201K H (-) MAK1 MAK1 – 1 = LK0 K01 MARD-KLABS + MKOL-SLABS
BWART +
SOBKZ
T156
SHKZG
T156SY
BUSTM
T156B
UMSOK
T156M T156F
501 S (+) MA01 MA01 2 1 = LQ1 MARD-INSME
201 H (–) MA01 MA01 2 1 = LQ1 MARD-INSME
201K H (–) MAK1 MAK1 2 1 = LKQ KQ1 MARD-KINSM + MKOL-SINSM
Movements 501, 201 and 201K without QM
Movements 501, 201 and 201K with QM
501: GR from vendor without purchase order
201: GI for cost center
201K: GI for cost center from vendor consignment
®
� SAP AG 2000 BWART 05/2000
T156M: Quantity Strings for Transfers
BWART +
SOBKZ
T156
SHKZG
T156SY
BUSTM
T156B
UMSOK
T156M T156F
301 H (–) MA04 MA01 – 1 = L01
MA01 – 2 = L01
MARD-LABST (–)
MARD-LABST (+)
411K H (–) MAK4 MAK4 – 1 = LK0 K01
MAK4 – 2 = L01
MARD-KLABS MKOL-SLABS (–)
MARD-LABST (+)
413Q H (–) MAAQ E MAAQ – 1 = Q01 QSL
MAAQ – 2 = A01 ASL
MSPR-PRLAB MSSQ-SQLAB (–)
MSKA-KALAB MSSA-SALAB (+)
453 S (+) MAR1 MAR1 – 1 = L01
MAR1 – 2 = LR0
MARD-LABST (+)
MARD-RETME (–)
301: Transfer from plant to plant in one step (no PO, unrestricted stock)
411K: Transfer from vendor consignment to unrestricted storage location
413Q: Transfer from project stock (Q) to customer order stock (E) - unrestricted
453: Transfer from returns stock to unrestricted storage location
®
� SAP AG 2000 BWART 05/2000
Other Movement Type Tables
®
� SAP AG 2000 BWART 05/2000
T156N: Subsequent Movement Types
� Key: FCODE + BWART
� ST 601 > 602: cancel movement type (used in
MB_CANCEL_GOODS_MOVEMENT)
� RL 101 > 122: return delivery transaction MBRL
� Special codes for automatic movements:
� WEUB 647-> 101 (one-step transfer with transfer PO)
� LBWA -> 543 (GI of components during GR subcontracting)
®
� SAP AG 2000 BWART 05/2000
T156B: Screen Layout
� Field modification for MB11 transactions
� Not possible for MB01 (101 mvt types) as account
assignment is copied from PO
� Determines also which account assignments will be
copied to FI document
� Not used in MB_CREATE_GOODS_MOVEMENT
� MIGO: new table MIGO_CUST_FIELDS
®
� SAP AG 2000 BWART 05/2000
T158B: Allowed Movement Types
� Allowed movement types per transaction
� MB_CREATE callers are responsible for creating the
entries in T158B for their own transaction
� Help view available for T158B/T157H
