FOP 212 + SOP S76 REV 03

Prévia do material em texto

FOP 212
RECIBO DE ACEITAÇÃO DE MANUAIS OU PROGRAMAS
De: GTCE Processo ANAC: 00058.035215/2019-02 Nº SEI 3498328 Data: 16/09/2019
DESTINATÁRIO
Nome da Organização: Omni Táxi Aéreo CNPJ: 03.670.763/0001-38
Endereço da Sede Administrativa: AAv. Ayrton Senna, Rua F1 , 2541 Lote 40 Barra da Tijuca., 2541, Rio de Janeiro - RJ
CEP: 22775-001
Em Atenção à: Mauro Gonçalves Brasil Cargo: Diretor de Operações
FOP 107-135 de Referência: 026/OPR/2019
DESCRIÇÃO DO MATERIAL
Procedimentos operacionais padrões
REVISÃO
TIPO IDENTIFICAÇÃO
Original Reedição X Nº da Revisão: 03 Data da Revisão: 05/09/2019
MODELOS AFETADOS
FABRICANTE MODELO FABRICANTE MODELO
Sikorsky S-76 - -
PUBLICAÇÕES DE REFERÊNCIA
TIPO DA PUBLICAÇÃO EMISSOR REVISÃO DATA
RBAC 135 ANAC - -
IS 119-003 ANAC A 17/05/2013
OBSERVAÇÕES E RESTRIÇÕES
Deve ser mantida uma cópia deste FOP anexada a cada cópia do SOP distribuído.
PARECER
ACEITAÇÃO: X DATA DE PROTOCOLO ANAC: 13/09/2019
Nome: Joel Sebastião Maia Júnior Cargo do Analista: Gerente Técnico
Nome: Joel Sebastião Maia Júnior Cargo do Aprovador: Gerente Técnico
Documento assinado eletronicamente por Joel Sebastiao Maia Junior, Gerente Técnico, em 16/09/2019, às 11:50,
conforme horário oficial de Brasília, com fundamento no art. 6º, § 1º, do Decreto nº 8.539, de 8 de outubro de 2015.
A autenticidade deste documento pode ser conferida no site http://sistemas.anac.gov.br/sei/autenticidade, informando o
código verificador 3498328 e o código CRC 338D6C01.
SEI/ANAC - 3498328 - FOP 212 https://sistemas.anac.gov.br/sei/modulos/pesquisa/md_pesq_document...
1 of 1 18/09/2019 16:58



STANDARD OPERATING
PROCEDURES
SOP 11
SIKORSKY – S 76C
ISSUED BY:
Department of Flight Operations
Diretoria de Operações da OMNI Táxi Aéreo S/A
APPROVED BY:
Brazilian Civil Aviation Authority
Agência Nacional de Aviação Civil - ANAC
Revision: 03
Issued Date: 05/SET/2019


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2
Revision: 02
Date: 04/01/2019


INTENTIONALLY BLANK



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 3
Revision: 02
Date: 04/01/2019



FOP 211



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4
Revision: 02
Date: 04/01/2019














INTENTIONALLY BLANK












OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5
Revision: 02
Date: 04/01/2019


TABLE OF CONTENTS
FOP 211 ........................................................................................................ 3
TABLE OF CONTENTS ............................................................................... 5
LIST OF ILLUSTRATIONS ........................................................................ 11
STATEMENT .............................................................................................. 12
RECORD OF REVISION ............................................................................ 14
LIST OF EFFECTIVE PAGES .................................................................... 16
SECTION 1. INTRODUCTION ............................................................. 1.1
1.1 GENERAL ....................................................................................... 1.1
1.2 STRUCTURE .................................................................................. 1.1
1.3 APPLICABILITY.............................................................................. 1.2
1.4 REFERENCES ............................................................................... 1.2
1.5 SYSTEM OF REVISION ................................................................. 1.3
1.6 CONTROL AND DISTRIBUTION ................................................... 1.3
1.7 ABREVIATIONS ............................................................................. 1.4
1.8 DEFINITIONS ................................................................................. 1.5
1.9 TERMINOLOGY ............................................................................. 1.7
1.10 USE OF PROCEDURAL WORDS ................................................ 1.8
SECTION 2. PHILOSOPHY AND OPERATING POLICIES ................ 2.9
2.1 COMPLIANCE WITH STANDARD OPERATING PROCEDURES . 2.9
2.2 CREW RESPONSIBILITIES ........................................................... 2.9
2.3 AREAS OF RESPONSIBILITY ..................................................... 2.13
2.4 TASK SHARING ........................................................................... 2.14
2.5 CHECKLIST .................................................................................. 2.14
2.6 CREW COORDINATION ................................................................. 19


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6
Revision: 02
Date: 04/01/2019


2.7 USE OF AUTOMATION ................................................................... 20
2.8 COMMUNICATIONS ....................................................................... 21
2.9 SITUACIONAL AWARENESS ......................................................... 23
2.10 SAFETY OF FLIGHT ..................................................................... 26
2.11 BRIEFINGS ................................................................................... 27
2.12 FLIGHT PLANNING ....................................................................... 27
2.13 PILOT INCAPACITATION ............................................................. 28
2.14 OFFSHORE OPERATIONS (FLIGHTS TO OIL RIGS OR VESSELS)
DURING THE DAY ................................................................................. 28
2.15 NIGHT FLIGHT TO OIL RIG OR VESSEL ..................................... 30
SECTION 3. OPERATING LIMITATIONS ........................................... 3.2
3.1 TYPES OF OPERATION ................................................................ 3.2
3.2 MINIMUM FLIGHT CREW .............................................................. 3.2
3.3 WEIGHT LIMITS ............................................................................. 3.3
3.4 CLIMB PERFORMANCE ................................................................ 3.3
3.5 PERFORMANCE CLASS ............................................................... 3.4
3.5.3 PERFORMANCE CLASS 2 ...................................................... 3.9
3.6 OEI TRAINING OPERATIONS ..................................................... 3.16
3.7 CENTER OF GRAVITY LIMITS .................................................... 3.16
3.8 LOADING LIMITS ......................................................................... 3.16
3.9 AIRSPEED LIMITS ....................................................................... 3.17
3.10 ALTITUDE LIMITS ...................................................................... 3.17
3.11 AMBIENT TEMPERATURE LIMITS ........................................... 3.17
3.12 FLIGHT LIMITS........................................................................... 3.17
3.13 ELECTRONIC FLIGHT INSTRUMENT SYSTEM (EFIS) LIMITS
 ............................................................................................................. 3.19


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7
Revision: 02
Date: 04/01/2019


3.14 SLIDING CABIN DOOR LIMITS ................................................. 3.19
3.15 FLOTATION SYSTEM LIMITS ................................................... 3.20
3.16 ENGINE LIMITS ......................................................................... 3.20
3.17 FUEL ...........................................................................................3.25
3.18 ENGINE OIL ............................................................................... 3.27
3.19 TRANSMISSION LIMITS ............................................................ 3.29
3.20 ROTOR LIMITS .......................................................................... 3.30
3.21 ROTOR BRAKE LIMITS ............................................................. 3.30
3.22 ENGINE COWLING LIMITS ....................................................... 3.31
3.23 RETRACTABLE BOARDING STEP LIMITS ............................... 3.31
3.24 EMERGENCY LOCATOR TRANSMITTER (ELT) ...................... 3.31
3.25 GARMIN GPS 500W LIMITATIONS ........................................... 3.31
3.26 TCAS I TRAFFIC COLLISION AVOIDANCE SYSTEM .............. 3.32
3.27 WEATHER RADAR SYSTEM ..................................................... 3.33
3.28 INSTRUMENT MARKINGS ........................................................ 3.33
3.29 PLACARDS ................................................................................ 3.33
SECTION 4. NORMAL PROCEDURES............................................... 4.1
4.1 EXTERIOR CHECK ........................................................................ 4.1
4.2 INTERIOR CHECK ......................................................................... 4.8
4.3 BEFORE FIRST FLIGHT OF THE DAY .......................................... 4.9
4.4 BEFORE START .......................................................................... 4.17
4.5 STARTING ENGINES .................................................................. 4.22
4.6 AFTER START ............................................................................. 4.27
4.7 TAXING ........................................................................................ 4.36
4.8 PRE TAKEOFF ............................................................................. 4.38
4.9 TAKEOFF ..................................................................................... 4.40


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8
Revision: 02
Date: 04/01/2019


4.10 AFTER TAKEOFF / GO AROUND .............................................. 4.42
4.11 CRUISE ...................................................................................... 4.43
4.12 APPROACH / DESCENT ............................................................ 4.44
4.13 PRE LANDING............................................................................ 4.46
4.14 AFTER LANDING ....................................................................... 4.47
4.15 SHUTDOWN............................................................................... 4.48
4.16 OFFSHORE HELIDECK / ONSHORE HELIPAD ........................ 4.51
4.17 ENGINE POWER ASSURANCE CHECK ................................... 4.58
4.18 BRIEFINGS AND CALLOUTS .................................................... 4.61
4.19 PROCEDURES FOR COMPRESSOR DRY-UPS ...................... 4.66
SECTION 5. PATTERNS AND TECHNIQUES .................................... 5.1
5.1 RUNWAY CLASS 1 TAKEOFF PROCEDURE. .............................. 5.1
5.2 RUNWAY CLASS 2 TAKEOFF ....................................................... 5.2
5.3 ONSHORE ELEVATED HELIPAD / ONSHORE GROUND HELIPAD
TAKEOFF WITHOUT NO OBSTRUCTIONS CLASS 2 ......................... 5.3
5.4 OFFSHORE HELIDECK TAKEOFF CLASS 2 ................................ 5.5
5.5 OFFSHORE AFTER TAKEOFF / GO AROUND ............................. 5.7
5.6 RUNWAY CLASS 1 LANDING ....................................................... 5.8
5.7 RUNWAY LANDING CLASS 1, ALTERNATE PROCEDURE ........ 5.9
5.8 RUNWAY LANDING PERFORMANCE CLASS 2 ........................ 5.11
5.9 LANDING PROCEDURE OFFSHORE HELIDECK ...................... 5.12
SECTION 6. EMERGENCY AND MALFUNCTION ............................. 6.3
6.1 INTRODUCTION ............................................................................ 6.3
6.2 DEFINITIONS ................................................................................. 6.4
6.3 BASIC PROCEDURE IN THE EVENT OF AN EMERGENCY ........ 6.2
6.4 MOVEMENT OF MAJOR SWITCHES AND CONTROLS .............. 6.3


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 9
Revision: 02
Date: 04/01/2019


6.5 CIRCUIT BREAKERS AND ELETRICAL COMPONENTS ............. 6.4
6.6 MASTER WARNING PANELS ....................................................... 6.5
6.7 ENGINE OUT .................................................................................. 6.5
6.8 LANDING GEAR ............................................................................. 6.6
6.9 FIRE ................................................................................................ 6.6
6.10 FD DCPL ....................................................................................... 6.6
6.11 EGPWS EMERGENCY PROCEDURES ...................................... 6.7
6.12 ENGINE FAILURES DURING TAKEOFF AND LANDING ........... 6.7
6.13 ENGINE FAILURE DURING TAKEOFF ....................................... 6.9
6.14 ENGINE FAILURE DURING APPROACH AND LANDING ........ 6.19
6.15 OFFSHORE HELIDECK ENGINE FAILURE .............................. 6.20
6.16 EXPANDED EMERGENCY CHECKLIST ................................... 6.22
6.17 ADDITIONAL CONSIDERATIONS FOR SINGLE ENGINE FAILURE
 ............................................................................................................. 6.23
6.18 ADDITIONAL CONSIDERATIONS DUAL ENGINE FAILURE ... 6.24
6.19 ADDITIONAL CONSIDERATIONS FOR MAIN GEARBOX
FAILURES ........................................................................................... 6.26
6.20 ADDITIONAL CONSIDERATIONS FOR TAIL ROTOR
MALFUNCTIONS ................................................................................ 6.27
6.21 ADDITIONAL CONSIDERATIONS FOR TAIL ROTOR DRIVE
FAILURE IN CRUISE........................................................................... 6.28
6.22 ADDITIONAL CONSIDERATIONS FOR ELECTRICAL FAILURES
 ............................................................................................................. 6.29
6.23 ADDITIONAL CONSIDERATIONS FOR DAFCS FAILURES ..... 6.29
6.24 ADDITONAL GUINDANCE FOR DITCHING .............................. 6.29
SECTION 7. PBN OPERATIONS ...................................................... 7.32
7.1 PURPOSE .................................................................................... 7.32


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 10
Revision: 02
Date: 04/01/2019


7.2 PBN EQUIPMENT AND SYSTEM ................................................ 7.32
7.3 GPS GARMIN 500W ..................................................................... 7.32
7.4 OPERATING PROCEDURES ...................................................... 7.33
7.5 EXTENDED PBN OPERATING CHECKLIST ............................... 7.40
SECTION 8. GPS NORMAL PROCEDURES ...................................... 8.1
8.1 INTRODUCTION ............................................................................ 8.1
8.2 POWER ON .................................................................................... 8.1
8.3 FLIGHT PLAN ................................................................................. 8.1
8.4 SELECT DEPARTURE (SID) ......................................................... 8.2
8.5 SELECT ARRIVAL (STAR) ............................................................. 8.3
8.6 SELECT AN APPROACH ............................................................... 8.3
8.7 TO SELECT DEPARTURE, ARRIVAL OR AN APPROACH BY PROC
KEY: ......................................................................................................8.4
8.8 TO REMOVE AN APPROACH, ARRIVAL OR DEPARTURE FROM
THE ACTIVE FLIGHT PLAN: ................................................................. 8.5
8.9 TO ACTIVATE AN EXISTING FLIGHT PLAN ................................. 8.5
8.10 TO NAVIGATE A FLIGHT PLAN................................................... 8.5
8.11 INVERTING FLIGHT PLAN .......................................................... 8.5
8.12 TO DELETE A FLIGHT PLAN: ...................................................... 8.6
8.13 TO PERFORM TRIP PLANNING OPERATIONS: ........................ 8.6
8.14 RAIM PREDICTION ...................................................................... 8.7
8.15 BASIC APPROACH OPERATION ................................................ 8.8
8.16 MISSED APPROACH PROCEDURE ........................................... 8.9
8.17 CDI SCALE SETTING: ............................................................... 8.10




OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 11
Revision: 02
Date: 04/01/2019


 LIST OF ILLUSTRATIONS
Figure 2-1: Night visual approach 32
Figure 3-1: Category A Maximum Takeoff and Landing Weight (sheet 1 of 2)
 ................................................................................................................. 3.17
Figure 3-2: Operating Envelope.................... Erro! Indicador não definido.
Figure 3-3: Category B Maximum Takeoff and Landing Weight (sheet 1 of 2)
 ...................................................................... Erro! Indicador não definido.
Figure 3-4: Center of Gravity Limits at Various Gross Weights ............. Erro!
Indicador não definido.
Figure 3-5: Engine or Drive System Operating Limits ............................. 3.21
Figure 3-6: Height / Velocity Diagram ...................................................... 3.23
Figure 3-7: Instrument Markings (sheet 1 of 4) ....................................... 3.35
Figure 3-8: Vne Placards (sheet 1 of 2) ................................................... 3.39
Figure 4-1: S76C External Inspection (Turnaround).................................. 4.1
Figure 5-1: Runway Takeoff Category A ...... Erro! Indicador não definido.
Figure 5-2: Runway Takeoff Category B ...... Erro! Indicador não definido.
Figure 5-3: Offshore Helideck / Onshore Helipad Takeoff Category B . Erro!
Indicador não definido.
Figure 5-4: Runway / ground helipad LandingErro! Indicador não
definido.
Figure 5-5: Offshore helideck / onshore elevated helipad Landing ....... Erro!
Indicador não definido.





OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 12
Revision: 02
Date: 04/01/2019


 INTENTIONALLY BLANK





STATEMENT

This Standard Operating Procedures (SOP) Manual was developed in
accordance with the procedures provided by the manufacturer of the
Helicopter and complies with ANAC Supplemental Instruction Nr 119-
003. Thus, this manual has my approval and I commit to promoting its
use by the crew of the OMNI Táxi Aéreo S/A.







 Mauro Gonçalves Brasil










OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 13
Revision: 02
Date: 04/01/2019






















 INTENTIONALLY BLANK


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 14
Revision: 03
Date: 05/09/2019




RECORD OF REVISION
The record of revision should be always updated. Upon the revision
has been received, must be registered in table below.

Revision Nr Issue Date Inserting Date Inserted by
00 18/May/2013 MJP 18/May/2013
01 09/Jan/2017 MJP 09/01/2017
02 01/Apr/2019 BR 01/Apr/2019



Revision Nr Issue Date Changes
00 - 01 - -
02 01/Apr/2019 Change of references and
procedures based on RFM and
International Standards.
03 05/09/2019 This revision is just to inform the
version of the RFM



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 15
Revision: 02
Date: 04/01/2019



 INTENTIONALLY BLANK

















OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 16
Revision: 02
Date: 04/01/2019



 List of Effective Pages
Chap Page Date Revision Chap Page Date Revision
CAPA 1 04/01/2019 02 2 2.11 04/01/2019 02
CAPA 2 04/01/2019 02 2 2.12 04/01/2019 02
FOP 3 04/01/2019 02 2 2.13 04/01/2019 02
FOP 4 04/01/2019 02 2 2.14 04/01/2019 02
TOC 5 04/01/2019 02 2 2.15 04/01/2019 02
TOC 6 04/01/2019 02 2 2.16 04/01/2019 02
TOC 7 04/01/2019 02 2 2.17 04/01/2019 02
TOC 8 04/01/2019 02 2 2.18 04/01/2019 02
TOC 9 04/01/2019 02 2 2.19 04/01/2019 02
TOC 10 04/01/2019 02 2 2.20 04/01/2019 02
TOC 11 04/01/2019 02 2 2.21 04/01/2019 02
TOC 12 04/01/2019 02 2 2.22 04/01/2019 02
LOI 13 04/01/2019 02
LOI 14 04/01/2019 02
STM 15 04/01/2019 02 3 3.1 04/01/2019 02
STM 16 04/01/2019 02 3 3.2 04/01/2019 02
ROR 17 04/01/2019 02 3 3.3 04/01/2019 02
ROR 18 04/01/2019 02 3 3.4 04/01/2019 02
LEP 19 04/01/2019 02 3 3.5 04/01/2019 02
LEP 20 04/01/2019 02 3 3.6 04/01/2019 02
LEP 21 04/01/2019 02 3 3.7 04/01/2019 02
LEP 22 04/01/2019 02 3 3.8 04/01/2019 02
 3 3.9 04/01/2019 02
 3 3.10 04/01/2019 02
 3 3.11 04/01/2019 02
1 1.1 04/01/2019 02 3 3.12 04/01/2019 02
1 1.2 04/01/2019 02 3 3.13 04/01/2019 02
1 1.3 04/01/2019 02 3 3.14 04/01/2019 02
1 1.4 04/01/2019 02 3 3.15 04/01/2019 02
1 1.5 04/01/2019 02 3 3.16 04/01/2019 02
1 1.6 04/01/2019 02 3 3.17 04/01/2019 02
1 1.7 04/01/2019 02 3 3.18 04/01/2019 02
1 1.8 04/01/2019 02 3 3.19 04/01/2019 02
 3 3.20 04/01/2019 02
 3 3.21 04/01/2019 02
 3 3.22 04/01/2019 02
2 2.1 04/01/2019 02 3 3.23 04/01/2019 02
2 2.2 04/01/2019 02 3 3.24 04/01/2019 02
2 2.3 04/01/2019 02 3 3.25 04/01/2019 02
2 2.4 04/01/2019 02 3 3.26 04/01/2019 02
2 2.5 04/01/2019 02 3 3.27 04/01/2019 02
2 2.6 04/01/2019 02 3 3.28 04/01/2019 02
2 2.7 04/01/2019 02 3 3.29 04/01/2019 02
2 2.8 04/01/2019 02 3 3.30 04/01/2019 02
2 2.9 04/01/2019 02 3 3.31 04/01/2019 02
2 2.10 04/01/2019 02 3 3.32 04/01/2019 02
3 3.33 04/01/2019 02 4 4.45 04/01/2019 02
3 3.34 04/01/2019 02 4 4.46 04/01/2019 02


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 17
Revision: 02
Date: 04/01/2019



Chap Page Date Revision Chap Page Date Revision
 4 4.47 04/01/2019 02
 4 4.48 04/01/2019 02
 4 4.49 04/01/2019 02
4 4.1 04/01/2019 02 4 4.50 04/01/2019 02
4 4.2 04/01/2019 02 4 4.51 04/01/2019 02
4 4.3 04/01/2019 02 4 4.52 04/01/2019 02
4 4.4 04/01/2019 02 4 4.53 04/01/2019 02
4 4.5 04/01/2019 02 4 4.54 04/01/2019 02
4 4.6 04/01/2019 02 4 4.55 04/01/2019 02
4 4.7 04/01/2019 02 4 4.56 04/01/2019 02
4 4.8 04/01/2019 02 4 4.57 04/01/2019 02
4 4.9 04/01/2019 02 4 4.58 04/01/2019 02
4 4.10 04/01/2019 02 4 4.59 04/01/2019 02
4 4.11 04/01/2019 02 4 4.60 04/01/2019 02
4 4.12 04/01/2019 02 4 4.61 04/01/2019 02
4 4.13 04/01/2019 02 4 4.62 04/01/2019 02
4 4.14 04/01/2019 02 4 4.63 04/01/2019 02
4 4.15 04/01/2019 02 4 4.64 04/01/2019 02
4 4.16 04/01/2019 02 4 4.65 04/01/2019 02
4 4.17 04/01/2019 02 4 4.66 04/01/2019 02
4 4.18 04/01/2019 02 4 4.67 04/01/2019 02
4 4.19 04/01/2019 02 4 4.68 04/01/2019 02
4 4.20 04/01/2019 02
4 4.21 04/01/2019 02
4 4.22 04/01/2019 02 5 5.1 04/01/2019 02
4 4.23 04/01/2019 02 5 5.2 04/01/2019 02
4 4.24 04/01/2019 02 5 5.3 04/01/2019 02
44.25 04/01/2019 02 5 5.4 04/01/2019 02
4 4.26 04/01/2019 02 5 5.5 04/01/2019 02
4 4.27 04/01/2019 02 5 5.6 04/01/2019 02
4 4.28 04/01/2019 02 5 5.7 04/01/2019 02
4 4.29 04/01/2019 02 5 5.8 04/01/2019 02
4 4.30 04/01/2019 02
4 4.31 04/01/2019 02
4 4.32 04/01/2019 02
4 4.33 04/01/2019 02
4 4.34 04/01/2019 02
4 4.35 04/01/2019 02
4 4.36 04/01/2019 02
4 4.37 04/01/2019 02
4 4.38 04/01/2019 02
4 4.39 04/01/2019 02 6 6.1 04/01/2019 02
4 4.40 04/01/2019 02 6 6.2 04/01/2019 02
4 4.41 04/01/2019 02 6 6.3 04/01/2019 02
4 4.42 04/01/2019 02 6 6.4 04/01/2019 02
4 4.43 04/01/2019 02 6 6.5 04/01/2019 02
4 4.44 04/01/2019 02 6 6.6 04/01/2019 02
6 6.7 04/01/2019 02 6 6.56 04/01/2019 02
6 6.8 04/01/2019 02 6 6.57 04/01/2019 02


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 18
Revision: 02
Date: 04/01/2019



Chap Page Date Revision Chap Page Date Revision
6 6.10 04/01/2019 02 6 6.58 04/01/2019 02
6 6.11 04/01/2019 02 6 6.59 04/01/2019 02
6 6.12 04/01/2019 02 6 6.60 04/01/2019 02
6 6.13 04/01/2019 02 6 6.61 04/01/2019 02
6 6.14 04/01/2019 02 6 6.62 04/01/2019 02
6 6.15 04/01/2019 02 6 6.63 04/01/2019 02
6 6.16 04/01/2019 02 6 6.64 04/01/2019 02
6 6.17 04/01/2019 02 6 6.65 04/01/2019 02
6 6.18 04/01/2019 02 6 6.66 04/01/2019 02
6 6.19 04/01/2019 02 6 6.67 04/01/2019 02
6 6.20 04/01/2019 02 6 6.68 04/01/2019 02
6 6.21 04/01/2019 02 6 6.69 04/01/2019 02
6 6.22 04/01/2019 02 6 6.70 04/01/2019 02
6 6.23 04/01/2019 02 6 6.71 04/01/2019 02
6 6.24 04/01/2019 02 6 6.72 04/01/2019 02
6 6.25 04/01/2019 02 6 6.73 04/01/2019 02
6 6.26 04/01/2019 02 6 6.74 04/01/2019 02
6 6.27 04/01/2019 02 6 6.75 04/01/2019 02
6 6.28 04/01/2019 02 6 6.76 04/01/2019 02
6 6.29 04/01/2019 02 6 6.77 04/01/2019 02
6 6.30 04/01/2019 02 6 6.78 04/01/2019 02
6 6.31 04/01/2019 02 6 6.79 04/01/2019 02
6 6.32 04/01/2019 02 6 6.80 04/01/2019 02
6 6.33 04/01/2019 02 6 6.81 04/01/2019 02
6 6.34 04/01/2019 02 6 6.82 04/01/2019 02
6 6.35 04/01/2019 02 6 6.83 04/01/2019 02
6 6.36 04/01/2019 02 6 6.84 04/01/2019 02
6 6.37 04/01/2019 02 6 6.85 04/01/2019 02
6 6.38 04/01/2019 02 6 6.86 04/01/2019 02
6 6.39 04/01/2019 02 6 6.87 04/01/2019 02
6 6.40 04/01/2019 02 6 6.88 04/01/2019 02
6 6.41 04/01/2019 02 6 6.89 04/01/2019 02
6 6.42 04/01/2019 02 6 6.90 04/01/2019 02
6 6.43 04/01/2019 02 6 6.91 04/01/2019 02
6 6.44 04/01/2019 02 6 6.92 04/01/2019 02
6 6.45 04/01/2019 02 6 6.93 04/01/2019 02
6 6.46 04/01/2019 02 6 6.94 04/01/2019 02
6 6.47 04/01/2019 02
6 6.48 04/01/2019 02
6 6.49 04/01/2019 02
6 6.50 04/01/2019 02 7 7.1 04/01/2019 02
6 6.51 04/01/2019 02 7 7.2 04/01/2019 02
6 6.52 04/01/2019 02 7 7.3 04/01/2019 02
6 6.53 04/01/2019 02 7 7.4 04/01/2019 02
6 6.54 04/01/2019 02 7 7.5 04/01/2019 02
6 6.55 04/01/2019 02 7 7.6 04/01/2019 02
 7 7.7 04/01/2019 02
8 8.1 04/01/2019 02 7 7.8 04/01/2019 02



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 19
Revision: 03
Date: 05/09/2019








8 8.2 04/01/2019 02 7 7.9 04/01/2019 02
8 8.3 04/01/2019 02 7 7.10 04/01/2019 02
8 8.4 04/01/2019 02
8 8.5 04/01/2019 02
8 8.6 04/01/2019 02
8 8.7 04/01/2019 02
8 8.8 04/01/2019 02
8 8.9 04/01/2019 02
8 8.10 04/01/2019 02
8 8.11 04/01/2019 02
Capa 1 05/09/2019 03
LOI 14 05/09/2019 03
1 1.2 05/09/2019 03

























OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.1
Revision: 02
Date: 18/May/2013


SECTION 1.
 INTRODUCTION
1.1 GENERAL
The SOP Manual provides information and guidance for the efficient
operation of the SIKORSKY S 76C helicopter.
This SOP Manual is not a replacement of any of the operational
manuals required by applicable regulations such as the Rotorcraft
Flight Manual - RFM or the OMNI General Operations Manual (Manual
Geral de Operações – MGO).
In the event of conflict between this SOP Manual and ANAC approved
RFM, the ANAC approved RFM shall govern.
The philosophy behind this manual is based on reducing crew
workload while maintaining the highest possible level of safety.
The standard operating procedures, herein, are a set of procedures
that serve to provide common ground for all crewmembers, usually
unfamiliar with each other's experience and technical capabilities. In a
well-standardized operation, another qualified pilot could replace an
active cockpit crewmember during the flight, and the operation would
continue safely and smoothly.
1.2 STRUCTURE
This SOP Manual is structured as follows:
 Cover
 FOP 211: ANAC approved document;
 Table Of Contents;
 Statement;
 Record Of Revision;
 List of Effective Pages;
 Section 1 – Introduction: This Section provides general information;
 Section 2 – Philosophy and Operating Policies: This Section has
directives related to how the operation should be conducted.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.2
Revision: 02
Date: 18/May/2013



 Section 3 – Operating limitations: This Section represents the S 76C
RFM Part 1, Section I – Operating Limitations. This Section contains
certification and aircraft limitations.
 Section 4 - Normal Procedures: This Section represents the S 76C RFM,
Part 1, Section II - Normal Procedures. The intention is to eliminate any
doubts regarding Flight Standards that may occur during the operation
of the S 76C helicopter.
 Section 5 - Patterns and Techniques: This Section provides some
recommended patterns and techniques for execution of required
maneuvers;
 Section 6 - Emergency Procedures: This Section represents S 76C RFM,
Part 1, Section III - Emergency and Malfunction Procedures in a detailed
manner. The intention is to guide the crew on how to perform the
required tasks to correct a situation or condition. Only the procedures
requiring high level of crew coordination will be presented.
 Section 7 – PBN Operations: This Section provides the operating
procedures for the S 76C’s PBN operations;
 Section 8 - GPS Procedures: This Section contains GPS flight operating
procedures designed to be used on a typical flight and arranged in the
order in which they would normally be employed.
1.3 APPLICABILITY
The procedures described here are specific for OMNI’s S 76C
helicopters fleet and apply to each particular phase of flight. Therefore,
it is the Captain’s responsibility of the exact observance of the
established standardization in this SOP Manual.
1.4 REFERENCES
 Manual Geral de Operações - MGO;
 Regulamento Brasileiro de Aviação Civil – RBAC 135;
 IS 119-003A - Procedimentos para elaboração e utilização de Manual
de Procedimentos Operacionais Padronizados (SOP);
 SIKORSKY S 76C Rotorcraft Flight Manual – RFM (Revision N°07 Part
1; Revision Nº09 Part 2) approved by ANAC.
Page: 1.2
Revision: 03
Date: 05/09/2019


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.3
Revision: 02
Date: 18/May/2013




1.5 SYSTEM OF REVISION
The update of this SOP Manual is responsibility of the Chief
Equipment. This SOP will be revised whenever necessary. Any
alteration on this SOP Manual will be submitted to Brazilian Civil
Aviation Authority (ANAC).
A vertical bar (change bar) in the margin indicates a change,addition
or deletion in the adjacent text for the current revision of that page only.
The change bar is dropped at the next revision of that page.
After the SOP Manual be reviewed and approved, it will be distributed
and the holder must record the revision in page “Record of Revisions”.
The SOP Manual may be completely replaced during an extensive
revision.
1.6 CONTROL AND DISTRIBUTION
The control and distribution of controlled copies of the SOP Manual
and its revisions will be the responsibility of the Technical Publication
Section. These activities will be performed in accordance with the
internal procedures, so that the updated version of SOP Manual is
available in time for all crew members involved in the activities of flight
operations.
Each copy of SOP Manual will be numbered and distributed according
to the following:
COPY NR HOLDER TYPE
1 ANAC CD
2 Flight Operations Director Printed
3 Safety Director Printed
4 Pilot Chief Printed
5 Equipment Chief Printed
6 to 10 Reserved N/A
11 to 100 Helicopters Printed
101 and upward Crews CD


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.4
Revision: 02
Date: 18/May/2013


1.7 ABREVIATIONS
Abbreviations and acronyms used throughout this Manual are defined
as follows:

ABBREVIATION DESCRIPTION
AGL Above ground level
ATC Air traffic control
CDI Course deviation indicator
CDP Critical Decision Point
COM/NAV Communication / navigation
DA Decision altitude
DECU Digital engine control unit
DH Decision height
FAF Final approach fix
IAF Initial approach fix
LSP / RSP Left / Right Seat Pilot
MAP Missed approach point
MDA Minimum descent altitude
N1 Gas producer speed
N2 Power turbine speed
NR Rotor speed
OEI One engine inoperative
PF Pilot flying
PIC Pilot in command
PM Pilot Monitoring
Q Torque
RFM Rotorcraft Flight Manual
SOP Standard operating procedure
T5 Power turbine inlet temperature
V1 Critical engine failure speed
V2 Takeoff safety speed
VBROC Best Rate Of Climb
VNE Velocity Never to exceed
VTOSS Takeoff safety speed


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.5
Revision: 02
Date: 18/May/2013


1.8 DEFINITIONS
1.8.1 CALLOUTS
Callouts are aids in maintaining awareness of the crew as to the status
of given tasks. They are extremely important in aiding situational
awareness. They are made to indicate that a system has deviated from
the assigned parameters or to describe tasks or events requiring a
high level of monitoring of highly dynamic and unstable events.
1.8.2 CHALLENGE AND RESPONSE
A checklist usage technique that consists of reading and
accomplishing each of the checklist items. The Checklist items will
follow the sequence corresponding to the sequence of actions
required.
1.8.3 CRM
Crew Resource Management is the effective use of all resources to
include human and other aviation system resources.
1.8.4 EMERGENCY
When emergency is used to describe a procedure or Checklist, it refers
to a non-routine operation (warning) in which certain procedures or
actions must be taken to protect the crew, passengers or the helicopter
from a serious hazard or potential hazard.
1.8.5 INSTRUCTOR PILOT
A pilot that acts as Flight Instructor to a not-yet qualified pilot or to a
qualified pilot undergoing flight instruction for refreshment or for any
other reason.
1.8.6 LAND AS SOON AS POSSIBLE
Land without delay at the nearest suitable area (i.e., open field) at
which a safe approach and landing is reasonably assured.
1.8.7 LAND AS SOON AS PRACTICAL
The duration of the flight and landing site are at the discretion of the
pilot. Extended flight beyond the nearest approved landing area is not
recommended.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.6
Revision: 02
Date: 18/May/2013


1.8.8 LAND IMMEDIATELY
The urgency of the landing is paramount. The primary consideration is
to assure the survival of the occupants.
1.8.9 CONTINUE FLIGHT
If the fault persists or returns after clearing, the ECL will
indicate whether there are any MEL implications and the
decision to continue as planned or to take alternative action
shall consider.
 If the fault can be deferred under the MEL for a
subsequente takeoff
 The operational implications of being AOG after the next
landing
 The implications of futher deterioration of the affected
system
If the fault clears, the flight may continue as planned without
restriction
1.8.10 PILOT FLYING (PF)
Pilot who is controlling the path and thrust setting of the helicopter in
flight (it is the primary responsibility of each pilot to monitor the
helicopter).
1.8.11 PILOT INCAPACITATION
A situation where one of the pilots is not able to perform his duties.
1.8.12 PILOT IN COMMAND (PIC)
The pilot that is legally responsible for the operation of the airplane
and who commands the operation of the airplane. He has the authority
to take actions, to request or to delegate any crewmember action as
he finds appropriate to ensure the safety of the flight.
1.8.13 PILOT MONITORING (PM)
Pilot who is actively assisting/monitoring Pilot Flying during operation
of the airplane. The active monitoring concept must be implemented,
trained, practiced and must have its effectiveness evaluated in order


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.7
Revision: 02
Date: 18/May/2013


to provide benefits. It is the primary responsibility of each pilot to
monitor the airplane and the other pilot.
1.8.14 RECALL ITEMS
Items of the checklist that must be memorized by the flight crew and
whose execution must be carried out immediately should the
corresponding checklist become applicable (immediate action). Recall
items should be verified after completion.
1.8.15 SECOND IN COMMAND (SIC)
A pilot that is not in command but can carry out the duty of flying the aircraft
under the circumstances established by company rules.
1.8.16 SITUATIONAL AWARENESS
Refers to the fact that the crew should be conscious of the helicopter's
condition under specific operational and environmental circumstances.
1.8.17 STERILE COCKPIT
Sterile Cockpit is the establishment of an environment at the cockpit in
which the crewmembers can concentrate on helicopter operation
during certain phases of the flight.
Below 1000 ft in VFR descent or after crossing the initial approach fix
(IAF) should be employed the concept of Sterile Cockpit and any
communication, talk or interruptions that do not relate to the
procedures of the current approach are prohibited.
1.9 TERMINOLOGY
WARNINGS, CAUTIONS AND NOTES
Warnings, Cautions and Notes are used throughout this manual to
emphasize important and critical instructions and are used as follows:
“WARNING”: An operating procedure, practice, etc., which, if not
correctly followed, could result in personal injury or loss of life.
“CAUTION”: An operating procedure, practice, etc., which, if not
strictly observed, could result in damage to, or destruction of,
equipment.
“NOTE”: An operating procedure, condition, etc., which is essential to
highlight.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 1.8
Revision: 02
Date: 18/May/2013


1.10 USE OF PROCEDURAL WORDS
The concept of procedural word usage and intended meaning which
has been adhered to in preparing this SOP is as follows:
″Shall″ or ″Must″ have been used only when application of a procedure
is mandatory.
″Should″ has been used only when application of a procedure is
recommended.
″May″ and “Need not” has been used only when application of a
procedureis optional.
″Will″ has been used only to indicate futurity, never to indicate a
mandatory procedure.
″Condition″ has been used to determine if the item under examination
presents external damage which could jeopardize its safe operation.
″Secured″ has been used to determine if the item under examination
is correctly locked; mainly referred to doors and disconnect table
items.
″Security″ has been used to determine if the item under examination
is correctly positioned and installed.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.9
Revision: 02
Date: 18/May/2013


SECTION 2.
 PHILOSOPHY AND OPERATING
POLICIES
2.1 COMPLIANCE WITH STANDARD OPERATING
PROCEDURES
It is mandatory for all pilots of the OMNI to follow the Standard
Operating Procedures Manual during each and every flight. Any
deviations from this standard should be informed to Flight Operations
Director and reported to OMNI’s SMS Manager through a written
occurrence report (RELPREV).
It is not possible to anticipate and provide a procedure for all possible
situations that a pilot might encounter. An unusual or emergency
situation may arise that requires a pilot to deviate from OMNI’s SOP
Manual, or to make a decision regarding something not covered in this
document. It is expected that the pilot will use his/her best judgment,
acting in the interest of safety.
Whenever an unusual condition necessitates a deviation from these
procedures, the PIC will brief the SIC accordingly.
Pilots are not to experiment with techniques and procedures of their
own. Suggestions for improvements to company procedures are
welcome and should be made, in writing, to the Flight Operations
Director.
When SOP Manual compliance of the PIC or SIC is considered
unsatisfactory, it is the duty of the observing crewmember to submit a
written occurrence report (RELPREV) detailing the deviance from
procedure. Failure to report non-compliance is considered a serious
offence and is subject to disciplinary action.
2.2 CREW RESPONSIBILITIES
2.2.1 PILOT IN COMMAND’S RESPONSIBILITIES
Pilot in Command (PIC) is equivalent to Captain. The PIC is legally in
command of, and has full authority for the conduct of the flight. The
PIC is delegated with final authority over all safety and operational
decisions during flight.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.10
Revision: 02
Date: 18/May/2013


The PIC must use common sense and good judgment when exercising
this authority.
The PIC must use crew resources in the most effective way and must
encourage other crewmembers to engage in teamwork by allowing
them to participate in and give suggestions whenever useful for the
execution of the flight.
The PIC must treat all crewmembers with respect and consideration
at all times.
The PIC has responsibility for compliance with CBA, RBACs,
NOTAMs, OMNI Policies, SOP Manual, the RFM and any written or
stated restrictions or limitations.
The PIC shall ensure that at all times the aircraft is flown in strict
accordance with the SOP Manual and RFM.
The PIC shall ensure that the SIC is briefed on all aspects of the flight,
and that strict adherence is paid to the normal and abnormal checklists
for the aircraft.
The PIC shall be responsible for ensuring that all necessary
documents relevant to the flight are carried on board the aircraft,
whether or not the duty for checking documents has been delegated
to another individual.
The PIC is ultimately responsible for whatever happens to the
occupants, to the helicopter or to any goods or persons outside the
airplane as result of the flight operation under his/her command.
a - PIC PRE-FLIGHT DUTIES
 Aircraft document check:
 Certificate of Airworthiness;
 Weight and Balance report;
 RFM, SOP and MEL;
 Determine helicopter airworthiness;
 Accept formally the aircraft for the flight, before starting the mission;
 Calculate the helicopter performance;
 Check the quantity of fuel, refueling and navigation planning presented
in the planning
 Check whether the Oil Rig or Vessel is approved and has operating
restriction that determine the half-load operation;


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.11
Revision: 02
Date: 18/May/2013


 Check the aeronautical information, weather conditions in route, the
destination and alternative, in addition to completing and filing the flight
plan;
b - PIC OTHERS DUTIES
 Before the first flight of the day, fill out the Preflight Risk Assessment (F-
OPR 34) by checking the risk level of flight and the feasibility of its
execution;
 Inform Flight Coordination about any changes during the flight;
 On the occasion of crew exchange, register any non-compliance, as well
as inform the substitute crew about the aircraft conditions;
 Record the discrepancies of the aircraft in the logbook;
 Contact the Flight Coordination, if the aircraft is unavailable as a result
of the pre-flight inspection
 In case of issues on technical matters, transmit the information to the
respective head of equipment;
 Check the cargo and passengers manifest, signing the two ways and
delivering there to Flight Coordination at the end of the mission;
 Fill out the performance assessment form of the SIC, at the end of the
fortnight, and send it to the operations sector.
 The completion of the flight report.
2.2.2 SECOND IN COMMAND’S RESPONSIBILITIES
The SIC is expected to assist the PIC through all phases of flight, be
a second set of eyes and ears, monitor the progress of the flight, and
serve as an advisor.
The SIC can and should immediately advise the Pilot in Command of
any operational discrepancy that may develop into a flight safety
problem. This entitlement to intervene must be practiced extensively
in the Simulator so that the SIC understands how and to what extent
this intervention is to be exercised. Should the Pilot-in-command
become incapacitated, the SIC acquires all the rights and duties of the
Pilot in Command.
The SIC can be designated as PF for any flight leg if the Pilot in
Command finds it appropriate.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.12
Revision: 02
Date: 18/May/2013


The SIC must ensure that they are aware of, and understand all
operational details relating to the conduct of the flight. This includes
(but is not limited to) flight plan and fuel requirements, NOTAMs, ATC
restrictions, expected weather and any written or stated restrictions or
limitations.
If the SIC feels unjustly treated by the PIC, a complaint in writing
should be made later to the Flight Operations Director. The first duty,
however, is to comply with the orders of the PIC.
a - SIC PRE-FLIGHT DUTIES
 The completion of the Flight Plan or Notification according with the
specific regulations; the SIC will collect data related to the route to be
flown including METAR, NOTAM and other needed information and shall
report to the PIC, who will decide if the flight should be carried out in
accordance with the planning;
 Certify that the publications that will be used on navigation are on board
the aircraft and up to date, as well as aircraft documentation, MGO and
other documents requested by legislation;
 Perform the Helicopter Pre-Flight inspection;
 Ensure that required equipment for the intended flight is on board and
properly stowed;
 Make sure the aircraft refueling was carried out as determined by the
PIC.
 Verify and check the Oil Rig or Vessel location, the existence of
photographs to aid in the knowledge of its characteristics and request
the Helideck Report.
 To verify the cleanness of the cockpit and cabin;
b - SIC OTHERSDUTIES
 Upgrade of aircraft navigation aids and returning the parts due to the
Flight Coordination;
 Perform the ambiance of the passengers on the aircraft characteristics,
emphasizing the most critical items.
 Check if there is any passenger who never flew a helicopter aiding the
same regarding the placement of the vest, headset and use of seatbelts;


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.13
Revision: 02
Date: 18/May/2013


 Read de checklist;
 Fill out the aircraft logbook in case of any scheduled flight;
 The completion of the flight report.
2.2.3 GENERAL PROCEDURES
The crew shall comply with the following steps for a scheduled flight:
 To get ready at least one (01) hour before the time set for starting;
 To be in possession of valid licenses and certificates;
 To guard the aircraft at least 30 (thirty) minutes before the estimated time
of the first flight of the day and 10 (ten) minutes before following
departures;
a - PRIOR THE EMBARK OF THE PASSENGERS
 The PIC receives the Passenger Manifest from dispatcher, check out the
destination, number of passengers and scheduled program. In case of
any change related to the initial planning, make the decision whether to
proceed with the flight, depending on the variables presented and the
safety of the flight.
b - TAXING
The SIC will only be allowed to taxi after authorized by Chief
Equipment.
Specific remarks:
 Shortly after the beginning of the taxi, check the brakes, which should
always be done with the collective fully lowered and pressing the brakes
lightly without stopping the aircraft.
 Making curves, observe and compare the magnetic compass with the
movements of the HSI, advertising: Curve to the right, Increasing
Markings. Left turn Decreasing Markings.
2.3 AREAS OF RESPONSIBILITY
This SOP establishes areas in the cockpit that are placed under the
responsibility of each specific cockpit crewmember.
Flight Operations are divided between Pilot Flying (PF) and Pilot
Monitoring (PM). Actions outside the crewmember’s area of


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.14
Revision: 02
Date: 18/May/2013


responsibility may be applicable sometimes and are properly indicated
in this SOP or are initiated at the discretion of the PIC.
2.4 TASK SHARING
Ground procedures are shared between the PIC and the SIC as per
the pertinent procedures in this SOP Manual.
The PF/PM task sharing concept applies from taxi to before shutdown
engines.
INFLIGHT:
 The PF is in charge of:
 Cyclic and Collective;
 Controlling flight path and speed;
 Carrying out the required actions at his areas of responsibility
(normal and emergency procedures);
 Airplane configuration;
 Navigation;
 Annunciating the mode of operation displayed in the EFIS (EADI and
EHSI)
 The PM is in charge of:
 Checklist reading;
 Carrying out the required actions at his areas of responsibility
(normal, abnormal and emergency procedures);
 Engine Shutdown (Coordinated with the PF);
 ATC communications;
 Passenger Briefing;
 Monitoring the flight and alerting the PF of any abnormal condition;

2.5 CHECKLIST
2.5.1 NORMAL PROCEDURES
All items of a given procedures are intended to prepare the aircraft for
the next phase of flight. Checklist items should be accomplished as
listed or as required by this SOP Manual.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.15
Revision: 02
Date: 18/May/2013


All checklist are initiated at the PIC’s command when on the ground,
and by the PF when in flight. On the ground the SIC is responsible for
reading the checklist and in flight the PM is responsible.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.16
Revision: 02
Date: 04/01/2019


When a checklist has been completed, the PM reports that the
checklist is complete and that the next checklist is standing by. For
example, “Approach checklist complete. Standing by with the Pre
Landing Checklist.”
The checklists are designed to be performed with a Challenge and
Response method. The Challenge items are in the left column, and the
expected Response is in the right column.
In reading the checklist, no item should remain pending. So, no other
item of the checklist should be read while the former has not been
answered satisfactorily. Any response different from the listed
response should indicate something is abnormal and should be
challenged by the other crewmember before continuing.
If, for instance, there was a situation that results in an interruption of
checklist reading, the PM should immediately announce "checklist
interrupted" and, at the same time, put his finger over the item
immediately before that one that was not complied by the PF. When
the cause of the disturb of checklist reading is finished, both pilots
should restart the checklist reading from the item that was pointed out
by the PM.
When a response on a checklist is “as required” the appropriate
crewmember should respond according to the actual switch position.
If an emergency occurs on takeoff after CDP and takeoff is continued,
no checklist should be initiated before the aircraft reaches a safe
altitude above the ground.
a - CHALLENGE ITENS
Challenge items proceeded with an asterisk (#) are required only
before the first flight of the day. All other checks are to be carried out
before each flight.
b - RESPONSE ITENS
Response items that contain a blank space or line indicate a specific
quantity or value is expected to be stated.
c - CHALLENGE / NO RESPONSE
If the PM observes and challenges a flight deviation or critical situation,
the PF should respond immediately. If the PF does not respond by oral
communication or action, the PM must issue a second challenge that


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.17
Revision: 02
Date: 04/01/2019


is loud and clear. If the PF does not respond after the second
challenge,
the PM must ensure the safety of the aircraft. The PM must announce
that he is assuming control and then take the necessary actions to
return the aircraft to a safe operating envelope
2.5.2 ABNORMAL / EMERGENCY PROCEDURES
When any crewmember recognizes malfunctions, an abnormal
or emergency condition, he/she should announce and the other
crewmember should confirm/identify the problem.
The PIC designates who controls the aircraft, who performs the
tasks, and any items to be monitored.
Following these designations, the PIC calls for the appropriate
checklist. The crewmember designated on the checklist
accomplishes the checklist items with the appropriate
challenge/response.
The pilot designated to fly the aircraft (i.e., PF) does not
perform tasks that compromise this primary responsibility,
regardless of whether he uses the autopilot or flies manually.
Both pilots must be able to respond to an emergency situation
that requires immediate corrective action without reference to a
checklist. The elements of an emergency procedure that must
be performed without reference to the appropriate checklist are
called memory or recall items. Accomplish all other abnormal
and emergency procedures while referring to the printed
checklist.
Accomplishing abnormal and emergency checklists differs
from accomplishing normal procedure checklists in that the
pilot reading the checklist states both the challenge and the
response when challenging each item.
When a checklist procedure calls for the movement or
manipulation of controls or switches critical to safety of flight
(e.g., throttles, engine fire switches, fire bottle discharge
switches), the pilot performingthe action obtains verification
from the other pilot that he is moving the correct control or
switch prior to initiating the action.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.18
Revision: 02
Date: 04/01/2019


Any checklist action pertaining to a specific control, switch, or
equipment that is duplicated in the cockpit is read to include its
relative position and the action required (e.g., “Engine Lever
(affected engine) - IDENTIFY/ STOP; Affected Engine Control
Switch – MANUAL).
In an emergency situation always remember:
 FLY THE AIRCRAFT – Maintain aircraft control.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.19
Revision: 02
Date: 04/01/2019


 RECOGNIZE CHALLENGE – Analyze the situation.
 RESPOND – Take appropriate action.
a - REJECTED TAKEOFF
The rejected takeoff procedure is a preplanned maneuver; both
crewmembers must be aware of and briefed on the types of malfunctions
that mandate an abort. Assuming that the crew trains the procedures
established in this SOP Manual, the PF may call for an abort.
The PF normally commands and executes the takeoff abort for directional
control problems or catastrophic malfunctions. The PF usually executes an
abort prior to TDP for any abnormality observed. Additionally, any
indication of one of the following malfunctions prior to TDP is cause for an
abort:
 Engine failure
 Engine fire
 Loss of directional control
Except for DECU or EEC major malfunctions that occur after takeoff power
is applied, the PF or PM will call for an abort prior to CDP for any abnormality
observed, regardless of severity. However, when operational or
meteorological conditions begin to reduce the safety margin, an abort may
be considered up to CDP. When such conditions exist, it is important to
include the procedures deviation in the briefing.
When the PM calls an abort situation, the PF announces “Abort” or
“Continue” and executes the appropriate procedure.
2.6 CREW COORDINATION
The Flight Crew must be on coordination. They must know their duty
and activities into the cockpit during a normal operation as well as in
an emergency situation. It is recommended that this coordination
should be carried out to practice during simulator training. Also, they
should brief between them about the whole flight operation before the
flight.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.20
Revision: 02
Date: 04/01/2019


2.6.1 CONTROL TRANSFER
Whenever necessary to transfer control of the aircraft the following
procedure should be followed:
 If the PF is initiating the control transfer:
 PF: “You have control” and shall not release the controls until he/she
hears:
 PM: “I have control”.
 If the PM is initiating the control transfer:
 PM: “I have control”.
 PF: “You have control” and shall release controls to the PM.
2.7 USE OF AUTOMATION
The use of AUTOMATISM shall occur after crossing 500ft
Pilots must be alert and avoid “automation complacency” generated
by the highly automated helicopter systems. Usage of automation
must be well trained in order to provide workload reduction and the
ability to correlate the different scenarios and systems.
Monitoring is an active role that Shall be placed on the same level of
importance as in acting.
The pilot is the most capable component during the flight and he must
determine the optimal use of automation.

Standard Flight Director Settings AEO
 Pitch Roll Collective Cues
Climb


VS NAV or
HDG
Manual
(max
allowed
MCP)
2
Cruise ALT NAV or
HDG
Manual
(max
allowed
MCP)
2
3Q Descent VS NAV or
HDG
IAS 3


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.21
Revision: 02
Date: 04/01/2019


3Q
Approach
VS or GS NAV or
HDG
IAS 3
Standard Flight Director Settings OEI
 Pitch Roll Collective Cues
Climb IAS NAV or HDG Manual
(max
allowed
within time
limits)
2
Cruise ALT NAV or HDG Manual
(MCP 107%
NR)
2
2Q Descent IAS NAV of HDG VS 2
2Q
Approach
IAS NAV or HDG VS or GS 2


When engaging 3 cue (4 axis) with OEI, it is essential to check that collective
command limits have not been exceeded. It is possible to have a CLTV light
illuminated without the collective decoupling (freeze). This may occur during OEI
situations, either actual or simulated. Additionally, an E43 or E44 autopilot error
code
may be displayed. In this situation, the collective will decouple as normal when
a
collective command limit is exceeded. During OEI 3Q operations, attentive
monitoring
of the collective is warranted.
2.8 COMMUNICATIONS
Cross-cockpit communication is vital for any two pilot crews. Any time
a Pilot makes any adjustments or changes to any information or
equipment on the cockpit, he must advise the other Pilot and get an
acknowledgment. Non-essential conversation should be avoided
during high workload flight phases.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.22
Revision: 02
Date: 04/01/2019


2.8.1 RADIO TUNING
The PM accomplishes navigation and communication radio tuning,
identification, and ground communication. For navigation radios, the
PM tunes and identifies all navigation aids. Before tuning the PF’s
radios, he announces the NAVAID to be set. In tuning the primary
NAVAID, the PM coordinates with the PF to ensure proper selection
sequencing with the flight director mode. After tuning and identifying
the PF’s NAVAID, the PM announces “(Facility) tuned and identified.”
Monitor NDB audio output, anytime the NDB is in use as the NAVAID.
Use the marker beacon audio as backup to visual annunciation for
marker passage confirmation.
In tuning the VHF radios for ATC communication, the PM places the
newly assigned frequency in the head not in use (i.e., pre-selected) at
the time of receipt. After contact on the new frequency, the PM retains
the previously assigned frequency for a reasonable time period.
2.8.2 COMMUNICATION OF URGENCY CONDITION
The initial communication, and if considered necessary, any
subsequent transmissions by an aircraft in life threatening situations
should begin with the signal MAYDAY, preferably repeated three
times. The signal PAN−PAN should be used in the same manner for
an urgency condition that are not immediately life threatening.
Transmit a distress or urgency message consisting of as many as
necessary of the following elements, preferably in the order listed:
 If distress, MAYDAY, MAYDAY, MAYDAY;
 If urgency, PAN−PAN, PAN−PAN, PAN−PAN;
 Name of station addressed;
 Aircraft identification and type;
 Nature of distress or urgency;
 Pilots intentions and request;
 Present position, heading and altitude or flight level;
 Fuel remaining in minutes;
 Number of people on board.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.23
Revision: 02
Date: 04/01/2019


 Any other useful information.

2.8.3 TRANSPONDER EMERGENCY OPERATIONS
When a distress or urgency condition is encountered, the Pilot should
alert a ground radar facility:
 Emergency Code 7700;
 Lack of communication 7600;
 Unlawful interference 7500;
2.8.4 SKYTRAC SYSTEM
The OMNI’s helicopters fleet owns the system SKYTRAC ISAT 100
for tracking and flight following. When appropriate, the pilots can used
this system to alert the Company about an emergency selecting the
switch EMERG. This does not replace the need to inform ATC by radio
and / or transponder code.
2.9 SITUACIONAL AWARENESS
2.9.1 WEATHER RADAR
During weather radar operations, the pilot operating the radar shouldinform any change before its execution, since it will affect the other
pilots’ presentation as well.
2.9.2 TCAS
Compliance with TCAS Resolution Advisory - RA is required unless
the pilot considers it unsafe to do so. Maneuvers that are in the
opposite direction of the RA are extremely hazardous, especially RAs
involving altitude crossing and thus are prohibited unless it is visually
determined to be the only means to assure safe separation.
Conflicting traffic within a cone of 45° at the back and above the
altitude of the aircraft cannot be displayed by TCAS. At distances
greater than 5 NM, duplicate images of targets can occasionally be
seen for a few seconds.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.24
Revision: 02
Date: 04/01/2019


2.9.3 EGPWS
The EGPWS is intended to increase the situational awareness of the
presence of obstacles on the ground that may interfere with the
trajectory of the flight.
The equipment is an important aid to the flight and their understanding
and operation must be assimilated by all crewmembers.
Its use should be made in all phases of flight, however, the system
should not be used for navigation, because its indications cannot
provide accuracy and fidelity to navigation decisions and routine route
planning purposes to avoid terrain and obstacles.
LOW ALTITTUDE mode should not be selected when operating in
IMC, except in procedures for IFR descent oil Rigs or Vessels.
The Database installed must be updated for the region to be flown.
Whenever the aircraft is moved to other areas in which pilots are not
familiar, should be planned familiarization with the terrain before the
arrival of the aircraft for the operation.
Verify in advance the obstacles of geographical area to be flown. The
database provides information terrain and obstacles higher than 100
ft AGL. Transmission Lines and wires are not included.
The system provides alerting in six modes:
MODE ALERTING
1 Excessive descent rate
2 Excessive terrain closure rate
3 Sink after takeoff
4 Too close to terrain
5 Excessive deviation below
glideslope
6 Autorotation altitude callouts
Navigation must not be predicated upon the use of the terrain
awareness display, it is intended to serve as a situational awareness
tool only. Confirm every 60 days that the EGPWS database is current
and appropriate for the intended area of operation.
In general, terrain advisory look-ahead distances are reduced, not all
obstacles are in the database:
 Obstacles less than 200feet AGL may not be included in the
database
 Obstacles within 5nm of an airport that are less than 100 feet
AGL may not be in the database


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.25
Revision: 02
Date: 04/01/2019


 New or non-charted obstacles may not be in the database
 Power lines are not included in the obstacle database
Audible alerts:
AUDIO CONDITION
Pull up Excessive rate of descent
Terrain Terrain Excessive closure rates
Pull up Excessive closure rates
Warning: terrain Look ahead terrain warning
Warning: obstacle Look ahead obstacle warning
Minimums Passing through RADALT bug
Caution: terrain Look ahead terrain caution
Caution: obstacle Look ahead obstacle caution
Too low terrain Below terrain clearance floor
Two hundred Altitude Callout
Too low gear Below terrain clearance floor and
gear up
Sink rate Excessive rate of descent
Don’t sink Altitude loss after takeoff
Glideslope Excessive downward deviation
from ILS G/S
Traffic traffic TCAS alert
Bank angle Excessive bank angle
Tail too low Excessive pitch attitude
Be alert, terrain inop Look ahead feature not
functioning

2.9.4 CFIT
The Pilots should be awareness to the risk of controlled collision
against the terrain. The procedures below may avoid a CFIT:
 Take some time before takeoff to familiarize with the flight and the terrain
that will be operating over;
 Terrain familiarization is critical to safe visual operations at night. Use
sectional chart or other topographic references to ensure that your
altitude will safely clear terrain and obstructions all along your route.
 When planning a night time Visual Flight Rules (VFR) flight, follow
Instrument Flight Rules (IFR) practices, such as climbing on a known


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.26
Revision: 02
Date: 04/01/2019


safe course until well above surrounding terrain. Choose a cruising
altitude that provides terrain separation similar to IFR flights (2,000 feet
above ground level in mountainous areas and 1,000 feet above the
ground in other areas);
It is forbidden to intentionally flight below 500 ft, except in phases for
takeoff and landing.
Below 1000 ft the PF should be able to take helicoper control
immediately.
When required an immediate change in the trajectory of the aircraft
(evasive maneuvers, unusual attitude recovery), fly the aircraft
manually without FD (the lowest level of automation).
The constraints of altitude (ALTITUDE CONSTRAINT) listed on STAR
or IAL should not be cancelled for safety reasons (CFIT), and may be
changed following ATC instructions.
The PIC is responsible to avoid HEADS DOWN situation on critical
phases of flight.

2.10 SAFETY OF FLIGHT
It is the responsibility of the pilot in command, in the event of an
occurrence that affects the safety of flight, to determine a plan of action
that will, to the fullest extent possible, ensure the safe completion of
the flight.
This plan of action must first ensure continued flight capability which,
most simply put, stresses the importance of flying the helicopter with
the available working equipment. Once the helicopter is under control
and at a safe minimum altitude, assigning crew duties and
responsibilities is of primary importance.
In an event of emergency during the take off after TDP, no action
should be taken below 400 ft, unless the emergency requires
immediate actions to be taken by memory, as when there are signals
of fire. The Flight Reference Cards should not be consulted below 400
ft.
Duties such as flying the helicopter, communications, and normal and
emergency checklist accomplishment must be assigned to deal most
effectively with the situation. Care should be taken to assign priorities
to individual tasks and not to overload an individual crewmember.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.27
Revision: 02
Date: 04/01/2019


When developing a plan of action, make effective use of all resources.
Checklists, other crewmembers, ATC and, home base personnel are
all examples of potential resources. Consider the alternatives prior to
making a decision, and monitor the progress of the plan of action. Be
prepared to make timely changes if necessary.
2.11 BRIEFINGS
Briefings should be conducted with casual language and personal
style to prevent the repetitious use of sentences and terms. Preflight
briefings are recommended on the first flight of the day and with any
crew changes. Briefings should include:
 Significant weather.
 Status of relevant helicopter systems.
 Refueling.
 Information on the terrain/water to be over flown.
 Flight Routes/Cruising Altitudes/Flight Time/Alternate Airports.
 Special procedures, as applicable.

Takeoff and approach briefings are detailed in the normal procedures.
The PIC must make sure the passengers receive a briefing covering
procedures for all flight phases.
2.12 FLIGHT PLANNING
Each flight should be planned adequately to ensure safe operations
and to provide the pilot with the data to be used during flight. The
Manual Geral de Operações (MGO), Section6, has the flight planning
detailed.
Essential weight and balance, and performance information should be
compiled as follows:
 Check type of mission to be performed and destination;
 Select appropriate performance charts to be used from S76 C RFM,
Section 4 – Performance;


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.28
Revision: 02
Date: 04/01/2019


2.13 PILOT INCAPACITATION
Pilot incapacitation is a possibility in all age groups and during all flight
phases, ranging from sudden death to partial loss of mental or physical
performance. Proper crew coordination involves checks and
crosschecks using verbal communications and standard operating
procedures to detect this problem.
The pilot flying is required to respond to significant deviation callouts.
A failure of the pilot flying to respond and take corrective action
indicates the need for a follow-up deviation call. The second Call
should be clear and positive. If the pilot flying fails to respond to the
second call, the pilot monitoring must then take whatever action is
deemed necessary to ensure the safety of the flight.
2.14 OFFSHORE OPERATIONS (FLIGHTS TO OIL RIGS OR
VESSELS) DURING THE DAY
2.14.1 GENERAL CONSIDERATIONS
The procedures herein are applicable to all day flights bound to oil rigs
or vessels and have the purpose of standardizing and increase safety.
Such operation requires a high degree of coordination among the
cabin crew. Strict compliance with procedures and proper training
allows the crew to perform their duties safely.
2.14.2 BEFORE STARTING
 Verify the status and place of maps, weather information and available
procedures for destination and alternative route.
 Carry out the complete checklist.

2.14.3 FLYING TO OIL RIG OR VESSEL
After takeoff, whenever possible, the flight level should done at the
level established by the ATC or according to an operational
agreement, when and wherever applicable.
The radar altimeter should be set:
- prior to take-off – 200 ft
- in cruise level up to 2500 ft - 100 ft below the cruising altitude
- in cruise level above 2500 ft - 2500 ft


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.29
Revision: 02
Date: 04/01/2019


- during descent – 100 ft below the target altitude
After leveling and all "checks" carried out, contact the Oil Rig or Vessel
as soon as possible, transmitting the estimated time of landing and
requesting all required data for a safe landing and takeoff. During the
flight should be reviewed all procedures that will be performed on take-
off and landing.
The ideal point to start descent should be calculated for the aircraft to
achieve 500 FT at 5 Nm from the oil rig or vessel.
2.14.4 TRAFFIC PATTERN FOR OIL RIG OR VESSEL
At a distance of 3 miles, maintaining 500 ft and up to 120 kts, set FD
to HDG and perform the Pre-Landing Checklist.
The traffic to circulate a helideck on an Oil Rig or Vessel on visual
approach should run at 500 ft/80 kt.
Cross the vertical of Oil Rig or Vessel to identify it correctly.
Check the clues to establish wind direction, downwind leg and final
approach headings.

2.14.5 IMPORTANT OPERATIONAL REMARK
When landing at a Fixed Rig, given the proper certainty that the rig is
not floatable and has not roll or pitch variations, engines must be
reduced to 70% (N1). In this case, chocks must be used.
Reduction of power in small ships is expressively prohibited.

2.14.6 TAKEOFF FROM OIL RIG OR VESSEL ON DAY
FLIGHT
After receiving the takeoff clearance, the crew must perform the
checklist accordingly.
Previously establish a free of obstacles takeoff heading. Be aware of
the prevailing wind.
When ready for takeoff, the PF calls “lifting”.
In hover or on a wheels light hover PF calls “CG OK”.
PM calls “all green, no lights, torque xx %”.
PF calls “takeoff” and start to apply the necessary power setting. Do
not exceed the takeoff power limit.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.30
Revision: 02
Date: 04/01/2019


At 20 ft approximately, over the helideck (vertically), the PF calls
“Rotating” and then lower the nose down up to a maximum of 10 pitch
down.
During takeoff PF should maintain heading and positive "climb".
The PM must emphasize the torque indications, heading, altitude, V2
and VBROC speeds. PM should inform PF to adjust power if necessary.
Above 300 FT, Floats off, landing gear up, after takeoff checks.
Above 500 ft, engage FD (VS and HDG modes), and initiate the
appropriate turns.
The ideal ascent rate should be between 500 ft/min and 1000ft/min.

2.15 NIGHT FLIGHT TO OIL RIG OR VESSEL
2.15.1 GENERAL CONSIDERATIONS
The procedures herein are applicable to all overnight flights bound to
oil rigs or vessels and have the purpose of standardizing and increase
safety.
Such operation requires a high degree of coordination among the
cabin crew. Strict compliance with procedures and proper training
allows the crew to perform their duties safely.
The crew must be aware that a night flight must be conducted with
maximum attention and caution.
All night maneuvers must be performed slower and higher than
daytime maneuvers.

2.15.2 BEFORE STARTING
 Check flashlights, cabin lights, and the all aircraft lights.
 Verify the status and place of maps, weather information and available
procedures for destination and alternative route.
 Carry out the complete checklist.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.31
Revision: 02
Date: 04/01/2019


2.15.3 TAKEOFF FROM AIRPORT/BASE TO OIL RIG OR
VESSEL
The taxi from parking spot to takeoff position should follow the path
previously established by the crew.
The takeoff from an airport should be performed from the runway in
use.
The takeoff should follow nighttime Oil Rig or Vessel takeoff pattern
(as specified further), to get the crew familiarized with takeoff
conditions.

2.15.4 FLYING TO OIL RIG OR VESSEL
The flight should be done at 2,000 FT or higher, depending on ATC
clearance.
The radar altimeter should be set:
- prior to take-off – 200 ft
- in cruise level up to 2500 ft - 100 ft below the cruising altitude
- in cruise level above 2500 ft - 2500 ft
- during descent – 100 ft below the target altitude
After leveling and all "checks" carried out, contact the Oil Rig or Vessel
as soon as possible, transmitting the estimated time of landing and
requesting all required data for a safe landing and takeoff. During the
flight should be reviewed all procedures that will be performed on take-
off and landing.
At 10 NM from oil rig or vessel the WX Radar should be set for 10 NM.
The ideal point to start descent should be calculated for the aircraft to
achieve 1000 FT and 100 Kts at 5 Nm from the oil rig or vessel.
At 3 Nm the RADALT should be set for 400 ft.
2.15.5 TRAFFIC PATTERN FOR OIL RIG OR VESSEL
At a distance of 3 miles, maintaining 1000 ft/80 Kts, perform the Pre-
Landing Checklist.
The traffic to circulate a helideck on an Oil Rig or Vessel on visual
approach should run at 1,000 ft/80 KIAS.
Cross Oil Rig or Vessel vertical to identify. If necessary, the crew
should request the Oil Rig or Vessel to flash the helideck lights.
Check the clues to establish wind direction, downwind leg and final
approach headings.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.32
Revision: 02
Date: 04/01/2019


Once wind direction is determined, set a 30 SEC crosswind leg.
On downwind leg, with the helideck abeam and leveled at 1,000 ft/80
Kts, start a 90 sec count. Adjust 500 ft on AL-300 and set ALT PRE.
After 90 seconds, turn to base leg.
On final reduce speed to 70 KIASand perform the Final Approach
Checklist.
Upon established on final approach to the Oil Rig or Vessel Helideck,
start descent to 500 ft (use VS/IAS) and level until the visualization of
the helideck lights (shape of ellipse – see item 2.15.6). From this point
disengage FD and maintain visual approach manually. Never use rate
of descent greater than 300 ft/min.
On final, set AL300 to 1000 FT for missed approach.
If a go around has been decided, it should be made with upward turn
of 30º to either right or left, according to obstacle and to what has been
briefed.
Climb to 1000 ft for obstacle clearance.

Figure 2-1: Night visual approach
2.15.6 HELIDECK LIGHTS
Use the helideck lights as if it were a "vasis". Check the visualization
of helideck lights:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.33
Revision: 02
Date: 04/01/2019


CIRCLE
LINE
(only seeing the lights
in front)
ELLIPSE



HIGH LOW IDEAL
Ramp higher than
ideal
Very low ramp, maybe
below the Oil Rig or
Vessel helideck
Ideal ramp
2.15.7 TAKEOFF FROM OIL RIG OR VESSEL ON NIGHT
FLIGHT
After receiving the takeoff clearance, the crew must perform the
checklist accordingly.
Previously establish a free of obstacles takeoff heading. Be aware of
the prevailing wind.
The PM should monitor and assist the PF keeping in mind that his
function is so or more important than the PF.
When ready for takeoff, the PF calls “lifting” and go to a hover.
In hover, PF calls “CG OK”.
PM calls “all green, no lights, torque xx %”.
PF calls “takeoff” and start to apply the necessary power setting,
avoiding the maximum performance takeoff.
At 20 ft approximately, over the helideck (vertically), the PF calls
“Rotating” and makes a slightly cyclic movement forward, keeping
BAR to BAR.
During takeoff PF should maintain heading and positive "climb".
The PM must emphasize the torque indications, heading, altitude, V2
and VBROC speeds. PM should inform PF to adjust power if necessary.
Above 500 ft, PM will perform the after takeoff checks. Engage FD
(VS, IAS HDG modes).
Only above 1,000 ft initiate any turn.
The ideal ascent rate will be within 500 ft/min.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 2.2
Revision: 02
Date: 04/01/2019





OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:2.1
Revision: 02
Date: 04/01/2019


2.15.8 GO AROUND ON NIGHT FLIGHT
If necessary to go around within low speed, did not used GO AROUND
in FD, apply the necessary power setting above 70%, avoiding the
maximum performance takeoff limits, movement cyclic to keeping BAR
to BAR.

During the night approach, if the pilot is disoriented in relation
to the helideck or the approach is not stabilized, the GO
AROUND procedure must be performed. Do not use the GO
AROUND mode with speed less than 60kts, the correct
procedure is to apply power with the COLLECTIVE, respecting
the engine limits and move the cyclic slightly forward to
maintain BAR to BAR.
NOTE: All turns should be performed with a maximum bank of 20
degrees.
NOTE: Any turns exceeding 20 degrees of bank should be informed to
the PM before doing it.
 If the PF exceeds 20 degrees of bank without prior notification,
PM must alert. After the second alert, if the PF does not answer
the “call out” for excessive banking, the PM should take the
commands of the aircraft.
 Do not make great power variations [collective]. Never lower
torque to less than 20%.




OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.2
Revision: 02
Date: 04/01/2019


SECTION 3.
OPERATING LIMITATIONS
3.1 TYPES OF OPERATION
3.1.1 CATEGORY "A" AND "B" OPERATIONS
Transport
Day, Night, IFR, VFR
IFR operations not approved with any doors open.
Not approved for ditching unless the emergency flotation gear, P/N
76076-02002, and suitable lifesaving equipment (life jackets, rafts,
etc.) as required by the operating rules are installed and compliance
with FAR 29.1411, 29.1415, and 29.1561 is shown.
3.1.2 CATEGORY "B" ROTORCRAFT - EXTERNAL LOAD
COMBINATIONS
Class "B" External Loads
NOTE: A class "B" external load is an external load that can be
jettisoned and is lifted free of land or water during rotorcraft
operation.
3.2 MINIMUM FLIGHT CREW
TWO PILOTS (IFR)
To be eligible for operations under IFR, the following equipment must
be installed and operating, in addition to any other instrument or
equipment which may be required by ANAC:
 One autopilot system operating in the ATT Mode.
 Two inverters, with inverter switching operational.
 Two DC generators.
 Standby attitude indicator with emergency battery.
 Copilot’s instrument and controls must be installed and operable.
 Cyclic stick force trim.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.3
Revision: 02
Date: 04/01/2019


 A navigation and communication system that has demonstrated
 compliance with the pertinent FAA requirements.
3.3 WEIGHT LIMITS
Maximum takeoff and landing weight is 11,700 pounds (5,307
kilograms). This helicopter is to be operated using the approved
loading schedule. Refer to RFM Loading Information, Section II, in Part
2.
For minimum operating weight, refer to Figure 3-4.
3.4 CLIMB PERFORMANCE
These essentially require the ability to climb PEI at 50feet/min,
1000 feet above the highest obstacle within 10 miles of track(
within ½ mile by day VFR)

3.4.1 DETERMINATION OF EN ROUTE OEI CLIMB
PERFORMANCE

MTOW may be affected by obstacle in the climb out, especially
at night, IFR departures or missed approach procedures that
require a steep climb angle. OEI performance should be
calculated and taken into account.

3.4.2 OEI RATE OF CLIMB

Conditions:
1. Maximum continuous power, OEI
2. 0 feet PA
3. Vbroc / Vy ( 74knots)
4. External sliding door is fitted and closed
5. Effect of Engine anti-ice negligible
6. For Effect of hoist, snow kit and operations with door open see RFM
S76C++ OEI rate of climb


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.4
Revision: 02
Date: 04/01/2019


 Weight
OAT(°C) 11700 11500 11000 10500 10000 9500 9000
40 0 95 230 350 475 590 705
35 140 205 300 425 550 660 775
30 215 265 390 500 615 720 830
25 290 335 450 560 675 785 895
20 365 405 515 625 740 850 965
15 415 455 555 670 790 895 1000

3.5 PERFORMANCE CLASS
3.5.1 DEFINITIONS
Performance class 1
Operations with performance such that, in the event of failure of the critical
power unit, the helicopter is able to land within the RTOD available or
safely continue the flight to an appropriate landing area, depending on
when the failure occurs. Class 1 masses will provide a minimum of 100 feet
per minute OEI rate of climb up to 200feet at VTOSS and at least 150 feet
per minute up to 1000 feet above the takeoff surface, at maximum
continuous power with the landing gear retracted

Performance class 2
Operations with performance such that, in the event of critical power failure,
the helicopter is able to safely continue the flight, except when the failure
occurs early during the takeoff manoeuvre or late in the landing
manoeuvre, in the which case a forced landing may be required.
Class 2 masses will provide a minimum of 150 feet per minute OEI rate of
climb at 1000 feet above the takeoff surface at maximum continuous power
with the landing performance can be achieved.
Performance class 2 enhanced (PC2E)
Operations with performance such that, in the event of a critical power
failure, a safe flyaway of safe landing at the takeoff surface is possiblewith
no exposure to deck edge strike or ditching given the available drop down,
headwind component, pressure altitude and OAT. Performance class 2E


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.5
Revision: 02
Date: 04/01/2019


gives the equivalent performance assurance of performance class 1
without the requirement for a surveyed obstacle free environment.
Elevated helideck (class 2)
A helideck on an offshore installation or vessel. The offshore elevated
helideck profile (class 2) shall be flown.
Elevated Helipad (onshore) ( Class 1 or 2)
An elevated helipad of restricted dimensions (for example, on a hospital
rooftop). The RFM category A (class 1) helipad profile shall be flow unless
operations with expouse are permitted by the authority, in which case the
offshore elevated helideck profile (class 2) shall be flown. A helipad is less
than 305m(1000 feet ) in length
Ground level helipad (class 1)
A ground level helipad or hard surfasse shorter than 300m (990 feet). If
class 1 operations are required ( for exemple a congested hostile
environment), the RFM category A helipad profile shall be flown.
Ground level helipad (class 2)
A gorund level helipad or hard surface shorter than 305m (1000 feet) where
the terrain is suitable for operations in class 2 with exposure (terrain
suitable for a forced landing); for example a runway shorter than 305m
(1000 feet) with a suitable overrun, or large field. The class 2 (RFM
category B) profile may be flown.
Long runway (class 1 or class 2)
A runway or equivalent surface of 550m (1800 feet ) or longer suitable for
operations in class 1, or class 2 without exposure (for exemple, if the
crosswind component or tailwind is outside the class 1 limits ).
Short runway (class 1 or class 2)
A runway or equivalent surface of between 305m(1000 feet) and
550m(1800 feet) suitable for operations in class 1, or class 2 without
exposure. (for exemple, if the crosswind component or tailwind is outside
the class 1 limits ).
FATO
Final approach and takeoff area: A defined area over which the final phase
of the approach manoeuvre to hover or landing is completed and from
which the takeoff manoeuvre is commenced. Where the FATO is to be


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.6
Revision: 02
Date: 04/01/2019


used by performance class 1 helicopters, the defined area includes the
RTOA available.
LDAH
Landing distance available (helicopter) : the length of the FATO plus any
additional area declared available and suitable for helicopters to complete
the landing manoeuvre from a defined height.
LDP
Landing decision point: This is a point defined by speed and height and is
the last point from which, provided an engine failure has been recognised,
the aircraft has the necessary performance to safely go around, clearing
the surface by 10.6m (35ft), or a single engine landing may be made.
LDR
Landing distance required: The horizontal distance required to land and
come to a full stop from a point 15.24m (50ft) above the landing surface.
RTOA
Refected takeoff area: the area bounded by the RTOD and 15.24m (50ft)
either side of the takeoff path.

RTOD
Rejected takeoff distance: The horizontal distance required from the start of
the takeoff to the point where the helicopter comes to a full stop after an
engine failure at TDP and rejected takeoff (also called the accelerate-stop
distance)
TDP
Takeoff decision point: TDP is the point during the takeoff manoeuvre at
which, provided an engine failure has been recognised, the aircraft has the
necessary performance to safely continue the takeoff or a rejected takeoff
may bem ade. TDP is defined by height and speed, or height and time
depending on the takeoff profile.


TODA
Takeoff distance available: The length of the final approach and takeoff
area plus the length of helicopter clearway (if provided) declared available
and suitable for helicopters to complete the takeoff.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.7
Revision: 02
Date: 04/01/2019


TODR
Takeoff distance required: The horizontal distance from the start of the
takeoff to a point 10.6m(35ft) above the takeoff surface at which
V2(VTOSS) and a positive climb gradiente are achieved after failure of the
critical power unit at TDP, with the remaining engine operating within
approved limits.

V2(VTOSS)
Takeoff safety speed. V2 is the initial climbing speed (first segment). For
the S76C, it is normally a fixed 59knots IAS, but may vary with runway
length. It is defined as the speed at which the rate of climb will be at least
100 feet/min with the critical engine inoperative and: the remaining engine
at the two-minute rating, the landing gear down and all engine air bleeds
off.
VBROC (Vy)
This is the speed for best rate of climb and is speed at which the second
segment and en route climbs are flown OEI. Vbroc is equal to 74kts IAS,
reduced by 1 knot per 1000 feet of pressure altitude above sea level. At
this speed, the rate of climb will be at least 150feet/min up to 1000 feet
above takeoff surface with the critical engine inoperative, the remaining
engine at maximum continuous OEI rating, the landing gear retracted and
all engine air bleeds off

3.5.2 PERFORMANCE CLASS 1
Maximum takeoff weight must not exceed any of the following:
 Maximum climb mass for the rate of climb required after takeoff
 Maximum en route mass
 Maximum landing mass (MLM), taking into account the
expected fuel consumption en route
Class 1 masses will provide a minimum of 100 feet per minute OEI
rate of climb up to 200 feet at Vtoss(V2) two-minute power, 100% NR,
landing gear down, and ar least 150 feet per minute up to 1000 feet
above the takeoff surface, at maximum continuous power, Vbroc(Vy),
100% NR with the landing gear retracted

a - CLASS 1 LONG RUNWAY MTOW / MLM

Conditions:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.8
Revision: 02
Date: 04/01/2019


1. Anti-icing and bleed air are off
2. Data is for 0 feet PA
3. No allowance is made for wind in this table
4. Allowance has been made for the sliding door installation
(closed position) in this chart
5. Chart: Category A maximum gross takeoff weight, part 1,
section 1, figure 1-1 of RFM


Surface OAT (°C) MTOW (lb) Surface
OAT(°C)
MTOW(lb)
45 10870 37 11510
44 10950 36 11590
43 11030 35 11670
42 11110 34 11700
41 11190 33 11700
40 11270 32 11700
39 11350 31 11700
38 11430 30 11700

b - CLASS 1 SHORT RUNWAY MTOW / MLM
Conditions:
1. Anti-icing and bleed air are off
2. Data is for 0 feet PA
3. No allowance is made for wind in this table
4. Allowance has been made for the sliding door installation
(closed position ) in this chart
5. Chart: Category A, maximum takeoff and landing gross weight,
part 1, section IV, figure 4-8 of the RFM; and Category A,
rejected and continued takeoff distances, part 1, section IV,
figure 4-7 of the RFM

Length in
feet
1000 1100 1200 1300 1400 1500 1600 1700 1800
TDP/Vtoss 34/44 37/47 40/50 43/53 45/55 48/58 49/59 49/59 49/59
48°C 9530 9800 10100 10350 10420 10630 10630 10630 10630
46°C 9690 9950 10210 10480 10600 10790 10790 10790 10790


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.9
Revision: 02
Date: 04/01/2019


44°C 9800 10080 10350 10600 10740 10890 10950 10950 10950
40°C 10040 10410 10610 10870 11000 11200 11270 11270 11270
38°C 10150 10450 10710 10990 11120 11210 11300 11430 11430
36°C 10250 10550 10850 11100 11240 11390 11490 11590 11590
34°C 10380 10670 10950 11210 11380 11500 1160011700 11700
32°C 10490 10790 11090 11340 11490 11640 11700 11700 11700
30°C 10600 10900 11190 11450 11610 11700 11700 11700 11700
28°C 10700 11000 11300 11580 11700 11700 11700 11700 11700
26°C 10800 11100 11400 11680 11700 11700 11700 11700 11700
24°C 10910 11190 11500 11700 11700 11700 11700 11700 11700
22°C 11100 11300 11610 11700 11700 11700 11700 11700 11700
20°C 11100 11400 11700 11700 11700 11700 11700 11700 11700
18°C 11180 11490 11700 11700 11700 11700 11700 11700 11700
16°C 11240 11550 11700 11700 11700 11700 11700 11700 11700

3.5.3 PERFORMANCE CLASS 2
The class 2 performance procedure may be used when the below
criteria are met. Maximum takeoff Weight must not exceed any of the
following:
 Maximum climb mass for the rate of climb required after takeoff
 Maximum en route mass
 Maximum Landing Mass (MLM), taking into account the expected
fuel consumption en route
 The terrain over which the aircraft is to be flown during acceleration
to Vtoss shall be suitable for a forced landing. Suitable means no
dynamic parts of the aircraft would be damaged during any forced
landing and that there would be no risk to third parties from a
forced landing
 The cloud base and visibility shall be such that in the event of an
engine failure acceleration to Vtoss may be achieved while
manoeuvring clear of cloud and with sufficient forward visibility to
permit obstacle avoidance by visual manoeuvring. In pratical terms,
this means a minimum cloud base such that aircraft can achieve a
PC1 climb profile which guarantees clearance from obstacles
before entering cloud and a minimum visibility of 800M


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.10
Revision: 02
Date: 04/01/2019


 Class 1 performance shall be achieved by the time obstacles can
no longer be avoided by visual manoeuvring and at the very latest
by 200 feet above the takeoff surface.

a - PERFORMANCE CLASS 2 OPERATIONS WITHOUT AN
EXPOSURE TIME DURING TAKEOFF AND LANDING
Onshore operations may be carried out class 2 without exposure( for
exmple, from and to a runway or other landing site where a safe
continued takeoff or safe forced landing can be assured).
 Maximum crosswind ................... 35 knots
Instrument approaches with a tailwind componente are permitted. If
the cloud base is below circling minimum for the approach, so a
downwind landing has to be made, the following minimum apply:
 Minimum cloud base ................ 200 feet
 Minimum visibility / RVR .......... 800m
In addition, for theses approaches only:
 Maximum tailwind componente ....... 10kts

b - PERFORMANCE CLASS 2 OPERATIONS TO
HELIDECKS AND ELEVATED HELIPORTS WITH AN
EXPOSURE TIME DURING TAKEOFF AND LANDING

Class 2 operations with an exposure time during takeoff and landing may
be carried out when approved by the authority.

Defined point after takeoff and defined point before landing
The notion of operations with an exposure time implies that there are
certain critical phases of the flight where safe continued flight or
safelanding cannot be guaranteed, due to the lack of performance of the
helicopter in the event of an engine failure. The defined points, after
takeoff (DPATO) and before landing (DPBL), are used to illustrate this
although they are in fact variable points at which the aircraft becomes safe
single engenine during a continued takeoff and can therefore comply with
the class 1 or 2 performance requirements.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.11
Revision: 02
Date: 04/01/2019


For the S76C++, in pratical terms this point may be taken as passage of
Vtoss accelerating, which will guarantee safe single engine performance
under worst case conditions of weight, altitude and temp. The DPBL is the
point (as a function of airspeed, rate of descent and height above the deck)
after which the aircraft may not have the performance to go around or to
continue to a safe landing and therefore may have to ditch. Again in pratical
terms, this point for S76 may be taken as the passage of Vtoss
decelerating. The expousure time is the time between passage of TDP
and DPATO or between DPBL and Committal Point.

c - PERFORMANCE CLASS 2 ONSHORE MTOW / MLM
Conditions:
1. Anti-icing and bleed air are off
2. Data is for 0 feet PA
3. No allowance is made for wind in this table
4. Allowance has been made for the sliding door installation
(closed position) in this chart
5. These figures are taken from the 150 feet per minute OEI at
1000 feet above the takeoff surface chart in the RFM. They are
based for sea level takeoff
6. Chart: Forward Climb Performance, Part 1, Section IV, Figure
4-11 of the RFM

Surface
OAT(°C)
C++ Surface
OAT(°C)
C+
45 10870 45 10300
44 10950 44 10400
43 11030 43 10500
42 11110 42 10600
41 11190 41 10700
40 11270 40 10800
39 11350 39 10850
38 11430 38 10950
37 11510 37 11000
36 11590 36 11100
35 11670 35 11150
34 11700 34 11250
33 11700 33 11250


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.12
Revision: 02
Date: 04/01/2019


32 11700 32 11300
31 11700 31 11400
30 11700 30 11500
29 11700 29 11600
28 11700 28 11700
27 11700 27 11700
26 11700 26 11700
25 11700 25 11700
24 11700 24 11700

d - PERFORMANCE CLASS 2 HELIPAD AND
HELIDECK MTOW

The data in the following tables is obtained from the AEO HOGE
performance at takeoff power. This mass is always more limiting than
the limiting mass for a 150 feet/min climb at MCP OEI 1000 feet above
the takeoff point.
Use:
 0% margin for normal operations, day and night
Notes:
1. Anti-icing and bleed air are off
2. Data is for 100 feet PA. For helipads above 150 feet PA, reduce
mass by 30lb for each 100 feet PA increase
3. MTOW must not exceed the class 2 takeoff mass, or the en
route mass
4. These tables are based on the HOGE chart in the RFM. 150
feet por minute OEI rate of climb at 1000 feet PA at maximum
continuous power gear up in included in this data.
5. Chart: Hover out of Ground effect , part 1, section IV, figure 4-
22 of the RFM
6. Chart: Forward climb performance, part 1, section IV, figure 4-
11 of the RFM

Surface
OAT(°C)
C++ Surface
OAT(°C)
C+
45 10870 45 10300
44 10950 44 10400


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.13
Revision: 02
Date: 04/01/2019


43 11030 43 10500
42 11110 42 10600
41 11190 41 10700
40 11270 40 10800
39 11350 39 10850
38 11430 38 10950
37 11510 37 11000
36 11590 36 11100
35 11670 35 11150
34 11700 34 11250
33 11700 33 11250
32 11700 32 11300
31 11700 31 11400
30 11700 30 11500
29 11700 29 11600
28 11700 28 11700
27 11700 27 11700
26 11700 26 11700
25 11700 25 11700
24 11700 24 11700

e - PERFORMANCE CLASS 2 ENHANCED

The following tables should be used when required to operate
offshore class 2 without exposure
Use:
 0% Margin for normal operations, day and night
Notes:
1. Anti-icing and bleed air are off
2. Data is for 100 feet PA. For helidecks above 150 feet PA,
reduce mass by 30lb for each 100 feet Pa increase
3. MTOW must not exceed the performance class 2E takeoff
mass, or the en route mass
4. These tables are based on the vertical operations from
elevated helideck chart in the RFM. 150 feet per min OEI rate


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.14
Revision: 02
Date: 04/01/2019


of climb at 1000 feet PA at maximum continuous power gear
up is included in this data
5. Chart: Verticaloperations from elevated helideck, part 2,
section IV, figure 4-43 of the RFM
6. Chart: Forward climb performance, part 1, section IV, figure 4-
11, and part 2, section IV, figure 4-42 of the RFM
7. Takeoff torque shall be sufficient for a vertical ascent to 30
feet, up to maximum allowed for conditions
8. Measure drop down from the deck edge to 35 feet above the
ocean
9. Use the applicable table based on wind conditions 0-14, 15-19
and 20+ knots
10. External sliding door in the closed position weight reduction
of 50lb has been applied

PC2E offshore Helideck MTOW
S76 C++ Table
0 to 14kt
Wind
 HELIDECK Height
°C 60 feet 80 feet 100 feet 120 feet
42 9610 9830 10060 10340
40 9750 9950 10200 10500
38 9830 10070 10360 10620
36 9910 10190 10520 10740
34 10030 10320 10670 10870
32 10190 10460 10810 11010
30 10350 10600 10950 11150
28 10390 10680 11010 11210
26 10430 10760 11070 11270
24 10480 10840 11120 11340
22 10540 10920 11160 11420
20 10600 11000 11200 11500


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.15
Revision: 02
Date: 04/01/2019


18 10660 11060 11260 11500
15 to 19
knots wind
 Helideck Height
°C 60 feet 80 feet 100 feet 120 feet
42 9850 10010 10290 10540
40 9950 10150 10450 10700
38 10050 10270 10630 10880
36 10150 10390 10810 11060
34 10270 10520 10970 11220
32 10410 10660 11110 11360
30 10550 10800 11250 11500
28 10630 10940 11310 11560
26 10710 11080 11370 11620
24 10790 11180 11430 11675
22 10870 11240 11490 11700
20 10950 11300 11550 11700
18 10990 11380 11610 11700
16 11030 11460 11670 11700
S76C++ table
S76C++ table
20 to 20+
Knots
wind
 Helideck Height
°C 60 feet 80 feet 100 feet 120 feet
42 10290 10580 10850 11110
40 10450 10800 11050 11250
38 10550 10880 11230 11475
36 10650 10960 11410 11700


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.16
Revision: 02
Date: 04/01/2019


34 10800 11080 11540 11700
32 11000 11240 11620 11700
30 11200 11400 11700 11700
28 11260 11520 11700 11700
26 11320 11640 11700 11700
24 11390 11700 11700 11700
22 11470 11700 11700 11700
20 11550 11700 11700 11700
18 11650 11700 11700 11700

3.6 OEI TRAINING OPERATIONS
See Figure 5-41 of RFM Part 2, Section V for variation of allowable
takeoff gross weight with altitude.
3.7 CENTER OF GRAVITY LIMITS
See Figure 3-4 for forward and aft center of gravity limits at various
gross weights.
Lateral C.G. Limits: Left or right 3-1/2 inches (89 mm) except as
restricted to left or right 2-1/2 inches (63.5 mm) at gross weights above
11,400 pounds (5,171 kg) for taxi, takeoff, and landing.
3.8 LOADING LIMITS
Maximum allowable cabin floor and baggage floor loading is 75
pounds per square foot (366 kg per square meter).
The maximum allowable floor loading for the baggage compartment is
75 pounds per square foot (366 kg per square meter) for weights up
to the maximum capacity of 600 pounds (272 kg).
CAUTION: Caution must be taken to be sure that passenger, fuel,
and/or baggage/cargo compartment loading does not
cause aircraft maximum gross weight and/or C.G. limits
to be exceeded.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.17
Revision: 02
Date: 04/01/2019


3.9 AIRSPEED LIMITS
Vmini (IFR) - 50 KIAS.
Vnei (IFR) - 155 KIAS.
Vne power on (Maximum Airspeed) is 155 KIAS.
See Vne placard, Figure 3-8, for variation of Vne with temperature,
pressure altitude, and gross weight.
Vne above 10,000 feet density altitude at actual gross weights greater
than 11,000 pounds is Best Rate-Of-Climb (BROC) airspeed (see
appropriate Vne placard, Figure 3-8).
Vne power off is 136 KIAS. See Vne placard, Figure 3-8, for variation
of Vne with temperature and pressure altitude.
Maximum airspeed for main landing gear down or in transit is 130
KIAS.
Maximum airspeed for windshield wiper operation is 141 KIAS.
Maximum groundspeed for landing, takeoff, or taxi is 54 knots.
Maximum groundspeed for brake application is 34 knots.
3.10 ALTITUDE LIMITS
Takeoff and landing, Category A: 5,000 feet density altitude.
Takeoff and landing, Category B: 15,000 feet density altitude.
Enroute: 15,000 feet density altitude.
Operating Envelope: Refer to Figure 3-2.
3.11 AMBIENT TEMPERATURE LIMITS
-34°C (-30°F) to ISA plus 37°C not to exceed 49°C (120°F).
3.12 FLIGHT LIMITS
See Figure 3-6 for altitude and airspeeds to be avoided at low altitude in
case of engine failure.
No aerobatic maneuvers allowed.
360° hovering turn in less than 12 seconds prohibited.
Flight in known icing conditions prohibited.
Maximum airspeed for sideward flight or crosswind hover is 35 knots.
Maximum airspeed for rearward flight or tailwind hover is 35 knots.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.18
Revision: 02
Date: 04/01/2019


With usable fuel per tank indicating 80 lbs or less, avoid sustained nose-
down pitch attitudes in excess of 5° nose low.
Cockpit ventilation must be provided by any of the following:
 Door vents
 Pilot's window
 Heater blower
 Heater bleed-air
 ECU
 Fuel cross-feed operations limited to:
 Category A - emergency operation only
 Category B - cruising flight only
Both engine control levers must remain in FLY during OEI (single engine)
training operations.
CAUTION: Movement of opposite engine lever out of FLY will not
cause engine to immediately exit OEI (single engine)
TRAINING operations. Nr will droop to approximately
90% before exiting OEI TRAINING.
Both engine control levers must remain in FLY during simulated ENGINE
CONTROL operations.
Engine ANTI-ICE ON at or below 2°C (36°F) with visible moisture.
External door locks must be unlocked before flight.
Maximum approved precision approach angle is 6.5° (uncoupled).
Operation vs. allowable wind limited to 35 knots sideward and rearward
flight.
Maximum density altitude is 15,000 feet (enroute).
IFR lateral CG limits are 3.5 inches left or right.
Preflight Test (level 1 minimum) of the DAFCS must be accomplished prior
to the first flight of the day or before planned flight in IMC conditions.
Flight director shall not be coupled below 60 KIAS.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.19
Revision: 02
Date: 04/01/2019


The Pulselite System should not be operated in the clouds at night or on
the ground while in close proximity to other aircraft.
3.13 ELECTRONIC FLIGHT INSTRUMENT SYSTEM (EFIS)
LIMITS
Separate, functional, calibrated, and pitot statically powered altimeter, and
airspeed indicator must be installed for use in conjunction with the 5x6
EFIS for all flight operations.
The composite mode is to be used for operational flights only after a failure
of the EADI and EHSI. This does not preclude the conduct of flight training
in the use of the composite mode.
The helicopter must be equipped with a functioning third attitude indicator
for IFR flight.
For IFR operation, the following equipment must be operational for takeoff:
1. Aircraft equipped with the single pilot IFR option - pilot’s symbol
generator, EADI, EHSI, and CRT fan.
2. Aircraft not equipped with the single pilot IFR option - pilot and copilot
symbol generators, EADI, EHSI, and CRT fan.
Takeoff with an engine DC generator inoperative is not authorized during
night or IFR conditions.
3.14 SLIDING CABIN DOOR LIMITS
Restrictions for either/or the right hand or the left hands are:
Maximum airspeed for opening and closing cabin sliding doors is 125 KIAS.
This includes up to 125 knots Maximum ContinuousPower (MCP) climb
and up to 125K autorotation. See Figure 3-8 for variation of maximum
airspeed with temperature and pressure altitude.
Maximum airspeed with either sliding door open, or both open is 125 KIAS.
This includes up to 125 knots MCP climb and up to 125K autorotation. See
Figure 3-8 for variation of maximum airspeed with temperature, and
pressure altitude.
IMC flight with either or both sliding doors open is prohibited.
For Category “A” operations, reduce the maximum takeoff gross weight
determined from Figure 3-1 by 100 lbs if flight is to be conducted with one
or both external sliding doors open.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.20
Revision: 02
Date: 04/01/2019


3.15 FLOTATION SYSTEM LIMITS
Maximum airspeed for inflation of the emergency flotation gear is 75 KIAS.
Maximum airspeed with emergency flotation gear inflated is 75 KIAS.
Maximum water contact speed with emergency flotation system inflated is
33 knots.
Landing gear must be down before float inflation.
Maximum demonstrated airspeed for sideward flight or crosswind hover is
20 knots.
Maximum pressure altitude with emergency flotation gear inflated is 5,000
feet.
3.16 ENGINE LIMITS
NOTE: Engine power usage at N1 greater than 99.6% will be
cumulatively counted. Other than operations using the OEI
training provision, display of either the 2-Minute or 30-Second
Usage light during high power operation is indicative that
usage counting is proceeding. Consult the engine
maintenance manual for any consequences regarding usage
counting.
3.16.1 ENGINE OR DRIVE SYSTEM OPERATING LIMITS
THIS TABLE IS A SUMMARY OF LIMITATIONS OBSERVE THE FIRST
LIMIT ENCOUNTERED FOR ANY GIVEN OPERATING CONDITIONS

OPERATING
CONDITIO
N
TIME
TRANSMISSIO
N
TORQUE LIMIT
(%)
ENGINE
TORQU
E
LIMIT
(%)
T5°C %N1 %N2
TAKEOFF
5
MIN
100 104 930 100.0 (1)
MAXIMUM
CONTINUOU
S
(5)
-- 100 104 893 97.8 (1)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.21
Revision: 02
Date: 04/01/2019


30 SEC
SINGLE
ENG
30
SEC 136 135 996 103.9 (1)
2 MIN
SINGLE
ENG
2
MIN
136 127 944 100.5 (1)
MAXIMUM
CONTINUOU
S
SINGLE
ENG
-- 128 115 (3) 926 99.4 (1)
TRANSIENT
SINGLE
ENG
5
SEC
150 (9) -- -- --
TRANSIENT
20
SEC -- 160 -- 100.5
109/11
5
(4)
TRANSIENT
10
SEC 115 (8) -- -- -- --
STARTING
10
SEC -- --
840
(6)
-- --
Figure 3-1: Engine or Drive System Operating Limits
NOTES:
(1) 108.5% N2 - maximum.
(3) The DECU will limit single engine torque to 110% at 106 - 108% N2 varying linearly to
115% torque at 100% Nr.
(4) 109% N2 transient maximum, power on. 115% N2 transient maximum, power off.
(5) See paragraph titled Engine Ratings and Recommended Usage in Part 2, Section 1.
(6) Time between 750 and 840°C is limited to 10 seconds. When T5 reaches 840°C. the start
will automatically be aborted.
(7) Shaded box with bold number denotes a DECU controlled limiter value.
(8) Dual engine transient limit 230% total torque.
(9) Typically associated with abnormal Nr droop at DECU controlled OEI limit.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.22
Revision: 02
Date: 04/01/2019





OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.23
Revision: 02
Date: 04/01/2019


Figure 3-2: Height / Velocity Diagram

3.16.2 ENGINE TORQUE LIMITS
NOTE: Refer to Transmission Limits in this section for additional
torque limits.
104% Torque: - 5-Minute takeoff and maximum continuous limit, dual-
engine (Refer to Engine Ratings and Recommended Usage,
RFM Section I, Part 2 for recommended usage of maximum
continuous torque.)
135% Torque: - 30-Second limit, single engine
127% Torque: - 2-Minute limit, single engine
115% Torque: - Maximum Continuous, single engine
160% Torque: - Maximum transient 20 seconds
NOTE: Operation above 104% torque, 100.5% N1, or 930°C T5 is
reserved for actual emergencies, inadvertent transient
excursions, or, as artificially biased indications, with the OEI
training provision.
3.16.3 N1 (GAS PRODUCER) SPEED LIMITS
TWO ENGINE OPERATION:
100.0% N1 – 5-Minute takeoff power limit, dual engine
97.8% N1 - Maximum continuous power, dual engine
OEI OPERATION:
103.9% N1 - 30-Second power, single engine
100.5% N1 - 2-Minute power, single engine
99.4% N1 - Maximum continuous power, single engine
TRANSITIONAL OPERATION, GROUND TO FLIGHT IDLE:
53-62% N1 - Avoid prolonged operation in this range.
TRANSITIONAL OPERATION, ROTOR RUNUP OR SHUTDOWN:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.24
Revision: 02
Date: 04/01/2019


87.0-90.5% N2 - Avoid prolonged operation in this range.
3.16.4 N2 (POWER TURBINE) SPEED LIMITS
Maximum, power-on or off: 108.5% N2
Minimum, power off: 90.5% N2
Transient Maximum, power-on: 109% N2 for 20 seconds
Transient Maximum, power-off: 115% N2 for 20 seconds
Transient Minimum: 68% N2 for 20 seconds while executing an OEI landing
3.16.5 T5 (POWER TURBINE) INLET TEMPERATURE LIMITS
Steady State Limits
TWO ENGINE OPERATION:
930°C - 5-Minute takeoff power limit, dual engine
893°C - Maximum continuous power, dual engine
OEI OPERATION:
996°C - 30-Second power, single engine
944°C - 2-Minute power, single engine
926°C - Maximum continuous power, single engine
Starting and Shutdown
750°C - no time limitation
750°C to 840°C - limited to 10 seconds

3.16.6 DIGITAL ENGINE CONTROL UNIT (DECU) LIMITS
Before takeoff, the following DECU conditions must be met:
1. Both engine DECUs must be free of all faults, Total, Degraded, and Minor,
as read on the IIDS display.
2. Both throttles must be in the FLY position with pilot’s and copilot’s blue
ENG CONTROL lights out.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.25
Revision: 02
Date: 04/01/2019


3.16.7 ENGINE BARRIER FILTER LIMITS
CAUTION: Engine operations with the barrier filters not installed is
prohibited.
NOTE: The BARRIER FILTER panel provides an indication of filter
blockage and is not a direct indication of available engine
power. A power assurance check is the only means by which to
ensure the availability of engine power necessary to meet the
performance data in this Rotorcraft Flight Manual.
1. With PWR ASSURANCE advisory light on the IIDS and the CHECK
condition light on the BARRIER FILTER panel latched prior to or during flight
(between 3 and 5 segment lights): Normal operations are permitted if a
ground or in-flight Power Assurance check is performed and the power and
T5 margin results for both engines are at least zero. Maintenance shall be
performed prior to the next day's flight.
2. With CHECK BAR FILT caution light on the IIDS and the MAINT condition
light on the BARRIER FILTER panel latched prior to flight (between 6 and 8
segment lights): Maintenance shall be performed prior to flight.
3. With CHECK BAR FILT caution light on the IIDS and CAUT condition light
on the BARRIER FILTER panel latched prior to flight (9 or 10 segment lights):
Maintenance shall be performed prior to flight.
4. A power assurance check must be performed when a new, cleaned, or
used filter element is installed.
3.17 FUEL
3.17.1 FUEL FLOW RANGE
Minimum: 75 pounds per hour
Maximum: 700 pounds per hour
NOTE: Fuel flow may go beyond these ranges during transient
operations including start and at idle.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.26
Revision: 02
Date: 04/01/2019


3.17.2 NORMAL FUELTYPE OF
FUEL
NATO
SYMB
OL
SPECIFICATION FUEL
TEMP
MIN.°
C
ANTI-ICE
ADDITIV
E U.S.A. U.K. FRANCE
Kerosene-
50
(AVTUR
FS II) JP8
F-34
JP-8,
MIL-T 83133
D.ENG.
RD
2453
AIR 3405
F-34
-
50°C
WITH
Kerosene-
50
(AVTUR)
JET A1
F-35
Jet A1,
ASTM-D-
1655
D.ENG.
RD
2494
AIR 3405
F-35
-
50°C
WITHO
UT1
Kerosen
e
--
ASTM-D-
1655
-- --
-
40°C
WITHO
UT1
High flash
Point
Kerosene
JP-5
(AVCAT
)
F-43 --
D.ENG.
RD
2498
AIR 3404
F-43
-
46°C
WITHO
UT1
High flash
Point
Kerosene
JP-5
(AVCAT
FS II)
F-44
JP-5,
MIL-T-
5624
D.ENG.
RD
2452
AIR 3404
F-44
-46°
C
WITH
Kerosene
TS-1, RT2
GOST
10227

-
46°C
WITH
Jet fuel
PRC
National
Standard
3
 CHINA
WITHO
UT1
NOTE:
1. Anti-icing additive must be used below 4°C (40°F) for fuels supplied without anti-icing
additive as listed above.
2. Maximum fuel temperature: +43°C.

3.17.3 AUTHORIZED FUEL ADDITIVES
Anti-icing additive:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.27
Revision: 02
Date: 04/01/2019


NATO symbol S 748, MIL-I-27686, D.ENG.RD 2451(AL-31), AIR 3652B, or
NATO symbol S 1745, MIL-I-85470A, D.ENG.RD 2451(AL-41), AIR 3652B,
or Type T1301 (standard SH0369) equivalent to NATO S748 (only for PRC3
fuel) in concentration by volume between 0.10% and 0.15%.
Fluid 1 (GOST 8313), fluid 1-M (TU6-10-1458), TGF (GOST 17477), TGF-M
(TU6-10-1457): in concentration by volume between 0.10% and 0.30%.
Jet fuel thermal stability improver: Type +100 – NATO symbol S1749, MIL-
DTL 83133E, SPEC AID 8Q462, APA 101 in concentration by volume of 256
mg/l.
NOTE: Additive for F34 and F35. F34 with +100 additive = F37.
 The water-separating filter is inoperative when this additive is
used.
Anti-static additive:
SHELL ASA-3, maximum concentration by volume 0.0001%.
DUPONT STADIS 450, maximum concentration by volume 0.0003%.
SIGBOL (TU 38-101741), maximum concentration by weight 0.0005%.
Anti-oxidation, metal de-activation, anti-corrosion additive, according to
current approved specifications in force (including anti-oxidation IONOL and
anticorrosion ANK).
Fungicide additive (Biobor) restricted to a treatment every 500 operating
hours or every 3 months.
3.18 ENGINE OIL
NOTE: The oil types mentioned under the heading “Other oil types”
shall not be used at high ambient temperature (T0 ≥ 30°C)
(84°F). The oil type to be used for normal use is the synthetic
fluid 5 cSt NATO symbol 0-156 between -30°C and +50°C (-22°F
to +122°F). If the engine is used at low temperature, the oil type
to be used for normal use is the 3 cSt oil. The use of an oil type
with a trademark and/or specification different from those
indicated must be approved by Sikorsky Aircraft.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.28
Revision: 02
Date: 04/01/2019



OIL TYPE
NATO
SYMB
OL
SPECIFICATION
APPROVED OIL
BRANDS FRAN
CE
USA U.K
Recommended
use
Average
synthetic
5 cSt at
98.9°C

0-156 - MIL-L-
23699
DERD
2499
EXXON Turbo Oil 2197
MOBIL Jet Oil 254
MOBIL Jet Oil 291
Normal use
Average
synthetics
5 cSt 98.9°C
0-156 - MIL-L-
23699
DERD
2499
CASTROL 5000
AeroShell Turbine Oil
500
EXXON Turbo Oil 2380
MOBIL Jet Oil 2
TURBO NYCOIL 600
TOTAL Aéro
Turbine 535
Other oil types
Synthetic fluid
3 to 3.5 cSt at
98.9°C
0-148 - MIL-L-
7808
 CASTROL 325
CASTROL 3C
EXXON Turbo Oil 2389
MOBIL AVREX 256
TURBO NYCOIL
160
 0-150 AIR
3514
- - ELF Jet Synthetic Oil 15
TURBO NYCOIL
13B
Synthetic fluid
3.9 cSt at
98.9°C
- - - - AeroShell Turbine
Oil 390
3.18.1 ENGINE OIL TEMPERATURE LIMITS
Maximum: 115°C (239°F)
3.18.2 ENGINE OIL PRESSURE LIMITS
In Flight: Precautionary 87 to 142 PSI with Oil Temp < 4ºC
 Normal 29 to 87 PSI
 Precautionary 24 to 29 PSI
 Minimum 24 PSI, only at N1 less than 85%


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.29
Revision: 02
Date: 04/01/2019


Ground Idle: Minimum 10 PSI
3.19 TRANSMISSION LIMITS
NOTE: Operation above 104% torque on one engine (200% total
torque), 100.0% N1, or 930°C T5 is reserved for actual
emergencies, inadvertent transient excursions, or, as artificially
biased indications, with the OEI training provision.
3.19.1 TORQUE LIMITS
Dual-Engine Operation
100% Torque per engine – 5-Minute takeoff and maximum continuous limit
NOTE: Takeoff torque may exceed 100% on one engine to a maximum
of 104% provided that the torque on the other engine is less
than 96% and the sum of the individual torque values does not
exceed 200%.
115% Torque per engine – 10-Second transient
OEI Operation
136% Torque - 2 1/2-Minute limit
128% Torque - Maximum Continuous
150% - 5-Second transient

3.19.2 TRANSMISSION OIL
Dexron II or III ATF - Low temperature limit -34°C (-30°F)
MIL-L-21260 Type I, Grade 30 - Low temperature limit -9°C (15°F)
MIL-L-23699 or DOD-L-85734 - Low temperature limit -34°C (-30°F)

3.19.3 TRANSMISSION OIL TEMPERATURE LIMITS
Maximum: 135°C
Minimum: -20°C


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.30
Revision: 02
Date: 04/01/2019


3.19.4 TRANSMISSION OIL PRESSURE LIMITS
Maximum: 120 PSI
Minimum: 20 PSI
3.20 ROTOR LIMITS
POWER OFF
Maximum: 115% Nr
Minimum: 91% Nr
Transient (Minimum): 74% Nr
Transient (Minimum): 68% Nr at touchdown while executing an autorotative
landing
Transient (Maximum): 121% Nr
POWER ON
Maximum: 108% Nr; except 109% transient operation for 20 seconds
Minimum: 106% Nr (dual-engine operation)
Minimum: 100% Nr (one engine inoperative)
Transient: 91% Nr
Transient 68% at touchdown while executing an OEI landing
One engine operation up to best rate of climb speed, 100% to 108% Nr
One engine operation above best rate of climb speed, 106% Nr to 108% Nr
3.21 ROTOR BRAKE LIMITS
ROTOR TURNING
Rotor brake application limited to one (or two) engine(s) operating at idle or
both engines shut down.
Maximum rotor speed for normal rotor brake application is 65% Nr.
Maximum rotor speed for emergency rotor brake application with both
engines shut down is 107% Nr.
A rotor shutdown using the rotor brake shall not be performed more than one
time in any 10-Minute period.
ROTOR STOPPED


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.31
Revision: 02
Date: 04/01/2019


Engine operation limited to one or both engines at idle.
Main rotor blades must be positioned at approximately 45° to the longitudinal
axis of the helicopter with one or both engines operating.
3.22 ENGINE COWLING LIMITS
ENGINE COWLING OPEN
Engine operation with cowling open or unlatched is prohibited.
ENGINE COWLING REMOVED
Single-engine operations permitted only with operational rotor brake applied
with main rotor blades positioned at 45° to the longitudinal axis of the
helicopter and nose of the helicopter positioned into the wind. Do not exceed
N1 52%.
3.23 RETRACTABLE BOARDING STEP LIMITS
If the BD STEP caution is annunciated:
 Maximum speed with step(s) extended is 141 knots.
 Maximum speed for step(s) transition (extend/retract) is 70 knots.
3.24 EMERGENCY LOCATOR TRANSMITTER (ELT)
The ELT should only be activated when an emergency landing is imminent.
It may be actuated for test under the following conditions only:
1. While on the ground.
2. During the first five minutes of each hour.3. For a maximum duration of three sweeps of the warble tone (about one
second).
4. The control tower has been notified prior to the test.
3.25 GARMIN GPS 500W LIMITATIONS
The GARMIN GPS 500W Pilot's Guide, P/N 190-00357-00 Rev. G or
later appropriate revision must be immediately available to the flight
crew whenever navigation is predicated on the use of the system.
Navigation predicated upon precision accuracy (eg. LPV approaches)
is not approved.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.32
Revision: 02
Date: 04/01/2019


No navigation is authorized north of 89° (degrees) north latitude or
south of 89° (degrees) south latitude.
IFR en-route and terminal operation predicated on current GPS
database only.
Any GPS or WAAS operation under Instrument Flight Rules (IFR)
requires that:
 Aircraft using the GPS or WAAS 50QW under IFR must be equipped
with an approved alternate means of navigation
 For flight planning purposes, if an alternate airport is required it must
have an approved instrument approach procedure other than GPS or
RNAV that is anticipated to be operational and available at the estimated
time of arrival. All equipment required for this procedure must be installed
and operational.
 For flight planning purposes, Garmin Prediction Program part number
006-A0154-03 (with the installed antenna part number selected) should
be used to confirm the availability of RAIM for the intended flight in
accordance with the local aviation authority guidelines for TSO-C129a
equipment. WAAS NOTAMS or their absence) and generic prediction
tools do not provide an acceptable indication of availability.
Instrument approaches utilizing the GPS receiver must be conducted
in the approach mode and Receiver Autonomous Integrity Monitoring
(RAIM) must be available at the Final Approach Fix (FAF).
 During GPS approaches, the pilot must verify the Garmin GPS 500W is
operating in the approach mode. (LNAV, LNAV+V)
 When conducting approaches referenced to true North, the heading
selection on the AUX pages must be adjusted to TRUE.
 Accomplishment of an ILS, LOC, LOC-BC, LDA, SDF, MLS, VOR
approach, or any other type of approach not approved for GPS overlay,
is not authorized with GPS navigation guidance.
VNAV Information may be utilized for advisory information only.
3.26 TCAS I TRAFFIC COLLISION AVOIDANCE SYSTEM
BENDIX/KING CAS-66A


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.33
Revision: 02
Date: 04/01/2019


1. The pilot should not maneuver the aircraft based on the traffic display only.
The traffic display is intended to assist in visually locating the traffic. The
traffic display lacks the resolution necessary for use in evasive maneuvering.
3.27 WEATHER RADAR SYSTEM
PRIMUS 440 DIGITAL
WARNING: The protection inherent in the Forced Standby Mode
should not be relied upon to prevent radiation of
personnel in the vicinity of the aircraft. Do not select a
radiation mode when personnel are close to the front of
the aircraft. Before overriding the Forced Standby Mode,
insure that personnel are at least fifty feet from the 270-
degree segment centered on the nose of the aircraft.

NOTE: The Forced Standby Mode prevents microwave radiation on the
ground, which, under some circumstances, could hazard
personnel in the vicinity of the aircraft. (See related Advisory
Circular in Appendix A of P-440 Pilot’s Manual.) Depression of
the S-76C Weight-On-Wheels switch upon landing terminates
radiation of the P-440, even if a radiation mode has been
selected. The Forced Standby feature inhibits selection of a
radiation mode on the ground. When ground radiation is
necessary for system checks or weather observation, the
Forced Standby Mode can be overridden by pressing the STAB
button four times in three seconds.
3.28 INSTRUMENT MARKINGS
See Figure 3-7.
3.29 PLACARDS
"THIS HELICOPTER MUST BE OPERATED IN ACCORDANCE WITH THE
OPERATING LIMITS SPECIFIED IN THE ANAC APPROVED
ROTORCRAFT FLT MAN. THE AIRWORTHINESS LIMITATIONS SECT
OF THE ROTORCRAFT MAINTENANCE MANUAL MUST BE COMPLIED
WITH." (On instrument panel.)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.34
Revision: 02
Date: 04/01/2019


"CAUTION - TURN OFF WHITE HISL LIGHTS DURING GROUND
OPERATION OR WHEN FLYING IN FOG, MIST OR CLOUDS. STANDARD
RED ANTI-COLLISION LIGHTS MUST BE USED FOR ALL NIGHT
OPERATIONS." (On instrument panel.)
CAUTION
"WITH USABLE FUEL PER TANK INDICATING 80 LBS OR LESS, AVOID
SUSTAINED NOSE DOWN PITCH ATTITUDES IN EXCESS OF 5°." (On
instrument panel.)
"THE MAXIMUM ALLOWABLE FLOOR LOADING FOR THE BAGGAGE
COMPT. IS 75 LB. PER SQ FT. FOR WEIGHTS UP TO THE MAXIMUM
COMPARTMENT CAPACITY OF 600 LB." (On baggage compartment
doors.)
"CAUTION - NORMAL ROTOR BRAKE STOPS ARE AUTHORIZED ONLY
AT 65% Nr OR LESS WITH BOTH ENGINES SHUT OFF, OR ONE OR
BOTH ENGINES AT IDLE." (On rotor brake handle.)
Caution
"ENGINE OPERATION WITH ROTOR STOPPED LIMITED TO: BLADES
45° TO LONG AXIS." (On instrument panel).
Vne PLACARDS: See Figure 3-8. (On instrument panel.)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.35
Revision: 02
Date: 04/01/2019


Figure 3-3: Instrument Markings (sheet 1 of 4)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.36
Revision: 02
Date: 04/01/2019


Figure 3-7: Instrument Markings (sheet 2 of 4)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.37
Revision: 02
Date: 04/01/2019


Figure 3-7: Instrument Markings (sheet 3 of 4)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.38
Revision: 02
Date: 04/01/2019


Figure 3-7: Instrument Markings (sheet 4 of 4)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.39
Revision: 02
Date: 04/01/2019


Figure 3-4: Vne Placards (sheet 1 of 2)



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.40
Revision: 02
Date: 04/01/2019


Figure 3-8: Vne Placards (sheet 2 of 2)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page:3.41
Revision: 02
Date: 04/01/2019


INTENTIONALLY BLANK



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.1
Revision: 02
Date: 04/01/2019


SECTION 4.
NORMAL PROCEDURES
4.1 EXTERIOR CHECK
The pilot will determine that the following exterior preflight check has been
done before the first flight of the day or before the next flight after extended
maintenance. Those items marked with an asterisk (*) should be checked
just prior to each flight.
Pilots shall conduct a walk around before each flight, checking for obvious
leaks, inspection panels and latches for security, and for any obvious aircraft
damage and any anomalies that may affect further flight. Specifically, the
engine cowling latches and straps must be checked as secure prior to each
flight.
Following removal and proper stowage of protective plugs, tie downs, and
other associated supplementary equipment, the following check is performed
beginning at the pilot's door and proceeding clockwise around the helicopter.


Figure 4-1: S76C External Inspection (Turnaround)



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.2
Revision: 02
Date: 04/01/2019


CHECK FOR
*Pilot and Right
Cabin Doors
Proper operation fit, condition, window clean
and unscratched, condition of hinges and
latches, security of jettison handles. Ensure
keylocks unlocked (if installed) by physically
opening each door from the outside.
Cyclic Base Covers
(Boots)
Check clear of interference withcontrols
Rotor Brake Off
Nose Flotation Gear
Bottle
Proper pressure
Retractable
Boarding Step
Condition and security
Right Cabin Sliding
Door
Proper operation, condition of window and rails,
security of window jettison handle.
Main Gear Box (right
side)
Proper oil level
Oil Filter Bypass
Unpopped
Hydraulic Module -
Second Stage
Proper fluid level, filter button, no leakage
Main Rotor Servo (If
aircraft has been non-
operational for more
than 2 hours in
freezing
temperatures)
Attempt to manually move input link to forward
main rotor servo. Input link should move freely
with no restrictions approximately ¼-inch.
Main Rotor Head
General condition
Main Rotor Blades
General condition: tip cap for condition and
security; blade upper and lower surfaces for
raised skin indicative of disbond. Rotate the
rotor system as required to view all blade
surfaces and tip caps.
CAUTION: Normal engines use a minimal amount of oil. Any sudden
increase in oil consumption is indicative of oil system
problems that must be corrected.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.3
Revision: 02
Date: 04/01/2019


CHECK FOR
Engine Oil
Reservoirs
Proper fluid level; if low and engine has been
stopped more than 15 minutes, motor engine 30
seconds and recheck. Ensure filler cap secure.
Engine Area
General condition of engine. Check all
accessible areas for obvious loose bolts, broken
or loose connections, security of mounting
accessories, broken or missing safeties, and
evidence of fuel and/or oil leakage.
*Inlet/Barrier Filter
Damage and security. Must be free of
accumulated debris, snow, ice, slush, etc.
*Fuel Filler Cap Fuel level, cap secure
*Baggage
Compartment
Contents, fuel leakage, door secure
*Electrical
Compartment
Access
Panel secure
Main Landing Gear
Compartment
Tire condition and inflation, strut extension, door
and gear actuator rods properly attached and
undamaged, condition of flotation bag sharp
edge protection, fluid leakage, elastomeric
bearing condition.
*Tiedown ring
Tiedown ring stowed in a position from flat
against shock strut to end of ring no more than
0.25 inches from strut.
CAUTION: Tiedown rings that are not stowed flat may lead to failure
of the landing gear to retract or extend.
CHECK FOR
*Downlock pin
Downlock pin removed.
Flotation Gear
Bags for proper storage, covers for condition
and security, bottles for proper pressure.
Fluid Drains and
Vents
Leakage


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.4
Revision: 02
Date: 04/01/2019


CHECK FOR
Oil Cooler Blower
Duct
Obstructions
Engine Fire Bottle Proper pressure
Antennas
Damage, corrosion, security
Tail Cone Static
Ports
Clear of soot and obstructions
Pylon Skin and
Fairings
General condition
Horizontal Stabilizer
General condition. Check that the attachment is
tight and that there is no movement (play) in any
direction
Side Position Light
Cracked or broken lens
Lower Surface of
Intermediate Gear
Box Fairing
Scrapes and condition
*Intermediate Gear
Box
Proper oil level, cooling inlet clear
Tail Rotor Head
General condition
Tail Rotor Blades
General condition
*Tail Rotor Gear Box
Proper oil level
Anti-collision and
Position Light
Cracked or broken lenses
Pylon Skin and
Fairings (Left Side)
General condition
Horizontal Stabilizer
General condition, IGB cooling inlet clear
Side Position Light
Cracked or broken lens
Antennas
Damage, corrosion, security
Tail Cone Static
Ports
Clear of soot and obstructions
Tail Cone Access
Panel
Security, condition
Engine Fire Bottle
Proper pressure


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.5
Revision: 02
Date: 04/01/2019


CHECK FOR
Oil Cooler Blower
Duct
Obstructions
Main Landing Gear
Compartment
Tire condition and inflation, strut extension door
and gear actuator rods properly attached and
undamaged, condition of flotation bag sharp
edge protection, fluid leakage, elastomeric
bearing condition.
*Tiedown ring
Tiedown ring stowed in a position from flat
against shock strut to end of ring no more than
0.25 inches from strut.
CAUTION: Tiedown rings that are not stowed flat may lead to failure
of the landing gear to retract or extend.
CHECK FOR
*Downlock pin
Downlock pin removed.
Flotation Gear
Bags for proper storage, covers for condition
and security, bottles for proper pressure.
Fluid Drains and
Vents
Leakage
Fuel Sump Drain
Drain - Check for water and visible
contaminants. Adequate water drainage is
provided only with the helicopter approximately
level (less than 3° nose up or down).
*Baggage
Compartment
Contents, fuel leakage, door secure
*Fuel Filler Cap
Fuel level, cap secure
Thermal Relief
Indicator Button
Unpopped
Engine Area
General condition of engine. Check all
accessible areas for obvious loose bolts, broken
or loose connections, security of mounting
accessories, broken or missing safeties, and
evidence of fuel and/or oil leakage.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.6
Revision: 02
Date: 04/01/2019


CHECK FOR
Oil and Fuel Filter
Bypasses Engine 1
Unpopped
Oil and Fuel Filter
Bypasses Engine 2
Unpopped
NOTE: It is possible for the impending oil filter bypass indicator to
extend during a start of a cold soaked engine, giving an
erroneous indication of a dirty oil filter. If the impending filter
bypass indicator is extended, run the engine until the oil is at
operating temperature and push the indicator button in. If the
button remains in throughout the normal speed range of the
engine, the filter does not require cleaning.
CHECK FOR
*Inlet/Barrier Filter
Damage and security. Must be free of
accumulated debris, snow, ice, slush, etc.
Main Rotor Head
General condition
Hydraulic Module -
First Stage
Proper fluid level, filter button, no leakage.
Main Rotor Servo (If
aircraft has been non-
operational for more
than 2 hours in
freezing
temperatures)
Attempt to manually move input link to Lateral
and Aft Main Rotor Servos.
Input link should move freely with no restrictions
approximately ¼ inch.
Rotor Brake
Accumulator
Proper fluid level, leakage
WARNING: Specifically check the security of the aft engine cowl
latches and straps just prior to each flight.
CHECK FOR
*All Engine and
Transmission Doors
and Cowls
Condition, security including hinges, latches,
camlocs, and straps.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.7
Revision: 02
Date: 04/01/2019


CHECK FOR
Left Cabin Sliding
Door
Proper operation, condition of window and
sliding rails, security of window jettison handle.
Retractable
Boarding Step
Condition and security
*Copilot and Left
Cabin Doors
Proper operation, fit, condition, window clean
and unscratched, condition of hinges and
latches, security of jettison handles. Ensure
keylocks unlocked (if installed) by physically
opening each door from the outside.
*Nose Gear Lockpin
(copilot's side of
console)
Removed
OEI Training Switch
OFF
*Copilot Seat Belt
Security, if seat is to be unoccupied.
Nose Flotation Gear
Bottle
Proper pressure
Electrical
Compartment
Panels closed
Windscreen Washer
Fluid level
Windscreen
Glass clean and unscratched
Windshield Wipers
Clean, wear, condition
T0 Sensor
Clean, free of obstructions
Nose Gear
CompartmentTire inflation, strut extension, doors and gear
actuator rods properly attached.
Battery Vents (if
equipped)
Free of obstructions
Nose Flotation Gear
Panels
Condition
Pitot Tubes
Covers removed, free of obstructions
Searchlight or
Landing Light
Lens damage, proper stowage


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.8
Revision: 02
Date: 04/01/2019


CHECK FOR
Emergency Blow
Down Bottle
Proper pressure
OAT Source
Free of obstructions
Main Rotor Free to turn; walk rotor through 90° to next 45°
position, as necessary.
4.2 INTERIOR CHECK
The weight and balance for takeoff and anticipated landing gross
weight should be determined before takeoff and checked against the
Loading Information contained in RFM Part 2, and Part 1, Operating
Limitations.
NOTE: Throughout the remainder of Section II, checks marked with a
plus symbol (+) are required only before the first flight of each
day. All other checks should be done before each flight.
CHECK FOR
Passenger briefing
Performed.
 General passenger briefing items are specified in MGO.

CHECK FOR
Cabin exits
Secure, locked, and accessible
Cargo
Secure.
Fire extinguishers
Charged and secure
First aid kit
Sealed and secure
Emergency locator
transmitter
Secure, antennas connected, switch to ARM.
Required aircraft
documents checked
- Flight and Technical Log;
- Flight Manual;
- MEL;
- Operations Specifications;
- Emergency Response Plan;


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.9
Revision: 02
Date: 04/01/2019


CHECK FOR
- Dispatch Release;
- Balance Manifest;
- Navigation Charts;
- Airworthiness Certificate;
- Registration Certificate;
- Weight and Balance Sheet;
4.3 BEFORE FIRST FLIGHT OF THE DAY
Before the first flight of the day, pilots should perform the following
procedures (these procedures should be done after the external checks).
OVERHEAD PANEL
Fire T Handles / Switch .................................................................. FWD/OFF
On overhead control panel verify if T Handles are in forward position and
if the FIRE EXT RESERVE-OFF-MAIN sw is in OFF position.
Search and Landing Light ....................................................................... OFF
On the copilot upper overhead switch panel verify if the SEARCH LT ON-
OFF-STOW sw is in OFF position and if the LAND LT OFF-ON sw is in
OFF position.
Emergency and HEELS Lights ................................................... TEST / OFF
Move HEELS “ON-OFF-ARM” switch though each position. Confirm the
HEELS lighting illuminates when switch is in the ON position and is
extinguished in the OFF and ARM positions.
Place switch in ARM position for flight.
Passenger Advisory Light ........................................................... TEST / OFF
On copilot overhead switch panel move the PASS ADV sw to FSB/NS
position, and then verify if the NO SMOKING and FAST SEAT BELT lights
go on. Passenger sign in cabin shall go on.
After the test move back the sw to OFF position.
Air Conditioner ........................................................................................ OFF
On the air conditioning control panel verify if AIR COND OFF/FAN sw is
in OFF position.
Life Raft Deployment System ............................................................ CHECK


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.10
Revision: 02
Date: 04/01/2019


A. Check that the break-a-way wire securing the DEPLOYMENT
HANDLE is in place and the handle is in stowed and secured position.
B. Remove the pin from the deployment handle prior to over water flight.
C. Ensure that the Ground Servicing Safety Pins are NOT fitted though
the cabin floor inboard of the cabin door forward posts or cockpit
deployment handle.
System Check Complete.
Heater Control Panel .............................................................................. OFF
On overhead control panel verify if the BLEED OFF/ON and BLOWER
OFF/ON switches are in OFF position.
Verify if the HEATER rotate knob is in OFF position and the TEMP CONT
rotate knob is in minimum position.
Fire Extinguisher Switch ...................................................................... NORM
On the after overhead switch panel, verify if EXT-FIRE
SHORT/OPEN/NORM sw is in NORM position and if the TEST DET AFT
BAG/NORM/FWD sw is in NORM position.
Prime Switches ....................................................................................... OFF
On the after overhead switch panel, verify if the No 1 ENG PRIME-OFF
and No 2 ENG PRIME-OFF switches are in OFF position.
Manual Reversion Switch ..................................................................... AUTO
On the after overhead switch panel, verify if the ENGINE CONTROL No
1 MAN-AUTO-No 2 MAN sw is in AUTO position.
Rotor Brake ........................................................................................... TEST
A. Rotor Brake handle ........................................ OFF, handle in detent
B. Check Rotor Brake Light ............................... OFF
C. Apply 2 Strokes, Check Rotor Brake Light .... ON AND 200 PSI
MINIMUM PRESSURE
D. For rotor brake off Start ................................. Release and check light
OFF within 3 seconds.
System Check Complete.
Autopilots C/B Panel ..................................................................... CHECK IN
On overhead C/B panel, verify all C/B IN.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.11
Revision: 02
Date: 04/01/2019


Anti-Ice / Windshield Panel ..................................................................... OFF
On pilot lower overhead switch panel:
Verify if the ENG ANTI-ICE No 1 and No 2 switches are in OFF position;
Verify if the WSHLD WIPER, WASH and HEAT switches are in OFF
position.
Standby Att Test ................................................................................... TEST
A. External Power and Battery. .......................... OFF
B. SBY ATT Switch ............................................ OFF
SBY ATT and BAT TEST Legends are OFF
C. SBY ATT Switch ............................................ DEPRESS
The SBY ATT and ON legends (on the SBY ATT switch) illuminate. The
Alarm OFF legend (on the BAT TEST switch) illuminates. The alarm tone
sounds. The OFF flag pulls out of view after the gyro spins up. Standby
Attitude indicator back lighting is on.
D. BAT TEST Switch .......................................... DEPRESS and HOLD
for 5 seconds
Alarm ceases. SBY ATT and ON legends extinguish. The GOOD legend
on the battery switch illuminates, indicating at least 75 % battery charge.
E. BAT TEST Switch .......................................... RELEASE
SBY ATT and ON legends illuminate. The GOOD legend extinguishes.
F. SBY ATT Switch. ........................................... DEPRESS
All legends and the instrument lighting extinguish. The OFF flag appears.
System Check Complete.
OEI Training ............................................................................................ OFF
On copilot instrument panel, open the access door and verify if the DUAL
ENG TRAIN LIM sw is in OFF position.
Aux Fuel Panel...................................................................................... SHUT
On AUX Fuel Panel verify if OPEN-SHUT sw is in SHUT position and
confirm the valve position on position indicator located near the switch.
Check fuel quantity on indicator and compare against planned fuel to
auxiliary tank.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S76C
Page: 4.12
Revision: 02
Date: 04/01/2019


Ext. Power ..................................................................................... OFF or ON
When sufficient battery power may not be available use external power.
On Pilot’s Upper Switch Panel place the EXT PWR OFF/ON sw in ON
position.
Before place the EXT PWR OFF/ON sw in ON position observe if the EXT
PWR yellow light is illuminate on Center Console.
Battery Switch ........................................................................................... ON
On pilot’s overhead switch panel place the BATT OFF-ON sw in ON
position.
Observe IIDS Self-Test (PAST or FAIL). Wait until the end of test before
engaging other switches, about 10 seconds.
NOTE: If Engine Control Lever are not in the STOP position when
power is applied to the aircraft, a DECU Total fault will be
displayed until the engine control levers are placed in STOP.
Observe the fuel quantity and compare against the planned fuel.
Select IIDS menu and then the ELEC page to check battery voltage
(above 20v).
Press IIDS menu for 3 seconds and observe if the fuel tanks are
balanced.
Fire Det. Test Switch ............................................................. FWD/AFT-BAG
A. Fire Detector Test Switch .............................. FWD
B. FIRE warning lights and T-handle lights should light and continuous
tone, 250 Hz, should be heard.
C. Press FIRE warning light capsules to reset tone. (PF)
D. Fire Detector Test Switch .............................. NORMAL
E. All FIRE warning lights off.
F. FIRE Detector Test Switch ............................ AFT/BAG
G. FIRE warning lights and T-handle lights should light and continuous
tone, 250 Hz, should heard.
NOTE: If external power is in use, the AFT BAG SMOK warning light
will go on.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.13
Revision: 02
Date: 04/01/2019


H. Press FIRE warning light capsules to reset tone. (PM)
I. Fire Detector Test Switch .............................. NORMAL
J. ALL FIRE warning lights off.
System Check Complete.
CENTRE CONSOLE
Circuit Breakers ................................................................................... ALL IN
On Upper and Lower Circuit Breaker Panels check no breakers popped
out with white circular ring in evidence.
Utility Flood Light ............................................................................... CHECK
A push-button switch and rheostat control are located on the rear of the
light. The push-button turns on the light when the switch is held in. The
rotating rheostat is used to adjust the brightness of the light.
Bypass Switches ............................................................................. NORMAL
On center console verify if EFIS BYPASS CPLT and PLT switches are in
NORM position.
CVR / FDR ............................................................................................ TEST
A. Test Button .................................................... DEPRESS
Check Light ......................................................... ON
B. Test Button .................................................... RELEASE
Check .................................................................. 35 seconds light out
System Check Complete.
ELT ....................................................................................................... TEST
Caution: To prevent inadvertent deployment, verify that the safety
strap is fitted to the beacon carrier, the left-hand beacon
switch is set to off, and that the Control Panel switches
are both set to off.
A. Cockpit Control Panel Check.
a) Ensure that the control panel ARMING switch, DPLY
ARM_OFF_XMT ARM is in the OFF position (CENTER).


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.14
Revision: 02
Date: 04/01/2019


b) Ensure that control panel OPERATE switch DEPL OFF-XMT/RST is
in the OFF position (CENTER).
c) With reference to the aircraft maintenance manual apply power to
the aircraft.
d) Ensure ADELT circuit breaker is set.
e) Check the Control Panel Illumination.
f) Check the Control Panel D`PLY/XMT light is NOT illuminated.
If continuously illuminated report to maintenance for correction:
If flashing, immediately follow CPT-900 deactivation procedure.
g) Check the control panel FR SW light is NOT illuminated, report to
maintenance for correction.
h) Check the control panel BATTERY light is NOT illuminated.
i) Check the control panel SQUIB light is NOT illuminated.
j) Check the aircraft IIDS ÄDELT SAFE” caption is ON.
k) Press the momentary press to “TEST” button on the cockpit control
panel and observe the led lights.
 “SQUIB” Green L.E.D. will illuminate if the cartridge is
serviceable.
 “BATTERY” Green L.E.D. will illuminate if the deployment battery
is available.
 FR/SW Red L.E.D. will illuminate if this indicator is serviceable.
 “D`PLYD/XMT will illuminate if the indicator is serviceable.
l) Release the “TEST” button and ensure that the lights illuminated in
step K) extinguish.
WARNING: Deployment must not be carried out on the ground.
 When the aircraft is not at operational readiness, a
SAFETY STRAP HOOKED to the carrier prevents
damage and injury in the event of accidental
deployment.
 Ground crew alert of activation is provided by an
audible sounder with the CPT-900 beacon.
System check complete.
Instrument Light ...................................................................................... OFF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.15
Revision: 02
Date: 04/01/2019


On lower console panel, verify if the FLT INST Lts rheostats (CPLT, PLT,
NON FLT, GLR SHLD and LWR CNSL) are in OFF position. For night
flights adjust as required
Eng Failure Warning System ................................................................ TEST
A. #1 and #2 ENG.OUT Warning lights ............. ON
B. Engine Out Ground Test Switch.
C. (Side of Console) ........................................... HOLD IN TEST
Check 550 Hz and 700 Hz Tone Alternate
D. Press ENGINE OUT warning capsules to reset tone.
Warning lights will remain on.
E. Engine Out Ground Test Switch .................... OFF(RELEASE)
System checks Complete.
Zapper Pulse Chip Det ......................................................................... TEST
A. CHIP DET TEST Switch ................................. TEST
B. IIDS 1ENG CHIP and 2ENG CHIP Caution LightsON
C. 1 ENG CHIP/2 ENG CHIP CB`s .................... PULL/RESET
D. IIDS 1ENG CHIP and 2ENG CHIP Caution Lights……….…..OFF
E. TEST .............................................................. COMPLETE
ESS BUS Recovery Switch .................................................................... OFF
Landing Gear Handle .......................................................................... DOWN
Verify if the LDG Handle is in DN position with three LDG GEAR green
lights high illuminates and the UNLKD red light extinguish.
Emergency Gear T-Handle .......................................................... IN / WIRED
Verify if EMER DN TURN & PULL T-Handle is wired.
Landing Gear Warning .......................................................................... TEST
Push the LDG GEAR UP PUSH TO RESET push button (pilot or copilot
side) and verify if the LDG GEAR UP PUSH TO RESET push button lights
illuminate on both sides.
Perform this test during preflight or other time when warning are not
active.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.16
Revision: 02
Date: 04/01/2019


A. Press and hold either LDG GEAR UP annunciator.B. If annunciator flashes and pulsed warning tone, 250 Hz, is heard,
system is operative.
C. If annunciator is on steady and no warning tone, ARINC 429 air data
input has failed. In this case the 60 KIAS warning not function.
INSTRUMENT PANEL
IIDS / Warning Lights ......................................................................... CHECK
A. IIDS REV Button………………………………….……PRESS 3 TIMES
(Observe displays rotation anticlockwise)
B. Test Button on IIDS Display………………………..PRESS, HOLD
(Note: It`s not possible to check the LHP performance display until #2 DC
PRIMARY is powered. All gauges will go from to top. If test fails FAIL will
be indicated.)
These additional lights should also be illuminated:
a) Master warning indicator.
b) Engine control lights, press to dim
c) Landing gear unlock
d) Fire Extinguisher test
e) Float panel Test (if installed)
f) OEI TRNG light
C. Return Engine Display to Center position
BV / Over Speed Lights ............................................................................ ON
On the IIDS observe if a green “BV” indication for each engine is
displayed above the N1 column and if a yellow “O/S” indication for each
engine is displayed above N2 column.
Engine Instruments ........................................................... CHECK/NORMAL
On the IIDS observe if all engine parameters are within normal range.
Fuel System / Quantity ...................................................................... CHECK
On the IIDS press MENU button for 3 seconds and verify enough fuel
quantity for intended flight (on Engine screen). Observe if the fuel tanks
are balanced too.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.17
Revision: 02
Date: 04/01/2019


Battery Voltage ................................................................ ABOVE 22 VOLTS
On the IIDS press MENU button and ELEC soft key (on Engine screen)
to present the volt/ammeter page. Check the battery voltage is above 22
volts.
Radar ...................................................................................................... OFF
Float Test Panel .............................................................................. NORMAL
On Float Test Panel verify if the FLOAT TEST/NORM sw is on NORM
position.
GEN / OVSP Test Switches ............................................... OFF/CENTERED
On Test Panel verify all switches on OFF position (centered).
Cycles Count......................................................................................... NOTE
On the IIDS press MENU button and MAINT soft key on Performance
screen to provide access to additional soft key CYCLE COUNT.
Press CYCLE COUNT soft key and take note of the information displayed
on flight log book.
Clocks ...................................................................................................... SET
Adjust the correct local time.
Ext. Power ............................................................................................... OFF
Battery ..................................................................................................... OFF
Cabin Equipment ........................................................................ ON BOARD
Verify if the following equipment is on board: Flashlights, First aid kit, Life
raft and Life vest.
REMARK: BEFORE FIRST FLIGHT OF THE DAY CHECKS are to be
performed either by the PIC or SIC.
4.4 BEFORE START
Parking Brake .............................................................................. RESET/ON
To set the parking brakes press pedals, pull up on brake handle, and
then release pedals.
Before First Flight Check ............................................................ COMPLETE
Make sure that First Flight Check was performed previously.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.18
Revision: 02
Date: 04/01/2019


Pins (Off Shore “6”)/Plugs/Chocks/ELT Safety Strap .................. REMOVED
Verify if all pin, plugs, safety straps and chocks were removed and
stocked correctly.
Battery Switch ........................................................................................... ON
NOTE: If Engine Control Lever are not in the STOP position when
power is applied to the aircraft, a DECU fault will be displayed
until the engine control levers are placed in STOP.
Ext. Power .................................................................................................. AR
(If available) On Pilot’s Upper Switch Panel place the EXT PWR
OFF/ON sw in ON position.
Master Start .............................................................................................. ON
On Pilot’s Upper Switch Panel place the MASTER START OFF/ON sw
in ON position.
DC / AC Generator ................................................................................... ON
On Pilot’s Upper Switch Panel place the GEN DC1 and DC2
RESET/OFF/ON switches in ON
If AC generator is installed, place the GEN AC TEST/OFF/ON sw in ON
position.
Inverters .................................................................................................. OFF
On Pilot’s Upper Switch Panel verify if INVERTERS No 1 and No 2
OFF/ON switches are on OFF position.
Anti-collision/ Pos Light ...................................................................... ON/ AR
On the copilot upper overhead switch panel place ANTI COLL
TOP/OFF/BOTH sw in TOP position and STROBE/POS POS-OFF-
BOTH sw in POS position.
PASS ADV lights ....................................................................................... AR
On the copilot upper overhead switch panel place PASS ADV FSB/NS-
OFF-FSB in FSB/NS position.
Levers ................................................................ OFF / X FEED / FORWARD
On Engine Control Quadrant verify if the No 1 and No 2 ENG Control
Levers are in STOP position.
Place the No1 and N2 ENG Fuel Levers on XFEED position.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.19
Revision: 02
Date: 04/01/2019


Verify if the ENG 1 and ENG 2 EMERG T Handles are in forward
position.
Heater / Air Conditioner .......................................................................... OFF
On Heater Control Panel verify if BLEED OFF/ON sw is in OFF position
and if BLOWER OFF/ON sw is in OFF position.
C/B Panel ...................................................................................... CHECK IN
On Circuit Brake Panel check no breakers popped out with white
circular ring in evidence.
Stick Trims ................................................................................................ ON
On Lower Center Console observe if the STICK TRIM CLTV, CYCLE,
and YAW Master switches are with “ON” green lights lit.
Compass Control Switch .................................................................... SLAVE
On Compass Control Panel verify if both SLAVE/FREE switches are in
SLAVE position.
Instruments Lights ................................................................... AR(BRT/DIM)
Adjust as required.
Collective Switch ......................................................................... CENTERED
On both collectives verify if the SERVO No 1/No2 switches are
centered.
DECU ......................................................................................... NO FAULTS
Press DECU FAULT switch and on IIDS check for present Total,
Degraded or Minor fault.
NOTE: Any DECU faults shown as previous flight status (shown in
white versus magenta) will be erased during engine start.
Essential Bus Recovery Switch .............................................................. OFF
On the right vertical side panelof the center console verify if the ESS
BUS RCVRY sw is in OFF position.
30 Seconds OEI Lights ........................................................................... OFF
On the IIDS observe if a upper green 30 seconds light is displayed
above the N1 column.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.20
Revision: 02
Date: 04/01/2019


BV/ Over Speed Lights ............................................................................. ON
On the IIDS observe if a green “BV” indication for each engine is
displayed above the N1 column and if a yellow “O/S” indication for each
engine is displayed above N2 column.
FUEL ............................................................................... QUANTITY CHECK
On the IIDS press MENU button for 3 seconds and verify enough fuel
quantity for intended flight. Observe if the fuel tanks are balanced too.
Stand by Attitude Indicator ........................................ ARM / BATTERY TEST
With all power off, press SBY ATT switch - SBY ATT and ON on the
SBY ATT switch and BATT TEST ALRM OFF on the BATT TEST switch
will illuminate, the alarm will sound, the attitude gyro will start to spin up,
and its flag will disappear.
BATT TEST switch - Press and hold for five seconds. The alarm will
stop. All legends on the SBY ATT switch will extinguish. GOOD on the
battery test switch will illuminate.
BATT TEST switch - Release after five seconds. GOOD on the BATT
TEST switch will extinguish and SBY ATT and ON on the SBY ATT
switch will illuminate.
Turn on aircraft power (battery or external). SBY ATT switch should
continue to annunciate ON.
Cage/uncage attitude indicator as necessary. Check PULL TO CAGE
knob – In.
Attitude indicator OFF flag – Retracted.
Vary the pilot’s instrument dimmer and verify the standby attitude
indicator lighting varies accordingly and tracks with the other pilot press
instruments. Turn the pilot’s instrument dimmer all the way down. Verify
the standby attitude indicator lighting is off.
Aux Fuel Panel...................................................................................... SHUT
On AUX FUEL Panel verify if the OPEN/SHUT sw is in SHUT position.
ATIS .................................................................................................. INF____
Copilot sets the ATIS frequency on VHF 2 and receives the ATIS
information.
Start Clearance ............................................................................... RECEIVE
SIC receives start engine clearance from tower or ground control.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.21
Revision: 02
Date: 04/01/2019



4.4.1 BEFORE START CHECKLIST
Challenger Response Performed
By
Parking Brake RESET/ON RSP
Before First Flight Check COMPLETE PF
Pins(offShore“6”)/Plugs/Chocks/ELT
Safety Strap.
REMOVED RSP/LFP
Battery Switch ON RSP
Ext. Power AR RSP
Master Start ON RSP
DC / AC Generator ON RSP
Inverters OFF RSP
Anti-collision/ Pos Light ON/ AR LSP
PASS ADV lights ON LSP
Levers OFF/XFEED/FORWARD PF
Heater / Air Conditioner OFF LSP
C/B Panel CHECK IN PF
Stick Trims ON PF
Compass Control Switch SLAVE PF
Instruments Lights AR(BRT/DIM) PF
Collective Switch CENTERED RSP/LSP
DECU NO FAULTS PF
Essential Bus Recovery
Switch
OFF RSP
30 Seconds OEI Lights OFF PF
BV/ Over Speed Lights ON PF
FUEL QUANTITY CHECK PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.22
Revision: 02
Date: 04/01/2019


Challenger Response Performed
By
Stand by Attitude Indicator ARM / BATTERY TEST PF
Aux Fuel Panel SHUT LSP
ATIS INF____ PM
Start Clearance RECEIVE / AR PM
4.5 STARTING ENGINES
Rotor Brake ................................................................................... OFF or ON
The normal procedure is rotor brake in OFF position.
Verify Rotor Brake handle in OFF position (handle in detent). Check
ROTOR BRAKE Caution light off.
When necessary (wind more than 25 kt) or at PIC’s discretion, move the
Rotor Brake handle to ON position. Normally 2 strokes will be required
to achieve the minimum pressure of 200 psi. Check ROTOR BRAKE
Caution light on and pressure gage for at least 200 psi.
CAUTION: Rotor brake limits are as follows: With blades positioned
45° to the longitudinal axis and rotor brake applied in
accordance with procedures, one or two engines may be
started and run at idle without time limitation.
 Engine operation with cowling open or unlatched is
prohibited.
 If rotor should begin to turn during start with the rotor
brake on, shut down the engine(s) or release the rotor
brake. See Emergency Procedures for details.
Radio Master Switch ............................................................................... OFF
Area / Fire Guard ............................................................ CLEAR/GUARDED
Prior to start engine make sure if the area is clear and where a fire
guard is required ensure the fire guard is present.
WARNING: Passengers and crewmembers should not be allowed
to approach or depart the helicopter directly from the
front because of rotor clearance, especially at low rpm
and with gusty wind conditions.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.23
Revision: 02
Date: 04/01/2019


Start Briefing ............................................................................... COMPLETE
START BRIEFING EXAMPLE:
Today we’ll start ENG #1. We are going to abort in case of hang start, hot start
or engine fire. In case of fire, identify, combat fire, rotor break and evacuate to
the right.
Do you have any questions?
Start First Engine ........................................................................ COMPLETE
Engine lever ........................................................ IDLE detent
Starter button ...................................................... Press and release
Observe increasing N1, check that the DECU controls T5…..Monitor
limits
Engine will automatically shut down if T5 reaches 840º but this does not
prevent the pilot from abort the start if the rate of T5 increase is
excessive
Oil pressure…………………………………Above 24 psi warning light off
Engine oil temperature ....................................... Check

NOTE:
 At idle, 48 to 52% N1, check No. 1 DC GEN caution light off
(confirmation of starter dropout).
 The duration of a normal start is 15 to 30 seconds.
 When starting with rotor brake off, check that overspeed caution light
goes off with N2 greater than 25%. Overspeed system warning light will
remain on with rotor brake on.

When necessary to abort a start engine:
The start is aborted by depressing the trigger and retarding the engine
lever to STOP. Consider motoring the engine if T5 fails to decrease
normally. If an abort is performed at ambient temperatures below –10°C,
motor the engine to achieve a T5 of 130°C or colder before attempting a
subsequent start.
Starter limits


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.24
Revision: 02
Date: 04/01/2019


Starter use limits vary depending on whether or not fuel ignition (light-off)
occurs in the engine.
 With fuel ignition, the starter limits are:
 60 second start ON………..60 second interval;
 60 second start ON………..15 minute interval. Repeat cycle.
 Without fuel ignition the limits are
 30 second ON………………30 second interval;
 30 second ON………………15 minute interval. Repeat cycle.
Engine instruments ......................................................... CHECK / NORMAL
On the IIDS observe if all engine parameters are within normal range.
ExternalPower........................................................ OFF / DISCONNECTED
On Pilot’s Upper Switch Panel place the EXT PWR OFF/ON sw in OFF
position.
Request maintenance personnel to remove the EXT PWR and observe
if the EXT PWR yellow light is extinguished on Center Console.
Rotor Brake (If ON, Release) ................................... RELEASE / LIGHT OFF
Pull the handle backward. Ensure that the brake handle is in detent
(OFF position). This will ensure activation of the pressure release valve.
Check that within 3 seconds the ROTOR BRAKE Caution light is
extinguished and system pressure on the gauge is 0 psi.
Over Speed Light .................................................................................... OUT
Check if overspeed warning light goes off when N2 exceeds 25%.
Transmission Oil / Hydraulic System ................................................. CHECK
Check IIDS for normal range, MGB PRESS warning light and SERVO
SYS caution lights Off.
First Engine ........................................................................................ 70% N1
Engine lever - Move forward towards FLY (70% N1) while positioning
cyclic to minimize droop stop interference.
NR ...................................................................................................... 65-70%
Observe 65 to 70% NR
# Flight Control Servo System & Stick Jump ........................................ TEST


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.25
Revision: 02
Date: 04/01/2019


A. Collective ........................................................ 65% to 70% NR / Full
down
Observe droop stops out.
CAUTION: If flight controls do not respond correctly or a restriction
in control motion is evident during operation on either
isolated hydraulic system, move servo switch to center
(both ON) and proceed with shutdown.
 Do not move flight control servo switch from ON during
flight, except in case of emergency where it is necessary
to turn off a malfunctioning servo stage
Move all flight controls through a displacement of 1 inch from trimmed
position, checking for binding or roughness. Observe tip-path plane for
proper response.
B. RH Pilot SERVOS sw ..................................... No 1 OFF
Place RH Pilot SERVOS sw to No 1 OFF position. Note that No 1
SERVO SYS caution light goes on immediately. There should be no
jump in controls. Check flight controls as above.
C. RH Pilot SERVOS sw .................................... No 2 OFF
Place rapidly RH Pilot SERVOS sw to No 2 OFF position. Note that No
1 SERVO SYS caution light goes off and No 2 SERVO SYS caution
light goes on immediately. There should be no jump in controls. Check
flight controls as above
D. RH Pilot SERVOS sw .................................... ON / centered
Place RH Pilot SERVOS sw centered. Both servo pressures normal and
both caution lights off
IIDS Electrical Page ......................................................................... 100 Amp
On the IIDS press MENU button and ELEC soft key (on Engine screen)
to present the volt/ammeter page. Check DC AMPS below 100 Amp.
Start Second Engine ................................................................... COMPLETE
START 2nd ENGINE BRIEFING EXAMPLE:
Standard briefing, however shutting the other engine off before applying rotor
break.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.26
Revision: 02
Date: 04/01/2019


Proceed as the first engine.
Over Speed Light .................................................................................... OUT
Check if overspeed warning light goes off when N2 exceeds 25%.
Second Engine................................................................................... 70% N1
Engine lever - Move forward towards FLY (70% N1).
Aux Fuel Panel...................................................................................... SHUT
On AUX FUEL Panel place the OPEN/SHUT sw in OPEN position and
check transfer fuel indication.
Place back the OPEN/SHUT sw in SHUT position.
GPS .......................................................................................................... ON
Turning on and observe the unit performs the seft-test.
When the database confirmation page appear check the current
database information.

4.5.1 STARTING ENGINES CHECKLIST
Challenger Response Performed By
Rotor Brake OFF or ON RSP
Radio Master Switch OFF RSP
Area / Fire Guard CLEAR/GUARDED RSP/LSP
Start Briefing COMPLETE PF
Start First Engine COMPLETE PF
Engine instruments CHECK / NORMAL PF
External Power OFF / DISCONNECTED RSP
Rotor Brake (If ON,
Release)
3 SEC LIGHT OUT RSP
Over Speed Light OUT PF
Transmission Oil /
Hydraulic System
CHECK PF
First Engine 70% N1 PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.27
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
NR 65-70% PF
Flight Control Servo
System
TEST PF/PM
Stick Jump TEST PF
IIDS Electrical Page 100 Amp. PM
Start Second Engine COMPLETE PF
Over Speed Light OUT PF
Second Engine 70% N1 PF
GPS ON PM
4.6 AFTER START
Engine instruments ......................................................... CHECK / NORMAL
On the IIDS observe if all engine parameters are within normal range.
Fuel Levers ....................................................................................... DIRECT
Place the No1 and N2 ENG Fuel Levers on DIRECT position.
Inverters .................................................................................................... ON
On Pilot’s Overhead Upper Switch Panel place INVERTERS No 1 and
No 2 OFF/ON switches in ON position.
Heater / Air Conditioner ............................................................ AS DESIRED
On Copilot’s Overhead Switch Panel place AIR COND OFF/FAN sw in
FAN position and HI/FAN/LO sw as desired.
Keep heater in OFF position.
Note: Activate the air conditioning system only when both
generators are operating. Do not retard the No 2 engine to idle
with the air conditioning system on, due to the heavy
generator loading.
 Engine ground operations below 70% of N1 with air
conditioner ON may cause loss of avionics systems.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.28
Revision: 02
Date: 04/01/2019


Smoke Detector Baggage ..............................................................AFT TEST
Fire detector test switch ........................................... AFT/BAG.
The AFT BAG SMOK warning light on the IIDS should illuminate. Also,
fire warning lights and T-handle lights should illuminate and continuous
tone should be heard.
Return fire detector test switch to NORM. All fire lights will go off.
NOTE: If a fire should occur in the baggage compartment, only the
AFT BAG SMOK warning light will go on. (The continuous tone
will not be heard.)
Emergency and HEELS Lights .......................................................... ARMED
On Copilot’s Overhead Panel place the EMER LTS ON/OFF/ARM sw
and HEELS ON/OFF/ARM sw in ARM position.
EMS Power sw........................................................................................... AR
Only for Emergency Medical Service Helicopters:
Place the EMS power sw in ON position. See OMNI’s EMS Helicopters
Operations Manual (Manual Aeromédico).
EFIS /Radio Master .................................................................................. ON
Verify RADIO MASTER sw on NORM position and the BYPASS
switches (EFIS MASTER 1 and EFIS MASTER 2) on NORM position.
Radar ....................................................................................................STBY
Place Radar in STBY
# N1 ...................................................................................................... TEST
With flat collective pitch, steady - stat engine conditions compare upper
N1 indication to lower N1 indication as follows:
A. IIDS Performance Display Menu .................... PRESS
B. N1 Test ........................................................... SELECT
C. N1 Test ........................................................... PRESS
(Check that the digital N1 test values are within 0,2% N1 of the normal
IIDS digital display. N1 TEST times out in 8 seconds.)
System check completed


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.29
Revision: 02
Date: 04/01/2019


# EFIS ................................................................................................... TEST
A. EFIS display controller ................................... PRESS TEST BUTTON
B. ALL Flags ....................................................... CHECK
C. FD annunciation light ..................................... ILLUMINATED
D. Check comparator warnings .......................... ATT/HDG/ADC/RA ON
Check “PASS” message.
System Check completed
# AHRS ................................................................................................. TEST
A. Test Button ..................................................... PRESS AND HOLD
Check:
a) Pitch +5 nose up.
b) Roll +45 right wing down.
c) HSI heading 015 degrees.
d) ROT right turn.
B. Test Button ..................................................... RELEASE
System Check completed
NOTE: This test is inhibited in flight.
# EGPWS .............................................................................................. TEST
NOTE: It may take 2-5 minutes after power-up before the GPS has
acquired a sufficient number of satellites for proper operation.
A. EGPWS INOP and TERR INOP Lights .......... OFF
B. EGPWS TEST Switch .................................... PRESS
NOTE: The Self-Test annunciates are 6dB lower than the normal
audio.
C. EGPWS TEST Switch .................................... PRESS AGAIN
NOTE: Observe Trend check NO FAULTS.
System Check completed
# TCAS ................................................................................................. TEST
A. Turn the SMALL RIGHT knob to select the Traffic Page.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.30
Revision: 02
Date: 04/01/2019


B. From the Traffic Page, press MENU to display the Page Menu.
C. Turn the SMALL RIGHT knob to select “SELF TEST?” and press
ENT.
VOICE: Skywatch System Test Pass.
System Check completed
NOTE: NOT AVAILABLE FOR AIRCRAFT WITH GARMIN 500 NON
WAAS.
# Floats ................................................................................................. TEST
Make this check for electrical continuity daily before all anticipated
overwater flights. DC external power must be available or DC
Generators must be operating to make this test.
A. Flotation Test Switch ...................................... TEST
Check RED WARNING indicator light ON
B. Floats Arming Switch ..................................... ARMED
Check FLOATS ARMED Advisory Light ON
C. Floats Inflation Switch (Pilot and Co-Pilot Cyclic)....PRESS
Check Test 1 and Test 2 Green Indicator Lights
D. Flotation Arming Switch ................................. OFF
Check FLOATS ARMED Advisory Light OFF
E. Flotation Test Switch ...................................... NORMAL
Check RED WARNING indicator light OFF
System Check completed
# AFDS ................................................................................................. TEST
A. FLOATS Arming Switch ................................. OFF
B. AFDS Light Switch ......................................... HOLD ON
C. PASS Light ..................................................... ILLUMINATED
D. AFDS Test Switch .......................................... RELEASE
NOTE:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.31
Revision: 02
Date: 04/01/2019


 If PASS Light Fails to Illuminate place AFDS controller Isolate
Switch – ISOLATE.
 The floatation system is available but must be manually deployed if
required.
System Check completed
# Barrier Filter ....................................................................................... TEST
A. Test Button ..................................................... PRESS AND HOLD
B. Segment Lights .............................................. ILLUMINATED
C.CHECK, MAINT, CAUT .................................. ILLUMINATED
D. IIDS ................................................................ CHECK BAR FILT ON
E. IIDS ................................................................ PWR ASSURANCE ON
F. Test button ...................................................... RELEASE
G. Segment Lights .............................................. EXTINGUISHED
H. Reset Button .................................................. PRESS / HOLD 5 SEC
ALL CONDITION LIGHTS EXTINGUISHED
If power assurance advisory is ON: monitor primary engine instruments.
Normal operation may continue. Engine performance may be degraded.
If possible, avoid maneuvers that require high power applications.
#Radar .................................................................................................. TEST
CAUTION: no personnel may be within 30 ft (all angles) and no
buildings or fueling operations within 100 ft.
Select ARC mode and adjust WX DIM to view WX test pattern.
Select TEST mode and observe:
 Noise Band
 Color Bands
 Range Marks
 FAIL Codes
Check:
 Range Control


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.32
Revision: 02
Date: 04/01/2019


 Target
 Variable Gain
 SCT
 VRM modes as desired
Return to STBY Mode.
Radios ...................................................................................................... SET
VHF 2 VHF 1
APP
ACC
TWR
Oil Rigs and Ships
Company
Air to Air
Arrival ATIS
GPS ...................................................................................... SET / # CHECK
Pilots should create and active a Flight Plan and insert a SID and
waypoints, verifying proper entry of their ATC assigned route upon initial
clearance and any subsequent change of route;
Pilots should ensure the waypoints sequence, depicted by their
navigation system, matches the route depicted on the appropriate
chart(s) and their assigned route.
For further details see Section 8, item 8.3 – Flight Plan.
Stand by Attitude Indicator ............................................................UNCAGED
Verify attitude indicator ungage and no flag.
ADELT .................................................................................... XMT / ARMED
On Center Console place ADELT in XMT/ARM position and observe if
ADELT SAFETY light is extinguished on IIDS.
Both Engine Levers ................................................................................. FLY
Move both Engine Levers to FLY position.
# Inverters ............................................................................................. TEST
Dual Static Inverter – Check (without AC GEN backup)
a. No.1 and No.2 inverter ................................... OFF
b. 1 and 2 INV FAIL caution light ........................ ON


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.33
Revision: 02
Date: 04/01/2019


c. 1 and 2 AHRS caution light ............................. ON
d. No.1 inverter................................................... ON
e. 1 INV FAIL caution light .................................. OFF
f. 1 and 2 AHRS caution light ............................. OFF
g. No.2 inverter ................................................... ON
h. 2 INV FAIL caution light .................................. OFF
i. No.1 inverter .................................................... OFF
j. 1 INV FAIL caution light ................................... ON
k. 1 and 2 AHRS caution light ............................. Remain OFF
l. No.1 inverter .................................................... ON
m. 1 INV FAIL caution light ................................. OFF
NOTE: When both AHRS are operational with one inverter turned
OFF, inverter switching is operational.
Dual Static Inverter – Check (with AC GEN backup)
NOTE: During steps b. and d., a 1 INV FAIL or 2 INV FAIL will appear
on the IIDS. During steps f, a 1 INV FAIL and 2 INV FAIL will
appear on the IIDS.
a. AC generator .................................................. OFF
b. No.2 inverter - ON and No.1 inverter - OFF
Observe that when rotating the course #1 and course #2 knobs on the
Remote Instrument Controller, the Pilot and Co-pilot´s course pointers
on each EHSI will move in the direction of knob movement.
c. No. 1 inverter .................................................. ON
d. No. 2 inverter .................................................. OFF check as in step b.
above
e. AC generator .................................................. ON
f. Both inverters ................................................... OFF check as in step b.
above


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.34
Revision: 02
Date: 04/01/2019


g. AC generator,.No.1 inverter and No.2 inverter - ON
NOTE: When both course pointers are inoperative during steps b or
d, an inverter is inoperative. When one course pointer is
inoperative during steps b or d, inverter switching is
inoperative.
System Check completed
# OEI Selection ..................................................................................... TEST
A. RHP Engine Lever #2 .................................... PULL, SLIGHTLY AFT
B. Engine #1 N1 indicator ................................... 2 MIN (Arm light ON)
C. Collective OEI Switch ..................................... SELECT MCP (No light)
D. Collective OEI Switch ..................................... SELECT 30 SEC (Arm
light on)
E. Collective OEI Switch ..................................... SELECT 2 MIN (Arm
light on)
F. Engine Lever #2 ............................................. FLY
G. Collective OEI Switch .................................... SELECT 2 MIN (Arm
light out)
REPEAT WITH ENGINE #1 AND LHP.
System Check completed
# DAFCS ............................................................................... SYSTEM TEST
Perform this test with the aircraft reasonable level and Engine matched
AC and DC electrical power normal and no flags. Level 1 pass is
required prior to IFR flight.
A. Autopilot Controller TEST Switch ................... ON
B. When AP 1 ON light Flashes ......................... DEPRESS
REMAIN CLEAR OF CONTROLS
CAUTION: During these tests, the rotor tip plane is actually being
deflected outside the aircraft. Use caution not to
endanger persons or objects near the helicopter rotor
disk. Guard Collective to protect against uncommanded
collective (up) runaway.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.35
Revision: 02
Date: 04/01/2019


C. When AP 2 ON Light Flashes ........................ DEPRESS
REMAIN CLEAR OF CONTROLS
D. Check for error codes on the AL-300. Pressing SBY sequences
though any codes.
E. When END 1 is displayed – Press autopilot controller TEST switch to
end test. (Press SBY to continue to level 2.)
NOTE: Autopilot should not be engaged until passing level 1 test.
Level 1 System Check Completed.
If Level 1 test fails repeatedly, use Level 2 test for additional
troubleshooting. Continue to press the flash simultaneously. This is a
bulb check. Each indicator may be pressing SBY twice. The Level 2 test
will terminate with a flashing TEST indication. Press TEST to end.
Engine instruments ......................................................... CHECK / NORMAL
On the IIDS observe if all engine parameters are within normal range.
4.6.1 AFTER START CHECKLIST
Challenger Response Performed By
Engine Instruments CHECK / NORMAL PM
Fuel Levers DIRECT PF
Inverters ON RSP
EMS Power Switch AR PM
Heater / Air Conditioner AS DESIRED LSP
Smoke Detector Baggage AFT TEST PM
Emergency and HEELS
Lights
ARMED LSP
Radar CB IN PM
EFIS /Radio Master ON RSP
Radar STBY PM
# N1 TEST PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.36
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
# EFIS TEST PF/PM
# AHRS TEST PF
# EGPWS TEST PF
# TCAS TEST PM
# Floats TEST PF/PM
# AFDS TEST PF
# Barrier Filter TEST PF
#Radar TEST PF
Radios SET PM
GPS SET / # CHECK PM
Standby Attitude Indicator UNCAGED PF
ADELT XMT – ARMED PM
Both Engine Levers FLY PF
# Inverters TEST RSP
# OEI Selection TEST PF/PM
# DAFCS SYSTEM TEST PF
Engine instruments CHECK / NORMAL PF
4.7 TAXING
All doors / locks .................................................................................. CHECK
On Center Console check DOOR OPEN WARN lights off and on IIDS
observe DOOR OPEN Caution light off.
Autopilots ................................................................................................ OFF
On Center Console verify AP1 and AP2 OFF.
DECU ......................................................................................... NO FAULTS
On Center Console or on collective press DECU FAULT switch and on
IIDS check for present Total, Degraded or Minor fault.
Engine instruments ......................................................... CHECK / NORMAL


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.37
Revision: 02
Date: 04/01/2019


On the IIDS observe if all engine parameters are within normal range.
FUEL ............................................................................... QUANTITY CHECK
On the IIDS press MENU button for 3 seconds and verify enough fuel
quantity for intended flight (on Engine screen).
Landing / Search Light ............................................................................... AR
Set as desired.
Area / Taxi .................................................................. CLEAR (THUMBS UP)
Before taxiing pilots must visually confirm chocks out and receive
thumbs up signal from the maintenance personnel.
Ensure all loose articles are removed from the door and under front of
disk.
Parking Brake ......................................................................................... OFF
Pressing either pilot’s right brake pedal releases the parking brake and
the handle return (spring moves) to the retracted position. Hold the
handle when releasing the brakes and do not allow the handle to drop
as this may cause damage to the indication system.
Wheel brakes/ Flt Inst ........................................................................ CHECK
When taxiing press the toe brake pedals to check the brakes’ efficient.
Check flight instrument indications.
4.7.1 TAXING CHECKLIST
Challenger Response Performed By
All doors / locks CHECK PF
Autopilots OFF PF
DECU NO FAULTS PF
Engine instruments CHECK / NORMAL PF
FUEL QUANTITY CHECK PM / PF
Landing / Search Light ON / AR LSPArea / Taxi CLEAR (THUMBS UP) PF
Parking Brake OFF RSP
Wheel brakes CHECK PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.38
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
Flight Instruments (HSI) CHECK PM
4.8 PRE TAKEOFF
Engine/ Fuel levers ................................................................. FLY / DIRECT
Verify if the No 1 and No 2 ENG Control Levers are on FLY position and
the No1 and N2 ENG Fuel Levers in DIRECT position.
NOTA: PM should touch the levers to confirm the correct positions.
Ensure “OUT OF FLY” Caution light is not displayed on the IIDS.
Altimeters ............................................................................. SET / X CHECK
Set according ATC and cross check (including STBY).
Radios ...................................................................................................... SET
Set according ATC.
VHF 2 VHF 1
APP
ACC
TWR
Oil Rigs and Ships
Company
Air to Air
Arrival ATIS
Nav Aids /EFIS..................................................................... SET / X CHECK
Ensure that the GPS and all traditional aids are tuned and set as
required for the flight being conducted.
Set and cross check both RHP and LHP EFIS displays.
PF and PM should have the source display from his own side. An amber
source displayed indicates that both pilots are using the same source.
This should be corrected before takeoff.
The only exception is the GPS (FMS). An amber source will be
displayed when both pilots use it for navigation.
A white source displayed indicates that the sources are reversed and
should be corrected before takeoff.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.39
Revision: 02
Date: 04/01/2019


Rad. Altimeter / Airspeed Bugs ................................................................ SET
Set both DH bugs and analog RADALT bug to 200 ft.
Set airspeed bugs as required.
Heading Bugs / Course Selector ............................................................. SET
Confirm the heading bugs setting and course selector.
Performance Data / Take- off briefing ..................... COMPLETE
The takeoff briefing is conducted by the crewmember designated as
Pilot Flying (PF) for the flight leg (See item 2.11 for what takeoff briefing
must include).
a. Review the departure procedure (route and altitude, type of takeoff,
significant terrain features, etc.).
b. Review anything out of the ordinary.
c. Review required callouts, unless standard calls have been agreed
upon, in which case, a request for “Standard Callouts” may be used.
d. Review the procedures to be used in case of an emergency on
departure.
e. As a final item, ask if there are any questions.
f. State that the takeoff briefing is complete.

EXAMPLE OF TAKEOFF BRIEFING:
This will be a Performance Class 1 (or Class 2) takeoff, runway XX or intersection
YY towards runway XX.
If anything abnormal occurs before V1 (or VTOSS), with the exception of Blue Light,
we’ll abort the takeoff and land ahead.
If anything abnormal occurs after V1 (or VTOSS), I will fly the aircraft and you will
assist me at my command.
Nothing will be done, except for: positive rate, gear up and climb at V2 (or VBROC)
up to the XX feet, which is our safety altitude.
Once at the safety altitude, you call the TWR and ask for return to RWY XX, and
then we’ll manage the emergency.
Do you have any questions?
Takeoff briefing: complete.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.40
Revision: 02
Date: 04/01/2019


@ Engine Power Assurance .............................................................. CHECK
See item 4.17 – Engine Power Assurance Check

4.8.1 PRE TAKEOFF CHECKLIST (READ & DO)
Item Task Performed By
Engine/ Fuel levers FLY / DIRECT PM
Altimeters SET / X CHECK PF/PM
Radios SET PM
Nav Aids /EFIS SET / X CHECK PF/PM
Rad. Altimeter / Airspeed
Bugs
SET PM
Heading Bugs / Course
Selector
SET PM
Take- off briefing COMPLETE PF
@ Engine Power
Assurance
CHECK PF/PM
4.9 TAKEOFF
NR ......................................................................................................... 107%
Make sure 107% NR
Parking Brake ......................................................................................... OFF
Make sure parking brake OFF.
Transponder.............................................................................................. ON
Select mode ALT
Autopilots / Flight Director ......................................................... ON / FD / AR
Ensure that the flight director is selected to 1 or 2 as appropriate for the
flying pilot and observe on FD SEL’s pushbutton the respective light ON.
NOTE: The order in which the autopilots are engaged determines
which flight director is active, FD 1 or FD2 and which flight
computer functions as the master computer.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.41
Revision: 02
Date: 04/01/2019


AL-300 / ALT. PRE ................................................................. SET / ARMED
Set AL-300 to cleared or cruise altitude. ALT PRE may be engaged at
this point (On the FD selected).
Radar ..........................................................................................STBY or ON
If required (due weather conditions) place WX Radar to ON, if not keep
it on STBY.
Nav. Lights .............................................................................................. POS
On Copilot’s Overhead Switch Panel place STROBE/POS
POS/OFF/BOTH sw in POS position.
HISL/ANTI COLL/Strobes ............................................................ OFF/BOTH
On Copilot’s Overhead Switch Panel place ANTI COLL TOP/OFF/BOTH
sw in BOTH position. Keep the HISL TOP/OFF/BOTH sw in OFF
position.
NOTE: The White mode of operation (HISL) is intended for in-flight,
daylight and VFR conditions. The system should be operated
in the red mode (ANTI COLL) for all other operating condition.
 When both white and red lights are switched on, the white
light overrides the red light.
 Both TOP and BOTTOM anti-collision lights must be operated
during normal flight operation.

WARNING: Turn off the white strobe light during operation near
ground personnel or taxing aircraft. Do not operate the
white strobe at night, in fog, mist or clouds or during
IFR conditions.
Landing / Search Light .............................................................................. ON
If required by local traffic conditions aircraft landing lights should be
turned on prior to Taxi.

4.9.1 TAKEOFF CHECKLIST
Challenger Response Performed By
NR 107% PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.42
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
Parking Brake OFF RSP
Transponder ON PM
Autopilots / Flight Director ON / FD / AR PM
AL-300 / ALT. PRE SET / ARMED PM/PF
Radar STBY or ON PM
Nav. Lights/Strobes/Hisl AR LSP
Landing / Search Light ON LSP
4.10 AFTER TAKEOFF / GO AROUND
Landing Gear ............................................................................................. UP
PF ensure a positive rate of climb is established and call for landing
gear retraction. Observe that gear lights are extinguishes.
Landing Light .......................................................................................... OFF
Place the LAND LT OFF/ON sw in OFF position.
Compass / Heading ......................................................... SLAVE / X CHECK
On Compass Control Panel verify ifboth SLAVE/FREE switches are in
SLAVE position. Cross check heading.


4.10.1 AFTER TAKEOFF CHECKLIST (DO & READ)
In order to preserve the crew’s situational awareness, this checklist should
be done after leaving the traffic pattern.

Item Task Performed By
Landing Gear UP PM
Landing Light OFF PM
Compass / Heading SLAVE / X CHECK PM


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.43
Revision: 02
Date: 04/01/2019


4.11 CRUISE
A cruise check is to be completed on first reaching cruise altitude / flight
level.
Cruise checks may be omitted at the commander's discretion during shuttle
operations and flights of short distances that may hinder the completion of
required descent /approach checks. Shuttle operations are defined as
flights of 10 nm or less in VMC not requiring an instrument approach
Altimeter / Rad Alt .................................................................................... SET
Set the QNH on Pilot and Copilot Altimeters and crosscheck value
inserted on each one.
VNE .................................................................................................... CHECK
Check the VNE on both EADI display.
Fuel Flow / Quantity ........................................................................... CHECK
On the IIDS press MENU button for 3 seconds and verify enough fuel
quantity for intended flight (on Engine screen).
Aux Fuel Panel........................................................................................... AR
If Auxiliary Fuel Tank is installed, on AUX FUEL Panel place
OPEN/SHUT sw in OPEN position and monitors fuel consumption.
# Trend Check ................................................................................... NOTED
See item 4.17 – Engine Power Assurance Check
Search Light ............................................................................................... AR

4.11.1 CRUISE CHECKLIST
Challenger Response Performed By
Altimeter / Rad Alt SET PF/PM
VNE CHECK PF
Fuel Flow / Quantity CHECK PF
Aux Fuel Panel AR LSP
# Trend Check NOTED PM
Search Light AR LSP


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.44
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
RADAR AR PM
4.12 APPROACH / DESCENT
ATIS .................................................................................................. INF____
Insert the ATIS frequency on VHF radio, listen and copy information in
order to prepare the arrival briefing.
Aux Fuel Panel...................................................................................... SHUT
If Auxiliary Fuel Tank is installed, on AUX FUEL Panel place
OPEN/SHUT sw in SHUT position.
Approach / Landing Briefing ....................................................... COMPLETE
a. Identify airport and approach.
b. Confirm primary NAV frequency tuned.
c. Review airport elevation.
d. Review MSA.
e. Confirm CRS set.
f. Confirm secondary navaids and RMI bearing pointers selected.
g. Review initial and secondary altitudes.
h. Review MDA or DH.
i. Review speed for the approach.
j. Review time on the approach.
k. Review rate of descent.
l. Review initial go-around instructions and set navaids if possible.
m. Review airport diagram.
n. Review approach lighting availability, VASI, parallel runways, length,
etc. If circling to land, brief procedure to be used.
o. Advise the PM of standard calls on the approach and any special
instructions. (Call DME stepdown fixes with next altitude, time the
approach from the FAF, advise runway in sight, etc.)
p. Questions? State that the Approach / Landing briefing is complete.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.45
Revision: 02
Date: 04/01/2019


Example of the Approach / Landing briefing – ON-SHORE:
We will descend to 500 ft. At 3 NM of the airport we perform the On-
shore pre-landing checklist.
We will perform the airfield traffic pattern to runway XX.
Is anything abnormal occurs before the airfield traffic pattern we follow
to landing. You inform the emergency to the TWR.
Do you have any questions? The Approach / Landing briefing is
completed.
EXAMPLE OF APPROACH/LANDING BRIEFING (OFF-SHORE):
We will descend to 500 ft. At 3 NM of the oil ring we’ll perform the Off-shore pre-
landing checklist
We will fly over the rig, identify, crosscheck for winds, and check the approach.
If anything abnormal occurs before decision, nothing will be done except for:
positive rate, gear up and climb at VBROC up to the safety altitude XX ft.
When we achieve safety altitude, you call the “Radio” and ask for return to
“SBXX”.
In case of landing over the water, I will deploy the floats and you set the
SKYTRAC.
Do you have any questions?
Approach/Landing Briefing: Complete.
Altimeter / RAD ALT ................................................................................ SET
Adjust Pilot, Copilot and Standby Altimeter according ATC
AL300/ALT PRE.............................................................................. SET/ARM
Select the first altitude restriction on AL-300.
Nav Aids / EFIS........................................................................ Set / X Check
Set the GPS:
Load a GPS approach if required;
Tune, Set, Identify traditional aids if required;
Select appropriate CDI source on both sides;
Select Nav aid needle sources on both sides;
Ensure the EFIS display is set as required and cross checked (PF/PM)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.46
Revision: 02
Date: 04/01/2019


Search Light .............................................................................................. ON
Place the SEARCH LT STOW/OFF/ON sw in ON position.
Radar…………………………………………………………………………....ON

4.12.1 APPROACH / DESCENT CHECKLIST
Challenger Response Performed By
ATIS INF____ PM
Aux Fuel Panel SHUT LSP
Approach / Landing
Briefing
COMPLETE PF
Altimeter / RAD ALT SET PF/PM
AL300 / ALT PRE SET / ARM RSP
Nav Aids / EFIS Set / X Check PM
Search Light ON LSP
Radar ON PM
4.13 PRE LANDING
Gear .......................................................................... DOWN / TREE GREEN
IAS max 120 KTS
Place the Landing Gear Handle to DOWN position and check 3 green
lights illuminated.
Parking Brake ............................................................................................ AR
Set as desired
Landing / Search Light .............................................................................. ON
Place the LAND LT OFF/On sw in ON position and keep the SEARCH
LT sw in ON position.
DECU ......................................................................................... NO FAULTS
Press DECU FAULT switch and on IIDS check for present Total,
Degraded or Minor fault.
Radar ......................................................................................................... AR


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.47
Revision: 02
Date: 04/01/2019


If required (due weather conditions) place WX Radar to ON, if not keep
it on STBY.
Heading Bugs…………………..……Set heading bugs for missing approach

FINAL APPROACH MEMORY ITEMS:

LANDING GEAR ...................................DOWN
PARKING BRAKE..................................APPLIED or RELEASED
MARITIME UNIT ...................................IDENTIFIED (offshore)
AUTHORIZATION .................................RECEIVED

4.13.1 PRE LANDING CHECKLIST
Challenger Response Performed By
Gear DOWN /THREE GREEN PM
Parking BrakeAR RSP
Landing / Search Light ON LSP
DECU NO FAULTS PM
Radar AR PM
Heading Bugs SET FOR MISSED
APPROACH
PM
Final Approach Memory
Itens
Perform PF/PM

4.14 AFTER LANDING
Wheel brakes ..................................................................................... CHECK
When taxiing check the brakes’ efficient.
Autopilots ................................................................................................ OFF
Radar .................................................................................................... STBY
Transponder.......................................................................................... STBY
Set transponder STBY


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.48
Revision: 02
Date: 04/01/2019


Landing/Search light/ANTICOLL/Strobes ............................................... OFF
Place the LAND LT OFF/ON sw in OFF position, the SEARCH LT
STOW/OFF/ON sw in OFF position.

4.14.1 AFTER LANDING CHECKLIST
Challenger Response Performed By
Wheel brakes CHECK PF
Autopilots OFF PM
Radar STBY PM
Transponder STBY PM
Landing/Search
light/ANTICOLL/Strobes
OFF (DAY/NIGHT AR) PM
4.15 SHUTDOWN
Parking Brake ........................................................................................... ON
 .....To set the parking brakes press pedals, pull up on brake handle, and
then release pedals.
Disc Horizontal ......................................................................................... SET
Both Engine Levers ........................................................................... 70% N1
Landing / Search light ............................................................................. OFF
Air Conditioning..................................................................... FAN 1 MINUTE
Place AIR COND/OFF/FAN sw in FAN position, wait one minute and
then place the switch in OFF position.
Clocks ............................................................................... START 1 MINUTE
Standby Attitude Power Switch................................................CAGED / OFF
Press the SBY ATT sw to turn it off and observe the legend annunciates
OFF. Pull to gage knob in.
GPS/RADAR ........................................................................................... OFF
Pitot Heat ................................................................................................ OFF
Place both PILOT HEAT OFF/ON switches in OFF position.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.49
Revision: 02
Date: 04/01/2019


EFIS / Radio Master Switches ................................................................ OFF
Verify if the RADIO MASTER BYPASS/OFF sw is in OFF position
Vent Blower ............................................................................................. OFF
On Heater Control Panel verify if BLEED OFF/ON sw is in OFF position
and if BLOWER OFF/ON sw is in OFF position.
Emergency and HEELS Lights ............................................................... OFF
On Copilot’s Overhead Panel place the EMER LTS ON/OFF/ARM sw
and HEELS ON/OFF/ARM sw in OFF position.
EMS Power Switch / ADELT / Aux Fuel ................................................. OFF
On Center Console place ADELT in OFF position and observe if ADELT
SAFETY light illuminates on IIDS.
Only for Emergency Medical Service Helicopters:
Place EMS Power sw in OFF position. See OMNI’s EMS Helicopters
Operations Manual (Manual Aeromédico).
On AUX FUEL Panel verify if the OPEN/SHUT sw is in SHUT position.
Controls ............................................................ CENTERED / DROOP STOP
Flight controls centered and collective down.
NOTE: The cyclic should be moved as required to prevent Droop Stop
interference as the Main Rotor slows down.
Clocks ................................................................................................... 1 MIN
Air Conditioner ........................................................................................ OFF
Verify AIR COND/OFF/FAN sw in OFF position,
Both Engine Levers ................................................................................ OFF
Move both ECL to IDLE position (50 ± 2% N1) then move ECL to STOP
position.
Air Conditioner ........................................................................................ OFF
Verify AIR COND/OFF/FAN sw in OFF position,
Fuel Levers ............................................................................................. OFF
Move both fuel levers to OFF position.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.50
Revision: 02
Date: 04/01/2019


Rotor Brake ................................................................................................ AR
Set rotor brake as desired. If ON two strokes is required (check ROTOR
BRAKE Caution light ON)
NOTE: Normal Nr for rotor brake application with one or both engines
at idle or with both engines shut down is 40% to 60% Nr.
Maximum for shutdown is 65%. For emergencies with both
engines shut off, rotor brake may be applied up to 107% Nr.
Radios ..................................................................................................... OFF
Set all radios OFF
All Switches and Inst Lights .................................................................... OFF
Set all switches and instruments lights off.
Cycles Count......................................................................................... NOTE
N1 cycles are recorded automatically by the IIDS and can be viewed if
required by:
MAINT soft key ................................................... Press
CYL COUNT ....................................................... Press 4 times
Battery ..................................................................................................... OFF
Place BATT OFF/ON sw in OFF position.
Pins / Plugs / Chocks / ELT Safety Strap .................................................. AR
Check pins, plugs, chocks and safety strap in place.
4.15.1 SHUTDOWN CHECKLIST
Challenger Response Performed By
Parking Brake ON RSP
Disc Horizontal SET PF
Both Engine Levers 70% N1 PF
Landing / Search light OFF LSP
Air Conditioner FAN 1 MINUTE LSP
Clocks START 1 MINUTE PM


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.51
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
Standby Att Power Sw CAGED/OFF PM
GPS / RADAR OFF PM
Pitot Heat OFF RSP
EFIS / Radio Master
Switches
OFF RSP
Vent Blower OFF LSP
Emergency and HEELS
Lights
OFF LSP
EMS Power Switch /
ADELT / Aux Fuel
OFF PM
Controls CENTERED/DROOP
STOP
PF
Clocks 1 MIN PM
Air Conditioner OFF LSP
Both Engine Levers Idle – then Off PF
Fuel Levers OFF PF
Rotor Brake AR RSP
Radios OFF PM
All Switches and Inst
Lights
OFF PM
Cycles Count NOTE PM
Battery OFF RSP
Pins / Plugs / Chocks /
ELT Safety Strap
AR PF/PM
4.16 OFFSHORE HELIDECK / ONSHORE HELIPAD
4.16.1 PRELANDING
Gear ................................................................................... DOWN/3 GREEN
IAS Max 120 kts


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.52
Revision: 02
Date: 04/01/2019


Place the Landing Gear Handle to DOWN position and verify 3 green
lights on.
Parking Brake ........................................................................................... ON
To set the parking brakes press pedals, pull up on brake handle, and
then release pedals.
DECU .........................................................................................NO FAULTS
PressOn Center Console or on collective press DECU FAULT switch
and on IIDS check for present Total, Degraded or Minor fault.
Compass ............................................................................................... FREE
On Compass Control Panel verify if both SLAVE/FREE switches are in
FREE position.
Landing Site ................................................................................IDENTIFIED
Both pilots must identify the landing site.
Radar .................................................................................................... STBY
Place WX Radar in STBY.
Wind Direction.................................................................................... CHECK
Establish contact with Oil Rig or Vessel, in order to update information
about wind direction.
Crane ................................................................. CHECK DOWN AND STOP
Verify if cranes are down and stopped.
Water Sense / AFDS ................................................................... LIGHT OFF
Verify if water sense warning light and AFDS light (near Radar display)
is not illuminated.
NOTE: If water sense warning light or AFDS light is illuminated, do not
arm the floats and return to base.
a - PRE-LANDING CHECKLIST
Challenger Response Performed By
Gear DOWN/3 GREEN PM
Parking Brake ON RSP


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.53
Revision: 02
Date: 04/01/2019


Challenger Response Performed By
DECU NO FAULTS PM
Compass FREE PM
Radar STBY PM
Water Sense / AFDS LIGHT OFF PM
Landing Site IDENTIFIED PF/PM
Wind Direction CHECK PF/PM
Landing Briefing COMPLETE PF
4.16.2 TRAFFIC PATTERN

Challenger Response Performed By
Landing Site Unit Confirmation PF/PM

4.16.3 FINAL APPROACH
Flight Direct...........................................................................................DCPL
 At Final with 80kts and 500ft
Floats ................................................................................ ARMED≤75 Knots
On Pilot’s Overhead Upper Switch Panel place the FLOATS OFF/ARM
sw in ARM position (< 75 kt).
Landing Site ................................................................. CONFIRM / Identified
The crew must identify the landing site.
Heading bugs…………………………….Set missing approach heading bugs

FINAL APPROACH MEMORY ITEMS:

LANDING GEAR ...................................DOWN
PARKING BRAKE..................................APPLIED or RELEASED
MARITIME UNIT ...................................IDENTIFIED (offshore)
AUTHORIZATION .................................RECEIVED



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.54
Revision: 02
Date: 04/01/2019


a - FINAL APPROACH CHECKLIST
Challenger Response Performed By
FD DCPL PF
Floats ARMED≤75 Knots PM
Landing Site CONFIRM / Identified PF/PM
Heading bugs SET FOR MISSED
APPROACH
PM
4.16.4 AFTER LANDING
Floats ...................................................................................................... OFF
On Pilot’s Overhead Upper Switch Panel place the FLOATS OFF/ARM
sw in OFF position.
Autopilots ................................................................................................... AR
Set as desired
Disc Horizontal ......................................................................................... SET
Anti-Collision / Strobes ........................................................................... OFF
On Copilot’s Overhead Switch Panel place ANTI COLL TOP/OFF/BOTH
sw in OFF position. Place the HISL TOP/OFF/BOTH sw in OFF position.
Chocks ....................................................................................................... AR
Wheel chocks are required on all shut down landings on moving
platforms (normally prior to shutdown). When ready for the chocks to be
inserted, the crew will give the chock insert signal to the HLO.

a - AFTER LANDING
Challenger Response Performed By
Floats OFF PM
Disc Horizontal SET PF
Anti-Collision/Strobes/Ldg
and Search lights
OFF PM
Chocks AR PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.55
Revision: 02
Date: 04/01/2019


4.16.5 PRE TAKEOFF
All Doors / Locks ................................................................................ CHECK
Check DOOR OPEN WARN lights off and on IIDS observe DOOR
OPEN Caution light off.
Performance Data / Takeoff briefing ........................................... COMPLETE
The takeoff briefing is conducted by the crewmember designated as
Pilot Flying (PF)
a. Review the departure procedure (route and altitude).
b. Review anything out of the ordinary.
c. Review required callouts, unless standard calls have been agreed
upon, in which case, a request for “Standard Callouts” may be used.
d. Review the procedures to be used in case of an emergency on
departure.
e. As a final item, ask if there are any questions.
f. State that the takeoff briefing is complete.
See example in item 4.8 (Takeoff Briefing)
Altimeters / Radalt ............................................................... SET / X CHECK
Set Pilot, Copilot and Standby altimeters as desired and crosscheck
value inserted on each one.
Set both DH bugs and analog RADALT bug to 200 ft.
Airspeed Bugs.................................................................................. SET / AR
Set airspeed bugs as per performance
Radios / Navaids / EFIS ....................................................... SET / X CHECK
Ensure that the GPS and all traditional aids are tuned and set as
required for the flight being conducted.
Set and cross check both RHP and LHP EFIS displays.
Engine/ Fuel Levers/ Nr ............................................... FLY/ DIRECT / 107%
On Engine Control Quadrant verify if the No 1 and No 2 ENG Control
Levers are on FLY position and the No1 and N2 ENG Fuel Levers on
DIRECT position.
NOTA: PM should touch the levers to confirm the correct positions.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.56
Revision: 02
Date: 04/01/2019


Ensure “OUT OF FLY” Caution light is not displayed on the IIDS.
Make sure 107% NR
Engine Instruments ........................................................... CHECK/NORMAL
On the IIDS observe if all engine parameters are within normal range.
FUEL ............................................................................... QUANTITY CHECK
On the IIDS press MENU button for 3 seconds and verify enough fuel
quantity for intended flight (on Engine screen).
Autopilots / FD SEL ........................................................................ ON / SET
Ensure that the flight director is selected to 1 or 2 as appropriate for the
flying pilot and observe on FD SEL’s pushbutton the respective light ON.
AL 300 / ALT PRE .................................................................. SET / ARMED
Set AL-300 to cleared or cruise altitude. ALT PRE may be engaged at
this point (On the FD selected).
Area / Chocks ............................................................ CLEAR / THUMBS UP
Pilots must visually confirm chocks out and receive thumbs up signal
from the maintenance personnel.
Ensure all loose articles are removed from the door and under front of
disk
Anti-collision / Strobes .............................................................................. ON
On Copilot’s Overhead Switch Panel place ANTI COLL TOP/OFF/BOTH
sw in BOTH position. Keep the HISL TOP/OFF/BOTH sw in OFF
position.
Landing / Search Lights .............................................................................AR
Set as desired
Water Sense / AFDS ................................................................... LIGHT OFF
Verify if water sense warning light and AFDS light (near Radar display)
is not illuminated.
Floats Over Water ..................................................................................... ON
On Pilot’s Overhead Upper Switch Panel place the FLOATS OFF/ARM
sw in ARM position.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.57
Revision: 02
Date: 04/01/2019


a - PRE-TAKEOFF CHECKLIST
Challenger Response Performed By
All Doors / Locks CHECK PF/PM
PD/Takeoff briefing COMPLETE PF
Altimeters / Radalt SET / X CHECK PF/PM/ RSP
Airspeed Bugs SET PM
Radios / Navaids / EFIS SET / X CHECK PF/PM
Radar AR PM
Engine/ Fuel Levers/ NR FLY/ DIRECT / 107% PF/PM
Engine Instruments CHECK/NORMAL PM
FUEL QUANTITY CHECK PM
Autopilots / FD SEL ON / SET PM
AL 300 / ALT PRE SET / ARMED PF/PM
Area / Chocks CLEAR / THUMBS UP PF
Anti-collision / Strobes ON LSP
Landing / Search Lights AR LSP
Water Sense / AFDS LIGHT OFF PM
Floats Over Water ON PM
4.16.6 AFTER TAKEOFF
Floats ...................................................................................................... OFF
On Pilot’s Overhead Upper Switch Panel place the FLOATS OFF/ARM
sw in OFF position.
Gear / Parking Brake ................................................................................. AR
Set as desired.
Landing / Search Lights ............................................................................. AR
Set as desired
Compass / Headings ....................................................... SLAVE / X CHECK


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.58
Revision: 02
Date: 04/01/2019


On Compass Control Panel place both SLAVE/FREE switches in
SLAVE position. Cross check heading.

a - AFTER TAKEOFF CHECKLIST
Challenger Response Performed By
Floats OFF PM
Gear / Parking Brake AR PM
Landing / Search Lights AR PM
Compass / Headings SLAVE / X CHECK PM
4.17 ENGINE POWER ASSURANCE CHECK
Engine Power Assurance (perform either a ground or in-flight check at least
once every 20 flight hours). If the power margin on both engines was 2% or
greater on the previous Power Assurance check, perform once per flight day
if the power margin of either engine was less than 2% on the previous Power
Assurance check, or perform after engine barrier filter maintenance) – Check
each engine separately at 107% NR.
NOTE: The engine power assurance check should be used to ensure
the availability of engine power necessary to meet the
performance data contained in the RFM. If the acceptance
criteria of engine power assurance procedure are not met,
engine maintenance action must be done in accordance with
the applicable maintenance manuals prior to flight.
 The power assurance check should be done only when engine
and transmission oil temperatures are in the normal range
(green arc).
4.17.1 GROUND POWER ASSURANCE
1. Position the helicopter nose into wind.
2. Heater bleed-air .................................................................................. OFF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.59
Revision: 02
Date: 04/01/2019


CAUTION: With aircraft anti-ice ON or OFF, as appropriate for
takeoff, depress PWR ASSUR soft key on the
performance display to command a power check with
anti-ice OFF.

NOTE: An exit from power assurance can be commanded at any time
by depressing the MENU key.
3. ECL ..................................................................................................... IDLE
On engine that is not to be check.
4. Collective OEI limit select switch ............................... OEI MCP (depress).
5. DC generator ...................................................................................... OFF
On the engine being checked.
6. Collective ................................................ Increase to set the 5%
increment torque value
indicated on the display
Although possibly light on wheels, the check must be accomplished on the
ground. Hover using the power of one engine only is prohibited.
7. Check that the countdown timer proceeds from 2:45 to 0 seconds and that
sampling is then initiated. If the countdown timer stops during the final 60
seconds, check indicated torque and adjust to the target value as required.
8. Observe the power assurance result normally displayed 15 seconds after
the start of sampling.
NOTE: If the DECU reports an INVALID check or if NO RESPONSE is
received within 30 seconds, the REPEAT soft key may be
commanded to REPEAT or CONTINUE selected if a check of the
other engine is desired.
9. Evaluate the power margin and T5 margin results. Also crosscheck with
cockpit indicators the pressure altitude and OAT values (± 250 ft, ± 2°C) that
are displayed. Select REPEAT if another check of that engine is desired.
10. DC generator ...................................................................................... ON


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.60
Revision: 02
Date: 04/01/2019


On the engine being checked.
11. CONTINUE soft key ................................................................ DEPRESS
12. ECL .................................................................................................... FLY
On engine that was not to be check.
13. Repeat steps (3) through (11) to check the other engine.
14. ECL Both engines ...................................... FLY, 107% NR, N1 matched.
15. Assess power assurance results:
 If the power and T5 margins are at least ZERO, published
performance is assured.
 If either the power margin or T5 margin is negative, there is no
margin and engine maintenance must be accomplished in
accordance with the maintenance manual before flight.
16. . Log results of power assurance check. Record past performance data.

4.17.2 IN FLIGHT POWER ASSURANCE
1. MENU ..................................................... Select, then press and
hold PA key for 3 seconds
Observe the last selected PA configuration is displayed
2. INFLIGHT Anti-Ice ............................................................ Select On or Off
3. CONTINUE soft key ............................... Select, or press and hold
PA key for 3 seconds to
change configurations
If configuration is changed, CONTINUE must be selected to initiate power
assurance.
4. Establish airspeed and power conditions as indicated. Ensure Bleed Valve
 ................................................................................................................ OFF
To ensure Bleed Valve closure, increase power at least 1% N1 above the
value the BV light extinguished. Allow airspeed and altitude to increase if
necessary.
5. Press respective DO ENG key when conditions are established
6. Observe IIDS display:
 SAMPLING for approximately 15 seconds


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.61
Revision: 02
Date: 04/01/2019


 PA configuration
 ENG1 or ENG2
If valid, IIDS shall display:
 Selected PA configuration
 ENG 1 or ENG 2;
 PASS or FAIL;
 Power Margin %;
 T5 margin in C°;
 Average parameters used for calculation (N1, Raw N1, HP, OAT,
Torque);
If test not valid, IIDS shall display:
 NO RESPONSE – if no DECU response within 30 seconds;
 INVALID – DECU has sent invalid bit;
7. CONTINUE soft key ..................................................... Press, as required.
NOTE: Press MENU key at any time to abort power assurance, and
return to normaldisplay
 If either the power margin or T5 margin is negative, there is no
margin. Normal operations may be continued, however,
published flight manual performance may not be available. If
possible, avoid maneuvers that require high power
applications. A ground power assurance check shall be
performed prior to the next flight to assure availability of
published RFM engine performance.
8. Log results of power assurance check. Record performance data

4.18 BRIEFINGS AND CALLOUTS
4.18.1 STARTING BRIEFING
a - STARTING FIRST ENGINE
PM PF
 Example:


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.62
Revision: 02
Date: 04/01/2019


I’ll start engine #1.
I’II abort in case of hung start, hot
start or Engine Fire.
In case of Fire, I’II identify,
combat and apply the rotor
break.
Evacuate to the right.
4.18.2 STARTING CALLOUTS
PM PF

N1 moving
Fuel flow alive
T5 rising
Oil press coming up
Oil press light out
Fuel press light out
DC on line





4.18.3 TAXIING CALLOUTS
PM PF
Before Taxiing READY FOR TAXI.
During Taxiing
LEFT TURNS: DECREASING
MARKS, RIGHT TURNS,
INCREASING MARKS.
4.18.4 TAKEOFF BRIEFING
PM PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.63
Revision: 02
Date: 04/01/2019


 EXAMPLE OF TAKEOFF
BRIEFING:
This will be a Performance Class 1
(or Class 2) takeoff, runway XX.
If anything abnormal occurs before
V1 (or VTOSS), with the exception of
Blue Light, we’ll abort the takeoff
and land ahead.
If anything abnormal occurs after V1
(or VTOSS), I will fly the aircraft and
you will assist me at my command.
Nothing will be done, except for:
positive rate, gear up and climb at
V2 (or VBROC) up to the XX feet,
which is our safety altitude.
Once at safety altitude, you call the
TWR and ask for return, and then
we’ll manage the emergency.
Do you have any questions?
Takeoff briefing: complete.

4.18.5 TAKEOFF CALLOUTS
PM PF
 LIFTING
 CG OK
ALL GREEN NO LIGHTS TQ
XX%

 TAKEOFF
 ROTATING (helideck, helipad…)
AIRSPEED ALIVE
V1 CROSSCHECK
V2
BROC SPEED
POSITIVE RATE OF CLIMB GEAR UP


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.64
Revision: 02
Date: 04/01/2019


4.18.6 CLIMB OR DESCENT CALLOUTS (VFR OR IFR)
PM PF
CROSSING XX THOUSAND
FEET*
(PM Shall callout for every
1,000 feet until reaching 1,000
to target altitude)
CROSSCHECK
1,000 TO CROSSCHECK
500 TO CROSSCHECK
200 TO CROSSCHECK
100 TO CROSSCHECK
CAPTURED CAPTURED
ALT ON ALT ON

4.18.7 APPROACH – PRECISION CALLOUTS
PM PF
At 1.000 ft above minimums
“1.000”
“DA___”
At 500 ft above minimums
“500”

“NO FLAGS”
At 200 ft above minimums
“200”

“DA___”
At 100 ft above minimums
“100”

“APPROACHING MINIMUMS”
Approach Lights/Runway in
sight
“Minimums. Approcah Lights (or
runway) at ___ (Clock Position)


“CONTINUING”

a - MISSED APPROACH CALLOUTS
PM PF
Runway is not in sight at Decision Height.
“Minimums RWY not in sight” “GOING AROUND”


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.65
Revision: 02
Date: 04/01/2019


“Climb Power” “SET”
“Positive ROC” “GEAR UP, AFTER TAKEOFF
CHECKLIST”
“Heading___” “HEADING___”
“Climb to___” ”CLIMBING TO___”
“Calling ATC” “Roger”
4.18.8 APPROACH – NONPRECISION CALLOUTS
PM PF
At 1.000 ft above minimums
“1.000”
“MDA___”
At 500 ft above minimums
“500”

NO FLAGS
At 200 ft above minimums
“200”

“MDA___”
At 100 ft above minimums
“100”

“APPROACHING MINIMUMS”
(At MDA ) Approach
Lights/Runway in sight
“Minimums. Approach Lights (or
runway) at ___ (Clock Position)


“CONTINUING”

a - MISSED APPROACH CALLOUTS
PM PF
Runway is not in sight at MDA.
“Minimums RWY not in sight” “GOING AROUND”
“Climb Power” “SET”
“Positive ROC” “GEAR UP, AFTER TAKEOFF
CHECKLIST”
“Heading___” “HEADING___”
“Climb to___” ”CLIMBING TO___”
“Calling ATC” “Roger”


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 4.66
Revision: 02
Date: 04/01/2019


4.18.9 SIGNIFICANT DEVIATION CALLOUTS
PM PF
IAS +/- 10 KIAS
“Check Speed”

CORRECTING TO ___
Heading +/- 10º en route, 5º on
approach
“Check Heading”

CORRECTING TO ___
Altitude +/- 100 ft en route, +50 /
-0 ft on final approach
“Check Altitude”
CORRECTING TO ___
CDI OR RMI left or right one dot
“Check Course”
CORRECTING
Vertical descent speed greater
than 1.000 fpm on final
approach
“Check Sink Rate”
CORRECTING
Bank in excess of 30º
“Check Bank”
CORRECTING
4.19 PROCEDURES FOR COMPRESSOR DRY-UPS
The following procedures shall be made upon the dry-ups of engines
(compressors), once the washouts have been made by the maintenance.
- Engines should be started according to checklist procedures;
- Engines shall be placed at 70% n1;
- Engine Anti-Ice On for 1 minute;
- Defroster On for 1 minute (if installed);
- After 1 minute turn off Anti-ice and Defroster;
- Shut down engines according to the checklist.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.1
Revision: 02
Date: 04/01/2019


SECTION 5.
PATTERNS AND TECHNIQUES

5.1 RUNWAY CLASS 1 TAKEOFF PROCEDURE.
5.1.1 TECHNIQUE
PF calls lifting and lifts to the hover at 5 feet after this PNF reports the hover
checks complete and TQ or N1 values (whichever is the limiting fator). Rotate
pitch down atitude, at rotating increse TQ value 6% above hover power to
initiate a gently acceleration to TDP. At TDP, contine acceleration to V2 then
adjust pitch atitude to approximately level on the ADI attain Vbroc. After
Vbroc, set climb power and climb rate. At 300 feet raise the landing gear.
Continue climb following the briefed procedure.
After takeoff checks when established in the climb above 500 feet AGL
5.1.2 RUNWAY CLASS 1 TAKEOFF CALLOUTS
FLIGHT EVENT PM PF
Take-off Checklist
complete
N/A "LIFTING"

At Hover N/A "CG OK"
At Hover "ALL GREEN, NO
LIGHTS, TORQUE
AT XX%"
“TAKE-OFF”

 Speed Alive N/A
IAS passing TDP "V1” “CROSSCHECK”
IAS passing V2

"V2" N/A
IAS passing VBROC "VBROC"
At or above 300 FT “300 FT” “GEAR UP”
Altitude passing 500
feet
“500 FT” After takeoff checklist




OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.2
Revision: 02
Date: 04/01/2019





5.2 RUNWAY CLASS 2 TAKEOFF
5.2.1 TECHNIQUE
This profile utilises the same profile as for a performance class 1 takeoff with
no obstacles present. With obstacles, use hover torque plus 10% rather than
TQ+6%. Climb out at Vtoss until clear of obstacles.
NOTE:
For class 2 takeoffs from sites other than an area meeting the class 1
requirements, TDP may not be where it is on a class 1 takeoff. TDP is called
by PF(“committed”) based on his assessment of the site and the helicopter’s
performance.



5.2.2 CALLOUTS
FLIGHT EVENT PM PF
Takeoff Checklist
completed

N/A "LIFTING"
Raises collective to
establish a stationary
hover at 5ft to 10ft


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.3
Revision: 02
Date: 04/01/2019


FLIGHT EVENT PM PF
At Hover "ALL GREEN, NO
LIGHTS, TORQUE
AT XX%"
"CG OK"
TAKEOFF
Positive airspeed
indication
“Airspeed ALIVE “
VSI positive
Indication

Climbing “CROSSCHECK”
IAS passing 49 knots V1
IAS passing 59 knots Vtoss
When insufficientreject area exist
 Committed
IAS passing Vbroc Vbroc Ensure Collective set
to 80%TQ climb
power
300 feet 300 feet GEAR UP
500 feet 500 feet After Takeoff checks


5.3 ONSHORE ELEVATED HELIPAD / ONSHORE GROUND
HELIPAD TAKEOFF WITHOUT NO OBSTRUCTIONS
CLASS 2
Many helipads are surrounded by rough terrain and obstacles, such that a
run-on-landing would be dangerous if an engine failure were to occur
immediately after departing the pad. By climbing vertically before rotating, it
is more likely that forward motion can be flared off if a reject is required. This
profile will minimize the time the aircraft is unable to fly away in evento f an
engine failure. Additionally, this profile will minimize time in a low hover
where FOD and dust may be an operational issue

5.3.1 TECHNIQUE
Rise vertically to 5-foot wheel height or establish a light wheel hover.
Increase power (not to exceed takeoff power limits).


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.4
Revision: 02
Date: 04/01/2019


At TDP (20ft radar altitude) rotate to 10 degrees pitch down (if possible) and
accelerate forward. Climb at V2 (VTOSS) and accelerate to Vbroc.

5.3.2 CALLOUTS
FLIGHT EVENT PM PF
After Takeoff
Checklist complete
N/A "LIFTING"

At Hover or wheels
light
N/A "CG OK"
At Hover or wheels
light
“ALL GREEN, NO
LIGHTS, TORQUE
AT XX%”
"TAKEOFF"

RAD ALT Passes
TDP
"20 FEET" "ROTATING"
Airspeed Signals “Airspeed Alive”
IAS passing 35
knots
"35 KNOTS" Adjust to climb
IAS passing 59
knots
"V2" Ensure collective set
to 80% TQ CLIMB
power
IAS passing VBROC "VBROC"
At or above 300 FT “300 FT” “GEAR UP”
Altitude passing 500
feet
“500 FT” After takeoff checks


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.5
Revision: 02
Date: 04/01/2019




5.4 OFFSHORE HELIDECK TAKEOFF CLASS 2
Factors to be considered when taking off or landing on an offshore elevated
platform;
TDP
The maximum statics height before visual cues become unacceptable is
40feet; this coincides with the height which may be achieved during the
ballooning effect, followinf a reject at 30 feet and when operating at light
mass. The ideal TDP is 20feet above the helideck. The actual TDP is defined
by the point at which a cyclic input is made initiating a nose down atitude
change (rotation point)
Defined point after takeoff (DPATO)
For the S76, in practical terms DPATO may be taken as passage of 35 knots
accelerating, which guarantee safe single engine performance under worst
case conditions of mass, altitude and temperature.

5.4.1 TECHNIQUE
Rise vertically to 5-foot wheel height or establish a light wheel hover.
Increase power (not to exceed takeoff power limits).


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.6
Revision: 02
Date: 04/01/2019


At TDP( 20ft radar altitude) rotate to 10 degrees pitch down (if possible) and
accelerate forward. Climb at V2 (VTOSS) and accelerate to Vbroc.




5.4.2 CALLOUTS

FLIGHT EVENT PM PF
After Takeoff
check list complete
 Lifiting
In hover or wheels
light
“xx % TQ, All
green no
Warnings Lights
Takeoff
Raises collective to
apply suficiente power


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.7
Revision: 02
Date: 04/01/2019


to climb vertically while
adhering to limitations

Rotation
(RADALT 20ft)
20ft Rotating
Airspeed Signals “Airspeed Alive”
IAS passing 35
knots
"35 KNOTS" Adjust to climb
IAS passing 59kts V2 Ensure collective
set to 80% TQ
CLIMB power
IAS passing
VBROC
VBROC
Alt 300ft 300 feet Gear Up
Alt 500ft 500 feet After takeoff
checks


5.5 OFFSHORE AFTER TAKEOFF / GO AROUND
The floats may be disarmed once the aircraft is safely established in the climb
above Vtoss or 300 feet. The floats shall be desarmed before the limiting
airspeed. The checklist may be completed from memory once the aircraft is
safely established in the climb (above 300feet RADALT and with airspeed at
or above Vbroc(VY). An exception, if OEI and in a continued flight
condition, landing gear will retract when a positive rate of climb is
established. However, the checklist should not be read until the aircraft is
safely established in the climb above 500feet RADALT on departure. It is
particularly important that PNF monitors the flight profile effectively during
IMC or night takeoffs and go around. No extra calls or actions are required
during this phase unless PNF notices a deviation from the expected flight
profile.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.8
Revision: 02
Date: 04/01/2019


If the checklist has been completed from memory, PNF must then consult
the checklist and review it to ensure all items have been completed correctly
5.6 RUNWAY CLASS 1 LANDING
This approach profile should Always bem ade to a firm level area with
suficiente space for a roll-on landing

5.6.1 TECHNIQUE
The procedure is designed for visual approaches to short or
minimum available field lengths. The approach should be
conducted so as to pass through the LDP of 200 feet indicated
and 45knots IAS with a maximum descent of 600 feet/min, but
300 feet/min is ideal for OEI. OEI must be considered when
planning the approach. Maximum nose up pitch attitude of 10°
at 30 feet and below. Descend below 30 feet only after pitch
attitude is 10° nose up or less.



5.6.2 CALLOUTS

FLIGHT EVENT PM PF
Estabished on final

Final checks
completed (before
arriving at LDP)
Final Check

Passing 200 feet
AGL
LDP Landing

Maintain 45kts at no
more than 300ft/min
Passing 50ft 50 feet Check
Commences flare to
reduce speed


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.9
Revision: 02
Date: 04/01/2019


FLIGHT EVENT PM PF
Passing 30ft Monitor pitch attitude
and height. Call
BELOW 10 when
pitch is stable below
10°
Check
Transition to Hover 10 feet Check

Figure 5-1: Runway / ground helipad Landing

5.7 RUNWAY LANDING CLASS 1, ALTERNATE
PROCEDURE

5.7.1 TECHNIQUE
This procedure is designed for approaches where landing distance available
is not critical or for transitions from instrument approaches. The alternate
LDP is passage of 75 feet ASL at 60 knots IAS with a rate of descente less
than 300 feet/min.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.10
Revision: 02
Date: 04/01/2019


The approach should be conducted so as to pass through the LDP of 75 feet
indicated and 60 knots IAS with a maximum descent of 300 feet/min, which
is ideal for OEI. OEI must be considered when planning the approach
Maximum nose up pitch atitude of 10° at 30 feet and below. Descend velow
30 feet only after pitch atitude is 10° nose up or less.




5.7.2 CALLOUTS

FLIGHT EVENT PNF PF
Established on final

Final checks
completed
Final checks
Gradually reduces
speed to arrive at 60
knots at 75 feet AGL.
Normal rate of descent
will be 300 ft/min


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.11
Revision: 02
Date: 04/01/2019


Passing 75 feet AGL LDP Landing
Passing 30 feet Monitor pitch atitude
and height. Call below
10 when pitch is stable
below 10°
Check
Transition to Hover 10 feet Check

5.8 RUNWAY LANDING PERFORMANCE CLASS 2
Performance Class 2 landings are conducted using a similar profile for the
normal class 1 procedure ( LDP 45kts and 200 feet ).Upon arrival at high
LDP, a gradual comfortable deceleration and rate of descente should be
used. Reaching the runway should be assured throughout, and a power loss
will simply terminate in a running lading.
Note:
For class 2 landings on sites other then an area meeting the class 1
requirements, LDP may not be where it is on a class 1 landing. PF class
“landing”(committal point) based on his assessment of the site and the
helicopter’s performance

5.8.1 TECHNIQUE
The approach should bem ade to a firm level area with sufficient space for a
roll-on lading. OEI at class 2 masses may require a landing distance (from
50feet) of up to 1000 feet. The approach should be conducted so as to pass
throught the LDP of 200 feet indicated and 45knots. IAS with a maximum
descente of 500 feet/min, but 300 feet/min is ideal for OEI. OEI must be
considered when planning the approach.
Gradual deleration and descent, maximum nose up pitch atitude of 10° at 30
feet and below. Descend below 30 feet onli after pitch atitude is 10° nose up
or less.

5.8.2 CALLOUTS
FLIGHT EVENT PM PF


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.12
Revision: 02
Date: 04/01/2019


Established on final

Final Checks
completed
Final Checks

Reduces speed and
altitude to arrive at
LDP. No more than
600 feet/min ROD
At Committal
Point(LDP)
Check Landing
Passing 45knots IAS
and 200 feet AGL
45 knots and
200 feet
Check
Gradually reduces
speed and altitude
Passing 30 feet Call Bellow 10
(monitors pitch angle)
Check
Hover 10 feet Check

5.9 LANDING PROCEDURE OFFSHORE HELIDECK
For helidecks, landing procedure employs an approach path offset at least
one rotor radius to the side of the helideck to permit an un-obstructed go-
around path in case of engine failure.
LDP should be set to a point 50ft above, 25 ft to the left or right of, and 150
ft short of the helideck.
On final approach, for headwind components up to 20 knots, add one half of
the estimated component to the target speed.
For headwind components greater than 20 knots, add 10 knots plus the
difference above 20 knots to the target speed.
Floats must be armed below 75 KIAS (if over water) and the parking brake
set.

5.9.1 COMMITTAL POINT (CP)
This is the point beyond which the pilot is committed to a landing in the event
of a single engine failure. The ideal committal point is a point on the final
approach where the rotor tip path plane is co-incident with the deck wdge,


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.1
Revision: 02
Date: 04/01/2019


the aircraft heights is approximately 50 feet above helideck elevation with
minimal rate of descent and the closing groundspeed is 20knots. This ideal
point may be modified to take account of factors such as turbulence, visual
cues, deck orientation, presence of obstacles and estimated power margin.
To clear obstructions, PF may elect to contine forward until the deck is
positioned up to 90° off the helicopter before the decision to land is made.

5.9.2 TECHNIQUE
Initiate a constant angle continually decelerating approach to the helideck,
Commencing at 80 KIAS at a height of 500 ft above sea level or landing
surface. Carry out final checks
Maintain a progressive deceleration while maintaining a rate of descent of
no more than 500 ft/min.
When passing through 100 ft above the helideck, allow the approach angle
to flatten to a descent rate of not more than 150 fpm at an airspeed of 35
KIAS in zero wind or the equivalent airspeed adjusted for headwind
component.
Continue to reduce altitude to arrive at the committal point. At the CP the
aircraft is flared to reduce airspeed. PF calls “Committed” when he considers
that, in the event of an engine failure, the safest option is to continue to the
deck.
During this flare, the pilot should maneuver the aircraft and complete the
landing vertically or transition to hover.
The nose attitude must be reduced below 10° nose up by 30 feet over the
deck. PM calls “bellow 10”when this attitude is achieved.
After landing, centralise the cyclic


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 5.2
Revision: 02
Date: 04/01/2019















5.9.3 CALLOUTS

FLIGHT EVENT PM PF
Estabilished on final
approach at 500
feet and 80knots
IAS, with less than
500 feet/min ROD


Final Checks
Complete
Final Checks.
When deck
clearance is received
and the deck is
identified.


At committial point Monitor pitch attitude
and height
Call “below 10” when
pitch is stable below
10°
Landing


Call: Check in
response to “ Below
10” PM callout




OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.3
Revision: 02
Date: 04/01/2019


SECTION 6.
EMERGENCY AND
MALFUNCTION
6.1 INTRODUCTION
Emergency/malfunction occurrences pose two simultaneous risks to
an aircraft's crew. The obvious risk is that of the
emergency/malfunction itself, but the other, less obvious but equally
important, is the distraction hazard that has the potential of causing
fixation and preoccupation leading to increased risk exposure.
It is therefore important to stress the team performance required to
minimize both of these risks. The occurrence of an
emergency/malfunction requires that crew coordination actions and
task management be accomplished. Specifically, the items below
should be addressed:
 Pilot Flying-Continues to fly the aircraft. Inherent in this statement is that
a determination of what continues to be working is of primary
consequence to this initial action. Safe attitude, altitude, and position are
primary criteria to be considered.
 Pilot in Command-Determines plan of action. The PIC first determines
who will be the flying pilot. If the PIC is currently the pilot flying, he may
elect to continue flying, or he may choose to assume the pilot not flying
duties. The PIC must then determine and communicate the plan of action
to be taken, e.g. change in destination, checklists to be accomplished,
safe altitudes, etc. Generally, the tasks assigned to the pilot flying and
pilot monitoring are as follows.
 Pilot Flying-Tasked to fly the aircraft or to monitor the autopilot system
and communicate the necessary information as to condition (emergency,
fuel state, position, and requirements) to ATC. He must ensure
continued safe attitude, altitude, and position.
 Pilot Monitoring - Tasked with the accomplishment of emergency/
malfunction procedures as directed by the PIC. Proper challenge "and
response techniques must be utilized when accomplishing emergency
checklists. Confirmation of critical controls (e.g., T-handle, fuel lever,
etc.) must be made by the pilot flying prior to the movement of that
control. Lack of time, such as on final approach, to accomplish critical
emergency items suggests a very high risk potential. Delaying the


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.4
Revision: 02
Date: 04/01/2019


accomplishment of those items until more time is available, such as on
the ground or after a missed approach, may be advisable.
The following are potential hazards in accomplishment of emergency
procedures:
 Even when duties have been assigned, it is normal for both pilots to
involve themselves with the accomplishment of an emergency
procedure. To the extent that both crewmembers need to be aware of
the total cockpit situation, this attention provides for increased situational
awareness. However, when the pilot flying becomes distracted from his
primary responsibilityof ensuring continued safe flight, this becomes a
critical risk.
 When identifying the roles and responsibilities of each crewmember, the
pilot in command must guard against overloading one crewmember.
When requiring the accomplishment of multiple tasks, prioritize the order
in which those tasks must be accomplished. As an example, if the aircraft
is being vectored for an approach and a malfunction occurs, it may be
beneficial to accomplish the "APPROACH (IN RANGE)" checklist before
the emergency procedure checklist. The accomplishment of an
emergency procedure at an inappropriate time may actually increase the
risk exposure to the aircraft by putting the crew behind the Power curve.

6.2 DEFINITIONS

WARNING
Draws attention to an operating procedure, practise or
condition that may result in injury or death if not carefully
observe dor followed.
CAUTION
Dras attention to an operating procedure or condition that may
damage equipment if not carefully observe dor followed.
NOTE
Draws attention to an operating procedure, practise or
condition that is essential to emphasise.


SAFE OEI FLIGHT


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.2
Revision: 02
Date: 04/01/2019


Safe OEI flight is defined as a sustainable airspeed of not less
than Vtoss(V2), the ability to obtain a positive rate of climb at
acceptable power levels anda n altitude which provides
sufficient clearance from the ground / obstables so that
required manoeuvring can be reasonably achieved. At crew
discretion, othr procedural checks / actions may be carried out
while these conditions are being established.
FLY MANUALLY
Use hands-on flying to control the flight path directly.
FLY ATTENTIVE
Maintain close controlo f the flight path using hands-on flying
when required. Even when the flight diretor is used, the pilot’s
hands should be close to the flight controls in order to
intervene when necessary.
EMERGENCY TRANSPONDER CODES
 Emergency...............................................7700
 Communication failure.............................7600
 Inlawful interference ( hijack)...................7500

6.3 BASIC PROCEDURE IN THE EVENT OF AN EMERGENCY
Once an emergency or abnormal situation has been recognised, the
following basic procedure should be followed:
I. Maintain aircraft control
II. Analyse the situation
III. Take appropriate action
Immediate actions Boxed memory items
Emergency Checklist Items read from the emergency
Check list
Normal checklist NCL items such as before
landing checks

6.3.1 MAINTAIN AIRCRAFT CONTROL
 The pilot recognising a failure or malfunction calls “type of
malfunction” or “MASTER CAUTION“ with the appropriate
caption( exemple “ENG OUT #1”)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.3
Revision: 02
Date: 04/01/2019


 PF controls the aircraft to achieve a stable safe flight condition
or an immediate landing as appropeiate. In or close to a hover
over a safe surface, PF lands and deals with the emergency
oh the ground. In the air, PF attains a safe flight configutarion

6.3.2 ANALYSE THE SITUATION
 PM identifies and states all the displayed warning, cancels the
MASTER CAUTION if appropriate, starts diagnosing and
states the problem to PF
 PF continues to fly the aircraft safely. Both pilots confirm the
symptoms and agree on the diagnosis of the problem. When
PF has the aircraft under control and is ready to deal with the
follow-up, he calls “immediate actions “

6.3.3 TAKE APPROPRIATE ACTION
 PM then carries out, or coodinates, the immediate actions,
stating clearly what he is doing. PM shall be precise and
methodical so that PF can monitor the immediate actions.
When the immediate actions are complete, PM will call
immediate actions complete. If there are none, PM states no
immediate actions. At this point PF will call for the emergency
checklist
 ‘PM starts reading the emergency checklist including the boxed
immediate actions, to comfirm they were out correctly. He then
carries out the other items using the emergency checklist as a
“read and do”

 PM then call Emergency checklist completed

 PF then calls for the normal checklist, if applicable
6.4 MOVEMENT OF MAJOR SWITCHES AND CONTROLS
MOVEMENT OF MAJOR SWITCHES AND CONTROLSMajor
switches or controls are defined as engine and fuel controls (throttles,
FIRE / ARM buttons and fuel selectors) and electrical generation


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.4
Revision: 02
Date: 04/01/2019


controls ( battery, generator or converter switches). PM will wait for PF
to check that he has the correct lever or switch before moving it. PM
will state the item ( switch or control lever) and lightly touch it. PF may
either confirm visually or may check by confirmation of position (for
exemple “is it the left hand switch?” Once verified, PF will say
CONFIRMED then PM will make and state the necessary slection.

Note:
Engine or fuel controls should not be moved in flight bellow 200feet
AGL or when the IAS is less than VBROC, unless there are visual
signs of FIRE or aircraft control is in jeopardy (for example with a tail
rotor failure). If rejecting before TDP there are no PM actions until the
aircraft has come to a stop on the ground.

6.5 CIRCUIT BREAKERS AND ELETRICAL COMPONENTS
Resetting electrical components and circuit breakers
Circuit breakers should not normally be reset. Hey may be reset once
onlye, provided there are no indications of an electrical fire and the
affected system is necessary for the safe continuation of the flight. Any
malfunctioning component such as a generator or alternator should be
reset once only unless specifically required by the emergency
procedure.
Circuit Breaker Collars
These CB should have collars:
 BUS TIE (2)
 ENGINE CHIP (2)
 MGB CHIP
 INT GEARBOX
 T/R GEARBOX
 SERVO JAM (2)
 LDG GEAR CONTROL
 LDG GEAR POS
 WSHLD HTR PWR (2)
WARNING, CAUTION AND ADVISORY SYSTEM
The warning / caution / advisory system for the S76C++/C+ is
designed to give the pilot visual and aural indications of system
malfunctions or normal operating conditions. The majority of


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.5
Revision: 02
Date: 04/01/2019


annunciations appears on the engine and performance displays of the
IIDS system, and on the master warning panel. In most cases, other
specific annunciator lights are located close to the associated system
control panels.

6.6 MASTER WARNING PANELS
Each master warning panel consists of an amber master caution light,
two red lights to indicate engine fire, two red lights to indicate engine
failure and spaced outboard he blue ENG CONTROL lights. To direct
the pilot’s attention to the IIDS displays when a warning or caution light
illuminates, the MASTER CAUTION light will also illuminate. After the
condition has been noted, the MASTER CAUTION should be reset to
allow it to illuminate again if another caution light should illuminate.
The master caution light does not illuminate when an advisory light on
the performance display illuminates. See below for further description.

Aural warning associated with the aircraft systems
A tone generator is used to alert the crew to the following warning
lights (listed in order of system-priority):
 ENG OUT
 LDG GEAR UP
 ENG FIRE

6.7 ENGINE OUT
In addition to an ENGINE OUT light, a high / low alternating tone will
be heard when airborne under the following conditions.
The decu detects an engine failure when:
 N1 decreases below 48% 5.5% N1 difference with both engine lever in the FLY position
 At 60% N1 with both engine levers in the FLY position
The tone may be cancelled by pressing either of illuminate ENGINE
OUT lights



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.6
Revision: 02
Date: 04/01/2019


6.8 LANDING GEAR
An intermittent low tone will be heard, along with the landing gear up
warning light when:
 The IAS is reduced below 60 knots
 Or the altitude is reduced below the highest DH setting on a
pilots RADALT
The tone may be cancelled by pressing either of the landing gear up
warning lights.

6.9 FIRE
In addition to the fire warning lights, a continuous tone will be heard
when the fire detectors in an engine compartment sense the presence
of a flame. The tone may be cancelled by pressing either of the
illuminated fire warning lights.

6.10 FD DCPL
The FD DCPL annunciator will activate when the active flight director
is de-coupled purposefully by any of the following actions:
I. The couple (CPL) button is pressed on the autopilot control
panel
II. The active flight director is ste to standby(SBY) on its mode
selector
III. The active flight director is set to standby with the
corresponding cyclic DECOUPLE switch. The previously
described de-couple events in a flashing mode, accompanied
by a non-repeating aural tone. The aural tone or voice alert is
an additional option. When the annunciator is pressed, the
flashing stops, and the annunciator remains illuminated until
the active flight director is again placed in a coupled mode
The FD DCPL annunciator will also illuminate if the active flight director
is de-coupled by following equipment shutdowns:
a) Failure of AP1 or AP2
b) De-selection of AP1 or AP2
c) AHRS failure


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.7
Revision: 02
Date: 04/01/2019


d) Air data computer failure if the same side active flight director
is coupled in a single cue air data mode
e) Air data computer failure if the same side active flight director
is coupled in a two cue air data mode, if both cues are air data
modes(example: IAS and ALT)
The FD DCPL annunciator will active in response o the previously
described de-couple events in a flashing mode, accompanied by a
non-repeating aural tone. The flashing stops, and the annunciator
remains illuminated until the active flight director is again placed in a
coupled mode.
Warning:
The FD DCPL annunciator is not intended to detect system failures
and the flight crew should monitor the cockpit for all standard failure
annunciations.

6.11 EGPWS EMERGENCY PROCEDURES
The EGPWS will automatically detect autorotation by monitoring the
torque output of each engine. The aircraft is considered to be in
autoritation when both engines fall below 7.5%Q. No pilot input is
required.
During autorotation, all other EGPWS alerts are inhibited.
During autorotation, the EGPWS will provide alert callouts 200 and 100
feet AGL
The too low gear alert will be provided at 400 feet AGL if the aircraft is
in autorotation and the gear is not down.

6.12 ENGINE FAILURES DURING TAKEOFF AND
LANDING
In the event of an emergency durgin takeoff or landin, there should be
no movement of engine or fuel controls and no action of immediate
actions until:
 If the emergency occurs during the takeoff before TDP (V1),
until the aircraft is back on the ground and stopped with the
parking brake applied, or


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.8
Revision: 02
Date: 04/01/2019


 If the emergency occurs during the takeoff after TDP (V1), until
the aircraft is above 200 feet AGL at Vbroc (VY), or greater, or
 If the emergency occurs during the landing below 200 feet, until
the aircraft is above 200 feet AGL at Vbroc (VY) or greater on
a go-around, or is on the ground and stopped with the parking
brake applied

The only exception to this procedure should be if there are confirmed
signs of fire in addition to the fire warning or when aircraft control is in
jeopardy.
The ECL is not to be read until the aircraft is above 500 feet AGL or safely
on the ground.
The SPZ7600 system will limit the demand for power from the remaining
engine at maximum continuous AEO parameters. In addition, the CLTV light
may illuminate during an engine failure and if below collective command
criteria, the collective will remain coupled.
After an engine failure, disengage FD mode that produce collective input, if
maximum single engine power is required

6.12.1 PM ACTIONS
During these emergencies, PM shall perfom the following actions:
 If an engine malfunction occurs, call “ TQ split “and if partial failure,
“NR high”(above 108%) or “NR Low” (below 100%) and monitor NR
trend
 Monitor the failed engine for signs of fire and other dangerous
indications
 Monitor the good engine parameters
 Call at Vtoss (V2) and Vbroc (Vy) and state if the aircraft is climbing
 Raise the landing gear at positive rate of climb
 Monitor time constraints and call power setting OEI 30S/ OEI 2min /
OEI MCP
 Monitor RADALT height, pitch attitude and flight path
 Call passing 200 feet and 500 feet
 Call pitch attitude below +10° before landing
 Peform immediate actions and emergency checklist on request



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.9
Revision: 02
Date: 04/01/2019


6.13 ENGINE FAILURE DURING TAKEOFF
6.13.1 RUNWAY CLASS 1 ENGINE FAILURE
Engine failure before TDP (V1):
 PF call Rejecting
 Set up to 10° nose up attitude below 30 feet
 Apply collective to cushion landing
 When on the ground centre cyclic, lower collective and apply brakes
as required. Perform immediate actions
 Continue with emergency checklist
Engine failure at or after TDP (V1):
 For climb adjust collective to maintain 100% NR (minimum 107% NR
if airspeed is above Vbroc (Vy), then decelerate to Vbroc or Vtoss
as appropriate and obtain 100% NR)
 Adjust pitch attitude to achieved Vtoss
 PM raises the landing gear at positive rate of climb
 When obstacles clearance is assured, accelerate to Vbroc (Vy),
select OEI 2M when 30seg power has elapsed
 Perform immediate actions when able
 Monitor OEI time constraints, select OEI MCP, at desired altitude,
adjust NR to 107% before accelerating above Vbroc
 At safe altitude not less than 500 feet, call for after takeoff checks or
emergency checklist as appropriate




OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.10
Revision: 02
Date: 04/01/2019



Engine failure before TDP
FLIGHT EVENT PM PF
Engine failure before
TDP
Eng OUT # XX
Torque split
Cancel engine out
tone
Rejecting
Takeoff Rejection Monitors airspeed,
altitude and pitch
attitude during landing
Decelerates, no more
than 10° pitch up
attitude below 30 feet
30 feet “Below 10” or calls
“Check pitch “ with
pitch attitude in excess
of 10°, 30 feet
RADALT or less
Sets maximum 10°
pitch attitude


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.11
Revision: 02
Date: 04/01/2019


Aircraft on ground Conducts immediate
actions on PF’s
command
Lowers collective and
brakes as required,
calls “immediate
actions”

Engine failure at or after TDP:
FLIGHT EVENT PM PF
Engine Failure at or
after TDP (V1)
Eng Out #XX
Toque split

Cancel engine out
tone
Continuing

Rate of climb Positive rate of
climb
Gear Up

Maintain 100% NR
and manage OEI
limiter
Vtoss (V2) V2 Selects 2min OEI
powerafter 30
seconds. Maintains
Vtoos until clear of
obstacles, and adjusts
collective to maintain
100% NR
Clear of obstacles Clear of obstacles Accelerates to Vbroc
(Vy), when safe OEI
flight calls: Immediate
Actions
Airspeed
approaches Vbroc (
Vy)
74 knotsat Sea
Level, decreasing 1
knot per every 1000
feet PA increase)
 Vbroc Maintais Vbroc (Vy)
and 100% NR until
reaching minimum
safe altitude, then
adjust Nr to 107%
before exceeding
Vbroc. Select MCP at


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.12
Revision: 02
Date: 04/01/2019


MSA or 2min
whichever first
Altitude passes 500
feet
500 feet After takeoff checks
/ ECL
Safe Altitude Emergency checklist

6.13.2 RUNWAY CLASS 2 ENGINE FAILURE
The Procedure is the same as for the runway class 1
However, in this case there is no defined TDP. The PF will make a decision
whether to fly away or not, based on the landing area remaining, by calling
COMMITTED. There is a common tendency to underestimate the RTOD in
an OEI condition
Before the “committed “call the PF will reject in the same manner as class 1
with the same calls.
After the “committed” call the PF will continue the takeoff in the same
manner as class 1 with the same calls.

6.13.3 OFFSHORE HELIDECK ENGINE FAILURE
Engine failure before rotation at TDP
 PF call Rejecting
 Ensure no drift and descend vertically to the deck
 Apply collective to cushion the touchdown
 When on deck, centre cyclic and lower collective gently. Perform
immediate actions
 Continue with emergency checklist

Engine failure at or after TDP, continued takeoff
 Set 15° to 20° pitch down (see note below)
 Adjust collective to maintain 100% NR when clear of the helideck
 When PM calls 35 knots or 50 feet, whichever comes first,
smoothly raise pitch up to horizon to achieve Vtoss (V2)
 At Vtoss (V2) climbing, monitor and select OEI 2min when
appropriate. PM raises landing gear
 Perform immediate actions when able


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.13
Revision: 02
Date: 04/01/2019


 Continue a climb acceleration to Vbroc (Vy) and continue climb at
Vbroc (Vy)
 When arriving at MSA, before exceeding Vbroc, recover Nr 107%
and set OEI MCP power
 At 500 feet, call for after takeoff checks or the emergency checklist,
as appropriate

Note:
Having committed the helicopter to a continued takeoff , it is important to
gain the optimum pitch rate and attitude to give the best chance of missing
the deck edge. The pith attitude detailed here is deemed to be the optimum.
However, there will inevitably be a compromise between these figures should
be reduced. The pitch down attitude may be reduced as a function of wind
speed. Any lowering of the collective during the initial rotation pitch down will
increases: this is important to minimize height loss during the procedure.

Engine failure at or after TDP (rotation), water landing
If airspeed and/or available dropdown preclude OEI acceleration to Vtoss,
or PM calls 35 knots or 50 feet and it becomes obvious that ditching is
inevitable, initiate a slow flare at 50 feet to decelerate and achieve a water
landing with minimum forward speed and drift
 Flare to 10° nose up to reduce forward speed and rate of descent
PF call “Ditching” and deploy the floats.
 PM calls Impact Position
 Ensure no drift and cushion the ditching with collective
 After touchdown, center cyclic and lower collective gently
 Perform immediate actions



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.14
Revision: 02
Date: 04/01/2019




Engine failure before TDP (Rotation):
FLIGHT EVENT PM PF
After Takeoff check Takeoff check
Complete
 Lift
Engine failure before
TDP ( before
rotation)
Eng Out # XX
Torque Split
Cancels Engine out
tone
Rejecting
Departure Rejecting At 10ft Apply CLTV for
control the impact


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.15
Revision: 02
Date: 04/01/2019


Aircraft on ground Conducts immediate
action on PF’s
command
Lowers collective
“Immediate actions”

Engine failure after TDP (water landing)
FLIGHT EVENT PM PF
TDP arrival 20 feet 20 feet Rotating
Engine failure at or
after TDP
Eng Out # XX
Torque Split
Cancels engine out
tone
Continuing, lowers
pitch attitude 15° to
20° pitch down

Adjust collective to
droop NR to 100%
and against OEI
limiter
50 feet ASL 50ft, negative climb Ditching (deploys
floats)
Adjusts pitch attitude
for water landing,
maximum 33 knots
After touchdown Immediate Actions

Engine failure at or after TDP (continued takeoff):
FLIGHT EVENT PM PF
TDP arrival 20 feet 20 feet Rotating
Rate of Climb on VSI
and altimeter
Eng Out #XX

Cancels engine out
tone
Adjust attitude for
Vtoss
Rate of Climb on VSI
and altimeter
Positive rate of climb Gear Up
Vtoss Vtoss


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.16
Revision: 02
Date: 04/01/2019


200 feet 200 feet Maintain appropriate
OEI limits, accelerate
to Vbroc
Airspeed approaches
Vbroc

(74kts at SL,
decreasing 1 knot per
1000 feet PA
increase)
Vbroc Maintains Vbroc and
100% NR until
reaching MSA, then
adjust Nr to 107%
before exceeding
Vbroc
Safe Altitude, 500 feet
or more
 Emergency checklist
Or / and
After takeoff checks

Note:
I. The ability to reach flyaway an engine failure depends on several
factors: aircraft position at the time of failure, fross weight, helideck
height, wind and OAT
II. The aircraft, may be at a low altitude or in ground effect some
distance from the ring. The Pm should monitor and call NR,
airspeed and RADALT height
III. During an PEI continued takeoff from an elevated helideck, it may
be advisable to establish a climb at Vtoss(V2) if there are
obstruction in the takeoff path or if it is considered necessary to
increase height above water prior to accelerating to Vbroc
IV. Under normal circumstances, climb straight ahead to at least 500
feet above the surface and accelerate to at least Vbroc ( Vy) or
mean wind speed plus 40 knots, if greater before manoeuvring or
carrying out any ECL checklist

6.13.4 ONSHORE HELIPAD ENGINE FAILURE
Onshore helipad engine failure (continued takeoff)
Same procedure is utilised as the offshore helideck failure (continue
takeoff)
Onshore helipad engine failure (continued takeoff with obstructions)


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.17
Revision: 02
Date: 04/01/2019


Same procedure is utilised as the offshore helideck engine failure(continue
takeoff), except Vtoss is maintained during climb out until clear of
obstructions.
Caution
During OEI recovery from a high hover the pilot must immediately lower the
collective in order to prevent NR decay. Difficultly in executing this
manoeuvre increases with the height at which a vertical recovery is
required.









OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.18
Revision: 02
Date: 04/01/2019


Engine failure before TDP (rejected takeoff):
FLIGHT EVENT PM PF
At hover Takeoff
Engine Failure
before TDP
Eng Out # XX
Torque split
Cancels engine ou
tone
Rejecting
Aicraft on ground Conducts immediate
actions on PF’s
command
Lower collective and
applies brakes as
required “immediate
actions “

Engine failure at or after TDP:
FLIGHT EVENT PM PFTDP arrival (briefed
RADALT value)
TDP Rotating
Engine failure at or
after TDP
Eng out #XX
Torque split

Continuing
Pitch attitude 10° to
15°
Positive Rate of
climb
Positive Rate of
Climb
Gear Up
Vbroc Vbroc Maintains Vbroc and
100% NR until
reaching MSA, then
adjust Nr to 107%
before exceeding
Vbroc
Safe altitude, 500
feet or above
 ECL and after takeoff
checklist



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.19
Revision: 02
Date: 04/01/2019


6.14 ENGINE FAILURE DURING APPROACH AND LANDING
6.14.1 RUNWAY ENGINE FAILURE CONTINUED LANDING
 Call Landing
 If high LDP profile, maintain 45knots until 50 feet. If low LDP
profile, maintain 60 knots until 75 feet
 Start flare at selected LDP
 Reduce speed, maintaining a constant attitude approach, to a
suitable groundspeed for the landing surface
 Conduct a rolling landing above effective translational lift if stop
distance is sufficent, otherwise if short-field or onshore
helipad(zero-speed touchdown), mange speed appropriately for
available stop distance
 Maintain NR above 100% until cushioning the touchdown
 Set 10° pitch up attitude below 30 feet
 When on the ground, centre cyclic, lower collective and apply
brakes as required. Perform immediate actions
 Continue with emergency checklist
 Complete after landing checklist

6.14.2 ENGINE FAILURE BEFORE LDP WITH GO-AROUND
 Call: Go-Around
 Adjust pitch attitude to obtain Vtoss
 Adjust collective if necessary to maintain 100% NR (below Vbroc
(Vy), (minimum 107% NF if airspeed is above Vbroc, then
decelerate to Vbroc or Vtoss as appropriate and obtain 100% NR)
 Positive Rate of Climb, Gear Up
 When obstacle clearance is assured, accelerate to Vbroc (Vy)
 Perform immediate actions when able
 Climb at Vbroc
 Manage OEI power within time constraints and NR 100%. Continue
climb to MSA
 At 500 feet, call for go-around checklist or the emergency checklist
drill, when appropriate.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.20
Revision: 02
Date: 04/01/2019




If a fire occurs late in the landing phase, a safe landing must take
precedence over fighting the fire.

6.15 OFFSHORE HELIDECK ENGINE FAILURE
The helideck engine failure procedures are identical to engine failure
runway procedures except at or after LDP, speed must be reduced for a
OEI zero speed touchdown. Additionally, if landing to water, the PF will
announce “Ditching, floats shall be deployed and operational limitations
with floats deployed shall be observed

6.15.1 ENGINE FAILURE BEFORE LDP, GO-AROUND
 Call Go-Around


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.21
Revision: 02
Date: 04/01/2019


 Maximum 15° pitch down
 Adjust collective if necessary to maintain 100% NR (below Vbroc
(Vy), (minimum 107% NF if airspeed is above Vbroc, then
decelerate to Vbroc or Vtoss as appropriate and obtain 100% NR)
 When PM calls airspeed alive or 50 feet positive rate of climb,
whichever comer first smoothly raise pitch up to obtain Vtoss
 When PM calls Positive rate of climb, floats off and gear up
 Continue a climbing acceleration to Vbroc (Vy), call for immediate
actions once established in safe OEI flight
 Manage OEI power against time contraints. At MSA, adjust NR to
107% and MCP ( if 2min power has not elapsed) and continue to
cruise OEI cruise flight
 At 500 feet, call for go-around checklist or the appropriate
emergency checklist drill, when appropriate

6.15.2 ENGINE FAILURE BEFORE LDP, WATER LANDING
If airspeed and/or available dropdown preclude OEI acceleration to Vtoss, it
becomes obvious that ditching is inevitable, initiate a slow flare at 50 feet to
decelerate and achieve a water landing with minimum forward speed and
drift
 Flare 10° nose up to reduce forward speed and rate of descent.
Call ditching and deploy the floats
 Ensure no drift and cushion the ditching with collective
 After touchdown, center cyclic and lower collective gently
Continue with emergency checklist

6.15.3 ENGINE FAILURE AT OF AFTER COMMITTAL POINT
 Committed
 If the obstacle environment allows, fly a straight-in or slightly offset
approach
 Set 10° nose up attitude below 30 feet
 Aim to cross the deck edge at between 20 to 25 feet above the
helideck at low speed
 Do not pause in the houver
 Ensure on drift and apply all available collective to cushion the
landing
 When on the ground, center cyclic and lower collective gently


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.22
Revision: 02
Date: 04/01/2019


 Continue with immediate actions and the emergency checklist as
appropriate


6.16 EXPANDED EMERGENCY CHECKLIST
Only the emergency checklist carried on board is to be used inflight.
The checklist has been completed taking into account the procedures
detailed in the flight manual and any additional procedures or restrictive
practices imposed by the company.
Each emergency ih the checklist has a number. The title shows the system
or component affected. They have been complied to take into account


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.23
Revision: 02
Date: 04/01/2019


procedures detailed in the flight manual, as well as any additional or more
restrictive company procedures.
The checklist are generally broken down into three sections:

6.16.1 INDICATIONS
The possible indications and symptoms of the malfunction are given
including any warning lights or captions, where appropriate. Warning lights
and captions are shown in colour to approximate as closely as possible to
the format seen in the aircraft, but allow better legibility during reduced
ambient light conditions.

6.16.2 ACTIONS
The required actions are numbered and listed in order of priority. Action
items surrounded by a black box are to be carried out from memory. When
the checklist is consulted, PM is to read through the boxed items first. He
then carries out the other items using the emergency checklist as a read
and do list.

6.16.3 CONSIDERATIONS
This section will cover any additional considerations that may be applicable
to a particular malfunction

6.17 ADDITIONAL CONSIDERATIONS FOR SINGLE ENGINE
FAILURE
Engine malfunctions can be divided into three types:
 Partial or total failure of the engine to provide power as demanded
 Failure of an engine control system
 Failure of an engine auxiliary system
In the case of a malfunction, the first responsibility of the crew is to
ensure continued safe flight until the malfunction can be diagnosed.
Particular care must be taken to confirm which engine has the
malfunction. When an engine failure occurs the PM should cancel the
ENGINE OUT warning tone.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.24
Revision: 02
Date: 04/01/2019


Care should be taken in confirming the failed engine prior to
commencing engine shutdown as given the Engine SHUTDOWN in
fight procedure. If the engine is shutdown, consider analyzing the
cause of the flame out with a view to restarting the engine. To attempt
restart use the Engine RESTART in flight procedure.

6.17.1 USE OF THE FLIGHT DIRECTOR
Coupling of the flight director following an engine failure will reduce pilot
workload significantly. When PF has the aircraft under control, the flight
director should be coupled in the 2-cue mode and the collective should be
manually adjusted to set de appropriate power.
In a climb out, engage HDG(or NAV)and IAS mode. Adjust the airspeed to
Vbroc. Once fully established in a climb at the required airspeed and
constant vertical speed, arm the ALTPRE mode and set the required
altitude in the AL300.
Ins a descent or approach, engage a lateral FD mode (as required) and
IAS mode and use collective to set the required rate of descent. If collective
command limits are not exceed.

6.18 ADDITIONAL CONSIDERATIONS DUAL ENGINE FAILURE
Varied conditions under which engine failure may occur prevent dictating a
standard procedure. Altitude and airspeed where the engines fail will
dictate the action taken to ensure a safe landing. On dual engine failure,
the helicopter nose will swing to the left due to reduction in torque as the
engine power decreases. Immediate collective reduction is required to
maintain NR within safe limits. Full down collective should be maintained
until NR recovers to the normal operating range. Once NR is within the
normal operating range, the collective should be applied to maintain NR
within the desired limits. Yaw pedals should be applied to maintain
heading. Currently, there is not a standalone low rotos audio / visual
warning available. NR must be closely monitored.

6.18.1 FAILURE IN THE HOUVER
Hold the aircraft in a level altitude, correct for lateral or aft drift and increase
collective to cushion the landing. Use yaw pedals to maintain heading.
Once on the ground, lower collective and apply the brakes.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.25
Revision: 02
Date: 04/01/2019



6.18.2 FAILURE IN CRUISE
Warning:
Rotor RPM will reduce to an unrecoverable state with resultant loss of control
unless autorotation is entered immediately following a dual engine failure.
Note:
Avoid excessive rapid reduction of collective at reduced rotor RPM while the cyclic
is near the full forward or full aft position. Avoid applying rapid cyclic motions
towards the forward or aft stop with the collective fully down.

 If power is lost over land at a height / speed combination below the
normal values for initiation of a flare (for example, just after TDP in
the climb), maintain the attitude and accept the resulting ground
speed. Any attempt to dive on speed will merely result in a
increased rate of descent, which is impossible to arrest
 Once established in a autorotation, restart of an engine will require
at least 35 seconds and probably at least 1700 feet to achieve. If
below 2000 feet do not attempt a restart, it may distract from the
landing. When the decision has been made not attempt a restart,
pull both t-handle aft
 While the target speed for autorotation is 75knots IAS, airspeed
may need to be varied in order to achieve a suitable landing area.
Better range, if necessary, is achievable by adjusting airspeed to
95knots IAS and drooping Nr to 91%; expect an increase in range
of just under 600 feet per 1000 feet of height by flying at 95knots
IAS instead of 75knots IAS. A comfortable ROD will be reached if
NR is adjusted between 100% to 105%
 If airspeed is reduced significantly below 75knots, at least 500 feet
may be required to recover airspeed and the recovery will involve
selecting and holding at least 20° nose down. In every case, the
aim is to be established at 75 knots IAS, into wind, with the highest
permissible NR (upt to 115%) by a minimum of 500feet above
touchdown
 PM shall make PA announcement stating: Position of impact
 PM should call out each 1000 feet, every 100 feet at and below
500 feet, 200 feet, 100 feet an 75 feet. All height calls below 1000
feet are to be radar altimeter readings
 At 75 feet flare to approximately 10° nose up. At 10 feet cushion
landing with collective. Maximum desired gorund contact speed is
40 knots ground speed.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.26
Revision: 02
Date: 04/01/2019


 Immediately after ground contact decrease collective pitch
smoothly and slowly neutralize cyclic and apply wheel brakes as
required. Effectiveness of directional control decreases with
decreasing NR after touchdown
 If landing on soft or rough ground, or ditching, flare harder initially,
aiming to reduce the ground speed to a minimum. This technique
will result in some loss of forward view and require a more
significant nose down correction by 10 feet above the surface, but
will help to reduce the impact forces
 At night or IMC, without visual contact with the surface, flare at 100
feet RADALT to 10° nose up. As the speed decays through
40knots or height passes 40feet, select and hold 10° nose up;
progressively apply all available collective to cushion the impact
 For ditching, aim for top of wave with swell from 30° to the left of
the nose. Maximum pitch attitude is 10° and maximum water
contact speed is 33knots ground speed.

6.19 ADDITIONAL CONSIDERATIONS FOR MAIN
GEARBOX FAILURES
Transmission system failures can be broken into three types:
1. Lubrication failurs
2. Component failures
3. Transmission accessory failures
The system temperature and pressure gauges, chip detection system, and
warning and caution lights should provide enough information to make an
informed decision if a mechanical transmission problem arises.
An impeding system failure may exhibit one or more of the following
symptoms:
1. Chip cautions from any of the transmission modules
2. Low MGB oil pressure with associated warning light
3. High transmission oil temperature with associated warning or
caution light
4. Increased power required at constant collective and airspeed
5. Aircraft yaw kicks
6. Howling, grinding or unusual noise from the main transmission
7. Increased medium or high frequency vibration levels
8. The odour of hot metal


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.27
Revision: 02
Date: 04/01/2019


In general a single failure indication dictates to land as soon as practicable
while a double failure dictates to land as soon as possible.
If multiple failures indications, including abnormal noise and/or vibration are
present, land immediately. Descend to an altitude from which a landing con
be quickly made with minimal power changes and fly at minimum power
speed. Descend at a reduced power setting, but with enough torque to
drive the transmission. Avoid rapid or frequent power changes. A running
landing if preferred since it requires lower power and smaller power
changes. A no-hover landing should be performed if a running landing area
is not available.

6.20 ADDITIONAL CONSIDERATIONS FOR TAIL ROTOR
MALFUNCTIONS
Tail rotor malfunctions may be caused by a wide variety of mechanical
failures with an equally broad range of resultant severity. It is imperative
that flight crew recognizes the differences in the symptoms associated with
each mode and to also recognize an impending failure.

6.20.1 LOSS OF TAIL ROTOR THRUST
Impending tail rotor drive failure may be preceded by excessive noise or
vibration from the tail rotor section.
With loss of tail rotor thrust, it is impossible to remain in level flight. This
failure is associated with a loss in drive and characterized by a sharp, right
yaw of the aircraft that requires immediate entry into autorotation (if in
forward flight) or landing (if in a hover). The severity of the initial yaw rate
will be determined by the airspeed, altitude, aircraft mass, centre of gravity
and power at the time of failure. The effectiveness of the vertical fin in
limiting the yaw rate and yaw angle will depend on the airspeed at the time
of the failure, fin effectiveness increasing at higher airspeeds.
Severe yaw rates will result in large yaw angles within a very short periodof time and, depending on the flight conditions at the time of failure, it is
possible that yaw angles in excess of 30° will be experienced. Additionally,
very high yaw rates will make the aircraft pitch and roll making retention of
control difficult without the use of large cyclics inputs, which are
undesirable. Finally, very high yaw rates will produce disorienting effects on
the pilots. Therefore, it is vital that corrective action be taken quickly to
prevent post-failure yaw rates from reaching unacceptably high levels.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.28
Revision: 02
Date: 04/01/2019


Once established in autorotation the aircraft can be flown to a stable pitch
and roll attitude with an acceptable level of sideslip

6.20.2 LOSS OF TAIL ROTOR CONTROL
Loss of tail rotor control in the inability to change tail rotor blade pitch
because of a mechanical failure in the yaw flight path, either due to a
mechanical restriction or damage to bellcranks, control rods or cables. The
tail rotor is still producing thrust however, and therefore this malfunction is
less critical than a loss of drive. In the event of mechanical failure of the tail
rotor cables, the self-centering tail rotor quadrant will return to a
predetermined position. This position maintains a tail rotor blade angle that
is the optimum for the anticipated flight conditions, thereby allowing level
flight to be maintained with an acceptable sideslip.

6.20.3 TAIL ROTOR CONTROL BINDING
With a bind or restriction, the pilot must deal with a tail rotor stuck at “fixed
pitch, the amount of which is dependent upon the yaw pedal position when
the failure takes place. Tail rotor pitch control binding is characterized
either by a lack of directional response, when a pedal is pushed, or by a
locked pedal. If pedals cannot be moved with a moderate amount of force,
do not attempt to apply maximum effort, since a more serious malfunction
could result. The resultant fixed tail rotor pitch will require the selection of a
combination of power, airspeed, and sideslip in order to maintain
controlled, fixed heading flight.

6.21 ADDITIONAL CONSIDERATIONS FOR TAIL ROTOR
DRIVE FAILURE IN CRUISE
 A sharp increase in tail rotor noise and/or vibration may be
indicative of damage to the tail rotor. Reduce speed towards 100
knots IAS and land as soon as possible
 Tail rotor drive system failure is always accompanied by a sharp
yaw to the right. Reduce collective as necessary to control the yaw.
Autorotation if necessary to control the yaw rate.
 Aim to land into wind. Try to recude lateral and forwards velocity to
minimum in the flare; ground contact speed should be held to a
minimum to reduce the tendency to roll over due to yaw
 On land use wheel brakes to try and maintain heading


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.29
Revision: 02
Date: 04/01/2019



6.22 ADDITIONAL CONSIDERATIONS FOR ELECTRICAL
FAILURES
The landing gear emergency down system requires power from the DC
essential system to operate. During a total electrical failure the first
consideration is to restore electrical power from one of the generators.
When electrical power cannot be restored select the landing gear lever
down and continue the procedure being aware that the fuel consumption
will be increased due to the lowered landing gear.

6.23 ADDITIONAL CONSIDERATIONS FOR DAFCS FAILURES
In the event of an uncommanded aircraft disturbance or oscillation during
coupled flight, initiate the applicable immediate action steps. Once the
aircraft under control, consult the ECL.
Note:
When operating with both autopilots engaged and with FD modes coupled, failure or
disengagement of either AP will automatically cancel the FD modes. Re-engaging the FD
modes is allowed, however coupling the FD to a single AP is inhibited. Manually control the
aircraft to satisfy the FD command cues.

6.23.1 LANDING WITH BOTH AUTOPILOTS INOPERATIVE
With both autopilots inoperative a running landing to a hard surface runway
is recommended, use the LDP ( 200 feet, 45knots and maximum
500feet/min) to minimise pitch attitude changes during the approach and
lading.
Landing at a helipad / helideck should be avoided when possible. To
prevent overcontrol minimise cyclic inputs as much as possible.

6.24 ADDITONAL GUINDANCE FOR DITCHING
 The flotation system is designed only for emergency landing on
water and is expected to keep the helicopter upright long enough to
permit passengers and crew to exit to life-rafts or rescue boats. A
subsequent takeoff or long term towing should not be attempted.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.30
Revision: 02
Date: 04/01/2019


 When it appears that ditching is likely, consideration must be given
to such factors as wind velocity, sea state conditions and helicopter
power available for ditching. The maximum permissible water entry
conditions are 33 knots ground speed at 300 feet/min ROD in a
calm sea. Optimum ditching conditions would occur in a calm sea
state with near zero forward and lateral helicopter speed. Minimum
touchdown forces will a minimum rate of descent. Greatly
increased touchdown forces will be experienced if the landing is
made on the front or rising face of a wave.
 Every effort should be made to land the helicopter with as little
sideward drift as possible as the roll rate after touchdown increases
sharply with any increases in lateral motion. Ditching with power
available (such as when fuel starvation is imminent, or a loss of
transmission oil pressure dictates such action) will greatly increase
controllability, reduce touchdown forces, and assist in preventing
the helicopter from rolling after impact. Power-off ditching
(autorotation) should be avoided if possible.
 With sufficient power available to fully control the helicopter
descent rate, sideward drift and forward speed to near zero
values, successful ditching may be accomplished in sea states up
to and including sea state 4, depending on wind conditions.
 All possible control available from the rotor system should be used
to prevent rolling after impact. Consideration should be given to
extended power-on water taxi, if wave conditions makes rotor to
water contact improbable. Power-on water taxi will greatly increase
the roll stability of the helicopter and will allow yaw and heading
control. If the helicopter is unstable or taking on water shut down
both engines. When shutting down, the rotor brakes should only be
used if a sudden helicopter evacuation is required. When using the
rotor brake, application should be gentle, since the application may
cause the helicopter to roll and turn to the left.
 The floats may be inflated at any time during the ditching
procedure, below 75knots IAS and 500 feet. Allow sufficient time
for full inflation before water contact. Float inflation time is within 10
seconds.
 The following general ditching techniques are recommended as the
best for a successful controlled emergency landing on water;
o Land in the proximity of ships or offshore installations if
possible
o Activate the floats in a hover if sufficient power is available
o Reduce forward speed to as near zero as possible
o Reduce lateral drift component to a minimum
o Reduce rate of descent to minimum at touchdown


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 6.31
Revision: 02
Date: 04/01/2019


o Avoid rising faces of larges waves
o Attempt to touchdown, into the wind, as near the crest or
back of a wave as possible to minimise impact vertical
velocity
o Fuselage angle at impact should be between 0° to 10°
nose upo Use all control available from the rotor system to prevent
the helicopter from pitching and rolling after touchdown

Warning:
Do not evacuate the helicopter until the rotor blades have stopped turning. Do not inflate life-
jackets until clear of the helicopter.

Caution:
Operation of the landing gear during or after float inflation may result in damage to the floats
and partial loss of flotation capability

Note:
1. Should the floats fail to inflate, the same procedures should be followed, but brief
passengers to evacuate the helicopter as soon as the rotor blades have stopped
2. When ditching, the landing gear should be extended before deploying the floats.
However, if landing gear cannot be extended for any reason, the floats can be
deployed with the gear rtracted.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.32
Revision: 02
Date: 04/01/2019


SECTION 7.
PBN OPERATIONS
7.1 PURPOSE
This Section provides the operating procedures for the SIKORSKY S
76C’s PBN operations.
7.2 PBN EQUIPMENT AND SYSTEM
Equipment /
Nomenclature
Quant Manufacturer
Model /
Part Number
TSO Class
GPS 1 Garmin GPS 500W TSO-C146a C1
VOR 2 Rockwell Collins VIR 32
76202-04015-020
TSO-C34d
TSO-C35d
TSO-C36d
TSO-C40b
N/A
DME 1 Rockwell Collins DME-42
622-6524-003
TSO-C66b N/A
7.3 GPS GARMIN 500W
The GPS 500W System is a fully integrated, panel-mounted
instrument, which contains a Global Positioning System (GPS)
Navigation computer. The system consists of a GPS antenna and GPS
Receiver. The primary function of the GPS portion of the system is to
acquire signals from the GPS system satellites, recover orbital data,
make range and Doppler measurements, and process this information
in real-time to obtain the user's position, velocity, and time.
Provided the GARMIN GPS 500W's GPS receiver is receiving
adequate usable signals, it has been demonstrated capable of and has
been shown to meet the accuracy specifications for:
 VFR/IFR en-route, terminal, and non-precision instrument approach
(GPS, VOR, VOR-DME, TACAW, NDB, NDB-DME, RNAV) and
approach procedures with vertical guidance operation in accordance
with AC 20-138A.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.33
Revision: 02
Date: 04/01/2019


 The system meets RNP5 airspace (BRNAV) requirements of AC 90-96
and in accordance with AC 20-138A, and JAA AM J 20X2 Leaflet 2
Revision 1, provided it is receiving usable navigation information from
the GPS receiver.
Navigation is accomplished using the WGS-84 (NAD-83) coordinate
reference datum- Navigation data is based upon use of only the Global
Positioning System (GPS) operated by the United States of America.
The Garmin display screen lighting is controlled by an internal
photocell and the adjacent Garmin switch back lighting is controlled by
the non-flight instrument rheostat.
7.4 OPERATING PROCEDURES
7.4.1 GENERAL
OMNI’s pilots should not request PBN operations unless they satisfy
all the criteria for the type of operation. If an aircraft not meeting these
criteria receives a clearance from ATC to conduct an RNAV/RNP
procedure, the pilot must advise ATC that he/she is unable to accept
the clearance and must request alternate instructions.
During the flight, where feasible, the pilot should use available data
from ground-based NAVAIDs to confirm navigational reasonableness.
For normal operations, cross-track error/deviation (the difference
between the RNAV system-computed path and the aircraft position
relative to the path) should be limited to ±½ the navigation accuracy
associated with the procedure or route (i.e. RNAV 5: 2.5 NM / RNAV
1: 0.5NM). Brief deviations from this standard (e.g. overshoots or
undershoots) during and immediately after procedure/route turns, up
to a maximum of one times the navigation accuracy (i.e. RNAV 5: 5
NM / RNAV 1: 1 NM), are allowable.
If ATS issues a heading assignment taking the aircraft off a route, the
pilot should not modify the flight plan in the RNAV/RNP system until a
clearance is received to rejoin the route or the controller confirms a
new clearance. When the aircraft is not on the published route, the
specified accuracy requirement does not apply.
a - SID SPECIFIC REQUIREMENTS
Prior to commencing take-off, pilots must verify the aircraft navigation
system is operating correctly and the correct runway and departure
procedure (including any applicable en-route transition) are entered


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.34
Revision: 02
Date: 04/01/2019


and properly depicted. Pilots who are assigned an RNAV/RNP
departure procedure and subsequently receive a change of runway,
procedure or transition must verify the appropriate changes are
entered and available for navigation prior to take-off.
Note: Pilots must not fly an RNP 1 SID unless it is retrievable by
procedure name from the on-board navigation database and
conforms to the charted procedure.
Note: When using GNSS, the signal must be acquired before the take-
off roll commences. If the departure begins at a runway waypoint,
then the departure airport does not need to be in the flight plan
to obtain appropriate monitoring and sensitivity.
b - STAR SPECIFIC REQUIREMENTS
Prior to the arrival phase, the pilot should verify that the correct
terminal route has been loaded. The active flight plan should be
checked by comparing the charts with the map display. This includes
confirmation of the waypoint sequence, reasonableness of track
angles and distances, any altitude or speed constraints, and, where
possible, which waypoints are fly-by and which are fly-over. If required
by a route, a check will need to be made to confirm that updating will
exclude a particular NAVAID. A route must not be used if doubt exists
as to the validity of the route in the navigation database.
Pilots must not fly an RNP 1 STAR unless it is retrievable by procedure
name from the on-board navigation database and conforms to the
charted procedure.
Note: As a minimum, the arrival checks could be a simple inspection of
a suitable map display that achieves the objectives of this
paragraph.
The creation of new waypoints by manual entry into the RNAV system
by the pilot would invalidate the route and is not permitted.
Where the contingency procedure requires reversion to a conventional
arrival route, necessary preparations must be completed before
commencing the RNAV route.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.35
Revision: 02
Date: 04/01/2019


Route modifications in the terminal area may take the form of radar
headings or “direct to” clearances and the pilot must be capable of
reacting in a timely fashion. This may include the insertion of tactical
waypoints loaded from the database. Manual entry or modification by
the pilot of the loaded route, using temporary waypoints or fixes not
provided in the database, is not permitted.
Pilots must verify their aircraft navigation system is operating correctly
and the correct arrival procedure and runway (including any applicable
transition) are entered and properly depicted.
Although a particular method is not mandated, any published altitude
and speed constraints must be observed.

7.4.2 PRE-FLIGHT PLANNING
Flight Plan: ...................................................................... FILLED, LETTER R
Pilots should use the appropriate ICAO flight plan designation
specified for the RNAV/RNP route flown. The letter “R” should be
placed in block 10 of the ICAO flight plan to indicate the pilot has
reviewed the planned route of flight to determine RNAV/RNP
requirements andthe aircraft and operator have been approved on
routes where RNAV/RNP is a requirement for operation. Additional
information needs to be displayed in the remarks section that indicates
the accuracy capability (See MGO Section 16).
Navigation database: ......................................................................... CHECK
The on-board navigation database must be current and must contain
the appropriate procedures, routes, waypoints and NAVAIDs.
Pilots should ensure that approaches that are to be used for the
intended flight (including those at alternate aerodromes) are not
prohibited by a company instruction or NOTAM and are selectable
from a valid aeronautical navigation database (current AIRAC cycle)
that has been verified by the appropriate process of the supplier.
RAIM Prediction: ................................................................................ CHECK
A check must be carried out on the availability of appropriate
NAVAIDs, including, where appropriate, RAIM prediction (for the
period of intended operations). Any relevant NOTAMS must be
addressed.
During the pre-flight planning phase, the availability of RAIM (or
equivalent monitor) at the destination should be verified as closely as
possible before takeoff, and in any event, not more than 24 hours


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.36
Revision: 02
Date: 04/01/2019


before take-off (RAIM should be available from 15 minutes before the
Estimated Time of Arrival (ETA) until 15 minutes after ETA). This may
be established either by an internal function of the receiver or an Air
Navigation Service Provider (ANSP) may offer an approved RAIM
availability service to users (for example:
http://augur.ecacnav.com/npa.html).
NOTE: Receiver-based RAIM prediction programs are not able to
predict short notice 'outages' and failures, and will not take
account of scheduled disruptions to the satellite signals.
Consequently, a receiver-based RAIM prediction may appear
sound when the actual availability proves insufficient to provide
the RAIM function. RAIM predictions do not normally take
account of terrain above the horizon. Where terrain interrupts
the 'view' of a satellite from the receiver as the aircraft descends
on approach, availability may be affected.
NOTE: Research has shown that such independently available RAIM
prediction tools may not have the latest accurate availability
data and are also unable to predict short notice outages and
failures. A RAIM prediction from these service providers is also
not guaranteed.
In the event of a predicted, continuous loss of appropriate level of fault
detection of more than five minutes for any part of the RNAV operation,
the flight plan should be revised (e.g. delaying the departure or
planning a different departure procedure).
Alternate approach: ....................................................................IDENTIFIED
Pilots must identify alternate approaches in the event of a loss of
RNAV capability. The appropriate installed equipment must be
serviceable.

7.4.3 AFTER START
GPS ................................................................................................ ON / SET
Pilots should confirm the status of the system and correct operation
before flight.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.37
Revision: 02
Date: 04/01/2019


On power up, Pilots should confirm the navigation database is current
and verify self-test properly performed. Check aircraft position, date
and time.
Once the database has been acknowledged, the Instrument Panel
Self-Test Page appears. To ensure that GPS unit and any connected
instruments are working properly, check for the following indications
on your CDI/HSI, RMI, external annunciators and other connected
instruments:
 Course deviation
 Glideslope
 TO/FROM flag
 Time to destination
 Bearing to destination
 Desired track
 Distance to destination
 Ground speed
 All external annunciators
Pilots should create and active a Flight Plan and insert a SID and
waypoints, verifying proper entry of their ATC assigned route upon
initial clearance and any subsequent change of route;
Pilots should ensure the waypoints sequence, depicted by their
navigation system, matches the route depicted on the appropriate
chart(s) and their assigned route. If required, the exclusion of specific
NAVAIDs should be confirmed.
Pilots should define the CDI scale. The default setting is “Auto”. At this
setting, when leaving your departure airport the CDI scale is set to 1.0
NM and gradually ramps up to 2 NM beyond 30 NM (from the
departure airport). En-route phase of flight the CDI scale is set to 2.0
NM.

Pilots should perform RAIM Prediction.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.38
Revision: 02
Date: 04/01/2019


Procedures are detail in Section 2 – GPS Normal Procedures, item 2.2
Power ON, 2.3 Flight Plan, 2.4 Select Departure, 2.9 To Activated an
Existing Flight Plan, 2.14 RAIM Prediction and 2.17 CDI Scale Setting
of this SOP or for further information refer to GPS 500W Pilot’s Guide.

7.4.4 PRE TAKEOFF
NAV AIDs .............................................................................. SET / XCHECK
Pilots must verify the aircraft navigation system is operating correctly
and the correct runway and departure procedure (including any
applicable en-route transition) are entered and properly depicted.
Pilots who are assigned an RNAV/RNP departure procedure and
subsequently receive a change of runway, procedure or transition
must verify the appropriate changes are entered and available for
navigation prior to take-off.

7.4.5 APPROACH / DESCENT
NAV AIDs .............................................................................. SET / XCHECK
Before reaching the IAF, Pilots should verify that the correct terminal
route has been loaded. The active flight plan should be checked by
comparing the charts with the map display. This includes confirmation
of the waypoint sequence, reasonableness of track angles and
distances of the approach legs, accuracy of the inbound course and
mileage of the final approach segment, any altitude or speed
constraints, and, where possible, which waypoints are fly-by and which
are fly-over.
Pilots should verify CDI / Alarms and define the scale. The default
setting is “Auto”. At this setting, the CDI scale is set to 2.0 NM during
the “en route” phase of flight. Within 31 NM of your destination airport,
the CDI scale gradually ramps down to 1.0 NM (terminal area).


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.39
Revision: 02
Date: 04/01/2019



Pilots confirm revised ETA (within RAIM Prediction Window).
Procedures are detail in Section 8 – GPS Normal Procedures, 8.5
Select Arrival (STAR), 8.6 Select an Approach, 8.7 Select Departure,
Arrival and Approach by PROC key, 8.14 RAIM Prediction, 8.15 Basic
Approach Operation and 8.17 CDI Scale Setting of this SOP or for
further information refer to GPS 500W Pilot’s Guide.
Approach Mode.......................................................................... ACTIVATED
By the time the aircraft reaches the IAF the pilots should have
completed the above and been cleared for the approach. Pilot should
verify if the Approach was activating.
During approach operations the CDI scale gradually transitions down
to an angular CDI scale. At 2.0 NM of the final approach fix (FAF), CDI
scaling is tightened from 1.0 to the angular full scale deflection (0.3
NM).
Procedures are detail in Section 8 – GPS Normal Procedures, 8.6
Select an Approach, 8.7 Select Departure, Arrival and Approach by
PROC key, 8.15 BasicApproach Operation and 8.17 CDI Scale
Setting of this SOP or for further information refer to GPS 500W Pilot’s
Guide.
Crosstrack Error ............................................................................... XCHECK
Before making any RNAV approach, pilots should perform a gross
error crosscheck fix with a terrestrial navigation aid (such as a
VOR/DME) and check that the GPS position correlates with this
crosscheck fix. This crosscheck should be completed at or before the
IAF. When working correctly, the accuracy of GPS will often expose
the operational error of the terrestrial navigation aid. Errors of up to 5º
may be normal in a VOR display, and DME may only be accurate to


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.40
Revision: 02
Date: 04/01/2019


about half a mile. DME indicates slant range but GPS displays
horizontal range, giving rise to a further small discrepancy, which
increases as you approach the DME station overhead.

7.4.6 CONTINGENCY PROCEDURES
The pilot must notify ATC of any loss of the RNAV/RNP capability,
together with the proposed course of action. If unable to comply with
the requirements of an RNAV/RNP route, pilots must advise ATS as
soon as possible. The loss of RNAV/RNP capability includes any
failure or event causing the aircraft to no longer satisfy the RNAV/RNP
requirements of the route.
For GPS-based approaches, receiver autonomous integrity monitoring
(RAIM) will monitor satellite conditions and alert you using an “INTEG”
annunciation at the bottom left corner of the display if protection limits
cannot be maintained.

If this occurs, the GPS receiver should not be used for primary
navigation guidance. Revert to an alternate navigation source. LPV,
LNAV+V, and L/VNAV approaches will downgrade to LNAV if GPS
integrity cannot be met. There is no need to switch to guidance by
other navigation equipment unless GPS LNAV is insufficient or
integrity degrades further.
In the event of communications failure, the pilot should continue with
the RNAV/RNP route in accordance with established lost
communications procedures.
7.5 EXTENDED PBN OPERATING CHECKLIST
NORMAL CHECK LIST
Extended PBN operating procedures are inside the green box.
PRE-FLIGHT PLANNING
FLIGHT PLAN ...................................FILLED, LETTER R
NAVIGATION DATABASE .................................. CHECK
RAIM PREDICTION ............................................. CHECK


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 7.41
Revision: 02
Date: 04/01/2019


ALTERNATE APPROACH .......................... IDENTIFIED
BEFORE START
STARTING ENGINES
AFTER START
GPS .................................................................... ON/SET
TAXING CHECK
PRE TAKEOFF
NAV AIDs .................................................. SET/XCHECK
TAKEOFF
AFTER TAKEOFF
CRUISE
APPROACH / DESCENT
NAV AIDs .................................................. SET/XCHECK
APPROACH MODE .......................................... ACTIVED
CROSSTRACK ERROR ................................... XCHECK
PRE LANDING
AFTER LANDING
SHUT DOWN



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.1
Revision: 02
Date: 04/01/2019


SECTION 8.
GPS NORMAL PROCEDURES
8.1 INTRODUCTION
This section describes the operational procedures of the GPS Garmin
500W.
The GPS 500W is TSO C146a certified for primary domestic, oceanic,
and remote navigation including en route, terminal, and non-precision
approaches, and approaches with vertical guidance, such as LPV and
LNAV/VNAV. The GPS 500W can simultaneously give approach
information and weather and traffic data in relation to their position on
a large, color moving map display.
8.2 POWER ON
1. Turn the COM power/volume knob clockwise to turn the unit on and
set the desired radio volume.
2. The Main and GPS software version page appears briefly, followed
by land and terrain database pages, as the unit conducts self-tests to
ensure proper operation.
3. Once the self-test concludes, database confirmation pages are
displayed, showing the effective and expiration dates of the databases
on the NavData® card. Press the ENT key to acknowledge the last
database page and proceed to the instrument panel self-test page.
4. The instrument panel self-test page allows to verify that the unit is
communicating properly with in-panel instruments. Compare on-
screen indications with the information depicted on connected
instruments, such as the CDI, HSI, RMI and/or external annunciators.
Once you have verified proper operation, turn the large right knob to
select "Set Full Fuel?", "Go To Checklist", or "OK?" (to display the
Satellite Status Page), and then press the ENT key.
5. When the GPS receiver has acquired a sufficient number of
satellites to determine a position, the Map Page is automatically
displayed showing your present position.
8.3 FLIGHT PLAN



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.2
Revision: 02
Date: 04/01/2019


8.3.1 CREATE A NEW FLIGHT PLAN
1. Press FPL and turn the small right knob to display the Flight Plan
Catalog.
2. Press MENU to display the Flight Plan Catalog Options.
3. Turn the large right knob to highlight “Create New Flight Plan?” and
press ENT.
4. A blank flight plan page will appear for the first empty storage
location. Use the small and large right knobs to enter the identifier of
the departure waypoint and press ENT.
5. Repeat step #4 above to enter the identifier for each additional flight
plan waypoint.
6. Once all waypoints have been entered, press the small right knob
to return to the Flight Plan Catalog.
NOTE: Any time you activate a flight plan, a copy of the flight plan is
automatically transferred to “flight plan 0” and overwrites any
previously active flight plan
8.3.2 FLIGHT PLAN EDITING
To add a waypoint to an existing flight plan:
1. Press FPL and turn the small right knob to display the Flight Plan
Catalog.
2. Press the small right knob to activate the cursor.
3. Turn the large right knob to highlight the desired flight plan and press
ENT.
4. Turn the large right knob to select the point where you wish to add
the new waypoint. If an existing waypoint is highlighted, the new
waypoint is placed directly in front of this waypoint.
8.4 SELECT DEPARTURE (SID)
To select a published standard instrument departure (SID) for the
departure airport, or replace the current departure with a new
selection, proceed as follow:
1. From the Active Flight Plan Page, press MENU to display the Active
Flight Plan Page Options.
2. Highlight the “Select Departure?” option from the Active Flight Plan
Page Options and press ENT.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.3
Revision: 02
Date: 04/01/2019


3. A window appears listing the available departures for your departure
airport. Turn the small right knob to select the desired departure and
press ENT.
4. A second window appears listing available transitions for the
departure. Turn the small right knob to highlight the desired transition
waypoint and press ENT.
5. A third window appears listing available runways for the departure.
Turn the small right knob to highlight the desired runway and press
ENT.
6. With “Load?” highlighted, press ENT. The departure is now inserted
into your flight plan.
8.5 SELECT ARRIVAL (STAR)
To select a published standard terminal arrival route (STAR) for the
destination airport, or replace the current arrival with a new selection,
proceed as follow:
1. From the Active Flight Plan Page, press MENU to display the Active
Flight Plan Page Options.
2. Highlightthe “Select Arrival?” option and press ENT.
3. A window appears listing the available arrivals for your destination
airport. Turn the small right knob to select the desired arrival and press
ENT.
4. A second window appears listing available transitions for the arrival.
Turn the small right knob to highlight the desired transition waypoint
and press ENT.
5. A third window appears listing available runways for the arrival. Turn
the small right knob to highlight the desired runway and press ENT.
6. With “Load?” highlighted, press ENT. The arrival is now inserted into
your flight plan.
8.6 SELECT AN APPROACH
1. From the Active Flight Plan Page, press MENU to display the Active
Flight Plan Page Options.
2. Highlight the “Select Approach?” option and press ENT.
3. A window appears listing the available approaches for your
destination airport. Turn the small right knob to highlight the desired
approach and press ENT.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.4
Revision: 02
Date: 04/01/2019


4. A second window appears listing available transitions for the
approach. Turn the small right knob to highlight the desired transition
waypoint and press ENT.
5. Turn the large right knob to highlight “Load?” or “Activate?” and
press ENT.
 “Load?” adds the approach to the flight plan without immediately using
the approach for navigation guidance. This allows you to continue
navigating the original flight plan until cleared for the approach, but keeps
the approach available for quick activation when needed.
 “Activate?” adds the approach to the flight plan and begins navigating
the approach course.
6. For precision approaches, and non-precision approaches not
approved for GPS, a reminder window appears indicating that GPS
guidance on such approaches is strictly for monitoring only. To confirm
this reminder, highlight “Yes?” and press ENT.
8.7 TO SELECT DEPARTURE, ARRIVAL OR AN
APPROACH BY PROC KEY:
1. Press the PROC key to display the Procedures Page.
2. Turn the large right knob to highlight “Select Approach?”, “Select
Departure?” or “Select Arrival?” and press ENT.
3. A window appears listing the available procedures. Turn the large
right knob to highlight the desired procedure and press ENT. (When a
direct-to destination is selected, departures are offered for the nearest
airport.)
4. A second window appears listing the available transitions. Turn the
large right knob to highlight the desired transition waypoint and press
ENT. (The approach “Vectors” option assumes you will receive vectors
to the final course segment of the approach and will provide navigation
guidance relative to the final approach course.)
5. Turn the large right knob to highlight “Load?” or “Activate?”
(approaches only) and press ENT. “Load?” adds the procedure to the
flight plan without immediately using it for navigation guidance. This
allows to continue navigating the original flight plan, but keeps the
procedure available on the Active Flight Plan Page for quick activation
when needed to later activate a departure orarrival.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.5
Revision: 02
Date: 04/01/2019


6. For VLOC-based precision approaches and some non-precision
approaches, a reminder window appears indicating that GPS guidance
on such approaches is strictly for monitoring only — use the VLOC
receiver and external CDI (or HSI) for primary navigation. To confirm
this reminder, highlight “Yes?” and press ENT.
8.8 TO REMOVE AN APPROACH, ARRIVAL OR
DEPARTURE FROM THE ACTIVE FLIGHT PLAN:
1. From the Active Flight Plan Page, press MENU to display the Active
Flight Plan Page Options.
2. Select the “Remove Approach?”, “Remove Arrival?” or “Remove
Departure?” option and press ENT.
3. A confirmation window appears listing the procedure you are about
to remove. With “Yes?” highlighted, press ENT.
8.9 TO ACTIVATE AN EXISTING FLIGHT PLAN
1. From the Flight Plan Catalog, press the small right knob to activate
the cursor.
2. Turn the large right knob to highlight the desired flight plan and press
MENU to display the Flight Plan Catalog Options.
3. Turn the large right knob to highlight “Activate Flight Plan?” and
press ENT.
8.10 TO NAVIGATE A FLIGHT PLAN
1. Press FPL and turn the small right knob to display the Flight Plan
Catalog.
2. Press the small right knob to activate the cursor.
3. Turn the large right knob to highlight the desired flight plan and press
MENU to display the Flight Plan Catalog Options.
4. Turn the large right knob to highlight “Activate Flight Plan?” and
press ENT.
8.11 INVERTING FLIGHT PLAN
To activate an existing flight plan in reverse order:
1. From the Flight Plan Catalog, press the small right knob to activate
the cursor.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.6
Revision: 02
Date: 04/01/2019


2. Turn the large right knob to highlight the desired flight plan and press
MENU to display the Flight Plan Catalog Options.
3. Turn the large right knob to highlight “Invert & Activate FPL?” and
press ENT. The original flight plan remains intact in its Flight Plan
Catalog storage location.
8.12 TO DELETE A FLIGHT PLAN:
1a. From the Active Flight Plan Page: Press MENU to display the
Active Flight Plan Options window.
OR
1b. From the Flight Plan Catalog: Press the small right knob to activate
the cursor, turn the large right knob to highlight the flight plan you wish
to delete, then press MENU to display the Flight Plan Catalog Options.
2. Turn the large right knob to highlight “Delete Flight Plan?” and press
ENT.
3. With “Yes?” highlighted, press ENT to delete the flight plan.
8.13 TO PERFORM TRIP PLANNING OPERATIONS:
1. Select “Trip Planning” from the Flight Planning Page.
2. The current trip planning “leg mode” is displayed at the top of the
page: “POINT TO POINT” or “FPL LEG” (for a flight plan leg). To
change the leg mode, press MENU to display an options window for
the other leg mode, then press ENT to accept the other leg mode.
3a. For direct-to planning, verify that the “from” waypoint field indicates
“P.POS” (present position). If necessary, press CLR to display
“P.POS”. Press ENT and the flashing cursor moves to the “to”
waypoint field. Turn the small and large right knobs to enter the
identifier of the “to” waypoint and press ENT to accept the waypoint.
OR,
3b. For point-to-point trip planning, turn the small and large right knobs
to enter the identifier of the “from” waypoint. Once the waypoint’s
identifier is entered, press ENT to accept the waypoint. The flashing
cursor moves to the “to” waypoint. Again, turn the small and large right
knobs to enter the identifier of the “to” waypoint and press ENT to
accept the waypoint.
OR,
3c. For “flight plan leg” trip planning, turn the small right knob to select
the desired flight plan (already stored in memory), by number. Turn the


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.7
Revision: 02
Date: 04/01/2019


large right knob to highlight the “LEG” field and turn the small right
knob to select the desired leg of the flight plan, or select “Cum” to apply
trip planning calculations to the entire flight plan.
4. Turn the large right knob to highlight the departure time (DEP TIME)
field.
5. Use the small and large right knobs to enter the departure time.
Press ENT when finished. (Departure time may be entered in local or
UTC time, depending upon unit settings).
6. If necessary, use the small and large right knobs to enter the
departure date. Press ENT when finished.
7. The flashing cursor moves to the ground speed (GS) field. Use the
small and large right knobs to override the current ground speed (and
enter a planningfigure). Press ENT when finished. (To return ground
speed reading to current conditions, highlight the ground speed [GS]
field, press CLR, then press ENT.)
8. With all variables entered, the following information is provided:
 DTK: Desired track, or desired course
 DIS: Distance to waypoint
 ETE: Estimated time en route
 ESA: En route safe altitude
 ETA: Estimated time of arrival
 Sunrise/Sunset times at the destination
8.14 RAIM PREDICTION
To predict RAIM availability:
1. Select “RAIM Prediction” from the utility page.
2. The flashing cursor highlights the waypoint field. Use the small and
large right knobs to enter the identifier of the waypoint at which you
wish to determine RAIM availability. Press ENT when finished. (To
determine RAIM availability for your present position, press CLR,
followed by ENT.).
3. The flashing cursor moves to the arrival date field. Use the small
and large right knobs to enter the date for which you wish to determine
RAIM availability. Press ENT when finished.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.8
Revision: 02
Date: 04/01/2019


4. The flashing cursor moves to the arrival time field. Use the small
and large right knobs to enter the time you wish to use reference for
determine RAIM availability. Press ENT when finished.
5. The flashing cursor moves to “Compute RAIM?”. Press ENT to
begin RAIM prediction.
Once calculations are complete, the unit displays one of the following
in the RAIM status field:
 RAIM Not Available - Satellite coverage is predicted to NOT be sufficient
for reliable operation during non-precision approaches;
 RAIM Available - Satellite coverage is predicted to be suficiente for
reliable operation during all flight phases, including non-precision
approaches;
8.15 BASIC APPROACH OPERATION
1. Select the destination airport using the direct to key, or as the last
waypoint in the active flight plan.
2. Choose the “Select Approach?” option from the Procedures Page
or from the Active Flight Plan Options.
3. “Load” the approach (often while en route) in anticipation of its future
use. This places the approach in the active flight plan, but retains
course guidance in the en route section until the approach is
“Activated”.
4. “Activate” the full approach or vectors-to-final, as appropriate. In
some scenarios, you may find it more convenient to immediately
activate the approach and skip the “Load” process outlined above in
step #3.

8.15.1 ACTIVATING AN APPROACH
1. With an approach loaded in the active flight plan, press the PROC
key to display the Procedures Page.
2. Turn the large right knob to highlight “Activate Approach?”.
3. Press ENT.



OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.9
Revision: 02
Date: 04/01/2019


8.15.2 ACTIVATING AN APPROACH WITH VECTORS-TO-
FINAL
The “Activate Vectors-To-Final?” option allows to activate the final
course segment of the approach. This option assumes you will receive
vectors to the final approach course and guides you to intercept the
final course, before reaching the FAF.
1. With an approach loaded in the active flight plan, press the PROC
key to display the Procedures Page.
2. Turn the large right knob to highlight “Activate Vectors-To-Final?”.
3. Press ENT.
8.16 MISSED APPROACH PROCEDURE
After you pass the MAP, if the runway isn’t in sight you must execute
a missed approach.
1. Press the OBS key to sequence to the first waypoint in the missed
approach procedure. This will simultaneously result in several
changes:
a. SUSP annunciation will extinguish.
b. The first waypoint in the missed approach procedure will be
sequenced.
c. The current approach annunciation (LPV, L/NAV, LNAV+V or LNAV)
will be replaced with either MAPR or TERM, depending on the design
of the approach. Normally, MAPR will be annunciated for missed
approach procedures in which the first leg is a climb straight ahead to
a waypoint, whereas TERM will be annunciated for missed approach
procedures requiring a turn.
d. CDI scaling will change to ±0.3 NM full scale deflection if MAPR is
annunciated, or ±1.0 NM if TERM is annunciated.
e. The “FROM” indicator will change to a “TO” indication.
2. Follow the missed approach procedures, as published on your
approach plate, for proper climb and heading instructions.
3. An alert message in the lower right hand corner of the screen
recommends entry procedures for the holding pattern. As you fly the
holding pattern, the timer in the lower right corner of the Default NAV
Page automatically resets on the outbound side of the hold when you
are abeam the hold waypoint. The timer again resets as you turn
inbound (within approximately 30° of the inbound course). This allows


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.10
Revision: 02
Date: 04/01/2019


you to use standard timing (typically one minute) to fly the inbound and
outbound legs of the hold
4. The unit provides course guidance only on the inbound side of the
holding pattern. Roll steering is provided to aircraft with compatible
autopilots. When leaving the holding pattern to re-fly the approach (or
another approach) press the PROC key to “Select Approach?” or
“Activate Approach?” as previously described. (Or, use the direct-to
key to select another destination.)
8.17 CDI SCALE SETTING:
1. Select “CDI / Alarms” from the Setup Page.
2. The flashing cursor highlights the “Selected CDI” field. Turn the
small right knob to select the desired CDI scale. The selected scale
and any lower scale settings are used during the various phases of
flight.
3. Press ENT to accept the selected scale. The “System CDI” field
displays the CDI scale currently in use. The “System CDI” setting may
differ from the “Selected CDI” depending upon the current phase of
flight.


OMNI TÁXI AÉREO S/A
SOP 11 SIKORSKY S 76C
Page: 8.11
Revision: 02
Date: 04/01/2019
