M E D I C I N E
Review Article
Exercise Training for Patients With
 Peripheral Arterial Occlusive Disease
Efficacy and Adherence
Maja Ingwersen, Ina Kunstmann, Carolin Oswald, Norman Best,
Burkhard Weisser, Ulf Teichgräber
A bout one-third of all persons with peripheral arterial
occlusive disease (PAOD) suffer from intermittent
claudication (1). Their quality of life is affected by
calf pain (1). In addition, they are at high cardiovascular
risk (amputation-free survival after five years ranges be-
tween 52% and 91%, depending on age and comorbid-
ities) (2). Progression of the disease is to be expected in
about one-quarter of patients (1).
Summary
Background: One-third of all persons with peripheral arterial occlusive disease (PAOD) suffer from intermittent claudication.
 Exercise training under appropriate supervision is recommended in the pertinent guidelines, but physicians order it too rarely,
and so-called vascular exercise groups are not available everywhere. This situation needs improvement in view of the impor -
tance of walking ability and cardiorespiratory fitness for patients’ quality of life and long-term disease outcome.
Methods: We review the scientific evidence on exercise training and on ways to lower barriers to the ordering of exercise train-
ing and to patient participation, on the basis of pertinent articles retrieved by a search of PubMed and in specialized sports
science journals.
Results: 10 meta-analyses, 12 randomized controlled trials (RCTs), and 7 cohort studies were considered for this review. Large-
scale cohort studies have shown that exercise is associated with a lower risk of death (relative risk 0.65–0.78 after 12 months of
exercise training, compared to an inactive lifestyle). Exercise training also improves the maximal walking distance by a mean of
136 m (training at home) or 180–310 m (supervised training). An additional improvement by a mean of 282 m can be expected
from a combination of exercise training and endovascular revascularization. Further behavior-modifying interventions, such as
goal-setting, planning, and feedback, increase both the maximum walking distance and the weekly duration of exercise.
Conclusion: Exercise improves walking ability and lowers mortality. To attract patients with intermittent claudication to exercise
training, a broad assortment of analog, digital and telemetric tools and a dense network of vascular exercise groups should be
made available, along with regular contact between physicians and patients.
Cite this as:
Ingwersen M, Kunstmann I, Oswald C, Best N, Weisser B, Teichgräber U: Exercise training for patients with peripheral arterial
occlusive disease—efficacy and adherence. Dtsch Arztebl Int 2023; 120: 879–85. DOI: 10.3238/arztebl.m2023.0231
Institute of Diagnostic
and Interventional
Radiology, Jena
 University Hospital,
Jena, Germany: Dr.
med. vet. Maja Ing-
wersen, Dr. med. Ina
Kunstmann, Carolin
Oswald, Prof. Dr.
med. Ulf Teichgräber
Institute of Physical
and Rehabilitation
Medicine, Sophien
and Hufeland Hospi-
tal Weimar, Academic
Teaching Hospital,
University of Jena,
Jena, Germany: PD
Dr. med. Norman
Best
Institute of Sports
Science, Department
of Sports Medicine,
Kiel University, Kiel,
Germany: Prof. Dr.
med. Burkhard
Weisser
Exercise can improve the symptoms, the quality
of life and the prognosis of PAOD patients (3–19).
A significant inverse dose-response relationship is
found between exercise and all-cause mortality (7,
10, 11, 20). Despite the fact that, due to the signifi-
cant evidence in support of this association, exer-
cise training under appropriate supervision is
clearly recommended in the pertinent guidelines as
part of con servative treatment ( level of evidence:
1; grade of recommendation: A) (21–26), this rec-
ommendation is rarely followed in practice (27).
Patients are often not informed about the risks and
possibilities of influencing the disease and are not
given much support in making the necessary be -
havioral changes. Until today, so-called vascular
exercise groups are not available everywhere in
Germany (28–31).
This article has been certified by the North Rhine Academy for Continuing
 Medical Education. Participation in the CME certification program is possible
only over the internet: cme.aerzteblatt.de. The deadline for submission is 26
December 2024.
cme plus
Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85 879
M E D I C I N E
The aim of this review is to provide an overview of
the available research evidence on exercise training
for patients with PAOD to shed light on the problem
of treatment adherence and to propose motivation
concepts.
Methods
We searched the PubMed database, using the following
search terms: “peripheral artery disease“, “claudi-
cation”, “intermittent claudication”, “supervised exer-
cise”, ”home-based exercise”, “exercise therapy”,
“physical activity”, “walking training”, and “exercise
program”. In addition, we considered references from
the field of sports science as well as online documents
of the German Federal Ministry of Health (BMG,
 Bundesgesundheitsministerium), the German Federal
Joint Committee (G-BA, Gemeinsamer Bundesaus -
schuss), the German Society for Angiology – Society
for Vascular Medicine e.V. (DGA), the German Vascu-
lar League e.V. (Deutsche Gefäßliga e. V.), and the
UK’s National Institute for Health and Care Excellence
(NICE).
Management and secondary prevention of intermittent
claudication
Exercise training is just as much an integral part of
guideline-adherent therapy of PAOD as is the control of
blood pressure and blood glucose levels and the use of
statins and antiplatelet agents. It is also essential that
smokers quit their nicotine habits (21, 22, 31). In addi-
tion, it is possible to address overweight and systemic
inflammatory processes through diet. Fruit, vegetables,
nuts, pulses, whole grains, and fish are considered
healthy foods (32).
Ideally, exercise training is supervised by certified
persons (German Society for the Prevention and Re-
habilitation of Cardiovascular Diseases [DGPR,
Deutsche Gesellschaft für Prävention und Rehabili-
tation von Herz-Kreislauferkrankungen e. V.]) (33,
34). Apart from a heart group leader’s license, those
who take on the supervision of vascular exercise
groups should also be qualified as vascular exercise
coaches (“Gefäßsporttrainer“, DGPR). Home training
is an alternative or complementary option (35–39). In
severely impaired patients, endovascular revascular-
ization should be considered as a supportive measure
(40).
Efficacy of exercise training
There is a substantial body of evidence to support a re-
duction in risk through exercise (eTable 1) (4, 8–14). In
addition, lack of exercise has been found to be an inde-
pendent risk factor for mortality and morbidity (15, 16).
Exercise training plays a significant role in increasing
cardiorespiratory fitness (CRF), a factor which is
strongly associated with both the risk of cardiovascular
events, such as arrhythmia and thrombosis, and mortal-
ity.
CRF is in fact a stronger predictor of mortality than
diabetes (e1–e3). It describes the maximum perform-
ance, i.e. the aerobic capacity of the body (maximum
oxygen uptake VO2-max in mL/kg/min). The resting
oxygen uptake capacity corresponds to a metabolic
equivalent of task (MET). A healthy middle-aged
adult has a CRF of 8 to 12 MET. CRF declines with
age and is lower in women. A meta-analysis of 33
 cohort studies showed that an increase in CRF by
1 MET was associated with a decrease in mortality by
13% (pooled relative risk [RR] 0.87; follow-up: 1–26
years) (e4).
Furthermore, it is well supported by evidence that
exercise training improves walking ability and quality
of life in patients with PAOD (eTable 2) (17–19, 33,
34, 37–39, e5–e8). The exact mechanism is not yet
fully understood. Improvements in endothelial func-
tion and increases in capillarydensity in muscle tissue
have been described. Exercise training improves
 mitochondrial function in muscle cells, while inflam-
matory mediators decrease. Consequently, muscular
microcirculation and metabolism are improved. In ad-
dition, there is an increase in cardiac stroke volume,
oxygen transport and metabolism as well as insulin
sensitivity (23, e9). After about four weeks of
 exercise training, an improvement in walking ability
can be expected (e10).
With regard to walking ability, combining exercise
training and revascularization has been shown to be
more effective overall than either measure alone (19,
e5, e7, e8). In addition, patients who engaged in exer-
cise training after a peripheral revascularization
 procedure required repeat revascularization less
 frequently (3, e11) (eTable 2).
The practice of exercise training
Classical walking training involves a minimum of three
weekly sessions, each of 30 to 45 minutes of actual
walking time. With treadmill training, patients start at a
comfortable speed with no incline. A short break of
about one minute is made each time a patient starts to
experience moderate to severe calf pain. The intensity
level should be chosen so that patients can walk for 5 to
10 minutes without stopping. Once they can walk for
more than 10 minutes without stopping, the intensity
(speed and incline) can be gradually increased. Ulti-
mately, the success of walking training depends more
on training intensity than on training duration and fre-
quency. Later in the training program, walking training
can be supplemented by resistance training. Possible
 alternatives to classical treadmill training include
physical activities such as climbing stairs, pedaling in a
lying position, upper-arm ergometry, cycling training
or everyday activities. These are particularly useful in
patients with severe intermittent claudication, previous
falls and unsteady gait, or if patients are reluctant to
commit to the training. Training should be ongoing and
preferably be carried out at moderate to high intensity
(7, 9–12, 17, 23, 25, e1, e9, e10, e12–e14) (Table 1).
Table 2 lists various examples of the intensity of
physical activities (e2, e15, e16). A moderate to
strong intensity corresponds to ≥ 3 MET. The exercise
880 Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85
M E D I C I N E
training program should consist of ≥ 500–1000 MET
minutes per week (9, e10, e12, e13, e16, e17). This
unit of measurement is based on the intensity (MET)
and duration (in minutes) of the respective activity.
Supervised exercise training for a minimum of twelve
weeks is considered the gold standard. The training
should then be continued independently as part of
everyday life. If patients cannot or only for a limited
time participate in a supervised exercise training
 program, training at home should be recommended
as an alternative or in addition. This also leads to
 improvements in walking ability and CRF, depending
on training duration and intensity (17, 38, 39)
 (eTable 2).
Overcoming personal barriers
With regard to the physical activity of PAOD patients,
the current picture is one of missed opportunities.
 Presently, primary care physicians and hospital doctors
discuss exercise training with only one in three patients
with intermittent claudication (29, 30). A survey study
on inpatients in German hospitals found that only 11%
of the PAOD patient in this patient population had ever
participated in an exercise training program. Only 26%
felt appropriately informed about the advantage of exer-
cise training by their GP practice and only 25% had
 access to information about local exercise training pro-
grams. Yet, a majority of these patients (65%) found it
conceivable that supervised exercise training may im-
prove their walking ability (28, 30). Physicians cited a
lack of time, inadequate financial compensation and a
lack of trust in patients‘ willingness to commit to exer-
cise training as reasons for not devoting much time to
this topic, as well as the lack of vascular exercise groups
(39).
According to the transtheoretical model, the stages
of change are pre-contemplation, contemplation,
preparation, action, and maintenance (e18, e19).
Based on this model, a phased approach to counseling
is advisable. One example of this approach is de-
scribed in the guideline on physical activity advice of
the National Institute for Health and Care Excellence
(NICE, Manchester, UK) (see Box) (25).
Identifying risk behavior
Given its prognostic significance, physicians should
ask patients about their physical activity as a “vital par-
ameter”: whether or not, what kind, for how long, how
frequently (25, 29). During a routine visit, this should
take no longer than three to four minutes..
 Recommending action
Once the assessment has been completed, patients are
informed about the health benefits of physical activity
(e10, e20). However, appeals and general advice alone
are usually ineffective (e21, e22).
Exploring willingness
Next, patients are asked whether they are willing to
change their behavior. Are the patients willing to start
exercise training? Are there any obstacles? How could
they start?
TABLE 1
Recommendations for improving walking ability and cardiovascular fitness
*1 For an individual prescription of physical activity with high intensity, a clinical examination should be per-
formed, including exercise ECG, especially in the presence of known cardiovascular risk factors, to rule
out abnormal cardiovascular reactions and to determine the physical fitness.
*2 Angina pectoris, dyspnea, hemodynamic instability, cardiac arrhythmia, rest pain and ulcers and/or
 gangrene on the foot require interruption of training and diagnostic workup (23).
*3 Swimming and water aerobics are viewed rather critically in patients with heart failure due to the
 increased preload (24, e14).
*4 Moderate intensity: 3–6 MET, 55–69% of max. heart rate (individually determined); respiratory rate
 increased, but talking is still possible, “running without puffing”, Borg scale 11–13 RPE (e14).
*5 High intensity: 6–9 MET, 70–89% of max. heart rate; fast respiratory rate and talking is difficult, 14–16
RPE (e14).
*6 Example: walking fast (5 MET) 30 min on 5 days/week and dancing (6 MET) 60 min on 1 day/week = 750
MET-min + 360 MET-min = 1110 MET-min
MET, metabolic equivalent; RPE, rate of perceived exertion (on the Borg scale)
Physical activity
Type
(23, e13, e14)
Intensity
(17, 23, e13, e14)
Frequency
(13, 17, 25, e13)
Duration
(7, 10–12, 25, e13)
Amount
(9, e13)
Pattern
(7, e14)
Progression
(e13)
Recommendation for continuous endurance training*1 *2
● First in intermittent claudication: treadmill training
● Involvement of large muscle groups (legs, arms, trunk)
● Continuous endurance training, e.g. walking, jogging,
 cycling, swimming*3, rowing, climbing stairs, dancing
 – supplementary dynamic, isometric resistance training
(strength endurance and muscle building) on ≥ 2 days/
week with moderate*4 to high*5 intensity (especially in
 persons aged ≥ 65 years), e.g. yoga, weight training,
 training with resistance bands, training with large equip-
ment (studio)
 – supplementary balance training in persons aged ≥ 65 years,
e.g. dancing, bowling, Tai-Chi, on ≥ 2 days/week
 – Time without movement /sedentary activities should be
 interrupted at least once per hour by 3–5 min standing or
walking (true inactivity1x to 2x/week
[“weekend warriors“])
● ≥ 150 min/week moderate*4 intensity (initially alsoPAOD)
RCT (35)
(symptomatic PAOD)
3 meta-analyses of 10 RCTs
(e35)
(adults in a healthcare facil-
ities)
Intervention
Weekly group visits with cogni-
tive behavioral intervention + HT
vs. weekly lectures on health
topics (6 months, n = 88/90)
Diverse interventions for
 behavioral change vs. no or al-
ternative behavioral measures
(5 months, n = 3350/3713)
ST with use of a mobile appli-
cation vs. medical advice alone
(3 months, n = 19/20)
Behavioral intervention + HT vs.
usual care (3 months, n =
74/74)
Brief counseling vs. no counsel-
ing (1–6 months, activity du-
ration: n = 748, steps: n = 117,
 MET hours: n = 104)
Elements for behavioral change
● Discussion (45 min) + indoor walking
distance (45 min). Discussion e.g.
about the benefits of the training,
weekly goals, implementation (at least
5 times/week, up to 50 min/unit), self-
monitoring, pain management
● Weekly individual feedback
● Effective: Planning of activities, in-
structions/tips for implementation,
stepwise goal setting, feedback,
 rewarding progress
● Mobile application: weekly targets
 entered; information on frequency and
duration of training as well as pain and
exhaustion.
● The app reminds users and provides
feedback on each exercise unit.
● Comparison to the users
● Motivating and informative personal
discussions and phone calls on per-
sonal goals und strategies (including
planning and self-monitoring).
● Enabling independent implementation
after intervention discussions
● Brief counseling (5–30 minutes) on
participation in physical activity
 programs offered in the healthcare
 facilities
Primary outcome
Change in 6-min walk distance:
+ 42 m vs. – 11 m, p0.20]. At 24 months, the effect was no longer
clinically important (36). A resolution passed by the
Federal Joint Committee (G-BA) on 24 January 2023
provides for an assessment of a nationwide implemen-
tation of this care model into routine care.
Vascular Check of the Legs
The “Gefäß-Check der Beine” project is a regional pilot
project at the Jena University Hospital. It enables
 community-based physicians to offer patients with sus-
pected PAOD a low-threshold “vascular check of the
legs”. Based on the walk-in clinic model, the “vascular
check” is performed in a specialist outpatient clinic at
short notice without waiting time. The check includes a
structured sequence of tests, including walking test,
ankle-brachial index (ABI) and vascular Doppler ultra-
sound. The results should typically be available on the
same day as the examination, together with treatment
recommendations. The aim is early detection of PAOD
so that progression and hospitalization can be
 prevented. Digitally supported training at home is
 arranged with patients who are diagnosed with PAOD.
Follow-up examinations and feedback discussions,
complementing the consultations with the primary care
physician, are an integral part of this project.
Conclusion
Despite the strong evidence supporting its efficacy in
patients with intermittent claudication, exercise train-
ing has not yet been adopted in clinical practice every-
where. Given the great prognostic significance of
physical activity, a stronger support of PAOD patients
by their physicians is desirable. This in turn requires
that more exercise training opportunities are offered.
Conflict of interest statement
The authors declare that no conflict of interest exists.
Manuscript received on 17 May 2023, revised version accepted on 18
 October 2023.
Translated from the original German by Ralf Thoene, MD.
References
1. Norgren L, Hiatt WR, Dormandy JA, Nehler MR, Harris KA, Fowkes
FG: Inter-society consensus for the management of peripheral arterial
disease (TASC II). J Vasc Surg 2007; 45 (Suppl S): S5–67.
2. Kreutzburg T, Peters F, Kuchenbecker J, et al.: Editor‘s choice—The
GermanVasc Score: a pragmatic risk score predicts five year
 amputation free survival in patients with peripheral arterial occlusive
disease. Eur J Vasc Endovasc Surg 2021; 61: 248–56.
3. Biswas MP, Capell WH, McDermott MM, et al.: Exercise training and
revascularization in the management of symptomatic peripheral artery
disease. JACC Basic Transl Sci 2021; 6: 174–88.
4. Mandsager K, Harb S, Cremer P, Phelan D, Nissen SE, Jaber W:
 Association of cardiorespiratory fitness with long-term mortality among
adults undergoing exercise treadmill testing. JAMA Netw Open 2018;
1: e183605.
5. Shiroma EJ, Lee IM: Physical activity and cardiovascular health:
 lessons learned from epidemiological studies across age, gender, and
race/ethnicity. Circulation 2010; 122: 743–52.
6. Kyu HH, Bachman VF, Alexander LT, et al.: Physical activity and risk of
breast cancer, colon cancer, diabetes, ischemic heart disease, and
ischemic stroke events: systematic review and dose-response
 meta-analysis for the Global Burden of Disease Study 2013. BMJ
2016; 354: i3857.
7. Kraus WE, Powell KE, Haskell WL, et al.: Physical activity, all-cause
and cardiovascular mortality, and cardiovascular disease. Med Sci
Sports Exerc 2019; 51: 1270–81.
8. Ekelund U, Steene-Johannessen J, Brown WJ, et al.: Does
 physical activity attenuate, or even eliminate, the detrimental
 association of sitting time with mortality? A harmonised meta-
 analysis of data from more than 1 million men and women. Lancet
2016; 388: 1302–10.
9. Hupin D, Roche F, Gremeaux V, et al.: Even a low-dose of
 moderate-to-vigorous physical activity reduces mortality by 22 % in
adults aged ≥ 60 years: a systematic review and meta-analysis.Br J
Sports Med 2015; 49: 1262–7.
10. Lee DH, Rezende LFM, Joh HK, et al.: Long-term leisure-time
 physical activity intensity and all-cause and cause-specific mortality:
a prospective cohort of US adults. Circulation 2022; 146: 523–34.
11. Moore SC, Patel AV, Matthews CE, et al.: Leisure time physical activity
of moderate to vigorous intensity and mortality: a large pooled cohort
analysis. PLoS Med 2012; 9: e1001335.
12. Samitz G, Egger M, Zwahlen M: Domains of physical activity and
 all-cause mortality: systematic review and dose-response meta-
 analysis of cohort studies. Int J Epidemiol 2011; 40: 1382–400.
13. Dos Santos M, Ferrari G, Lee DH, et al.: Association of the „Weekend
Warrior“ and other leisure-time physical activity patterns with all-cause
and cause-specific mortality: a nationwide cohort study. JAMA Intern
Med 2022; 182: 840–8.
884 Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85
M E D I C I N E
14. Lear SA, Hu W, Rangarajan S, et al.: The effect of physical activity on
mortality and cardiovascular disease in 130 000 people from 17 high-
income, middle-income, and low-income countries: the PURE study.
Lancet 2017; 390: 2643–54.
15. Jingjie W, Yang L, Jing Y, Ran L, Yiqing X, Zhou N: Sedentary time
and its association with risk of cardiovascular diseases in adults: an
updated systematic review and meta-analysis of observational
 studies. BMC Public Health 2022; 22: 286.
16. Lee IM, Shiroma EJ, Lobelo F, Puska P, Blair SN, Katzmarzyk PT:
 Effect of physical inactivity on major non-communicable diseases
worldwide: an analysis of burden of disease and life expectancy.
 Lancet 2012; 380: 219–29.
17. McDermott MM, Spring B, Tian L, et al.: Effect of low-intensity vs
 high-intensity home-based walking exercise on walk distance in
 patients with peripheral artery disease: The LITE Randomized Clinical
Trial. JAMA 2021; 325: 1266–76.
18. Nicolaï SPA, Teijink JAW, Prins MH: Multicenter randomized clinical trial
of supervised exercise therapy with or without feedback versus walking
advice for intermittent claudication. J Vasc Surgery 2010; 52: 348–55.
19. Saratzis A, Paraskevopoulos I, Patel S, et al.: Supervised exercise
therapy and revascularization for intermittent claudication: network
meta-analysis of randomized controlled trials. JACC Cardiovasc Interv
2019; 12: 1125–36.
20. Arem H, Moore SC, Patel A, et al.: Leisure time physical activity and
mortality: a detailed pooled analysis of the dose-response relationship.
JAMA Intern Med 2015; 175: 959–67.
21. Aboyans V, Ricco JB, Bartelink MEL, et al.: 2017 ESC Guidelines on
the Diagnosis and Treatment of Peripheral Arterial Diseases, in
 collaboration with the European Society for Vascular Surgery (ESVS):
Document covering atherosclerotic disease of extracranial carotid and
vertebral, mesenteric, renal, upper and lower extremity arteries
 Endorsed by: the European Stroke Organization (ESO), The Task
 Force for the Diagnosis and Treatment of Peripheral Arterial Diseases
of the European Society of Cardiology (ESC) and of the European
 Society for Vascular Surgery (ESVS). Eur Heart J 2018; 39: 763–816.
22. Lawall H, Huppert P, Espinola-Klein C, Rümenapf G: Clinical practice
guideline: The diagnosis and treatment of peripheral arterial vascular
disease. Dtsch Arztebl Int 2016; 113: 729–36.
23. Treat-Jacobson D, McDermott MM, Bronas UG, et al.: Optimal
 exercise programs for patients with peripheral artery disease: a
 scientific statement from the American Heart Association. Circulation
2019; 139: e10–e33.
24. Pelliccia A, Sharma S, Gati S, et al.: 2020 ESC Guidelines on sports
cardiology and exercise in patients with cardiovascular disease. Eur
Heart J 2021; 42: 17–96.
25. Piepoli MF, Hoes AW, Agewall S, et al.: 2016 European Guidelines on
cardiovascular disease prevention in clinical practice: The Sixth Joint
Task Force of the European Society of Cardiology and Other Societies
on Cardiovascular Disease Prevention in Clinical Practice (constituted
by representatives of 10 societies and by invited experts) developed
with the special contribution of the European Association for
 Cardiovascular Prevention & Rehabilitation (EACPR). Eur Heart J
2016; 37: 2315–81.
26. Powell KE, King AC, Buchner DM, et al.: The Scientific Foundation for
the Physical Activity Guidelines for Americans, 2nd Edition. J Phys Act
Health 2018: 1–11. Doi: 10.1123/jpah.2018–0618. Online ahead of print.
27. Lanzi S, Belch J, Brodmann M, et al.: Supervised exercise training in
patients with lower extremity peripheral artery disease. Vasa 2022; 51:
267–74.
28. Alushi K, Hinterseher I, Peters F, et al.: Distribution of mobile health
applications amongst patients with symptomatic peripheral arterial dis-
ease in Germany: a cross-sectional survey study. J Clin Med 2022; 11:
498.
29. Berra K, Rippe J, Manson JE: Making physical activity counseling a
priority in clinical practice: the time for action is now. JAMA 2015; 314:
2617–8.
30. Li Y, Rother U, Rosenberg Y, et al.: A prospective survey study on the
education and awareness about walking exercise amongst inpatients
with symptomatic peripheral arterial disease in Germany. Vasa 2023;
52: 218–23.
31. Rümenapf G, Morbach S, Schmidt A, Sigl M: Intermittent claudication
and asymptomatic peripheral arterial disease—conservative treatment
versus revascularisation. Dtsch Arztebl Int 2020; 117: 188–93.
32. Wan D, Dehghan MA-O, de Souza RA-OX, et al.: Dietary intake and
cardiovascular outcomes in patients with chronic vascular disease:
 insights from the COMPASS trial cohort. Eur J Prev Cardiol 2023; 30:
709–18.
33. Hageman D, Fokkenrood HJ, Gommans LN, van den Houten MM,
 Teijink JA: Supervised exercise therapy versus home-based exercise
therapy versus walking advice for intermittent claudication. Cochrane
Database Syst Rev 2018; 4: CD005263.
34. Siercke M, Jørgensen LP, Missel M, et al.: Cardiovascular
 rehabilitation increases walking distance in patients with intermittent
claudication. Results of the CIPIC rehab study: a randomised
 controlled trial. Eur J Vasc Endovasc Surg 2021; 62: 768–76.
35. Bearne LM, Volkmer B, Peacock J, et al.: Effect of a home-based,
 walking exercise behavior change intervention vs usual care on
 walking in adults with peripheral artery disease: the MOSAIC
 randomized clinical trial. JAMA 2022; 327: 1344–55.
36. Paldán K, Steinmetz M, Simanovski J, et al.: Supervised exercise
 therapy using mobile health technology in patients with peripheral
 arterial disease: pilot randomized controlled trial. JMIR Mhealth
 Uhealth 2021; 9: e24214.
37. Sandberg A, Bäck M, Cider Å, et al.: Effectiveness of supervised
 exercise, home-based exercise or walk advice strategies on walking
performance and muscle endurance in patients with intermittent
 claudication (SUNFIT trial): a randomized clinical trial. Eur J
 Cardiovasc Nurs 2022; 22: 400–11.
38. Gardner AW, Parker DE, Montgomery PS, Blevins SM: Step-
 monitored home exercise improves ambulation, vascular function,
and inflammation in symptomatic patients with peripheral artery
 disease: a randomized controlled trial. J Am Heart Assoc 2014; 18:
e001107.
39. Pymer S, Ibeggazene S, Palmer J, et al.: An updated systematic
 review and meta-analysis of home-based exercise programs for
 individuals with intermittent claudication. J Vasc Surg 2021; 74:
2076–85.e20.
40. Woo K, Siracuse JJ, Klingbeil K, et al.: Society for vascular surgery
appropriate use criteria for management of intermittent claudication. J
Vasc Surg 2022; 76: 3–22.e1.
Corresponding author
Prof. Dr. med. Ulf Teichgräber
Institut für Diagnostische und Interventionelle Radiologie
Friedrich-Schiller-Universität Jena
Universitätsklinikum Jena,
Am Klinikum 1, 07747 Jena, Germany
ulf.teichgraeber@med.uni-jena.de
Cite this as:
Ingwersen M, Kunstmann I, Oswald C, Best N, Weisser B, Teichgräber U:
Exercise training for patients with peripheral arterial occlusivedisease—
efficacy and adherence. Dtsch Arztebl Int 2023; 120: 879–85.
DOI: 10.3238/arztebl.m2023.0231
►Supplementary material
eReferences, eTables:
www.aerzteblatt-international.de/m2023.0231
Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85 885
M E D I C I N E
-- Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85 | Supplementary material
Supplementary material to:
Exercise Training for Patients With Peripheral Arterial Occlusive Disease
Efficacy and Adherence
by Maja Ingwersen, Ina Kunstmann, Carolin Oswald, Norman Best, Burkhard Weisser, and Ulf Teichgräber
Dtsch Arztebl Int 2023; 120: 879–85. DOI: 10.3238/arztebl.m2023.0231
e21. Thornton J, Nagpal T, Reilly K, Stewart M, Petrella R: The ‚miracle cure‘: how do
primary care physicians prescribe physical activity with the aim of improving clinical
outcomes of chronic disease? A scoping review. BMJ Open Sport Exerc Med 2022;
8: e001373.
e22. Spring B, Ockene JK, Gidding SS, et al.: Better population health through behavior
change in adults: a call to action. Circulation 2013; 128: 2169–76.
e23. Howlett N, Trivedi D, Troop NA, Chater AM: Are physical activity interventions for
healthy inactive adults effective in promoting behavior change and maintenance,
and which behavior change techniques are effective? A systematic review and
meta-analysis. Transl Behav Med 2019; 9: 147–57.
e24. McDermott MM, Guralnik JM, Criqui MH, et al.: Home-based walking exercise in
peripheral artery disease: 12-month follow-up of the GOALS randomized trial. J
Am Heart Assoc 2014; 3: e000711.
e25. McDermott MM, Liu K, Guralnik JM, et al.: Home-based walking exercise
 intervention in peripheral artery disease: a randomized clinical trial. JAMA 2013;
310: 57–65.
e26. Patnode CD, Redmond N, Iacocca MO, Henninger M: Behavioral counseling
 interventions to promote a healthy diet and physical activity for cardiovascular
disease prevention in adults without known cardiovascular disease risk factors:
updated systematic review for the U.S. Preventive Services Task Force [Internet].
 Rockville (MD) 2022; Report No.: 22–05289-EF-1.
e27. O‘Connor EA, Evans CV, Rushkin MC, Redmond N, Lin JS: Behavioral counseling
to promote a healthy diet and physical activity for cardiovascular disease prevention
in adults with cardiovascular risk factors: updated evidence report and systematic
review for the US Preventive Services Task Force. JAMA 2020; 324: 2076–94.
e28. Williams PT: Physical fitness and activity as separate heart disease risk factors:
a meta-analysis. Med Sci Sports Exerc 2001; 33: 754–61.
e29. Regensteiner JG, Treat-Jacobson D: What does the future hold for structured ex-
ercise training for people with PAD? Ideas from two masters of the society for
vascular medicine. Vasc Med 2022; 27: 116–9.
e30. Höchli B, Brügger A, Messner C: Exploring the influence of goals at different
 levels of abstraction on self-reported and electronically measured exercise
 frequency: an experimental field study. International Journal of Sport and
 Exercise Psychology 2022; 20: 474–96.
e31. Simonsmeier BA, Andronie M, Buecker S, Frank C: The effects of imagery
 interventions in sports: a meta-analysis. Int Rev Sport Exerc Psychol 2021; 14:
186–207.
e32. Williamson O, Swann C, Bennett KJM, et al.: The performance and psychological
effects of goal setting in sport: a systematic review and meta-analysis. Int Rev
Sport Exerc Psychol 2022: 1–29 DOI: 10.1080/1750984X.2022.2116723.
e33. Franklin BA, Myers J, Kokkinos P: Importance of lifestyle modification on
 cardiovascular risk reduction: counseling strategies to maximize patient outcomes.
J Cardiopulm Rehabil Prev 2020; 40: 138–43.
e34. Powell CA, Kim GY, Edwards SN, et al.: Characterizing patient- reported claudication
treatment goals to support patient-centered treatment selection and measurement
strategies. J Vasc Surg 2023; 77: 465–73.
e35. Green ET, Cox NS, Arden CM, Warren CJ, Holland AE: What is the effect of a
brief intervention to promote physical activity when delivered in a health care
 setting? A systematic review. Health Promot J Austr 2023, doi: 10.1002/hpja.697.
Online ahead of print.
e36. Nugteren MJ, Catarinella FS, Koning OHJ, Hinnen JW: Mobile applications in
 peripheral arterial disease (PAD): a review and introduction of a new innovative
telemonitoring application: JBZetje. Expert Rev Med Devices 2021; 18: 581–6.
e37. Sardi L, Idri A, Fernández-Alemán JL: A systematic review of gamification in
e-Health. J Biomed Inform 2017; 71: 31–48.
e38. Veiga C, Pedras S, Oliveira R, Paredes H, Silva I: A systematic review on smart-
phone use for activity monitoring during exercise therapy in intermittent claudi-
cation. J Vasc Surg 2022; 76: 1734–41.
e39. Serrano Ripoll MJ, Oliván-Blázquez B, Vicens-Pons E, et al.: Lifestyle change
 recommendations in major depression: Do they work? J Affect Disord 2015; 183:
221–8.
e40. Cohen BE, Edmondson D, Kronish IM: State of the art review: depression, stress,
anxiety, and cardiovascular disease. Am J Hypertens 2015; 28: 1295–302.
 eReferences
e1. Ross R, Blair SN, Arena R, et al.: Importance of assessing cardiorespiratory
 fitness in clinical practice: a case for fitness as a clinical vital sign: a scientific
statement from the American Heart Association. Circulation 2016; 134:
e653–e99.
e2. Jelinek M, Hossack K: Implications of cardio-respiratory fitness on the performance
of exercise tests. Heart Lung Circ 2019; 28: e64–e6.
e3. Myers J, Prakash M, Froelicher V, Do D, Partington S, Atwood JE: Exercise
 capacity and mortality among men referred for exercise testing. N Engl J Med
2002; 346: 793–801.
e4. Kodama S, Saito K, Tanaka S, et al.: Cardiorespiratory fitness as a quantitative
predictor of all-cause mortality and cardiovascular events in healthy men and
 women: a meta-analysis. JAMA 2009; 301: 2024–35.
e5. Fakhry F, Spronk S, van der Laan L, et al.: Endovascular revascularization and
supervised exercise for peripheral artery disease and intermittent claudication:
a randomized clinical trial. JAMA 2015; 314: 1936–44.
e6. Fakhry F, van de Luijtgaarden KM, Bax L, et al.: Supervised walking therapy in
patients with intermittent claudication. J Vasc Surg 2012; 56: 1132–42.
e7. Murphy TP, Cutlip DE, Regensteiner JG, et al.: Supervised exercise, stent
 revascularization, or medical therapy for claudication due to aortoiliac peripheral
artery disease: the CLEVER study. J Am Coll Cardiol 2015; 65: 999–1009.
e8. Pandey A, Banerjee S, Ngo C, et al.: Comparative efficacy of endovascular
 revascularization versus supervised exercise training in patients with intermittent
claudication: meta-analysis of randomized controlled trials. JACC Cardiovasc
 Interv 2017; 10: 712–24.
e9. Tucker WJ, Fegers-Wustrow I, Halle M, Haykowsky MJ, Chung EH, Kovacic JC:
Exercise for primary and secondary prevention of cardiovascular disease: JACC
Focus Seminar 1/4. J Am Coll Cardiol 2022; 80: 1091–106.
e10. Treat-Jacobson D, McDermott MM, Beckman JA, et al.: Implementation of
 supervised exercise therapy for patients with symptomatic peripheral artery dis-
ease: a science advisory from the American Heart Association. Circulation 2019;
140: e700–e10.
e11. Kato T, Miura T, Yamamoto S, et al.: Intensive exercise therapy for restenosis
 after superficial femoral artery stenting: the REASON randomized clinical trial.
Heart Vessels 2022; 37: 1596–603.
e12. Ehrman JK, Gardner AW, Salisbury D, Lui K, Treat-Jacobson D: Supervised
 exercise therapy for symptomatic peripheral artery disease: a review of current
experience and practice-based recommendations. J Cardiopulm Rehabil Prev
2023; 43: 15–21.
e13. Garber CE, Blissmer B, Deschenes MR, et al.: American College of Sports
 Medicine position stand. Quantity and quality of exercise for developing and
maintaining cardiorespiratory, musculoskeletal, and neuromotor fitness in
 apparently healthy adults: guidance forprescribing exercise. Med Sci Sports
Exerc 2011; 43: 1334–59.
e14. Hacke C, Weisser B: [Sport and exercise in prevention and therapy of cardiovascular
diseases]. Dtsch Med Wochenschr 2021; 146: 381–8.
e15. Franklin BA, Brinks J, Berra K, Lavie CJ, Gordon NF, Sperling LS: Using metabolic
equivalents in clinical practice. Am J Cardiol 2018; 121: 382–7.
e16. Jetté M, Sidney K, Blümchen G: Metabolic equivalents (METS) in exercise testing,
exercise prescription, and evaluation of functional capacity. Clin Cardiol 1990; 13:
555–65.
e17. Salisbury DL, Swanson K, Brown RJ, Treat-Jacobson D: Total body recumbent
stepping vs treadmill walking in supervised exercise therapy: a pilot study. Vasc
Med 2022; 27: 150–7.
e18. Pinto BM, Goldstein MG, Marcus BH: Activity counseling by primary care physicians.
Prev Med 1998; 27: 506–13.
e19. Prochaska JO, DiClemente CC, DiClemente CC, Prochaska JO: Stages and
 processes of self-change of smoking: toward an integrative model of change Self-
change and therapy change of smoking behavior: a comparison of processes of
change in cessation and maintenance. J Consult Clin Psychol 1983; 51: 390–5.
e20. Elley CR, Kerse N, Arroll B, Robinson E: Effectiveness of counselling patients on
physical activity in general practice: cluster randomised controlled trial. BMJ
2003; 326: 793.
M E D I C I N E
Deutsches Ärzteblatt International | Dtsch Arztebl Int 2023; 120: 879–85 | Supplementary material --
eTABLE 1
Association between physical activity and mortality
CRF, cardiorespiratory fitness; CV mortality, cardiovascular mortality; FU, follow-up; HR, hazard ratio; CHD, coronary heart disease; MET-h, metabolic equivalent in one hour; ns.,
 non-significant; vs., versus; RR, relative risk
Study
Samitz, 2011 (12)
Lee, 2012 (16)
Moore, 2012 (11)
Hupin, 2015 (9)
Ekelund, 2016 (8)
Lear, 2017 (14)
Mandsager, 2018 (4)
Dos Santos, 2022 (13)
Lee, 2022 (10)
Jingije, 2022 (15)
Study design
Meta-analysis of 80 cohort
studies: n = 1 339 143
Analysis of data from large cohort
studies worldwide (Lancet physi-
cal activity series working group)
Pooled analysis of 6 cohort
studies: n = 654 827 (median
 follow-up: 10 years)
Meta-analysis of 9 prospective
cohort studies: n = 122 417
>60-year-olds
Meta-analysis of 13 prospective
cohort studies: n = 1 005 791
Physical activity:
● low: 16 MET-h/week
● high: > 35.5 MET-h/week
Prospective cohort studies:
n = 168 916
Retrospective cohort studies:
n = 22 007 (median FU 8.4
years)
Prospective cohort studies:
n = 350 978
(median FU 10.4 years)
Pooled analysis of 2 prospective
cohort studies:
n = 116 221 (FU 30 years)
Meta-analysis of 17 prospective
cohort studies and 2 cross-
 sectional studies: n = 1 451 730
Intervention
Physical activity:
highest versus lowest inten-
sity
Physical inactivity
6–224 MET-min/week vs.
0 MET-min/week
Physical activity vs. inactivity
Time without movement
> 8 h/day
vs.
 3 000 MET-min/
week
vs.
control:
p
