Explanation: The changes in the frequency is not reflected due to the flux density variation
correspondingly.
9. There are two identical transformers A and B such that flux density applied to B is doubled.
Then magnetizing current of B is
a) larger than A
b) double of A
c) half of A
d) same as that of A.
View Answer
Answer: a
Explanation: When we double the flux density, as per the magnetization curve of the core, the
magnetizing current is much larger than double of the machine A.
10. A 20KVA, 2200/220 V, 50 Hz single phase transformer has the below parameters:
HV : r = 2.4 ​Ω, X=6 ​Ω
LV: r = 0.03 ​Ω, X = 0.07 ​Ω
The primary reactance referred to secondary is
a) 0.024 ​Ω
b) 0.06 ​Ω
c) 3 ​Ω
d) 7 ​Ω
View Answer
Answer: b
Explanation: Primary reactance referred to secondary = x1*(N2/N1)^2 = 6*(220/2200)^2
= 0.06 ​Ω.
11. A 20KVA, 2200/220 V, 50 Hz single phase transformer has the below parameters:
HV : r = 2.4 ​Ω, X=6 ​Ω, Primary
LV: r = 0.03 ​Ω, X = 0.07 ​Ω, Secondary
The secondary reactance referred to primary is
a) 0.024 ​Ω
b) 0.06 ​Ω
c) 3 ​Ω
d) 7 ​Ω
View Answer
Answer: d
Explanation: Secondary reactance referred to primary = x2*(N1/N2)^2 = 0.07*(2200/220)^2 =
7.0 Ω
12. A 20KVA, 2200/220 V, 50 Hz single phase transformer has the below parameters:
HV : r = 2.4 ​Ω, X=6 ​Ω
LV: r = 0.03 ​Ω, X = 0.07 ​Ω
The primary resistance referred to secondary is
a) 0.024 ​Ω
b) 0.06 ​Ω
c) 3 ​Ω
