10. A 3-phase, 4-pole, 50 Hz induction motor is uses DOL method of starting. It is later replaced
by reactance method of starting with a fraction of ‘x’, then the
starting torque reduces by
a) x
b) x^2
c) 1/x
d) no change in the starting current
View Answer
Answer: b
Explanation: Tst/Tfl = (x^2)(Ist/Ifl)^2*slip.

11. Series reactor method of starting has main disadvantage of
a) lowering the starting power
b) increasing the starting current
c) increasing starting torque
d) all of the mentioned
View Answer
Answer: a
Explanation: Main disadvantage of using reactors is that ot reduces the starting power of the
machine and so the efficiency.
12. Series reactor method of starting has main disadvantage of lowering the starting power. This
can be overcome by
a) using series resistance
b) using parallel reactor
c) using parallel resistance
d) using series reactor
View Answer
Answer: a
Explanation: Adding series resistance instead od reactors will help improving the starting power.
13. A 3-phase, 4-pole, 50 Hz induction motor is uses DOL method of starting. It is later replaced
by auto transformer method of starting with a tapping ratio of ‘x’, then the
starting current reduces by
a) x
b) x^2
c) 1/x
d) no change in the starting current
View Answer
Answer: b
Explanation: The starting current reduces by a fraction of x^2.
14. A 3-phase, 4-pole, 50 Hz induction motor is uses DOL method of starting. It is later replaced
by auto transformer method of starting with a tapping ratio of ‘x’, then the
starting torque will be
a) x *Tfl
