d) starting torque decreases, maximum torque remains same, smT decrease
View Answer
Answer: a
Explanation: As the resistance has been changed as the aluminium has replaced copper, it will
not affect the maximum torque.
7. A 3-phase slip ring IM is has its copper bars changed by the aluminium bars in the machine.
With the above change,
a) starting torque remains same
b) starting torque increase
c) starting torque decrease
d) maximum torque increase
View Answer
Answer: a
Explanation: Resistance increase, so the starting torque increase.
8. A center ammeter connected to the rotor end circuit of a 6-pole,50 Hz, induction motor makes
45 complete oscillations in a minute.
Then the rotor speed and the speed of stator field w.r.t. rotor is
a) 985, 15
b) 970, 1000
c) 985, 985
d) 985, 970
View Answer
Answer: a
Explanation: Rotor frequency = s*f1 = 45/60 = 0.75 Hz.
s = 0.75/50 = 0.015
rotor speed = 1000(1-0.015) = 985
rpm.
Speed of stator field w.r.t. rotor = Ns-Nr = 1000-985=15 rpm.
9. Choose from the below which can be obtained by the equivalent circuit of an electrical
machine?
a) Complete performance characteristics of the machine
b) Temperature coefficients of the machine components
c) Type of protection to be used in the machine
d) Design parameters of the windings
View Answer
Answer: a
Explanation: Equivalent circuit can help to give the complete performance characteristics of an
electrical machine.
10. If one of the supply fuses blows off and gets open circuited, then for the connected induction
machine continues to run with increased slip.
a) True
b) False
View Answer
