hybriSpot12 Service Manual V3.EO_EN (17/12/2015) 1/41




SERVICE MANUAL













VITRO S.A
Calle Luís Fuentes Bejarano. Edificio Nudo Norte (Local 3)
41020 Sevilla (SPAIN)
www.vitro.bio
T. +34 902 366 974
F. +34 902 366 977
e-mail: vitro@vitro.bio
http://www.vitro.bio/
mailto:vitro@vitro.bio


hybriSpot12 Service Manual 2/41

INDEX
1 GENERAL DESCRIPTION ....................................................................................................... 3
1.1 Introduction .......................................................................................................................3
1.2 Aim ......................................................................................................................................3
1.3 Rights and Warranties ......................................................................................................3
1.3.1 Intellectual property ................................................................................................3
1.3.2 Usage ..........................................................................................................................3
1.3.3 Documentation and general information ..........................................................4
1.4 Information and security instructions ............................................................................5
2 TECHNICAL INFORMATION ................................................................................................. 6
2.1 Technical data ..................................................................................................................6
2.2 Minimum requirements for a computer .......................................................................6
2.3 Serial Number ....................................................................................................................7
2.4 Special Tools ......................................................................................................................7
2.5 Recommended Tools.......................................................................................................8
2.6 Content list .........................................................................................................................9
2.7 Troubleshooting .............................................................................................................. 10
3 UNPACKAGING ................................................................................................................. 12
4 INSTALLATION ..................................................................................................................... 13
5 HYBRISOFT INSTALLATION .................................................................................................. 13
6 USB BARCODE READER CONFIGURATION ....................................................................... 13
7 MECHANICAL SYSTEM ....................................................................................................... 13
7.1 Safety Instructions .......................................................................................................... 13
7.2 General Description – Spare Parts .............................................................................. 14
7.2.1 Housing and Covers.............................................................................................. 14
7.2.2 Reaction Chamber ............................................................................................... 17
7.2.3 Hydraulic System ................................................................................................... 18
7.2.4 Electronic System .................................................................................................. 19
7.3 Access to the Hydraulic Circuit................................................................................... 21
7.4 Access into the instrument and electronics circuits ............................................... 21
8 ELECTRONIC SYSTEM .......................................................................................................... 23
8.1 Cables Colour Codes ................................................................................................... 23
8.2 General Description ...................................................................................................... 23
8.2.1 Boards interconnections ...................................................................................... 24
8.2.2 Power Circuit Board .............................................................................................. 25
8.2.3 Main Connections ................................................................................................. 26
8.3 Display Circuit Board ..................................................................................................... 30
8.4 Service Port and Program Port .................................................................................... 31
8.5 DC Power Connector ................................................................................................... 32
8.6 Camera circuit board and Camera Housing .......................................................... 32
9 HYDRAULIC SYSTEM ........................................................................................................... 33
8 CONTROL SOFTWARE ......................................................................................................... 34
8.1 Valves and Pumps Control Area ................................................................................ 34
8.2 Temperature Control .................................................................................................... 35
8.3 Commands Menu ......................................................................................................... 37
8.4 Auto Settings Menu ....................................................................................................... 37
8.5 Flash Memory Programming........................................................................................ 38


hybriSpot12 Service Manual 3/41

1 GENERAL DESCRIPTION
1.1 Introduction
HybriSpot 12 is a new semi-automatic analyzer that meets all the requirements
to perform PCR amplification and later DNA array reverse hybridization on a
nylon membrane, based on the principle of the DNA-FLOW.
By means of this technology, hybridization process takes place by passing the
reagents through the membrane by means of a hydraulic vacuum system that
causes a vertical liquid flow. This assay allows hybridization to occur in a
tridimensional environment and improves incubation time from hours to minutes
and increases sensitivity and specificity.
HybriSpot 12 is used for the design and automation of in vitro molecular tests in
the field of infectious disease, cancer as well as genetic diseases among others,
where quick sensitive and specific results are required.
HybriSpot 12 is manufactured by Vitro, S.A in our industrial plants located in
Seville-Spain.
1.2 Aim
This manual is a referencing guide for the Technical Service field engineers
when these procedures are performed:
 Unpacking.
 Hardware installation.
 Technical checkout.
 Maintenance.
1.3 Rights and Warranties
1.3.1 Intellectual property
All acts that violate the rights of intellectual property inherent to the product as
a whole or any of its components or parts are prohibited.
1.3.2 Usage
This device has been designed to be used in an in vitro diagnosis laboratory.
We disclaim any liability, in the event that the same or any component thereof
is subject to misuse and / or use other than for which it was designed. Users are
the only responsible for the management,use, testing, processes and
outcomes that occur and are obtained with the instrument, or as an auxiliary
device.



hybriSpot12 Service Manual 4/41

The manufacturer of the product or one of the components could not take
responsibility for defects when the product has been sold or misused in a
market for which it was not designed for.
By means of CE marker, the manufacturer indicates that the device complies
with the requirements laid down in European Directives to be applied.
1.3.3 Documentation and general information
The manual supplied with the instrument is owned by Vitro, SA and is provided
to customers and authorized distributors for its use. Unless prior express written
consent of Vitro SA authorization, copying, dissemination and distribution- fully
or partially- is forbidden, in any form and/or mean, including all systems and
electronic means, the text, images and illustrations contained in the manual.
The information contained in the manual (data, figures, drawings, technical
details etc.) represent the current state of scientific knowledge and latest
technology as we understand it after conducting thorough investigations in this
field, and should not be considered as warranted as our products. Note this
depends on the commercial contract between the parties.
No liability, damages, financial loss or profit is accepted from or relevant to the
statements contained in the manual.
The manufacturer reserves the right to change the technical specifications and
manufacturing processes without notice. Only in this way it is possible to
continuously improve technology and manufacturing techniques used in our
products.












hybriSpot12 Service Manual 5/41

1.4 Information and security instructions

The following safety precautions and regulations must be observed when the
instrument is used particularly for medical diagnosis and in vitro. The failure to
follow these instructions can lead to reporting false negative results and the
incorrect distribution of the samples.
I. All notes in the Service Manual should be read carefully, paying particular
attention to the following sections:
 Installation
 Disinfection procedures
II. The installation must follow these reasonable steps to ensure that the
location where the instrument is installed meets the environmental and
electromagnetic specifications for the analyzer. Any significant movement
of the equipment must be performed by qualified personnel.
III. The user should be informed and trained to perform daily maintenance and
check to ensure the correct operation of the instrument.
IV. Carefully, follow the instructions in the Service Manual for the operations to
perform to turn on and off the hybriSpot 12.
V. All precautions and recommendations, normally used in the laboratory
(good laboratory practice standards), must be followed.
VI. If the laboratory does not have power sources protected, you may need an
uninterruptible power supply (UPS) to protect and nurture the instrument
during a power outage.
VII. Using hybriSpot 12 do not ensure the absence of contamination by
biological risk, so the instrument should be handled as potentially infectious
item and the usual precautions for these cases should also be followed. Do
not eat, drink or smoke while handling the device.
VIII. To reduce the risk of electric shock: Keep away from open circuits. The
instrument must be connected to a ground. The instrument must be
equipped with a three-pole cable for connection to 230V or 115V.


hybriSpot12 Service Manual 6/41

2 TECHNICAL INFORMATION
2.1 Technical data

Nominal Voltage: 100 – 240 V
Nominal Frequency: 50/60 Hz
Secondary Fuses: 2 xPTC
Nominal Power 150 VA
Dimensions (Length X width x height) (without
webcam embedding)
235x230x200mm
Gross weight (without packaging material) 5 kg
Gross weight (with packaging material) 6.8 kg
Operating Temperature Range 15ºC - 32º C
Operating ability 12 samples per cycle
Standard Cycle Time 50 min – 12 samples
Temperature Range 20°C - 60°C (Reaching limit
temperature takes longer)


Heating Rate
4,5°C/Min. (Measured between 30°-
40°C with ambient temp. of approx.
23°C)
Cooling Rate 2°C/Min. (Measured between 30ª-
40°C with ambient temp. of approx.
23°C)
Temperature Accuracy ± 2°C(worsened at high
temperatures)
Temperature Uniformity ± 1,5°C
Temperature Range During Storage Suggested between +5°C and + 45°C
Samples Configuration Max.12 operating samples
Operating Pressure Only tested at atmospheric pressure
Operating Humidity Suggested between 30% - 70% non-
condensing
Humidity During Storage Suggested between 30% - 70% non-
condensing
2.2 Minimum requirements for a computer
Processor: Intel Core i3
Memory: 4 Gb
Hard Drive: 250 Gb
Operating System: Windows 7 (32/64 bits)
Windows 8.1 (32/64 bits)
USB ports free: 1 (as minimum)
Network Connection: Ethernet 10/100 Mbps – RJ45
Recommended Display: 16:9 format


hybriSpot12 Service Manual 7/41

2.3 Serial Number
To get the serial number of manufacture of the product, see the nameplate on
the back of the instrument.
2.4 Special Tools
These tools are not provided with the instrument.
Used for:
 Firmware updating.
 Communication with the PC to use the Technical Service Software.
 Vacuum verification.
PC Connector cable

Program Port Cable Kit.

Vacuometer



Vacuum Test Cap




VIT-20001 – PC Connector Cable
VIT-20002 – Program Port Cable Kit
VIT-20003 – Vacuometer
VIT-20004 – Vacuum Test Cap



hybriSpot12 Service Manual 8/41

2.5 Recommended Tools

These tools are recommended in order to the Technical Service can give
Support to the instrument. These tools are not supplied as spare parts neither as
special tools.
Clean Cutter Pliers


Socket Wrench Socket Set


Set of Allen Wrenches (Metric)


Set of Torx Screwdrivers


Set of flat Screwdrivers


Set of Philips Screwdrivers


Set of Tube Wrenches


Pliers


Tweezers



Thread Sealant




hybriSpot12 Service Manual 9/41

Thermal Paste


Infrared Thermal Detector





2.6 Content list
Spares included in the hybriSpot12 are:
hybriSpot 12
hybriSpot12 equipment
Clean tube
Waste tube
Clean bottle
Waste bottle
USB cable
Power supply
Power cord
Orings set
Grids set


hybriSpot12 Service Manual 10/41

2.7 Troubleshooting
INCIDENCE COMMENTS CHECKS
POSSIBLE CAUSE OF FAILURE (In
case failure persists after
checking)
RESOLUTION
The instrument does
not start
When the instrument is on (and the rear switch is
pressed) the display lights should turn on immediately
showing the firmware version installed. The side fan
should also turn on.
Verify that the power supply is functioning
properly. Green LED lighting should be on.
Otherwise, check that the outlet has
power supply and cable A / C is properly
connected
Power supply failure
Replace power
supply
Check that the power is properly
connected to the instrument

PCB or wiring error
Replace the
instrument
The display does not
work properly


It is possible that the instrument is properly powered, but
due to a failure in the wiring of the display, it is not
turned on or simply it does not show text.In any case,
the side fan should be on

Check that the side fan is on

If the fan works properly, it means that
the equipment is properly powered.
The failure should be the display
board.
Replace the
instrument.
The instrument does
not create a vacuum

There can be several causes. Is the failure is coming from
the presence of a residue in one of the wells of a row
that fails, the final user can try to solve it. Other causes
such as failure of peristaltic pumps, valves, fittings, etc.,
can only be solved by field engineers

Check that there is no waste in the area of
the o-ring. If the fault persists, it is
recommended to remove the grids and o-
ring and placing them back

Possible leakage in the hydraulic
system.
Replace the
instrument. Follow the
instructions for check
and review the
Hydraulic System.
The instrument loses
fluid (reactive /
wash)


Both in normal operation and during a wash cycle, some
leaking can be detected by checking the bottom of the
instrument. More likely, one connector of the peristaltic
pumps is leaking.




Leaking at hose pump connector. If
the user has a 2.5mm allen key, he
can open the maintenance plate
and check this. In any case, the
instrument should be replaced.

Replace the
instrument
The instrument takes
too long to reach the
target temperature
Typically, for HPV or zoonoses, the highest temperature
ramps should not take more than 10 minutes to
complete. This depends, also, on the room temperature.
Check that the instrument is properly used
and that the side fan is on. You should also
check that the computer display changes
the temperature of the reaction chamber.
Possible failures: Fan breakdown,
temperature sensors, PCB…
Replace the
instrument


hybriSpot12 Service Manual 11/41

INCIDENCE COMMENTS CHECKS

POSSIBLE CAUSE OF FAILURE (In case
failure persists after checking)

RESOLUTION
The instrument does
not indicate when it
reaches target time /
temperature


When the target temperature/time is reached, the
instrument buzzes with built- in speaker included in the
display board in order to alert the user and continue the
cycle. In case of temperature, the buzz should coincide
with the green led lighting of the display

 Failure in the display board Replace the instrument
The LED lighting
system of the image
capture system are
not turned on

With the image capture system connected to the PC
USB and the switch ON, both diffuser LEDs lighting and
the red LED signal should be ON

Check that the USB cable
connections on PC and capture
system are correct
Failure on the image capture system
electronic board

Replace the image
capture system

hybriSoft does not get
images from webcam
If the LEDs work correctly, hybriSoft should receive the
image from the webcam
Make sure MS Windows recognizes
the webcam.

If MS Windows recognizes the camera,
the failure is in the software. Otherwise,
there is a failure either in the camera or
in any other electronic connections.

Replace the image
capture system





hybriSpot12 Service Manual 12/41

3 UNPACKAGING

 Remove the documentation included.
 Remove packaging waste.

 Remove the plastic protection of the reaction chamber cover and
image capture system and pick up both items.
 Remove protection foam.

 Remove the power supply, cables and auxiliary tubes, bottle and
hybriSpot




hybriSpot12 Service Manual 13/41

4 INSTALLATION
 Connect hybriSpot 12 to power supply
 Connect waste and cleaning tubes to the side connectors
 Connect waste tank to the corresponding tubes.
5 HYBRISOFT INSTALLATION

Please refer to the hybriSoft_ Installation guide located at Vitro ftp site.
6 USB BARCODE READER CONFIGURATION

An external USB barcode reader could be used.
In this case you must assure that the barcode reader has the correct USB PC
keyboard configuration.
It is necessary add a CR suffix, Carriage Return, for a properly operation.
Please refer to the specific manufacturer barcode reader documentation for
more information about how to configure it.
7 MECHANICAL SYSTEM
7.1 Safety Instructions
 Before carrying out any work on the instrument (or on the device), it
should be disconnected from the power supply.
 After repairing, all parts must be connected as originally connected by
the manufacturer.
 No power cord should be clamped between the housing and any other
part.
 Do not disconnect the LCD panel while the instrument is on.
 Follow the rules to work with components at risk of electrostatic
discharge.


hybriSpot12 Service Manual 14/41

7.2 General Description – Spare Parts

7.2.1 Housing and Covers
7.2.1.1 Top Panel

VIT-120036 – Top Panel
VIT-120044 – Housing Cap Set (Top Caps)
VIT-120025 – Reaction Chamber
VIT-120059 – Reaction Chamber Cover



hybriSpot12 Service Manual 15/41


VIT-120030 – O-ring Set
VIT-120057 – Grids Set
VIT-120032 – Caps Set

VIT-120026 – Reaction Chamber Cover Gasket


hybriSpot12 Service Manual 16/41

7.2.1.2 Display Panel

VIT-120040 – Display Panel
VIT-120041 – Front Panel

7.2.1.3 Connections & Maintenance rear panel



hybriSpot12 Service Manual 17/41

VIT-120006 – I/O Switch
VIT-120007 – DC Power Connector
VIT-120011 – Service Port Cable
VIT-120021 – Panel Tube Connection Kit
VIT-120042 – Connection Rear Panel
VIT-120043 – Maintenance Rear Panel
7.2.2 Reaction Chamber

VIT-120012 – Thermoelectric Cold Plate Cooler

VIT-120012 Thermoelectric Cold Plate Cooler
VIT-120023 Bar Straight Set


hybriSpot12 Service Manual 18/41

VIT-120029 Quarter turn fastener receptacle


VIT-120026 – Reaction Chamber Gasket

7.2.3 Hydraulic System

VIT-120003 – Miniature Solenoid Valve
VIT-120018 – Tygon Tube ID1/8” – OD1/4”


hybriSpot12 Service Manual 19/41

VIT-120019 – Tygon Tube ID1/16” – OD3/16”
VIT-120020 – Tygon Tube ID3/32” – OD7/32”
VIT-120024 – Manifold Set
VIT-120037 – Bottom Panel
VIT-120045 – Hydraulic Plate
VIT-120046 – Hydraulic Base Plate
VIT-120055 – Peristaltic Pump 1.5x1.0mm
VIT-120056 – Peristaltic Pump Head 1.5x1.0mm
7.2.4 Electronic System



hybriSpot12 Service Manual 20/41

VIT-120004 – Housing Fan
VIT-120005 – Temperature Sensor
VIT-120008 – Peltier Fan Cable
VIT-120009 – Peltier Cable
VIT-120010 – Display Ribbon Cable
VIT-120013 – Power Circuit Board
VIT-120014 – Display Circuit Board


VIT-120060 – Web Camera Circuit Board




hybriSpot12 Service Manual 21/41


VIT-120033 – Image Capture System Webcam
VIT-120058 – Image Capture System V2
7.3 Access to the Hydraulic Circuit
 To access the hydraulic circuit, remove the five (5) screws of the
Maintenance Rear Panel and remove it.


7.4 Access into the instrument and electronics circuits
 Remove carefully the top panel 4 Housing Caps with the help of two
screwdrivers.
 Insert a screwdriver Phillips nº 2 into the hole of each Housing Caps after
the snap fit unblock the lid and pull up it.


hybriSpot12 Service Manual 22/41


 Lift the lid carefully to avoid damaging the connecting pipes between
pumps, valves and Incubation block:




hybriSpot12 Service Manual 23/41

8 ELECTRONIC SYSTEM
8.1 Cables Colour Codes

As convention all the cables used in the HS12’s components have a specific colour in order to
help in a faster identification of each component.
Type of Component Colour Picture
Fans Green-Black

Peltier Purple-Black

Valves Yellow-Black

Pumps Orange-Black

Temperature Sensor Red-White-Black

DC Power Red-Black



8.2 General Description



hybriSpot12 ServiceManual 24/41

8.2.1 Boards interconnections




hybriSpot12 Service Manual 25/41

8.2.2 Power Circuit Board




hybriSpot12 Service Manual 26/41

8.2.3 Main Connections



hybriSpot12 Service Manual 27/41

Close-up of the connections of Power Supply & Switch, Peltiers and
Temperature Sensors:



hybriSpot12 Service Manual 28/41

Close-up of the connections of the pumps, valves and fans:




hybriSpot12 Service Manual 29/41

Close-up of the location of resettable fuses and control LEDS:

Close-up of the location of LEDs control valves and pumps:



hybriSpot12 Service Manual 30/41

8.3 Display Circuit Board



hybriSpot12 Service Manual 31/41

8.4 Service Port and Program Port

VIT-20001 - Service Port Cable (Technical Service Tool)
VIT-20002 – Program Port Cable Kit (Technical Service Tool)


hybriSpot12 Service Manual 32/41

8.5 DC Power Connector




8.6 Camera circuit board and Camera Housing




hybriSpot12 Service Manual 33/41

9 HYDRAULIC SYSTEM
General Description
2
1
2
1
2
1
REACTION CHAMBER
VALVE 3 VALVE 2 VALVE 1
PUMP 3 PUMP 2 PUMP 1
WASTE TANK
WASTE CONNECTION
CLEAN/AIR CONNECTION
SUCTION
MANIFOLD
WASTE
MANIFOLD
CLEAN/AIR TANK
CLEAN/AIR CONNECTION
3xTYGON R3630 TUBING
(1/16" ID x 3/32" OD)
CHAMBER TEMPERATURE
SENSOR HOLE
TYGON R3603 TUBING
(1/8" ID x 1/4" OD)
TYGON R3603 TUBING
 (1/8" ID x 1/4" OD)
TYGON R3603 TUBING
 (1/8" ID x 1/4" OD)
TYGON R3603 TUBING
 (1/8" ID x 1/4" OD)
3xTYGON R3630 TUBING
(3/32" ID x 7/32" OD)
3xTYGON R3630 TUBING
(3/32" ID x 7/32" OD)
A1A2B2
B1
C3 C2 C1
D3 D2 D1
C6 C5 C4
D6 D5 D4
Instrument hybriSpot 12
Plan HYDRAULIC DIAGRAM
Author DJ
Versión: V01
Fecha: 04/02/14



hybriSpot12 Service Manual 34/41

8 CONTROL SOFTWARE

The control software, HS12 Monitor, detects automatically the USB port
connection of hybriSpot 12. In case it not automatically detected, you can
select the connection port using the drop menu HS12 Port:

8.1 Valves and Pumps Control Area

You can make an independent or full set of control for the valves and pumps.
To do this, open the Valves / Pump section.
ON button turns the valve or pump on and OFF button turns it off. There is a
color code to the right of each valve indicating the status of each component:
•Valves:
 Green: Turned off
 Red: Turned on
 Blue: Low consumption



hybriSpot12 Service Manual 35/41











•Pumps:
 Green: Turned off
 Red: Turned on
When the valve remains on for long, Duty Cycle Time is activated and low
consumption mode is powered on to safeguard the integrity of the valve and
save energy.
Note that there are two different fans connected to the Valve 4 and Pump 4
positions. The chassis fan is connected to the Pump 4 position and it is always
working (This position is always in red color). The peltier fan is connected to the
Valve 4 position and is controlled directly by software. The ON and OFF buttons
don’t work in this position.
8.2 Temperature Control
The temperature control can be monitored through the Temperature Control
section.
 Target Temperature: Target temperature to be reached
 P, I, D, I Lim Values, Delta Shutdown: Target Parameters (internal use and
no documentary evidence)
 Fan Stop Temp (º C): Temperature at which the fan stops working.
 Fan Stop Time (Seg): Time when the fan stop working when reaching
“Fan Stop Temp”.
 Temp Gain, Temp OffSet: Target Parameters (internal use and no
documentary evidence)



hybriSpot12 Service Manual 36/41



There is a visual control to manage if the temperature target value has been
reached and the control of the fans. To perform the temperature control, press
the Run Control button and to stop control, press the Stop Control button.
Temp. Control:
 Green: Turned off
 Red: Turned on
 Blue: Low consumption
Target Reach:
 Green: Target temperature unreached
 Red: Target temperature reached
Fan On:
 Green: Peltier Fan is not working.
 Red: Fan Peltier Fan is working.




hybriSpot12 Service Manual 37/41

8.3 Commands Menu
 Read Config: read the configuration of the current RAM memory of the
system.
 Send Config: Send the current configuration to the RAM memory of the
system.
 Write Config in Flash: Write the current configuration from the RAM
memory to the Flash memory of the system.
 Reload Flash Config: Refresh the current configuration in the RAM
memory with the one stored in the Flash Memory of the system.
 Factory Settings: Set the default parameters.
 System Reset
 Stop System:

8.4 Auto Settings Menu





hybriSpot12 Service Manual 38/41

 TEC Profile: Tool used for temporary temperature control settings on the
instrument. It is used as a worksheet in which different steps are added,
such us objectives temperatures and how long you have to maintain
that temperature.
8.5 Flash Memory Programming
The procedure for programming the Flash memory is as follows:
Connect the Cable Port Kit Program (VIT-20002) to your computer using the USB
cable and the program port of the Power Circuit Board.

 Start the STM ST-LINK utility and connect to the device. The Connect to
the target icon is used.


hybriSpot12 Service Manual 39/41


 Before programming the instrument, delete the content stored in the
Flash, pressing the Full Chip Erase button.

• A message will indicate the complete deletion of the memory.


hybriSpot12 Service Manual 40/41


 Once the deletion process is finished, check that the memory content is
FFFFFFFF in all entries.

 To program the new firmware version click on the Program Verify- icon
and a new dialog box will appear.


hybriSpot12 Service Manual 41/41

 Press the Browse button to select the file with the new program to install
and press the Start button to begin programming.

 Once the process is completed, verify that the memory has been
successfully programmed.
