SYSTEMATIC REVIEW PROTOCOL
Rehabilitation for tibial plate
au fractures in adults: a
scoping review protocol
Tri M. Phan1 � John Arnold2 � Lucian B. Solomon1,3
1Trauma and Orthopedics Hospital, Ho Chi Minh City, Vietnam, 2School of Health Sciences and Sansom Institute for Health Research, University of
South Australia, Adelaide, Australia, and 3Discipline of Orthopaedics and Trauma, The University of Adelaide, Adelaide, Australia
Review objective: Based on the observation that rehabilitation practices for tibial plateau fractures are inconsistent
and lack uniformity in the published literature, this scoping review will seek to identify all relevant studies that have
reported on rehabilitation for tibial plateau fractures in order to comprehensively map the characteristics of the
practices. This scoping review will then be used to identify commonalities across the included studies in order to
identify potential focus questions for subsequent systematic reviews.
Keywords physical therapy; proximal tibial fractures; rehabilitation; tibial plateau fractures; weight-bearing
JBI Database System Rev Implement Rep 2017; 15(10):2437–2444.
Background
T ibial plateau fractures (TPFs) which involve the
proximal tibia in its articular and meta-epiphy-
seal segments are one of the commonest intra-artic-
ular fractures, representing approximately 1% of all
fractures in adults.1-3 These fractures are caused
mainly by axial loading with concomitant varus/
valgus or flexion/extension bending, and have vari-
ous morphology involving the lateral, medial or both
tibial condyles with many degrees of articular de-
pression widening and angulation.4-7 Tibial plateau
fractures are frequently complex intra-articular in-
juries with a variety of fracture patterns, portending
a poor prognosis due to associated complications,
i.e. compartment syndrome, cartilage destruction,
soft-tissue envelope damage, post-surgery infection,
knee instability or stiffness, and post-traumatic os-
teoarthritis.8-11 As such, they are managed mainly in
hospital settings, and they not only pose challenges
for the surgeon,12,13 but also have an enormous
impact on patients and devastating socio-economic
consequences due to the time taken off work for
the patient and impaired functional integrity of the
knee.14-17
Achieving fracture reduction and stabilization
is only the initial step; good postoperative
Correspondence: Tri M. Phan, phanminhtri.md@gmail.com
There is no conflict of interest in this project.
DOI: 10.11124/JBISRIR-2016-002949
JBI Database of Systematic Reviews and Implementation Reports
©2017 Joanna Briggs Institute. Unauthorize
rehabilitation is necessary as early mobilization
may limit complications following intra-articular
fractures, including knee joint stiffness, muscle
and bone atrophy, synovial adhesions and capsular
contractions to adversely impact on outcomes.18-22
However, there is no consensus about rehabilitation
practices as immobilization and protection from
weight bearing varies widely among orthopedic
surgeons.
There is confusion as to whether range of motion
exercises should be passive, active assisted or active
in nature.23 While some authors have recommended
passive exercises immediately postoperatively,24-26
after the second postoperative day27 or once wounds
were sealed and dry,28 others considered immediate
active motion protected in a hinged knee orthosis,29
or never employed continuous passive motion re-
gime for their patients.29 In addition, there is large
variation regarding the immobilization time, ranging
from 10 days30 to six weeks postoperatively.28,31,32
Regarding weight bearing after TPFs fixation,
there remains confusion in the rehabilitation prac-
tices with recommendations varying from no weight
bearing from four to 12 weeks,8,25,26,28,33 partial
weight bearing from six to 12 weeks,24,29,30,34,35
partial weight bearing prescribed on an individual
basis,36 full weight bearing from nine to 12 weeks
postoperatively,29,30,36 or when union observed on
plain film is significant.37-39
While commencing weight bearing too early may
increase the risk for implant failure, leading to the
� 2017 THE JOANNA BRIGGS INSTITUTE 2437
d reproduction of this article is prohibited.
mailto:phanminhtri.md@gmail.com
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
loss of fracture reduction and malunion,40 there is
a substantial difference in energy expenditure
between non and partial weight-bearing gait,
impacting on patient independence and hospital
length of stay.23
A preliminary search of the literature in
Cochrane Database of Systematic Reviews, JBI
Database of Systematic Reviews and Implementa-
tion Reports, CINAHL, PubMed, PROSPERO and
Epistemonikos identified that no systematic or
scoping review has addressed the proposed topic.
Considering the lack of current evidence, together
with characteristics of a scoping review in exam-
ining ‘‘the extent, range and nature of research
activity . . . to determine the value of undertaking
a full systematic review’’,41(p.6) we recommend
a scoping review to map the relevant literature.
This scoping review will be conducted in accor-
dance with the methodology for JBI scoping
reviews.42,43
Inclusion criteria
Types of participants
The review will consider studies that include patients
over 16 years of age undergoing rehabilitation prac-
tices for TPFs. Patients under 16 will be excluded as
many will still have open growth plates, as open
growth plates fractures differ dramatically from
fractures that occur at skeletal maturity.44 Studies
that recruited people following periprosthetic frac-
tures, pathological fractures or multiple fractures of
the same limb will be excluded. Periprosthetic and
pathological fractures will be excluded as their treat-
ment and outcomes are preponderantly related to
one of the prosthesis or neoplastic process. Cases
with multiple ipsilateral lower limb fractures will be
excluded as they affect the overall healing and reha-
bilitation of the limb.
Concepts
The review will consider all research studies that
address rehabilitation practices for TPFs in adults
including weight-bearing status, application of im-
mobilization device (brace, cast, immobilizers), post-
operative motion and exercises.
Context
The review will consider studies conducted in
hospital settings.
JBI Database of Systematic Reviews and Implementation Reports
©2017 Joanna Briggs Institute. Unauthorize
Sources
This review will consider quantitative studies that
may include, but will not be limited to, randomized,
quasi-randomized controlled trials, case-control and
case series studies.
Search strategy
The search strategy aims to find both published and
unpublished literature. A three-step search will be
utilized in each component of this review. An initial
limited search of MEDLINE and CINAHL will be
undertaken followed by an analysis of the text words
contained in the title and abstract, and of the index
terms used to describe relevant articles. A second
search using all the identified keywords and index
terms will then be undertaken across all included
databases. Third, the reference list of all included
studies will be searched for additional studies. Stud-
ies published in English will be considered for inclu-
sion in this review. No time limit will be imposed on
studies for inclusion in this review.
The databases to be searched will include:
�
d r
MEDLINE
�
 CINAHL
�
 Embase
�
 Cochrane Database of Systematic Reviews,
Cochrane Central Register of Controlled Trials
(CENTRAL)
�
 JBI Database of Systematic Reviews and
Implementation Reports
�
 Scopus
�
 PEDRO.
The search for unpublished studies will include:
�
 ClinicalTrials.gov
�
 International Clinical Trials Registry Platform
�
 UK Clinical Trials Gateway
�
 ProQuest Dissertations and Theses
�
 Grey Literature (The New York Academy of
Medicine)
�
 Open Grey (System for Information on Grey
Literature in Europe)
�
 MedNar
�
 Trove (theses).
Initial keywords to be used will be, but will not belimited to: ‘‘tibial plateau’’ OR ‘‘proximal tibial’’
OR ‘‘knee fractures’’ AND ‘‘rehabilitation’’ OR
‘‘exercise’’ OR ‘‘joint loading’’ OR ‘‘weight
bearing’’ OR ‘‘physical therapy’’ OR ‘‘knee
function’’ OR ‘‘scoping review’’.
� 2017 THE JOANNA BRIGGS INSTITUTE 2438
eproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
Data extraction
A data extraction form for this scoping review will
be developed, based on those from JBI SUMARI (a
draft of the adapted form is shown in Appendix I) as
well as discussion among all reviewers. The reported
variables will include specific details about authors,
populations, study method, type of tibial plateau
fractures, types of treatments, type of rehabilitation
practices and duration, outcome of significance and
key findings relating to the scoping review objective.
This may be further refined at the review stage.
Two reviewers will extract data independently.
Any disagreement will be resolved by discussion with
a third reviewer. The author of the primary study
will be contacted if further clarification of the data is
required.
Data mapping
After the data have been extracted, we will: i) map
the key concepts and available evidence, ii) summa-
rize the existing research findings, and iii) identify
research gaps in the existing literature. The key
findings will be mapped and presented in formats
reflecting the objectives of this scoping review as
appropriate (diagrammatic, tabular summary or de-
scriptive format). The process will be further refined
toward the end of the review when reviewers have
the greatest awareness of the contents of the included
studies.42
Acknowledgements
Tri M. Phan is supported by an Endeavour Executive
Fellowship from the Australian Government.
References
1. Ravindran B, Babu BK, Rallapalli R, Shaik MV. An outcome of
surgical management of the tibial plateau fractures. Int J
Health Allied Sci 2014;3(2):110–4.
2. Moore TM, Patzakis MJ, Harvey JP. Tibial plateau fractures:
definition, demographics, treatment rationale, and long-
term results of closed traction management or operative
reduction. J Orthop Trauma 1987;1(2):97–119.
3. Lansinger O, Bergman B, Korner L, Anderson GBJ. Tibial
condylar fractures: a twenty-year follow-up. J Bone Joint
Surg 1986;68(1):13–9.
4. Fenton P, Porter K. Tibial plateau fractures: A review. Trauma
2011;13(3):181–7.
5. Koval KJ, Helfet DL. Tibial plateau fractures: Evaluation and
treatment. J Am Acad Orthop Surg 1995;3(2):86–94.
JBI Database of Systematic Reviews and Implementation Reports
©2017 Joanna Briggs Institute. Unauthorize
6. Booth FW. Physiologic and biochemical effects of immo-
bilization on muscle. Clin Orthop Relat Res 1987;219:
15–20.
7. Blakemore ME. Fractures of the tibial plateau. Trauma
1999;1:235–43.
8. Gaston P, Will EM, Keating JF. Recovery of knee function
following fracture of the tibial plateau. J Bone Joint Surg [Br]
2005;87(9):1233–6.
9. Gardner MJ, Yacoubian S, Geller D, Pode M, Mintz D, Helfet
DL, et al. Prediction of soft-tissue injuries in Schatzker II tibial
plateau fractures based on measurements of plain radio-
graphs. J Trauma 2006;60(2):319–23.
10. Stevens DG, Beharry R, McKee MD, Waddell JP, Schemitsch
EH. The long-term functional outcome of operatively
treated tibial plateau fractures. J Orthop Trauma 2001;
15(5):312–20.
11. Houben PFJ, Linden ESvd, Wildenberg FAJMvd, Stapert
JWJL. Functional and radiological outcome after intra-
articular tibial plateau fractures. Injury 1997;28(7):459–62.
12. Biggi F, Fabio SD, D’Antimo C, Trevisani S. Tibial plateau
fractures: Internal fixation with locking plates and the
MIPO technique. Injury, Int J Care Injured 2010;41(11):
1178–82.
13. Elsoe R, Larsen P, Shekhrajka N, Ferreira L, Ostgaard SE,
Rasmussen S. The outcome after lateral tibial plateau frac-
ture treated with percutaneus screw fixation show a ten-
dency towards worse functional outcome compared with
a reference population. Eur J Trauma Emerg Surg 2016;
42(2):177–84.
14. Chen HW, Liu GD, Wu LJ. Clinical and radiological outcomes
following arthroscopic-assisted management of tibial
plateau fractures: A systematic review. Knee Surg Sports
Traumatol Arthrosc 2015;23(12):3464–72.
15. Honkonen SE. Degenerative arthritis after tibial plateau
fractures. J Orthop Trauma 1995;9(4):273–7.
16. Kraus TM, Martetschlager F, Muller D, Braun KF, Ahrens P,
Siebenlist S, et al. Return to sports activity after tibial plateau
fractures 89 cases with minimum 24-month follow-up. Am J
Sports Med 2012;40(12):2845–52.
17. Manidakis N, Dosani A, Dimitriou R, Stengel D, Matthews S,
Giannoudis P. Tibial plateau fractures: functional outcome
and incidence of osteoarthritis in 125 cases. Int Orthop
2010;34(4):565–70.
18. Cole PA, Zlowodzki M, Kregor PJ. Less invasive stabilization
system (LISS) for fractures of the proximal tibia: Indications,
surgical technique and preliminary results of the UMC
Clinical Trial. Injury 2003;34(Supl 1):A16–29.
19. Akeson WH, Amiel D, Abel MF, Garfin SR, Woo S-Y. Effects
of immobilization in joint. Clin Orthop Relat Res 1987;
1987(219):28–37.
20. Jenkins DG, Imms FJ, Prestidge SP, Small GI. Muscle strength
before and after menisectomy: A comparison of methods of
post-operative management. Rheum Rehabil 1976;15(3):
153–5.
� 2017 THE JOANNA BRIGGS INSTITUTE 2439
d reproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
21. Narayan B, Harris C, Nayagam S. Treatment of high-energy
tibial plateau fractures. Strat Traum Limb Recon 2006;
1(1):18–28.
22. Hurley MV. The effects of joint damage on muscle function,
proprioception and rehabilitation. Man Ther 1997;2(1):11–7.
23. Smith TO, Hedges C, Schankat K. A systematic review of the
rehabilitation of LISS plate fixation of proximal tibial frac-
tures. Adv Physiother 2010;12(2):100–10.
24. Boldin C, Fankhauser F, Hofer HP, Szyszkowitz R. Three year
results of proximal tibia fractures treated with LISS. Clin
Orthop Relat Res 2006;445:222–9.
25. Cole PA, Zlowodzki M, Kregor PJ. Treatment of proximal tibia
fractures using the Less Invasive Stabilization System.
Surgical experience and early clinical results in 77 fractures.
J Orthop Trauma 2004;18(8):528–35.
26. Zura RD, Browne JA, Black MD, Olson SA. Current manage-
ment of high-energy tibial plateau fractures. Curr Orthop
2007;21(3):229–35.
27. Egol KA, Kubiak EN, Fulkerson E, Kummer FJ, Koval KJ.
Biomechanics of locked plates and screws. J Orthop Trauma
2004;18(8):488–93.
28. Jiang R, Luo C-F, Zeng B-F. Biomechanical evaluation of
different fixation methods for fracture dislocation involving
proximal tibia. Clin Biomech 2008;23(8):1059–64.
29. Rossi R, Bonasia DE, Blonna D, Assom M, Castoldi F. Pro-
spective follow-up of a simple arthroscopic-assisted tech-
nique for lateral tibial plateau fractures: Results at 5 years.
The Knee 2008;15(5):378–83.
30. Dall’Oca C, Maluta T, Lavini F, Bondi M, Micheloni GM,
Bartolozzi P. Tibial plateau fractures: Compared outcomes
between ARIF and ORIF. Strat Traum Limb Recon 2012;
7(3):163–75.
31. Phisitkul P, Mckinley TO, Nepola JV, Marsh JL. Complications
of locking plate fixation in complex proximal tibia injuries.
J Orthop Trauma 2007;21(2):83–91.
32. Stannard JP, Wilson TC, Volgas DA, Alonso JE. The less
invasive stabilization system in the treatment of complex
fractures of the tibial plateau: Short-term results. J Orthop
Trauma 2004;18(8):552–8.
33. Ohdera T, Tokunaga M, Hiroshima S, Yoshimoto E, Tokunaga
J, Kobayashi A. Arthroscopic management of tibial plateau
JBI Database of Systematic Reviews and Implementation Reports
©2017 Joanna Briggs Institute. Unauthorize
fractures – comparison with open reduction method. Arch
Orthop Trauma Surg 2003;123(9):489–93.
34. Ricci WM, Rudzki JR, Borrelli J. Treatment of complex
proximal tibia fractures with the less invasive skeletal sta-
bilization system. J Orthop Trauma 2004;18(8):521–7.
35. Smith WR, Shank JR. Tibialplateau fractures: Minimally
invasive fracture techniques. Operative Techniques in
Orthopaedics 2001;11(3):187–94.
36. Lee JA, Papadakis SA, Moon C, Zalavras CG. Tibial plateau
fractures treated with the less invasive stabilisation system.
Int Orthop 2007;31(3):415–8.
37. Lee M-H, Hsu C-J, Lin K-C, Renn J-H. Comparison of outcome
of unilateral locking plate and dual plating in the treatment
of bicondylar tibial plateau fractures. J Orthop Surg Res
2014;9(62):1–8.
38. Ehlinger M, Adamczewski B, RahméM, Adam P, Bonnomet F.
Comparison of the pre-shaped anatomical locking plate of
3.5mm versus 4. 5mm for the treatment of tibial plateau
fractures. Int Orthop 2015;39(12):2465–71.
39. Chin TYP, Bardana D, Bailey M, Williamson OD, Miller R,
Edwards ER, et al. Functional outcome of tibial plateau
fractures treated with the fine-wire fixator. Injury, Int J Care
Injured 2005;36(12):1467–75.
40. Schütz M, Müller M, Krettek C, Hontzsch D, Regazzoni P, Haas
N. Minimally invasive fracture stabilisation of distal femoral
fractures with the LISS: A prospective multicenter study.
Results of a clinical study with special emphasis on difficult
cases. Injury 2001;32(Supl 3):SC3–13.
41. Arksey H, O’Malley L. Scoping studies: towards a methodo-
logical framework. Int J Soc Res Methodol 2005;8(1):
19–32.
42. Peters MDJ, Godfrey CM, McInerney P, Soares CB,
Khalil H, Parker D. Methodology for JBI scoping reviews.
In: Aromataris E, editor. The Joanna Briggs Institute
Reviewers’ Manual 2015. Adelaide: The Joanna Briggs
Institute, 2015;1–24.
43. Peters MD, Godfrey CM, Khalil H, McInerney P, Parker D,
Soares CB. Guidance for conducting systematic scoping
reviews. Int J Evid Based Healthc 2015;13(3):141–6.
44. Peterson HA. Epiphyseal growth plate fractures. Germany:
Springer-Verlag Berlin Heidelberg; 2007.
� 2017 THE JOANNA BRIGGS INSTITUTE 2440
d reproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
Appendix I: Data extraction instrument
Data extraction form (tick where applicable)
Reviewer: .................................................................................... Date .........................................
Author ......................................................................................... Year .........................................
Title ............................................................................................. .................................................
Journal......................................................................................... Vol & Iss ................................
Study method
RCT � Quasi RCT � Retrospective cohort �
Prospective cohort � Case control � Case studies �
Other:...................................................................................
Participants
Country ........................................................ .................................................
Sample size: ................................................. Age (mean (min, max))...........
Gender: Male ............................................... Female.....................................
Type of fractures and number
Open � No....................... Close � No..........................
Classification ( AO, Schatzker, Hohl and Moore, etc) and numbers
............................................................ ................................................. ..............................
............................................................ ................................................. ..............................
............................................................ ................................................. ..............................
............................................................ ................................................. ..............................
Fracture treatment:
Nonoperative � No...................
Surgical � No ..................
Unicondylar fractures
Standard open reduction internal fixation (ORIF) No...................
Circular external fixation with limited internal fixation (hybrid fixation) No...................
JBI Database of Systematic Reviews and Implementation Reports � 2017 THE JOANNA BRIGGS INSTITUTE 2441
©2017 Joanna Briggs Institute. Unauthorized reproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
Less invasive stabilisation system (LISS) No...................
Arthroscopically assisted percutaneous reduction and internal fixation No...................
Other ............................................................................................................ No...................
Bicondylar fractures
Standard unilateral open reduction internal fixation (ORIF) No...................
Circular external fixation with limited internal fixation (hybrid fixation) No...................
Less invasive stabilisation system (LISS) No...................
Double plating open reduction internal fixation No...................
Arthroscopically assisted percutaneous reduction and internal fixation No...................
Other ............................................................................................................ No...................
Bone graft (autologous) No...................
Bone fillers (specify type) ........................................................................... No...................
Intervention: rehabilitation practices
..................................................................................................... .......................................
..................................................................................................... .......................................
..................................................................................................... .......................................
..................................................................................................... .......................................
..................................................................................................... .......................................
Intervention: device use (brace, walking aids)
..................................................................................................... ......................................
..................................................................................................... .......................................
Outcomes
Follow period (months & number of time-points)................................
Lost to follow up...................................................................................
Range of motion (ROM):
Extension (mean (min, max)) .................................................
Flexion (mean (min, max)) .....................................................
JBI Database of Systematic Reviews and Implementation Reports � 2017 THE JOANNA BRIGGS INSTITUTE 2442
©2017 Joanna Briggs Institute. Unauthorized reproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
Radiology
Fracture reduction X-ray � CT �
Lateral plateau step (mm)............................................................ .......................................
Medial plateau step (mm) ........................................................... .......................................
Medial plateau depression (mm) ................................................. .......................................
Lateral plateau depression (mm) ................................................. .......................................
Fracture gap deformity (mm) ...................................................... .......................................
Metaphyseal-diaphyseal angulation (degree) ..............................
Healed fracture X-ray � CT � RSA �
Lateral plateau step (mm)
Medial plateau step (mm) ..................................................................................................
Medial plateau depression (mm) ................................................. .......................................
Lateral plateau depression (mm) ................................................. .......................................
Fracture gap deformity (mm) ...................................................... .......................................
Metaphyseal-diaphyseal angulation (degree) ..............................
Radiological evidence of tibiofemoral joint osteoarthritis ..........No
Time to observable callus formation (weeks) .............................
Time to radiological union (weeks).............................................
Functional outcome measures
Time to full weight bearing (weeks) ...........................................
Applied score (HSS, SF-36, WOMAC, etc.) .............................. .......................................
Mean (min, max & time-point)............................................... .......................................
................................................................................................ .......................................
................................................................................................ .......................................
................................................................................................ .......................................
Complications No � Yes �
Nonunion .....................................................................................No ...................................
JBI Database of Systematic Reviews and Implementation Reports � 2017 THE JOANNA BRIGGS INSTITUTE 2443
©2017 Joanna Briggs Institute. Unauthorized reproduction of this article is prohibited.
SYSTEMATIC REVIEW PROTOCOL T.M. Phan et al.
Delay union .................................................................................No ...................................
Implant failure ............................................................................No ...................................
Abnormal Valgus/varus deformity ..............................................No ...................................
Flexion/extension deformity........................................................No ...................................
Others ..........................................................................................No ...................................
Author conclusions
................................................................................................ .......................................
................................................................................................ .......................................
................................................................................................ .......................................
Reviewer conclusions
................................................................................................ .......................................
................................................................................................ .......................................
................................................................................................ .......................................
JBI Database of Systematic Reviews and Implementation Reports � 2017 THE JOANNA BRIGGS INSTITUTE 2444
©2017 Joanna Briggs Institute. Unauthorized reproduction of this article is prohibited.
