The skin is a barrier organ that separates the body
from the outside environment. Because many physical,
chemical and microbial insults affect the skin, various
types of immune cells reside in or are recruited into the
skin to maintain skin homeostasis upon inflammatory
challenges.
In the epidermis, Langerhans cells (LCs), which are
a unique subset of professional antigen-presenting cells
(APCs), reside between keratinocytes (Fig. 1a). Although
LCs were previously considered a subset of dendritic cells
(DCs) because they migrate to the lymph nodes, recent
ontogenic studies have revealed that LCs are actua-
lly a subset of tissue-resident macrophages that acquire
a DC-like phenotype and functions upon further differ-
entiation in the skin1,2. In addition to LCs, two specific
subsets of T cells can be found in the mouse epidermis: γδ
T cells and CD8+ resident memory T (TRM) cells. γδ T cells
are a subset of innate immune cells that reside perma-
nently in the epidermis of mice but not humans. CD8+ TRM
cells comprise populations of non-circulating memory
T cells that appear after the resolution of skin inflam-
mation, such as that caused by herpes simplex virus
(HSV) infection3. TRM cells have been identified in var-
ious non-lymphoid tissues4,5, and their longevity differs
between tissues. For example, skin TRM cells in mice per-
sist for over a year6, whereas lung TRM cells are maintained
for only a few months7.
Anatomically, the most unique feature of the epider-
mis is the existence of the stratum corneum8,9 (Box 1;
Fig. 1a). The stratum corneum is the outermost layer
of the epidermis and consists of piles of dead keratino-
cytes (known as corneocytes) and intercellular lipids.
This structure blocks the entry or exit of water and
water-soluble substances; thus, it is essential for animals
to survive outside of water. Its barrier function is, how-
ever, imperfect because it contains many holes for skin
appendages, such as hair follicles and sweat ducts. Skin
appendages are useful to protect the body from mechan-
ical damage, ultraviolet light, temperature changes and
dryness. Thus, animals develop skin appendages at
the expense of the integral stratum corneum. It is of
note that numerous microorganisms (known as the
microbiota) live on the surfaces of our body in a com-
mensal relationship and may influence our cutaneous
immune reactions10,11. As skin appendages lack the
stratum corneum, the skin microbiota coexists beside
living keratinocytes in these areas11. This results in skin
appendages being immunologically unique spots.
In the dermis, there are several types of innate
immune cells, including dermal DCs, macrophages,
mast cells, γδ T cells and innate lymphoid cells (ILCs)12.
In the steady state, small numbers of neutrophils, mono-
cytes and αβ T cells survey the dermis for pathogens; in
response to inflammatory stimuli, many more immune
cells rapidly accumulate in the dermis13–15. Anatomically,
the dermis is characterized by an abundant extracellu-
lar matrix (ECM), comprising collagen and elastin fibres
that fill the extracellular spaces. The ECM provides a
scaffold for immune cell migration16. Throughout the
ECM, mesh-like networks of blood and lymph vascu-
latures and neurons are distributed. Immune cells are
constantly recruited to the skin via the blood vascular
systems. The recruited cells include the precursor cells of
skin-resident DCs and macrophages as well as some pas-
senger cells, such as neutrophils and T cells, which scout
for foreign pathogens. Dermal DCs that have captured
The immunological anatomy
of the skin
Kenji Kabashima 1,2*, Tetsuya Honda1, Florent Ginhoux 2,3 and Gyohei Egawa1*
Abstract | The skin is the outermost organ of the body and is continuously exposed to external
pathogens. Upon inflammation, various immune cells pass through, reside in or are recruited to the
skin to orchestrate diverse cutaneous immune responses. To achieve this, immune cells interact
with each other and even communicate with non-immune cells, including peripheral nerves
and the microbiota. Immunologically important anatomical sites, such as skin appendages
(for example, hair follicles and sweat glands) or postcapillary venules, act as special portal sites for
immune cells and for establishing tertiary lymphoid structures, including inducible skin-associated
lymphoid tissue. Here, we provide an overview of the key findings and concepts of cutaneous
immunity in association with skin anatomy and discuss how cutaneous immune cells fine-tune
physiological responses in the skin.
1Department of Dermatology,
Graduate School of Medicine,
Kyoto University, Kyoto,
Japan.
2Singapore Immunology
Network (SIgN) and Institute
of Medical Biology (IMB),
Agency for Science,
Technology and Research
(A*STAR), Biopolis,
Singapore.
3Shanghai Institute of
Immunology, Shanghai
JiaoTong University School of
Medicine, Shanghai, China.
*e-mail: kaba@
kuhp.kyoto-u.ac.jp; gyohei@
kuhp.kyoto-u.ac.jp
https://doi.org/10.1038/
s41577-018-0084-5
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 19
http://orcid.org/0000-0002-0773-0554
http://orcid.org/0000-0002-2857-7755
mailto:kaba@
kuhp.kyoto-u.ac.jp
mailto:kaba@
kuhp.kyoto-u.ac.jp
mailto:gyohei@kuhp.kyoto-u.ac.jp
mailto:gyohei@kuhp.kyoto-u.ac.jp
https://doi.org/10.1038/s41577-018-0084-5
https://doi.org/10.1038/s41577-018-0084-5
FAS ligand
Specific ECM
components
Treg cell and/or
CD4+ TRM cell
Infundibulum
Isthmus
IL-17A
Neutrophil
T
H
17 cells
T
H
17 cells
IL-17A
Bulge
Demodex sp.
(mite)
Monocyte
and/or
macrophage
CD8+
T
RM
 cell
CCL20
and/or
IL-15
CCL8
IL-10
TGFβ
IL-1β
TGFβ IL-6
CCL2
and/or
IL-17
Microbiota
Lymph duct
DC
P. acnes
T
RM
 cell LC
Sweat duct
Stratum
corneum
Epidermis
Hair shaft
a
b c
Stratum
corneum
Stratum
granulosum
Stratum
spinosum
Stratum
basale
Lymph
duct
Subcutaneous
adipose tissue
Dermis
Blood
vessel
γδ T cell
Keratinocyte
Tight
junction
Sebaceous
gland
Sweat
gland
Fig. 1 | Physical and immunological barrier of the skin. a | Structures of the skin. In the epidermis, tight junctions are
formed underneath the stratum corneum (in the stratum granulosum), and three types of immune cell populations
(Langerhans cells (LCs), γδ T cells and resident memory T (TRM) cells) reside between keratinocytes. b | A schematic of
immune privilege of hair follicles. Hair follicles express FAS ligand while lacking MHC class II expression, and they are
surrounded by immune-suppressive extracellular matrix (ECM) components. TRM cells and regulatory T (Treg) cells are found
in the vicinity of hair follicles. Numerous microorganisms live deep inside the hair follicles. Follicular keratinocytes in
different parts of the follicle produce distinct chemokines and control the traffic of leukocytes in the skin. c | A schematic
of immune modulation by sebaceous glands. The bacterium Propionibacterium acnes stimulates sebaceous glands to
produce IL-1β, IL-6 and transforming growth factor-β (TGFβ), which leads to the activation of dermal dendritic cells (DCs)
that can preferentially prime T helper 17 (TH17) cells. The TH17 cells promote neutrophil recruitment and inflammation at
the hair follicle. CCL , CC-chemokine ligand.
www.nature.com/nri
R e v i e w s
20 | JANuARY 2019 | volume 19
cutaneous antigens migrate back to the draining lymph
nodes via the lymphatics17. Neurons endow a sensory
function to the skin and can directly communicate with
immune cells18,19.
Recent developments in imaging studies in vivo have
demonstrated the dynamic behaviour of immune cells in
the skin and underscored the unique distribution pattern
of each immune subset that is related to skin anatomical
structures. Thus, knowledge of the interaction between
immune cells and non-immune structures is important
for a deep understanding of the basic mechanisms of
cutaneous immune reactions. In this Review, we dis-cuss the unique nature of some anatomical parts and
non-immune components of the skin (for example, hair
follicles, blood vessels, neurons, sebaceous glands and
the microbiota) and focus on the function of a specific
immunological unit, called inducible skin-associated
lymphoid tissue (iSALT)20, which has an essential role
in the induction of cutaneous adaptive immunity.
Immunological anatomy of the epidermis
The main function of keratinocytes is to maintain the
physical barrier of the skin by developing into the stra-
tum corneum. This is achieved by keratinocytes passing
through three inner cell layers: the stratum basale, the
stratum spinosum and the stratum granulosum (Fig. 1).
Keratinocytes are not merely a progenitor of the bar-
rier but also a component of the innate immune sys-
tem. They express several different pattern recognition
receptors and produce a variety of cytokines, including
thymic stromal lymphopoietin (TSLP), tumour necro-
sis factor (TNF), IL-33 and other IL-1 family members,
upon inflammation21. These cytokines are essential for
activation of skin-resident immune cells and for immune
cell recruitment to the skin (reviewed previously22). As
skin appendages lack the stratum corneum, they are
points of entry for external pathogens. In addition to
low-molecular-weight compounds, such as haptens,
living microorganisms (for example, bacteria, fungi,
viruses, parasites and mites such as Demodex spp.)
can easily reach the vicinity of keratinocytes living in
these areas11 (Fig. 1b). To handle this unique situation,
hair follicles are equipped with specific immunological
properties, as described below.
Monocyte interaction with hair follicles. Previous
in vivo imaging studies demonstrated that hair folli-
cles interact closely with recruited monocytes23. When
LCs were depleted by diphtheria toxin treatment of
Langerin-DTR mice, GR1high monocyte-derived LC pre-
cursor cells appeared around hair follicles within
weeks23. This suggested that hair follicles are portal
sites where LC precursors enter the epidermis. Such
LC repopulation is dependent on CC-chemokine
receptor 2 (CCR2) and CCR6, suggesting that hair fol-
licles constitutively produce chemoattractants for LCs.
Fluorescence-activated cell sorting-based cell isolation
and gene expression analyses revealed that the chemo-
kine expression patterns of follicular keratinocytes differ
according to their location. Specifically, keratinocytes in
the hair follicle infundibulum produce CC-chemokine
ligand 20 (CCL20); keratinocytes in the isthmus produce
CCL2; and keratinocytes around the hair bulge region
produce CCL8 (Fig. 1b).
Monocyte-derived cells also rally around hair fol-
licles during inflammation. These cells have several
confusing synonyms and have been referred to as
inflammatory monocytes, inflammatory macrophages
and inflammatory DCs. When entering the epider-
mis, they are called inflammatory dendritic epidermal
cells24. After the induction of skin inflammation by hap-
ten painting, CX3C-chemokine receptor 1 (CX3CR1)+
monocyte-derived cells form clusters around hair fol-
licles within a day in a CCR2-dependent manner25.
Although the immunological function of these clus-
ters remains unclear, the activation of T cells and their
production of IFNγ is facilitated by cluster formation,
suggesting that antigen presentation in the skin under
inflammatory conditions depends, at least in part, on
activated inflammatory monocytes.
T cell interaction with hair follicles. In contrast to the
folliculotropic properties of monocytes, hair follicles
have a repellent nature towards effector T cells in the
steady state, which has led the hair follicle to be classified
as a site of immune privilege26 (Fig. 1b). This is charac-
terized by the downregulation of MHC class I expres-
sion in follicular keratinocytes, the local production
of potent immunosuppressants (such as transforming
growth factor-β1 (TGFβ1) and IL-10), the establish-
ment of a unique ECM surrounding the hair follicle
and the production of FAS ligands to delete autoreac-
tive FAS-expressing T cells. Why hair follicles have this
immune privilege is still under discussion, but it likely
leads to the sequestration of not only self-antigens in
hair follicles but also colonized microorganisms, pre-
venting their exposure to T cells. As such, the collapse of
immune privilege at these sites and the development
of T cell responses against the skin microbiota may
potentially result in autoimmune responses against hair
follicles, such as those observed in alopecia areata27.
By contrast to their repellent effect on effector T cells,
hair follicles harbour skin-resident TRM cells, which are
responsible for long-term skin immunity28. CD4+ and
CD8+ TRM cells predominantly reside around hair fol-
licles. Keratinocytes in the infundibulum and isthmus
produce IL-15, which is required for the persistence of
Langerin-DTR mice
Mice that express diphtheria
toxin receptor (DTR) under the
control of the Langerin gene
promoter. Treatment of these
mice with diphtheria toxin
leads to the deletion of all
Langerin-expressing cells.
Alopecia areata
A patchy hair loss mainly
occurring in the scalp. it is
believed to be one of the
autoimmune diseases.
Box 1 | Stratum corneum
The stratum corneum is the outermost layer of the
epidermis, and it has a central role in maintaining the
barrier function of the skin. Its thickness ranges from 10
to 30 μm and varies substantially between body sites.
In the stratum corneum, keratinocytes become flattened
and denucleated and are called corneocytes; their
membranes are replaced by a unique barrier structure
known as the cornified envelope8,88. Intercellular spaces
are filled with lipids. These structures are often described
as the ‘bricks’ (corneocytes) and ‘mortar’ (intercellular
lipids), which together provide a highly hydrophobic
barrier against the environment. Importantly, the stratum
corneum is not formed at skin appendages, which thus
provides an outside-to-inside route for small-molecule
drugs and chemicals and an inside-to-outside route for
transepidermal water loss.
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 21
CD8+ TRM cells in the epidermis. By contrast, IL-7, which
is required for both CD4+ and CD8+ TRM cells, is pre-
dominantly produced by infundibulum keratinocytes.
Another study has shown that CD11b+ cells (most likely
macrophages and/or DCs) and CD8+ T cells around the
hair follicles produce CCL5, which is proposed to recruit
memory CD4+ T cells to form clusters29. During second-
ary immune responses, most IFNγ-producing T cells
localize around the hair follicles, suggesting that these
clusters may protect against pathogens by efficiently acti-
vating effector T cells. Because hair follicles facilitate the
trafficking of DCs23 as well as T cells28, they may serve
as an essential site for antigen presentation in the skin
under certain conditions.
As for CD4+ regulatory T (Treg) cells, they are pre-
dominantly distributed near the hair bulge area where
hair follicular stem cells reside. Intriguingly, the deple-
tion of skin-resident Treg cells results in the perturbation
of hair cycles30. These findings suggest that Treg cells
can control hair cycles by interacting with hair follicu-
lar stem cells and that they are essential for preserving
immune privilege in the follicles.
Immune modulation by sebaceous glands. Sebaceous
glands are another unique structure that accompanies
hair follicles (Fig. 1c). These glands secrete lipids as part of
the skin barrier function and produce antimicrobial pep-
tides and cytokines and chemokines that modulate skin
immunity. In pathological conditions, such as acne, IL-17-
producing T helper 17 (TH17) cells accumulate around
sebaceous glands31. In vitro analysis demonstrated that
Propionibacterium acnes induced sebocytes to produce
IL-6, TGFβ and IL-1β, which activateddermal DCs to
preferentially prime TH17 cells31. In another pathologi-
cal context — eosinophilic pustular folliculitis — sebaceous
glands were surrounded by a massive number of eosin-
ophils32. In this condition, prostaglandin D2 (PGD2)
expression is upregulated in hair follicles, which acts on
sebocytes to produce the eosinophil chemoattractant
CCL26. It is evident that there are many potential ways in
which sebocytes can modulate skin immune responses.
Influence of the skin microbiota. Numerous microor-
ganisms cover skin surfaces and reside in skin append-
ages (Fig. 1b,c). These microorganisms have a profound
effect on immune processes of the skin11. The metabo-
lites and/or structural components of microorganisms
may influence both innate and adaptive immunity. For
example, Staphylococcus epidermidis, which constitutes
a major population of commensal bacteria found on the
skin, produces lipoteichoic acid that acts selectively on
keratinocytes through Toll-like receptor 3 (TLR3) to
inhibit inflammatory cytokine release33. S. epidermidis
is also directly captured by dermal APCs, probably at
skin appendages, and antigens from the bacteria are pre-
sented on MHC class I molecules by APCs in the drain-
ing lymph nodes34. As a result, S. epidermidis-specific
CD8+ T cells that express IL-17A or IFNγ (and have been
referred to as Tc17 or Tc1 cells, respectively) are recruited
to the skin in the absence of overt inflammation34. It is
of note that S. epidermidis-specific CD8+ T cells have a
unique gene expression profile in that they express genes
associated with immunoregulation, angiogenesis, tissue
remodelling and ECM production. Consistent with
this, S. epidermidis-specific CD8+ T cells promote rapid
keratinocyte proliferation and accelerate wound healing.
As corneocytes are dead cells and express no active
biological sensors for microorganisms, microorgan-
isms in the skin appendages are likely to have a greater
influence on cutaneous immunity than microorganisms
residing on the stratum corneum. Indeed, the compo-
sition of the microbiota varies substantially between
the surface areas and the deeper areas of the skin35. For the
same reason, pathogenic microorganisms target skin
appendages unless barrier-disrupted injury exists. Thus,
it should be emphasized that the method used to sample
skin microbiota, such as swab, tape stripping and skin
biopsy, is important to consider when interpreting data
from skin microbiota studies35.
The expansion of pathogenic bacteria and fungi
in skin appendages easily stimulates neighbouring
keratinocytes to produce inflammatory cytokines and
chemokines that can recruit neutrophils and monocytes,
leading to the development of folliculitis and hidrade-
nitis. By contrast, pathogenic viruses that invade skin
appendages sometimes establish latent infection and
form their ‘nest’ in these sites (for example, human pap-
illoma viruses), probably owing to the repellent nature
of these appendages against T cells36. How the cutaneous
immune system discriminates pathogenic microorgan-
isms from commensal microorganisms has yet to be
fully elucidated, and characterizing the critical molecules
required for this recognition would be of clinical interest.
Immune responses in the dermis
Immune modulation by dermal blood vessels. Dermal
blood vessels can be divided into four different parts
with distinct functions: arteries, capillaries, postcapil-
lary venules and collecting venules (Fig. 2). Among these
vessels, postcapillary venules have a unique property that
is particularly important during inflammation. Adjacent
blood endothelial cells are sealed with tight junctions
and adherence junctions. These barrier structures limit
the passage of plasma proteins larger than 70 kDa, sug-
gesting that extravasation of albumin and immunoglob-
ulins (which have molecular masses of approximately
70 kDa and 150 kDa, respectively) is limited under
homeostatic conditions37 (Fig. 2). Importantly, this vascu-
lar permeability is variable only at postcapillary venules.
During inflammation, intercellular tight and/or adher-
ence junctions are diminished, and immunoglobulins,
albumin and water shift into the dermal interstitium and
lead to tissue swelling. This phenomenon demonstrates
that postcapillary venules are specific portal sites that
allow key mediators of humoral immunity to access the
skin under inflammatory conditions (Fig. 2).
In postcapillary venules, endothelial cells are sur-
rounded by the basement membrane and pericytes,
and macrophages and mast cells are located nearby.
Recent studies using a mouse model of Staphylococcus
aureus infection have demonstrated that these cellular
and matrix components act as integrated functional
units, termed the ‘perivascular extravasation units’38
(Fig. 2). In these units, perivascular macrophages are
Eosinophilic pustular
folliculitis
A recurrent folliculitis that is
often formed in the face. in this
condition, many eosinophils
are pathologically accumulated
around hair follicles.
www.nature.com/nri
R e v i e w s
22 | JANuARY 2019 | volume 19
critically important for neutrophil extravasation.
Perivascular macrophages express high levels of the
neutrophil-attracting chemokines CXC-chemokine
ligand 1 (CXCL1) and CXCL2, and neutrophils extra-
vasate in the vicinity of perivascular macrophages. These
macrophages are depleted when they are exposed to the
S. aureus-derived exotoxin α-haemolysin, and in
the absence of perivascular macrophages, neutrophil
recruitment to the skin is markedly suppressed38.
Postcapillary venules also play a crucial role dur-
ing T cell recruitment to and activation in the skin20
(Fig. 2). During cutaneous inflammation, T cells, DCs
and perivascular macrophages form clusters, which have
been termed iSALT, around postcapillary venules. The
iSALT provides a site of antigen presentation in the skin,
which is critical for the elicitation of adaptive immunity.
The induction and function of iSALT will be discussed
in detail in a later section.
Neuro-immune interactions in the skin. The skin func-
tions as both a barrier and a sensory interface. It is inner-
vated by abundant sensory nerves and also by a smaller
number of autonomic nerve fibres. Neurons form
mesh-like bundles in the dermis, and a large number of
the nerve ends reach the epidermis (Fig. 3a). Whole-mount
immune staining analysis revealed that a large fraction of
dermal DCs are in close contact with neurons, suggest-
ing there is neural regulation of DC functions19. Until
recently, it was unclear whether peripheral neurons reg-
ulate cutaneous immune responses. However, studies
involving the genetic and pharmacological ablation of
transient receptor potential subfamily V member 1 (TRPV1)-
expressing sensory neurons have demonstrated that
neurons have key roles in regulating cutaneous immune
responses19,39.
For example, skin inflammation induced by the TLR7
ligand imiquimod is significantly suppressed with the
pharmacological ablation of TRPV1+ sensory nerves19.
Topical application of imiquimod causes a skin inflam-
mation that is similar to human psoriasis, particularly in
terms of the dependence of the response on the IL-17–
IL-23 axis40. Following nerve deletion, dermal DCs fail
to produce IL-23 in imiquimod-exposed skin and, con-
sequently, the local production of IL-17 by dermal γδ
T cells is significantly suppressed40. In a Candida albicans
infection model, TRPV1+ sensory nociceptors directly
sense fungal agents and release calcitonin gene-related
peptide (CGRP); this peptide upregulates the production
of IL-23 by CD301b+ DCs, which in turn drives IL-17A
production by dermal γδ T cells18 (Fig. 3a).
In contrast to these pro-inflammatory roles for cuta-
neous neurons, immunoregulatory roles for neurons
have been reported in the squaric acid dibutylester
(SADBE)-induced model of contact hypersensitivity
(CHS)41 (Box 2). Upon SADBEapplication to the skin,
TRPV1-expressing neurons directly recognize this hapten
and suppress the pro-inflammatory function of dermal
macrophages. By contrast, when TRPV1-deficient mice
are treated with SADBE, dermal macrophages abundantly
produce pro-inflammatory cytokines, such as TNF, IL-1β
and IL-6, and this markedly exacerbates skin inflamma-
tion (Fig. 3a). These findings suggest that neurons are
important immune regulators that can either promote or
suppress skin inflammation depending on the context.
Immunity in subcutaneous adipose tissue
Below the dermis, subcutaneous adipose tissue is distrib-
uted throughout the body. It acts as padding, an energy
reserve and insulation for thermoregulation42. Adipose
tissue contains a variety of immune cells, including
T cells, B cells and macrophages. In the obese condi-
tion, however, the number of macrophages is increased
by fourfold compared with the lean condition43, and
the production of a variety of inflammatory media-
tors, termed adipokines, is increased. These mediators
include adiponectin, leptin, IL-6 and TNF. Subcutaneous
adipose tissue is also essential for host defence against
Immunoglobulin Low-molecular-weight
proteins (70 kDa)
Stable state
b
Inflammatory state
Water
Water
Arteriole Capillaries
Postcapillary
venules
Collecting
venules
a
T cell
DC
Immunoglobulins
Perivascular
macrophage
Neutrophils
A unit for
neutrophil
extravasation
Hyper-permeability
for humoral immunity
iSALT for T cell
activation
Fig. 2 | A specific contribution of postcapillary venules in cutaneous immunity. a |
Skin blood vessels can be divided into four distinct types: arterioles, capillaries,
postcapillary venules and collecting venules. Among them, postcapillary venules display
unique properties during inflammation. Inducible skin-associated lymphoid tissues
(iSALT) are induced for the activation of T cells that have infiltrated the skin. Perivascular
extravasation units are essential for neutrophil recruitment. Perivascular macrophages
are critically important for neutrophil extravasation. Hyper-permeabilization occurs in
postcapillary venules, and this enables the recruitment of immunoglobulins from the
blood. b | A schematic of hyper-permeabilization of postcapillary venules is shown.
In the steady state, only plasma components with a molecular mass of 70 kDa), such as
albumin and immunoglobulins, freely pass through the hyper-permeabilized blood vessel
walls. DC, dendritic cell.
Transient receptor potential
subfamily V member 1
(TRPV1). Also known as
capsaicin receptor; TRPV1 is a
cation channel member
selectively expressed on
peripheral sensory neurons
that serves as a molecular
sensor (nociceptor) for noxious
stimuli.
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 23
S. aureus infection via the production of cathelicidin,
which kills bacteria44. This suggests diverse roles for
adipocytes in cutaneous immunity.
Recent in vivo imaging analysis revealed that adi-
pocytes form clusters around dermal blood vessels,
which are termed perivascular adipose tissues (PATs)45
(Fig. 3b). The functions of PATs in the skin remain unre-
solved, but they may be involved in vascular regula-
tion or could provide a harbour for specific subsets of
immune cells, analogous to the role played by PATs in
other organs46,47.
Skin anatomy and induction of adaptive immunity
Before eliciting adaptive immune responses in the
skin, external antigens breach the skin barrier and are
captured by cutaneous DCs. Anatomically, the barrier
function of the skin is dependent on two key structures,
the stratum corneum and the tight junction8,9 (Fig. 1).
As described above, skin appendages lack the stratum
corneum, and the tight junction is thus the primary bar-
rier in these tissues. As skin appendages act as ‘shunt
routes’ into the body for drugs and chemicals, the
tight junction is considered the determinant of skin
barrier functions.
Most contact dermatitis is caused by haptens.
Haptens are small molecules that acquire antigenicity
only when binding to self-proteins in the skin (lead-
ing to the formation of hapten–self complexes). The
tight junction limits the passage of molecules larger
than 500 Da, and the molecular weight of haptens is
less than this. As such, haptens can easily pass through
the tight junction and penetrate the skin under phys-
iological conditions (Fig. 4). By contrast, macromole-
cules, such as proteins, are too large to penetrate tight
junctions and cannot diffuse into the underlying skin
tissues. However, during inflammation, activated
LCs elongate their dendrites outward beyond the
tight junction and uptake external antigens48. This is
another shunt route into the skin, mediated by LCs,
that plays a crucial role in percutaneous sensitization
by macromolecular proteins.
Antigen presentation by cutaneous APCs. The antigens
that breach the stratum corneum and tight junctions are
then captured by the second line of the immunologi-
cal barrier, cutaneous DCs. DCs are a diverse family of
cells that play a crucial role in linking our innate and
Dermal
DC
Neuron Dermal γδ T cells Blood
vessel
Perivascular
adipose tissue
LC
Tight
junction
a b
Macrophages
HaptensFungi and/or bacteria
IL-17ACGRP
IL-23
Stratum
corneum
Stratum
granulosum
Stratum
spinosum
Stratum
basale
Fig. 3 | Neuro-immune interactions and perivascular adipose tissue in the skin. a | A schematic of neuro-immune
interactions in the skin. Components of fungi and bacteria as well as haptens can be directly sensed by transient receptor
potential subfamily V member 1 (TRPV1)+ nociceptors. The activated TRPV1+ nerves produce calcitonin gene-related
peptide (CGRP) to upregulate the production of IL-23 by CD301b+ dendritic cells (DCs), which in turn drives IL-17A
production by dermal γδ T cells. TRPV1+ nerves also recognize haptens and modulate skin inflammation by regulating the
function of dermal macrophages. b | Perivascular adipose tissue in the skin. BODIPY (green) and fluorescent-conjugated
dextran (red) were simultaneously injected to visualize lipophilic cells and blood vessels, respectively. Second-harmonic
generation represents dermal collagen fibres (blue). LC, Langerhans cell.
Box 2 | Contact hypersensitivity responses
The contact hypersensitivity (CHS) response provides a murine model of allergic contact
dermatitis. It is induced by small compounds called haptens. Haptens are conjugated to
self-proteins and are captured by cutaneous dendritic cells (DCs). DCs carry the hapten–
self complex to the draining lymph nodes and mediate antigen presentation to prime
antigen-specific effector T cells, namely, cytotoxic CD8+ T cells and T helper 1 cells (known
as the sensitization phase)73,89,90. With subsequent exposure to the same haptens, activation
of the effector T cells is induced by antigen-presenting cells in the skin, leading to
spongiotic dermatitis (known as the elicitation phase)68.
www.nature.com/nri
R e v i e w s
24 | JANuARY 2019 | volume 19
adaptive immune system49. Generally, four cell types
were classified in the DC family in the skin: epidermal
LCs, conventional DCs (cDCs), plasmacytoid DCs and
monocyte-derived DCs. cDCs can be further subdi-
vided into the cDC1 and cDC2 subsets on the basis of
subset-specific gene expression profiles, their depend-
ence on different transcription factors and unique subset
functions50,51.
During inflammation and neoplasm formation in the
skin (Box 3), effector T cells are recruited and retained
in the skin with limited antigen dependency52. The
skin-infiltrating effector T cells actively migrate in order
to explore antigens presented by cutaneous APCs53.
Once they encounter their cognate antigens, effector
T cells initiate stable contact with APCs and are activatedto produce inflammatory cytokines52,54,55. The motility
and the activation status of effector T cells are inversely
correlated and finely regulated52.
In the elicitation of CHS, dermal DCs are the most
important APCs in the skin and form clusters for effi-
cient antigen presentation to T cells20 (Fig. 5). In addition
to dermal DCs, several other cell populations, such as
mast cells and LCs, are proposed as possible APCs in
the skin. Mast cells participate in antigen presentation
in the skin in CHS by acquiring MHC class II molecules
from DCs56. Basophils may also act as APCs in the skin
because they can also acquire MHC class II molecules by
trogocytosis and present antigens to induce TH2 cells in
the lymph nodes57. Although the role of LCs as APCs
in the elicitation of CHS remains unclear, LCs may have
potential APC functions in a graft versus host disease
model, where the depletion of LCs in the effector phase
causes impaired CD8+ T cell activation in the skin58.
In addition, a recent report using mice with transgenic
expression of a fragment of the human gene encoding
CD1a on LCs demonstrated that LCs can present lipid
antigens to effector T cells in the skin and amplify the
inflammatory response in allergic contact dermatitis
and psoriasis59. These reports suggest the diverse poten-
tial of LCs as APCs in the skin. Furthermore, the loss
of MHC class I on radioresistant cells led to impaired
granzyme B production in CD8+ T cells in the elicitation
phase of CHS60, suggesting the possible involvement of
endothelial cells61 and keratinocytes62,63 as APCs in the
skin, although in vivo evidence for this remains lack-
ing. As co-stimulatory molecules are not required for
activation of effector T cells64, various cells may carry
out APC functions in the skin in a context-dependent
manner (TABLe 1).
iSALT formation around postcapillary venules.
Recently, a leukocyte-clustering structure named
iSALT was proposed to serve as a site for efficient anti-
gen presentation in the skin20 (Fig. 5). Around 1980, the
antigen-presenting capability of the skin was identified
and people offered the term skin-associated lymphoid
tissue (SALT) to describe this function65–67. Although
SALT is a conceptual term, iSALT is an actual structure
that transiently appears around postcapillary venules in
response to various immunogenic stimuli, including hap-
tens and infection68,69. The iSALT is composed of various
types of leukocytes, including perivascular macrophages,
dermal DCs and T cells20. After hapten application to the
skin, dermal DCs exhibit cluster formation around post-
capillary venules within hours. IL-1α produced by kerat-
inocytes in response to external insults activates M2-like
macrophages around postcapillary venules, which then
produce CXCL2 and recruit dermal DCs to the cluster.
Leukotriene B4 (LTB4), a lipid mediator, also mediates
the cluster formation by promoting DC migration70.
Subsequently, effector T cells accumulate in the cluster
and are presented antigens by dermal DCs, leading to
their proliferation and activation. In the cluster, both
major dermal DC subsets71, namely, CD11b+ dermal
DCs and CD103+ dermal DCs, are detected72. It is cur-
rently unclear, however, which dermal DC subsets medi-
ate antigen presentation in the cluster60. Each DC subset
in the cluster may work in a compensatory manner
D
er
m
is
Hapten (FITC) Protein antigen
FITC–OVA Claudin 1 DAPI
Ep
id
er
m
is
D
erm
is
Epiderm
is
Tight
junction
Fig. 4 | Penetration of hapten and proteins into the skin. A hapten (fluorescein
isothiocyanate (FITC); molecular mass = 389; left) or FITC-conjugated ovalbumin (FITC–
OVA ; molecular mass = 66 kDa; right) were painted onto the ear skin. After 24 hours, the
ears were harvested and sliced. Nuclei (blue) and claudin 1 (red) were visualized. FITC
distributed into the dermis (left), probably mainly through the hair follicles and cracks in
the stratum corneum, while FITC–OVA remained outside the tight junctions (right). DAPI,
4′,6-diamidino-2-phenylindole.
Box 3 | Antigen presentation in skin neoplasms
Antigen presentation by antigen-presenting cells and the subsequent activation of
cytotoxic CD8+ T cells in the tumour site are essential for antitumour immunity.
The blockade of programmed cell death 1 (PD1) signalling is believed to exert antitumour
effects by inducing CD8+ T cell activation in the tumour52,91. In cancer, tumour-associated
macrophages, CD11b+ dermal dendritic cells (DCs) and CD103+ dermal DCs can interact
with CD8+ T cells and restrict the motility of the cells92,93. In melanoma, however, it has
been reported that only CD103+ DCs can effectively activate the CD8+ T cells in the
tumour94,95. As CD103+ dermal DCs constitute only approximately 1% of the total tumour
DCs, the trapping of CD8+ T cells by CD11b+ dermal DCs and tumour-associated
macrophages would limit the chance for CD8+ T cells to meet CD103+ dermal DCs and be
activated, which may lead to inefficient antitumour immune responses. Because
tumour-associated macrophages express PD1, which inhibits phagocytosis and the
tumour immunity of tumour-associated macrophages96, PD1 inhibitors may exert their
antitumour effects by affecting tumour-associated macrophages.
Trogocytosis
Lymphocytes that conjugate to
antigen-presenting cells
sometimes ‘rob’ the surface
molecules and express them
on their own surfaces. ‘Trogo’
means ‘gnaw’ in greek.
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 25
Sensitization Elicitation
CD103+
dermal DC
IFNγ
CD11b+
dermal DC
Skin-draining
lymph node
12–24 hours
Dermal
DC Effector
T cell
a
b
• Antigen presentation
• Effector T cell
differentiation
(Tc1 and/or T
H
1 cell)
Stratum
corneum
Stratum
granulosum
Stratum
spinosum
Stratum
basale
LC
Hapten
Epidermis
Dermis
Effector
T cell
CXCL2LTB4 Perivascular
macrophage
Postcapillary
venule
IL-1α
Migration
• Antigen presentation
• Effector T cell activation
Tight
junction
IFNγ
Oedema and�
vesicle formation
Dermal
DC
• iSALT formation
• Effector T cell activation
Fig. 5 | A schematic view of the sensitization and elicitation phases
of contact hypersensitivity. a | In the sensitization phase of contact
hypersensitivity , haptens pass through the skin barrier (stratum corneum and
tight junction) and are captured by cutaneous dendritic cells (DCs), including
Langerhans cells (LCs) and dermal DCs. DCs, especially CD103+ dermal DCs,
present antigens to naive T cells and induce the differentiation of effector
T cells — most notably IFNγ-producing cytotoxic T cells (which have been
referred to as Tc1 cells) and T helper 1 (TH1) cells — in the skin-draining lymph
nodes. In the elicitation phase, haptens captured by dermal DCs are
presented to effector T cells in the skin. The activated effector T cells produce
IFNγ and elicit skin inflammation. b | Haptens induce IL-1α production from
keratinocytes, which activates M2-type macrophages that are located
around postcapillary venules. The activated macrophages then produce
CXC-chemokine ligand 2 (CXCL2), which promotes the accumulation of
dermal DCs. Leukotriene B4 (LTB4) also plays an important role in driving DC
accumulation by increasing DC motility. Effector T cells are activated within
the DC clusters (present in inducible skin-associated lymphoid tissue (iSALT))
and produce cytokines.
www.nature.com/nri
R e v i e w s
26 | JANuARY 2019 | volume 19
like DCs in the sensitization phase73. Nevertheless,
the blockade of CXCL2 and IL-1 receptor signal-
ling impairs the formation of leukocyte clusters
and effector T cell activation, indicating that iSALT
is an essential structure for antigen presentation
in mouse CHS responses. An interesting remaining
question is the role of iSALT in inflammatory skin dis-
eases other than allergic contact dermatitis. In fact, in
psoriasis, an iSALT-like structure has been reported
in the skinlesions in humans74. Therefore, iSALT may
serve as an important structure that supports the devel-
opment of immune responses in other inflammatory
skin diseases.
iSALT and other tertiary lymphoid structures. Under
some pathological circumstances such as infection,
chronic inflammation and cancers, lymph node-like
structures called tertiary lymphoid structures (TLSs)
have been detected in various non-lymphoid tissues75.
In the lung, for example, leukocyte clusters called induc-
ible bronchial-associated lymphoid tissue (iBALT) are
formed after pulmonary inflammation or infection76.
iBALT can support the priming of naive B cells and
T cells and also maintain memory B cell and T cell popu-
lations. Thus, iBALTs are considered essential structures
that support rapid and efficient immune responses in the
lung against some pathogens.
TLSs seem to play important roles in host protec-
tion against external antigens and also against internal
antigens in the development of pathogenic conditions
such as autoimmune diseases and cancers75,77,78. The
TLSs involved in skin immune responses have not yet
been clearly defined, but in order to be considered bona
fide TLSs, they should show several of the following
characteristics: the existence of distinct T cell and B cell
compartments, the presence of a follicular reticular
cell (FRC) network, the expression of peripheral node
addressin (PNAd)+, the presence of high endothelial
venules (HEVs) and a lymphatic vasculature, and evi-
dence of B cell class switching77. Most TLSs are not
genetically programmed and do not develop postnatally.
Instead, cytokines (lymphotoxin and TNF), lymphoid
chemokines (CCL19, CCL21 and CXCL13) and recep-
tor activator of nuclear factor-κB ligand (RANKL; also
known as TNFSF11) play crucial roles in the develop-
ment of TLSs. The characteristics of each leukocyte
cluster are summarized in TABLe 2.
On the basis of these structural criteria, iSALT may
not be classified as a TLS because of the absence of
B cells, naive T cells, HEVs and the FRC network and
the involvement of lymphoid chemokines have not
yet been described in iSALT. However, from a func-
tional point of view, iSALT possesses the key feature
of TLS in that it is an efficient site for effector T cell
activation; some researchers thus use the term TLS
for iSALT, focusing on this point78,79. Leukocyte clus-
ters are also reported in the genital mucosa after HSV
infection and have been named ‘memory lymphocyte
clusters’80. They are mainly composed of CD11c+ MHC
class II+ cells and CD4+ memory T cells and do not con-
tain PNAd+ HEVs or lymphatic vessels. CD4+ memory
T cells are recruited and maintained in the cluster
through CCL5 produced by macrophages. In the mem-
ory lymphocyte clusters, CD4+ T cells rarely recirculate
into the blood and are critical for preventing the local
reinfection of HSV.
iSALT formation in human skin. It remains unclear
whether iSALT is formed in human skin and supports
T cell activation in an analogous manner to that seen
in mice. Although iSALT-like structures (perivascular
leukocyte infiltrations) are frequently observed by histo-
logical examination in many inflammatory skin diseases,
these may simply reflect the extravasation process of leu-
kocytes, and it is not clear whether activation of effector
T cells actually occurs in these structures. However, in
some inflammatory skin diseases, this structure may
serve as an iSALT by presenting antigens to effector
T cells. In allergic contact dermatitis, DC–T cell clusters
are found in the dermis and are accompanied by vesi-
cle formation, a marker of inflammatory cytokine pro-
duction in the epidermis above the cluster that suggest
Table 1 | Putative APCs in the skin under different pathological conditions
Disease model Putative antigen-presenting cells in the skin
Contact hypersensitivity Dermal DCs20, mast cells56, blood endothelial cells61,
radioresistant cells60 or LCs73,97
Graft versus host diseases LCs58 or keratinocytes63
Psoriasis Dermal DCs98 or LCs59
DC, dendritic cell; LC, Langerhans cell.
Table 2 | Characteristics and comparison of leukocyte clusters
Characteristic Type of leukocyte cluster
iSALT Memory
lymphocyte clusters
iBALT
Presence of HEVs, lymphatic vessels and FRC No No Yes
Mediators involved in formation CXCL2, IL-1α
and LTB4
CCL5 and CXCL9 Lymphotoxin, IL-17 , TNF,
CCL19, CCL20 and CXCL13
Supports priming of naive T cells and B cells No No Yes
Supports reactivation of effector T cells Yes Yes Yes
Existence in human Unknown Unknown Yes
CCL , CC-chemokine ligand; CXCL , CXC-chemokine ligand; FRC, follicular reticular network; HEV, high endothelial venule;
iBALT, inducible bronchial-associated lymphoid tissue; iSALT, inducible skin-associated lymphoid tissue; LTB4, leukotriene B4;
TNF, tumour necrosis factor.
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 27
that the activation of T cells occurs at the cluster20. In
psoriasis, the existence of HEVs has been reported81,
and clusters of DC-LAMP (also known as LAMP3)+ DCs and
T cells have been detected in the dermis74 with abundant
expression of CCL19 and CCL20 (ReFs82,83). This cluster
disappears after treatment with TNF inhibitors74, sug-
gesting the involvement of TNF in the maintenance of
the cluster. iSALT-like structures with CXCL13+ cells
have been reported in the skin lesions of patients with
secondary syphilis infections69. In melanoma, clus-
ters with TLS features, such as the existence of HEVs,
T cells, B cells and mature DCs, have been detected in
the extratumoural area and are associated with tumour
regression or favourable overall survival in patients84,85.
Lymphoid follicles are created in the skin lesions of
cutaneous lupus erythematosus86 or Kimura disease87.
Thus, although the functional importance of the leu-
kocyte clusters or lymphoid follicles in the skin remains
unclear, these structures may play important roles in the
promotion or regulation of disease development (TABLe 3).
Conclusions and perspectives
The skin is a barrier organ that separates the body
from the external environment. The skin consists of
three main parts: the epidermis, dermis and subcuta-
neous tissues. Each constituent has unique cells and
structures, including immune cells and non-immune
cells, which induce various immune responses to
external stimuli in a coordinated manner. Substantial
progress has been made in understanding the func-
tions of the different cell types in the skin and the
mechanisms that they use to communicate harmoni-
ously. In particular, the understanding of the roles of
non-immune cells, such as vascular cells and neurons,
has shed light on the complexity of skin immunity and
diseases. In addition, the identification of key loca-
tions and/or structures, such as hair follicles, perivas-
cular extravasation units and iSALT, has improved
the understanding of cutaneous immune responses
(Fig. 6). Moreover, it is now known that commensal
and pathogenic bacteria directly regulate the func-
tional properties of skin immune cells, which has pro-
vided new paradigms that highlight the importance of
host–microorganism interactions.
Despite such progress, we still lack a comprehen-
sive understanding of the skin in health and disease.
Table 3 | Leukocyte clusters in human diseases in skin or genital mucosa
Disease Characteristics of the clusters Refs
Contact dermatitis Clusters of CD3+ cells and CD11c+ cells below
epidermal vesicles
20
Psoriasis Existence of DC-L AMP+ DCs and T cells with
CCL19 and CCL20 expression in the clusters
83
Secondary syphilis Existence of CXCL13+ fibroblast-like cells 69
HSV infection (skin) Variable numbers of CD30+ or CD56+ cells 99
HSV infection (genital
mucosa)
Existence of CCR5+CD4+ T cells contiguous to
CD123 or DC-SIGN+ DCs
100
Chlamydia trachomatis
infection (genital mucosa)
Germinal centre formation 101
Kimura disease Germinalcentre formation 87
Cutaneous lupus
erythematosus
Existence of plasmacytoid DCs 86,102
CCL , CC-chemokine ligand; CCR5, CC-chemokine receptor 5; CXCL13, CXC-chemokine
ligand 13; DC, dendritic cell; HSV, herpes simplex virus.
Epidermis
Dermis
Hair follicles
• Recruitment of immune cells
(LCs and T cells)
• Memory T cell responses
(T
RM
 cells)
• Immune privilege
(T
reg
 cells)
Postcapillary venules
• Formation of iSALT (transient
effector T cell activation)
• Formation of perivascular
extravasation units (neutrophil
extravasation)
Fig. 6 | Newly identified key locations and structures in skin immunity. Hair follicles serve as locations for immune cell
recruitment and create structures for memory T cell response as well as immune privilege. Inducible skin-associated
lymphoid tissue (iSALT) and perivascular extravasation units are formed around postcapillary venules, which induce the
transient activation of effector T cells and neutrophil activation, respectively. LC, Langerhans cell; Treg cell, regulatory T cell;
TRM cell, resident memory T cell.
Kimura disease
A chronic inflammatory
disorder characterized by a
painless lymphadenopathy or
masses on head and neck
regions.
www.nature.com/nri
R e v i e w s
28 | JANuARY 2019 | volume 19
We do not exactly understand which immune cells and/or
non-immune cells interact with each other and at which
immune response time points these interactions occur
(for example, during the acute, chronic and resolution
stages of inflammation); we also do not know the pre-
cise anatomical locations of these interactions in the
skin. Considering the fundamental differences between
mouse and human skin is another important challenge.
Evaluation of these points may lead to a breakthrough in
the understanding of the immunological mechanisms of
various cutaneous immune responses and healthy skin
homeostasis.
Published online 14 November 2018
1. Hoeffel, G. et al. Adult Langerhans cells derive
predominantly from embryonic fetal liver monocytes
with a minor contribution of yolk sac–derived
macrophages. J. Exp. Med. 209, 1167–1181 (2012).
2. Ginhoux, F. et al. Langerhans cells arise from
monocytes in vivo. Nat. Immunol. 7, 265–273 (2006).
3. Gebhardt, T. et al. Memory T cells in nonlymphoid
tissue that provide enhanced local immunity during
infection with herpes simplex virus. Nat. Immunol. 10,
524–530 (2009).
4. Masopust, D. et al. Dynamic T cell migration program
provides resident memory within intestinal epithelium.
J. Exp. Med. 207, 553–564 (2010).
5. Wakim, L. M., Woodward-Davis, A. & Bevan, M. J.
Memory T cells persisting within the brain after
local infection show functional adaptations to their
tissue of residence. Proc. Natl Acad. Sci. USA 107,
17872–17879 (2010).
6. Mackay, L. K. et al. Long-lived epithelial immunity by
tissue-resident memory T (TRM) cells in the absence
of persisting local antigen presentation. Proc. Natl
Acad. Sci. USA 109, 7037–7042 (2012).
7. Wu, T. et al. Lung-resident memory CD8 T cells (TRM)
are indispensable for optimal cross-protection against
pulmonary virus infection. J. Leukoc. Biol. 95,
215–224 (2014).
8. Matsui, T. & Amagai, M. Dissecting the formation,
structure and barrier function of the stratum corneum.
Int. Immunol. 27, 269–280 (2015).
9. Egawa, G. & Kabashima, K. Multifactorial skin barrier
deficiency and atopic dermatitis: essential topics to
prevent the atopic march. J. Allergy Clin. Immunol.
138, 350–358.e351 (2016).
10. Belkaid, Y. & Tamoutounour, S. The influence of skin
microorganisms on cutaneous immunity. Nat. Rev.
Immunol. 16, 353–366 (2016).
11. Byrd, A. L., Belkaid, Y. & Segre, J. A. The human
skin microbiome. Nat. Rev. Microbiol. 16, 143–155
(2018).
12. Tong, P. L. et al. The skin immune atlas: three-
dimensional analysis of cutaneous leukocyte subsets
by multiphoton microscopy. J. Invest. Dermatol. 135,
84–93 (2015).
13. Lämmermann, T. et al. Neutrophil swarms require
LTB4 and integrins at sites of cell death in vivo.
Nature 498, 371–375 (2013).
14. Jain, R., Tikoo, S., Egawa, G. & Weninger, W.
in Encyclopedia of Immunobiology Vol. 3 (ed. Ratcliffe,
M.) 493–504 (Elsevier, 2016).
15. Tamoutounour, S. et al. Origins and functional
specialization of macrophages and of conventional
and monocyte-derived dendritic cells in mouse skin.
Immunity 39, 925–938 (2013).
16. Wolf, K., Müller, R., Borgmann, S., Bröcker, E.-B.
& Friedl, P. Amoeboid shape change and contact
guidance: T-lymphocyte crawling through fibrillar
collagen is independent of matrix remodeling by
MMPs and other proteases. Blood 102, 3262–3269
(2003).
17. Tomura, M. et al. Activated regulatory T cells are the
major T cell type emigrating from the skin during a
cutaneous immune response in mice. J. Clin. Invest.
120, 883–893 (2010).
18. Kashem, S. W. et al. Nociceptive sensory fibers drive
interleukin-23 production from CD301b+ dermal
dendritic cells and drive protective cutaneous
immunity. Immunity 43, 515–526 (2015).
19. Riol-Blanco, L. et al. Nociceptive sensory neurons
drive interleukin-23-mediated psoriasiform skin
inflammation. Nature 510, 157–161 (2014).
20. Natsuaki, Y. et al. Perivascular leukocyte clusters are
essential for efficient activation of effector T cells in
the skin. Nat. Immunol. 15, 1064–1069 (2014).
This study shows that perivascular leukocyte
clusters including macrophages and DCs are
essential structures for effector T cell activation in
the skin and proposes the concept of iSALT.
21. Carmi-Levy, I., Homey, B. & Soumelis, V. A modular
view of cytokine networks in atopic dermatitis.
Clin. Rev. Allergy Immunol. 41, 245–253 (2011).
22. Nestle, F. O., Di Meglio, P., Qin, J.-Z. & Nickoloff, B. J.
Skin immune sentinels in health and disease. Nat. Rev.
Immunol. 9, 679–691 (2009).
23. Nagao, K. et al. Stress-induced production of
chemokines by hair follicles regulates the trafficking
of dendritic cells in skin. Nat. Immunol. 13, 744–752
(2012).
This is the first study to show the importance of
hair follicles for immune cell trafficking from
dermis to the epidermis.
24. Wollenberg, A., Kraft, S., Hanau, D. & Bieber, T.
Immunomorphological and ultrastructural
characterization of Langerhans cells and a novel,
inflammatory dendritic epidermal cell (IDEC)
population in lesional skin of atopic eczema. J. Invest.
Dermatol. 106, 446–453 (1996).
25. Liu, Z. et al. Visualization of T cell-regulated monocyte
clusters mediating keratinocyte death in acquired
cutaneous immunity. J. Invest. Dermatol. 138,
1328–1337 (2018).
This study demonstrates that monocytes cluster
around hair follicles after hapten painting to the
skin.
26. Paus, R. et al. The hair follicle and immune privilege.
J. Investig. Dermatol. Symp. Proc. 8, 188–194
(2003).
27. Kang, H. et al. Hair follicles from alopecia areata
patients exhibit alterations in immune privilege-
associated gene expression in advance of hair loss.
J. Invest. Dermatol. 130, 2677–2680 (2010).
28. Adachi, T. et al. Hair follicle–derived IL-7 and IL-15
mediate skin-resident memory T cell homeostasis and
lymphoma. Nat. Med. 21, 1272–1279 (2015).
29. Collins, N. et al. Skin CD4+ memory T cells exhibit
combined cluster-mediated retention and
equilibration with the circulation. Nat. Commun. 7,
11514 (2016).
This study shows that leukocyte clusters around
hair follicles may serve as the structures for
memory T cell activation after hapten application
or HSV infection.
30. Ali, N. et al. Regulatory T cells in skin facilitate
epithelial stem cell differentiation. Cell 169,
1119–1129.e1111 (2017).
31. Mattii, M. et al. Sebocytes contribute to skin
inflammation by promoting the differentiation of
T helper 17 cells. Br. J. Dermatol. 178, 722–730
(2018).
32. Nakahigashi, K. et al. PGD2 induces eotaxin-3 via
PPARγ from sebocytes: a possible pathogenesis of
eosinophilic pustular folliculitis. J. Allergy Clin. Immunol.
129, 536–543 (2012).33. Lai, Y. et al. Commensal bacteria regulate Toll-like
receptor 3–dependent inflammation after skin injury.
Nat. Med. 15, 1377–1382 (2009).
34. Linehan, J. L. et al. Non-classical immunity controls
microbiota impact on skin immunity and tissue repair.
Cell 172, 784–796 (2018).
35. Grice, E. A. et al. A diversity profile of the human skin
microbiota. Genome Res. 18, 1043–1050 (2008).
36. Egawa, N., Egawa, K., Griffin, H. & Doorbar, J. Human
papillomaviruses; epithelial tropisms, and the
development of neoplasia. Viruses 7, 3863–3890
(2015).
37. Egawa, G. et al. Intravital analysis of vascular
permeability in mice using two-photon microscopy.
Sci. Rep. 3, 1932 (2013).
38. Abtin, A. et al. Perivascular macrophages mediate
neutrophil recruitment during bacterial skin infection.
Nat. Immunol. 15, 45–53 (2014).
39. Szallasi, A., Cortright, D. N., Blum, C. A. & Eid, S. R.
The vanilloid receptor TRPV1: 10 years from channel
cloning to antagonist proof-of-concept. Nat. Rev. Drug
Discov. 6, 357–372 (2007).
40. van der Fits, L. et al. Imiquimod-induced psoriasis-like
skin inflammation in mice is mediated via the IL-23/
IL-17 axis. J. Immunol. 182, 5836–5845 (2009).
41. Feng, J. et al. Sensory TRP channels contribute
differentially to skin inflammation and persistent itch.
Nat. Commun. 8, 980 (2017).
42. Nakamizo, S. & Egawa, G. in Immunology of the Skin
(ed. Kabashima, K.) 227–238 (Springer, 2016).
43. Weisberg, S. P. et al. Obesity is associated with
macrophage accumulation in adipose tissue.
J. Clin. Invest. 112, 1796–1808 (2003).
44. Zhang, L.-J. et al. Dermal adipocytes protect against
invasive Staphylococcus aureus skin infection. Science
347, 67–71 (2015).
45. Egawa, G., Miyachi, Y. & Kabashima, K. Identification
of perivascular adipose tissue in the mouse skin
using two-photon microscopy. J. Dermatol. Sci. 70,
139–140 (2013).
46. Gao, Y. J., Lu, C., Su, L. Y., Sharma, A. & Lee, R.
Modulation of vascular function by perivascular
adipose tissue: the role of endothelium and hydrogen
peroxide. Br. J. Pharmacol. 151, 323–331 (2007).
47. Rajsheker, S. et al. Crosstalk between perivascular
adipose tissue and blood vessels. Curr. Opin.
Pharmacol. 10, 191–196 (2010).
48. Kubo, A., Nagao, K., Yokouchi, M., Sasaki, H.
& Amagai, M. External antigen uptake by Langerhans
cells with reorganization of epidermal tight junction
barriers. J. Exp. Med. 206, 2937–2946 (2009).
49. Dress, R. J., Wong, A. Y. & Ginhoux, F. Homeostatic
control of dendritic cell numbers and differentiation.
Immunol. Cell Biol. 96, 463–476 (2018).
50. Guilliams, M. et al. Unsupervised high-dimensional
analysis aligns dendritic cells across tissues and
species. Immunity 45, 669–684 (2016).
51. Schlitzer, A., McGovern, N. & Ginhoux, F. Dendritic
cells and monocyte derived cells: two complementary
and integrated functional systems. Semin. Cell Dev.
Biol. 41, 9–22 (2017).
52. Honda, T. et al. Tuning of antigen sensitivity by T cell
receptor-dependent negative feedback controls T cell
effector function in inflamed tissues. Immunity 40,
235–247 (2014).
This study shows a regulatory mechanism of
effector T cell motility and its activation status in
the skin.
53. Krummel, M. F., Bartumeus, F. & Gerard, A. T cell
migration, search strategies and mechanisms.
Nat. Rev. Immunol. 16, 193–201 (2016).
54. Egawa, G. et al. In vivo imaging of T cell motility in the
elicitation phase of contact hypersensitivity using
two-photon microscopy. J. Invest. Dermatol. 131,
977–979 (2011).
55. Matheu, M. P. et al. Imaging of effector memory
T cells during a delayed-type hypersensitivity reaction
and suppression by Kv1.3 channel block. Immunity
29, 602–614 (2008).
56. Dudeck, J. et al. Mast cells acquire MHCII from
dendritic cells during skin inflammation. J. Exp. Med.
214, 3791–3811 (2017).
57. Miyake, K. et al. Trogocytosis of peptide-MHC class II
complexes from dendritic cells confers antigen-
presenting ability on basophils. Proc. Natl Acad. Sci.
USA 114, 1111–1116 (2017).
58. Bennett, C. L. et al. Langerhans cells regulate
cutaneous injury by licensing CD8 effector cells
recruited to the skin. Blood 117, 7063–7069 (2011).
59. Kim, J. H. et al. CD1a on Langerhans cells controls
inflammatory skin disease. Nat. Immunol. 17,
1159–1166 (2016).
This study shows that LCs play crucial roles in the
induction of allergic reactions to urushiol as well as
in psoriasis via their expression of CD1a.
60. Ono, S., Honda, T. & Kabashima, K. Requirement of
MHC class I on radioresistant cells for granzyme B
expression from CD8+ T cells in murine contact
hypersensitivity. J. Dermatol. Sci. 90, 98–101
(2018).
61. Kish, D. D., Volokh, N., Baldwin, W. M. 3rd &
Fairchild, R. L. Hapten application to the skin induces
an inflammatory program directing hapten-primed
effector CD8 T cell interaction with hapten-presenting
endothelial cells. J. Immunol. 186, 2117–2126
(2011).
62. Gaspari, A. A. & Katz, S. I. Induction and functional
characterization of class II MHC (Ia) antigens on
NATuRe RevIeWS | IMMuNoLogy
R e v i e w s
 volume 19 | JANuARY 2019 | 29
murine keratinocytes. J. Immunol. 140, 2956–2963
(1988).
63. Kim, B. S. et al. Keratinocytes function as accessory
cells for presentation of endogenous antigen
expressed in the epidermis. J. Invest. Dermatol. 129,
2805–2817 (2009).
64. Krummel, M. F., Heath, W. R. & Allison, J. Differential
coupling of second signals for cytotoxicity and
proliferation in CD8+ T cell effectors: amplification
of the lytic potential by B7. J. Immunol. 163,
2999–3006 (1999).
65. Streilein, J. W. Skin-associated lymphoid tissues
(SALT): origins and functions. J. Invest. Dermatol. 80
(Suppl.), 12–16 (1983).
66. Streilein, J. W. Circuits and signals of the skin-
associated lymphoid tissues (SALT). J. Invest. Dermatol.
85, S10–S13 (1985).
67. Sontheimer, R. Perivascular dendritic macrophages
as immunobiological constituents of the human
dermal microvascular unit. J. Invest. Dermatol. 93,
S96–S101 (1989).
68. Honda, T. & Kabashima, K. Novel concept of iSALT
(inducible skin-associated lymphoid tissue) in the
elicitation of allergic contact dermatitis. Proc. Jpn. Acad.
92, 20–28 (2016).
69. Kogame, T. et al. Possible inducible skin-associated
lymphoid tissue (iSALT)-like structures with CXCL13+
fibroblast-like cells in secondary syphilis. Br. J. Dermatol.
177, 1737–1739 (2017).
70. Sawada, Y. et al. Resolvin E1 inhibits dendritic
cell migration in the skin and attenuates contact
hypersensitivity responses. J. Exp. Med. 212,
1921–1930 (2015).
71. Kashem, S. W., Haniffa, M. & Kaplan, D. H. Antigen-
presenting cells in the skin. Annu. Rev. Immunol. 35,
469–499 (2017).
72. Okada, T., Takahashi, S., Ishida, A. & Ishigame, H.
In vivo multiphoton imaging of immune cell dynamics.
Pflugers Arch. 468, 1793–1801 (2016).
This study shows the in vivo dynamics of skin DC
subsets in iSALT by multiphoton microscopy.
73. Honda, T. et al. Compensatory role of Langerhans cells
and langerin-positive dermal dendritic cells in the
sensitization phase of murine contact hypersensitivity.
J. Allergy Clin. Immunol. 125, 1154–1156.e1152
(2010).
74. Zaba, L. C. et al. Amelioration of epidermal hyperplasia
by TNF inhibition is associated with reduced Th17
responses. J. Exp. Med. 204, 3183–3194 (2007).
75. Pitzalis, C., Jones, G. W., Bombardieri, M. & Jones, S. A.
Ectopic lymphoid-like structures in infection, cancer
and autoimmunity. Nat. Rev. Immunol. 14, 447–462
(2014).
76. Randall, T. D. Bronchus-associated lymphoid tissue
(BALT) structure and function. Adv. Immunol. 107,
187–241 (2010).
77. Dieu-Nosjean, M. C., Goc, J., Giraldo, N. A.,
Sautes-Fridman, C. & Fridman, W. H. Tertiary
lymphoid structures in cancer and beyond. Trends
Immunol. 35, 571–580 (2014).
78. Colbeck, E. J., Ager, A., Gallimore, A. & Jones, G. W.
Tertiary lymphoid structures in cancer: drivers of
antitumor immunity, immunosuppression, orbystander sentinels in disease? Front. Immunol. 8,
1830 (2017).
79. Neyt, K., Perros, F., GeurtsvanKessel, C. H., Hammad, H.
& Lambrecht, B. N. Tertiary lymphoid organs in
infection and autoimmunity. Trends Immunol. 33,
297–305 (2012).
80. Iijima, N. & Iwasaki, A. A local macrophage chemokine
network sustains protective tissue-resident memory
CD4 T cells. Science 346, 93–98 (2014).
This study shows that leukocyte clusters in genital
mucosa after HSV infection are essential structures
where activation of memory T cells is induced for
the elimination of HSV.
81. Lowe, P. M. et al. The endothelium in psoriasis.
Br. J. Dermatol. 132, 497–505 (1995).
82. Mitsui, H. et al. Combined use of laser capture
microdissection and cDNA microarray analysis
identifies locally expressed disease-related genes
in focal regions of psoriasis vulgaris skin lesions.
J. Invest. Dermatol. 132, 1615–1626 (2012).
83. Kim, T. G. et al. Dermal clusters of mature dendritic
cells and T cells are associated with the CCL20/CCR6
chemokine system in chronic psoriasis. J. Invest.
Dermatol. 134, 1462–1465 (2014).
84. Martinet, L. et al. High endothelial venules (HEVs)
in human melanoma lesions: major gateways for
tumor-infiltrating lymphocytes. Oncoimmunology 1,
829–839 (2012).
85. Ladanyi, A. et al. Density of DC-LAMP+ mature
dendritic cells in combination with activated
T lymphocytes infiltrating primary cutaneous melanoma
is a strong independent prognostic factor. Cancer
Immunol. Immunother. 56, 1459–1469 (2007).
86. Arps, D. P. & Patel, R. M. Lupus profundus
(panniculitis): a potential mimic of subcutaneous
panniculitis-like T cell lymphoma. Arch. Pathol.
Lab. Med. 137, 1211–1215 (2013).
87. Kung, I. T., Gibson, J. B. & Bannatyne, P. M. Kimura’s
disease: a clinico-pathological study of 21 cases and
its distinction from angiolymphoid hyperplasia with
eosinophilia. Pathology 16, 39–44 (1984).
88. Murata, T. et al. Transient elevation of cytoplasmic
calcium ion concentration at a single cell level precedes
morphological changes of epidermal keratinocytes
during cornification. Sci. Rep. 8, 6610 (2018).
89. Honda, T., Egawa, G., Grabbe, S. & Kabashima, K.
Update of immune events in the murine contact
hypersensitivity model: toward the understanding of
allergic contact dermatitis. J. Invest. Dermatol. 133,
303–315 (2013).
90. Kaplan, D. H., Igyártó, B. Z. & Gaspari, A. A.
Early immune events in the induction of allergic contact
dermatitis. Nat. Rev. Immunol. 12, 114–124 (2012).
91. Topalian, S. L. et al. Safety, activity, and immune
correlates of anti-PD-1 antibody in cancer. N. Engl.
J. Med. 366, 2443–2454 (2012).
92. Boissonnas, A. et al. CD8+ tumor-infiltrating T cells are
trapped in the tumor-dendritic cell network. Neoplasia
15, 85–94 (2013).
93. Engelhardt, J. J. et al. Marginating dendritic cells of
the tumor microenvironment cross-present tumor
antigens and stably engage tumor-specific T cells.
Cancer Cell 21, 402–417 (2012).
94. Broz, M. L. et al. Dissecting the tumor myeloid
compartment reveals rare activating antigen-presenting
cells critical for T cell immunity. Cancer Cell 26,
638–652 (2014).
This study identifies the cutaneous DC subset
responsible for antigen presentation in the skin in
melanoma.
95. Gardner, A. & Ruffell, B. Dendritic cells and cancer
immunity. Trends Immunol. 37, 855–865 (2016).
96. Gordon, S. R. et al. PD-1 expression by
tumour-associated macrophages inhibits phagocytosis
and tumour immunity. Nature 545, 495–499 (2017).
97. Noordegraaf, M., Flacher, V., Stoitzner, P. &
Clausen, B. E. Functional redundancy of Langerhans
cells and Langerin+ dermal dendritic cells in contact
hypersensitivity. J. Invest. Dermatol. 130,
2752–2759 (2010).
98. Wohn, C. et al. Langerinneg conventional dendritic
cells produce IL-23 to drive psoriatic plaque formation
in mice. Proc. Natl Acad. Sci. USA 110, 10723–10728
(2013).
99. Leinweber, B., Kerl, H. & Cerroni, L. Histopathologic
features of cutaneous herpes virus infections (herpes
simplex, herpes varicella/zoster): a broad spectrum of
presentations with common pseudolymphomatous
aspects. Am. J. Surg. Pathol. 30, 50–58 (2006).
100. Zhu, J. et al. Persistence of HIV-1 receptor-positive
cells after HSV-2 reactivation is a potential mechanism
for increased HIV-1 acquisition. Nat. Med. 15,
886–892 (2009).
101. Kiviat, N. B. et al. Endometrial histopathology in
patients with culture-proved upper genital tract
infection and laparoscopically diagnosed acute
salpingitis. Am. J. Surg. Pathol. 14, 167–175 (1990).
102. Farkas, L., Beiske, K., Lund-Johansen, F., Brandtzaeg, P.
& Jahnsen, F. L. Plasmacytoid dendritic cells (natural
interferon- α/β-producing cells) accumulate in
cutaneous lupus erythematosus lesions. Am. J. Pathol.
159, 237–243 (2001).
Acknowledgements
This work was supported by grants from the Japan Society for
the Promotion of Science KAKENHI (JP15K09766,
JP15H05096 (to T.H.) and 263395 (to K.K)), Grants-in-Aid
for Scientific Research (15H05790, 15H1155 and
15K15417 to K.K.) and the Japan Agency for Medical
Research and Development (AMED) (16ek0410011h0003
and 16he0902003h0002 to K.K.). The authors thank A.
Hayday of the King’s College London School of Medicine,
London, UK, and E. Epstein Jr of PellePharm for the critical
reading of the manuscript.
Author contributions
All authors contributed to the discussion of the content of the
article. G.E. and T.H. also contributed to researching data and
the writing of the article. K.K. and F.G. also contributed to the
review and editing of the manuscript.
Competing interests
The authors declare no competing interests.
Publisher’s note
Springer Nature remains neutral with regard to jurisdictional
claims in published maps and institutional affiliations.
Reviewer information
Nature Reviews Immunology thanks B. Malissen and the
other anonymous reviewer(s) for their contribution to the peer
review of this work.
www.nature.com/nri
R e v i e w s
30 | JANuARY 2019 | volume 19
	The immunological anatomy of the skin
	Stratum corneum
	Immunological anatomy of the epidermis
	Monocyte interaction with hair follicles.
	T cell interaction with hair follicles.
	Immune modulation by sebaceous glands.
	Influence of the skin microbiota.
	Immune responses in the dermis
	Immune modulation by dermal blood vessels.
	Neuro-immune interactions in the skin.
	Contact hypersensitivity responses
	Immunity in subcutaneous adipose tissue
	Skin anatomy and induction of adaptive immunity
	Antigen presentation by cutaneous APCs.
	Antigen presentation in skin neoplasms
	iSALT formation around postcapillary venules.
	iSALT and other tertiary lymphoid structures.
	iSALT formation in human skin.
	Conclusions and perspectives
	Acknowledgements
	Fig. 1 Physical and immunological barrier of the skin.
	Fig. 2 A specific contribution of postcapillary venules in cutaneous immunity.
	Fig. 3 Neuro-immune interactions and perivascular adipose tissue in the skin.
	Fig. 4 Penetration of hapten and proteins into the skin.
	Fig. 5 A schematic view of the sensitization and elicitation phases of contact hypersensitivity.
	Fig. 6 Newly identified key locations and structures in skin immunity.
	Table 1 Putative APCs in the skin under different pathological conditions.
	Table 2 Characteristics and comparison of leukocyte clusters.
	Table 3 Leukocyte clusters in human diseases in skin or genital mucosa.
