SQM Details
Rich Brown
If you want to set up SQM to minimize bufferbloat, you should start at the SQM Howto page.
The remainder of this page gives some of the theory behind SQM, should you be curious about it. You should also
check the Bufferbloat site for considerably more detail.
Smart Queue Management (SQM) is our name for an intelligent combination of better packet scheduling (flow
queueing) techniques along with with active queue length management (AQM).
OpenWrt/LEDE has full capability of tuning the network traffic control parameters. If you want to do the work,
you can read the full description at the Traffic Control HOWTO. You may still find it useful to get into all the
details of classifying and prioritizing certain kinds of traffic, but the SQM algorithms and scripts (fq_codel, cake,
and sqm-scripts) require a few minutes to set up, and work as well or better than most hand-tuned classification
schemes.
Current versions of OpenWrt/LEDE have SQM, fq_codel, and cake built in. These algorithms were developed as
part of the CeroWrt project. They have been tested and refined over the last four years, and have been accepted
back into OpenWrt, the Linux Kernel, and in dozens of commercial offerings.
To use SQM in your router, use the SQM QoS tab in the web interface. This will optimize the performance of the
WAN interface (generally eth0) that connects your router to the ISP/the Internet. There are three sub-tabs in the
SQM QoS page that you may configure:
Set the Download and Upload speeds in the web GUI for the speed of your Internet connection. To do this
1.
2. Set Download and Upload according to those link speeds. See examples below.
3. Be sure to check the Enable box and set the Interface for your WAN interface.
4.
Example 1: If your your provider boasts “7 megabit download/768 kbps upload”, set Download to 5950 kbit/s
and Upload to 653 kbit/s. Those numbers are 85% of the advertised speeds.
Example 2: If you have measured your bandwidth with a speed test (be sure to disable SQM first), set the
Download and Upload speeds to 95% of those numbers. For example, if you have measured 6.2 megabits down
and 0.67 megabits up (6200 kbps and 670 kbps, respectively), set your Download and Upload speeds to 95% of
those numbers (5890 and 637 kbps, respectively)
Basic Settings - the details…
SQM is designed to manage the queues of packets waiting to be sent across the slowest (bottleneck) link, which is
usually your connection to the Internet. The algorithm cannot automatically adapt to network conditions on DSL,
cable modems or GPON without any settings. Since the majority of ISP provided configurations for buffering are
broken today, you need take control of the bottleneck link away from the ISP and move it into the router so it can
be fixed. You do this by entering link speeds that are a few percent below the actual speeds.
Use a speed test program or web site like the DSL Reports Speed Test to get an estimate of the actual download
and upload values. After setting the initial Download and Upload entries, you should feel free to try the
suggestions at A little about tuning SQM above to see if you can further increase the speeds.
Note: sqm-scripts shaper interprets the bandwidth values as gross bandwidth, while speedtests typically report
TCP/IPv4 good-put. So how to estimate what speedtest result is a good match for a given shaper bandwidth? Just
use the following formula and plug in the correct values:
${ShaperBandwidth} * (${pMTU} - ${IPv4Header} - ${TCPHeader}) / (${pMTU} + ${Overhead})
with: pMTU typically around 1500, IPv4Header = 20 bytes, TCPHeader = 20 bytes, Overhead the value you
specified in the shaper (or typically 14 bytes if you did not explicitly configured this)
E.g.: for a DOCSIS link with 18 bytes overhead you at best get a 100-100*(1500-20-20)/(1500+18) = 3.82%
SQM Details https://openwrt.org/docs/guide-user/network/tra...
1 of 8 21/04/2021 18:59
lower good-put than gross bandwidth.
The Queue Discipline tab controls how packets are prioritized for sending and receipt. The default settings shown
here work very well for nearly all circumstances. Those defaults are:
Queueing Discipline - the details…
The default cake queueing discipline works well in virtually all situations. Feel free to try out other algorithms to
see if they work better in your environment.
The default piece_of_cake.qos script has a traffic shaper (the Queueing Discipline you select) and three classes
with different priorities for traffic. This provides good defaults.
Explicit Congestion Notification (ECN) is a mechanism for notifying a sender that its packets are encountering
congestion and that the sender should slow its packet delivery rate. Instead of dropping a packet, fq_codel marks
the packet with a congestion notification and passes it along to the receiver. That receiver sends the congestion
notification back to the sender, which can adjust its rate. This provides faster feedback than having the router drop
the received packet. Note: this technique requires that the TCP stack on both sides enable ECN.
At low bandwidth, we recommend that you turn ECN off for the Upload (outbound, egress) direction, because
fq_codel handles and drops packets before they reach the bottleneck, leaving room for more important packets to
get out. For the Download (inbound, ingress) link, we recommend you turn ECN on so that fq_codel can inform
the local receiver (that will in turn notify the remote sender) that it has detected congestion without loss of a
packet.
The “Dangerous Configuration” options allow you to change other parameters. They are not heavily error
checked, so be careful that they are exactly as shown when you enter them. As with other options in this tab, it is
safe to leave them at their default. They include:
Please note that if any of the “Advanced option strings” contain values that are not interpreted by the selected
qdisc, sqm will _silently_ fail to instantiate, so make sure to always check these two field on changing the qdisc.
Also run “tc -d qdisc ; tc -s qdisc” on the router's command line to check whether the expected shapers
(ingress/egress) were instantiated, “not heavily error checked” for these two fields is emphatic for “not at all” and
the placement under “Dangerous Configuration” quite fitting.
The purpose of Link Layer Adaptation is to give the shaper more knowledge about the actual size of the packets
so it can calculate how long packets will take to send. When the upstream ISP technology adds overhead to the
packet, we should try to account for it. This primarily makes a big difference for traffic using small packets, like
VOIP or gaming traffic. If a packet is only 150 bytes and say 44 bytes are added to it, then the packet is 29%
larger than expected and so the shaper will be under-estimating the bandwidth used if it doesn't know about this
overhead.
Getting this value exactly right is less important than getting it close, and over-estimating by a few bytes is
generally better at keeping bufferbloat down than underestimating. With this in mind, to get started, set the Link
Layer Adaptation options based on your connection to the Internet. The general rule for selecting the Link Layer
Adaption is:
If you are not sure what kind of link you have, first try using Ethernet with Overhead and set 44 bytes. Then run
the Quick Test for Bufferbloat. If the results are good, you’re done. If you get your internet through an old-style
copper wired phone line and your speeds are less than a couple of megabits, you have ATM so see above for the
ATM entry. If you have a slow connection such as less than 2Mbps in either direction and/or you regularly use
several VOIP calls at once while gaming etc (so that more than 10 to 20% of your bandwidth is small packets)
then it can be worth it to tune the overhead more carefully, see below for extra details.
An important exception to the above rules is when the bandwidth limit is set by the ISP's traffic shaper, not bythe
equipment that talks to the physical line. Let's consider an example. The ISP sells a 15 Mbit/s package and
enforces this limit, but lets the ADSL modem connect at whatever speed is appropriate for the line. And the
modem “thinks” (as confirmed in its web interface) that 18 Mbps is appropriate. In this case, the ATM Link Layer
Adaptation is likely inappropriate, because the ISP's shaper is the only relevant speed limiter, and it does not work
at the ATM level. In fact, it is more likely to work at the IP level, which means that none is the appropriate setting.
Link Layer Adaptation - the details…
Various link-layer transmission methods affect the rate that data is transmitted/received. Setting the Link Layer
properly helps SQM make accurate predictions, and improves performance. There are several components of
overhead, the first comes from the basic transport technology itself:
In addition to those overheads it is common to have VLAN tags (4 extra bytes) or PPPoE encapsulation (8 bytes)
or even more exotic issues such as ipv4 provided over ipv6 in the DS-Lite scheme (where ipv4 packets experience
SQM Details https://openwrt.org/docs/guide-user/network/tra...
2 of 8 21/04/2021 18:59
a 40 byte ipv6 header overhead). Because of these variables and the fact that overestimation is generally better, we
offer the default suggested sizes in the first table).
The “Advanced Link Layer” choices are relevant if you are sending packets larger than 1500 bytes. This would be
unusual for most home setups, since ISPs generally limit traffic to 1500 byte packets. UPDATE 2017, most recent
link technologies will transfer complete L2 ethernet frames including the FCS; that in turn means that they will
effectively all inherit the ethernet minimal packet size of 64 bytes. It is hence recommended to set tcMPU to 64.
Note that most (but not all) ATM based links will exclude the FCS and hence probably do not require that setting.
As of March 2017 sqm-scripts does not evaluate tcMPU if cake is selected as “link layer adaptation mechanism”.
In that case add “mpu 64” to the advanced option strings for ingress and egress. As of middle of 2018 sqm-scripts
will try to evaluate tcMPU for cake also.
Please note that as of middle 2018 cake, and cake only, will try to interpret any given overhead to be applied on
top of IP packets, all other qdiscs (and cake if configured with the “raw” keyword) will add the specified overhead
on top of the overhead the kernel already accounted for. This seems confusing, because it is ;) so if in doubt stick
to cake.
Unless you are experimenting, you should use the default choice for the link layer adaptation mechanism. This
will select cake if cake is used as qdisc other wise tc_stab.
TL;DR: Use cake, not fq_codel.
Note: As of early 2017, cake is an improvement both in speed and capabilities over the original fq_codel
algorithm first deployed in May 2012. cake is in every way better than fq_codel. The following description is
preserved for historical information.
The right queue setup script (simple, hfsc_lite, …) for you depends on the combination of several factors like the
ISP connection's speed and latency, router's CPU power, wifi/wired connection from LAN clients etc.. You will
need likely to experiment with several scripts to see which performs best for you. Below is a summary of real-life
testing with three different setup scripts.
This was tested with WNDR3700 running trunk with kernel 4.1.16 and SQM 1.0.7 with simple, hfsc_lite and
hfsc_litest scripts with SQM speed setting 85000/10000 (intentionally lower than ISP connection speed),
110000/15000 (that should exceed the ISP connection speed and also totally burden the router's CPU), as well as
110000/15000 using Wifi.
 wired 85/10 wired 110/15 Wifi 110/15
 Download/Up/Latency Download/Up/Latency Download/Up/Latency
Simple 19.5/2.1/18.5 21.2/2.7/19 11.0/3.0/21
hfsc_lite 20.7/2.2/19.5 25.0/2.7/50 19.0/2.9/35
hfsc_litest 20.7/2.2/18.7 25.0/2.7/52 18.0/2.8/35
(“flent” network measurement tool reports the overview as average of the 4 different traffic classes, so the total
bandwidth was 4x the figures shown in the above table that shows “per-class” speed. The maximum observed
combined download+upload speed was ~110 Mbit/s.)
With wired 85/10 the experience was almost identical with all four qdisc strategies in SQM. Approx. 20 Mbit/s
download / 2.1 Mbit/s upload and 19 ms latency shown in the flent summary graph.
With wired 110/15 there was more difference. Interestingly “simple” kept latency at 20 ms, while with the other 3
strategies latency jumped to 50 ms after ~20 seconds. (Might be a flent peculiarity, but still mentioning it.)
“simple” kept low latency at 19 ms and 21 Mbit/s download, while the other 3 strategies had 50 ms latency while
having 24-25 Mbit/s download per class.
But when the LAN client connected with Wifi to the router with 110/15 limits, “simple” lost its download speed.
Latency was still low, but download speed was really low, just half of the normal. Likely the CPU power required
for wifi limited the CPU available for other processing and the router choked.
At least on the tested setup, the download speed using wifi and SQM “simple” was half of that what could
achieved with hfsc_lite+wifi, or simple+wired.
The key message of this note is that the right setup script for you will depend on your connection, your router and
your LAN clients. It pays off to test the various setup scripts.
Making cake sing and dance, on a tight rope without a safety net (aka
advanced features)
By now, we hope the SQM message has been clear: stick to the defaults and use cake.
SQM Details https://openwrt.org/docs/guide-user/network/tra...
3 of 8 21/04/2021 18:59
But cake offers new options that make it the nicest and most complete shaper for a typical home network: Per-
Host Isolation in the presence of network address translation (NAT), so that all hosts' traffic shares are equal. (You
can choose to isolate per-internal or per-external host IP addresses, but typically fairness by internal host IPs
seems in bigger demand.)
A quick aside about Network Address Translation (NAT): ISPs usually assign only one external IP address to each
customer. The home router assigns unique internal addresses for each computer in the home, and uses a technique
called NAT (or “masquerading”) to rewrite those internal IP addresses and ports to work across the single external
address.
NAT works pretty well, too, but causes problems when shaping traffic. Since all the traffic going to/from the ISP
has the same external IP address, cake treats every traffic flow (or stream or connection) identically: a single
Netflix stream to one internal computer gets the same bandwidth as a single BitTorrent stream to another. But
since a BitTorrent client can start many BitTorrent streams, the second machine can get “more than its share” of
the capacity.
Recent versions of cake (in OpenWrt/LEDE 17.01.0 and newer) have two options that avoid this problem:
1. Cake can now access the kernel's internal translation tables and get access to the true source and destination
addresses of incoming and outgoing packets;
2. Cake can use the information about true source and destination addresses to control traffic from/to internal
external hosts by true IP address, not per-stream.
Cake's original isolation mode was based on flows: each stream was isolated from all the others, and the link
capacity was divided evenly between all active streams independent of IP addresses. More recently Cake
switched to triple-isolate, which will first make sure that no internal or external host will hog too much
bandwidth and then will still guarantee for fairness for each host. In that mode, Cake mostly does the right thing.
It would ensure that no single stream and no single host could hog all the capacity of the WAN link. However, it
can't prevent a BitTorrentclient - with multiple connections - from monopolizing most of the capacity. And
running speedtests from multiple internal hosts to the same speedtest server can give unpredictable results.
Cake now uses the true source/destination address information to create Per-Host Isolation, and dynamically
distributes the available bandwidth fairly between the currently-active IP addresses. So a single Netflix stream to
one host ideally gets just as much capacity as all the BitTorrent traffic destined to another.
To enable Per-Host Isolation Add the following to the “Advanced option strings” (in the Interfaces → SQM-QoS
page; Queue Discipline tab, look for the Dangerous Configuration options):
For queueing disciplines handling incoming packets from the internet (internet-ingress): nat dual-dsthost
For queueing disciplines handling outgoing packets to the internet (internet-egress): nat dual-srchost
Please note the addition of the ingress keyword to the “Advanced option strings”
Regarding cake's “ingress” keyword: Conceptually a traffic shaper will drop and/or delay packets in a way that the
rate of packets leaving the shaper is smaller or equal to the configured shaper-rate. This works well on egress, but
for post-bottleneck shaping as is typical for the internet ingress (the download direction) this is not ideal. For this
kind of shaping we actually want to make sure that there is as little as possible packet-backspill into the upstream
devices buffers (if those buffers where sized and managed properly we would not need to shape on ingress in the
first place). And to avoid backspill we need to make sure that the combined rate of packets coming into the
upstream device (rarely) exceeds the bottleneck-link's true capacity. The “ingress” keyword instructs cake to
basically try to keep the incoming packet rate ⇐ the configured shaper rate. This leads to slightly more aggressive
dropping, but this also ameliorates one issue we have with post-bottleneck shaping, namely the inherent
dependency of the required bandwidth “sacrifice” with the expected number of concurrent bulk flows. As far as I
can tell the more aggressive dropping in ingress-mode automatically scales with the load and hence it should make
it possible to get away with configuring an ingress-mode rate closer to the true bottleneck-rate, and actually also
get higher throughput if only few bulk flows are active. For further reference I recommend to have a look at cake's
source at https://github.com/dtaht/sch_cake?files=1
With the 'ingress' keyword, the above example for incoming packets from the internet would be nat dual-dsthost
ingress
Notes:
SQM seems to be confused, my measured download speed is actually close to my configured upload speed:
Depending on the directionality of the interface with the directionality towards the internet that is not unexpected;
try to flip the values in the GUI and see whether measured values better match your expectation.
SQM Details https://openwrt.org/docs/guide-user/network/tra...
4 of 8 21/04/2021 18:59
SQM seems confused, both download and upload bandwidth in speedtests measure around the lower value
of the configured download and upload bandwidth:
This situation can arise when using a router that uses one of its switch ports as the WAN port and only has one
CPU to switch port; assuming the cpu port to the switch is eth0 and VLAN 2 is used for WAN, VLAN 1 for
LAN;in that case the appropriate WAN interface from sqms perspective is eth0.2. Instantiating sqm on eth0 (note
the lack of the VLAN tags) will make sure that eth0.2 is effectively throttled to min(download_bandwidth,
upload_bandwidth), as eth0 egress shaping will affect both internet egress (via eth0.2 egress) as well as internet
ingress (via eth0.1 egress). In short make sure to instantiate sqm on the real wan interface if internet shaping is
intended…
How to figure out which interface is actually connected to the internet:
From the Network→Interfaces
GUI
From the Command Line
The WAN port box shows the
name of the WAN interface:
Run the following from the router's command line:
ifstatus wan | grep -e l3_device
The command above might display:
“l3_device”: “eth0”,
which means eth0 is the WAN interface. Select it in Network→SQM
QoS GUI,
if you want the typical “shape my internet access” configuration.
Measured goodput in speed tests with SQM is considerably lower than without
Traffic shaping is relative CPU intensive, not necessarily as sustained load. To be able to keep buffering in the
device driver low SQM only releases small amounts of packets into the next layer (often the device driver). To
keep throughput up, the qdisc now only has the small time window from handing the last packets up to the diver
and the point these packets will be transmitted at the desired shaper rate to hand more packets to the driver. If
SQM does not get access to the CPU inside that time window, it will effectively not use some nominal transmit
opportunities, and hence throughput will stay below the configured rate.
One sign of such under-throughput by CPU-overload is that the CPU rarely falls idle. Aquick an dirty test for that
is to run `top -d 1` and watch the %idle column in one of the upper rows, if that gets too close to 0% (you need to
generate a load, like a speedtest and while this test runs observe the %idle column and try to get a feel what the
minimum %idle is that shows up) sqm is likely CPU bound. Since that test will only show aggregate usage over
full second intervals, but SQM operates on smaller time windows, often an observed min %idle of 10% already
indicates CPU limitations to sqm. Please note that for multicore routers reading %idle gets more complicated, as
50% idle on a dual core, might mean one core is fully loaded and one is idle (bad if sqm runs on the overloaded
core) or that both cores are loaded only 50%. Please note that htop (opkg update ; opkg install htop`) has a per
CPU stats display that can be toggled by pressing t and includes the traditional mode as well:
top - 11:29:29 up 12 days, 14:42, 0 users, load average: 0.06, 0.02, 0.00
Tasks: 158 total, 1 running, 157 sleeping, 0 stopped, 0 zombie
%Cpu0 : 2.0 us, 0.0 sy, 0.0 ni, 97.0 id, 0.0 wa, 0.0 hi, 1.0 si, 0.0 st
%Cpu1 : 3.0 us, 1.0 sy, 0.0 ni, 93.1 id, 0.0 wa, 0.0 hi, 3.0 si, 0.0 st
This should allow to eye-ball whether a single core might be pegged. In this example without load, both CPUs idle
> 90% of the time, no sign of any overload ;) Pressing F1 in htop, shows the color legend for the CPU bars, and
F2 Setup → Display options → Detailed CPU time (System/IO-Wait/Hard-IRQ/Soft-IRQ/Steal/Guest), allows to
enable the display of the important (for network loads) Soft-IRQ category.
Also to make things even more complicated, CPU power/frequency scaling (to save power) can interfere
negatively with SQM. Probably due to SQM's bursty nature it might not be recognised by the power governor and
the CPU (that at 100% is capable of shaping to the desired sqm rate) gets too slow to service SQM in time and
throughput suffers, and due to the burstyness the governor might never realise it should scale frequency back up.
SQM Details https://openwrt.org/docs/guide-user/network/tra...
5 of 8 21/04/2021 18:59
This can be remedied by trying to optimise the transition rules for up-scaling frequency/power or by switching to a
non-scaling governor. The former requires a bit of trial and error but maintains power saving, while the latter
probably is easier to achieve and hence might be a good way to figure out whether power saving might be an issue
in the first place. @experts, please feel free to elaborate on which power save settings are worth exploring.
The commands below help to collect the information required to debug problems with SQM. To use them, SSH
into the router, and enter each line, one at a time. Then copy/paste the entire terminal session in your report.
Display all currently defined sqm instances (enabled and disabled):
 cat /etc/config/sqmDisplay all information about the WAN interface:
 ifstatus wan
Display relatively detailed output of the process of stopping and starting SQM:
 SQM_DEBUG=1 SQM_VERBOSITY_MAX=8 /etc/init.d/sqm stop ; SQM_DEBUG=1 SQM_VERBOSITY_MAX=8 /etc/init.d/sqm start
Display the log file created by the commands above:
 cat /var/run/sqm/*debug.log
Display the logread output of the sqm start and stop:
 logread | grep SQM
Display the detailed output of linix's tc (traffic control) system:
 tc -d qdisc
Display the statistics output of tc system:
 tc -s qdisc
Now generate some traffic through the router (and the SQM instance). The easiest way to do this is to run the
DSLReports Speedtest (http://www.dslreports.com/speedtest)
Now display the tc statistics again: this shows the increased traffic the SQM instance should have seen.
 tc -s qdisc
Finally, copy/paste the entire session into your report.
How I use CAKE to control bufferbloat and fair share my Internet connection on Openwrt.
CAKE has been my go to solution to bufferbloat for years, not just because of solving bufferbloat but also for
fairer sharing of my link. Whilst CAKE has some sensible defaults there are a few extra options & tweaks that can
improve things further.
This note assumes that you have an Internet facing interface, usually eth0 and will call traffic leaving that interface
TO the ISP egress traffic. Traffic received on that interface FROM the ISP is called ingress traffic. This interface
is usually connected to an ISP's modem.
Controlling egress bufferbloat to the ISP's modem is relatively straightforward. If you ensure that traffic doesn't
arrive at the modem faster than it can pass to the ISP then bufferbloat within the ISP's modem is eliminated. This
involves using something called a shaper to control how quickly data leaves eth0. CAKE has a built in packet
shaper that times the release of packets out of the interface so as to not overload the upstream modem. Packets
also tend to accumulate extra data or overhead the closer they get to the ISP's link. For example VDSL modem
links will have some framing overhead and may also acquire a 4 byte VLAN tag. CAKE's shaper is also able to
take into account a wide variety of overheads adjusting its timed release mechanism to cope.
For my ISP (Sky UK) things are straightforward. They basically run ethernet over PTM over VDSL2 and I have
an 80mbit ingress / 20mbit egress link. Looking at my modem's status page I can see that the egress of 20mbit is
achieved but the ingress is slightly lower than 80mbit. BT are the incumbent VDSL2 infrastructure provider and
require a VLAN ID 101 tag on packets across the link so we have to account for that. Similarly there's a minimum
packet size limit, which empirically I'll set to 72 bytes, based on the smallest packets we ever see on the ingress
side. so we're already at a stage where we can start specifying things to cake:
egress: 19950 bridged-ptm ether-vlan mpu 72 ingress: 78000 bridged-ptm ether-vlan mpu 72 ingress
SQM Details https://openwrt.org/docs/guide-user/network/tra...
6 of 8 21/04/2021 18:59
We'll come back to the 'ingress' option a little later.
CAKE also has a means of fair sharing bandwidth amongst hosts. A simple example/question: If I have two hosts
one which starts 2 data streams and the other starts 8, then one host would get 80% of the bandwidth allocated to it
and the other 20%. From a fairness point of view it would be better if the available bandwidth was split evenly
across the active hosts irrespective of the number of flows each host starts, such that one host cannot obtain all of
the bandwidth just because it starts all of the transfers.
By default CAKE does 'triple-isolate' fair sharing which fair shares across both source machine addresses (internal
lan) and destination addresses (external wan). In other words (and a bit simplistically) google's hosts cannot
monopolise all the bandwidth from Apple's hosts (or Microsoft, Facebook, github etc) in the same way that one
internal host cannot monopolise all the bandwidth.
There is a small fly in this ointment in the form of IPv4 Network Address Translation (NAT) where typically the
ISP subscriber is given one Internet facing IPv4 address in which all the internal LAN traffic (usually in
192.168.x.x) is masqueraded behind. Since all the internal addresses have been hidden behind this one external
Internet address, how can CAKE fair share across the internal hosts? If CAKE is running on the device performing
IPv4 NAT then it can look into the device's NAT tables to determine the internal addresses and then base the
fairness on that. Unfortunately it's not the default, so we have to specify it:
egress: 19950 bridged-ptm ether-vlan nat mpu 72 ingress: 78000 bridged-ptm ether-vlan nat ingress
In fact what I do is force cake to only worry about internal fairness. In other words I care that my internal
machines get a fair share of the traffic irrespective of number of flows each machine has, but I don't care if
external machines are unbalanced (eg. google vs netflix)
egress: 19950 dual-srchost bridged-ptm ether-vlan nat mpu 72 ingress 78000 dual-dsthost bridged-ptm ether-vlan
nat ingress
Having dealt with host fairness we now need to deal with flow fairness & control. A full link isn't a bad thing, in
fact it's the best thing since we're using all the bandwidth that we're paying for. What is bad is when access to that
link cannot be achieved in a timely manner because an excessive queue has built up in front of our packet. CAKE
prevents the queue building up and ensures fair access by using a variation of codel to control delay (latency) on
individual flows.
Simplistically, codel works by looking at how long a packet has been in a queue at the time it is scheduled to be
sent and if it is too old the packet gets dropped. This may seem like madness after all 'isn't packet loss bad?', well
packet loss is a mechanism that TCP uses to determine whether it is sending too much data and overflowing a link
capacity. So shooting the right packets at the right time is actually a fundamental signalling mechanism to avoid
excessive queueing. Some TCP stacks/connections support another signalling mechanism called ECN, whereby
packets are marked or flagged instead of being dropped. CAKE supports ECN marking too.
CAKE looks at each data flow in turn and either releases or drops a packet from each flow to match the shapers'
schedule and by dropping packets from a flow before it has built up a significant queue is able to keep each flow
under control.
ingress mode modifies how CAKE's shaper accounts for dropped packets, in essence they still count to the
bandwidth used calculation even though they're dropped - this makes sense, since they arrived with us but we
decided that the particular flow was occupying too much bandwidth so we dropped a packet to signal the other end
to slow down. The shaper on egress doesn't count dropped packets, instead it looks in the queues to find a more
worthy packet to occupy the space. The bottom line, if you're trying to control ingress packet flow use ingress
mode, else don't.
Traffic classification.
At this point we have a reasonably fair system. Flow fairness has been handled by a variation codel and we
deliberately make that unfair if required by ensuring per-host fairness. But what if I have some types of traffic that
are less or more important than others? CAKE deals with traffic classification by dividing it up into priority tins
based on packet DSCP (diffserv) values. By default CAKE uses a 3 tin classification mode called 'diffserv3'. Other
modes of possible interest are 'besteffort', 'diffserv4' and 'diffserv8'. Besteffort effectively ignores DSCP values,
every packet is as important as the other and so just flow & host fairness come into play. The diffserv modes split
DSCP into an increasing number of tins. I prefer diffserv4 as I then have 4 traffic categories in increasing order of
importance: 'Bulk', 'Best Effort', 'Video', 'Voice'.CAKE enforces minimum bandwidth limits for each category,
Voice gets a minimum of 1/4 bandwidth, Video 1/2, Bulk 1/16th and Best Effort has a minimum of all of it(!?)
Note these are minimums so if 'Video' needed all the bandwidth and there was no other competing traffic in any
other category it can by all means take it. Similarly, the lowest priority tin 'Bulk' can have all the capacity if there's
no other traffic, though it is guaranteed 1/16th of the bandwidth in order to prevent it from being completely
starved. Best effort having the full bandwidth as a minimum appears mad but what it is in essence saying is it can
have whatever is left from full - (1/2 + 1/4 + 1/16)
SQM Details https://openwrt.org/docs/guide-user/network/tra...
7 of 8 21/04/2021 18:59
I use diffserv4 over diffserv3 because of the 'Bulk' category - in other words I have somewhere to de-prioritise
traffic to, eg. a long term download or upload (think network backup) probably isn't important in 'wall clock time'
but I don't want it disturbing general web browsing or worse video streaming or worse voip/facetime calls. I've
had backups running for days at Bulk, vacuuming up all the spare upload capacity and it's completely unnoticeable
(my network monitoring tells me there's an average 2mS increase in latency with peaks up to 4mS)
egress: 19950 diffserv4 dual-srchost bridged-ptm ether-vlan nat mpu 72 ingress 78000 diffserv4 dual-dsthost
bridged-ptm ether-vlan nat ingress
The cherry on top.
This is only really relevant for egress traffic and for asymmetric links. In essence TCP acknowledgements can be
sitting in a queue waiting to be sent. We only really need the newest ack to be sent, since it acknowledges
everything the 'old' acks acknowledge - so let's not send too many of the old acks - it saves a little egress
bandwidth.
egress: 19950 diffserv4 dual-srchost bridged-ptm ether-vlan nat mpu 72 ack-filter ingress 78000 diffserv4 dual-
dsthost bridged-ptm ether-vlan nat ingress
SQM Details https://openwrt.org/docs/guide-user/network/tra...
8 of 8 21/04/2021 18:59
