CHAPTER 22 953

aromatic ring. The integration of this signal is 5, which
indicates that the ring is monosubstituted:



The presence of a monosubstituted ring is confirmed by
the four signals between 100 and 150 ppm in the 13C
NMR spectrum (the region associated with sp2
hybridized carbon atoms), just as expected for a
monosubstituted aromatic ring:



In the 1H NMR spectrum, the pair of triplets (each with
an integration of 2) indicates a pair of neighboring
methylene groups:



These methylene groups account for the two upfield
signals in the 13C NMR spectrum.
Thus far, we have accounted for all of the atoms in the
molecular formula, except for one nitrogen atom and two
hydrogen atoms, suggesting an amino group. This would
indeed explain the singlet in the 1H NMR spectrum with
an integration of 2.
We have now analyzed all of the signals in both spectra,
and we have uncovered the following three fragments,
which can be connected to each other in only one way:




22.82. The product has four C-N bonds, each of which
can be prepared via a reductive amination process. As
such, the product can be made from the following
starting materials (two equivalents of ammonia and two
equivalents of a dialdehyde):


The necessary dialdehyde has only three carbon atoms,
but the starting material (benzene) has six carbon atoms.
This suggests that we must somehow break apart the
aromatic ring into two fragments. This might seem
impossible at first, as we have seen that aromatic rings
are particularly stable. We did, however, cover a
reaction that destroys aromaticity (a Birch reduction will
convert benzene into 1,4-cyclohexadiene). If a Birch
reduction is followed by ozonolysis, the resulting
dialdehyde can then be treated with ammonia and
sodium cyanoborohydride (with an acid catalyst) to give
the product:

3) DMS
H
O
H
O
HN NH
1) Na, NH3, CH3OH
2) O3
4) [ H+ ], NaBH3CN, NH3Na, NH3
CH3OH
2) DMS
1) O3
NH3
NaBH3CN
[ H+ ]


22.83. The starting material exhibits a five-membered
ring, while the product exhibits a six-membered ring that
contains a nitrogen atom. Since we have not learned a
way to insert a nitrogen atom into an existing ring, we
must consider opening the ring, and then closing it back
up again (in a way that incorporates the nitrogen atom
into the ring). There are certainly many acceptable
synthetic routes. One such route derives from the
following retrosynthetic analysis. An explanation of
each of the steps (a-d) follows.
