Update Training – Process Engineering
Chapter 1 – Simulation Setup
• Two parts simulation setup
• Gui improvements
• Improvements on measurement tools
• Aerial Cams
• New Operation Setups
• Measurement scenarios setup
Chapter 2 – Elastic Tool Deflection Study
• Benefits and Definition of Elastic Tool Deflection
• Solid Tool preparation and ETD simulation setup
Chapter 3 – Multi-Blank
• Combine two different works on two separate parts
• Analyze of the combined effect of using these tools together on the
Press Table
Chapter 4 – Thermal Effects
• Combine two different works on two separate parts
• Analyze of the combined effect of using these tools together on the
Press Table
Contents
Chapter 5 – Multi-Sheet Analysis
• Study of Formcheck on Multi-Sheet.
• Spring back analysis of multiple parts.
Chapter 6 – Die Face Quality Design
• DieDesigner plus first steps
• Introduction of AutoForm SMART Design Workflow
• Concept Geometry Generation
AutoForm Proprietary – Confidential
Chapter 1
Simulation Setup
Update Training
Process Engineering AutoForm R11
AutoForm Proprietary – Confidential
5
Chapter 1
• Task and Learning Targets
• Simulation Setup
• Main Focus
• Two parts simulation setup
• Gui improvements
• Improvements on measurement tools
• Aerial Cams
• New Operation Setups
• Measurement scenarios setup
Objectives
AutoForm Proprietary – Confidential
6
Chapter 1
• Material
• DX56D+Z
• Minimal tensile strength 311.3 MPa (N/mm²)
• Sheet thickness: 1.00 mm
Hood Inner
1483 mm
1
6
6
3
 m
m
DX56D
1.00 mm
AutoForm Proprietary – Confidential
7
Chapter 1
• Material
• DX56D+Z
• Minimal tensile strength 311.3 MPa (N/mm²)
• Sheet thickness: 1.00 mm
Small Part
100 mm
1
1
3
 m
m
DX56D
1.00 mm
AutoForm Proprietary – Confidential
8
Chapter 1
Hood Inner – Process plan Information
D-20
Single action
draw
T-30
Segmented
outer trim
T-40
Piercings in
working
direction
Segmented
outer trim
AutoForm Proprietary – Confidential
9
Chapter 1
Hood Inner – Process plan Information
F-50
Secondary
Forming
Extruded
Holes
AutoForm Proprietary – Confidential
10
General
There are new features on context menus.
• Go to… (1)
Using the Go to option, by clicking with RMB in
a curve you can go directly to the page where
this curve was generated.
• Edit… (2)
If the user is already on the page where the
curve was generated, and clicks with RMB on
curve, a pop-up will appear giving the user the
option to Edit the curve.
• Hide Symmetry plane (3)
The option Hide Symmetry Plane appears when
the user clicks with the RMB over the plane on
GUI.
Context Menus
Essentials
1 2
3
Context Menus
New
AutoForm Proprietary – Confidential
11
3D View
• If the anchor point is visible, it's displayed as
a white point.
• If the anchor point is hidden, it's displayed
as a semi-transparent white dot.
• Label is Color Coded depending on the
reference color.
Label Visibility
Essentials
UT – R11
AutoForm Proprietary – Confidential
12
Instead of starting with just one part, we will
produce two distinct products together.
1. Click on new design
2. Click on part import
3. Select :
• SmallPart_Surface_V2.igs
• AF_Hood_inner.igs
4. Confirm the thickness direction
The hood inner is positioned on the car
positioning . The small part is positioned on
the equipment orientation. We need to
modify to put them together
This is the second release of the product
Small Surface. To check the usability of the
new feature Geometry Comparisson, import
the first release of the part:
Part Stage
Import Part Geometry
Exercise 1
1
Import
2
3
4
UT – R11
AutoForm Proprietary – Confidential
13
1. Click on Import Part…
2. Select : SmallPart_Surface_V1.igs
3. On Application Toolbar click on
Geometry Comparison
4. Define the Measured and Reference
Parts
Once selected both the Measured and
the Reference geometry in the Geometry
Comparison dialog, the functionality offers
the possibility to analyze the following
deviations on the displayed Measured
geometry.
• Nearest Distance
• Angle Deviation
• Boundary Deviation
5. Check the deviations
6. Delete the “SmallPart_Surface_V1”
Part Stage
Import Part Geometry
Exercise 1 Import
Angle Deviation
Nearest Distance
Boundary Deviation
1
2
3
4
5
UT – R11
AutoForm Proprietary – Confidential
14
Application Toolbar
The Major and Minor Curvature functions have
been improved.
Now, both Major and Minor Curvature analyses,
offer as output result, in addition to the
curvature value, also the value of the
corresponding radius.
To define the limits of the color scale, both the
curvature value or the formula 1/radius are
accepted (e.g. to define as limit of the color
scale a radius equal to 5, it will be possible to
enter the formula 1/5 or the resulting curvature
value equal to 0.2).
Major and Minor Curvature
analyses
Essentials
New
Application Toolbar
UT – R11
AutoForm Proprietary – Confidential
15
Application Toolbar
There are new options on measurement field:
• World Measurement
• Screen Measurement
• Curve Measurement enhance
• Principle Radii
New Measuring Options
Essentials
New
Application Toolbar
AutoForm Forming R10
AutoForm Forming R11
UT – R11
AutoForm Proprietary – Confidential
16
Application Toolbar
It is a Combination of the 3D Measurement and
the Vector Measurement
The Vector components can be shown by
clicking on the coordinate system symbol (1)
World Measurement
Essentials Application Toolbar
AutoForm Forming R10 AutoForm Forming R11
1New
UT – R11
AutoForm Proprietary – Confidential
17
Application Toolbar
It is a Combination of the 2D Measurement and
the Vector Measurement
The Vector components can be shown by
clicking on the coordinate system symbol (1)
Screen Measurement
Essentials Application Toolbar
New
AutoForm Forming R10 AutoForm Forming R11
1
1
UT – R11
AutoForm Proprietary – Confidential
18
Application Toolbar
The curve can be now projected in X, Y or Z
direction
The most suitable projection direction is
determined automatically
The projection direction can be switched by
releasing and pressing again the Alt key
Curve Measurement
Essentials
AutoForm Forming R11AutoForm Forming R10
Application Toolbar
New
UT – R11
AutoForm Proprietary – Confidential
19
Application– Measurement Scenarios
	Slide 71: Essentials – Measurement Scenarios
	Slide 72: Essentials – Measurement Scenarios
	Slide 73: Essentials – Measurement Scenarios
	Slide 74: Measurement
	Slide 75: Measurement
	Slide 76: Measurement
	Slide 77: Simulation
	Slide 78: Evaluation
	Slide 79: Process Stage
	Slide 80: Autoform Sigma
	Slide 81: Autoform Sigma
	Slide 82: Autoform Sigma
	Slide 83: Evaluation
	Slide 84: Genral
	Slide 85: Chapter 2 Elastic Tool Deflection (ETD)
	Slide 86: Chapter 2
	Slide 87: Essentials - Motivation
	Slide 88: Essentials - Elastic tool deflection
	Slide 89: Essentials - Elastic tool deflection
	Slide 90: Elastic Tool Deflection
	Slide 91: Tool Solid
	Slide 92: Solid Tool Preparation - Punch
	Slide 93: Elastic Tool Deflection
	Slide 94: Solid Tool Preparation - Punch
	Slide 95: Solid Tool Preparation - Punch
	Slide 96: Elastic tool deflection
	Slide 97: Elastic tool deflection
	Slide 98: Elastic tool deflection
	Slide 99: Essentials - Elastic tool deflection
	Slide 100: Solid Tool Preparation - Punch
	Slide 101: Chapter 2 - Tool Preparation
	Slide 102: Solid Tool Preparation - Die
	Slide 103: Solid Tool Preparation - Die
	Slide 104: Solid Tool Preparation - Die
	Slide 105: Chapter 2 - Tool Preparation
	Slide 106: Elastic Tool Deflection
	Slide 107: Elastic Tool Deflection
	Slide 108: Elastic Tool Deflection
	Slide 109: Essentials - Overcrowning
	Slide 110: Essentials - Overcrowning
	Slide 111: Essentials - Overcrowning
	Slide 112: Essentials - Overcrowning
	Slide 113: Overcrowning
	Slide 114: Overcrowning
	Slide 115: Overcrowning
	Slide 116: Essentials - Overcrowning
	Slide 117: Chapter 3 Multi Blank
	Slide 118: Chapter 3
	Slide 119: Advanced Max. Failure
	Slide 120: Chapter 3
	Slide 121: Chapter 3
	Slide 122: Chapter 3
	Slide 123: Advanced Max. Failure
	Slide 124: Evaluation
	Slide 125: Getting started
	Slide 126: Getting started
	Slide 127: Process Setup
	Slide 128: Process Setup
	Slide 129: Process Setup
	Slide 130: Process Setup
	Slide 131: Process Setup
	Slide 132: Process Setup
	Slide 133: Advanced Max. Failure
	Slide 134: Chapter 3
	Slide 135: Chapter 4 Thermal Effects
	Slide 136: Chapter 4
	Slide 137: Essentials - Motivation
	Slide 138: Essentials - Motivation
	Slide 139: Essentials - Smart Ramp Up
	Slide 140: Essentials - Cold Forming with Temperature Effects
	Slide 141: Essentials - Cold Forming with Temperature Effects
	Slide 142: Preliminary Steps
	Slide 143: Essentials - Cold Forming with Temperature Effects
	Slide 144: PL Thermal
	Slide 145: Cold forming with temperature effects
	Slide 146: PL Thermal
	Slide 147: Cold forming with temperature effects
	Slide 148: Thermal Results
	Slide 149: Thermal Results
	Slide 150: Thermal Results
	Slide 151: Thermal Results
	Slide 152: Formability
	Slide 153: Robustness
	Slide 154: Essentials - Cold Forming with Temperature Effects
	Slide 155: Chapter 5 Multi Sheet
	Slide 156: Chapter 5
	Slide 157: Multi Sheet
	Slide 158: Multi Sheet
	Slide 159: Multi Sheet
	Slide 160: Multi Sheet
	Slide 161: Multi Sheet
	Slide 162: Multi Sheet
	Slide 163: Charpter 5 – Multi sheet
	Slide 164: Charpter 5 – Multi sheet
	Slide 165: Multi Sheet
	Slide 166: Postprocessing
	Slide 167: Chapter 6 Die Face Quality Design
	Slide 168: Chapter 6
	Slide 169: Exercise 6
	Slide 170: Exercise 6
	Slide 171: Exercise 6
	Slide 172: Die Face Quality Design
	Slide 173: Die Face Quality Design
	Slide 174: Die Face Quality Design
	Slide 175: Die Face Quality Design
	Slide 176: Die Face Quality Design
	Slide 177: Die Face Quality Design
	Slide 178: Die Face Quality Design
	Slide 179: Die Face Quality Design
	Slide 180: Die Face Quality Design
	Slide 181: Die Face Quality Design
	Slide 182: Die Face Quality Design
	Slide 183: Die Face Quality Design
	Slide 184: Die Face Quality Design
	Slide 185: Die Face Quality Design
	Slide 186: Die Face Quality Design
	Slide 187: Die Face Quality Design
	Slide 188: Die Face Quality Design
	Slide 189: Die Face Quality Design
	Slide 190: Die Face Quality Design
	Slide 191: Exercise 6
	Slide 192Toolbar
• It's listed at the bottom of the menu,
separated from the other tools since its
handling is slightly different (Alt + click).
• Major and minor curvatures at a clicked point
are calculated to a radii values which are just
the inverse of the principal curvatures.
• In the label the top value refers to the major
curvature as radius value
• and the one on the bottom refers to the
minor curvature as radius value
• The arcs visualize the curvature directions as
well as their radii.
Principle Radii
Essentials Application Toolbar
New
UT – R11
AutoForm Proprietary – Confidential
20
Application Toolbar
During the measurement, potential snap points
are displayed as small circles (1).
They are also available during the measurement
in dynamic section (2).
Is it possible to activate or deactivate this
function on AutoForm Preferences (3).
Snapping points
Essentials Application Toolbar
New
1
2
2
UT – R11
AutoForm Proprietary – Confidential
21
Application Toolbar
Hovering and Moving
If hovered over an endpoint, the endpoint size
increases. When clicking and moving only the
endpoint moves. (1)
If hovered over the line in between, the
complete measurement gets thicker. When
clicking and moving the complete measurement
moves. (2)
Measurement Editing
Essentials
2
1
New
Application Toolbar
UT – R11
AutoForm Proprietary – Confidential
22
1. Click on Automatic Tipping.
2. Set the tipping definition for Hood Inner
3. Set the tipping definition for Small Part
The most important thing in the tipping is to
positioned the small part in the middle of
the Hood-Inner(as shown in the figure) and
at the same height.
Part Stage
Tip
Exercise 1
1
Tip
2
3
UT – R11
AutoForm Proprietary – Confidential
23
1. Go Back to Import page and define a
Symmetry plane
Part Stage
Symmetry Plane
Exercise 1
1
Import
2
UT – R11
AutoForm Proprietary – Confidential
24
1. Click on Add Material.
2. Select the DX56D+Z Material card.
3. Confirm the 1.0 mm Thickness by
clicking on OK.
Part Stage
Define Blank Material
Exercise 1
1
Material
2
3
UT – R11
AutoForm Proprietary – Confidential
26
Material Card
Joining Class is a text field used in AF-Assembly
for filtering. This cannot be stored in the ASCII
file.
Density can now be entered in place of Specific
Weight. In the material card only Specific
Weight can be stored.
Specific Heat Capacity can now be entered in
place of Volumetric Heat Capacity. In the
material card only Volumetric Heat Capacity can
be stored.
Lubrication & Fromability File are now
mandatory entries when generating a new
material card.
This is intended to get Users to think about the
importance of these files when creating a card
and to ultimately stop incorrect formability
plots.
This is not enforced on cards that have already
been created.
New Concept
Essentials Material
New
UT – R11
AutoForm Proprietary – Confidential
27
1. Click on Create Empty Plan.
2. Create the production Line as shown on
image beside.
3. Skip the operations from T-30.
Plan Stage
Getting Started
Exercise 1
1
2
3
UT – R11
AutoForm Proprietary – Confidential
28
1. Define the Process Units as shown
beside.
Defining the process units
Process units
Exercise 1 Production
UT – R11
AutoForm Proprietary – Confidential
29
1. Define the segmentation for the outer
trim.
Trim Plan
Trim Segments
Exercise 1 Plan
UT – R11
AutoForm Proprietary – Confidential
30
1. Define the segmentation for the large
holes
2. Set the correct cutting angle
Trim Plan
Trim Segments
Exercise 1 Plan
1 2
UT – R11
AutoForm Proprietary – Confidential
31
Plan Stage
Edit Direction
Exercise 1 Plan
To avoid problems with backdraft on flange
region, change the F-50 tipping:
1. On directions, click on F-50.
2. Define the tipping of 0.00° on “Y”.
3
1
2
UT – R11
AutoForm Proprietary – Confidential
32
1. Activate Die Face to generate forming
geometries.
Generation of Forming
Geometries
Activation of Die Face Stage
Exercise 1
1
UT – R11
AutoForm Proprietary – Confidential
33
1. On “F-50” stage go to “Form” page
2. For both extruded holes define the
following settings
• Type: Wiper Flange
• Radius: 3.00mm
• Height: 20.00mm
• Width: 20.0mm
3. Click on Apply
Tool Creation in F-50
Wiper Flange Definition
Exercise 1 FormF-50
1
2
3
UT – R11
AutoForm Proprietary – Confidential
34
To connect the two parts, we have two options:
1. The user can choose to connect them on
the modify page , using “Double Fill” and
“fill holes”.
2. Or the user can connect them using two
addendums.
The user can decide which one to use. In this
example we will use the second option.
Drawing Tool Preparation
Connecting the two parts
Exercise 1 ModifyD-20
1 2
UT – R11
AutoForm Proprietary – Confidential
35
1. Click on “Fill Multiple Holes”
2. Click on “+” symbol.
3. Select the “Part Hole 3”
4. Click on Apply
Part Geometry Preparation
Fill Multiple Holes
Exercise 1 ModifyD-20
1
Detail : modification is planned in this corner
2
3
4
UT – R11
AutoForm Proprietary – Confidential
36
Use the outer fill module to prepare the part
geometry for the addendum generation.
1. Add the module Outer Fill – Manual.
2. Select the two boundaries of the corner.
3. Click on OK & Next.
4. Select the two boundaries of the other
corner.
5. Click on Ok.
6. Apply.
Part Geometry Preparation
Outer Fill
Exercise 1 ModifyD-20
1
2
3
5
4
UT – R11
AutoForm Proprietary – Confidential
37
Follow the next steps to create the extension
with the desired shape.
1. Click on add “Tangential Extension”.
2. Select the Part Boundary of the Small Part.
3. Click on “Ok”.
4. Select the “Variable” .
5. Click on Add Segments.
6. Select the segments as shown on image.
7. Click on OK.
8. Define the width of 20.00 mm.
9. Click on Apply.
Part Geometry Preparation
Extension Generation
Exercise 1 ModifyD-20
1
2
3
4
5
6
7
8
UT – R11
AutoForm Proprietary – Confidential
38
1. Create an Automatic binder surface.
2. Click on Add Curve.
3. Select the Hood inner boundary and Click
on “OK”.
4. Define the weight of “0.60”.
5. Click on apply.
Binder Generation
Profile Binder
Exercise 1 BinderD-20
1
2
3
4
5
1
UT – R11
AutoForm Proprietary – Confidential
39
1. Click on “plus” symbol.
2. Select the “part Hole 3”.
3. Click on “OK”.
4. Click on “Automatic”.
5. Click on Add curve.
6. Select the “part Hole 3”.
7. Deactivate the option “Single curved”.
8. Define the weight of “1.00”.
9. Click on Apply.
Binder Generation
Creation of the second Binder
Exercise 1 BinderD-20
1
2
3
4
5
6
7
8
9
UT – R11
AutoForm Proprietary – Confidential
40
Now it’s time for the addendum. At this point,
the user must create 3 addendums:
1. The first one to connect the edge of the
Hood inner to the Binder 1.
2. The second one to connect the Small Part
to Binder 2
3. And the third one to connect Binder 2 to
Part Hole 3
Ask the user to use addendum and second
modify to create a good shape of draw die.
Addendum Generation
Addendum on Form Region
Exercise 1 AddendumD-20
1
2
3
UT – R11
AutoForm Proprietary – Confidential
41
Die Face Stage
The trim options for curves defined in all Trim
modules have been renamed to Split Only, Keep
Outer and Keep Inner for closed curves […]
Trim Modification
Esssentials
Forming R10 Forming R11
Modify
UT – R11
AutoForm Proprietary – Confidential
42
Die Face Stage
[…] and to Split Only, Keep Larger and Keep
Smaller for open curves that completely cross
the boundary of the geometry to be trimmed.
Trim Modification
Esssentials
Forming R10 Forming R11
Modify
UT – R11
AutoForm Proprietary – Confidential
43
Die Face Stage
The Forming R11 version allows the definition of
multiple profiles for the geometry generation of
the Modify>Add Gainer module.
Once the module has been defined, it is possible
to create a multi-profile Gainerby defining
points along the defined base curve.
Select the Edit (1) button, at the bottom of the
Profile Parameters list to invoke the Edit Gainer
Parameters dialog and perform the following
actions:
• Add Point: Mouse button Ctrl+Click on the
base line (2)
• Delete Point: Select the point and press the
Del key
• Move Point: Drag and drop the point in the
3D view with the mouse button.
Gainer Improvements
Esssentials Modify
1
2
UT – R11
AutoForm Proprietary – Confidential
44
1. On Trimcheck page, click on Add Trimcheck.
2. Click on Apply
Trimcheck Analysis
Add Trimcheck
Exercise 1 TrimchkD-20
1
2
UT – R11
AutoForm Proprietary – Confidential
45
1. Click on Add Formcheck.
2. Click on Apply.
The Formcheck blank line will be used as
reference on Blank Stage.
With the measuring tools, check the length of
the blank.
Formcheck Analysis
Check Feasibility and Estimate Minimal
Blank Size
Exercise 1 FormchkD-20
1
2
UT – R11
AutoForm Proprietary – Confidential
46
1. Click on Create Flat Blank big button.
2. Select the option Copy From… for blank
outline.
3. Select Blank Outline – Formchk DieFace
and
4. Click on OK.
Blank Creation
Blank Outline
Exercise 1 Outline
1
2
3
4
UT – R11
AutoForm Proprietary – Confidential
47
Blank Creation
Embed/Nest
Exercise 1 Outline
1
2
3
4
1. Click on Embedding and Nesting on Coil.
2. Click on the parameters window.
3. Select None.
4. Select the option “Rectangle: Stepped”.
5. Click on the Variants for Embedding and
Nesting.
5
UT – R11
AutoForm Proprietary – Confidential
48
Process Stage
In the new version of the R11 software, there is
a new subdivision of the Process stage pages.
New pages segmentation
Esssentials
Forming R10 Forming R11
UT – R11
AutoForm Proprietary – Confidential
49
On PL page on Process Stage there are two
options for which type of friction model to use.
When you choose the TriboForm Friction a
tribology data set is loaded from the lubrication
file.
Tribology data sets can be generated using the
TriboForm Analyzer and describe the friction
and lubrication conditions for specific
combinations of sheet material, tooling material
and lubricants applied in sheet metal forming.
For this example use the TriboForm friction
model
1. On PL page select the TriboForm Friction
Model
2. On Lubrification condition choose the
option TF – Mild Steel (EG Coated)
Friction setting
TribForm plugin
Exercise 1 LubePL
1
2
UT – R11
AutoForm Proprietary – Confidential
50
Process Stage
• Are driven by the ram.
• Can change their direction during moving.
• By default all added cams are conventional
cams, to turn it into an aerial cam, it has to
be moved to the ram by drag-and-drop.
Limitation:
• Only rigid tools are allowed
• Only ram driven
Aerial Cam
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
51
Process Stage
Reorganized options:
• Start:
• Rigid Body Transformation
• Locating/Gravity
• End:
• Sheet Separation
• Tool Opening
• Free Springback
• Misc:
• Cutting Mode
• Scaling of Tools
• Bending Line
Operation Setup
Essentials
Forming R10 Forming R11
New
UT – R11
AutoForm Proprietary – Confidential
52
1. On D-20 setup, go to End and select the
option “Free Springback at End of
Operation”
Operation Setup
Free Springback at End of Operation
Exercise 1 SetupD-20
1
UT – R11
AutoForm Proprietary – Confidential
53
1. On D-20 setup, go to Misc and select the
option “Perform Scaling – For All tools of
this operation”
Operation Setup
Perform Scaling
Exercise 1 SetupD-20
1
UT – R11
AutoForm Proprietary – Confidential
54
Before Defining the binder force. Make sure the
tools surfaces are well defined.
On Binder, Define the force of 2500kN on
option Constant Force(1)(2).
Tool Setting
Binder Force
Exercise 1 ToolsD-20
1
2
Drawing Tools
UT – R11
AutoForm Proprietary – Confidential
55
Application Toolbar
• The visibility of all arrows display items can
be switched on (1) or off (2).
• It is always available; the state will be kept
on all stages and pages.
• The button in Geometry/Items was
removed.
Show/Hide All Directions
Essentials
2
1
Application Toolbar
New
UT – R11
AutoForm Proprietary – Confidential
56
The drawbead will be created as Profile Based
3D & Adaptive Line Bead.
1. Select the Profile Based 3D Bead model.
2. Choose Copy From… option for drawbead
curve.
3. Pick the Die Entry Curve of the first
Addendum.
4. Edit the curve.
5. On Modification, expand the curve by
“20.00 mm”.
6. Select round as profile type.
Process Setup
Drawbead Generation
Exercise 1 BeadsD-20
1
2
3
4
5
6
UT – R11
AutoForm Proprietary – Confidential
57
Definition of a Reduction Strategy
Create the reduction strategy for the drawbead.
1. Click on Define the Reduction Strategy.
2. Add a Parameter, choose bead height.
3. From 5mm to 0mm.
4. Click on Ok.
Setting Reduction Strategy
Exercise 1 BeadsD-20
2
3
4
1
UT – R11
AutoForm Proprietary – Confidential
58
Drawbead Setup
The segments can be defined based on the
determined local drawbead settings.
5. Select Edit Segments
6. Create Segments as shown on the image
Definition of the Drawbead Segments
Exercise 1 BeadsD-20
5
6
UT – R11
AutoForm Proprietary – Confidential
59
Definition of a Reduction Strategy
7. Set the following reduction state:
• Front – 0.6
• Sides – 0.7
• Back – 0.5
• Back corners – 0.0
8. Click on “Apply”.
Setting Reduction Strategy
Exercise 1 BeadsD-20
Result of Reduction Strategy
7
8
UT – R11
AutoForm Proprietary – Confidential
60
Forming R10 Forming R11
Evaluation
• Tool geometry consistent with geometry
sheet in case of flattening
• Note: Files needs to be recomputed for
Forming R11 to show the correct behavior
Handling of Drawbead flattening
Essentials
Drawbead missing in the tool
New
UT – R11
AutoForm Proprietary – Confidential
61
Process Stage
Following variants are now possible:
• Round bead on a step bead (1)
• Two step beads (2)
• And other combinations (3)
• Round bead can leave a step bead (4)
Drawbeads
Essentials
1
2
3
4
New
UT – R11
AutoForm Proprietary – Confidential
62
Process Stage
In the new version of the R11 software, there is
a new subdivision of the Process stage pages.
New pages segmentation
Esssentials BeadsD-20
UT – R11
AutoForm Proprietary – Confidential
63
1. On D-20, REF click on “Add Reference”
2. Click on Define.
3. Click on Imported.
4. Select “AF Hood Inner”.
5. Click on “Complete Geometry.
6. Select “Small Part”.
7. Click on “Complete Geometry”.
8. Click on Ok.
Reference Geometry
Definition of the Reference Geometry
Exercise 1 RefD-20
1
2
3
4
5
6
7
UT – R11
AutoForm Proprietary – Confidential
65
1. Go to Setup > Misc.
2. Select the “Cutting with Tools”.
3. Repeat the creation procedure of
Reference and Measure scenario.
Select the same settings for the operation T-40.
Operation Setup
Cutting Mode 1
2
Exercise 1 SetupT-30
UT – R11
AutoForm Proprietary – Confidential
66
1. Go to Process> T-50 > Setup >End.
2. Enable the sheet separation option.
3. Select “AF_hood_Inner” and press “Split
sheet” button.
4. The definition of sheet separation is now
completed.
This change will keep both parts at the end of
the operation F-50
Operation Setup
Sheet Separation 1
4
Exercise 1 F-50 Setup
2
3
UT – R11
AutoForm Proprietary – Confidential
67
After splitting the sheets, it is possible to create
measurement scenario and reference for each
sheet.
1. Go to F-50 REF.
2. Select the Sheet.
3. Click on “Add Reference Geometry”.
4. On Geometry Click on “Define…”.
5. Click on Imported.
6. Select “AF Hood Inner”.
7. Click on “Complete Geometry.
8. Click on Ok.
9. Repeat the procedure for “Sheet2” using
“Small part” as reference.
Reference Geometry
Defining the reference geometry
1
4
5
Exercise 1 F-50 Ref
2
3
9
6
7
8
UT – R11
AutoForm Proprietary –Confidential
68
Essentials – Measurement Scenarios
• Measurement Scenarios replace the Forming R10 measurement and inter OP measurement operations.
• At the end of each operation, several independent Measurement Scenarios can be defined. The results of the Measurement Scenarios are not used as
inputs for subsequent operations. This means that Measurement is no longer a part of the material flow in the press line.
Introduction
Inter OP
Measurement
Multiple Measurement
Operations
OP-40
Scenario 1
Scenario 2 Scenario 1
Scenario 1
Scenario 2
Scenario 3OP-30OP-20
UT – R11
AutoForm Proprietary – Confidential
69
Essentials – Measurement Scenarios
• Important: The base for a springback scenario computation is always the closed tool position (bottom dead center) in any case.
• Since springback measurement is no longer part of the press line, the measurement operation has been removed from the plan stage. Measurement
now appears as ‘Measure’ page at the process stage and the measurement definition is part of the operation from which it branches off.
Introduction
UT – R11
AutoForm Proprietary – Confidential
70
Essentials – Measurement Scenarios
• The new Measure page offers the familiar functionalities of the Forming R10 Measurement Operation, such as Real Measurement, Constrained
Springback, Fixed Boundary Condition, and Free Springback.
• The user can define as many Measurement Scenarios as desired per operation. One of these measurement scenarios must be set as the Default.
• At the Evaluation Stage, the results of the Default marked Measurement Scenario are preselected and displayed.
Set up pages
UT – R11
AutoForm Proprietary – Confidential
71
Essentials – Measurement Scenarios
• The results of the scenarios are part of the operation also. Since scenarios are not part of the main time line, they are specially indicated in the time
slider.
Time line
UT – R11
AutoForm Proprietary – Confidential
72
Essentials – Measurement Scenarios
Existing Measurement and Inter OP Measurement operations are automatically converted into Measurement Scenarios.
Attention: There is a different treatment of measurement OPs in AFF R10 and R11:
• In R10, the measurement operations were part of the material flow, so the results of the springback influence the subsequent operations.
• In R11, the measurement operations are converted into scenarios and attached to the previous operations. The scenarios are not part of the
material flow and therefore do not affect subsequent operations.
• If free springback should be part of the material flow, R11 offers the checkbox "Free Springback at End of Operation", as in R10.
Conversion of R10 files
D20 M30 T40 M50 …
D20
M30
T40
M50
…
D20 Free SBK T40 Free SBK …
R10
Converted
in R11
Free Springback
at End of
Operation
UT – R11
AutoForm Proprietary – Confidential
73
Essentials – Measurement Scenarios
• Additional Free Springback at Start of Scenario.
A common real use case is a Real Measurement operation with a
preceding Free Springback. In R11 this is taken into account per default
with the ‘additional free springback at start of scenario’ option.
• Restart option
A restart option to compute the scenarios of a certain single operation
is available as context menu.
Scenarios can be modified/added/removed in that restart job. Always
all scenarios will be computed.
Options
UT – R11
AutoForm Proprietary – Confidential
74
1. Click on “Add Measurement Scenario”
2. On “select sheet” select the “Sheet
3. Click on “Constraints”
4. On Constraints click on “Real
Measurement”
Measurement
Measurement scenarios
Exercise 1 MeasureF-50
1
2
3
4
UT – R11
AutoForm Proprietary – Confidential
75
Define the Pilots and Clamps.
Measurement
Real Measurement
Exercise 1 MeasureF-50
Pilots and Clamps of Sheet
UT – R11
AutoForm Proprietary – Confidential
76
1. Now add the measurement scenario for
“Small Part”
2. Click on “Add Measurement Scenario”
3. On Setup page, on select sheet field, select
the “Sheet 2”
4. On Constraints click on “Real
Measurement”
5. Define the Pilots and Clamps.
Measurement
Real Measurement
Exercise 1 MeasureF-50
Pilots and Clamps of Sheet 2
1
4
2
3
5
UT – R11
AutoForm Proprietary – Confidential
77
Simulation
1. On Simulation Stage > Control > Main >
Engineering Phase > Select “FV”.
2. On Control > Results > Select “All On”.
You can now start the Simulation.
Simulation Start and Reopen Results
Exercise 1 Start
1
2
UT – R11
AutoForm Proprietary – Confidential
78
Evaluation
• Tool listing in force page has become a
structure to easily switch visibility
• Weights have been moved out of the tool list
Improved forces page
Essentials
New
Forming R10Forming R11
UT – R11
AutoForm Proprietary – Confidential
79
Process Stage
With R11, is now possible to create a simple
surface that can be used as a surface guide.
It is no longer necessary to import constructed
surfaces.
Surface guides
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
80
New
Autoform Sigma
New Sigma variables for Pressure and Time in a
hydro-mechanical operation(1).
New Sigma variables for Bearing Areas (local
line modification, convex and expand
attributes)(2).
New Sigma Variables
Essentials
UT – R11
AutoForm Proprietary – Confidential
81
Autoform Sigma
• Forming R10 → Assembly R10:
*.asm-files with Sigma data has to be
exported again by this tool to be able to use
it in Assembly,
• Forming R11 → Assembly R11:
No separate Data Exporter required anymore
for Sigma *.asm-files
Preprocessing: Output for Assembly
Essentials
Forming R10 Forming R11
UT – R11
AutoForm Proprietary – Confidential
82
Autoform Sigma
Meanwhile the Realization Logfiles in the R10
were accessible after their calculation.
The realization Logfiles in the R11 are accessible
during their calculation.
Log Files
Essentials
Forming R10 Forming R11
New
UT – R11
AutoForm Proprietary – Confidential
83
Evaluation
Options material point labeling:
• Display Name
• Display Value
Improved material point labeling
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
84
Genral
New shortcut F8 automatically leads to
AutoForm HelpDesk.
• Quickly create a ticket.
• Fast exchange of data.
HelpDesk
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
Chapter 2
Elastic Tool Deflection (ETD)
Update Training
Process Engineering AutoForm R11
UT – R11
AutoForm Proprietary – Confidential
86
Chapter 2
• Task and Learning Targets
• Elastic Tool Deflection Study
• Main Focus
• Benefits and Definition simulating the Elastic Tool Deflection
• Solid Tool Preparation and Simulation setup
• Overcrowning
Objectives
UT – R11
AutoForm Proprietary – Confidential
87
Why consider elastic tool deflection?
1. Realistic: Elastic deformation of press and tool during closing
• Influence on forming process
2. Press Forces: Analysis of the influence on press forces
3. Forming result: Analysis of the influence on springback and draw-in
4. Overcrowning: Compensation by tool overcrowning
• Overcrowning strategies necessary
5. Multi-Blank: Elastic tool deflection with several blanks / tools on the press
Benefits:
• Reduce spotting time of Die and Punch of Drawing Operation
by accounting press and tool deflection.
• Provide an overcrowning function to get a compensated surface for milling.
Essentials - Motivation
Elastic tool deflection
Bolster
Draw Cushion
Ram
Die
Punch
UT – R11
AutoForm Proprietary – Confidential
88
The simulation of the elastic tool deflection follows the forming simulation
Essentials - Elastic tool deflection
Simulation
1. Forming Simulation 2. Calculation of the deflection 3. Result of the deflection
Linear-elastic Solver
UT – R11
AutoForm Proprietary – Confidential
89
In order to simulate the elastic deflection of the tools, the following input is required:
1. Tool surfaces
2. Tool solids (CADor AF Substructure Generator)
3. Press elasticity data
Essentials - Elastic tool deflection
Required simulation input
Option 1:
3D Substructure Generator
Option 2:
Tool Import
+ +
1
2
3
UT – R11
AutoForm Proprietary – Confidential
90
Elastic Tool Deflection
Make an analysis of the tool deflection in the
drawing operation of the hood inner part.
To do this, open the following backup file:
R11_UT_AF_HoodInner.afd
Base File
Chapter 2 D-20
UT – R11
AutoForm Proprietary – Confidential
91
Tool Solid
First, activate Tool Solids on the Process Stage.
• Add Solid object (1)
The three following fields need to be defined:
• Tool Surface (2)
• Tool Substructure + Elastic Material
Properties (3)
• Press Elasticity Data (4)
The summary of used Elasticity Data is shown
on Press Elasticity Data (5)
Elastic Tool Deflection
Essentials
New
Solids
1
2
3
4
5
UT – R11
AutoForm Proprietary – Confidential
92
Solid Tool Preparation - Punch
Let's create the solid tools for D-20.
On Process Stage, go to D-20 and go to page
Solids.
1. Click on Add Solid.
After this, start with the Punch setup:
2. On Solid field, rename the Solid into Punch.
3. On Tool Surface, click on Add Tool.
4. Select the Punch from the Tools of D-20 to
assign the tool surface to the solid.
5. Click on OK.
In this example the solid structure is not
available yet from the die design department,
but for these cases it is possible to create a
substructure inside the software.
Using this substructure, you can already get a
feeling about the amount of deflection.
Add a Solid tool
1 2
3
4
5
Chapter 2 SolidsD-20
UT – R11
AutoForm Proprietary – Confidential
93
Elastic Tool Deflection
This is used to create a substructure with
reinforcing ribs. Here the user can create a
rough 3D Tool which consists of the offset
surface, outer wall and inner ribs and an
extended surface.
Then the generator GUI looks as follows:
• Surface Thickness (1)
• Outer Wall (2) - Wall Height and Wall
Thickness
• Surface Extension (3) - Defined by a
Rectangle for x and y dimension, the Height
for the z dimension and the Thickness for the
surface.
• Reinforcing Grid (4) - Defined by the Spacing
between the ribs in x and y direction, the
Origin of the grid and the Thickness of the
ribs.
• Feature Ribs (5) - Single ribs can be defined
by using a curve and entering a thickness
value.
Tool Substructure Generator
Essentials
New
*Wall Height is measured from the lowest point
of surface boundary
1
2
3
4
5
Solids
UT – R11
AutoForm Proprietary – Confidential
94
Solid Tool Preparation - Punch
Now it’s time to define the Tool Substructure.
1. On Geometry click on Create…
2. On the new window, activate the Surface
Extension field, by checking Create.
3. Define the settings as shown in the picture.
4. Define the Rectangle of the Surface
Extension as shown in the picture.
Create Substructure Geometry
1
2
3
4
4
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
95
Solid Tool Preparation - Punch
Create an additional rib.
1. Activate Feature Ribs by checking Use.
2. Click on Add.
3. Create the additional Rib following the
picture.
4. After the creation of additional rib, click on
Calculate.
5. After calculation, click on OK.
Add a Solid tool
1
54
3
2
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
96
Elastic tool deflection
The Press Elasticity Model Generator is used to
create press elasticity substitution models for
the ram and bolster to calculate the deflection
of tools.
The Generator is in the Application Menu in the
Utilities section.
There are five fields to set the Elasticity Model:
• Model
• Geometry
• Material
• Force
• Deflection
Press Elasticity Model Generator
Essentials
New
1
2
3
4
5
Solids
UT – R11
AutoForm Proprietary – Confidential
97
Elastic tool deflection
There are two different ways to set up a model
depending on the complexity of the input:
• Basic
• Advanced
The Basic (1) mode represents a typical
procedure in press acceptance protocols where
a defined Force is applied on a Load Area
(usually 2/3 of the bolster) and the deflection is
measured.
Press Elasticity Model Generator
Essentials
New
1
Load Area
Measured deflection
F
Solids
UT – R11
AutoForm Proprietary – Confidential
98
Elastic tool deflection
The Advanced (2) mode can be used if more
measurements are available.
More measurements data can be gathered e.g.,
with a special tool called press finger print tool.
This tool has hydraulic cylinders which
introduce a force load onto the bolster and ram.
Multiple load cases can be applied by clicking on
the plus symbol (3).
Press Elasticity Model Generator
Essentials
New
2
3
Load Area
Measured deflection
F F
Solids
UT – R11
AutoForm Proprietary – Confidential
99
The solver uses this data to calibrate an internal elasticity model to fit the elastic properties of the press.
Essentials - Elastic tool deflection
Elasticity Model
UT – R11
AutoForm Proprietary – Confidential
100
Now its time to define the material of the
substructure:
1. On Tool Substructure Material click on
Import…
2. Select the material EN-GJL-250 from the
Elastic folder of the material database and
click on OK.
Forming R11 comes with two elastic material
cards for the 3D tools:
• EN-GJL-250 (Lamellar cast iron)
• EN-GJS-700-2 (Spheroidal cast iron)
Set the Elasticity Data of the Fixture Plate:
3. On Elasticity Data click on Import…
4. Select UT_ElasticityData_Bolster.afed from
training folder and click on OK.
Material and Elasticity Data
Solid Tool Preparation - Punch
1
4
3
2
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
101
Chapter 2 - Tool Preparation
Solid Punch
UT – R11
AutoForm Proprietary – Confidential
102
Solid Tool Preparation - Die
Now repeat the procedure for the D-20 Die.
1. Click on Add Solid.
Define the Die setup:
2. On Solid field, rename the new Solid into
Die.
3. On Tool Surfaces, click on Add Tool.
4. Select the Die to assign the tool surface to
the solid.
5. Click on OK.
Add a Solid tool
1
2
3
4
5
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
103
Solid Tool Preparation - Die
Define the Die substructure:
1. On Geometry click on Create…
2. On the new window, on the Surface
Extension field, click on Create.
3. Define the settings as shown on Image.
4. Define the Rectangle of the Surface
Extension as shown in the picture.
5. Click on Calculate.
6. Click on OK.
Create Substructure Geometry
1
2
3
65
4
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
104
Now its time to define the material of the
substructure:
1. On Tool Substructure Material click on
Import…
2. Select the material EN-GJL-250 from the
Elastic folder of the material database and
click on OK.
Set the Elasticity Data of the Fixture Plate:
3. On Elasticity Data click on Import…
4. Select UT_ElasticityData_Ram.afed from
training folder and click on OK.
Material and Elasticity Data
Solid Tool Preparation - Die
1
4
3
2
Chapter 2 D-20 Solids
UT – R11
AutoForm Proprietary – Confidential
105
Chapter 2 - Tool Preparation
Solid Die
UT – R11
AutoForm Proprietary – Confidential
106
StartChapter 2
The setup is ready for simulation.
1. Start the simulation.
(Backup File: R11_UT_AF_HoodInner_ETD.afd)
Start the simulation
Elastic Tool Deflection
D-20 Tool Solids
1
UT – R11
AutoForm Proprietary – Confidential
107
The ETD operation step returns its results by
means of a new tool result variable group called
"Tool Deflection".
This group contains the deflection values for the
three principal directions.
The result variables in the group can be
assessed from the Tool Results panel in the
ribbon.
1. Check the tool deflection in Z-direction and
set the scale form -1 mm to 1 mm.
Evaluation
Elastic Tool Deflection
1
Chapter2 D-20
UT – R11
AutoForm Proprietary – Confidential
108
2. Display the Tool Solids and do a section cut
to evaluate the deflection of the press.
3. To better visualize the elastic deflection,
you can define a scaling factor. Click on the
corresponding icon and set Scaling to 50.0.
4. In addition, switch on the original
geometries without deflection.
Evaluation
Elastic Tool Deflection
Chapter 2 D-20
2
3
4
UT – R11
AutoForm Proprietary – Confidential
109
Die and Punch are over-crowned separately.
Essentials - Overcrowning
Overcrowning strategies (1)
Ram
Die
Punch
Bolster
Under LoadLoad Free
Without overcrowning
Ram
Die
Punch
Bolster
With overcrowning
Under LoadLoad Free
Ram
Die
Punch
Bolster
Ram
Bolster
Punch
Die
Die deflection
Punch deflection
UT – R11
AutoForm Proprietary – Confidential
110
Only Die is over-crowned with Punch and Die deflections.
Essentials - Overcrowning
Overcrowning strategies (2)
Ram
Die
Punch
Bolster
Under LoadLoad Free
Without overcrowning
Ram
Die
Punch
Bolster
With overcrowning
Under LoadLoad Free
Ram
Punch
Bolster
Ram
Bolster
Punch
Die
Die over-crowning = I Die deflection I + I Punch deflection I
Die
UT – R11
AutoForm Proprietary – Confidential
111
In addition, the user can decide whether to compensate the sagging of the tool by means of overcrowning. The fixture plate deflection causes a
translation of the tool opposite to the working direction which we name “Tool Sag".
Essentials - Overcrowning
Sagging
Under Load
Overcrowning with Sagging
Ram
Die
Punch
Bolster
Sagging Sagging
Overcrowning without Sagging
UT – R11
AutoForm Proprietary – Confidential
112
In addition, the user can decide whether to compensate the sagging of the tool by means of overcrowning. The fixture plate deflection causes a
translation of the tool opposite to the working direction which we name “Tool Sag".
Essentials - Overcrowning
Sagging
Under Load
Ram
Die
Punch
Bolster
Overcrowning with Tool Sag
Tool Sag Tool Sag
Overcrowning without Tool Sag
UT – R11
AutoForm Proprietary – Confidential
113
ModifyChapter 2
In order to get a compensated surface for
milling the tool surface will be overcrowned in
the next steps.
1. Go to Modify on the Part Stage and click on
Overcorwning.
2. Select Die from the Tools.
3. Include Deflection of Opposite Side to
compensate both the punch and die
deflection on one surface.
4. Note that Tool Sag is activated by default.
5. Click on Apply.
Setup
Overcrowning
1
2
5
3
4
UT – R11
AutoForm Proprietary – Confidential
114
ModifyChapter 2
1. Display the Geometry and the
Overcrowning Amount to see the result.
It can be seen that the maximum deflection is
1.60 mm (including the sagging of the tool).
Result
Overcrowning
1
UT – R11
AutoForm Proprietary – Confidential
115
Chapter 2
Finally, the compensated tool surface can be
exported.
1. Go to the Application Menu and click on
Export… or use the shortcut Ctrl+E.
2. On the Compensation Tab the Format /
Type can be selected.
3. Finally, click on Export…
Export
Overcrowning
1
3
2
UT – R11
AutoForm Proprietary – Confidential
116
For the elastic tool deflection of Multi Blank Processes an overcrowning in the center of the press table would not have worked, because the maximum
deflection is not in the center. The combination of the new Elastic Tool Deflection and the Multi Blank feature, which will be discussed in the next chapter,
can solve this problem as well.
Essentials - Overcrowning
Off-center overcrowning
UT – R11
AutoForm Proprietary – Confidential
Chapter 3
Multi Blank
Update Training
Process Engineering AutoForm R11
UT – R11
AutoForm Proprietary – Confidential
118
Chapter 3
• Task and Learning Targets
• MultiBlank usecase
• Main Focus
• Combine two different works on two separate parts
• Analyze of the combined effect of using these tools together on the Press Table
Objectives
UT – R11
AutoForm Proprietary – Confidential
119
Advanced Max. Failure
1. Display the advanced Max Failure at the end
of D-20.
The advanced Max Failure is under 0.8 and the
process is safe in that regard.
First Investigation
Chapter 3 FormabilityD-20
UT – R11
AutoForm Proprietary – Confidential
120
Chapter 3
• Material
• HC300B
• Minimal tensile strength 446.9 MPa (N/mm²)
• Sheet thickness: 1.10 mm
Cross Member
443 mm
1
5
5
4
 m
m
HC300B
1.10 mm
UT – R11
AutoForm Proprietary – Confidential
121
Chapter 3
Hood Inner – Process plan Information
D-20
Single action
draw
T-30
Segmented
outer trim
T-40
Piercings with
cam
UT – R11
AutoForm Proprietary – Confidential
122
Chapter 3
Hood Inner – Process plan Information
F-50
Piercing
UT – R11
AutoForm Proprietary – Confidential
123
Advanced Max. Failure
1. Display the advanced Max Failure at the end
of D-20.
2. Check the wrinkles with the new Wrinkles
Highlighting.
The advanced Max Failure is just a little over 0.8
and the process is mainly safe in that regard.
First Investigation
Chapter 3 FormabilityD-20
UT – R11
AutoForm Proprietary – Confidential
124
Evaluation
• New option to highlight wrinkles
• Easier to find wrinkles for further
investigation
• Not a numerical indicator, meaning it can not
be used in combination with issues, sigma
etc.
Wrinkle Highlighting
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
125
Getting started
1. Create a New Design file.
2. Go to the application menu and select “New
Multi Blank”.
Open New Design
Chapter 3 Import
1
2
UT – R11
AutoForm Proprietary – Confidential
126
Getting started
3. Click on the big button ´”Import Design”.
4. Select both
“01_R11_UT_AF_CrossMemberV1_Simulati
on.afd” and
“06_R11_UT_AF_Hood_inner_Proposal_V6
_Simulation.afd” at the same time and press
OK.
In such a setup, most of the design file are
locked. No changes like material, blank, changes
are allowed.
Open New Design
Chapter 3 Import
3
4
UT – R11
AutoForm Proprietary – Confidential
127
Process Setup
1. Display the tools.
As you can see, the tools appear to be on top of
each other. The next step will be to reposition
the tools.
To do so, import a press table geometry.
Multi Blank
Chapter 3 Multi BlankD-20
1
UT – R11
AutoForm Proprietary – Confidential
128
Process Setup
1. Click on Import Tool Surface.
2. Select the geometry
R11_UT_PressTable.igs.
The press table will help to position the tools
and it will enable us to visualize the position of
the tools on the press. It has no effect on
simulation.
Multi Blank
Chapter 3
1
Import
2
UT – R11
AutoForm Proprietary – Confidential
129
Process Setup
1. Select the Hood inner.
2. Translate it in the X-Direction by -600mm
and in the Z-Direction by +200 mm.
3. Select the Cross Member.
4. Translate it in the X-Direction by +1000mm
and in the Z-Direction by +200 mm.
This position of the tools is roughly in the
middle of the press table.
This can be considered as the first guess of a
process engineer regarding tool positioning.
Parts Reposition
Chapter 3 Multi BlankD-20
1
2 3 4
UT – R11
AutoForm Proprietary – Confidential
130
Process Setup
There are 4 pin holes from both left and right
side.
1. Set the loading condition to columns.
2. Press the “+” symbol to define the column
positions.
Two columns in the middle of the press table
will be defined.
Binder Columns
Chapter 3 Multi BlankD-20
1
2
UT – R11
AutoForm Proprietary – Confidential
131
Process Setup
1. Define a first column center point with the
following coordinates: (-650,0,0).
2. Define a second column center point with
the following coordinates (950,0,0).
3. Define the force as 1800 kN for each of the
columns.
This force is the same as in the single
simulations.
Binder Columns
Chapter 3 Multi BlankD-20
1
3
2
UT – R11
AutoForm Proprietary – Confidential
132
Process Setup
1. Define both binders on Draw Cushion
(check the boxes).The setup is ready for simulation.
Draw Cushions
Chapter 3 Multi BlankD-20
1
UT – R11
AutoForm Proprietary – Confidential
133
Advanced Max. Failure
Open the file
01_R11_UT_MultiBlank_Simulation.afd
1. Display the advanced Max Failure at the end
of D-20.
Regarding the Advanced Max Failure, the
process is mainly safe for both blanks.
Multi Blank
Chapter 3 FormabilityD-20
UT – R11
AutoForm Proprietary – Confidential
134
Chapter 3
• Generation of a Multi Blank simulation
• Use of a Press Table
Objectives Achieved
UT – R11
AutoForm Proprietary – Confidential
Chapter 4
Thermal Effects
Update Training
Process Engineering AutoForm R11
UT – R11
AutoForm Proprietary – Confidential
136
Chapter 4
• Task and Learning Targets
• Check the effect of temperature increase during mass production (robustness of the production)
• Calculating the steady state tool and part temperatures
• Main Focus
• Thermal Analysis
• Part and Tool Temperatures
Objectives
UT – R11
AutoForm Proprietary – Confidential
137
Essentials - Motivation
In cold forming processes, both sheet and tools heat up due to plastic work in sheet and friction work.
This may lead to problems in production as lubrication and material properties are temperature dependent.
The formability of the part may be affected during production.
Effect of temperature increase during mass production
UT – R11
AutoForm Proprietary – Confidential
138
Essentials - Motivation
In R10 the gradual heating up of the tools over many cycles can be computed with the help of hot forming simulations, using the "real cycling" option.
However, this approach is not straightforward and has two drawbacks:
• 3D geometries of ribbed tools cannot be defined easily.
• CPU times are very high, since each new part is computed again with a fully coupled thermomechanical cycle.
Solution: Heating up of the 3D tools is approximated with a so called "smart ramp up" step.
Gradual heating up of tools
UT – R11
AutoForm Proprietary – Confidential
139
Essentials - Smart Ramp Up
1. One fully coupled thermomechanical cycle
• Thermal simulation of blank
• Thermal simulation of tools
• Mechanical simulation of blank
2. Memorize mechanical work and effective
heat transfer coefficients HTCeff
3. Further thermal simulation of tools only
• Estimation of target cycle’s tool temperature
4. Another fully coupled thermomechanical cycle
(optional)
Basic idea of the smart tool temperature ramp up
2D tool surface with analytical energy balance,
for each surface node
Tools with 3D FE temperature solution
Wmech
q(i)
Ttool
(i)
Tsheet
(i)
Ttool
(i+1)
q(i) = HTCeff (Tsheet
(i) - Ttool
(i))
UT – R11
AutoForm Proprietary – Confidential
140
Essentials - Cold Forming with Temperature Effects
With Cold Forming with Temperature Effects the temperature at the interface is taken as the average between the tool and sheet temperature
This temperature is used as input to calculate the friction coefficient when TriboForm friction is used.
Temperature effects on friction
Tool Temperature Sheet TemperatureInterface Temperature
Mean temperature
at the interface:
42.5 °C
25.0 ᵒC 60.0 ᵒC
UT – R11
AutoForm Proprietary – Confidential
141
Essentials - Cold Forming with Temperature Effects
Within TriboForm the friction coefficient depends on the contact pressure, strain in the sheet material, sliding velocity and temperature at the interface.
The interface temperature effects the viscosity of the lubricant (it becomes more liquid). Because the viscosity decreases, the load carrying capacity of the
lubricant decreases as well, meaning that more load is carried by sheet-tool contact. This normally leads to an increase of the friction coefficient, which
will be more visible under high sliding velocities.
In the figure it can be clearly seen that the friction coefficient (as function of contact pressure) increases for increasing temperatures.
Temperature effects on friction
UT – R11
AutoForm Proprietary – Confidential
142
Preliminary Steps
Open the file R11_UT_Front_Fender_Cold.afd.
1. Click on the temperature icon on the left
upper part of the toolbar.
2. Select the new use case “Cold Forming with
Temperature Effects”.
3. Press OK for the “Change Simulation Type”
Dialog.
4. Press OK for the “Replace Material” Dialog.
The material will not be changed.
This option is applicable to all cold forming
processes. This will ease the setup of the
simulation.
Cold Forming with Temperature Effects
Chapter 4
2
1
3
4
UT – R11
AutoForm Proprietary – Confidential
143
Essentials - Cold Forming with Temperature Effects
All standard cold and thermal materials are supported in cold forming with temperature with effects, including materials with phase transformation.
Note that in the last operation step that has a blank, the blank is instantaneously cooled down to its initial temperature. If the material has thermal strains
defined, this can lead to some distortion.
Supported material cards
UT – R11
AutoForm Proprietary – Confidential
144
PL Thermal
1. In the Thermal Stage of the Process Line,
select D-20 as the target Operation.
Cold Forming with Temperature Effects
Chapter 4
1
ThermalPL
UT – R11
AutoForm Proprietary – Confidential
145
Cold forming with temperature
effects
• Definition of target operation (1)
Simulation of gradual heating of tools
• for a stationary state (2)
• for a specific number of parts (3)
Optional:
• Calculation of another fully coupled
thermomechanical cycle (4)
Essentials ThermalPL
1
2
3
4
To
o
l T
e
m
p
er
at
u
re
 [
°C
]
Number of parts produced
Stationary
3
2
Estimated tool temperature
Input for Calculation of
another fully coupled
thermomechanical cycle
4
Definition on the PL Page
UT – R11
AutoForm Proprietary – Confidential
146
PL Thermal
1. In the Thermal Stage of D-20, select the Die.
2. Click on Apply.
3. Reiterate with the Punch and the Binder.
A surface mesh will be generated along every
“Apply”. It will be used afterwards as the basis
of 3D mesh of the tools.
Parameters like surface thickness or rib
thickness are used to calculate thermal
properties of the tool volume.
The simulation is ready to be calculated. A
backup file will be used for the rest of this
chapter.
Cold Forming with Temperature Effects
Chapter 4
2
ThermalD-20
1
3
UT – R11
AutoForm Proprietary – Confidential
147
Cold forming with temperature
effects
• Surface thickness with bulk material
properties (1)
• Additional ribbed height with effective
material properties (2)
• Rib thickness of the ribbing (3)
• Core Size of the ribbing (4)
Essentials ThermalPL
Definition of 3D heat conduction in ribbed
tools
1
2
3
4
Tool surface
(with contact to sheet)
Ground plate
(with fixed ambient temperature)
3
4
1
2
UT – R11
AutoForm Proprietary – Confidential
148
Thermal Results
1. Open the file
R11_UT_Front_Fender_Thermal.afd.
There are 2 cycles of the simulation:
D-20.01 and D-20.02.
The first cycle can be thought as the “first part
of the day.” Cold tools meet the first blank.
There is a “smart ramp up” step after the first
cycle. Here, the steady state working
temperature of the tools during mass
production will be automatically calculated.
In the second cycle, the part is produced with
the real tool temperatures in production. Since
the second cycle is the “real” solution, the focus
will be on the results of this cycle.
Cycles of Simulation
Chapter 4 D-20
1
UT – R11
AutoForm Proprietary – Confidential
149
Thermal Results
1. Display the Temperature at the End of
Drawing of D-20.02.
2. Set the scale from 20 °C to 100 °C.
The temperature of the part goes up to about
63 °C locally.
Part Temperature
Chapter 4 D-20
1 2
1
UT – R11
AutoForm Proprietary – Confidential
150
Thermal Results
1. Hide the Sheet and show the Die.
2. Display the Tool Temperature and set the
scale from 20 °C to 30 °C.
The temperatureof the tool goes up to about
29 °C locally.
Tool Temperature
Chapter 4 D-20
1
2
UT – R11
AutoForm Proprietary – Confidential
151
Thermal Results
1. Display the Simulation History at the End of
the Process.
2. Click on a spot of the Die where the
maximum temperature is to be seen.
Analyze:
• The first cycle is the “first part of the day”
• The “smart ramp up” is the jump between
the two cycles
• The second cycle shows the actual results
with steady state tool temperatures.
At the end of the diagram, the temperature
goes down during opening. It does not reach
the same temperature as in the beginning of
the cycle because “Waiting for Blank” step is
not calculated.
Simulation History
Chapter 4 D-20
2
1
UT – R11
AutoForm Proprietary – Confidential
152
Formability
1. Compare the files
R11_UT_Front_Fender_Cold.afd and
R11_UT_Front_Fender_Thermal.afd.
2. Display the Maximum Failure (Advanced) at
the End of Drawing for the Cold Simulation
and the first and last cycles of the Thermal
Simulation.
As can be seen, the Maximum Failure
(Advanced) increases when thermal effects are
taken into account. It increases even more with
higher tool temperature. Starting from a
feasible part, the simulation shows that due to
thermal effects splits will occur during mass
production.
Maximum Failure (Advanced)
Chapter 4 D-20
1
2
Cold Thermal - 1st cycle
Thermal - Steady State
UT – R11
AutoForm Proprietary – Confidential
153
Robustness
1. Open the file
R11_UT_Front_Fender_Cold_Robustness.afd
from the training files.
2. Display the Maximum Failure (Advanced) at
the End of Drawing and the Process
Capability Index Upper Cpk.
An extensive robustness analysis on the cold
simulation setup without considering
temperature effects in cold forming shows a
robust and reliable process. However, a single
simulation with thermal effects, showed the
exact opposite. Therefore, it is crucial to
consider thermal effects for friction sensitive
parts.
Maximum Failure (Advanced)
Chapter 4 D-20
1
2
2
UT – R11
AutoForm Proprietary – Confidential
154
Essentials - Cold Forming with Temperature Effects
Other part geometries such as wheelhouses can also react very sensitively to temperature effects in cold forming, as a lot of heat is generated due to the
high drawing depth.
In the figure can be seen that the tool temperature for an exemplary part goes up to about 55 °C.
Sensitive part geometries
UT – R11
AutoForm Proprietary – Confidential
Chapter 5
Multi Sheet
Update Training
Process Engineering AutoForm R11
UT – R11
AutoForm Proprietary – Confidential
156
Chapter 5
• Task and Learning Targets
• Multi-Sheet Analysis
• Main Focus
• Study of Formcheck on Multi-Sheet.
• Spring back analysis of multiple parts.
Objectives
UT – R11
AutoForm Proprietary – Confidential
157
Formability
Multi Sheet
Remember that in chapter 1, during the
simulation setup, the multi sheet was activated.
Now starts study of the applications of multi
sheet.
Run the full simulation or open the backup file :
07_R11_UT_AF_Hood_inner_Proposal_V6_Full_
Simulation.afd
Starting
Chapter 5 F-50
UT – R11
AutoForm Proprietary – Confidential
158
Formability
Multi Sheet
1. Go to the F-50 cutting
2. On View Options, activate the Sheet and
Sheet 2
3. On Evaluation Stage go to Advanced FLD
Formability
Chapter 5 F-50
1
2
3
UT – R11
AutoForm Proprietary – Confidential
159
Formability
Multi Sheet
The Advanced FLD shows the result of both
parts when Hood Inner and Small Part are
activated.
Formability – Both Parts
Chapter 5 F-50
UT – R11
AutoForm Proprietary – Confidential
160
Formability
Multi Sheet
But is also possible to show the result of just
one part.
Deactivate the Sheet 2 to check just the result of
Hood Inner
Formability – Hood Inner
Chapter 5 F-50
UT – R11
AutoForm Proprietary – Confidential
161
Formability
Multi Sheet
Invert the selection and show the result of the
Small Part
Formability – Small Part
Chapter 5 F-50
UT – R11
AutoForm Proprietary – Confidential
162
Formability
Multi Sheet
Now its time to check the Springback
1. On View Options, activate the Sheet and
Sheet 2
2. Go to Evaluation Stage
3. Go to Springback on F-50
4. Click on Distance from Reference on normal
Dir.
See that the two measurement scenarios that
were defined in chapter one are available for
analysis in the springback page.
5. Check the springback results for both parts.
Formability
Chapter 5 F-50
1
2
3
4
5
UT – R11
AutoForm Proprietary – Confidential
163
Charpter 5 – Multi sheet
Distance from Reference on normal Dir
Measurement Scenario 1
UT – R11
AutoForm Proprietary – Confidential
164
Charpter 5 – Multi sheet
Distance from Reference on normal Dir
Measurement Scenario 2
UT – R11
AutoForm Proprietary – Confidential
165
Formability
Multi Sheet
These springback results can be used together
for part compensation.
The image shows the compensation vector field
of two pieces that will be used in the first
compensation loop.
Formability
Chapter 5 F-50
UT – R11
AutoForm Proprietary – Confidential
166
Postprocessing
Multiple Sheets are fully supported by Sigma
including Draw In. However, we are aware of
release-blocking bugs to be resolved during the
alpha/test phase.
Limitation: Skid Lines are not testable with
Multiple Sheets and will most likely not be
supported in R11.
Support of multiple sheets on
Resolve page
Essentials
New
UT – R11
AutoForm Proprietary – Confidential
Chapter 6
Die Face Quality Design
Update Training
Process Engineering AutoForm R11
UT – R11
AutoForm Proprietary – Confidential
168
Chapter 6
• Task and Learning Targets
• DieDesigner Plus first steps
• Main Focus
• Introduction of AutoForm SMART Design Workflow
• Concept Geometry Generation
Objectives
UT – R11
AutoForm Proprietary – Confidential
169
Exercise 6
Integration of Stamping and BiW assembly Process Chains
UT – R11
AutoForm Proprietary – Confidential
170
Exercise 6
AutoForm SMART Design Workflow
UT – R11
AutoForm Proprietary – Confidential
171
Exercise 6
Tailgate Outer
UT – R11
AutoForm Proprietary – Confidential
172
Die Face Quality Design
1. Open the Design File AF-Tailgate Outer_Full
Stamping Process_Process Design II-
S0_Start.afd
Concept Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
173
Die Face Quality Design
1. Go to DieFace stage -> D20 -> Addendum
2. Check geometry with Curve & Surfaces
Analysis
Concept Geometry
Exercise 6
2
1
UT – R11
AutoForm Proprietary – Confidential
174
Die Face Quality Design
1. Go to DieFace stage -> D20 -> Addendum
2. Check geometry with Curve & Surfaces
Analysis
Concept Geometry
Exercise 6
2
1
2
UT – R11
AutoForm Proprietary – Confidential
175
Die Face Quality Design
1. Check Gaps between faces (G0)
Concept Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
176
Die Face Quality Design
1. Check Angle between Faces (G1)
2. Switch on Label values out of range
Concept Geometry
Exercise 6
1
2
UT – R11
AutoForm Proprietary – Confidential
177
Die Face Quality Design
1. Check Curvature Types
Concept Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
178
Die Face Quality Design
1. Activate the diamond to change the
environment from Concept to Quality
Geometry.
2. The diamond displayed on Part Stage and
DieFace Stage indicates the availability of
DieDesigner Plus on that level.
3. Go to Part Stage > Import Page. Switch on
Curve & Surface Analysis and check
“Modifications at Import to Repair
Gaps/Overlaps”. The imported Part
geometry is not healed anymore! The
imported shape remains unchanged
according to the standard requirements in
CAD. This is the first significant difference
between CG and QG.
Quality Geometry
Exercise 6
1
2
3
3
UT – R11
AutoForm Proprietary – Confidential
179
Die Face Quality Design
1. Goto Plan Stage > Plan and check Process
Plan. The Plan stage and thus the Process
setup is shared by Concept Geometry &
Quality Geometry. No action is needed.
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
180
Die Face Quality Design
1. Open the Design File AF-Tailgate Outer_Full
Stamping Process_Process Design II-
S8_Addendum_Exercise.afd and go to
DieFace Stage F-60.
2. Based on the Concept Form steel of F-60, F-
50 and F-40 coming from DieDesigner
Quality Forms were already generated in
this file. These Quality Forms are
automatically forwarded to the Process
Stage.
3. Go to T-30. Tool geometries are also
automatically forwarded to the Process
Stage.
Quality Geometry
Exercise 6
2 3
UT – R11
AutoForm Proprietary – Confidential
181
Die Face Quality Design
1. Go to D-20 and the workflow to generate
the tool geometries pops up - we simply
follow the steps from left to right.
2. Tip: Nothing to do.
3. Modify: Modify is used to prepare the Part
geometry for the Draw process, for example
Fill all Part holes. With Fill Multiple Holes all
holes automatically filled by using native
faces if possible or a fill surface if the hole is
too complex. This was already done in the
file. You can check the quality by using the
Curve & Surface Analysis.
4. Binder: Display the Concept binder. This
was used as reference for the Quality
Binder. The Quality Binder was already
created in this file.
Quality Geometry
Exercise 6
3 4
UT – R11
AutoForm Proprietary – Confidential
182
Die Face Quality Design
1. Go to the Quality Die Page. The design
workflow with the tabs
Support/Boundary/Wall/Addendum and
Die appears. Support is used to create
additional, independent surfaces. Boundary
is used to generate Part extension surfaces.
Wall is used to create a wall ring.
Addendum is used to create a connection
between Boundary and Wall. Die is used to
create the final Die surface. Everything is
already prepared in the file except two
segment.
2. Click on the line to create a fillet between
Wall and Boundary.
3. Click on Fillet.
Quality Geometry
Exercise 6
1
2
3
UT – R11
AutoForm Proprietary – Confidential
183
Die Face Quality Design
1. Two faces are automatically provided by the
software; these are Input Boundary and
Input Wall.
2. Invert the vectors for the Fillet by clicking
with the RMB on the vector.
3. Define the Fillet geometrie.
4. Press Apply. The segment is complete. The
fillet is using the radii of the neighboring
fillets.
Quality Geometry
Exercise 6
1
2
3
4
UT – R11
AutoForm Proprietary – Confidential
184
Die Face Quality Design
1. Activate the line on the left side for the
remaining segment.
2. Due to a self symmetric design the result of
the right segment is mirrored to the left one
by clicking on Apply.
3. Click on Finish at the end and press Apply
to generate the final result. The punch is
complete now.
Quality Geometry
Exercise 6
1
2
3
UT – R11
AutoForm Proprietary – Confidential
185
Die Face Quality Design
1. Punch construction is complete.
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
186
Die Face Quality Design
1. Use the Die radius module to bring Punch
and Binder surface together to create the
final Die Surface. Click on Add Die Radius.
2. Pick curve: Part Boundary OK
3. Choose a Die radius of 6mm and press
Apply.
Quality Geometry
Exercise 6
1
2
3
UT – R11
AutoForm Proprietary – Confidential
187
Die Face Quality Design
1. Die construction is complete.
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
188
Die Face Quality Design
1. Check Gaps between faces (G0)
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
189
Die Face Quality Design
1. Check Angle between Faces (G1)
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
190
Die Face Quality Design
1. Check Curvature Types
Quality Geometry
Exercise 6
1
UT – R11
AutoForm Proprietary – Confidential
191
Exercise 6
AutoForm-DieDesigner Plus Benefits
Integrated
• Integrated within AutoForm-Forming – Digital workflow can be further improved
• No other software platform needed
• All processing information is contained in same file – seamless and effortless communication
Intuitive
• Defined methodology (step by step) for surface creation
• No additional management of features or Organization
• Specific features for stamping process design
• No file translation for simulation workflow
Efficient
• Quick to learn/use features – no CAD specific knowledge required
• Manufacturing relative tolerances = more efficient
• Concept Design Reference – Visual reference can be used. Don`t redesign from scratch
• Faster than traditional CAD
• Associativity – Part design changes can be applied
UT – R11
AutoForm Proprietary – Confidential
© 2023 AutoForm Engineering GmbH, Switzerland.
"AutoForm" and other trademarks listed under www.autoform.com or trade
names contained in this documentation or the Software are trademarks or
registered trademarks of AutoForm Engineering GmbH. Third party
trademarks, trade names, product names and logos may be the trademarks or
registered trademarks of their respective owners. AutoForm Engineering
GmbH owns and practices various patents and patent applications that are
listed on its website www.autoform.com. Software and specifications may be
subject to change without notice.
AutoForm Offices
Switzerland Wilen b. Wollerau +41 43 444 61 61
Germany Dortmund +49 231 9742 320
The Netherlands Capelle a/d Ijssel +31 180 668 255
France Aix-en-Provence +33 4 42 90 42 60
Spain Barcelona +34 93 320 84 22
Italy Turin +39 011 620 41 11
USA Troy, MI +1 888 428 8636
Mexico Corregidora, Qro. +52 442 225 1104
Brazil São Bernardo do Campo +55 11 4121 1644
India Hyderabad +91 40 4068 9999
China Hongkong +85 2 2546 9069
Japan Tokyo +81 3 6459 0881
Korea Seoul +82 2 2113 0770
Czech Republic Prague +420 221 228 481
	Default Section
	Slide 1: Process Engineering AutoForm R11
	Slide 2
	Slide 3: Update Training – Process Engineering
	Slide 4: Chapter 1 Simulation Setup
	Slide 5: Chapter 1
	Slide 6: Chapter 1
	Slide 7: Chapter 1
	Slide 8: Chapter 1
	Slide 9: Chapter 1
	Slide 10: General
	Slide 11: 3D View
	Slide 12: Part Stage
	Slide 13: Part Stage
	Slide 14: Application Toolbar
	Slide 15: Application Toolbar
	Slide 16: Application Toolbar
	Slide 17: Application Toolbar
	Slide 18: Application Toolbar
	Slide 19: Application Toolbar
	Slide 20: Application Toolbar
	Slide 21: Application Toolbar
	Slide 22: Part Stage
	Slide 23: Part Stage
	Slide 24: Part Stage
	Slide 26: Material Card
	Slide 27: Plan Stage
	Slide 28: Defining the process units
	Slide 29: Trim Plan
	Slide 30: Trim Plan
	Slide 31: Plan Stage
	Slide 32: Generation of Forming Geometries
	Slide 33: Tool Creation in F-50
	Slide 34: Drawing Tool Preparation
	Slide 35: Part Geometry Preparation
	Slide 36: Part Geometry Preparation
	Slide 37: Part Geometry Preparation
	Slide 38: Binder Generation
	Slide 39: Binder Generation
	Slide 40: Addendum Generation
	Slide 41: Die Face Stage
	Slide 42: Die Face Stage
	Slide 43: Die Face Stage
	Slide 44: Trimcheck Analysis
	Slide 45: Formcheck Analysis
	Slide 46: Blank Creation
	Slide 47: Blank Creation
	Slide 48: Process Stage
	Slide 49: Friction setting
	Slide 50: Process Stage
	Slide 51: Process Stage
	Slide 52: Operation Setup
	Slide 53: Operation Setup
	Slide 54: Tool Setting
	Slide 55: Application Toolbar
	Slide 56: Process Setup
	Slide 57: Definition of a Reduction Strategy
	Slide 58: Drawbead Setup
	Slide 59: Definition of a Reduction Strategy
	Slide 60: Evaluation
	Slide 61: Process Stage
	Slide 62: Process Stage
	Slide 63: Reference Geometry
	Slide 65: Operation Setup
	Slide 66: Operation Setup
	Slide 67: Reference Geometry
	Slide 68: Essentials – Measurement Scenarios
	Slide 69: Essentials – Measurement Scenarios
	Slide 70: Essentials
