Exercise
Base Training
Planning & Bidding I
PB I – R8
AutoForm Proprietary – Confidential
4
Exercise: Sidemember - Transfer Press
• Definition of a symmetrical setup and a mirrored part
• Identification of issues on Formcheck page and application of suitable countermeasures
• Refinement of Tooling and Die Set settings
Objectives
PB I – R8
AutoForm Proprietary – Confidential
5
Exercise: Sidemember - Transfer Press
• Part Data: SIDEMEMBER.CATPart
Part Information and Required Data
3
1
 m
m
View from x
View from z
1
3
0
 m
m
459 mm
HC180B
1.50 mm
PB I – R8
AutoForm Proprietary – Confidential
6
Getting started
1. Import Part SIDEMEMBER.CATPart.
2. Select afterwards the reference side and
3. Extract the surface.
Import Part Geometry
Exercise Import
1
Reference
Side
2
3
PB I – R8
AutoForm Proprietary – Confidential
7
The Automatic Tipping can be calculated by
reference to selected surface patches.
1. Select two surface patches as tipping
reference and
2. Click on Automatic Tipping.
The Tip Angle has to be modified manually to
allow a suitable drawing process.
3. Go to Tip Angle tab and
4. Rotate the part by 180 ° around current Y
axis.
Tipping the Part Data
Automatic Tipping
Exercise Tip
2
1
Reference
Patches
3
4
Rotation
Amount
PB I – R8
AutoForm Proprietary – Confidential
8
1. Click on Half Input, Double Attached,
Symmetrical to define a symmetrical setup
2. Open the Symmetry Plane Editor and
3. Decrease Offset to Symmetry Plane.
Create a Mirrored Part
Use a Symmetry Plane
Exercise Import
1
2
3
PB I – R8
AutoForm Proprietary – Confidential
9
Due to the new setup a new center of die has to
be defined.
1. Click on Modify Center of Die.
Tipping the Part Data
Center of Die Definition
Exercise Tip
Center of
Die
1
PB I – R8
AutoForm Proprietary – Confidential
10
1. Select a HC180B material from the
AutoForm material database. The thickness
is defined automatically from the solid
import geometry.
Define Blank Material
Assign Material
Exercise Material
1
PB I – R8
AutoForm Proprietary – Confidential
11
To separate drawing areas from secondary
forming areas it might be necessary to trim
surface patches. It will simplify the definition of
forming areas.
1. Add a Trim module.
2. Add a trim curve and separate the flange.
Apply the modification afterwards.
Part Preparation
Adding a Trim Curve
Exercise Modify
Detail
Detail view: added trim curve
1
1
PB I – R8
AutoForm Proprietary – Confidential
12
Before calculating the Formcheck analysis the
part has to be prepared. Areas for secondary
forming operations should be defined to
exclude them from the analysis.
1. Click on Draw Parts.
2. Select all flanges and patches of extruded
holes.
3. Add these patches to Secondary Forming
register.
4. Generate a Boundary Fill with 200 mm Roll
Radius.
5. Generate a Double Fill and apply the
generation. Edit the double fill afterwards.
Note: Double fill modifications are accessible via
context menu or double click on corresponding
spines.
Formability Analysis
Exercise Formchk
Indication of Critical Part Areas
1
2
3
4
5
Double Fill between the parts
PB I – R8
AutoForm Proprietary – Confidential
13
6. Generate a Binder and reduce the Draw-In
Reserve.
The Draw-In Reserve defines the amount of
material that is assumed to stay on the binder
surface after drawing and, as such, the
estimated blank outline will be affected by this
parameter.
7. Generate an Addendum via Geometric
method and apply the generation.
8. An error message occurs stating that
Development fails at 1 flange (see next
slide).
Formability Analysis
Exercise Formchk
Indication of Critical Part Areas
6
7
8
PB I – R8
AutoForm Proprietary – Confidential
14
The error message shows, that one extruded
hole could not be developed.
1. The reason for that is an embossed radius
which is designed into the CAD-surface. An
offset of 1.5mm is not possible for a radius
of 1mm.
2. The development will not be further
considered for Formcheck. When defining
the process plan, the radius embossment
has to be considered.
3. Go to the Develop Part tab and start the
Formcheck analysis.
4. Increase the Outer Holding Condition to 0.2.
This is a meaningful compromise between
sufficient strain and little potential splits.
Formability Analysis
Exercise Formchk
Indication of Critical Part Areas
3
4
1
PB I – R8
AutoForm Proprietary – Confidential
15
Basically there exists a critical part area, that
shows a risk of splits even for a minor outer
holding condition (0.2).
The production of the part will not be feasible,
so that the critical area has to be modified
before developing the process in detail. For a
first estimation of countermeasures and their
effect the tools of the modify page are helpful.
Formability Analysis
Exercise Formchk
Indication of Critical Part Areas
Detail
Detail : Critical part area
PB I – R8
AutoForm Proprietary – Confidential
16
Formability Analysis
As a first optimization step, a segmentation of
the Outer Holding Condition will be performed
to avoid potential splits.
• Segmentation with Variable Holding
Condition
• Realistic representation of outer holding
in an early phase.
• Approximation of minimal blank size with
an adjusted Outer Holding Condition
value of 0.2 for the segmented holding
condition.
• Calculated forces of the Variable Holding
Condition will be passed on to Plan-Stage.
1. Define proper segments in order to
decrease potential splits.
Segmentation of Outer Holding Condition
Exercise Formchk
1
PB I – R8
AutoForm Proprietary – Confidential
17
Formability Analysis
1. Define the Segment 2 with Holding
Condition „Free“.
2. Click Apply to recalculate the formability
result.
Using Variable Holding Conditions leads to a
slight improvement in regards of potential
splits.
To eliminate potential splits completely, a
Preform will be added. This Preform will be used
for the drawing operation while the final
geometry will be formed in a following forming
operation.
Segmentation of Outer Holding Condition
Exercise Formchk
1
before after
PB I – R8
AutoForm Proprietary – Confidential
18
To smoothen the identified critical area, a
Preform will be added.
1. Add a Preform.
2. Click on Input and selectsurface patches
according to the picture on the right.
3. Assign those by clicking on In.
4. Since the curve is located on the lower
radius, click on Swap.
5. Move the control points in the straight area
of the radius.
Part modification
Adding a Preform
Exercise Modify
1
2
5
PB I – R8
AutoForm Proprietary – Confidential
19
1. Change the Part Radius and Height Radius
to 2.5mm which fits to the existing part
radius.
2. Reduce theWall Radius to 4mm.
3. Set the Total Width to Min Width.
4. Confirm your inputs by clicking on Apply.
Part modification
Adding a Preform
Exercise Modify
1
2
3
PB I – R8
AutoForm Proprietary – Confidential
20
1. Repeat the Formcheck analysis including the
part modification and check the results. If
the results are not sufficient, edit the
Preform and start a new analysis.
The determined part modification can be
directly taken as recommendation for the
customer.
Formability Analysis
Exercise Formchk
Validation of Part Modification
Detail : Improved critical part area
Detail
1
PB I – R8
AutoForm Proprietary – Confidential
21
In this exercise a predefined press will be used.
1. Click on Create Plan with Custom Press.
Open Transfer Press 11000kN.zip from
training directory.
2. Check the Basic Properties in the Press
Preview. Consider parameters like Bed
Length or Ram Tonnage when defining the
process plan.
Plan Stage
Create Plan
Exercise
1
Production
2
PB I – R8
AutoForm Proprietary – Confidential
22
3. Check the detected features on Plan page.
Some features are missing. In addition,
there are not enough operations for the
amount of features.
4. Go back to Production page and add a Form
Trim operation.
Plan Stage
Create Plan
Exercise PlanProduction
3
4
PB I – R8
AutoForm Proprietary – Confidential
23
1. Get an overview of the detected features
and their assignment to the operations. The
automatically created plan will be modified
in the next steps.
2. Edit the Trim Plan. The option is accessible
via context menu.
Process Plan
Feature Assignment
Exercise Plan
2
PB I – R8
AutoForm Proprietary – Confidential
24
3. Define trim segments. The part separation
is assigned to the last operation.
4. Assign hole piercing to F-50.
Process Plan
Feature Assignment
Exercise Plan
3 4
PB I – R8
AutoForm Proprietary – Confidential
25
5. Assign flanging features to F-60.
6. Assign extruded holes to F-60.
Process Plan
Feature Assignment
Exercise Plan
5 6
PB I – R8
AutoForm Proprietary – Confidential
26
7. Add the missing flange as new feature and
assign it to F-60.
8. The radius embossment (see result from
Formcheck) is represented by a second
Processing Unit.
9. Add a second PU “Extruding Up” to F-60.
10. The Preform also has to be formed to match
the imported CAD geometry.
11. Add a Form Region and assign it to F-70.
Process Plan
Feature Assignment
Exercise Plan
7
9
11
PB I – R8
AutoForm Proprietary – Confidential
27
1. To smoothen the process plan, add another
Form / Trim operation.
2. Subsequently, evenly distribute the
Processing Units.
3. The final process plan is shown on the right.
Process Plan
Process Plan
Exercise Plan
PB I – R8
AutoForm Proprietary – Confidential
28
Sharing Die Sets means that certain components
(Die Set Components) are shared between the
affected operations. The consequence is that
the amount and the size of those components
are not derived from the size of the operation
any more but from the total size of all
operations that participate in the sharing.
A click between two operations activates die set
sharing.
1. Share the die set of T-30, T-40 and F-50.
2. Share the die set of F-60, F-70 and F-80.
Advanced Settings
Shared Die Sets
Exercise Production
1 2
PB I – R8
AutoForm Proprietary – Confidential
29
1. Select D-20 and
2. Edit Tooling Settings.
3. Set Height to 600 mm.
4. Apply Tooling Size afterwards to adopt
height modification to other operations.
Advanced Settings
Modification of Tooling Settings
Exercise Production
1
2
4
3
PB I – R8
AutoForm Proprietary – Confidential
30
1. Select B-10 and
2. Edit Die Set Settings.
3. Set Height to 600 mm.
4. Edit the die set height also for the two
remaining die sets.
Advanced Settings
Modification of Die Set Settings
Exercise Production
3
1
2
PB I – R8
AutoForm Proprietary – Confidential
31
1. Click on Create Flat Blank.
2. Choose Copy From… and select the Blank
Outline from the Formcheck.
3. The defined blank represents the minimal
shaped blank. It will further be embedded
in a ruled geometry.
Blank
Blank Definition
Exercise Outline
1
2
Generated Blank Outline
3
PB I – R8
AutoForm Proprietary – Confidential
32
1. Click on Nesting and Embedding to embed
the shaped blank in a minimal rectangular
blank.
2. Add a variant Embed: Rectangle: Stepped.
3. Since the utilization is nearly identical, the
variant Embed: Rectangle will be used for
further planning.
Blank
Blank Definition
Exercise Embed/Nest
1
2
Embedded Blank Outline
3
PB I – R8
AutoForm Proprietary – Confidential
33
1. Add Tooling.
2. Add Piece Cost.
Each category contains a set of input values and
a set of cost result values specific for that
particular category. Input values are either
taken from other modules or categories within
the Piece Cost. Others are just default values
that can be adapted manually or within the
Piece Cost standard.
The categories will be introduced in the
following slides.
3. Export calculated piece cost to a CSV file.
Tooling Cost and Piece Cost
Calculation
Exercise Tooling Piece Cost
1 2
PB I – R8
AutoForm Proprietary – Confidential
34
Piece Cost
Tool and Maintenance Cost (1)
• Part Material: Informational value set within
Part / Material page regarding the material
type.
• Tooling Cost: Total cost of the dies
(Engineering, CNC machining, Die making,
Die try-out and the Tool material costs).
When the tooling costs are available on Plan
/ Tooling, Total Tooling Cost value is taken
automatically into Piece Cost, otherwise -
manual input is necessary.
• Maintenance Parameters: maximum possible
number of strokes before necessary tool
maintenance and percentage of the total
tooling cost and defines the cost of one
maintenance cycle (new gas springs, re-
coating, die cleaning…).
Input Values
Essentials Piece Cost
1
PB I – R8
AutoForm Proprietary – Confidential
35
Piece Cost
Blank Material Cost (2)
• Utilization Factor presents the percentage of
coil material that is used solely for the part
production. This value is taken from the
Blank stage; if no blank is available, default
value of 70 % is set.
• Coil Weight per Blank is estimated coil
weight necessary for one blank. It is
calculated based on the part weight and
given Utilization Factor.
Input Values
Essentials Piece Cost
2
PB I – R8
AutoForm Proprietary – Confidential
36
Piece Cost
Production Line Cost (3)
• Press Hourly Cost is derived from the loaded
press.
• Press and Operation Downtime represents
the percentage of downtime for press line
service and maintenance
• Used Stroke Rate is set in respect to Press
Min and Max stroke rate
• Strokes per Run has the default value of
5000. The default value can be changed
directly in the GUI or within Process Plan
Standard.
• Forming Issues Downtime per Run is the
estimated downtime due the forming issues
during one run.
Input Values
Essentials Piece Cost
3
PB I – R8
AutoForm Proprietary – Confidential
37
Piece Cost
Rework Cost (4)
• Rework Cost per Part describes the cost for
the necessary rework process(es) for one
part.
• Quality Rework Rate represents the
percentage of parts of the Total Production
Volume that needs to be reworked. The
default value depends on the Robustness
Level : an increasing Robustness Level leads
to a decreasing rework rate.
Input Values
Essentials Piece Cost
4
PB I – R8
AutoForm Proprietary– Confidential
38
Piece Cost
Shipping Cost (5)
• Fixed Cost per Batch describes shipping cost
that occurs for each batch of produced parts.
• Variable Cost per Tonne contains the
shipping cost for each tonne of produced
parts.
• Strokes per Batch represents the number of
strokes that are "shipped" within one batch.
Note that with one stroke there could be
more than one part exiting the production
line and therefore the number of strokes per
batch can be smaller than the number of
parts per batch.
• Part Weight is calculated based on the part
area and the material density. Taken from
Part / Formcheck or Blank stages if available
(considering thinning in these cases).
Input Values
Essentials Piece Cost
5
PB I – R8
AutoForm Proprietary – Confidential
39
1. Go to Forces tab and
2. Calculate Approximate Form Forces per
Operation.
Besides the forces per operation also the total
force is calculated. The initially selected press
(11000 kN) is oversized.
Forces
Calculation
Exercise Plan
1
2
PB I – R8
AutoForm Proprietary – Confidential
40
1. Drag the Custom Press icon and drop it onto
the existing production line to replace the
initially selected press.
2. Select the Transfer Press 6300 kN. It has
sufficient ram tonnage.
Production Line Modification
Press Replacement
Exercise Production
1
PB I – R8
AutoForm Proprietary – Confidential
41
3. Go to Operation tab and
4. Check the warning messages.
An overlap was detected. Therefore the pitch or
the tool length has to be modified. Consider
also the bed length when modifying these
values.
5. Go back to Production Line tab and
6. Increase the Pitch to 500mm.
Production Line Modification
Press Replacement
Exercise Production
3
6
5
4
PB I – R8
AutoForm Proprietary – Confidential
42
Check, if the new pitch corresponds to tool size
and die set length.
7. Set Tooling Length to 500 mm. Apply it also
to other tools.
8. Set the Die Set Length to 1500 mm.
Production Line Modification
Press Replacement
Exercise Production
PB I – R8
AutoForm Proprietary – Confidential
43
1. Check the new calculated piece cost. Due to
a reduction of the Production Line cost the
total cost per piece is dropped.
Piece Cost
Calculation
Exercise Piece Cost
1
PB I – R8
AutoForm Proprietary – Confidential
44
Exercise: Sidemember - Transfer Press
• Using a symmetry plane to create a mirrored setup
• Improving Formcheck results via details on modify page
• Defining a detailed process plan setup
• Calculation of costs considering advanced settings
• Replacement of a press
Objectives Achieved
AutoForm Proprietary – Confidential
© 2019 AutoForm Engineering GmbH, Switzerland.
"AutoForm" and other trademarks listed under www.autoform.com or trade
names contained in this documentation or the Software are trademarks or
registered trademarks of AutoForm Engineering GmbH. Third party
trademarks, trade names, product names and logos may be the trademarks or
registered trademarks of their respective owners. AutoForm Engineering
GmbH owns and practices various patents and patent applications that are
listed on its website www.autoform.com. Software and specifications may be
subject to change without notice.
AutoForm Offices
Switzerland Wilen b. Wollerau +41 43 444 61 61
Germany Dortmund +49 231 9742 320
The Netherlands Krimpen a/d Ijssel +31 180 668 255
France Aix-en-Provence +33 4 42 90 42 60
Spain Barcelona +34 93 320 84 22
Italy Turin +39 011 620 41 11
USA Troy, MI +1 888 428 8636
Mexico Corregidora, Qro. +52 442 225 1104
Brazil São Bernardo do Campo +55 11 4121 1644
India Hyderabad +91 40 4068 9999
China Hongkong +85 2 2546 9069
Japan Tokyo +81 3 6459 0881
Korea Seoul +82 2 2113 0770
