Heliyon 11 (2025) e42648
Available online 15 February 2025
2405-8440/© 2025 The Authors. Published by Elsevier Ltd. This is an open access article under the CC BY-NC-ND license
(http://creativecommons.org/licenses/by-nc-nd/4.0/).
Research article
Antimicrobial activity and biocompatibility of alpha-silver
tungstate nanoparticles
Sarah Raquel de Annunzio a,*,1, Bruna de Lima Moraes b,1, Marcelo Assis c, Paula
Aboud Barbugli a, Vinícius Henrique Ferreira Pereira de Oliveira a, Elson Longo d,
Carlos Eduardo Vergani a
a São Paulo State University (UNESP), School of Dentistry, Araraquara, SP, Brazil
b São Paulo State University (UNESP), School of Pharmaceutical Sciences, Araraquara, SP, Brazil
c Department of Physical and Analytical Chemistry, University Jaume I (UJI), Castelló 12071, Spain
d CDMF, Federal University of São Carlos (UFSCar) 13565-905, São Carlos, SP, Brazil
A R T I C L E I N F O
Keywords:
Silver tungstate nanoparticles
Nanotechnology
Antimicrobial activity
Biocompatibility
A B S T R A C T
The growing global threat posed by microorganisms resistant to conventional antimicrobials
underscores the urgent need for novel agents to control infections. The aim of this study was to
evaluate the antimicrobial activity and biocompatibility of alpha-silver tungstate (α-Ag2WO4)
nanoparticles (NPs) synthesized by the ultrasonic method. The NPs were characterized, and their
antimicrobial activity was assessed against Candida albicans, Staphylococcus aureus, and Escher-
ichia coli using the broth microdilution method, determining the minimum inhibitory concen-
tration (MIC) and minimum bactericidal/fungicidal concentration (MBC/MFC). Intracellular
reactive oxygen species (ROS) production was detected by fluorescence using the CM-H₂DCFDA
probe. Cytotoxicity was evaluated using murine L929 fibroblasts by MTT assay. Cell viability of
both microorganisms and L929 fibroblasts was further assessed using Confocal Laser Scanning
Fluorescence Microscopy (CLSM). For C. albicans, the MIC was 3.90 μg/mL, and the MFC was
7.81 μg/mL. For S. aureus, the MIC and MBC were both 62.50 μg/mL, while E. coli exhibited MIC
and MBC values of 0.48 μg/mL. The biocompatibility assay revealed a significant reduction in cell
viability at concentrations starting from 15.62 μg/mL. CLSM images corroborated the results from
both microbiological and biocompatibility assays. Additionally, ROS production was detected in
all three microorganisms upon exposure to the NPs, confirming their antimicrobial mechanism. In
conclusion, α-Ag₂WO₄ NPs effectively inactivated C. albicans, S. aureus, and E. coli. However, a
higher concentration was required to inhibit S. aureus compared to E. coli and C. albicans. The
biocompatibility assay revealed concentration-dependent cytotoxic effects. These findings high-
light the potential of α-Ag2WO4 NPs as antimicrobial agents and suggest further research into
their efficacy against biofilms, optimization of their biocompatibility, and the application of these
nanomaterials in the incorporation and coating of materials used in biomedical and dental
devices.
* Corresponding author.
E-mail addresses: sarah.annunzio@unesp.br (S.R. de Annunzio), bl.moraes@unesp.br (B. Lima Moraes), marcelostassis@gmail.com (M. Assis),
paula.barbugli@unesp.br (P.A. Barbugli), vinicius.vhfpo@gmail.com (V. Henrique Ferreira Pereira de Oliveira), elson.liec@gmail.com
(E. Longo), carlos.vergani@unesp.br (C.E. Vergani).
1 These authors contributed equally to this work.
Contents lists available at ScienceDirect
Heliyon
journal homepage: www.cell.com/heliyon
https://doi.org/10.1016/j.heliyon.2025.e42648
Received 14 May 2024; Received in revised form 12 January 2025; Accepted 10 February 2025
mailto:sarah.annunzio@unesp.br
mailto:bl.moraes@unesp.br
mailto:marcelostassis@gmail.com
mailto:paula.barbugli@unesp.br
mailto:vinicius.vhfpo@gmail.com
mailto:elson.liec@gmail.com
mailto:carlos.vergani@unesp.br
www.sciencedirect.com/science/journal/24058440
https://www.cell.com/heliyon
https://doi.org/10.1016/j.heliyon.2025.e42648
http://crossmark.crossref.org/dialog/?doi=10.1016/j.heliyon.2025.e42648&domain=pdf
https://doi.org/10.1016/j.heliyon.2025.e42648
http://creativecommons.org/licenses/by-nc-nd/4.0/
Heliyon 11 (2025) e42648
2
1. Introduction
The emergence of microorganisms resistant to conventional antimicrobials has become a global threat to human health [1]. The
escalating prevalence of antimicrobial-resistant and multidrug-resistant (MDR) microorganisms has intensified the search for new
infection control agents [2–4]. Antimicrobial resistance stems from natural evolutionary processes involving genetic mutations or the
acquisition of resistance genes from other microorganisms. These processes limit drug absorption, inactivate and/or efflux drugs, and
alter the target of antimicrobials [5,6]. Often, these mechanisms are associated with the indiscriminate use of antimicrobials for the
prevention and management of infections and associated diseases [7].
Antimicrobial-resistant and MDR microorganisms include Gram-positive and Gram-negative bacteria and fungi. Among Gram-
positive bacteria, Staphylococcus aureus is a major pathogen responsible for a significant portion of invasive infections worldwide,
contributing to 80 % of hospital infections [8]. This microorganism is associated with skin, cardiovascular, and pulmonary infections
[9]. Escherichia coli, a Gram-negative bacterium, establishes commensal relationships with the gastrointestinal microbiota of verte-
brates, but can also cause infections in the urinary, abdominal, and pulmonary regions [10]. Candida albicans, a notable fungal species,
is frequently found in the oral cavity and is considered an opportunistic pathogen that resides as a commensal in the human body.
Imbalances in the host immune system can lead to superficial or invasive infections [11]. Furthermore, C. albicans is the most
commonly isolated Candida species in patients with candidemia [12]. Consequently, the development of effective antimicrobials
against these microorganisms is clinically relevant.
Nanotechnology has been used to develop novel materials with antimicrobial properties [7,13]. Throughout history, silver-based
materials have been recognized for their antimicrobial properties [14,15]. However, silver nanoparticles (AgNPs) are known for their
instability, aggregation tendency, and high toxicity [16,17]. To address these challenges, previous studies have explored materials
containing silver, focusing on maintaining antimicrobial efficacy while enhancing biocompatibility. Silver-based semiconductors such
as vanadates, molybdates, phosphates, and tungstates have gained attention due to their potent antimicrobial activity [18–21]. One
material showing significant promise for advancing healthcare technologies is α-Ag2WO4, a semiconducting metallic oxide with a
complex three-dimensional structure [22], typically appearing as microcrystals. Extensive research has validated its antimicrobial
effect against methicillin-resistant S. aureus (MRSA), C. albicans, and E. coli [18,23–25]. Its mechanism of action involves the formation
of ROS and the ionic release of Ag+ [26,27].
To enhance the antimicrobial activity of α-Ag2WO4, various synthetic strategies can be employed, particularly during the synthesis
process. Macedo et al. [28] synthesized α-Ag2WO4 microcrystals using the SDS surfactant, resulting in cuboid microcrystals, while
water-based synthesis yielded hexagonal microrod-like materials. Theoretical simulations revealed alterations in the (101) surface of
hexagonal microrods compared with the (001) surface in cuboid morphologies. This surface stabilization contributed to a two-fold
decrease in the antimicrobial activity of cuboid particles against MRSA. Another study by Laier et al. [29] demonstrated that con-
trolling the size of α-Ag2WO4, achieved through microwave irradiation, modulated the antimicrobial effect of this materialin its
hexagonal microrod-like morphology. Foggi et al. [23] observed changes in the synthesis of α-Ag2WO4 microcrystals using water,
ammonia solution, and alcoholic solution as solvents, resulting in alterations in the morphology and variations in antimicrobial
effectiveness. This emphasizes the influence of surface type and stabilized surface amount on the antimicrobial properties of
α-Ag2WO4.
One strategy rooted in the principles of nanotechnology involves the reduction of material size. This size reduction not only en-
hances the production of ROS and the release of Ag+ but also facilitates the material’s entry into the cell, thereby increasing the ef-
ficacy of this compound [1,7,13]. Recently, Ribeiro et al. [30] demonstrated that the utilization of different carboxylic acids during
synthesis could control the size of this particle, although the antimicrobial efficacy of α-Ag2WO4 NPs needs to be established. In this
context, the present study aimed to synthesize α-Ag2WO4 NPs and evaluate the interaction of these materials with different micro-
organisms and their biocompatibility.
2. Materials and methods
2.1. Synthesis and characterization of α-Ag2WO4 NPs
The α-Ag2WO4 NPs were synthesized utilizing the ultrasonic method [30]. To assess their properties, X-ray diffraction (XRD) and
scanning electron microscopy (SEM) were employed. Furthermore, their behavior in solution was examined through dynamic light
scattering (DLS), zeta potential analyses, and ion release studies. Details about the synthesis and characterization of α-Ag2WO4 NPs can
be found in the Supplementary Materials.
2.2. Antimicrobial activity
Tests were performed using the broth microdilution method established by the Clinical and Laboratory Standards Institute (CLSI –
M27 A2 and CLSI – M07 A9) [31,32]. Following the methodology established by Foggi et al. [23], concentrations ranging from 0.24 to
125 μg/mL were evaluated. During the experiment, the NPs were weighed in sterile 1.5-mL microtubes using a precision scale and then
dispersed in sterile deionized water at a concentration of 2 mg/mL. Subsequently, the tube underwent ultrasonication for 3 cycles, with
each cycle lasting 8 min [33] to ensure optimal dispersion of the NPs. After dispersion, two 1:1 (v/v) dilutions were carried out in
Roswell Park Memorial Institute medium (RPMI-1640; Sigma-Aldrich, St. Louis, MO, USA) or Mueller Hinton broth (MH; KASVI,
S.R. de Annunzio et al.
Heliyon 11 (2025) e42648
3
Paraná, Brazil). As a result, the microtube containing the dispersed NPs used to start the serial dilutions attained the final concentration
of 500 μg/mL. The NPs were serially diluted to obtain the desired concentrations. Subsequently, a 100 μL aliquot of the prepared
Candida albicans (American Type Culture Collection (ATCC) 90028) suspension was added to each well containing the NPs for fungi.
For bacteria, a 20 μL aliquot of the adjusted Staphylococcus aureus (ATCC 25923) and Escherichia coli (ATCC 25922) suspensions was
added to each of the wells. Then, the plates were wrapped in plastic film to prevent evaporation and incubated in an oven at 37 ◦C for
24 h. Following incubation, the MIC was determined by measuring the absorbance at 562 nm for C. albicans and 595 nm for bacteria
using the EZ Read 400 microplate reader (Biochrom), with the aid of the Adapt 2.0 BioChrom software. The MIC was identified as the
lowest concentration of NPs inhibiting microorganism growth. The MFC and MBC were determined by counting the number of
colony-forming units (CFU/mL). The MFC and MBC were determined at the lowest concentration with no detectable colony growth.
The experiment was performed in triplicate on three separate occasions (Supplementary Materials).
2.2.1. Confocal laser scanning fluorescence microscopy (CLSM)
The antimicrobial effect of α-Ag2WO4 NPs was also evaluated through CLSM (Carl Zeiss LSM 800 with Airyscan) using the LIVE/
DEAD BacLight™ Bacterial Viability Kit (Molecular Probes, OR, USA). Images were acquired using a CLSM at a 20 × magnification
objective. The laser wavelength was set to 488 nm, and the laser ranges used for detection were 488–546 nm for Syto-9 (with a gain of
685 V) and 561–700 nm for Propidium iodide (PI) (with a gain of 766 V) [34]. The tests were performed in quintuplicate (Supple-
mentary Materials).
2.2.2. Intracellular ROS quantification
Intracellular ROS production was quantified following established procedures Carmello et al. [35] The fluorescent probe
CM-H2DCFDA (General Oxidative Stress Indicator, Thermo Fischer Scientific, Waltham, MA USA) was resuspended in 144 μL of
ethanol (600 μM stock solution), and 2 μL was added to each well containing 200 μL of microorganism suspensions at 5 × 106 CFU/mL
(probe final concentration: 6 μM) (supplementary material). Control cells containing only the culture medium and a control containing
10 mM of H2O2 (Sigma-Aldrich) were also used. Fluorescence intensity was measured (Ex. 492 nm and Em. 520 nm) using a microplate
reader (Synergy H1 multimode microplate reader, BioTek, Winooski, VT, EUA). The assays were performed in triplicate on three
separate occasions.
2.3. Cell viability assay
Murine fibroblasts (L929) were used in this study [36,37]. The L929 fibroblast cells were resuspended in Dulbecco’s Modified Eagle
Medium (low glucose, 1 g/L), counted in a Neubauer chamber, plated in a 96-well plate (30.000 cells per well), and incubated at 37 ◦C
with 5 % CO2 for 24 h. To assess NP biocompatibility, the following concentrations were tested: 1.95, 3.90, 7.81, and 15.62 μL. Wells
containing cells alone were used as positive controls (PC), and wells containing 0.1 % Triton-X were used as death controls (DCs).
Thiazolyl blue tetrazolium bromide (MTT, Sigma-Aldrich) was prepared at a concentration of 1 mg/mL in RPMI broth without phenol
red (Sigma-Aldrich). After 24 h of incubation with NPs, the culture medium was removed, and 100 μL aliquots of the previously
prepared MTT solution were added to each of the wells containing the cells. The plates were incubated for 12 h. Subsequently, the MTT
solution was removed from the wells, 150 μL of isopropyl alcohol (Synth, Diadema, SP, Brazil) was added to each well, and the content
was transferred to another 96-well plate. Next, the absorbance at 562 nm was read on an EZ Read 400 microplate reader (Biochrom)
using Adapt 2.0 Biochrom software. This experiment was performed in triplicate on three separate occasions (Supplementary
Materials).
2.3.1. CLSM
Cell viability post-exposure to NPs was assessed using CLSM (Carl Zeiss LSM 800 with Airyscan) according to a protocol adopted in
Pimentel et al.’s study [20]. The lasers used were 405 nm with detection up to 470 nm for the Hoechst 33342, 488 with detection up to
530 nm for the ActinGreen™ stain, and up to 600 nm for the PI. The samples were analyzed at a 10 × magnification objective. The tests
were performed in quintuplicate (Supplementary Material).
2.4. Statistical analysis
The data obtained underwent normality analysis (Shapiro-Wilk test). Statistical analyses of the MIC, intracellular ROS detection,
and biocompatibility assays were performed using an analysis of variance test (one-way ANOVA) followed by Tukey’s post hoc test. For
the MBC and MFC tests, the Kruskal-Wallis test followed by Dunn’s post hoc test was applied. All analyses were performed using
GraphPad Prism® version 5.01 software (Graph Pad Software Inc., La Jolla, CA, USA). The significance level adopted for statistical
tests was set at 5 % (pexhibit an orthorhombic structure and belong to the
S.R. de Annunzio et al.
Heliyon 11 (2025) e42648
4
Pn2n space group, aligning with the crystallographic data number 248969 in the Inorganic Crystal Structure Database. The absence of
additional peaks that were observed signifies the high purity of the synthesized NPs. To further investigate the size reduction of
α-Ag2WO4, SEM images were acquired (Fig. 1B), confirming that the synthesized NPs display a nanorod morphology, with a length of
122 ± 32 nm and a width of 24 ± 14 nm.
3.2. Ionic liberation, zeta potential, and particle size
Table 1 presents the values of Ag and W released into the water after 24 h of incubation under conditions identical to those used in
subsequent cell cultures. The ionic release is dependent on the concentration of α-Ag2WO4 NPs, with a reduction in this release
observed after reaching 15.62 μg/mL. The maximum values obtained for the concentration of 62.50 μg/mL were 1.82 and 1.69 ppm for
Ag and W, respectively. The zeta potential of α-Ag2WO4 NPs dispersed in water at a concentration of 125 μg/mL was − 28.40 ± 0.4 mV
at pH 7. To assess particle size and polydispersity index (PdI), the α-Ag2WO4 NPs were examined at a concentration of 125 μg/mL
under three different conditions (Table 2). I. The samples were dispersed, and readings were performed. II. The samples were
dispersed, incubated for 24 h at 37 ◦C, and redispersed in ultrasound, and reading was performed. III. The samples were incubated for
24 h under the conditions described previously, washed three times with distilled water, redispersed, and analyzed. Significant ag-
gregation was not observed. The PDI results obtained were consistently similar, indicating uniform polydispersity (Table 2).
3.3. Antimicrobial activity
Antimicrobial assays were performed using the broth microdilution method. The MIC was determined at the α-Ag2WO4 NP con-
centration at which antimicrobial growth was not detected and the MFC or MBC at the concentration at which no colony growth was
detected. In tests using C. albicans, the MIC value was 3.90 μg/mL; for other concentrations evaluated, the reduction in absorbance
exhibited a significant difference compared with the PC (p 0.05). However, concentrations of 1.95 and
3.90 μg/mL resulted in reductions of 2.75 (p 0.05). Inhibition of bacterial growth was
noted from a concentration of 15.62 μg/mL. Concentrations of 7.81 and 15.62 μg/mL did not show significant reductions in colony
counts compared with the PC (p > 0.05). However, the concentration of 31.25 μg/mL showed a reduction of 1.54 log 10 (p 0.05).
3.4. CLSM
The LIVE/DEAD assay revealed that the untreated controls of each microorganism exhibited viability, with cells stained in green
(Fig. 3A–D, and G). Additionally, DCs were carried out, highlighting the presence of dead cells stained in red (Fig. 3B–E, and H). DCs
were performed by treating C. albicans with 16 μg/mL of fluconazole and the bacteria with 0.06 % chlorhexidine gluconate. The images
illustrate that suspensions treated with the NPs (1.95 μg/mL for C. albicans, 31.25 μg/mL for S. aureus, and 0.24 μg/mL for E. coli) align
with the MIC and MBC/MFC tests, revealing a more pronounced reduction in the viability of C. albicans (Fig. 3C) and a lesser impact for
Fig. 1. A) XRD and B) SEM images of the α-Ag2WO4 NPs.
S.R. de Annunzio et al.
Heliyon 11 (2025) e42648
5
Table 1
Ionic release of Ag and W at different concentrations of α-Ag2WO4 NPs.
Concentration (μg/mL) Concentration (ppm)
Ag W
62.5 2.12 3.29
31.25 1.97 2.04
15.6 1.82 1.69
7.81 0.81 0.94
3.9 0.41 0.614
1.95 0.24 0.33
0.97 0.11 0.09
0.48 0.03 0.056
Ppm: parts per million.
Table 2
Mean and standard deviation of particle size values and PdI of α-Ag2WO4 NPs dispersed in aqueous medium.
Conditions Diameter (nm) PdI
I 189.25 (±0.64) ​ 0.292 (±0.01)
II 151.60 (±0.40) ​ 0.332 (±0.02)
III 150.55 (±1.34) ​ 0.252 (±0.01)
PdI: polydispersity index.
Fig. 2. Antimicrobial activity of α-Ag2WO4 NPs against suspensions of C. albicans, S. aureus, and E. coli treated with different concentrations of
α-Ag2WO4 NPs. A) Mean absorbance values of C. albicans suspensions. The asterisks represent the statistical difference between groups and the
positive control (PC). One-way analysis of variance with Tukey’s post hoc test. ***p 0.05). However,contact of cells with α-Ag2WO4 NPs at a concentration of
15.62 μg/mL led to a decrease in cell viability compared with the PC (p 0.05) (Fig. 5A). According to the In-
ternational Organization for Standardization (ISO) 10993–5:2009 [36], inhibition of cell growth above 70 % indicates severe material
toxicity.
3.7. CLSM
To qualitatively evaluate the L929 cells after contact with the NPs, the cells were labeled with ActinGreen™ 488 (cytoskeleton, in
green), Hoechst 33342 (nucleus, in blue), and PI (cell death, in red) and were visualized under a CLSM (Fig. 5B). The PC shows the
living PC cells stained in green and blue. The α-Ag2WO4 [7.81 μg/mL] figure represents the fibroblasts that were in contact with the
NPs at a concentration of 7.81 μg/mL and are also viable. The cells in the DC group were stained in red, indicating non-viability
(Figure DC). Similarly, in the image representing the cells that were in contact with the NPs at a concentration of 15.62 μg/mL, a
reddish color was evident (α-Ag2WO4 [15.62 μg/mL] figure). These observations align with the MTT assay results, revealing a
significant reduction in cell viability after contact with NPs at a concentration of 15.62 μg/mL.
4. Discussion
Infectious diseases are one of the main causes of mortality worldwide [13]. The emergence of antimicrobial-resistant and MDR
strains poses a public health concern [1]. The appearance of these strains is attributed to the indiscriminate use of antibiotics and
antifungals, leading to the evolution of new resistant microorganisms at a faster pace [5,6]. Recent applications of nanotechnology
have led to the development of novel materials with antimicrobial properties [7]. NPs surpass conventional antimicrobial agents in
terms of antimicrobial efficacy, owing to their high surface-area/volume ratio.
The precise mechanism of action of metal oxide NPs warrants further exploration; however, current understanding indicates that
these materials predominantly engage in electrostatic interactions with the cell membrane, internalization, alterations, disruption of
the cell wall, and disruption of enzymatic and nucleic acid due to ionic release or the production of ROS [38,39]. These mechanisms
differ from those of the conventional antimicrobial agents. Cellular damage caused by metal oxide NPs in microorganisms occurs at
both the biochemical and molecular levels. Thus, these NPs are promising antimicrobial agents [40,41].
In the present investigation, the negative zeta potential values of α-Ag2WO4 NPs imply a low affinity between the samples and the
cell membrane, given their shared negative potentials. This poses a challenge for electrostatic interactions, especially at pH values
close to the physiological levels. Consequently, mechanisms such as internalization and cell membrane disruption caused by the
electrostatic interactions between the NP and the material may be challenging to occur. Observations under the three conditions using
distilled water as a dispersion medium do not indicate significant aggregation, as the hydrodynamic radius values obtained are similar
to the largest size of the α-Ag2WO4 NPs. The PDI results obtained were similar, indicating uniform polydispersity.
α-Ag2WO4 can release Ag + ions and W6+ ions, with Ag+ ions exhibiting high toxicity to both eukaryotic and bacterial cells. In this
study, the concentrations of released Ag + ions were considerably higher than those required to inhibit the growth of S. aureus, E. coli,
and C. albicans [42]. With regard to the cytotoxic effects on L929 cells, Souter et al. [43] found that Ag+ ions at a concentration of
16.78 ppm caused a 50 % reduction in L929 cells. In our studies, the toxic concentration of the NPs (15.62 μg/mL) induced the release
of Ag+ ions (1.82 ppm) much lower than 16.78 ppm. Thus, our data suggest that the antimicrobial activity and cytotoxicity are not
directly related to the release of Ag+ ions. However, only a few studies have reported the toxic effects of W6+ ions.
The antimicrobial tests revealed the capability of α-Ag2WO4 NPs to inhibit the growth of C. albicans, S. aureus, and E. coli in
suspension, findings supported by the acquired CLSM images. Different MIC and MBC/MFC values were observed for the inactivation
of these three microorganisms. Lower concentrations of NPs inactivated E. coli and C. albicans. However, higher concentrations were
required to inactivate S. aureus. This difference in bacterial susceptibility might be linked to the distinct chemical compositions of their
cell walls [44]. S. aureus, a Gram-positive bacterium, possesses a thick layer of peptidoglycan on the plasma membrane; therefore, if
Fig. 4. Intracellular ROS detection. Mean values of fluorescence intensity of A) C. albicans, B) S. aureus, and C) E. coli cells using the fluorescent
probe CM-H2DCFDA after contact with the NPs (1.95 μg/mL for C. albicans, 31.25 μg/mL for S. aureus, and 0.24 μg/mL for E. coli) and H2O2. The
asterisks represent the statistical difference between the groups and the positive control (PC). One-way analysis of variance with Tukey’s post hoc
test. **pemission in all
three microorganisms. This finding indicates that ROS formation occurs in microorganisms after exposure to α-Ag2WO4 NPs.
ROS formation can also damage host cells. These free radicals can lead to oxidative modifications of proteins, lipid peroxidation,
DNA strand breakage, and modulation of gene expression and inflammatory response, leading to mutations or cell death [47].
Therefore, evaluating the biocompatibility of these nanomaterials is essential to determine the biomedical application of α-Ag2WO4
NPs. The present study showed that the cytotoxicity of α-Ag2WO4 NPs is concentration dependent. At an NP concentration of 15.62
Fig. 5. Biocompatibility after contact with NPs. A: Mean values of cell viability (%) of L929 cells exposed to different concentrations of NPs. The
asterisks represent the statistical difference between the groups and the positive control (PC). One-way analysis of variance with Tukey’s post hoc
test. ***pto overcome antimicrobial resistance: challenges and prospects, Nanomedicine 18 (5) (2023) 471–484,
https://doi.org/10.2217/nnm-2023-0022.
[8] B. Alonso, M.J. Pérez-Granda, M.C. Latorre, C. Sánchez-Carrillo, E. Bouza, P. Muñoz, M. Guembe, Production of biofilm by Staphylococcus aureus: association
with infective endocarditis? Enferm. Infecc. Microbiol. Clín. 40 (8) (2022) 418–422, https://doi.org/10.1016/j.eimce.2021.03.009.
[9] G.Y.C. Cheung, J.S. Bae, M. Otto, Pathogenicity and virulence of Staphylococcus aureus, Virulence 12 (1) (2021) 547–569, https://doi.org/10.1080/
21505594.2021.1878688.
[10] E. Denamur, O. Clermont, S. Bonacorsi, D. Gordon, The population genetics of pathogenic Escherichia coli, Nat. Rev. Microbiol. 19 (1) (2021) 37–54, https://
doi.org/10.1038/s41579-020-0416-x.
[11] F.A. Alshubaily, Enhanced antimycotic activity of nanoconjugates from fungal chitosan and Saussurea costus extract against resistant pathogenic Candida
strains, Int. J. Biol. Macromol. 141 (2019) 499–503, https://doi.org/10.1016/j.ijbiomac.2019.09.022.
[12] L. Zhong, S. Zhang, K. Tang, F. Zhou, C. Zheng, K. Zhang, J. Cai, H. Zhou, Y. Wang, B. Tian, Z. Zhang, W. Cui, Z. Dong, G. Zhang, Clinical characteristics, risk
factors and outcomes of mixed Candida albicans/bacterial bloodstream infections, BMC Infect. Dis. 20 (1) (2020) 810, https://doi.org/10.1186/s12879-020-
05536-z.
[13] A. Raghunath, E. Perumal, Metal oxide nanoparticles as antimicrobial agents: a promise for the future, Int. J. Antimicrob. Agents 49 (2) (2017) 137–152,
https://doi.org/10.1016/j.ijantimicag.2016.11.011.
[14] S. Arora, J. Jain, J.M. Rajwade, K.M. Paknikar, Cellular responses induced by silver nanoparticles: in vitro studies, Toxicology letters 179 (2) (2008) 93–100,
https://doi.org/10.1016/j.toxlet.2008.04.009.
[15] P.V. Asharani, G. Low Kah Mun, M.P. Hande, S. Valiyaveettil, Cytotoxicity and genotoxicity of silver nanoparticles in human cells, ACS Nano 3 (2) (2009)
279–290, https://doi.org/10.1021/nn800596w.
[16] S. Hackenberg, A. Scherzed, M. Kessler, S. Hummel, A. Technau, K. Froelich, C. Ginzkey, C. Koehler, R. Hagen, N. Kleinsasser, Silver nanoparticles: evaluation of
DNA damage, toxicity and functional impairment in human mesenchymal stem cells, Toxicology letters 201 (1) (2011) 27–33, https://doi.org/10.1016/j.
toxlet.2010.12.001.
[17] S.I. Kaba, E.M. Egorova, In vitro studies of the toxic effects of silver nanoparticles on HeLa and U937 cells, Nanotechnol. Sci. Appl. 8 (2015) 19–29, https://doi.
org/10.2147/NSA.S78134.
[18] M. Assis, T. Robeldo, C.C. Foggi, A.M. Kubo, G. Mínguez-Vega, E. Condoncillo, H. Beltran-Mir, R. Torres-Mendieta, J. Andrés, M. Oliva, C.E. Vergani, P.
A. Barbugli, E.R. Camargo, R.C. Borra, E. Longo, Ag nanoparticles/α-Ag2WO4 composite formed by electron beam and femtosecond irradiation as potent
antifungal and antitumor agents, Sci. Rep. 9 (1) (2019) 9927, https://doi.org/10.1038/s41598-019-46159-y.
[19] B.N.A.D.S. Pimentel, C.C. de Foggi, P.A. Barbugli, R.C. de Oliveira, E.D. de Avila, E. Longo, C.E. Vergani, Antifungal activity and biocompatibility of α-AgVO3
microcrystals: a promising material against oral Candida disease. Materials science & engineering, C, Materials for biological applications 108 (2020) 110405,
https://doi.org/10.1016/j.msec.2019.110405.
[20] B.N.A.D.S. Pimentel, F.H. Marin-Dett, M. Assis, P.A. Barbugli, E. Longo, C.E. Vergani, Antifungal activity and biocompatibility of α-AgVO3, α-Ag2WO4, and
β-Ag2MoO4 using a three-dimensional coculture model of the oral mucosa, Front. Bioeng. Biotechnol. 10 (2022) 826123, https://doi.org/10.3389/
fbioe.2022.826123.
[21] B.N.A.D.S. Pimentel, S.R. De Annunzio, M. Assis, P.A. Barbugli, E. Longo, C.E. Vergani, Biocompatibility and inflammatory response of silver tungstate, silver
molybdate, and silver vanadate microcrystals, Front. Bioeng. Biotechnol. 11 (2023) 1215438, https://doi.org/10.3389/fbioe.2023.1215438.
[22] C. Janáky, K. Rajeshwar, N.R. de Tacconi, W. Chanmanee, M.N. Huda, Tungsten-based oxide semiconductors for solar hydrogen generation, Catal. Today 199
(2013) 53–64, https://doi.org/10.1016/j.cattod.2012.07.020.
[23] C.C.D. Foggi, R.C. De Oliveira, M.T. Fabbro, C.E. Vergani, J. Andres, E. Longo, et al., Tuning the morphological, optical, and antimicrobial properties of
α-Ag2WO4 microcrystals using different solvents, Cryst. Growth Des. 17 (2017) 6239–6246, https://doi.org/10.1021/acs.cgd.7b00786.
[24] C.C. Foggi, M.T. Fabbro, L.P.S. Santos, Y.V.B. de Santana, C.E. Vergani, A.L. Machado, et al., Synthesis and evaluation of α-Ag2WO4 as novel antifungal agent,
Chem. Phys. Lett. 674 (2017) 125–129, https://doi.org/10.1016/j.cplett.2017.02.067.
[25] M. Assis, E. Cordoncillo, R. Torres-Mendieta, H. Beltrán-Mir, G. Mínguez-Vega, R. Oliveira, E.R. Leite, C.C. Foggi, C.E. Vergani, E. Longo, J. Andrés, Towards the
scale-up of the formation of nanoparticles on α-Ag2WO4 with bactericidal properties by femtosecond laser irradiation, Sci. Rep. 8 (1) (2018) 1884, https://doi.
org/10.1038/s41598-018-19270-9.
[26] H. Kong, J. Jang, Antibacterial properties of novel poly(methyl methacrylate) nanofiber containing silver nanoparticles, Langmuir: the ACS journal of surfaces
and colloids 24 (5) (2008) 2051–2056, https://doi.org/10.1021/la703085e.
[27] V.M. Longo, C.C. De Foggi, M.M. Ferrer, A.F. Gouveia, R.S. André, W. Avansi, C.E. Vergani, A.L. Machado, J. Andrés, L.S. Cavalcante, A.C. Hernandes, E. Longo,
Potentiated electron transference in α-Ag2WO4 microcrystals with Ag nanofilaments as microbial agent, J. Phys. Chem. A 118 (31) (2014) 5769–5778, https://
doi.org/10.1021/jp410564p.
[28] N.G. Macedo, T.R. Machado, R.A. Roca, M. Assis, C.C. Foggi, V. Puerto-Belda, G. Mínguez-Vega, A. Rodrigues, M.A. San-Miguel, E. Cordoncillo, H. Beltrán-Mir,
J. Andrés, E. Longo, Tailoring the bactericidal activity of Ag nanoparticles/α-Ag2WO4 composite induced by electron beam and femtosecond laser irradiation:
integration of experiment and computational modeling, ACS Appl. Bio Mater. 2 (2) (2019) 824–837, https://doi.org/10.1021/acsabm.8b00673.
[29] L.O. Laier, M. Assis, C.C. Foggi, et al., Surface-dependent properties of α-Ag2WO4: a joint experimental and theoretical investigation, Theor. Chem. Acc. 139
(108) (2020) 1–11, https://doi.org/10.1007/s00214-020-02613-z.
[30] L.K. Ribeiro, A.F. Gouveia, F.D.C.M. Silva, L.F.G. Noleto, M. Assis, A.M. Batista, L.S. Cavalcante, E. Guillamón, I.L.V. Rosa, E. Longo, J. Andrés, G.E. Luz Júnior,
Tug-of-War driven by the structure of carboxylic acids: tuning the size, morphology, and photocatalytic activity of α-Ag2WO4, Nanomaterials 12 (19) (2022)
3316, https://doi.org/10.3390/nano12193316.
[31] CLSI, Reference Method for Broth Dilution Antifungal Susceptibility Testing of Yeasts; Approved Standard, third ed., Clinical and Laboratory Standards Institute,
Wayne, PA, 2008. CLSI Document M27-A2.
[32] CLSI, Methods for Dilution Antimicrobial Susceptibility Tests for Bacteria that Grow Aerobically; Approved Standard—Ninth Edition, M07-A9 v. 2, 2012.
[33] B.N.A.S. Pimentel, Avaliação da atividade antifúngica e citotoxicidade de microcristais de alfa vanadato de prata (α-AgVO3) sintetizados em diferentes
temperaturas. Dissertação (Mestrado) UNESP - Universidade Estadual Paulista “Júlio de Mesquita Filho, 2017. Araraquara.
[34] L.H.P. Zago, S.R. de Annunzio, K.T. de Oliveira, P.A. Barbugli, B.R. Valdes, M. Feres, C.R. Fontana, Antimicrobial photodynamic therapy against metronidazole-
resistant dental plaque bactéria, J. Photochem. Photobiol. B Biol. 209 (2020) 111903, https://doi.org/10.1016/j.jphotobiol.2020.111903.
[35] J.C. Carmello, A.C. Pavarina, R. Oliveira, B. Johansson, Genotoxic effect of photodynamic therapy mediated by curcumin on Candida albicans, FEMS Yeast Res.
15 (4) (2015) fov018, https://doi.org/10.1093/femsyr/fov018.
[36] International Standard ISO 10993-5, Third Edition 2009-06-01.Biological Evaluation of Medical Devices-Part 5: Tests for inVitro Cytotoxicity, International
Organization for Standardization, Geneve, Switzerland, 2009.
[37] A.S. Vidane, F.C. Nunes, J.A. Ferreira, H. Fukumasu, S.H. Freitas, E.M. Pallone, C.E. Ambrósio, Biocompatibility and interaction of porous alumina-zirconia
scaffolds with adipose-derived mesenchymal stem cells for bone tissue regeneration, Heliyon 9 (9) (2023) e20128, https://doi.org/10.1016/j.heliyon.2023.
e20128.
[38] G.M. Whitesides, Nanoscience, nanotechnology, and chemistry, Small 1 (2) (2005) 172–179, https://doi.org/10.1002/smll.200400130.
S.R. de Annunzio et al.
https://doi.org/10.1080/21655979.2021.1996747
https://doi.org/10.1080/21655979.2021.1996747
https://doi.org/10.3934/microbiol.2018.3.482
https://doi.org/10.3934/microbiol.2018.3.482
https://doi.org/10.3390/antibiotics10010003
https://doi.org/10.2217/nnm-2023-0022
https://doi.org/10.1016/j.eimce.2021.03.009
https://doi.org/10.1080/21505594.2021.1878688
https://doi.org/10.1080/21505594.2021.1878688
https://doi.org/10.1038/s41579-020-0416-x
https://doi.org/10.1038/s41579-020-0416-x
https://doi.org/10.1016/j.ijbiomac.2019.09.022
https://doi.org/10.1186/s12879-020-05536-z
https://doi.org/10.1186/s12879-020-05536-z
https://doi.org/10.1016/j.ijantimicag.2016.11.011
https://doi.org/10.1016/j.toxlet.2008.04.009
https://doi.org/10.1021/nn800596w
https://doi.org/10.1016/j.toxlet.2010.12.001
https://doi.org/10.1016/j.toxlet.2010.12.001
https://doi.org/10.2147/NSA.S78134
https://doi.org/10.2147/NSA.S78134
https://doi.org/10.1038/s41598-019-46159-y
https://doi.org/10.1016/j.msec.2019.110405
https://doi.org/10.3389/fbioe.2022.826123
https://doi.org/10.3389/fbioe.2022.826123
https://doi.org/10.3389/fbioe.2023.1215438
https://doi.org/10.1016/j.cattod.2012.07.020
https://doi.org/10.1021/acs.cgd.7b00786
https://doi.org/10.1016/j.cplett.2017.02.067
https://doi.org/10.1038/s41598-018-19270-9
https://doi.org/10.1038/s41598-018-19270-9
https://doi.org/10.1021/la703085e
https://doi.org/10.1021/jp410564p
https://doi.org/10.1021/jp410564p
https://doi.org/10.1021/acsabm.8b00673
https://doi.org/10.1007/s00214-020-02613-z
https://doi.org/10.3390/nano12193316
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref31
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref31
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref32
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref33
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref33
https://doi.org/10.1016/j.jphotobiol.2020.111903
https://doi.org/10.1093/femsyr/fov018
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref36
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref36
https://doi.org/10.1016/j.heliyon.2023.e20128
https://doi.org/10.1016/j.heliyon.2023.e20128
https://doi.org/10.1002/smll.200400130
Heliyon 11 (2025) e42648
11
[39] X. Zhu, E. Hondroulis, W. Liu, C.Z. Li, Biosensing approaches for rapid genotoxicity and cytotoxicity assays upon nanomaterial exposure, Small 9 (9–10) (2013)
1821–1830, https://doi.org/10.1002/smll.201201593.
[40] A. Kumar, A.K. Pandey, S.S. Singh, R. Shanker, A. Dhawan, Cellular response to metal oxide nanoparticles in bacteria, J. Biomed. Nanotechnol. 7 (1) (2011)
102–103, https://doi.org/10.1166/jbn.2011.1222.
[41] A. Kumar, A.K. Pandey, S.S. Singh, R. Shanker, A. Dhawan, Engineered ZnO and TiO(2) nanoparticles induce oxidative stress and DNA damage leading to
reduced viability of Escherichia coli, Free Radic. Biol. Med. 51 (10) (2011) 1872–1881, https://doi.org/10.1016/j.freeradbiomed.2011.08.025.
[42] A. Ahmad, A. Viljoen, The in vitro antimicrobial activity of Cymbopogon essential oil (lemon grass) and its interaction with silver ions, Phytomedicine:
international journal of phytotherapy and phytopharmacology 22 (6) (2015) 657–665, https://doi.org/10.1016/j.phymed.2015.04.002.
[43] P. Souter, J.C. Cunningham, A. Horner, P.G. Genever, The variable toxicity of silver ions in cell culture media, Toxicol. Vitro : an international journal published
in association with BIBRA 60 (2019) 154–159, https://doi.org/10.1016/j.tiv.2019.05.015.
[44] N. Durán, M. Durán, M.B. de Jesus, A.B. Seabra, W.J. Fávaro, G. Nakazato, Silver nanoparticles: a new view on mechanistic aspects on antimicrobial activity,
Nanomed. Nanotechnol. Biol. Med. 12 (3) (2016) 789–799, https://doi.org/10.1016/j.nano.2015.11.016.
[45] J.S. Kim, E. Kuk, K.N. Yu, J.H. Kim, S.J. Park, H.J. Lee, S.H. Kim, Y.K. Park, Y.H. Park, C.Y. Hwang, Y.K. Kim, Y.S. Lee, D.H. Jeong, M.H. Cho, Antimicrobial
effects of silver nanoparticles, Nanomed. Nanotechnol. Biol. Med. 3 (1) (2007) 95–101, https://doi.org/10.1016/j.nano.2006.12.001.
[46] K. Soo-Hwan, H.-S. Lee, D.-S. Ryu, S.-J. Choi, D.-S. Lee, Antibacterial activity of silver-nanoparticles against Staphylococcus aureus and Escherichia coli, Korean
J. Microbiol. Biotechnol. (39) (2011) 77–85.
[47] N.L. Haro Chávez, E.D. de Avila, P.A. Barbugli, R.C. de Oliveira, C.C. de Foggi, E. Longo, C.E. Vergani, Promising effects of silver tungstate microcrystals on
fibroblast human cells and three dimensional collagen matrix models: a novel non-cytotoxic material to fight oral disease, Colloids Surf. B Biointerfaces 170
(2018) 505–513, https://doi.org/10.1016/j.colsurfb.2018.06.023.
S.R. de Annunzio et al.
https://doi.org/10.1002/smll.201201593
https://doi.org/10.1166/jbn.2011.1222
https://doi.org/10.1016/j.freeradbiomed.2011.08.025
https://doi.org/10.1016/j.phymed.2015.04.002
https://doi.org/10.1016/j.tiv.2019.05.015
https://doi.org/10.1016/j.nano.2015.11.016
https://doi.org/10.1016/j.nano.2006.12.001
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref46
http://refhub.elsevier.com/S2405-8440(25)01028-X/sref46
https://doi.org/10.1016/j.colsurfb.2018.06.023
	Antimicrobial activity and biocompatibility of alpha-silver tungstate nanoparticles
	1 Introduction
	2 Materials and methods
	2.1 Synthesis and characterization of α-Ag2WO4 NPs
	2.2 Antimicrobial activity
	2.2.1 Confocal laser scanning fluorescence microscopy (CLSM)
	2.2.2 Intracellular ROS quantification
	2.3 Cell viability assay
	2.3.1 CLSM
	2.4 Statistical analysis
	3 Results
	3.1 Physicochemical assessment
	3.2 Ionic liberation, zeta potential, and particle size
	3.3 Antimicrobial activity
	3.4 CLSM
	3.5 Intracellular ROS detection
	3.6 MTT assay
	3.7 CLSM
	4 Discussion
	5 Conclusions
	CRediT authorship contribution statement
	Funding
	Declaration of competing interest
	Appendix A Supplementary data
	References
