INSTITUTO DE INFORMÁTICA
Universidade Federal de Goiás
Ecossistema Hadoop
Prof. Savio Salvarino Teles de Oliveira
Ecossistema Hadoop
HDFS
The Hadoop Distributed File System
● Construído em hardware “commodity”
● Altamente tolerante a falha
● Projetado para processamento em lote -
Acesso a dados tem alto “throughput” ao
invés de baixa latência (ocultar latência)
● Suporta datasets muito grandes
HDFS
Name Node
Data Nodes
(Commodity Hardware)
• Armazena a árvore de diretório do
sistema de arquivos.
• Armazena todos os metadados com as
informações sobre os arquivos:
• File name, permissões, diretório
• Quais nós contém cada bloco.
• Os metadados são armazenados em
memória e em disco.
• Não se esqueça de fazer o backup
dos metadados
• Se você perder o NameNode você
perdeu TODO HDFS.
Name Node
Name Node
Data Nodes
(Commodity Hardware)
• Armazena e administra blocos
do HDFS no disco local.
• Informa a saúde e status de
repositório de dados
individuais ao NameNode.
Vamos quebrar o texto em blocos de sentenças...
● Diferentes tamanhos de
arquivos são processados
da mesma forma;
● O armazenamento é
simplificado;
● Unidade para replicação e
tolerância a falhas;
● Tamanho de bloco padrão
é de 128 MB;
HDFS
8
Escrita no HDFS
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Data Node - A Data Node - D
Data Node - B Data Node - E
Data Node - C Data Node - F
500mb
128mb
128mb
128mb
128mb
Data Node - A Data Node - D
Data Node - B Data Node - E
Data Node - C Data Node - F
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03
Blk_01
Blk_04
Blk_02
Data Node - A Data Node - D
Data Node - B Data Node - E
Data Node - C Data Node - F
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B Data Node - E
Data Node - C Data Node - F
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B
blk_01
Data Node - E
Data Node - C Data Node - F
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B
blk_01
Data Node - E
Data Node - C Data Node - F
blk_01Blk_01: A, B, F
Registrado no metadados do NameNode.
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B
blk_01
Data Node - E
Data Node - C Data Node - F
blk_01Blk_01: A, B, F
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B
blk_01
Data Node - E
Data Node - C Data Node - F
blk_01Blk_01: A, E, F
blk_01
Alterado metadados do
NameNode.
500mb
Name Node
#hadoop fs –put arquivo.txt /path/in/hdfs
Blk_03 Blk_04
Blk_02
Data Node - A
blk_01
Data Node - D
Data Node - B
blk_01
Data Node - E
Data Node - C Data Node - F
blk_01Blk_01: A, E, F
blk_01
Alterado metadados do
NameNode.
150 bytes
O que é acontece se um dos
blocos for corrompido???
Replicação no HDFS
1.Replicar blocos baseados
em um fator de replicação;
2.Armazenar replicas em
diferentes locais;
Replicação no HDFS
A localização das réplicas
são armazenadas no
Namenode!
Replicação no HDFS
Armazena réplicas em
diferentes nós
MAXIMIZAR
REDUNDÂNCIA
Replicação no HDFS
A terceira localização é interessante que fique no
mesmo rack do segundo mas em um nó diferente…
Replicação no HDFS
23
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Resource Manager
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Resource Manager
Execute – wc.jar
ApplicationId
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Resource Manager
Execute – wc.jar
Resource Request
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Resource Manager
Execute – wc.jar
Resource Request
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
wc.jar
Execute
Resource Manager
Execute – wc.jar
Resource Request
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
wc.jar
wc.jar
Execute
Execute
Resource Manager
Execute – wc.jar
Resource Request
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Execute – wc.jar
Application
Master
wc.jar
wc.jar
Execute
Execute
Resource Manager
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Execute – wc.jar
Application
Master
Resource Status
wc.jar
wc.jar
Execute
Execute
Resource Manager
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Resource Request
wc.jar
wc.jar
Execute
Execute
Resource Manager
Done!
Client
#hadoop jar wc.jar arquivo.txt
Node Manager - A
blk_01
Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Resource Request
wc.jar
wc.jar
Execute
Execute
Resource Manager
Done!
Client
#hadoop jar groupcount.jar arquivo.txt
groupcount.jar
groupcount.jarApplication
Master
YARN (Mapreduce /
MRv2)
Resource Manager
Node Manager
HDFS
Name Node
Data Node
Master
Slave
Hadoop 2.x Core
Componentes
Hadoop Deamons
Client
#hadoop jar wc.jar arquivo.txt
Node Manager – A
Data Node - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Done!
wc.jar
Map Task
wc.jar
Map Task
Resource Manager
blk_01
blk_02 wc.jar
Map Task
blk_03
Client
#hadoop jar wc.jar arquivo.txt
Node Manager – A
Data Node - A Node Manager - D
Node Manager - B Node Manager - E
Node Manager - C Node Manager - F
Application
Master
Done!
wc.jar
Reduce Task
wc.jar
Reduce Task
Resource Manager
blk_01
blk_02 wc.jar
Reduce Task
blk_03
MapReduce:
Programação
Distribuída
Funcionamento do MapReduce
MapReduce: exemplo
MapReduce: exemplo
Funcionamento do MapReduce
Entrada de Dados
O processo começa
com dados brutos.
Função Map
Aplica uma função
"map" a cada registro
de dados, gerando
pares chave-valor
intermediários.
Shuffle e Combine
Os pares chave-valor
são embaralhados e
ordenados por chave
Função Reduce
A função "reduce"
combina valores com a
mesma chave,
produzindo o resultado
final da operação.
Referências
Referências
● KIMBALL, Ralph; CASERTA, Joe. The Data Warehouse?
ETL Toolkit: Practical Techniques for Extracting, Cleaning,
Conforming, and Delivering Data. John Wiley & Sons, 2011.
● DOAN, AnHai; HALEVY, Alon; IVES, Zachary. Principles of
data integration. Elsevier, 2012.
● KRISHNAN, Krish. Data warehousing in the age of big data.
Newnes, 2013.
● Big Data ETL:
○ https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-
suren-nathan
○ https://software.intel.com/sites/default/files/article/402274/etl-big-
data-with-hadoop.pdf
43
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathanhttps://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://www.slideshare.net/SparkSummit/spark-summit-keynote-by-suren-nathan
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
https://software.intel.com/sites/default/files/article/402274/etl-big-data-with-hadoop.pdf
Referências
● FRIEDMAN, Ellen; TZOUMAS, Kostas. Introduction to
Apache Flink: Stream Processing for Real Time and
Beyond. 2016.
● NARKHEDE, Neha; SHAPIRA, Gwen; PALINO, Todd. Kafka:
The Definitive Guide. 2016.
● JAIN, Ankit; NALYA, Anand. Learning storm. Packt
Publishing, 2014.
● KARAU, Holden et al. Learning spark: lightning-fast big
data analysis. " O'Reilly Media, Inc.", 2015.
● DEROOS, Dirk et al. Hadoop for Dummies. John Wiley &
Sons, Incorporated, 2014.
44
● [Cae16] Wu, Caesar, Buyya, Rajkumar, Ramamohanarao,
Kotagiri: Big Data Analytics: Machine Learning plus Cloud
Computing, Big Data: Principles and Paradigms, Morgan
Kaufmann, 1–27, Eds: Buyya, Rajkumar, Calheiros, Rodrigo N.,
Dastjerdi, Amir Vahid, January 2016
● [Mar15] Marz, Nathan, Warren, James: , Big Data: Principles
and best practices of scalable realtime data systems, 1st
edition, Manning Publications, 328, May 2015
45
Referências
Savio Salvarino Teles de Oliveira
savioteles@ufg.br
	Slide 1: Ecossistema Hadoop
	Slide 2: Ecossistema Hadoop
	Slide 3
	Slide 4
	Slide 5: Name Node
	Slide 6
	Slide 7
	Slide 8
	Slide 9
	Slide 10
	Slide 11
	Slide 12
	Slide 13
	Slide 14
	Slide 15
	Slide 16
	Slide 17
	Slide 18
	Slide 19
	Slide 20
	Slide 21
	Slide 22
	Slide 23
	Slide 24
	Slide 25
	Slide 26
	Slide 27
	Slide 28
	Slide 29
	Slide 30
	Slide 31
	Slide 32
	Slide 33
	Slide 34: Hadoop Deamons
	Slide 35
	Slide 36
	Slide 37
	Slide 38
	Slide 39
	Slide 40
	Slide 41
	Slide 42: Referências
	Slide 43: Referências
	Slide 44: Referências
	Slide 45
	Slide 46: Savio Salvarino Teles de Oliveira savioteles@ufg.br
