Journal of Cosmetic and Laser Therapy
ISSN: 1476-4172 (Print) 1476-4180 (Online) Journal homepage: http://www.tandfonline.com/loi/ijcl20
Ultrasound associated with caffeine increases
basal and beta-adrenoceptor response in
adipocytes isolated from subcutaneous adipose
tissue in pigs
Maria Silvia Mariani Pires-de-Campos, Juliana De Almeida, Valéria Wolf-
Nunes, Elaine Souza-Francesconi & Dora Maria Grassi-Kassisse
To cite this article: Maria Silvia Mariani Pires-de-Campos, Juliana De Almeida, Valéria Wolf-
Nunes, Elaine Souza-Francesconi & Dora Maria Grassi-Kassisse (2016): Ultrasound associated
with caffeine increases basal and beta-adrenoceptor response in adipocytes isolated from
subcutaneous adipose tissue in pigs, Journal of Cosmetic and Laser Therapy
To link to this article: http://dx.doi.org/10.3109/14764172.2015.1063659
Published online: 28 Jan 2016.
Submit your article to this journal
View related articles
View Crossmark data
Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
http://www.tandfonline.com/action/journalInformation?journalCode=ijcl20
http://www.tandfonline.com/loi/ijcl20
http://dx.doi.org/10.3109/14764172.2015.1063659
http://www.tandfonline.com/action/authorSubmission?journalCode=ijcl20&page=instructions
http://www.tandfonline.com/action/authorSubmission?journalCode=ijcl20&page=instructions
http://www.tandfonline.com/doi/mlt/10.3109/14764172.2015.1063659
http://www.tandfonline.com/doi/mlt/10.3109/14764172.2015.1063659
http://crossmark.crossref.org/dialog/?doi=10.3109/14764172.2015.1063659&domain=pdf&date_stamp=2016-01-28
http://crossmark.crossref.org/dialog/?doi=10.3109/14764172.2015.1063659&domain=pdf&date_stamp=2016-01-28
Journal of CosmetiC and laser therapy
http://dx.doi.org/10.3109/14764172.2015.1063659
ORIGINAL RESEARCH REPORT
CONTACT dora maria Grassi-Kassisse doramgk@unicamp.br laboratory of stress study (laBeest), department of structural and functional Biology, institute of
Biology university of Campinas (uniCamp), Cidade universitária Zeferino Vaz, rua monteiro lobato, 255, Campinas, sp, Brazil, Cep 13083–862.
this study is part of a phd program done by maria silvia mariani pires-de-Campos and supervised by dr. dora maria Grassi-Kassisse.
Color versions of one or more of the figures in the article can be found online at http://www.tandfonline.com/ijcl
© 6 taylor & francis Group, llC
Ultrasound associated with caffeine increases basal and beta-adrenoceptor response
in adipocytes isolated from subcutaneous adipose tissue in pigs
Maria Silvia Mariani Pires-de-Campos1,2, Juliana De Almeida1, Valéria Wolf-Nunes1, Elaine Souza-Francesconi1,
and Dora Maria Grassi-Kassisse1
1laboratory of stress study (laBeest), department of structural and functional Biology, Biology institute, university of Campinas (uniCamp),
Campinas, sp, Brazil; 2physiotherapy, faculty of health sciences (faCis) university methodist of piracicaba (unimep), piracicaba, sp, Brazil
Introduction
Cellulite affects the vast majority of women. It is a change in the
skin for which there is still no effective treatment defined. New
forms of treatment are proposed every day, which are physical
or drug treatments (1, 2). Among the drug proposals, many are
for topical application; however, their absorption is difficult
through the skin. This issue leads researchers to investigate the
use of different chemical substances in the formulation, as well
as physical methods such as ultrasound (US) to facilitate the
penetration of drugs through the skin in a process known as
“phonophoresis” or “sonophoresis” (3).
Due to this demand, the transdermal transport has been
intensely studied over the past decades. Specifically, since the ini-
tial treatment of polyarthritis with hydrocortisone ointment by
Fellingher and Schmidt in the 1950s (4), the transdermal delivery
of therapeutic drugs such as fentanyl, caffeine, heparin, ketopro-
fen, and insulin has become a major concern for clinical medicine
(5). This technique has several advantages, as it is noninvasive,
avoids the first-pass effects through the liver, and also prevents the
degradation of peptides and proteins that can compose the formu-
lation. The downside is that this transport is limited to the outer-
most layer of the epidermis, that is, the stratum corneum (6).
In vitro and in vivo studies (rats, pigs, and humans) using pho-
nophoresis with caffeine were done in skin. Some of them analyz-
ing permeation and others the efficiency of caffeine to localized
fat treatment. In vitro studies, carried out using diffusion cells
constructed with pieces of shaved skin, excluding hypodermis,
extracted from swine dorsal region, demonstrated that US sig-
nificantly accelerated the permeation of caffeine through the skin
(7). This same group showed in vivo pigs study in which only caf-
feine associated with US reduced the layer of adipose tissue with
reduction in thickness of hypodermis and adipocytes number (8).
Borcaud et al. (9) evaluated effects of phonophoresis on transder-
mal transport of fentanyl and caffeine across both hairless rat and
human skin. Phonophoresis enhanced transdermal drug delivery
(TDD) of fentanyl (about 35-folds greater than control) and caf-
feine (about 4-folds greater than control) across human and hair-
less rat skin. These experiments were performed using 20-kHz US
applied at either continuous or pulsed mode and with an average
intensity of 2.5 W/cm2. The results showed that low-frequency
US enhanced the transdermal transport of both fentanyl and
caffeine across human and hairless rat skin. Besides these
studies, a functional study of adipocytes isolated from areas that
received topical treatment has not been carried out yet.
ABSTRACT
Background: The topical use of caffeine has been indicated for the lipodystrophies treatment as it pro-
motes increased lipolysis. Ultrasound (US) is often used in cutaneous diseases, esthetic conditions, and as
a skin permeation enhancer. Objective: We investigate the lipolytic response of adipocytes isolated from
subcutaneous adipose pigs tissue subjected to treatment with topical application of phonophoresis asso-
ciated with caffeine. Method: We treated dorsal regions of pigs (Landrace  Large White, 35 days, 15 kg,
n  6) daily for 15 days with gel, gel  US [3 MHz, continuous, 0.2 Wcm2, 1 min/cm2, in total 2 min], gel 
caffeine (5%w/w), and gel  caffeine  US. We used a fifth untreated region as control. Twenty-four hours
after the last application, we isolated the adipocytes of each treated area and quantified the basal and
stimulated lipolytic responses to isoprenaline. The results, in mmol glycerol/106cells/60 min, were analyzed
with analysis of variance or ANOVA followed by Newman–Keuls test. The value of p  0.05 was indicative
of statistical difference. Results: Only the adipocytes isolated from the area treated with caffeine  US
showed increased basal lipolysis (0.76  0.26; p  0.0276) and maximal isoprenaline stimulation (0.38  0.15,
p  0.0029) compared with the other areas. Conclusion: The results demonstrate that increased lipolysis of
caffeine  US is due to an increase in basal and beta-adrenoceptor response by caffeine, and caffeine’s
effect is local, avoiding unwanted effects.
ARTICLE HISTORY
received 10 october 2014
accepted 8 June 2015
KEYWORDS
Glycerol; isoproterenol;
phonophoresis; topical
agents
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
2 M. S. M. PIRES-DE-CAMPOS ET AL.
lipolysis of adipocytes isolated from this treated area will be
increased when compared with other treatment areas, acting as
local effect.
Materials and methodsAnimals
We used five uncastrated male hybrid pigs (Landrace  Large
White), 35 days old (∼ 15 kg), which were obtained from a com-
mercial breeder. The animals were kept in pigpen, divided into
individual boxes. Twice a day, the stalls were stocked with water
and feed specific for pigs, composed of a mixture of ground corn,
soybean meal, meat meal, calcium salts added of Fapec polynu-
cleotides (8). As a prophylactic measure against ectoparasites,
pigs were pretreated with Ivomecâ. One day before beginning
the treatments, the dorsal region was carefully trichotomized
with a shearing machine, avoiding damage to the corneal layer.
During the experiments, the pigs were cared for in accordance
with the principles set out by Olfert et al. (23) for the use of ani-
mals in research and education, and the experimental protocols
we used were approved by the Animal Research Ethics Commit-
tee (EEC/UNICAMP, Protocol 614-2).
Topical treatments
The dorsal region of each pig, trichotomized, was divided into
five areas (8 cm2 each), one for each of the five treatments: appli-
cation of gel (GEL; see text for composition); application of gel
and caffeine (CAF; see text for composition); application of gel
and US; application of gel, caffeine, and US (CAF  US); and a
control area which did not receive treatment (Figure 1).
The amount of gel applied in each area was 3 g. All treat-
ments were performed once a day, always at the same time, for
The adipocytes are cells that primarily compose adipose tis-
sue, and can be isolated so their lipolytic function is evaluated.
In adipocytes there are basal and stimulate lipolysis. Lipolysis in
these cells is predominantly stimulated by adrenergic agonists
that interact with beta-adrenoceptors (b-ARs) stimulating the
Gs protein (Gs), with subsequent activation of adenylyl cyclase,
which increases the synthesis of cyclic adenosine monophos-
phate (cAMP). This product, in turn, activates the protein
kinase A or PKA that phosphorylates the hormone-sensitive
lipase (HSL) and the perilipins. This signaling cascade starts
the lipolysis, which releases fatty acids and glycerol from the
adipose cell (10).
Endogenously, the b-ARs are activated by norepinephrine
and epinephrine, which are mostly known as lipolytic agents
(10). In contrast, adenosine A1 receptors (A1Rs) inhibit adeny-
lyl cyclase and reduce the levels of intracellular cAMP, so that
the stimulation of A1R opposes the lipolytic action of b-AR
(11). Lipolysis can also be decreased by increasing the activity
of cAMP phosphodiesterase, which hydrolyzes cAMP to AMP
and adenosine (11). In contrast, insulin induces phosphodi-
esterase enzyme activation causing a decrease in lipolysis effect
of b-lipolytic agents (10).
Basal lipolysis suffers influence mainly by adenosine, which
can act in different receptor subtypes. There are four subtypes of
adenosine receptors: A1, A2a, A2b, and A3 that signal primar-
ily through the stimulation (A2a and A2b) and inhibition (A1
and A3) of cAMP synthesis. A2 receptors are also known to be
expressed in preadipocytes, whereas A1Rs are predominantly
expressed in mature adipocytes. Adenosine, acting through
A1R, has been implicated in many of the physiological func-
tions of adipocytes. It has been associated, in particular, with an
inhibition of lipolysis (12).
Caffeine is the most common stimulant used for treatment
of lipodystrophy (5, 13, 14). It is a derivative of xanthine, which
inhibits phosphodiesterase of cAMP, increasing and prolonging
its dependent adrenergic responses, and blocks the adenosine
receptors A1 and A2A (15, 16). For this reason, caffeine is widely
used to potentiate the lipolytic response and is found in a large
number of cosmetic preparations for topical application (16).
Despite some controversy (17), studies suggest that caffeine
can break down the stored fat through stimulation of lipolysis,
reducing fat cell deposits (18, 19). Due to unwanted side effects
of caffeine ingestion, like nervous excitation, sleep disturbances,
heart rate increase, and diuresis, its application in cellulite treat-
ment is preferably topical (8).
The population of adrenoceptors in adipocytes may vary,
depending on the adipose tissue location and the species stud-
ied. The adipocytes isolated from hypodermis of pigs have rel-
evant similarities with those in the human hypodermis (20).
Moreover, the responses of b-adrenergic stimulation and inhi-
bition in pigs is similar to those of humans, which suggests that
the proportion of adrenoceptor subtypes in the adipose tissue of
the two species is similar: 70–80%, 20%, and less than 10% for
b1, b2, and b3, respectively (21, 22).
Thus, the aim of this study was to investigate the lipolytic
response of adipocytes isolated from subcutaneous adipose tis-
sues of pigs subjected to treatment of topical caffeine applica-
tion and phonophoresis. As US promotes caffeine permeation,
the hypothesis of this study is that basal and beta-stimulated
Figure 1. the dorsal region with different shaved areas of one of the pigs from
this study.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
JOURNAL OF COSMETIC AND LASER THERAPy 3
performed exactly as previously described by Pires-de-Campos
et al. (8). Briefly, intensities for those in vitro (7) and in vivo (8)
US studies were calculated as suggested by Watson (24). Watson
shows that to induce therapeutic effects the target tissue should
be kept at 40 and 45°C for 5 min, so it is necessary to have a
variation of 5°C. For this US, frequency of 3 MHz, intensity of
0.2 W/cm2 (SATA), power of 0.8 W, effective radiation area or
ERA of 4 cm2 with continuous emission, and application time
of 1 min/cm2 were used; it means a total of 2 min, 24 J (7, 8)
(Figure 3).
Isolation of adipocyte and lipolysis measurement
The pigs were sacrificed by deepening of anesthesia (xylazine
 ketamine—at initial doses of 2 mg/kg  20 mg/kg, respec-
tively) after 12 h fasting and 24 h after the last day of treatment.
We removed the tissues and the adipocytes were isolated from
different areas. The isolation followed the modification of the
procedure described by Grassi-Kassisse et al. (25). Briefly, we
weighted the adipose tissue of each area, divided it into five sam-
ples of 2–3 g, and each sample was then chopped and digested
in 20-mL polyethylene bottle containing 6 mL of Krebs Ringer
bicarbonate buffer (KRB), 25 mM HEPES, and 6 mM glucose,
at pH 7.4, with 1 mg/mL of collagenase (type 2, Clostridium
histolyticum) and 3% bovine serum albumin (BSA, fraction V,
free fatty acid) (referred to as KRBA). The bottles were shaken
(60 cycles/min) at 37°C for 45 min, after which the resulting
cell suspension was filtered through a nylon mesh (200 mm)
and washed three times with 10 mL of KRBA. Cell suspensions
of five bottles were combined and washed 3 times with 3-min
intervals between the washes. Before incubation, an aliquot of
the final suspension was used to count cells in Malassez cham-
ber (26). Aliquots of the cell suspension (100,000 cells) were dis-
tributed in 2-mL polyethylene bottles containing 1 mL of fresh
KRBA, and then we added 10 mL of isoprenaline (final concen-
tration: 10 nM to 10 mM) to the bottles, followed by 60 min of
incubation with agitation at 60 cycles/min, at 37°C. The reac-
tion was stopped in an ice bath. After approximately 30 min,
15 consecutive days, exactly as described previously by Pires-
de-Campos et al. (8).
Composition and gel application
The gel, consisting of 1% carboxyvinyl acid, 10% propylene
glycol, sodium acetate buffer (0.1 M; pH 7.1), 25% absolute
ethyl alcohol, and triethanolamine (pH 7.0), was applied to the
skin in circular friction by only one physiotherapist trained
to perform massage until accomplishing hyperemia and
increased skin temperature. Thisgel served as a vehicle for
topical application of caffeine and was prepared as described by
Pires-de-Campos et al. (8).
Treatment with gel and caffeine
The gel with caffeine was prepared as described by Pires-de-
Campos et al. (8), adding 5% of anhydrous caffeine (Sigmaâ
Chemical CO., St Louis, MO, USA) to the gel described above.
Caffeine was dissolved in 0.1 M sodium acetate buffer (pH 7.1)
containing 25% of absolute ethyl alcohol and propylene glycol
at 10%; the final solution (pH 7.0–7.5) was incorporated into
the gel (8).
Caffeine gel was applied to the skin on a daily basis, for 15
days, using circular friction (therapy massage) by a single thera-
pist trained to perform massage until accomplishing hyperemia
and increased skin temperature, which takes 2 min (Figure 2).
Application of ultrasound
Ultrasound (US; Sonomaster Microcontrolado, KWâ Indús-
tria Nacional de Tecnologia Ltda, Amparo, SP, Brazil) was
applied daily, for 15 days, in areas of skin covered by gel (US) or
caffeine gel (CAF  US), during 2 min with parameters
described as follows: first, the frequency of US was set at 3
MHz and was calibrated with a balance of US from OHMIC
CS Instruments Co. (Easton, MD, USA) and the attenuation
evaluation of the ultrasonic wave to the gel with caffeine was
Figure 2. Caffeine gel application. Figure 3. ultrasound (us) application.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
4 M. S. M. PIRES-DE-CAMPOS ET AL.
None of the treatments caused a change in the adrenocep-
tors’ sensitivity evaluated by the pD2 value (Table 1). As the
same pig received all the treatments (Figures 1–3), we discarded
the anesthetic effects at lipolysis.
Discussion
Esthetics has become the focus of intense commercial activ-
ity, with different product offerings, especially for localized fat
reduction (1). However, the use and efficiency of such products
are still controversial and there are few scientific studies that
validate these practices (1, 16).
The focus of this work is to study lipolysis induced by
b-agonists with a local effect. The functional effects and the
ligand-binding patterns for a variety of bAR agonists and antag-
onists are rather atypical in porcine compared with rodent adi-
pocytes (29). The porcine adipocyte has approximately 70–80%
b1AR, 20% b2AR, and 10% b3AR, as indicated by of the subtype
transcripts concentration (21) and by binding of ligands found
to be specific for the cloned porcine b1AR and b2AR (30). Pig
skin model is the most indicated model, because according to
the literature (31, 32), it is the one that most closely resembles
the human skin in its morphological and functional aspects,
and these similarities explain why this model is widely used in
cosmetic and dermatological studies (20, 33). In these tissues,
there is also an important similarity in the adipocyte response
to b-adrenergic agonists, since the ratio of adrenoceptor sub-
types b1, b2, and b3 is similar in both species, and this subtype
distribution is totally different from that in rodent adipocytes,
which have  90% b3AR (20, 21, 34, 35).
In this study we demonstrate that adipocytes isolated from
skin areas exposed to caffeine and associated with US initially
showed a significantly higher basal production of glycerol. The
definition of the mechanisms involved with basal lipolysis is still
incomplete; it is known that insulin is an important antilipoly-
tic agent; however, it is efficient for the inhibition of stimulated
lipolysis and has almost no effect on basal lipolysis (10). Some
clarifications appear with studies on the role of lipases in adipo-
cytes that have advanced after the cloning of the adipose triacyl-
glycerol lipase enzyme. Studies indicate that the HSL is the main
the floating adipocytes were discarded and the infranatant was
stored for glycerol analysis.
Lipolysis was then quantified following the glycerol release in
the incubation medium. Aliquots of infranatant (100 mL) were
used to quantify the glycerol. We analyzed each test in tripli-
cate, and the results represent the average of the experiments
performed in different areas of each of the animals. Glycerol
production was measured after action of the enzymes: glycerol
kinase, glycerol-3-phosphate oxidase, and peroxidase. Glyc-
erol is phosphorylated by ATP to obtain glycerol-1-phosphate
and ADP, in a reaction catalyzed by glycerol kinase. Glycerol-
1-phosphate is then oxidized by glycerol phosphate oxidase
into dihydroxyacetone phosphate and hydrogen peroxide. A
quinoneimine dye is produced by the coupling of peroxidase-
catalyzed 4-aminoantipyrine (4-AAP) and sodium N-ethyl-N-
(3-sulfopropyl)-m-anisidine (ESPA) with hydrogen peroxide,
which presents maximum absorbance at 540 nm. The increase
in absorbance at 540 nm is directly proportional to the glycerol
contained in the samples. We performed all tests using com-
mercial kits (catalog number 02700, Labor Labâ AS, Guarulhos,
SP, Brazil [27]).
Concentration–effect curves for isoprenaline were built and
the values of the concentration that cause 50% of the maximum
response were calculated (pD2-log EC50). The results were
expressed in glycerol/106cells/60 min. Concentration–response
curves were built using the maximum response of glycerol
release induced by isoprenaline in control adipocytes as 100%.
Statistical analysis
The results are presented as mean  standard deviations. In
order to analyze data normal distribution we used Shapiro–
Wilk test. Since the normality supposition was verified we used
one-way analysis of variance (ANOVA) followed by Newman–
Keuls multiple comparison test (28), considering statistical
significance at 5%. Analyses were done using GraphPad Prism
software (Prism 5 for Windows, version 5.01).
Results
Adipocytes isolated from skin areas exposed to caffeine treat-
ment associated with US showed a significant increase in basal
release of glycerol of 55% more than the values obtained by adi-
pocytes isolated from the control area (Table 1, in mmol of glyc-
erol/106 cells/60 min, Control: 0.49  0.05; Gel: 0.61  0.12; US:
0.48  0.2; Caffeine: 0.51  0.13; Caffeine  US: 0.76  0.26,
p  0.0276). Adipocytes isolated from this area also showed
a significant increase in lipolysis stimulated by isoprenaline
(10 mM; Figure 4, and Table 1, 10 mM: Control: 0.25  0.03;
Gel: 0.19  0.07; US: 0.20  0.07; Caffeine: 0.18  0.05; Caffeine
 US: 0.38  0.15, p  0.0029). The CAF  US treatment
promoted an increase of 52% in the production of glycerol at
the maximum concentration of isoprenaline, considering the
glycerol produced by adipocytes isolated from the control area.
Adipocytes isolated from areas treated only with the applica-
tion of Gel, or US, or CAF did not show any significant change
in basal lipolysis or lipolysis stimulated by isoprenaline (1 and
10 mM; Figure 4, Table 1).
Table 1. Basal lipolysis, lipolytic potency, and maximal lipolytic response to
isoprenaline in isolated subcutaneous adipocytes from pigs treated with caffeine
by phonophoresis.
isoprenaline
treatment Basal pd2 emax
Control 0.49  0.05 7.74  0.92 0.25  0.03
Gel 0.61  0.12 7.39  0.93 0.19  0.07
ultrasound 0.48  0.20 7.95  0.60 0.20  0.07
Caffeine 0.51  0.13 7.62  0.69 0.18  0.05
Caffeine  ultrasound 0.76  0.26* 7.35  0.51 0.38  0.15#
the values are the mean  sd of five experiments and are expressed as mmol
glycerol/106cells/60 min. each experiment was run in triplicate, and the results rep-
resent the means of experiments from separate animals done on different days.
the different treatment potencies were compared based on their eC50, that is, the
concentration of agonist inducing 50% of maximal lipolysis, expressed as pd2(2log
eC50). emax is the maximal response minus the basal lipolysis. statistical compari-
sons were done using anoVafollowed by the newman–Keuls test: Basal.
*p  0.0276 compared with the other groups emax.
#p  0.029.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
JOURNAL OF COSMETIC AND LASER THERAPy 5
phosphodiesterase enzyme activity (16). Studies of glycerol pro-
duction induced by isoprenaline in isolated pig adipocytes are
done using theophylline at medium bath. In these conditions,
Gardan et al. (40) show a basal of 35 nmol glycerol/105cells/2
h and 75 nmol glycerol/105cells/2 h when adipocytes were
stimulated by isoproterenol 10 mM plus theophylline 1 mM,
around 100% of glycerol production at maximal concentration
of isoprenaline. Mersmann (41), in turn, showed in adipose tis-
sue slices a stimulation induced by isoprenaline without theo-
phylline of 320%, and 190% in the presence of theophylline. In
these assays, the presence of theophylline induced an increase
of 198% in basal lipolysis after 120 min of incubation. In most
cases, when isolated adipocytes and adipose tissue slices from
the same animal were stimulated with various lipolytic agents
(adrenergic agonists, theophylline, and adenosine deaminase),
the qualitative response was similar. Isolated adipocytes were
not more sensitive than tissue slices to stimulation by lipolytic
agents (42). The maximal responses induced in our conditions
are 1.14  0.17 mmol of glycerol/106 cells/60 min and basal of
0.76  0.11 mmol of glycerol/106 cells/60 min, around 56% of
stimulation. The main difference concerns on how to get xan-
thine effects. Gardan et al. (40) and Mersmann (41) directly used
adipocytes already isolated and we used TDD of adipocytes.
Considering the different densities of ARs it is also possible
to get different amounts of glycerol induced by isoprenaline
while stimulation achieved by isolated adipocytes from subcu-
taneous adipose tissue from pig is around 50–100%, in adipo-
cytes isolated from epididymal adipose tissue it is possible to get
a 200% or 300% stimulation (25, 43). These differences under-
score the importance of studying pigs as a source of fat cells in
order to evaluate the efficiency of drug-dispensing studies by
lipase involved in lipolysis induced both by catecholamines and
by the atrial natriuretic factor, while adipose triacylglycerol
lipase mediates the hydrolysis of triacylglycerides during basal
lipolysis (10). It is known that, as a paracrine mediator, adenos-
ine has an important inhibitory effect on basal lipolysis (36).
Being endogenously released, adenosine acts by binding to an
A1 type membrane receptor expressed in the plasma membrane
of mature adipocytes, and this binding triggers the inhibition
of adenylyl cyclase, which has the ultimate effect of reducing
lipolysis (11, 12). In addition, since caffeine inhibits the action
of adenosine, consequently, the effect of increased basal lipoly-
sis can be inferred as coming from this caffeine effect that was
only seen when the application was associated with US.
Besides, adenosine, acting through A1R, has been impli-
cated in many other physiological functions of adipocytes.
It can be considered as a possible target for inclusion in the
overall management of obesity. The A1R also has a physiologi-
cal role in protecting against obesity-related insulin resistance
(37), and A1R agonism has been shown to lower plasma-free
fatty acids and glycerol in obese Zucker rats (38). In addition,
consumption of large quantities of caffeine has been reported
to be beneficial and associated with a reduced risk of type 2 dia-
betes (39); however, the mechanisms involved remain unclear.
On the other hand, the agonists involved in lipolysis stimula-
tion are well known: the catecholamines, which use the stimula-
tion by the activation of adenylyl cyclase (adrenoceptors), and
more recently the natriuretic peptides via stimulation of guany-
late cyclase (10). As a result, isolated adipocytes from the skin
area treated with caffeine associated with US showed significant
increase in lipolysis stimulated by isoprenaline. Studies confirm
that caffeine and its derivatives stimulate lipolysis by inhibiting
(A) (B)
0
20
40
60
80
100
120
140
160
180 Gel
Control
log [isoprenaline] M
R
e
s
p
o
n
s
e

(
%

o
f

m
a
x
i
m
a
l
)
–10 –9 –8 –7 –6 –5–10 –9 –8 –7 –6 –5
–10 –9 –8 –7 –6 –5 –10 –9 –8 –7 –6 –5
0
20
40
60
80
100
120
140
160
180 CAF
Control
log [isoprenaline] M
R
e
s
p
o
n
s
e

(
%

o
f

m
a
x
i
m
a
l
)
0
20
40
60
80
100
120
140
160
180 US
Control
log [isoprenaline] M
R
e
s
p
o
n
s
e

(
%

o
f

m
a
x
i
m
a
l
)
0
20
40
60
80
100
120
140
160
180 US+CAF
Control
log [isoprenaline] M
R
e
s
p
o
n
s
e

(
%

m
a
x
i
m
a
l
)
(C) (D)
*
*
Figure 4. Concentration–response curves for the stimulation of glycerol released by subcutaneous adipocytes of pigs isolated from dorsal regions exposed to different
treatments: control (▫), gel (▪), us (▴), caffeine (▾), and caffeine plus us (♦). in all cases, the results were normalized relative to the maximal response of control adipocytes
(considered to be 100%). the points are the mean  sem of six experiments, each done in triplicate.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
6 M. S. M. PIRES-DE-CAMPOS ET AL.
US 3 MHz, with 2-min applications and intensities above 1
W/cm2 up to 2 W/cm2 caused a significant increase in the epi-
dermis thickness, the presence of a mild inflammatory infiltra-
tion below the epidermis, and also a change in collagen fibers,
making them thinner and numerous in epithelial tissue of
Wistar rats. This researcher group warns on the use of US in
high doses, especially in esthetic treatments. Furthermore, the
intensity of US shall be chosen according to the target tissue
absorption coefficient as well as with the attenuation coeffi-
cient, which is related to tissues through which the ultrasonic
wave passes before reaching the target tissue, as described in
the methodology. This study, in turn, demonstrates that US was
not efficient in changing the lipolysis or lipolytic response in
adipocytes; however, it was extremely effective in increasing
skin permeation to caffeine that induced local effects. The litera-
ture reports that this increase in permeation is predominantly
mechanical, through cavitations, radiation forces, and acoustic
microflow (7, 8, 55).
A limitation of this study is that treatment is performed on
consecutive days, which usually does not happen in clinical
practice. Although this study focused on the investigation of the
basal lipolytic response of phonophoresis with caffeine, as well
as the one stimulated by isoprenaline, in addition to the sensi-
tivity analysis of beta adrenergic receptors, other studies should
consider the evaluation of adenosine receptors, and adenosine
production, including adenosine deaminase in the incubation
buffer and analyze global responses.
This work confirms the data obtained in previous morpho-
logical research demonstrating that the lipolytic effect of topical
application of caffeine needs association with US therapeutic.
The results demonstrate that increased lipolysis of caffeine  US
is due to an increase in basal and AR response by caffeine, and
caffeine’s effect is local—avoiding unwanted effects.
Acknowledgement
We would like to thank Espaço da Escrita, General Coordination of the
University UNICAMP, for the language services provided.
Funding
We would like to thank the University of Campinas (UNICAMP); the
Foundation for Research Support of the State of São Paulo—FAPESP,
Teaching and Research Support Foundation (FAEP), and the Research
Support Fund (FAP) of the University Methodist of Piracicaba (UNIMEP)
for the financial support.
Declaration ofinterest
The authors report no declarations of interest. The authors alone are
responsible for the content and writing of the paper.
References
1. Wanner M, Avram M. An evidence-based assessment of treatments
for cellulite. J Drugs Dermatol. 2008;7:341–345.
2. De Godoy JMP, De Godoy MFG. Treatment of cellulite based on
the hypothesis of a novel physiopathology. Clin Cosmet Investig
Dermatol. 2011;4:55–59.
the transdermal route delivery. TDD has several significant
advantages compared with oral drug delivery, including elimi-
nation of pain and sustained drug release. However, the use of
TDD is limited by low skin permeability due to the stratum cor-
neum, the outermost layer of the skin. Phonophoresis is a tech-
nique that temporarily increases skin permeability such that
various medications can be delivered noninvasively. The acous-
tic phenomena occurring between the skin and the transducer
US, such as refraction, reflection, absorption, and scattering
produce disturbance in lipid and protein configuration of the
cellular membranes, altering the barrier skin. Based on these
various studies, several possible mechanisms of phonophore-
sis have been suggested. For example, cavitation is believed to
be the predominant mechanism responsible for drug delivery
in phonophoresis (5). Some authors suggest that the increase
in cutaneous temperature induces acceleration in permeation
due to the formation of intracellular spaces and pores (44–46)
as well as by increasing local circulation (47). However, in stud-
ies with massage, even inducing hyperemia and, consequently,
increased temperature did not alter the lipolytic response of adi-
pocytes to isoprenaline, suggesting that caffeine was not perme-
ated enough to induce its effect. These results differ from those
of Velasco et al. (19) who reported a study with topical appli-
cation of caffeine gel that induced a reduction in diameter of
adipocytes in Wistar female mice.
The use of US has also been reported for body contouring
(48, 49). This effect is related to the US’s ability to induce cavi-
tation. Cavitations are easily observed in liquid medium in
response to local variation in the acoustic pressure induced by
the US wave that generates small bubbles. They can be stable in
response to regular pressure changes or unstable when there is
a violent implosion of bubbles associated with an intense peak.
Unstable cavitations induce the production of free radicals (47).
Rohrich et al.(48), using histological and enzyme analyses, did
not find changes in adipocytes after using US and massage.
These results confirm that US only produces the effect on tissues
that absorb its waves and where the adipose tissue absorption
coefficient is very low (3, 24).
Glick et al. (50) also found no significant changes in cAMP
content in the skin, lungs, and peritoneal cells of mice subjected
to US.
The spread of US in biological tissue is longitudinal, where
the tissue particles vibrate parallel to the direction of wave
propagation (51). The US sound field is divided into 2 parts.
The Fresnel zone is the closest zone to the transducer and has a
very irregular beam, with spatial and temporal peaks of energy.
Fraunhofer zone, also called the “far field,” as the farthest from
the transducer, has more regular behavior (52). It is known
that physical therapy treatments, especially those that want
to achieve fat, are performed in the next field, which makes it
difficult to evaluate the wave behavior in the tissue. Another
important aspect to be considered is that the depth of the tissue
that is desired to be reached also determines the choice of the
frequency of the US since the 3-MHz frequency is more shal-
low (approximately 2-cm depth), while 1 MHz is indicated for
deeper tissues (4–5 cm) (53). Although the US is often used for
therapeutic and esthetic purposes, research shows unfounded
data on the intensity, exposure time, and calibration conditions
for US players (54). Bem et al. (54) observed that the ongoing
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
JOURNAL OF COSMETIC AND LASER THERAPy 7
25. Grassi-Kassisse DM, Wolf-Nunes V, Miotto AM, Farias-Silva E,
Souza Brito ARM, Nunes DS, et al. Sensitivity to b-adrenoceptor
agonists of adipocytes from rats treated with an aqueous extract of
Croton cajucara Benth. J Pharm Pharmacol. 2003;55:253–257.
26. Crege DRX de O, Silveira HJV, Chaim ÉAC, Pareja JC, Géloen A,
Grassi-Kassisse DM. Sex difference in lactate production by adipo-
cytes from lean humans. Open J Endocrine Metab Dis. 2014;4:52–58.
27. McGowan MW, Artiss JD, Strandbergh DR, Zak B. A peroxidase
coupled method for the colorimetric determination of serum triglyc-
erides. Clin Chem. 1983;29:538–542.
28. Rice JA. Matematical statistical and data analysis. Belmont: Thomson;
2007.
29. Mills SE, Mersmann HJ. Beta-adrenergic agonists, their receptors,
and growth: Special reference to the peculiarities in pigs. In: Smith SB,
Smith DR, editors. Biology of fat in meat animals: Current advances.
Champaign, IL: American Society of Animal Science; 1995. pp. 1–34.
30. Liang W, Mills SE. Distribution of beta-adrenergic receptor subtypes
in pig tissues. FASEB J. 1999;13:A258.
31. Huong SR, Bun H, Fourneron JD, Reynier JP, Andrieu V. Use of
various models for in vitro percutaneous absorption studies of
ultraviolet filters. Skin Res Technol. 2009;15:253–261.
32. Di Giancamillo A, Rossi R, Vitari F, Pastorelli F, Corino C,
Domeneghini C. Dietaryconjugatedlinoleicacidsdecreaseleptin in
porcine adipose tissue. J Nutr. 2009;139:1867–1872.
33. Guimarães GN, Chorilli M, Leonardi GR, Prestes OS, Garcia G,
Pires-de-Campos MSM, Polacow MLO. Effects of formulations
containing dimethylaminoethanol (DMAE) acetoamidobenzoate and
pidolate on the skin. Lat Am J. 2011;30:614–616.
34. Feve B, Emorine LJ, Lasnier F, Blin N, Baude B, Nahmias C,
Strosberg AD, Pairault J. 1991. Atypical b-adrenergic receptor in
3T3–F442A adipocytes. J Biol Chem. 1991;266:20329–20336.
35. Langin D, Portillo MP, Saulnier-Blache J-S, Lafontan M. Coexistence
of three b-adrenoceptor subtypes in white fat cells of various mam-
malian species. Eur J Pharmacol. 1991:199;291–301.
36. Castan I, Valet P, Quideau N, Voisin T, Ambid L, Laburthe M,
et al. Antilipolytic effects of alpha2-adrenergic agonists, neuropep-
tide Y, adenosine, and PGE1 in mammal adipocytes. Am J Physiol.
1994;266:R1141–R1147.
37. Dong Q, Ginsberg HN, Erlanger BF. Overexpression of the A1 ade-
nosine receptor in adipose tissue protects mice from obesity related
insulin resistance. Diabetes Obes Metab. 2001;3:360–366.
38. Schoelch C, Kuhlmann J, Gossel M, Mueller G, Neumann-Haefelin C,
Belz U et al. Characterization of adenosine-A1 receptor-mediated
antilipolysis in rats by tissue microdialysis, 1 H spectroscopy and
glucose clamp studies. Diabetes. 2004;53:1920–1926.
39. van Dam RM, Hu FB. Coffee consumption and risk of type 2 diabetes:
A systematic review. J Am Med Assoc. 2005;294:97–104.
40. Delphine G, Gondret F, Louveau, I. Lipid metabolism and secretory
function of porcine intramuscular adipocytes compared with subcu-
taneous and perirenal adipocytes. Am J Physiol Endocrinol Metab.
2006;291:E372–E380.
41. Mersmann HJ. Adenosine-theophylline interactions on the lipolytic
response to beta-adrenergic agonists in porcine adipose tissue. Camp
Biochem Physiol. 1992; 103C(3):541–547.
42. Mersmann HJ, Shparber A. Is the lipolytic response in porcine
adipose tissue slices equivalent to the lipolytic response in isolated
adipocytes? Int J Biochem. 1993;25(11):1673–1679.
43. Farias-Silva E, Grassi-Kassisse DM, Wolf-Nunes V, Spadari-Bratfisch,
RC. Stress-induced alteration in the lipolytic response to b-adrenoceptor
agonists in rat white adipocytes. J Lip Res. 1999;40(9):1719–1727.
44. Rao R, Nanda S. Sonophoresis:Recent advancements and future
trends. J Pharm Pharmacol. 2009;61:689–705.
45. Zhao YZ, Du LN, Lu CT, Jin YG, Ge SP. Potential and problems in
ultrasound-responsive drug delivery systems. Int J Nanomedicine.
2013;8:1621–1633.
46. Azagury A, Khoury L, Enden G, Kost J. Ultrasound mediated trans-
dermal drug delivery. Adv Drug Deliv Rev. 2014;72:127–143.
47. Polat BE, Hart D, Langer R, Blankschtein D. Ultrasound-mediated
transdermal drug delivery: mechanisms, scope, and emerging trends.
J Control Rel. 2011;152:330–348.
3. Akomeah FK. Topical dermatological drug delivery: Quo vadis?
Current Drug Deliv. 2010;7(4):283–296.
4. Fellinger K, Schmid J. Klinik und merapiedes Chmnischen
Gelenkhuematismum. Vienna, Austria: Maudrich (Austrian);1954:
549–552.
5. Park D, Park H, Seo J, Lee S. Sonophoresis in transdermal drug deliv-
erys. Ultrasonics 2014;54:56–65.
6. Maia Filho ALM, Villaverde AB, Munin E, Aimbire F, Albertini R.
Comparative study of the topical application of aloe vera gel,
therapeutic ultrasound and phonophoresis on the tissue repair in
collagenase-induced rat tendinitis. Ultrasound Med Biol. 2010;36:
1682–1690.
7. Pires-De-Campos MSM, Polacow MLO, Granzotto TM,
Spadari-Bratfisch RC, Leonardi GR, Grassi-Kassisse DM. Influence of
the ultrasound in cutaneous permeation of the caffeine: In vitro study.
Pharmacol Online. 2007;1:477–486. Retrieve from: http://pharmacol-
ogyonline.silae.it/files/archives/2007/vol1/49_Campos.pdf
8. Pires-De-Campos MSM, Leonardi GR, Chorilli M, Spadari-Bratfisch
RC, Polacow MLO, Grassi-Kassisse DM. The effect of topical caffeine
on the morphology of swine hypodermis as measured by ultrasound.
J Cosm Derm 2008;7:232–237.
9. Boucaud A, Machet L, Arbeille B, Machet M, Sournac M, Mavon A,
Patat F, Vaillant L. In vitro study of low-frequency ultrasound-
enhanced transdermal transport of fentanyl and caffeine across
human and hairless rat skin, Int. J. Pharm. 2001;228:69–77.
10. Langin D. Adipose tissue lipolysis as a metabolic pathway to define
pharmacological strategies against obesity and the metabolic syn-
drome. Pharmacol Res. 2006;53:482–491.
11. Dhalla AK, Chisholm JW, Reaven GM, Belardinelli L. A1 adenos-
ine receptor: role in diabetes and obesity. Handb Exp Pharmacol.
2009;193:271–295.
12. Gharibi B, Abraham AA, Ham J, Evans BAJ. Contrasting effects
of A1 and A2b adenosine receptors on adipogenesis. Int J Obes.
2012;36:397–406.
13. Dias M, Farinha A, Faustino E, Hadgraft J, Pais J, Toscano C. Topical
delivery of caffeine from some commercial formulations. Int J Pharm.
1999;182:41–47.
14. Sarheed O, Rasool BKA. Development of an optimised application
protocol for sonophoretic transdermal delivery of a model hydro-
philic drug. Open Biomed Eng J. 2011;5:14–24.
15. Fredholm BB, Battig K, Holmen J, Nehlig A, Zvartau EE. Actions of
caffeine in the brain with special reference to factors that contribute to
its widespread use. Pharmacol Rev. 1999;51:83–133.
16. Herman A, Herman AP. Caffeine’s mechanisms of action and its
cosmetic use. Skin Pharmacol Physiol. 2013;26:8–14.
17. Siddons S. Cellulite causes and treatments. Discov Fit Health.
2013;22:1 http://health.howstuffworks.com/skin-care/problems/
beauty/cellulite2015.htm
18. Lupi O, Semenovitch IJ, Treu C, Bottino D, Bouskela E. Evaluation
of the effects of caffeine in the microcirculation and edema on thighs
and buttocks using the orthogonal polarization spectral imaging and
clinical parameters. J Cosmet Dermatol. 2007;6(2):102–107.
19. Velasco MV, Tano CT, Machado-Santelli GM, Consiglieri VO,
Kaneko TM, Baby AR. Effects of caffeine and siloxanetriol alginate
caffeine, as anticellulite agents, on fatty tissue: histological evaluation.
J Cosmet Dermatol. 2008;7(1):23–29.
20. Bergen WG, MersmannHJ. Comparative aspects of lipid metabolism:
Impact on contemporary research and use of animal models. J Nutr.
2005;135:2499–2502.
21. McNeel RL, Mersmann HJ. Distribution and quantification of beta1-,
beta2- and beta3- adrenergic receptor subtype transcripts in porcine
tissues. J Anim Sci. 1999;77:611–621.
22. Ding ST, McNeel RL, O’Brian Smith E, Mersmann HJ. Modulation of
porcine adipocyte b-adrenergic receptors by a b-adrenergic agonist.
J Anim Sci. 2000;78:919–929.
23. Olfert ED, Cross BM, McWilliam AA. Guide to the care and use of
experimental animals. Ottawa, Ontario: Canadian Council on Animal
Care; 1993. p. 213.
24. Watson R. Ultrasound in contemporary physiotherapy pratice.
Ultrasonics. 2008;48:321–329.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
8 M. S. M. PIRES-DE-CAMPOS ET AL.
52. Hedrick WR, Hykes DL, Starchman DL. Ultrasound physics and
instrumentation. Saint Louis: Mosby; 2005.
53. Altomare M, Nascimento AP, Romana-Souza B, Amadeu TP,
Monte-Alto-Costa A. Ultrasound accelerates healing of normal wounds
but not of ischemic ones. Wound Repair Regen. 2009;17(6):825–831.
54. Bem DM, Maciel CD, Zuanon JÁ, Neto CB, Parizotto NA. Histological
analysis of healthy epithelium of Wistar rats in vivo irradiated with
different intensities of therapeutic ultrasound. Rev Bras Fisioter.
2010;14(2):114–120.
55. Goraj-Szczypiorowska B, Zajac L, Skalska-Izdebska R. Evaluation of
factors influencing the quality and efficacy of ultrasound and phono-
phoresis treatment. Ortop Traumatol Rehabil. 2007;9:449–584.
48. Rohrich RJ, Morales DE, Krueger JE, Ansari M, Ochoa O Jr
et al. Comparative lipoplasty analysis of in vivo-treated adipose
tissue. Plast Reconstr Surg. 2000;105:2152–2158.
49. Garcia O Jr, Schafer M. The effects of nonfocused external ultrasound
on tisseu temperature and adipocyte morphology. Aesthet Surg J.
2013;33:117–127.
50. Glick D, Adamovics A, Edmonds PD, Taenzer JC. Search for
biochemical effects in cells and tissues of ultrasonic irradiation of
mice and of the in vitro irradiation of mouse peritoneal and human
amniotic cells. Ultrasound Med Biol. 1979;5:23–33.
51. Leighton TG. What is ultrasound? Prog Biophys Mol Biol. 2007;
93(1–3):3–83.
D
ow
nl
oa
de
d
by
 [
G
az
i U
ni
ve
rs
ity
]
at
 0
9:
19
 2
8
Ja
nu
ar
y
20
16

Licenciado para - Franciane Cardoso Ramos - 03185733002 - Protegido por Eduzz.com
