Professor Obert has observed in his famous treatise on Thermodynamics that concepts are
better understood by their repeated applications to real life situations. A firm conviction of
this principle has prompted the author to arrange the text material in each chapter in the
following order.
In the first section after enunciating the basic concepts and laws mathematical models
are developed leading to rate equations for heat transfer and determination of temperature
field, simple and direct numerical examples are included to illustrate the basic laws. More
stress is on the model development as compared to numerical problems.
A section titled “SOLVED PROBLEMS” comes next. In this section more involved
derivations and numerical problems of practical interest are solved. The investigation of the
effect of influencing parameters for the complete spectrum of values is attempted here. Problems
involving complex situations are shown solved in this section. Two important ideas are stressed
in this section. These are checking of dimensional homogeneity in the case of all equations
derived and the validation of numerical answers by cross checking. This concept of validation
in professional practice is a must in all design situations.
In the next section objective type questions are given. These are very useful for
understanding the basis and resolving misunderstandings.
In the final section a large number of graded exercise problems involving simple to
complex situations are included.
In the first of the 14 chapters the basic laws for the three modes of heat transfer are
introduced and the corresponding rate equations are developed. The use of electrical analogy
is introduced and applied to single and multimode heat transfer situations. The need for iterative
working is stressed in the solved problems.
The second chapter deals with one dimensional steady state conduction. Mathematical
models are developed by the three geometries namely Plate, Hollow Cylinder and Hollow Sphere.
Multilayer insulation is also discussed. The effect of variation of thermal conductivity on heat
transfer and temperature field is clearly brought out. Parallel flow systems are discussed.
Examples on variation of area along the heat flow direction are included. The use of electrical
analogy is included in all the worked examples. The importance of calculating the temperature
gradient is stressed in many of the problems.
In the third chapter models for conduction with heat generation are developed for three
geometric configurations namely plate, cylinder and sphere. The effect of volume to surface
area and the convection coefficient at the surface in maintaining lower material temperature
is illustrated. Hollow cylindrical shape with different boundary conditions is discussed.
Conduction with variable heat generation rate is also modelled.
Fins/extended surface or conduction-convection situation is discussed in the fourth
chapter. Models for heat transfer and temperature variation are developed for four different
PREFACE TO THE THIRD EDITION
boundary conditions. Optimisation of the shape of the fin of specified volume for maximum
heat flow is discussed. Circumferential fins and variable area fins are analysed. The use of
numerical method is illustrated. Error in measurement of temperature using thermometer is
well discussed. The possibility of measurement of thermal conductivity and convective heat
transfer coefficient using fins is illustrated.
Two dimensional steady state conduction is discussed in the fifth chapter. Exact analysis
is first developed for two types of boundary conditions. The use of numerical method is illustrated
by developing nodal equations. The concept and use of conduction shape factor is illustrated
for some practical situations.
One dimensional transient (unsteady) heat conduction is discussed in Chapter 6. Three
types of models arise in this case namely lumped heat capacity system, semi-infinite solid and
infinite solid. Lumped heat capacity model for which there are a number of industrial
applications is analysed in great detail and problems of practical interest are shown solved.
The condition under which semi-infinite solid model is applicable as compared to infinite solid
model is clearly explained. Three types of boundary conditions are analysed. Infinite solid
model for three geometric shapes is analysed next. The complexity of the analytical solution is
indicated. Solution using charts is illustrated in great detail. Real solids are of limited
dimensions and these models cannot be applied directly in these cases. In these cases product
solution is applicable. A number of problems of practical interest for these types of solids are
worked out in this section. In both cases a number of problems are solved using numerical
methods. Periodic heat flow problems are also discussed.
Concepts and mechanism of convection are discussed in the seventh chapter. After
discussing the boundary layer theory continuity, momentum and energy equations are derived.
Next the different methods of solving these equations are discussed. In addition to the exact
analysis approximate integral method, analogy method and dimensional analysis are also
discussed and their applicability is indicated. General correlations for convective heat transfer
coefficient in terms of dimensionless numbers are arrived at in this chapter.
In Chapter 8, in addition to the correlations derived in the previous chapter, empirical
correlations arrived at from experimental results are listed and applied to flow over surfaces
like flat plate, cylinder, sphere and banks of tubes. Both laminar and turbulent flows situation
are discussed.
Flow through ducts is discussed in Chapter 9. Empirical correlations for various situations
are listed. Flow developing region, fully developed flow conditions, constant wall temperature
and constant wall heat flux are some of the conditions analysed. Flow through non-circular
pipes and annular flow are also discussed in this chapter.
Natural convection is dealt with in Chapter 10. Various geometries including enclosed
space are discussed. The choice of the appropriate correlation is illustrated through a number
of problems. Combined natural and forced convection is also discussed.
Chapter 11 deals with phase change processes. Boiling, condensation, freezing and
melting are discussed. Basic equations are derived in the case of freezing and melting and
condensation. The applicable correlations in boiling are listed and their applicability is
illustrated through numerical examples.
Chapter 12 deals with heat exchangers, both recuperative and regenerative types. The
LMTD and NTU-effectiveness methods are discussed in detail and the applicability of these
methods is illustrated. Various types of heat exchangers are compared for optimising the size.
vi PREFACE
Thermal radiation is dealt with in Chapter 13. The convenience of the use of electrical
analogy for heat exchange among radiating surfaces is discussed in detail and is applied in
almost all the solved problems. Gas radiation and multi-body enclosures are also discussed.
Chapter 14 deals with basic ideas of mass transfer in both diffusion and convection
modes. A large number of problems with different fluid combinations are worked out in this
chapter.
A large numbernoting that temperature is a function of all the four,
the following steps lead to the general differential equation (Ref. Fig. 2.1(a)).
dx
dy
dz
qx qy
qz
z
x
y
x
y
z
P(x, y, z)
Fig. 2.1. (a) An elemental volume considered in cartesian coordinates.
The heat flow by conduction through the boundary is obtained by considering the
conduction over all six faces. The area perpendicular to x direction has a value dydz. Using
Fourier’s law, the heat flow at the dydz face at x over time period dτ = – k dydz . ∂
∂
T
x
 dτ
The flow at x + dx is = – k dy dz dτ ∂
∂
∂
∂
τ ∂
∂
T
x x
k dy dz d T
x
dx+ −FHG
I
KJ
The net flow in the x direction is obtained by taking the sum of these two which yields
∂
∂
∂
∂
τ
x
k T
x
dy dz d dx. .F
HG
I
KJ = ∂
∂
∂
∂
τ
x
k T
x
dx dy dz d. .F
HG
I
KJ
Similar consideration in y and z directions give
∂
∂
∂
∂
τ
y
k T
y
dx d dz dy.F
HG
I
KJ and ∂
∂
∂
∂
τ
z
k T
z
dx dy d dz.F
HG
I
KJ
Heat generated in the volume during dτ is given by q dx dy dz dτ
The change in the energy of this volume over the time dτ when temperature changes is
ρc dx dy dz ∂T.
The sum is simplified by assuming dx, dy and dz do not change along the coordinate
directions and k is constant
∂
∂
∂
∂
∂
∂
ρ ∂
∂τ
2 2 2T
x
T
y
T
z
q
k
c
k
T
2 2 2+ + + = . ...(2.2)
k
cρ
 is defined as thermal diffusivity denoted by α.
∴
∂
∂
∂
∂
∂
∂ α
∂
∂τ
2 2 2T
x
T
y
T
z
q
k
T
2 2 2
1+ + + = . ...(2.3)
VED
c-4\n-demo\damo2-1
28 FUNDAMENTALS OF HEAT AND MASS TRANSFER
If say k varies with location it should be within the differential like ∂
∂
∂
∂x
k T
x
F
HG
I
KJ and the
integration of the equation has to consider the functionality of k with direction.
2.1.2. Similar steps may be followed to obtain the following differential equations in the
cylindrical and spherical coordinate systems. Here it has to be noted that the area value
changes in the coordinate directions.
In cylindrical coordinate (r, Φ, z), Fig. 2.1 (b), we get
1 1
2r r
kr T
r r
k T∂
∂
∂
∂
∂
∂Φ
∂
∂Φ
F
HG
I
KJ + F
HG
I
KJ + F
HG
I
KJ + =∂
∂
∂
∂
ρ ∂
∂τz
k T
z
q c T ...(2.4)
With k constant eqn. in 2.4 reduces to
1 1
2
2
2r r
r T
r r
T∂
∂
∂
∂
∂
∂Φ
F
HG
I
KJ + + + =
∂
∂ α
∂
∂τ
2
2
1T
z
q
k
T. ...(2.4a)
dz
Z
dr
r
(r, , z)�
Y
X
� d�
Z
(r, , )	 �
Y
X
� d�
Z
dr

d
Fig. 2.1. (b) Elemental volume in cylindrical Fig. 2.1. (c) Elemental volume in spherical
 coordinates. coordinates.
In spherical coordinates (r, Φ, θ), Fig. 2.1(c), we get
1 1
2
2
2 2r r
kr T
r r
k T∂
∂
∂
∂ θ
∂
∂Φ
∂
∂Φ
F
HG
I
KJ + F
HG
I
KJsin
.
+ 1
2r
k T q c T
sin
. sin
θ
∂
∂θ
θ ∂
∂θ
ρ ∂
∂τ
F
HG
I
KJ + = FHG
I
KJ ...(2.5)
With k constant eqn. 2.5 reduces to
1 1
2
2
2 2
2
2r r
r T
r r
T∂
∂
∂
∂ θ
∂
∂Φ
F
HG
I
KJ +
F
HG
I
KJsin
.
+ 1 1
2r
T q
k
T
sin
. sin
θ
∂
∂θ
θ ∂
∂θ α
∂
∂τ
F
HG
I
KJ + = FHG
I
KJ ...(2.5a)
