CAT C4 4 PARTS MANUAL J1Z1-UP S1M1-UP

Prévia do material em texto

TThhiiss PPaarrttss MMaannuuaall iiss aallssoo AAvvaaiillaabbllee iinn PPDDFF FFoorrmmaatt oonn CCoommppaacctt
DDiisskk ((CCDD--RROOMM))-- CCaatteerrppiillllaarr FFoorrmm NNoo.. SSEERRPP44115522
SAFETY.CAT.COM
Parts
Manual
C4.4 Marine Gen Set
LL11KK11--UUpp ((GGeenneerraattoorr SSeett))
SS11MM11--UUpp ((GGeenneerraattoorr
SSeett))
DD11KK11--UUpp ((EEnnggiinnee))
JJ11ZZ11--UUpp ((EEnnggiinnee))
SSEEBBPP44115522--4488
AAuugguusstt 22001144
PPrroodduucctt aanndd DDeeaalleerr IInnffoorrmmaattiioonn
Note: For product identification plate locations, see the section “Product Identification Information” in the
Operation and Maintenance Manual.
DDeelliivveerryy DDaattee::
PPrroodduucctt IInnffoorrmmaattiioonn
Model:
Product Identification Number:
Engine Serial Number:
Transmission Serial Number:
Generator Serial Number:
Attachment Serial Numbers:
Attachment Information:
Customer Equipment Number:
Dealer Equipment Number:
DDeeaalleerr IInnffoorrmmaattiioonn
Name: Branch:
Address:
Dealer Contact Phone Number Hours
Sales:
Parts:
Service:
MMEEMMOORRAANNDDAA
MEMORANDA SEBP4152-48
SEBP4152-48 TABLE OF CONTENTS AA11
GGEENNEERRAALL IINNFFOORRMMAATTIIOONN .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. AA33
RREEPPAAIIRR AALLTTEERRNNAATTIIVVEESS .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. AA66
SSUUPPPPLLEEMMEENNTTAALL CCOOOOLLAANNTT
AADDDDIITTIIVVEESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A7
MMAAIINNTTEENNAANNCCEE PPAARRTTSS.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. AA88
IINNDDEEXX.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. ..AA1122
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 11
ENGINE AR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
ENGINE AR-COMPLETE . . . . . . . . . . . . . . . . . . . . . . 2
ENGINE AR-PRIMARY . . . . . . . . . . . . . . . . . . . . . . . 12
GENERAL AR-GENERATOR. . . . . . . . . . . . . . . . . . 19
BBAASSIICC EENNGGIINNEE.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 2200
BARRING & MOUNTING GP . . . . . . . . . . . . . . . . . 20
BRACKET GP-MOUNTING. . . . . . . . . . . . . . . . . . . . 21
CAMSHAFT GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
COUPLING GP-GENERATOR. . . . . . . . . . . . . . . . . 27
COVER GP-CYLINDER HEAD . . . . . . . . . . . . . . . . 29
COVER GP-ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . 30
COVER GP-ENGINE LIFTING EYE . . . . . . . . . . . 31
COVER GP-FRONT HOUSING. . . . . . . . . . . . . . . . 34
COVER GP-VALVE MECHANISM . . . . . . . . . . . . . 36
CRANKSHAFT GP . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
CYLINDER BLOCK GP. . . . . . . . . . . . . . . . . . . . . . . 67
CYLINDER HEAD GP. . . . . . . . . . . . . . . . . . . . . . . . 77
GUARD GP-BELT. . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
HOUSING GP-FLYWHEEL. . . . . . . . . . . . . . . . . . . . 86
HOUSING GP-FRONT. . . . . . . . . . . . . . . . . . . . . . . . 88
LIFTING GP-ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . 90
MOUNTING GP-ALTERNATOR. . . . . . . . . . . . . . . . 94
MOUNTING GP-BRACKET. . . . . . . . . . . . . . . . . . . . 95
MOUNTING GP-ENGINE . . . . . . . . . . . . . . . . . . . . . 97
MOUNTING GP-ENGINE &
GENERATOR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
PAN GP-OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
PISTON & ROD GP . . . . . . . . . . . . . . . . . . . . . . . . 110
PISTON GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
PLUG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
PLUG GP-ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . 125
PULLEY GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
PULLEY GP-CRANKSHAFT. . . . . . . . . . . . . . . . . . 129
PULLEY GP-FAN DRIVE . . . . . . . . . . . . . . . . . . . . 130
PULLEY GP-WATER PUMP . . . . . . . . . . . . . . . . . 131
ROCKER ARM GP . . . . . . . . . . . . . . . . . . . . . . . . . 133
SHAFT GP-STUB . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
SPACER GP-BLOCK. . . . . . . . . . . . . . . . . . . . . . . . 135
V-BELT GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
V-BELT SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
VALVE MECHANISM GP. . . . . . . . . . . . . . . . . . . . 138
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 114444
BREATHER GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
DRAIN GP-OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
FILTER GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . 150
LINES GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . 154
LINES GP-OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 155
PUMP GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . 156
CCOOOOLLIINNGG SSYYSSTTEEMM.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 115577
CONNECTION GP-WATER . . . . . . . . . . . . . . . . . . 157
CONNECTOR GP-CAB HEATER
LINES. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
COOLER GP-ENGINE OIL. . . . . . . . . . . . . . . . . . . 164
COOLER GP-FLTR BASE & ENG
OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
COVER GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
FITTING GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
FLANGE GP-RADIATOR . . . . . . . . . . . . . . . . . . . . 175
HEAT EXCHANGER GP-SEA
WATER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 176
HOSE GP-RADIATOR . . . . . . . . . . . . . . . . . . . . . . . 178
KIT-WATER PUMP. . . . . . . . . . . . . . . . . . . . . . . . . . 180
LINES GP-WATER. . . . . . . . . . . . . . . . . . . . . . . . . . 181
PUMP GP-AUXILIARY SEA WATER . . . . . . . . . 235
PUMP GP-WATER. . . . . . . . . . . . . . . . . . . . . . . . . . 237
RADIATOR & MOUNTING GP . . . . . . . . . . . . . . . 243
RADIATOR AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
RADIATOR GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
TANK GP-COOLANT. . . . . . . . . . . . . . . . . . . . . . . . 251
TANK GP-EXPANSION. . . . . . . . . . . . . . . . . . . . . . 256
TUBE AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM .. .. .. .. .. .. .. .. .. 225599
ADAPTER-EXHAUST. . . . . . . . . . . . . . . . . . . . . . . . 259
AFTERCOOLER GP . . . . . . . . . . . . . . . . . . . . . . . . 260
AIR CLEANER GP. . . . . . . . . . . . . . . . . . . . . . . . . . 262
ELBOW GP-AIR INLET. . . . . . . . . . . . . . . . . . . . . . 277
ELBOW GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . . 278
EXHAUST GP-FLEXIBLE . . . . . . . . . . . . . . . . . . . . 291
EXTENSION GP-EXHAUST . . . . . . . . . . . . . . . . . . 293
FASTENER GP-FILTER . . . . . . . . . . . . . . . . . . . . . 294
FLANGE GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . 295
MANIFOLD GP-EXHAUST . . . . . . . . . . . . . . . . . . . 297
MOUNTING GP-AIR CLEANER . . . . . . . . . . . . . . 300
MOUNTING GP-EXHAUST. . . . . . . . . . . . . . . . . . . 301
SHIELD GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . . 302
TURBOCHARGER GP . . . . . . . . . . . . . . . . . . . . . . 308
VALVE GP-DRAIN . . . . . . . . . . . . . . . . . . . . . . . . . . 318
FFUUEELL SSYYSSTTEEMM .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 331199
BRACKET GP-MOUNTING. . . . . . . . . . . . . . . . . . . 319
FILTER & LINES GP-FUEL. . . . . . . . . . . . . . . . . . 320
FILTER GP-FUEL . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
LINES GP-FLEXIBLE FUEL.NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 232-7528 1 CAMSHAFT GP 22
–OR–
Y 367-2792 1 CAMSHAFT GP 26
Y 230-8086 1 CONNECTION GP-WATER 157
Y 238-2799 1 COOLER GP-FLTR BASE & ENG OIL 166
Y 272-2230 1 COVER GP-CYLINDER HEAD 29
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 272-2228 1 COVER GP-VALVE MECHANISM 36
Y 232-7439 1 CRANKSHAFT GP 56
–OR–
Y 367-2788 1 CRANKSHAFT GP 65
Y 232-7606 1 CYLINDER BLOCK GP 69
–OR–
Y 367-2787 1 CYLINDER BLOCK GP 76
Y 232-7524 1 CYLINDER HEAD GP 78
–OR–
Y 367-2790 1 CYLINDER HEAD GP 83
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 232-7442 1 PISTON & ROD GP 110
–OR–
Y 367-2789 1 PISTON & ROD GP 120
Y 225-4317 1 PLUG GP-ENGINE 125
Y 232-6204 1 PLUG GP-ENGINE 126
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 272-2799 1 PUMP GP-FUEL INJECTION 348
Y 230-7355 1 PUMP GP-WATER 237
Y 232-7526 1 VALVE MECHANISM GP 138
–OR–
Y 367-2791 1 VALVE MECHANISM GP 143
AVAILABLE GASKET KIT(S):
277-5156 1 KIT-GASKET (TOP)
272-2232 1 KIT-GASKET (BOTTOM)
Y - SEPARATE ILLUSTRATION
>
1144 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
272-2841 ENGINE AR-PRIMARY*R
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1000 i05832984
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 232-7528 1 CAMSHAFT GP 22
–OR–
Y 367-2792 1 CAMSHAFT GP 26
Y 230-8086 1 CONNECTION GP-WATER 157
Y 238-2799 1 COOLER GP-FLTR BASE & ENG OIL 166
Y 272-2230 1 COVER GP-CYLINDER HEAD 29
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 272-2228 1 COVER GP-VALVE MECHANISM 36
–OR–
Y 367-2220 1 COVER GP-VALVE MECHANISM 51
Y 232-7439 1 CRANKSHAFT GP 56
–OR–
Y 367-2788 1 CRANKSHAFT GP 65
Y 232-7606 1 CYLINDER BLOCK GP 69
–OR–
Y 367-2787 1 CYLINDER BLOCK GP 76
Y 232-7524 1 CYLINDER HEAD GP 78
–OR–
Y 367-2790 1 CYLINDER HEAD GP 83
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 232-7442 1 PISTON & ROD GP 110
–OR–
Y 367-2789 1 PISTON & ROD GP 120
Y 225-4317 1 PLUG GP-ENGINE 125
Y 232-6204 1 PLUG GP-ENGINE 126
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 272-2291 1 PUMP GP-FUEL INJECTION 341
Y 230-7355 1 PUMP GP-WATER 237
Y 232-7526 1 VALVE MECHANISM GP 138
–OR–
Y 367-2791 1 VALVE MECHANISM GP 143
AVAILABLE GASKET KIT(S):
277-5156 1 KIT-GASKET (TOP)
272-2232 1 KIT-GASKET (BOTTOM)
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 1155
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
273-0872 ENGINE AR-PRIMARY*R
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1000 i05205993
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 233-7236 1 CAMSHAFT GP 23
–OR–
Y 367-2089 1 CAMSHAFT GP 25
Y 230-8086 1 CONNECTION GP-WATER 157
Y 245-4665 1 CONNECTOR GP-CAB HEATER LINES 163
Y 253-2472 1 COOLER GP-FLTR BASE & ENG OIL 168
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 273-0871 1 COVER GP-VALVE MECHANISM 44
Y 233-7027 1 CRANKSHAFT GP 59
–OR–
Y 367-2085 1 CRANKSHAFT GP 64
Y 233-7007 1 CYLINDER BLOCK GP 71
–OR–
Y 367-2084 1 CYLINDER BLOCK GP 75
Y 233-7234 1 CYLINDER HEAD GP 79
–OR–
Y 367-2087 1 CYLINDER HEAD GP 82
Y 233-7491 1 ELBOW GP-AIR INLET 277
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 233-7233 1 PISTON & ROD GP 114
–OR–
Y 367-2086 1 PISTON & ROD GP 118
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 273-0869 1 PUMP GP-FUEL INJECTION 354
–OR–
Y 367-2070 1 PUMP GP-FUEL INJECTION 370
Y 230-7355 1 PUMP GP-WATER 237
Y 233-7235 1 VALVE MECHANISM GP 139
–OR–
Y 367-2088 1 VALVE MECHANISM GP 142
267-5367 1 CYLINDER BLOCK GP-SHORT
AVAILABLE GASKET KIT(S):
277-5156 1 KIT-GASKET (TOP)
272-0494 1 KIT-GASKET (BOTTOM)
Y - SEPARATE ILLUSTRATION
>
1166 ENGINE ARRANGEMENT 1 of 2 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
273-1454 ENGINE AR-PRIMARY*R
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1000 i05811903
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 232-7528 1 CAMSHAFT GP 22
S/N: J1Z1-247
Y 288-1434 1 CAMSHAFT GP 24
S/N: J1Z248-3105
Y 367-2792 1 CAMSHAFT GP 26
S/N: J1Z3106-UP
Y 230-8086 1 CONNECTION GP-WATER 157
Y 238-2799 1 COOLER GP-FLTR BASE & ENG OIL 166
Y 272-2230 1 COVER GP-CYLINDER HEAD 29
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 272-2228 1 COVER GP-VALVE MECHANISM 36
S/N: J1Z1-3105
Y 367-2220 1 COVER GP-VALVE MECHANISM 51
S/N: J1Z3106-UP
Y 232-7439 1 CRANKSHAFT GP 56
S/N: J1Z1-247
Y 274-4717 1 CRANKSHAFT GP 61
S/N: J1Z248-3105
Y 367-2788 1 CRANKSHAFT GP 65
S/N: J1Z3106-UP
Y 232-7606 1 CYLINDER BLOCK GP 69
S/N: J1Z1-247
Y 274-4718 1 CYLINDER BLOCK GP 73
S/N: J1Z248-3105
Y 367-2787 1 CYLINDER BLOCK GP 76
S/N: J1Z3106-UP
Y 232-7524 1 CYLINDER HEAD GP 78
S/N: J1Z1-247
Y 288-1424 1 CYLINDER HEAD GP 81
S/N: J1Z248-3105
Y 367-2790 1 CYLINDER HEAD GP 83
S/N: J1Z3106-UP
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL (ENGINE) 106
Y 232-7442 1 PISTON & ROD GP 110
S/N: J1Z1-247
Y 274-4720 1 PISTON GP 122
S/N: J1Z248-3105
Y 367-2789 1 PISTON & ROD GP 120
S/N: J1Z3106-UP
Y 225-4317 1 PLUG GP-ENGINE (FRONT HOUSING, CYLINDER HEAD) 125
Y 232-6204 1 PLUG GP-ENGINE (CYLINDER HEAD) 126
Y 253-2479 1 PLUG GP-ENGINE (CYLINDER BLOCK) 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 273-1407 1 PUMP GP-FUEL INJECTION 357
Y 230-7355 1 PUMP GP-WATER 237
Y 232-7526 1 VALVE MECHANISM GP 138
S/N: J1Z1-247
Y 275-0170 1 VALVE MECHANISM GP 140
S/N: J1Z248-3105
Y 367-2791 1 VALVE MECHANISM GP 143
S/N: J1Z3106-UP
AVAILABLE GASKET KIT(S):
SEBP4152-48 2 of 2 ENGINE ARRANGEMENT 1177
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
273-1454 ENGINE AR-PRIMARY (ccoonnttdd..) i05811903
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
277-5156 1 KIT-GASKET (TOP)
272-0494 1 KIT-GASKET (BOTTOM)
Y - SEPARATE ILLUSTRATION
>
1188 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
286-2370 ENGINE AR-PRIMARY*R
S/N: J1Z1-UP
118 BRAKE KW (158 BHP) AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i05834197
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 232-7528 1 CAMSHAFT GP 22
–OR–
Y 288-1434 1 CAMSHAFT GP 24
–OR–
Y 367-2792 1 CAMSHAFT GP 26
Y 230-8086 1 CONNECTION GP-WATER 157
Y 238-2799 1 COOLER GP-FLTR BASE & ENG OIL 166
Y 272-2230 1 COVER GP-CYLINDER HEAD 29
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 272-2228 1 COVER GP-VALVE MECHANISM 36
–OR–
Y 367-2220 1 COVER GP-VALVE MECHANISM 51
Y 232-7439 1 CRANKSHAFT GP 56
–OR–
Y 274-4717 1 CRANKSHAFT GP 61
–OR–
Y 367-2788 1 CRANKSHAFT GP 65
Y 232-7606 1 CYLINDER BLOCK GP 69
–OR–
Y 274-4718 1 CYLINDER BLOCK GP 73
–OR–
Y 367-2787 1 CYLINDER BLOCK GP 76
Y 232-7524 1 CYLINDER HEAD GP 78
–OR–
Y 288-1424 1 CYLINDER HEAD GP 81
–OR–
Y 367-2790 1 CYLINDER HEAD GP 83
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 232-7442 1 PISTON & ROD GP 110
–OR–
Y 274-4720 1 PISTON GP 122
–OR–
Y 367-2789 1 PISTON & ROD GP 120
Y 225-43171 PLUG GP-ENGINE 125
Y 232-6204 1 PLUG GP-ENGINE 126
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 286-2365 1 PUMP GP-FUEL INJECTION 364
Y 230-7355 1 PUMP GP-WATER 237
Y 232-7526 1 VALVE MECHANISM GP 138
–OR–
Y 275-0170 1 VALVE MECHANISM GP 140
–OR–
Y 367-2791 1 VALVE MECHANISM GP 143
268-0867 1 CYLINDER BLOCK GP-SHORT
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 1199
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
284-5268 GENERAL AR-GENERATOR
S/N: L1K1-UP
50-HZ
AN ATTACHMENT
SMCS-4450 i02519754
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3307 1 ENGINE AR-COMPLETE 5
Y 263-7105 1 GENERATOR GP 500
Y 266-5347 1 MOUNTING GP-ENGINE & GENERATOR 98
Y - SEPARATE ILLUSTRATION
>
284-5269 GENERAL AR-GENERATOR
S/N: L1K1-UP
60-HZ
AN ATTACHMENT
SMCS-4450 i02519755
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3305 1 ENGINE AR-COMPLETE 5
Y 263-7105 1 GENERATOR GP 500
Y 266-5347 1 MOUNTING GP-ENGINE & GENERATOR 98
Y - SEPARATE ILLUSTRATION
>
2200 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
263-5845 BARRING & MOUNTING GP
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH POWER TAKE-OFF SHAFT
AN ATTACHMENT
SMCS-1235 i02304849
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-5844 1 TOOL-BARRING
2 1 8T-9381 2 BOLT (7/16-20X1-IN)
3 1 3E-4988 2 LOCKWASHER
GRAPHIC #1 > g01155400
SEBP4152-48 1 of 1 BASIC ENGINE 2211
BBAASSIICC EENNGGIINNEE
292-5280 BRACKET GP-MOUNTING–CRANKCASE BREATHER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1317 i02540665
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 292-5278 1 BRACKET
2 1 156-6964 2 BOLT
3 1 245-4745 1 SPACER (36X76X12-MM THK)
4 1 292-5279 1 BRACKET
GRAPHIC #1 > g01274046
2222 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7528 CAMSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1210 i02317983
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 1B-8736 1 KEY-WOODRUFF
2 1 225-5967 1 CAMSHAFT
GRAPHIC #1 > g00911297
SEBP4152-48 1 of 1 BASIC ENGINE 2233
BBAASSIICC EENNGGIINNEE
233-7236 CAMSHAFT GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1210 i03640757
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 350-1846 1 CAMSHAFT AS
1A 1 1B-8736 1 KEY-WOODRUFF
GRAPHIC #1 > g01956663
2244 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
288-1434 CAMSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1210 i05075369
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6095 8 ROD
2 1 138-2053 8 TAPPET
3 1 350-2374 1 CAMSHAFT AS
3A 1 067-6135 1 KEY-WOODRUFF
GRAPHIC #1 > g03337967
SEBP4152-48 1 of 1 BASIC ENGINE 2255
BBAASSIICC EENNGGIINNEE
367-2089 CAMSHAFT GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1210 i05206992
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6095 8 ROD
2 1 138-2053 8 TAPPET
3 1 350-1846 1 CAMSHAFT AS
3A 1 1B-8736 1 KEY-WOODRUFF
GRAPHIC #1 > g01964680
2266 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2792 CAMSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1210 i05224115
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6095 8 ROD
2 1 138-2053 8 TAPPET
3 1 350-2374 1 CAMSHAFT AS
3A 1 067-6135 1 KEY-WOODRUFF
GRAPHIC #1 > g03337967
SEBP4152-48 1 of 1 BASIC ENGINE 2277
BBAASSIICC EENNGGIINNEE
263-7929 COUPLING GP-GENERATOR
S/N: D1K1-UP; L1K1-UP; S1M1-UP
CANNOT BE USED WITH AFTER COOLER
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272, 284-5273, 284-
5274, 284-5275, 290-9639, 300-2928, 300-2929, 300-2930, 300-2931, 300-2933, 300-
2935, 300-2938, 300-2939 GENERATOR AR
AN ATTACHMENT
SMCS-4456 i02364980
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 033-8510 8 STUD (3/8-24X1.375-IN)
2 1 2F-8616 8 LOCKNUT (3/8-24-THD)
3 1 150-1262 4 STUD
4 1 196-7700 4 NUT (M10X1.5-THD)
5 1 9F-4976 10 LOCKWASHER
M 6 1 8T-4196 6 BOLT (M10X1.5X35-MM)
7 1 196-0346 8 WASHER (19X10X1.9-MM THK)
M - METRIC PART
GRAPHIC #1 > g01148790
2288 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
277-6150 COUPLING GP-GENERATOR
S/N: D1K1-UP; S1M1-UP
FOR USE WITH THE C4.4 TURBOCHARGED AFTERCOOLED MARINE GENSET PACKAGE
CANNOT BE USED WITH THE C4.4 NATURALLY ASPIRATED AND TURBOCHARGED MARINE GENSET
PACKAGES
PART OF 300-2942, 300-2943, 300-2945, 300-2946, 300-2947, 300-2948, 300-2949, 300-
2950 GENERATOR AR
AN ATTACHMENT
SMCS-4456 i05751840
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 033-8510 8 STUD (3/8-24X1.375-IN)
2 1 2F-8616 8 LOCKNUT (3/8-24-THD)
3 1 150-1262 4 STUD
4 1 196-7700 4 NUT (M10X1.5-THD)
5 1 7X-0796 12 LOCKWASHER
M 6 1 8T-4196 8 BOLT (M10X1.5X35-MM)
7 1 196-0346 8 WASHER (19X10X1.9-MM THK)
M - METRIC PART
GRAPHIC #1 > g01192659
SEBP4152-48 1 of 1 BASIC ENGINE 2299
BBAASSIICC EENNGGIINNEE
272-2230 COVER GP-CYLINDER HEAD
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1100 i03823109
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 111-8222 12 BOLT (M8X16-MM)
2 1 114-2579 3 GASKET
3 1 185-6627 3 PLATE
GRAPHIC #1 > g02131938
3300 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-0553 COVER GP-ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1000 i05165165
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 364-5170 1 PLATE
2 1 193-5164 2 WASHER (3/8 FLAT)
M 3 1 8T-0389 2 LOCKNUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g03356090
SEBP4152-48 1 of 1 BASIC ENGINE 3311
BBAASSIICC EENNGGIINNEE
270-0081 COVER GP-ENGINE LIFTING EYE
S/N: D1K1-UP; L1K1-UP; S1M1-UP
CANNOT BE USED WITH AFTERCOOLED ENGINES
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272, 300-2928, 300-
2929, 300-2930, 300-2931, 300-2933, 300-2935, 300-2938, 300-2939 GENERATOR AR
AN ATTACHMENT
SMCS-1122 i02291023
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-0699 1 CLIP
M 2 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 3 1 8T-0389 1 LOCKNUT (M10X1.15-THD)
M - METRIC PART
GRAPHIC #1 > g01148593
3322 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
270-0089 COVER GP-ENGINE LIFTING EYE
S/N: D1K1-UP; L1K1-UP; S1M1-UP
FOR USE WITH NATURALLY ASPIRATED, TURBOCHARGED, AND AFTERCOOLED ENGINES
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272, 284-5273, 284-
5274, 284-5275, 290-9639, 300-2928, 300-2929, 300-2930, 300-2931, 300-2933, 300-
2935, 300-2938, 300-2939, 300-2942, 300-2943, 300-2945, 300-2946, 300-2947, 300-
2948, 300-2949,300-2950 GENERATOR AR
AN ATTACHMENT
SMCS-1122 i02291027
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 213-0982 1 COVER
M 2 1 8T-0389 1 LOCKNUT (M10X1.5-THD)
M 3 1 111-0859 1 BOLT (M10X1.5X35-MM)
M - METRIC PART
GRAPHIC #1 > g01148366
SEBP4152-48 1 of 1 BASIC ENGINE 3333
BBAASSIICC EENNGGIINNEE
270-1513 COVER GP-ENGINE LIFTING EYE
S/N: D1K1-UP; L1K1-UP; S1M1-UP
FOR USE WITH NATURALLY ASPIRATED, TURBOCHARGED, AND AFTERCOOLED ENGINES
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272, 284-5273, 284-
5274, 284-5275, 290-9639, 300-2928, 300-2929, 300-2930, 300-2931, 300-2933, 300-
2935, 300-2938, 300-2939, 300-2942, 300-2943, 300-2945, 300-2946, 300-2947, 300-
2948, 300-2949, 300-2950 GENERATOR AR
AN ATTACHMENT
SMCS-1122 i02291085
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 3T-0852 1 LOCKNUT (M8X1.25-THD)
2 1 7X-0602 1 WASHER-HARD (10X38X1.6-MM THK)
M 3 1 6I-1090 1 BOLT (M8X1.25X40-MM)
4 1 270-1512 1 WASHER
M - METRIC PART
GRAPHIC #1 > g01148782
3344 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
230-9196 COVER GP-FRONT HOUSING
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1151, 1166 i02655374
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 100-4830 1 BOLT (M10X1.5X20-MM)
2 1 111-8222 5 BOLT (M8X16-MM)
3 1 209-5502 1 COVER AS (POWER TAKE-OFF)
3A 1 209-5503 1 SEAL-COVER
4 1 6I-0646 1 BOLT (M10X1.5X14-MM)
5 1 214-3203 1 WASHER (SEALING)
M - METRIC PART
GRAPHIC #1 > g01342815
SEBP4152-48 1 of 1 BASIC ENGINE 3355
BBAASSIICC EENNGGIINNEE
230-9196 COVER GP-FRONT HOUSING
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1151, 1166 i03257698
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-0646 1 BOLT (M10X1.5X14-MM)
M 2 1 100-4830 1 BOLT (M10X1.5X20-MM)
3 1 111-8222 5 BOLT (M8X16-MM)
4 1 214-3203 1 WASHER (SEALING)
C 5 1 329-7854 1 PLATE AS
5A 1 329-7856 1 SEAL-O-RING
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
GRAPHIC #1 > g01649494
3366 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1107 i02623606
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 6I-0846 3 BOLT (M6X1X14-MM)
5 1 5D-1026 1 CLAMP-BAND
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
8 1 230-9144 1 CONNECTOR
8A 1 150-7732 1 SEAL-O-RING
8B 1 225-6455 2 BOLT
8C 1 225-6517 1 GASKET
9 1 230-9152 1 FILLER GP-ENGINE OIL
9A 1 6I-1201 1 SEAL-O-RING
9B 1 130-9888 1 CAP-OIL FILLER (ENGINE)
9C 1 113-1504 1 SEAL-O-RING
10 1 236-8184 1 COVER GP-VALVE MECHANISM
10A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
10B 1 124-0506 1 SEAL
10C 1 225-6451 1 GASKET (VALVE COVER)
10D 1 225-6455 10 BOLT
10E 1 225-6456 1 SPRING
10F 1 225-6461 1 CAP (CRANKCASE BREATHER)
10G 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
10H 1 225-6477 1 PLATE
10J 1 225-6478 4 SCREW-MACHINE
10K 1 225-6479 1 CAP
11 1 230-9127 1 COVER
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 3377
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02623606
GRAPHIC #1 > g01157751
3388 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1107 i02614877
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 6I-0846 3 BOLT (M6X1X14-MM)
5 1 5D-1026 1 CLAMP-BAND
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
C 8 1 287-8573 1 PIPE-BREATHER
9 1 230-9152 1 FILLER GP-ENGINE OIL
9A 1 6I-1201 1 SEAL-O-RING
9B 1 130-9888 1 CAP-OIL FILLER (ENGINE)
9C 1 113-1504 1 SEAL-O-RING
C 10 1 247-7797 1 COVER GP-VALVE MECHANISM
10A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
10B 1 124-0506 1 SEAL (VALVE COVER)
10C 1 225-6451 1 GASKET (VALVE COVER)
10D 1 225-6455 10 BOLT
10E 1 225-6456 1 SPRING
10F 1 225-6461 1 CAP (CRANKCASE BREATHER)
10G 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
10H 1 225-6477 1 PLATE
10J 1 225-6478 4 SCREW-MACHINE
10K 1 225-6479 1 CAP
11 1 230-9127 1 COVER
C 12 1 100-4838 2 BOLT (M6X1X20-MM)
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 3399
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02614877
GRAPHIC #1 > g01288485
4400 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 3
SMCS-1107 i02891504
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 6I-0846 3 BOLT (M6X1X14-MM)
5 1 5D-1026 1 CLAMP-BAND
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
8 1 287-8573 1 PIPE-BREATHER
9 1 230-9152 1 FILLER GP-ENGINE OIL
9A 1 6I-1201 1 SEAL-O-RING
9B 1 130-9888 1 CAP-OIL FILLER (ENGINE)
9C 1 113-1504 1 SEAL-O-RING
C 10 1 308-1793 1 COVER GP-VALVE MECHANISM
10A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
10B 1 124-0506 1 SEAL (VALVE COVER)
10C 1 225-6451 1 GASKET (VALVE COVER)
10D 1 225-6456 1 SPRING
10E 1 225-6461 1 CAP (CRANKCASE BREATHER)
10F 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
10G 1 225-6477 1 PLATE
10H 1 225-6478 4 SCREW-MACHINE
10J 1 225-6479 1 CAP
11 1 230-9127 1 COVER
12 1 100-4838 2 BOLT (M6X1X20-MM)
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 4411
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02891504
GRAPHIC #1 > g01401787
4422 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 4
SMCS-1107 i04952736
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 6I-0846 3 BOLT (M6X1X14-MM)
5 1 5D-1026 1 CLAMP-BAND
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
8 1 287-8573 1 PIPE-BREATHER
C 9 1 321-2383 1 FILLER GP-ENGINE OIL
9A 1 306-2337 1 SEAL-O-RING
9B 1 130-9888 1 CAP-OIL FILLER (ENGINE)
9C 1 113-1504 1 SEAL-O-RING
CY 10 1 308-1793 1 COVER GP-VALVE MECHANISM 50
11 1 230-9127 1 COVER
12 1 100-4838 2 BOLT (M6X1X20-MM)
13 1 217-9039 1 STRAP-CABLE
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 BASIC ENGINE 4433
BBAASSIICC EENNGGIINNEE
272-2228 COVER GP-VALVE MECHANISM (ccoonnttdd..) i04952736
GRAPHIC #1 > g03182696
4444 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1107 i02435271
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 230-9127 1 COVER
3 1 6I-0846 3 BOLT (M6X1X14-MM)
4 1 230-9125 1 CONNECTOR
4A 1 150-7732 1 SEAL-O-RING
4B 1 225-6455 2 BOLT
4C 1 225-6517 1 GASKET
5 1 236-8184 1 COVER GP-VALVE MECHANISM
5A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
5B 1 124-0506 1 SEAL
5C 1 225-6451 1 GASKET (VALVE COVER)
5D 1 225-6455 10 BOLT
5E 1 225-6456 1 SPRING
5F 1 225-6461 1 CAP
5G 1225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
5H 1 225-6477 1 PLATE
5J 1 225-6478 4 SCREW-MACHINE
5K 1 225-6479 1 CAP
FM 6I-0254 1 BOLT (M8X1.25X30-MM)
F 6I-4374 1 BOLT (M8X1.25X60-MM)
F 236-9152 1 BOSS
F - NOT SHOWN
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 4455
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02435271
GRAPHIC #1 > g01160695
4466 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1107 i02623656
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 230-9127 1 COVER
3 1 6I-0846 3 BOLT (M6X1X14-MM)
4 1 286-3029 1 PIPE-BREATHER
4A 1 150-7732 1 SEAL-O-RING
4B 1 286-3030 2 RING-SEAL
5 1 247-7797 1 COVER GP-VALVE MECHANISM
5A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
5B 1 124-0506 1 SEAL (VALVE COVER)
5C 1 225-6451 1 GASKET (VALVE COVER)
5D 1 225-6455 10 BOLT
5E 1 225-6456 1 SPRING
5F 1 225-6461 1 CAP (CRANKCASE BREATHER)
5G 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
5H 1 225-6477 1 PLATE
5J 1 225-6478 4 SCREW-MACHINE
5K 1 225-6479 1 CAP
6 1 100-4838 2 BOLT (M6X1X20-MM)
FM 6I-0254 1 BOLT (M8X1.25X30-MM)
F 6I-4374 1 BOLT (M8X1.25X60-MM)
F 236-9152 1 BOSS
F - NOT SHOWN
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 4477
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02623656
GRAPHIC #1 > g01288216
4488 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM
S/N: D1K1-UP
AN ATTACHMENT
TYPE 3
SMCS-1107 i02766845
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 230-9127 1 COVER
3 1 6I-0846 3 BOLT (M6X1X14-MM)
4 1 286-3029 1 PIPE-BREATHER
4A 1 150-7732 1 SEAL-O-RING
4B 1 286-3030 2 RING-SEAL
C 5 1 308-1793 1 COVER GP-VALVE MECHANISM
5A 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
5B 1 124-0506 1 SEAL (VALVE COVER)
5C 1 225-6451 1 GASKET (VALVE COVER)
5D 1 225-6456 1 SPRING
5E 1 225-6461 1 CAP (CRANKCASE BREATHER)
5F 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
5G 1 225-6477 1 PLATE
5H 1 225-6478 4 SCREW-MACHINE
5J 1 225-6479 1 CAP
6 1 100-4838 2 BOLT (M6X1X20-MM)
FM 6I-0254 1 BOLT (M8X1.25X30-MM)
F 6I-4374 1 BOLT (M8X1.25X60-MM)
F 236-9152 1 BOSS
C - CHANGE FROM PREVIOUS TYPE
F - NOT SHOWN
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 4499
BBAASSIICC EENNGGIINNEE
273-0871 COVER GP-VALVE MECHANISM (ccoonnttdd..) i02766845
GRAPHIC #1 > g01420621
5500 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
308-1793 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
PART OF 272-2228, 367-2220 COVER GP-VALVE MECHANISM
AN ATTACHMENT
SMCS-1107 i05010953
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
1A 1 124-0506 1 SEAL (VALVE COVER)
2 1 225-6478 4 SCREW-MACHINE
3 1 225-6456 1 SPRING (CRANKCASE BREATHER)
4 1 225-6461 1 CAP (CRANKCASE BREATHER)
5 1 225-6464 1 DIAPHRAGM (CRANKCASE PRESSURE CONTACTOR)
6 1 225-6477 1 PLATE
7 1 225-6479 1 CAP (CRANKCASE BREATHER)
8 1 225-6451 1 GASKET (VALVE COVER)
9 1 349-2746 10 BOLT
GRAPHIC #1 > g03189638
SEBP4152-48 1 of 1 BASIC ENGINE 5511
BBAASSIICC EENNGGIINNEE
367-2220 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1107 i05179233
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 032-9020 1 CLIP
5 1 100-4838 2 BOLT (M6X1X20-MM)
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
8 1 287-8573 1 PIPE-BREATHER
8A 1 150-7732 1 SEAL-O-RING
8B 1 286-3030 1 RING-SEAL
Y 9 1 308-1793 1 COVER GP-VALVE MECHANISM 50
10 1 321-2383 1 FILLER GP-ENGINE OIL
10A 1 130-9888 1 CAP-OIL FILLER (ENGINE)
10B 1 306-2337 1 SEAL-O-RING
11 1 217-9039 1 STRAP-CABLE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03332217
5522 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2220 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1107 i05897312
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0254 1 BOLT (M8X1.25X30-MM)
2 1 6I-4374 1 BOLT (M8X1.25X60-MM)
3 1 7C-1281 1 BRACKET
4 1 032-9020 1 CLIP
5 1 100-4838 2 BOLT (M6X1X20-MM)
6 1 162-1565 1 SPRING (CRANKCASE BREATHER HOSE)
7 1 198-8645 1 HOSE (CRANKCASE BREATHER)
8 1 287-8573 1 PIPE-BREATHER
8A 1 150-7732 1 SEAL-O-RING
8B 1 286-3030 1 RING-SEAL
Y 9 1 449-1277 1 COVER GP-VALVE MECHANISM 53
10 1 321-2383 1 FILLER GP-ENGINE OIL
10A 1 130-9888 1 CAP-OIL FILLER (ENGINE)
10B 1 306-2337 1 SEAL-O-RING
11 1 217-9039 1 STRAP-CABLE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03332217
SEBP4152-48 1 of 1 BASIC ENGINE 5533
BBAASSIICC EENNGGIINNEE
449-1277 COVER GP-VALVE MECHANISM
S/N: J1Z1-UP
PART OF 367-2220 COVER GP-VALVE MECHANISM
AN ATTACHMENT
SMCS-1107 i05897733
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-6451 1 GASKET (VALVE COVER)
2 1 225-6478 4 SCREW-MACHINE
3 1 349-2746 10 BOLT
4 1 431-1704 1 PLATE
5 1 449-0818 1 COVER-VALVE MECHANISM
6 1 136-3608 1 CAP AS (ENGINE OIL FILLER)
6A 1 124-0506 1 SEAL (VALVE COVER)
GRAPHIC #1 > g03704112
5544 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7400 CRANKSHAFT GP
S/N: D1K1-UP; J1Z3106-UP
WITH SPLINE
PART OF 233-7027, 367-2788 CRANKSHAFT GP
AN ATTACHMENT
SMCS-1202 i05584152
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 1B-8736 1 KEY-WOODRUFF
2 1 225-7772 1 BEARING SET-MAIN (STANDARD)
AB 1 233-3785 KIT-CRANKSHAFT BEARING (0.50-MM US)
AB 1 233-3784 KIT-CRANKSHAFT BEARING (0.25-MM US)
AB 1 233-3786 KIT-CRANKSHAFT BEARING (0.75-MM US)
3 1 032-9090 2 WASHER-THRUST (STANDARD-UPPER)
AB 1 067-6873 WASHER-THRUST (0.18-MM OS)
4 1 032-9091 2 WASHER-THRUST (STANDARD-LOWER)
AB 1 067-6874 WASHER-THRUST (0.18-MM OS)
5 1 353-2205 1 KIT-ROD BEARING
AB 1 353-2206 KIT-ROD BEARING (0.25-MM US)
AB 1 353-2207 KIT-ROD BEARING (0.50-MM US)
AB 1 353-2208 KIT-ROD BEARING (0.75-MM US)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
SEBP4152-48 2 of 2 BASIC ENGINE 5555
BBAASSIICC EENNGGIINNEE
232-7400 CRANKSHAFT GP (ccoonnttdd..) i05584152
GRAPHIC #1 > g01369317
5566 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7439 CRANKSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1202 i05583219
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 1B-8736 1 KEY-WOODRUFF
2 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
J 3 1 232-7400 1 CRANKSHAFT GP (WITH SPLINE) (CONNECTING ROD,
63.48-MM DIA)
4 1 225-7772 1 BEARING SET-MAIN (STANDARD)
AB 1 233-3784 KIT-CRANKSHAFT BEARING (0.25-MM US)
AB 1 233-3785 KIT-CRANKSHAFT BEARING (0.50-MM US)
AB 1 233-3786 KIT-CRANKSHAFT BEARING (0.75-MM US)
5 1 225-7781 1 BEARING SET-ROD (STANDARD)
AB 1 233-3788 KIT-ROD BEARING (0.25-MM US)
AB 1 233-3789 KIT-ROD BEARING (0.50-MM US)
AB 1 233-3790 KIT-ROD BEARING (0.75-MM US)
6 1 032-9090 2 WASHER-THRUST (STANDARD-UPPER)
AB 1 067-6873 WASHER-THRUST (0.18-MM OS) (UPPER)
7 1 032-9091 2 WASHER-THRUST (STANDARD-LOWER)
AB 1 067-6874 WASHER-THRUST (0.18-MM OS) (LOWER)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - CHECK CONNECTING ROD JOURNALS TO ENSURE THIS IS THE CORRECT CRANKSHAFT
SEBP4152-48 2 of 2 BASIC ENGINE 5577
BBAASSIICC EENNGGIINNEE
232-7439 CRANKSHAFT GP (ccoonnttdd..) i05583219
GRAPHIC #1 > g00950782
5588 BASICENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7439 CRANKSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1202 i05165338
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
C 1 1 067-6135 1 KEY-WOODRUFF
2 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
CJY 3 1 359-0715 1 CRANKSHAFT GP (W/O SPLINE) (CONNECTING ROD,
68-MM DIA) 62
C - CHANGE FROM PREVIOUS TYPE
J - CHECK CONNECTING ROD JOURNAL TO ENSURE THIS IS THE CORRECT CRANKSHAFT
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02177264
SEBP4152-48 1 of 1 BASIC ENGINE 5599
BBAASSIICC EENNGGIINNEE
233-7027 CRANKSHAFT GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1202 i05167678
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
JY 1 1 232-7400 1 CRANKSHAFT GP (WITH SPLINE) (CONNECTING ROD,
63.48-MM DIA) 54
2 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
J - CHECK CONNECTING ROD JOURNAL TO ENSURE THIS IS THE CORRECT CRANKSHAFT
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02152725
6600 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
233-7027 CRANKSHAFT GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1202 i05165329
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
CJY 2 1 359-0715 1 CRANKSHAFT GP (W/O SPLINE) (CONNECTING ROD,
68-MM DIA) 62
C 3 1 067-6135 1 KEY-WOODRUFF
C - CHANGE FROM PREVIOUS TYPE
J - CHECK CONNECTING ROD JOURNAL TO ENSURE THIS IS THE CORRECT CRANKSHAFT
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02163313
SEBP4152-48 1 of 1 BASIC ENGINE 6611
BBAASSIICC EENNGGIINNEE
274-4717 CRANKSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1202 i05857578
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
CJY 2 1 359-0715 1 CRANKSHAFT GP (W/O SPLINE) (CONNECTING ROD,
68-MM DIA) 62
C 3 1 067-6135 1 KEY-WOODRUFF
AVAILABLE REPLACEMENT PART(S):
Y 364-2829 1 CRANKSHAFT GP 63
C - CHANGE FROM PREVIOUS TYPE
J - CHECK CONNECTING ROD JOURNALS TO ENSURE THIS IS CORRECT CRANKSHAFT
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02163313
6622 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
359-0715 CRANKSHAFT GP
S/N: D1K1-UP; J1Z1-UP
W/O SPLINE
PART OF 232-7439, 233-7027, 274-4717 CRANKSHAFT GP
AN ATTACHMENT
SMCS-1202 i05294620
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 032-9090 2 WASHER-THRUST (STANDARD-UPPER)
AB 1 067-6873 WASHER-THRUST (0.18-MM OS)
2 1 032-9091 2 WASHER-THRUST (STANDARD-LOWER)
AB 1 067-6874 WASHER-THRUST (0.18-MM OS)
3 1 353-7423 1 KIT-BEARING (MAIN)
AB 1 233-3786 KIT-CRANKSHAFT BEARING (0.75-MM US)
AB 1 353-7424 KIT-BEARING (0.25-MM US) (0.25-MM US)
AB 1 353-7425 KIT-BEARING (0.50-MM US)
AB 1 353-7426 KIT-BEARING (0.75-MM US)
4 1 360-3986 1 KIT-BEARING (CONNECTING ROD) (STANDARD)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
GRAPHIC #1 > g02174712
SEBP4152-48 1 of 1 BASIC ENGINE 6633
BBAASSIICC EENNGGIINNEE
364-2829 CRANKSHAFT GP
S/N: D1K1-UP; J1Z1-UP
WITH SPLINE
PART OF 274-4717, 367-2085, 367-2788 CRANKSHAFT GP
AN ATTACHMENT
SMCS-1202 i05206379
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6135 1 KEY-WOODRUFF (CRANKSHAFT)
B 2 1 032-9090 2 WASHER-THRUST (STANDARD-UPPER)
AB 1 067-6873 WASHER-THRUST (0.18-MM OS)
B 3 1 032-9091 2 WASHER-THRUST (STANDARD-LOWER)
AB 1 067-6874 WASHER-THRUST (0.18-MM OS)
B 4 1 353-2205 1 KIT-ROD BEARING
AB 1 353-2206 KIT-ROD BEARING (0.25-MM US)
AB 1 353-2207 KIT-ROD BEARING (0.5-MM US)
AB 1 353-2208 KIT-ROD BEARING (0.75-MM US)
B 5 1 353-7423 1 KIT-BEARING
AB 1 233-3786 KIT-CRANKSHAFT BEARING (0.030-IN US)
AB 1 353-7424 KIT-BEARING (0.25-MM US)
AB 1 353-7425 KIT-BEARING (0.50-MM US)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
GRAPHIC #1 > g02178360
6644 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2085 CRANKSHAFT GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1202 i05206370
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
Y 2 1 364-2829 1 CRANKSHAFT GP 63
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01402486
SEBP4152-48 1 of 1 BASIC ENGINE 6655
BBAASSIICC EENNGGIINNEE
367-2788 CRANKSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1202 i05225053
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
Y 2 1 232-7400 1 CRANKSHAFT GP (WITH SPLINE) 54
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03349537
6666 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2788 CRANKSHAFT GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1202 i05266743
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 216-8314 1 GEAR-CRANKSHAFT (34-TEETH)
CY 2 1 364-2829 1 CRANKSHAFT GP 63
C - CHANGE FROM PREVIOUS TYPE
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03352389
SEBP4152-48 1 of 2 BASIC ENGINE 6677
BBAASSIICC EENNGGIINNEE
232-7604 CYLINDER BLOCK GP
S/N: D1K1-UP; J1Z1-UP
PART OF 232-7606, 233-7007 CYLINDER BLOCK GP
AN ATTACHMENT
SMCS-1201 i03251702
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 4 BOLT (M8X1.25X20-MM)
2 1 035-8068 10 BOLT (5/8-18X3.75-IN)
3 1 067-6002 10 DOWEL
4 1 067-6006 1 PLUG
5 1 067-6043 1 PLUG-SIDE
M 6 1 100-4841 4 BOLT (M6X1X10-MM)
7 1 185-0884 2 DOWEL
8 1 225-7944 1 GASKET (ENGINE OIL FILTER BASE)
9 1 225-8858 2 PLUG
10 1 232-3751 1 PLATE
11 1 232-7440 1 BEARING
12 1 276-5605 4 JET AS-PISTON COOLING
13 1 232-7596 1 PLUG
14 1 232-7597 2 PLUG
15 1 232-7599 1 PLUG
16 1 232-7600 1 PLUG-CUP
17 1 232-7603 1 PLUG
M - METRIC PART
6688 BASIC ENGINE 2 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7604 CYLINDER BLOCK GP (ccoonnttdd..) i03251702
GRAPHIC #1 > g01652625
SEBP4152-48 1 of 1 BASIC ENGINE 6699
BBAASSIICC EENNGGIINNEE
232-7606 CYLINDER BLOCK GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1201 i02317984
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
Y 3 1 232-7604 1 CYLINDER BLOCK GP 67
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g00952056
7700 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7606 CYLINDER BLOCK GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1201 i04339189
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
CY 3 1 362-2190 1 CYLINDER BLOCK GP 74
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02500198
SEBP4152-48 1 of 1 BASIC ENGINE 7711
BBAASSIICC EENNGGIINNEE
233-7007 CYLINDER BLOCK GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1201 i02316238
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
Y 3 1 232-7604 1 CYLINDER BLOCK GP 67
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g00952056
7722 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
233-7007 CYLINDER BLOCK GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1201 i04339335NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
CY 3 1 362-2190 1 CYLINDER BLOCK GP 74
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02500198
SEBP4152-48 1 of 1 BASIC ENGINE 7733
BBAASSIICC EENNGGIINNEE
274-4718 CYLINDER BLOCK GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1201 i05075070
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
Y 3 1 362-2190 1 CYLINDER BLOCK GP 74
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g00952056
7744 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
362-2190 CYLINDER BLOCK GP
S/N: D1K1-UP; J1Z1-UP
PART OF 232-7606, 233-7007, 274-4718, 367-2084, 367-2787 CYLINDER BLOCK GP
AN ATTACHMENT
SMCS-1201 i04340129
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 1 BOLT (M8X1.25X20-MM)
2 1 6I-0646 1 BOLT (M10X1.5X14-MM)
3 1 035-8063 1 PLUG
M 4 1 100-4841 4 BOLT (M6X1X10-MM)
5 1 214-3203 1 WASHER (SEALING)
6 1 225-7944 1 GASKET
7 1 232-3751 1 PLATE
8 1 232-7600 1 PLUG-CUP
9 1 232-7603 1 PLUG
10 1 276-5605 4 JET AS-PISTON COOLING
M - METRIC PART
GRAPHIC #1 > g02500056
SEBP4152-48 1 of 1 BASIC ENGINE 7755
BBAASSIICC EENNGGIINNEE
367-2084 CYLINDER BLOCK GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1201 i05206328
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
CY 3 1 362-2190 1 CYLINDER BLOCK GP 74
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02500198
7766 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2787 CYLINDER BLOCK GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1201 i05224036
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 209-9219 10 BOLT (M8X1.25X16-MM)
2 1 232-7449 1 HOUSING AS
Y 3 1 362-2190 1 CYLINDER BLOCK GP 74
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02500198
SEBP4152-48 1 of 1 BASIC ENGINE 7777
BBAASSIICC EENNGGIINNEE
232-7519 CYLINDER HEAD GP
S/N: D1K1-UP; J1Z1-UP
PART OF 232-7524, 233-7234, 288-1424, 367-2790 CYLINDER HEAD GP
AN ATTACHMENT
SMCS-1100 i04921701
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 1 PLUG-PIPE
2 1 9Y-5015 2 PLUG-FREEZE
3 1 067-6006 4 PLUG
4 1 147-1979 16 RETAINER-VALVE SPRING
5 1 185-0882 8 GUIDE-VALVE
6 1 199-9751 1 SEAL-O-RING
7 1 329-6655 4 INSERT-VALVE SEAT (INLET)
8 1 322-9663 4 INSERT-VALVE SEAT (EXHAUST)
9 1 225-5495 4 VALVE-INLET
10 1 225-5496 8 SPRING-VALVE
11 1 252-6438 4 SEAL-INLET VALVE
12 1 225-5498 8 CAP
13 1 225-5499 4 VALVE-EXHAUST
14 1 232-1322 1 PLUG
15 1 254-3954 4 SEAL-EXHAUST VALVE
GRAPHIC #1 > g01095382
7788 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7524 CYLINDER HEAD GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1100 i05295187
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5501 7 BOLT (M15X1.5X137-MM)
2 1 225-5502 3 BOLT (M15X1.5X162-MM)
3 1 258-4946 1 GASKET-CYLINDER HEAD
AB 1 369-3705 1 GASKET-CYLINDER HEAD
Y 4 1 232-7519 1 CYLINDER HEAD GP 77
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g00909291
SEBP4152-48 1 of 1 BASIC ENGINE 7799
BBAASSIICC EENNGGIINNEE
233-7234 CYLINDER HEAD GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1100 i05293610
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5501 7 BOLT (M15X1.5X137-MM)
2 1 225-5502 3 BOLT (M15X1.5X162-MM)
3 1 237-1911 1 GASKET-CYLINDER HEAD
AB 1 369-3705 1 GASKET-CYLINDER HEAD
Y 4 1 232-7519 1 CYLINDER HEAD GP 77
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g00909291
8800 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
247-4868 CYLINDER HEAD GP
S/N: D1K1-UP
PART OF 367-2087 CYLINDER HEAD GP
AN ATTACHMENT
SMCS-1100 i05206450
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 1 PLUG-PIPE
2 1 9Y-5015 2 PLUG-FREEZE
3 1 067-6006 4 PLUG
4 1 147-1979 16 RETAINER-VALVE SPRING
5 1 185-0882 8 GUIDE-VALVE
6 1 199-9751 1 SEAL-O-RING
7 1 329-6655 4 INSERT-VALVE SEAT (INLET)
8 1 322-9663 4 INSERT-VALVE SEAT (EXHAUST)
9 1 225-5495 4 VALVE-INLET
10 1 225-5496 8 SPRING-VALVE
11 1 225-5498 8 CAP
12 1 225-5499 4 VALVE-EXHAUST
13 1 232-1322 1 PLUG
14 1 252-6438 4 SEAL-INLET VALVE
15 1 254-3954 4 SEAL-EXHAUST VALVE (EXHAUST VALVE)
GRAPHIC #1 > g01078948
SEBP4152-48 1 of 1 BASIC ENGINE 8811
BBAASSIICC EENNGGIINNEE
288-1424 CYLINDER HEAD GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1100 i05075351
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5501 7 BOLT (M15X1.5X137-MM)
2 1 225-5502 3 BOLT (M15X1.5X162-MM)
Y 3 1 232-7519 1 CYLINDER HEAD GP 77
4 1 258-4946 1 GASKET-CYLINDER HEAD
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03337938
8822 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2087 CYLINDER HEAD GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1100 i05295215
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5501 7 BOLT (M15X1.5X137-MM)
2 1 225-5502 3 BOLT (M15X1.5X162-MM)
3 1 258-4946 1 GASKET-CYLINDER HEAD
AB 1 369-3705 1 GASKET-CYLINDER HEAD
Y 4 1 247-4868 1 CYLINDER HEAD GP 80
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01269653
SEBP4152-48 1 of 1 BASIC ENGINE 8833
BBAASSIICC EENNGGIINNEE
367-2790 CYLINDER HEAD GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1100 i05224095
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5501 7 BOLT (M15X1.5X137-MM)
2 1 225-5502 3 BOLT (M15X1.5X162-MM)
Y 3 1 232-7519 1 CYLINDER HEAD GP 77
4 1 258-4946 1 GASKET-CYLINDER HEAD
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03349488
8844 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
265-6535 GUARD GP-BELT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7174 i05077410
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 265-6532 1 GUARD-BELT
2 1 196-0270 3 GROMMET
3 1 196-0272 6 WASHER (8.3X25.4X1.5-MM)
4 1 196-0340 3 SETSCREW (M8X1.25X25-MM)
5 1 204-0370 2 SPACER
6 1 265-6533 1 SPACER (M8X1.25-THD)
7 1 196-0271 3 SPACER (8.5X14.3X8-MM THK)
8 1 265-6534 1 GROMMET
9 1 245-1094 3 NUT-RETAINING
GRAPHIC #1 > g03323493
SEBP4152-48 1 of 1 BASIC ENGINE 8855
BBAASSIICC EENNGGIINNEE
357-7596 GUARD GP-BELT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7174 i05145991
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 357-7597 1 GUARD-BELT
2 1 196-0270 3 GROMMET
3 1 196-0272 6 WASHER (8.3X25.4X1.5-MM)
4 1 196-0340 3 SETSCREW (M8X1.25X25-MM)
5 1 196-0271 3 SPACER (8.5X14.3X8-MM THK)
6 1 265-6534 1 GROMMET
7 1 245-1094 3 NUT-RETAINING
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
GRAPHIC #1 > g03334468
8866 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICCEENNGGIINNEE
263-7044 HOUSING GP-FLYWHEEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH SINGLE STARTER ONLY
AN ATTACHMENT
SMCS-1157 i02612960
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 220-8632 1 HOUSING-FLYWHEEL
2 1 7W-4642 1 SHIELD-DUST
M 3 1 6I-0423 2 BOLT (M12X1.75X30-MM)
M 4 1 121-0883 6 BOLT (M10X1.5X30-MM)
5 1 287-8597 2 DOWEL
6 1 7W-1176 1 PLATE-COVER
7 1 101-3615 2 BOLT (M8X1.25X10-MM)
8 1 6I-0847 1 PLUG
9 1 210-6655 1 PLUG
10 1 103-6131 1 FLYWHEEL AS
10A 1 033-7687 1 RING-STARTING MOTOR (126-TEETH)
11 1 5P-8245 10 WASHER-HARD (13.5X25.5X3-MM THK)
12 1 0S-1603 10 BOLT (1/2-20X1.5-IN)
M 13 1 6I-0593 3 BOLT (M10X1.5X30-MM)
M - METRIC PART
GRAPHIC #1 > g01147784
SEBP4152-48 1 of 1 BASIC ENGINE 8877
BBAASSIICC EENNGGIINNEE
263-7059 HOUSING GP-FLYWHEEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH TWIN STARTER ONLY
AN ATTACHMENT
SMCS-1157 i02612964
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 210-7730 1 HOUSING-FLYWHEEL
2 1 287-8597 2 DOWEL
M 3 1 6I-0423 2 BOLT (M12X1.75X30-MM)
M 4 1 121-0883 6 BOLT (M10X1.5X30-MM)
5 1 5P-8245 10 WASHER-HARD (13.5X25.5X3-MM THK)
6 1 0S-1603 10 BOLT (1/2-20X1.5-IN)
7 1 103-6131 1 FLYWHEEL AS
7A 1 033-7687 1 RING-STARTING MOTOR (126-TEETH)
8 1 7W-4642 1 SHIELD-DUST
9 1 6I-0847 1 PLUG
M 10 1 6I-0593 3 BOLT (M10X1.5X30-MM)
M - METRIC PART
GRAPHIC #1 > g01149348
8888 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-6179 HOUSING GP-FRONT
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1151, 1162, 1206 i04003800
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-0422 1 SEAL-OIL (FRONT)
2 1 323-3515 1 HOUSING-FRONT
2A 1 225-6522 1 PLUG-CUP
M 3 1 6I-0217 6 BOLT (M8X1.25X20-MM)
M 4 1 6I-0645 4 BOLT (M8X1.25X25-MM)
CM 5 1 6I-0650 3 BOLT (M10X1.5X65-MM)
6 1 7C-4616 1 BOLT (M12X1.75X45-MM)
7 1 067-6179 1 DOWEL
C 8 1 324-0444 1 HUB-IDLER GEAR
C 9 1 295-1711 1 PLATE-RETAINING
M 10 1 100-3751 5 BOLT (M8X1.25X65-MM)
M 11 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 12 1 124-3815 9 BOLT (M8X1.25X16-MM)
13 1 232-3666 1 WASHER-THRUST
14 1 216-8634 1 GEAR-CAMSHAFT (68-TEETH)
15 1 277-3012 1 GASKET-COVER
16 1 251-4336 1 GEAR AS-IDLER (73-TEETH)
17 1 226-8767 1 COVER AS-FRONT
17A 1 226-8766 1 GASKET-COVER
18 1 133-1011 1 WASHER
M 19 1 101-3895 2 BOLT (M8X1.25X35-MM)
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 8899
BBAASSIICC EENNGGIINNEE
232-6179 HOUSING GP-FRONT (ccoonnttdd..) i04003800
GRAPHIC #1 > g02196736
9900 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
233-7432 LIFTING GP-ENGINE
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1122 i02317461
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 100-4830 4 BOLT (M10X1.5X20-MM)
2 1 225-8848 2 PLATE-LIFTING
M - METRIC PART
GRAPHIC #1 > g00955299
SEBP4152-48 1 of 1 BASIC ENGINE 9911
BBAASSIICC EENNGGIINNEE
269-3748 LIFTING GP-ENGINE
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1122 i03655037
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 342-7555 1 BRACKET-MOUNTING
2 1 6I-0789 2 BOLT (M10X1.5X60-MM)
3 1 269-3747 1 BRACKET-LIFTING
M 4 1 6I-0654 3 BOLT (M10X1.5X25-MM)
M - METRIC PART
GRAPHIC #1 > g01160402
9922 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
289-9801 LIFTING GP-ENGINE
S/N: D1K1-UP; L1K1-UP; S1M1-UP
PART OF 300-2928, 300-2929, 300-2930, 300-2931, 300-2933, 300-2935, 300-2938, 300-
2939, 300-2942, 300-2943, 300-2945, 300-2946, 300-2947, 300-2948, 300-2949, 300-
2950 GENERATOR AR
AN ATTACHMENT
SMCS-1122 i02540163
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-9802 4 PLATE
M 2 1 6I-0423 12 BOLT (M12X1.75X30-MM)
M 3 1 6I-0233 12 NUT (M12X1.75-THD)
M - METRIC PART
GRAPHIC #1 > g01274158
SEBP4152-48 1 of 1 BASIC ENGINE 9933
BBAASSIICC EENNGGIINNEE
295-2236 LIFTING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1122 i02566791
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 295-2237 1 PLATE-LIFTING
M 2 1 6I-0654 2 BOLT (M10X1.5X25-MM)
3 1 275-2452 1 PLATE-LIFTING
M 4 1 100-4830 2 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01311049
9944 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
263-7700 MOUNTING GP-ALTERNATOR
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1154, 1405 i02288465
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 3T-0852 1 LOCKNUT (M8X1.25-THD)
2 1 8T-4224 2 WASHER-HARD (8.8X16X2-MM THK)
M 3 1 100-8451 1 BOLT (M8X1.25X130-MM)
M 4 1 8T-0389 1 LOCKNUT (M10X1.5-THD)
5 1 214-3205 1 SPACER (10.32X19.05X6.35-MM THK)
6 1 263-7688 1 LEVER
7 1 6I-4045 1 BOLT (M10X1.5X75-MM)
M 8 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 9 1 140-8783 2 BOLT (M10X1.5X45-MM)
10 1 233-9530 1 BRACKET
M - METRIC PART
GRAPHIC #1 > g01147030
SEBP4152-48 1 of 1 BASIC ENGINE 9955
BBAASSIICC EENNGGIINNEE
292-0213 MOUNTING GP-BRACKET–AIR CLEANER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7174 i02761678
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 290-2488 1 BRACKET-MOUNTING
M 2 1 100-4830 2 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01627913
9966 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
357-7613 MOUNTING GP-BRACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH BRONZE SEA WATER PUMP
AN ATTACHMENT
SMCS-7174 i05153517
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 265-6533 1 SPACER (M8X1.25-THD)
2 1 204-0370 1 SPACER
3 1 357-6811 1 BRACKET
4 1 327-4170 2 BOLT-SOCKET HEAD
GRAPHIC #1 > g03341184
SEBP4152-48 1 of 1 BASIC ENGINE 9977
BBAASSIICC EENNGGIINNEE
272-2231 MOUNTING GP-ENGINE
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1152, 1153, 1154 i02316079
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 139-7007 1 BRACKET
2 1 145-2881 1 SPACER
3 1 183-1343 4 STUD
4 1 186-3594 1 BRACKET
5 1 195-2221 8 NUT (M12X1.75-THD)
6 1 247-8314 4 STUD (M12X1.75X55-MM)
GRAPHIC #1 > g01158020
9988 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
266-5347 MOUNTING GP-ENGINE & GENERATOR
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272 GENERATOR AR
AN ATTACHMENT
SMCS-1021, 1152 i02301198
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 196-0405 2 MOUNT-FLEXIBLE
2 1 103-6716 2 BOLT
M 3 1 102-9941 7 BOLT (M12X1.75X25-MM)
M 4 1 6I-0233 10 NUT (M12X1.75-THD)
5 1 266-5351 1 CABLE AS
6 1 196-0348 2 WASHER (13X23.5X2.5-MM THK)
7 1 8T-4224 1 WASHER-HARD (8.8X16X2-MM THK)
8 1 266-5356 2 STUD
M 9 1 6I-0423 1 BOLT (M12X1.75X30-MM)
10 1 166-5000 1 PLUG
11 1 266-5354 2 MOUNT-FLEXIBLE
12 1 266-5355 2 SPACER
13 1 266-5360 2 WASHER (13X37X3-MM THK)
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 9999
BBAASSIICC EENNGGIINNEE
266-5347 MOUNTING GP-ENGINE & GENERATOR (ccoonnttdd..) i02301198
GRAPHIC #1 > g01153083
110000 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
268-3640 MOUNTING GP-ENGINE & GENERATOR
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLEDENGINES
PART OF 284-5273, 284-5274, 284-5275, 290-9639 GENERATOR AR
AN ATTACHMENT
SMCS-1021, 1152 i02288978
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 196-0405 2 MOUNT-FLEXIBLE
2 1 103-6716 4 BOLT
M 3 1 102-9941 7 BOLT (M12X1.75X25-MM)
M 4 1 6I-0233 8 NUT (M12X1.75-THD)
M 5 1 6I-0423 1 BOLT (M12X1.75X30-MM)
6 1 196-0348 2 WASHER (13X23.5X2.5-MM THK)
7 1 266-5351 1 CABLE AS
8 1 166-5000 1 PLUG
9 1 268-3639 2 WASHER (16.5X50X3-MM THK)
10 1 8T-4224 1 WASHER-HARD (8.8X16X2-MM THK)
11 1 266-5354 2 MOUNT-FLEXIBLE
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 110011
BBAASSIICC EENNGGIINNEE
268-3640 MOUNTING GP-ENGINE & GENERATOR (ccoonnttdd..) i02288978
GRAPHIC #1 > g01146955
110022 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
291-4867 MOUNTING GP-ENGINE & GENERATOR
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1021, 1152 i02540702
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 266-5354 4 MOUNT-FLEXIBLE
M 2 1 7X-2553 4 BOLT (M16X2X40-MM)
M 3 1 102-9941 7 BOLT (M12X1.75X25-MM)
M 4 1 176-5311 4 LOCKNUT (M16X2-THD)
5 1 291-4868 1 CABLE AS
6 1 196-0348 2 WASHER (13X23.5X2.5-MM THK)
7 1 7X-0591 6 WASHER-HARD (17X29X3-MM THK)
M 8 1 6I-0423 1 BOLT (M12X1.75X30-MM)
9 1 166-5000 1 PLUG
M 10 1 6I-0233 8 NUT (M12X1.75-THD)
11 1 291-4869 2 SPACER
12 1 291-4870 2 STUD (M16X2X108-MM)
13 1 291-4871 1 BRACKET
14 1 196-7702 2 LOCKWASHER
15 1 268-3639 2 WASHER (16.5X50X3-MM THK)
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 110033
BBAASSIICC EENNGGIINNEE
291-4867 MOUNTING GP-ENGINE & GENERATOR (ccoonnttdd..) i02540702
GRAPHIC #1 > g01274051
110044 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
300-2114 MOUNTING GP-ENGINE & GENERATOR
S/N: D1K1-UP; S1M1-UP
PART OF 300-2942, 300-2943, 300-2945, 300-2946, 300-2947, 300-2948, 300-2949, 300-
2950 GENERATOR AR
AN ATTACHMENT
SMCS-1021, 1152 i02635428
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 196-0405 2 MOUNT-FLEXIBLE
2 1 103-6716 4 BOLT
M 3 1 6I-0423 1 BOLT (M12X1.75X30-MM)
M 4 1 6I-0233 8 NUT (M12X1.75-THD)
M 5 1 102-9941 7 BOLT (M12X1.75X25-MM)
6 1 196-0348 2 WASHER (13X23.5X2.5-MM THK)
8 1 268-3639 2 WASHER (16.5X50X3-MM THK)
9 1 266-5354 2 MOUNT-FLEXIBLE
M - METRIC PART
GRAPHIC #1 > g01345974
SEBP4152-48 1 of 1 BASIC ENGINE 110055
BBAASSIICC EENNGGIINNEE
300-2115 MOUNTING GP-ENGINE & GENERATOR
S/N: D1K1-UP; S1M1-UP
PART OF 300-2928, 300-2929, 300-2930, 300-2931, 300-2933, 300-2935, 300-2938, 300-
2939 GENERATOR AR
AN ATTACHMENT
SMCS-1021, 1152 i02635345
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 196-0405 2 MOUNT-FLEXIBLE
2 1 103-6716 2 BOLT
M 3 1 102-9941 7 BOLT (M12X1.75X25-MM)
M 4 1 6I-0233 10 NUT (M12X1.75-THD)
6 1 196-0348 2 WASHER (13X23.5X2.5-MM THK)
7 1 266-5360 2 WASHER (13X37X3-MM THK)
M 8 1 6I-0423 1 BOLT (M12X1.75X30-MM)
9 1 266-5354 2 MOUNT-FLEXIBLE
10 1 266-5355 2 SPACER
11 1 266-5356 2 STUD
M - METRIC PART
GRAPHIC #1 > g01345975
110066 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2224 PAN GP-OIL
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1302 i02317466
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 2 PLUG-PIPE
2 1 5P-6718 2 SEAL-O-RING
M 3 1 6I-0217 8 BOLT (M8X1.25X20-MM)
4 1 6I-0289 1 PLUG
M 5 1 6I-0291 2 NUT (M8X1.25-THD)
6 1 6I-0292 2 BOLT (M8X1.25X140-MM)
7 1 6I-0293 4 BOLT (M8X1.25X80-MM)
M 8 1 6I-0363 2 BOLT (M6X1X20-MM)
9 1 6I-1497 1 SEAL
10 1 7C-0351 2 PLUG-DRAIN (ENGINE OIL)
11 1 067-6213 1 GASKET
M 12 1 6I-0260 2 BOLT (M8X1.25X25-MM)
13 1 124-7702 1 TUBE AS
14 1 6I-4079 1 NUT
15 1 131-4291 1 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE)
16 1 155-4828 2 STUD
17 1 220-8311 4 BOLT (M8X1.25X115-MM)
18 1 225-6005 1 GASKET
19 1 230-8094 1 BRIDGE
20 1 230-8251 1 PAN-OIL
21 1 272-2226 1 TUBE-OIL SUCTION
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 110077
BBAASSIICC EENNGGIINNEE
272-2224 PAN GP-OIL (ccoonnttdd..) i02317466
GRAPHIC #1 > g01157582
110088 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
272-2224 PAN GP-OIL
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1302 i02660362
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 2 PLUG-PIPE
2 1 275-9883 2 SEAL (SUMP DRAIN PLUG)
M 3 1 6I-0217 8 BOLT (M8X1.25X20-MM)
4 1 6I-0289 1 PLUG
M 5 1 6I-0291 2 NUT (M8X1.25-THD)
6 1 6I-0292 2 BOLT (M8X1.25X140-MM)
7 1 6I-0293 4 BOLT (M8X1.25X80-MM)
M 8 1 6I-0363 2 BOLT (M6X1X20-MM)
9 1 6I-1497 1 SEAL
10 1 7C-0351 2 PLUG-DRAIN (ENGINE OIL)
11 1 067-6213 1 GASKET
M 12 1 6I-0260 2 BOLT (M8X1.25X25-MM)
C 13 1 124-7702 1 TUBE AS
13A 1 6I-4079 1 NUT
15 1 131-4291 1 GAUGE AS-OIL LEVEL (DIPSTICK) (ENGINE)
16 1 155-4828 2 STUD
17 1 220-8311 4 BOLT (M8X1.25X115-MM)
18 1 225-6005 1 GASKET
19 1 230-8094 1 BRIDGE
20 1 230-8251 1 PAN-OIL (ENGINE)
21 1 272-2226 1 TUBE-OIL SUCTION
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
SEBP4152-48 2 of 2 BASIC ENGINE 110099
BBAASSIICC EENNGGIINNEE
272-2224 PAN GP-OIL (ccoonnttdd..) i02660362
GRAPHIC #1 > g01370367
111100 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7442 PISTON & ROD GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1225 i05296252
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5437 4 PISTON AS
(EACH INCLUDES)
AB 1 288-1394 PISTON AS (0.5-MM OS)
AB 1 288-1395 PISTON AS (1-MM OS)
2 1 124-3536 2 RING-RETAINING
3 1 225-5436 1 KIT-PISTON RING
AB 1 334-2318 KIT-PISTON RING (1-MM OS)
AB 1 334-2319 KIT-PISTON RING (0.5-MM OS)
J 4 1 225-5441 4 ROD AS-CONNECTING (L-GRADE) (L)
–OR–
J 1 225-5451 4 ROD AS-CONNECTING (GRADE K) (K)
–OR–
J 1 225-5453 4 ROD AS-CONNECTING (J-GRADE) (J)
–OR–
J 1 225-5454 4 ROD AS-CONNECTING (GRADE H) (H)
–OR–
J 1 225-5458 4 ROD AS-CONNECTING (GRADE G) (G)
–OR–
J 1 225-5459 4 ROD AS-CONNECTING (F-GRADE) (F)
(EACH ROD AS INCLUDES)
5 1 225-5438 1 BUSHING
6 1 225-5439 2 BOLT-SPECIAL (CONNECTING ROD)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 111111
BBAASSIICC EENNGGIINNEE
232-7442 PISTON & ROD GP (ccoonnttdd..) i05296252
GRAPHIC #1 > g00909669
111122 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7442 PISTON & ROD GP
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1225 i05296253
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5437 4 PISTON AS
(EACH PISTON AS INCLUDES)
1A 1 124-3536 2 RING-RETAINING
AB 1 288-1394 PISTON AS (0.5-MM OS)
AB 1 288-1395 PISTON AS (1-MM OS)
1B 1 225-5436 1 KIT-PISTON RING
AB 1 334-2318 KIT-PISTON RING (1-MM OS)
AB 1 334-2319 KIT-PISTON RING (0.5-MM OS)
BJ 2 1 359-0724 4 ROD AS-CONNECTING (LENGTH B)
–OR–
BJ 1 359-0723 4 ROD AS-CONNECTING (LENGTH P)
–OR–
BJ 1 359-0722 4 ROD AS-CONNECTING (LENGTH G)
–OR–
BJ 1 359-0721 4 ROD AS-CONNECTING (LENGTH W)
–OR–
BJ 1 359-0720 4 ROD AS-CONNECTING (LENGTH O)
–OR–
BJ 1 359-0719 4 ROD AS-CONNECTING (LENGTH R)
(EACH ROD AS INCLUDES)
2A 1 225-5438 1 BUSHING
2B 1 323-9312 2 BOLT (M10X1X50-MM)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 111133
BBAASSIICC EENNGGIINNEE
232-7442 PISTON & ROD GP (ccoonnttdd..) i05296253
GRAPHIC #1 > g02188983
111144 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
233-7233 PISTON & ROD GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1225i04563348
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 233-7232 4 PISTON AS
(EACH PISTON AS INCLUDES)
2 1 124-3536 2 RING-RETAINING
3 1 233-7231 1 RING GP-PISTON
BJ 4 1 225-5441 4 ROD AS-CONNECTING (L-GRADE)
–OR–
BJ 1 225-5451 4 ROD AS-CONNECTING (GRADE K)
–OR–
BJ 1 225-5453 4 ROD AS-CONNECTING (J-GRADE)
–OR–
BJ 1 225-5454 4 ROD AS-CONNECTING (GRADE H)
–OR–
BJ 1 225-5458 4 ROD AS-CONNECTING (GRADE G)
–OR–
BJ 1 225-5459 4 ROD AS-CONNECTING (F-GRADE)
(EACH ROD AS INCLUDES)
5 1 225-5438 1 BUSHING
6 1 225-5439 2 BOLT-SPECIAL (CONNECTING ROD)
AVAILABLE REPAIR KIT(S):
AB 288-9942 1 PISTON AS (0.5-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 288-9943 1 PISTON AS (1-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 334-1996 1 KIT-PISTON RING (0.5-MM OS)
AB 334-1997 1 KIT-PISTON RING (1-MM OS)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 111155
BBAASSIICC EENNGGIINNEE
233-7233 PISTON & ROD GP (ccoonnttdd..) i04563348
GRAPHIC #1 > g00909669
111166 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
233-7233 PISTON & ROD GP
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1225 i04563345
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 233-7232 4 PISTON AS
(EACH PISTON AS INCLUDES)
1A 1 124-3536 2 RING-RETAINING
1B 1 233-7231 1 RING GP-PISTON
BJ 2 1 359-0724 4 ROD AS-CONNECTING (LENGTH B)
–OR–
BJ 1 359-0723 4 ROD AS-CONNECTING (LENGTH P)
–OR–
BJ 1 359-0722 4 ROD AS-CONNECTING (LENGTH G)
–OR–
BJ 1 359-0721 4 ROD AS-CONNECTING (LENGTH W)
–OR–
BJ 1 359-0720 4 ROD AS-CONNECTING (LENGTH O)
–OR–
BJ 1 359-0719 4 ROD AS-CONNECTING (LENGTH R)
(EACH ROD AS INCLUDES)
2A 1 225-5438 1 BUSHING
2B 1 323-9312 2 BOLT
AVAILABLE REPAIR KIT(S):
AB 288-9942 1 PISTON AS (0.5-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 288-9943 1 PISTON AS (1-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 334-1996 1 KIT-PISTON RING (0.5-MM OS)
AB 334-1997 1 KIT-PISTON RING (1-MM OS)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 111177
BBAASSIICC EENNGGIINNEE
233-7233 PISTON & ROD GP (ccoonnttdd..) i04563345
GRAPHIC #1 > g02189194
111188 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2086 PISTON & ROD GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1225 i05297317
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 233-7232 4 PISTON AS
(EACH PISTON AS INCLUDES)
2 1 124-3536 2 RING-RETAINING
3 1 233-7231 1 RING GP-PISTON
BJ 4 1 225-5441 4 ROD AS-CONNECTING (L-GRADE)
–OR–
BJ 1 225-5451 4 ROD AS-CONNECTING (GRADE K)
–OR–
BJ 1 225-5453 4 ROD AS-CONNECTING (J-GRADE)
–OR–
BJ 1 225-5454 4 ROD AS-CONNECTING (GRADE H)
–OR–
BJ 1 225-5458 4 ROD AS-CONNECTING (GRADE G)
–OR–
BJ 1 225-5459 4 ROD AS-CONNECTING (F-GRADE)
(EACH ROD AS INCLUDES)
5 1 225-5438 1 BUSHING
6 1 225-5439 2 BOLT-SPECIAL (CONNECTING ROD)
AVAILABLE REPAIR KIT(S):
AB 288-9942 1 PISTON AS (0.5-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 288-9943 1 PISTON AS (1-MM OS)
(INCLUDES RETAINING RINGS AND PISTON RING KIT)
AB 334-1996 1 KIT-PISTON RING (0.5-MM OS)
AB 334-1997 1 KIT-PISTON RING (1-MM OS)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 111199
BBAASSIICC EENNGGIINNEE
367-2086 PISTON & ROD GP (ccoonnttdd..) i05297317
GRAPHIC #1 > g00909669
112200 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2789 PISTON & ROD GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1225 i05222201
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5437 4 PISTON AS
(EACH PISTON AS INCLUDES)
1A 1 124-3536 2 RING-RETAINING
1B 1 225-5436 1 KIT-PISTON RING
AB 1 334-2318 KIT-PISTON RING (1-MM OS)
AB 1 334-2319 KIT-PISTON RING (0.5-MM OS)
AB 1 288-1394 PISTON AS (0.5-MM OS)
AB 1 288-1395 PISTON AS (1-MM OS)
BJ 2 1 225-5441 4 ROD AS-CONNECTING (L-GRADE)
–OR–
BJ 1 225-5451 4 ROD AS-CONNECTING (GRADE K)
–OR–
BJ 1 225-5453 4 ROD AS-CONNECTING (J-GRADE)
–OR–
BJ 1 225-5454 4 ROD AS-CONNECTING (GRADE H)
–OR–
BJ 1 225-5458 4 ROD AS-CONNECTING (GRADE G)
–OR–
BJ 1 225-5459 4 ROD AS-CONNECTING (F-GRADE)
(EACH ROD AS INCLUDES)
2A 1 225-5438 1 BUSHING
2B 1 225-5439 2 BOLT-SPECIAL (CONNECTING ROD)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - ENSURE THAT CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 112211
BBAASSIICC EENNGGIINNEE
367-2789 PISTON & ROD GP (ccoonnttdd..) i05222201
GRAPHIC #1 > g01374535
112222 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
274-4720 PISTON GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1214 i05075150
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5437 4 PISTON AS
(EACH INCLUDES)
1A 1 124-3536 2 RING-RETAINING
1B 1 225-5436 1 KIT-PISTON RING
AB 1 334-2318 KIT-PISTON RING (1.0-MM OS)
AB 1 334-2319 KIT-PISTON RING (0.5-MM OS)
AB 1 288-1394 PISTON AS (0.5-MM OS)
AB 1 288-1395 PISTON AS (1-MM OS)
BJ 2 1 359-0724 4 ROD AS-CONNECTING (LENGTH B)
–OR–
BJ 1 359-0723 4 ROD AS-CONNECTING (LENGTH P)
–OR–
BJ 1 359-0722 4 ROD AS-CONNECTING (LENGTH G)
–OR–
BJ 1 359-0721 4 ROD AS-CONNECTING (LENGTH W)
–OR–
BJ 1 359-0720 4 ROD AS-CONNECTING (LENGTH O)
–OR–
BJ 1 359-0719 4 ROD AS-CONNECTING (LENGTH R)
(EACH ROD ASSEMBLY INCLUDES)
2A 1 225-5438 1 BUSHING
2B 1 323-9312 2 BOLT (M10X1X50-MM)
A - NOT PART OF THIS GROUP
B - USE AS REQUIRED
J - INSURE CORRECT ROD LENGTH IS FITTED
SEBP4152-48 2 of 2 BASIC ENGINE 112233
BBAASSIICC EENNGGIINNEE
274-4720 PISTON GP (ccoonnttdd..) i05075150
GRAPHIC #1 > g02201533
112244 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
356-1211 PLUG
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-0663, 1201 i05072851
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-6522 1 PLUG-CUP
GRAPHIC #1 > g03356414
SEBP4152-48 1 of 1 BASIC ENGINE 112255
BBAASSIICC EENNGGIINNEE
225-4317 PLUG GP-ENGINE
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1100, 1201 i02317966
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 3 PLUG-PIPE
GRAPHIC #1 > g00911937
112266 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-6204 PLUG GP-ENGINE
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1100, 1201 i02317968
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 199-9751 1 SEAL-O-RING
2 1 232-1322 1 PLUG
GRAPHIC #1 > g00950934
SEBP4152-48 1 of 1 BASIC ENGINE 112277
BBAASSIICC EENNGGIINNEE
253-2479 PLUG GP-ENGINE
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1100, 1201 i02317488
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 035-8063 1 PLUG
2 1 199-9267 1 SEAL-O-RING
3 1 232-3861 1 PLUG (BLANKING)
GRAPHIC #1 > g01079757
112288 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
198-4119 PULLEY GP
S/N: L1K1-UP; S1M1-UP
3-GROOVE, 5-INCH PULLEY WITH A LOCK BUSHING
AN ATTACHMENT
SMCS-1205, 1359, 1384, 1425 i02312670
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4656 1 PULLEY (3-GROOVE)
2 1 195-4657 1 BUSHING AS
GRAPHIC #1 > g00748016
SEBP4152-48 1 of 1 BASIC ENGINE 112299
BBAASSIICCEENNGGIINNEE
230-7352 PULLEY GP-CRANKSHAFT
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1205 i02317463
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-0501 1 BLOCK
2 1 7W-4634 3 BOLT (7/16-20X1.5-IN)
3 1 111-3297 1 PULLEY
GRAPHIC #1 > g00658339
113300 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
291-4645 PULLEY GP-FAN DRIVE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1359 i02540700
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 230-8065 1 HOUSING AS
M 2 1 111-0859 4 BOLT (M10X1.5X35-MM)
3 1 130-3879 1 PULLEY-FAN DRIVE
4 1 135-6363 1 EXTENSION-FAN
5 1 135-6362 4 STUD
6 1 113-6349 4 NUT (M8X1.25-THD)
M - METRIC PART
GRAPHIC #1 > g01274016
SEBP4152-48 1 of 1 BASIC ENGINE 113311
BBAASSIICC EENNGGIINNEE
357-7598 PULLEY GP-WATER PUMP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1384 i05072855
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 237-2339 1 BUSHING
2 1 237-2703 1 PULLEY
GRAPHIC #1 > g03357145
113322 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
359-5106 PULLEY GP-WATER PUMP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1384 i05142249
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 237-2339 1 BUSHING
2 1 359-4771 1 PULLEY
GRAPHIC #1 > g03335346
SEBP4152-48 1 of 1 BASIC ENGINE 113333
BBAASSIICC EENNGGIINNEE
225-5963 ROCKER ARM GP
S/N: D1K1-UP; J1Z1-UP
PART OF 367-2088, 367-2791 VALVE MECHANISM GP
AN ATTACHMENT
SMCS-1123 i05206988
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 225-5625 4 LEVER AS
(EACH INCLUDES)
1A 1 5B-9079 1 NUT-JAM (3/8-24-THD)
1B 1 185-1546 1 SCREW
2 1 225-5634 1 SHAFT AS
2A 1 225-5629 2 PLUG
3 1 225-5638 3 SPRING
4 1 225-5640 4 LEVER AS
(EACH INCLUDES)
4A 1 5B-9079 1 NUT-JAM (3/8-24-THD)
4B 1 185-1546 1 SCREW
5 1 225-5959 2 CLIP
6 1 225-5960 1 BOLT (M8X1.25X60-MM)
7 1 225-5961 2 WASHER (26.7X34.32X0.38-MM THK)
8 1 225-5962 3 BOLT (M8X1.25X30-MM)
GRAPHIC #1 > g01368510
113344 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
210-6507 SHAFT GP-STUB
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1237 i05697175
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 089-7722 4 BOLT (7/16-20X1.25-IN)
2 1 204-7519 1 SHAFT-STUB
3 1 204-7521 1 KEY
4 1 3E-4988 4 LOCKWASHER
GRAPHIC #1 > g00850918
SEBP4152-48 1 of 1 BASIC ENGINE 113355
BBAASSIICC EENNGGIINNEE
355-8703 SPACER GP-BLOCK
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1221 i05153449
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 339-6482 1 BLOCK-SPACER
2 1 356-4967 2 ADAPTER
3 1 6V-0407 2 SEAL-BONDED
M 4 1 6V-5192 4 BOLT-SOCKET HEAD (M8X1.25X30-MM)
5 1 287-7441 2 ADAPTER
6 1 281-1303 1 TUBE
7 1 281-1304 1 TUBE
8 1 140-7473 2 CLIP
9 1 287-7442 1 ADAPTER
10 1 281-1305 1 TUBE
11 1 287-7443 1 TUBE
12 1 281-0574 3 ADAPTER
13 1 333-2306 1 GASKET
14 1 288-4110 1 FILTER GP-ENGINE OIL
14A 1 081-4661 2 FILTER-ENGINE OIL
15 1 6V-0409 2 SEAL-BONDED
16 1 356-4968 2 ADAPTER
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
M - METRIC PART
GRAPHIC #1 > g03343582
113366 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
269-9118 V-BELT GP–FAN
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1357 i02330682
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-9117 1 V-BELT (FAN) (INCLUDES ONE BELT)
GRAPHIC #1 > g01153100
SEBP4152-48 1 of 1 BASIC ENGINE 113377
BBAASSIICC EENNGGIINNEE
4N-8771 V-BELT SET–INCLUDES 2-BELTS
S/N: L1K1-UP; S1M1-UP
1359 MM (53.5 IN) LG
AN ATTACHMENT
SMCS-1357 i02586941
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
276-2978 V-BELT SET
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1357 i02579605
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
113388 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
232-7526 VALVE MECHANISM GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1102, 1121, 1123, 1209 i02317981
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6095 8 ROD
2 1 138-2053 8 TAPPET
3 1 225-5963 1 ROCKER ARM GP
4 1 225-5625 4 LEVER AS
(EACH INCLUDES)
5 1 5B-9079 1 NUT-JAM (3/8-24-THD)
6 1 185-1546 1 SCREW
7 1 225-5634 1 SHAFT AS
8 1 225-5629 2 PLUG
9 1 225-5638 3 SPRING
10 1 225-5640 4 LEVER AS
(EACH INCLUDES)
11 1 5B-9079 1 NUT-JAM (3/8-24-THD)
12 1 185-1546 1 SCREW
13 1 225-5959 2 CLIP
14 1 225-5960 1 BOLT (M8X1.25X60-MM)
15 1 225-5961 2 WASHER (26.7X34.32X0.38-MM THK)
16 1 225-5962 3 BOLT (M8X1.25X30-MM)
GRAPHIC #1 > g00910253
SEBP4152-48 1 of 1 BASIC ENGINE 113399
BBAASSIICC EENNGGIINNEE
233-7235 VALVE MECHANISM GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1102, 1121, 1123, 1209 i02316396
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 067-6095 8 ROD
2 1 138-2053 8 TAPPET
3 1 225-5963 1 ROCKER ARM GP
4 1 225-5625 4 LEVER AS
(EACH INCLUDES)
5 1 5B-9079 1 NUT-JAM (3/8-24-THD)
6 1 185-1546 1 SCREW
7 1 225-5634 1 SHAFT AS
8 1 225-5629 2 PLUG
9 1 225-5638 3 SPRING
10 1 225-5640 4 LEVER AS
(EACH INCLUDES)
11 1 5B-9079 1 NUT-JAM (3/8-24-THD)
12 1 185-1546 1 SCREW
13 1 225-5959 2 CLIP
14 1 225-5960 1 BOLT (M8X1.25X60-MM)
15 1 225-5961 2 WASHER (26.7X34.32X0.38-MM THK)
16 1 225-5962 3 BOLT (M8X1.25X30-MM)
GRAPHIC #1 > g00910253
114400 BASIC ENGINE 1 of 2 SEBP4152-48
BBAASSIICC EENNGGIINNEE
275-0170 VALVE MECHANISM GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1102, 1121, 1123, 1209 i05075254
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
4 1 225-5963 1 ROCKER ARM GP
5 1 225-5625 4 LEVER AS
(EACH INCLUDES)
6 1 5B-9079 1 NUT-JAM (3/8-24-THD)
7 1 185-1546 1 SCREW
8 1 225-5634 1 SHAFT AS
9 1 225-5629 2 PLUG
10 1 225-5638 3 SPRING
11 1 225-5640 4 LEVER AS
(EACH INCLUDES)
12 1 5B-9079 1 NUT-JAM (3/8-24-THD)
13 1 185-1546 1 SCREW
14 1 225-5959 2 CLIP
15 1 225-5960 1 BOLT (M8X1.25X60-MM)
16 1 225-5961 2 WASHER (26.7X34.32X0.38-MM THK)
17 1 225-5962 3 BOLT (M8X1.25X30-MM)
SEBP4152-48 2 of 2 BASIC ENGINE 114411
BBAASSIICC EENNGGIINNEE
275-0170 VALVE MECHANISM GP (ccoonnttdd..) i05075254
GRAPHIC #1 > g01282738
114422 BASIC ENGINE 1 of 1 SEBP4152-48
BBAASSIICC EENNGGIINNEE
367-2088 VALVE MECHANISM GP
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1102, 1121, 1123, 1209 i05206963
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 225-5963 1 ROCKER ARM GP 133
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 BASIC ENGINE 114433
BBAASSIICC EENNGGIINNEE
367-2791 VALVE MECHANISM GP
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1102, 1121, 1123, 1209 i05224111
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 225-5963 1 ROCKER ARM GP 133
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03349465
114444 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
264-8940 BREATHER GP–CRANKCASE
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1317 i03635811
NNOOTTEE
RREEFF. . . . . . . . . . . . . . . . . 333
LINES GP-FUEL . . . . . . . . . . . . . . . . . . . . . . . . . . . . 336
LINES GP-FUEL FILTER . . . . . . . . . . . . . . . . . . . . 339
PUMP GP-FUEL INJECTION . . . . . . . . . . . . . . . . 340
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
TTAABBLLEE OOFF CCOONNTTEENNTTSS
AA22 TABLE OF CONTENTS SEBP4152-48
PUMP GP-FUEL PRIMING . . . . . . . . . . . . . . . . . . 380
SHIELD GP-FUEL LINES. . . . . . . . . . . . . . . . . . . . 382
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG
SSYYSSTTEEMM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 384
ALTERNATOR GP-CHARGING. . . . . . . . . . . . . . . 384
BRACKET GP-SUPPORT. . . . . . . . . . . . . . . . . . . . 386
CABLE GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 388
CONNECTION GP-ELECTRICAL . . . . . . . . . . . . . 391
CONTACTOR GP. . . . . . . . . . . . . . . . . . . . . . . . . . . 393
CONTACTOR GP-GENERATOR. . . . . . . . . . . . . . 397
CONTACTOR GP-OIL PRESSURE . . . . . . . . . . . 398
CONTACTOR GP-TEMPERATURE . . . . . . . . . . . 400
CONTROL GP-ELECTRONIC . . . . . . . . . . . . . . . . 403
CONVERTER GP-ELECTRICAL . . . . . . . . . . . . . . 405
GLOW PLUG GP . . . . . . . . . . . . . . . . . . . . . . . . . . . 406
HARNESS AS-PANEL. . . . . . . . . . . . . . . . . . . . . . . 408
HARNESS AS-WIRING . . . . . . . . . . . . . . . . . . . . . . 409
HARNESS GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
HARNESS GP-WIRING. . . . . . . . . . . . . . . . . . . . . . 416
HEATER GP-JACKET WATER. . . . . . . . . . . . . . . 417
MOUNTING GP-SENSOR. . . . . . . . . . . . . . . . . . . . 419
MOUNTING GP-STARTING MOTOR . . . . . . . . . 420
MOUNTING GP-WIRING. . . . . . . . . . . . . . . . . . . . . 422
RELAY GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
SENDER GP-TEMP & PRESS . . . . . . . . . . . . . . . 425
SENSOR GP-LIQUID LEVEL . . . . . . . . . . . . . . . . 429
SENSOR GP-SPEED. . . . . . . . . . . . . . . . . . . . . . . . 430
SENSOR GP-TEMPERATURE . . . . . . . . . . . . . . . 432
SOLENOID GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 433
STARTING MOTOR GP-AIR . . . . . . . . . . . . . . . . . 434
STARTING MOTOR GP-ELECTRIC . . . . . . . . . . 436
SWITCH GP-DISCONNECT. . . . . . . . . . . . . . . . . . 438
SWITCH GP-LIQUID LEVEL . . . . . . . . . . . . . . . . . 439
TRANSFORMER GP-CURRENT. . . . . . . . . . . . . . 441
WIRING GP-ENGINE. . . . . . . . . . . . . . . . . . . . . . . . 457
WIRING GP-GENERATOR. . . . . . . . . . . . . . . . . . . 467
WIRING GP-INSTR & IGNITION . . . . . . . . . . . . . 468
WIRING GP-PANEL . . . . . . . . . . . . . . . . . . . . . . . . . 472
WIRING GP-SHUTOFF . . . . . . . . . . . . . . . . . . . . . . 474
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD
BBAASSEESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 476
BASE GP-ENGINE & GENERATOR. . . . . . . . . . 476
COVER GP-ACCESS . . . . . . . . . . . . . . . . . . . . . . . 477
DUCT GP-ENCLOSURE . . . . . . . . . . . . . . . . . . . . . 478
ENCLOSURE AS-GENERATOR . . . . . . . . . . . . . . 482
GGEENNEERRAATTOORRSS .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 448877
BRACKET GP-MOUNTING. . . . . . . . . . . . . . . . . . . 487
GENERATOR AR . . . . . . . . . . . . . . . . . . . . . . . . . . . 489
GENERATOR GP. . . . . . . . . . . . . . . . . . . . . . . . . . . 497
LIFTING GP-GENERATOR. . . . . . . . . . . . . . . . . . . 509
PPRRIIMMEE PPAACCKKAAGGEE .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 551100
HOSE GP-TRANSFER . . . . . . . . . . . . . . . . . . . . . . 510
LINES GP-HEATER . . . . . . . . . . . . . . . . . . . . . . . . . 518
MOUNTING GP-HEATER . . . . . . . . . . . . . . . . . . . . 529
OOPPEERRAATTOORR SSTTAATTIIOONN .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 553333
ALARM GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 533
BOX GP-CONTROL PANEL . . . . . . . . . . . . . . . . . 536
BRACKET GP-MOUNTING. . . . . . . . . . . . . . . . . . . 537
GROMMET GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 539
MOUNTING GP-CONTROL . . . . . . . . . . . . . . . . . . 541
MOUNTING GP-CONTROL PANEL. . . . . . . . . . . 544
PANEL AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 550
PANEL AS-CONTROL. . . . . . . . . . . . . . . . . . . . . . . 551
PANEL AS-ELECTRICAL . . . . . . . . . . . . . . . . . . . . 555
PANEL AS-ELECTRONIC. . . . . . . . . . . . . . . . . . . . 556
PANEL GP-CONTROL . . . . . . . . . . . . . . . . . . . . . . 557
PANEL GP-ELECTRONIC . . . . . . . . . . . . . . . . . . . 565
PLATE-MOUNTING. . . . . . . . . . . . . . . . . . . . . . . . . . 587
SSEERRVVIICCEE EEQQUUIIPPMMEENNTT AANNDD
SSUUPPPPLLIIEESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 588
CHART-PLATE & FILM. . . . . . . . . . . . . . . . . . . . . . 588
PPAARRTT NNUUMMBBEERR IINNDDEEXX.. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. BB11
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
TTAABBLLEE OOFF CCOONNTTEENNTTSS
SEBP4152-48 GENERAL INFORMATION AA33
11.. EENNGGIINNEE IIDDEENNTTIIFFIICCAATTIIOONN
Cat engines are identified with Serial Numbers and
Arrangement Numbers. In some cases, Modification
Numbers are also used. The serial number plate which
shows these numbers is mounted on the engine.
Cat dealers need this information to determine which
components were included on the engine when it was
assembled at the factory. This permits accurate
identification of replacement part numbers.
Effective First Quarter 2001 the Cat Product Identification
Number (PIN) changed from 8 to 17 characters. In an
effort to provide uniform equipment identification,
Caterpillar and other construction equipment
manufacturers are moving to comply with the latest
version of the product identification numbering standard.
Non-road machine PINs are defined by ISO 10261. The
new PIN format will apply to all Cat machines and
generator sets. The PIN plates and frame marking will
display the 17 character PIN. The new format will look
like the following:
Where:
1. Caterpillar's World Manufacturing Code (characters 1-
3)
2. Machine Descriptor (characters 4-8)
3. Check Character (character 9)
4. Machine Indicator Section (MIS) or Product Sequence
Number (characters 10-17). These were previously
referred to as the Serial Number.
Machines and generator sets produced before First
Quarter 2001 will maintain their 8 character PIN format.
Components such as engines, transmissions, axles, etc.
and work tools will continue to use an 8 character Serial
Number (S/N).
22.. OORRDDEERRIINNGG PPAARRTTSS
Quality Cat replacement parts are available from Cat
dealers throughout the world. Their parts inventories are
up to date and include all parts normally required to
protect your investment in Cat machines. Dealers may
offer repair kits or remanufactured parts to allow selection
of the most effective repair alternative for a particular
situation. When ordering parts, your order should specify
the quantity, part number, part name, and the serial
number/product identification number of the engine for
which the parts are needed.
33.. PPAARRTTSS MMAANNUUAALL OORRGGAANNIIZZAATTIIOONN
Product information in this manual is presented as
"information elements" that represent all of the
components for the specific model. Engine Arrangement
and Seat Group are examples of information elements.
The information elements are organized alphabetically by
part name and secondarily by part number within each
major section of the manual.
44.. TTAABBLLEE OOFF CCOONNTTEENNTTSS
A table of contents (TOC) is found at the beginning of the
manual. The TOC lists each section of the manual with a
complete list of all information elements organized as
they appear in the manual. Page numbers are provided
for quick reference to detailed parts identification
illustrations and serviceable consist lists.NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5141 4 CLAMP-HOSE
2 1 264-8909 1 HOSE (BREATHER TURBO)
3 1 210-6977 1 ADAPTER
4 1 1S-0994 1 CLIP
M 5 1 6I-4200 1 BOLT (M10X1.5X16-MM)
6 1 230-5811 2 CLAMP-HOSE
7 1 216-9618 1 VALVE-CHECK
8 1 264-8914 1 ADAPTER
E 9 1 268-6427 HOSE (100-CM)
10 1 262-1044 1 BREATHER AS (CRANKCASE)
1 229-3555 1 FILTER ELEMENT-BREATHER (CRANKCASE)
1 262-1046 1 SEAL-O-RING (CRANKCASE BREATHER)
11 1 112-7704 2 BOLT (M6X1X30-MM)
12 1 264-8924 1 HOSE (CRANKCASE BREATHER UPPER)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01147982
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 114455
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
268-8625 BREATHER GP–CRANKCASE
S/N: S1M1-UP; J1Z1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES, NATURALLY ASPIRATED
ENGINES
AN ATTACHMENT
SMCS-1317 i03635773
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5141 4 CLAMP-HOSE
2 1 268-8623 1 HOSE
M 3 1 6I-0291 1 NUT (M8X1.25-THD)
4 1 1S-0994 1 CLIP
M 5 1 6I-4200 1 BOLT (M10X1.5X16-MM)
6 1 230-5811 2 CLAMP-HOSE
7 1 216-9618 1 VALVE-CHECK
8 1 264-8914 1 ADAPTER
E 9 1 268-6427 HOSE (100-CM)
10 1 262-1044 1 BREATHER AS (CRANKCASE)
1 229-3555 1 FILTER ELEMENT-BREATHER (CRANKCASE)
1 262-1046 1 SEAL-O-RING (CRANKCASE BREATHER)
11 1 112-7704 2 BOLT (M6X1X30-MM)
12 1 193-5192 1 CLIP
13 1 268-8624 1 HOSE
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01147881
114466 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
292-8529 BREATHER GP–CRANKCASE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1317 i03636730
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5141 4 CLAMP-HOSE
2 1 292-8530 1 HOSE (CRANKCASE BREATHER)
3 1 1S-0994 1 CLIP
M 4 1 6I-4200 1 BOLT (M10X1.5X16-MM)
5 1 230-5811 2 CLAMP-HOSE
6 1 216-9618 1 VALVE-CHECK
7 1 264-8914 1 ADAPTER
E 8 1 268-6427 HOSE (100-CM)
9 1 262-1044 1 BREATHER AS (CRANKCASE)
9A 1 229-3555 1 FILTER ELEMENT-BREATHER (CRANKCASE)
9B 1 262-1046 1 SEAL-O-RING (CRANKCASE BREATHER)
10 1 112-7704 2 BOLT (M6X1X30-MM)
11 1 292-8532 1 HOSE (CRANKCASE BREATHER UPPER)
12 1 193-5192 1 CLIP
M 13 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 14 1 6I-0291 1 NUT (M8X1.25-THD)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01291240
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 114477
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
299-2227 BREATHER GP–CRANKCASE
S/N: D1K1-UP; S1M1-UP; J1Z1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1317 i03635796
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5141 4 CLAMP-HOSE
2 1 299-2228 1 HOSE
3 1 1S-0994 1 CLIP
M 4 1 6I-4200 1 BOLT (M10X1.5X16-MM)
5 1 230-5811 2 CLAMP-HOSE
6 1 216-9618 1 VALVE-CHECK
7 1 264-8914 1 ADAPTER
E 8 1 268-6427 HOSE
9 1 262-1044 1 BREATHER AS (CRANKCASE)
1 229-3555 1 FILTER ELEMENT-BREATHER (CRANKCASE)
1 262-1046 1 SEAL-O-RING (CRANKCASE BREATHER)
10 1 112-7704 2 BOLT (M6X1X30-MM)
11 1 264-8924 1 HOSE
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01382453
114488 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
299-2229 BREATHER GP–CRANKCASE
S/N: D1K1-UP; S1M1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1317 i03635800
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5141 4 CLAMP-HOSE
2 1 299-2230 1 HOSE
3 1 1S-0994 1 CLIP
M 4 1 6I-4200 1 BOLT (M10X1.5X16-MM)
5 1 230-5811 2 CLAMP-HOSE
6 1 216-9618 1 VALVE-CHECK (CRANKCASE BREATHER)
7 1 264-8914 1 ADAPTER
E 8 1 268-6427 HOSE (100-CM)
9 1 262-1044 1 BREATHER AS (CRANKCASE)
1 229-3555 1 FILTER ELEMENT-BREATHER (CRANKCASE)
1 262-1046 1 SEAL-O-RING
10 1 112-7704 2 BOLT (M6X1X30-MM)
11 1 264-8924 1 HOSE
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01420779
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 114499
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
267-2529 DRAIN GP-OIL–ENGINE
AN ATTACHMENT
SMCS-1372 i02288884
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 194-7158 1 SEAL-O-RING
2 1 193-5101 1 ADAPTER (3/8X3/4)
3 1 234-2489 1 ADAPTER
4 1 195-4644 1 VALVE GP-MANUAL
5 1 7M-7410 1 PLUG-PIPE
GRAPHIC #1 > g01148047
115500 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
272-2229 FILTER GP-ENGINE OIL
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1306, 1308 i02317467
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 7W-2326 1 FILTER AS-ENGINE OIL
GRAPHIC #1 > g00950898
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 115511
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
288-4113 FILTER GP-ENGINE OIL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1306, 1308 i03635803
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4110 1 FILTER GP-ENGINE OIL
1A 1 081-4661 2 FILTER-ENGINE OIL
2 1 6V-0409 2 SEAL-BONDED
3 1 288-4111 2 ADAPTER
4 1 288-4112 2 HOSE AS
M 5 1 6I-0454 2 BOLT (M10X1.5X70-MM)
M 6 1 6I-0594 2 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g01273830
115522 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
298-5190 FILTER GP-ENGINE OIL
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1306, 1308 i03635806
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4110 1 FILTER GP-ENGINE OIL
1A 1 081-4661 2 FILTER-ENGINE OIL
2 1 6V-0409 2 SEAL-BONDED
3 1 288-4111 2 ADAPTER
4 1 298-5192 2 HOSE
M 5 1 6I-0454 2 BOLT (M10X1.5X70-MM)
M 6 1 6I-0594 2 NUT (M10X1.5-THD)
7 1 223-1770 1 BRACKET
8 1 290-1129 1 STRAP
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M - METRIC PART
GRAPHIC #1 > g01420735
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 115533
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
355-8704 FILTER GP-ENGINE OIL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1306, 1308 i05140429
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-7287 1 HOSE
2 1 355-7288 1 HOSE
M 3 1 6I-0454 2 BOLT (M10X1.5X70-MM)
M 4 1 6I-0594 2 NUT (M10X1.5-THD)
5 1 193-5183 2 CLIP
M 6 1 124-3815 1 BOLT (M8X1.25X16-MM)
M 7 1 6I-0291 1 NUT (M8X1.25-THD)
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
M - METRIC PART
GRAPHIC #1 > g03333715
115544 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
271-9995 LINES GP-ENGINE OIL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1307 i02306161
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 237-4092 2 TUBE
2 1 238-1783 3 CAP
3 1 236-6056 1 WASHER-SPECIAL
4 1 271-9994 1 TUBE
GRAPHIC #1 > g01156771
SEBP4152-48 1 of 1 LUBRICATION SYSTEM 115555
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
293-4297 LINES GP-OIL–ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1307 i02544910
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-1277 1 TUBE
2 1 281-0574 1 ADAPTER
3 1 281-1278 1 ADAPTER
GRAPHIC #1 > g01276087
115566 LUBRICATION SYSTEM 1 of 1 SEBP4152-48
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
230-7578 PUMP GP-ENGINE OIL
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1304, 1315 i02317468
NNOOTTEE
RREEFFNNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 100-4461 5 BOLT (M10X1.50X50-MM)
2 1 225-8329 1 PUMP AS-ENGINE OIL
M - METRIC PART
GRAPHIC #1 > g00911993
SEBP4152-48 1 of 1 COOLING SYSTEM 115577
CCOOOOLLIINNGG SSYYSSTTEEMM
230-8086 CONNECTION GP-WATER
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1380 i02654157
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 1 BOLT (M8X1.25X25-MM)
M 2 1 100-3751 1 BOLT (M8X1.25X65-MM)
3 1 254-2268 1 REGULATOR AS-WATER TEMPERATURE (CONNECTOR
INCLUDED)
3A 1 291-8813 1 PLUG
3B 1 291-8845 1 SEAL-O-RING
3C 1 254-2270 1 SEAL-O-RING (WATER TEMPERATURE REGULATOR)
M - METRIC PART
GRAPHIC #1 > g01263922
115588 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
270-0170 CONNECTION GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY, KEEL COOLED ENGINES ONLY
AN ATTACHMENT
SMCS-1380 i02291082
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5158 2 FITTING (1/4)
2 1 100-3752 1 STUD (M8X1.25X30-MM)
M 3 1 6I-0291 2 NUT (M8X1.25-THD)
4 1 196-0272 1 WASHER (8.3X25.4X1.5-MM)
5 1 193-5151 1 CLIP
M - METRIC PART
GRAPHIC #1 > g01148329
SEBP4152-48 1 of 1 COOLING SYSTEM 115599
CCOOOOLLIINNGG SSYYSSTTEEMM
273-7100 CONNECTION GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY
AN ATTACHMENT
SMCS-1380 i02312046
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5158 1 FITTING (1/4)
2 1 100-3752 1 STUD (M8X1.25X30-MM)
M 3 1 6I-0291 2 NUT (M8X1.25-THD)
4 1 196-0272 1 WASHER (8.3X25.4X1.5-MM)
5 1 193-5151 1 CLIP
M - METRIC PART
GRAPHIC #1 > g01159433
116600 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
295-2295 CONNECTION GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1380 i02565472
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 254-2267 1 REGULATOR GP-TEMPERATURE (INCLUDES
CONNECTOR) (WATER)
1A 1 254-2270 1 SEAL-O-RING
M 2 1 6I-0260 2 BOLT (M8X1.25X25-MM)
M - METRIC PART
GRAPHIC #1 > g01319398
SEBP4152-48 1 of 1 COOLING SYSTEM 116611
CCOOOOLLIINNGG SSYYSSTTEEMM
355-5424 CONNECTION GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1380 i05069951
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 262-0511 1 ADAPTER
2 1 2V-9121 1 FITTING
GRAPHIC #1 > g03356698
116622 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
355-5457 CONNECTION GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1380 i05072674
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 262-0511 1 ADAPTER
2 1 176-0569 1 ADAPTER
GRAPHIC #1 > g03356808
SEBP4152-48 1 of 1 COOLING SYSTEM 116633
CCOOOOLLIINNGG SSYYSSTTEEMM
245-4665 CONNECTOR GP-CAB HEATER LINES
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1380 i02317454
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2B-0858 2 PLUG-PIPE
2 1 7W-4669 1 ADAPTER
3 1 173-0418 1 ADAPTER
GRAPHIC #1 > g01029823
116644 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
232-3722 COOLER GP-ENGINE OIL
S/N: J1Z1-UP
PART OF 238-2799 COOLER GP-FLTR BASE & ENG OIL
AN ATTACHMENT
SMCS-1378 i02534920
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 10 BOLT (M8X1.25X25-MM)
2 1 6I-4374 3 BOLT (M8X1.25X60-MM)
M 3 1 101-3895 4 BOLT (M8X1.25X35-MM)
4 1 225-6817 1 COOLER-OIL (ENGINE)
5 1 225-6818 2 SEAL
6 1 272-2265 1 SEAL
M - METRIC PART
GRAPHIC #1 > g01111678
SEBP4152-48 1 of 1 COOLING SYSTEM 116655
CCOOOOLLIINNGG SSYYSSTTEEMM
354-1274 COOLER GP-ENGINE OIL
S/N: D1K1-UP; J1Z1-UP
PART OF 238-2799, 253-2474 COOLER GP-FLTR BASE & ENG OIL
AN ATTACHMENT
SMCS-1378 i05513641
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 10 BOLT (M8X1.25X25-MM)
2 1 6I-4374 3 BOLT (M8X1.25X60-MM)
M 3 1 101-3895 4 BOLT (M8X1.25X35-MM)
4 1 225-6817 1 COOLER-OIL
J 5 1 225-6818 2 SEAL
6 1 272-2265 1 SEAL
AVAILABLE REPAIR KIT(S):
J 416-8777 1 KIT-SEALING (ENGINE OIL COOLER)
(INCLUDES SEALS & LEAFLET)
J - KIT MARKED J SERVICES PART(S) MARKED J
M - METRIC PART
GRAPHIC #1 > g02140458
116666 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
238-2799 COOLER GP-FLTR BASE & ENG OIL
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1306, 1378 i02574313
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 4 BOLT (M8X1.25X20-MM)
M 2 1 6I-0645 4 BOLT (M8X1.25X25-MM)
3 1 8T-7876 1 SEAL-O-RING
4 1 225-7941 1 PLUG
5 1 225-7944 2 GASKET
6 1 249-0974 1 HEAD AS-OIL FILTER
Y 7 1 232-3722 1 COOLER GP-ENGINE OIL 164
8 1 232-3751 1 PLATE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01289551
SEBP4152-48 1 of 1 COOLING SYSTEM 116677
CCOOOOLLIINNGG SSYYSSTTEEMM
238-2799 COOLER GP-FLTR BASE & ENG OIL
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1306, 1378 i03890783
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 4 BOLT (M8X1.25X20-MM)
M 2 1 6I-0645 4 BOLT (M8X1.25X25-MM)
3 1 8T-7876 1 SEAL-O-RING
4 1 225-7941 1 PLUG
5 1 225-7944 2 GASKET
6 1 249-0974 1 HEAD AS-OIL FILTER
Y 7 1 354-1274 1 COOLER GP-ENGINE OIL 165
8 1 232-3751 1 PLATE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02140432
116688 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
253-2472 COOLER GP-FLTR BASE & ENG OIL
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1306, 1378 i02578011
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 4 BOLT (M8X1.25X20-MM)
M 2 1 6I-0645 4 BOLT (M8X1.25X25-MM)
3 1 8T-7876 1 SEAL-O-RING
4 1 225-7941 1 PLUG
5 1 225-7944 2 GASKET
6 1 249-0974 1 HEAD AS-OIL FILTER (ENGINE)
7 1 232-3751 1 PLATE
8 1 233-7223 1 COOLER AS-OIL (ENGINE)
M 8A 1 6I-0260 10 BOLT (M8X1.25X25-MM)
8B 1 6I-4374 3 BOLT (M8X1.25X60-MM)
M 8C 1 101-3895 4 BOLT (M8X1.25X35-MM)
8D 1 225-6818 2 SEAL
8E 1 225-6820 1 GASKET
8F 1 233-7222 1 COOLER-OIL (ENGINE)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 116699
CCOOOOLLIINNGG SSYYSSTTEEMM
253-2472 COOLER GP-FLTR BASE & ENG OIL (ccoonnttdd..) i02578011
GRAPHIC #1 > g01300525
117700 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
253-2472 COOLER GP-FLTR BASE & ENG OIL
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1306, 1378 i04025674
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 4 BOLT (M8X1.25X20-MM)
M 2 1 6I-0645 4 BOLT (M8X1.25X25-MM)
3 1 8T-7876 1 SEAL-O-RING
4 1 225-7941 1 PLUG
5 1 225-7944 2 GASKET
6 1 249-0974 1 HEAD AS-OIL FILTER
7 1 232-3751 1 PLATE
C 8 1 355-6224 1 COOLER AS-OIL (ENGINE)
8A 1 272-2265 1 SEAL
M 8B 1 6I-0260 10 BOLT (M8X1.25X25-MM)
8C 1 6I-4374 3 BOLT (M8X1.25X60-MM)
M 8D 1 101-3895 4 BOLT (M8X1.25X35-MM)
8E 1 225-6818 2 SEAL
8F 1 233-7222 1 COOLER-OIL (ENGINE)
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 117711
CCOOOOLLIINNGG SSYYSSTTEEMM
253-2472 COOLER GP-FLTR BASE & ENG OIL (ccoonnttdd..)i04025674
GRAPHIC #1 > g02208493
117722 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
253-2474 COOLER GP-FLTR BASE & ENG OIL
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1306, 1378 i05233584
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0645 4 BOLT (M8X1.25X25-MM)
2 1 8T-7876 1 SEAL-O-RING
3 1 225-7941 1 PLUG
4 1 225-7944 1 GASKET
Y 5 1 354-1274 1 COOLER GP-ENGINE OIL 165
6 1 252-6318 1 PLATE (BLANKING)
7 1 233-9408 2 GASKET
8 1 235-2451 4 BOLT (M6X1X35-MM)
9 1 249-0975 1 HEAD AS-OIL FILTER (ENGINE)
10 1 244-6872 1 ADAPTER-FILTER
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g02151484
SEBP4152-48 1 of 1 COOLING SYSTEM 117733
CCOOOOLLIINNGG SSYYSSTTEEMM
461-9681 COVER GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1378 i05802869
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-0846 3 BOLT (M6X1X14-MM)
2 1 230-9127 1 COVER
GRAPHIC #1 > g03683761
117744 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
292-7757 FITTING GP
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1380 i02540663
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-4131 1 ADAPTER
2 1 230-7225 1 CONNECTOR
GRAPHIC #1 > g01274052
SEBP4152-48 1 of 1 COOLING SYSTEM 117755
CCOOOOLLIINNGG SSYYSSTTEEMM
294-5387 FLANGE GP-RADIATOR
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i02566793
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0645 4 BOLT (M8X1.25X25-MM)
2 1 238-8289 1 PIPE AS
1 238-8288 1 GASKET-INLET
M - METRIC PART
GRAPHIC #1 > g01311059
117766 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5117 HEAT EXCHANGER GP-SEA WATER
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1379 i02288369
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 210-6896 1 HEAT EXCHANGER GP-SEA WATER
2 1 196-7661 1 CAP AS-END
3 1 194-7227 2 SEAL-O-RING
4 1 210-6897 1 BUNDLE AS-TUBE
5 1 6I-0843 12 BOLT (M6X1X25-MM)
6 1 6I-0235 1 BOLT (M12X1.75X50-MM)
M 7 1 101-3895 2 BOLT (M8X1.25X35-MM)
8 1 270-4176 1 BRACKET-SUPPORT
9 1 210-6899 1 BRACKET
10 1 210-6900 1 BOLT-FLANGE HEAD (M12X1.75X100-MM)
11 1 196-7662 1 CAP-END
12 1 203-9845 1 PLUG
13 1 194-7226 1 PLUG
14 1 214-7654 1 SEAL-O-RING
M 15 1 124-3815 4 BOLT (M8X1.25X16-MM)
M 16 1 100-4830 1 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01148982
SEBP4152-48 1 of 1 COOLING SYSTEM 117777
CCOOOOLLIINNGG SSYYSSTTEEMM
268-8711 HEAT EXCHANGER GP-SEA WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES, HEAT EXCHANGER COOLED ENGINES
CANNOT BE USED WITH KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1379 i02305080
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 210-6896 1 HEAT EXCHANGER GP-SEA WATER
1A 1 196-7662 1 CAP-END
1B 1 196-7661 1 CAP AS-END
1C 1 194-7226 1 PLUG
2 1 194-7227 2 SEAL-O-RING
3 1 210-6897 1 BUNDLE AS-TUBE
4 1 6I-0843 12 BOLT (M6X1X25-MM)
5 1 6I-0235 1 BOLT (M12X1.75X50-MM)
M 6 1 101-3895 2 BOLT (M8X1.25X35-MM)
7 1 270-4176 1 BRACKET-SUPPORT
8 1 210-6899 1 BRACKET
9 1 210-6900 1 BOLT-FLANGE HEAD (M12X1.75X100-MM)
10 1 203-9845 1 PLUG
11 1 214-7654 1 SEAL-O-RING
M 12 1 124-3815 4 BOLT (M8X1.25X16-MM)
M 13 1 100-4830 1 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01155487
117788 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
293-9253 HOSE GP-RADIATOR
S/N: L1K1-UP; S1M1-UP
PART OF 367-0547 HOSE GP-RADIATOR
AN ATTACHMENT
SMCS-1353, 1380 i02566798
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 293-9250 1 CAP
2 1 293-9254 1 BRACKET
3 1 266-7092 8 CLAMP-HOSE
4 1 293-9255 1 TUBE
5 1 293-9256 1 TUBE
E 6 1 5P-1259 HOSE (48-CM)
M 7 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 8 1 6I-0291 1 NUT (M8X1.25-THD)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01311039
SEBP4152-48 1 of 1 COOLING SYSTEM 117799
CCOOOOLLIINNGG SSYYSSTTEEMM
367-0547 HOSE GP-RADIATOR
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353, 1380 i05137031
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 293-9253 1 HOSE GP-RADIATOR 178
2 1 288-4588 1 PLUG-DRAIN
3 1 8L-6557 1 CONNECTOR
4 1 245-7692 3 FITTING-FLARED
5 1 371-1810 1 HOSE AS
6 1 367-0524 1 HOSE
7 1 371-1811 1 ADAPTER
8 1 367-2796 1 VALVE
9 1 195-4640 1 PLUG
10 1 8T-6757 1 PLUG-PIPE
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03342196
118800 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
432-5955 KIT-WATER PUMP
S/N: L1K1-UP; S1M1-UP
PART OF 425-5412 PUMP GP-AUXILIARY SEA WATER
AN ATTACHMENT
SMCS-1361 i05592370
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 196-0387 1 RING-RETAINING
2 1 196-0392 1 GASKET
3 1 196-0393 1 SEAL
4 1 263-7536 1 IMPELLER-PUMP
5 1 263-7537 1 SEAL-O-RING
6 1 420-4328 1 SEAL
7 1 196-0401 6 BOLT (M5X0.8X8-MM)
8 1 263-7539 4 SCREW
GRAPHIC #1 > g03574262
SEBP4152-48 1 of 2 COOLING SYSTEM 118811
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5387 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED ENGINES ONLY
CANNOT BE USED WITH KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02288364
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 1 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 124-6260 3 CLAMP-HOSE
4 1 263-5162 1 TUBE
5 1 263-5164 1 HOSE
6 1 263-5166 1 TUBE
7 1 263-5168 1 HOSE
8 1 214-4131 1 ADAPTER
9 1 263-5173 1 HOSE
10 1 205-2294 1 PLUG-PIPE
11 1 263-5177 1 TUBE
M 12 1 6I-0593 2 BOLT (M10X1.5X30-MM)
13 1 089-7338 1 SLEEVE
14 1 263-5179 1 HOSE
15 1 263-5183 1 HOSE
16 1 5D-1026 2 CLAMP-BAND
17 1 2S-3440 2 CLAMP-HOSE
18 1 193-5183 2 CLIP
19 1 263-5191 1 SPACER (11X19X3-MM THK)
20 1 263-5193 1 BRACKET
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 2J-6540 1 CLAMP-HOSE
23 1 195-4708 1 PLUG
M - METRIC PART
118822 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5387 LINES GP-WATER (ccoonnttdd..) i02288364
GRAPHIC #1 > g01146734
SEBP4152-48 1 of 1 COOLING SYSTEM 118833
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5676 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES, KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02288379
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-5668 1 HOSE
2 1 263-5673 1 HOSE
3 1 263-5670 1 HOSE
4 1 2S-3440 4 CLAMP-HOSE
5 1 5D-1026 2 CLAMP-BAND
GRAPHIC #1 > g01146717
118844 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5766 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02288412
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6258 6 CLAMP-HOSE
2 1 210-6869 1 HOSE
3 1 193-5132 1 HOSE-ELBOW
4 1 263-5763 1 TUBE
5 1 193-5198 2 CLIP
6 1 263-5764 2 SPACER (11X20X60-MM THK)
7 1 210-6871 1 TUBE
8 1 193-5192 1 CLIP
9 1 210-6872 1 BRACKET
M 10 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 11 1 6I-0291 1 NUT (M8X1.25-THD)
M 12 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 13 1 6I-0594 3 NUT (M10X1.5-THD)
M 14 1 103-5687 2 BOLT (M10X1.5X85-MM)15 1 210-6873 1 HOSE
16 1 194-7181 1 WIRE AS-GROUND
17 1 194-7184 2 LOCKWASHER
M 18 1 199-1291 2 NUT-BRASS (M6X1-THD)
19 1 196-0278 1 WIRE AS (BONDING)
M - METRIC PART
GRAPHIC #1 > g01146641
SEBP4152-48 1 of 2 COOLING SYSTEM 118855
CCOOOOLLIINNGG SSYYSSTTEEMM
266-5846 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02288802
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-0164 5 CLAMP-HOSE
2 1 193-5120 1 HOSE
3 1 205-2294 1 PLUG-PIPE
4 1 266-5847 1 TUBE AS
M 5 1 6I-0260 2 BOLT (M8X1.25X25-MM)
6 1 266-5848 2 BRACKET-SUPPORT
7 1 5C-1809 2 SPACER (8X19X6.5-MM)
8 1 237-4089 2 CLIP
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 10 1 6I-0291 2 NUT (M8X1.25-THD)
11 1 194-7201 2 HOSE-REDUCER
12 1 9M-2904 2 CLAMP-HOSE
13 1 210-6655 2 PLUG
14 1 2S-3440 1 CLAMP-HOSE
15 1 263-5193 1 BRACKET
16 1 263-5179 1 HOSE
17 1 5D-1026 3 CLAMP-BAND
18 1 266-5849 1 TUBE AS
19 1 193-5183 2 CLIP
M 20 1 6I-0593 2 BOLT (M10X1.5X30-MM)
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 263-5191 1 SPACER (11X19X3-MM THK)
23 1 089-7338 1 SLEEVE
24 1 196-0383 1 CLAMP-HOSE
25 1 263-5168 1 HOSE
26 1 266-5850 1 TUBE AS
27 1 7W-4666 1 HOSE
M - METRIC PART
118866 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
266-5846 LINES GP-WATER (ccoonnttdd..) i02288802
GRAPHIC #1 > g01146875
SEBP4152-48 1 of 1 COOLING SYSTEM 118877
CCOOOOLLIINNGG SSYYSSTTEEMM
268-9251 LINES GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES, KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02290173
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-2904 8 CLAMP-HOSE
2 1 268-9245 1 HOSE
3 1 268-9246 1 TUBE
4 1 193-5184 2 CLIP
M 5 1 102-9941 2 BOLT (M12X1.75X25-MM)
6 1 268-9247 1 HOSE
7 1 268-9248 1 TUBE
M 8 1 103-5687 2 BOLT (M10X1.5X85-MM)
9 1 193-5198 2 CLIP
10 1 263-5764 2 SPACER (11X20X60-MM THK)
M 11 1 6I-0594 2 NUT (M10X1.5-THD)
12 1 193-5133 1 HOSE
13 1 268-9249 1 TUBE
14 1 268-9250 1 HOSE
M - METRIC PART
GRAPHIC #1 > g01147815
118888 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
269-1754 LINES GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02290179
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 2S-3440 4 CLAMP-HOSE
2 1 268-4270 1 HOSE
3 1 193-5104 1 HOSE-ELBOW
GRAPHIC #1 > g01147741
SEBP4152-48 1 of 1 COOLING SYSTEM 118899
CCOOOOLLIINNGG SSYYSSTTEEMM
269-1767 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02290306
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-5668 1 HOSE
2 1 2S-3440 2 CLAMP-HOSE
GRAPHIC #1 > g01147979
119900 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
269-4247 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES, MARINE SOCIETY APPROVED ENGINES ONLY
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02301327
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-0164 5 CLAMP-HOSE
2 1 193-5120 1 HOSE
3 1 205-2294 1 PLUG-PIPE
4 1 269-4246 1 TUBE
M 5 1 6I-0260 2 BOLT (M8X1.25X25-MM)
6 1 266-5848 2 BRACKET-SUPPORT
7 1 5C-1809 2 SPACER (8X19X6.5-MM)
8 1 237-4089 2 CLIP
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 10 1 6I-0291 2 NUT (M8X1.25-THD)
11 1 194-7201 2 HOSE-REDUCER
12 1 9M-2904 2 CLAMP-HOSE
13 1 210-6655 2 PLUG
14 1 2S-3440 1 CLAMP-HOSE
15 1 263-5193 1 BRACKET
16 1 263-5179 1 HOSE
17 1 5D-1026 3 CLAMP-BAND
18 1 266-5849 1 TUBE AS
19 1 193-5183 2 CLIP
M 20 1 6I-0593 2 BOLT (M10X1.5X30-MM)
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 263-5191 1 SPACER (11X19X3-MM THK)
23 1 089-7338 1 SLEEVE
24 1 196-0383 1 CLAMP-HOSE
25 1 263-5168 1 HOSE
26 1 266-5850 1 TUBE AS
27 1 7W-4666 1 HOSE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 119911
CCOOOOLLIINNGG SSYYSSTTEEMM
269-4247 LINES GP-WATER (ccoonnttdd..) i02301327
GRAPHIC #1 > g01153023
119922 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
269-9096 LINES GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES, HEAT EXCHANGER COOLED ENGINES ONLY
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02291012
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5104 1 HOSE-ELBOW
2 1 263-5673 1 HOSE
3 1 263-5670 1 HOSE
4 1 2S-3440 6 CLAMP-HOSE
5 1 5D-1026 2 CLAMP-BAND
6 1 268-4270 1 HOSE
SEBP4152-48 2 of 2 COOLING SYSTEM 119933
CCOOOOLLIINNGG SSYYSSTTEEMM
269-9096 LINES GP-WATER (ccoonnttdd..) i02291012
GRAPHIC #1 > g01158044
119944 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
271-0151 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED ENGINES, TWIN STARTER MOTOR ENGINES WHICH ARE
FITTED WITH A WATER JACKET HEATER
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02291568
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 1 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 124-6260 3 CLAMP-HOSE
4 1 263-5162 1 TUBE
5 1 263-5164 1 HOSE
6 1 263-5166 1 TUBE
7 1 263-5168 1 HOSE
8 1 214-4131 1 ADAPTER
9 1 263-5173 1 HOSE
10 1 205-2294 1 PLUG-PIPE
11 1 271-0149 1 TUBE
M 12 1 6I-0593 2 BOLT (M10X1.5X30-MM)
13 1 089-7338 1 SLEEVE
14 1 263-5179 1 HOSE
15 1 263-5183 1 HOSE
16 1 5D-1026 2 CLAMP-BAND
17 1 2S-3440 2 CLAMP-HOSE
18 1 193-5183 2 CLIP
19 1 263-5191 1 SPACER (11X19X3-MM THK)
20 1 263-5193 1 BRACKET
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 2J-6540 1 CLAMP-HOSE (WITH LINER)
23 1 195-4708 1 PLUG
24 1 214-0697 1 ADAPTER
25 1 214-7269 1 BRACKET
M 26 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 119955
CCOOOOLLIINNGG SSYYSSTTEEMM
271-0151 LINES GP-WATER (ccoonnttdd..) i02291568
GRAPHIC #1 > g01148591
119966 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
271-1337 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED, SINGLE STARTER MOTOR ENGINES FITTED WITH A WATER
JACKET HEATER
CANNOT BE USED WITH KEEL COOLED OR TWIN STARTER MOTOR ENGINES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02309237
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 1 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 124-6260 3 CLAMP-HOSE
4 1 263-5162 1 TUBE
5 1 263-5164 1 HOSE
6 1 263-5166 1 TUBE
7 1 263-5168 1 HOSE
8 1 214-4131 1 ADAPTER
9 1 263-5173 1 HOSE
10 1 205-2294 1 PLUG-PIPE
11 1 271-0149 1 TUBE
M 12 1 6I-0593 2 BOLT (M10X1.5X30-MM)
13 1 089-7338 1 SLEEVE
14 1 263-5179 1 HOSE
15 1 263-5183 1 HOSE
16 1 5D-1026 2 CLAMP-BAND
17 1 2S-3440 2 CLAMP-HOSE
18 1 193-5183 2 CLIP
19 1 263-5191 1 SPACER (11X19X3-MM THK)
20 1 263-5193 1 BRACKET
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 196-0383 1 CLAMP-HOSE
23 1 195-4708 1 PLUG
24 1 214-0697 1 ADAPTER
25 1 214-0694 1 BRACKET
M 26 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 119977
CCOOOOLLIINNGG SSYYSSTTEEMM
271-1337 LINES GP-WATER (ccoonnttdd..) i02309237
GRAPHIC #1 > g01157328
119988 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
272-4907 LINES GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY, HEAT EXCHANGER COOLED ENGINES
ONLY
AN ATTACHMENT
SMCS-1355, 1380, 1393i02745129
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 210-6871 1 TUBE
2 1 193-5192 3 CLIP
3 1 210-6872 1 BRACKET
M 4 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 5 1 6I-0291 2 NUT (M8X1.25-THD)
M 6 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 7 1 6I-0594 3 NUT (M10X1.5-THD)
8 1 194-7181 2 WIRE AS-GROUND
9 1 194-7184 5 LOCKWASHER
M 10 1 199-1291 5 NUT-BRASS (M6X1-THD)
11 1 272-4904 1 TUBE
12 1 196-0278 3 WIRE AS
13 1 263-5764 2 SPACER (11X20X60-MM THK)
14 1 193-5198 2 CLIP
M 15 1 103-5687 2 BOLT (M10X1.5X85-MM)
16 1 268-9248 1 TUBE
17 1 272-4905 1 TUBE
18 1 272-4906 1 TUBE
19 1 6I-4793 1 BOLT (M8X1.25X50-MM)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 119999
CCOOOOLLIINNGG SSYYSSTTEEMM
272-4907 LINES GP-WATER (ccoonnttdd..) i02745129
GRAPHIC #1 > g01160383
220000 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
272-6941 LINES GP-WATER
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY, HEAT EXCHANGER COOLED ENGINES
ONLY
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02314957
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-2904 14 CLAMP-HOSE
2 1 9M-0164 2 CLAMP-HOSE
3 1 210-6873 2 HOSE
4 1 193-5122 1 HOSE-REDUCER
5 1 193-5105 1 STRAINER
6 1 205-2247 1 HOSE
7 1 193-5133 2 HOSE
8 1 268-9247 1 HOSE
9 1 272-6940 1 HOSE
SEBP4152-48 2 of 2 COOLING SYSTEM 220011
CCOOOOLLIINNGG SSYYSSTTEEMM
272-6941 LINES GP-WATER (ccoonnttdd..) i02314957
GRAPHIC #1 > g01160389
220022 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
281-2368 LINES GP-WATER
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02516940
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 268-9245 1 HOSE
2 1 268-9246 1 TUBE
3 1 193-5184 1 CLIP
M 4 1 6I-0423 1 BOLT (M12X1.75X30-MM)
5 1 268-9247 1 HOSE
6 1 268-9248 1 TUBE
M 7 1 103-5687 2 BOLT (M10X1.5X85-MM)
8 1 193-5198 2 CLIP
10 1 263-5764 2 SPACER (11X20X60-MM THK)
M 11 1 6I-0594 2 NUT (M10X1.5-THD)
12 1 193-5133 1 HOSE
13 1 268-9249 1 TUBE
14 1 268-9250 1 HOSE
15 1 9M-2904 8 CLAMP-HOSE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 220033
CCOOOOLLIINNGG SSYYSSTTEEMM
281-2368 LINES GP-WATER (ccoonnttdd..) i02516940
GRAPHIC #1 > g01278761
220044 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
287-1940 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02516106
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-2904 6 CLAMP-HOSE
2 1 210-6869 1 HOSE
3 1 193-5132 1 HOSE-ELBOW
4 1 263-5763 1 TUBE
5 1 193-5198 2 CLIP
6 1 263-5764 2 SPACER (11X20X60-MM THK)
7 1 210-6871 1 TUBE
8 1 193-5192 1 CLIP
9 1 210-6872 1 BRACKET
M 10 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 11 1 6I-0291 1 NUT (M8X1.25-THD)
M 12 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 13 1 6I-0594 3 NUT (M10X1.5-THD)
M 14 1 103-5687 2 BOLT (M10X1.5X85-MM)
15 1 210-6873 1 HOSE
16 1 287-1938 1 WIRE AS
17 1 194-7184 2 LOCKWASHER
M 18 1 199-1291 2 NUT-BRASS (M6X1-THD)
19 1 287-1939 1 WIRE AS
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 220055
CCOOOOLLIINNGG SSYYSSTTEEMM
287-1940 LINES GP-WATER (ccoonnttdd..) i02516106
GRAPHIC #1 > g01267419
220066 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
287-2924 LINES GP-WATER
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02746195
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 210-6871 1 TUBE
2 1 193-5192 3 CLIP
3 1 210-6872 1 BRACKET
M 4 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 5 1 6I-0291 2 NUT (M8X1.25-THD)
M 6 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 7 1 6I-0594 3 NUT (M10X1.5-THD)
8 1 287-1938 2 WIRE AS
9 1 194-7184 5 LOCKWASHER
M 10 1 199-1291 5 NUT-BRASS (M6X1-THD)
11 1 272-4904 1 TUBE
12 1 287-1939 3 WIRE AS
13 1 263-5764 2 SPACER (11X20X60-MM THK)
14 1 193-5198 2 CLIP
M 15 1 103-5687 2 BOLT (M10X1.5X85-MM)
16 1 268-9248 1 TUBE
17 1 272-4905 1 TUBE
18 1 272-4906 1 TUBE
19 1 6I-4793 1 BOLT (M8X1.25X50-MM)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 220077
CCOOOOLLIINNGG SSYYSSTTEEMM
287-2924 LINES GP-WATER (ccoonnttdd..) i02746195
GRAPHIC #1 > g01265268
220088 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
293-0745 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02628699
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6258 3 CLAMP-HOSE
2 1 5D-1026 1 CLAMP-BAND
3 1 297-5844 1 REGULATOR-WATER TEMPERATURE (82-DEG C)
4 1 293-0749 1 HOSE
5 1 293-0750 1 HOSE
6 1 293-0751 1 HOSE
7 1 263-5668 1 HOSE
8 1 2S-3440 4 CLAMP-HOSE
9 1 193-5198 1 CLIP
10 1 8T-4121 1 WASHER-HARD (11X21X2.5-MM THK)
GRAPHIC #1 > g01277666
SEBP4152-48 1 of 1 COOLING SYSTEM 220099
CCOOOOLLIINNGG SSYYSSTTEEMM
294-4423 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02566795
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6258 3 CLAMP-HOSE
2 1 5D-1026 1 CLAMP-BAND
3 1 297-5844 1 REGULATOR-WATER TEMPERATURE (82-DEG C)
4 1 293-0749 1 HOSE
5 1 294-4426 1 HOSE
6 1 293-0751 1 HOSE
7 1 263-5668 1 HOSE
8 1 2S-3440 4 CLAMP-HOSE
M 9 1 100-4830 1 BOLT (M10X1.5X20-MM)
10 1 8T-4121 1 WASHER-HARD (11X21X2.5-MM THK)
11 1 193-5198 1 CLIP
12 1 210-6797 1 BRACKET
13 1 124-6260 1 CLAMP-HOSE
M 14 1 6I-0594 1 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g01311967
221100 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
296-0364 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02618271
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5192 2 CLIP
2 1 195-4660 1 PIPE
3 1 193-5133 1 HOSE
4 1 124-6258 2 CLAMP-HOSE
5 1 4P-8525 1 SPACER (9X16X30-MM THK)
M 6 1 6I-0291 1 NUT (M8X1.25-THD)
M 7 1 6I-0455 1 BOLT (M8X1.25X55-MM)
M - METRIC PART
GRAPHIC #1 > g01311611
SEBP4152-48 1 of 1 COOLING SYSTEM 221111
CCOOOOLLIINNGG SSYYSSTTEEMM
298-5280 LINES GP-WATER
S/N: D1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED, ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02637497
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 2 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 298-5281 1 PIPE
4 1 298-5282 1 PIPE
5 1 231-1351 3 GROMMET
6 1 231-1350 2 GROMMET
GRAPHIC #1 > g01420749
221122 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
298-5288 LINES GP-WATER
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02637790
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6258 4 CLAMP-HOSE
2 1 210-6869 1 HOSE
3 1 193-5132 1 HOSE-ELBOW
4 1 263-5763 1 TUBE
5 1 193-5198 2 CLIP
6 1 263-5764 2 SPACER (11X20X60-MM THK)
M 7 1 6I-0594 2 NUT (M10X1.5-THD)
M 8 1 103-5687 2 BOLT (M10X1.5X85-MM)
9 1 194-7184 1 LOCKWASHER
M 10 1 3C-3681 1 NUT
11 1 196-0278 1 WIRE AS
M - METRIC PART
GRAPHIC #1 > g01420758
SEBP4152-48 1 of 2 COOLING SYSTEM 221133
CCOOOOLLIINNGG SSYYSSTTEEMM
299-3088 LINES GP-WATER
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02638414
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5192 1 CLIP
M 2 1 6I-0291 1 NUT (M8X1.25-THD)
3 1 194-7184 3 LOCKWASHER
M 4 1 3C-3681 3 NUT5 1 272-4904 1 TUBE
6 1 196-0278 3 WIRE AS
7 1 263-5764 2 SPACER (11X20X60-MM THK)
8 1 193-5198 2 CLIP
M 9 1 103-5687 2 BOLT (M10X1.5X85-MM)
10 1 268-9248 1 TUBE
11 1 272-4905 1 TUBE
M 12 1 6I-0254 1 BOLT (M8X1.25X30-MM)
M 13 1 6I-0594 2 NUT (M10X1.5-THD)
M - METRIC PART
221144 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
299-3088 LINES GP-WATER (ccoonnttdd..) i02638414
GRAPHIC #1 > g01382181
SEBP4152-48 1 of 2 COOLING SYSTEM 221155
CCOOOOLLIINNGG SSYYSSTTEEMM
299-3089 LINES GP-WATER
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02638403
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6259 10 CLAMP-HOSE
2 1 9M-0164 2 CLAMP-HOSE
3 1 210-6873 1 HOSE
4 1 193-5122 1 HOSE-REDUCER
5 1 193-5105 1 STRAINER (INLET)
6 1 205-2247 1 HOSE
7 1 193-5133 1 HOSE
8 1 268-9247 1 HOSE
9 1 272-6940 1 HOSE
221166 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
299-3089 LINES GP-WATER (ccoonnttdd..) i02638403
GRAPHIC #1 > g01382157
SEBP4152-48 1 of 1 COOLING SYSTEM 221177
CCOOOOLLIINNGG SSYYSSTTEEMM
299-5482 LINES GP-WATER
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1355, 1380, 1393 i02638378
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-5481 1 PIPE
2 1 193-5192 1 CLIP
3 1 9M-2904 2 CLAMP-HOSE
4 1 193-5133 1 HOSE
M 5 1 101-3895 1 BOLT (M8X1.25X35-MM)
M 6 1 3C-3681 1 NUT
7 1 194-7181 1 WIRE AS-GROUND
8 1 194-7184 1 LOCKWASHER
M - METRIC PART
GRAPHIC #1 > g01382491
221188 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
324-0213 LINES GP-WATER
S/N: L1K1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i03539031
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 323-8714 1 HOSE
2 1 323-8728 1 HOSE
3 1 282-1637 1 HOSE
4 1 2S-3440 3 CLAMP-HOSE
5 1 9M-2904 2 CLAMP-HOSE
6 1 5D-1026 2 CLAMP-BAND
7 1 282-1673 1 HOSE
8 1 124-6260 2 CLAMP-HOSE
9 1 205-2260 1 HOSE
SEBP4152-48 2 of 2 COOLING SYSTEM 221199
CCOOOOLLIINNGG SSYYSSTTEEMM
324-0213 LINES GP-WATER (ccoonnttdd..) i03539031
GRAPHIC #1 > g01903281
222200 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
355-5464 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05124629
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 1 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 124-6260 3 CLAMP-HOSE
4 1 263-5162 1 TUBE
5 1 263-5164 1 HOSE
6 1 355-7270 1 PIPE
7 1 263-5168 1 HOSE
8 1 2V-9121 1 FITTING
9 1 263-5173 1 HOSE
10 1 205-2294 1 PLUG-PIPE
11 1 271-0149 1 TUBE
M 12 1 6I-0593 2 BOLT (M10X1.5X30-MM)
13 1 089-7338 1 SLEEVE
14 1 263-5179 1 HOSE
15 1 263-5183 1 HOSE
16 1 5D-1026 2 CLAMP-BAND
17 1 2S-3440 2 CLAMP-HOSE
18 1 193-5183 2 CLIP
19 1 263-5191 1 SPACER (11X19X3-MM THK)
20 1 263-5193 1 BRACKET
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 2J-6540 1 CLAMP-HOSE
23 1 262-0511 1 ADAPTER
24 1 001-9440 1 CONNECTOR
25 1 355-7271 1 CONNECTOR
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 222211
CCOOOOLLIINNGG SSYYSSTTEEMM
355-5464 LINES GP-WATER (ccoonnttdd..) i05124629
GRAPHIC #1 > g03356236
222222 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8701 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05124658
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 9M-0164 3 CLAMP-HOSE
2 1 193-5120 1 HOSE
3 1 205-2294 1 PLUG-PIPE
4 1 266-5847 1 TUBE AS
M 5 1 6I-0260 2 BOLT (M8X1.25X25-MM)
6 1 266-5848 2 BRACKET-SUPPORT
7 1 5C-1809 2 SPACER (8X19X6.5-MM)
8 1 237-4089 2 CLIP
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 10 1 6I-0291 2 NUT (M8X1.25-THD)
11 1 001-9440 1 CONNECTOR
12 1 245-7692 1 FITTING-FLARED
13 1 2S-3440 1 CLAMP-HOSE
14 1 263-5193 1 BRACKET
15 1 263-5179 1 HOSE
16 1 5D-1026 3 CLAMP-BAND
17 1 266-5849 1 TUBE AS
18 1 193-5183 2 CLIP
M 19 1 6I-0593 2 BOLT (M10X1.5X30-MM)
M 20 1 6I-0654 1 BOLT (M10X1.5X25-MM)
21 1 263-5191 1 SPACER (11X19X3-MM THK)
22 1 089-7338 1 SLEEVE
23 1 196-0383 1 CLAMP-HOSE
24 1 263-5168 1 HOSE
25 1 355-7283 1 PIPE
26 1 7W-4666 1 HOSE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 222233
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8701 LINES GP-WATER (ccoonnttdd..) i05124658
GRAPHIC #1 > g03340312
222244 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8702 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05140385
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6259 10 CLAMP-HOSE
2 1 268-9245 1 HOSE
3 1 268-9246 1 TUBE
4 1 193-5184 2 CLIP
5 1 186-0236 1 BOLT
6 1 268-9247 1 HOSE
7 1 268-9248 1 TUBE
M 8 1 103-5687 2 BOLT (M10X1.5X85-MM)
9 1 193-5198 2 CLIP
10 1 263-5764 2 SPACER (11X20X60-MM THK)
M 11 1 6I-0594 2 NUT (M10X1.5-THD)
12 1 193-5133 1 HOSE
13 1 355-7285 1 PIPE
14 1 268-9250 1 HOSE
15 1 292-1524 1 SPACER (12.5X25X12-MM THK)
16 1 262-0524 1 ADAPTER
17 1 195-4644 1 VALVE GP-MANUAL
18 1 7M-7410 1 PLUG-PIPE
19 1 1K-5845 2 CLAMP-HOSE
M 20 1 124-3815 1 BOLT (M8X1.25X16-MM)
M 21 1 6I-0291 1 NUT (M8X1.25-THD)
22 1 195-4690 1 ELBOW
23 1 355-7286 1 PIPE
24 1 245-7692 2 FITTING-FLARED
25 1 359-3874 1 BRACKET
M 26 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 222255
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8702 LINES GP-WATER (ccoonnttdd..) i05140385
GRAPHIC #1 > g03341063
222266 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8708 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05125734
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5120 1 HOSE
2 1 9M-0164 4 CLAMP-HOSE
3 1 193-5139 3 CLAMP-HOSE
4 1 263-5162 1 TUBE
5 1 263-5164 1 HOSE
6 1 355-7270 1 PIPE
7 1 263-5168 1 HOSE
8 1 2V-9121 1 FITTING
9 1 263-5173 1 HOSE
10 1 205-2294 1 PLUG-PIPE
11 1 263-5177 1 TUBE
M 12 1 6I-0593 2 BOLT (M10X1.5X30-MM)
13 1 089-7338 1 SLEEVE
14 1 263-5179 1 HOSE
15 1 193-5183 2 CLIP
16 1 5D-1026 2 CLAMP-BAND
17 1 2S-3440 2 CLAMP-HOSE
18 1 263-5183 1 HOSE
19 1 263-5191 1 SPACER (11X19X3-MM THK)
20 1 263-5193 1 BRACKET
M 21 1 6I-0654 1 BOLT (M10X1.5X25-MM)
22 1 196-0383 1 CLAMP-HOSE
23 1 001-9440 1 CONNECTOR
24 1 355-7271 1 CONNECTOR
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 222277
CCOOOOLLIINNGG SSYYSSTTEEMM
355-8708 LINES GP-WATER (ccoonnttdd..) i05125734
GRAPHIC #1 > g03333916
222288 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
362-2788 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH BRONZE COOLING PUMP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05153534
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 245-4743 2 ADAPTER
2 1 357-6812 1 PIPE
3 1 357-6813 2 ADAPTER
4 1 357-6814 1 HOSE
5 1 124-6259 14 CLAMP-HOSE
6 1 210-6798 1 HOSE
7 1 357-6815 1 PIPE
8 1 193-5198 2 CLIP
M 9 1 103-5687 2 BOLT (M10X1.5X85-MM)
10 1 263-5764 2 SPACER (11X20X60-MM THK)
M 11 1 6I-0594 2 NUT (M10X1.5-THD)
12 1 100-4458 1 BOLT (M8X1.25X14-MM)
13 1 234-3106 1 WASHER
M 14 1 6I-0291 1 NUT (M8X1.25-THD)
15 1 287-1939 4 WIRE AS
16 1 194-7184 5 LOCKWASHER
M 17 1 3C-3681 5 NUT
18 1 237-2251 1 CAP
19 1 237-2248 1 CLIP
20 1 193-5133 2 HOSE
21 1 268-9248 1 TUBE
22 1 268-9247 1 HOSE
23 1 272-6940 1 HOSE
24 1 210-6873 1 HOSE
25 1 272-4905 1 TUBE
26 1 272-4906 1 TUBE
27 1 193-5192 2 CLIP
28 1 6I-4793 1 BOLT (M8X1.25X50-MM)
29 1 287-1938 1 WIRE AS
M- METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 222299
CCOOOOLLIINNGG SSYYSSTTEEMM
362-2788 LINES GP-WATER (ccoonnttdd..) i05153534
GRAPHIC #1 > g03355781
223300 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
362-3230 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05153550
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4618 1 ELBOW
2 1 245-4743 1 ADAPTER
3 1 210-6873 1 HOSE
4 1 357-6816 1 PIPE
5 1 210-6795 1 HOSE
6 1 124-6259 10 CLAMP-HOSE
7 1 237-2251 1 CAP
8 1 237-2248 1 CLIP
9 1 210-6869 1 HOSE
10 1 357-6813 2 ADAPTER
11 1 237-2244 1 PIPE
12 1 357-6818 1 HOSE
13 1 357-6819 1 PIPE
14 1 263-5764 2 SPACER (11X20X60-MM THK)
M 15 1 103-5687 2 BOLT (M10X1.5X85-MM)
16 1 193-5198 2 CLIP
M 17 1 6I-0594 2 NUT (M10X1.5-THD)
18 1 287-1938 1 WIRE AS
19 1 194-7184 4 LOCKWASHER
M 20 1 3C-3681 4 NUT
21 1 287-1939 3 WIRE AS
22 1 100-4458 1 BOLT (M8X1.25X14-MM)
23 1 234-3106 1 WASHER
24 1 357-6814 1 HOSE
25 1 357-6812 1 PIPE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 223311
CCOOOOLLIINNGG SSYYSSTTEEMM
362-3230 LINES GP-WATER (ccoonnttdd..) i05153550
GRAPHIC #1 > g03355230
223322 COOLING SYSTEM 1 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
364-5219 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05153562
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 364-5156 1 PIPE
2 1 193-5192 3 CLIP
3 1 210-6872 1 BRACKET
M 4 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 5 1 6I-0291 2 NUT (M8X1.25-THD)
M 6 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 7 1 6I-0594 3 NUT (M10X1.5-THD)
8 1 287-1938 2 WIRE AS
9 1 194-7184 5 LOCKWASHER
M 10 1 3C-3681 5 NUT
11 1 364-5157 1 PIPE
12 1 287-1939 3 WIRE AS
13 1 263-5764 2 SPACER (11X20X60-MM THK)
14 1 193-5198 2 CLIP
M 15 1 103-5687 2 BOLT (M10X1.5X85-MM)
16 1 268-9248 1 TUBE
17 1 272-4905 1 TUBE
18 1 272-4906 1 TUBE
19 1 6I-4793 1 BOLT (M8X1.25X50-MM)
20 1 357-6813 2 ADAPTER
21 1 124-6259 14 CLAMP-HOSE
22 1 9M-0164 2 CLAMP-HOSE
23 1 210-6873 2 HOSE
24 1 193-5122 1 HOSE-REDUCER
25 1 193-5105 1 STRAINER
26 1 205-2247 1 HOSE
27 1 193-5133 2 HOSE
28 1 268-9247 1 HOSE
29 1 272-6940 1 HOSE
M - METRIC PART
SEBP4152-48 2 of 2 COOLING SYSTEM 223333
CCOOOOLLIINNGG SSYYSSTTEEMM
364-5219 LINES GP-WATER (ccoonnttdd..) i05153562
GRAPHIC #1 > g03359077
223344 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
364-5220 LINES GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1355, 1380, 1393 i05140437
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 124-6259 6 CLAMP-HOSE
2 1 364-5159 1 HOSE
3 1 193-5132 1 HOSE-ELBOW
4 1 375-0132 1 TUBE
5 1 193-5198 2 CLIP
6 1 263-5764 2 SPACER (11X20X60-MM THK)
7 1 364-5156 1 PIPE
8 1 193-5192 1 CLIP
9 1 210-6872 1 BRACKET
M 10 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 11 1 178-3336 1 NUT-HEX FLANGE (M8X1.25-THD)
M 12 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 13 1 6I-0594 3 NUT (M10X1.5-THD)
M 14 1 103-5687 2 BOLT (M10X1.5X85-MM)
15 1 210-6873 1 HOSE
16 1 287-1938 1 WIRE AS
17 1 194-7184 2 LOCKWASHER
M 18 1 3C-3681 2 NUT
19 1 287-1939 1 WIRE AS
20 1 357-6813 2 ADAPTER
21 1 371-1813 1 ADAPTER
M - METRIC PART
GRAPHIC #1 > g03356112
SEBP4152-48 1 of 2 COOLING SYSTEM 223355
CCOOOOLLIINNGG SSYYSSTTEEMM
425-5412 PUMP GP-AUXILIARY SEA WATER
S/N: L1K1-UP; S1M1-UP
PART OF 263-7530 PUMP GP-WATER
AN ATTACHMENT
SMCS-1371 i05367582
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
J 1 1 196-0387 1 RING-RETAINING
2 1 196-0388 1 PLATE-WEAR
J 3 1 196-0393 1 SEAL
4 1 7F-9993 2 BALL BEARING
5 1 196-0397 1 RING-RETAINING
6 1 196-0399 1 SHAFT-PUMP
7 1 199-1336 1 SEAL-SHAFT
8 1 263-7533 1 SCREW
9 1 263-7535 1 CAM
J 10 1 263-7536 1 IMPELLER-PUMP
J 11 1 263-7537 1 SEAL-O-RING
12 1 263-7540 1 GEAR
13 1 263-7541 1 SEAL-O-RING
J 14 1 420-4328 1 SEAL
15 1 432-5959 1 HOUSING-WATER PUMP
16 1 441-5566 1 COVER-PUMP
J 17 1 263-7539 4 SCREW
AVAILABLE REPAIR KIT(S):
JY 432-5955 1 KIT-WATER PUMP 180
J - KIT MARKED J SERVICES PARTS MARKED J
Y - SEPARATE ILLUSTRATION
223366 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
425-5412 PUMP GP-AUXILIARY SEA WATER (ccoonnttdd..) i05367582
GRAPHIC #1 > g03554116
SEBP4152-48 1 of 2 COOLING SYSTEM 223377
CCOOOOLLIINNGG SSYYSSTTEEMM
230-7355 PUMP GP-WATER
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1361 i03568524
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 2 1 6I-0254 2 BOLT (M8X1.25X30-MM)
M 3 1 100-3751 5 BOLT (M8X1.25X65-MM)
4 1 113-8129 2 BOLT (M8X1.25X75-MM)
5 1 225-7741 1 CONNECTION AS
6 1 225-7738 1 SEAL-O-RING
7 1 225-7739 1 SEAL-O-RING
8 1 225-8016 1 PUMP GP-WATER
8A 1 225-8019 1 GASKET
8B 1 286-3592 1 GEAR-WATER PUMP
AVAILABLE REPAIR KIT(S):
247-0144 1 KIT-WATER PUMP
(INCLUDES 2 DIFFERENT GASKETS)
M - METRIC PART
223388 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
230-7355 PUMP GP-WATER (ccoonnttdd..) i03568524
GRAPHIC #1 > g01897273
SEBP4152-48 1 of 1 COOLING SYSTEM 223399
CCOOOOLLIINNGG SSYYSSTTEEMM
263-7530 PUMP GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
TYPE 1
SMCS-1361 i02419185
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 263-7531 1 PUMP GP-WATER 241
2 1 194-7205 1 PLATE-CLAMP
3 1 194-7151 1 SEAL-O-RING
4 1 113-4597 2 BOLT (M8X10-MM)
5 1 6I-0303 1 BOLT (M10X1.5X30-MM)
M 6 1 6I-0840 1 STUD (M8X20-MM)
7 1 100-3752 2 STUD (M8X1.25X30-MM)
M 8 1 6I-0291 2 NUT (M8X1.25-THD)
9 1 194-7206 1 WASHER
AVAILABLE REPAIR KIT(S):
278-8697 1 KIT-SERVICE (WATER PUMP)
(INCLUDES IMPELLER, END COVER SCREWS, END COVER
SEAL, AND LIP SEAL)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01148886
224400 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
263-7530 PUMP GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
TYPE 2
SMCS-1361 i05369534
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
CY 1 1 425-5412 1 PUMP GP-AUXILIARY SEA WATER 235
2 1 194-7205 1 PLATE-CLAMP
3 1 194-7151 1 SEAL-O-RING
4 1 113-4597 2 BOLT (M8X10-MM)
5 1 6I-0303 1 BOLT (M10X1.5X30-MM)
M 6 1 6I-0840 1 STUD (M8X20-MM)
7 1 100-3752 2 STUD (M8X1.25X30-MM)
M 8 1 6I-0291 2 NUT (M8X1.25-THD)
9 1 194-7206 1 WASHER
AVAILABLE REPAIR KIT(S):
278-8697 1 KIT-SERVICE (WATER PUMP)
(INCLUDES IMPELLER, END COVER SCREWS, END COVER
SEAL, AND LIP SEAL)
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01148886
SEBP4152-48 1 of 1 COOLING SYSTEM 224411
CCOOOOLLIINNGG SSYYSSTTEEMM
263-7531 PUMP GP-WATER
S/N: L1K1-UP; S1M1-UP
PART OF 263-7530 PUMP GP-WATER
AN ATTACHMENT
SMCS-1361 i02314937
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 7F-9993 2 BALL BEARING
2 1 196-0387 1 RING-RETAINING
3 1 196-0388 1 PLATE-WEAR
4 1 196-0393 1 SEAL
5 1 196-0397 1 RING-RETAINING
6 1 196-0399 1 SHAFT-PUMP
7 1 199-1336 1 SEAL-SHAFT
8 1 205-3018 1 SEAL
9 1 263-7532 1 HOUSING-PUMP
10 1 263-7533 1 SCREW
11 1 263-7535 1 CAM
12 1 263-7536 1 IMPELLER-PUMP
13 1 263-7537 1 SEAL-O-RING
14 1 263-7538 1 COVER-PUMP
15 1 263-7539 4 SCREW
16 1 263-7540 1 GEAR
17 1 263-7541 1 SEAL-O-RING
GRAPHIC #1 > g01160036
224422 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
357-7595 PUMP GP-WATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1361 i05153511
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 372-2282 1 BRACKET
2 1 238-9574 1 PUMP
3 1 6I-0917 4 BOLT (M6X1X25-MM)
4 1 6I-0918 4 NUT
M 5 1 6I-0291 1 NUT (M8X1.25-THD)
M 6 1 9X-6277 1 BOLT (M8X1.25X60-MM)
M 7 1 6I-0654 1 BOLT (M10X1.5X25-MM)
M 8 1 6I-0594 2 NUT (M10X1.5-THD)
9 1 237-2237 1 BOLT (M12X120-THD)
10 1 237-2195 1 SPACER (13X25X72.4-MM THK)
11 1 196-0348 1 WASHER (13X23.5X2.5-MM THK)
12 1 357-7593 1 SPACER
13 1 357-7594 1 SPACER
14 1 198-5809 2 LEVER-ALTERNATOR
15 1 364-2132 1 BOLT-SQUARE NECK
M 16 1 124-3815 2 BOLT (M8X1.25X16-MM)
M - METRIC PART
GRAPHIC #1 > g03341114
SEBP4152-48 1 of 1 COOLING SYSTEM 224433
CCOOOOLLIINNGG SSYYSSTTEEMM
292-1522 RADIATOR & MOUNTING GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i05113709
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 236-8773 1 BRACKET-MOUNTING
2 1 101-7537 8 BOLT (M12X1.75X35-MM)
3 1 320-9211 2 MOUNTING
4 1 105-4173 2 BOLT (M10X1.5X60-MM)
5 1 101-7539 2 WASHER
6 1 101-7540 2 WASHER
7 1 292-1524 2 SPACER (12.5X25X12-MM THK)
8 1 101-7541 4 BOLT
9 1 316-7990 1 BRACKET
10 1 101-7546 1 MOUNT
M 11 1 6I-0594 2 NUT (M10X1.5-THD)
M 12 1 100-4830 2 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01273952
224444 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
294-4472 RADIATOR & MOUNTING GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i03536480
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 251-8404 1 BRACKET
M 2 1 6I-0593 6 BOLT (M10X1.5X30-MM)
3 1 320-9211 2 MOUNTING
M 4 1 100-4461 2 BOLT (M10X1.5X50-MM)
5 1 101-7539 2 WASHER
6 1 101-7540 2 WASHER
7 1 101-7541 4 BOLT
8 1 292-2949 1 BRACKET-SUPPORT
9 1 101-7546 1 MOUNT
M 10 1 6I-0594 2 NUT (M10X1.5-THD)
M 11 1 100-4830 2 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01311064
SEBP4152-48 1 of 1 COOLING SYSTEM 224455
CCOOOOLLIINNGG SSYYSSTTEEMM
367-0546 RADIATOR AS
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i05136951
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 293-9242 1 RADIATOR GP 247
2 1 266-7092 8 CLAMP-HOSE
M 3 1 6I-0645 4 BOLT (M8X1.25X25-MM)
4 1 238-8289 1 PIPE AS
4A 1 238-8288 1 GASKET-INLET
M 5 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 6 1 178-3336 1 NUT-HEX FLANGE (M8X1.25-THD)
7 1 367-0519 1 HOSE
8 1 288-4588 1 PLUG-DRAIN
9 1 367-0520 1 HOSE
10 1 8L-6557 1 CONNECTOR
11 1 245-7692 3 FITTING-FLARED
12 1 371-1810 1 HOSE AS
13 1 367-0522 1 HOSE
14 1 371-1811 1 ADAPTER
15 1 367-2796 1 VALVE
16 1 195-4640 1 PLUG
17 1 8T-6757 1 PLUG-PIPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03355530
224466 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
433-8144 RADIATOR AS
S/N: L1K1-UP; S1M1-UP
PART OF 433-8147, 439-0118 RADIATOR GP
AN ATTACHMENT
SMCS-1353 i05356651
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 8T-4984 4 CLAMP-HOSE
2 1 293-9250 1 CAP
3 1 433-8145 1 PIPE
4 1 433-8146 1 PIPE
5 1 436-6304 1 PIPE
6 1 437-4084 1 PIPE
7 1 437-4090 2 HOSE
8 1 437-4091 2 HOSE
9 1 437-4092 3 HOSE
10 1 437-4094 1 BRACKET
11 1 144-0367 4 CLAMP-HOSE
GRAPHIC #1 > g03677372
SEBP4152-48 1 of 2 COOLING SYSTEM 224477
CCOOOOLLIINNGG SSYYSSTTEEMM
293-9242 RADIATOR GP
S/N: L1K1-UP; S1M1-UP
PART OF 367-0546 RADIATOR AS
AN ATTACHMENT
SMCS-1353 i03635810
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 266-7092 8 CLAMP-HOSE
2 1 293-9243 1 TUBE
3 1 293-9244 1 TUBE
4 1 293-9245 1 TUBE
5 1 293-9246 1 TUBE
6 1 256-2058 2 HOSE
7 1 266-2815 2 HOSE-RADIATOR
E 8 1 5P-1259 HOSE (8-CM)
E 8A 1 5P-1259 HOSE (12-CM)
E 8B 1 5P-1259 HOSE (12-CM)
E 8C 1 5P-1259 HOSE (12-CM)
9 1 293-9250 1 CAP
10 1 8T-4984 4 CLAMP-HOSE
11 1 144-0367 4 CLAMP-HOSE
M 12 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 13 1 6I-0291 1 NUT (M8X1.25-THD)
14 1 293-9251 1 BRACKET
E - ORDER BY THE CENTIMETER
M - METRIC PART
224488 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
293-9242 RADIATOR GP (ccoonnttdd..) i03635810
GRAPHIC #1 > g01376099
SEBP4152-48 1 of 1 COOLING SYSTEM 224499
CCOOOOLLIINNGG SSYYSSTTEEMM
433-8147 RADIATOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i05356679
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 2 1 6I-0291 1 NUT (M8X1.25-THD)
M 3 1 6I-0645 4 BOLT (M8X1.25X25-MM)
4 1 108-1478 1 VALVE GP
1 238-5081 1 SEAL-O-RING
5 1 238-8289 1 PIPE AS
1 238-8288 1 GASKET-INLET
6 1 266-7092 8 CLAMP-HOSE
7 1 288-4588 1 PLUG-DRAIN
Y 8 1 433-8144 1 RADIATOR AS 246
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03429701
225500 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
439-0118 RADIATOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1353 i05401887
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 2 1 6I-0291 1 NUT (M8X1.25-THD)
M 3 1 6I-0645 4 BOLT (M8X1.25X25-MM)
4 1 108-1478 1 VALVE GP
1 238-5081 1 SEAL-O-RING
5 1 195-4640 1 PLUG
6 1 238-8289 1 PIPE AS
1 238-8288 1 GASKET-INLET
7 1 245-7692 3 FITTING-FLARED
8 1 266-7092 8 CLAMP-HOSE
9 1 288-4588 1 PLUG-DRAIN
10 1 367-0522 1 HOSE
11 1 367-2796 1 VALVE
12 1 371-1810 1 HOSE AS
13 1 371-1811 1 ADAPTER
Y 14 1 433-8144 1 RADIATOR AS 246
15 1 8L-6557 1 CONNECTOR
16 1 8T-6757 1 PLUG-PIPE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03432802
SEBP4152-48 1 of 2 COOLING SYSTEM 225511
CCOOOOLLIINNGG SSYYSSTTEEMM
268-3870 TANK GP-COOLANT
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1377 i02327209
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-5632 1 TANK AS (COOLANT)
M 2 1 161-7619 6 SCREW (M4X0.7X10-MM)
3 1 245-6013 1 ADAPTER
4 1 245-6014 1 SEAL-O-RING
5 1 263-5639 2 ELBOW
6 1 153-0709 4 BOLT (M10X1.5X140-MM)
7 1 263-5640 4 SPACER (11X20X40-MM THK)
8 1 210-6738 1 GASKET (EXPANSION TANK CAP)
9 1 230-5119 1 CAP-PRESSURE (7-PSI) (EXPANSION TANK)
E 10 1 197-3800 LOOM (22-CM)
E 11 1 265-2757 HOSE (27-CM)
12 1 205-2260 1 HOSE
13 1 263-5647 1 PLUG
E - ORDER BY THE CENTIMETER
M - METRIC PART
225522 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
268-3870 TANK GP-COOLANT (ccoonnttdd..) i02327209
GRAPHIC #1 > g01146736
SEBP4152-48 1 of 2 COOLING SYSTEM 225533
CCOOOOLLIINNGG SSYYSSTTEEMM
271-0108 TANK GP-COOLANT
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY
CANNOT BE USED WITH HEAT EXCHANGER COOLED ENGINES
AN ATTACHMENT
SMCS-1377 i02330711
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 234-2610 1 HOSE
2 1 193-5187 2 COUPLING-HOSE
3 1 194-7148 2 PLUG
4 1 205-2260 1 HOSE
5 1 213-7483 2 ADAPTER
6 1 230-5119 1 CAP-PRESSURE (7-PSI) (EXPANSION TANK)
7 1 213-7487 1 RING
8 1 213-7488 1 SEAL-O-RING
9 1 213-7491 1 TUBE AS-FILLER
10 1 195-4677 4 SCREW-MACHINE (M4X0.7X16-MM)
M 11 1 213-7489 1 SCREW (M4X25-MM)
12 1 213-7490 1 TANK (COOLANT)
13 1 213-7482 1 GAUGE-SIGHT (FLUID LEVEL) (COOLANT)
14 1 210-6738 1 GASKET (EXPANSION TANK CAP)
15 1 234-2611 1 HOSE
16 1 124-6258 4 CLAMP-HOSE
17 1 271-0109 1 TEE
18 1 271-0110 1 TEE
M - METRIC PART
225544 COOLING SYSTEM 2 of 2 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
271-0108 TANK GP-COOLANT (ccoonnttdd..) i02330711
GRAPHIC #1 > g01153169
SEBP4152-48 1 of 1 COOLING SYSTEM 225555
CCOOOOLLIINNGG SSYYSSTTEEMM
374-2078 TANK GP-COOLANTS/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1377 i05587448
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 205-2260 1 HOSE
2 1 194-7148 2 PLUG
3 1 213-7483 2 ADAPTER
4 1 193-5187 2 COUPLING-HOSE
5 1 234-2610 1 HOSE
6 1 234-2611 1 HOSE
7 1 124-6259 4 CLAMP-HOSE
8 1 271-0109 1 TEE
9 1 271-0110 1 TEE
10 1 449-2872 1 CAP-PRESSURE (7-PSI) (COOLANT)
11 1 213-7487 1 RING
12 1 213-7488 1 SEAL-O-RING
13 1 213-7491 1 TUBE AS-FILLER
14 1 195-4677 4 SCREW-MACHINE (M4X0.7X16-MM)
M 15 1 213-7489 1 SCREW (M4X0.7X25-MM)
16 1 374-2077 1 TANK
17 1 213-7482 1 GAUGE-SIGHT (FLUID LEVEL)
18 1 210-6738 1 GASKET
M - METRIC PART
GRAPHIC #1 > g03342005
225566 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
263-5658 TANK GP-EXPANSION
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES, KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1354 i02327216
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-5632 1 TANK AS
M 2 1 161-7619 6 SCREW (M4X0.7X10-MM)
3 1 245-6013 1 ADAPTER
4 1 245-6014 1 SEAL-O-RING
5 1 263-5639 2 ELBOW
6 1 153-0709 4 BOLT (M10X1.5X140-MM)
7 1 263-5640 4 SPACER (11X20X40-MM THK)
8 1 210-6738 1 GASKET (EXPANSION TANK CAP)
9 1 230-5119 1 CAP-PRESSURE (7-PSI) (EXPANSION TANK)
E 10 1 197-3800 LOOM (27-CM)
E 11 1 265-2757 HOSE (33-CM)
12 1 205-2260 1 HOSE
13 1 263-5647 1 PLUG
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01146714
SEBP4152-48 1 of 1 COOLING SYSTEM 225577
CCOOOOLLIINNGG SSYYSSTTEEMM
269-1895 TANK GP-EXPANSION
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED ENGINES
CANNOT BE USED WITH KEEL COOLED ENGINES
AN ATTACHMENT
SMCS-1354 i02290368
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 245-1235 1 TANK GP-EXPANSION
2 1 245-1236 1 HOSE
GRAPHIC #1 > g01147795
225588 COOLING SYSTEM 1 of 1 SEBP4152-48
CCOOOOLLIINNGG SSYYSSTTEEMM
289-0458 TUBE AS
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1374, 5057 i02539336
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-0459 1 TUBE-FUEL
GRAPHIC #1 > g01273801
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 225599
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-3127 ADAPTER-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7498 i03635329
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
GRAPHIC #1 > g01951257
226600 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
265-7802 AFTERCOOLER GP
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1063 i03526441
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 343-1813 1 AFTERCOOLER AS
2 1 153-0709 3 BOLT (M10X1.5X140-MM)
3 1 265-7804 1 DUCT
M 4 1 6I-0260 4 BOLT (M8X1.25X25-MM)
5 1 100-3753 1 STUD
6 1 265-7806 2 STUD
8 1 265-7180 2 BRACKET
M 9 1 124-3815 2 BOLT (M8X1.25X16-MM)
10 1 265-7808 1 SEAL-O-RING
M 11 1 100-4830 2 BOLT (M10X1.5X20-MM)
12 1 9R-5383 3 BOSS (11X25X20-MM THK)
13 1 194-7227 1 SEAL-O-RING
M 14 1 6I-0291 4 NUT (M8X1.25-THD)
15 1 230-5120 1 STUD
16 1 035-8063 1 PLUG
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 226611
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
265-7802 AFTERCOOLER GP (ccoonnttdd..) i03526441
GRAPHIC #1 > g01148971
226622 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
233-5180 AIR CLEANER GP
S/N: L1K1-UP; S1M1-UP
PART OF 268-6276, 292-0468 AIR CLEANER GP
AN ATTACHMENT
SMCS-1051, 1054 i02309731
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 233-5182 1 FILTER ELEMENT AS-AIR (PRIMARY)
2 1 233-5184 1 FILTER ELEMENT AS-AIR (SECONDARY)
GRAPHIC #1 > g01086817
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 226633
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
252-8751 AIR CLEANER GP
S/N: S1M1-UP
8 INCH DIAMETER
PART OF 269-3099, 367-3313 AIR CLEANER GP
AN ATTACHMENT
SMCS-1051, 1054 i02623694
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 110-6326 1 FILTER ELEMENT AS-AIR (PRIMARY)
2 1 110-6331 1 FILTER ELEMENT AS-AIR (SECONDARY)
3 1 9M-6738 1 CLAMP-HOSE
4 1 101-7856 1 CAP (AIR CLEANER)
5 1 127-9376 1 COVER
6 1 127-9377 1 VALVE-AIR CLEANER DUST
7 1 175-2584 1 BRACKET
8 1 252-9208 1 INDICATOR-AIR FILTER CHANGE
GRAPHIC #1 > g01078182
226644 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
265-6528 AIR CLEANER GP
S/N: L1K1-UP; S1M1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES
AN ATTACHMENT
SMCS-1051, 1054 i05393884
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 381-9374 1 AIR CLEANER GP 276
2 1 265-6526 1 HOSE
3 1 265-6527 2 CLIP
M 4 1 6I-0260 2 BOLT (M8X1.25X25-MM)
5 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01159436
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 226655
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
268-6276 AIR CLEANER GP
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1051, 1054 i02288988
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0291 2 NUT (M8X1.25-THD)
M 2 1 6I-1090 2 BOLT (M8X1.25X40-MM)
3 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
4 1 2J-6540 1 CLAMP-HOSE
5 1 268-6277 1 HOSE
6 1 6V-3582 1 CLAMP-HOSE
Y 7 1 233-5180 1 AIR CLEANER GP 262
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01159473
226666 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
269-3099 AIR CLEANER GP
S/N: S1M1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES, TURBOCHARGED AND AFTERCOOLED
ENGINES
AN ATTACHMENT
TYPE 1
SMCS-1051, 1054 i02301197
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 252-8751 1 AIR CLEANER GP 263
2 1 269-3100 1 HOSE
3 1 101-7860 1 CLIP
4 1 101-7861 1 CLIP
M 5 1 6I-0260 1 BOLT (M8X1.25X25-MM)
6 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
M 7 1 6I-1090 1 BOLT (M8X1.25X40-MM)
8 1 210-6977 1 ADAPTER
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01157330
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 226677
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
269-3099 AIR CLEANER GP
S/N: S1M1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES, TURBOCHARGED AND AFTERCOOLED
ENGINES
AN ATTACHMENT
TYPE 2
SMCS-1051, 1054 i05523491
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
C 1 1 101-7856 1 CAP (AIR CLEANER)
2 1 269-3100 1 HOSE
3 1 101-7860 1 CLIP
4 1 101-7861 1 CLIP
M 5 1 6I-0260 1 BOLT (M8X1.25X25-MM)
6 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
M 7 1 6I-1090 1 BOLT (M8X1.25X40-MM)
8 1 210-6977 1 ADAPTER
C 9 1 110-2556 1 AIR CLEANER GP
9A 1 110-6326 1 FILTER ELEMENT AS-AIR (PRIMARY)
9B 1 110-6331 1 FILTER ELEMENT AS-AIR (SECONDARY)
C 10 1 315-4691 1 INDICATOR-AIR FILTER CHANGE
C 11 1 418-3216 1 BRACKET
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
GRAPHIC #1 > g03689774
226688 AIR INLET AND EXHAUSTSYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
292-0468 AIR CLEANER GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1051, 1054 i02540712
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0291 2 NUT (M8X1.25-THD)
M 2 1 6I-0254 2 BOLT (M8X1.25X30-MM)
3 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
4 1 4D-7922 1 CLAMP-HOSE
5 1 292-0469 1 HOSE
6 1 1W-4724 1 CLAMP-HOSE
Y 7 1 233-5180 1 AIR CLEANER GP 262
8 1 210-6977 1 ADAPTER
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01274175
SEBP4152-48 1 of 2 AIR INLET AND EXHAUST SYSTEM 226699
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-2208 AIR CLEANER GP
S/N: L1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1051, 1054 i05522305
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-2209 1 HOSE
2 1 196-0383 1 CLAMP-HOSE
3 1 6V-3582 1 CLAMP-HOSE
4 1 210-6977 1 ADAPTER
5 1 299-2210 1 HOSE
6 1 8T-6726 2 CLAMP-HOSE
7 1 296-7500 1 AIR CLEANER AS
1 233-5182 1 FILTER ELEMENT AS-AIR (PRIMARY)
M 8 1 6I-0254 1 BOLT (M8X1.25X30-MM)
9 1 8C-0572 1 WASHER (8.8X25.5X2-MM THK)
M 10 1 6I-0291 1 NUT (M8X1.25-THD)
M - METRIC PART
227700 AIR INLET AND EXHAUST SYSTEM 2 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-2208 AIR CLEANER GP (ccoonnttdd..) i05522305
GRAPHIC #1 > g01478734
SEBP4152-48 1 of 2 AIR INLET AND EXHAUST SYSTEM 227711
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-2213 AIR CLEANER GP
S/N: L1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1051, 1054 i05523518
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-2215 1 HOSE
2 1 196-0383 1 CLAMP-HOSE
3 1 6V-3582 1 CLAMP-HOSE
4 1 210-6977 1 ADAPTER
5 1 299-2210 1 HOSE
6 1 8T-6726 2 CLAMP-HOSE
7 1 296-7500 1 AIR CLEANER AS
1 233-5182 1 FILTER ELEMENT AS-AIR (PRIMARY)
M 8 1 6I-0254 1 BOLT (M8X1.25X30-MM)
9 1 8C-0572 1 WASHER (8.8X25.5X2-MM THK)
M 10 1 6I-0291 1 NUT (M8X1.25-THD)
M - METRIC PART
227722 AIR INLET AND EXHAUST SYSTEM 2 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-2213 AIR CLEANER GP (ccoonnttdd..) i05523518
GRAPHIC #1 > g01478734
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 227733
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-2231 AIR CLEANER GP
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1051, 1054 i02638351
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 296-7498 1 AIR CLEANER AS
1 123-2367 1 FILTER ELEMENT-AIR (PRIMARY)
M 2 1 6I-0260 2 BOLT (M8X1.25X25-MM)
3 1 8C-0572 1 WASHER (8.8X25.5X2-MM THK)
4 1 265-6526 2 HOSE
5 1 265-6527 4 CLIP
M - METRIC PART
GRAPHIC #1 > g01382475
227744 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-3085 AIR CLEANER GP
S/N: L1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1051, 1054 i05523530
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-3100 1 HOSE
2 1 8T-6726 2 CLAMP-HOSE
3 1 101-7860 1 CLIP
4 1 101-7861 1 CLIP
M 5 1 6I-0260 1 BOLT (M8X1.25X25-MM)
6 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
M 7 1 6I-1090 1 BOLT (M8X1.25X40-MM)
8 1 210-6977 1 ADAPTER
9 1 296-7499 1 AIR CLEANER AS
1 212-4478 1 FILTER ELEMENT-AIR (PRIMARY)
10 1 299-3087 1 HOSE
M - METRIC PART
GRAPHIC #1 > g01478192
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 227755
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
367-3313 AIR CLEANER GP
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1051, 1054 i05218259
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 252-8751 1 AIR CLEANER GP 263
2 1 269-3100 1 HOSE
3 1 101-7860 1 CLIP
4 1 101-7861 1 CLIP
M 5 1 6I-0260 1 BOLT (M8X1.25X25-MM)
6 1 8C-0572 2 WASHER (8.8X25.5X2-MM THK)
M 7 1 6I-1090 1 BOLT (M8X1.25X40-MM)
8 1 210-6977 1 ADAPTER
9 1 293-1937 2 CLAMP-HOSE
10 1 367-0523 1 HOSE
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g03359228
227766 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
381-9374 AIR CLEANER GP
S/N: L1K1-UP; S1M1-UP
PART OF 265-6528 AIR CLEANER GP
AN ATTACHMENT
SMCS-1051, 1054 i05555129
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 101-4920 1 CAP (AIR CLEANER)
1A 1 9M-6738 1 CLAMP-HOSE
2 1 122-6616 1 FILTER GP-AIR
2A 1 123-2367 1 FILTER ELEMENT-AIR (PRIMARY)
2B 1 123-2368 1 FILTER ELEMENT-AIR (SECONDARY)
2C 1 127-9674 1 COVER
2D 1 127-9675 1 VALVE-AIR CLEANER DUST
3 1 127-9676 1 CLAMP
4 1 315-4691 1 INDICATOR-AIR FILTER CHANGE
GRAPHIC #1 > g03522036
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 227777
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
233-7491 ELBOW GP-AIR INLET
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1087 i03798893
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0572 2 BOLT (M8X1.25X20-MM)
2 1 111-8222 12 BOLT (M8X16-MM)
3 1 114-2579 4 GASKET
4 1 256-4447 1 ELBOW AS-AIR INLET
4A 1 238-8288 1 GASKET-INLET
5 1 185-6627 3 PLATE
6 1 233-7489 2 BOLT (M8X1.25-THD)
M - METRIC PART
GRAPHIC #1 > g02076879
227788 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
263-5805 ELBOW GP-EXHAUST
S/N: D1K1-UP; L1K1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES
AN ATTACHMENT
SMCS-1061 i02304803
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-4012 4 STUD
2 1 263-5802 1 GASKET
3 1 263-5803 1 ELBOW
4 1 6I-0563 4 NUT (M10X1.5-THD)
GRAPHIC #1 > g01155445
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 227799
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
269-5153 ELBOW GP-EXHAUST
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1061 i02308832
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-5149 1 ELBOW
2 1 269-5150 1 JACKET AS
3 1 7W-4566 1 GASKET (EXHAUST OUTLET)
4 1 269-5151 6 BOLT (M8X1.25X40-MM)
5 1 101-3803 6 LOCKNUT (M8X1.25-THD)
6 1 195-4639 1 PLUG
GRAPHIC #1 > g01147950
228800 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
272-6535 ELBOW GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES ONLY
AN ATTACHMENT
SMCS-1061 i02308837
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4628 1 HOSE
2 1 9M-2904 2 CLAMP-HOSE
3 1 272-6531 1 ELBOW AS-EXHAUST
4 1 272-6532 1 SHIELD AS-HEAT
5 1 195-4715 1 GASKET-EXHAUST
6 1 269-5151 4 BOLT (M8X1.25X40-MM)
7 1 101-3803 4 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g01158933
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 228811
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
272-6993 ELBOW GP-EXHAUST
S/N: S1M1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES, TURBOCHARGED AND AFTERCOOLED
ENGINES
AN ATTACHMENT
SMCS-1061 i02306158
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4628 1 HOSE
2 1 9M-2904 2 CLAMP-HOSE
3 1 272-6991 1 ELBOW AS-EXHAUST
4 1 272-6992 1 SHIELD-EXHAUST
5 1 195-4715 1 GASKET-EXHAUST
6 1 269-5151 4 BOLT (M8X1.25X40-MM)
7 1 101-3803 4 LOCKNUT (M8X1.25-THD)55.. MMAAIINNTTEENNAANNCCEE PPAARRTTSS IINNDDEEXX
The Maintenance Parts Index, located near the beginning
of the manual, references most frequently used
maintenance part numbers, providing description,
quantity, usage and page number. This information is
organized alphabetically by part description.
GGEENNEERRAALL IINNFFOORRMMAATTIIOONN
AA44 GENERAL INFORMATION SEBP4152-48
66.. IINNDDEEXX
The index located near the front of the manual is an
alphabetical listing of all information elements included in
the manual. Page numbers are provided for quick
reference to detailed parts identification illustrations and
serviceable consist lists.
77.. PPAARRTT NNUUMMBBEERR IINNDDEEXX
A numerical index listing all part numbers and the
corresponding page number(s) appears at the back of
the manual.
88.. CCAAPPTTIIOONNSS
Captions located at the beginning of each information
element identify the part number and part name along
with additional descriptive information. S/N information
found in each caption should be used to select correct
information for a specific engine. Field replacement
options, identification of optional attachment
components, and where used ("part of") information is
also provided.
The first line of a caption is shown in larger type font to
indicate the beginning of an information element.
Captions for additional pages that may be required to
illustrate an information element will be shown in
standard type font and will include the term (contd.) .
99.. NNOONN--SSEERRVVIICCEEDD PPAARRTTSS
In some instances it is necessary to display non-serviced
parts that are a link to lower level serviceable consist
lists. These non-serviced part numbers are shown in
italic type indicating that they are not available. All consist
lists have not been converted to reflect this
enhancement.
1100.. PPAARRTTSS LLIISSTT RREEFFEERREENNCCEE NNUUMMBBEERRSS
Numbers shown in the Ref No column correspond to
numbers used in the associated graphic(s). An
alphabetic suffix may be added to a reference number to
identify lower level consist items. Numbers shown in the
Graphic Ref column refer to the graphic number identifier
displayed in the lower left corner of each illustration. The
Graphic Ref number may be used in combination with the
item Ref No to determine the correct part number. There
may be intentional omission of a Ref No in a consist list
as information is updated to reflect the latest serviceable
part numbers.
1111.. IINNDDEENNTTEEDD PPAARRTT NNAAMMEESS
When a part name is indented in a parts list, it is part of
(included in) the group or assembly under which it is
indented.
1122.. IILLLLUUSSTTRRAATTIIOONN RREEFFEERREENNCCEE LLEETTTTEERRSS
When necessary, illustrations contain reference letters
(A, B, C etc.) that are intended to track lines and
harnesses from one point to another. They are also used
to show where to reconnect illustrations that have been
separated.
1133.. AABBBBRREEVVIIAATTIIOONNSS AANNDD SSYYMMBBOOLLSS
OO..DD.. – Outside Diameter
II..DD.. – Inside Diameter
AA – Not Part Of This Group
BB – Use As Required
CC – Change From Previous Type
DD – Order By The Meter
EE – Order By The Centimeter
FF – Not Shown
GG – Order By The Inch
II – Refer To Hydraulic Information System
MM – Metric Part
RR – Remfg Part May Be Available
YY – Separate Illustration
ZZ – Not Serviced Separately
1144.. RREEPPLLAACCEEMMEENNTT PPAARRTTSS FFOORR GGEENNEERRAATTOORRSS
Only those generators which are sold and serviced
exclusively by Cat Dealers are illustrated on the following
pages. Externally-regulated Cat Diesel Electric Sets are
equipped with generators made by other manufacturers.
Parts for these generators are NOT serviced by
Caterpillar Inc. Parts lists and parts should be ordered
from the manufacturer whose name is shown on the
Generator Name Plate, always giving the generator
rating and serial number shown.
1155.. DDEESSCCRRIIPPTTIIOONN OOFF TTYYPPEE CCHHAANNGGEESS
Type - A type is defined as any configuration change that
requires an additional Information Element for an
Arrangement, Group, or Assembly. If serial number
breaks for types are not available, a type # ( Type 1,
Type 2, etc.) will be displayed in the caption. These
"type" changes are identified with a "C" note (change
from previous type) in the Parts List. Only the "types" that
apply to this Parts Manual will be included. Additional
types may exist causing "C" notes to appear on an
Information Element when no other types are shown.
GGEENNEERRAALL IINNFFOORRMMAATTIIOONN
SEBP4152-48 GENERAL INFORMATION AA55
1166.. >
This symbol indicates the end of an information element.
NNOOTTEE::
CCoonnttiinnuuiinngg iimmpprroovveemmeenntt aanndd aaddvvaanncceemmeenntt ooff
pprroodduucctt ddeessiiggnn mmaayy ccaauussee cchhaannggeess ttoo yyoouurr mmaacchhiinnee
wwhhiicchh mmaayy nnoott bbee iinncclluuddeedd iinn tthhiiss ppuubblliiccaattiioonn..
WWhheenneevveerr aa qquueessttiioonn aarriisseess rreeggaarrddiinngg yyoouurr CCaatt
pprroodduucctt oorr tthhiiss ppuubblliiccaattiioonn,, pplleeaassee ccoonnssuulltt yyoouurr CCaatt
ddeeaalleerr ffoorr tthhee llaatteesstt aavvaaiillaabbllee iinnffoorrmmaattiioonn..
GGEENNEERRAALL IINNFFOORRMMAATTIIOONN
AA66 REPAIR ALTERNATIVES SEBP4152-48
RREEMMAANNUUFFAACCTTUURREEDD CCOOMMPPOONNEENNTTSS
As an option when making repairs consider Cat Remanufactured Components. Components that are available through
the Cat Remanufactured Program are identified three ways in the parts book:
• with the letter R in the note field of the parts list
• with an R* at the beginning of the first line of the caption
• with an *R at the end of the first line of the caption
Typical components included in the Remanufacturing Program include:
ALTERNATORS
CONNECTING RODS
CRANKSHAFTS - UNDERSIZE
CRANKSHAFTS - UPGRADE TO NEW
CYLINDER HEADS
ELECTRONIC CONTROLMODULES (ECM)
ELECTRONIC SENSORS
FUEL INJECTORS
FUEL NOZZLES
FUEL PUMPS
GOVERNORS
OIL PUMPS
PISTONS
SHORT BLOCKS
STARTERS
TURBOCHARGERS - COMPLETE
TURBOCHARGER CARTRIDGES
WATER PUMPS
Cat Remanufactured engines for many engine arrangements are also available.
RREEPPAAIIRR AALLTTEERRNNAATTIIVVEESS
SEBP4152-48 SUPPLEMENTAL COOLANT ADDITIVES AA77
CCUUSSTTOOMMEERR BBEENNEEFFIITTSS::
Protects against cavitation, foam, erosion, corrosion, and scale buildup in cooling systems.
• Provides measured coolant conditioner.
DDEESSCCRRIIPPTTIIOONN::
Additives deplete from the coolant with normal operation. For this reason, Supplemental Coolant Additives (SCA) must
be added to all heavy duty coolants at regular intervals. In addition, when not using a fully formulated, pre-charged
antifreeze, like Cat DEAC, an initial charge of SCA must be added to the cooling system. The amount of SCA added to
the system is dependent on the capacity of the system.
The SCA for initial fill is provided as a liquid. SCA's for maintenance intervals are available in liquid form and as a spin-
on element. (No Spin-on available for 3600 Family of Engines)
NNOOTTEE::
The amount of SCA added at initial fill is not the same as the amount added at maintenance intervals.
The coolant additive elements can be used with any ethylene or propylene glycol type antifreeze which meets ASTM
D4985 or ASTM D5345 Specifications.
NNOOTTEE::
For use with standard heavy duty coolant only, not for use with Extended Life Coolant.
PPAARRTTSS NNEEEEDDEEDD::
CCoooolliinngg SSyysstteemm CCaappaacciittyy
LLiiqquuiidd SSCCAA aatt IInniittiiaall FFiillll LLiiqquuiidd SSCCAA aatt
MMaaiinntteennaannccee**
SSppiinn--oonn SSCCAA MMaaiinntteennaannccee
EElleemmeenntt**LLiitteerrss GGaalllloonnss
22-30 (6-8) 3P-2044 (1) 6V-3542 (1) 111-2370 (1)
30-38 (8-10) 3P-2044 (1)
6V-3542 (1) 111-2372 (1) 111-2369 (1)
38-49 (10-13) 3P-2044 (1)
8T-1589 (1) 111-2372 (1) 111-2369 (1)
49-64 (13-17) 3P-2044 (2) 8T-1589 (1) 9N-3368 (1)
64-83 (17-22) 3P-2044 (2)
8T-1589 (1)
111-2372 (1)
6V-3542 (1) 111-2371 (1)
83-114 (22-30) 3P-2044 (3)
8T-1589 (1) 3P-2044 (1) 9N-3718 (1)
114-163 (30-43) 3P-2044 (5) 3P-2044 (1)
6V-3542GRAPHIC #1 > g01158933
228822 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
274-1939 ELBOW GP-EXHAUST
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1061 i02319542
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 204-7003 1 HOSE
2 1 9M-2904 2 CLAMP-HOSE
3 1 274-1937 1 ELBOW AS-EXHAUST
4 1 274-1938 1 SHIELD AS-HEAT
5 1 7W-4566 1 GASKET
6 1 269-5151 6 BOLT (M8X1.25X40-MM)
7 1 101-3803 6 LOCKNUT (M8X1.25-THD)
8 1 195-4618 1 ELBOW
GRAPHIC #1 > g01160615
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 228833
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
299-5536 ELBOW GP-EXHAUST
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1061 i02638550
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-5537 1 ELBOW AS-EXHAUST
2 1 9M-2904 1 CLAMP-HOSE
3 1 195-4618 1 ELBOW
4 1 195-4628 1 HOSE
5 1 7W-4566 1 GASKET
6 1 269-5151 6 BOLT (M8X1.25X40-MM)
7 1 101-3803 6 LOCKNUT (M8X1.25-THD)
8 1 274-1938 1 SHIELD AS-HEAT
GRAPHIC #1 > g01326379
228844 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
300-5252 ELBOW GP-EXHAUST
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1061 i02638171
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-5537 1 ELBOW AS-EXHAUST
2 1 300-5253 1 ELBOW-EXHAUST
3 1 8T-4986 4 CLAMP-HOSE
4 1 9M-2904 1 CLAMP-HOSE
5 1 300-5254 1 HOSE
6 1 195-4627 1 HOSE
7 1 195-4618 1 ELBOW
8 1 7W-4566 1 GASKET
9 1 269-5151 6 BOLT (M8X1.25X40-MM)
10 1 101-3803 6 LOCKNUT (M8X1.25-THD)
11 1 274-1938 1 SHIELD AS-HEAT
GRAPHIC #1 > g01382545
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 228855
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
301-6932 ELBOW GP-EXHAUST
S/N: D1K1-UP; S1M1-UP
FOR USE WITH MCS ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1061 i02638753
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 301-6933 1 ELBOW AS-EXHAUST
2 1 301-6934 1 ELBOW-EXHAUST
3 1 144-0367 4 CLAMP-HOSE
4 1 9M-2904 2 CLAMP-HOSE
5 1 301-6935 1 HOSE
6 1 301-6936 1 HOSE
7 1 110-8760 2 STRAP
8 1 195-4715 1 GASKET-EXHAUST
9 1 269-5151 4 BOLT (M8X1.25X40-MM)
10 1 101-3803 4 LOCKNUT (M8X1.25-THD)
M 11 1 6I-0217 2 BOLT (M8X1.25X20-MM)
12 1 301-6937 1 BRACKET
13 1 301-6938 1 BLANKET-EXHAUST
M - METRIC PART
GRAPHIC #1 > g01326396
228866 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
301-6939 ELBOW GP-EXHAUST
S/N: D1K1-UP; S1M1-UP
FOR USE WITH MCS ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1061 i02638749
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 301-6933 1 ELBOW AS-EXHAUST
2 1 301-6934 1 ELBOW-EXHAUST
3 1 144-0367 4 CLAMP-HOSE
4 1 9M-2904 1 CLAMP-HOSE
5 1 301-6940 1 HOSE
6 1 301-6941 1 HOSE
7 1 110-8760 2 STRAP
8 1 195-4715 1 GASKET-EXHAUST
9 1 269-5151 4 BOLT (M8X1.25X40-MM)
10 1 101-3803 4 LOCKNUT (M8X1.25-THD)
M 11 1 6I-0217 2 BOLT (M8X1.25X20-MM)
12 1 301-6937 1 BRACKET
13 1 301-6938 1 BLANKET-EXHAUST
M - METRIC PART
GRAPHIC #1 > g01326414
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 228877
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4590 ELBOW GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1061 i05153555
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-4012 4 STUD
2 1 263-5802 1 GASKET
3 1 359-4112 1 ELBOW
4 1 6I-0563 4 NUT (M10X1.5-THD)
5 1 195-4639 1 PLUG
6 1 195-4640 1 PLUG
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
GRAPHIC #1 > g03334848
228888 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4906 ELBOW GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1061 i05165138
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 359-4117 1 ELBOW-EXHAUST
2 1 195-4639 1 PLUG
3 1 195-4640 1 PLUG
GRAPHIC #1 > g03355959
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 228899
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
374-7383 ELBOW GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1061 i05155198
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4628 1 HOSE
2 1 9M-2904 2 CLAMP-HOSE
3 1 374-7381 1 ELBOW AS-EXHAUST
4 1 272-6532 1 SHIELD AS-HEAT
5 1 195-4715 1 GASKET-EXHAUST
6 1 269-5151 4 BOLT (M8X1.25X40-MM)
7 1 101-3803 4 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g03354983
229900 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
374-7384 ELBOW GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1061 i05155270
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4628 1 HOSE
2 1 9M-2904 2 CLAMP-HOSE
3 1 374-7382 1 ELBOW AS-EXHAUST
4 1 272-6992 1 SHIELD-EXHAUST
5 1 195-4715 1 GASKET-EXHAUST
6 1 269-5151 4 BOLT (M8X1.25X40-MM)
7 1 101-3803 4 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g03355832
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 229911
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
271-9964 EXHAUST GP-FLEXIBLE
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY
AN ATTACHMENT
SMCS-1061 i02306049
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4654 1 BELLOWS AS-EXHAUST
2 1 101-3803 6 LOCKNUT (M8X1.25-THD)
3 1 195-4667 6 BOLT (M8X35-MM)
4 1 271-9963 1 SHIELD AS-HEAT
5 1 7W-4566 1 GASKET
6 1 195-4639 1 PLUG
GRAPHIC #1 > g01155748
229922 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
273-0702 EXHAUST GP-FLEXIBLE
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1061 i02319555
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4716 1 BELLOWS-EXHAUST
2 1 101-3803 4 LOCKNUT (M8X1.25-THD)
3 1 195-4667 4 BOLT (M8X35-MM)
4 1 273-0705 1 SHIELD AS-HEAT
5 1 195-4715 1 GASKET-EXHAUST
GRAPHIC #1 > g01160635
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 229933
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
298-5285 EXTENSION GP-EXHAUST
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1061 i02637608
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-5151 4 BOLT (M8X1.25X40-MM)
2 1 101-3803 4 LOCKNUT (M8X1.25-THD)
3 1 195-4715 1 GASKET-EXHAUST
4 1 298-5286 1 TUBE AS-EXHAUST
5 1 298-5287 1 SHIELD AS-HEAT
GRAPHIC #1 > g01420752
229944 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
355-8709 FASTENER GP-FILTER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7553 i05072838
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 100-4830 2 BOLT (M10X1.5X20-MM)
M 2 1 6I-0594 2 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g03357122
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM229955
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
217-8261 FLANGE GP-EXHAUST
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1061 i02312953
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4718 1 FLANGE-EXHAUST
2 1 195-4715 1 GASKET-EXHAUST
3 1 195-4667 4 BOLT (M8X35-MM)
4 1 101-3803 4 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g00862001
229966 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
273-1696 FLANGE GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1061 i02319554
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 195-4718 1 FLANGE-EXHAUST
2 1 195-4715 1 GASKET-EXHAUST
3 1 269-5151 4 BOLT (M8X1.25X40-MM)
4 1 101-3803 4 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g00862001
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 229977
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
263-4793 MANIFOLD GP-EXHAUST
CANNOT BE USED WITH TURBOCHARGED AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1059 i02286899
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-4797 1 MANIFOLD (EXHAUST)
2 1 263-4794 1 GASKET
3 1 103-0050 4 BOLT (M10X1.5X100-MM)
4 1 6I-4045 4 BOLT (M10X1.5X75-MM)
5 1 263-4798 1 ADAPTER
6 1 035-8063 1 PLUG
GRAPHIC #1 > g01148779
229988 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
268-4268 MANIFOLD GP-EXHAUST
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1059 i02288983
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 268-4269 1 MANIFOLD (EXHAUST)
2 1 263-4794 1 GASKET
3 1 100-4715 8 BOLT
4 1 035-8063 2 PLUG
5 1 263-4798 1 ADAPTER
6 1 268-4271 1 TUBE
GRAPHIC #1 > g01146975
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 229999
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
291-4625 MANIFOLD GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
FOR USE WITH RADIATOR COOLED MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1059 i02540697
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 291-4626 1 MANIFOLD-EXHAUST
2 1 263-4794 1 GASKET
3 1 103-0050 4 BOLT (M10X1.5X100-MM)
4 1 6I-4045 4 BOLT (M10X1.5X75-MM)
5 1 035-8063 1 PLUG
6 1 263-4798 1 ADAPTER
7 1 263-5647 1 PLUG
GRAPHIC #1 > g01277648
330000 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
268-7665 MOUNTING GP-AIR CLEANER
S/N: S1M1-UP; J1Z1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES
AN ATTACHMENT
SMCS-1051 i02288990
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 268-7663 1 BRACKET
M 2 1 6I-0645 2 BOLT (M8X1.25X25-MM)
M - METRIC PART
GRAPHIC #1 > g01148910
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 330011
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
272-2240 MOUNTING GP-EXHAUST
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1061 i02308833
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 7W-4566 1 GASKET
2 1 269-5151 6 BOLT (M8X1.25X40-MM)
3 1 101-3803 6 LOCKNUT (M8X1.25-THD)
GRAPHIC #1 > g01159377
330022 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
269-3749 SHIELD GP-EXHAUST
S/N: D1K1-UP; L1K1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES ONLY
AN ATTACHMENT
SMCS-1067 i02306183
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-9714 1 JACKET AS
GRAPHIC #1 > g01155753
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 330033
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
270-0340 SHIELD GP-EXHAUST
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY
AN ATTACHMENT
SMCS-1067 i02308838
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 270-0341 1 SHIELD AS
GRAPHIC #1 > g01158934
330044 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
273-3613 SHIELD GP-EXHAUST
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES, TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1067 i02311907
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-3614 1 SHIELD AS-EXHAUST
GRAPHIC #1 > g01159431
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 330055
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
367-0549 SHIELD GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1067 i05165146
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 359-4113 1 SHIELD-HEAT
GRAPHIC #1 > g03340642
330066 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
367-0550 SHIELD GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1067 i05165155
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 359-4115 1 SHIELD-HEAT
GRAPHIC #1 > g03356554
SEBP4152-48 1 of 1 AIR INLET AND EXHAUST SYSTEM 330077
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
367-0551 SHIELD GP-EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1067 i05155193
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 359-4118 1 SHIELD-HEAT
GRAPHIC #1 > g03359253
330088 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
266-7090 TURBOCHARGER GP
S/N: S1M1-UP; J1Z1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES, TURBOCHARGED AND AFTERCOOLED
ENGINES
AN ATTACHMENT
SMCS-1052, 1053 i05218299
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 234-2988 1 TURBOCHARGER GP
2 1 263-5802 1 GASKET
3 1 149-4236 4 STUD (M10X1.5X37-MM)
4 1 6I-0563 10 NUT (M10X1.5-THD)
5 1 367-5799 1 TUBE
6 1 266-7092 2 CLAMP-HOSE
7 1 234-3029 1 HOSE
M 8 1 6I-0572 4 BOLT (M8X1.25X20-MM)
9 1 234-3030 1 GASKET-INLET
10 1 285-3030 1 TUBE AS
11 1 353-3477 1 GASKET-TURBOCHARGER (TURBOCHARGER)
12 1 353-3478 1 GASKET-TURBOCHARGER
M 13 1 106-8916 2 BOLT (M6X16-MM)
M 14 1 6I-0217 2 BOLT (M8X1.25X20-MM)
15 1 285-3031 1 TUBE AS
16 1 225-8524 2 BOLT-SPECIAL (BANJO)
17 1 225-8526 4 WASHER (10.4X13.75X1.37-MM THK)
18 1 227-4562 1 ELBOW-EXHAUST
19 1 307-2805 1 BRACKET
20 1 302-0581 1 ADAPTER-EXHAUST
M 21 1 6I-0654 3 BOLT (M10X1.5X25-MM)
M 22 1 6I-0593 2 BOLT (M10X1.5X30-MM)
23 1 147-5553 3 STUD
24 1 6I-4012 3 STUD
25 1 6I-4039 1 GASKET
26 1 195-4639 1 PLUG
27 1 270-4163 1 ADAPTER-EXHAUST
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 330099
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
266-7090 TURBOCHARGER GP (ccoonnttdd..) i05218299
GRAPHIC #1 > g01147013
331100 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
268-5362 TURBOCHARGER GP
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1052, 1053 i05166110
NNOOTTEE
RREEFFNNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 268-5357 1 TUBE AS
2 1 225-8524 2 BOLT-SPECIAL (BANJO)
3 1 225-8526 4 WASHER (10.4X13.75X1.37-MM THK)
M 4 1 6I-4200 2 BOLT (M10X1.5X16-MM)
5 1 266-7092 2 CLAMP-HOSE
6 1 268-5358 1 HOSE
7 1 263-5802 1 GASKET
8 1 268-5359 1 TURBOCHARGER
9 1 6I-4012 7 STUD
M 10 1 6I-0594 4 NUT (M10X1.5-THD)
11 1 353-3477 1 GASKET-TURBOCHARGER
12 1 268-5360 2 STUD (M6X1X24-MM)
13 1 6I-0918 2 NUT
14 1 353-3478 1 GASKET-TURBOCHARGER
M 15 1 6I-0840 2 STUD (M8X20-MM)
M 16 1 6I-0291 2 NUT (M8X1.25-THD)
17 1 268-5361 1 HOSE AS
18 1 6I-0563 3 NUT (M10X1.5-THD)
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 331111
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
268-5362 TURBOCHARGER GP (ccoonnttdd..) i05166110
GRAPHIC #1 > g01149091
331122 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
291-9846 TURBOCHARGER GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1052, 1053 i05166038
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 236-8746 1 TURBOCHARGER GP
2 1 263-5802 1 GASKET
3 1 149-4236 4 STUD (M10X1.5X37-MM)
4 1 6I-0563 10 NUT (M10X1.5-THD)
5 1 285-3030 1 TUBE AS
6 1 353-3477 1 GASKET-TURBOCHARGER
7 1 353-3478 1 GASKET-TURBOCHARGER
M 8 1 106-8916 2 BOLT (M6X16-MM)
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
10 1 285-3031 1 TUBE AS
11 1 225-8524 2 BOLT-SPECIAL (BANJO) (BANJO)
12 1 225-8526 4 WASHER (10.4X13.75X1.37-MM THK)
13 1 227-4562 1 ELBOW-EXHAUST
14 1 307-2805 1 BRACKET
15 1 302-0581 1 ADAPTER-EXHAUST
M 16 1 6I-0654 3 BOLT (M10X1.5X25-MM)
M 17 1 6I-0593 2 BOLT (M10X1.5X30-MM)
18 1 147-5553 3 STUD
19 1 291-9847 1 ADAPTER-EXHAUST
20 1 6I-4039 1 GASKET (EXHAUST)
21 1 6I-4012 3 STUD
22 1 195-4639 1 PLUG
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 331133
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
291-9846 TURBOCHARGER GP (ccoonnttdd..) i05166038
GRAPHIC #1 > g01277638
331144 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4895 TURBOCHARGER GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1052, 1053 i05146833
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 234-2988 1 TURBOCHARGER GP
2 1 263-5802 1 GASKET
3 1 6I-0563 10 NUT (M10X1.5-THD)
4 1 367-5799 1 TUBE
5 1 266-7092 2 CLAMP-HOSE
6 1 234-3029 1 HOSE
M 7 1 6I-0572 4 BOLT (M8X1.25X20-MM)
8 1 234-3030 1 GASKET-INLET
9 1 285-3030 1 TUBE AS
10 1 225-8533 1 GASKET
11 1 225-8534 1 GASKET
M 12 1 106-8916 2 BOLT (M6X16-MM)
M 13 1 6I-0217 2 BOLT (M8X1.25X20-MM)
14 1 285-3031 1 TUBE AS
15 1 225-8524 2 BOLT-SPECIAL (BANJO)
16 1 225-8526 4 WASHER (10.4X13.75X1.37-MM THK)
17 1 227-4562 1 ELBOW-EXHAUST
18 1 307-2805 1 BRACKET
19 1 302-0581 1 ADAPTER-EXHAUST
M 20 1 6I-0654 3 BOLT (M10X1.5X25-MM)
M 21 1 6I-0593 2 BOLT (M10X1.5X30-MM)
22 1 195-4639 1 PLUG
23 1 147-5553 7 STUD
24 1 359-4114 1 ADAPTER-EXHAUST
25 1 6I-4039 1 GASKET
26 1 6I-4012 3 STUD
27 1 195-4640 1 PLUG
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 331155
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4895 TURBOCHARGER GP (ccoonnttdd..) i05146833
GRAPHIC #1 > g03358886
331166 AIR INLET AND EXHAUST SYSTEM 1 of 2 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4902 TURBOCHARGER GP
S/N: L1K1-UP; S1M1-UP
FOR USE WITH RADIATOR COOLED C4.4 MARINE GENSET
AN ATTACHMENT
SMCS-1052, 1053 i05146850
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 236-8746 1 TURBOCHARGER GP
2 1 263-5802 1 GASKET
3 1 147-5553 7 STUD
4 1 6I-0563 10 NUT (M10X1.5-THD)
5 1 285-3030 1 TUBE AS
6 1 225-8533 1 GASKET
7 1 225-8534 1 GASKET
M 8 1 106-8916 2 BOLT (M6X16-MM)
M 9 1 6I-0217 2 BOLT (M8X1.25X20-MM)
10 1 285-3031 1 TUBE AS
11 1 225-8524 2 BOLT-SPECIAL (BANJO)
12 1 225-8526 4 WASHER (10.4X13.75X1.37-MM THK)
13 1 227-4562 1 ELBOW-EXHAUST
14 1 307-2805 1 BRACKET
15 1 302-0581 1 ADAPTER-EXHAUST
M 16 1 6I-0654 3 BOLT (M10X1.5X25-MM)
M 17 1 6I-0593 2 BOLT (M10X1.5X30-MM)
18 1 359-4116 1 ADAPTER-EXHAUST
19 1 6I-4039 1 GASKET
20 1 6I-4012 3 STUD
21 1 195-4639 1 PLUG
22 1 195-4640 1 PLUG
M - METRIC PART
SEBP4152-48 2 of 2 AIR INLET AND EXHAUST SYSTEM 331177
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
362-4902 TURBOCHARGER GP (ccoonnttdd..) i05146850
GRAPHIC #1 > g03355107
331188 AIR INLET AND EXHAUST SYSTEM 1 of 1 SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
367-2800 VALVE GP-DRAIN
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1094, 1372 i05165168
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 367-2797 1 ADAPTER
2 1 367-2796 1 VALVE
3 1 195-4640 1 PLUG
GRAPHIC #1 > g03356363
SEBP4152-48 1 of 1 FUEL SYSTEM 331199
FFUUEELL SSYYSSTTEEMM
375-3200 BRACKET GP-MOUNTING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1702 i05155291
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4583 1 BRACKET
2 1 288-4585 1 TRAY-DRIP
M 3 1 100-4830 4 BOLT (M10X1.5X20-MM)
M 4 1 245-6541 5 BOLT (M5X0.8X12-MM)
5 1 288-4588 1 PLUG-DRAIN
M 6 1 6I-0594 4 NUT (M10X1.5-THD)
7 1 100-4838 2 BOLT (M6X1X20-MM)
M - METRIC PART
GRAPHIC #1 > g03355897
332200 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
265-3858 FILTER & LINES GP-FUEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1261, 1274 i04222937
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 367-1814 1 FILTER AS-FUEL (PRIMARY)
2 1 265-5541 1 HOSE AS
3 1 265-5542 1 HOSE AS
4 1 033-7849 1 PLUG
5 1 032-8100 1 WASHER (0.531X0.718X0.064-IN THK)
6 1 265-5543 1 HOSE AS
7 1 265-5545 1 ADAPTER
8 1 265-5546 2 WASHER (5.1X8X1-MM THK)
9 1 265-5547 1 VALVE
10 1 265-5548 1 CONNECTION
11 1 263-8001 1 CLIP
12 1 263-7999 1 CLIP
13 1 232-3126 1 CLIP
14 1 067-6269 3 FERRULE
15 1 067-6268 3 NUT-FUEL LINE (1/2-IN)
M 16 1 6I-0593 2 BOLT (M10X1.5X30-MM)
E 17 1 276-9384 HOSE (8-CM)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g02401280
SEBP4152-48 1 of 2 FUEL SYSTEM 332211
FFUUEELL SSYYSSTTEEMM
265-5562 FILTER & LINES GP-FUEL
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH TURBOCHARGED AND ASPIIRATED ENGINES
AN ATTACHMENT
SMCS-1261, 1274 i05125816
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 367-1814 1 FILTER AS-FUEL (PRIMARY)
1A 1 205-3041 1 PLUG-DRAIN (FUEL FILTER)
1B 1 250-6527 1 FILTER ELEMENT-FUEL
2 1 265-5541 1 HOSE AS
3 1 277-5674 1 HOSE AS
4 1 033-7849 1 PLUG
5 1 032-8100 1 WASHER (0.531X0.718X0.064-IN THK)
6 1 265-5543 1 HOSE AS
7 1 265-5545 1 ADAPTER
8 1 265-5546 2 WASHER (5.1X8X1-MM THK)
9 1 265-5547 1 VALVE
10 1 265-5548 1 CONNECTION
11 1 263-8001 1 CLIP
12 1 263-7999 1 CLIP
13 1 232-3126 1 CLIP
14 1 067-6269 4 FERRULE
15 1 067-6268 4 NUT-FUEL LINE (1/2-IN)
16 1 265-5555 1 BRACKET
M 17 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 18 1 6I-0593 2 BOLT (M10X1.5X30-MM)
19 1 6I-0846 1 BOLT (M6X1X14-MM)
M 20 1 6I-0594 2 NUT (M10X1.5-THD)
21 1 276-9384 HOSE (8-CM)
M - METRIC PART
332222 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
265-5562 FILTER & LINES GP-FUEL (ccoonnttdd..) i05125816
GRAPHIC #1 > g01190286
SEBP4152-48 1 of 2 FUEL SYSTEM 332233
FFUUEELL SSYYSSTTEEMM
288-4593 FILTER & LINES GP-FUEL
S/N: L1K1-UP; J1Z1-824
AN ATTACHMENT
SMCS-1261, 1274 i03635842
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTTNNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4572 1 FILTER GP-FUEL
1A 1 287-6052 2 FILTER-FUEL
2 1 6I-4045 2 BOLT (M10X1.5X75-MM)
3 1 288-4574 1 HOSE AS
4 1 288-4575 1 HOSE AS
5 1 288-4576 3 CLIP
6 1 263-8001 6 CLIP
7 1 304-8797 2 SEAL-BONDED
8 1 288-4579 2 ADAPTER
9 1 288-4580 2 ADAPTER-TEE
10 1 288-4581 3 ADAPTER
11 1 231-0324 1 ADAPTER
M 12 1 6I-0594 6 NUT (M10X1.5-THD)
13 1 067-6269 1 FERRULE
14 1 067-6268 1 NUT-FUEL LINE (1/2-IN)
15 1 288-4582 1 BRACKET
16 1 263-7999 3 CLIP
17 1 288-4583 1 BRACKET
18 1 288-4585 1 TRAY-DRIP
M 19 1 100-4830 4 BOLT (M10X1.5X20-MM)
M 20 1 245-6541 5 BOLT (M5X0.8X12-MM)
21 1 288-4588 1 PLUG-DRAIN (SPILL PROTECTION)
22 1 288-4589 1 TUBE
23 1 288-4591 1 TUBE
24 1 288-4590 1 TUBE
M - METRIC PART
332244 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
288-4593 FILTER & LINES GP-FUEL (ccoonnttdd..) i03635842
GRAPHIC #1 > g01271193
SEBP4152-48 1 of 2 FUEL SYSTEM 332255
FFUUEELL SSYYSSTTEEMM
288-4593 FILTER & LINES GP-FUEL
S/N: D1K1-UP; S1M825-UP
AN ATTACHMENT
SMCS-1261, 1274 i03635841
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4572 1 FILTER GP-FUEL
1A 1 287-6052 2 FILTER-FUEL
2 1 6I-4045 2 BOLT (M10X1.5X75-MM)
3 1 288-4574 1 HOSE AS
4 1 288-4575 1 HOSE AS
5 1 288-4576 3 CLIP
C 6 1 263-8001 7 CLIP
7 1 304-8797 2 SEAL-BONDED
8 1 288-4579 2 ADAPTER
9 1 288-4580 2 ADAPTER-TEE
C 10 1 288-4581 1 ADAPTER
11 1 231-0324 1 ADAPTER
M 12 1 6I-0594 6 NUT (M10X1.5-THD)
13 1 067-6269 1 FERRULE
14 1 067-6268 1 NUT-FUEL LINE (1/2-IN)
15 1 288-4582 1 BRACKET
C 16 1 263-7999 4 CLIP
17 1 288-4583 1 BRACKET
18 1 288-4585 1 TRAY-DRIP
M 19 1 100-4830 4 BOLT (M10X1.5X20-MM)
M 20 1 245-6541 5 BOLT (M5X0.8X12-MM)
21 1 288-4588 1 PLUG-DRAIN (SPILL PROTECTION)
C 22 1 316-4719 2 HOSE
C 23 1 213-7483 2 ADAPTER
24 1 288-4590 1 TUBE
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
332266 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
288-4593 FILTER & LINES GP-FUEL (ccoonnttdd..) i03635841
GRAPHIC #1 > g01409697
SEBP4152-48 1 of 2 FUEL SYSTEM 332277
FFUUEELL SSYYSSTTEEMM
305-0550 FILTER GP-FUEL
S/N: L1K1-UP; S1M1-824
AN ATTACHMENT
SMCS-1261 i02655804
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4572 1 FILTER GP-FUEL
1 287-6052 2 FILTER-FUEL
2 1 6I-4045 2 BOLT (M10X1.5X75-MM)
3 1 288-4574 1 HOSE AS
4 1 288-4575 1 HOSE AS
5 1 288-4576 3 CLIP
6 1 263-8001 6 CLIP
7 1 304-8797 2 SEAL-BONDED
8 1 288-4579 2 ADAPTER
9 1 288-4580 2 ADAPTER-TEE
10 1 288-4581 3 ADAPTER
11 1 231-0324 1 ADAPTER
M 12 1 6I-0594 2 NUT (M10X1.5-THD)
13 1 067-6269 1 FERRULE
14 1 067-6268 1 NUT-FUEL LINE (1/2-IN)
15 1 288-4582 1 BRACKET
16 1 263-7999 3 CLIP
17 1 288-4583 1 BRACKET
M 18 1 100-4830 4 BOLT (M10X1.5X20-MM)
19 1 288-4589 1 TUBE
20 1 288-4591 1 TUBE
21 1 288-4590 1 TUBE
M - METRIC PART
332288 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
305-0550 FILTER GP-FUEL (ccoonnttdd..) i02655804
GRAPHIC #1 > g01478592
SEBP4152-48 1 of 2 FUEL SYSTEM 332299
FFUUEELL SSYYSSTTEEMM
305-0550 FILTER GP-FUEL
S/N: L1K1-UP; S1M825-UP
AN ATTACHMENT
SMCS-1261 i02843922
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4572 1 FILTER GP-FUEL
1 287-6052 2 FILTER-FUEL
2 1 6I-4045 2 BOLT (M10X1.5X75-MM)
3 1 288-4574 1 HOSE AS
4 1 288-4575 1 HOSE AS
5 1 288-4576 3 CLIP
C 6 1 263-8001 7 CLIP
7 1 304-8797 2 SEAL-BONDED
8 1 288-4579 2 ADAPTER
9 1 288-4580 2 ADAPTER-TEE
C 10 1 288-4581 1 ADAPTER
11 1 231-0324 1 ADAPTER
M 12 1 6I-0594 2 NUT (M10X1.5-THD)
13 1 067-6269 1 FERRULE
14 1 067-6268 1 NUT-FUEL LINE (1/2-IN)
15 1 288-4582 1 BRACKET
C 16 1 263-7999 4 CLIP
17 1 288-4583 1 BRACKET
M 18 1 100-4830 4 BOLT (M10X1.5X20-MM)
C 20 1 316-4719 2 HOSE
21 1 288-4590 1 TUBE
C 22 1 213-7483 2 ADAPTER
C - CHANGE FROM PREVIOUS TYPE
M - METRIC PART
333300 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
305-0550 FILTER GP-FUEL (ccoonnttdd..) i02843922
GRAPHIC #1 > g01896653
SEBP4152-48 1 of 2 FUEL SYSTEM 333311
FFUUEELL SSYYSSTTEEMM
355-8700 FILTER GP-FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1261 i05145610
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4572 1 FILTER GP-FUEL
1A 1 287-6052 2 FILTER-FUEL
2 1 355-7281 1 CLIP
3 1 6I-4045 2 BOLT (M10X1.5X75-MM)
M 4 1 6I-0594 2 NUT (M10X1.5-THD)
5 1 304-8797 2 SEAL-BONDED
6 1 288-4579 2 ADAPTER
7 1 288-4580 2 ADAPTER-TEE
8 1 355-7278 1 PIPE
9 1 331-4368 1 COUPLING
10 1 355-7279 1 HOSE
11 1 149-6116 2 CLIP
M 12 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M 13 1 6I-0291 2 NUT (M8X1.25-THD)
14 1 067-6268 1 NUT-FUEL LINE (1/2-IN)
15 1 067-6269 1 FERRULE
16 1 355-7280 1 HOSE
17 1 288-4581 1 ADAPTER
18 1 231-0324 1 ADAPTER
19 1 263-7999 1 CLIP
M - METRIC PART
333322 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
355-8700 FILTER GP-FUEL (ccoonnttdd..) i05145610
GRAPHIC #1 > g03343575
SEBP4152-48 1 of 2 FUEL SYSTEM 333333
FFUUEELL SSYYSSTTEEMM
263-8003 LINES GP-FLEXIBLE FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1274 i02288470
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-7995 1 HOSE AS
2 1 263-7997 1 HOSE AS
3 1 263-7999 1 CLIP
4 1 263-8001 1 CLIP
5 1 205-8712 1 CLIP
6 1 193-5183 1 CLIP
M 7 1 100-4830 1 BOLT (M10X1.5X20-MM)
M - METRIC PART
333344 FUEL SYSTEM 2 of 2 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
263-8003 LINES GP-FLEXIBLE FUEL (ccoonnttdd..) i02288470
GRAPHIC #1 > g01147967
SEBP4152-48 1 of 1 FUEL SYSTEM 333355
FFUUEELL SSYYSSTTEEMM
263-8674 LINES GP-FLEXIBLE FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1274 i02288610
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-8669 1 HOSE AS
2 1 263-8670 1 HOSE AS
3 1 263-7999 1 CLIP
4 1 263-8001 1 CLIP
5 1 205-8712 1 CLIP
6 1 193-5183 1 CLIP
M 7 1 100-4830 1 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01147830
333366 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
263-8111 LINES GP-FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1274 i02288477
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-8093 1 LINE AS-FUEL (CYLINDER ONE)
2 1 263-8094 1 LINE AS-FUEL (CYLINDER TWO)
3 1 263-8095 1 LINE AS-FUEL (CYLINDER THREE)
4 1 263-8096 1 LINE AS-FUEL (CYLINDER FOUR)
M 5 1 8T-2224 2 BOLT-SOCKET HEAD (M8X1.25X85-MM)
6 1 8T-4224 5 WASHER-HARD (8.8X16X2-MM THK)
7 1 234-3106 3 WASHER
8 1 196-7699 2 NUT (M8X1.25-THD)
9 1 234-3108 3 SEAL-O-RING
10 1 234-3350 1 PLUG
11 1 234-3068 1 FITTING AS
12 1 263-8098 1 BRACKET
13 1 234-3353 1 TUBE
14 1 234-3107 1 COUPLING
15 1 169-0122 1 TANK AS-FUEL (ALARM)
16 1 205-7289 1 FASTENER GP-FUEL TANK
17 1 196-0340 1 SETSCREW (M8X1.25X25-MM)
M - METRIC PART
GRAPHIC #1 > g01147798
SEBP4152-48 1 of 1 FUEL SYSTEM 333377
FFUUEELL SSYYSSTTEEMM
287-5627 LINES GP-FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1274 i02516103
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 287-5624 1 TUBE
2 1 287-5625 1 ADAPTER (BRASS)
3 1 287-5626 1 ADAPTER (PLATED STEEL)
4 1 265-5546 2 WASHER (5.1X8X1-MM THK)
5 1 265-5547 1 VALVE
6 1 265-5545 1 ADAPTER (NICKLE PLATED BRASS)
E 7 1 276-9384 HOSE (8-CM)
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01260137
333388 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
289-9772 LINES GP-FUEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1274 i02540156
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-8791 2 HOSE AS
2 1 231-0324 2 ADAPTER
GRAPHIC #1 > g01273810
SEBP4152-48 1 of 1 FUEL SYSTEM 333399
FFUUEELL SSYYSSTTEEMM
247-4885 LINES GP-FUEL FILTER
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1261, 1274 i02317987
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 247-4884 1 TUBE AS
2 1 232-3126 1 CLIP
GRAPHIC #1 > g01123693
334400 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2290 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
PART OF 272-2291 PUMP GP-FUEL INJECTION
AN ATTACHMENT
SMCS-1251, 1290 i02623654
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 111-3422 1 NUT (M14X1.5-THD)
2 1 111-3423 1 WASHER
3 1 152-3968 1 SEAL-O-RING
4 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT) (FUEL SHUTOFF)
M - METRIC PART
GRAPHIC #1 > g01160107
SEBP4152-48 1 of 3 FUEL SYSTEM 334411
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1251, 1290 i02585845
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
4 2 7M-7410 1 PLUG-PIPE
5 2 9F-2247 1 PLUG-PIPE
7 1 110-8760 1 STRAP
M 8 1 124-3815 1 BOLT (M8X16X1.25-MM)
9 1 140-8714 1 CLIP
10 2 203-6797 1 SENSOR-SPEED (ENGINE)
11 2 203-6798 1 ADAPTER
12 1 230-8989 1 GEAR-FUEL PUMP
13 1 230-8995 1 TUBE AS (CYL NO.1)
14 1 230-8996 1 TUBE AS (CYL NO.2)
15 1 230-8997 1 TUBE AS (CYL NO.3)
16 1 230-8998 1 TUBE AS (CYL NO.4)
17 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
17A 1 140-8718 1 WASHER
18 1 230-9527 1 BRACKET
19 2 232-1323 1 PLUG-CUP
20 1 232-1328 1 CAP
21 1 232-1794 3 HOSE
22 1 232-2725 2 CLIP
23 1 232-2726 1 CLIP
24 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
26 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
27 1 238-8671 4 CLAMP-INJECTOR
28 1 272-2223 1 ACTUATOR GP-GOVERNOR
28A 1 241-4288 4 SEAL-O-RING
28B 1 241-4291 1 SCREW
Y 29 1 272-2290 1 PUMP GP-FUEL INJECTION 340
M - METRIC PART
Y - SEPARATE ILLUSTRATION
334422 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02585845
GRAPHIC #1 g01300569
SEBP4152-48 3 of 3 FUEL SYSTEM 334433
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02585845
GRAPHIC #2 > g01160857
334444 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1251, 1290 i05195476
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
4 2 7M-7410 1 PLUG-PIPE
5 2 9F-2247 1 PLUG-PIPE
7 1 110-8760 1 STRAP
M 8 1 124-3815 1 BOLT (M8X1.25X16-MM)
9 1 140-8714 1 CLIP
10 2 203-6797 1 SENSOR-SPEED (ENGINE)
11 2 203-6798 1 ADAPTER
12 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
13 1 230-8995 1 TUBE AS (CYL NO. 1)
14 1 230-8996 1 TUBE AS (CYL NO. 2)
15 1 230-8997 1 TUBE AS (CYL NO. 3)
16 1 230-8998 1 TUBE AS (CYL NO. 4)
17 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
1 232-2724 1 NOZZLE
1 275-1038 1 SEAL-O-RING
17A 1 140-8718 1 WASHER
18 1 240-5571 1 BRACKET
20 1 232-1328 1 CAP
21 1 232-1794 3 HOSE
22 1 232-2725 2 CLIP
23 1 232-2726 1 CLIP
24 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
26 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
27 1 238-8671 4 CLAMP-INJECTOR
28 1 272-2223 1 ACTUATOR GP-GOVERNOR
28A 1 241-4288 4 SEAL-O-RING
28B 1 241-4291 1 SCREW
Y 29 1 272-2290 1 PUMP GP-FUEL INJECTION 340
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 3 FUEL SYSTEM 334455
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05195476
GRAPHIC #1 g01300567
334466 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2291 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05195476
GRAPHIC #2 > g03028156
SEBP4152-48 1 of 1 FUEL SYSTEM 334477
FFUUEELL SSYYSSTTEEMM
272-2797 PUMP GP-FUEL INJECTION*R
S/N: J1Z1-UP
PART OF 272-2799 PUMP GP-FUEL INJECTION
AN ATTACHMENT
SMCS-1251, 1290 i02623738
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 111-3422 1 NUT (M14X1.5-THD)
2 1 111-3423 1 WASHER
3 1 152-3968 1 SEAL-O-RING
4 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT) (FUEL SHUTOFF)
M - METRIC PART
GRAPHIC #1 > g01160107
334488 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1251, 1290 i02585843
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
4 2 7M-7410 1 PLUG-PIPE
5 2 9F-2247 1 PLUG-PIPE
7 1 110-8760 1 STRAP
M 8 1 124-3815 1 BOLT (M8X16X1.25-MM)
9 1 140-8714 1 CLIP
10 2 203-6797 1 SENSOR-SPEED (ENGINE)
11 2 203-6798 1 ADAPTER
12 1 230-8989 1 GEAR-FUEL PUMP
13 1 230-8995 1 TUBE AS (CYL NO.1)
14 1 230-8996 1 TUBE AS (CYL NO.2)
15 1 230-8997 1 TUBE AS (CYL NO.3)
16 1 230-8998 1 TUBE AS (CYL NO.4)
17 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
17A 1 140-8718 1 WASHER
17B 1 232-2724 1 NOZZLE
17C 1 275-1038 1 SEAL-O-RING
18 1 230-9527 1 BRACKET
19 1 232-1115 1 CLIP-PIPE
20 2 232-1323 1 PLUG-CUP
21 1 232-1328 1 CAP
22 1 232-1794 3 HOSE
23 1 232-2725 2 CLIP
24 1 232-2726 1 CLIP
25 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
27 1 232-3274 1 BOLT (M8X1.25X48.1-MM)
28 1 238-8671 4 CLAMP-INJECTOR
29 1 272-2223 1 ACTUATOR GP-GOVERNOR
29A 1 241-4288 1 SEAL-O-RING
29B 1 241-4291 4 SCREW
Y 30 1 272-2797 1 PUMP GP-FUEL INJECTION 347
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 3 FUEL SYSTEM 334499
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02585843
GRAPHIC #1 g01295166
335500 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02585843
GRAPHIC #2 > g01158460
SEBP4152-48 1 of 3 FUEL SYSTEM 335511
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1251, 1290 i05195475
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
4 2 7M-7410 1 PLUG-PIPE
5 2 9F-2247 1 PLUG-PIPE
7 1 110-8760 1 STRAP
M 8 1 124-3815 1 BOLT (M8X1.25X16-MM)
9 1 140-8714 1 CLIP
10 2 203-6797 1 SENSOR-SPEED (ENGINE)
11 2 203-6798 1 ADAPTER
12 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
13 1 230-8995 1 TUBE AS (CYL NO. 1)
14 1 230-8996 1 TUBE AS (CYL NO. 2)
15 1 230-8997 1 TUBE AS (CYL NO. 3)
16 1 230-8998 1 TUBE AS (CYL NO. 4)
17 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
17A 1 140-8718 1 WASHER
17B 1 232-2724 1 NOZZLE
17C 1 275-1038 1 SEAL-O-RING
18 1 240-5571 1 BRACKET
19 1 232-1115 1 CLIP-PIPE
21 1 232-1328 1 CAP
22 1 232-1794 3 HOSE
23 1 232-2725 2 CLIP
24 1 232-2726 1 CLIP
25 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
27 1 232-3274 1 BOLT (M8X1.25X48.1-MM)
28 1 238-8671 4 CLAMP-INJECTOR
29 1 272-2223 1 ACTUATOR GP-GOVERNOR
29A 1 241-4288 1 SEAL-O-RING
29B 1 241-4291 4 SCREW
Y 30 1 272-2797 1 PUMP GP-FUEL INJECTION 347
M - METRIC PART
Y - SEPARATE ILLUSTRATION
335522 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05195475
GRAPHIC #1 g01295166
SEBP4152-48 3 of 3 FUEL SYSTEM 335533
FFUUEELL SSYYSSTTEEMM
272-2799 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05195475
GRAPHIC #2 > g03036062
335544 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
273-0869 PUMP GP-FUEL INJECTION
S/N: D1K1-UP
AN ATTACHMENT
SMCS-1251, 1290 i03376162
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 5 1 124-38151 BOLT (M8X1.25X16-MM)
6 1 140-8714 1 CLIP
7 2 235-1790 1 SWITCH-TEMPERATURE (ENGINE COOLANT)
8 2 203-6797 1 SENSOR-SPEED (ENGINE)
9 2 203-6798 1 ADAPTER
10 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
11 1 230-8995 1 TUBE AS (CYL NO. 1)
12 1 230-8996 1 TUBE AS (CYL NO. 2)
13 1 230-8997 1 TUBE AS (CYL NO. 3)
14 1 230-8998 1 TUBE AS (CYL NO. 4)
15 2 232-1323 1 PLUG-CUP
16 1 232-1328 1 CAP
17 2 232-1793 1 CABLE
18 1 232-1794 2 HOSE
19 1 232-2725 2 CLIP
20 1 232-2726 1 CLIP
22 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
24 1 232-3274 3 BOLT (M8X1.25X48.1-MM)
25 1 238-8671 3 CLAMP-INJECTOR
26 1 240-5571 1 BRACKET
27 1 266-6830 3 INJECTOR AS-FUEL
(EACH INCLUDES)
27A 1 140-8718 1 WASHER
27B 1 234-0387 1 NOZZLE
27C 1 275-1038 1 SEAL-O-RING
28 1 272-2223 1 ACTUATOR GP-GOVERNOR
28A 1 241-4288 4 SEAL-O-RING
28B 1 241-4291 1 SCREW
29 1 273-0870 1 PUMP GP-FUEL INJECTION
M - METRIC PART
SEBP4152-48 2 of 3 FUEL SYSTEM 335555
FFUUEELL SSYYSSTTEEMM
273-0869 PUMP GP-FUEL INJECTION (ccoonnttdd..) i03376162
GRAPHIC #1 g01439733
335566 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
273-0869 PUMP GP-FUEL INJECTION (ccoonnttdd..) i03376162
GRAPHIC #2 > g01160773
SEBP4152-48 1 of 3 FUEL SYSTEM 335577
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1251, 1290 i02746194
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-1408 1 PUMP GP-FUEL INJECTION
M 2 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 5 1 124-3815 1 BOLT (M8X1.25X16-MM)
6 1 140-8714 1 CLIP
7 2 235-1790 1 SWITCH-TEMPERATURE (ENGINE COOLANT)
8 2 203-6797 1 SENSOR-SPEED (ENGINE)
9 2 203-6798 1 ADAPTER
10 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
11 1 230-8995 1 TUBE AS (CYL NO. 1)
12 1 230-8996 1 TUBE AS (CYL NO. 2)
13 1 230-8997 1 TUBE AS (CYL NO. 3)
14 1 230-8998 1 TUBE AS (CYL NO. 4)
15 2 232-1323 1 PLUG-CUP
16 1 232-1328 1 CAP
17 2 232-1793 1 CABLE
18 1 232-1794 2 HOSE
19 1 232-2725 2 CLIP
20 1 232-2726 1 CLIP
22 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
24 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
25 1 238-8671 4 CLAMP-INJECTOR
26 1 240-5571 1 BRACKET
27 1 236-1674 4 INJECTOR AS-FUEL
(EACH INCLUDES)
27A 1 140-8718 1 WASHER
27B 1 236-1673 1 NOZZLE
28 1 272-2223 1 ACTUATOR GP-GOVERNOR
28A 1 241-4288 4 SEAL-O-RING
28B 1 241-4291 1 SCREW
M - METRIC PART
335588 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02746194
GRAPHIC #1 g01444202
SEBP4152-48 3 of 3 FUEL SYSTEM 335599
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02746194
GRAPHIC #2 > g01160773
336600 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1251, 1290 i05199488
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-1408 1 PUMP GP-FUEL INJECTION
M 2 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 5 1 124-3815 1 BOLT (M8X1.25X16-MM)
6 1 140-8714 1 CLIP
7 2 235-1790 1 SWITCH-TEMPERATURE (ENGINE COOLANT)
8 2 203-6797 1 SENSOR-SPEED (ENGINE)
9 2 203-6798 1 ADAPTER
10 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
11 1 230-8995 1 TUBE AS (CYL NO. 1)
12 1 230-8996 1 TUBE AS (CYL NO. 2)
13 1 230-8997 1 TUBE AS (CYL NO. 3)
14 1 230-8998 1 TUBE AS (CYL NO. 4)
15 1 272-2223 1 ACTUATOR GP-GOVERNOR
15A 1 241-4288 4 SEAL-O-RING
15B 1 241-4291 1 SCREW
16 1 232-1328 1 CAP
17 2 232-1793 1 CABLE
18 1 232-1794 2 HOSE
19 1 232-2725 2 CLIP
20 1 232-2726 1 CLIP
22 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
24 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
25 1 238-8671 4 CLAMP-INJECTOR
26 1 240-5571 1 BRACKET
R 27 1 236-1674 4 INJECTOR AS-FUEL
(EACH INCLUDES)
27A 1 140-8718 1 WASHER
27B 1 236-1673 1 NOZZLE
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
SEBP4152-48 2 of 3 FUEL SYSTEM 336611
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05199488
GRAPHIC #1 g03339926
336622 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
273-1407 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05199488
GRAPHIC #2 > g03339927
SEBP4152-48 1 of 1 FUEL SYSTEM 336633
FFUUEELL SSYYSSTTEEMM
286-2364 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
PART OF 286-2365 PUMP GP-FUEL INJECTION
AN ATTACHMENT
SMCS-1251, 1290 i02623743
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 111-3422 1 NUT (M14X1.5-THD)
2 1 111-3423 1 WASHER
3 1 152-3968 1 SEAL-O-RING
4 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT) (FUEL SHUTOFF)
M - METRIC PART
GRAPHIC #1 > g01160107
336644 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 1
SMCS-1251, 1290 i02768398
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0217 1 BOLT (M8X1.25X20-MM)
M 2 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 3 1 6I-0291 1 NUT (M8X1.25-THD)
4 2 9F-2247 1 PLUG-PIPE
5 2 7M-7410 1 PLUG-PIPE
M 6 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 7 1 124-3815 1 BOLT (M8X1.25X16-MM)
8 1 140-8714 1 CLIP
9 2 203-6797 1 SENSOR-SPEED (TIMING ADVANCE)
10 2 203-6798 1 ADAPTER
11 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
12 1 230-8995 1 TUBE AS (CYL NO. 1)
13 1 230-8996 1 TUBE AS (CYL NO. 2)
14 1 230-8997 1 TUBE AS (CYL NO. 3)
15 1 230-8998 1 TUBE AS (CYL NO. 4)
R 16 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
16A 1 140-8718 1 WASHER
16B 1 232-2724 1 NOZZLE
16C 1 275-1038 1 SEAL-O-RING
17 2 232-1323 1 PLUG-CUP
18 1 232-1328 1 CAP
19 1 232-1794 3 HOSE
20 1 232-2725 2 CLIP
21 1 232-2726 1 CLIP
23 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
24 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
25 1 238-8671 4 CLAMP-INJECTOR
26 1 240-5571 1 BRACKET
27 1 272-2223 1 ACTUATOR GP-GOVERNOR
27A 1 241-4288 4 SEAL-O-RING
27B 1 241-4291 1 SCREW
Y 28 1 286-2364 1 PUMP GP-FUEL INJECTION 363
29 1 232-3157 1 BRACKET
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 3 FUEL SYSTEM 336655
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02768398
GRAPHIC #1 g01397413
336666 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION (ccoonnttdd..) i02768398
GRAPHIC #2 > g01259891
SEBP4152-48 1 of 3 FUEL SYSTEM 336677
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
TYPE 2
SMCS-1251, 1290 i05257457
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 286-2364 1 PUMP GP-FUEL INJECTION 363
M 2 1 6I-0260 3 BOLT (M8X1.25X25-MM)
3 1 272-2223 1 ACTUATOR GP-GOVERNOR
3A 1 241-4288 4 SEAL-O-RING
3B 1 241-4291 1 SCREW
4 2 9F-2247 1 PLUG-PIPE
5 2 7M-7410 1 PLUG-PIPE
6 1 240-5571 1 BRACKET
M 7 1 124-3815 1 BOLT (M8X1.25X16-MM)
8 1 140-8714 1 CLIP
9 2 203-6797 1 SENSOR-SPEED (TIMING ADVANCE)
10 2 203-6798 1 ADAPTER
11 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
12 1 230-8995 1 TUBE AS (CYL NO. 1)
13 1 230-8996 1 TUBE AS (CYL NO. 2)
14 1 230-8997 1 TUBE AS (CYL NO. 3)
15 1 230-8998 1 TUBE AS (CYL NO. 4)
R 16 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
16A 1 140-8718 1 WASHER
16B 1 232-2724 1 NOZZLE
16C 1 275-1038 1 SEAL-O-RING
17 1 238-8671 4 CLAMP-INJECTOR
18 1 232-1328 1 CAP
19 1 232-1794 3 HOSE
20 1 232-2725 2 CLIP
21 1 232-2726 1 CLIP
22 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
23 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
Y - SEPARATE ILLUSTRATION
336688 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05257457
GRAPHIC #1 g03356621
SEBP4152-48 3 of 3 FUEL SYSTEM 336699
FFUUEELL SSYYSSTTEEMM
286-2365 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05257457
GRAPHIC #2 > g03339752
337700 FUEL SYSTEM 1 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM367-2070 PUMP GP-FUEL INJECTION
S/N: D1K1-UP
AN ATTACHMENT
TYPE 1
SMCS-1251, 1290 i04636730
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 2 1 124-3815 1 BOLT (M8X1.25X16-MM)
3 1 140-8714 1 CLIP
4 2 169-5326 1 SWITCH-TEMPERATURE
5 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
6 1 230-8995 1 TUBE AS (CYL NO. 1)
7 1 230-8996 1 TUBE AS (CYL NO. 2)
8 1 230-8997 1 TUBE AS (CYL NO. 3)
9 1 230-8998 1 TUBE AS (CYL NO. 4)
10 2 232-1323 1 PLUG-CUP
11 1 232-1328 1 CAP
12 1 232-1794 3 HOSE
13 1 232-2725 2 CLIP
14 1 232-2726 1 CLIP
15 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
16 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
17 1 238-8671 4 CLAMP-INJECTOR
18 1 240-5571 1 BRACKET
R 19 1 266-6830 4 INJECTOR AS-FUEL
(EACH INCLUDES)
19A 1 140-8718 1 WASHER
19B 1 234-0387 1 NOZZLE
19C 1 275-1038 1 SEAL-O-RING
20 1 272-2223 1 ACTUATOR GP-GOVERNOR
20A 1 241-4291 4 SCREW
20B 1 241-4288 1 SEAL-O-RING
21 1 367-2069 1 PUMP-FUEL INJECTION
M 21A 1 111-3422 1 NUT (M14X1.5-THD)
21B 1 111-3423 1 WASHER
21C 1 152-3968 1 SEAL-O-RING
21D 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT)
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
SEBP4152-48 2 of 3 FUEL SYSTEM 337711
FFUUEELL SSYYSSTTEEMM
367-2070 PUMP GP-FUEL INJECTION (ccoonnttdd..) i04636730
GRAPHIC #1 g02817537
337722 FUEL SYSTEM 3 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
367-2070 PUMP GP-FUEL INJECTION (ccoonnttdd..) i04636730
GRAPHIC #2 > g02817876
SEBP4152-48 1 of 3 FUEL SYSTEM 337733
FFUUEELL SSYYSSTTEEMM
367-2070 PUMP GP-FUEL INJECTION
S/N: D1K1-UP
AN ATTACHMENT
TYPE 2
SMCS-1251, 1290 i04896074
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
M 2 1 124-3815 1 BOLT (M8X1.25X16-MM)
3 1 140-8714 1 CLIP
4 2 169-5326 1 SWITCH-TEMPERATURE
5 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
6 1 230-8995 1 TUBE AS (CYL NO. 1)
7 1 230-8996 1 TUBE AS (CYL NO. 2)
8 1 230-8997 1 TUBE AS (CYL NO. 3)
9 1 230-8998 1 TUBE AS (CYL NO. 4)
11 1 232-1328 1 CAP
12 1 232-1794 3 HOSE
13 1 232-2725 2 CLIP
14 1 232-2726 1 CLIP
15 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
16 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
17 1 238-8671 4 CLAMP-INJECTOR
18 1 240-5571 1 BRACKET
R 19 1 266-6830 4 INJECTOR AS-FUEL
(EACH INCLUDES)
19A 1 140-8718 1 WASHER
19B 1 234-0387 1 NOZZLE
19C 1 275-1038 1 SEAL-O-RING
20 1 272-2223 1 ACTUATOR GP-GOVERNOR
20A 1 241-4291 4 SCREW
20B 1 241-4288 1 SEAL-O-RING
21 1 367-2069 1 PUMP-FUEL INJECTION
M 21A 1 111-3422 1 NUT (M14X1.5-THD)
21B 1 111-3423 1 WASHER
21C 1 152-3968 1 SEAL-O-RING
21D 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT)
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
337744 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
367-2070 PUMP GP-FUEL INJECTION (ccoonnttdd..) i04896074
GRAPHIC #1 g02817537
SEBP4152-48 3 of 3 FUEL SYSTEM 337755
FFUUEELL SSYYSSTTEEMM
367-2070 PUMP GP-FUEL INJECTION (ccoonnttdd..) i04896074
GRAPHIC #2 > g03055396
337766 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
441-4291 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
PART OF 441-4311 PUMP GP-FUEL INJECTION
AN ATTACHMENT
SMCS-1251, 1290 i05787341
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 111-3422 1 NUT (M14X1.5-THD)
2 1 111-3423 1 WASHER
3 1 152-3968 1 SEAL-O-RING
4 1 176-6219 1 VALVE GP-SOLENOID (12-VOLT) (FUEL SHUTOFF)
M - METRIC PART
GRAPHIC #1 > g01397810
SEBP4152-48 1 of 3 FUEL SYSTEM 337777
FFUUEELL SSYYSSTTEEMM
441-4311 PUMP GP-FUEL INJECTION
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1251, 1290 i05787330
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0260 3 BOLT (M8X1.25X25-MM)
2 2 7M-7410 1 PLUG-PIPE
M 3 2 124-3815 1 BOLT (M8X1.25X16-MM)
4 1 140-8714 1 CLIP
5 1 230-8989 1 GEAR-FUEL PUMP (68-TEETH)
6 1 230-8995 1 TUBE AS (CYL NO. 1)
7 1 230-8996 1 TUBE AS (CYL NO. 2)
8 1 230-8997 1 TUBE AS (CYL NO. 3)
9 1 230-8998 1 TUBE AS (CYL NO. 4)
R 10 1 230-8999 4 INJECTOR AS-FUEL
(EACH INCLUDES)
10A 1 140-8718 1 WASHER
10B 1 275-1038 1 SEAL-O-RING
10C 1 232-2724 1 NOZZLE
11 2 232-1323 1 PLUG-CUP
12 1 232-1328 1 CAP
13 1 232-1794 3 HOSE
14 1 232-2725 2 CLIP
15 1 232-2726 1 CLIP
16 1 232-3149 3 WASHER (8.35X16.85X1.55-MM THK)
17 1 232-3274 4 BOLT (M8X1.25X48.1-MM)
18 1 238-8671 4 CLAMP-INJECTOR
19 2 240-5571 1 BRACKET
20 1 272-2223 1 ACTUATOR GP-GOVERNOR
20A 1 241-4288 1 SEAL-O-RING
20B 1 241-4291 4 SCREW
21 2 292-3462 1 PLUG-PIPE
Y 22 1 441-4291 1 PUMP GP-FUEL INJECTION 376
M - METRIC PART
R - REMFG PART MAY BE AVAILABLE
Y - SEPARATE ILLUSTRATION
337788 FUEL SYSTEM 2 of 3 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
441-4311 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05787330
GRAPHIC #1 g03660846
SEBP4152-48 3 of 3 FUEL SYSTEM 337799
FFUUEELL SSYYSSTTEEMM
441-4311 PUMP GP-FUEL INJECTION (ccoonnttdd..) i05787330
GRAPHIC #2 > g03660848
338800 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
288-6607 PUMP GP-FUEL PRIMING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1258 i04930107
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-6605 1 PUMP-FUEL (12-VOLT)
2 1 100-4838 2 BOLT (M6X1X20-MM)
3 1 210-6852 1 ADAPTER
4 1 288-6606 1 ELBOW
GRAPHIC #1 > g01270027
SEBP4152-48 1 of 1 FUEL SYSTEM 338811
FFUUEELL SSYYSSTTEEMM
288-6608 PUMP GP-FUEL PRIMING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1258 i04930106
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-6609 1 PUMP-FUEL (24-VOLT)
2 1 100-4838 2 BOLT (M6X1X20-MM)
3 1 210-6852 1 ADAPTER
4 1 288-6606 1 ELBOW
GRAPHIC #1 > g01273797
338822 FUEL SYSTEM 1 of 1 SEBP4152-48
FFUUEELL SSYYSSTTEEMM
270-0357 SHIELD GP-FUEL LINES
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1067, 1252 i02301704
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 270-0358 1 SHIELD AS
GRAPHIC #1 > g01153532
SEBP4152-48 1 of 1 FUEL SYSTEM 338833
FFUUEELL SSYYSSTTEEMM
270-0367 SHIELD GP-FUEL LINES
S/N: L1K1-UP; S1M1-UP
FOR USE WITH SHEATHED FUEL LINES ONLY
AN ATTACHMENT
SMCS-1067, 1252 i02291957
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 270-0379 1 COVER AS
2 1 270-0380 1 BRACKET
3 1 270-0381 1 BRACKET
4 1 6I-0631 4 BOLT (M6X1X12-MM)
5 1 112-7704 2 BOLT (M6X1X30-MM)
E 6 1 197-3800 LOOM (5-CM)
E 7 1 197-3800 LOOM (3-CM)
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01148340
338844 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
263-7657 ALTERNATOR GP-CHARGING
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-1405 i02288458
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-7656 1 ALTERNATOR
GRAPHIC #1 > g01149239
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 338855
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
263-7673 ALTERNATOR GP-CHARGING
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1405 i03636073
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-7672 1 ALTERNATOR AS (24-VOLT)
GRAPHIC #1 > g01146742
338866 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
355-5146 BRACKET GP-SUPPORT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-0635, 1408 i05124615
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTTNNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-5138 1 BRACKET
M 2 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
GRAPHIC #1 > g03355833
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 338877
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
357-7614 BRACKET GP-SUPPORT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-0635, 1408 i05165125
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 356-9705 1 BRACKET
M 2 1 100-4830 3 BOLT (M10X1.5X20-MM)
M 3 1 6I-0594 3 NUT (M10X1.5-THD)
4 1 356-9706 3 CLIP
5 1 356-9707 2 CLIP
6 1 356-9708 13 CLIP
M 7 1 5C-9553 15 BOLT (M6X1X16-MM)
M 8 1 208-8469 15 LOCKNUT (M6X1-THD)
9 1 241-4291 3 SCREW
M 10 1 3T-0851 3 LOCKNUT (M5X0.8-THD)
M - METRIC PART
GRAPHIC #1 > g03341189
338888 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
271-3542 CABLE GP
S/N: L1K1-UP; S1M1-UP
FOR USE WITH REMOTE MOUNTED, STANDARD GENSET CONTROL PANELS
AN ATTACHMENT
SMCS-1408, 4459, 4480 i02308839
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 271-3543 1 HARNESS AS-WIRING
GRAPHIC #1 > g01158939
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 338899
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
288-6115 CABLE GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408, 4459, 4480 i03634842
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-6114 1 CABLE AS
GRAPHIC #1 > g01951153
339900 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
288-6120 CABLE GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408, 4459, 4480 i03634843
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-6119 1 CABLE AS
GRAPHIC #1 > g01951229
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 339911
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
273-0611 CONNECTION GP-ELECTRICAL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02421635
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-0612 1 CONNECTOR
2 1 271-3537 1 CONNECTOR AS
3 1 186-3735 23 PIN-CONNECTOR (16-GA TO 18-GA)
4 1 8T-8737 10 PLUG-SEAL
GRAPHIC #1 > g01160392
339922 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
289-3725 CONNECTION GP-ELECTRICAL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02539366
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-2396 1 BRACKET
M 2 1 106-8916 2 BOLT (M6X16-MM)
3 1 6I-0918 2 NUT
4 1 289-3726 2 BLOCK-TERMINAL
5 1 193-5186 4 WASHER (M8X1.25-THD)
6 1 196-7699 4 NUT (M8X1.25-THD)
7 1 196-0344 2 WASHER-LOCK
8 1 260-6702 1 SCREW-PAN HEAD (M4X0.7X20-MM)
M 9 1 095-0733 2 SCREW-MACHINE (M4X0.7X40-MM)
10 1 196-0347 3 WASHER (4.3X8.7X0.8-MM THK)
M 11 1 178-9983 3 LOCKNUT (M4X0.7-THD)
M - METRIC PART
GRAPHIC #1 > g01273858
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 339933
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
281-0571 CONTACTOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1400, 7400 i03636630
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-0573 1 BRACKET
M 2 1 102-9941 2 BOLT (M12X1.75X25-MM)
3 1 281-0574 2 ADAPTER
4 1 281-0575 1 TUBE
M 5 1 8T-0266 2 BOLT-SOCKET HEAD (M5X0.8X40-MM)
6 1 281-0572 1 SWITCH (PRESSURE)
7 1 264-0564 1 CONNECTION GP-TEST
M - METRIC PART
GRAPHIC #1 > g01284943
339944 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
281-1274 CONTACTOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1400, 7400 i05800252
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-1279 1 BRACKET
M 2 1 102-9941 2 BOLT (M12X1.75X25-MM)
3 1 264-1423 1 CONNECTION GP-TEST
M 4 1 8T-3283 4 BOLT-SOCKET HEAD (M5X0.8X45-MM)
5 1 281-1275 1 TRANSMITTER-PRESSURE
6 1 281-1276 1 TRANSMITTER-PRESSURE
7 1 281-1277 1 TUBE
8 1 281-1278 1 ADAPTER
9 1 281-0574 1 ADAPTER
M - METRIC PART
GRAPHIC #1 > g01260094
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 339955
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
362-2821 CONTACTOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1400, 7400 i05165127
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 309-5910 1 SENSOR-PRESSURE
2 1 288-3643 1 SWITCH-TEMPERATURE
3 1 288-3636 1 SENSOR-TEMPERATURE
4 1 357-7463 1 SENSOR-TEMPERATURE
5 1 288-3641 1 THERMOWELL
M 6 1 295-4155 6 BOLT-SOCKET HEAD (M5X0.8X35-MM)
7 1 9T-4057 4 SEAL-O-RING
8 1 264-1423 1 CONNECTION GP-TEST
9 1 281-1275 1 TRANSMITTER-PRESSURE
10 1 281-1276 1 TRANSMITTER-PRESSURE
11 1 236-6056 1 WASHER-SPECIAL
M 12 1 8T-3283 10 BOLT-SOCKET HEAD (M5X0.8X45-MM)
13 1 199-1187 2 NUT (M5X0.8-THD)
14 1 288-3637 1 WASHER (19X24X2-MM THK)
15 1 288-3642 1 CLIP
M 16 1 6I-4200 1 BOLT (M10X1.5X16-MM)
17 1 309-0715 1 MANIFOLD GP-FUEL
18 1 309-5909 1 SWITCH
19 1 219-1643 1 SEAL
20 1 210-6962 1 ADAPTER
21 1 334-5083 1 THERMOWELL
M - METRIC PART
GRAPHIC #1 > g03355753
339966 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
362-2986 CONTACTOR GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1400, 7400 i05165132
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 309-5910 1 SENSOR-PRESSURE
2 1 297-4659 1 SWITCH AS-TEMPERATURE
3 1 288-3636 1 SENSOR-TEMPERATURE
4 1 357-7463 1 SENSOR-TEMPERATURE
5 1 288-3641 1 THERMOWELL
M 6 1 295-4155 6 BOLT-SOCKET HEAD (M5X0.8X35-MM)
7 1 9T-4057 4 SEAL-O-RING
8 1 264-1423 1 CONNECTION GP-TEST
9 1 281-1275 1 TRANSMITTER-PRESSURE
10 1 281-1276 1 TRANSMITTER-PRESSURE
11 1 236-6056 1 WASHER-SPECIAL
M 12 1 8T-3283 10 BOLT-SOCKET HEAD (M5X0.8X45-MM)
13 1 199-1187 2 NUT (M5X0.8-THD)
14 1 288-3637 1 WASHER (19X24X2-MM THK)
15 1 288-3642 1 CLIP
M 16 1 6I-4200 1 BOLT (M10X1.5X16-MM)
17 1 309-0715 1 MANIFOLD GP-FUEL
18 1 309-5909 1 SWITCH
19 1 219-1643 1 SEAL
20 1 210-6962 1 ADAPTER
21 1 334-5083 1 THERMOWELL
M - METRIC PART
GRAPHIC #1 > g03355779
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 339977
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
309-5908 CONTACTOR GP-GENERATOR–FUEL
S/N: L1K1-UP; J1Z1-UP
FOR USE WITH C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-4450 i03635849
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-1300 1 VALVE
2 1 309-5909 1 SWITCH (FUEL PRESSURE)
3 1 309-5910 1 SENSOR-PRESSURE (FUEL)
4 1 219-1643 1 SEAL
5 1 309-0720 2 SEAL-O-RING
6 1 281-0791 2 BOLT-SOCKET HEAD (M5X0.8X40-MM)
M 7 1 8T-3283 4 BOLT-SOCKET HEAD (M5X0.8X45-MM)
M - METRIC PART
GRAPHIC #1 > g01946392
339988 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-7444 CONTACTOR GP-OIL PRESSURE–ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7400, 7421 i03635945
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-1302 1 PLATE
2 1 287-7440 2 ADAPTER
3 1 6V-0407 2 SEAL-BONDED
4 1 105-2740 4 BOLT
5 1287-7441 2 ADAPTER
6 1 281-1303 1 TUBE
7 1 281-1304 1 TUBE
8 1 140-7473 2 CLIP
9 1 287-7442 1 ADAPTER
10 1 281-1305 1 TUBE
11 1 287-7443 1 TUBE
12 1 281-0574 3 ADAPTER
13 1 281-1306 1 GASKET
14 1 281-1300 1 VALVE
15 1 281-1301 1 SWITCH-PRESSURE (ENGINE OIL)
M 16 1 8T-3283 8 BOLT-SOCKET HEAD (M5X0.8X45-MM)
17 1 281-1279 1 BRACKET
M 18 1 102-9941 2 BOLT (M12X1.75X25-MM)
19 1 264-1423 1 CONNECTION GP-TEST
20 1 281-1275 1 TRANSMITTER-PRESSURE
21 1 281-1276 1 TRANSMITTER-PRESSURE (ENGINE OIL)
M - METRIC PART
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 339999
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-7444 CONTACTOR GP-OIL PRESSURE (ccoonnttdd..) i03635945
GRAPHIC #1 > g01271407
440000 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
288-3644 CONTACTOR GP-TEMPERATURE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1906 i03637220
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-3634 1 PLATE-MOUNTING
M 2 1 6I-0594 2 NUT (M10X1.5-THD)
M 3 1 100-4830 2 BOLT (M10X1.5X20-MM)
4 1 288-3636 1 SENSOR-TEMPERATURE (ENGINE OIL)
5 1 288-3637 1 WASHER (19X24X2-MM THK)
6 1 288-3639 1 SENSOR-TEMPERATURE
7 1 236-6056 1 WASHER-SPECIAL
8 1 288-3641 1 THERMOWELL
9 1 195-4615 2 STRAP
10 1 199-1187 2 NUT (M5X0.8-THD)
M 11 1 6I-4200 1 BOLT (M10X1.5X16-MM)
12 1 288-3642 1 CLIP
13 1 288-3643 1 SWITCH-TEMPERATURE (WATER COOLANT)
M 14 1 8T-3283 2 BOLT-SOCKET HEAD (M5X0.8X45-MM)
M - METRIC PART
GRAPHIC #1 > g01274315
SEBP4152-48 1 of 2 ELECTRICAL AND STARTING SYSTEM 440011
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
297-4660 CONTACTOR GP-TEMPERATURE
S/N: D1K1-UP; S1M1-UP
FOR USE WITH MCS APPROVED RADIATOR COOLED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1906 i03637221
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-3634 1 PLATE-MOUNTING
M 2 1 6I-0594 2 NUT (M10X1.5-THD)
M 3 1 100-4830 2 BOLT (M10X1.5X20-MM)
4 1 288-3636 1 SENSOR-TEMPERATURE (ENGINE OIL)
5 1 288-3637 1 WASHER (19X24X2-MM THK)
6 1 288-3639 1 SENSOR-TEMPERATURE (WATER COOLANT)
7 1 236-6056 1 WASHER-SPECIAL
8 1 288-3641 1 THERMOWELL
9 1 195-4615 2 STRAP
10 1 199-1187 2 NUT (M5X0.8-THD)
M 11 1 6I-4200 1 BOLT (M10X1.5X16-MM)
12 1 288-3642 1 CLIP
13 1 297-4659 1 SWITCH AS-TEMPERATURE (WATER COOLANT)
M 14 1 8T-3283 2 BOLT-SOCKET HEAD (M5X0.8X45-MM)
M - METRIC PART
440022 ELECTRICAL AND STARTING SYSTEM 2 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
297-4660 CONTACTOR GP-TEMPERATURE (ccoonnttdd..) i03637221
GRAPHIC #1 > g01580955
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 440033
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
304-4757 CONTROL GP-ELECTRONIC
S/N: L1K1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635332
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
304-4758 CONTROL GP-ELECTRONIC
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635334
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
304-4759 CONTROL GP-ELECTRONIC
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635336
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
304-4760 CONTROL GP-ELECTRONIC
S/N: L1K1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635337
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
304-4761 CONTROL GP-ELECTRONIC
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635340
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
440044 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
304-4762 CONTROL GP-ELECTRONIC
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1917, 1924 i03635341
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 440055
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
272-0505 CONVERTER GP-ELECTRICAL
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1421 i02308842
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-0506 1 CONVERTER AS
GRAPHIC #1 > g01157372
440066 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
232-6661 GLOW PLUG GP
S/N: D1K1-UP; J1Z1-UP
AN ATTACHMENT
SMCS-1412 i04660276
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 368-3151 1 BUS BAR GP
1 370-2909 1 WIRE AS (STARTING AID)
1 276-1151 1 PIN-CONNECTOR (8-GA TO 10-GA)
1 369-0473 1 LOCKNUT
1 369-2472 1 SPACER
2 1 232-6662 4 GLOW PLUG (12-VOLT)
3 1 232-3126 1 CLIP
GRAPHIC #1 > g02792742
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 440077
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
272-0499 GLOW PLUG GP
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1412 i02306185
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 226-8770 4 GLOW PLUG (24-VOLT)
GRAPHIC #1 > g01157298
440088 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
300-9751 HARNESS AS-PANEL
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02635041
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-2453 1 HARNESS AS-PANEL
2 1 215-1262 3 FUSE (6.5-AMPERE)
3 1 273-2461 1 PLATE
GRAPHIC #1 > g01343767
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 440099
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
296-5096 HARNESS AS-WIRING
S/N: D1K1-UP; S1M1-UP
FOR USE WITH C4.4 ENCLOSED MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1408 i02637236
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
(NO SERVICED PARTS)
>
441100 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
299-2194 HARNESS AS-WIRING
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-1408 i02637762
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-2195 1 HARNESS AS-WIRING
M 2 1 178-9983 1 LOCKNUT (M4X0.7-THD)
3 1 196-0347 1 WASHER (4.3X8.7X0.8-MM THK)
M - METRIC PART
GRAPHIC #1 > g01420774
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 441111
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
299-2206 HARNESS AS-WIRING
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02637746
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-2207 1 HARNESS AS-WIRING
2 1 196-0384 10 TIE-CABLE
GRAPHIC #1 > g01420777
441122 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-5212 HARNESS GP
S/N: L1K1-UP; S1M1-UP
25-FT
FOR USE WITH 12-VOLT OR 24-VOLT REMOTE STOP/START PANELS OR REMOTE START/STOP PANELS
WITH INSTRUMENTS
CANNOT BE USED WITH REMOTE STANDARD PANELS
AN ATTACHMENT
SMCS-1408 i02290414
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCTLEVEL)
SSEEEE
PPAAGGEE
1 1 269-5199 1 HARNESS AS-PANEL (INTERCONNECT)
1A 1 155-2255 2 KIT-CONNECTING PLUG (12-PIN)
(EACH INCLUDES PLUG AS AND WEDGE)
GRAPHIC #1 > g01148002
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 441133
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-5213 HARNESS GP
S/N: L1K1-UP; S1M1-UP
45-FT
FOR USE WITH 12-VOLT RO 24-VOLT REMOTE STOP/START PANELS OR REMOTE START/STOP PANELS
WITH INSTRUMENTS
CANNOT BE USED WITH REMOTE STANDARD PANELS
AN ATTACHMENT
SMCS-1408 i02290471
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-5200 1 HARNESS AS-WIRING
1A 1 155-2255 2 KIT-CONNECTING PLUG (12-PIN)
(EACH INCLUDES PLUG AS AND WEDGE)
GRAPHIC #1 > g01148002
441144 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-5214 HARNESS GP
S/N: L1K1-UP; S1M1-UP
80-FT
FOR USE WITH 12-VOLT OR 24-VOLT REMOTE STOP/START PANELS OR REMOTE START/STOP PANELS
WITH INSTRUMENTS
CANNOT BE USED WITH REMOTE STANDARD PANELS
AN ATTACHMENT
SMCS-1408 i02290521
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-5202 1 HARNESS AS-WIRING
1A 1 155-2255 2 KIT-CONNECTING PLUG (12-PIN)
(INCLUDES PLUG AS AND WEDGE)
GRAPHIC #1 > g01147729
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 441155
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
357-7611 HARNESS GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i05103030
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 361-3353 1 HARNESS AS-WIRING
2 1 361-3354 1 HARNESS AS-WIRING
3 1 290-1129 3 STRAP
4 1 8L-8413 3 STRAP-CABLE (WHITE)
M 5 1 6I-4200 1 BOLT (M10X1.5X16-MM)
6 1 196-0350 1 LOCKWASHER
M - METRIC PART
GRAPHIC #1 > g03341179
441166 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-5211 HARNESS GP-WIRING
S/N: L1K1-UP; S1M1-UP
15-FT
FOR USE WITH 12-VOLT OR 24-VOLT REMOTE STOP/START PANELS OR REMOTE START/STOP PANELS
WITH INSTRUMENTS
CANNOT BE USED WITH REMOTE STANDARD PANELS
AN ATTACHMENT
SMCS-1408 i02290405
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-5198 1 HARNESS AS-WIRING
1A 1 155-2255 2 KIT-CONNECTING PLUG (12-PIN)
(EACH INCLUDES PLUG AS AND WEDGE)
GRAPHIC #1 > g01148002
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 441177
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
213-6970 HEATER GP-JACKET WATER
S/N: L1K1-UP; S1M1-UP
240-VOLT
AN ATTACHMENT
SMCS-1383 i02312951
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 213-8193 1 HEATER AS (WATER)
GRAPHIC #1 > g00856218
441188 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
213-6971 HEATER GP-JACKET WATER
S/N: L1K1-UP; S1M1-UP
120-VOLT
AN ATTACHMENT
SMCS-1383 i02312952
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 213-8194 1 HEATER AS (WATER)
GRAPHIC #1 > g00856218
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 441199
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-3491 MOUNTING GP-SENSOR
S/N: L1K1-UP; S1M1-UP
FOR USE WITH ENGINES FITTED WITH DOUBLE SKINNED INJECTION PIPES
AN ATTACHMENT
SMCS-1439 i02319549
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 274-3492 1 BRACKET
2 1 101-3927 1 CLIP
M 3 1 102-9941 2 BOLT (M12X1.75X25-MM)
4 1 274-3493 1 TUBE
M - METRIC PART
GRAPHIC #1 > g01160624
442200 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
210-6434 MOUNTING GP-STARTING MOTOR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-1452, 1453 i02312949
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 7W-4540 1 SPACER
M 2 1 101-5115 3 STUD (M10X1.5X40-MM)
M 3 1 6I-0594 3 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g00850624
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 442211
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
270-1911 MOUNTING GP-STARTING MOTOR
S/N: L1K1-UP; S1M1-UP
FOR USE WITH ELECTRIC STARTERS ONLY
AN ATTACHMENT
SMCS-1452, 1453 i02291099
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 6I-0562 3 STUD
M 2 1 6I-0594 3 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g01148578
442222 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-1228 MOUNTING GP-WIRING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02540672
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 290-1229 1 SUPPORT
2 1 290-1231 1 BRACKET
3 1 290-1232 1 BRACKET
M 4 1 245-6541 3 BOLT (M5X0.8X12-MM)
5 1 199-1187 3 NUT (M5X0.8-THD)
M - METRIC PART
GRAPHIC #1 > g01274250
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 442233
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-2483 MOUNTING GP-WIRING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408 i02540685
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 290-1229 1 SUPPORT
2 1 290-1231 1 BRACKET
3 1 290-1232 1 BRACKET
4 1 6I-0235 1 BOLT (M12X1.75X50-MM)
M 5 1 6I-1090 2 BOLT (M8X1.25X40-MM)
6 1 270-4176 1 BRACKET-SUPPORT
7 1 210-6899 1 BRACKET
8 1 210-6900 1 BOLT-FLANGE HEAD (M12X1.75X100-MM)
M 9 1 124-3815 2 BOLT (M8X1.25X16-MM)
M 10 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 11 1 6I-0291 4 NUT (M8X1.25-THD)
M 12 1 245-6541 3 BOLT (M5X0.8X12-MM)
13 1 199-1187 3 NUT (M5X0.8-THD)
M 14 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M - METRIC PART
GRAPHIC #1 > g01274064
442244 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
371-4046 RELAY GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1422, 4493 i05119317
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 371-4035 1 SWITCH
2 1 371-4036 1 RELAY-POWER
3 1 371-4037 1 RELAY AS
4 1 371-4038 1 PLATE
GRAPHIC #1 > g03334970
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 442255
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
263-8006 SENDER GP-TEMP & PRESS
S/N: L1K1-UP; S1M1-UP
FOR USE WITH SINGLE STATION CONTROL PANELS
CANNOT BE USED WITH DUAL STATION CONTROL PANELS
AN ATTACHMENT
SMCS-1906, 7400 i05459870
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5150 1 SWITCH AS-TEMPERATURE (96-DEG) (COOLANT)
2 1 210-6962 1 ADAPTER
3 1 433-1846 1 SWITCH-PRESSURE (ENGINE)
4 1 7E-6831 1 SENDER-WATER TEMPERATURE
GRAPHIC #1 > g01148780
442266 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
270-6983 SENDER GP-TEMP & PRESS
S/N: L1K1-UP; S1M1-UP
FOR USE WITH DUAL STATION CONTROL PANELS
AN ATTACHMENT
SMCS-1906, 7400 i05371640
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 193-5150 1 SWITCH AS-TEMPERATURE (96-DEG) (COOLANT)
2 1 210-6962 1 ADAPTER
3 1 433-1846(1) 111-2371 (2)
163-242 (43-64) 3P-2044 (8) 3P-2044 (2) 9N-3718 (2)
* Normal maintenance period is 250 hrs. See your Operation and Maintenance Manual for complete coolant
maintenance instructions.
( ) Indicates quantity required.
SSUUPPPPLLEEMMEENNTTAALL CCOOOOLLAANNTT AADDDDIITTIIVVEESS
AA88 MAINTENANCE PARTS SEBP4152-48
AAIIRR IINNLLEETT AANNDD EEXXHHAAUUSSTT SSYYSSTTEEMM
FILTER ELEMENT AS-AIR (PRIMARY) 110-6326 1 AIR CLEANER GP 263
263 1 AIR CLEANER GP 267
267 233-5182 1 AIR CLEANER GP 262
262 1 AIR CLEANER GP 269
269 1 AIR CLEANER GP 271
271FILTER ELEMENT AS-AIR (SECONDARY) 110-6331 1 AIR CLEANER GP 263
263 1 AIR CLEANER GP 267
267 233-5184 1 AIR CLEANER GP 262
262FILTER ELEMENT-AIR (PRIMARY) 123-2367 1 AIR CLEANER GP 273
273 1 AIR CLEANER GP 276
276 212-4478 1 AIR CLEANER GP 274
274FILTER ELEMENT-AIR (SECONDARY) 123-2368 1 AIR CLEANER GP 276
276GASKET 114-2579 4 ELBOW GP-AIR INLET 277
277 225-8533 1 TURBOCHARGER GP 314
314 1 TURBOCHARGER GP 316
316GASKET-INLET 234-3030 1 TURBOCHARGER GP 308
308 1 TURBOCHARGER GP 314
314GASKET-TURBOCHARGER 353-3477 1 TURBOCHARGER GP 310
310 1 TURBOCHARGER GP 312
312 353-3478 1 TURBOCHARGER GP 308
308 1 TURBOCHARGER GP 310
310 1 TURBOCHARGER GP 312
312GASKET-TURBOCHARGER
(TURBOCHARGER)
353-3477 1 TURBOCHARGER GP 308
308
BBAASSIICC EENNGGIINNEE
CAP AS (ENGINE OIL FILLER) 136-3608 1 COVER GP-VALVE MECHANISM 36
36 1 COVER GP-VALVE MECHANISM 38
38 1 COVER GP-VALVE MECHANISM 40
40 1 COVER GP-VALVE MECHANISM 44
44 1 COVER GP-VALVE MECHANISM 46
46 1 COVER GP-VALVE MECHANISM 48
48 1 COVER GP-VALVE MECHANISM 50
50 1 COVER GP-VALVE MECHANISM 53
53CAP-OIL FILLER (ENGINE) 130-9888 1 COVER GP-VALVE MECHANISM 36
36 1 COVER GP-VALVE MECHANISM 38
38 1 COVER GP-VALVE MECHANISM 40
40 1 COVER GP-VALVE MECHANISM 42
42 1 COVER GP-VALVE MECHANISM 51
51 1 COVER GP-VALVE MECHANISM 52
52FILTER-ENGINE OIL 081-4661 2 SPACER GP-BLOCK 135
135GASKET 225-7944 1 CYLINDER BLOCK GP 74
74GASKET (ENGINE OIL FILTER BASE) 225-7944 1 CYLINDER BLOCK GP 67
67GASKET (VALVE COVER) 225-6451 1 COVER GP-VALVE MECHANISM 36
36 1 COVER GP-VALVE MECHANISM 38
38 1 COVER GP-VALVE MECHANISM 40
40 1 COVER GP-VALVE MECHANISM 44
DDEESSCCRRIIPPTTIIOONN
PPAARRTT
NNUUMMBBEERR QQTTYY WWHHEERREE UUSSEEDD PPAAGGEE
MMAAIINNTTEENNAANNCCEE PPAARRTTSS
SEBP4152-48 MAINTENANCE PARTS AA99
44 1 COVER GP-VALVE MECHANISM 46
46 1 COVER GP-VALVE MECHANISM 48
48 1 COVER GP-VALVE MECHANISM 50
50 1 COVER GP-VALVE MECHANISM 53
53PLUG-DRAIN (ENGINE OIL) 7C-0351 2 PAN GP-OIL 106
106 2 PAN GP-OIL 108
108SEAL (VALVE COVER) 124-0506 1 COVER GP-VALVE MECHANISM 38
38 1 COVER GP-VALVE MECHANISM 40
40 1 COVER GP-VALVE MECHANISM 46
46 1 COVER GP-VALVE MECHANISM 48
48 1 COVER GP-VALVE MECHANISM 50
50 1 COVER GP-VALVE MECHANISM 53
53V-BELT (FAN) (INCLUDES ONE BELT) 269-9117 1 V-BELT GP 136
136
CCOOOOLLIINNGG SSYYSSTTEEMM
CAP-PRESSURE (7-PSI) (COOLANT) 449-2872 1 TANK GP-COOLANT 255
255CAP-PRESSURE (7-PSI) (EXPANSION
TANK)
230-5119 1 TANK GP-COOLANT 251
251 1 TANK GP-COOLANT 253
253 1 TANK GP-EXPANSION 256
256GASKET 225-7944 2 COOLER GP-FLTR BASE & ENG OIL 166
166 2 COOLER GP-FLTR BASE & ENG OIL 167
167 2 COOLER GP-FLTR BASE & ENG OIL 168
168 2 COOLER GP-FLTR BASE & ENG OIL 170
170HOSE-RADIATOR 266-2815 2 RADIATOR GP 247
247PLUG-DRAIN 288-4588 1 HOSE GP-RADIATOR 179
179 1 RADIATOR AS 245
245 1 RADIATOR GP 249
249 1 RADIATOR GP 250
250REGULATOR AS-WATER
TEMPERATURE (CONNECTOR
INCLUDED)
254-2268 1 CONNECTION GP-WATER 157
157REGULATOR GP-TEMPERATURE
(INCLUDES CONNECTOR) (WATER)
254-2267 1 CONNECTION GP-WATER 160
160REGULATOR-WATER TEMPERATURE
(82-DEG C)
297-5844 1 LINES GP-WATER 208
208 1 LINES GP-WATER 209
209STRAINER 193-5105 1 LINES GP-WATER 232
232STRAINER (INLET) 193-5105 1 LINES GP-WATER 215
215
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
CIRCUIT BREAKER (10-AMPERE) 274-1239 1 WIRING GP-ENGINE 458
458 1 WIRING GP-ENGINE 462
462 1 WIRING GP-ENGINE 464
464 1 WIRING GP-INSTR & IGNITION 468
468 1 WIRING GP-INSTR & IGNITION 470
470 1 WIRING GP-SHUTOFF 474
474CIRCUIT BREAKER (80-AMPERE) 274-1240 1 WIRING GP-ENGINE 458
458 1 WIRING GP-ENGINE 462
DDEESSCCRRIIPPTTIIOONN
PPAARRTT
NNUUMMBBEERR QQTTYY WWHHEERREE UUSSEEDD PPAAGGEE
MMAAIINNTTEENNAANNCCEE PPAARRTTSS
AA1100 MAINTENANCE PARTS SEBP4152-48
462 1 WIRING GP-ENGINE 464
464 1 WIRING GP-INSTR & IGNITION 468
468 1 WIRING GP-INSTR & IGNITION 470
470 1 WIRING GP-SHUTOFF 474
474FUSE (5-AMPERE) 274-1237 1 WIRING GP-ENGINE 458
458 1 WIRING GP-ENGINE 462
462 1 WIRING GP-ENGINE 464
464 1 WIRING GP-INSTR & IGNITION 468
468 1 WIRING GP-INSTR & IGNITION 470
470 1 WIRING GP-SHUTOFF 474
474FUSE (6.5-AMPERE) 215-1262 3 HARNESS AS-PANEL 408
408 3 WIRING GP-PANEL 472
472 3 WIRING GP-PANEL 473
473GLOW PLUG (12-VOLT) 232-6662 4 GLOW PLUG GP 406
406GLOW PLUG (24-VOLT) 226-8770 4 GLOW PLUG GP 407
407KEY (BATTERY DISCONNECT) 8H-5306 1 SWITCH GP-DISCONNECT 438
438KEY-LOCK (CIRCUIT BREAKER) 290-5533 1 WIRING GP-ENGINE 458
458 1 WIRING GP-ENGINE 462
462RELAY (12-VOLT) 307-4517 3 WIRING GP-ENGINE 458
458
FFUUEELL SSYYSSTTEEMM
CAP 232-1328 1 PUMP GP-FUEL INJECTION 364
364 1 PUMP GP-FUEL INJECTION 370
370 1 PUMP GP-FUEL INJECTION 373
373 1 PUMP GP-FUEL INJECTION 377
377FILTER AS-FUEL (PRIMARY) 367-1814 1 FILTER & LINES GP-FUEL 320
320 1 FILTER & LINES GP-FUEL 321
321FILTER ELEMENT-FUEL 250-6527 1 FILTER & LINES GP-FUEL 321
321FILTER-FUEL 287-6052 2 FILTER & LINES GP-FUEL 323
323 2 FILTER & LINES GP-FUEL 325
325 2 FILTER GP-FUEL 327
327 2 FILTER GP-FUEL 329
329 2 FILTER GP-FUEL 331
331PLUG-DRAIN 288-4588 1 BRACKET GP-MOUNTING 319
319PLUG-DRAIN (FUEL FILTER) 205-3041 1 FILTER & LINES GP-FUEL 321
321PLUG-DRAIN (SPILL PROTECTION) 288-4588 1 FILTER & LINES GP-FUEL 323
323 1 FILTER & LINES GP-FUEL 325
325
LLUUBBRRIICCAATTIIOONN SSYYSSTTEEMM
BREATHER AS (CRANKCASE) 262-1044 1 BREATHER GP 144
144 1 BREATHER GP 145
145 1 BREATHER GP 146
146 1 BREATHER GP 147
147 1 BREATHER GP 148
148FILTER AS-ENGINE OIL 7W-2326 1 FILTER GP-ENGINE OIL 150
150FILTER ELEMENT-BREATHER
(CRANKCASE)
229-3555 1 BREATHER GP 144
144 1 BREATHER GP 145
DDEESSCCRRIIPPTTIIOONN
PPAARRTT
NNUUMMBBEERR QQTTYY WWHHEERREE UUSSEEDD PPAAGGEE
MMAAIINNTTEENNAANNCCEE PPAARRTTSS
SEBP4152-48 MAINTENANCE PARTS AA1111
145 1 BREATHER GP 146
146 1 BREATHER GP 147
147 1 BREATHER GP 148
148FILTER-ENGINE OIL 081-4661 2 FILTER GP-ENGINE OIL 151
151 2 FILTER GP-ENGINE OIL 152
152
OOPPEERRAATTOORR SSTTAATTIIOONN
CIRCUIT BREAKER (10-AMPERE) 371-3981 3 PANEL GP-ELECTRONIC 581
581 3 PANEL GP-ELECTRONIC 583
583CIRCUIT BREAKER (80-AMPERE) 274-1240 1 PANEL GP-ELECTRONIC 581
581 1 PANEL GP-ELECTRONIC 583
583FUSE (5-AMPERE) 198-4212 2 PANEL GP-ELECTRONIC 581
581 2 PANEL GP-ELECTRONIC 583
583KEY-LOCK (CIRCUIT BREAKER) 290-5533 1 PANEL GP-ELECTRONIC 581
581 1 PANEL GP-ELECTRONIC 583
583LAMP (12-VOLT, 2-WATT) 271-2724 2 PANEL AS-CONTROL 552
552 2 PANEL AS-CONTROL 553
553LAMP (24-VOLT, 2-WATT) 271-2723 2 PANEL AS-CONTROL 551
551 2 PANEL AS-CONTROL 554
554LAMP-LED (12-VOLT, AMBER) 317-4945 3 PANEL GP-ELECTRONIC 581
581LAMP-LED (24-VOLT, AMBER) 317-4959 3 PANEL GP-ELECTRONIC 583
583PLUG-DRAIN 288-4588 1 MOUNTING GP-CONTROL 543
543
DDEESSCCRRIIPPTTIIOONN
PPAARRTT
NNUUMMBBEERR QQTTYY WWHHEERREE UUSSEEDD PPAAGGEE
MMAAIINNTTEENNAANNCCEE PPAARRTTSS
AA1122 INDEX SEBP4152-48
A
ACTUATOR GP-GOVERNOR . . . . . . . . . . . . . . . . . . 341
344
348
351
354
357
360
364
367
370
373
377
ADAPTER-EXHAUST. . . . . . . . . . . . . . . . . . . . . . . . . . 259
AFTERCOOLER GP . . . . . . . . . . . . . . . . . . . . . . . . . . 260
AIR CLEANER GP . . . . . . . . . . . . . . . . . . . . . . . . . . . 262
263
264
265
266
267
268
269
271
273
274
275
276
ALARM GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 533
534
535
ALTERNATOR AS (24-VOLT). . . . . . . . . . . . . . . . . . 385
ALTERNATOR GP-CHARGING . . . . . . . . . . . . . . . . 384
385
B
BARRING & MOUNTING GP . . . . . . . . . . . . . . . . . . . 20
BASE GP-ENGINE & GENERATOR. . . . . . . . . . . . 476
BOX GP-CONTROL PANEL . . . . . . . . . . . . . . . . . . . 536
BRACKET2 SWITCH-PRESSURE (ENGINE)
4 1 7E-6831 1 SENDER-WATER TEMPERATURE (COOLANT)
5 1 270-6959 1 ADAPTER
6 1 270-6969 1 SENDER-WATER TEMPERATURE (COOLANT)
7 1 236-6056 1 WASHER-SPECIAL
GRAPHIC #1 > g01148363
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 442277
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
291-5828 SENDER GP-TEMP & PRESS
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1906, 7400 i05371641
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 7E-6831 1 SENDER-WATER TEMPERATURE
2 1 210-6962 1 ADAPTER
3 1 433-1846 1 SWITCH-PRESSURE (ENGINE)
4 1 291-5829 1 SWITCH-HIGH TEMPERATURE (COOLANT)
GRAPHIC #1 > g01310573
442288 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
291-5830 SENDER GP-TEMP & PRESS
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1906, 7400 i05371643
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 291-5829 1 SWITCH-HIGH TEMPERATURE (COOLANT)
2 1 210-6962 1 ADAPTER
3 1 433-1846 2 SWITCH-PRESSURE (ENGINE)
4 1 7E-6831 1 SENDER-WATER TEMPERATURE (COOLANT)
5 1 270-6959 1 ADAPTER
6 1 270-6969 1 SENDER-WATER TEMPERATURE (COOLANT)
7 1 236-6056 1 WASHER-SPECIAL
GRAPHIC #1 > g01311062
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 442299
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-1132 SENSOR GP-LIQUID LEVEL–COOLANT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7422 i02540669
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-2372 1 SWITCH-LEVEL (COOLANT)
2 1 236-6056 1 WASHER-SPECIAL
3 1 290-1129 6 STRAP
4 1 290-1128 1 HARNESS AS-WIRING
GRAPHIC #1 > g01279010
443300 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
270-3880 SENSOR GP-SPEED–ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1907 i02623633
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 270-3881 1 SENSOR AS-SPEED (ENGINE)
1 9W-0852 2 PIN-CONNECTOR (14-GA TO 16-GA)
1 102-8802 1 KIT-RECEPTACLE (2-PIN)
(INCLUDES RECEPTACLE AS AND WEDGE)
GRAPHIC #1 > g01148622
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 443311
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
289-6005 SENSOR GP-SPEED–ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1907 i02614911
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-6006 1 SENSOR AS-SPEED (ENGINE)
GRAPHIC #1 > g01274306
443322 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
355-8697 SENSOR GP-TEMPERATURE–EXHAUST
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1906, 1919, 1921, 1922, 1928, 1929 i05128789
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-8696 1 SENSOR-TEMPERATURE (EXHAUST)
2 1 357-7464 1 TRANSMITTER-PRES
M 3 1 213-7489 1 SCREW (M4X0.7X25-MM)
4 1 9B-7233 1 LOCKWASHER
5 1 196-0347 1 WASHER (4.3X8.7X0.8-MM THK)
6 1 370-0338 1 WIRE AS
M - METRIC PART
GRAPHIC #1 > g03329556
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 443333
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
288-6476 SOLENOID GP
S/N: L1K1-UP; S1M1-UP
12-VOLT. ENERGIZED TO STOP
AN ATTACHMENT
SMCS-1467 i05086170
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 206-1515 1 SOLENOID AS
GRAPHIC #1 > g03252656
443344 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
289-2419 STARTING MOTOR GP-AIR
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1451 i02539369
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-2364 1 MOTOR-STARTING
2 1 214-6584 1 SOLENOID (AIR START)
3 1 214-6585 1 HOSE
4 1 289-2396 1 BRACKET
M 5 1 106-8916 2 BOLT (M6X16-MM)
6 1 6I-0918 2 NUT
E 7 1 289-3195 CONDUIT (55-CM)
M 8 1 245-6541 2 BOLT (M5X0.8X12-MM)
9 1 199-1187 2 NUT (M5X0.8-THD)
10 1 289-2397 2 TERMINAL
E 11 1 197-3800 LOOM (67-CM)
12 1 289-2400 1 ADAPTER
13 1 289-2401 2 ADAPTER
14 1 289-2402 1 SILENCER-EXHAUST
15 1 214-6574 2 FITTING
16 1 217-7843 1 CAP
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01274104
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 443355
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
289-2420 STARTING MOTOR GP-AIR
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-1451 i02539362
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-2364 1 MOTOR-STARTING
2 1 214-6593 1 SOLENOID (STARTING MOTOR) (STARTER)
3 1 214-6585 1 HOSE
4 1 289-2396 1 BRACKET
M 5 1 106-8916 2 BOLT (M6X16-MM)
6 1 6I-0918 2 NUT
E 7 1 289-3195 CONDUIT (55-CM)
M 8 1 245-6541 2 BOLT (M5X0.8X12-MM)
9 1 199-1187 2 NUT (M5X0.8-THD)
10 1 289-2397 2 TERMINAL
E 11 1 197-3800 LOOM (67-CM)
12 1 289-2400 1 ADAPTER
13 1 289-2401 2 ADAPTER
14 1 289-2402 1 SILENCER-EXHAUST
15 1 214-6574 2 FITTING
16 1 217-7843 1 CAP
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01273642
443366 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-7371 STARTING MOTOR GP-ELECTRIC
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1453 i05218300
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 370-4011 1 MOTOR-STARTING
GRAPHIC #1 > g01148783
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 443377
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
269-7374 STARTING MOTOR GP-ELECTRIC
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-1453 i02290996
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 269-7368 1 MOTOR-STARTING
GRAPHIC #1 > g01148783
443388 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
7N-0718 SWITCH GP-DISCONNECT–BATTERY
S/N: L1K1-UP; S1M1-UP
PART OF 380-5787, 380-5788 PANEL GP-ELECTRONIC, 290-5538, 290-6413, 293-6298 WIRING
GP-ENGINE, 274-1241, 274-1871 WIRING GP-INSTR & IGNITION, 293-8098 WIRING GP-SHUTOFF
AN ATTACHMENT
SMCS-1411 i02516999
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 8H-5306 1 KEY (BATTERY DISCONNECT)
2 1 8H-5303 1 NUT (3/4-16-THD)
3 1 2H-3922 2 LOCKWASHER
4 1 9F-5644 2 LOCKWASHER
5 1 6F-7045 2 NUT-FULL (3/8-24-THD)
GRAPHIC #1 > g00715584
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 443399
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
281-2371 SWITCH GP-LIQUID LEVEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7422 i02615458
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-2372 1 SWITCH-LEVEL (COOLANT)
2 1 236-6056 1 WASHER-SPECIAL
GRAPHIC #1 > g01260127
444400 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
297-1324 SWITCH GP-LIQUID LEVEL
S/N: D1K1-UP; S1M1-UP
FOR USE WITH MCS APPROVED RADIATOR COOLED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-7422 i02637266
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERRQQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 297-1325 1 BRACKET-MOUNTING
M 2 1 6I-4200 1 BOLT (M10X1.5X16-MM)
3 1 297-1326 1 ADAPTER
4 1 236-6056 1 WASHER-SPECIAL
5 1 281-2372 1 SWITCH-LEVEL (COOLANT)
6 1 193-5187 1 COUPLING-HOSE
7 1 193-5158 3 FITTING (1/4)
E 8 1 5P-1465 HOSE (41-CM)
E 8A 1 5P-1465 HOSE (103-CM)
9 1 297-1327 1 HARNESS AS-SWITCH
10 1 205-8712 2 CLIP
11 1 301-1039 1 ELBOW
12 1 290-1129 1 STRAP
13 1 213-7483 1 ADAPTER
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g01479213
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 444411
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3146 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288942
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6241 1 TRANSFORMER
GRAPHIC #1 > g01157914
444422 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3147 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288962
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 215-7473 3 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 444433
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3150 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02312171
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6238 1 TRANSFORMER
GRAPHIC #1 > g01157916
444444 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3152 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288965
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6240 3 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 444455
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3178 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288969
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 215-7471 3 TRANSFORMER
GRAPHIC #1 > g01157916
444466 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3188 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288972
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6239 1 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 444477
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3199 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288973
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6237 1 TRANSFORMER
GRAPHIC #1 > g01157916
444488 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
268-3235 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02288976
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 215-7472 3 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 444499
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
272-0518 TRANSFORMER GP-CURRENT
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY
AN ATTACHMENT
SMCS-4476 i02305969
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-0519 1 TRANSFORMER
2 1 272-0520 3 TRANSFORMER
GRAPHIC #1 > g01155723
445500 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
276-5177 TRANSFORMER GP-CURRENT
S/N: S1M1-UP
FOR USE WITH THE C4.4 TA MARINE GENSET PACKAGE.
AN ATTACHMENT
SMCS-4476 i02363199
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 276-5179 3 TRANSFORMER
GRAPHIC #1 > g01193330
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 445511
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
276-5178 TRANSFORMER GP-CURRENT
S/N: S1M1-UP
FOR USE WITH THE C4.4 TA MARINE GENSET PACKAGE.
AN ATTACHMENT
SMCS-4476 i02363201
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 276-5181 1 TRANSFORMER
GRAPHIC #1 > g01193330
445522 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-1855 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02516094
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6238 3 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 445533
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-1856 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02516101
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6239 3 TRANSFORMER
GRAPHIC #1 > g01157916
445544 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-1857 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02516129
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6237 3 TRANSFORMER
GRAPHIC #1 > g01157916
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 445555
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-1858 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02516130
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-6241 3 TRANSFORMER
GRAPHIC #1 > g01157914
445566 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
287-1859 TRANSFORMER GP-CURRENT
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4476 i02516131
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 276-5181 3 TRANSFORMER
GRAPHIC #1 > g01193330
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 445577
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-5529 WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1000, 1408 i02540688
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-4200 1 BOLT (M10X1.5X16-MM)
2 1 195-4615 3 STRAP
3 1 290-1129 19 STRAP
4 1 290-5534 3 CAP
5 1 290-5535 1 INSERT
M 6 1 6I-0594 2 NUT (M10X1.5-THD)
M 7 1 100-4830 2 BOLT (M10X1.5X20-MM)
8 1 290-5537 1 HARNESS AS-WIRING
Y 9 1 290-5538 1 WIRING GP-ENGINE 458
M - METRIC PART
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01277844
445588 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-5538WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
PART OF 290-5529 WIRING GP-ENGINE
AN ATTACHMENT
SMCS-1000, 1408 i02680980
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 8T-0337 14 SCREW-MACHINE (M4X0.7X12-MM)
2 1 9B-7233 15 LOCKWASHER
3 1 307-4517 3 RELAY (12-VOLT)
4 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
5 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
Y 6 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
7 1 196-0346 2 WASHER (19X10X1.9-MM THK)
8 1 195-4677 1 SCREW-MACHINE (M4X0.7X16-MM)
M 9 1 095-0733 1 SCREW-MACHINE (M4X0.7X40-MM)
10 1 290-5533 1 KEY-LOCK (CIRCUIT BREAKER)
M 11 1 8T-0265 4 SCREW-MACHINE (M3X0.5X16-MM)
12 1 199-1191 4 WASHER (3.3X7X0.8-MM THK)
13 1 196-0327 4 LOCKNUT (M3X0.5-THD)
14 1 274-1237 1 FUSE (5-AMPERE)
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 445599
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-5538 WIRING GP-ENGINE (ccoonnttdd..) i02680980
GRAPHIC #1 > g01605514
446600 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-6411 WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1000, 1408 i02566186
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-4200 1 BOLT (M10X1.5X16-MM)
2 1 195-4615 3 STRAP
3 1 290-1129 19 STRAP
4 1 290-5534 3 CAP
5 1 290-5535 1 INSERT
M 6 1 6I-0594 2 NUT (M10X1.5-THD)
M 7 1 100-4830 2 BOLT (M10X1.5X20-MM)
8 1 290-6412 2 RESISTOR
9 1 290-5537 1 HARNESS AS-WIRING (CIRCUIT BREAKER)
Y 10 1 290-6413 1 WIRING GP-ENGINE 462
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 446611
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-6411 WIRING GP-ENGINE (ccoonnttdd..) i02566186
GRAPHIC #1 > g01278668
446622 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-6413 WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
PART OF 290-6411 WIRING GP-ENGINE
AN ATTACHMENT
SMCS-1000, 1408 i02655803
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 8T-0337 14 SCREW-MACHINE (M4X0.7X12-MM)
2 1 9B-7233 15 LOCKWASHER
3 1 243-4632 3 RELAY-GLOW PLUG
4 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
5 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
Y 6 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
7 1 196-0346 2 WASHER (19X10X1.9-MM THK)
8 1 195-4677 1 SCREW-MACHINE (M4X0.7X16-MM)
M 9 1 095-0733 1 SCREW-MACHINE (M4X0.7X40-MM)
10 1 290-5533 1 KEY-LOCK (CIRCUIT BREAKER)
11 1 196-7691 4 SCREW (M3X16-MM)
12 1 199-1191 4 WASHER (3.3X7X0.8-MM THK)
13 1 196-0327 4 LOCKNUT (M3X0.5-THD)
14 1 274-1237 1 FUSE (5-AMPERE)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 446633
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
290-6413 WIRING GP-ENGINE (ccoonnttdd..) i02655803
GRAPHIC #1 > g01276465
446644 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
293-6298 WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1000, 1408 i05307951
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 431-9532 1 HARNESS AS-ENGINE
Y 2 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
3 1 274-1232 1 HARNESS AS-WIRING
4 1 274-1231 1 HARNESS AS-WIRING
5 1 274-1230 1 BRACKET
6 1 144-3852 1 FILM-INFORMATION (BATTERY POWER DISCONNECT)
7 1 6I-0631 6 BOLT (M6X1X12-MM)
8 1 293-7210 1 BRACKET
9 1 196-7715 1 CLIP
10 1 274-1237 1 FUSE (5-AMPERE)
M 11 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 12 1 6I-0594 2 NUT (M10X1.5-THD)
13 1 243-4628 2 RELAY (START)
14 1 243-4632 3 RELAY-GLOW PLUG (24-VOLT)
15 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
16 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
17 1 196-0346 1 WASHER (19X10X1.9-MM THK)
18 1 100-4458 1 BOLT (M8X1.25X14-MM)
19 1 195-4615 4 STRAP
20 1 196-0384 1 TIE-CABLE
21 1 8Q-2778 1 TIE-CABLE
22 1 274-1228 1 BRACKET
M 23 1 6I-4200 1 BOLT (M10X1.5X16-MM)
24 1 169-2876 1 FILM-IDENTIFICATION (POWER RECEPTACLE, 12-
VOLT)
25 1 272-0506 1 CONVERTER AS
26 1 196-7708 3 LOCKNUT (M5X0.8-THD)
27 1 196-7728 3 WASHER (5.1X11X1.3-MM THK)
28 1 193-5189 3 SCREW (M5X0.8X12-MM)
29 1 263-8001 1 CLIP
30 1 263-7999 1 CLIP
M 31 1 245-6541 1 BOLT (M5X0.8X12-MM)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 446655
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
293-6298 WIRING GP-ENGINE (ccoonnttdd..) i05307951
GRAPHIC #1 > g01277679
446666 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
367-0552 WIRING GP-ENGINE
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1000, 1408 i05165161
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 326-8646 1 HARNESS AS-ENGINE
GRAPHIC #1 > g03340543
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 446677
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-1989 WIRING GP-GENERATOR
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1404, 1408, 4459 i02319548
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 274-1991 1 HARNESS AS-ENGINE
GRAPHIC #1 > g01160630
446688 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-1241 WIRING GP-INSTR & IGNITION
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-1408, 1550, 7451 i05305523
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 431-9532 1 HARNESS AS-ENGINE
Y 2 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
3 1 274-1232 1 HARNESS AS-WIRING
4 1 274-1231 1 HARNESS AS-WIRING
5 1 274-1230 1 BRACKET
6 1 144-3852 1 FILM-INFORMATION (BATTERY POWER DISCONNECT)
7 1 6I-0631 6 BOLT (M6X1X12-MM)
8 1 274-1229 1 BRACKET
9 1 196-7715 1 CLIP
10 1 274-1237 1 FUSE (5-AMPERE)
M 11 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 12 1 6I-0594 2 NUT (M10X1.5-THD)
13 1 232-6567 2 RELAY AS (12-VOLT)
14 1 225-4956 3 RELAY-POWER
15 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
16 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
17 1 196-0346 1 WASHER (19X10X1.9-MM THK)
18 1 100-4458 1 BOLT (M8X1.25X14-MM)
19 1 195-4615 2 STRAP
20 1 196-0384 1 TIE-CABLE
21 1 8Q-2778 1 TIE-CABLE
22 1 274-1228 1 BRACKET
M 23 1 6I-4200 1 BOLT (M10X1.5X16-MM)
24 1 263-8001 1 CLIP
25 1 263-7999 1 CLIP
M 26 1 245-6541 2 BOLT (M5X0.8X12-MM)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 446699
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-1241 WIRING GP-INSTR & IGNITION (ccoonnttdd..) i05305523
GRAPHIC #1 > g01189982
447700 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-1871 WIRING GP-INSTR & IGNITION
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-1408, 1550, 7451 i05307970
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 431-9532 1 HARNESS AS-ENGINE
Y 2 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
3 1 274-1232 1 HARNESS AS-WIRING
4 1 274-1231 1 HARNESS AS-WIRING
5 1 274-1230 1 BRACKET
6 1 144-3852 1 FILM-INFORMATION (BATTERY POWER DISCONNECT)
7 1 6I-0631 6 BOLT (M6X1X12-MM)
8 1 274-1229 1 BRACKET
9 1 196-7715 1 CLIP
10 1 274-1237 1 FUSE (5-AMPERE)
M 11 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 12 1 6I-0594 2 NUT (M10X1.5-THD)13 1 243-4628 2 RELAY (START, 24-VOLT)
14 1 243-4632 3 RELAY-GLOW PLUG (24-VOLT)
15 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
16 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
17 1 196-0346 1 WASHER (19X10X1.9-MM THK)
18 1 100-4458 1 BOLT (M8X1.25X14-MM)
19 1 195-4615 2 STRAP
20 1 196-0384 1 TIE-CABLE
21 1 8Q-2778 1 TIE-CABLE
22 1 274-1228 1 BRACKET
M 23 1 6I-4200 1 BOLT (M10X1.5X16-MM)
24 1 169-2876 1 FILM-IDENTIFICATION (POWER RECEPTACLE, 12-
VOLT)
25 1 272-0506 1 CONVERTER AS
M 26 1 3T-0851 3 LOCKNUT (M5X0.8-THD)
27 1 196-7728 3 WASHER (5.1X11X1.3-MM THK)
28 1 193-5189 3 SCREW (M5X0.8X12-MM)
29 1 263-8001 1 CLIP
30 1 263-7999 1 CLIP
M 31 1 245-6541 2 BOLT (M5X0.8X12-MM)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 447711
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
274-1871 WIRING GP-INSTR & IGNITION (ccoonnttdd..) i05307970
GRAPHIC #1 > g01189998
447722 ELECTRICAL AND STARTING SYSTEM 1 of 1 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
273-2451 WIRING GP-PANEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH PREMIUM CONTROL PANELS
AN ATTACHMENT
SMCS-4459 i03636001
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-2452 1 HARNESS AS-PANEL
2 1 215-1262 3 FUSE (6.5-AMPERE)
3 1 273-2461 1 PLATE
4 1 273-2453 1 HARNESS AS-PANEL
M 5 1 178-9983 5 LOCKNUT (M4X0.7-THD)
6 1 196-0347 5 WASHER (4.3X8.7X0.8-MM THK)
7 1 214-9193 4 SCREW (M4X0.7X16-MM)
M - METRIC PART
GRAPHIC #1 > g01263961
SEBP4152-48 1 of 1 ELECTRICAL AND STARTING SYSTEM 447733
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
289-8296 WIRING GP-PANEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4459 i03636005
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 289-8298 1 PLATE
2 1 215-1262 3 FUSE (6.5-AMPERE)
3 1 289-8297 1 HARNESS AS-PANEL
GRAPHIC #1 > g01278999
447744 ELECTRICAL AND STARTING SYSTEM 1 of 2 SEBP4152-48
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
293-8098 WIRING GP-SHUTOFF
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1408, 7418 i05307952
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 431-9532 1 HARNESS AS-ENGINE
Y 2 1 7N-0718 1 SWITCH GP-DISCONNECT (BATTERY) 438
3 1 274-1232 1 HARNESS AS-WIRING
4 1 274-1231 1 HARNESS AS-WIRING
5 1 274-1230 1 BRACKET
6 1 144-3852 1 FILM-INFORMATION (BATTERY POWER DISCONNECT)
7 1 6I-0631 6 BOLT (M6X1X12-MM)
8 1 293-7210 1 BRACKET
9 1 193-5183 1 CLIP
10 1 274-1237 1 FUSE (5-AMPERE)
M 11 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 12 1 6I-0594 2 NUT (M10X1.5-THD)
13 1 232-6567 2 RELAY AS (12-VOLT)
14 1 225-4956 3 RELAY-POWER
15 1 274-1239 1 CIRCUIT BREAKER (10-AMPERE)
16 1 274-1240 1 CIRCUIT BREAKER (80-AMPERE)
17 1 196-0346 1 WASHER (19X10X1.9-MM THK)
18 1 100-4458 1 BOLT (M8X1.25X14-MM)
19 1 195-4615 4 STRAP
20 1 196-0384 1 TIE-CABLE
21 1 8Q-2778 1 TIE-CABLE
22 1 274-1228 1 BRACKET
M 23 1 6I-4200 1 BOLT (M10X1.5X16-MM)
24 1 263-8001 1 CLIP
25 1 263-7999 1 CLIP
M 26 1 245-6541 2 BOLT (M5X0.8X12-MM)
M - METRIC PART
Y - SEPARATE ILLUSTRATION
SEBP4152-48 2 of 2 ELECTRICAL AND STARTING SYSTEM 447755
EELLEECCTTRRIICCAALL AANNDD SSTTAARRTTIINNGG SSYYSSTTEEMM
293-8098 WIRING GP-SHUTOFF (ccoonnttdd..) i05307952
GRAPHIC #1 > g01393987
447766 ENCLOSURES, GUARDS AND BASES 1 of 1 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
263-3782 BASE GP-ENGINE & GENERATOR
S/N: L1K1-UP; S1M1-UP
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR, 284-5271, 284-5272, 284-5273, 284-
5274, 284-5275, 290-9639 GENERATOR AR
AN ATTACHMENT
SMCS-7060 i02286897
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 263-3788 1 BASE AS
GRAPHIC #1 > g01149036
SEBP4152-48 1 of 1 ENCLOSURES, GUARDS AND BASES 447777
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
298-5122 COVER GP-ACCESS
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-726A i02637319
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 298-5124 1 PLATE
M 2 1 124-3815 4 BOLT (M8X16X1.25-MM)
M - METRIC PART
GRAPHIC #1 > g01420732
447788 ENCLOSURES, GUARDS AND BASES 1 of 1 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
298-7829 DUCT GP-ENCLOSURE
S/N: D1K1-UP; S1M1-UP
PART OF 300-2928, 300-2929, 300-2930, 300-2931 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02635352
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 297-5713 1 DUCT AS
2 1 6I-0846 4 BOLT (M6X1X14-MM)
BE 3 1 117-4654 SEAL (112-CM)
B - USE AS REQUIRED
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01345992
SEBP4152-48 1 of 1 ENCLOSURES, GUARDS AND BASES 447799
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
298-7830 DUCT GP-ENCLOSURE
S/N: D1K1-UP; S1M1-UP
PART OF 300-2933, 300-2935, 300-2938, 300-2939 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02635431
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 297-5714 1 DUCT AS
2 1 6I-0846 4 BOLT (M6X1X14-MM)
BE 3 1 117-4654 SEAL (112-CM)
B - USE AS REQUIRED
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01353492
448800 ENCLOSURES, GUARDS AND BASES 1 of 1 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
298-7831 DUCT GP-ENCLOSURE
S/N: D1K1-UP; S1M1-UP
PART OF 300-2942, 300-2945, 300-2947, 300-2948, 300-2949 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02635430
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 297-5715 1 DUCT AS
2 1 6I-0846 4 BOLT (M6X1X14-MM)
BE 3 1 117-4654 SEAL (160-CM)
B - USE AS REQUIRED
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01353510
SEBP4152-48 1 of 1 ENCLOSURES, GUARDS AND BASES 448811
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
298-7832 DUCT GP-ENCLOSURE
S/N: D1K1-UP; S1M1-UP
PART OF 300-2943, 300-2946, 300-2950 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02629209
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 297-5716 1 DUCT AS
2 1 6I-0846 4 BOLT (M6X1X14-MM)
BE 3 1 117-4654 SEAL (160-CM)
B - USE AS REQUIRED
E - ORDER BY THE CENTIMETER
GRAPHIC #1 > g01346044
448822 ENCLOSURES, GUARDS AND BASES 1 of 3 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
299-6930 ENCLOSURE AS-GENERATOR
S/N: D1K1-UP; S1M1-UP
PART OF 300-2930, 300-2931, 300-2938, 300-2939, 300-2947, 300-2949, 300-
2950 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02635418
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-6902 8 SUPPORT
2 1 299-6903 4 SUPPORT
3 1 299-6904 2 SUPPORT
4 1 299-6905 2 SUPPORT
5 1 299-6906 4 SUPPORT
6 2 299-6907 2 SUPPORT
7 2 299-6909 1 SUPPORT
8 1 299-6910 2 PANEL
9 1 299-6911 1 PANEL-SIDE
10 1 299-6912 1 PANEL-SIDE
11 1 299-6913 1 PANEL-SIDE
12 1 299-6914 1 PANEL-TOP
13 1 299-6915 1 PANEL-TOP
14 1 299-6916 1 PANEL
15 1 299-6917 1 PANEL-REAR
16 1 299-6918 1 PANEL-FRONT
17 1 299-6919 4 RETAINER
18 1 299-6920 1 RETAINER
19 1 299-6921 1 BASE AS
20 1 299-6922 1 PANEL
21 1 299-6923 1 PANEL-TOP
22 1 299-6924 1 PANEL-TOP
23 1 298-5124 1 PLATE
24 1 299-6925 13 LATCH AS
M 25 2 124-3815 52 BOLT (M8X1.25X16-MM)
26 2 231-2765 6 BOLT
M 27 2 6I-0291 6 NUT (M8X1.25-THD)
28 2 299-6926 2 BRACKET
M 29 2 095-0755 4 SCREW-MACHINE (M4X0.7X12-MM)
M 30 2 178-9983 4 LOCKNUT (M4X0.7-THD)
31 1 229-8329 1 FILM-IDENTIFICATION (CAT)
32 1 229-8330 2 FILM-IDENTIFICATION(CAT MARINE POWER)
33 1 229-8331 1 FILM-IDENTIFICATION (CATERPILLAR)
34 1 233-6748 1 FILM (FIRE EXTINGUISHER)
M 35 1 102-9941 4 BOLT (M12X1.75X25-MM)
36 1 299-6929 1 BRACKET
37 1 166-5000 2 PLUG
M 38 1 6I-4200 1 BOLT (M10X1.5X16-MM)
M - METRIC PART
SEBP4152-48 2 of 3 ENCLOSURES, GUARDS AND BASES 448833
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
299-6930 ENCLOSURE AS-GENERATOR (ccoonnttdd..) i02635418
GRAPHIC #1 g01346343
448844 ENCLOSURES, GUARDS AND BASES 3 of 3 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
299-6930 ENCLOSURE AS-GENERATOR (ccoonnttdd..) i02635418
GRAPHIC #2 > g01346345
SEBP4152-48 1 of 2 ENCLOSURES, GUARDS AND BASES 448855
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
299-9310 ENCLOSURE AS-GENERATOR
S/N: D1K1-UP; S1M1-UP
PART OF 300-2928, 300-2929, 300-2933, 300-2935, 300-2942, 300-2943, 300-2945, 300-
2946, 300-2948 GENERATOR AR
AN ATTACHMENT
SMCS-7274 i02629196
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 299-6902 8 SUPPORT
2 1 299-6903 4 SUPPORT
3 1 299-6904 2 SUPPORT
4 1 299-6905 2 SUPPORT
5 1 299-6906 4 SUPPORT
6 1 299-6907 2 SUPPORT
7 1 299-6909 1 SUPPORT
8 1 299-6910 2 PANEL
9 1 299-9308 1 PANEL
10 1 299-9309 1 PANEL-SIDE
11 1 299-6913 1 PANEL-SIDE
12 1 299-6914 1 PANEL-TOP
13 1 299-6915 1 PANEL-TOP
14 1 299-6916 1 PANEL
15 1 299-6917 1 PANEL-REAR
16 1 299-6918 1 PANEL-FRONT
17 1 299-6919 4 RETAINER
18 1 299-6920 1 RETAINER
19 1 299-6921 1 BASE AS
20 1 299-6922 1 PANEL
21 1 299-6923 1 PANEL-TOP
22 1 299-6924 1 PANEL-TOP
23 1 299-6925 13 LATCH AS
M 24 1 124-3815 48 BOLT (M8X1.25X16-MM)
25 1 231-2765 6 BOLT
M 26 1 6I-0291 6 NUT (M8X1.25-THD)
27 1 229-8329 1 FILM-IDENTIFICATION (CAT)
28 1 229-8330 2 FILM-IDENTIFICATION (CAT MARINE POWER)
29 1 229-8331 1 FILM-IDENTIFICATION (CATERPILLAR)
30 1 233-6748 1 FILM (FIRE EXTINGUISHER)
M 31 1 102-9941 4 BOLT (M12X1.75X25-MM)
32 1 166-5000 2 PLUG
M - METRIC PART
448866 ENCLOSURES, GUARDS AND BASES 2 of 2 SEBP4152-48
EENNCCLLOOSSUURREESS,, GGUUAARRDDSS AANNDD BBAASSEESS
299-9310 ENCLOSURE AS-GENERATOR (ccoonnttdd..) i02629196
GRAPHIC #1 > g01346244
SEBP4152-48 1 of 1 GENERATORS 448877
GGEENNEERRAATTOORRSS
291-6466 BRACKET GP-MOUNTING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4459, 5258 i03655033
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 342-7555 1 BRACKET-MOUNTING
2 1 6I-0789 2 BOLT (M10X1.5X60-MM)
GRAPHIC #1 > g01274000
448888 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
296-0365 BRACKET GP-MOUNTING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4459, 5258 i02628701
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4583 1 BRACKET
M 2 1 100-4830 4 BOLT (M10X1.5X20-MM)
M - METRIC PART
GRAPHIC #1 > g01354684
SEBP4152-48 1 of 1 GENERATORS 448899
GGEENNEERRAATTOORRSS
284-5271 GENERATOR AR
S/N: S1M1-UP
50 HERTZ
AN ATTACHMENT
SMCS-4450 i02434185
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3304 1 ENGINE AR-COMPLETE 4
Y 265-2849 1 GENERATOR GP 503
Y 266-5347 1 MOUNTING GP-ENGINE & GENERATOR 98
Y - SEPARATE ILLUSTRATION
>
284-5272 GENERATOR AR
S/N: S1M1-UP
60 HERTZ
AN ATTACHMENT
SMCS-4450 i02434276
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3303 1 ENGINE AR-COMPLETE 4
Y 265-2849 1 GENERATOR GP 503
Y 266-5347 1 MOUNTING GP-ENGINE & GENERATOR 98
Y - SEPARATE ILLUSTRATION
>
284-5273 GENERATOR AR
S/N: S1M1-UP
50 HERTZ
AN ATTACHMENT
SMCS-4450 i02434272
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3300 1 ENGINE AR-COMPLETE 2
Y 265-3731 1 GENERATOR GP 506
Y 268-3640 1 MOUNTING GP-ENGINE & GENERATOR 100
Y - SEPARATE ILLUSTRATION
>
449900 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
284-5274 GENERATOR AR
S/N: S1M1-UP
60 HERTZ
AN ATTACHMENT
SMCS-4450 i02434260
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3301 1 ENGINE AR-COMPLETE 3
Y 265-3740 1 GENERATOR GP 507
Y 268-3640 1 MOUNTING GP-ENGINE & GENERATOR 100
Y - SEPARATE ILLUSTRATION
>
284-5275 GENERATOR AR
S/N: S1M1-UP
50 HERTZ
AN ATTACHMENT
SMCS-4450 i02434235
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3302 1 ENGINE AR-COMPLETE 3
Y 265-3740 1 GENERATOR GP 507
Y 268-3640 1 MOUNTING GP-ENGINE & GENERATOR 100
Y - SEPARATE ILLUSTRATION
>
290-9639 GENERATOR AR
S/N: S1M1-UP
60 HERTZ
AN ATTACHMENT
SMCS-4450 i02529142
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-3782 1 BASE GP-ENGINE & GENERATOR 476
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0089 2 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 267-3299 1 ENGINE AR-COMPLETE 2
Y 265-3731 1 GENERATOR GP 506
Y 268-3640 1 MOUNTING GP-ENGINE & GENERATOR 100
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 GENERATORS 449911
GGEENNEERRAATTOORRSS
300-2928 GENERATOR AR
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4450 i02635163
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7829 1 DUCT GP-ENCLOSURE 478
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2929 GENERATOR AR
S/N: D1K1-UP
AN ATTACHMENT
SMCS-4450 i02635371
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7829 1 DUCT GP-ENCLOSURE 478
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2930 GENERATOR AR
S/N: D1K1-UP
FOR USE WITH ENCLOSED C4.4 DINA MARINGE GENSET
AN ATTACHMENT
SMCS-4450 i02635366
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7829 1 DUCT GP-ENCLOSURE 478
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>449922 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
300-2931 GENERATOR AR
S/N: D1K1-UP
AN ATTACHMENT
SMCS-4450 i02635364
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7829 1 DUCT GP-ENCLOSURE 478
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2933 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02638453
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7830 1 DUCT GP-ENCLOSURE 479
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2935 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642371
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7830 1 DUCT GP-ENCLOSURE 479
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 GENERATORS 449933
GGEENNEERRAATTOORRSS
300-2938 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642377
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7830 1 DUCT GP-ENCLOSURE 479
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2939 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642383
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 263-7929 1 COUPLING GP-GENERATOR 27
Y 270-0081 1 COVER GP-ENGINE LIFTING EYE 31
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7830 1 DUCT GP-ENCLOSURE 479
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2115 1 MOUNTING GP-ENGINE & GENERATOR 105
296-5097 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2942 GENERATOR AR
S/N: D1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4450 i02635368
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7831 1 DUCT GP-ENCLOSURE 480
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
449944 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
300-2943 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642387
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7832 1 DUCT GP-ENCLOSURE 481
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2945 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642388
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7831 1 DUCT GP-ENCLOSURE 480
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2946 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642390
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7832 1 DUCT GP-ENCLOSURE 481
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 GENERATORS 449955
GGEENNEERRAATTOORRSS
300-2947 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642391
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7831 1 DUCT GP-ENCLOSURE 480
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2948 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642394
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7831 1 DUCT GP-ENCLOSURE 480
Y 299-9310 1 ENCLOSURE AS-GENERATOR 485
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
300-2949 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642400
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7831 1 DUCT GP-ENCLOSURE 480
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
449966 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
300-2950 GENERATOR AR
S/N: S1M1-UP
AN ATTACHMENT
SMCS-4450 i02642402
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 277-6150 1 COUPLING GP-GENERATOR 28
Y 270-0089 1 COVER GP-ENGINE LIFTING EYE 32
Y 270-1513 1 COVER GP-ENGINE LIFTING EYE 33
Y 298-7832 1 DUCT GP-ENCLOSURE 481
Y 299-6930 1 ENCLOSURE AS-GENERATOR 482
Y 289-9801 1 LIFTING GP-ENGINE 92
Y 300-2114 1 MOUNTING GP-ENGINE & GENERATOR 104
296-5098 1 PLATE
Y - SEPARATE ILLUSTRATION
>
345-3436 GENERATOR AR
S/N: L1K1-UP
AN ATTACHMENT
SMCS-4450 i03632814
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 329-9929 1 ENGINE AR 1
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 2 GENERATORS 449977
GGEENNEERRAATTOORRSS
263-7100 GENERATOR GP
S/N: L1K1-UP
PART OF 263-7105 GENERATOR GP
AN ATTACHMENT
TYPE 1
SMCS-4450 i05136814
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 262-5911 1 FAN
2 1 262-5913 1 BRACKET
3 1 262-5914 1 SCREEN
4 1 375-8194 1 BRACKET
5 1 263-0173 1 ROD
6 1 262-5916 1 BOX-TERMINAL
7 1 262-5917 1 BOX-TERMINAL
8 1 262-5918 1 LID
9 1 262-5919 1 SCREEN-INLET
10 1 262-5921 1 BEARING
11 1 262-5922 1 RING
12 1 262-5923 1 EXCITER
13 1 262-5926 1EXCITER
14 1 262-5927 1 SUPPORT-DIODE
15 1 262-5928 1 PLATE-TERMINAL
16 1 262-6219 1 REGULATOR AS-VOLTAGE (GENERATOR)
17 1 262-5929 1 RUBBER-CUSHION
18 1 262-6213 1 COUPLING
19 1 262-6216 1 DIODE AS
20 1 214-0587 1 DIODE-SURGE SUPPRESSION
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
449988 GENERATORS 2 of 2 SEBP4152-48
GGEENNEERRAATTOORRSS
263-7100 GENERATOR GP (ccoonnttdd..) i05136814
GRAPHIC #1 > g02932358
SEBP4152-48 1 of 1 GENERATORS 449999
GGEENNEERRAATTOORRSS
263-7100 GENERATOR GP
S/N: L1K1-UP
PART OF 263-7105 GENERATOR GP
AN ATTACHMENT
TYPE 2
SMCS-4450 i05865322
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
262-5911 1 FAN
262-5913 1 BRACKET
262-5914 1 SCREEN
375-8194 1 BRACKET
263-0173 1 ROD
262-5916 1 BOX-TERMINAL
262-5917 1 BOX-TERMINAL
262-5918 1 LID
262-5919 1 SCREEN-INLET
262-5921 1 BEARING
262-5922 1 RING
262-5923 1 EXCITER
262-5926 1 EXCITER
262-5927 1 SUPPORT-DIODE
262-5928 1 PLATE-TERMINAL
262-5929 1 RUBBER-CUSHION
262-6216 1 DIODE AS
262-6217 1 VARISTOR
345-0369 1 DISC-COUPLING
>
550000 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
263-7105 GENERATOR GP
S/N: L1K1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES
PART OF 284-5268, 284-5269 GENERAL AR-GENERATOR
AN ATTACHMENT
SMCS-4450 i04672775
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 263-7100 1 GENERATOR GP 497
AVAILABLE REPAIR KIT(S):
263-7101 1 KIT-GENERATOR
(INCLUDES DIODE, REGULATOR, SURGE SUPRESSOR, &
FUSES)
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01158651
SEBP4152-48 1 of 2 GENERATORS 550011
GGEENNEERRAATTOORRSS
265-2843 GENERATOR GP
S/N: L1K1-UP; S1M1-UP
PART OF 265-2849 GENERATOR GP
AN ATTACHMENT
SMCS-4450 i04807431
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 262-5911 1 FAN
2 1 262-5913 1 BRACKET
3 1 262-5914 1 SCREEN
4 1 375-8194 1 BRACKET
5 1 263-0172 1 ROD
6 1 375-8197 1 BOX-TERMINAL
7 1 262-5917 1 BOX-TERMINAL
8 1 262-5918 1 LID
9 1 262-5919 1 SCREEN-INLET
10 1 262-5921 1 BEARING
11 1 262-5922 1 RING
12 1 262-5923 1 EXCITER
13 1 262-5926 1 EXCITER
14 1 262-5927 1 SUPPORT-DIODE
15 1 375-8196 1 PLATE-TERMINAL
16 1 267-9118 1 REGULATOR (VOLTAGE)
17 1 262-5929 1 RUBBER-CUSHION
18 1 345-0369 1 DISC-COUPLING
19 1 262-6216 1 DIODE AS
20 1 214-0587 1 DIODE-SURGE SUPPRESSION
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
550022 GENERATORS 2 of 2 SEBP4152-48
GGEENNEERRAATTOORRSS
265-2843 GENERATOR GP (ccoonnttdd..) i04807431
GRAPHIC #1 > g02932358
SEBP4152-48 1 of 1 GENERATORS 550033
GGEENNEERRAATTOORRSS
265-2849 GENERATOR GP
S/N: L1K1-UP; S1M1-UP
CANNOT BE USED WITH NATRUALLY ASPIRATED AND TURBOCHARGED AND AFTERCOOLED ENGINES
PART OF 284-5271, 284-5272 GENERATOR AR
AN ATTACHMENT
SMCS-4450 i04678370
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 265-2843 1 GENERATOR GP 501
AVAILABLE REPAIR KIT(S):
263-7101 1 KIT-GENERATOR
(INCLUDES DIODE, REGULATOR, SURGE SUPPRESSOR, &
FUSES)
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01158651
550044 GENERATORS 1 of 2 SEBP4152-48
GGEENNEERRAATTOORRSS
265-3728 GENERATOR GP
S/N: S1M1-UP
PART OF 265-3731 GENERATOR GP
AN ATTACHMENT
SMCS-4450 i05293103
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-0587 1 DIODE-SURGE SUPPRESSION
2 1 262-5920 1 DOOR-INSPECTION
3 1 262-5927 1 SUPPORT-DIODE
4 1 262-5929 1 RUBBER-CUSHION
5 1 262-6215 1 SHIM
6 1 262-6216 1 DIODE AS
7 1 263-0152 1 FAN
8 1 263-0154 1 BRACKET
9 1 263-0155 1 SCREEN
10 1 263-0157 1 BOX-CONTROL PANEL
11 1 263-0158 1 BOX-CONTROL PANEL
12 1 263-0160 1 SCREEN-AIR INLET
13 1 263-0161 1 BEARING
14 1 263-0162 1 RING
15 1 263-0163 1 EXCITER
16 1 263-0165 1 ARMATURE
17 1 263-0166 1 TERMINAL
18 1 262-6219 1 REGULATOR AS-VOLTAGE (GENERATOR)
19 1 345-0364 1 COVER-BOX
20 1 357-3165 1 TIE ROD
21 1 375-8199 1 BRACKET
22 1 375-8200 1 DISC-COUPLING
SEBP4152-48 2 of 2 GENERATORS 550055
GGEENNEERRAATTOORRSS
265-3728 GENERATOR GP (ccoonnttdd..) i05293103
GRAPHIC #1 > g03356551
550066 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
265-3731 GENERATOR GP
S/N: S1M1-UP
PART OF 284-5273, 290-9639 GENERATOR AR
AN ATTACHMENT
SMCS-4450 i05293102
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 265-3728 1 GENERATOR GP 504
AVAILABLE REPAIR KIT(S):
263-7101 1 KIT-GENERATOR
(INCLUDES DIODE, REGULATOR, SURGE SUPPRESSOR, &
FUSES)
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01158651
SEBP4152-48 1 of 1 GENERATORS 550077
GGEENNEERRAATTOORRSS
265-3740 GENERATOR GP
S/N: S1M1-UP
PART OF 284-5274, 284-5275 GENERATOR AR
AN ATTACHMENT
SMCS-4450 i03830391
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 265-3739 1 GENERATOR
AVAILABLE REPAIR KIT(S):
263-7101 1 KIT-MAGNET
(INCLUDES DIODE, REGULATOR, SURGE SUPPRESSOR, &
FUSES)
GRAPHIC #1 > g01158651
550088 GENERATORS 1 of 1 SEBP4152-48
GGEENNEERRAATTOORRSS
272-2262 GENERATOR GP
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY
AN ATTACHMENT
SMCS-4450 i03830392
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-2261 1 GENERATOR GP
AVAILABLE REPAIR KIT(S):
263-7101 1 KIT-GENERATOR
(INCLUDES DIODE, REGULATOR, SURGE SUPPRESSOR, &
FUSES)
GRAPHIC #1 > g01158651
SEBP4152-48 1 of 1 GENERATORS 550099
GGEENNEERRAATTOORRSS
269-9110 LIFTING GP-GENERATOR
S/N: S1M1-UP; J1Z1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES
AN ATTACHMENT
SMCS-1122, 4450 i02291015
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
M 1 1 6I-0654 4 BOLT (M10X1.5X25-MM)
2 1 269-9111 1 BRACKET-LIFTING
M - METRIC PART
GRAPHIC #1 > g01148626
551100 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
355-8698 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05142169
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-7272 1 HOSE
2 1 355-7273 1 HOSE
3 1 355-7275 2 ADAPTER
GRAPHIC #1 > g03333726
SEBP4152-48 1 of 1 PRIME PACKAGE 551111
PPRRIIMMEE PPAACCKKAAGGEE
355-8705 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05145731
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-7289 1 HOSE
2 1 263-8001 1 CLIP
3 1 263-7999 1 CLIP
4 1 355-7290 1 HOSE
5 1 288-4581 2 ADAPTER
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
GRAPHIC #1 > g03333639
551122 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
357-9073 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05146091
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 245-7692 2 FITTING-FLARED
2 1 263-8001 1 CLIP
3 1 263-7999 1 CLIP
4 1 355-8311 1 HOSE AS
5 1 355-8312 1 HOSE AS
GRAPHIC #1 > g03334042
SEBP4152-48 1 of 1 PRIME PACKAGE 551133
PPRRIIMMEE PPAACCKKAAGGEE
357-9074 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05146109
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 245-7692 2 FITTING-FLARED
2 1 263-8001 5CLIP
3 1 263-7999 5 CLIP
4 1 310-8318 1 HOSE AS
5 1 355-8313 1 HOSE AS
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
GRAPHIC #1 > g03334265
551144 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
367-0548 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05165139
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 357-6813 2 ADAPTER
2 1 364-5161 1 HOSE
3 1 364-5162 1 HOSE
4 1 263-8001 2 CLIP
5 1 263-7999 2 CLIP
GRAPHIC #1 > g03360051
SEBP4152-48 1 of 1 PRIME PACKAGE 551155
PPRRIIMMEE PPAACCKKAAGGEE
367-2779 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05165166
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 357-6813 2 ADAPTER
2 1 364-5161 1 HOSE
3 1 367-2784 1 HOSE
4 1 263-8001 2 CLIP
5 1 263-7999 2 CLIP
GRAPHIC #1 > g03355907
551166 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
369-6213 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05119273
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 357-6813 2 ADAPTER
2 1 369-6214 1 HOSE
3 1 369-6215 1 HOSE
4 1 263-8001 1 CLIP
5 1 263-7999 1 CLIP
GRAPHIC #1 > g03355836
SEBP4152-48 1 of 1 PRIME PACKAGE 551177
PPRRIIMMEE PPAACCKKAAGGEE
369-6216 HOSE GP-TRANSFER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7554 i05119312
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 357-6813 2 ADAPTER
2 1 369-6217 1 HOSE
3 1 369-6218 1 HOSE
4 1 263-8001 2 CLIP
5 1 263-7999 2 CLIP
GRAPHIC #1 > g03355834
551188 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
268-9177 LINES GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES, SINGLE STARTER MOTOR ENGINES
AN ATTACHMENT
SMCS-1296, 1383 i02290052
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 214-0695 1 HOSE (0.016X0.74-M)
3 1 214-0696 1 HOSE (0.016X0.5-M)
4 1 195-4615 1 STRAP
5 1 6I-0917 4 BOLT (M6X1X25-MM)
6 1 6I-0918 4 NUT
GRAPHIC #1 > g01148018
SEBP4152-48 1 of 2 PRIME PACKAGE 551199
PPRRIIMMEE PPAACCKKAAGGEE
270-6888 LINES GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY, TWIN STARTER MOTOR ENGINES ONLY
AN ATTACHMENT
SMCS-1296, 1383 i02421620
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 214-7272 1 HOSE
3 1 270-6872 1 HOSE
4 1 195-4615 1 STRAP
5 1 6I-0631 4 BOLT (M6X1X12-MM)
6 1 6I-0918 4 NUT
7 1 263-8001 1 CLIP
8 1 279-1526 1 CLIP
552200 PRIME PACKAGE 2 of 2 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
270-6888 LINES GP-HEATER (ccoonnttdd..) i02421620
GRAPHIC #1 > g01263928
SEBP4152-48 1 of 2 PRIME PACKAGE 552211
PPRRIIMMEE PPAACCKKAAGGEE
271-0190 LINES GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED ENGINES, TWIN STARTER MOTOR ENGINES
AN ATTACHMENT
SMCS-1296, 1383 i02291572
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 214-7270 1 HOSE
3 1 270-6872 1 HOSE
4 1 195-4615 1 STRAP
5 1 6I-0631 4 BOLT (M6X1X12-MM)
6 1 6I-0918 4 NUT
7 1 214-0699 1 CLIP
552222 PRIME PACKAGE 2 of 2 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
271-0190 LINES GP-HEATER (ccoonnttdd..) i02291572
GRAPHIC #1 > g01148343
SEBP4152-48 1 of 1 PRIME PACKAGE 552233
PPRRIIMMEE PPAACCKKAAGGEE
271-1336 LINES GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH HEAT EXCHANGER COOLED, SINGLE STARTER MOTOR ENGINES FITTED WITH A WATER
JACKET HEATER
CANNOT BE USED WITH KEEL COOLED OR TWIN STARTER MOTOR ENGINES
AN ATTACHMENT
SMCS-1296, 1383 i02309227
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 270-6872 1 HOSE
3 1 214-0696 1 HOSE (0.016X0.5-M)
4 1 195-4615 1 STRAP
5 1 6I-0917 4 BOLT (M6X1X25-MM)
6 1 6I-0918 4 NUT
7 1 214-0699 1 CLIP
GRAPHIC #1 > g01157336
552244 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
292-2304 LINES GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i02540717
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-0694 1 BRACKET
2 1 214-0697 1 ADAPTER
3 1 214-0698 1 ADAPTER
M 4 1 102-9941 4 BOLT (M12X1.75X25-MM)
M - METRIC PART
GRAPHIC #1 > g01273943
SEBP4152-48 1 of 1 PRIME PACKAGE 552255
PPRRIIMMEE PPAACCKKAAGGEE
292-2308 LINES GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i02540719
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-7269 1 BRACKET
2 1 214-0697 1 ADAPTER
3 1 214-0698 1 ADAPTER
M 4 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
GRAPHIC #1 > g01274125
552266 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
355-5425 LINES GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i05072558
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
E 2 1 6V-8843 HOSE (92-CM)
E 2A 1 6V-8843 HOSE (85-CM)
3 1 195-4615 1 STRAP
4 1 6I-0631 4 BOLT (M6X1X12-MM)
5 1 6I-0918 4 NUT
6 1 214-0699 1 CLIP
M 7 1 124-3815 1 BOLT (M8X1.25X16-MM)
M 8 1 6I-0291 1 NUT (M8X1.25-THD)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g03356708
SEBP4152-48 1 of 1 PRIME PACKAGE 552277
PPRRIIMMEE PPAACCKKAAGGEE
355-5427 LINES GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i05072641
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
E 2 1 6V-8843 HOSE (85-CM EACH)
3 1 195-4615 1 STRAP
4 1 6I-0631 4 BOLT (M6X1X12-MM)
5 1 6I-0918 4 NUT
6 1 214-0699 1 CLIP
M 7 1 124-3815 1 BOLT (M8X1.25X16-MM)
M 8 1 6I-0291 1 NUT (M8X1.25-THD)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g03356765
552288 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
355-5458 LINES GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i05072833
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
E 2 1 6V-8843 HOSE (100-CM)
E 2A 1 6V-8843 HOSE (85-CM)
3 1 195-4615 1 STRAP
4 1 6I-0631 4 BOLT (M6X1X12-MM)
5 1 6I-0918 4 NUT
6 1 214-0699 1 CLIP
M 7 1 124-3815 1 BOLT (M8X1.25X16-MM)
M 8 1 6I-0291 1 NUT (M8X1.25-THD)
E - ORDER BY THE CENTIMETER
M - METRIC PART
GRAPHIC #1 > g03356889
SEBP4152-48 1 of 1 PRIME PACKAGE 552299
PPRRIIMMEE PPAACCKKAAGGEE
268-9203 MOUNTING GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES, SINGLE STARTER MOTOR ENGINES
AN ATTACHMENT
SMCS-1296, 1383 i02290168
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-0694 1 BRACKET (MOUNTING)
2 1 214-0697 1 ADAPTER
3 1 214-4131 1 ADAPTER
M 4 1 102-9941 4 BOLT (M12X1.75X25-MM)
M - METRIC PART
GRAPHIC #1 > g01147835
553300 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
270-8356 MOUNTING GP-HEATER–WATER JACKET
S/N: L1K1-UP; S1M1-UP
FOR USE WITH KEEL COOLED ENGINES ONLY, TWIN STARTER MOTORENGINES ONLY
AN ATTACHMENT
SMCS-1296, 1383 i02291542
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 214-7269 1 BRACKET
2 1 214-0697 1 ADAPTER
3 1 214-4131 1 ADAPTER
M 4 1 102-9941 2 BOLT (M12X1.75X25-MM)
M - METRIC PART
GRAPHIC #1 > g01148599
SEBP4152-48 1 of 1 PRIME PACKAGE 553311
PPRRIIMMEE PPAACCKKAAGGEE
292-2307 MOUNTING GP-HEATER
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-1296, 1383 i02540718
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 214-7270 1 HOSE
3 1 214-0696 1 HOSE (0.016X0.5-M)
4 1 195-4615 1 STRAP
5 1 6I-0917 4 BOLT (M6X1X25-MM)
M 6 1 102-9941 4 BOLT (M12X1.75X25-MM)
M 7 1 6I-0217 1 BOLT (M8X1.25X20-MM)
8 1 214-0699 2 CLIP
M 9 1 6I-0291 1 NUT (M8X1.25-THD)
M - METRIC PART
GRAPHIC #1 > g01273991
553322 PRIME PACKAGE 1 of 1 SEBP4152-48
PPRRIIMMEE PPAACCKKAAGGEE
292-2309 MOUNTING GP-HEATER
S/N: L1K1-UP; S1M1-UP
FOR USE WITH RADIATOR COOLED, TWIN STARTER
AN ATTACHMENT
SMCS-1296, 1383 i02540720
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 5D-1026 4 CLAMP-BAND
2 1 214-4132 1 HOSE (0.016X1-M)
3 1 270-6872 1 HOSE
4 1 195-4615 1 STRAP
5 1 6I-0631 4 BOLT (M6X1X12-MM)
M 6 1 102-9941 4 BOLT (M12X1.75X25-MM)
M 7 1 6I-0217 1 BOLT (M8X1.25X20-MM)
8 1 214-0699 2 CLIP
M 9 1 6I-0291 1 NUT (M8X1.25-THD)
M - METRIC PART
GRAPHIC #1 > g01274135
SEBP4152-48 1 of 1 OPERATOR STATION 553333
OOPPEERRAATTOORR SSTTAATTIIOONN
288-6468 ALARM GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7400, 7407 i02529742
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 174-0503 1 KIT-CONNECTING PLUG (3-PIN)
(INCLUDES PLUG AS AND WEDGE)
2 1 3E-3371 1 WEDGE-RECEPTACLE LOCK (3-PIN)
3 1 186-3736 2 SOCKET-CONNECTOR (16-GA TO 18-GA)
4 1 8T-8737 1 PLUG-SEAL
5 1 288-6466 1 HORN
GRAPHIC #1 > g01270053
553344 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
357-6878 ALARM GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7400, 7407 i05140435
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 281-1300 1 VALVE
2 1 357-6877 1 TRANSMITTER-PRES
3 1 9T-4057 2 SEAL-O-RING
M 4 1 295-4155 4 BOLT-SOCKET HEAD (M5X0.8X35-MM)
M 5 1 8T-3283 4 BOLT-SOCKET HEAD (M5X0.8X45-MM)
M - METRIC PART
GRAPHIC #1 > g03341090
SEBP4152-48 1 of 1 OPERATOR STATION 553355
OOPPEERRAATTOORR SSTTAATTIIOONN
377-2851 ALARM GP
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7400, 7407 i05140443
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 309-0715 1 MANIFOLD GP-FUEL
2 1 281-1301 1 SWITCH-PRESSURE
3 1 9T-4057 2 SEAL-O-RING
M 4 1 295-4155 4 BOLT-SOCKET HEAD (M5X0.8X35-MM)
M 5 1 8T-3283 4 BOLT-SOCKET HEAD (M5X0.8X45-MM)
M - METRIC PART
GRAPHIC #1 > g03355906
553366 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
371-4047 BOX GP-CONTROL PANEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-4490, 7451 i05162529
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 371-4039 1 BOX AS
2 1 371-4040 1 PLATE
3 1 371-4041 1 CONTROLLER
M 4 1 245-6541 4 BOLT (M5X0.8X12-MM)
5 1 8U-7803 6 SCREW
M - METRIC PART
GRAPHIC #1 > g03363407
SEBP4152-48 1 of 1 OPERATOR STATION 553377
OOPPEERRAATTOORR SSTTAATTIIOONN
355-8706 BRACKET GP-MOUNTING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-5258 i05145951
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-7291 1 BRACKET
2 1 290-1231 1 BRACKET
3 1 290-1232 1 BRACKET
M 4 1 245-6541 3 BOLT (M5X0.8X12-MM)
5 1 199-1187 3 NUT (M5X0.8-THD)
PARTS SHOWN IN GRAPHIC(S) WITHOUT A REFERENCE
NUMBER ARE NOT SERVICED SEPARATELY
M - METRIC PART
GRAPHIC #1 > g03333580
553388 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
355-8707 BRACKET GP-MOUNTING
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-5258 i05142115
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 355-7291 1 BRACKET
2 1 290-1231 1 BRACKET
3 1 290-1232 1 BRACKET
4 1 6I-0235 1 BOLT (M12X1.75X50-MM)
M 5 1 6I-1090 2 BOLT (M8X1.25X40-MM)
6 1 270-4176 1 BRACKET-SUPPORT
7 1 210-6899 1 BRACKET
8 1 210-6900 1 BOLT-FLANGE HEAD (M12X1.75X100-MM)
M 9 1 124-3815 2 BOLT (M8X1.25X16-MM)
M 10 1 100-4830 1 BOLT (M10X1.5X20-MM)
M 11 1 6I-0291 4 NUT (M8X1.25-THD)
M 12 1 245-6541 3 BOLT (M5X0.8X12-MM)
13 1 199-1187 3 NUT (M5X0.8-THD)
M 14 1 6I-0217 2 BOLT (M8X1.25X20-MM)
M - METRIC PART
GRAPHIC #1 > g03333389
SEBP4152-48 1 of 1 OPERATOR STATION 553399
OOPPEERRAATTOORR SSTTAATTIIOONN
300-9748 GROMMET GP
S/N: L1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-7553 i02638090
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 231-1350 2 GROMMET
2 1 231-1351 3 GROMMET
GRAPHIC #1 > g01382445
554400 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
300-9749 GROMMET GP
S/N: L1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-7553 i02638088
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 300-9750 1 GROMMET
GRAPHIC #1 > g01382174
SEBP4152-48 1 of 1 OPERATOR STATION 554411
OOPPEERRAATTOORR SSTTAATTIIOONN
272-1568 MOUNTING GP-CONTROL
S/N: S1M1-UP
FOR USE WITH TURBOCHARGED AND AFTERCOOLED ENGINES ONLY
AN ATTACHMENT
SMCS-7451 i02308831
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-1567 1 BRACKET
2 1 204-9535 1 SUPPORT-PANEL
3 1 204-9534 1 SUPPORT-PANEL
M 4 1 100-4830 8 BOLT (M10X1.5X20-MM)
M 5 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 6 1 6I-0594 10 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g01159412
554422 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
308-1187 MOUNTING GP-CONTROL
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-7451 i02746199
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 274-3668 1 BRACKET
2 1 250-1026 1 SUPPORT-PANEL (LH)
3 1 250-1025 1 SUPPORT-PANEL (RH)
M 4 1 100-4830 8 BOLT (M10X1.5X20-MM)
M 5 1 6I-0594 10 NUT (M10X1.5-THD)
M 6 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M - METRIC PART
GRAPHIC #1 > g01400606
SEBP4152-48 1 of 1 OPERATOR STATION 554433
OOPPEERRAATTOORR SSTTAATTIIOONN
367-3314 MOUNTING GP-CONTROL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7451 i05155196
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 288-4583 1 BRACKET
2 1 367-3315 2 SPACER
3 1 288-4585 1 TRAY-DRIP
M 4 1 100-4461 8 BOLT (M10X1.5X50-MM)
M 5 1 245-6541 5 BOLT (M5X0.8X12-MM)
6 1 288-4588 1 PLUG-DRAIN
M 7 1 6I-0594 8 NUT (M10X1.5-THD)
8 1 100-4838 2 BOLT (M6X1X20-MM)
9 1 361-3351 1 SUPPORT-PANEL
10 1 361-3352 1 SUPPORT-PANEL
11 1 367-3316 2 SPACER
M - METRIC PART
GRAPHIC #1 > g03359955
554444 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
272-9238 MOUNTING GP-CONTROL PANEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH REMOTE INSTRUMENT PANELS
AN ATTACHMENT
SMCS-7451 i02305896
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERRQQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 272-9237 1 BRACKET AS
2 1 214-9193 4 SCREW (M4X0.7X16-MM)
3 1 260-6684 4 NUT (M4X0.7-THD)
4 1 196-0347 4 WASHER (4.3X8.7X0.8-MM THK)
M 5 1 095-0755 6 SCREW-MACHINE (M4X0.07X12-MM)
M - METRIC PART
GRAPHIC #1 > g01155711
SEBP4152-48 1 of 1 OPERATOR STATION 554455
OOPPEERRAATTOORR SSTTAATTIIOONN
273-2054 MOUNTING GP-CONTROL PANEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7451 i02319557
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 250-1025 1 SUPPORT-PANEL (RH)
2 1 250-1026 1 SUPPORT-PANEL (LH)
M 3 1 100-4830 4 BOLT (M10X1.5X20-MM)
M 4 1 6I-0594 4 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g01160024
554466 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
274-3666 MOUNTING GP-CONTROL PANEL
S/N: L1K1-UP; S1M1-UP
FOR USE WITH NATURALLY ASPIRATED ENGINES
AN ATTACHMENT
SMCS-7451 i02319551
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 250-1025 1 SUPPORT-PANEL (RH)
2 1 250-1026 1 SUPPORT-PANEL (LH)
M 3 1 100-4830 5 BOLT (M10X1.5X20-MM)
M 4 1 6I-0594 5 NUT (M10X1.5-THD)
5 1 205-1118 1 PLATE
6 1 6I-0631 6 BOLT (M6X1X12-MM)
7 1 6I-0918 6 NUT
8 1 263-5191 1 SPACER (11X19X3-MM THK)
M - METRIC PART
GRAPHIC #1 > g01160621
SEBP4152-48 1 of 2 OPERATOR STATION 554477
OOPPEERRAATTOORR SSTTAATTIIOONN
274-3667 MOUNTING GP-CONTROL PANEL
S/N: S1M1-UP
CANNOT BE USED WITH NATURALLY ASPIRATED ENGINES
AN ATTACHMENT
SMCS-7451 i02319553
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 274-3668 1 BRACKET
2 1 250-1025 1 SUPPORT-PANEL (RH)
3 1 250-1026 1 SUPPORT-PANEL (LH)
M 4 1 100-4830 8 BOLT (M10X1.5X20-MM)
M 5 1 6I-0654 2 BOLT (M10X1.5X25-MM)
M 6 1 6I-0594 10 NUT (M10X1.5-THD)
7 1 205-1118 1 PLATE
8 1 6I-0631 6 BOLT (M6X1X12-MM)
9 1 6I-0918 6 NUT
M - METRIC PART
554488 OPERATOR STATION 2 of 2 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
274-3667 MOUNTING GP-CONTROL PANEL (ccoonnttdd..) i02319553
GRAPHIC #1 > g01160619
SEBP4152-48 1 of 1 OPERATOR STATION 554499
OOPPEERRAATTOORR SSTTAATTIIOONN
361-3350 MOUNTING GP-CONTROL PANEL
S/N: L1K1-UP; S1M1-UP
AN ATTACHMENT
SMCS-7451 i05146212
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 361-3351 1 SUPPORT-PANEL
2 1 361-3352 1 SUPPORT-PANEL
M 3 1 100-4830 4 BOLT (M10X1.5X20-MM)
M 4 1 6I-0594 4 NUT (M10X1.5-THD)
M - METRIC PART
GRAPHIC #1 > g03355831
555500 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
366-0020 PANEL AS
S/N: L1K1-UP; S1M1-UP
PART OF 366-0023, 366-0025 PANEL GP-ELECTRONIC
AN ATTACHMENT
SMCS-7337 i05146530
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 366-0022 1 DOOR AS-ACCESS
2 1 205-3657 1 HINGE AS
M 2A 1 203-5398 4 INSERT-THREADED (M5X0.8-THD)
2B 1 204-8658 1 HINGE
3 1 273-4935 1 PANEL AS-ELECTRICAL
4 1 273-4937 1 PLATE
M 5 1 245-6541 18 BOLT (M5X0.8X12-MM)
M 6 1 178-9983 4 LOCKNUT (M4X0.7-THD)
7 1 196-0347 4 WASHER (4.3X8.7X0.8-MM THK)
M 8 1 6V-9672 4 SCREW-MACHINE (M4X0.7X16-MM)
9 1 273-4359 1 PLATE
10 1 121-4721 1 STRIP-DUST SEAL
M - METRIC PART
GRAPHIC #1 > g03355492
SEBP4152-48 1 of 1 OPERATOR STATION 555511
OOPPEERRAATTOORR SSTTAATTIIOONN
271-2725 PANEL AS-CONTROL
S/N: L1K1-UP; S1M1-UP
24-VOLT
PART OF 271-2727 PANEL GP-CONTROL
AN ATTACHMENT
SMCS-7451 i02624435
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 271-2691 1 PANEL-INSTRUMENT
2 1 256-6504 1 HORN
3 1 271-2702 1 BUTTON
4 1 271-2703 1 SWITCH (START, STOP)
5 1 271-2704 2 CONTACT AS-ELECTRICAL
6 1 271-2721 1 INDICATOR (RED) (ALARM)
7 1 271-2722 1 INDICATOR (GREEN) (ENGINE RUNNING)
8 1 271-2723 2 LAMP (24-VOLT, 2-WATT)
9 1 196-7701 4 SCREW (NO 8X0.75-IN)
10 1 102-8801 1 KIT-RECEPTACLE (12-PIN)
(INCLUDES RECEPTACLE AS AND WEDGE)
GRAPHIC #1 > g01162372
555522 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
271-2726 PANEL AS-CONTROL
S/N: L1K1-UP; S1M1-UP
12-VOLT
PART OF 271-2728 PANEL GP-CONTROL
AN ATTACHMENT
SMCS-7451 i02624442
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 271-2691 1 PANEL-INSTRUMENT
2 1 256-6504 1 HORN
3 1 271-2702 1 BUTTON
4 1 271-2703 1 SWITCH (START, STOP)
5 1 271-2704 2 CONTACT AS-ELECTRICAL
6 1 271-2721 1 INDICATOR (RED) (ALARM)
7 1 271-2722 1 INDICATOR (GREEN) (ENGINE RUNNING)
8 1 271-2724 2 LAMP (12-VOLT, 2-WATT)
9 1 196-7701 4 SCREW (NO 8X0.75-IN)
10 1 102-8801 1 KIT-RECEPTACLE (12-PIN)
(INCLUDES RECEPTACLE AS AND WEDGE)
GRAPHIC #1 > g01156780
SEBP4152-48 1 of 1 OPERATOR STATION 555533
OOPPEERRAATTOORR SSTTAATTIIOONN
271-3526 PANEL AS-CONTROL
S/N: L1K1-UP; S1M1-UP
12-VOLT
PART OF 271-3522 PANEL GP-CONTROL
AN ATTACHMENT
SMCS-7451 i02624443
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 271-3525 1 PANEL-INSTRUMENT
2 1 231-5914 1 GAUGE-PRESSURE (12-VOLT) (ENGINE OIL)
3 1 231-5915 1 GAUGE-TEMPERATURE (12-VOLT) (WATER)
4 1 231-5916 1 VOLTMETER GP (12-VOLT)
5 1 256-6504 1 HORN
6 1 271-2702 1 BUTTON
7 1 271-2703 1 SWITCH (START, STOP)
8 1 271-2704 2 CONTACT AS-ELECTRICAL
9 1 271-2721 1 INDICATOR (RED) (ALARM)
10 1 271-2722 1 INDICATOR (GREEN) (ENGINE RUNNING)
11 1 271-2724 2 LAMP (12-VOLT, 2-WATT)
12 1 196-7701 6 SCREW (NO 8X0.75-IN)
13 1 102-8801 1 KIT-RECEPTACLE (12-PIN)
(INCLUDES RECEPTACLE AS AND WEDGE)
GRAPHIC #1 > g01159032
555544 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
271-3527 PANEL AS-CONTROL
S/N: L1K1-UP; S1M1-UP
24-VOLT
PART OF 271-3523 PANEL GP-CONTROL
AN ATTACHMENT
SMCS-7451 i03636006
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 271-3525 1 PANEL-INSTRUMENT
2 1 243-3851 1 GAUGE GP-ENGINE OIL PRESSURE (24-VOLT)
3 1 243-3852 1 GAUGE-WATER TEMPERATURE (24-VOLT)
4 1 243-3853 1 VOLTMETER GP (24-VOLT)
5 1 256-6504 1 HORN
6 1 271-2702 1 BUTTON
7 1 271-2703 1 SWITCH (START, STOP)
9 1 271-2721 1 INDICATOR (RED) (ALARM)
10 1 271-2722 1 INDICATOR (GREEN) (ENGINE RUNNING)
11 1 271-2723 2 LAMP (24-VOLT, 2-WATT)
12 1 196-7701 6 SCREW (NO 8X0.75-IN)
13 1 102-8801 1 KIT-RECEPTACLE (12-PIN)
(INCLUDES RECEPTACLE AS AND WEDGE)
GRAPHIC #1 > g01426082
SEBP4152-48 1 of 1 OPERATOR STATION 555555
OOPPEERRAATTOORR SSTTAATTIIOONN
273-5783 PANEL AS-ELECTRICAL
S/N: L1K1-UP; S1M1-UP
PART OF 273-6214, 273-6381 PANEL GP-ELECTRONIC
AN ATTACHMENT
SMCS-1417, 7451 i03632385
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-5784 1 DOOR AS-ACCESS
2 1 205-3657 1 HINGE AS
M 1 203-5398 4 INSERT-THREADED (M5X0.8-THD)
3 1 273-4935 1 PANEL AS-ELECTRICAL
4 1 273-4937 1 PLATE
M 5 1 245-6541 18 BOLT (M5X0.8X12-MM)
M 6 1 178-9983 4 LOCKNUT (M4X0.7-THD)
7 1 196-0347 4 WASHER (4.3X8.7X0.8-MM THK)
8 1 214-9193 4 SCREW (M4X0.7X16-MM)
9 1 273-4359 1 PLATE
10 1 121-4721 1 STRIP-DUST SEAL
M - METRIC PART
GRAPHIC #1 > g01160026
555566 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
273-4349 PANEL AS-ELECTRONIC
S/N: L1K1-UP; S1M1-UP
PART OF 273-4361, 273-5663 PANEL GP-ELECTRONIC
AN ATTACHMENT
SMCS-4490, 7490 i02312154
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 273-4922 1 DOOR AS
2 1 205-3657 1 HINGE ASGP-MOUNTING . . . . . . . . . . . . . . . . . . . . 319
487
488
537
538
BRACKET GP-MOUNTING–CRANKCASE
BREATHER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
BRACKET GP-SUPPORT . . . . . . . . . . . . . . . . . . . . . 386
387
BREATHER AS (CRANKCASE) . . . . . . . . . . . . . . . . 144
145
146
147
148
BREATHER GP–CRANKCASE . . . . . . . . . . . . . . . . . 144
145
146
147
148
C
CABLE GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 388
389
390
CAMSHAFT GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
23
24
25
26
CAP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 364
370
373
377
CAP AS (ENGINE OIL FILLER) . . . . . . . . . . . . . . . . 36
38
40
44
46
48
50
53
CAP-OIL FILLER (ENGINE) . . . . . . . . . . . . . . . . . . . . 36
38
40
42
51
52
CAP-PRESSURE (7-PSI) (COOLANT) . . . . . . . . . . 255
CAP-PRESSURE (7-PSI) (EXPANSION
TANK) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 251
253
256
CHART-PLATE & FILM . . . . . . . . . . . . . . . . . . . . . . . 588
CIRCUIT BREAKER (10-AMPERE) . . . . . . . . . . . . . 458
462
464
468
470
474
581
583
CIRCUIT BREAKER (80-AMPERE) . . . . . . . . . . . . . 458
462
464
468
470
474
581
583
CONNECTION GP-ELECTRICAL . . . . . . . . . . . . . . . 391
392
CONNECTION GP-TEST . . . . . . . . . . . . . . . . . . . . . . 393
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
SEBP4152-48 INDEX AA1133
CONNECTION GP-WATER . . . . . . . . . . . . . . . . . . . . 157
158
159
160
161
162
CONNECTOR GP-CAB HEATER LINES. . . . . . . . 163
CONTACTOR GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 393
394
395
396
CONTACTOR GP-GENERATOR–FUEL . . . . . . . . . 397
CONTACTOR GP-OIL PRESSURE–ENGINE . . . . 398
CONTACTOR GP-TEMPERATURE . . . . . . . . . . . . . 400
401
CONTROL GP-ELECTRONIC . . . . . . . . . . . . . . . . . . 403
404
CONVERTER GP-ELECTRICAL. . . . . . . . . . . . . . . . 405
COOLANT HEATER LINES. . . . . . . . . . . . . . . . . . . . 524
525
COOLER GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . 164
165
COOLER GP-FLTR BASE & ENG OIL . . . . . . . . . 166
167
168
170
172
COUPLING GP-GENERATOR. . . . . . . . . . . . . . . . . . . 27
28
COVER GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
COVER GP-ACCESS . . . . . . . . . . . . . . . . . . . . . . . . . 477
COVER GP-CYLINDER HEAD . . . . . . . . . . . . . . . . . . 29
COVER GP-ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . . 30
COVER GP-ENGINE LIFTING EYE . . . . . . . . . . . . . 31
32
33
COVER GP-FRONT HOUSING . . . . . . . . . . . . . . . . . 34
35
COVER GP-VALVE MECHANISM. . . . . . . . . . . . . . . 36
38
40
42
44
46
48
50
51
52
53
CRANKSHAFT GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
56
58
59
60
61
62
63
64
65
66
CYLINDER BLOCK GP . . . . . . . . . . . . . . . . . . . . . . . . 67
69
70
71
72
73
74
75
76
CYLINDER HEAD GP. . . . . . . . . . . . . . . . . . . . . . . . . . 77
78
79
80
81
82
83
D
DIAPHRAGM (CRANKCASE PRESSURE
CONTACTOR) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
DRAIN GP-OIL–ENGINE. . . . . . . . . . . . . . . . . . . . . . . 149
DUCT GP-ENCLOSURE. . . . . . . . . . . . . . . . . . . . . . . 478
479
480
481
E
ELBOW GP-AIR INLET . . . . . . . . . . . . . . . . . . . . . . . 277
ELBOW GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . . . . 278
279
280
281
282
283
284
285
286
287
288
289
290
ENCLOSURE AS-GENERATOR. . . . . . . . . . . . . . . . 482
485
ENGINE AR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
ENGINE AR-COMPLETE . . . . . . . . . . . . . . . . . . . . . . . . 2
3
4
5
6
7
8
9
10
11
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
AA1144 INDEX SEBP4152-48
ENGINE AR-PRIMARY . . . . . . . . . . . . . . . . . . . . . . . . . 12
13
14
15
16
18
EXHAUST GP-FLEXIBLE . . . . . . . . . . . . . . . . . . . . . . 291
292
EXTENSION GP-EXHAUST. . . . . . . . . . . . . . . . . . . . 293
F
FASTENER GP-FILTER . . . . . . . . . . . . . . . . . . . . . . . 294
FILLER GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . . 36
38
40
42
51
52
FILM-IDENTIFICATION (CAT MARINE
POWER) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 482
485
FILM-IDENTIFICATION (CAT) . . . . . . . . . . . . . . . . . . 482
485
FILM-IDENTIFICATION (CATERPILLAR) . . . . . . . . 482
485
561
563
FILM-IDENTIFICATION (PANEL LIGHTS) . . . . . . . 561
563
FILM-IDENTIFICATION (PANEL) . . . . . . . . . . . . . . . 561
563
585
586
FILM-INFORMATION (BATTERY POWER
DISCONNECT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 464
468
470
474
581
583
FILTER & LINES GP-FUEL. . . . . . . . . . . . . . . . . . . . 320
321
323
325
FILTER AS-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . 150
FILTER AS-FUEL (PRIMARY) . . . . . . . . . . . . . . . . . 320
321
FILTER BASE & ENG OIL COOLER. . . . . . . . . . . 166
167
168
170
172
FILTER ELEMENT AS-AIR (PRIMARY) . . . . . . . . . 262
263
267
269
271
FILTER ELEMENT AS-AIR (SECONDARY) . . . . . 262
263
267
FILTER ELEMENT-AIR (PRIMARY) . . . . . . . . . . . . 273
274
276
FILTER ELEMENT-AIR (SECONDARY) . . . . . . . . . 276
FILTER ELEMENT-BREATHER
(CRANKCASE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
145
146
147
148
FILTER ELEMENT-FUEL . . . . . . . . . . . . . . . . . . . . . . 321
FILTER GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . 150
151
152
153
FILTER GP-FUEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
329
331
FILTER-ENGINE OIL. . . . . . . . . . . . . . . . . . . . . . . . . . 135
151
152
FILTER-FUEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 323
325
327
329
331
FITTING GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 174
FLANGE GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . . . 295
296
FLANGE GP-RADIATOR . . . . . . . . . . . . . . . . . . . . . . 175
FUSE (5-AMPERE) . . . . . . . . . . . . . . . . . . . . . . . . . . . 458
462
464
468
470
474
581
583
FUSE (6.5-AMPERE). . . . . . . . . . . . . . . . . . . . . . . . . . 408
472
473
G
GASKET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
166
167
168
170
277
314
316
GASKET (ENGINE OIL FILTER BASE). . . . . . . . . . 67
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
SEBP4152-48 INDEX AA1155
GASKET (VALVE COVER) . . . . . . . . . . . . . . . . . . . . . 36
38
40
44
46
48
50
53
GASKET-INLET. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
314
GASKET-TURBOCHARGER . . . . . . . . . . . . . . . . . . . 308
310
312
GASKET-TURBOCHARGER
(TURBOCHARGER) . . . . . . . . . . . . . . . . . . . . . . . . . 308
GAUGE AS-OIL LEVEL (DIPSTICK)
(ENGINE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
108
GAUGE GP-ENGINE OIL PRESSURE. . . . . . . . . . 565
GAUGE GP-ENGINE OIL PRESSURE (24-
VOLT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 554
GAUGE GP-ENGINE OIL PRESSURE (ENGINE
OIL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 567
GAUGE-PRESSURE (12-VOLT) (ENGINE
OIL) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 553
GAUGE-SIGHT (FLUID LEVEL) . . . . . . . . . . . . . . . . 255
GAUGE-SIGHT (FLUID LEVEL) (COOLANT) . . . . 253
GAUGE-TEMPERATURE (12-VOLT) (WATER) . . 553
567
GAUGE-WATER TEMPERATURE (24-VOLT). . . . 554
565
GENERAL AR-GENERATOR . . . . . . . . . . . . . . . . . . . 19
GENERATOR AR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 489
490
491
492
493
494
495
496
GENERATOR GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 497
499
500
501
503
504
506
507
508
GLOW PLUG (12-VOLT) . . . . . . . . . . . . . . . . . . . . . . 406
GLOW PLUG (24-VOLT) . . . . . . . . . . . . . . . . . . . . . . 407
GLOW PLUG GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 406
407
GROMMET GP . . . . . . . . . . .M 1 203-5398 4 INSERT-THREADED (M5X0.8-THD)
3 1 273-4935 1 PANEL AS-ELECTRICAL
4 1 273-4937 1 PLATE
M 5 1 245-6541 18 BOLT (M5X0.8X12-MM)
M 6 1 178-9983 8 LOCKNUT (M4X0.7-THD)
7 1 196-0347 8 WASHER (4.3X8.7X0.8-MM THK)
8 1 214-9193 8 SCREW (M4X0.7X16-MM)
9 1 273-4359 2 PLATE
10 1 121-4721 1 STRIP-DUST SEAL
M - METRIC PART
GRAPHIC #1 > g01160026
SEBP4152-48 1 of 1 OPERATOR STATION 555577
OOPPEERRAATTOORR SSTTAATTIIOONN
271-2727 PANEL GP-CONTROL
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-4490, 7451 i02306095
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 271-2725 1 PANEL AS-CONTROL 551
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01156778
555588 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
271-2728 PANEL GP-CONTROL
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-4490, 7451 i02306121
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 271-2726 1 PANEL AS-CONTROL 552
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01156778
SEBP4152-48 1 of 1 OPERATOR STATION 555599
OOPPEERRAATTOORR SSTTAATTIIOONN
271-3522 PANEL GP-CONTROL
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-4490, 7451 i02326474
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 271-3526 1 PANEL AS-CONTROL (12-VOLT) 553
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01157359
556600 OPERATOR STATION 1 of 1 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
271-3523 PANEL GP-CONTROL
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-4490, 7451 i02326478
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 271-3527 1 PANEL AS-CONTROL (24-VOLT) 554
Y - SEPARATE ILLUSTRATION
GRAPHIC #1 > g01157345
SEBP4152-48 1 of 2 OPERATOR STATION 556611
OOPPEERRAATTOORR SSTTAATTIIOONN
300-0229 PANEL GP-CONTROL
S/N: D1K1-UP; S1M1-UP
FOR USE WITH 12-VOLT ELECTRONICS
CANNOT BE USED WITH 24-VOLT ELECTRONICS
AN ATTACHMENT
SMCS-4490, 7451 i05102539
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 394-8201 1 KIT-CONTROLLER
(KIT INCLUDES CONTROLLER, FILM, & HARNESS
ASSEMBLIES)
2 1 271-2702 1 BUTTON
3 1 273-4282 1 BUTTON-STOP
4 1 273-4283 1 CONTACT AS
5 1 273-4287 1 CONTACT AS
6 1 300-0232 1 PANEL AS
7 1 300-0233 1 FILM-IDENTIFICATION (PANEL)
M 8 1 124-3815 4 BOLT (M8X1.25X16-MM)
9 1 232-6568 4 RELAY AS (12-VOLT) (RUN)
M 10 1 178-9983 3 LOCKNUT (M4X0.7-THD)
11 1 196-0347 3 WASHER (4.3X8.7X0.8-MM THK)
12 1 214-9193 3 SCREW (M4X0.7X16-MM)
13 1 273-4352 3 SPACER (4.34X7.94X6.35-MM THK)
14 1 273-4359 2 PLATE
15 1 256-6504 1 HORN
16 1 300-0234 1 HARNESS AS-PANEL
17 1 300-0235 1 FILM-IDENTIFICATION (PANEL LIGHTS)
18 1 300-0236 1 FILM-IDENTIFICATION (CATERPILLAR)
M - METRIC PART
556622 OPERATOR STATION 2 of 2 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
300-0229 PANEL GP-CONTROL (ccoonnttdd..) i05102539
GRAPHIC #1 > g01382196
SEBP4152-48 1 of 2 OPERATOR STATION 556633
OOPPEERRAATTOORR SSTTAATTIIOONN
300-0237 PANEL GP-CONTROL
S/N: D1K1-UP; S1M1-UP
FOR USE WITH ENCLOSED C4.4 MARINE GENSET PACKAGES
AN ATTACHMENT
SMCS-4490, 7451 i05102540
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
1 1 394-8201 1 KIT-CONTROLLER
(KIT INCLUDES CONTROLLER, FILM, & HARNESS
ASSEMBLIES)
2 1 271-2702 1 BUTTON
3 1 273-4282 1 BUTTON-STOP
4 1 273-4283 1 CONTACT AS
5 1 273-4287 1 CONTACT AS
6 1 300-0232 1 PANEL AS
7 1 300-0233 1 FILM-IDENTIFICATION (PANEL)
M 8 1 124-3815 4 BOLT (M8X1.25X16-MM)
9 1 243-4630 4 RELAY (24-VOLT) (RUN)
M 10 1 178-9983 3 LOCKNUT (M4X0.7-THD)
11 1 196-0347 3 WASHER (4.3X8.7X0.8-MM THK)
12 1 214-9193 3 SCREW (M4X0.7X16-MM)
13 1 273-4352 3 SPACER (4.34X7.94X6.35-MM THK)
14 1 273-4359 2 PLATE
15 1 256-6504 1 HORN
16 1 300-0234 1 HARNESS AS-PANEL
17 1 300-0235 1 FILM-IDENTIFICATION (PANEL LIGHTS)
18 1 300-0236 1 FILM-IDENTIFICATION (CATERPILLAR)
M - METRIC PART
556644 OPERATOR STATION 2 of 2 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
300-0237 PANEL GP-CONTROL (ccoonnttdd..) i05102540
GRAPHIC #1 > g01382227
SEBP4152-48 1 of 2 OPERATOR STATION 556655
OOPPEERRAATTOORR SSTTAATTIIOONN
273-4361 PANEL GP-ELECTRONIC
S/N: L1K1-UP; S1M1-UP
24-VOLT
AN ATTACHMENT
SMCS-4490, 7490 i05582570
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 273-4349 1 PANEL AS-ELECTRONIC 556
2 1 452-9871 1 GAUGE GP-ENGINE OIL PRESSURE
3 1 243-3852 1 GAUGE-WATER TEMPERATURE (24-VOLT)
4 1 243-3853 1 VOLTMETER GP (24-VOLT)
5 1 318-4535 1 METER GP-SERVICE (24-VOLT)
6 1 271-2702 1 BUTTON (ALARM SILENCE)
7 1 273-4282 1 BUTTON-STOP
8 1 273-4283 1 CONTACT AS
9 1 273-4287 1 CONTACT AS
10 1 273-4715 1 GROMMET
11 1 256-6504 1 HORN
12 1 206-9503 1 MODULE-CONTROL (520)
13 1 273-4355 1 FILM
14 1 196-7715 1 CLIP
M 15 1 178-9983 2 LOCKNUT (M4X0.7-THD)
16 1 196-0347 4 WASHER (4.3X8.7X0.8-MM THK)
17 1 273-4352 3 SPACER (4.34X7.94X6.35-MM THK)
18 1 214-9193 3 SCREW (M4X0.7X16-MM)
19 1 273-4356 2 PLUG
20 1 212-9865 1 CONNECTOR
21 1 186-3735 15 PIN-CONNECTOR (16-GA TO 18-GA)
22 1 211-0052 1 NUT (1-11/16-18-THD)
23 1 128-4249 1 LOCKWASHER
24 1 243-4630 3 RELAY (24-VOLT) (RUN, 24-VOLT)
25 1 273-4357 1 HARNESS AS-PANEL
26 1 6I-0631 6 BOLT (M6X1X12-MM)
27 1 6I-0918 6 NUT
28 1 305-3659 1 SHROUD
M - METRIC PART
Y - SEPARATE ILLUSTRATION
556666 OPERATOR STATION 2 of 2 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
273-4361 PANEL GP-ELECTRONIC (ccoonnttdd..) i05582570
GRAPHIC #1 > g01369998
SEBP4152-48 1 of 2 OPERATOR STATION 556677
OOPPEERRAATTOORR SSTTAATTIIOONN
273-5663 PANEL GP-ELECTRONIC
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-4490, 7490 i05582572
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 273-4349 1 PANEL AS-ELECTRONIC 556
2 1 452-9871 1 GAUGE GP-ENGINE OIL PRESSURE (ENGINE OIL)
3 1 231-5915 1 GAUGE-TEMPERATURE (12-VOLT) (WATER)
4 1 231-5916 1 VOLTMETER GP (12-VOLT)
5 1 231-5917 1 METER GP-SERVICE (12-VOLT)
6 1 271-2702 1 BUTTON
7 1 273-4282 1 BUTTON-STOP
8 1 273-4283 1 CONTACT AS
9 1 273-4287 1 CONTACT AS
10 1 273-4715 1 GROMMET
11 1 256-6504 1 HORN
12 1 206-9503 1 MODULE-CONTROL (520)
13 1 273-4355 1 FILM
14 1 196-7715 1 CLIP
M 15 1 178-9983 2 LOCKNUT (M4X0.7-THD)
16 1 196-0347 4 WASHER (4.3X8.7X0.8-MM THK)
17 1 273-4352 3 SPACER (4.34X7.94X6.35-MM THK)
18 1 214-9193 3 SCREW (M4X0.7X16-MM)
19 1 273-4356 2 PLUG
20 1 212-9865 1 CONNECTOR
21 1 186-3735 15 PIN-CONNECTOR (16-GA TO 18-GA)
22 1 211-0052 1 NUT (1-11/16-18-THD)
23 1 128-4249 1 LOCKWASHER
24 1 232-6568 3 RELAY AS (12-VOLT) (RUN)
25 1 273-4357 1 HARNESS AS-PANEL
26 1 6I-0631 6 BOLT (M6X1X12-MM)
27 1 6I-0918 6 NUT
28 1 305-3659 1 SHROUD
M - METRIC PART
Y - SEPARATE ILLUSTRATION
556688 OPERATOR STATION 2 of 2 SEBP4152-48
OOPPEERRAATTOORR SSTTAATTIIOONN
273-5663 PANEL GP-ELECTRONIC (ccoonnttdd..) i05582572
GRAPHIC #1 > g01369933
SEBP4152-48 1 of 2 OPERATOR STATION 556699
OOPPEERRAATTOORR SSTTAATTIIOONN
273-6214 PANEL GP-ELECTRONIC
S/N: L1K1-UP; S1M1-UP
12-VOLT
AN ATTACHMENT
SMCS-4490, 7490 i02681250
NNOOTTEE
RREEFF
NNOO
GGRRAAPPHHIICC
RREEFF PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 1 1 273-5783 1 PANEL AS-ELECTRICAL 555
2 1 271-2702 1 BUTTON
3 1 273-4282 1 BUTTON-STOP
4 1 273-4283 1 CONTACT AS
5 1 273-4287 1 CONTACT AS
6 1 256-6504 1 HORN
7 1 213-0014 1 MODULE-CONTROL (550)
8 1 273-4355 1 FILM
9 1 196-7715 1 CLIP
M 10 1 178-9983 5 LOCKNUT (M4X0.7-THD)
11 1 196-0347 5 WASHER (4.3X8.7X0.8-MM. . . . . . . . . . . . . . . . . . . . 539
540
GUARD GP-BELT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
85
H
HARNESS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 583
HARNESS AS-ENGINE . . . . . . . . . . . . . . . . . . . . . . . 464
466
468
470
474
HARNESS AS-PANEL. . . . . . . . . . . . . . . . . . . . . . . . . 408
472
473
561
563
565
567
569
571
573
575
577
579
581
583
585
586
HARNESS AS-SWITCH . . . . . . . . . . . . . . . . . . . . . . . 440
HARNESS AS-WIRING. . . . . . . . . . . . . . . . . . . . . . . . 409
410
411
414
415
429
457
464
468
470
474
581
583
HARNESS AS-WIRING (CIRCUIT BREAKER) . . . 460
HARNESS GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 412
413
414
415
HARNESS GP-WIRING. . . . . . . . . . . . . . . . . . . . . . . . 416
HEAT EXCHANGER GP-SEA WATER . . . . . . . . . 176
177
HEATER GP-JACKET WATER. . . . . . . . . . . . . . . . . 417
418
HOSE GP-RADIATOR. . . . . . . . . . . . . . . . . . . . . . . . . 178
179
HOSE GP-TRANSFER . . . . . . . . . . . . . . . . . . . . . . . . 510
511
512
513
514
515
516
517
HOSE-RADIATOR . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
AA1166 INDEX SEBP4152-48
HOUSING GP-FLYWHEEL. . . . . . . . . . . . . . . . . . . . . . 86
87
HOUSING GP-FRONT . . . . . . . . . . . . . . . . . . . . . . . . . 88
I
INDICATOR (GREEN) (ENGINE RUNNING). . . . . 551
552
553
554
INDICATOR (RED) (ALARM) . . . . . . . . . . . . . . . . . . 551
552
553
554
INDICATOR-AIR FILTER CHANGE. . . . . . . . . . . . . 263
267
276
K
KEY (BATTERY DISCONNECT) . . . . . . . . . . . . . . . 438
KEY-LOCK (CIRCUIT BREAKER) . . . . . . . . . . . . . . 458
462
581
583
KIT-CONNECTING PLUG (12-PIN) . . . . . . . . . . . . . 413
414
416
KIT-WATER PUMP . . . . . . . . . . . . . . . . . . . . . . . . . . . 180
L
LAMP (12-VOLT, 2-WATT) . . . . . . . . . . . . . . . . . . . . 552
553
LAMP (24-VOLT, 2-WATT) . . . . . . . . . . . . . . . . . . . . 551
554
LAMP-LED (12-VOLT, AMBER) . . . . . . . . . . . . . . . . 581
LAMP-LED (24-VOLT, AMBER) . . . . . . . . . . . . . . . . 583
LIFTING GP-ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . 90
91
92
93
LIFTING GP-GENERATOR . . . . . . . . . . . . . . . . . . . . 509
LINES GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . . 154
LINES GP-FLEXIBLE FUEL . . . . . . . . . . . . . . . . . . . 333
335
LINES GP-FUEL. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 336
337
338
LINES GP-FUEL FILTER . . . . . . . . . . . . . . . . . . . . . . 339
LINES GP-HEATER. . . . . . . . . . . . . . . . . . . . . . . . . . . 524
525
526
527
528
LINES GP-HEATER–WATER JACKET . . . . . . . . . . 518
519
521
523
LINES GP-OIL–ENGINE . . . . . . . . . . . . . . . . . . . . . . . 155
LINES GP-WATER. . . . . . . . . . . . . . . . . . . . . . . . . . . . 181
183
184
185
187
188
189
190
192
194
196
198
200
202
204
206
208
209
210
211
212
213
215
217
218
220
222
224
226
228
230
232
234
M
MANIFOLD GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . 297
298
299
MANIFOLD GP-FUEL . . . . . . . . . . . . . . . . . . . . . . . . . 395
396
535
METER GP-SERVICE (12-VOLT) . . . . . . . . . . . . . . 567
METER GP-SERVICE (24-VOLT) . . . . . . . . . . . . . . 565
MOUNTING GP-AIR CLEANER . . . . . . . . . . . . . . . . 300
MOUNTING GP-ALTERNATOR . . . . . . . . . . . . . . . . . 94
MOUNTING GP-BRACKET . . . . . . . . . . . . . . . . . . . . . 96
MOUNTING GP-BRACKET–AIR CLEANER. . . . . . . 95
MOUNTING GP-CONTROL . . . . . . . . . . . . . . . . . . . . 541
542
543
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
SEBP4152-48 INDEX AA1177
MOUNTING GP-CONTROL PANEL . . . . . . . . . . . . 544
545
546
547
549
MOUNTING GP-ENGINE . . . . . . . . . . . . . . . . . . . . . . . 97
MOUNTING GP-ENGINE & GENERATOR . . . . . . . 98
100
102
104
105
MOUNTING GP-EXHAUST . . . . . . . . . . . . . . . . . . . . 301
MOUNTING GP-HEATER. . . . . . . . . . . . . . . . . . . . . . 531
532
MOUNTING GP-HEATER–WATER JACKET . . . . . 529
530
MOUNTING GP-SENSOR . . . . . . . . . . . . . . . . . . . . . 419
MOUNTING GP-STARTING MOTOR . . . . . . . . . . . 420
421
MOUNTING GP-WIRING . . . . . . . . . . . . . . . . . . . . . . 422
423
P
PAN GP-OIL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
108
PANEL AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 550
PANEL AS-CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 551
552
553
554
PANEL AS-ELECTRICAL . . . . . . . . . . . . . . . . . . . . . . 555
PANEL AS-ELECTRONIC . . . . . . . . . . . . . . . . . . . . . 556
PANEL GP-CONTROL . . . . . . . . . . . . . . . . . . . . . . . . 557
558
559
560
561
563
PANEL GP-ELECTRONIC . . . . . . . . . . . . . . . . . . . . . 565
567
569
571
573
575
577
579
581
583
585
586
PISTON & ROD GP . . . . . . . . . . . . . . . . . . . . . . . . . . 110
112
114
116
118
120
PISTON GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
PLATE-MOUNTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 587
PLUG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
PLUG GP-ENGINE . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
126
127
PLUG-DRAIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
245
249
250
319
543
PLUG-DRAIN (ENGINE OIL). . . . . . . . . . . . . . . . . . . 106
108
PLUG-DRAIN (FUEL FILTER). . . . . . . . . . . . . . . . . . 321
PLUG-DRAIN (SPILL PROTECTION) . . . . . . . . . . . 323
325
PULLEY GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
PULLEY GP-CRANKSHAFT . . . . . . . . . . . . . . . . . . . 129
PULLEY GP-FAN DRIVE . . . . . . . . . . . . . . . . . . . . . . 130
PULLEY GP-WATER PUMP . . . . . . . . . . . . . . . . . . . 131
132
PUMP GP-AUXILIARY SEA WATER . . . . . . . . . . . 235
PUMP GP-ENGINE OIL . . . . . . . . . . . . . . . . . . . . . . . 156
PUMP GP-FUEL INJECTION . . . . . . . . . . . . . . . . . . 340
341
344
347
348
351
354
357
360
363
364
367
370
373
376
377
PUMP GP-FUEL PRIMING . . . . . . . . . . . . . . . . . . . . 380
381
PUMP GP-WATER. . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
239
240
241
242
R
RADIATOR & MOUNTING GP. . . . . . . . . . . . . . . . . 243
244
RADIATOR AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 245
246
RADIATOR GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
249
250
REGULATOR (VOLTAGE) . . . . . . . . . . . . . . . . . . . . . 501
REGULATOR AS-VOLTAGE (GENERATOR) . . . . 497
504
REGULATOR AS-WATER TEMPERATURE
(CONNECTOR INCLUDED) . . . . . . . . . . . . . . . . . . 157
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
AA1188 INDEX SEBP4152-48
REGULATOR GP-TEMPERATURE (INCLUDES
CONNECTOR) (WATER) . . . . . . . . . . . . . . . . . . . . 160
REGULATOR-WATER TEMPERATURE (82-DEG
C) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 208
209
RELAY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 581
583
RELAY (12-VOLT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 458
581
RELAY (24-VOLT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 579
RELAY (24-VOLT) (RUN, 24-VOLT) . . . . . . . . . . . . 565
571
RELAY (24-VOLT) (RUN). . . . . . . . . . . . . . . . . . . . . . 563
575
583
586
RELAY (ON/STOP, 24-VOLT) (ON) . . . . . . . . . . . . 575
RELAY (START, 24-VOLT) . . . . . . . . . . . . . . . . . . . . 470
RELAY (START). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 464
RELAY AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
RELAY AS (12-VOLT, LATCHING) (ON). . . . . . . . 573
RELAY AS (12-VOLT). . . . . . . . . . . . . . . . . . . . . . . . . 468
474
577
581
585
RELAY AS (12-VOLT) (RUN) . . . . . . . . . . . . . . . . . . 561
567
569
573
RELAY GP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
RELAY-GLOW PLUG . . . . .. . . . . . . . . . . . . . . . . . . . 462
RELAY-GLOW PLUG (24-VOLT) . . . . . . . . . . . . . . . 464
470
583
RELAY-POWER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 424
468
474
ROCKER ARM GP . . . . . . . . . . . . . . . . . . . . . . . . . . . 133
S
SEAL (VALVE COVER) . . . . . . . . . . . . . . . . . . . . . . . . 38
40
46
48
50
53
SENDER GP-TEMP & PRESS. . . . . . . . . . . . . . . . . 425
426
427
428
SENDER-WATER TEMPERATURE . . . . . . . . . . . . . 425
427
SENDER-WATER TEMPERATURE
(COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 426
428
SENSOR AS-SPEED (ENGINE). . . . . . . . . . . . . . . . 430
431
SENSOR GP-LIQUID LEVEL–COOLANT. . . . . . . . 429
SENSOR GP-SPEED–ENGINE. . . . . . . . . . . . . . . . . 430
431
SENSOR GP-TEMPERATURE–EXHAUST. . . . . . . 432
SENSOR-PRESSURE . . . . . . . . . . . . . . . . . . . . . . . . . 395
396
SENSOR-PRESSURE (FUEL). . . . . . . . . . . . . . . . . . 397
SENSOR-SPEED (ENGINE) . . . . . . . . . . . . . . . . . . . 341
344
348
351
354
357
360
SENSOR-SPEED (TIMING ADVANCE) . . . . . . . . . 364
367
SENSOR-TEMPERATURE . . . . . . . . . . . . . . . . . . . . . 395
396
400
SENSOR-TEMPERATURE (ENGINE OIL) . . . . . . . 400
401
SENSOR-TEMPERATURE (EXHAUST) . . . . . . . . . 432
SENSOR-TEMPERATURE (WATER
COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401
SHAFT GP-STUB. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
SHIELD GP-EXHAUST . . . . . . . . . . . . . . . . . . . . . . . . 302
303
304
305
306
307
SHIELD GP-FUEL LINES. . . . . . . . . . . . . . . . . . . . . . 382
383
SOLENOID (AIR START). . . . . . . . . . . . . . . . . . . . . . 434
SOLENOID (STARTING MOTOR) (STARTER) . . 435
SOLENOID GP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 433
SPACER GP-BLOCK. . . . . . . . . . . . . . . . . . . . . . . . . . 135
STARTING MOTOR GP-AIR. . . . . . . . . . . . . . . . . . . 434
435
STARTING MOTOR GP-ELECTRIC . . . . . . . . . . . . 436
437
STRAINER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 232
STRAINER (INLET) . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
SWITCH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 395
396
424
581
583
SWITCH (FUEL PRESSURE) . . . . . . . . . . . . . . . . . . 397
SWITCH (SPEED) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 573
575
SWITCH (START, STOP) . . . . . . . . . . . . . . . . . . . . . 551
552
553
554
SWITCH AS-TEMPERATURE . . . . . . . . . . . . . . . . . . 396
SWITCH AS-TEMPERATURE (96-DEG)
(COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 425
426
SWITCH AS-TEMPERATURE (WATER
COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 401
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
SEBP4152-48 INDEX AA1199
SWITCH GP-DISCONNECT (BATTERY) . . . . . . . . 464
468
470
474
SWITCH GP-DISCONNECT–BATTERY . . . . . . . . . 438
SWITCH GP-LIQUID LEVEL . . . . . . . . . . . . . . . . . . . 439
440
SWITCH-HIGH TEMPERATURE (COOLANT). . . . 427
428
SWITCH-LEVEL (COOLANT) . . . . . . . . . . . . . . . . . . 429
439
440
SWITCH-PRESSURE. . . . . . . . . . . . . . . . . . . . . . . . . . 535
SWITCH-PRESSURE (ENGINE OIL) . . . . . . . . . . . 398
SWITCH-PRESSURE (ENGINE). . . . . . . . . . . . . . . . 425
426
427
428
SWITCH-TEMPERATURE. . . . . . . . . . . . . . . . . . . . . . 370
373
395
SWITCH-TEMPERATURE (ENGINE
COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
357
360
SWITCH-TEMPERATURE (WATER
COOLANT) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 400
T
TANK AS-FUEL (ALARM) . . . . . . . . . . . . . . . . . . . . . 336
TANK GP-COOLANT. . . . . . . . . . . . . . . . . . . . . . . . . . 251
253
255
TANK GP-EXPANSION. . . . . . . . . . . . . . . . . . . . . . . . 256
257
TRANSFORMER GP-CURRENT . . . . . . . . . . . . . . . 441
442
443
444
445
446
447
448
449
450
451
452
453
454
455
456
TUBE AS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 258
TURBOCHARGER GP . . . . . . . . . . . . . . . . . . . . . . . . 308
310
312
314
316
V
V-BELT (FAN) (INCLUDES ONE BELT) . . . . . . . . 136
V-BELT GP–FAN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 136
V-BELT SET . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
V-BELT SET–INCLUDES 2-BELTS . . . . . . . . . . . . . 137
VALVE GP-DRAIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . 318
VALVE MECHANISM GP. . . . . . . . . . . . . . . . . . . . . . 138
139
140
142
143
VOLTMETER GP (12-VOLT). . . . . . . . . . . . . . . . . . . 553
567
VOLTMETER GP (24-VOLT). . . . . . . . . . . . . . . . . . . 554
565
W
WIRING GP-ENGINE. . . . . . . . . . . . . . . . . . . . . . . . . . 457
458
460
462
464
466
WIRING GP-GENERATOR. . . . . . . . . . . . . . . . . . . . . 467
WIRING GP-INSTR & IGNITION . . . . . . . . . . . . . . . 468
470
WIRING GP-PANEL. . . . . . . . . . . . . . . . . . . . . . . . . . . 472
473
WIRING GP-SHUTOFF. . . . . . . . . . . . . . . . . . . . . . . . 474
NNAAMMEE PPAAGGEE NNAAMMEE PPAAGGEE
IINNDDEEXX
MMEEMMOORRAANNDDAA
AA2200 MEMORANDA SEBP4152-48
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 11
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
329-9929 ENGINE AR*R
S/N: D1K1-UP
47 BRAKE KW (63 BPH) AT 1500 RPM
PART OF 345-3436 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i05868472
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 367-2089 1 CAMSHAFT GP 25
Y 230-8086 1 CONNECTION GP-WATER 157
Y 253-2474 1 COOLER GP-FLTR BASE & ENG OIL 172
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 273-0871 1 COVER GP-VALVE MECHANISM 44
Y 367-2085 1 CRANKSHAFT GP 64
Y 367-2084 1 CYLINDER BLOCK GP 75
Y 367-2087 1 CYLINDER HEAD GP 82
Y 233-7491 1 ELBOW GP-AIR INLET 277
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 367-2086 1 PISTON & ROD GP 118
Y 225-4317 1 PLUG GP-ENGINE 125
Y 232-6204 1 PLUG GP-ENGINE 126
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 367-2070 1 PUMP GP-FUEL INJECTION 370
Y 230-7355 1 PUMP GP-WATER 237
Y 367-2088 1 VALVE MECHANISM GP 142
267-5367 1 CYLINDER BLOCK GP-SHORT
AVAILABLE GASKET KIT(S):
272-0494 1 KIT-GASKET (BOTTOM)
277-5156 1 KIT-GASKET (TOP)
Y - SEPARATE ILLUSTRATION
>
22 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
267-3299 ENGINE AR-COMPLETE
S/N: S1M1-UP
118 BRAKE KW (158 BHP) AT 1800 RPM
PART OF 290-9639 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635487
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 264-8940 1 BREATHER GP (CRANKCASE) 144
Y 268-6276 1 AIR CLEANER GP 265
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 286-2370 1 ENGINE AR-PRIMARY 18
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
267-3300 ENGINE AR-COMPLETE
S/N: S1M1-UP
103 BRAKE KW (138 BHP) AT 1500 RPM
PART OF 284-5273 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635488
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 268-6276 1 AIR CLEANER GP 265
Y 264-8940 1 BREATHER GP (CRANKCASE) 144
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2837 1 ENGINE AR-PRIMARY 12
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-53621 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 33
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
267-3301 ENGINE AR-COMPLETE
S/N: S1M1-UP
94 BKW (126 BHP) AT 1800 RPM
PART OF 284-5274 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635489
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 268-6276 1 AIR CLEANER GP 265
Y 264-8940 1 BREATHER GP (CRANKCASE) 144
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2839 1 ENGINE AR-PRIMARY 13
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
267-3302 ENGINE AR-COMPLETE
S/N: S1M1-UP
83 BRAKE KW (111 BHP) AT 1500 RPM
PART OF 284-5275 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635491
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 268-6276 1 AIR CLEANER GP 265
Y 264-8940 1 BREATHER GP (CRANKCASE) 144
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2841 1 ENGINE AR-PRIMARY 14
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
44 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
267-3303 ENGINE AR-COMPLETE
S/N: S1M1-UP
71 BKW (95 BHP) AT 1800 RPM
PART OF 284-5272 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635495
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 269-3099 1 AIR CLEANER GP 266
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
Y - SEPARATE ILLUSTRATION
>
267-3304 ENGINE AR-COMPLETE
S/N: S1M1-UP
62 BRAKE KW (83 BHP) AT 1500 RPM
FOR USE WITH THE C4.4 TURBOCHARGED 1500 RPM MARINE GENSET PACKAGE
PART OF 284-5271 GENERATOR AR
AN ATTACHMENT
SMCS-1000 i03635499
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 269-3099 1 AIR CLEANER GP 266
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 55
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
267-3305 ENGINE AR-COMPLETE
S/N: L1K1-UP
54 BRAKE KW (72 BHP) AT 1800 RPM
PART OF 284-5269 GENERAL AR-GENERATOR
AN ATTACHMENT
SMCS-1000 i03635501
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-6528 1 AIR CLEANER GP 264
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
267-3307 ENGINE AR-COMPLETE
S/N: L1K1-UP
44 BRAKE KW (59 BHP) AT 1500 RPM
PART OF 284-5268 GENERAL AR-GENERATOR
AN ATTACHMENT
SMCS-1000 i03635503
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-6528 1 AIR CLEANER GP 264
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 270-3880 1 SENSOR GP-SPEED (ENGINE) 430
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
300-2912 ENGINE AR-COMPLETE
S/N: D1K1-UP
38 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635507
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-2231 1 AIR CLEANER GP 273
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
66 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2913 ENGINE AR-COMPLETE
S/N: J1Z1-UP
51 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635509
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-3085 1 AIR CLEANER GP 274
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
PLEASE USE THE GASKET KIT LINK IN SIS OR CONTACT
YOUR LOCAL DEALER FOR THE LATEST GASKET KIT
INFORMATION
Y - SEPARATE ILLUSTRATION
>
300-2914 ENGINE AR-COMPLETE
S/N: J1Z1-UP
69 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635512
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2208 1 AIR CLEANER GP 269
Y 299-2227 1 BREATHER GP (CRANKCASE) 147
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2841 1 ENGINE AR-PRIMARY 14
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 77
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2915 ENGINE AR-COMPLETE
S/N: J1Z1-UP
86 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635515
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2213 1 AIR CLEANER GP 271
Y 299-2229 1 BREATHER GP (CRANKCASE) 148
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2837 1 ENGINE AR-PRIMARY 12
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
300-2916 ENGINE AR-COMPLETE
S/N: D1K1-UP
44 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635518
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-2231 1 AIR CLEANER GP 273
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
300-2917 ENGINE AR-COMPLETE
S/N: J1Z1-UP
58 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635519
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-3085 1 AIR CLEANER GP 274
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
Y - SEPARATE ILLUSTRATION
>
88 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2918 ENGINE AR-COMPLETE
S/N: J1Z1-UP
76 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000i03635520
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2208 1 AIR CLEANER GP 269
Y 299-2227 1 BREATHER GP (CRANKCASE) 147
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2839 1 ENGINE AR-PRIMARY 13
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
300-2919 ENGINE AR-COMPLETE
S/N: J1Z1-UP
99 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635521
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2213 1 AIR CLEANER GP 271
Y 299-2229 1 BREATHER GP (CRANKCASE) 148
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 286-2370 1 ENGINE AR-PRIMARY 18
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 99
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2920 ENGINE AR-COMPLETE
S/N: D1K1-UP
38 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635522
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-2231 1 AIR CLEANER GP 273
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
300-2921 ENGINE AR-COMPLETE
S/N: J1Z1-UP
51 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635530
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-3085 1 AIR CLEANER GP 274
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
Y - SEPARATE ILLUSTRATION
>
300-2922 ENGINE AR-COMPLETE
S/N: J1Z1-UP
69 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635532
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2208 1 AIR CLEANER GP 269
Y 299-2227 1 BREATHER GP (CRANKCASE) 147
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2841 1 ENGINE AR-PRIMARY 14
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
1100 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2923 ENGINE AR-COMPLETE
S/N: J1Z1-UP
86 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635533
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2213 1 AIR CLEANER GP 271
Y 299-2229 1 BREATHER GP (CRANKCASE) 148
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2837 1 ENGINE AR-PRIMARY 12
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
300-2924 ENGINE AR-COMPLETE
S/N: D1K1-UP
44 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635536
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-2231 1 AIR CLEANER GP 273
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 263-5805 1 ELBOW GP-EXHAUST 278
Y 273-0872 1 ENGINE AR-PRIMARY 15
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 269-3749 1 SHIELD GP-EXHAUST 302
Y - SEPARATE ILLUSTRATION
>
300-2925 ENGINE AR-COMPLETE
S/N: J1Z1-UP
58 EKW AT 1500 RPM
AN ATTACHMENT
SMCS-1000 i03635539
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 299-3085 1 AIR CLEANER GP 274
Y 268-8625 1 BREATHER GP (CRANKCASE) 145
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 273-1454 1 ENGINE AR-PRIMARY 16
Y 269-3748 1 LIFTING GP-ENGINE 91
Y 263-4793 1 MANIFOLD GP-EXHAUST 297
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 273-3613 1 SHIELD GP-EXHAUST 304
Y 266-7090 1 TURBOCHARGER GP 308
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 1111
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
300-2926 ENGINE AR-COMPLETE
S/N: J1Z1-UP
76 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635541
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2208 1 AIR CLEANER GP 269
Y 299-2227 1 BREATHER GP (CRANKCASE) 147
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 272-2839 1 ENGINE AR-PRIMARY 13
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
300-2927 ENGINE AR-COMPLETE
S/N: J1Z1-UP
99 EKW AT 1800 RPM
AN ATTACHMENT
SMCS-1000 i03635554
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 265-7802 1 AFTERCOOLER GP 260
Y 299-2213 1 AIR CLEANER GP 271
Y 299-2229 1 BREATHER GP (CRANKCASE) 148
Y 267-2529 1 DRAIN GP-OIL (ENGINE) 149
Y 269-5153 1 ELBOW GP-EXHAUST 279
Y 286-2370 1 ENGINE AR-PRIMARY 18
Y 269-9110 1 LIFTING GP-GENERATOR 509
Y 268-4268 1 MANIFOLD GP-EXHAUST 298
Y 268-7665 1 MOUNTING GP-AIR CLEANER 300
Y 270-0340 1 SHIELD GP-EXHAUST 303
Y 268-5362 1 TURBOCHARGER GP 310
Y - SEPARATE ILLUSTRATION
>
1122 ENGINE ARRANGEMENT 1 of 1 SEBP4152-48
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
272-2837 ENGINE AR-PRIMARY*R
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1000 i05832987
NNOOTTEE PPAARRTT NNUUMMBBEERR QQTTYY
PPAARRTT NNAAMMEE
1 2 3 4 5 6 (PRODUCT LEVEL)
SSEEEE
PPAAGGEE
Y 232-7528 1 CAMSHAFT GP 22
–OR–
Y 288-1434 1 CAMSHAFT GP 24
–OR–
Y 367-2792 1 CAMSHAFT GP 26
Y 230-8086 1 CONNECTION GP-WATER 157
Y 238-2799 1 COOLER GP-FLTR BASE & ENG OIL 166
Y 272-2230 1 COVER GP-CYLINDER HEAD 29
Y 230-9196 1 COVER GP-FRONT HOUSING 34
Y 272-2228 1 COVER GP-VALVE MECHANISM 36
–OR–
Y 367-2220 1 COVER GP-VALVE MECHANISM 51
Y 232-7439 1 CRANKSHAFT GP 56
–OR–
Y 274-4717 1 CRANKSHAFT GP 61
–OR–
Y 367-2788 1 CRANKSHAFT GP 65
Y 232-7606 1 CYLINDER BLOCK GP 69
–OR–
Y 274-4718 1 CYLINDER BLOCK GP 73
–OR–
Y 367-2787 1 CYLINDER BLOCK GP 76
–OR–
Y 232-7524 1 CYLINDER HEAD GP 78
–OR–
Y 288-1424 1 CYLINDER HEAD GP 81
–OR–
Y 367-2790 1 CYLINDER HEAD GP 83
Y 272-2229 1 FILTER GP-ENGINE OIL 150
Y 232-6661 1 GLOW PLUG GP 406
Y 232-6179 1 HOUSING GP-FRONT 88
Y 233-7432 1 LIFTING GP-ENGINE 90
Y 247-4885 1 LINES GP-FUEL FILTER 339
Y 272-2231 1 MOUNTING GP-ENGINE 97
Y 272-2224 1 PAN GP-OIL 106
Y 232-7442 1 PISTON & ROD GP 110
–OR–
Y 274-4720 1 PISTON GP 122
–OR–
Y 367-2789 1 PISTON & ROD GP 120
Y 225-4317 1 PLUG GP-ENGINE (FRONT HOUSING, CYLINDER HEAD) 125
Y 232-6204 1 PLUG GP-ENGINE (CYLINDER HEAD) 126
Y 253-2479 1 PLUG GP-ENGINE 127
Y 230-7352 1 PULLEY GP-CRANKSHAFT 129
Y 230-7578 1 PUMP GP-ENGINE OIL 156
Y 441-4311 1 PUMP GP-FUEL INJECTION 377
Y 230-7355 1 PUMP GP-WATER 237
Y 232-7526 1 VALVE MECHANISM GP 138
–OR–
Y 275-0170 1 VALVE MECHANISM GP 140
–OR–
Y 367-2791 1 VALVE MECHANISM GP 143
AVAILABLE GASKET KIT(S):
277-5156 1 KIT-GASKET (TOP)
272-2232 1 KIT-GASKET (BOTTOM)
Y - SEPARATE ILLUSTRATION
>
SEBP4152-48 1 of 1 ENGINE ARRANGEMENT 1133
EENNGGIINNEE AARRRRAANNGGEEMMEENNTT
272-2839 ENGINE AR-PRIMARY*R
S/N: J1Z1-UP
AN ATTACHMENT
SMCS-1000 i05832982
NNOOTTEE PPAARRTT
