Data Handling in Science and Technology
Hyperspectral Imaging
Volume 32
Series Editor
José Manuel Amigo
Elsevier
Radarweg 29, PO Box 211, 1000 AE Amsterdam, Netherlands
The Boulevard, Langford Lane, Kidlington, Oxford OX5 1GB, United Kingdom
50 Hampshire Street, 5th Floor, Cambridge, MA 02139, United States
Copyright © 2020 Elsevier B.V. All rights reserved.
No part of this publication may be reproduced or transmitted in any form or by any
means, electronic or mechanical, including photocopying, recording, or any
information storage and retrieval system, without permission in writing from the
Publisher. Details on how to seek permission, further information about the Publisher’s
permissions policies and our arrangements with organizations such as the Copyright
Clearance Center and the Copyright Licensing Agency, can be found at our website:
www.elsevier.com/permissions.
This book and the individual contributions contained in it are protected under
copyright by the Publisher (other than as may be noted herein).
Notices
Knowledge and best practice in this field are constantly changing. As new research and
experience broaden our understanding, changes in research methods, professional
practices, or medical treatment may become necessary.
Practitioners and researchers must always rely on their own experience and knowledge
in evaluating and using any information, methods, compounds, or experiments
described herein. In using such information or methods they should be mindful of
their own safety and the safety of others, including parties for whom they have a
professional responsibility.
To the fullest extent of the law, neither AACCI nor the Publisher, nor the authors,
contributors, or editors, assume any liability for any injury and/or damage to persons
or property as a matter of products liability, negligence or otherwise, or from any use
or operation of any methods, products, instructions, or ideas contained in the material
herein.
Library of Congress Cataloging-in-Publication Data
A catalog record for this book is available from the Library of Congress
British Library Cataloguing-in-Publication Data
A catalogue record for this book is available from the British Library
ISBN: 978-0-444-63977-6
ISSN: 0922-3487
For information on all Elsevier publications visit our website at
https://www.elsevier.com/books-and-journals
Publisher: Susan Dennis
Acquisition Editor: Kathryn Eryilmaz
Editorial Project Manager: Vincent Gabrielle
Production Project Manager: Divya KrishnaKumar
Cover Designer: Matthew Limbert
Typeset by TNQ Technologies
http://www.elsevier.com/permissions
https://www.elsevier.com/books-and-journals
Contributors
Nuria Aleixos Departamento de Ingenierı́a Gráfica, Universitat Politècnica de
València, València, Spain
José Manuel Amigo Professor, Ikerbasque, Basque Foundation for Science;
Department of Analytical Chemistry, University of the Basque Country, Spain;
Chemometrics and Analytical Technologies, Department of Food Science,
University of Copenhagen, Denmark
Josselin Aval ONERA/DOTA, Université de Toulouse, Toulouse, France
Touria Bajjouk Laboratoire d’Ecologie Benthique Côtière (PDG-ODE-DYNECO-
LEBCO), Brest, France
Jean-Baptiste Barré Univ. Grenoble Alpes, Irstea, LESSEM, Grenoble, France
Jon Atli Benediktsson University of Iceland, Reykjavik, Iceland
Jose Blasco Centro de Agroingenierı́a, Instituto Valenciano de Investigaciones Agrarias
(IVIA), Valencia, Spain
Johan Bøtker Department of Pharmacy, University of Copenhagen, Copenhagen,
Denmark
Xavier Briottet ONERA/DOTA, Université de Toulouse, Toulouse, France
Ingunn Burud Faculty of Science and Technology, Norwegian University of Life
Sciences NMBU, Norway
Daniel Caballero Professor, Ikerbasque, Basque Foundation for Science; Department
of Analytical Chemistry, University of the Basque Country, Spain; Chemometrics
and Analytical Technologies, Department of Food Science, Faculty of Science,
Copenhagen, Denmark; Computer Science Department, Research Institute of
Meat and Meat Product (IproCar), University of Extremadura, Cáceres, Spain
Rosalba Calvini Department of Life Sciences, University of Modena and Reggio
Emilia, Modena, Italy
Gustau Camps-Valls Image Processing Laboratory (IPL), Universitat de València,
València, Spain
Véronique Carrère Laboratoire de Planétologie et Géodynamique (LPG), Nantes,
France
Andrea Casini Istituto di Fisica Applicata “Nello Carrara” - National Research
Council (IFAC-CNR), Sesto Fiorentino (Florence), Italy
Jocelyn Chanussot Gipsa-lab, Grenoble INP, Grenoble, Rhône Alpes, France; Univ.
Grenoble Alpes, CNRS, Grenoble INP (Institute of Engineering Univ. Grenoble
Alpes), GIPSA-lab, Grenoble, France
xvii
Sergio Cubero Centro de Agroingenierı́a, Instituto Valenciano de Investigaciones
Agrarias (IVIA), Valencia, Spain
Costanza Cucci Istituto di Fisica Applicata “Nello Carrara” - National Research
Council (IFAC-CNR), Sesto Fiorentino (Florence), Italy
Mauro Dalla Mura Univ. Grenoble Alpes, CNRS, Grenoble INP (Institute of
Engineering Univ. Grenoble Alpes), GIPSA-lab, Grenoble, France; Tokyo Tech
World Research Hub Initiative (WRHI), School of Computing, Tokyo Institute of
Technology, Tokyo, Japan
Michele Dalponte Department of Sustainable Agro-ecosystems and Bioresources,
Research and Innovation Centre, Fondazione Edmund Mach, San Michele
all’Adige, Italy
Florian de Boissieu TETIS, Irstea, AgroParisTech, CIRAD, CNRS, Université Mont-
pellier, Montpellier, France
Anna de Juan Chemometrics group, Department of Chemical Engineering and Analyt-
ical Chemistry, Universitat de Barcelona (UB), Barcelona, Spain
Sylvain Dout Institut de Planétologie et d’Astrophysique de Grenoble (IPAG), Greno-
ble, France; Météo-France-CNRS, CNRM/CEN, Saint Martin d’Hères, France
Lucas Drumetz Lab-STICC, IMT Atlantique, Brest, Brittany, France
Marie Dumont Météo-France-CNRS, CNRM/CEN, Saint Martin d’Hères, France
Sophie Fabre ONERA/DOTA, Université de Toulouse, Toulouse, France
Nicola Falco Lawrence Berkeley National Laboratory, Berkeley, CA, United States
Baowei Fei Department of Bioengineering, The University of Texas at Dallas, Richard-
son, TX, United States; Department of Radiology, The University of Texas South-
western Medical Center, Dallas, TX, United States; Advanced Imaging Research
Center, The University of Texas Southwestern Medical Center, Dallas, TX, United
States
Jean-Baptiste Féret TETIS, Irstea, AgroParisTech, CIRAD, CNRS, Université Mont-
pellier, Montpellier, France
João Fortuna Idletechs AS, Trondheim, Norway; Department of Engineering Cyber-
netics, Norwegian University of Science and Technology NTNU, Trondheim,
Norway
Pierre-Yves Foucher ONERA/DOTA, Université de Toulouse, Toulouse, France
Neal B. Gallagher Chemometrics, Eigenvector Research, Inc., Manson, WA, United
States
Luis Gómez-Chova Image Processing Laboratory (IPL), Universitat de València,
València, Spain
Aoife Gowen UCD School of Biosystems and Food Engineering, University College of
Dublin (UCD), Belfield, Dublin, Ireland
Silvia Grassi Department of Food, Environmental and Nutritional Sciences (DeFENS),
Università degli Studi di Milano, Milano, Italy
xviii Contributors
Ana Herrero-Langreo UCD School of Biosystems and Food Engineering, University
College of Dublin (UCD), Belfield, Dublin, Ireland
Christian Jutten Gipsa-lab, Université Grenoble Alpes, Grenoble, Rhône-Alpes,
France
Xudong Kang Hunan University, College of Electrical and Information Engineering,
Hunan, China
Tatiana Konevskikh Faculty of Science and Technology, Norwegian University of
Life Sciences NMBU, Norway; Department of Fundamental Mathematics, Perm
State University PSU, Perm, Russia
Valero Laparra Image Processing Laboratory (IPL), Universitat de València, València,
Spain
Anthony Laybros AMAP, IRD, CNRS, CIRAD, INRA, Univ. Montpellier, Montpel-
lier, France
Shutao Li Hunan University, College of Electrical and Information Engineering,
Hunan, China
Giorgio Antonino Licciardi E.Amaldi Foundation, Rome, Italy
Federico Marini Department of Chemistry, University of Rome La Sapienza, Roma,
Italy
Rodolphe Marion CEA/DAM/DIF, Arpajon, France
Harald Martens Idletechs AS, Trondheim, Norway; Department of Engineering
Cybernetics, Norwegian University of Science and Technology NTNU, Trondheim,
Norway
Gabriel Martı́n Instituto de Telecomunicações, Lisbon, Portugal
Luca Martino Image Processing Laboratory (IPL), Universitat de València, València,
Spain
Théo Masson Univ. Grenoble Alpes, CNRS, Grenoble INP, Institute of Engineering
Univ. Grenoble Alpes, GIPSA-Lab, Grenoble, France
Gonzalo Mateo-Garcı́a Image Processing Laboratory (IPL), Universitat de València,
València, Spain
Audrey Minghelli Laboratoire des Sciences de l’Information et des Systèmes (LSIS),
University of South Toulon Var ISITV, La Valette, France
Jean-Matthieu Monnet Univ. Grenoble Alpes, Irstea, LESSEM, Grenoble, France
Pascal Mouquet Saint Leu, La Réunion, France
Sandra Munera Centro de Agroingenierı́a, Instituto Valenciano de Investigaciones
Agrarias (IVIA), Valencia, Spain
Jordi Muñoz-Marı́ Image Processing Laboratory (IPL), Universitat de València,
València, Spain
José Nascimento ISEL - Instituto Superior de Engenharia de Lisboa, Instituto Politéc-
nico de Lisboa, Lisbon, Portugal; Instituto de Telecomunicações, Lisbon, Portugal
xixContributors
Hodjat Rahmati Idletechs AS, Trondheim, Norway
Jukka Rantanen Department of Pharmacy, University of Copenhagen, Copenhagen,
Denmark
Carolina Santos Department of Fundamental Chemistry, Federal University of
Pernambuco, Recife, Brazil
Amalia G.M. Scannell UCD Institute of Food and Health, University College of
Dublin (UCD), Belfield, Dublin, Ireland; UCD Center for Food Safety, University
College of Dublin (UCD), Belfield, Dublin, Ireland; UCD School of Agriculture
and Food Science, University College of Dublin (UCD), Belfield, Dublin, Ireland
Frédéric Schmidt GEOPS, Univ. Paris-Sud, CNRS, Université Paris-Saclay, Orsay,
France
Petter Stefansson Faculty of Science and Technology, Norwegian University of Life
Sciences NMBU, Norway
Daniel H. Svendsen Image Processing Laboratory (IPL), Universitat de València,
València, Spain
Irina Torres Department of Bromatology and Food Technology, University of
Córdoba, Campus of Rabanales, Córdoba, Spain
Eduardo Tusa Univ. Grenoble Alpes, Irstea, LESSEM, Grenoble, France; Univ.
Grenoble Alpes, CNRS, Grenoble INP (Institute of Engineering Univ. Grenoble
Alpes), GIPSA-lab, Grenoble, France; Universidad Técnica de Machala, Facultad
de Ingeniería Civil, AutoMathTIC, Machala, Ecuador
Alessandro Ulrici Department of Life Sciences, University of Modena and Reggio
Emilia, Modena, Italy
Kuniaki Uto School of Computing, Tokyo Institute of Technology, Tokyo, Japan
Jochem Verrelst Image Processing Laboratory (IPL), Universitat de València,
València, Spain
Grégoire Vincent AMAP, IRD, CNRS, CIRAD, INRA, Univ. Montpellier, Montpel-
lier, France
Gemine Vivone Department of Information Engineering, Electrical Engineering and
Applied Mathematics, University of Salerno, Salerno, Italy
Christiane Weber TETIS, Irstea, AgroParisTech, CIRAD, CNRS, Université Montpel-
lier, Maison de la Télédétection, Montpellier, France
Jian X. Wu Oral Formulation Research, Novo Nordisk A/S, Denmark
Junshi Xia RIKEN Center for Advanced Intelligence Project, Tokyo, Japan
xx Contributors
List of Figures
Chapter 1.1
Figure 1 Confocal laser scanning microscopy image of a yogurt sample. The image is
one of the images used in Ref. [2]. The right part of the figure shows the
histogram of the grayscale values and the result of applying two different
threshold values (24 for protein and 100 for microparticulated whey protein). 5
Figure 2 Real color picture in RGB color space of a butterfly, and representation of the
red, green, and blue monochannels using the color map displayed in the right
part of the figure. The two images in the bottom are the transformed image in
L*a*b* color space. 6
Figure 3 Multispectral image taken to a 10 euros paper note (top left). The top right
part shows the intensities of the 19 different wavelengths for two pixels.
The bottom part shows different single channel pictures extracted for eight
channels. 7
Figure 4 Representation of the image of a cookie measured with a hyperspectral
camera in the wavelength range of 940e1600 nm (near infrared, NIR) with
a spectral resolution of 4 nm. The spectra obtained in two pixels are shown
and the false color image (single channel image) obtained at 1475 nm. The
single channel image selected highlighted three areas of the cookie where
water was intentionally added. This water is invisible in the VIS region
(nothing can be appreciated in the real color picture). Nevertheless, water is
one of the main elements that can be spotted in NIR. 8
Figure 5 Comprehensive flowchart of the analysis of hyperspectral and multispectral
images. ANN, artificial neural networks; AsLS, asymmetric least squares;
CLS, classical least squares; EMSC, extended multiplicative scatter correction;
FSW-EFA; fixed size window-evolving factor analysis; ICA, independent
component analysis; LDA, linear discriminant analysis; MCR, multivariate
curve resolution; MLR, multiple linear regression; MSC, multiplicative scatter
correction; NLSU, nonlinear spectral unmixing; OPA, orthogonal projection
approaches; PCA, principal component analysis; PLS-DA, partial least
squares-discriminant analysis; PLS, partial least squares; SIMCA, soft
independent modeling of class analogy; SIMPLISMA, simple-to-use
interactive self-modeling mixture analysis; SNV, standard normal variate;
SVM, support vectors machine; WLS, weighted least squares. 10
Chapter 1.2
Figure 1 Comparison of the basic setups for conventional imaging, hyperspectral and
multispectral cameras, and conventional spectroscopy. 18
Figure 2 Lightematter interaction. Depiction of the physical and chemical effects that
a photon might have when iterated with matter. 19
lxxix
Figure 3 RGB picture of part of a hand and the corresponding image taken at 950 nm. 20
Figure 4 Point, line, and plane scan configurations in hyperspectral and multispectral
(only the plane scan) imaging devices and the structure of the final data
cube of dimensions X � Y � l. 21
Figure 5 Spectral irradiance spectra of atmospheric terrestrial and extraterrestrial light. 24
Figure 6 Different geometries that the light sources can adopt, highlighting the emitted
and reflected (or transmitted) light path, and how light interacts with the
sample. 25
Figure 7 Black, reflectance of spectralon reference material for camera calibration.
Red, energy emission of a Tungsten Halogen lamp at 3300 K. Green,
emission of a green LED. Dark red, behavior of a band-pass filter at 1200 nm.
The Y axis scale only belongs to the reflectance of Spectralon. 26
Figure 8 Example of printable checkerboards (the USAF 1951 and a customized one)
used for line mapping and plane scan HSI and MSI cameras. HSI,
hyperspectral imaging; MSI, multispectral imaging. 31
Chapter 2.1
Figure 1 Original and distorted aerial images of houses. 38
Figure 2 Left, false RGB of a hyperspectral image showing four different clusters of
plastic pellets. The spectral range was from 940 to 1640 nm with a spectral
resolution of 4.85 nm. Further information about the acquisition, type of
hyperspectral camera, and calibration can be found in Ref. [3]. Right, raw
spectra of the selected pixels (marked with an “x” in the left figure). The black
line in the left figure indicates a missing scan line. 39
Figure 3 Top, distorted image (dashed squares) and corrected image (solid squares).
The pixel of interest is highlighted in bold. Bottom, three of the
methodologies for pixel interpolation, highlighting in each ones the pixels of
the distorted image used for the interpolation. 41
Figure 4 Left, spectrum containing one spiked point. The continuous red line denotes
the mean of thespectrum. The upper and lower dashed red lines denote
the mean � six times the standard deviation. Right, corrected spectrum
where the spike has been localized and its value substituted by an average of
the neighboring spectral values. 42
Figure 5 Top, raw spectra of Fig. 2 and the spectra after different spectral preprocessing
methods. Bottom, the image resulting at 1220 nm for each spectral
preprocessing. 43
Figure 6 Example of spectral preprocessing for minimizing the impact of the shape of
the sample in the spectra. Top left, RGB image of a nectarine. Top middle, the
average signal of the pixels contained in the green line of the top left figure.
Top right, spectra of the green line of the top left figure showing the effect of
the curvature. Bottom middle, average signal of the preprocessed spectra (with
standard normal variate (SNV)) of the green line of the top left figure. Bottom
right, preprocessed spectra of the green line of the top left figure. 44
Figure 7 Depiction of three different methodologies for background removal. Left,
false RGB image. Top, K-means analysis of the hyperspectral image in
SNV and the selection of clusters 2 and 4 to create the mask. Middle, false
color image obtained at 971 nm of the hyperspectral image in SNV and the
result of applying a proper threshold to create the mask. Bottom, PCA scatter
plot of the hyperspectral image in SNV with the selected pixels highlighted in
red to create the mask. All the analysis have been made using HYPER-Tools
[28], freely download in Ref. [29]. SNV, standard normal variate; PCA,
principal component analysis. 46
lxxx List of Figures
Figure 8 Comparison of two PCA models performed in the hyperspectral image of the
plastics [3]. For each PCA model, the score surfaces of the first two PCs, the
scatter plot of PC1 versus PC2 and the corresponding loadings are shown. All
the analyses have been made using HYPER-Tools [28], freely download in
Ref. [29]. PCA, principal component analysis; PC, principal component. 47
Chapter 2.2
Figure 1 Vector quantization compression block diagram. 57
Figure 2 Predictive coding compression block diagram. 60
Figure 3 Transform-based compression block diagram. 61
Chapter 2.3
Figure 1 An example of spectral distortion for component substitution approaches (see,
e.g., the river area on the right side of the images). An image acquired by the
IKONOS sensor over the Toulouse city is fused: (A) Ground-truth (reference
image) and the fusion products using the (B) GrameSchmidt (GS) and (C) the
GS adaptive (GSA) approaches. A greater spatial distortion can be pointed out
in the case of GS where a lower similarity between the panchromatic and the
multispectral spatial (intensity) component is shown with respect to the GSA
case. 72
Figure 2 An example of spectral distortion for component substitution approaches. An
image acquired by the IKONOS sensor over the Toulouse city is fused. Error
maps between the ground-truth (reference image) and the fusion products
using (A) the GrameSchmidt (GS) and (B) the GS adaptive (GSA)
approaches. A greater spatial distortion can be pointed out in the case of GS
where a lower similarity between the panchromatic and the multispectral
spatial (intensity) component is shown with respect to the GSA case. 72
Figure 3 An example of the spectral distortion reduction due to the histogram-matching
for component substitution approaches (see, e.g., the river area on the right
side of the images). An image acquired by the IKONOS sensor over the
Toulouse city is fused: (A) Ground-truth (reference image) and the fusion
products using the (B) principal component substitution (PCS) without
histogram-matching and (C) PCS with histogram-matching. A greater spatial
distortion can be pointed out in the case of PCS without the histogram-
matching with respect to the same procedure including the histogram-
matching processing step. 73
Figure 4 An example of the spectral distortion reduction due to the histogram-matching
for component substitution approaches. An image acquired by the IKONOS
sensor over the Toulouse city is fused. Error maps between the ground-truth
(reference image) and the fusion products using (A) the principal component
substitution (PCS) without histogram-matching and (B) the PCS with
histogram-matching. A greater spatial distortion can be pointed out in the case
of PCS without the histogram-matching with respect to the same procedure
including the histogram-matching processing step. 74
Figure 5 Flowchart presenting the blocks of a generic component substitution
pansharpening procedure. HSR, Higher spectral resolution; LPF, Low-pass
filter. 75
Figure 6 Flowchart of a generic multiresolution analysis pansharpening approach. HSR,
higher spectral resolution. 77
List of Figures lxxxi
Figure 7 Reduced resolution Hyp-ALI data set (Red ¼ band 30, Green ¼ band 20, Blue
¼ band 14): (A) ground-truth; (B) EXP; (C) principal component substitution;
(D) GrameSchmidt; (E) GrameSchmidt adaptive; (F) smoothing filter-based
intensity modulation; (G) modulation transfer function-generalized Laplacian
pyramid; (H) modulation transfer function-generalized Laplacian pyramid
with high pass modulation. 85
Figure 8 Close-ups of the full resolution Hyp-ALI data set (Red ¼ band 30, Green ¼
band 20, Blue ¼ band 14): (A) panchromatic; (B) EXP; (C) principal
component substitution; (D) GrameSchmidt; (E) GrameSchmidt adaptive;
(F) smoothing filter-based intensity modulation; (G) modulation transfer
function-generalized Laplacian pyramid; (H) modulation transfer function-
generalized Laplacian pyramid with high pass modulation. 87
Chapter 2.4
Figure 1 Exploration of a Raman image of an emulsion [1,2]. Left, false color image of
a Raman hyperspectral image. Top right, 30 random spectra taken from the
image and bottom right, the corresponding images obtained for some selected
wavelengths. 94
Figure 2 Graphical representation of a principal component analysis model of a
hyperspectral sample containing two chemical compounds. 96
Figure 3 Principal component analysis (PCA) model of the emulsion sample. Top left,
the false color image. Top, right, the first four PCs with the corresponding
explained variance. Bottom left, a composite image using PC1, PC2, and PC3
surfaces, and they were the RGB channels. Bottom right, the loadings
corresponding to the first four PCs. PC, principal component. 97
Figure 4 Principal component analysis (PCA) model of a multispectral image of a
banknote of 10 euros. Top left, the true color (RGB) image. Bottom left, a
composite image using PC1, PC2, and PC3 surfaces, and they were the RGB
channels. Middle, the first four PCs with the corresponding explained
variance. Right, the loadings corresponding to the first four PCs. PC, principal
component. 98
Figure 5 Sign ambiguity shown in the example of Fig. 2. Left shows the result obtained
in the analysis in Fig. 2. Right shows the same result, but multiplied times �1.
PC, principal component. 99
Figure 6 PC1 versus PC2 density scatter plot of the multispectral image of the banknote
of 10 euros and the selection of four different pixel regions in the scatter plot
and their position in the sample. PC, principal component. 100
Figure 7 Principal component analysis (PCA) models performed to a hyperspectral
image of a tablet (further information [11]). For every line the first four
PCs and the corresponding loadings are shown. (A) PCA model of the whole
surface. (B) PCA model of the coatings and the core of the tablet. (C) PCA
model of only the core of the tablet. (D) PCA model of only the coatings of
the tablet. PC, principal component. 102
Figure 8 Schematic representation of a dendrogram for a simulated data set involving
37 objects from three clusters with different within-group variance. Complete
linkage was used as metrics and the resulting hierarchical tree shows the
progressive agglomeration of the groups from individual sample clustersup to
the last step when all objects are grouped into a single cluster. 106
Figure 9 K-means clustering of the banknote by using four, five, and six clusters. Top,
cluster assignation by colors. Bottom, the corresponding centroids. 111
lxxxii List of Figures
Figure 10 Cluster analysis of a mixture composed by ibuprofen and starch. Top,
K-means models with 2, 3, and 10 clusters with the corresponding
centroids. Bottom, Fuzzy clustering model with two clusters and the
corresponding centroids. 112
Chapter 2.5
Figure 1 Image cube and bilinear model. 116
Figure 2 (A) Bilinear model of a 4D image formed by three spatial dimensions (x, y,
and z) and one spectral dimension. (B) Trilinear model of a 4D image
formed by two spatial dimensions (x and y) and two spectral (excitation/
emission) dimensions. 118
Figure 3 Principal component analysis (PCA) model (top plot) and multivariate curve
resolution (MCR) model (bottom plot) from a Raman emulsion image. 120
Figure 4 (A) Fixed size image window-evolving factor analysis application to a
hyperspectral image. Principal component analysis (PCA) analyses and
local rank map (B) combination of local rank and reference spectral
information to obtain masks of absent components in pixels (in red). These
absences are used as local rank constraints in multivariate curve resolution
analysis. 125
Figure 5 (A) Four-dimensional excitation-emission fluorescence measurement image
structured as a data matrix. (B) Implementation of the trilinearity constraint
in the ST matrix of emission spectra signatures. PCA, Principal component
analysis. 127
Figure 6 Multiset structures and bilinear models for (A) several images obtained with
the same spectroscopic platform and (B) a single image obtained with several
platforms. 129
Figure 7 Multivariate curve resolution results (maps and spectral signatures) obtained
from a multiset analysis of ink images obtained at different depths in a
document. The sequence of use of inks can be seen from the distribution maps
(Pilot BPG is more dominant in the upper layers in the ink intersection and
crosses over Pilot BAB). 131
Figure 8 Incomplete multiset used to couple images obtained from different
spectroscopic platforms with different spatial resolutions. 134
Figure 9 Multivariate curve resolution results obtained from the analysis of an
incomplete multiset formed by Raman and FT-IR images from a sample of
tonsil tissue. FT-IR, Fourier-transform infrared. 135
Figure 10 (A) Image fusion of 3D and 4D excitation-emission fluorescence
measurement fluorescence images. 136
Figure 11 (A) Maps and resolved spectra for a kidney stone Raman image, (B)
segmentation maps and centroids obtained from raw image spectra and
from multivariate curve resolution (MCR) scores. 138
Figure 12 Use of multivariate curve resolution scores for quantitative image analysis at a
bulk image and local pixel level. 139
Figure 13 Heterogeneity information obtained from multivariate curve resolution
(MCR) maps of compounds in a pharmaceutical formulation, see Ref. [37]
(top plot). Constitutional heterogeneity represented by histograms obtained
from map concentration values (middle plots). Distributional heterogeneity
represented by heterogeneity curves (bottom plots). AAS, Acetylsalicylic acid. 141
Figure 14 Superresolution strategy based on the combination of multivariate curve
resolution multiset analysis, and superresolution applied on to the resolved
maps from a set of images slightly shifted from one another. MCR-ALS,
Multivariate curve resolution-alternating least square. 142
List of Figures lxxxiii
Figure 15 Combination of multivariate curve resolution resampling and use of resolved
spectral signatures to develop compound-specific PLS-DA or ASCA models. 144
Chapter 2.6
Figure 1 Illustration of the linear mixture model. 152
Figure 2 Illustration of different nonlinear scenarios. (A) Multilayered mixtures. (B)
Intimate mixtures. 153
Figure 3 Schematic diagram of the radiative transfer model. IFOV, Instantaneous field
of view. 155
Figure 4 Color image corresponding to the 3D model used to generate the synthetic
hyperspectral data sets. (A) Orchard image with only two endmembers (soil
and trees) and (B) orchard data set considering three endmembers (soil, trees,
and weeds). 158
Figure 5 Washington, DC, data set (band 50). 161
Figure 6 Abundance fractions. (Top) Grass; (center) trees; (bottom) shadows. 161
Figure 7 Endmembers spectral signatures: anorthite, enstatite, and olivine. 162
Figure 8 Two-dimensional scatterplot of the intimate mixture. (A) Reflectance. (B)
Average single-scattering albedo. True endmembers (circles), intimate
mixtures (dots), endmember estimates by nonlinear unmixing method
(squares), simplex identification via split augmented Lagrangian (SISAL)
endmember estimates (triangles), vertex component analysis (VCA) (stars). 163
Chapter 2.7
Figure 1 (A) Geometric interpretation of the linear mixing model (LMM) in the case of
three endmembers (red dots). The axes represent a basis of the linear subspace
spanned by the endmembers. A pixel that does not satisfy the usual LMM (xk’)
is shown. (B) A nonlinear mixture of the three endmembers for pixel xk’. (C)
Spectral variability in an LMM framework. 170
Figure 2 (A) Concept of spectral bundles. (B) Geometric interpretation of using fully
constrained least-squares unmixing (FCLSU) on the whole extracted
dictionary. The red polytopes are the convex hulls of the different bundles.
The yellow points are accessible endmembers when using FCLSU, whereas
they were not extracted by the endmember extraction algorithm. 176
Figure 3 (A) Example of the construction of a binary partition tree (BPT). At each step
of the merging process, the two most similar regions are merged. (B) Example
of pruning of the BPT of (A). 180
Figure 4 (A) Geometric interpretation of local spectral unmixing. (B) The fluctuations
of local endmembers around references (in green) are at the core of most
computational models to address material variability. (C) A simple parametric
model to deal with endmember variability (one free parameter). (D) A more
complex model (two free parameters). 182
Figure 5 Acquisition angles for a given spatial location (red dot). The tangent plane at
this point of the surface is in brown. The incidence angle is q0, the emergence
angle is q, and the angle between the projections of the sun and the sensor is
the azimuthal angle, denoted as f. g is the phase angle. q0 and q are defined
with respect to the zenith, which is defined locally (in each point of the
observed surface) as the normal vector to the observed surface at this point. 187
Figure 6 Geometric interpretation of the extended linear mixing model in the case of
three endmembers. In blue are two data points, in red are the reference
endmembers, and in green are the scaled versions for the two considered
pixels. The simplex used in the linear mixing model is shown in dashed lines. 192
lxxxiv List of Figures
Figure 7 (A) An RGB representation of the Houston hyperspectral data set. (B) High-
spatial-resolution color image acquired over the same area at a different time.
(C) Associated LiDAR data, where black corresponds to 9.6 m and white
corresponds to 46.2 m. 195
Figure 8 The abundance maps estimated by all algorithms for the Houston data set. The
color scale goes from 0 (blue) to 1 (red). ELMM, Extended linear mixing
model; FCLSU, Fully constrained least-squares unmixing; NCM, Normal
compositional model; PLMM, Perturbed linear mixing model; SCLSU, Scaled
(partially) constrained least-squares unmixing. 196
Figure 9 Magnitude of the perturbed linear mixing model (PLMM) variability term (top
row), the scaling factors estimated by scaled (partially) constrained least-
squares unmixing (SCLSU) (middle row), and the proposed approach (bottom
row). ELMM, Extended linear mixing model. 197
Figure 10 Scatterplots of the results of the tested algorithms, represented using the firstthree principal components of the data. Data points are in blue, extracted
endmembers are in red, and reference endmembers are in black (except for the
bundles, where all the endmember candidates are in black). ELMM, Extended
linear mixing model; FCLSU, Fully constrained least-squares unmixing;
NCM, Normal compositional model; PLMM, Perturbed linear mixing model;
SCLSU, Scaled (partially) constrained least-squares unmixing. 197
Chapter 2.8
Figure 1 Development of the X matrix from different hyperspectral imaging or
multispectral imaging samples by extracting the region of interest (RoI). 209
Figure 2 Raw image (A), prediction maps of chlorophyll-a (B), chlorophyll-b (C), total
chlorophyll (D), and carotenoids (E) by applying the corresponding partial
least square models using optimal wavelengths on a randomly selected image. 210
Figure 3 Visualization of internal quality index (IQI) prediction using partial least
squares and optimal wavelengths for different cultivars of nectarines. 214
Figure 4 Tenderness distribution maps for beef longissimus muscle from PLS-DA
models using the mean spectrum of the whole rib eye area. SF50 and
SF300b: the region of interest (RoI) is the rib eye area. SF300a: the RoI is the
core position. 219
Figure 5 An overview of the overall process monitoring of roll compaction and
tableting; the implementation of NIR-CI to gain information related to the
physical or chemical properties of intermediate or final product. 221
Figure 6 Active principal ingredient (API) distribution map of tablets predicted by
partial least squares regression (PLS-R) model. 222
Chapter 2.9
Figure 1 (A) The model implied by Eq.(9) where the measured signal is x ¼ xc þ
csþ e. (B) The model implied by Eq. (10) where the measured signal is
x ¼ ccxc þ csþ e. (C) The model implied by Eq. (10) with strict closure on
the contributions. 236
Figure 2 (A) Scores image for principal component (PC) 1 for a near-infrared image of
wheat gluten (no signal processing was used). (B) Scores on PC 2 versus PC 1
with approximate 95% and 99% confidence ellipses based on the assumption
of normality. (C) Scores histograms for PC 1 (top) and PC 2 (bottom)
compared to Gaussian distributions. 237
List of Figures lxxxv
Figure 3 (Left) RGB image of the PCA scores on PCs 1, 2, and 3. (Right) Image of
PCA Q residuals showing Pixel 560 has high Q (bright yellow). Its
measured spectrum is plotted in Fig. 4 (bottom right). PCA, Principal
component analysis; PC, Principal component. 238
Figure 4 (Left) Contrasted image of target contributions. (top right) Pixel Group A
spectra. (Bottom right) Normalized spectrum for Pixel 560 compared to
Pixel 383. 239
Figure 5 (Left) RGB image of the contributions (MCR scores), (top right) estimated
normalized pure component spectra, (bottom right) scores profile for the
white arrow in the image. In each image/graph: Blue is Component 1 ¼ major
wheat gluten signal, Red is Component 2 ¼ minor wheat gluten signal (pixels
interspersed), and Green is Component 3 ¼ melamine target. 240
Figure 6 (Left) Image of Lake Chelan and the surrounding area based on bands 3, 2, 1
(RGB) listed in Table 1. (Right) Binary image of pixels comprising signal
primarily associated with water (yellow). Lake Chelan, the Chelan River, and
four small regions (circled) were correctly classified as water. 241
Figure 7 (Left) Class Lawn detections (yellow) and other Class Green (dark blue).
(Right) Class Cherries detections (yellow) and other Class Green (dark blue). 243
Figure 8 (Left) RGB image with an overlay of Class Lawn (green), Class Cherries
(blue), Class Green (non-Lawn and non-Cherries) (yellow), and Class Bare
Earth (red). 244
Chapter 2.10
Figure 1 The ensemble topologies (A) Concatenation style; (B) Parallel style. 249
Figure 2 Flowchart of rotation random forest-kernel principal component analysis
(RoRFeKPCA). RF, Random forest. 252
Figure 3 (A) Three-band color composite of AVIRIS image (B) Reference map. 252
Figure 4 Classification maps obtained by (A) random forest, (B) support vector
machine, (C) rotation random forest-principal component analysis, (D)
rotation random forest-kernel principal component analysis (RoRF-KPCA)
with linear, (E) RoRF-KPCA with RBF, and (F) RoRF-KPCA with
polynomial. 254
Figure 5 Reduced AP obtained by fusing the multiscale information extracted by a
large AP built on a single input feature. Thickening and thinning profiles
are the two components that compose the entire AP. The final rAP is
composed by the original feature (middle), a feature for the thickening
component (left) and one for the thinning component (right). 257
Figure 6 Overview of the Hyperion hyperspectral image over Sodankylä: (A) RGB true
color composition; (B) area defined for the training (green) and test (red) sets. 257
Figure 7 Classification performance for the Hyperion hyperspectral image over
Sodankylä: (A) reference map and the (B) classification map obtained by
using the proposed approach. 258
Figure 8 Schematic of (A) EPF-based feature extraction, and (B) EPF-based
probability optimization for classification of hyperspectral images. EPF,
Edge-preserving filtering. 259
Figure 9 The effect of edge-preserving filteringebased feature extraction. (A) Input
hyperspectral band (B) Filtered image. 260
Figure 10 The effect of edge-preserving filtering in probability optimization. (A) Input
probability map. (B) Guidance image. (C) Filtered probability map. 261
lxxxvi List of Figures
Figure 11 Indian Pines data set. (A) Three-band color composite. (B) Reference data.
(C) Class names. 263
Figure 12 Classification maps obtained by different methods on the Indian Pines data set
using 1% of the available samples as training set: (A) support vector machine,
overall accuracy (OA) ¼ 52.96%; (B) extended multiattribute profile, OA ¼
68.71%; (C) guided filteringebased probability optimization, OA ¼ 66.55%;
(D) hierarchical guidance filtering, OA ¼ 77.81%; (E) image fusion and
recursive filtering, OA ¼ 73.92%; (F) principal component analysisebased
edge-preserving features, OA ¼ 84.17%. 263
Figure 13 Classification maps obtained by different methods on the Indian Pines data set
using 10% of the available samples as training set: (A) Support vector
machine, overall accuracy (OA) ¼ 52.96%; (B) Extended multiattribute
profile, OA ¼ 93.66%; (C) guided filteringebased probability optimization,
OA ¼ 93.36%; (D) Hierarchical guidance filtering, OA ¼ 96.89%; (E) Image
fusion and recursive filtering, OA ¼ 97.77%; (F) Principal component
analysisebased edge-preserving features, OA ¼ 98.91%. 264
Chapter 2.11
Figure 1 Fusion categories defined by five different authors. 283
Figure 2 Graphical representation of processes for illustrating fusion methods: (A) Unit
of data symbolizes the spatial space and the type of information. (B) A block
expresses the task for processing data and information. (C) Interaction arrow
for representing the inputs and outputs of processing blocks. (D) Input
simultaneity to a processing block. 283
Figure 3 Illustration of fusion at low level or observation level. 284
Figure 4 Fusion at medium level or feature level. 286
Figure 5 Fusion at high level or decision level. 292
Chapter 2.12
Figure 1 The experiment (A) Illustration of experimental setup used to measure the
spectral reflectance and weight of a drying wood sample (B) RGB
rendering of wood sample in wet state (drying time ¼ 0 h) (C) RGB rendering
of wood sample in dry state (drying time ¼ 21 h). 308
Figure 2 Overview of experimental data acquisition and modeling of hyperspectral
video (a) Input data: (2200 � 1070) pixels � 159 wavelength channels �
150 time points. (bei) Model what is known about input data: EMSC
modeling of two-way input data for 159 wavelength channels at 353,100,000
pixels (2200 � 1070 � 150) � 159 wavelengths, and spatiotemporal
averaging. (jeo) Model what is unknown: Adaptive bilinear modeling of two-
way residual data for 353,100,000 pixels� 159 wavelengths. EMSC, extended
multiplicative signal correction; OTFP, On-the-fly-processing. 309
Figure 3 Modeling the known: Spectral and temporal structure of the parameters from
extended multiplicative signal correction (EMSC). Left column shows EMSC
model spectra chosen for modeling apparent absorbance; (A) Absorbance
spectrum m for estimating optical path length, calculated as the average
spectra of the last (driest) image in the series. (B) Constant “spectrum” for
estimating baseline offset. (C) Linear “spectrum” for estimating baseline
slope. (D) Dominant pigment spectrum DsWoodPigment, defined as the average
difference between early- and latewood pixels in the last (driest) image in the
List of Figures lxxxvii
series. (E) Water spectrum DsWater. Right column shows the temporal
development of all EMSC parameters (estimated at each point in time by
averaging over all image pixels). 313
Figure 4 Weight vector used to assign weights to different wavelength regions during
EMSC and OTFP. Red dotted line represents measured signal-to-noise ratio.
Dark solid line represents smoothed S/N curve used as weight vector v in both
EMSC and OTFP. EMSC, extended multiplicative signal correction; OTFP,
On-the-fly-processing. 315
Figure 5 (A) Weight of wood sample as function of drying time. (B) Percentage of
water in wood sample as function of drying time, calculated as water% ¼
100,(wwood � 245.46 g) /245.46. (C) Rate of change d(water%) /dt as
function of drying time. (D) Rate of change d(water%) /dt as function of
water%, with four local approximation lines. (E) ln(wwood � 245.46 g) as
function of drying time. (F) lnðwater%Þ wood as function of drying time, with
three local approximation lines. 319
Figure 6 Apparent absorbance spectra from 10 typical pixels of the wood sample in wet
condition (left) at t ¼ 0 h and dry condition (right) at t ¼ 21 h. The black
dotted line represents the chosen reference spectrum m, which is the average
of all pixels in the image taken after 21 h of drying. Top figures show spectra
before EMSC preprocessing. Middle figures show spectra after EMSC
preprocessing. Bottom figures show unmodeled spectral residuals after the
EMSC modeling. Windows within the figures show a magnification of the
940e1005 nm region strongly associated with water absorption. EMSC,
extended multiplicative signal correction. 320
Figure 7 Modeling the known: Spatial structure of EMSC parameters. 2D visualization
of fitted EMSC parameters in wet wood sample, i.e., t ¼ 0 h (upper row) and
dry wood sample, i.e., t ¼ 21 h (lower row) for all parameters used in the
EMSC model. EMSC, extended multiplicative signal correction. 323
Figure 8 Modeling the unknown: Spectral and temporal structure of the parameters
from adaptive bilinear modeling in the on-the-fly-processing (OTFP)
implementation. Left column shows the OTFP model spectra estimated for
modeling of apparent absorbance. Deweighted loadings for components 1e5.
Right column shows the temporal development of the adaptive bilinear
modeling parameters (estimated at each point in time by averaging over all
image pixels). 325
Figure 9 Modeling the unknown: Spatial structure of OTFP parameters. 2D
visualization of reconstructed OTFP scores of wet wood sample, i.e., t ¼
0 h (upper row) and dry wood sample, i.e., t ¼ 21 h (lower row) for the five
first principal components (PCs). 326
Figure 10 How the variation at the different wavelengths was explained by the sequence
of modeling steps: In the input data, after EMSC and after OTFP PCs #1, #2,
#3, #4 and #5. Left: Residual standard deviations, statistically weighted.
Right: Residual standard deviations, deweighted. EMSC, extended
multiplicative signal correction; OTFP, On-the-fly-processing; PC, Principal
component. 327
Figure 11 Kinetic modeling of the hyperspectral video developments: Analysis of the
known and unknown temporal developments of the parameters from EMSC
(left) and OTFP (right), averaged over all pixels, as first-order dynamic
processes. Dotted: ln(normalized parameters); densely dotted represent the
data points used in the least squares estimation of the kinetic parameters.
Straight red lines: Model fitted. EMSC, extended multiplicative signal
correction; OTFP, On-the-fly-processing; PC, Principal component. 329
lxxxviii List of Figures
Chapter 2.13
Figure 1 Forward and inverse problems in remote sensing data modeling. RTM,
radiative transfer model. 335
Figure 2 Statistical inverse modeling. 337
Figure 3 Leaf area index (LAI) map [m2/m2] processed by Gaussian process regression
(GPR) using all 125 bands (top left), LAI map processed by PLS-GPR using
five components (top right), associated GPR uncertainty estimates (s),
respectively (bottom). Relative differences in SD (s) between GPR of all 125
bands and PLS-GPR are also provided (bottom right) [36]. 340
Figure 4 Subsets of S2 composite LAIgreen and LAIbrown product [m
2/m2] for South of
Toulouse, France (left), and West of Valladolid, Spain (right). LAI, leaf area
index. 342
Figure 5 (A) LAI and fAPAR MODIS 8 daily time series of Spain rice are from 2003 to
2014. (B) Predictions made using individual, single-output models. (C)
Predictions made using the ICM model. fAPAR, fraction of absorbed
photosynthetically active radiation; LAI, leaf area index; MODIS, Moderate
Resolution Imaging Spectroradiometer. 347
Figure 6 (A) Predictions with individual Gaussian processes using a covariance
function with three terms: bias, linear, and Matérn kernel. (B) The same
predictions using the linear model of coregionalization multioutput model.
fAPAR, fraction of absorbed photosynthetically active radiation; LAI, leaf area
index. 348
Figure 7 Projection of data only NDVIeLAI space, showing how different crop types
tend to cluster together. LAI, leaf area index; NDVI, normalized difference
vegetation index. 351
Figure 8 Different Gaussian process (GP) approximations to estimate surface
temperature from infrared atmospheric sounding interferometer radiances:
classical GPs, sparse spectrum (SSGPs), and sparse approximation based on
inducing variables (FITC). [Left] Root mean squared error (RMSE) as a
function of the number of data points present in the kernel (m). [Center]
Training time as a function of m. [Right] RMSE as a function of training time. 356
Figure 9 Scheme of an automatic emulator. RTM, radiative transfer model. 357
Figure 10 General sketch of the Automatic Emulation (AE) procedure. Top: the radiative
transfer model g(y) (solid line), its approximation bgtðyÞ (dashed line).
Bottom: the acquisition function At(y). Its maximum suggests where a new
node should be added there. 358
Figure 11 RMSE on test grid computed for emulators using different sampling methods.
Each method is initialized with 50 points sampled with the LHS scheme, upon
which 50 more are sampled. AMOGAPE, Automatic Multi-Output Gaussian
Process Emulator; LHS, Latin hypercube sampling; RMSE, Root mean
squared error. 363
Chapter 3.1
Figure 1 Three-dimensional oblique view of a portion of the Russell dune on Mars.
Information on the nature of the materials and on their texture as well as
on the active areas is extracted from different types of imagery and
represented using color coding. 377
List of Figures lxxxix
Figure 2 Spectral endmembers extracted from the data set presented in Fig. 1 using
different methods (A) VCA (vertex component analysis), (B) BPSS
(Bayesian positive source separation), (C) MVC-NMF (minimum volume
constrained non-negative matrix factorization), and (D) spatial-VCA (vertex
component analysis) methods (see Ref. [44] for more details). 378
Figure 3 Global distribution of coastal and inland aquatic ecosystems. Red indicates
regions where water depth is less than 50 m and where land elevation is
less than 50 m. Light violet to dark violet gives the concentration of inland
wetlands, lakes, rivers, and other aquatic systems. Increased darkness means
greaterpercentage of areal coverage for inland aquatic ecosystems [48,49]. 380
Figure 4 Example of spectra of the main materials of interest in the campaign of
acquisition. 382
Figure 5 From left to right: coral reef, hyperspectral image acquired over Saint Gilles
reef flat (Reunion island, Indian Ocean), bathymetry estimation, classified
coral vitality index distribution from low (orange) to high (blue green) values,
and evolution of the coral cover with areas of degradation in red and
progression in blue. 383
Figure 6 True color atmospherically corrected hyperspectral images (R ¼ 638 nm, G ¼
551 nm, B ¼ 471 nm) of (top left) Boucan and (bottom left) Ermitage in
Reunion Island, hyperspectral derived bathymetry (to right), and RGB
composition of unmixing results for corals, algae, and sand abundances
corresponding, respectively, to red, green, and blue channels (bottom right).
Seagrass (absent in outer reef area) is indirectly represented by the dark pixels
(modified from Petit et al. [86]). 384
Figure 7 Typical minimal and maximal snow extent over the northern hemisphere. 385
Figure 8 (Top) Reflectance of the first seven bands of MODIS over an area of 100 by 80
km near Grenoble, France. Pixels covered by clouds are masked and reported
in white. (Bottom) Reflectance of the seven materials considered as
endmembers for spectral unmixing. 388
Figure 9 Results of a binary detection of the snow cover from a simple thresholding of
the NDSI (left, snow in yellow), and fractional results obtained by spectral
unmixing, following the approach of Pascal et al. [100]. NDSI, normalized
difference snow index. 389
Figure 10 Example of biodiversity mapping results throughout the CICRA site located in
lowland Amazonia. Panels are as follows: (A) natural color composite image
from the CAO visible-to-shortwave infrared (VSWIR) imaging spectrometer;
(B) a-diversity based on the Shannon index; and (C) b-diversity based on
BrayeCurtis dissimilarity (no color scale is applicable, and a larger
BrayeCurtis dissimilarity between two plots corresponds to larger differences
in color in the RGB space between the two corresponding pixels). 394
Figure 11 Simulation of airborne optical imaging in a tropical forest from French Guiana
(Paracou). The simulation is based on the integration of airborne LiDAR and
field spectroscopy into the 3D radiative transfer model DART [163]. Three-
dimensional mockups were computed from airborne LiDAR cloud points
using AMAPvox [164], and leaf optical properties corresponding to sampled
trees (delineated in red) were assigned to leaf elements from all voxels on the
vertical column of the mockup. A generic set of leaf optical properties was
applied to all trees with undocumented leaf optical properties using the
PROSPECT leaf model [127]. Left: original image (red ¼ 640 nm; green ¼
549 nm; blue ¼ 458 nm); center: simulation using a turbid representation for
leaf elements; right: simulation using triangle approach for leaf elements. 396
xc List of Figures
Chapter 3.2
Figure 1 Example of spectral signatures for the tree species considered in this study. 414
Figure 2 Airborne data (A) visible near-infrared, (B) short-wavelength infrared, (C)
panchromatic, (D) digital surface model. 414
Figure 3 Results (A) Visible near-infrared, (B) short-wavelength infrared, (C)
panchromatic, (D) digital surface model. Red tree crowns indicate
misclassifications while blue crowns indicate good classifications. 415
Figure 4 Pléiades image of Mangegarri waste storage area (upper left) and field spectra
of main materials: alumina, bauxite, and Bauxaline (upper right). Mangegarri
is located at Gardanne, southern France, and area extension is about 0.5 � 1.5
km2. Pléiades image of Ochsenfeld waste storage area (lower left) and
laboratory spectra of main materials: red and white gypsum (middle right),
and samples presenting a mixture of calcite and iron oxyhydroxides in various
proportions compared to red gypsum (lower right). The Ochsenfeld site is
located at Thann, eastern France, and area extension is about 0.5 � 1.0 km2. 420
Figure 5 HySpex VNIR color composites of Gardanne (upper left) and maps of
alumina (green), bauxite (red), and Bauxaline (blue) (lower left) based on
band positions in the VNIR and SWIR. APEX VNIR color composite of
Thann (upper right) and map of red gypsum (red), white gypsum (green), and
calcite (blue) (lower right) based on band positions in the VNIR and SWIR.
VNIR, Visible near-infrared; SWIR, Short-wavelength infrared. 422
Figure 6 CH4 map in ppm/m retrieved during the NAOMI (Collaboration project
between ONERA and TOTAL) using HySpex-NEO SWIR hyperspectral
camera and ONERA algorithm. 430
Figure 7 Top: CH4 map in ppm/m retrieved over Kern Oil River site (California) using
HyTES LWIR hyperspectral camera (JPL) and ONERA algorithm. Bottom:
CH4 map in ppm/m retrieved during the NAOMI (Collaboration project
between ONERA and TOTAL) using TELOPS LWIR HyperCam
hyperspectral camera and ONERA algorithm IMGSPEC. LWIR, Long-wave
infrared. 431
Figure 8 Top: SWIR spectral sensitivity (reflectance change in % corresponding to a
nominal reflectance of 0.1) due to CH4 corresponding to 2000 ppm m (red
line) compared to reflectance uncertainties due to a signal-to-noise ratio
(SNR) of 1000 and atmospheric correction. Bottom: LWIR spectral sensitivity
(brightness temperature signal change after atmospheric compensation) due to
CH4 corresponding to 1000 ppm m for a thermal contrast of 1K (red), 2K
(blue), and 3K (green) compared to brightness temperature uncertainties from
LWIR SNR spectra. SWIR, Short-wavelength infrared; LWIR, Long-wave
infrared. 432
Figure 9 UAV route and the ground truth acquisition points (field 3). 436
Figure 10 A color image converted from a reflectance image along a UAV route of
field 3. 437
Figure 11 Reflectance of rice, white sheet, and orange sheet. 437
List of Figures xci
Chapter 3.3
Figure 1 Precision agriculture among different crop fields. 455
Figure 2 Clustering results by new methods. (A) FCM, fuzzy c-means; (B) FCIDE,
automatic fuzzy clustering using an improved differential evolution
algorithm; (C) AMASFC, adaptive memetic fuzzy clustering algorithm with
spatial information; (D) AFCMDE, automatic fuzzy clustering method based
on adaptive multi-objective differential evolution; (E) AFCMOMA, adaptive
multi-objective memetic fuzzy clustering algorithm. 457
Figure 3 Heavy metal pollution in rice in all of the research area. 459
Figure 4 Light reflections in healthy, stressed, and dead leaves. The graphs below
indicate the relative reflection in the blue (B), green (G), red (R), and near-
infrared (NIR) channels. 460
Figure 5 Levels of water concentration in crop fields. (A) true colour image of a NVT
(National Variety Trials) wheat field after sowing (the red rectangles are the
experimental field boundaries); (B) image resulting from dividing first and
second principal component images. 461
Figure 6 Interpretation of hyperspectral images of maize for detecting healthy and dead
leaves of maize. 463
Chapter 3.5
Figure 1 EA.hy926 endothelial cell infected with Staphylococcus aureus. (A) White
light imaging. Intracellular spherical particles (1 mm, indicated with white
arrows) in single forms or grapelike groupings, characteristic of
staphylococci. (B) False color Raman image (pixel size: 1 � 1 mm2) centered
at 2938 cm�1 (CH stretching vibration) in arbitrary units showed in the
grayscale bar. (C) High-resolution Raman scan N-FINDR (pixel size: 0.25 �
0.25 mm2) of the section marked in part A in a false color image. The relative
RGB color contributions are assigned to bacteria (green), cellular nucleus
(blue), perinuclear region (red), and background (black) spectral profiles. (D)
Labeled fluorescence image of the same cell stained with an antibody binding
S. aureus (Alexa Fluor 488, green) and DAPI binding DNA (blue), present in
the nucleus and the bacteria. (E) Z-stack (depth imaging) of N-FINDRimages
recorded at 1-mm intervals (C corresponds to the 2-mm plane). 509
Figure 2 (A) Raman spectra of biofilm treated with CS-PLGA NPs. The lower and
upper spectra indicate Raman spectra of CS-PLGA NPs and biofilm,
respectively, within biofilm treated with CS-PLGA NPs. (B) Visualization of
biofilm treated with CS-PLGA NPs for 4 h by slit-scanning Raman
spectromicroscopy. The Raman band images were reconstructed from Raman
bands at 1770 cme1 (i) and 3180 cm�1 (ii). A superimposed image (iii) of CS-
PLGA NPs (1770 cm�1), shown in blue in (i), and biofilm (3180 cm�1),
shown in yellow in (ii), is also shown. Scale bars ¼ 5 mm. CS, chitosan; NPs,
nanoparticles; PLGA, poly lactide-co-glycolide. 510
Figure 3 (A) Raman image acquired from a 48-h swarm plate constructed from a
1338e1376 cm�1 filter to include the marker band for quinolones/
quinolines; (B) loading plot of PC1 generated from analysis of the Raman
image of the 48 h swarm plate. PC1 contains features that correspond to bands
from standard spectra of quinolines possessing the same functional group. 511
xcii List of Figures
Figure 4 Principal component loading plots from (A) “ex situ” protocol: Pantoea sp.
YR343 planktonic cells mixed with preformed Ag nanoparticles and (B) “in
situ” protocol: Pantoea sp. YR343 cells intimately coated with Ag NPs. 513
Figure 5 Theoretical Raman (red) calculated from vibrational frequencies (cm�1) of
pyocyanin and corresponding assignments and experimental Resonant
Raman (black) spectra of pyocyanin obtained at the indicated excitation
wavelengths. 514
Figure 6 Imaging of violacein and pyocyanin expression in coculture of
Chromobacterium violaceum (CV026) and Pseudomonas aeruginosa (PA14)
grown for 20 h. The dashed squares indicate the confrontation zone. Culture
was grown on gold 60 nm nanospheres on glass covered by lysogeny-broth
agar (Au@agar). (A) SERS mapping of violacein (727 cm�1) (B) SERRS
mapping of pyocyanin (544 cm�1) (C) SERS mapping of violacein and
pyocyanin. (D) SERS intensities of violacein (727 cm�1) and SERRS
intensities of pyocyanin (544 cm�1) as a function of distance. Three
repetitions measured at the spots indicated in (C) with white asterisks and
plotted. Standard deviation for each spot is shown in error bars. All
measurements were acquired with an excitation laser wavelength of 785 nm,
5� objective, and a laser power of 12.21 kW cm�2 for 10 s. SERS, surface-
enhanced Raman scattering; SERRS, Surface-enhanced resonance Raman
scattering. 515
Figure 7 Detection of bacteria in milk. (A) CARS image of Escherichia coliemilk
mixture. (B) Reconstructed map of E. coli and milk components after MCR
analysis. The E. coli is mapped with red color and the milk is mapped with
green color. The red dashed rectangular in (A) and (B) indicates the location
where E. coli and milk are overlapped. (C) Corresponding phase retrieved
output spectra of each component after MCR analysis. (D) CARS image of
milk alone dried on glass. (E) Reconstructed map of E. coli and milk
components after MCR analysis. (F) Corresponding phase retrieved output
spectra of each component after MCR analysis. Scale bars: 10 mm. CARS,
coherent anti-Stokes Raman scattering; MCR, multivariate curve resolution. 516
Chapter 3.6
Figure 1 Comparison between hypercube and RGB image. Hypercube is three-
dimensional data set a 2D image on each wavelength. The lower left is the
reflectance curve (spectral signature) of a pixel in the image. RGB color
image only has three image bands on red, green, and blue wavelength,
respectively. The lower right is the intensity curve of a pixel in the RGB
image. 526
Figure 2 Schematic diagram of a push broom hyperspectral imaging system. NIR,
Near-infrared. 527
Figure 3 A gray scale image of a melanoma lesion showing the transmission spectra in
the nuclear and interstitial areas. 539
Figure 4 Spatial oxygen saturation maps. (A) Healthy male (29 years old) oxygen
saturation map. Vascular separation from the background is seen as well as
reasonable saturation values for veins versus arteries. (B) Zero-order color
image. (C) Healthy male (58 years old) oxygen saturation map. (D) Zero-
order color images [99]. 543
List of Figures xciii
Figure 5 (A) Cross-section diagram of tissue sample for ADSI testing. (B) Color
photographs of mouse tumor tissue sandwiched between two glass slides.
The opening due to the black mask that was used for transmission imaging is
marked by the yellow dashed line. The black line (left panel) indicates the
location of bone embedded in the tissue. (C) Normalized spectra from regions
of tumor and muscle tissue (as indicated in (B)). (D) Correlation map of data
cube based on reference spectral signature related to the muscle tissue. (E)
Correlation map of data cube based on reference spectral signature related to
the tumor tissue [153]. ADSI, Angular domain spectroscopic imaging. 546
Figure 6 (A) Photomicroscopic and corresponding medical hyperspectral imaging
image from breast tumor in situ (4 � 3 cm) (upper left and upper middle
panels). Resected tumor and surrounding tissue (5 � 7 mm) was stained with
hematoxylin and eosin and evaluated by histopathology after resection.
Microscopic histological images with further resolution are displayed (right
panels). (B) Representative examples of normal tissue (grade 0), benign tumor
(grade 1), intraductal carcinomas (grade 2), papillary and cribriform
carcinoma (grade 3), and carcinoma with invasion (grade 4) are represented
[56]. 548
Figure 7 (A) Photographic image of the biliary tissue structure. (B) Classification of the
biliary tissue types based on hyperspectral imaging, superimposed with the
fluorescence image of the ICG-loaded microballoons. The dual-mode image
clearly identifies the biliary anatomy and its relative location with respect to
the surrounding tissue components. 550
Figure 8 The RGB image is shown on the left side. Using the method described, the
segmented image can be viewed on the right side. Spleen is shown in red,
peritoneum in pink, urinary bladder in blue, colon in green, and small intestine
in yellow. 551
Chapter 3.7
Figure 1 An example of image analytical quantification of crystal count and area
coverage of a metastable amorphous drug crystallizing over time. Top
image series (AeD) illustrates series of polarized light micrographs obtained
from the center position of a sample over time. Image series (EeH) presents
the polarized light micrograph obtained from the edge of same sample over
time. It was readily observed that the crystallization was more extensive and
occurred earlier for sample series (EeH) as compared with (AeD). Bottom:
AeD illustrate the response from the image analysis, where different samples
followed over time demonstrate different crystallization extent. A total of over
80 polarized light micrographs were obtained during this study, and without
image analysis drawing chemical objective conclusions based on the 80
micrographs will be very challenging. 569
Figure 2 Water distribution in freeze-dried well plates after different storage times at
11% RH (relative humidity) for Plate 1 and 43% RH for Plate 3. The color
scale depicts the percentage moisture content. Recrystallization of the sample
after 10-day storage in Plate 3 (storage at 43% RH). 573
Figure 3 Fourier transformed infrared images of the dissolution process of tablets with
20 wt% drug loading. The color scales indicate the integrated absorbance that
each color represents. PEG, Polyethylene glycol. 574
Figure 4 Dissolution troubleshooting with Raman imaging; example of polymorphic
transformations in the extruded pharmaceutical (polymer drug mixture). 575
xciv List of Figures
Figure 5 Coherent anti-Stokes Raman scattering (CARS) and sum-frequency
generation (SFG) combined for sensitive multimodal imaging of multiple
solid-state forms and their changes on drug tablet surfaces. 576
Figure 6 Decision-making tool based on optical imagesand fuzzy logic. 579
Figure 7 X-ray computed micro tomography data generated subvolumes of 3D printed
geometries filled with silicon oil. The brighter regions correspond to the
silicon oil which is visible in the outer and inner compartment (A), only in the
outer compartment (B), and only in the inner compartment (C). 580
Chapter 3.8
Figure 1 Schematic view of hyperspectral data cube and the different approaches to
data processing in typical cultural heritage applications. IR, infrared; PCA,
principal component analysis; MNF, minimum noise fraction. 588
Figure 2 The prototype of the IFAC-CNR hyperspectral scanner during a measurement
campaign on a panel painting belonging to the San Marco museum collection
in Florence (Italy). 591
Figure 3 (A) RGB colorimetric reconstruction using the Vis image cube of the “The
Annunciation,” a scene from a tempera panel attributed to Beato Angelico,
part of the artwork “Armadio degli Argenti” (1451 ca.) from the collection of
San Marco museum in Florence. Image reconstructed by IFAC-CNR with the
permission granted by San Marco museumdMinistero per i Beni e le Attività
Culturali. The reproduction rights are reserved. (B) Elaborated false color
image: PC2 ¼ R; PC4 ¼ G; PC5 ¼ B. The numbers indicate the pixel
locations from which the four endmember spectra were extracted. (C)
Reflectance spectra of the endmembers: 1) ultramarine blue (lapis); 2) mixture
1: ultramarine blue with an unknown pigment; 3) mixture 2: ultramarine blue
mixed with unknown pigment; 4) cobalt blue. (D) spectral angle mapping
classification map obtained using the endmembers spectra reported in C). 597
Chapter 3.9
Figure 1 Handprint near-infrared false-color hyperspectral images. The presence of
explosive residues is highlighted by colored pixels: (A) in pink for
ammonium nitrate, (B) in yellow for dynamite, (C) in red for single-base (SB)
smokeless gunpowder, (D) in blue for double-base (DB) smokeless
gunpowder, and (E) in green for black powder. There are 15,402 pixels in a
finger sample and 24,821 pixels in a hand palm sample. Enlargements of
regions in (B) and (D) are included for clarification. 608
Figure 2 Classical least squares (CLS) classification model applied to a mixture of
semen and vaginal fluid on cotton fabric. The CLS colored maps for each
class (cotton, semen, urine, and vaginal fluid) are displayed. The maximum
CLS weight values obtained for each class within the two selected stained
regions are indicated above every color map, the first value corresponding to
region 1 and the second to region 2. 609
Figure 3 False color images obtained from the elaboration of Raman images of
crossing lines drawn with gel and oil blue pen inks. Different times
separating the application of each line were considered, and the horizontal line
(in green) was always applied first. 611
List of Figures xcv
Figure 4 RGB images of (A and C) two concrete drill core samples and (B and D)
corresponding prediction images obtained with a partial least-squares
discriminant analysis classification model. The classes are aggregates (A, in
red) and mortar (M, in blue). 615
Figure 5 (AeD) Four examples of prediction images obtained from a near-infrared
hyperspectral system and corresponding RGB images. The imaged objects
are made of polypropylene (PP), polyvinyl chloride (PVC), paper, high-
density polyethylene (HDPE), low-density polyethylene (LDPE),
polyethylene terephthalate (PET), polystyrene (PS), and other plastic
polymers (OTHER; N.A.). 616
Figure 6 Relationships between remote sensing and fieldwork operations. 618
xcvi List of Figures
List of Tables
Chapter 2.1
Table 1 Summary of the main preprocessing steps, the techniques for their application,
and their benefits/drawbacks. 48
Chapter 2.3
Table 1 Reduced resolution assessment. Quantitative results on the Hyp-ALI data set.
Best results among the compared fusion approaches are in boldface. 86
Table 2 Full resolution assessment. Quantitative results on the Hyp-ALI data set. Best
results are in boldface. 86
Chapter 2.4
Table 1 Parameters of the LanceeWilliams update formula for the different
agglomeration methods, together with the definition of the initial
dissimilarity measure. 106
Chapter 2.6
Table 1 Normalized mean squared errors (NMSE) between estimated and reconstructed
abundance fractions by the bilinear and linear mixture models, for the data sets
orchard2 and orchard3, with and without considering shadows. 159
Table 2 Normalized mean squared errors (NMSE) between the estimated and the
reconstructed images by the bilinear and the linear mixture models for the
data sets orchard2 and orchard3, with and without considering shadows. 160
Table 3 Mass fractions of the endmembers for each mixture [25]. 162
Table 4 Evaluation results for the intimate mixture experiment. 164
Chapter 2.7
Table 1 Running times and reconstruction errors of the tested algorithms on the
Houston data set. 198
Chapter 2.8
Table 1 Overview of near-infrared hyperspectral imaging in agricultural products. 215
Table 2 Overview of near-infrared hyperspectral imaging in other food products (fish
and meat). 217
Table 3 Overview of near-infrared hyperspectral imaging in other products. 220
xcvii
Chapter 2.9
Table 1 Landsat 8 imaging bands. 242
Chapter 2.10
Table 1 Studies of remote sensing image classification using ensemble methods
published in journals since 2008. 251
Table 2 Classification results in percentage by using 20 training samples per class. 253
Table 3 Classification performance obtained using the standard method (all the
spectral band) and the proposed method. The table reports the mean class
accuracies (%) and relative standard deviations over 10-fold cross-validation.
The best accuracies are highlighted in bold. 258
Table 4 Classification performance of the SVM [72], EMAP [41], EPF [69], HGF [73],
IFRF [68], and PCA-EPFs [70] methods for the Indian Pines data set with 1%
training samples. Class accuracies, average accuracies (AA), overall
accuracies (OA), and the kappa coefficients, are reported with the relative
standard deviations. For each row, the highest accuracy is shown in bold. 265
Table 5 Classification performance of the SVM [72], EMAP [41], EPF [69], HGF [73],
IFRF [68], and PCA-EPFs [70] methods for the Indian Pines data set with 10%
training samples. Class accuracies, average accuracies (AA), and overall
accuracies (OA), are reported with the relative standard deviations. For each
row, the highest accuracy is shown in bold. 267
Table 6 Classification performance of different filters, i.e., the BF [60], GF [66], RGF
[81], BTF [61], WLS [62], and DTRF [63] on the feature extraction
framework. Class accuracies, average accuracies (AA), overall accuracies
(OA), and kappa coefficients are reported with the relative standard deviations.
For each row, the highest accuracy is shown in bold. 269
Table 7 Classification performance of different filters, i.e., the BF [60], GF [66], RGF
[81], BTF [61], WLS [62], and DTRF [63] on the probability optimization
framework. Class accuracies, average accuracies (AA), overall accuracies
(OA), and kappa coefficients are reported with the relative standard deviations.
For each row, the highest accuracy is shown in bold. 271
Chapter 2.11
Table 1 List of statistical feature descriptors with the respective references divided by
the data source: height from 3D point cloud, amplitude of the return signal,
CHM, or spectral band. 287
Table 2 List of topographic feature descriptors with the respective references divided
by the data source: height from 3D point cloud or CHM. 288
Table 3 List of structural feature descriptors with the respective references divided by
the data source: height from 3D point cloud or return intensity. 289
Table 4 List of VI with the respective references. 290
Table 5 Studies of forest monitoring classified by the type of application and the level
of fusion. 295
xcviii List of Tables
Chapter 2.13
Table1 Root mean squared error (RMSE) for different Gaussian process (GP)
schemes, when the source crops of the training data are low in leaf area
index, and vice verse for the test data. 351
Table 2 Values of physical parameters used for simulating with the PROSAIL model,
corresponding to wheat. 362
Chapter 3.1
Table 1 List of the main remote sensing imaging spectrometer instruments (more than
hundreds of spectral channels) in Earth and Planetary science, with their main
characteristics (date of arrival, mission platform, planetary body, spectral
range, maximum number of recorded wavelength). 373
Chapter 3.2
Table 1 Observed fields. 435
Table 2 Correlation coefficients between SPAD readings and estimated chlorophyll
indices. 437
Chapter 3.3
Table 1 Detection of heavy metals at crop fields by using remote sensing. 458
Table 2 Reflectance indices for water stress assessment from different species by using
hyperspectral imaging and remote sensing. 461
Table 3 Main applications of hyperspectral imaging in quality evaluation of
agricultural and preharvest products. 464
Chapter 3.5
Table 1 Vis-NIR, IR HSI application articles reviewed. 497
Table 2 Raman research articles reviewed. 499
Chapter 3.6
Table 1 Summary of representative hyperspectral imaging systems and their medical
applications. 534
List of Tables xcix
Personal Thinking and
Acknowledgments
It has been an amazing journey. It allowed me to realize how spread hyper-
spectral and multispectral cameras are in a more and more complex world that
looks for fast and reliable responses. Also it allowed me to see how the data
mining/chemometrics/multivariate data analysis is faced from different per-
spectives depending on the case, the application, and the educational back-
ground of the researcher. And this helped me to acquire a knowledge that is
difficult to acquire otherwise. This book has encouraged me to continue with
further projects (like my immediate one AVITechdArtificial Vision Tech-
nologies research group, granted by IKERBASQUE, the Basque Foundation
for Science) and making more available the knowledge (with courses) and the
methods (with www.hypertools.org).
Rephrasing one friend of mine (Dr. Manel Bautista), “one image is worth
1000 spectra.” He might be right, but I would add “depending on the wave-
length you are looking at.” And, of course, the type of camera, radiation, and
algorithms for obtaining that image, etc. But all in all, the spirit of this sen-
tence makes me forecast that we will see real-time applications of hyper-
spectral and multispectral cameras in many different fields in the near future.
Lastly, I would like to express my deepest gratitude to all the invited au-
thors who have been part in this project. Without their wise contribution and
their advices, this book would have never been possible.
lxxvii
http://www.hypertools.org
Also, I would like to thank all the people who, in one way or another, were
involved in the development of this book.
Bilbao, July 2019
José Manuel Amigo
Ikerbasque Research Professor (July 2019ePresent)
Distinguished Professor of the University of Basque Country, Spain
(July 2019ePresent)
Associate Professor of the University of Copenhagen, Denmark
(January 2011eJune 2019)
Guest Professor of the Federal University of Pernambuco, Brazil
(January 2017eApril 2018)
lxxviii Personal Thinking and Acknowledgments
Preface
This book offers a wide overview of modern hyperspectral and multispectral
imagings (HSI and MSI, respectively), the ways of obtaining them, the most
important algorithms used to extract the relevant information hidden in them,
and the different research fields that are having important benefits using them.
Nowadays, cameras that are able to measure at wavelengths where the human
being eyes cannot are becoming more and more available. From the first ap-
plications in remote sensing to the ultramodern hyperspectral microscopes,
there have been around 40 years of evolution in sensing capability, reliability,
and portability of the devices and improvement in the data/image handling and
analysis. This evolution has made it possible that nowadays it is normal to find
general and tailored HSI or MSI devices in laboratories and industries.
This breakthrough has promoted that scientists coming from different
disciplines must face the analysis of the massive amount of information lying
in HSI. Therefore, scientists with different points of view must handle similar
data structures. And it is here that the spirit of this book resides. This book
collects, for the first time, examples and algorithms used by the different
communities using HSI. The scientific communities represented here (remote
sensing, chemometrics, food science, pharmaceutics, forensics, art, analytical
chemistry, medicine, etc.) are a clear example of how spread and how
attractive HSI technology is. This books raises as an example that even
analyzing different samples (potatoes, a tablet, the surface of a planet, or an
artwork) we can find tailored equipment and we can use the same (or similar)
algorithms. That is why this book is addressed to graduate and postgraduate
students, researchers in many different fields, industries, and practitioners in
any field dealing with any kind of HSI or MSI.
This book contains chapters written by different invited authors in an in-
dividual manner. All of them are renowned experts in their fields. Despite the
fact of the individuality of the chapters, they have been meticulously chosen
and arranged to represent a global understanding of what HSI and MSI are and
how to analyze them. This is why the book is divided into three major sections.
The first section introduces the basic spectroscopic and instrumental
concepts in a very general manner. This was done in this way for two main
reasons: (1) There are fundamental and basic concepts about spectroscopy
(visible, near and middle infrared, Raman, X-ray, etc.) that can be found in
well-known text books and (2) technology is continuously advancing, and it
lxxv
was decided that the essential aspects must be covered, acknowledging that
there might be released new advances by the time this book is published.
The second section is devoted to explain in detail different aspects in the
analysis of HSI and MSI images. The chapters are arranged in a logical
connecting thread when dealing with the application of methods, while I must
say that this arrangement might vary depending of the type of HSI and their
final aim. In that sense, the chapters deal with spatial and spectral pre-
processing, image compression, pansharpening, exploratory analysis, spectral
unmixing/multivariate curve resolution together with finding endmembers,
regression, classification, image fusion, time series analysis, and statistical
analysis. All the chapters are nicely conducted by the authors, and they contain
dozens of examples. Moreover, most of the raw HSI and MSI algorithms are
open source or they are available upon request.
The third section is the final demonstration of the wide applicative range
of HSI and MSI technology. Covering all the application areas is almost
impossible. That is why the most known ones have been chosen. The section
starts, obviously, with different applications in remote sensing. Three chapters
collect applications in natural landscapes, anthropogenic activities, and
vegetation and crops (precision agriculture). Then, the following chapters
show how HS and MS cameras can be adapted to more laboratory and in-
dustrial applications (e.g., food industry, biochemistry, medicine, pharma-
ceutical industry, and artwork). Since the physical space of the book was
limited, I decided to include a final chapter that shows different fields in which
HSI and MSI are also used (e.g., forensics, waste sorting/recycling, archae-
ology, and entomology).
Being aware that there are topics, algorithms, and fields of expertise that
could have been included in the book (maybe for a new edition), the book
represents anoverall vision of HSI and MSI, and it includes an extensive
bibliography.
lxxvi Preface
Chapter 1.1
Hyperspectral and
multispectral imaging: setting
the scene
José Manuel Amigo*
Professor, Ikerbasque, Basque Foundation for Science; Department of Analytical Chemistry,
University of the Basque Country, Spain; Chemometrics and Analytical Technologies, Department
of Food Science, University of Copenhagen, Denmark
*Corresponding author. e-mail: jmar@life.ku.dk
1. Images: basic concepts, spatial resolution, and spectral
information
It might be a bit odd to start a book about hyperspectral imaging (HSI) and
multispectral imaging (MSI) by defining what an “image” is. Nevertheless, I
found it very appropriated, since nowadays the literature is full of surnames or
forenames adopted depending on the type of images we are talking about.
Terms like chemical imaging, confocal imaging, HSI, MSI, satellite imaging,
microscope imaging, etc., are filling the papers, depending on the type of
device used for acquiring the image or sometimes the use we want to give to
the image. Thus, according to the Oxford Dictionary, an image is the repre-
sentation of the external form of a person or thing in art. It is also a visible
impression obtained by a camera, telescope, microscope, or other device, or
displayed on a computer video screen [1]. For our purpose, let us say that an
image is a bidimensional representation of a surface produced by any device
that has the ability to obtain information in an XeY direction of the surface in
a correlated manner.
1.1 Spatial resolution
From my point of view, the most appropriate concept of image is the math-
ematical one, “an image is a point or set formed by mapping from another
point or set.” That is, to create an image, you need, at least, two-point sets.
Putting together both definitions, it is clear that these two-point sets must be
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00001-8
Copyright © 2020 Elsevier B.V. All rights reserved. 3
https://doi.org/10.1016/B978-0-444-63977-6.00001-8
somehow spatially correlated, providing us the indirect definition of pixel, the
second most used term in imaging. A pixel is the spatial subdivision of images.
They are unique pieces of information that are, as well, spatially correlated. In
other words, a pixel is affected by the surrounding pixels in such a way that the
information contained in one of them depends on the information that the
surrounding pixels contain (i.e., neighbors).
A clear distinction must be made between the total amount of pixels and
the size of that pixel with respect to the full image that it is being measured. If
an image is the spatial representation of a surface, and that image is divided
into pixels, the term spatial resolution comes up. According to the interna-
tional standards, the spatial resolution of an image is the total amount of pixels
in which an image is divided. A basic example is that if an image contains X
pixels in the row direction and Y pixels in the column direction, the image has
a spatial resolution of X � Y pixels. Even accepting this as a common prac-
tice, it must be stressed that this definition is incomplete. The spatial resolution
must be always measured in relative terms of distance. For instance, let us give
the example of having a camera that is 10 � 10 pixels. If that camera is taking
the picture of a 1 � 1 m, the real spatial resolution should be said to be
0.01 m2; while if the same camera is taking a picture of 0.5 � 0.5 m, the
spatial resolution should be said to be 0.0025 m2. This will directly address the
need of setting the area of the surface information that every pixel contains.
1.2 Spectral information: types of images
There are different ways of classifying images. One of the most adequate ways
is considering the amount of information that a pixel can contain. The infor-
mation can come from a simple difference in intensities with respect to a
reference, generating one single channel of information per pixel (e.g., scan-
ning electron microscopy (SEM) images). Nevertheless, it is common nowa-
days to find images that contain more channels of information for each pixel.
These are the color-space images, the multispectral images, and the hyper-
spectral images.
1.2.1 Single channel images
Images for which there is only a single value of intensity for each pixel are
called monochannel or single channel images. The values that each pixel can
have vary depending of the type of device taking the image, and they are
normally ranging between certain limits. For instance, Fig. 1 shows one single
channel image of yogurt obtained with confocal laser scanning microscopy
(CLSM) (see Ref. [2] for further details). Single channel images can be
extracted from any image device by choosing one channel of spectral infor-
mation or by using a device that only gives one point of information per pixel
(e.g., CLSM, SEM, atomic force microscopy (AFM), etc.).
4 SECTION j I Introduction
There are many ways of representing a single channel image by using
different color maps. The most popular one is the grayscale color map in
which the intensity value corresponds to a specific value of the grayscale
(denoted with the corresponding color bar in Fig. 1). Normally, the spatial
resolution of these devices trends to be considerably good, arising to micro-
scope scale. The main drawback is normally the lack of chemical information,
since all the information relies on one single value. Therefore, one of the most
common methods to analyze these images is the direct application of
thresholds, grouping the pixels in groups with similar value of pixel (ref digital
image). Coming back to the example in Fig. 1, two different thresholds applied
to the same picture give two different responses. In this case, the threshold
around 24 gives an account of total protein content, while the threshold around
100 gives an account of microparticulated whey protein [2].
1.2.2 Color-space images
Color-space images are the images that try to mimic the human vision. They
are composed normally by three channels of spectral information, the red
(around 700 nm), green (around 550 nm), and blue (around 450 nm), that
combined are able to recreate real colors in what is known as the RGB color
space (image denoted as real color in Fig. 2) [3]. It is important to remark that
the RGB is not the only color space that is used in this type of images. There
are many ways of coding the color in other color spaces (like the
hueesaturationevalue color-space or the luminosity-Red to Green-Blue
gradient (L*a*b*), among others [3]) (Fig. 2).
Color-space images are known for many years, and the technology for
obtaining them is continuously advancing. Defining that technology is out of
FIGURE 1 Confocal laser scanning microscopy image of a yogurt sample. The image is one of
the images used in Ref. [2]. The right part of the figure shows the histogram of the grayscale values
and the result of applying two different threshold values (24 for protein and 100 for micro-
particulated whey protein).
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 5
this book chapter. However, it is important to remark that these images have
normally a high spatial resolution, and once the illumination and the focal
distance is controlled, they can be extremely powerful devices with limited
chemical information. For instance, a flatbed scanner in the RGB mode can be
an extraordinary analytical tool for specific cases since they have a high spatial
resolution, the light income is constant and the focal distance is normally fixed
[4e6].
1.2.3 Multiband images
Multiband or multispectral images are those that capture individual images at
specific wave numbers or wavelengths, frequently taken by specific filters or
LEDs, across the electromagnetic spectrum (normally the visible (VIS) and
near-infrared (NIR) regions [7]. Multispectral images can be considered as
special case of hyperspectralimages in which the wavelength range collected
cannot be considered as continuous. That is, instead a continuous measure-
ment between a certain wavelength range, the multispectral images contain
information in discrete and specific wavelengths. Fig. 3 shows an example of a
FIGURE 2 Real color picture in RGB color space of a butterfly, and representation of the red,
green, and blue monochannels using the color map displayed in the right part of the figure. The two
images in the bottom are the transformed image in L*a*b* color space.
6 SECTION j I Introduction
10 euros paper note that has been measured at 18 different wavelengths. That
is, every single pixel contains the specific information collected at 18 different
wavelengths. As it can be observed in the figure, when the sample is irradiated
with light at different wavelengths, specific information is obtained. Each
individual image can be considered as a single channel image. Therefore, it is
mandatory to place the corresponding values of the color intensities obtained
in each individual image.
As we will see in further chapters, the fact of differentiating MSI from HSI
is due to the different treatment that must be given to the images. The spectra
obtained with MSI cannot be considered spectra, since normally the spectral
signatures are measured at nonequidistant discrete wavelengths. It was applied
in remote sensing, and it was the precursor of the hyperspectral images. A
good example of MSI applied in remote sensing is the well-known Landsat
satellite [8].
1.2.4 Hyperspectral images
Hyperspectral images are the images in which one continuous spectrum is
measured for each pixel [9]. Normally, the spectral resolution is given in
nanometers or wave numbers (Fig. 4).
Hyperspectral images can be obtained from many different electromagnetic
measurements. The most popular are visible (VIS), NIR, middle infrared
FIGURE 3 Multispectral image taken to a 10 euros paper note (top left). The top right part shows
the intensities of the 19 different wavelengths for two pixels. The bottom part shows different
single channel pictures extracted for eight channels.
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 7
(MIR), and Raman spectroscopy. Nevertheless, there are many other types of
HSI that are gaining popularity like confocal laser microscopy scanners that
are able to measure the complete emission spectrum at certain excitation
wavelength for each pixel, Terahertz spectroscopy, X-ray spectroscopy, 3D
ultrasound imaging, or even magnetic resonance.
Hyperspectral images are the only type of images where we can talk about
spectral resolution (also known as radiometric resolution in remote sensing
field). The spectral resolution is defined as the interval or separation (gap)
between different wavelengths measured in a specific wavelength range.
Obviously, the more bands (or spectral channels) acquired in a smaller
wavelength range, the higher the spectral resolution will be.
FIGURE 4 Representation of the image of a cookie measured with a hyperspectral camera in
the wavelength range of 940e1600 nm (near infrared, NIR) with a spectral resolution of 4 nm.
The spectra obtained in two pixels are shown and the false color image (single channel image)
obtained at 1475 nm. The single channel image selected highlighted three areas of the
cookie where water was intentionally added. This water is invisible in the VIS region (nothing
can be appreciated in the real color picture). Nevertheless, water is one of the main elements that
can be spotted in NIR.
8 SECTION j I Introduction
2. Data mining: chemometrics
2.1 Structure of a hyperspectral image
A hyperspectral or multispectral image can be visualized as a hypercube of
data (Figs. 3 and 4). The hypercube is defined by three dimensions: Two
spatial (X and Y) and one spectral (l) [9]. The mathematical notation will be,
then, a hypercube D will have dimensions (X � Y � l) [9]. This structure
contains all the chemical information related to the surface measured. That is,
hyperspectral data cubes are normally multicomponent systems. The pixels
measured seldom contain selective wavelengths for a specific component since
they trend to contain mixed information of more than one component.
Moreover, it also contains artifacts like the spectral noise, spatial interferences,
and redundant information. Therefore, there is a strong need to extract the
desired information and get rid of the noise and further artifacts. As we will
see further in the book, there is a plethora of algorithms that are able to extract
the desired information from the data cube, and there are more and more
coming due to the generation of faster computers and more reliable sensors.
2.2 Chemometrics
It can be said without mistake that one of the major reasons for the expansion
of HSI and MSI is the integration of data mining to extract the relevant in-
formation from the data cube in a multivariate fashion. Most of the informa-
tion gathered with HSI and MSI can be considered as chemical information.
Therefore, it is also called chemometrics. Chemometrics is basically data
mining applied to chemical information by using mathematical, statistical, and
data analysis methods to achieve objective data evaluation by extracting the
most important information from related and unrelated collections of chemical
data by using mathematical and statistic tools [10].
The main aim of chemometrics is to provide a final image where selective
information for a specific component can be found (in terms of concentration/
quantitative or presence/qualitative). Nevertheless, one of the major problems
of chemometrics is that sometimes it becomes cumbersome to know which
method to apply in each situation [9]. This will be unraveled and defined
during the book. Fig. 5 gives an account of the major building blocks of data
mining/chemometrics application in HSI and MSI. This flowchart is merely a
guidance, and the methods included there are not exclusive for the building
blocks. Also, the path to follow is strongly dependent of the type of analysis
and the final target.
The main building blocks in the analysis of HSI and MSI images (Fig. 5)
are preprocessing, pattern recognition/exploration, resolution/spectral unmix-
ing, segmentation, regression, classification, and image processing [9]. Each
one of them aims at different purposes:
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 9
2.2.1 Preprocessing
Sometimes this is a previous step that does not have the deserved importance,
and, nevertheless, it is the main responsible for obtaining optimal results when
any multivariate data model is applied afterward. The presence of erroneous or
missed data values (e.g., dead pixels [7]), noninformative background, or
extreme outliers; or the presence of spatial and spectral artifact (e.g., scattering
or atmospheric influence) are aspects that must be considered way before or
even during the modeling part. There are many methods for minimizing
artifacts in our data or to highlight information on it (in both spectral and
FIGURE 5 Comprehensive flowchart of the analysis of hyperspectral and multispectral im-
ages. ANN, artificial neural networks; AsLS, asymmetric least squares; CLS, classical least
squares; EMSC, extended multiplicative scatter correction; FSW-EFA; fixed size window-
evolving factor analysis; ICA, independent component analysis; LDA, linear discriminant
analysis; MCR, multivariate curve resolution; MLR, multiple linear regression; MSC, multi-
plicative scatter correction; NLSU, nonlinear spectral unmixing; OPA, orthogonal projection
approaches; PCA, principal component analysis; PLS-DA, partial least squares-discriminant
analysis; PLS, partial least squares; SIMCA, soft independent modeling of class analogy;
SIMPLISMA, simple-to-use interactive self-modeling mixture analysis; SNV, standard normal
variate; SVM, support vectors machine; WLS, weighted least squares. Partiallyextracted and
modified from J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis.
A tutorial, Analytica Chimica Acta 896 (2015) 34e51. doi:10.1016/j.aca.2015.09.030. with
permission of Elsevier.
10 SECTION j I Introduction
spatial directions). And, luckily, there are many algorithms that can help in this
quest. Nevertheless, the decision of the proper preprocessing method is not
sometimes straightforward, and normally is based in the combination of
different methods to achieve a preprocessed data cube that, still, needs to be
processed properly.
2.2.2 Pattern recognition/exploration
Pattern recognition is, among the building blocks of Fig. 5, the only ones that
can be purely denoted as not supervised (or unsupervised). They do not need
a previous step of calibration (training), neither a decision step (e.g., number
of components needed) in order to find hidden patterns in the data. The
purpose of the unsupervised methods is to identify relationships between
pixels, without any prior knowledge of classes or groups. They are used to
give a first overview of the main sources of variance (variability) in the
images. Among them, the most common method is principal component
analysis (PCA). PCA is useful in order to elucidate the complex nature of
HSI and MSI multicomponent systems by using mapping and displaying
techniques [9,11].
2.2.3 Segmentation
Segmentation methods compile all the clustering methodologies and dendro-
grams [12]. They divide the pixels in different groups considering their
spectral similarities and dissimilarities. And even being unsupervised methods
(no training step needed), there is a step in which a decision should be made.
In the case of clustering, it is essential to guess the final number of clusters,
and in dendrograms, a threshold must be set in order to group the pixels. Even
though segmentation methods group the pixels according to their similarity,
they cannot be considered as classification methods, since no training step is
used.
2.2.4 Curve resolution methods/spectral unmixing
Curve resolution or spectral unmixing methods aim at resolving mixtures that
each individual pixel might contain, given the correct number of constituents
[13,14]. The final result is a set of selective images for each constituent and
their pure spectral profile. The main difference with explorative methods like
PCA is that curve resolution methods do not aim at studying the main sources
of variation in the data, but at giving an account of the hidden physicochemical
behavior of each constituent in each pixel. A big debate could be stablished
concerning the nature of curve resolution methods. In some aspects, they
behave as unsupervised methods. Nevertheless, many of the occasions they
rely in giving good initial estimations and proper spectral and spatial con-
straints to obtain a suitable response.
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 11
2.2.5 Regression and classification
Calculating the concentration of several compounds in an image (regression)
and, specially, the classification of elements in different well-defined cate-
gories (classification) is one of the major targets in HSI and MSI analysis.
Regression and classification methods are pure supervised methods, since a
robust and reliable set of samples of well-known concentration or well-known
category is needed for the essential step of training of the model (calibration
step). Once the training is perfectly performed, the properties or the classes are
predicted in new images in a pixel-by-pixel manner [15]. Many algorithms for
linear or nonlinear training models like partial least squares (PLS), multilinear
regression, support vectors machine, or artificial neural networks can be found
in regression and their adaptation for classification purposes (e.g.,
PLS-discriminant analysis). Moreover, many algorithms can be found being
specifically designed for a purpose, like the single class approach that SIMCA
(soft independent modeling of class analogy) offers [16]. Being supervised
methods, the core of their reliability depends on the mandatory validation step.
Validation (internal cross-validation or external validation) is the only tool able
to give a real account of the ability of the model to predict.
2.2.6 Image processing
Once one selective image for each individual constituent is achieved, the final
aim might be to analyze the distribution, amount, shape of those constituents
in the surface measured. This is directly linked to the well-known digital
imaging processing methodologies [3]. There is, again, a plethora of algo-
rithms that can be used for many different purposes. It is not the aim of this
book chapter to focus on those methods. Therefore, we encourage the readers
to read the provided references to have a better account of them [3].
3. Growing the number of application fields of HSI and MSI
The evolution in HSI and MSI cameras in the market has grown exponentially
since the first works in remote sensing were published in the late 1970s,
beginning of 1980s. The first scientific instrument capable of measuring MSI
images was developed by Goetz et al. [17]. It was called the Shuttle Multi-
spectral Infrared Radiometer (SMIRR), and it was placed in the second flight
of the space shuttle in 1981 [17,18]. SMIRR was able to measure 10 narrow
bands, and the main purpose was the identification of minerals in the surface of
the planet. Seeing the excellent results, Goetz et al. proposed the creation of
what it would be the first HSI camera, the Airbone Imaging Spectrometer
(AIS) [19]. AIS was the first HSI camera that was able to collect 128 spectral
bands in the range of 1200e2400 nm with a spectral resolution of 9.6 nm. The
detector was able to collect a line of 32 pixels moving as a scanner (what is
commonly known line mapping or push broom systems [19]).
12 SECTION j I Introduction
From this point on, the technological advances in HSI and MSI have
generated the eruption of the application fields within the area of remote
sensing [20]. These technological advances are due to the rapid increasing in
the sensing technology, higher computational capability, more robust and
versatile instruments that can be adapted in different scenarios, and, of
course, improvement in the data mining algorithms for processing the
overwhelming amount of data that were being generated [21e23]. Airborne
and satellite imaging opened the applications in the mineralogy [17],
oceanography [24], environmental monitoring and water resources man-
agement [25], vegetation [23,26], or precision agriculture [27]. Moreover,
soon the scientific knowledge generated to create cameras working on the
visible and NIR spectral range was also applied to other spectral radiations
like MIR, Raman, nuclear magnetic resonance (NMR), fluorescence, X-ray,
or even Terahertz spectroscopy, exponentially increasing the amount of ap-
plications of HSI and MSI cameras [28].
Another of the major breakthroughs was produced when the HSI and MSI
started to be adapted in more controlled environments. Normally, there is a
“from minor to major” path in sciences. That is, new devices are developed in
the laboratories, and then the devices go out of the laboratory environment.
With HSI and MSI, the evolution was “from major to minor,” from satellites
scanning the planet to the laboratory. Fields like biochemistry [29],
food processing [27,30e34], pharmaceutical research and processing
[12,35e38], forensic investigations [39,40], artwork and cultural heritage
[41,42], medical research [43], recycling [9,44,45], among other areas started
to use the same cameras as in remote sensing but adapted to their particular
problem.
All in all, and to finish this introductory chapter, I can certify that even
though HSI and MSI are a science that is around 50 years old, it is still new
and exciting. And there is an exciting and challenging future ahead of us,
where faster and more reliable hyperspectral cameras willbe developed and,
consequently, the data analysis technology to analyze them.
References
[1] O. university Press, Oxford dictionary, (n.d.). https://www.oxforddictionaries.com/.
[2] I.C.I.C. Torres, J.M. Amigo Rubio, R. Ipsen, J.M. Amigo, R. Ipsen, Using fractal image
analysis to characterize microstructure of low-fat stirred yoghurt manufactured with
microparticulated whey protein, Journal of Food Engineering 109 (2012) 721e729, https://
doi.org/10.1016/j.jfoodeng.2011.11.016.
[3] R.C. Gonzalez, R.E. Woods, S.L. Eddins, Digital Image Processing Using Matlab, 2004,
https://doi.org/10.1117/1.3115362.
[4] M. Vidal, J.M.M. Amigo, R. Bro, F. van den Berg, M. Ostra, C. Ubide, Image analysis for
maintenance of coating quality in nickel electroplating baths e real time control, Analytica
Chimica Acta 706 (2011) 1e7, https://doi.org/10.1016/j.aca.2011.08.007.
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 13
https://www.oxforddictionaries.com/
https://doi.org/10.1016/j.jfoodeng.2011.11.016
https://doi.org/10.1016/j.jfoodeng.2011.11.016
https://doi.org/10.1117/1.3115362
https://doi.org/10.1016/j.aca.2011.08.007
[5] L. de Moura França, J.M. Amigo, C. Cairós, M. Bautista, M.F. Pimentel, J. Manuel
Amigo, C. Cair os, M. Bautista, M. Fernanda Pimentel, Evaluation and assessment of
homogeneity in images. Part 1: unique homogeneity percentage for binary images,
Chemometrics and Intelligent Laboratory Systems 171 (2017), https://doi.org/10.1016/
j.chemolab.2017.10.002.
[6] N.C. da Silva, L. de Moura França, J.M. Amigo, M. Bautista, M.F. Pimentel, Evaluation and
assessment of homogeneity in images. Part 2: homogeneity assessment on single channel
non-binary images. Blending end-point detection as example, Chemometrics and Intelligent
Laboratory Systems 180 (2018), https://doi.org/10.1016/j.chemolab.2018.06.011.
[7] M. Vidal, J.M. Amigo, Pre-processing of hyperspectral images. Essential steps before image
analysis, Chemometrics and Intelligent Laboratory Systems 117 (2012) 138e148, https://
doi.org/10.1016/j.chemolab.2012.05.009.
[8] NASA, Landsat Science, (n.d.). https://www.oxforddictionaries.com/.
[9] J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis. A tutorial,
Analytica Chimica Acta 896 (2015) 34e51, https://doi.org/10.1016/j.aca.2015.09.030.
[10] D.L. Massart, B.G.M. Vandeginste, J.M.C. Buydens, S. de Jong, P.J. Lewi, J. Smeyers-
Verberke, L.M.C. Buydens, S. De Jong, J. Smeyers-Verbeke, Handbook of Chemometrics
and Qualimetrics, 1997. https://doi.org/10.1016/S0922-3487(97)80056-1.
[11] A.K. Smilde, R. Bro, Principal component analysis (tutorial review), Analytical Methods 6
(2014) 2812e2831. https://doi.org/10.1039/c3ay41907j.
[12] J.M. Amigo, J. Cruz, M. Bautista, S. Maspoch, J. Coello, M. Blanco, Study of pharma-
ceutical samples by NIR chemical-image and multivariate analysis, Trends in Analytical
Chemistry 27 (2008). https://doi.org/10.1016/j.trac.2008.05.010.
[13] F. Franch-Lage, J.M. Amigo, E. Skibsted, S. Maspoch, J. Coello, Fast assessment of the
surface distribution of API and excipients in tablets using NIR-hyperspectral imaging, In-
ternational Journal of Pharmaceutics 411 (2011) 27e35. https://doi.org/10.1016/j.ijpharm.
2011.03.012.
[14] A. de Juan, R. Tauler, Multivariate curve resolution (MCR) from 2000: progress in concepts
and applications, Critical Reviews in Analytical Chemistry 36 (2006) 163e176. https://doi.
org/10.1080/10408340600970005.
[15] C. Ravn, E. Skibsted, R. Bro, Near-infrared chemical imaging (NIR-CI) on pharmaceutical
solid dosage forms-comparing common calibration approaches, Journal of Pharmaceutical
and Biomedical Analysis 48 (2008) 554e561. https://doi.org/10.1016/j.jpba.2008.07.019.
[16] S. Wold, W.J. Dunn, E. Johansson, J.W. Hogan, D.L. Stalling, J.D. Petty, T.R. Schwartz,
Application of Soft Independent Method of Class Analogy (SIMCA) in Isomer Specific
Analysis of Polychlorinated Biphenyls, 2009, pp. 195e234. https://doi.org/10.1021/bk-
1985-0284.ch012.
[17] A.F.H. Goetz, L.C. Rowan, M.J. Kingston, Mineral identification from orbit: initial results
from the shuttle multispectral infrared radiometer, Science 218 (1982) 1020e1024. https://
doi.org/10.1126/science.218.4576.1020, 80-.
[18] J.S. MacDonald, S.L. Ustin, M.E. Schaepman, The contributions of Dr. Alexander F.H.
Goetz to imaging spectrometry, Remote Sensing of Environment 113 (2009). https://doi.org/
10.1016/j.rse.2008.10.017.
[19] G. Vane, A.F.H. Goetz, J.B. Wellman, Airborne imaging spectrometer: a new tool for
remote sensing, IEEE Transactions on Geoscience and Remote Sensing GE-22 (2013)
546e549. https://doi.org/10.1109/tgrs.1984.6499168.
[20] J.B. Campbell, R.H. Wynne, Introduction to Remote Sensing, 2011.
14 SECTION j I Introduction
https://doi.org/10.1016/j.chemolab.2017.10.002
https://doi.org/10.1016/j.chemolab.2017.10.002
https://doi.org/10.1016/j.chemolab.2018.06.011
https://doi.org/10.1016/j.chemolab.2012.05.009
https://doi.org/10.1016/j.chemolab.2012.05.009
https://www.oxforddictionaries.com/
https://doi.org/10.1016/j.aca.2015.09.030
https://doi.org/10.1016/S0922-3487(97)80056-1
https://doi.org/10.1039/c3ay41907j
https://doi.org/10.1016/j.trac.2008.05.010
https://doi.org/10.1016/j.ijpharm.2011.03.012
https://doi.org/10.1016/j.ijpharm.2011.03.012
https://doi.org/10.1080/10408340600970005
https://doi.org/10.1080/10408340600970005
https://doi.org/10.1016/j.jpba.2008.07.019
https://doi.org/10.1021/bk-1985-0284.ch012
https://doi.org/10.1021/bk-1985-0284.ch012
https://doi.org/10.1126/science.218.4576.1020
https://doi.org/10.1126/science.218.4576.1020
https://doi.org/10.1016/j.rse.2008.10.017
https://doi.org/10.1016/j.rse.2008.10.017
https://doi.org/10.1109/tgrs.1984.6499168
[21] S.C. Yoon, B. Park, Hyperspectral image processing methods, in: Food Eng. Ser., 2015,
pp. 81e101. https://doi.org/10.1007/978-1-4939-2836-1_4.
[22] L. Wang, C. Zhao, Hyperspectral Image Processing, 2015. https://doi.org/10.1007/978-3-
662-47456-3.
[23] A. Pelizzari, R.A. Goncalves, M. Caetano, Computational Intelligence for Remote Sensing,
2008. https://doi.org/10.1007/978-3-540-79353-3.
[24] S. Martin, An Introduction to Ocean Remote Sensing, 2013. https://doi.org/10.1017/
CBO9781139094368.
[25] P.S. Thenkabail, Remote Sensing Handbook: Remote Sensing of Water Resources, Di-
sasters, and Urban Studies, 2015. https://doi.org/10.1201/b19321.
[26] P.S. Thenkabail, R.B. Smith, E. De Pauw, Hyperspectral vegetation indices and their re-
lationships with agricultural crop characteristics, Remote Sensing of Environment (2000).
https://doi.org/10.1016/S0034-4257(99)00067-X.
[27] B. Park, R. Lu, Hyperspectral Imaging Technology in Food and Agriculture, 2015. https://
doi.org/10.1007/978-1-4939-2836-1.
[28] S. Delwiche, J. Qin, K. Chao, D. Chan, B.-K. Cho, M. Kim, Line-scan hyperspectral im-
aging techniques for food safety and quality applications, Applied Sciences 7 (2017) 125.
https://doi.org/10.3390/app7020125.
[29] R. Vejarano, R. Siche, W. Tesfaye, Evaluation of biological contaminants in foods by
hyperspectral imaging: a review, International Journal of Food Properties 20 (2017)
1264e1297. https://doi.org/10.1080/10942912.2017.1338729.
[30] J.M. Amigo, I. Martı́, A. Gowen, Hyperspectral imaging and chemometrics. A perfect
combination for the analysis of food structure, composition and quality, Data Handling in
Science and Technology 28 (2013) 343e370. https://doi.org/10.1016/B978-0-444-59528-7.
00009-0.
[31] S. Munera, J.M. Amigo, N. Aleixos, P. Talens, S. Cubero, J. Blasco, Potential of VIS-NIR
hyperspectral imaging and chemometric methods to identify similar cultivars of nectarine,
Food Control 86 (2018). https://doi.org/10.1016/j.foodcont.2017.10.037.
[32] X. Zou, J. Zhao, Nondestructive Measurement in Food and Agro-Products, 2015. https://doi.
org/10.1007/978-94-017-9676-7.
[33] Y. Liu, H. Pu, D.W. Sun, Hyperspectral imaging technique for evaluating food quality and
safety duringvarious processes: a review of recent applications, Trends in Food Science &
Technology 69 (2017) 25e35. https://doi.org/10.1016/j.tifs.2017.08.013.
[34] D. Wu, D.W. Sun, Advanced applications of hyperspectral imaging technology for food
quality and safety analysis and assessment: a review e Part II: fundamentals, Innovative
Food Science and Emerging Technologies 19 (2013) 1e14. https://doi.org/10.1016/j.ifset.
2013.04.014.
[35] J.X. Wu, D. Xia, F. Van Den Berg, J.M. Amigo, T. Rades, M. Yang, J. Rantanen, A novel
image analysis methodology for online monitoring of nucleation and crystal growth during
solid state phase transformations, International Journal of Pharmaceutics 433 (2012) 60e70.
https://doi.org/10.1016/j.ijpharm.2012.04.074.
[36] A.A. Gowen, C.P. O’Donnell, P.J. Cullen, S.E.J. Bell, Recent applications of Chemical
Imaging to pharmaceutical process monitoring and quality control, European Journal of
Pharmaceutics and Biopharmaceutics 69 (2008) 10e22. https://doi.org/10.1016/j.ejpb.2007.
10.013.
[37] M. Khorasani, J.M. Amigo, C.C. Sun, P. Bertelsen, J. Rantanen, Near-infrared chemical
imaging (NIR-CI) as a process monitoring solution for a production line of roll compaction
Hyperspectral and multispectral imaging: setting the scene Chapter j 1.1 15
https://doi.org/10.1007/978-1-4939-2836-1_4
https://doi.org/10.1007/978-3-662-47456-3
https://doi.org/10.1007/978-3-662-47456-3
https://doi.org/10.1007/978-3-540-79353-3
https://doi.org/10.1017/CBO9781139094368
https://doi.org/10.1017/CBO9781139094368
https://doi.org/10.1201/b19321
https://doi.org/10.1016/S0034-4257(99)00067-X
https://doi.org/10.1007/978-1-4939-2836-1
https://doi.org/10.1007/978-1-4939-2836-1
https://doi.org/10.3390/app7020125
https://doi.org/10.1080/10942912.2017.1338729
https://doi.org/10.1016/B978-0-444-59528-7.00009-0
https://doi.org/10.1016/B978-0-444-59528-7.00009-0
https://doi.org/10.1016/j.foodcont.2017.10.037
https://doi.org/10.1007/978-94-017-9676-7
https://doi.org/10.1007/978-94-017-9676-7
https://doi.org/10.1016/j.tifs.2017.08.013
https://doi.org/10.1016/j.ifset.2013.04.014
https://doi.org/10.1016/j.ifset.2013.04.014
https://doi.org/10.1016/j.ijpharm.2012.04.074
https://doi.org/10.1016/j.ejpb.2007.10.013
https://doi.org/10.1016/j.ejpb.2007.10.013
and tableting, European Journal of Pharmaceutics and Biopharmaceutics 93 (2015). https://
doi.org/10.1016/j.ejpb.2015.04.008.
[38] A.V. Ewing, S.G. Kazarian, Recent advances in the applications of vibrational spectroscopic
imaging and mapping to pharmaceutical formulations, Spectrochimica Acta Part A: Mo-
lecular and Biomolecular Spectroscopy 197 (2018) 10e29. https://doi.org/10.1016/j.saa.
2017.12.055.
[39] P. Chemistry, Near promising future of near infrared hyperspectral imaging in forensic
sciences, Journal of Indexing and Metrices 25 (2014) 6e9. https://doi.org/10.1255/nirn.
1443.
[40] G.J. Edelman, E. Gaston, T.G. Van Leeuwen, P.J. Cullen, M.C.G. Aalders, Hyperspectral
imaging for non-contact analysis of forensic traces, Forensic Science International 223
(2012) 28e39. https://doi.org/10.1016/j.forsciint.2012.09.012.
[41] C. Cucci, M. Picollo, Reflectance Spectroscopy Safeguards Cultural Assets, SPIE News-
room, 2013. https://doi.org/10.1117/2.1201303.004721.
[42] M. Bacci, C. Cucci, A.A. Mencaglia, A.G. Mignani, Innovative sensors for environmental
monitoring in museums, Sensors 8 (2008) 1984e2005. https://doi.org/10.3390/s8031984.
[43] G. Lu, B. Fei, Medical hyperspectral imaging: a review, Journal of Biomedical Optics 19
(2014) 010901. https://doi.org/10.1117/1.jbo.19.1.010901.
[44] M. Vidal, A. Gowen, J.M. Amigo, NIR hyperspectral imaging for plastics classification,
Journal of Indexing and Metrices (2012). https://doi.org/10.1255/nirn.1285.
[45] D. Caballero, M. Bevilacqua, J. Amigo, Application of hyperspectral imaging and che-
mometrics for classifying plastics with brominated flame retardants, Journal of Spectral
Imaging 8 (2019). https://doi.org/10.1255/jsi.2019.a1.
16 SECTION j I Introduction
https://doi.org/10.1016/j.ejpb.2015.04.008
https://doi.org/10.1016/j.ejpb.2015.04.008
https://doi.org/10.1016/j.saa.2017.12.055
https://doi.org/10.1016/j.saa.2017.12.055
https://doi.org/10.1255/nirn.1443
https://doi.org/10.1255/nirn.1443
https://doi.org/10.1016/j.forsciint.2012.09.012
https://doi.org/10.1117/2.1201303.004721
https://doi.org/10.3390/s8031984
https://doi.org/10.1117/1.jbo.19.1.010901
https://doi.org/10.1255/nirn.1285
https://doi.org/10.1255/jsi.2019.a1
Chapter 1.2
Configuration of hyperspectral
and multispectral imaging
systems
José Manuel Amigoa,* and Silvia Grassib
aProfessor, Ikerbasque, Basque Foundation for Science; Department of Analytical Chemistry,
University of the Basque Country, Spain; Chemometrics and Analytical Technologies, Department
of Food Science, University of Copenhagen, Denmark; bDepartment of Food, Environmental and
Nutritional Sciences (DeFENS), Università degli Studi di Milano, Milano, Italy
*Corresponding author. e-mail: jmar@life.ku.dk
1. Introduction
Instrumentation is the key point of any reliable measurement system. In the
field of hyperspectral imaging (HSI) and multispectral imaging (MSI),
instrumentation has suffered an incredible expansion in the very last years due
to the advances in sensing materials. HSI and MSI instrumentation is being
continuously generated increasing the wavelength ranges of the electromag-
netic spectrum and other types of spectroscopy (ultraviolet-visible, NIR, MIR,
Raman, confocal laser fluorescence microscopy, XRI, X-ray computed to-
mography (X-ray CT), TI, or ultrasound imaging (UI)). As we will see further
in this chapter, all HSI and MSI methods, independently from the nature of the
radiation, are a mixture between conventional imaging and conventional
single-point spectroscopy (Fig. 1) in such a way that the combination of both
makes possible to create HSI and MSI devices.
The basic setup of an HSI or MSI system consist of a light source (i.e., a
lighting system), adequate objective lens, a wavelength dispersion device, and
a camera with a 2D detector (Fig. 1).
The configurations shown in Fig. 1 might be different in some scenarios, as
it is well known that single-point spectroscopy can be adapted to map a surface
converting the technique in hyperspectral technique, with the adequate
equipment. Also HSI and MSI configurations will depend on the type of
camera and the final usage. While MSI trends to be closer to an advanced
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00002-X
Copyright © 2020 Elsevier B.V. All rights reserved. 17
https://doi.org/10.1016/B978-0-444-63977-6.00002-X
imaging system, HSI combines perfectly the spectral abilities of wavelength
dispersion devices with the state-of-the-art 2D detectors to produce highly
resolved images. Citing Qin et al. “If conventional imaging tries to answer the
question where and conventional spectroscopy tries to answer the question
what, then hyperspectral (and multispectral) imaging tries to answer the
question where is what” [1].
This chapter primarily focuses on instrumentation for HSI and MSI that is
normally applied in the visible and NIR wavelength range. That is why the first
section (Section 2) deals with what happens when the light interacts with the
matter. Section 3 will show the basic structure of an HSI and MSI image as
well as define what are the main methods to obtain such data structures.
Following sections are focused on showing the most important features of the
main components of cameras: light source (Section 4), wavelength dispersion
devices (Section 5), and detectors (Section 6). To finalize the chapter, the
importance of the calibration of the camera is further discussed (Section 7).
During the reading of the chapter, some key references will be provided (with
further explanations of the important concepts).
2. Lightematter interaction
The main fundamental for HSI and MSI is the fact that light interacts with the
molecules that thesample contains. This interaction will depend on the nature of
the sample (chemical interactions) and the physical properties of the surface
(roughness, harness, compaction level, among others). When a photon is emitted
FIGURE 1 Comparison of the basic setups for conventional imaging, hyperspectral and multi-
spectral cameras, and conventional spectroscopy.
18 SECTION j I Introduction
from a certain light source, they do it with a specific energy and trajectory. That
energy and trajectory will be affected by the interaction with the sample [2]:
First, the energy will decrease, and second the trajectory will change. The en-
ergy will decrease depending mostly on the chemical properties of the mole-
cules of the sample that the photon is hitting [2]. Therefore, when the photon
arrives to the detector, it does it with a different energy, creating the bands that
are characteristic of the spectrum of the molecules. We say that the molecules
absorb certain amount of energy from the photon, allowing the remaining en-
ergy to arrive to the detector. Nevertheless, before the energy (photon with
different energy) arrives to the detector, several effects can occur in its trajec-
tory. Basically, the photon, after hitting the sample, can be absorbed completely
(therefore, converted into heat energy), reflected, or transmitted (Fig. 2).
Absorption: It occurs when the photon at a given frequency hits a mole-
cule (or better, the atoms of that molecule) whose electrons have the same
vibrational frequency (Fig. 2). Then it is said that the electrons of the mole-
cules and the photons are in resonance. And, consequently, the photons will
not arrive to the detector.
Reflection and transmission: Reflection and transmission of photon waves
are due to the fact that the frequencies of the photon waves are not the same than
the natural frequencies of the molecules that they are hitting (or better said, the
vibrational frequencies of the electrons conforming those molecules are not the
same). Consequently, the electrons vibrate for short periods of time with smaller
amplitudes of vibration, and the energy is reemitted as photons with different
frequency. If the object is transparent to the vibrational frequencies of the
photon, the vibrations of the electrons are passed on to neighboring atoms
through the bulk of the material and reemitted on the opposite side of the object.
FIGURE 2 Lightematter interaction. Depiction of the physical and chemical effects that a
photon might have when iterated with matter.
Configuration of hyperspectral Chapter j 1.2 19
Then, the photon is said to be transmitted. If the molecules are opaque to the
frequencies of the photon, the vibrations of the electrons of the molecules in the
surface vibrate for short periods of time and then the energy is reflected,
allowing the photon with different energy to arrive to the detector (Fig. 2).
Depending on the energy of the photon and the properties of the molecules, as
well as the surface characteristics, the photon can be reflected in a specular
mode (reflected with the same angle than the incident) or in a scattered mode
(reflected with different angle than the incident).
Reflection might come with previous transmission from the interior of the
sample. That is, there is certain degree of penetration of the photon. That is,
depending on the energy of that photon and some characteristics of the sample,
the photon will penetrate several micrometers or even millimeters in the
sample, then it will follow a path inside the sample (thus, being affected by
the different vibrational energies that it is crossing) and then reflected toward
the detector (if the trajectory is the adequate) [3]. As example, Fig. 3 shows the
color image of part of a hand. The right part of the figure shows the intensity
image (reflectance) of the image taken at 950 nm where it can be observed the
details of the veins in the fingers, demonstrating that the photons at 950 nm
had enough energy to penetrate certain millimeters the human skin.
Reflection and transmission of light are the two more common modes of
measuring light in HSI and MSI. Especially popular is reflection, which has
been used for many years in important scientific fields like remote sensing or
industrial implementations. As a matter of example, Fig. 2 shows the different
paths that a photon can have when it hits the sample and before it arrives to the
detector. In remote sensing, moreover, there might be an interaction with
dispersed solids in the atmosphere or aerosols, like the clouds. In that case, the
photon can have the same effects as with the sample. Moreover, there might
be photons that are transmitted toward the cloud and arrive to the sample and
photos that are directly reflected to the detector before arriving the sample.
FIGURE 3 RGB picture of part of a hand and the corresponding image taken at 950 nm.
20 SECTION j I Introduction
3. Acquisition modes
HSI and MSI images are basically data cubes with two spatial dimensions
(normally denoted as X and Y directions) and a third dimension with the
spectral information per pixel (l). The cameras to acquire such data cubes can
be classified according to the mechanical procedure to acquire an image. They
can be grouped in spectral scanning (area and snapshot scanning), spatial
scanning (point and line scanning), spatial-spectral scanning [4], and snapshot
imaging [1]. Fig. 4 shows a graphical representation of point, line, and plane
scan configurations.
3.1 Area or plane scanning. Global imaging
The most straightforward way to obtain an HSI or MSI image is by taking a
snapshot of all the spatial information at one single wavelength. Then, the
wavelength can be tuned, and a new snapshot can be taken, allowing the record
of 2D images one wavelength after the other. This is also known as global
imaging, and the sequence of signal at different wavelengths gives a complete
data cube with two spatial dimensions (X and Y) and one spectral dimension
(l). This configuration is the preferred one for MSI systems, where a limited
number of wavelengths are used. Several snapshot approaches are making
inroads in bioimaging, such as tomography [6] and microscopy [7]. The
cameras are normally very fast in the acquisition of images, and they have
affordable prices. The light source is normally the environmental light, if a
FIGURE 4 Point, line, and plane scan configurations in hyperspectral and multispectral (only the
plane scan) imaging devices and the structure of the final data cube of dimensions X � Y � l.
Figure extracted from J.M. Amigo, Practical issues of hyperspectral imaging analysis of solid
dosage forms, Analytical and Bioanalytical Chemistry 398 (2010) 93e109. doi:10.1007/s00216-
010-3828-z. and slightly modified with permission of Springer.
Configuration of hyperspectral Chapter j 1.2 21
multiobjective camera or a camera with tuneable filters is used. Nevertheless,
there are versions of MSI devices using light emission devices as source of
light [8]. The main drawback of these types of cameras is that the chemical
information is normally poor, except for those cameras working with acousto-
optic tunable filters (AOTF) in which a higher amount of wavelengths can be
measured. Another drawback is the fact that the sample must remain still in
order to acquire a sharp image.
3.2 Point scanning. Single-point mapping or whisker-broom
imaging
It is a scanning methodology that consists of the acquisition of one spectrum at a
single spatial location (pixel) by moving the sample and, therefore, giving one-
dimensional spectral information in every measurement. The data cube is then
obtained by multiple scans in two orthogonal spatial directions (X and Y).
These types of configurations result in a time-consuming measurement as it
entails the acquisition of a single spectrum at a time, practically working as a
normal spectrometer. However, it reduces the side effect of the sample illumi-
nation as it guarantees the retention of a constantlighting path between the
optical system and the sample. Moreover, it also guarantees a higher spectral
resolution, which could be much more important than speed in specific appli-
cations. These cameras are normally expensive and require additional supplies
of, for instance, liquid nitrogen to cool down the temperature of the sensors.
3.3 Line scanning or push-broom imaging
Line scanning systems are other spatial scanning imagers [9]. For each scan
the sensor acquires the intensity spectrum of multiple spatial positions in one
of the spatial dimensions (X or Y). Each line gives a 2D spatial-spectral in-
formation and, thanks to a line by line augmentation, an HSI data cube is
obtained with only one direction movement between the sample and the de-
tector. Generally, the direction is transverse to the slit, turning into a conve-
nient solution for industrial implementation such as conveyor belts systems.
Recording a line at a time, push-broom systems are time-saving compared to
whisker-broom systems, reaching up to a 100 times faster performance
depending on the scanning area [10]. Nowadays, this is one of the preferred
technologies for bench-top instruments but also in industrial applications.
3.4 Spatial-spectral or spatiospectral scanning
Another methodology is what is known as time-scan imaging. With this
method a set of images is acquired and then superimposed along the spectral or
spatial dimension and transformed to the spectral image using, for example,
Fourier methods [11].
22 SECTION j I Introduction
3.5 Snapshot imaging
The snapshot imaging is the only method in which there is no spatial or
spectral scanning. The snapshot methodology aims at recording both spatial
and spectral information of the sample with one single shot (i.e., it captures a
hyperspectral image in a single integration time of a detector array). This type
of hyperspectral imaging is still in evolution, since average size areas can be
measured at a relative few wavelengths, mostly in the wavelength range of
400e910 nm [1], making it more a multispectral device rather than a hyper-
spectral one. Nevertheless, the high speed of acquiring a multispectral image
(that can go to 20 multispectral images per second) makes it worth to explore
technology for video recording of scenes or real-time actions.
3.6 Encoding the data
When a hyperspectral image is acquired, it is stored in a file where the spectra
must be ordered in a logical manner in order to be able to reconstruct the data
cube in any software. The most common formats are the band interleaved by
pixel (BIP), band interleaved by line (BIL), and band sequential (BSQ). BIP is
the encoding system in which the first pixels of all bands are placed in
sequential order, followed by the second pixels of all bands, and so on. Instead,
BIL stores the first line of the first band followed by the first line of the second
band, etc. BSQ refers to the method in which each line of the data is followed
immediately by the next line in the same spectral band. This format is optimal
for the access of any part of a single spectral band, being the most used in MSI.
Nowadays, the fact of storing the MSI or HSI images in any format does not
make any difference in the sense of data reconstruction or retrieval, since most
software contain dedicated algorithms to reconstruct the data cube properly.
4. Light source
MSI and specially HSI systems can be considered as the merging of a spec-
trometer and a vision-based device. Thus, the radiation source plays a key role in
the setup since both, spectrometers and vision-based devices, are based on the
lightematter interaction. Therefore, it is essential to design a lighting system to
maximize the performance of the HSI system for the specific purpose.
In the case of cameras implemented in satellites or airborne devices the
light source is the sun. The sun behaves as a black body, emitting light in the
electromagnetic spectrum of the ultraviolet (UV), visible, and near-infrared
(NIR) wavelength range (Fig. 5).
Concerning bench-top instruments, the selection of the light source should
take into consideration the emitting range of the source, i.e., the source should
emit in the spectral range necessary for the defined aim. Moreover, it is
preferred the use of a source warranting the highest homogeneity in
Configuration of hyperspectral Chapter j 1.2 23
illumination over a large area and the preservation of the samples. Regardless
of the technology or the spectral range considered, HSI systems normally need
more light than other vision-based systems. Indeed, after the light emission,
before or after interacting with the sample, the radiation is always dispersed
into narrow wavelength bands which are then measured individually. As for
spectrometers, the available sources are mainly constituted of halogen lamps,
light-emitting diodes (LEDs), and lasers. Besides these sources, with specific
performance detailed below, xenon lamps, low-pressure metal vapor lamps,
ultraviolet fluorescent lamps have been implemented for excitation mean for
fluorescence spectroscopy. The optimal illumination must be as homogeneous
as possible, covering a large area and without damaging the sample [5].
Moreover, how the light source arrives to the sample will strongly depend on
the geometry of the sample and the light geometry as well (Fig. 6).
The lighting configuration will vary according to the different acquisition
configurations seen before (Fig. 4). In this way, line mapping systems are
characterized by the fact that only the specific spatial position of the line being
acquired in every step needs to be illuminated in every moment. In most cases,
the light sources are normally placed forming a 45 degrees angle with the
sample. Plane scan configurations require an illumination able to cover a much
larger area with a homogeneous distribution of the light.
4.1 Halogen lamps
In the operating range of ultraviolet, visible, and NIR regions, the appropriate
illumination could be achieved by halogen lamps, generally tungsten halogen
lamps (Fig. 7).
FIGURE 5 Spectral irradiance spectra of atmospheric terrestrial and extraterrestrial light.
24 SECTION j I Introduction
The broadband illumination emitted by halogen lamps has a smooth and
continuous spectrum (Fig. 7) which is convenient for different acquisition
modes. Generally, good performances have been achieved for reflectance
applications. Nevertheless, when implementing high-intensity bulbs, also
transmittance measurements could be achieved.
The main advantages of halogen lamps are their commercial availability, the
low costdlinked to bulb price and low voltage requireddand the wide elec-
tromagnetic range covered (340e2500 nm; 29,500e4000 cm�1). However,
some disadvantages should be remarked. One of the main one is the heat
generated through the incandescent emission of the tungsten filament. The high
temperature generated in the filament could be dangerous for temperature-
sensitive samples [5], from explosive materials to ancient/precious pieces of
art; moreover, changes related to temperature could bring to the shift of spectral
peaks. Finally, in the instrument setup it should be considered that halogen
lamps are also sensitive to vibrations, which could lead to source damage.
4.2 Light-emitting diodes
LED solutions have been developed as a cheap alternative to generate light
in VISeNIReHSI systems. Even though LEDs emit a monochromatic light
FIGURE 6 Different geometries that the light sources can adopt, highlighting the emitted and
reflected (or transmitted) light path, and how light interacts with the sample.
Configuration of hyperspectral Chapter j 1.2 25
in the VIS region, generating different narrow-band wavelength (Fig. 7)
depending on the material used for pen junction, there are several ways to
combine them to generate white light; mainly dichromatic, trichromatic, or
tetrachromatic approaches can be implemented in HSI systems [8]. Indeed,
from two monochromatic visible-spectrumemitters, one emitting in the
blue and the other one in the yellow spectral region, it is possible to
generate complementary wavelengths. A more efficient dichromatic
approach consisted in a blue-emitting LED generates white light combined
with a semiconductor, AlGaInP, which acts as a wavelength converter.
Higher-quality white light can also be generated by the mixing of three
primary colors (trichromatic), or more (tetrachromatic). In case of
trichromatic approaches, mainly GaInN blue, GaInN green, and AlGaInP
orange emitters are implemented covering the VIS range (400e660 nm)
with Gaussian distributions around the maximums at 455 nm, 525 nm, and
605 nm.
In the infrared range, the first reported LEDs were based on GaAs
covering a region of 870e980 nm [12]. From then, high number of LEDs
system patents have been presented. Among them it is worth to mention
FIGURE 7 Black, reflectance of spectralon reference material for camera calibration. Red, en-
ergy emission of a Tungsten Halogen lamp at 3300 K. Green, emission of a green LED. Dark red,
behavior of a band-pass filter at 1200 nm. The Y axis scale only belongs to the reflectance of
Spectralon.
26 SECTION j I Introduction
the patent presented by Rosenthal [13] developing an NIR quantitative
analysis instrument with an LED light source covering 1200e1800 nm
region by isolating and employing harmonic wavelengths emitted by an
eight array of commercially available LEDs optically isolated via opaque
light baffles.
The implementation of LEDs as light source in imaging systems brings to
various advantages, like the high-energy efficiency, long lifespan
(10,000e50,000 h), low maintenance cost, small size, fast response, and
enhanced reliability and durability even in case of vibrations.
4.3 Lasers
As tungsten lamps and LEDs are highly implemented for visible and
NIReHSI systems in reflectance and transmittance modes, lasers are highly
implemented for Raman and fluorescence measurements. Indeed, lasers are
real monochromatic sources with high power and directional energy, thus
acting as proper excitation sources. In this case, measurements are based on
changes of the incident light, after the interaction with the sample, in terms
of intensity at different wavelengths. The light intensity changes, also
defined as frequency shift, cause Raman scattering or fluorescence emission
related to the chemical composition of the sample under study. Lasers have
been implemented in HSI system as continuous wave or pulse mode
emitters in different Raman and fluorescence imaging applications
[14e16].
4.4 Tunable light sources with wavelength dispersion devices
Fig. 1 shows a configuration in which the wavelength dispersive device is
placed before it arrives to the sample. That is, the sample is hit with light at
specific wavelengths because the incident light is filtered or dispersed before
arriving to the sample. This type of illumination is achieved with wavelength
dispersion devices that will be introduced in the next section.
5. Wavelength dispersion devices
The emitted broadband light by the light source or the reflected broadband light
reflected by the sample (see Fig. 1 for seeing the different configurations) is
dispersed by wavelength-dispersing elements before arriving to the detector. This
part is an essential element in any hyperspectral and multispectral configuration.
Here we empathize features of the most commonly used dispersive devices, like
variable and tunable filters, imaging spectrographs, and Fourier-transform spec-
trometers, acknowledging that this is a field in continuous development and more
devices are continuously developed (e.g., the computer-generated hologram
disperser used in snapshot hyperspectral imaging [17]).
Configuration of hyperspectral Chapter j 1.2 27
5.1 Variable and tunable filters
In spectral scanning systems, i.e., area scanning, variable or tunable filters are
normally implemented as wavelength dispersion devices and can be positioned
between the sample and the detector or between the lighting system and
sample (Fig. 1).
The variable filters are the simplest methods for wavelength selection.
They consist in band-pass filters assembled on a wheel surface, whose rotation
causes the light transfer through the different band-pass filters. The filters are
characterized by a narrow band gap, allowing the pass of only a narrow part of
the frequency of light (Fig. 7). Different features of the filters to consider are
the center wavelength (CWL), filter width at half maximum (FWHM), and the
peak transmission (PT). Filters are normally constructed with dielectric ma-
terials that will allow the pass of the light at certain CWL, characterized by an
FWHM. Depending on the material, there will be only a small fraction of the
light intensity that will pass through the filter, which is the PT. They are mainly
used for MSI devices as they acquire few separated wavelengths.
In global imaging (plane scan) systems, the so-called tunable filters [18]
are the most common lightning systems, mainly represented by electronically
tunable filters such as liquid crystal (LC) and AOTF. AOTFs use acoustic wave
frequencies to deform a birefringent crystal, normally tellurium dioxide, which
acts as a grating by dispersing light in different wavelengths in a given di-
rection [19]. The liquid crystal tunable filter (LCFT) is another optical filter
that uses electronically controlled LC elements to transmit the selected
wavelength [1,19]. One of the most classical examples of LCTF is the Lyot
filter, constructed with birefringent plates or LyoteOhman system [20]. It
works by varying a voltage on two linear polarizers which causes the polari-
zation of an LC interlayer. Thus, the light is transmitted in narrow-band
wavelengths with a resolution of several nanometers. Tunable filters can be
customized according to the desired wave range. They can be used in array in
which each filter selects a spectral band, allowing the exposure time optimi-
zation for each separate wavelength. The main disadvantage is the unmodifi-
able spectral resolution, which depends on the hardware structure.
5.2 Imaging spectrographs
In general terms, a grating is a structure composed by transmitting or dispersing
elements separated in periodic mode capable to split the broadband light into
several beams with their own amplitude and phase. In point and line scanning
systems, the dispersive element is normally a high-efficiency prism, even though
diffraction grating solutions are available. Indeed, gratings are normally used in
combination with prisms [21]. There are two main approaches in the con-
struction of imaging spectrographs: reflection and transmission gratings.
A reflection grating is mainly composed by reflective optical components
(mirrors), which can be classified on the base of surface geometry, thus,
28 SECTION j I Introduction
distinguishing plane (concave) and curved (convex) gratings. There are
many different optical configurations, allowing the generation of high-
quality images in terms of signal-to-noise ratio (SNR), absence of high-
order aberration, and large field size [22]. On the other hand, reflecting
gratings require expensive solutions to correct natural induced distortions.
The solutions are often implemented in line scanning systems and could be
an appropriate solution in case of Raman and fluorescence imaging, which
requires high-reflective efficiency as low lighting conditions should be
completely profited.
The dispersive element is generally constituted by a transmission grating
placed between two prisms with the integration of short and long pass filters.
The light from the source is collimated to the first prism, the reflected beam
reaches the grating, and it diffracts the light to the second prism. Thus, the
light propagation depends on the specific wavelength, being the central waves
propagated symmetrically and the external ones (shorter and longer) dispersed
above and below the central wavelengths. The dispersedwavelengths are then
projected, through a back lens, to the detector.
5.3 FT-imaging spectrometers
Interferometers are widely used in infrared and Raman spectroscopies. They
are based on the self-interference of a broadband light, which is split in two
equal beams and recombined after different paths. The principle is easily
translatable into imaging systems. The basis of the interferometer is that one
beam of light is deviated to a fixed mirror and the other is oriented to a moving
mirror. The beams are reflected back and recombined, but the changes in
distance of moving mirror generate optical path difference and, thus, inter-
ference, which is collected as interferogram by the detector and converted into
a spectrum by Fourier transform.
The mirror translation is highly influenced by vibrations, which can
change mirror positions and thus signal angle recombination. Nevertheless,
more reliable solutions to this problem have proposed in recent years, such as
the corner cube Michelson interferometer in Fourier transform LWIR
hyperspectral camera [23]. Even the Sagnac interferometer has been
implemented as robust alternative in HSI systems [24]. In this case, the two
beams originated from the beam splitter cover a ring path, reflecting by two
or more mirrors and originating a triangular or squared path before exiting
the interferometer. The changes in the interference are generated by the
rotation of the beam splitter in a stepwise manner. The ring interferometer
strategy allows more stable HSI solutions and covers shorter-wavelength
range (up to visible region).
In any case, interferometers are high sensible solutions when compared to
other wavelength dispersion filters as they can reach high spectral resolution
along a wide spectral range.
Configuration of hyperspectral Chapter j 1.2 29
6. Detectors
The detectors are designed to collect the incident light and convert it into
electrical signals that can be transduced to visual interpretation of the spectral
signature. In HSI and MSI, the detectors are normally mounted in the shape of
focal plane array (FPA) architectures. An FPA is a sensing array (normally
rectangular) assembled at the focal plane of the device that is composed by
hundreds of individual detectors. Those detectors are, indeed, the ones in
charge of transforming the light incoming into electronic pulses. In the market,
there are two main solid-state detectors, the charge-coupled devices (CCDs)
and the complementary metal-oxide-semiconductor detectors (CMOS),
together with the main variations of both architectures.
CCDs are devices composed by many light-sensitive materials (a.k.a.
photodiodes) such as silicon (Si), germanium (Ge), indium gallium arsenide
(InGaAs), indium antimonite (InSb), or mercury cadmium telluride (HgCdTe).
Silicon (Si) is the most widely used material in semiconductor devices due to
its low cost, relatively simple processing, and useful temperature range.
Combined with other materials, it is nowadays possible to achieve CCDs that
work in the range of 400e1000 nm (Si arrays) or even between 1000 and
5000 nm (InSb, HgCdTe, InGaAs) [25,26]. The CCD detector is characterized
by high-quality images when there is sufficient light reaching the sensor.
Nevertheless, for other applications in which the light intensity is low (e.g.,
fluorescence and Raman), high-performance cameras with electron multi-
plying CCD or intensified CCD are usually preferred due to the high SNR [1].
Despite the advantages of CCDs, the CMOS are the alternative that is
gaining more acceptance, since they include both photodetector and readout
amplification for every pixel. This makes that the architecture of a CMOS is
less complex than in CCDs, since the transformation light/electricity is done
for every single pixel, without the vertical and horizontal collectors of the
CCDs. That means lower manufacturing and power consumption cost.
Nevertheless, the main problem of CMOS is the higher spectral noise.
There is a continuous trend to compare which type of detector (CCD or
CMOS) performs better. This is a very difficult question, and it strongly de-
pends on many factors. Litwiller wrote a very well-detailed manuscript [26]
comparing both architectures, pros and cons, making clear that both archi-
tectures have room to grow in the coming years.
7. Calibration
HSI and MSI cameras are mostly spectroscopic devices. Therefore, as all
spectrometers, they need to be calibrated in order to obtain a reliable spectral
information. But, moreover, they collect spatial information that must be well
correlated with the ground coordinates (XeY spatial directions) of the scene
that is measuring. Variations in the intensity of the light source, the capability
30 SECTION j I Introduction
of all the sensing technologies involved in the process, mechanical parts, and
vibrations may create spatial and spectral signatures that are biased from the
real ones. Therefore, calibrating the camera is an essential step to be done
before and during the collection of images to be sure that the spatial and
spectral signatures are collected in the right conditions. When an HSI or MSI
camera is purchased, the spatial response of the camera and the correct po-
sition of the wavebands have been already calibrated by the manufacturer.
Nevertheless, there are some operations in calibrating the lenses and the
spectral response that must be done before, and sometimes during, the
measurements.
The spatial calibration is aimed at determining the range and the resolution
of the spatial information collected. It will depend on the type of acquisition
method used (line scan or plane scan). In bench-top instruments this calibra-
tion can be easily performed by adjusting the focal distance and the lenses of
one of the lines or images at a specific wavelength by using a printed
checkerboard (Fig. 8).
The reflectance calibration accounts for correcting and adjusting the 0%e
100% reflectance values for the sensors. This is done by taking an image of the
dark response (0% of reflectance obtained by turning off the light sources or
covering the lenses with nonreflective opaque black cap), and an image of the
background response (100% reflectance obtained by measuring a uniform,
high-reflectance standard or white ceramic-like Spectralon) (Fig. 7) [10]. With
these two images, the relative reflectance image of the sample (I) is then
obtained from the raw spectral image (I0) as follows:
I ¼ ðIo � DÞ
ðW � DÞ (1)
where D and W correspond to the dark and background reference images,
respectively. Accounting that absorbance follows a linear behavior, the
FIGURE 8 Example of printable checkerboards (the USAF 1951 and a customized one) used for
line mapping and plane scan HSI and MSI cameras. HSI, hyperspectral imaging; MSI, multi-
spectral imaging.
Configuration of hyperspectral Chapter j 1.2 31
consequent step is to transform the reflectance into absorbance as shown in Eq.
(2):
A¼ � log10
�ðI0 � DÞ
W � D
�
(2)
The operations in remote sensing devices are, somehow similar, with two
main drawbacks. The spectral calibration must be done in a prelaunching step
and, moreover, the light sources to calibrate the cameras in the laboratory are
different from the light of the sun (the laboratory signals are too low in the
blue and too high in the red). Therefore, the prelaunch radiance calibration is
done by using light diffusers or radiometric spheres [1]. Nevertheless, in this
field and specially in drone imaging, many alternatives are continuously
proposed for obtaining in-flight radiance calibrations and corrections [27e29].
8. Conclusions
Hyperspectral and multispectral devices are continuously improving. That is
a fact. More efficient sensors are developed, higher spatial and spectral
resolution and shorter measurement time of the data cube are being generated
by a growing offer that supplies the high demand of cameras. In this chapter,
we have highlighted the most common aspects to what concerns
instrumentation.
The acquisitionmode is arguably a decision-making point in the purchase
of a camera. It will depend on the final application to know whether a line scan
or a single-point system (or any other configuration) is needed. This is a
difficult decision to make that depends on the spatial and spectral resolution
needed and also the speed of the measurement. Light sources also play an
important role in the decision of purchasing a camera, since depending of the
application the light source should comply not only with the spatial-spectral
needs but also with the setup possibilities. From a customer point of view,
we trend to put less attention to the wavelength-dispersive devices imple-
mented and the detectors. Fortunately, these two elements are normally quite
robust and reliable and depend on the manufacturer. Nevertheless, it is
important to know what is the dispersive device implemented in the purchased
camera as well as to know which type of CCD or CMOS configurations we
purchase (if they are the ones implemented as detectors).
Considering all these aspects, we acknowledge that what we look as cus-
tomers is a combination of speed, high spatial and spectral resolution, and, of
course, an affordable price. These aspects will be treated in another chapter of
this book. Nevertheless, it seems that the direction to go is the new technol-
ogies of single-shot devices, which are able to measure a data cube in milli-
seconds with a reasonable spatial and spectral resolution. All in all, we can
conclude that further and better advances in instrumentation are expected in a
very promising future of HSI and MSI devices.
32 SECTION j I Introduction
References
[1] J. Qin, Hyperspectral imaging instruments, in: Hyperspectral Imaging Food Qual. Anal.
Control, 2010, pp. 129e172, https://doi.org/10.1016/B978-0-12-374753-2.10005-X.
[2] V.F. Weisskopf, How light interacts with matter, Scientific American 219 (2010) 60e71,
https://doi.org/10.1038/scientificamerican0968-60.
[3] J.A. Abbott, Quality measurement of fruits and vegetables, Postharvest Biology and
Technology 15 (1999) 207e225, https://doi.org/10.1016/S0925-5214(98)00086-6.
[4] Y. Garini, I.T. Young, G. McNamara, Spectral imaging: principles and applications,
Cytometry, Part A 69 (2006) 735e747, https://doi.org/10.1002/cyto.a.20311.
[5] J.M. Amigo, Practical issues of hyperspectral imaging analysis of solid dosage forms,
Analytical and Bioanalytical Chemistry 398 (2010) 93e109, https://doi.org/10.1007/
s00216-010-3828-z.
[6] N. Hagen, M.W. Kudenov, Review of snapshot spectral imaging technologies, Optical
Engineering 52 (2013) 090901, https://doi.org/10.1117/1.oe.52.9.090901.
[7] T. Gottschall, T. Meyer, M. Schmitt, J. Popp, J. Limpert, A. Tünnermann, Advances in laser
concepts for multiplex, coherent Raman scattering micro-spectroscopy and imaging, Trends
in Analytical Chemistry 102 (2018) 103e109, https://doi.org/10.1016/j.trac.2018.01.010.
[8] E.F. Schubert, Light-emitting Diodes, second ed., 2006, https://doi.org/10.1017/
CBO9780511790546.
[9] J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis. A tutorial,
Analytica Chimica Acta 896 (2015) 34e51, https://doi.org/10.1016/j.aca.2015.09.030.
[10] G. ElMasry, D.W. Sun, Principles of hyperspectral imaging technology, in: Hyperspectral
Imaging Food Qual. Anal. Control, 2010, pp. 3e43. https://doi.org/10.1016/B978-0-12-
374753-2.10001-2.
[11] S. Grusche, Basic slit spectroscope reveals three-dimensional scenes through diagonal slices of
hyperspectral cubes, Applied Optics 53 (2014) 4594. https://doi.org/10.1364/ao.53.004594.
[12] T.M. Quist, R.H. Rediker, R.J. Keyes, W.E. Krag, B. Lax, A.L. McWhorter, H.J. Zeigler,
Semiconductor maser of GaAs, Applied Physics Letters 1 (1962) 91e92. https://doi.org/10.
1063/1.1753710.
[13] R.D. Rosenthal, Using LED Harmonic Wavelengths for Near-Infrared Quantitative,
5,218,207, 1993.
[14] S. Begin, B. Burgoyne, V. Mercier, A. Villeneuve, R. Vallee, D. Cote, Coherent anti-Stokes
Raman scattering hyperspectral tissue imaging with a wavelength-swept system, Biomed-
ical Optics Express 2 (2011) 1296e1306. https://doi.org/10.1364/BOE.2.001296.
[15] J. Ando, A.F. Palonpon, M. Sodeoka, K. Fujita, High-speed Raman imaging of cellular
processes, Current Opinion in Chemical Biology 33 (2016) 16e24. https://doi.org/10.1016/
j.cbpa.2016.04.005.
[16] S. Delwiche, J. Qin, K. Chao, D. Chan, B.-K. Cho, M. Kim, Line-scan hyperspectral im-
aging techniques for food safety and quality applications, Applied Sciences 7 (2017) 125.
https://doi.org/10.3390/app7020125.
[17] C.E. Volin, M.F. Hopkins, E.L. Dereniak, T.M. Gleeson, M.R. Descour, D.W. Wilson,
P.D. Maker, Demonstration of a computed-tomography imaging spectrometer using a
computer-generated hologram disperser, Applied Optics 36 (2008) 3694. https://doi.org/10.
1364/ao.36.003694.
[18] H.H. Szu, M. Vetterli, W.J. Campbell, J.R. Buss, N. Gat, O. Systems, Imaging spectroscopy
using tunable filters : a review, SPIE - The International Society of Optical Engineering
4056 (2000) 50e64.
Configuration of hyperspectral Chapter j 1.2 33
https://doi.org/10.1016/B978-0-12-374753-2.10005-X
https://doi.org/10.1038/scientificamerican0968-60
https://doi.org/10.1016/S0925-5214(98)00086-6
https://doi.org/10.1002/cyto.a.20311
https://doi.org/10.1007/s00216-010-3828-z
https://doi.org/10.1007/s00216-010-3828-z
https://doi.org/10.1117/1.oe.52.9.090901
https://doi.org/10.1016/j.trac.2018.01.010
https://doi.org/10.1017/CBO9780511790546
https://doi.org/10.1017/CBO9780511790546
https://doi.org/10.1016/j.aca.2015.09.030
https://doi.org/10.1016/B978-0-12-374753-2.10001-2
https://doi.org/10.1016/B978-0-12-374753-2.10001-2
https://doi.org/10.1364/ao.53.004594
https://doi.org/10.1063/1.1753710
https://doi.org/10.1063/1.1753710
https://doi.org/10.1364/BOE.2.001296
https://doi.org/10.1016/j.cbpa.2016.04.005
https://doi.org/10.1016/j.cbpa.2016.04.005
https://doi.org/10.3390/app7020125
https://doi.org/10.1364/ao.36.003694
https://doi.org/10.1364/ao.36.003694
[19] H.R. Morris, C.C. Hoyt, P.J. Treado, Imaging spectrometers for fluorescence and Raman
microscopy: acousto-optic and liquid crystal tunable filters, Applied Spectroscopy 48 (2005)
857e866. https://doi.org/10.1366/0003702944029820.
[20] J. Beeckman, Liquid-crystal photonic applications, Optical Engineering 50 (2011) 081202.
https://doi.org/10.1117/1.3565046.
[21] C.H. Palmer, Diffraction Grating Handbook (2016). https://doi.org/10.1364/JOSA.46.
000050.
[22] D. Bannon, R. Thomas, Harsh environments dictate design of imaging spectrometer, Laser
Focus World 41 (2005) 93.
[23] M. Fridlund, D. Bergström, T. Svensson, L. Axelsson, T. Hallberg, Design, Calibration and
Characterization of a Low-cost Spatial Fourier transform LWIR Hyperspectral Imaging
Camera With Spatial and Temporal Scanning Modes, 2018, p. 33. https://doi.org/10.1117/
12.2304628.
[24] Y. Ferrec, Optimal geometry for Sagnac and Michelson interferometers used as spectral
imagers, Optical Engineering 45 (2006) 115601. https://doi.org/10.1117/1.2395923.
[25] J.S. MacDonald, S.L. Ustin, M.E. Schaepman, The contributions of Dr. Alexander F.H.
Goetz to imaging spectrometry, Remote Sensing of Environment 113 (2009). https://doi.org/
10.1016/j.rse.2008.10.017.
[26] D. Litwiller, CMOS vs. CCD: maturing technologies, maaturing markets, Photonics Spectra
39 (2005) 54e61. https://doi.org/10.1016/S0030-3992(03)00078-1.
[27] T. Hakala, L. Markelin, E. Honkavaara, B. Scott, T. Theocharous, O. Nevalainen, R. Näsi,
J. Suomalainen, N. Viljanen, C. Greenwell, N. Fox, Direct reflectance measurements from
drones: sensor absolute radiometric calibration and system tests for forest reflectance
characterization, Sensors 18 (2018). https://doi.org/10.3390/s18051417.
[28] P. Wang, J. Zhang, Y. Lan, Z. Zhou, X. Luo, Radiometric calibration of low altitude mul-
tispectral remote sensing images, Nongye Gongcheng Xuebao/Transactions Chinese Society
of Agricultural Engineering 30 (2014) 199e206.https://doi.org/10.3969/j.issn.1002-6819.
2014.19.024.
[29] Y. Guo, J. Senthilnath, W. Wu, X. Zhang, Z. Zeng, H. Huang, Radiometric calibration for
multispectral camera of different imaging conditions mounted on a UAV platform, Sus-
tainability 11 (2019) 978.
34 SECTION j I Introduction
https://doi.org/10.1366/0003702944029820
https://doi.org/10.1117/1.3565046
https://doi.org/10.1364/JOSA.46.000050
https://doi.org/10.1364/JOSA.46.000050
https://doi.org/10.1117/12.2304628
https://doi.org/10.1117/12.2304628
https://doi.org/10.1117/1.2395923
https://doi.org/10.1016/j.rse.2008.10.017
https://doi.org/10.1016/j.rse.2008.10.017
https://doi.org/10.1016/S0030-3992(03)00078-1
https://doi.org/10.3390/s18051417
https://doi.org/10.3969/j.issn.1002-6819.2014.19.024
https://doi.org/10.3969/j.issn.1002-6819.2014.19.024
Chapter 2.1
Preprocessing of hyperspectral
and multispectral images
José Manuel Amigoa,* and Carolina Santosb
aProfessor, Ikerbasque, Basque Foundation for Science; Department of Analytical Chemistry,
University of the Basque Country, Spain; Chemometrics and Analytical Technologies, Department
of Food Science, University of Copenhagen, Denmark; bDepartment of Fundamental Chemistry,
Federal University of Pernambuco, Recife, Brazil
*Corresponding author. e-mail: jmar@life.ku.dk
1. Why preprocessing?
Hyperspectral imaging (HSI) and multispectral imaging (MSI) are analytical
techniques based in the study of the chemical and physical behavior of the
reflected or scattered light coming from a specific surface. The camera
(sensor), the surface, and the light source are the analytical elements involved
in each measurement. And, as any analytical element, they provide a response
that is composed by the relevant analytical information, spectral noise, and
different artifacts [1].
Attending to the light source, the analytical information is related to the
number of photons emitted arriving to the surface. This light source is also
subjected to fluctuations, whether is the sun, in a remote sensing scenario, or a
halogen lamp, for bench-top hyperspectral devices. In both cases, the energy
emitted might vary with time. Moreover, concerning remote sensing, that energy
will pass through different atmospheric conditions before arriving to the sample.
The surface measured (sample) is hit by the photons coming from the light
source. The chemical nature (composition) and the physical nature (relieve,
roughness) of the surface make the photons behave differently in different
parts of the sample. Thus, the number of reflected photons and their remaining
amount of energy is composed not only by the analytical relevant information
but also by the physical influence of the surface.
When the photons arrive to the camera in reflectance mode, they are
detected by sensors that are also subjected to instrumental noise. Moreover,
different sensors have different sensitivity to the photons, making the spectral
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00003-1
Copyright © 2020 Elsevier B.V. All rights reserved. 37
https://doi.org/10.1016/B978-0-444-63977-6.00003-1
signature dependent not only of the arriving photons but also of the quality of
the sensing device.
The effects in each one of these three parts of the measurement cannot be
considered as individuals, since the signal collected is a combination/mixture of
all the effects. They are reflected in two main types of distortions: the distortions
reflected in the geometry of the sample and the ones reflected in the spectral signal.
When the imaging area is small enough, the lens and/or Earth curvature does
not cause significant distortions. However, if this is not the case, distortions such
as the ones shown in Fig. 1 are observed. The figure shows an image that has
been geometrically distorted due to the sensor and its position in the moment of
image acquisition. On the other hand, when the field of view is small, different
types of distortions can be observed, such as the ones indicated by Fig. 2 [3].
This image was taken using a bench-top instrument. This point is important to
consider, since, as it was said before, the stability of light source, the sample,
and the sensor plays also a fundamental role, in such a way that bench-top
instruments (HSI and MSI cameras adapted to a platform in the laboratory)
are more affected by certain types of artifacts than mobile/portable cameras
(cameras implanted in satellites, drones, or industrial setups), and vice versa.
1.1 Spatial/geometric distortions
Spatial issues are those that arise from the geometry of the sample, from un-
controlled movements of the camera, and from the optics of the camera. The
uncontrolled movements of the imaging system are especially relevant in mobile
and portable cameras. In satellite imaging, for instance, the earth rotation and
curvature will generate a known distortion in the acquired image; while cameras
implemented in drones or airborne cameras will suffer from wind exposure and
also ability of the operator during the fly. Normal geometric aberrations are
optical distortions, such as the well-known pincushion and barrel distortions
shown in Fig. 1, the aspect ratio between scales in the vertical direction with
respect to the horizontal or viewing geometry, among others [4].
Cameras implemented in industrial setups working in conveyor belts could
have deformities in the acquired image. In bench-top instruments, the platform
FIGURE 1 Original and distorted aerial images of houses. The image is a free access photo taken
by Blake Wheeler from Unplash website (https://unsplash.com/).
38 SECTION j II Algorithms and methods
https://unsplash.com/
where the camera is implemented is normally quite robust, avoiding any
problem of deformity of the acquired image. However, if confocal equipment
is being employed, a specific portion of the sample could be out of focus,
providing spatial distortions. Nevertheless, all cameras suffer from the
roughness of the sample or irregularities of the measured surface.
One problem that is more important in bench-top instruments is the fact
that many samples are not squared or are smaller than the field of view. That is,
part of the acquired image contains irrelevant information of the surface where
the sample is placed for the measurement. As example, Fig. 2 shows four
clusters of plastics laying over a neutral black paper.
1.2 Spectral/radiometric distortions
Spectral distortions are mainly due to data recording instruments, fluctuations of
the light source, and the nature of the sample. Regardless the spectral technique
employed for image acquisition, the most common spectral issue is the noise.
Sensors nowadays have the ability of measuring the spectral information with a
high signal-to-noise ratio (SNR). Nevertheless, spectral noise will still be pre-
sent (e.g., spectra shown in Fig. 2 are somehow affected by noise).
In image analysis scenario, another important aspect to consider is the
saturation of light that some pixels can exhibit. Since samples are normally a
distribution of different elements in the surface, it is normal, that due to the
shape of the elements, their different chemical nature, and the incident angle of
FIGURE 2 Left, false RGB of a hyperspectral image showing four different clusters of plastic
pellets. The spectral range was from 940 to 1640 nm with a spectral resolution of 4.85 nm. Further
information about the acquisition, type of hyperspectral camera, and calibration can be found in
Ref. [3]. Right, raw spectra of the selected pixels (marked with an “x” in the left figure). The black
line in the left figure indicates a missing scan line. This figure is partially inspired by J.M. Amigo,
H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis. A tutorial, Analytica Chimica
Acta 896 (2015) 34e51. https://doi.org/10.1016/j.aca.2015.09.030.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 39
https://doi.org/10.1016/j.aca.2015.09.030
the light,many pixels contain saturated information. This can be observed in
the bottom right part of the false RGB image of Fig. 2, where many pixels are
white due to the saturation of light in the detector.
Light scattering is also a major concern when talking about reflectance mode
and, especially, about near-infrared radiation. Scattering (in additive or multi-
plicative way) will make the absorbance to drift the baseline of the spectra in a
nonparametric manner to higher or lower values of absorbances. Scattering is
due to the nature of the elements but also to the different shape of the elements,
the roughness of the surface, and the ability of the radiation to penetrate in the
element. See, for instance, how the baseline of the spectra shown in Fig. 2 is
different for all of them. In remote sensing, the effect of the atmospheric
scattering is of a major concern. The atmospheric scattering is caused by gases
such as oxygen, nitrogen, ozone and also aerosols-like airborne particulate
matter or clouds. When talking about Raman spectroscopy, scattered light is the
source of relevant information, and fluorescence is the main cause of baseline
drift, which is usually highly intense. This issue rises either from the sample
itself or the highly energetic particles hitting the detector [5].
The background also plays an important role in the spectral signatures. If
the background is not sufficiently neutral in the signal, it will influence the
pixels belonging to the edge between the background and the elements.
Background information is not of major concern on remote sensing. The signal
is, however, affected by the atmosphere and the presence of aerosols and
particles in suspension, which is not that relevant in bench-top instruments.
For both image scenarios, one crucial spectral issue is the presence of dead
pixels. Images are usually a set of a high number of pixels, and eventually,
there are pixels that contain spiked signals in the spectrum, or parts of the
spectrum are saturated, or simply they do not contain any information (black
line in the false RGB figure of Fig. 2). This is normally generated by the
malfunction of the sensor (in the case of spiked signals or no information) or
by a wrong light exposure (saturated levels of light).
Different approaches have been proposed to retain the analytical signal and
minimize the effect of the different issues commented before. This chapter
offers a revision of the main methodologies for HSI and MSI preprocessing.
Moreover, we will emphasize the benefits and drawbacks arising in the
application of each one of them.
2. Geometric corrections of distortions coming from the
instrument
A geometric correction is a transformation of HSI or MSI image applied to
each individual channel in such a way that the distorted image is translocated
to a standard reference axis (e.g., projected to coordinates in maps). This type
of corrections is common in remote sensing scenarios, where a reference map
of the scanned land is normally available [6e8]. The correction steps are two:
40 SECTION j II Algorithms and methods
finding a proper set of coordinates in the images and in the reference map and
then a step of interpolation/resampling of the distorted image to the correct
reference points. The most common geometric correction method is based on
ground control points (GCPs). The GCPs are reference points that are common
to the distorted image and the reference map. They are normally permanent
elements like road intersections or airport runways. Once the GPCs are chosen,
a step of interpolation is performed. The most common resampling methods
are the nearest neighbor, the bilinear, and the bicubic interpolations (Fig. 3).
The nearest neighbor resampling is the most straightforward way of
resampling. It consists of assigning the nearest pixel value to the corrected
pixel (Fig. 3). Bilinear interpolation, instead, considers the closest 2 � 2
neighborhood of known pixel values of the distorted image surrounding the
unknown pixel. This method gives much smoother looking images than
the nearest neighborhood (Fig. 3). Finally, the bicubic interpolation considers
the 4 � 4 neighborhood, instead. Bicubic interpolation normally produces
sharper images than the previous two methods.
3. Dead pixels, spikes, and missing scan lines
Dead pixels, spiked points in the spectra, and missing scan lines are caused by
a punctual malfunction of the detector or by a saturation of light in certain
points of the surface measured [9]. They can be encoded as missing values,
FIGURE 3 Top, distorted image (dashed squares) and corrected image (solid squares). The pixel
of interest is highlighted in bold. Bottom, three of the methodologies for pixel interpolation,
highlighting in each ones the pixels of the distorted image used for the interpolation.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 41
zero or infinite values; and their location and spread might vary depending on
the quality of the detector and the reflectance of the sample. They all can
distort the further processing of the HSI or MSI image. This is highly prob-
lematic, since many of the routines for data mining can only handle a limited
amount of missing values.
Missing scan lines and dead pixels occur when a detector fails to operate
during a scan (Fig. 2). Detecting missing scan lines and dead pixels can be done
using different algorithms with major or minor complexity (like thresholding
techniques [10], genetic or evolutionary algorithms [11e13], orminimumvolume
ellipsoid (MVE) [14]). A much simpler methodology is the establishment of a
predefined threshold in the number of zero values allowed in the spectrum of the
pixel. Evidently, the threshold must be selected considering the nature of the data.
Spiked wavelengths are sudden and sharp rises and falls in the spectrum
(Fig. 4) [15]. They are caused by an abnormal behavior of the detector or
saturation of light in certain spectral region. Spikes can be normally distin-
guished in an easy manner. They trend to present a high deviation from the
mean value of the spectrum (Fig. 4). Therefore, if a proper threshold of mean
and standard deviation is chosen, they can be easily detecting, always consid-
ering difference between the normal signal, the spiked signal, and the SNR [16].
Once the missing scan lines, dead pixels, and spikes have been detected,
they must be replaced by a more appropriated value. In the case of spiked
wavelengths, the most straightforward way of replacing the spiked value is the
substitution of that value by the mean or median of a spectral window centered
in the spiked point (Fig. 4). For missing scan lines and dead pixels, many
alternatives have been proposed in the literature [16e21]. Nevertheless,
profiting the rich amount of spatial information that HSI and MSI normally
provide, one straightforward manner to replace missing scan lines and dead
pixels is substitute them by the mean or the median of the spectral of the
neighboring pixels.
FIGURE 4 Left, spectrum containing one spiked point. The continuous red line denotes the mean
of the spectrum. The upper and lower dashed red lines denote the mean � six times the standard
deviation. Right, corrected spectrum where the spike has been localized and its value substituted
by an average of the neighboring spectral values.
42 SECTION j II Algorithms and methods
4. Spectral preprocessing
Spectral preprocessing can be defined as the set of mathematical operations
that minimize and/or eliminate the influence of undesirable phenomena
affecting directly to the spectral signature obtained (e.g., light scattering,
particle size effects, or morphological differences, such as surface roughness
and detector artifacts [22]). In HSI, it is common to adapt the preprocessing
methods coming from classical spectroscopy [5,23]. They can be divided into
different families, attending their purpose. Fig. 5 shows an example of their
effect in the spectral signal and in the visualizationof the surface information:
- Smoothing/denoising: The instrumental noise can be partly removed by
using smoothing techniques, being SavitzkyeGolay the most popular one
[23]. SavitzkyeGolay methodologies are based on the selection of a sub-
window around a specific point and calculating its projection onto a
polynomial fitting of the points of the subwindow. It is simple to imple-
ment. Nevertheless, special care must be taken in the selection of the
spectral subwindow, since large subwindows will eliminate informative
peaks, while small windows might generate more noise.
- Scatter correction: Scattering is reflected in a drift in the baseline of the spectra
(Figs. 2 and 6). That drift can be additive or multiplicative, depending on the
nature of the sample and the physical interaction of the sample with the light.
There are two main methods for scattering removal. The first one, standard
normal variate (SNV), is the most straightforward method. It subtracts the
mean of the spectrum and divides it by the standard deviation. SNV removes
FIGURE 5 Top, raw spectra of Fig. 2 and the spectra after different spectral preprocessing
methods. Bottom, the image resulting at 1220 nm for each spectral preprocessing. This sample
belongs to a data set by J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image
analysis. A tutorial, Analytica Chimica Acta 896 (2015) 34e51. https://doi.org/10.1016/j.aca.
2015.09.030.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 43
https://doi.org/10.1016/j.aca.2015.09.030
https://doi.org/10.1016/j.aca.2015.09.030
additive scattering without changing the shape of the original spectrum.
Nevertheless, it cannot handle multiplicative scattering effect. Therefore,
multiplicative scatter correction (MSC) is preferred when multiplicative
scattering appears. MSC is also a quite straightforward method, since it pro-
jects the spectrum of pixels against one reference spectrum and then the cor-
rected spectrum is the subtraction of the offset from the original spectrum
divided by the slope [23]. Themain drawback ofMSC is that it depends of the
correct selection of a reference spectrum. This is quite complicated to achieve
in hyperspectral images, since the samples trend to be a mixture of different
compounds with different spectra.
- Derivatives: The SavitzkyeGolay methodology can also be used for
calculating the derivative profile of the spectrum. In that sense, the sub-
window of points chosen is first fitted to a polynomial degree and then the
derivative is calculated. First (1D) and second (2D) derivatives are the most
common ones in spectroscopy. First derivative removes the additive scat-
tering; while second derivative removes multiplicative scattering [26].
Another effect of derivatives is their ability of highlighting minor spectral
FIGURE 6 Example of spectral preprocessing for minimizing the impact of the shape of the
sample in the spectra. Top left, RGB image of a nectarine. Top middle, the average signal of the
pixels contained in the green line of the top left figure. Top right, spectra of the green line of the top
left figure showing the effect of the curvature. Bottom middle, average signal of the preprocessed
spectra (with standard normal variate (SNV)) of the green line of the top left figure. Bottom right,
preprocessed spectra of the green line of the top left figure. This sample belongs to a data set by S.
Munera, J.M. Amigo, N. Aleixos, P. Talens, S. Cubero, J. Blasco, Potential of VIS-NIR hyper-
spectral imaging and chemometric methods to identify similar cultivars of nectarine, Food Control.
86 (2018). doi:10.1016/j.foodcont.2017.10.037; S. Munera, J.M. Amigo, J. Blasco, S. Cubero, P.
Talens, N. Aleixos, Ripeness monitoring of two cultivars of nectarine using VIS-NIR hyperspectral
reflectance imaging, Journal of Food Engineering 214 (2017) 29e39. https://doi.org/10.1016/j.
jfoodeng.2017.06.031.
44 SECTION j II Algorithms and methods
https://doi.org/10.1016/j.jfoodeng.2017.06.031
https://doi.org/10.1016/j.jfoodeng.2017.06.031
differences. Nevertheless, special care must be taken in the choice of the
derivative degree and in the subwindow size, since a high derivative degree
with a small window size can create high amount of noise, while large
subwindows can eliminate informative parts of the spectra [23].
One of the main properties of some spectral preprocessing methods is that
they are also able to remove physical artifacts reflected in the signal. This is
the case of the scattering promoted by the roughness of the sample measured
or its nonplanar shape. As a matter of example, Fig. 6 shows how SNV can
minimize the impact of the round shape of a nectarine [24,25]. In the figure, it
is shown the raw data and the preprocessed data of one line of the hyper-
spectral cube. This line of spectra is clearly affected by the shape of the
nectarine, effect that is minimized when SNV is applied.
5. Background removal
The selection of the regions of interest (RoI) of a sample is an important step
before the analysis of the sample. This is especially relevant when the ge-
ometry of the sample does not cover the whole area measured (as illustrated in
the example of Fig. 2). If the sample does not cover all the scanned area, the
area left outside the sample is usually composed by highly noisy spectra, and
thus, it might hamper the good performance of further models. Moreover,
removing it implies a substantial saving of computing time.
As a matter of fact, successful background removal starts at image acqui-
sition step. For bench-top instrument, it is usually possible to choose an
appropriate background which facilitates its segmentation from the elements of
interest. Manual selection of the RoIs, the use of specific thresholds in the
histogram of the image obtained at specific wavelengths, K-means clustering, or
even using the score surfaces of a principal component analysis (PCA) model
are some of the methodologies that can be employed [27]. All of them have their
own implication in the final result also considering the nature and the shapes of
the samples in the surface. For example, Fig. 7 shows the performance of three
different methodologies for removing the background of the preprocessed
hyperspectral image (missing lines removed and SNVapplied) shown in Fig. 7.
As it can be seen in the figure, three different methodologies provide three
different answers. In this case, discerning between the edges of the samples
and the background is a hard task, since the edges are pixels that contain
strongly mixed information of the spectral signature of the plastic and the
background. Therefore, special care must be placed in the accidental removal
of informative areas of the sample.
6. Some advices on preprocessing
Preprocessing is, probably, the main engine for a successful interpretation of
our hyperspectral and multispectral images. As a matter of example, Fig. 8
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 45
shows an example of two PCA models performed on the hyperspectral image
of the plastics. The first PCA model is made on the raw data (normalized prior
PCA). It can be seen that even though PC1 explains almost 89% of the vari-
ance, this variance is wasted explaining the difference between the background
and the plastics (Table 1).
The second PCA is made on the preprocessed data (using the spectra in first
derivative and removing the background). The PCA clearly shows the spectral
differences of the four plastics by using only two principal components, making
the model much more understandable, parsimonious, and probably stable.
Most of the software packages for processing HSI and MSI already provide
some preprocessing algorithms. And in this chapter, we have shown the
benefits and drawbacks of some of the methodologies that can be applied.
Nevertheless, one of the major issues in applying preprocessing methods is
that the effectiveness of the correction applied must be evaluatedafter the
application of processing algorithms. That is, as is shown in Fig. 8, the effi-
ciency of the preprocessing methodology must be evaluated after seeing the
FIGURE 7 Depiction of three different methodologies for background removal. Left, false RGB
image. Top, K-means analysis of the hyperspectral image in SNV and the selection of clusters 2
and 4 to create the mask. Middle, false color image obtained at 971 nm of the hyperspectral image
in SNV and the result of applying a proper threshold to create the mask. Bottom, PCA scatter plot
of the hyperspectral image in SNV with the selected pixels highlighted in red to create the mask.
All the analysis have been made using HYPER-Tools [28], freely download in Ref. [29]. SNV,
standard normal variate; PCA, principal component analysis.
46 SECTION j II Algorithms and methods
results of PCA. Therefore, applying preprocessing is, most of the times, a
game of trial and error, although there are specific reports of genetic algo-
rithms for preprocessing optimization [30,31].
Some main blocks have been presented here. Table 1 collects all the methods
revisited here giving an account of their major benefits and drawbacks. One
question that might arise is the order and number of preprocessing steps that must
be used. Unfortunately, there is not a specific answer for that question. Or, better
said, the answer can be again a trial error game. Sometimes the background is
easily removed from the raw data and then the data included in the RoI are pre-
processed; and sometimes a spectral preprocessing is needed for removing the
background while another spectral preprocessing is needed for the analysis of the
sample. In any case, there are some major advices that can be given:
- Parsimony. The simpler, the better: Preprocessing normally changes the
spatial and the spectral information, in such a way that those changes can
remove informative parts in our image. Moreover, it can also introduce
artifacts or generate the loss of important information if the proper method
is not selected or correctly applied. Therefore, the simpler a preprocessing
methodology is, the better, as long as we achieve the desired results.
- Spatial and spectral corrections are connected: Smoothing the spectra in an
HSI sample will not only remove the spectral noise but also will smooth the
images arising from the data. The application of spectral corrections has an
implication in the surface and vice versa.
- There is a price to pay: By applying preprocessing, there will always be lost
information. It is our responsibility to lose only the information that we can
consider noise and stay with the analytical relevant information.
FIGURE 8 Comparison of two PCA models performed in the hyperspectral image of the plastics
[3]. For each PCA model, the score surfaces of the first two PCs, the scatter plot of PC1 versus PC2
and the corresponding loadings are shown. All the analyses have been made using HYPER-Tools
[28], freely download in Ref. [29]. PCA, principal component analysis; PC, principal component.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 47
TABLE 1 Summary of the main preprocessing steps, the techniques for
their application, and their benefits/drawbacks.
Preprocessing
step Techniques
Types
of
images Benefits Drawbacks
Dead pixels Detection
Median spectra/
thresholding
[10,32]
MSI
and
HSI
Easy to
implement
and
calculate
Highly dependent
of the signal-to-
noise ratio. Risk of
false positives.
Genetic/
evolutionary
algorithms
[9,12,13]
MSI
and
HSI
Robust and
reliable
To find the best
combination of
parameters to
optimize the
models.
Chosen criteria MSI
and
HSI
Easy to
implement
and
calculate
Difficulties in
finding the proper
threshold.
Suppression
Neighboring
interpolation
MSI
and
HSI
Easy to
implement
and
calculate
If the cluster of dead
pixels is big, there
could be the risk of
losing resolution in
this area
Spikes Detection
Manual
inspection
MSI
and
HSI
Robust and
reliable
Time-consuming,
specially in HSI
images
Neighbor filters
[15,18,19]
Robust and
reliable
To find the best
combination of
parameters to
optimize the filters.
When the
background is an
important part of
the image, there
may be problems to
differentiate the
spikes.
48 SECTION j II Algorithms and methods
TABLE 1 Summary of the main preprocessing steps, the techniques for
their application, and their benefits/drawbacks.dcont’d
Preprocessing
step Techniques
Types
of
images Benefits Drawbacks
Wavelets
[17,20,21]
Robust and
reliable
The selection of the
proper wavelet (in
the spatial and the
spectral channels)
for each type of
image.
Chosen criteria Robust and
reliable
Difficulties in
finding the proper
threshold.
Suppression
Neighbor
interpolation
[15,17e21]
Easy to
implement
and
calculate
Background/
ROI
PCA
thresholding
[10,33]
MSI
and
HSI
Robust
selection of
a specific
area based
of PC
scores
images
The selection of the
proper threshold is
tedious and not
obvious in some
situations.
Manual Selection
of the
desired
area
Time-consuming,
specially working
with time series
images or large data
sets
K-means [34] Easy to
implement
and
calculate
Spectral
preprocessing
Denoising
SavitzkyeGolay
smoothing [23]
HSI Easy to
implement
To find the best
combination of
parameters to
optimize the filter,
especially the
window size.
Continued
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 49
TABLE 1 Summary of the main preprocessing steps, the techniques for
their application, and their benefits/drawbacks.dcont’d
Preprocessing
step Techniques
Types
of
images Benefits Drawbacks
Scatter correction
MSC, SNV [23] SNV does
not change
the shape
of the
spectra
Sometimes the
suppression of
artifacts is not
totally achieved.
MSC and derived
techniques need
additional
information and
may change the
shape of the
spectra.
Derivatives [23] Removal of
different
baseline
artifacts
To find the best
combination of
parameters to
optimize the filter.
Especially the
window size and
the derivative order.
Geometric
corrections
Nearest
neighbor
interpolation
[35]
MSI
and
HSI
Easy to
implement
To find the proper
set of reference
points to make
proper
interpolation.
Bilinear
interpolation
[35]
Easy to
implement
Smooth
edges are
created
To find the proper
set of reference
points to make
proper
interpolation.
Bicubic
interpolation
[35]
Easy to
implement
Smooth
edges are
created
Sharper
images
To find the proper
set of reference
points to make
proper
interpolation.
HIS, Hyperspectral imaging; MSC, Multiplicative scatter correction; MSI, Multispectral imaging;
PCA, Principal component analysis; SNV, Standard normal variate.
Extracted and reproduced from M. Vidal, J.M. Amigo, Pre-processing of hyperspectral images.
Essential steps before image analysis, Chemometrics and Intelligent Laboratory Systems 117 (2012)
138e148. https://doi.org/10.1016/j.chemolab.2012.05.009 and modified with permission of
Elsevier.
50 SECTION j II Algorithms and methods
https://doi.org/10.1016/j.chemolab.2012.05.009
References
[1] M. Vidal, J.M. Amigo, Pre-processing of hyperspectral images. Essential steps before image
analysis, Chemometrics and Intelligent Laboratory Systems 117 (2012) 138e148, https://
doi.org/10.1016/j.chemolab.2012.05.009.
[2] Unplash, Unplash, (n.d.). https://unsplash.com/.
[3] J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis. A tutorial,
Analytica Chimica Acta 896 (2015) 34e51, https://doi.org/10.1016/j.aca.2015.09.030.
[4] P.K. Varshney, M.K. Arora, Advanced Image Processing Techniques for Remotely Sensed
Hyperspectral Data, Springer, 2004.
[5] T. Bocklitz, A. Walter, K. Hartmann, P. Rösch, J. Popp, How to pre-process Raman spectra
for reliable and stable models? Analytica Chimica Acta 704 (2011) 47e56, https://doi.org/
10.1016/j.aca.2011.06.043.
[6] T. Toutin, Review article: geometric processing of remote sensing images: models, algo-
rithms and methods,International Journal of Remote Sensing 25 (2004) 1893e1924, https://
doi.org/10.1080/0143116031000101611.
[7] N.G. Kardoulas, A.C. Bird, A.I. Lawan, Geometric correction of SPOT and landsat Imag-
ery : a comparison of M a p and GPS-derived control points, Photogrammetric Engineering
& Remote Sensing 62 (1996) 1173e1177.
[8] A.J. De Leeuw, L.M.M. Veugen, H.T.C. Van Stokkom, Geometric correction of remotely-
sensed imagery using ground control points and orthogonal polynomials, International
Journal of Remote Sensing 9 (2007) 1751e1759, https://doi.org/10.1080/
01431168808954975.
[9] R. Leardi, Genetic algorithms in chemometrics and chemistry: a review, Journal of Che-
mometrics 15 (2001) 559e569, https://doi.org/10.1002/cem.651.
[10] J. Burger, P. Geladi, Hyperspectral NIR image regression part I: calibration and correction,
Journal of Chemometrics 19 (2005) 355e363. https://doi.org/10.1002/cem.986.
[11] R. Leardi, Experimental design in chemistry: a tutorial, Analytica Chimica Acta 652 (2009)
161e172. https://doi.org/10.1016/j.aca.2009.06.015.
[12] B. Walczak, Outlier detection in multivariate calibration, Chemometrics and
Intelligent Laboratory Systems 28 (1995) 259e272. https://doi.org/10.1016/0169-7439(95)
80062-E.
[13] P. Vankeerberghen, J. Smeyers-Verbeke, R. Leardi, C.L. Karr, D.L. Massart, Robust
regression and outlier detection for non-linear models using genetic algorithms, Chemo-
metrics and Intelligent Laboratory Systems 28 (1995) 73e87. https://doi.org/10.1016/0169-
7439(95)80041-7.
[14] C. Junghwan, P.J. Gemperline, Pattern recognition analysis of near-infrared spectra by
robust distance method, Journal of Chemometrics 9 (1995) 169e178. https://doi.org/10.
1002/cem.1180090304.
[15] L. Zhang, M.J. Henson, A practical algorithm to remove cosmic spikes in Raman imaging
data for pharmaceutical applications, Applied Spectroscopy 61 (2007) 1015e1020. https://
doi.org/10.1366/000370207781745847.
[16] Z. Nenadic, J.W. Burdick, Spike detection using the continuous wavelet transform, IEEE
Transactions on Biomedical Engineering 52 (2005) 74e87. https://doi.org/10.1109/TBME.
2004.839800.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 51
https://doi.org/10.1016/j.chemolab.2012.05.009
https://doi.org/10.1016/j.chemolab.2012.05.009
https://unsplash.com/
https://doi.org/10.1016/j.aca.2015.09.030
https://doi.org/10.1016/j.aca.2011.06.043
https://doi.org/10.1016/j.aca.2011.06.043
https://doi.org/10.1080/0143116031000101611
https://doi.org/10.1080/0143116031000101611
https://doi.org/10.1080/01431168808954975
https://doi.org/10.1080/01431168808954975
https://doi.org/10.1002/cem.651
https://doi.org/10.1002/cem.986
https://doi.org/10.1016/j.aca.2009.06.015
https://doi.org/10.1016/0169-7439(95)80062-E
https://doi.org/10.1016/0169-7439(95)80062-E
https://doi.org/10.1016/0169-7439(95)80041-7
https://doi.org/10.1016/0169-7439(95)80041-7
https://doi.org/10.1002/cem.1180090304
https://doi.org/10.1002/cem.1180090304
https://doi.org/10.1366/000370207781745847
https://doi.org/10.1366/000370207781745847
https://doi.org/10.1109/TBME.2004.839800
https://doi.org/10.1109/TBME.2004.839800
[17] F. Ehrentreich, L. Summchen, Spike removal and denoising of Raman spectra by wavelet
transform methods, Analytical Chemistry 73 (2001) 4364e4373. https://doi.org/10.1021/
ac0013756.
[18] C.J. Behrend, C.P. Tarnowski, M.D. Morris, Identification of outliers in hyperspectral
Raman image data by nearest neighbor comparison, Applied Spectroscopy 56 (2002)
1458e1461. https://doi.org/10.1366/00037020260377760.
[19] C.V. Cannistraci, F.M. Montevecchi, M. Alessio, Median-modified Wiener filter provides
efficient denoising, preserving spot edge and morphology in 2-DE image processing, Pro-
teomics 9 (2009) 4908e4919. https://doi.org/10.1002/pmic.200800538.
[20] K. Koshino, H. Zuo, N. Saito, S. Suzuki, Improved spike noise removal in the scanning laser
microscopic image of diamond abrasive grain using wavelet transforms, Optics Commu-
nications 239 (2004) 67e78. https://doi.org/10.1016/j.optcom.2004.05.056.
[21] P. Du, W.A. Kibbe, S.M. Lin, Improved peak detection in mass spectrum by incorporating
continuous wavelet transform-based pattern matching, Bioinformatics 22 (2006)
2059e2065. https://doi.org/10.1093/bioinformatics/btl355.
[22] J.M.Amigo, Practical issues of hyperspectral imaging analysis of solid dosage forms,Analytical
and Bioanalytical Chemistry 398 (2010) 93e109. https://doi.org/10.1007/s00216-010-3828-z.
[23] A. Rinnan, F. van den Berg, S.B. Engelsen, Review of the most common pre-processing
techniques for near-infrared spectra, TRAC Trends in Analytical Chemistry 28 (2009)
1201e1222, isi:000272098600016.
[24] S. Munera, J.M. Amigo, N. Aleixos, P. Talens, S. Cubero, J. Blasco, Potential of VIS-NIR
hyperspectral imaging and chemometric methods to identify similar cultivars of nectarine,
Food Control 86 (2018). https://doi.org/10.1016/j.foodcont.2017.10.037.
[25] S. Munera, J.M. Amigo, J. Blasco, S. Cubero, P. Talens, N. Aleixos, Ripeness monitoring of
two cultivars of nectarine using VIS-NIR hyperspectral reflectance imaging, Journal of Food
Engineering 214 (2017) 29e39. https://doi.org/10.1016/j.jfoodeng.2017.06.031.
[26] P. Geladi, D. MacDougall, H. Martens, Correction for near-infrared reflectance spectra of
meat, Applied Spectroscopy (1985). https://doi.org/10.1366/0003702854248656.
[27] N.R. Pal, S.K. Pal, A review on image segmentation techniques, Pattern Recognition 26
(1993) 1277e1294.
[28] N. Mobaraki, J.M. Amigo, HYPER-Tools. A graphical user-friendly interface for hyper-
spectral image analysis, Chemometrics and Intelligent Laboratory Systems 172 (2018).
https://doi.org/10.1016/j.chemolab.2017.11.003.
[29] J.M. Amigo, HYPER-tools Official Website, (n.d.). Hypertools.org (accessed March 10,
2019).
[30] O. Devos, L. Duponchel, Parallel genetic algorithm co-optimization of spectral pre-
processing and wavelength selection for PLS regression, Chemometrics and Intelligent
Laboratory Systems 107 (2011) 50e58. https://doi.org/10.1016/j.chemolab.2011.01.008.
[31] R.M. Jarvis, R. Goodacre, Genetic algorithm optimization for pre-processing and variable
selection of spectroscopic data, Bioinformatics 21 (2005) 860e868. https://doi.org/10.1093/
bioinformatics/bti102.
[32] P. Geladi, J. Burger, T. Lestander, Hyperspectral imaging: calibration problems and solu-
tions, Chemometrics and Intelligent Laboratory Systems 72 (2004) 209e217,
isi:000222986900012.
[33] J. Burger, P. Geladi, Hyperspectral NIR image regression part II: dataset preprocessing
diagnostics, Journal of Chemometrics 20 (2006) 106e119. https://doi.org/10.1002/cem.986.
52 SECTION j II Algorithms and methods
https://doi.org/10.1021/ac0013756
https://doi.org/10.1021/ac0013756
https://doi.org/10.1366/00037020260377760
https://doi.org/10.1002/pmic.200800538
https://doi.org/10.1016/j.optcom.2004.05.056
https://doi.org/10.1093/bioinformatics/btl355
https://doi.org/10.1007/s00216-010-3828-z
https://doi.org/10.1016/j.foodcont.2017.10.037
https://doi.org/10.1016/j.jfoodeng.2017.06.031
https://doi.org/10.1366/0003702854248656
https://doi.org/10.1016/j.chemolab.2017.11.003
http://Hypertools.org
https://doi.org/10.1016/j.chemolab.2011.01.008
https://doi.org/10.1093/bioinformatics/bti102
https://doi.org/10.1093/bioinformatics/bti102
https://doi.org/10.1002/cem.986
[34] N. Dhanachandra, K. Manglem, Y.J. Chanu, Image segmentation using K -means clustering
algorithm and subtractive clustering algorithm, Procedia Computer Science 54 (2015)
764e771. https://doi.org/10.1016/j.procs.2015.06.090.
[35] D. Han, Comparison of commonly used image interpolation methods, in: Proc. 2nd Int.
Conf. Comput. Sci. Electron. Eng. (ICCSEE 2013), 2013, pp. 1556e1559.
Preprocessing of hyperspectral and multispectral images Chapter j 2.1 53
https://doi.org/10.1016/j.procs.2015.06.090
Chapter 2.2
Hyperspectral compression
Giorgio Antonino Licciardi
E. Amaldi Foundation, Rome, Italy
1. IntroductionThe necessity to extract increasingly detailed information content led to the
evolution of hyperspectral sensors toward the acquisition of measurements
with significantly greater spectral breadth and resolution. This, on one hand,
permits the hyperspectral sensors to acquire information in hundreds of
contiguous bands, allowing the possibility to have detailed spectral signa-
tures and, on the other hand, hyperspectral images can be extremely large and
their management, storage, and transmission can be extremely difficult.
Thus, in several applications of hyperspectral image processing, data
compression becomes mandatory. For instance, in Earth observation,
hyperspectral images are acquired by sensors mounted on airborne or
satellite-borne carriers. However, due to the size of a typical hyperspectral
data set, not all the acquired data can be downlinked to a ground station. To
give an example, a typical scene acquired by the EO-1 Hyperion instrument
cover an area of 42 � 7 km corresponding approximately to 3129 � 256
pixels, each having 242 bands at 16 bit. In this case the dimensionality
reduction of hyperspectral data becomes necessary in order to match the
available transmission bandwidth.
In general, image compression approaches can be divided according to the
preservation of information. Lossless compression techniques preserve
the total amount of information, and the reconstructed image is identical to the
original. In near-lossless compression, the maximum absolute difference be-
tween the reconstructed and original image does not exceed a user-defined
value. On the other hand, lossy compression approaches are oriented to
obtain a given target bit rate, thus, the reconstructed image should be as similar
as possible to the original one. In general, lossless compression is highly
desired to preserve all the information contained in the image. However,
lossless algorithms are not able to provide high compression ratios. Aside from
this general subdivision, compression algorithms can be grouped according to
type of redundancy or correlation exploited.
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00004-3
Copyright © 2020 Elsevier B.V. All rights reserved. 55
https://doi.org/10.1016/B978-0-444-63977-6.00004-3
Basically, the information compression process depends mainly on the four
types of redundancies present in hyperspectral images, such as statistical
redundancy, spatial redundancy, spectral redundancy, and visual redundancy.
Methods based on statistical redundancy analyze the probability of sym-
bols. Popular techniques are designed to assign short code words to high-
probability symbols, and long code words to low-probability symbols. These
methods are usually called entropy coding.
Spatial redundancy, also called intraband correlation, is based on the
assumption that the pixel information could be partially obtained by neigh-
boring pixels. Spatial redundancy can be removed through the use of spatial
decorrelation techniques, such as transformation, that transform the image
from the spatial domain into another domain, or prediction, that is used to
predict the pixel values from the neighbor pixels.
Spectral redundancy, or interbands correlation, is based on the high cor-
relation existing between neighboring bands in hyperspectral images. Thus,
spectral decorrelation is used to project the original spectra of the image into a
low-dimensional feature space.
Finally, visual redundancy is based on the fact that human eyes tend to be
not very sensitive to high frequencies, thus compression based on visual
redundancy is obtained by using data quantization. In general, the use of
interband or intrabands correlations permits to divide compression algorithms
into 2D and 3D approaches. 2D image compression algorithms usually exploit
separately the intraband and interband correlations, while 3D approaches refer
to the simultaneous use of both inter- and intraband correlations.
Aside from the different techniques presented in the literature, usually
hyperspectral compression makes use of quantization followed by entropy
encoding in order to further compress the file size. With the term
quantization, it is usually indicated the process to reduce a large set of values
to a discrete set. In hyperspectral image compression quantization is in
general applied in the frequency domain. Quantization is in general followed
by entropy encoders that compress data by representing each input symbol
with a variable length code word. The length of the code words depends on
the frequency of the associated symbols. This means that the most frequent
symbols have associated the shortest codes. The most common
entropy encoders used for image compression are Huffman and arithmetic
codings [1,2].
2. Lossless approaches
Most lossless hyperspectral image compression techniques are based on one of
the following techniques: vector quantization (VQ), predictive coding or
transform coding. However, transform-based schemes can yield excellent
coding gain for lossy compression at low bit rates, while their lossless coding
performance is inferior to specialized lossless compression schemes.
56 SECTION j II Algorithms and methods
2.1 Vector quantization
VQ is a technique extensively analyzed for the compression of speech and
images and can be resumed in a four-step processing (Fig. 1). In the first step,
the original data are decomposed into a set of vectors. Then, a subset of those
vectors is selected to form a training set on a second step. In the third step, an
iterative clustering algorithm is used to generate a codebook from the
training set. In the final step, defined as quantization, for each vector, the
code word for the closest code vector in the codebook is found and trans-
mitted [3].
2.1.1 Vector formation
The formation of vector process applied to hyperspectral images depends on
the type of vector to be formed, that could be spatial or spectral, and the size of
vector formed. Then, a codebook is generated for each block. For instance, a
vector formed in the spectral domain of a hyperspectral image comprising N
bands, has a length L, resulting from subdividing the N bands into B blocks
such that N ¼ B � L.
The compression in VQ is then obtained by replacing each vector with a
label. Intuitively, code words associated to larger vectors can lead to higher
compression rates. However, in lossless compression, there is a balance be-
tween the increased matching error and the reduction in address entropy that
results in an optimum length.
2.1.2 Training set selection
Once the vectors for the original image are formed, the following step is to
select the training sets and generate the relative codebooks. The quality of the
training set depends mainly on the vector selection process and on the number
of vectors selected. Since the statistical information of the training set should
FIGURE 1 Vector quantization compression block diagram.
Hyperspectral compression Chapter j 2.2 57
be representative of the original image, the training vectors are usually
selected in order to be evenly distributed across the image [4]. The number of
training vectors, on the other hand, depends mainly on the desired general-
ization properties of the compression algorithm. Using a number of training
vectors limited to a small number of images will produce a codebook able to
obtain a high compression rate but probably is not applicable to other images.
In this case, it is possible to transmit and store the codebook along with the
compressed image. However, this may be not acceptable for practical trans-
mission and storage uses since the development of the codebook for each
image would require considerable time. Conversely, the use of universal
codebooks generated from a large pool of images will result in a marginal
degradation of compression rate but will provide a good generalization and
faster results.
2.1.3 Codebook generation
The algorithm used to generate the codebook influences the quality ofthe
selected codebook. For instance, the K-Mean clustering method can be used to
produce codebooks of a fixed size, giving better control over address entropy
[5].
Another important issue influencing the quality of the codebook is related
to the size of the codebook itself. As the size of the codebook is increased,
each input vector will be able to find a closer reference vector, and therefore
the difference image entropy will decrease. At the same time, however, the
address entropy will increase.
2.1.4 Quantization
This last step deals with the method used to search the codebook. There exist
several approaches in the literature, spanning from full search to tree search [5]
to lattice search [6]. However, since in general the codebook is unstructured, a
full search is required despite of the high time consumption.
In the literature, several other approaches have been derived from the VQ
technique. For instance, the mean-normalized vector quantization (M-NVQ)
has been proposed in Ref. [1], while in Ref. [7] a discrete cosine transform has
been used in both spatial and spectral domains to exploit the redundancy in the
M-NVQ output. In Ref. [8], the input vectors have been partitioned into a
number of consecutive subsegments and a variation of the generalized Lloyd
algorithm has been used to train vector quantizers for these subsegments. The
subsegments are then quantized independently, and the quantization residual is
entropy coded to achieve lossless compression. An optimization of this
method, named local optimal partitioned vector quantization (LPVQ) has been
presented in Ref. [9], where the distortion caused by local partition boundaries
has been minimized. In Ref. [10], a technique called mean/shape vector
58 SECTION j II Algorithms and methods
quantization (M/SVQ) subtracts the sample mean from the input vector and is
scalar quantized for transmission; the resulting shape is vector quantized.
While in Ref. [11], each block of the image is converted into a vector with zero
mean and unit standard variation. Each input vector is then vector quantized,
and the mean and variance are scalar quantized for transmission.
Usually, VQ-based techniques require offline codebook training and online
quantization-index searching. For these reasons these methods are extremely
expensive from a computational point of view and not always well suited for
real-time applications.
2.2 Predictive coding
In predictive approaches for image compression, the main idea is to predict the
value of a pixel using previously visited neighbor pixels. This process often
consists of two distinct and independent components: modeling and coding. In
the modeling part, once a prediction for a pixel is made, the difference be-
tween the pixel and its prediction (defined as the prediction error), are stored.
Then an encoding method is used to compress them. More in detail, ap-
proaches using predictive coding are based on spatial, spectral, or hybrid
predictors to decorrelate the original image, and the prediction error samples
are then fed to an entropy coder. However, since prediction error samples
usually present some residual correlation, in several cases, context-based en-
tropy coding is carried out. In this framework, the samples are classified into a
predefined number of homogeneous classes based on their spatial or spectral
context. This means that the entropy of the context-conditioned model will be
lower than that of the stationary one, resulting in the entropy coder providing
improved compression.
In general, the modeling part can be formulated as an inductive inference
problem, in which the image is observed sample by sample (e.g., raster scan)
according to a predefined order. At each interval t, after having scanned past
data xt ¼ x1x2 . xt, it is possible to make inference on the next sample value
xtþ1 by assigning to it a conditional probability distribution P($jxt). In a
sequential formulation, the distribution P($jxt) can be derived from the past
and is available to the decoder as it decodes the past string sequentially
(Fig. 2). An alternative approach is based on a two-step scheme where the
conditional distribution is learned in a first step from the whole image instead
of a single sequence, then the obtained conditional distribution is provided to
the decoder as header information.
Today, the most widely used compression approach is JPG-LS (name
derived from the Joint Photographic Experts Group), thanks to its good
speed and compression ratio [12]. This technique implements the LOCO-I
algorithm (low-complexity lossless compression for images), where the
prediction is based on three neighboring points. Moreover, in JPG-LS,
Hyperspectral compression Chapter j 2.2 59
context modeling is used to detect local features such as smoothness and
texture patterns. Other techniques have been developed to improve the
compression rate but with significantly more complex algorithms, such as
the context-based, adaptive, lossless image codec (CALIC) [13], TMW [14],
and EDP [15] (these references are derived from the author names). CALIC
uses a more complex context-based method, which uses a large number of
modeling states to condition a nonlinear predictor and adapt the predictors to
varying the statistics of the source. The approach proposed in CALIC is
extended in TMW by extracting global images information used to improve
the overall quality of the predictions. EDP, on the other hand, makes use of
an edge direct prediction approach using a large number of neighboring
points.
An extension of the CALIC algorithm from 2D to 3D has been proposed in
Ref. [16], where depending on the correlation coefficient the algorithms switch
between intraband and interband predictions. The resulting residual is then
coded using context-based arithmetic codes. A further modification of
3D-CALIC algorithm has been proposed in Ref. [17], where, rather than
switching between interband and intraband modes, the M-CALIC algorithm
uses the full interband and a universal spectral predictor.
In Ref. [18], an optimum linear predictor in terms of minimum mean
square error and entropy coding are used, while in Ref. [19], the number of
predictors is selected in both spatial and spectral domains through the use of
fuzzy clustering and fuzzy prediction.
FIGURE 2 Predictive coding compression block diagram.
60 SECTION j II Algorithms and methods
A method based on Spectral-oriented Least SQuares (SLSQ) has been
proposed in Ref. [20], where linear prediction is used to exploit spectral
correlation while the prediction error is then entropy coded. The same authors
proposed a low-complexity method using an interband linear predictor and
interband least square predictor [21].
In Ref. [22], the spectral bands of the image are clustered and filtered by
means of an optimum linear filter for each cluster. The output of the filters is
then encoded using an adaptive entropy coder. This concept has been further
extended in Ref. [23], where the lookup tables have been introduced. In this
approach, the pixel that is nearest and equal to the pixel colocated with the
one to be predicted in the previous band is taken as the prediction. The sign
of the residual is coded first, followed by adaptive range coding of its
absolute value.
3. Lossy approaches
Recently, there has been an increasing interest in lossy compression because it
permits to obtain higher compression rates than lossless approaches with a
negligible loss of information. Many lossy approaches are based on transform
coding in order to perform spatial or spectral decorrelations, followed by a
quantization stage and an entropy coder (Fig. 3). More in particular, transform
coding works in two steps, the first step is to transform the data in a domain
where the representation of the data is more compact and less correlated. The
second step is to encode this information as efficiently as possible.
One of the most widely used approaches is the JPEG2000 (name derived
from the Joint PhotographicExperts Group) that uses wavelet transform to
perform decorrelation in the two spatial dimensions. The typical wavelet filter
used in JPEG2000 is a reversible 5/3 filter. This approach has the ability to
perform both lossless and lossy compression with the same algorithm. Indeed,
FIGURE 3 Transform-based compression block diagram.
Hyperspectral compression Chapter j 2.2 61
lossy compression can be obtained from a lossless encoded file by truncating
the bitstream at the appropriate point [24].
Since hyperspectral images exhibit both spatial and spectral redundancy,
several methods in the literature follow a high-performance scheme combining
a spectral decorrelator, such as the KarhuneneLoève transform (KLT) or
principal component analysis (PCA), the discrete wavelet transform (DWT), or
the discrete cosine transform (DCT), followed by the JPEG2000 algorithm
performing the spatial decorrelation, rate allocator, and entropy coder.
3.1 KarhuneneLoève transform
The most efficient transform is the KLT which is strongly related to the PCA.
The KLT procedure uses an orthogonal transformation to convert a set of
correlated variables into a set of linearly uncorrelated features. The trans-
formation is designed in order to have the first feature with the highest vari-
ance possible, and the successive features have the highest variance possible,
considering the orthogonality to the preceding features. In general, features
showing high variance are associated to information while low variance is
associated to noise. This permits to approximate the data in the feature space
by discarding the features having the less relevant variances. Although the
KLT is provably an optimal transformation, it has a few drawbacks. In
particular, the KLT algorithm consists of sequential processes, which are
computationally intensive, such as the covariance matrix computation,
eigenvector evaluation, and matrix multiplications. Moreover, since the KLT
transformation matrix is data dependent, it is necessary to transmit it to the
decoder in any KLT-based compression system.
In order to deal with the high computational complexity of the KLT, in
Ref. [25], precomputed transform coefficients, obtained using a set of typical
images, are applied to any image. However, this technique fits well with
multispectral images but becomes problematic with hyperspectral images
because the variations in the spectra between pixels become too important to
be efficiently decorrelated by a KLT. Other approaches have proposed a
simplified version of the KLT to be implemented onboard satellites [26,27].
In Ref. [28], the KLT has been deployed in JPEG2000 to provide spectral
decorrelation as well as spectral dimensionality reduction.
3.2 Discrete wavelet transform
The other most popular transform is the wavelet family. The DWT [29] is a
widely used technique for the efficient decorrelation of data obtained by
splitting the data into two half-rate subsequences, carrying information,
respectively, on the approximation and detail of the original signal, or
equivalently on the low- and high-frequency half-bands of its spectrum. Since
most of the signal energy of real-world signals is typically concentrated in low
62 SECTION j II Algorithms and methods
frequencies, this process splits the signal in a very significant and a little
significant part, leading to good energy compaction. Wavelet-based lossy
compression techniques are of particular interest due to their long history of
providing excellent rate-distortion performance for traditional 2D imagery.
Consequently, a number of prominent 2D compression algorithms have been
extended to 3D. These include the 3D extensions of JPEG2000, SPIHT (set
partitioning in hierarchical trees), and SPECK (Set Partitioned Embedded
bloCK Coder) [30e34]. In particular, these approaches employ a 1D discrete
wavelet transform for the spectral decorrelation, while a 2D DWT works
spatially.
In the literature several papers proposed hyperspectral lossy compression
based on DWT which is becoming the standard [26,29,35,36]. Where in
general multiresolution, wavelet transform is fully applied to each spectrum,
and then the dyadic 2D wavelet decomposition is applied on each resulting
plane. Wavelet-based compression techniques typically implement pro-
gressive transmission through the use of embedded coding. Progressive
image transmission allows an approximate image to be built up quickly and
the details to be transmitted progressively through several passes over the
image.
3.3 Discrete cosine transform
The DCT is a technique allowing the conversion of a signal into elementary
frequency components. More in particular, in the DCT the input signal is
represented as a linear combination of weighted basis functions that are related
to its frequency components.
In general, the DCT does not directly reduce the number of bits required to
represent the block. For instance, for an 8 � 8 block of 8-bit pixels, the DCT
produces an 8 � 8 of 11-bit coefficients due to the range of coefficient values.
However, considering that the DCT concentrate, the low-frequency co-
efficients, and remaining other coefficients are mainly zero, the compression
can be achieved by transmitting the near-zero coefficients and by quantizing
and coding the remaining coefficients.
The DCT, even if can be considered as an approximation of the full
optimality of the KLT, offers an computational cost versus performance ratio
and has been adopted for international standards, such as JPEG [37].
3.4 Quality evaluation
The introduction of lossy and near-lossy compression leads to the evaluation
of the quality of the reconstructed images. From a theoretical point of view, the
best practice would be to use ground truth. However, in many cases the ground
truth is not available or not completely accurate. Besides the availability of
ground truth, there are several ways to measure the quality of the reconstructed
Hyperspectral compression Chapter j 2.2 63
images, for instance, through the use of statistic distortion measures, such as
the signal-to-noise ratio (SNR) defined in Ref. [29] as:
SNR ¼ 10 Log10
s2
MSE
(4.1)
where s2 is the variance of the original image while MSE is the mean square
error between the original and the reconstructed images. In the case of real
images, noise-free references may not be available. Thus, the SNR can be
derived as the ratio between the mean value msignal of the pixels in the
image and the standard deviation of the pixels snoise of a uniform area in the
image:
SNR ¼ 10 Log10
msignal
snoise
(4.2)
In general, a lossy compression will remove noise, redundancies, and not
relevant information from the image, thus it is expected to have an improve-
ment of the SNR of the reconstructed image.
Another evaluation measure can be obtained through the use of the Spectral
Angle Mapper (SAM) algorithm that measures the spectral distance between
the reconstructed image and the original one:
SAM ¼ arccos
�
< X;X0 >
kXk2kX0k2
�
(4.3)
SAM produces positive values with an ideal value of 0. However, due to
noise suppression, values that are lower than three are referred to a good
reconstructed image.
4. Conclusions
Even if several approaches have been presented in the literature and imple-
mented or used in real situations, there is still a high number of issues to be
carried out in compression of hyperspectral image compression. First of all,
the choice between lossless, lossy, or nearly lossless approaches mainly de-
pends on the final use of the data. In the case of laboratory images where
archiving and distribution are more important than data transmission and error
recovery, the issues related to the compression are focused more on the pro-
cessing and visualization sides. This means that a high compression rate is
preferable over information preservation. For instance, progressive encoding
permits the rapid quick of the compressed image with limited computational
resources. On the other hand, in case of satellite-basedsensors, data trans-
mission becomes relevant. Indeed, the trend for hyperspectral sensors is to-
ward a continuous increase in spatial, spectral, and radiometric resolutions of
the images. This means that the increase in the amount of data produced by the
sensors is in contrast with the limited transmission capability, thus, there is the
64 SECTION j II Algorithms and methods
need to perform the compression onboard the satellites. However, onboard
compression presents several challenges. The first point is that when lossless
compression is used, it is not possible to obtain high compression rates and
consequently the acquisition capability is strongly reduced. On the other hand,
lossy compression techniques allow high compression rates, but part of the
information is lost. Near-lossless compression offers the best trade-off be-
tween compression rates and quality preservation, but the community still
refuses to accept these kinds of approaches even if the impact is proven to be
negligible. Another important point is related to the processing capability.
While the compression of laboratory images do not present any particular
problems in terms of processing approach and computational time, the
compression of images acquired onboard satellites presents several critical-
ities. In particular, the electronic instrumentations onboard satellites have to
follow several design constraints in terms of power consumption, heating,
radiation protection, and data storage. This means that the processing power is
reduced if compared to consumer electronic, thus not all the existing ap-
proaches can be used for compression of hyperspectral images acquired from
satellite. For these reasons, a direct comparison of the different compression
methods is not possible.
References
[1] D. Huffman, A method for the construction of minimum-redundancy codes, Proceedings of
the IRE 40 (9) (1952) 1098e1101.
[2] I.H. Witten, R.M. Neal, J.G. Cleary, Arithmetic coding for data compression, Communi-
cations of the ACM 30 (6) (1987) 520e540.
[3] M.J. Ryan, J.F. Arnold, The lossless compression of AVIRIS images by vector quantization,
IEEE Transactions on Geoscience and Remote Sensing 35 (3) (1997) 546e550.
[4] Y. Linde, et al., An algorithm for vector quantizer design, IEEE Transactions on Commu-
nications 28 (1980) 84e95. COMM.
[5] B. Ramamurthi, A. Gersho, Image vector quantization with a perceptually based classifier,
in: Proc. IEEE Int. Conf. Acoust., Speech, Sign. Process. , San Diego, CA, vol. 2, 1984, pp.
32.10.1e32.10.4.
[6] J. Conway, N. Sloane, Fast quantizing and decoding algorithms for lattice quantizers and
codes, IEEE Transactions on Information Theory 28 (1982) 227e232. IT.
[7] M.R. Pickering, M.J. Ryan, Efficient spatial-spectral compression of hyperspectral data,
IEEE Transactions on Geoscience and Remote Sensing 39 (7) (2001) 1536e1539.
[8] G. Motta, F. Rizzo, and J. Storer, “Partitioned vector quantization: application to lossless
compression of hyperspectral images,” in Proc. ICASSP, Apr. 6e10, 2003, vol. 3, pp. III-
241eIII-244.
[9] G. Motta, F. Rizzo, and J. A. Storer, “Compression of hyperspectral imagery,” in Proc. DCC,
Mar. 2003, pp. 333e342.
[10] R. Baker, R. Gray, Image compression using nonadaptive spatial vector quantization, in:
Conf. Rec. 16th Asilomar Conf. Circuits, Syst., Comput, 1982, pp. 55e61.
[11] T. Murakami, K. Asai, E. Yamazaki, Vector quantizer of video signals, Electronics Letters 7
(1982) 1005e1006.
Hyperspectral compression Chapter j 2.2 65
[12] M. Weinberger, G. Seroussi, G. Sapiro, The LOCO-I lossless image compression algorithm:
principles and standardization into JPG-LS, IEEE Transactions on Image Processing 9
(2000) 1309e1324.
[13] X. Wu, N. Memon, Context-based, adaptive, lossless image coding, IEEE Transactions on
Communications 45 (1997) 437e444.
[14] B. Meyer, P. Tischer, TMWA new method for lossless image compression, in: Proc. 1997
Int. Picture Coding Symp, 1997.
[15] X. Li, M.T. Orchard, Edge directed prediction for lossless compression of natural images,
in: Proceedings 1999 International Conference on Image Processing (Cat. 99CH36348),
Kobe, vol. 4, 1999, pp. 58e62.
[16] X. Wu, N. Memon, Context-based lossless interband compression d extending CALIC,
IEEE Transactions on Image Processing 9 (2000) 994e1001.
[17] E. Magli, G. Olmo, E. Quacchio, Optimized onboard lossless and near-lossless compression
of hyperspectral data using CALIC, IEEE Geoscience and Remote Sensing Letters 1 (1)
(2004) 21e25.
[18] R.E. Roger, M.C. Cavenor, Lossless compression of AVIRIS images, IEEE Transactions on
Image Processing 5 (5) (1996) 713e719.
[19] B. Aiazzi, P. Alba, L. Alparone, S. Baronti, Lossless compression of multi/hyper-spectral
imagery based on a 3-D fuzzy prediction, IEEE Transactions on Geoscience and Remote
Sensing 37 (5) (1999) 2287e2294.
[20] F. Rizzo, B. Carpentieri, G. Motta, J.A. Storer, High performance compression of hyper-
spectral imagery with reduced search complexity in the compressed domain, in: Proc. DCC,
2004, pp. 479e488.
[21] F. Rizzo, B. Carpentieri, G. Motta, J.A. Storer, Low-complexity lossless compression of
hyperspectral imagery via linear prediction, IEEE Signal Processing Letters 12 (2) (2005)
138e141.
[22] J. Mielikainen, P. Toivanen, Clustered DPCM for the lossless compression of hyperspectral
images, IEEE Transactions on Geoscience and Remote Sensing 41 (12) (2003) 2943e2946.
[23] J. Mielikainen, Lossless compression of hyperspectral images using lookup tables, IEEE
Signal Processing Letters 13 (3) (2006) 157e160.
[24] Jpeg2000 Part 2 e Extensions, Document ISO/IEC 15444-2.
[25] C. Thiebaut, E. Christophe, D. Lebedeff, C. Latry, CNES studies of on-board compression
for multispectral and hyperspectral images, in: SPIE, Satellite Data Compression, Com-
munications, and Archiving III, Vol. 6683. SPIE, 2007.
[26] B. Penna, T. Tillo, E. Magli, G. Olmo, Transform coding techniques for lossy hyperspectral
data compression, IEEE Transactions on Geoscience and Remote Sensing 45 (5) (2007)
1408e1421.
[27] B. Penna, T. Tillo, E. Magli, G. Olmo, A new low complexity KLT for lossy hyperspectral
data compression, in: IEEE International Geoscience and Remote Sensing Symposium,
IGARSS’06, 2006, pp. 3525e3528.
[28] Hyperspectral image compression using JPEG2000 and principal component analysis Q.
Du, J.E. Fowler IEEE Geoscience and Remote Sensing Letters 4 (2), 201-205.
[29] J.E. Fowler, J.T. Rucker, 3D wavelet-based compression of hyperspectral imagery, in: C.-
I. Chang (Ed.), Hyperspectral Data Exploitation: Theory and Applications, Wiley, Hoboken,
2007, pp. 379e407 (Chapter 14).
[30] B. Penna, T. Tillo, E. Magli, G. Olmo, Progressive 3-d coding of hyperspectral images based
on jpeg 2000, IEEE Geoscience and Remote Sensing Letters 3 (1) (2006) 125e129.
66 SECTION j II Algorithms and methods
[31] B.-J. Kim, Z. Xiong, W.A. Pearlman, Low bit-rate scalable video coding with 3-d set
partitioning in hierarchical trees (3-d spiht), IEEE Transactions on Circuits and Systems for
Video Technology 10 (8) (2000) 1374e1387.
[32] X. Tang, W.A. Pearlman, Scalable hyperspectral image coding, in: Proceedings of the In-
ternational Conference on Acoustics, Speech, and Signal Processing, Philadelphia, PA, vol.
2, 2005, pp. 401e404.
[33] X. Tang, C. Sungdae, W.A. Pearlman, 3D set partitioning coding methods in hyperspectral
image compression, in: Proc. Of ICIP e IEEE International Conference on Image Pro-
cessing, Barcelona, Spain, 2003.
[34] X. Tang, W.A. Pearlman, Three-dimensional wavelet-based compression of hyperspectral
images, in: Hyperspectral Data Compression, Kluwer Academic Publishers, 2005.
[35] E. Christophe, C. Mailhes, P. Duhamel, Hyperspectral image compression: adapting SPIHT
and EZW to anisotropic 3D wavelet coding, IEEE Transactions on Image Processing 17
(12) (2008) 2334e2346.
[36] G. Liu, F. Zhao, Efficient compression algorithm for hyperspectral images based on cor-
relationcoefficients adaptive 3D zerotree coding, IET Image Processing 2 (2) (2008)
72e82.
[37] G. Wallace, The JPEG still picture compression standard, IEEE Transactions on Consumer
Electronics 38 (1) (1992).
Hyperspectral compression Chapter j 2.2 67
Chapter 2.3
Pansharpening
Gemine Vivone*
Department of Information Engineering, Electrical Engineering and Applied Mathematics,
University of Salerno, Salerno, Italy
*e-mail: gvivone@unisa.it
1. Introduction
Pansharpening, which stands for panchromatic (PAN) sharpening, refers to the
fusion of a PAN image and a multispectral (MS) image. These images are
usually simultaneously acquired over the same area. Pansharpening can be
included into the data fusion framework because its goal is to combine, in a
unique synthetic image, the spatial information provided by the PAN image
(but not present in the MS) with the spectral information of the MS image
(against the single PAN channel).
Nowadays, PAN and MS images can be simultaneously acquired by several
commercial satellites, see, e.g., the four-band MS cases, such as IKONOS and
Geo-Eye, and the eight-band MS cases as the WorldView satellites (capturing
bands from the visible near-infrared (VNIR) spectrum to the shortwave
infrared (SWIR) spectrum). Thus, the possibility to reach very high-resolution
images in both the spatial and spectral domains is really appealing. Unfortu-
nately, physical constraints preclude this goal from being achieved by using a
unique sensor, and data fusion approaches are the sole viable solution to reach
this ambitious goal. Hence, the demand for pansharpened products is contin-
uously growing and commercial products, such as Google Earth and Bing
Maps, make massive use of them. Furthermore, pansharpening is a crucial
preliminary step for many remote sensing tasks, such as change detection [1],
object recognition [2], visual image analysis, and scene interpretation [3]. This
interest can be even noticed into the scientific community, and it is justified by
(1) the contest launched by the data fusion committee of the institute of
electrical and electronics engineers (IEEE) Geoscience and Remote Sensing
Society in 2006 [4], (2) the detailed surveys that can be easily found in the
literature, see, e.g., Refs. [5e7], and (3) the comprehensive book dedicated to
this problem recently published in Ref. [8].
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00005-5
Copyright © 2020 Elsevier B.V. All rights reserved. 69
https://doi.org/10.1016/B978-0-444-63977-6.00005-5
This chapter proposes an overview of this issue. Section 2 is dedicated to the
classification of pansharpening methods. Pansharpening techniques are divided
into three main classes. The first two classes historically split methods in spectral
and spatial techniques. The first presented category, the so-called component
substitution (CS), is based on a spectral transformation in order to separate the
spatial and the spectral information of the MS image. The second class, usually
named multiresolution analysis (MRA), is relied upon the decomposition of the
PAN image in order to extract its spatial details to be injected into the MS image.
The last (third) class consists of new generation approaches for pansharpening.
These are mainly based on the application of constrained optimization algorithms
to solve the ill-posed problem of pansharpening.
Afterward, in Section 3, we focus attention on the tricky problem of the
assessment of pansharpening approaches. Unfortunately, as in many data
fusion problems, a reference image is missing and, thus, universal measures
for evaluating the quality of the enrichment introduced by pansharpening
cannot be explicitly formulated. A first solution to this issue dates back to
Wald et al. [9]. They define a protocol based on two properties: consistency
and synthesis. Whereas the former is more easily achievable, the latter requires
the knowledge of the original MS image at a higher resolution (i.e., the PAN
one). This leads to some critical issues about the implementation of this
protocol, such as the unavailability of a (reference) high-resolution MS image
thus precluding the evaluation of the synthesis property. In order to face these
problems, two main solutions are presented in this chapter. The first one relies
on the reduction of the spatial resolution of both the original MS and PAN
images in order to exploit the original MS image as reference [4]. It implicitly
leads to a hypothesis of invariance among scales of the fusion procedures.
Unfortunately, this hypothesis could be not always valid in practice [9,10].
Hence, the second solution employs indexes that do not require the availability
of a reference image, see, e.g., Refs. [11,12].
Pansharpening has also been proposed for the fusion of PANand hyperspectral
(HS) data [13]. In this chapter, and, in particular, in Section 4, the HS pan-
sharpening problem is discussed. The new challenges in fusingHS data instead of
classical MS images are remarked first. Afterward, a real example of fusing HS
and PAN data simultaneously acquired by the HS imager (Hyperion) and the
advanced land imager (ALI) sensors over the center of Paris (France) is presented.
Finally, this chapter ends with concluding remarks in Section 5.
2. Classification of pansharpening methods
Pansharpening approaches are historically classified into two main classes: CS
and MRA [5,8]. The main difference between them is how to extract PAN
details. MRA methods extract PAN details using spatial filters applied to the
PAN image. Instead, CS exploits both the high spectral resolution image and
the PAN image to extract PAN details. This difference in detail extraction
70 SECTION j II Algorithms and methods
influences the main features of the final outcomes [5,14]. Recently, in the
literature, even other fusion approaches, the so-called new generation of
pansharpening [8], have been proposed. These are mainly related to Bayesian
approaches [15], compressed sensing [16e18], and total variation techniques
[19,20]. These methods cannot be recast in one of the two main classes, but
they have shown, in some cases, appreciable results usually paid by an
increment of the computational burden. In the next sections, we will go deep
into the details of all these three classes. Some powerful examples of pan-
sharpening techniques, even tested for HS pansharpening, will be detailed. All
the approaches that will be presented in this chapter are global, i.e., the fusion
is applied in the same way for the whole image. Some generalizations to
context-based (or local) approaches can be found in the literature, see, e.g.,
Refs. [21e24], where the injection model is context-dependent and thus
varying inside the acquired image.
2.1 Notation
The notation and conventions used in the next sections are detailed first.
Vectors are indicated in bold lowercase (e.g., x) with the ith element indicated
as xi. Two- and three-dimensional arrays are expressed in bold uppercase (e.g.,
X). A high spectral resolution image X ¼ fXkgk¼1;.;N is a three-dimensional
array composed by N bands indexed by the subscript k ¼ 1,., N; accordingly,
Xk indicates the kth band of X.
2.2 Component substitution techniques
CS approaches are based on a forward transformation of the higher spectral
resolution (HSR) image, usually MS or, similarly, HS images, in order to
separate the spatial and spectral information [6]. The sharpening process is
obtained by substituting the spatial component, which theoretically retains all
the spatial information, with the PAN image, which represents the data with
the highest spatial content. In the literature, approaches that only partially
replace the PAN image have been also proposed, see, e.g., Ref. [25].
The greater the correlation between the PAN and the replaced spatial
component, the lesser the spectral distortion into the final fusion product [6].
Fig. 1 shows an example of fusion using two CS approaches (i.e.,
GrameSchmidt (GS) and GS adaptive (GSA)).In the case of GS, the spatial
component, also called intensity component, is less correlated with the PAN
image causing a greater spectral distortion with respect to the GSA, as can be
seen in Fig. 1B comparing it with the reference image in Fig. 1A. In order to
increase the correlation reducing the spectral distortion in the fused product, a
histogram-matching (or equalization) procedure between the PAN and the
intensity component is usually exploited. Figs. 2 and 3 shows an example of
the benefits in applying this processing step before the CS using a principal
Pansharpening Chapter j 2.3 71
component substitution (PCS) fusion approach [5]. The reduction of the
spectral distortion is clear in Fig. 3. A greater color fidelity can be remarked
when the histogram-matching is applied.
Finally, once the substitution of the spatial (intensity) component with the
PAN image is performed, a backward transformation is applied to transform the
new spatial and spectral components in bands yielding the final fused image.
Summarizing, the main steps to get a fused product into the CS framework are:
l The upsampling of the HSR image to reach the same scale as the PAN
image (this operation is preparatory for the image fusion);
l The forward transformation of the HSR image in order to separate the
spatial and the spectral contents;
FIGURE 1 An example of spectral distortion for component substitution approaches (see, e.g.,
the river area on the right side of the images). An image acquired by the IKONOS sensor over the
Toulouse city is fused: (A) Ground-truth (reference image) and the fusion products using the (B)
GrameSchmidt (GS) and (C) the GS adaptive (GSA) approaches. A greater spatial distortion can
be pointed out in the case of GS where a lower similarity between the panchromatic and the
multispectral spatial (intensity) component is shown with respect to the GSA case.
FIGURE 2 An example of spectral distortion for component substitution approaches. An image
acquired by the IKONOS sensor over the Toulouse city is fused. Error maps between the ground-
truth (reference image) and the fusion products using (A) the GrameSchmidt (GS) and (B) the GS
adaptive (GSA) approaches. A greater spatial distortion can be pointed out in the case of GS where
a lower similarity between the panchromatic and the multispectral spatial (intensity) component is
shown with respect to the GSA case.
72 SECTION j II Algorithms and methods
l The substitution of the spatial component with the PAN image (a
histogram-matching can be also required in this phase);
l The backward transformation to get the fused product.
Under the hypotheses of (1) linear transformation and (2) spatial infor-
mation retained in a unique component [26], the CS fusion process can be
strongly simplified [5]. dHSRk ¼ gHSRk þ gkðP� ILÞ; (1)
where dHSR is the pansharpened image, gHSR is the upsampled HSR image,
the subscript k indicates the kth band, N is the number of bands, g ¼ [g1,.,gk,
.,gN] is the vector of the injection gains, while, IL is defined as follows:
IL ¼
XN
i¼1
wi
gHSRi; (2)
where the weights w ¼ [w1, .,wi, .,wN] measure the spectral overlap among
the spectral bands and the PAN image [6,27] (Fig. 4).
Fig. 5 shows a flowchart describing the fusion process of the CS approach.
Specifically, it is possible to notice blocks for (1) upsampling the HSR image
to reach the PAN scale; (2) calculating the intensity component by Eq. (2); (3)
histogram-matching the PAN image with the intensity component; (4)
injecting the extracted details according to (1).
The main advantages of CS-based fusion techniques are (1) high fidelity in
rendering the spatial details in the final product [28] and (2) fast and easy
FIGURE 3 An example of the spectral distortion reduction due to the histogram-matching for
component substitution approaches (see, e.g., the river area on the right side of the images). An
image acquired by the IKONOS sensor over the Toulouse city is fused: (A) Ground-truth (refer-
ence image) and the fusion products using the (B) principal component substitution (PCS) without
histogram-matching and (C) PCS with histogram-matching. A greater spatial distortion can be
pointed out in the case of PCS without the histogram-matching with respect to the same procedure
including the histogram-matching processing step.
Pansharpening Chapter j 2.3 73
implementation [26]. Furthermore, robustness with respect to spatial mis-
alignments can be also remarked [14]. On the contrary, the main shortcoming is
the generation of a significant spectral distortion in the final fused product due to
the spectral mismatch between the PAN and the intensity component [6].
The CS family includes many popular pansharpening approaches. In
Refs. [13,29], three approaches based on KarhuneneLoéve [30] and
GrameSchmidt [28,31] transformations have been compared for sharpening
HS data. In the following, we will focus attention on these techniques that will
be included in our benchmark for fusing HS and PAN data in the real example
in Section 4.
2.2.1 Principal component substitution
The PCS, proposed in Ref. [30], is a technique widely employed for pan-
sharpening. It is based on the principal component analysis (PCA), a.k.a.
KarhuneneLoéve transform or Hotelling transform. A rotation of the original
data (i.e., a linear transformation) is performed to yield the so-called PCs. The
hypothesis underlying its application to pansharpening is that the spatial in-
formation (shared by all the channels) is concentrated in the first PC, while the
spectral information (specific to each single band) is accounted by the other
PCs.
The whole fused process can be described by the general formulation stated
by (1), where the w and g coefficient vectors are image-dependent because
derived by the PCA procedure on the HSR image.
FIGURE 4 An example of the spectral distortion reduction due to the histogram-matching for
component substitution approaches. An image acquired by the IKONOS sensor over the Toulouse
city is fused. Error maps between the ground-truth (reference image) and the fusion products using
(A) the principal component substitution (PCS) without histogram-matching and (B) the PCS with
histogram-matching. A greater spatial distortion can be pointed out in the case of PCS without the
histogram-matching with respect to the same procedure including the histogram-matching pro-
cessing step.
74 SECTION j II Algorithms and methods
2.2.2 GrameSchmidt
The GS transformation is often exploited by pansharpening approaches. Its
first implementation for pansharpening dates back to a patent by Kodak [31].
GS constitutes a more general method than PCS, which can be obtained by
using the first PC as the low-resolution PAN image into the GS framework
[23].
The fusion process starts by using, as the first basis vector, a synthetic low
spatial resolution PAN image IL at the same scale of the HSR image. The
representation of the HSR image is then carried out by building a complete
orthogonal basis. The pansharpening procedure is completed by substituting
the first component with the PAN image and by inverting the transformation.
This fusion process can be expressed using (1), with gains [28].
gk ¼
cov
 gHSRk; IL
!
varðILÞ ; (3)
where cov (X, Y) indicates the covariance between X and Y and var (X) is the
variance of X.
By changing the way to generate the low spatial resolution PAN image, we
can have different techniques. The simplest way to generate IL consists in
FIGURE 5 Flowchart presenting the blocks of a generic component substitution pansharpening
procedure. HSR, Higher spectral resolution; LPF, Low-pass filter.
Pansharpening Chapter j 2.3 75
averaging the HSR bands (i.e., in setting wi ¼ 1/N, for all i ¼ 1, ., N); this
fusion approach is often called GrameSchmidt [31]. In Ref. [28], the authors
proposed an enhanced version, called GS adaptive (GSA), in which IL is
generated by the linear model in (2) with the weights estimated via theminimization of the mean square error between (2) and a filtered and down-
sampled version of the PAN image.
2.3 Multiresolution analysis methods
The main concept under the approaches belonging to this category is to extract
details by decomposing the PAN image exploiting the MRA framework. In the
last years, this approach has been questioned considering it is time consuming
for the specific application. Indeed, it has been demonstrated that the full
decomposition of the PAN image is not generally required and only the low-pass
filters have to be properly designed to extract PAN details [5,32]. Thus, the
MRA approaches can collapse into the category of the spatial filtering methods,
where the key issue is represented by the design of the low-pass filter to extract
the details of the PAN image [5]. Several approaches have been developed in the
literature to deal with this issue, and many pansharpening methods differ from
this step. Indeed, the literature proposes the application of both linear filters
(such as Gaussian filters [32], box filters [33], wavelet decompositions [34,35])
and, recently, nonlinear filters (see e.g., Ref. [36]). Filter estimation procedures,
based on the deconvolution framework, have been also proposed [37].
Summarizing, the fusion process, for k ¼ 1, ., N, is formalized as follows
[5]. dHSRk ¼ gHSRk þGkðP� PLÞ; (4)
where PL indicates the low spatial resolution PAN image and G is a matrix of
injection coefficients with the same size of gHSR.
According to Eq. (4), the different approaches belonging to this category
can differ from (1) the spatial filters used to get PL (some widespread solutions
have been listed above) and (2) the injection coefficients fGkgk¼1;.;N.
Common choices for these latter are:
1. Gk ¼ 1 for each k ¼ 1, ., N, where 1 is a unitary matrix with the same
size as P. This choice identifies the so-called additive injection scheme
[5,38];
2. Gk ¼ gHSRk =PL for each k ¼ 1,., N. In this case, the details are weighted
by the ratio of the HSR and PL, with the aim of reproducing, in the fused
image, the local intensity contrast of the PAN [38]. This coefficient se-
lection is often named high pass modulation (HPM) method or multipli-
cative injection scheme.
3. Gk ¼ 1 covð gHSRk;PLÞ=varðPLÞ for each k ¼ 1,.,N. This injection model
is often called projective in the literature [5,32].
76 SECTION j II Algorithms and methods
The general scheme of MRA fusion methods is reported in Fig. 6.
Accordingly, the required blocks are (1) upsampling of HSR image to reach
the PAN scale; (2) low-pass filtering of P to get PL; (3) calculation of the
injection gains fGkgk¼1;.;N; (4) injection of the extracted details according to
Eqn (4). Apart from the filter, the methods can differ from the application or
not of the decimation step for PL. In the case of decimated approaches, it is
possible, by properly designing the spatial filters, to compensate the aliasing of
the HSR image through the fusion process [39].
The MRA family includes many popular pansharpening approaches. In the
literature [13,29], three approaches have been compared for sharpening HS data.
In the following, we will focus attention on these techniques that will be included
in our benchmark for fusing HS and PAN data in the real example in Section 4.
2.3.1 Smoothing filter-based intensity modulation
A popular implementation of (4) consists in applying a linear time-invariant
(LTI) low-pass filter (LPF) hLP to the PAN image P to get PL. Therefore,
PL ¼ P * hLP in which * denotes the convolution operator. The smoothing
filter-based intensity modulation (SFIM) algorithm [33] sets hLP to a simple
box (i.e., an average) filter and exploits the HPM as injection scheme.
2.3.2 Laplacian pyramid
The resolution reduction can be obtained in more than one step in order to get
the low-pass signal PL at the original resolution of the HSR image. This is
FIGURE 6 Flowchart of a generic multiresolution analysis pansharpening approach. HSR, higher
spectral resolution.
Pansharpening Chapter j 2.3 77
commonly referred to as pyramidal decomposition and dates back to the
seminal work of Burt and Adelson [40]. Gaussian filters can be tuned to
closely match the HSR sensors’ modulation transfer function (MTF) [32], thus
extracting all the required details to enhance the HSR image to the PAN spatial
resolution. In order to properly design the filters to match the sensors’ MTF,
the standard deviation, which is the unique parameter that characterizes the
whole Gaussian distribution in this case, is set starting from sensor-based
information (i.e., the value of the amplitude response at the Nyquist fre-
quency provided by the manufacturer).
Both the additive and the multiplicative injection schemes [32,38] have
been exploited for HS sharpening. They are usually referred to as
MTF-generalized Laplacian pyramid (MTF-GLP) [32] and MTF-GLP with
high pass modulation (MTF-GLP-HPM) [38], respectively.
2.4 A new generation of pansharpening approaches
The new generation of pansharpening approaches is based on superresolution
paradigms or, generally speaking, the application of constrained optimization
algorithms to solve the ill-posed problem of pansharpening. These paradigms
are related to the issue of reconstructing the high spatial resolution image by
fusing its low spatial resolution versions. This inverse problem is usually
strongly ill-posed implying a nonunique solution.
Therefore, various regularization methods, introducing different prior
knowledge, have been proposed to stabilize the inversion [41]. A powerful and
emerging approach relies upon the sparse representation of signals or com-
pressed sensing theory [42,43]. The first seminal work for pansharpening is
presented in Ref. [16], but it is not practicable requiring a huge database of
unavailable high spatial high spectral images. Thus, several approaches have
been proposed in the literature to overcome this issue, which employ standard
representation matrices [44] or dictionaries constructed from a set of available
PAN and HSR images [45]. A feasible option consists in deriving the dictio-
naries only from the data set at hand. In particular, different solutions comprise
a dictionary built from (1) only the PAN image [17], (2) both the PAN and the
original HSR image [46], and (3) a set of synthetic pansharpened images [47].
Another class of new generation approaches is represented by Bayesian
methods [15]. This is based on a posterior distribution of the full resolution image
given the observed HSR and PAN images. The posterior is composed by two
factors: (1) the likelihood function,which is theprobability density of the observed
HSR and PAN images given the full resolution image and (2) the prior probability
density of the target image. The prior probability is of critical importance to cope
with the usual ill-posedness of the pansharpening inverse problem.
Variational techniques, see e.g., Refs. [19,20], can be interpretable as a
particular case of Bayesian methods thus representing another class of new
generation pansharpening approaches. In this case, the target image is estimated
by maximizing the posterior probability density of the full resolution image.
78 SECTION j II Algorithms and methods
Examples of application of new generation approaches for HS pan-
sharpening can be found in the comprehensive review [13]. However, the most
of the methods belonging to this class suffer, on one hand, from modeling
inaccuracies, and, on other hand, from high computational complexity that
limits their applicability in practical cases and, in particular, with the growing
of the spectral bands to be fused.
3. Quality assessment of pansharpening products
The absence of a reference image in order to assess the performance is the main
limitation for validating pansharpening products. To this aim, two main pro-
cedures for assessing pansharpening approaches have been proposed in the
literature. Historically speaking, the first protocol that tries to overcome theproblem of assessing pansharpening products dates back to Wald et al. [9]. The
main idea is to spatially degrade the two images to fuse (i.e.,HSR andPAN). Thus,
spatialLTI low-passfilters are usually exploited.Once the twoproducts tobe fused
are properly degraded, the original HSR image is used as reference (target) image
(or ground-truth). On one hand, this procedure is very accurate generating a
reference image for the performance evaluation, on other hand, a hypothesis of
invariance among scale of the performance of fused products has to be performed
[3,5]. A further issue is also related to how to design the low-pass filters in order to
have a proper degradation to get the new, artificially generated, products to be
fused (indeed, this can bias the assessment of the fusion methods). In the
following, we will try to give an answer to this question, see Section 3.1.
In order to deal with these issues, the performance assessment at full
resolution (i.e., the original resolutions of HSR and PAN images) has been
proposed in the literature. On one hand, these approaches overcome the lim-
itations of a validation at reduced resolution (i.e., Wald’s protocol), on other
hand, these advantages are paid by a reduction of the performance assessment
accuracy. In Section 3.2, we will detail a recent approach used for the vali-
dation at full resolution.
Due to the shortcomings of both the quantitative evaluation procedures, a
qualitative evaluation of the fused outcomes through visual inspection is still
necessary to support the quantitative evaluation [4,5].
3.1 Wald’s protocol
The procedure operating at reduced resolution is based on Wald’s protocol [9].
This requires that:
1. Any fused synthetic image, once degraded to its original resolution, should
be as identical as possible to the original image HSRk.
2. Any fused synthetic image should be as identical as possible to the image
that the corresponding sensor would observe with the highest resolution.
Pansharpening Chapter j 2.3 79
3. The multi/hyperspectral set of synthetic images should be as identical as
possible to the multi/hyperspectral set of images that the corresponding
sensor would observe with the highest resolution.
Thus, the fusion of the HSR and PAN images at reduced resolution can
easily verify the synthesis properties of Wald’s protocol, see the second and
third statements, thanks to the presence of the reference image (represented by
the original HSR image). In particular, the degradation of the spatial resolution
of the starting images is obtained by decimating (i.e., applying a low-pass filter
and downsampling) by a sampling factor equal to the resolution ratio between
the two images. Let us denote the reduced resolution of the HSR image and of
the PAN image by HSR* and P*, respectively.
To verify the requirements of this protocol, the choice of degradation filters
becomes crucial. Generally speaking, the filters are defined for ensuring the
consistency of the pansharpening process (the first Wald’s statement). Since
the pansharpened image (that should match as close as possible with the
original reference image HSR), once degraded to its original resolution,
should be identical to the original HSR image (whose part is acted by its low
spatial resolution version HSR*), it is straightforward that the resolution
reduction of the HSR image has to be performed by employing a filter
simulating the sensor’s optical transfer function (OTF) (i.e., the Fourier
transform of the point spread function (impulse-response of the optical sys-
tem)). The OTF consists of the phase transfer function and the MTF. The
former can be safely neglected for our purposes, and the sensor’s blur is thus
modeled by the sole MTF. Practically, the degradation filter has to match the
MTF of the HSR sensor [32]. In addition, the filter used for obtaining the PAN
image, P*, has to be designed. An ideal filter is a widespread choice for
degrading it [32]. This is usually the right choice for degrading the PAN data
because these images are used to be restored before being distributed.
Several indexes have been proposed for comparing the fused product with
the reference image according to Wald’s protocol. Vectorial (i.e., jointly
considering all the spectral bands) similarity indexes are usually exploited.
The most used are:
l The spectral angle mapper (SAM) [48] is a simple index that measures the
image spectral distortion. It calculates the angle between the corresponding
pixels of the fused and reference images into the space defined by consid-
ering each spectral band as a coordinate axis. Let I{n} ¼ [I1,{n}, . ,IN,{n}]
and J{n} ¼ [J1,{n}, ., JN,{n}] be the pixel vectors of the HSR images I and J
with N bands, the SAM between these two images is defined as:
SAMðIfig; JfigÞ ¼ arccos
� hIfig; Jfigi
kIfigkkJfigk
�
(5)
80 SECTION j II Algorithms and methods
in which h$,$i denotes the scalar product (or inner product) and k$k the
vector l2 norm. The global value of SAM for the whole image is obtained by
averaging the single measures over all the pixels. The SAM is usually
measured in degrees. The optimal value of the SAM index is 0. The higher the
value of the SAM index, the greater the measured spectral distortion.
l The Erreur Relative Globale Adimensionnelle de Synthèse (ERGAS) [49] is
a credited vectorial index accounting for spatial/radiometric distortions. It
is defined as:
ERGAS ¼ 100
R
ffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffi
1
N
XN
k¼1
�
RMSEðIk; JkÞ
mðIkÞ
�2
;
vuut (6)
where RMSE is the root mean square error defined as
RMSEðI; JÞ ¼
ffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffi
E
h
ðI� JÞ2
ir
; (7)
m represents the mean of the image, R is the scale ratio between the PAN and
the HSR data, and E [$] denotes the mean operator. Since the ERGAS is
composed by a sum of RMSE values, its optimal value is 0. The higher the
value of the ERGAS index, the greater the measured distortion.
l The Q4 or the Q2n indexes [50,51] are vectorial extensions, accounting for
spectral distortion, of the Q-index [52] to vector data up to four bands, Q4
index [50], and to vector data with a number of spectral bands greater than
four, Q2n index [51]. In practice, the Q4/Q2n indexes are based on
modeling each pixel I{i} as a quaternion.
Ifig ¼ Ifig;1 þ iIfig;2 þ jIfig;3 þ kIfig;4: (8)
The Q-index [52] (or universal image quality index) has been developed in
the image processing literature to overcome some limitations of the RMSE for
perceptual quality assessment [52]. Its physical interpretation becomes
straightforward by writing its expression in the form:
QðI; JÞ ¼ sIJ
sIsJ
2IJ�
I
�2 þ �J�2 2sIsJ�
s2I þ s2J
�; (9)
where sIJ is the sample covariance of I and J, I is the sample mean of I, and sI
is the sample standard deviation of I. Accordingly, it comprises, in the order,
an estimate of correlation coefficient, the differences in the mean luminance
and in the contrast.
Pansharpening Chapter j 2.3 81
All the Q-indexes vary in the range [e1, 1], where 1 denotes the best fi-
delity to reference.
3.2 The quality without reference assessment
In order to perform the quality evaluation at the original (full) resolution,
several quality without no reference (QNR) indexes have been proposed in the
literature [8]. A powerful recent proposal combines the evaluation of
the spatial quality for pansharpened images, i.e., the spatial distortion DS, of
the QNR protocol [11] and the spectral quality, measured by the spectral
distortion index Dl, proposed in Ref. [53]. The comprehensive index is called
hybrid QNR (HQNR) [12]. It is defined as:
HQNR ¼ ð1� DlÞað1� DSÞb: (10)
Namely, it is composed by the product, weighted by the coefficients a and
b, of two separate values Dl and DS, which quantify the spectral and the spatial
distortion, respectively. The higher the HQNR index, the better the quality of
the fused product.The ideal value is 1 when both the spectral distortion (Dl)
and spatial distortion (DS) are equal to 0.
Dl is inspired by the consistency (first) property of Wald’s protocol. Thus, a
low-pass filter matching the shape of the MTF of the corresponding spectral
channel (usually the MTFs of HSR instruments have a Gaussian shape) is
applied to the fused product to compare it, after downsampling, with the
original HSR image. The similarity between the decimated pansharpened
product and the original low spatial resolution HSR data is measured by the
means of the Q4/Q2n index [50,51].
Instead, DS is calculated by
DS ¼
ffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffi
1
N
XN
i¼1
				Q� dHSRi ;P
�
� QðHSRi;PLPÞ
				q;q
vuut (11)
where PLP is a low-resolution (artificial) PAN image at the same resolution of
the HSR image obtained by filtering with a low-pass filter the original PAN
image and q is usually set to 1 [11]. From a theoretical point of view, the
perfect (even local) alignment between the interpolated version of the HSR
and the PAN images should be assured to avoid the loss of meaning for this
quality index. Unfortunately, practically, local small disalignments between
the HSR and PAN images can be observed (e.g., roofs of skyscrapers could be
misaligned because of the two images are often aligned on the ground).
4. Sharpening of hyperspectral data
Different spatial resolutions of satellite sensors are due to the trade-off in the
design of electro-optical systems. Such a trade-off is aimed at balancing
82 SECTION j II Algorithms and methods
some aspects, such as the signal-to-noise ratio (SNR), the physical di-
mensions of sensor arrays, and the transmission rate from the satellite to the
ground stations. Indeed, SNR usually decreases when spatial and spectral
resolutions increase. The time delay integration is a technology that is able to
increase the SNR for high-resolution PAN and MS sensors. Unfortunately,
this solution is not feasible for HS instruments [8], thus, for satellite in-
struments, the spatial resolution of HS sensors is expected to be limited to
tenths of meters in the next future. Physical dimensions of sensor arrays are
also crucial for SNR. Indeed, the SNR is reduced with the reduction of their
physical dimensions.
Although new technologies can be developed, see e.g., efficient detectors
based on solid state devices, spatial resolution will be limited by the need of
obtaining reasonable large swath widths. Last but not the least, limitation is
given by the transmission rate. Indeed, because of the high spectral resolution
of HS sensors, a huge volume of data to be stored on-board and transmitted to
the ground stations is expected with consequently strong power and memory
requirements. This implies limits to the spatial resolution of HS systems.
All these considerations advise the simultaneous acquisitions of a PAN
image and an HS image, and then fusing them to obtain a synthetic product
with both high spatial and high spectral resolutions. Thus, HS pansharpening
represents a hot topic to be investigated. In fact, many researchers have
focused attention on this issue trying to give an answer to the question how HS
and PAN images can be fused in a proper way. Thus, a comprehensive review
about the state-of-the-art for HS pansharpening has been proposed in Ref. [13].
The most of the presented approaches have been heritage from the MS pan-
sharpening literature. Hence, a real example of fusion for HS and PAN data
exploiting classical pansharpening methods is presented in Section 4.2. State-
of-the-art pansharpening approaches have been used as benchmark. These are
related to the CS and MRA classes. Despite new generation methods have
shown good performance in the literature of HS pansharpening, these are
neglected in this section due to the usual huge computational burden. Before
having a look at the real example, the new challenges in HS pansharpening are
reviewed first in Section 4.1.
4.1 New challenges in hyperspectral pansharpening
HS pansharpening is more complicated than that of the classical pan-
sharpening problem fusing MS data. The main reasons, which justify why this
fusion process is more complex than the classical MS pansharpening, are
listed, below:
l Whereas PAN and MS sensors almost acquire in the same spectral range,
the spectral range of an HS sensor is usually wider than that of a PAN
sensor. Indeed, the spectral range of a PAN sensor is close to the visible
Pansharpening Chapter j 2.3 83
spectral range, instead, HS sensors often cover the visible, the NIR, and the
SWIR spectrum ranges. Thus, a key point for HS pansharpening techniques
is the injection model required to preserve the spectral information of the
HSR data. Indeed, spatial details that are not available for several HS bands
have to be inferred through this model, in particular, when there is no
overlap between the HS spectrum and the PAN spectrum. This difficulty
already existed, to some extent, in the classical MS pansharpening, but it is
much more important in the case of HS pansharpening.
l The spatial scale ratio between HS and PAN can be greater than four
(typical case for pansharpening) and/or not power of two (see the fusion
example in Section 4.2). This implies that the application of some
extraction detail approaches developed for the classical MS pansharpening,
such as the wavelet-based ones, is not straightforward.
l The format of HS data is crucial. Unlike MS pansharpening, in which
spectral radiance and reflectance are equivalent from a performance point
of view, for HS pansharpening the presence of (1) absorption bands, (2)
spectrally selective path radiance offsets, and (3) strong decaying of solar
irradiance make fusion to be processed if a reflectance data product is
available.
l The adopted fusion approaches should be as simple as possible in order to limit
the computational complexity due to the hundreds of spectral bands tobe fused.
l Because of the number of spectral bands to be fused, the spectral distortion
plays a crucial rule. Thus, an HS pansharpening approach should be
designed to minimize the spectral distortion.
4.2 Hyperspectral pansharpening: a real example
Several classical pansharpening approaches are compared on a data set acquired
over the center of Paris (France) by theHS imager (Hyperion) and theALI sensors
on-board of the Earth Observing-1 (EO-1) satellite. The Hyperion sensor is
capable of resolving 220 spectral bands (from 0.4 to 2.5 mm) with a 30-m spatial
resolution. Instead, the ALI sensor acquires nine MS channels and a PAN image.
ThePANcamera has a spatial resolution of 10 m (scale ratio between PANandHS
is 3) and a spectral coverage from 0.48 to 0.69 mm. Both sensors are mounted on
the same platform, thus alleviating image coregistration issues. The swaths ofALI
andHyperion are partially overlapped in such away that there is a part of the scene,
in which the PAN and HS data are simultaneously available. In the experiments,
the sole bands, which overlap the spectral range of the PAN channel, are exploited
for the fusion (i.e., fromband14 to band 33). This data set is namedHyp-ALI, from
here on. ThePCS [30], theGS [31], and theGSA [28]methods are considered into
the CS class. Whereas, the SFIM [33], the Gaussian Laplacian pyramid with
MTF-matched filter (MTF-GLP) [32], and theGaussianMTF-matched filterwith
high pass modulation (MTF-GLP-HPM) injection model [38] are analyzed into
the MRA class.
84 SECTION j II Algorithms and methods
A first assessment at reduced resolution is provided to the readers in Fig. 7
in which GT indicates the ground-truth (reference) image corresponding to the
original HS data before the simulation process according to Wald’s protocol
described in Section 3.1. Thus, both the original HS and PAN images are
degradedat a lower spatial resolution. In particular, the original HS image is
degraded in order to simulate a spatial resolution of 90 m and the PAN image
is degraded to get a spatial resolution equal to 30 m (retaining the original
scale ratio equal to 3). The filters used in this phase are detailed in Section 3.1.
The quantitative results are reported in Table 1. The best results are provided
by the MTF-GLP-based approaches. By focusing attention on this category,
the best injection strategy is provided by the HPM with slightly better results
(see the overall quality index Q2n in Table 1) than the additive strategy,
corroborating the outcomes in the pansharpening literature, see e.g., Ref. [38].
The best CS approach is instead the GSA that exploits a regression approach to
build the intensity component reducing the spectral distortion (see the SAM
index in Table 1) with respect to the other compared approaches in the same
class. The performance of the GSA are very close to the best MRA-based
approaches with a very good rendering (very close to the GT), see Fig. 7E.
Into the MRA family, the advantages of using Gaussian MTF-matched filters
with respect to the box filter (used by the SFIM approach) are straightforward.
Indeed, the former are preferable compared to the latter, thanks to (1) the
capability to extract more spatial details and (2) a strong reduction of artifacts,
see Fig. 7FeH.
FIGURE 7 Reduced resolution Hyp-ALI data set (Red ¼ band 30, Green ¼ band 20, Blue ¼ -
band 14): (A) ground-truth; (B) EXP; (C) principal component substitution; (D) GrameSchmidt;
(E) GrameSchmidt adaptive; (F) smoothing filter-based intensity modulation; (G) modulation
transfer function-generalized Laplacian pyramid; (H) modulation transfer function-generalized
Laplacian pyramid with high pass modulation.
Pansharpening Chapter j 2.3 85
These results are corroborated by the full resolution assessment. The
quantitative results using the HQNR index are reported in Table 2. Again, the
best results are clearly obtained by the MTF-GLP approaches (HQNR indexes
TABLE 1 Reduced resolution assessment. Quantitative results on the Hyp-
ALI data set. Best results among the compared fusion approaches are in
boldface.
Algorithm Q2n SAM [o] ERGAS
GT 1.0000 0.0000 0.0000
EXP 0.5283 0.9661 3.1941
PCS 0.7965 0.7977 2.2648
GS 0.7967 0.7976 2.2637
GSA 0.8877 0.7301 2.3373
SFIM 0.7997 0.7990 2.2411
MTF-GLP 0.8889 0.7188 1.7478
MTF-GLP-HPM 0.8930 0.7209 1.7170
GS, GrameSchmidt; GSA, GS adaptive; GT, Ground-truth; MTF-GLP, Modulation transfer function-
generalized Laplacian pyramid;MTF-GLP-HPM, Modulation transfer function-generalized Laplacian
pyramid with high pass modulation; PCS, Principal component substitution; SFIM, Smoothing filter-
based intensity modulation.
TABLE 2 Full resolution assessment. Quantitative results on the Hyp-ALI
data set. Best results are in boldface.
Algorithm Dl DS HQNR
EXP 0.0486 0.3210 0.6460
PCS 0.1839 0.0321 0.7899
GS 0.1840 0.0318 0.7901
GSA 0.0771 0.0732 0.8553
SFIM 0.0368 0.0627 0.9028
MTF-GLP 0.0216 0.0337 0.9455
MTF-GLP-HPM 0.0202 0.0375 0.9430
GS, GrameSchmidt; GSA, GS adaptive; MTF-GLP, Modulation transfer function-generalized Lap-
lacian pyramid; MTF-GLP-HPM, Modulation transfer function-generalized Laplacian pyramid with
high pass modulation; PCS, Principal component substitution; SFIM, Smoothing filter-based intensity
modulation.
86 SECTION j II Algorithms and methods
very close to each other). A strong reduction of the spectral distortion is
generally shown by the MRA-based methods with respect to the CS-based
techniques, see the Dl index in Table 2. Again, the unique CS approach that
is able to reduce this kind of distortion is the GSA, which obtains intermediate
performance, and it is in between the PCS/GS and MRA approaches. On the
other hand, the MRA approaches slightly suffer from a spatial distortion, DS,
point of view, compared to CS-based methods, such as PCS and GS. In
particular, the SFIM approach obtains a very high value of DS, see Table 2,
corroborating the inability of box filters in properly extracting spatial details.
The visual inspection of some close-ups of the fused products obtained at full
resolution is shown in Fig. 8. These corroborate the quantitative outcomes.
5. Concluding remarks
With the increasing of satellite missions and the number of on-orbit sensors,
data fusion approaches are getting more and more attention into the scientific
community. Pansharpening is one of the main image fusion problems. In this
chapter, the principal approaches for pansharpening and their classification have
been presented. The two main assessment procedures have also been discussed.
The last part of the chapter has been dedicated to the particularization of the
pansharpening problem to the sharpening of HS data, i.e., to the fusion of a PAN
image with HS (instead of MS) data. New challenges with regard to this
problem have been pointed out, and a real example of the fusion of HS and PAN
FIGURE 8 Close-ups of the full resolution Hyp-ALI data set (Red ¼ band 30, Green ¼ band 20,
Blue ¼ band 14): (A) panchromatic; (B) EXP; (C) principal component substitution; (D)
GrameSchmidt; (E) GrameSchmidt adaptive; (F) smoothing filter-based intensity modulation;
(G) modulation transfer function-generalized Laplacian pyramid; (H) modulation transfer func-
tion-generalized Laplacian pyramid with high pass modulation.
Pansharpening Chapter j 2.3 87
data (acquired by the Hyperion sensor and the ALI sensor, respectively) has
been shown exploiting a benchmark of classical state-of-the-art pansharpening
techniques. The performance of the compared approaches has been evaluated
using both the assessment protocols. The advantages in using MRA methods,
and, in particular, the ones based on a prior physical knowledge about the
acquisition systems (i.e., spatial filters matched with the sensor’s MTF) what-
ever the adopted injection rule (i.e., additive or HPM), have been pointed out in
comparison with some widely used CS techniques. This gap in performance,
verified both at reduced resolution and at full resolution, can be justified by
considering that MRA methods are able to reduce the spectral distortion of
fused products, which represents a key point when HS data are fused.
References
[1] C. Souza Jr., L. Firestone, L.M. Silva, D. Roberts, Mapping forest degradation in the Eastern
Amazon from SPOT 4 through spectral mixture models, Remote Sensing of Environment 87
(2003) 494e506.
[2] A. Mohammadzadeh, A. Tavakoli, M.J. Valadan Zoej, Road extraction based on fuzzy logic
and mathematical morphology from pan-sharpened IKONOS images, Photogrammetric
Record 21 (2006) 44e60.
[3] F. Laporterie-Déjean, H. de Boissezon, G. Flouzat, M.-J. Lefèvre-Fonollosa, Thematic and
statistical evaluations of five panchromatic/multispectral fusion methods on simulated
PLEIADES-HR Images, Information Fusion 6 (2005) 193e212.
[4] L. Alparone, L. Wald, J. Chanussot, C. Thomas, P. Gamba, L.M. Bruce, Comparison of
pansharpening algorithms: outcome of the 2006 GRS-S data fusion contest, IEEE Trans-
actions on Geoscience and Remote Sensing 45 (2007) 3012e3021.
[5] G. Vivone, L. Alparone, J. Chanussot, M. Dalla Mura, A. Garzelli, G. Licciardi, R. Restaino,
L. Wald, A critical comparison among pansharpening algorithms, IEEE Transactions on
Geoscience and Remote Sensing 53 (2015) 2565e2586.
[6] C. Thomas, T. Ranchin, L. Wald, J. Chanussot, Synthesis of multispectral images to high
spatial resolution: a critical review of fusion methods based on remote sensing physics,
IEEE Transactions on Geoscience and Remote Sensing 46 (2008) 1301e1312.
[7] B. Aiazzi, L. Alparone, S. Baronti, A. Garzelli, M. Selva, Twenty-five years of pansharpening:
a critical review and new developments, in: C.-H. Chen (Ed.), Signal and Image Processing for
Remote Sensing, second ed., CRC Press, Boca Raton, FL, USA, 2012, pp. 533e548.
[8] L.Alparone,B.Aiazzi, S.Baronti, A.Garzelli, RemoteSensing ImageFusion,CRCPress, 2015.
[9] L. Wald, T. Ranchin, M. Mangolini, Fusion of satellite images of different spatial resolu-
tions: assessing the quality of resulting images, Photogrammetric Engineering & Remote
Sensing 63 (1997) 691e699.
[10] C. Thomas, L. Wald, Analysis of changes in quality assessment with scale, in: Proc. 9th Int.
Conf. Inf. Fusion, 2006, pp. 1e5.
[11] L. Alparone, B. Aiazzi, S. Baronti, A. Garzelli, F. Nencini, M. Selva, Multispectral and
panchromatic data fusion assessment without reference, Photogrammetric Engineering &
Remote Sensing 74 (2008) 193e200.
[12] B. Aiazzi, L. Alparone, S. Baronti, R. Carlà, A. Garzelli, L. Santurri, Full scale assessment of
pansharpening methods and data products, in: SPIE Remote Sensing, 2014, 924402e924402.
88 SECTION j II Algorithms and methods
[13] L. Loncan, S. Fabre, L.B. Almeida, J.M. Bioucas-Dias, L. Wenzhi, X. Briottet,
G.A. Licciardi, J. Chanussot, M. Simoes, N. Dobigeon, J.Y. Tourneret, M.A. Veganzones,
W. Qi, G. Vivone, N. Yokoya, Hyperspectral pansharpening: a review, IEEE Geoscience and
Remote Sensing Magazine 3 (2015) 27e46.
[14] S. Baronti, B. Aiazzi, M. Selva, A. Garzelli, L. Alparone, A theoretical analysis of the
effects of aliasing and misregistration on pansharpened imagery, IEEE Journal of Selected
Topics in Signal Processing 5 (2011) 446e453.
[15] D. Fasbender, J. Radoux, P. Bogaert, Bayesian data fusion for adaptable image pan-
sharpening, IEEE Transactions on Geoscience and Remote Sensing 46 (2008) 1847e1857.
[16] S. Li, B. Yang, A new pan-sharpening method using a compressed sensing technique, IEEE
Transactions on Geoscience and Remote Sensing 49 (2011) 738e746.
[17] X.X. Zhu, R. Bamler, A sparse image fusion algorithm with application to pan-sharpening,
IEEE Transactions on Geoscience and Remote Sensing 51 (2013) 2827e2836.
[18] M.R. Vicinanza, R. Restaino, G. Vivone, M. Dalla Mura, G. Licciardi, J. Chanussot,
A pansharpening method based on the sparse representation of injected details, IEEE
Geoscience and Remote Sensing Letters 12 (2015) 180e184.
[19] F. Palsson, J.R. Sveinsson, M.O. Ulfarsson, A new pansharpening algorithm based on total
variation, IEEE Transactions on Geoscience and Remote Sensing 11 (2014) 318e322.
[20] X. He, L. Condat, J. Bioucas-Dias, J. Chanussot, J. Xia, A new pansharpening method based
on spatial and spectral sparsity priors, IEEE Transactions on Image Processing 23 (2014)
4160e4174.
[21] B. Aiazzi, L. Alparone, S. Baronti, A. Garzelli, Context-driven fusion of high spatial and
spectral resolution images based on oversampled multiresolution analysis, IEEE Trans-
actions on Geoscience and Remote Sensing 40 (2002) 2300e2312.
[22] R. Restaino, M. Dalla Mura, G. Vivone, J. Chanussot, Context-adaptive pansharpening
based on image segmentation, IEEE Transactions on Geoscience and Remote Sensing 55
(2017) 753e766.
[23] B. Aiazzi, S. Baronti, F. Lotti, M. Selva, A comparison between global and context-adaptive
pansharpening of multispectral images, IEEE Transactions on Geoscience and Remote
Sensing 6 (2009) 302e306.
[24] A. Garzelli, Pansharpening of multispectral images based on nonlocal parameter
optimization, IEEE Transactions on Geoscience and Remote Sensing 53 (2015)
2096e2107.
[25] J. Choi, K. Yu, Y. Kim, A new adaptive component-substitution-based satellite image fusion
by using partial replacement, IEEE Transactions on Geoscience and Remote Sensing 49
(2011) 295e309.
[26] T.-M. Tu, S.-C. Su, H.-C. Shyu, P.S. Huang, A new look at IHS-like image fusion methods,
Information Fusion 2 (2001) 177e186.
[27] T.-M. Tu, P.S. Huang, C.-L. Hung, C.-P. Chang, A fast intensity- hue-saturation fusion
technique with spectral adjustment for IKONOS imagery, IEEE Transactions on Geoscience
and Remote Sensing 1 (2004) 309e312.
[28] B. Aiazzi, S. Baronti, M. Selva, Improving component substitution pansharpening through
multivariate regression of MSþPan data, IEEE Transactions on Geoscience and Remote
Sensing 45 (2007) 3230e3239.
[29] G. Vivone, R. Restaino, G. Licciardi, M. Dalla Mura, J. Chanussot, Multiresolution analysis
and component substitution techniques for hyperspectral pansharpening, in: Proc. IEEE
IGARSS, 2014, pp. 2649e2652.
Pansharpening Chapter j 2.3 89
[30] P.S. Chavez Jr., S.C. Sides, J.A. Anderson, Comparison of three different methods to merge
multiresolution and multispectral data: landsat TM and SPOT panchromatic, Photogram-
metric Engineering & Remote Sensing 57 (1991) 295e303.
[31] C.A. Laben, B.V. Brower, Process for Enhancing the Spatial Resolution of Multispectral
Imagery Using Pan-Sharpening, U.S. Patent # 6,011,875, 2000.
[32] B. Aiazzi, L. Alparone, S. Baronti, A. Garzelli, M. Selva, MTF-tailored multiscale fusion of
high-resolution MS and pan imagery, Photogrammetric Engineering & Remote Sensing 72
(2006) 591e596.
[33] J.G. Liu, Smoothing filter based intensity modulation: a spectral preserve image fusion
technique for improving spatial details, International Journal of Remote Sensing 21 (2000)
3461e3472.
[34] J. Núñez, X. Otazu, O. Fors, A. Prades, V. Palà, R. Arbiol, Multiresolution-based image
fusion with additive wavelet decomposition, IEEE Transactions on Geoscience and Remote
Sensing 37 (1999) 1204e1211.
[35] X. Otazu, M. González-Audı́cana, O. Fors, J. Núñez, Introduction of sensor spectral
response into image fusion methods. Application to wavelet-based methods, IEEE Trans-
actions on Geoscience and Remote Sensing 43 (2005) 2376e2385.
[36] R. Restaino, G. Vivone, M. Dalla Mura, J. Chanussot, Fusion of multispectral and
panchromatic images based on morphological operators, IEEE Transactions on Image
Processing 25 (2016) 2882e2895.
[37] G. Vivone, M. Simões, M. Dalla Mura, R. Restaino, J. Bioucas-Dias, G. Licciardi,
J. Chanussot, Pansharpening based on semiblind deconvolution, IEEE Transactions on
Geoscience and Remote Sensing 53 (2015) 1997e2010.
[38] G. Vivone, R. Restaino, M. Dalla Mura, G. Licciardi, J. Chanussot, Contrast and error-based
fusion schemes for multispectral image pansharpening, IEEE Geoscience and Remote
Sensing Letters 11 (2014) 930e934.
[39] B. Aiazzi, L. Alparone, S. Baronti, A. Garzelli, M. Selva, Advantages of Laplacian pyra-
mids over “à trous” wavelet transforms, in: L. Bruzzone (Ed.), Proc. SPIE Image Signal
Process. Remote Sens. XVIII, vol. 8537, 2012, 853704e1e853704e10.
[40] P.J. Burt, E.H. Adelson, The Laplacian pyramid as a compact image code, IEEE Trans-
actions on Communications 31 (1983) 532e540.
[41] J. Yang, J. Wright, T. Huang, Y. Ma, Image super-resolution via sparse representation, IEEE
Transactions on Image Processing 19 (2010) 2861e2873.
[42] D.L. Donoho, Compressed sensing, IEEE Transactions on Information Theory 52 (2006)
1289e1306.
[43] E.J. Candès, J. Romberg, T. Tao, Robust uncertainty principles: exact signal reconstruction
from highly incomplete frequency information, IEEE Transactions on Information Theory
52 (2006) 489e509.
[44] D. Liu, P.T. Boufounos, Pan-sharpening with multi-scale wavelet dictionary, in: Proc. IEEE
IGARSS, 2012, pp. 2397e2400.
[45] C. Jiang, H. Zhang, H. Shen, L. Zhang, A practical compressed sensing- based pan-
sharpening method, IEEE Geoscience and Remote Sensing Letters 9 (2015) 629e633.
[46] S. Li, H. Yin, L. Fang, Remote sensing image fusion via sparse representations over learned
dictionaries, IEEE Transactions on Geoscience and Remote Sensing 51 (2013) 4779e4789.
[47] M. Cheng, C. Wang, J. Li, Sparse representation based pansharpening using trained dic-
tionary, IEEE Transactions on Geoscience and Remote Sensing 11 (2014) 293e297.
90 SECTION j II Algorithms and methods
[48] R. H. Yuhas, A. F. H. Goetz, J. W. Boardman, Discrimination among semi-arid landscape
endmembers using the spectral angle mapper (SAM) algorithm, in: Proc. Summaries 3rd
Annu. JPL Airborne Geosci. Workshop, pp. 147e149.
[49] L. Wald, Data Fusion: Definitions and Architectures d Fusion of Images of Different
SpatialResolutions, Les Presses de l’École des Mines, Paris, France, 2002.
[50] L. Alparone, S. Baronti, A. Garzelli, F. Nencini, A global quality measurement of pan-
sharpened multispectral imagery, IEEE Geoscience and Remote Sensing Letters 1 (2004)
313e317.
[51] A. Garzelli, F. Nencini, Hypercomplex quality assessment of multi-/hyper-spectral images,
IEEE Transactions on Geoscience and Remote Sensing 6 (2009) 662e665.
[52] Z. Wang, A.C. Bovik, A universal image quality index, IEEE Signal Processing Letters 9
(2002) 81e84.
[53] M.M. Khan, L. Alparone, J. Chanussot, Pansharpening quality assessment using the mod-
ulation transfer functions of instruments, IEEE Transactions on Geoscience and Remote
Sensing 11 (2009) 3880e3891.
Pansharpening Chapter j 2.3 91
Chapter 2.4
Unsupervised exploration of
hyperspectral and
multispectral images
Federico Marinia,* and José Manuel Amigob
aDepartment of Chemistry, University of Rome La Sapienza, Roma, Italy;
bProfessor, Ikerbasque, Basque Foundation for Science; Department of Analytical Chemistry,
University of the Basque Country, Spain; Chemometrics and Analytical Technologies, Department
of Food Science, University of Copenhagen, Denmark
*Corresponding author. e-mail: federico.marini@uniroma1.it
1. Unsupervised exploration methods
Hyperspectral and multispectral images) are normally complex data sets
composed by a finite number of chemical compounds distributed in a surface.
Depending on the type of spectroscopic method used for acquiring the spectral
information per pixel, finding selective information for each compound is
essential to understand the chemical information that the image contains. One
method could be the simple exploration of an image by displaying the infor-
mation gathered by different wavelengths. Let us take as example, the Raman
image depicted in Fig. 1. This image is an emulsion of oil-in-water analyzed by
modified Raman imaging (SA Explorer 1) [1,2]. The image was recorded using
a laser at 633 nm excitation. The composition of this surface has been widely
described elsewhere [1e4], to the point that it is now often used as a bench-
mark image. The surface is composed by a background phase and several drops
of the oily phase. The total amount of spectral features are four, being two pure
signatures and two mixtures. One of the main features of Raman spectroscopy
is the fact that it almost always results in sharp peaks, some of them being
selective for a specific chemical compound. In this case, the display of some
selective wavelengths helps in a great extent to elucidate qualitatively the
presence and distribution of some of the chemical compounds in the sample
(Fig. 1, right). Even, a simple exposition of a false color image generated by
mimicking the hyperspectral channels into false RGB channels can offer some
qualitative information of the distribution of certain compounds.
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00006-7
Copyright © 2020 Elsevier B.V. All rights reserved. 93
https://doi.org/10.1016/B978-0-444-63977-6.00006-7
Nevertheless, this information must be taken with extreme caution, since it
is merely qualitative and hidden compounds can be found in small peaks or
even peaks being overlapped. Considering other types of images, wavelength
exploration is even more cumbersome. For example, near-infrared (NIR)
hyperspectral images are characterized by broad bands that trend to overlap
with other bands coming from different compounds in the sample. Moreover,
many times neither the spectral nor the spatial signatures contain selective
information of one particular component. That is, the pixels are normally
composed by mixtures of different compounds and the spectral signatures,
therefore, are normally overlapped. The main goals of exploratory data anal-
ysis, as introduced by Tukey [5], are to obtain the best insight into a data set, to
uncover its underlying structure, and to detect outliers and anomalies, mostly
by means of graphical approaches.
It is evident how the multivariate nature of the involved signals (both in
bulk spectroscopy and in hyperspectral imaging) makes a direct representation
of the data cumbersome and suboptimal. Indeed, since the human eye is able to
see at most three dimensions, inspection of a multivariate data set would
require to consider all the possible plots obtainable by combining two or three
of the measured variables: this operation would be not only impossibly
lengthy, but also it would provide a very partial picture of the system since, in
each plot, the largest part of the overall variability would remain undisplayed.
Based on this consideration, it is evident how the main problem in exploratory
data analysis is to find a way to summarize the most salient features in the data
in a few variables (ideally two or three), so that they could also be used for
graphical display without a significant loss in information.
Unsupervised exploration methods are methods that give qualitative in-
formation of the compounds distributed in a surface in a simple and non-
supervised manner by using only the self-contained information of the sample.
FIGURE 1 Exploration of a Raman image of an emulsion [1,2]. Left, false color image of a
Raman hyperspectral image. Top right, 30 random spectra taken from the image and bottom right,
the corresponding images obtained for some selected wavelengths.
94 SECTION j II Algorithms and methods
These methods are mostly based on the differences/similarities in the spectral
signatures of the pixels conforming the hyperspectral image and provide a first
overview of the distribution of some compounds in the sample.
Two big families are most used in hyperspectral imaging (his) and multi-
spectral imaging (MSI) framework, projection methods and clustering tech-
niques. In this chapter, we explain how projection methods and clustering
work dealing with hyperspectral and multispectral images, highlighting their
main benefits and drawbacks. Everything is illustrated with simple examples
used as benchmark examples. All analysis were developed by using
HYPER-Tools [6] (freely downloadable from www.hypertools.orgdlast
accessed April 2019).
2. Projection methods: Principal component analysis
In more rigorous geometrical terms, there is a necessity of finding a subset of
suitable (i.e., relevant to the problem under investigation) directions in space
onto which projecting the data points and the methods which operate such
transformation are called projection techniques or, focusing on the mathe-
matical nature of the corresponding models, bilinear methods.
Given the data matrix D, which in the case of hyperspectral imaging could
correspond, e.g., to the unfolded data hypercube, the goal of projection
methods is to look for F directions in space (characterized by their direction
cosines, gathered in the data matrix B), so that when the data are projected
onto them according to:
A ¼ DB (1)
the corresponding scores A, i.e., the coordinates of the points in this new
subspace describe the system as relevantly as possible according to some
prespecified criterion of interest.
Within this general framework, in the context of exploratory data analysis,
the most used projection method is principal component analysis (PCA) which
searches for direction which provides a representation of the data set which is
as close as possible to the original matrix D, i.e., which constitute the best
F-dimensional fit of the data in a least squares sense. Due to its fundamental
importance for data analysis, PCA and its applications to unsupervised anal-
ysis of hyperspectral images will be discussed in detail in the following
section.
2.1 Basics of principal component analysis
PCA [7] is a projection method that looks for orthogonal directions in the
multivariate space which account for as much as possible of the variability in
the data, i.e., which provide the representation that best approximates the data
in the least square sense.
Unsupervisedexploration Chapter j 2.4 95
http://www.hypertools.org
Given a data cube D with two spatial dimensions (X and Y) and one
spectral dimension (l), the first step before applying any bilinear model is the
unfolding of the data cube into a matrix such as D(X � Y,l) (Fig. 2).
The first principal component (PC1), whose direction cosines are called the
loadings p1, is then identified as follows. If the projection of the original data
D onto the direction p1 is indicated as bD1, then:bD1 ¼Dp1
�
pT1 p1
��1
pT1 ¼ Dp1p
T
1 (2)
where the last equality holds since p1 is unit norm. This principal component is
calculated in the direction of the maximum variance. Therefore, it will be the
most important principal component. The second principal component is
calculated in a similar manner but not on the original matrix D, but on the
“deflated” matrix resulting from subtracting the first principal component from
the original matrix:
Dnew ¼D� bD1 (3)
This operation is repeated for as many principal components as needed in
such a way that the matrix in now decomposed by a series of orthogonal
principal components that contain all the relevant information together with a
residual matrix E(X�Y,l):
D¼ t1p
T
1 þ t2p
T
2 þ.þ E (4)
Giving the general PCA model:
D¼TPT þ E (5)
FIGURE 2 Graphical representation of a principal component analysis model of a hyperspectral
sample containing two chemical compounds.
96 SECTION j II Algorithms and methods
Once the corresponding scores and loadings are calculated, the final step in
HSI and MSI is the refolding of the scores to obtain the so-called score sur-
faces (as seen in Fig. 2).
Considering the previous example of the emulsion, Fig. 3 shows the PCA
model of this hyperspectral image. As it can be denoted, the first three PCs
account for 97.55% of the explained variance, showing the distribution of the
three major compounds and leaving just 0.84% of the variance for the fourth
PC.
One of the main advantages of PCA is that since it is an unsupervised
exploratory method there is not a strong need to assess the exact amount of
PCs needed to explain all the sources of variance in the sample [8]. This choice
is left to the analyst, and, consequently, it is the analyst who decides how many
PCs are needed. In the previous example, a question could arise about whether
the fourth PC is needed or not. The answer to this question is in the loading. If
the loading profile denotes explainable chemical changes (as it might be this
case), then the PC contains relevant information. Otherwise, this information
will go to the residuals of the sample.
Another effect that can be observed in the composite image (using PC1,
PC2, and PC3 as they were the R, G, and B channels of a digital image) of the
PCA model in Fig. 3 is the smoothing effect that can be appreciated in the
surface. The surface of the false color image looks noisier, while the composite
image looks smoother. This is due to the fact that random and instrumental
FIGURE 3 Principal component analysis (PCA) model of the emulsion sample. Top left, the false
color image. Top, right, the first four PCs with the corresponding explained variance. Bottom left, a
composite image using PC1, PC2, and PC3 surfaces, and they were the RGB channels. Bottom
right, the loadings corresponding to the first four PCs. PC, principal component.
Unsupervised exploration Chapter j 2.4 97
noise, together with other minor artifacts in the surface have been removed and
left in the residuals, since they represent neglectable sources of variance. This
is one of the reasons why PCA is also called a variable reduction method, and
it is used for hyperspectral data compression [8,9].
2.2 PCA in multispectral imaging
The application of PCA in MSI follows the same principles as in HSI. The
main difference is that the preprocessing and normalization steps are more
adequate to the fact that the images at different wavelengths are measured in a
noncontinuous manner so they can be nonequidistant [9,10]. Therefore, vari-
ables are normalized using autoscaling instead of mean centering, which is the
standard procedure in HSI [8,9]. As an example, Fig. 4 presents a PCA model
made on the MSI of a banknote of 10 euros. This MSI was composed of 18
different wavelengths covering a range between 350 and 950 nm. The PCA
model denotes that there are different parts of the banknote painted with
different types of paints (some of them totally invisible in the NIR region).
2.3 Common misunderstandings using PCA in HSI and MSI
PCA model has some features that have been seeing by several authors as
either errors or drawbacks and, therefore, have discouraged researchers to use
FIGURE 4 Principal component analysis (PCA) model of a multispectral image of a banknote of
10 euros. Top left, the true color (RGB) image. Bottom left, a composite image using PC1, PC2,
and PC3 surfaces, and they were the RGB channels. Middle, the first four PCs with the corre-
sponding explained variance. Right, the loadings corresponding to the first four PCs. PC, principal
component.
98 SECTION j II Algorithms and methods
it. For this reason we consider fundamental to cite here some of the common
misunderstandings that might arise in the literature.
- Sign ambiguity: One of the major features of PCA is the sign ambiguity in
the calculations. The sing ambiguity is shown here as:
t1p
T
1 ¼ ð� t1Þ
�� pT1
�
(6)
Obviously, the mathematical results of the left and right parts in the
equation are the same. Nevertheless, it might happen that, apparently,
different results are obtained when running PCA several times on the same
sample (Fig. 5).
This issue has been said to be a big problem in certain publications.
Nevertheless, far for being an issue, this is a mathematical artifact that has
no impact whatsoever in the final result.
- Scores with negative concentration and loadings with negative spectral
intensity: First of all, we must clarify that scores are not absolute values of
concentrations and, analogously, loadings are absolute values of intensity.
The fact of obtaining negative score values for one component in a score
surface does not mean that the component is less important than another
that has positive score values. The importance is relative to the origin. In
such a way that scores of the same absolute value but with different sign
have the same importance. The same fact can be applied to the loading
profiles. This is something logical, since the scores and loadings are
calculated on data which are almost always at least centered and anyway in
FIGURE 5 Sign ambiguity shown in the example of Fig. 2. Left shows the result obtained in the
analysis in Fig. 2. Right shows the same result, but multiplied times �1. PC, principal component.
Unsupervised exploration Chapter j 2.4 99
order to maximize a measure of variance calculated onto an orthogonal
basis. Moreover, the data are usually normalized prior to the analysis.
- One PC is not one chemical compound: One of major mistakes applying
PCA in HSI and MSI is to ascertain that each PC belongs exclusively to one
chemical compound. This is not true, since PCA is a variance method.
Therefore, the PCs are calculated to maximize the variance. Moreover, each
PC is constrained to be orthogonal and it is wrongly assumed that each
chemical compound is an independent source of variance. A simple
example can be found in the PCA model of the banknote presented in
Fig. 4. A density scatter plot of PC1 versus PC2 denotes four different
groups of pixels, grouped this way due to their spectral similarity and, at
the same time, dissimilarity (Fig. 6). Observing this distribution of pixels
and retrieving the spatial information of their location, it can be observed
that each one of those four groups represents a different area in the surface
of the banknote, in such a way that using PC1 and PC2 scatter plots and
their corresponding loadings we can study the chemical compounds in the
banknote and the different combinationsbetween them.
For these reasons, it is absolutely mandatory to display the score surface
obtained together with the corresponding loading profile, to be able to
elucidate, to some extent, the chemistry hidden in the samples.
2.4 Splitting the sample
One aspect that is particularly interesting applying PCA to images is the fact
that the area measured might contain multiple sources of variance with
different influence on the data. It can happen that one area of the sample is
FIGURE 6 PC1 versus PC2 density scatter plot of the multispectral image of the banknote of 10
euros and the selection of four different pixel regions in the scatter plot and their position in the
sample. PC, principal component.
100 SECTION j II Algorithms and methods
covered by a compound (or a combination of compounds) whose spectral
influence is much higher pixel-wise than other minor compounds. In such
cases, a common practice should be to study the different areas separately in
order to fully understand the different sources of variability of the sample
under study. As an example, Fig. 7 shows different PCA models performed in
different areas of one single sample. The sample is a pharmaceutical tablet that
contains an external cover, different layers of coatings, and a core composed of
several chemical compounds. The HSI was taken in a wavelength range of
1000e2600 nm. Further information can be found elsewhere [11].
The PCA model performed in the whole surface can only barely differen-
tiate between the core of the tablet and the exterior layers (Fig. 7A). Sequen-
tially removing the different parts of the tablet, we can observe much clearer
details of the different compounds in the different sections (Fig. 7B,C and D).
3. Clustering
Another important aspect of the (unsupervised) exploratory analysis of
multivariate data is clustering [12e14]. Clustering methods partition the
available data into groups of objects (usually, but also variables can be clus-
tered), sharing similar features. The idea behind clustering is that objects
allocated in the same groups are as similar as possible to one another and as
different as possible from the individuals in the other groups. These groups are
also called clusters. In this paragraph, the most commonly adopted strategies
for clustering of multivariate data will be presented, with special focus on their
application in the context of image analysis.
Clustering algorithms are usually divided into hierarchical and partitioning
(nonhierarchical) strategies: the former, as the name suggests, operate by
defining a hierarchy of clusters, which are ordered according to increasing
similarity/dissimilarity, whereas the latter learn the group structure directly.
3.1 Hierarchical clustering
Hierarchical clustering methods [15] are based on building a hierarchy of
clusters, which is often represented graphically by means of a tree structure
called a dendrogram. This hierarchy results from the fact that clusters of
increasing similarity are merged to form larger ones (agglomerative algo-
rithms) or that larger clusters are split into smaller ones of decreasing dis-
similarities (divisive procedure). Such an approach has the advantage of
allowing exploration of the data at different levels of similarity/dissimilarity
and providing a deeper insight into the relationships among samples (or var-
iables, if those are the items to be clustered). Another big advantage is that,
since they are based on defining a similarity index among the clusters, any
kind of data (real-valued, discrete, binary) can be analyzed by these
techniques.
Unsupervised exploration Chapter j 2.4 101
FIGURE 7 Principal component analysis (PCA) models performed to a hyperspectral image of a tablet (further information [11]). For every line the first four PCs
and the corresponding loadings are shown. (A) PCA model of the whole surface. (B) PCA model of the coatings and the core of the tablet. (C) PCA model of only
the core of the tablet. (D) PCA model of only the coatings of the tablet. PC, principal component.
1
0
2
S
E
C
T
IO
N
j
II
A
lgo
rith
m
s
an
d
m
eth
o
d
s
In detail, in agglomerative clustering, one starts with single object clusters
(singletons) and proceeds by progressively merging the most similar clusters,
until a stopping criterion (which could be a predefined number of groups k) is
reached. In some cases, the procedure ends only when all the clusters are
merged into a single one, which is when one aims at investigating the overall
granularity of the data structure. On the other hand, divisive strategies start
with a single cluster which is iteratively split into groups which are as dis-
similar as possible from one another, until either a stopping criterion is met or
any cluster is a singleton.
In general, hierarchical procedures have the further advantage of not
requiring the definition of the final number of clusters a priori, as instead occurs
with partitioning strategies. In this paragraph, agglomerative procedures, which
are the ones most frequently adopted, will be discussed in greater detail, but
the same concepts can be easily generalized to the divisive ones.
As briefly anticipated above, agglomerative hierarchical techniques start
with a configuration in which each sample is a (singleton) cluster and proceed
by recursively merging the most similar clusters until a termination criterion is
met. Accordingly, two elements are of utmost importance when defining a
hierarchical strategy: a measure of similarity/dissimilarity, which is usually
related to a distance, and a way to generalize this measure to be applied to
pairs of clusters (subsets of individuals), rather than to pairs of samples; the
latter is usually called a linkage metrics. The definition of the linkage metrics
is fundamental as it determines the connectivity between the clusters and, in
general, the shape of the tree. Using as a prototype of dissimilarity measure the
Euclidean distance between two samples dij:
dij ¼kxi � xjk ¼
ffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiffiXNv
l¼1
ðxil � xjlÞ2
vuut (7)
where xi and xj are the vectors of measurements on the samples i and j,
respectively, while xil and xjl are their lth components, Nv being the total
number of measured variables, the main linkage distances usually adopted in
hierarchical clustering will be briefly discussed and compared.
In single linkage (nearest neighbor), the distance between two clusters is
defined as the smallest distance between objects belonging to these clusters,
i.e., the distance between the closest objects of the two individual groups:
dðCm;CnÞ¼min
i; j
dij i˛Cm; j˛Cn (8)
where d(Cm, Cn) is the distance between clusters m and n. This metrics favors
cluster separation and does not take in any account the internal cohesion of the
groups. On the other hand, if a small cluster is initially formed, it can lead to
the progressive merging of one object at a time to this cluster in what is called
a chain effect.
Unsupervised exploration Chapter j 2.4 103
Complete linkage (farthest neighbor) metrics, which defines the inter-
cluster distance as the maximum distance between the samples in the two
groups, i.e., as the distance of the farthest objects, behaves oppositely to single
linkage. As said, the distance between two clusters m and n is defined as:
dðCm;CnÞ¼max
i; j
dij i˛Cm; j˛Cn (9)
Complete linkage produces clusters which are usually similar in size across
the whole agglomeration process, and, as a consequence, the resulting
dendrogram appears more balanced.
A linkage metrics which is intermediate between nearest and farthest
neighbors is the average linkage, also called UPGMA (unweighted pair group
method using arithmetic averages). In this approach, the distance between two
clusters m and n is calculated as the arithmetic average of the distances be-
tween all possible pair of objects belonging to the different groups:
dðCm;CnÞ¼
PNm
i¼1
PNn
j¼1
dij
NmNn
i˛Cm; j˛Cn (10)
whereNm and Nn being the number of objects in clusters m and n, respectively.
Differently than in the cases described above, other linkage metrics,
sometimes also called geometric approaches, assume that the clusters may be
represented by their central points, e.g., the centroid or the median. In the
centroid method, also called UPGMC (unweighted pair group method using
centroids), the distance between two clusters m and n is defined as the distance
between their respective means (centroids) xm and xn:
dðCm;CnÞ ¼ kxm � xnk (11)
where
xm ¼
PNm�1
i¼1
PNm
j¼iþ1
dij
Nm
i; j˛Cm (12)
and
xn ¼
PNn�1
i¼1
PNn
j¼iþ1
dij
Nn
i; j˛Cn (13)
Although rather straightforward and geometrically sound, in some cases,
this metrics can lead to the paradox that the centroid of a new cluster resulting
from the fusion of, let us say, clusters m and n, CmWn; is closer to a third
cluster than either m or n were, leading to an incongruence to the tree hier-
archical structure. This drawback can be partially overcome by resorting to the
104 SECTION j II Algorithms and methods
median method, or WPGMC (weighted pair group method using centroids), in
which the (pseudo)-centroid of the cluster formed by merging clusters m and n
is defined as the average of the centroids of the two groups, so that, in defining
the next step of agglomeration, the dominance of the largest group is
downweighed:
xmWn ¼ xm þ xn
2
(14)
A last group of strategies focus on optimizing the homogeneity within
clusters and define the agglomeration strategy as the one minimizing the
decrease of homogeneity upon the merging; this is normally measured in terms
of minimum increase of the within cluster variance, as in the most commonly
used of these approaches, i.e., Ward’s method [16].
For algorithmic purposes, it is worth mentioning that all hierarchical
methods described in this paragraph can be easily implemented through the so-
called LanceeWilliams dissimilarity update formula [17]. Indeed, agglomer-
ative clustering is based on merging pairs of clusters defined at previous stages
of the recursive procedure. When doing so, to proceed to the next steps it is
necessary to calculate the distance between the newly formed group and the
remaining clusters. LanceeWilliams formula allows to calculate this distance
straightforwardly, according to the following relation:
dðCmWn;CsÞ¼amdðCm;CsÞ þ andðCn;CsÞ þ bdðCm;CnÞ
þ gjdðCm;CsÞ � dðCn;CsÞj
(15)
where the coefficients am, an, b, and g define the agglomerative criterion. The
values of these coefficients for the linkage metrics discussed above, together
with the information on whether Euclidean distance or its squared value, are
taken as dissimilarity measures, as reported in Table 1.
Whatever the linkage metrics chosen, as already anticipated the main
outcome of hierarchical methods is a tree structure representing the whole
process of progressively merging the less dissimilar clusters. Such a tree is
called a dendrogram and has the structure displayed in Fig. 8, for the case of
37 individuals.
The bottom part of the plot represents the starting point of the analysis,
where there are as many clusters as individuals (the abscissa does not have a
numerical scale and just accommodates object indices arranged so as to pro-
vide the best readability of the figure). As the agglomeration proceeds, pairs of
clusters are merged to form new ones (the horizontal lines in the plot indicate
these fusions), until at the end of the process, there is only one big group
containing all the objects. The ordinate of the plot is the distance at which the
various mergings occur: at each stage of the procedure, this distance represents
also the minimum distance between pairs of clusters.
Unsupervised exploration Chapter j 2.4 105
TABLE 1 Parameters of the LanceeWilliams update formula for the
different agglomeration methods, together with the definition of the initial
dissimilarity measure.
Method am an b g
Dissimilarity
measure
Single linkage 1
2
1
2 0 �
1
2
dij
Complete linkage 1
2
1
2 0 1
2 dij
Average linkage
(UPGMA)
Nm
NmþNn
Nn
NmþNn
0 0 dij
Centroid (UPGMC) Nm
NmþNn
Nn
NmþNn
�NmNn
ðNmþNnÞ2
0 d2
ij
Median (WPGMC) 1
2
1
2 � 1
4 0 d2
ij
Ward NmþNs
NmþNnþNs
NnþNs
NmþNnþNs
�Ns
NmþNnþNs
0 d2
ij
FIGURE 8 Schematic representation of a dendrogram for a simulated data set involving 37
objects from three clusters with different within-group variance. Complete linkage was used as
metrics and the resulting hierarchical tree shows the progressive agglomeration of the groups from
individual sample clusters up to the last step when all objects are grouped into a single cluster.
106 SECTION j II Algorithms and methods
3.2 Partitional clustering methods
Partition clustering algorithms [18] are the second group of clustering technique
which will be presented in this chapter and are, by far, the ones which are most
often used in the framework of image analysis, due to their characteristics,
which make them more suitable to deal with this kind of data. Indeed, given a
data set constituted of N individuals, partitioning techniques split the data into a
predefined numberK of groups, so that each object should bemapped (assigned)
only to a single cluster and each cluster should contain at least one sample
(“crisp” or “hard” clustering conditions). These conditions can be mathemati-
cally defined by introducing the membership function U, i.e., a matrix repre-
sentation of the partition: the generic element ofU, which is indicated as uik, can
only take values in [0,1], as it describes the membership degree of the ith object
(characterized by the vector of measurements xi) to the kth cluster Ck.
Accordingly, the matrix elements should satisfy the following rules:XN
i¼1
uik > 0 ck (16)
XK
k¼1
uik ¼ 1 ci (17)
(N and K being the total number of objects and clusters, respectively), so that a
value of 0 means that the individual is not a member of the group, whereas the
value 1 means that it completely belongs to the cluster. Under this premises,
the conditions for partitional clustering can be summarized as follows:
uik ¼
�
1 if xi ˛Ck
0 otherwise
(18)
These algorithms operate by iteratively relocating objects among groups
until a stopping criterion, which is usually expressed in terms of a minimum of
a loss function, is met. Unfortunately, the obtained partition may result to be
only locally optimal, as global optimality could only be guaranteed by an
exhaustive search which is computationally impractical. Iterative relocation
methods, whose most famous and used member is K-means, identify pro-
totypes as the most representative points of the clusters and define the loss
function Jm as the overall discrepancy in the partition, i.e., as the sum of an
appropriate dissimilarity/distance between each point and the prototype of the
cluster it has been assigned to. In K-means [19e22], the prototypes are defined
as the cluster centroids xCk
and the squared Euclidean distance is used as
dissimilarity measure in the loss function:
Jm
�
U; xCk
� ¼XN
i¼1
XK
k¼1
uik
��xi � xCk
��2 (19)
Unsupervised exploration Chapter j 2.4 107
Accordingly, the main steps of the algorithm can be summarized as
follows [21]:
1. Define an initial partition of the data, by providing a first estimate of the
centroids of the K clusters (e.g., by random selection or by less na€ıve
initialization procedures)
2. (Re)calculate the memberships of all the data points based on the current
centroids
3. Update the coordinates of the centroids for some or all the clusters based
on the new memberships of the individuals
4. Repeat steps 2 and 3 until convergence (no changes in Jm or U)
When looking at the algorithm, it is relatively straightforward to observe
that, if the number of objects to be clustered is large, K-means is significantly
faster, from a computational standpoint, than hierarchical approaches, and this
is one of the main reasons why it is often preferred when dealing with images.
Moreover, it producesconvex-shaped clusters which are, in general, tighter
than those resulting from hierarchical techniques. On the other hand, the main
drawback is that the choice of the optimal value of K is not trivial, and it is
normally done by trying different values and comparing the outcomes.
However, comparing the quality of the obtained clusters may also be not very
straightforward.
3.2.1 Fuzzy clustering
Partitional clustering algorithms may also be “fuzzified” to allow the possi-
bility of individuals belonging to two or more groups with a different degree of
membership [23e25]. This is accomplished by removing the constraint rep-
resented by Eq. (18), and allowing the elements of the matrix U describing the
partition to take any possible value in the interval [0,1]. Accordingly, the
matrix U is said to define K fuzzy sets, i.e., a partition in groups with a
continuous degree of membership. Fuzzy clustering strategies, then, aim at
finding not only the optimal coordinates of the cluster centroids, but also the
best values of the membership functions. This is accomplished by minimizing
a loss function which resembles the one of Eq. (19), the only difference being
the introduction of the fuzzy exponent m (which is always >1):
Jm
�
U; xCk
� ¼XN
i¼1
XK
k¼1
umik
��xi � xCk
��2
A
(20)
In Eq. (20), the notation k/k2A generically indicates the norm induced by
the metrics A on the multivariate space, which almost always is the Euclidean
norm. The role of the meta-parameter m is to modulate the extent of “fuzzi-
ness” in the partition: smaller membership values (“softer” clustering) are
favored by increasing values of m. Anyway, it is reported in the literature that a
value of 2 should work for most of the applications.
108 SECTION j II Algorithms and methods
Also in the case of fuzzy K-means, to calculate the optimal partition an
iterative relocation algorithm is used, whose relevant steps are summarized
below [25]:
1. Decide the number of clusters K, fix the value of the fuzzy coefficient m
and define the metrics of the multivariate space, in order to be able to
calculate the norm k/k2A
2. Obtain a first estimate of the partition matrix U, e.g., by random selection
or specific initialization approaches
3. Calculate the cluster centroids as xCk
¼
PN
i¼1
umikxiPN
i¼1
umik
4. Update the membership functions according to
uik ¼
0@PK
s¼1

kxi�xCkkA
kxi�xCskA
! 2
m�1
1A�1
5. Repeat steps 3 and 4 until convergence, e.g., until
��Uiter � Uiter�1
��2
A
< ε:
3.2.2 Spatio-spectral fuzzy clustering
When applying clustering algorithms to a data set, partitioning is normally
based only on the values of the measured variables; in the context of spectral
imaging, this means that only the spectral signature of the pixels, here defined
as xi, constitutes the basis for clustering. However, by doing so the spatial
relationship among the pixels is not taken into account when defining the
grouping and this could constitute a limitation in practical applications, since it
is reasonable to think that objects which are close in space may possess similar
clustering tendencies. To overcome this drawback, it is possible to modify the
fuzzy K-means algorithm, so that also the spatial information contributes to the
definition of the partition [26].
In detail, the spatio-spectral fuzzy K-means algorithms follow the steps of
the conventional fuzzy K-means procedure up to the update of the membership
function uik (step 4). After that, a spatial function is introduced to exploit the
spatial information:
hik ¼
X
j˛NBðxiÞ
ujk (21)
where NB(xi) defines a square window of pixels centered in xi (and usually
having dimensions 3 � 3 or 5 � 5). The function hik can be considered as a
membership function estimated only on the basis of the spatial information
and, analogously to uik, accounts for the probability of the i
th pixel to belong to
the kth cluster. Accordingly, the spatial function is then used to update the
membership function through the relation:
unewik ¼ upikh
q
ikPK
k¼1u
p
ikh
q
ik
(22)
Unsupervised exploration Chapter j 2.4 109
where the exponents p and q govern the relative contribution of the spectral
and spatial information, respectively. Here it should be stressed that in cases
where the image is relatively homogeneous, the introduction of the spatial
information just strengthens the spectral-based partitioning, so that the
resulting clusters are the same that would be obtained by standard fuzzy
C-means. On the other hand, when there are noisy pixels, the introduction of
the spatial contribution may allow to downweigh the effect of noise, blur, and/
or spikes reducing the impact of misassignments and ameliorating the
segmentation.
3.3 Common misunderstandings using clustering
As with PCA, the main advantage (and risk, to some extent) of using clustering
is the facility of applying any type of clustering and obtaining quantitative
conclusions from methodologies that are merely explorative. Therefore, it is
also important to highlight here some common misunderstandings that might
occur applying clustering methods.
- Clustering (and also PCA) are not classification methods: There is a
trend to refer to clustering (and, by extension, PCA) as classification
methods. In strict terms, the word “classification” involves supervision.
That is, any method that is aimed at classifying needs a previous step of
“training” and a further step of “validation.” In clustering and PCA, those
stages do not exist per se. It is true that PCA can be used as a class-
modeling methodology, but in order to do so, it should be followed by
the definition of a suitable classification criterion and proper validation;
anyway, even when these steps are undertaken, the resulting approach
should be named SIMCA (soft independent modeling of class analogy)
[27].
- It is complicated to set the proper number of clusters: Since clustering is
not a classification method (does not rely on the a priori knowledge on the
existence of a specified number of categories) and clustering techniques are
unsupervised approaches based mostly on distances, there might be groups
of pixels with similar distances between them that could be considered as
independent clusters or only a cluster. For example, Fig. 9 shows different
K-means analyses of the banknote using different number of clusters in the
calculations.
Based on the information obtained in the PCA model of the banknote
(Fig. 4), one can argue that four clusters could be enough. Moreover, the
centroids make perfect chemical sense, and they are similar to the loadings
previously obtained. Nevertheless, a K-means model of the same sample
but using five clusters denotes that there might exist a fifth cluster (pink
cluster in the figure) that shows different features in the banknote (e.g., the
star in the middle of the banknote). There have been several proposals to
110 SECTION j II Algorithms and methods
find the correct amount of clusters to use (e.g., silhouette index [28] or,
simply, PCA). Nevertheless, these parameters are merely informative and
care must be taken when applied.
- Clustering methods with pixels containing mixtures: A clear distinction
must be done when applying clustering depending of the type of infor-
mation that one pixel can contain. If the pixel contains only the spectral
signature of one chemical compound (a plastic, for instance) then, using
methods like K-means could be advisable (one pixel, one cluster identifi-
cation). Nevertheless, if the pixel contains a mixture of chemical com-
pounds, methods like K-means might lead to a misgrouping of pixels, since
now one pixel might belong to some groups at the same time. Therefore,
methods like fuzzy clustering might be advisable (one pixel, different
probabilities of belonging to the different clusters). For instance, let us take
the sample displayed in Fig. 10. This sample is a simple binary mixture of
ibuprofen and starch. The sample was measured with an NIR-hyperspectral
camera working in the wavelength rangeof 1000e2000 nm. Further
technical information can be found elsewhere [28]. Applying K-means with
two clusters, it is obvious that the answer is suboptimal, since there is
ibuprofen and starch. But there is also a mixture area separating both
compounds. Therefore, it can be considered that there might be three
clusters (ibuprofen, starch, and the mixing area). The main problem is that
the mixing area, itself, contains pixels with different degrees of mixtures, in
such a way that a K-means model with 10 clusters might seem also valid.
Nevertheless, looking at the centroids obtained for the analysis with 10
clusters it can be observed that they are all linear combinations of the pure
spectra of ibuprofen and starch. In this case, since the pixels might contain
FIGURE 9 K-means clustering of the banknote by using four, five, and six clusters. Top, cluster
assignation by colors. Bottom, the corresponding centroids.
Unsupervised exploration Chapter j 2.4 111
a mixture of different chemical compounds, a more appropriated fuzzy
clustering methodology with two clusters can be performed, obtaining not a
straight assignment of one pixeldone cluster, but calculating a probability
of belonging of one pixel to each cluster (Fig. 10).
4. Final observations
In the present chapter, some of the most used unsupervised exploration
methods, namely projection techniques and clustering, have been revised and
discussed with particular focus on their application in the context of HSI and
MSI. Here it should be stressed that such approaches have been chosen since
they are the most popular ones, and therefore the most frequently used, but
they are not the only ones. Information was also provided on how to use the
discussed approaches and, in particular, it was highlighted which their benefits
and their potential drawbacks could be, trying to demystify some common
misunderstandings about these techniques.
FIGURE 10 Cluster analysis of a mixture composed by ibuprofen and starch. Top, K-means
models with 2, 3, and 10 clusters with the corresponding centroids. Bottom, Fuzzy clustering
model with two clusters and the corresponding centroids. Sample taken from J.M. Amigo, J. Cruz,
M. Bautista, S. Maspoch, J. Coello, M. Blanco, Study of pharmaceutical samples by NIR chemical-
image and multivariate analysis, TrAC Trends in Analytical Chemistry 27 (2008). doi:10.1016/
j.trac.2008.05.010.
112 SECTION j II Algorithms and methods
Indeed, especially when the final focus of the data analysis is some sort of
prediction, be it of qualitative (classification) or quantitative (calibration)
nature, the role of exploratory data analysis is often underrated, and this is
something that should be avoided. Indeed, exploratory analysis provides a
wealth of information per se and gives a first insight into the data which can be
very useful even when exploration itself is not the final goal. Unsupervised
methods are a source of knowledge that can give extremely valuable infor-
mation as a first approach to the analysis of any HSI and MSI samples, since
they are hypothesis-free and allow the data to “talk for themselves.” At the
same time, one should always be conscious of the unsupervised nature of the
models which means, for instance, the lack of any predictive validation, and
treat the information extracted from the data as it is, without being tempted by
overinterpretation of the results obtained. Only by doing so, exploratory data
analysis can represent a powerful tool to inspect HSI and MSI data.
References
[1] J.J. Andrew, M.A. Browne, I.E. Clark, T.M. Hancewicz, A.J. Millichope, Raman imaging of
emulsion systems, Applied Spectroscopy 52 (1998) 790e796, https://doi.org/10.1366/
0003702981944472.
[2] J.J. Andrew, T.M. Hancewicz, Rapid analysis of Raman image data using two-way multi-
variate curve resolution, Applied Spectroscopy 52 (1998) 797e807, https://doi.org/10.1366/
0003702981944526.
[3] A. De Juan, M. Maeder, T. Hancewicz, R. Tauler, Use of local rank-based spatial infor-
mation for resolution of spectroscopic images, Journal of Chemometrics 22 (2008)
291e298, https://doi.org/10.1002/cem.1099.
[4] A. de Juan, M. Maeder, T. Hancewicz, R. Tauler, Local rank analysis for exploratory
spectroscopic image analysis. Fixed size image window-evolving factor analysis, Chemo-
metrics and Intelligent Laboratory Systems 77 (2005) 64e74, isi:000229851300008.
[5] J.W. Tukey, Exploratory Data Analysis, Addison Wesley, Reading, MA, 1977.
[6] N. Mobaraki, J.M. Amigo, HYPER-Tools. A graphical user-friendly interface for hyper-
spectral image analysis, Chemometrics and Intelligent Laboratory Systems 172 (2018),
https://doi.org/10.1016/j.chemolab.2017.11.003.
[7] A.K. Smilde, R. Bro, Principal component analysis (tutorial review), Anal. Methods. 6
(2014) 2812e2831, https://doi.org/10.1039/c3ay41907j.
[8] J.M. Amigo, H. Babamoradi, S. Elcoroaristizabal, Hyperspectral image analysis. A tutorial,
Analytica Chimica Acta 896 (2015) 34e51, https://doi.org/10.1016/j.aca.2015.09.030.
[9] M. Vidal, J.M. Amigo, Pre-processing of hyperspectral images. Essential steps before image
analysis, Chemometrics and Intelligent Laboratory Systems 117 (2012) 138e148, https://
doi.org/10.1016/j.chemolab.2012.05.009.
[10] J.M. Amigo, Practical issues of hyperspectral imaging analysis of solid dosage forms,
Analytical and Bioanalytical Chemistry 398 (2010) 93e109. https://doi.org/10.1007/
s00216-010-3828-z.
[11] C. Cairós, J.M. Amigo, R. Watt, J. Coello, S. Maspoch, Implementation of enhanced cor-
relation maps in near infrared chemical images: application in pharmaceutical research,
Talanta 79 (2009) 657e664. https://doi.org/10.1016/j.talanta.2009.04.042.
Unsupervised exploration Chapter j 2.4 113
https://doi.org/10.1366/0003702981944472
https://doi.org/10.1366/0003702981944472
https://doi.org/10.1366/0003702981944526
https://doi.org/10.1366/0003702981944526
https://doi.org/10.1002/cem.1099
https://doi.org/10.1016/j.chemolab.2017.11.003
https://doi.org/10.1039/c3ay41907j
https://doi.org/10.1016/j.aca.2015.09.030
https://doi.org/10.1016/j.chemolab.2012.05.009
https://doi.org/10.1016/j.chemolab.2012.05.009
https://doi.org/10.1007/s00216-010-3828-z
https://doi.org/10.1007/s00216-010-3828-z
https://doi.org/10.1016/j.talanta.2009.04.042
[12] D.L. Massart, L. Kaufmann, The Interpretation of Analytical Chemical Data by the Use of
Cluster Analysis, Wiley, New York, NY, 1983.
[13] L. Kaufmann, P.J. Rousseeuw, Finding Groups in Data, Wiley, New York, NY, 1990.
[14] B.S. Everitt, S. Landau, M. Leese, D. Stahl, Cluster Analysis, fifth ed., Wiley, New York,
NY, 2011.
[15] F. Murtagh, P. Contreras, Algorithms for hierarchical clustering: an overview, Wiley
Interdisciplinary Reviews: Data Mining and Knowledge Discovery 7 (2017) e1219. https://
doi.org/10.1002/widm.1219.
[16] J.H. Ward Jr., Hierarchical grouping to optimize an objective function, Journal of the
American Statistical Association 58 (1963) 236e244.
[17] G.N. Lance, W.T. Williams, A general theory of classificatory sorting strategies. 1. Hier-
archical systems, Computer Journal 9 (1967) 373e380.
[18] X. Jin, J. Han, Partitional clustering, in: C. Sammut, G.I. Webb (Eds.), Encyclopedia of
Machine Learning, Springer, Boston, MA, 2011. https://doi.org/10.1007/978-0-387-30164-
8_631.
[19] H. Steinhaus, Sur la division des corps matériels en parties, Bulletin De L’academie
Polonaise des Sciences 4 (1957) 801e804.
[20] Least square quantization in PCM, Bell Telephone Laboratories Paper S.P. Lloyd, Least
squares quantization in PCM, Published later as: S.P. Lloyd, IEEE Transactions on Infor-
mation Theory 28 (2) (1957) 129e137.
[21] E.W. Forgy, Cluster analysis of multivariate data: efficiency versus interpretability of
classifications, Biometrics 21 (1965) 768e769.
[22] J.B. MacQueen, Some methods for classification and analysis of multivariate observations,
in: Proc. 5th Berkeley Symposium on Mathematical Statistics and Probability, vol. 1,
University of CaliforniaPress, Berkeley, CA, 1967, pp. 281e297.
[23] J.C. Bedzek, Pattern Recognition with Fuzzy Objective Functions, Plenum Press, New York,
NY, 1981.
[24] J.C. Bedzek, R. Ehrlich, M. Trivedi, W.E. Full, Fuzzy clustering: a new tool for geo-
statistical analysis, Int. Syst, Means, Decis. 2 (1981) 13.
[25] J.C. Bedzek, R. Ehrlich, W.E. Full, FCM: the fuzzy c-means clustering algorithm, Com-
puters & Geosciences 10 (1984) 191e203.
[26] K.-S. Chuang, H.-L. Tzeng, S. Chen, J. Wu, T.-J. Chen, Fuzzy c-means clustering with
spatial information for image segmentation, Computerized Medical Imaging and Graphics
30 (2006) 9e15. https://doi.org/10.1016/j.compmedimag.2005.10.001.
[27] S. Wold, M. Sjöström, SIMCA: a method for analyzing chemical data in terms of similarity
and analogy. In: Kowalski, B.R. (Ed.) Chemometrics, Theory and Application, American
Chemical Society Symposium Series No. vol. 52, American Chemical Society: Washington,
pp 243-282. doi:10.1021/bk-1977-0052.ch012.
[28] J.M. Amigo, J. Cruz, M. Bautista, S. Maspoch, J. Coello, M. Blanco, Study of pharma-
ceutical samples by NIR chemical-image and multivariate analysis, TrAC Trends in
Analytical Chemistry 27 (2008). https://doi.org/10.1016/j.trac.2008.05.010.
114 SECTION j II Algorithms and methods
https://doi.org/10.1002/widm.1219
https://doi.org/10.1002/widm.1219
https://doi.org/10.1007/978-0-387-30164-8_631
https://doi.org/10.1007/978-0-387-30164-8_631
https://doi.org/10.1016/j.compmedimag.2005.10.001
https://doi.org/10.1016/j.trac.2008.05.010
Chapter 2.5
Multivariate curve resolution
for hyperspectral image
analysis
Anna de Juana,*
aChemometrics group, Department of Chemical Engineering and Analytical Chemistry, Universitat
de Barcelona (UB), Barcelona, Spain
*Corresponding author. e-mail: anna.dejuan@ub.edu
1. Hyperspectral images: Structures and related models
An image provides spatial information on a sample surface. We can go from
simpler images, represented by a gray intensity value associated with each
pixel to others represented by the basic form of color, displayed in R(ed),
G(reen), and B(lue) coordinates. These simple and pioneering images were
focused on the plain representation of shape and color and were more linked to
a visual description of objects.
When chemistry enters into play, more sample characteristics are relevant.
The beauty of images lies on the fact that the classical questions related to the
composition of a sample, summarized by which components and how much of
each of them, go together with spatial-related questions, such as where and
how components distribute in the sample.
The measurement that joins together chemical and spatial information
about the samples is the hyperspectral image. Thus, sample surfaces are
compartmented in small areas (pixels) and a spectrum is recorded on each of
them. In this way, images link the chemical information (spectrum) to the
spatial structure of the samples (represented by the pixel areas) [1e4].
The typical way to represent a hyperspectral image (HSI) is as a cube with
two spatial dimensions (represented by the pixel coordinates of a sample) and
a third spectral dimension (see Fig. 1). To understand the behavior of this
measurement, we should not forget that an HSI is formed by thousands of
spectra that, as such, obey the bilinear BeereLambert law. Thus, any pixel
spectrum can be described by the sum of the spectral signatures of the image
Hyperspectral Imaging. https://doi.org/10.1016/B978-0-444-63977-6.00007-9
Copyright © 2020 Elsevier B.V. All rights reserved. 115
https://doi.org/10.1016/B978-0-444-63977-6.00007-9
constituents that form the sample, weighted by the concentration of each of
these constituents in that particular pixel. To formulate the BeereLambert law
adapted to an HSI, the original image cube needs to be unfolded into a data
table (or data matrix D) by putting the image spectra one on top of each other.
This image data table, D (sized nr. pixels � nr. of spectral channels), is
described by the bilinear model CST, where ST (sized nr. image constituents �
nr. of spectral channels) is the matrix that contains the spectral signatures of
the image constituents, i.e., the qualitative composition, and C (sized nr.
pixels � nr. of image constituents) is the matrix that contains the related
concentration profiles for each of the spectral signatures, i.e., the abundance of
a particular image constituent in each of the pixels of the image, the quanti-
tative composition. In an image defined by a bilinear model, every image
constituent is defined by a dyad of vectors, formed by the spectral signature of
the constituent and the related concentration profile. The unfolded represen-
tation of an image misses the spatial description of the sample surface. To
recover this information, it is sufficient to refold the concentration profile of
every constituent into a 2D map recovering the original sample geometry. In
this way, both quantitative information and spatial distribution are displayed in
a single visual representation (see Fig. 1).
Despite the fact that the image is displayed as a data cube, it is relevant to
understand that the two spatial dimensions are only related to pixel position
and the image cube should never be attempted to be mathematically described
by products of three factor terms linked to the three spatial dimensions of the
cube.
FIGURE 1 Image cube and bilinear model.
116 SECTION j II Algorithms and methods
Although most hyperspectral images have three dimensions, 4D or 5D
images can also be encountered. Such a situation can happen because the
spatial or the spectral information increases in complexity. Speaking about
spatial complexity, it often happens that images are devoted to describe sample
volumes. In this case, the term voxel is used instead of pixel and the distri-
bution of the components in the sample is studied in the three spatial di-
mensions, i.e., covering different depth slices of the sample. This provides a
4-D image, with three spatial dimensions (linked to x, y, and z pixel co-
ordinates) and one spectral dimension. As in the case of the 3D image in
Fig. 1, the three spatial dimensions indicate only position and these images
follow the BeereLambert law, represented by the bilinear model D ¼ CST. To
accommodate to the bilinear model, the pixels of the different slices in these
4D images will be unfolded into a single data table and will be described as in
Fig. 1. The only different step will be the refolding of the concentration
profiles into maps, since every concentration profile will be block-wise
refolded into the related maps of each of the original cube slices (see
Fig. 2A) [3e5].
A different case happens when the increase in complexity comes from the
spectral measurement. In Fig. 1, it is implicitly assumed that the spectral in-
formation is enclosed in a vector of numbers and this happens most of the
times when Raman, IR, MS, or UV spectra are used. However, in some in-
stances, such as for excitation-emission fluorescence measurements (EEM), a
2D spectral measurement can be obtained per pixel. As a consequence, when a
sample surface is imaged by EEM measurements, a 4D image is obtained, with
two spatial dimensions and two spectral dimensions (excitation/emission). In
this particular case, the mathematical model that describes the measurement is
different. The original 4D hypercube needs to be unfolded into a data cube,
where the 2D EEM landscapes of the different pixels will be stacked one on
top of the other. The image cube will be sized (nr. pixels � nr. of excitation
channels � nr. of emission channels) and will obey a trilinear model, i.e.,
every image constituent will be represented by a triad of profiles, the excitation
spectrum, the emission spectrum, and the related concentration profile (see
Fig. 2B) [6,7].
As in Fig. 1, the concentration profile will be refolded into the suitable 2D
map to recover the spatial structure of the sample surface. In the framework of
EEM fluorescenceimages, when different depths of the sample are imaged, a
5D image would be obtained, where three dimensions would associate with the
three pixel coordinates and two to the EEM fluorescence landscape. Again,
since pixel coordinates only indicate position, an image cube would be ob-
tained and a trilinear model would still hold to describe these measurements.
As in Fig. 2A, the concentration profile would need to be block-wise refolded
into the maps of the different 3D sample slices.
This introductory section was devoted to explain the natural measurement
models of hyperspectral images and, intentionally, we did not mention any
Multivariate curve resolution Chapter j 2.5 117
data analysis tool. The ideal algorithms to treat HSI should adapt to these
models and, at the same time, preserve the natural characteristics of the
spectral signatures and concentration profiles of the image constituents.
Multivariate curve resolution (MCR) is one of these methods and will be
explained in detail in next sections.
FIGURE 2 (A) Bilinear model of a 4D image formed by three spatial dimensions (x, y, and z)
and one spectral dimension. (B) Trilinear model of a 4D image formed by two spatial dimensions
(x and y) and two spectral (excitation/emission) dimensions.
118 SECTION j II Algorithms and methods
2. Multivariate curve resolution: The direct link with the
measurement model
When analyzing hyperspectral images, the sole starting information is the
image itself. Although it is known that the measurement behaves according to
the BeereLambert law, the raw image spectra do not provide a straight answer
about the number of image constituents, the spectral identity of each of them,
or their related concentration map and, nevertheless, this tends to be the sought
information by the scientist.
Knowing that the BeereLambert law is formally a bilinear model, it is not
surprising that the first and most common multivariate data analysis tool used
to interpret data matrices coming from HSI information was principal
component analysis (PCA) [1,8e11]. Indeed, PCA provides a bilinear model,
expressed as:
D[ TPTDE (1)
where T are scores, PT are loadings, and E is the variance unexplained by the
model. PCA aims at reproducing the original data with an optimal fit using a
small number of components that do not repeat information among them.
Components are orthogonal to each other and are sorted in decreasing order of
variance explained. The description of an image using a bilinear model with a
small number of components matches some of the requirements of the mea-
surement, i.e., bilinearity and simplicity, since a few spectral signatures
properly combined can reproduce any pixel spectrum in the image. However,
the reason why PCA is not the ultimate solution to recover the natural Beer-
eLambert law of HSI is the condition of orthogonality imposed to the com-
ponents (scores and loadings) retrieved. Indeed, when thinking of the spectral
signatures of image constituents provided by IR, Raman, fluorescence imaging
systems, it is extremely unlikely that the correlation coefficient among all of
them be zero. These signatures always show to a major or minor extent a
similarity between them, and PCA cannot adapt to this characteristic. Like-
wise, other abstract bilinear decomposition tools, such as independent
component analysis (ICA) [12e16], generally fail at retrieving the HSI natural
BeereLambert law because the bilinear components provided by the method
are statistically independent, another characteristic rarely obeyed by spectral
signatures of image constituents. For this reason, PCA and ICA are known to
provide useful information about relevant spatial and spectral features in im-
ages, but the components that these methods provide should never be asso-
ciated in a straightforward manner with spectral signatures and concentration
profiles of image constituents.
MCR is one of the tools that best adapts to the HSI measurement
[3,4,17e20]. In common with PCA and ICA, it describes the data matrix of
Multivariate curve resolution Chapter j 2.5 119
image spectra, D, with a bilinear model providing an optimal fit, expressed as
the BeereLambert law,
D[CSTDE (2)
where C is the matrix of concentration profiles, ST is the matrix of spectral
signatures of the image constituents, and E is the variance unexplained by the
model. However, MCR replaces strong mathematical requirements, such as
orthogonality or statistical independence, by other constraints more adapted to
the real chemical characteristics of the concentration profiles and spectral
signatures of image constituents, such as nonnegativity. The selection of
constraints that respect the real properties of the HSI measurement explains
why the use of MCR has increased in popularity to deal with this kind of data.
For a better understanding of the explanation above, the bilinear decomposi-
tion of the same Raman emulsion image by PCA and MCR is represented in
Fig. 3. Whereas PCA scores and loadings present negative values (unaccept-
able in concentration maps and Raman signatures), MCR provides maps and
spectral signatures that respect this condition. It is relevant to say that, since
both methods aim at explaining optimally the original HSI data with the
smallest possible number of components, PCA is often used before MCR to
have an estimate of how many image constituents are present in an image. It is
assumed that the number of components needed in a PCA model will be the
same as the number of MCR components required.
FIGURE 3 Principal component analysis (PCA) model (top plot) and multivariate curve reso-
lution (MCR) model (bottom plot) from a Raman emulsion image.
120 SECTION j II Algorithms and methods
Thus, MCR designs the family of methods that provide bilinear de-
compositions that describe data with an optimal fit with chemically mean-
ingful components. Within this description, many algorithms can be
considered. Within the field of hyperspectral image analysis, the most common
ones come from the remote sensing community, e.g., vertex component
analysis [21], simplex-based decomposition algorithms [22,23], or from the
chemometric field, such as nonnegative matrix factorization [24e26] or
multivariate curve resolution-alternating least squares (MCR-ALS)
[3,4,27e32]. Almost all these methods, in a compulsory or flexible manner,
use the nonnegativity constraint to derive the spectral signatures and con-
centration profiles of image constituents. Remote sensing algorithms use
sometimes additional mathematical conditions, e.g., the assumption that the
vertices of the simplex enclosing all image spectra correspond to the pure
spectral signatures of components (endmembers), and some methods require
necessarily the presence of pure pixel spectra for a correct performance
[21e23]. Other chapters of this book describe more extensively these algo-
rithms, known in the remote sensing community as unmixing methods. To
avoid duplications, this chapter will be devoted to the detailed description of
the MCR-ALS method. The choice of this algorithm responds to the capability
to adapt to single image analysis or image fusion scenarios and to the intensive
work oriented to design dedicated constraints to respond to the natural spectral
and spatial characteristics of images [3e5].
3. Multivariate curve resolution-alternating least squares
MCR-ALS is an iterative curve resolution based on the alternating optimiza-
tion of the C and ST matrices under the action of constraints [4,6,19,20]. As
the name suggests, it is a least squares approach that involves in each iterative
cycle the two following operations oriented to least squares estimate matrices
C and ST:
C ¼ DSðSTSÞ�1
(3)
ST [ ðCTCÞ�1
CTD (4)
In each one of these steps, matrices C and ST are modified in a suitable way
introducing all the available information about the shape and behavior of both
spectral signatures and concentration profiles of the image of interest. This
information can vary depending on thespatial structure of the sample and the
imaging platform used, as will be described later on in this section. Likewise,
when nothing else is specified, the least squares steps are carried out according
to Eqs. (3) and (4) above and assuming random homoscedastic noise in the raw
image measurement. When other kinds of noise are present, e.g., hetero-
scedastic noise proportional to the signal, and the noise structure is well
known, weighted alternating least squares algorithms can be used that
Multivariate curve resolution Chapter j 2.5 121
incorporate the noise-related information in the estimation of C and ST
[33e35]. However, the routine practice shows that no significant differences
are obtained between MCR-ALS and multivariate curve resolution-weighted
least squares (MCR-WALS) unless the noise level is high, and superior re-
sults are only obtained for MCR-WALS when the noise information is spec-
ified in an accurate way.
The main steps followed in an MCR-ALS analysis are listed below and will
be explained in detail afterward:
1. Determination of the number of components in the raw image (D).
2. Generation of initial estimates of C or ST matrix.
3. Alternating least-squares optimization of C and ST under constraints until
convergence is achieved.
Before analyzing the raw image, a suitable preprocessing of the image raw
spectra is required to avoid that undesirable artifacts of the measurement could
compromise the bilinearity of the data and could hinder retrieving correct
results. Preprocessing in imaging has been addressed in many works, and it is
not the main scope of this chapter. It involves essentially the same treatments
that could be performed on classical spectroscopic data obtained with similar
platforms [3]. Thus, as examples, Raman spectra will be corrected for the
presence of cosmic peaks and the often high fluorescence background will be
suppressed by the asymmetric least squares method [36,37]; near-infrared
spectra instead would be subject to a multiplicative scatter correction to
eliminate background or could be used in derivative form to suppress back-
ground and enhance spectral differences among image constituents [37,38].
Other preprocessing treatments linked to image measurements imply the
detection of abnormal pixels because of spectral saturation or null intensity
(dead pixels). In these instances, the abnormal pixels are simply suppressed
from the analysis or are replaced by estimates based on the use of normal
neighboring spectra. Sometimes preprocessing can also be oriented to decrease
the dimensionality of images and binning treatments or other compression
methods can be used.
Once the image spectra are suitably preprocessed, they can be submitted to
MCR-ALS analysis. The first step in MCR-ALS involves estimating the
number of components needed in the MCR model. Such information can be
known beforehand but, otherwise, can be inferred by using auxiliary algo-
rithms, such as PCA. It is important to know that the number of components
estimated in this way is not definitive and, often, several MCR models with
different number of components are tested. The definitive MCR results are
chosen on the basis of the model fit and the interpretability of the spectral
signatures and distribution maps. As in many other data analysis tools,
parsimony is preferred and the smallest model that can describe well the data
is the best. At this point, it is important to discuss the wide concept of
component in HSI. It is actually any entity that can provide a distinct spectral
122 SECTION j II Algorithms and methods
signature. This includes the classical association of component with chemical
compound, but also other possibilities, such as polymorphic forms of the same
substance or biological tissues or cell compartments. In the biological context,
a component is defined by a spectral signature, but it is known to be formed by
a homogeneous mixture of many chemical compounds or biomolecules. The
same wide concept of component applies to environmental images, when
vegetation, asphalt, water, etc., i.e., landscape compartments, are designed as
components.
Since MCR-ALS is based on an alternating least squares optimization, Eqs.
(3) and (4) need to use the original image matrix, D, and either C or ST to
retrieve the counterpart matrix of the bilinear model. Before starting the HSI
analysis, only D is available and an initial estimate of C or ST is required.
There are many possibilities to generate initial estimates, but some guidelines
can be provided. A golden rule is starting with initial estimates that obey the
natural properties of the concentration profiles or spectral signatures sought. In
this way, the optimization will happen in a faster way because the starting
point is closer to the final optimum and there is less chance to have divergence
problems. Such a rule discards, for instance, starting with profiles formed by
sets of random numbers, or advises against the use of profiles that may have
negative parts, e.g., PCA scores or loadings, if concentration profiles or pos-
itive spectral signatures need to be retrieved.
In the history of MCR, many auxiliary methods were designed to help in
the task of initial estimate generation. Some of them, based on local rank
analysis, were oriented to process analysis and relied on the continuous and
sequential character that concentration profiles have in this context, e.g.,
chromatographic peaks elute one after the other or, in reaction systems, re-
agents turn into products [39,40]. This does not happen in HSI, where con-
centration profiles are linked to the unfolded pixel direction. In this case, the
concentration profiles do not present the necessary sequential pattern and other
methods are required to generate initial estimates. The best option in this
context is offered by the methods of purest variables selection [41]. Algo-
rithms of this kind, such as SIMPLISMA [42], orthogonal projection approach
(OPA) [43], or key set factor analysis (KSFA) [44], among others, find the
most dissimilar rows or columns in a data set D. The big advantage of these
algorithms is that no need of ordered spectral or concentration patterns is
required and, as such, they adapt to any kind of scenario, from process analysis
to images or to environmental data. Besides, they select rows or columns of the
D matrix and, in doing so, provide an estimate that is clearly related to the final
profiles sought.
Purest variable selection methods on HSI analysis can select the purest
pixels (rows) of the image matrix D and provide an initial estimate of spectral
signatures for matrix ST or select the purest spectral channels of D (columns)
and provide an initial estimate of the matrix of concentration profiles C.
Although either option is potentially acceptable, the tendency in HSI is using
Multivariate curve resolution Chapter j 2.5 123
spectral estimates because they tend to provide more unmixed information,
i.e., there are usually more chances to find pixels where only one component or
a simple mixture of few components is present than spectral channels with
specific information for a particular component [3].
Although purest variable selection methods offer clear advantages to
generate initial estimates, it is worth advising against the use of those as MCR
methods. The assumption that the purest spectra selected are the pure spectral
signatures sought and, as such, a single least squares step using the selected
spectra and the original image as in Eq. (4) will provide the concentration
profiles of the pure image constituents is often erroneous. This will only be
valid if there are pure pixels for each of the constituents of the image, and this
is often unlikely and, in most cases, unproven by additional data analysis
exploration.
Once initial estimates are available, the alternating least squares optimi-
zation of C and ST can start. This is the core step of the MCR-ALS algorithm,
and constraints play an essential role. Constraints have a doublefunction: on
the one hand, they encode the systematic information about the general
properties of spectral signatures and concentration profiles to provide chemi-
cally meaningful solutions and, on the other hand, they drive the optimization
process and limit the span of feasible solutions for the final profiles of the
MCR bilinear model, i.e., they decrease the ambiguity associated with MCR
solutions [27].
Constraints modify the shape of any calculated profile so that it fulfills a
preset condition. Within the MCR framework, the application of constraints is
always optional, and it can be done in a flexible way. Thus, the selected
constraints can be different for profiles in C and ST and for the different
components of the system [3,29].
The most typical constraint applied in MCR methods is nonnegativity. It is
always applied to concentration profiles because concentrations can only be
positive or null and very often to spectral profiles, since many signal intensities
are naturally positive, e.g., Raman or fluorescence intensities, absorption
[29,45].
In HSI, the use of constraints may seem more limited than in other areas,
such as process analysis. Indeed, none of the constraints usually applied to
evolving process profiles, based on sequential or monotonic characteristics, is
useful [29]. This limitation and the fact that HSI were seen for a long time
mainly as large spectroscopic data sets restricted the use of constraints to
nonnegativity. Nowadays, the spatial dimension of images is taken in
consideration, and this has led to the emergence of adapted and specific HSI
constraints.
The spatial dimension of images was first used to encode adapted selec-
tivity and local rank constraints [27,29]. This kind of constraints set the
absence of one or more components per pixel and are among the most
important to reduce the ambiguity in MCR solutions. The way to set local rank
124 SECTION j II Algorithms and methods
constraints in HSI starts by an exploratory local rank analysis using the fixed
size image window-evolving factor analysis (FSIW-EFA) algorithm [46].
FSIW-EFAworks performing PCA analyses on small 2D or 3D pixel windows
that contain a pixel spectrum and all its spatial neighbors. Such an operation is
done scanning all possible pixel windows across the whole image surface (see
Fig. 4). This exhaustive analysis provides a local rank map that displays the
number of overlapping components present in every pixel. To know the
identity of the absent components in every pixel, reference spectral informa-
tion of the image constituents and local rank information must be combined.
The reference spectral information can come from pure variable selection
methods or from a preliminary MCR resolution of the image using only
nonnegativity. For every pixel, the correlation coefficients between the pixel
spectrum and the reference spectra of the image constituents are calculated.
Knowing the number of absent constituents in every pixel from the local rank
map, the components with lowest correlation coefficient with the pixel spec-
trum are set to be absent. As for any other constraint, the application is flexible
and only the pixels with a clear estimate of the rank (number of overlapping
components) and a clear identification of the absent components are con-
strained [47].
FIGURE 4 (A) Fixed size image window-evolving factor analysis application to a hyperspectral
image. Principal component analysis (PCA) analyses and local rank map (B) combination of local
rank and reference spectral information to obtain masks of absent components in pixels (in red).
These absences are used as local rank constraints in multivariate curve resolution analysis.
Multivariate curve resolution Chapter j 2.5 125
In the local rank constraints, the spatial concept of pixel neighborhood is
used. There are other constraints that take into account characteristics related
to the spatial distribution of components in the concentration map. To impose
these constraints, the stretched pixel concentration profiles are refolded into
the related maps, onto which the suitable spatial conditions are applied [48].
The possible characteristics exploited to set spatial constraints are the
smoothness in maps, the preservation of edges to define objects more accu-
rately, or the sparseness for maps known to belong to minor and scattered
compounds [49e51]. Obviously, the application of these constraints has a
close relationship with the spatial nature of the image analyzed. For instance,
environmental images can benefit from edge-preserving constraints because
landscape compartments are, by nature, well delimited. Instead, pharmaceu-
tical powder mixtures, much less spatially structured, may accommodate
sparseness constraints for a better spatial definition of minor compounds in
formulations.
So far, the constraints described relate to properties of the spectral signa-
tures or concentration profiles (maps). There are other constraints related to the
model of the measurement. Indeed, Section 1 described that most hyper-
spectral images follow a bilinear model, as defined by MCR, but some of them
obey trilinear models, such as EEM fluorescence images. There are algorithms
that provide naturally trilinear models, such as PARAFAC [6], or trilinear
decomposition [52] and can be used to deal with the latter kind of images.
However, MCR can still perform in an appropriate manner when trilinearity is
used as a constraint [53,54]. To do that, the cube in Fig. 2B will be unfolded
into a data matrix, sized nr. pixels x (nr. excitation channels x nr. emission
channels) (see Fig. 5). Every row in the matrix contains the emission spectra
corresponding to the different excitation wavelengths scanned. The trilinearity
constraint will be applied in the spectral dimension (ST matrix) and will force
a common shape to all emission spectra related to the different excitation
channels for a particular component. To do so, each component is constrained
separately (see Fig. 5). Within an iteration, all emission spectra calculated for a
particular component are arranged as columns in a single matrix, and a PCA
analysis is performed. The first component includes all necessary information.
Thus, the score shows the common shape for all emission spectra and the
loading the scale information of every emission spectrum, related to each
excitation wavelength. The trilinear emission spectra are reconstructed using
the product of the first score by the loading related to the suitable excitation
wavelength. After MCR analysis, the concentration profiles are refolded into
maps and a single emission spectral shape is obtained per every component.
The excitation spectrum per every component is derived by integrating the
area of the emission spectra at the different excitation wavelengths. Although
this strategy does not offer any advantage over the use of trilinear-born
methods, such as PARAFAC, it is particularly suitable when image fusion
with other measurements is of interest, as will be seen in the next section [5].
126 SECTION j II Algorithms and methods
Once the MCR optimization of concentration profiles and spectral signa-
tures is finished, figures of merit related to the model fit are used, such as the
lack of fit (% LOF) or variance explained (in Eqs. (5) and (6), respectively) can
be calculated.
%LOF ¼ 100
ffiffiffiffiffiffiffiffiffiffiffiffiffiffiP
i; je
2
ijP
i; jd
2
ij
s
(5)
%var:expl: ¼ 100

1�
P
i; je
2
ijP
i; jd
2
ij
!
(6)
where eij is the residual associated with the MCR reproduction of the related
element in the original data set, dij.
FIGURE 5 (A) Four-dimensional excitation-emission fluorescence measurement image struc-
tured as a data matrix. (B) Implementation of the trilinearity constraint in the ST matrix of
emission spectra signatures. PCA, Principal component analysis.
Multivariate curve resolution Chapter j 2.5 127
The optimization is usually finished when the difference of model fit be-
tween consecutive iterationsdoes not improve significantly (e.g., a difference
of less than 0.1% among the lack of fit between consecutive iterations). Other
possibilities are using a maximum number of iterations or criteria based on the
comparison of shapes of the optimized profiles among iterations.
To complete the MCR-ALS analysis, it is advisable to estimate the am-
biguity associated with the resolved profiles. Although image analysis does not
tend to provide very ambiguous solutions because the large amount and di-
versity of pixel composition helps to obtain accurate concentration profiles and
spectra, there are many methods with available software that inform on the
presence or absence of ambiguity and on the extent of ambiguity when
existing [55e57]. Some of these methods, such as the so-called MCR bands,
do not show limitations linked to the number of components of the system
[57].
4. Image fusion (or multiset analysis)
Image fusion defines the scenario of working with several images altogether,
coming from a single or from different platforms [5]. There are many sci-
entific problems that require acquiring and relating several images, e.g., in
process monitoring, when images come from different depth layers of the
same sample, when the information of different spectroscopic platforms is
complementary, but too often this task is done by analyzing images one by
one and relating the final results. Possible reasons for the lack of real image
fusion examples are the scarce available algorithms for this purpose and the
presence of complex problems, such as the spatial congruence and the dif-
ferences in spatial resolution when images from different platforms need to be
fused.
Image fusion in the framework of MCR is called multiset analysis [20,54].
Indeed, there are many fields in which MCR-ALS works with multisets, also
called augmented data matrices, formed by several data blocks that come from
different experiments, different samples, or that can be monitored with
different instrumental measurements. The only requirement to append data
blocks to form a multiset is that they share, at least, one mode in common and
some components. A multiset formed by data matrices that behave according
to a bilinear model will also follow a bilinear model. This means that the same
bilinear decomposition methods applied to a single data set are also valid to
interpret the information contained in multisets [20,54].
Multisets in hyperspectral image analysis can be formed by several images
collected with the same platform, images on the same sample collected by
different platforms, or both possibilities at the same time (see Fig. 6) [3e5].
When a multiset includes several images from the same platform, the spectral
mode needs to be common, i.e., the images should have been scanned covering
the same spectral range, and the multiset is built appending the blocks of pixel
128 SECTION j II Algorithms and methods
spectra one on top of each other. This gives rise to a column-wise augmented
matrix and to the related bilinear model, as expressed in Eq. (7):
½D1; D2;.; Dn�[ ½C1; C2;.; Cn�STD½E1; E2;.; En� (7)
where Di is the data matrix that contains the pixel spectra of the ith image in
the multiset and Ci is the related set of concentration profiles. In this case, the
bilinear model related to the multiset [D1;D2;.;Dn] is formed by an
augmented concentration matrix, [C1;C2;.;Cn] and a single ST matrix, with
spectral signatures valid for all images in the multiset. The maps for each
image constituent in every image would be recovered refolding conveniently
the related Ci profiles.
It is relevant to mention that the multisets structured as column-wise
augmented matrices can have a completely different pixel mode in every
image because only the spectral mode needs to be common. This offers a
wealth of possibilities since images with different sizes, geometries, and
spatial resolution can be analyzed together as long as the spectral measurement
has been carried out in the same way. Besides, since the only information in
common is the spectral mode, relevant interesting spectroscopic information,
such as pixel spectra from known compounds (embedding media, identified
constituents, etc.) can also be part of the multiset if required [38]. The bilinear
model provides also a single matrix ST, with spectral signatures valid for all
images in the multiset that are very well defined because of the amount and
diversity of information contained in all images treated together.
FIGURE 6 Multiset structures and bilinear models for (A) several images obtained with the same
spectroscopic platform and (B) a single image obtained with several platforms.
Multivariate curve resolution Chapter j 2.5 129
When a multiset is formed by images collected on the same image by
different spectroscopic platforms, the pixel mode needs to be common, i.e.,
there should be spatial congruency among the different images collected and
the pixel size needs to be the same. This requirement often needs pre-
processing that involves spatial transforms and balancing spatial resolutions
among images [5]. When the pixel mode is common, the blocks of pixel
spectra of the different images are placed one besides the other forming a row-
wise augmented data matrix, and the multiset structure obeys the bilinear
model expressed in Eq. (8):
½D1D2.Dn�[C
�
ST1 S
T
2.STn
�
D½E1E2.En� (8)
The bilinear model is formed by a single C matrix, which will give rise to a
single set of maps, and an extended ST matrix, formed by many Si
T blocks as
spectroscopic techniques used in the different platforms. This kind of multiset
benefits from the complementary information provided by different techniques
that can help to differentiate much better among image constituents. In the
most extreme case, different techniques can be sensitive to different compo-
nents and only the fused structure will provide a complete reliable picture of
all image constituents in the sample analyzed.
A third possible scenario would imply joining images from different
samples and acquired in different platforms. In this case, the images appended
would form a row- and column-wise augmented matrix. The related bilinear
model is shown in Eq. (9):
2
6666666666664
D11 D12 D13 :::: D1L
D21 D22 D23 :::: D2L
D31 D32 D33 :::: D3L
:::: :::: :::: :::: ::::
DK1 DK2 DK3 :::: DKL
3
7777777777775
¼
0
BBBBBBBBBBBB@
C1
C2
C3
::::
CK
1
CCCCCCCCCCCCA
h
ST1 ST2 ST3 :::: STL
i
þ
0
BBBBBBBBBBBB@
E11 E12 E13 :::: E1L
E21 E22 E23 :::: E2L
E31 E32 E33 :::: E3L
:::: :::: :::: :::: ::::
EK1 EK2 EK3 :::: EKL
1
CCCCCCCCCCCCA
¼ CaugS
T
augDEaug
(9)
In this case, both C and ST matrices would be augmented and the
requirements and advantages of the previous multisets would also hold.
Analyzing a multiset by MCR-ALS follows the same steps listed in Section
2 for a single image analysis because the work is done on an (augmented)
matrix. The determination of components and initial estimates should be
performed on the multiset and the previous constraints described are also
applicable. In terms of flexibility in constraint application, multisets offer an
additional turn of the screw, since constraints can be applied differently per
block. Such optionality helps to respect the spatial and spectral characteristics
of all data blocks appended [28,54].
130 SECTION j II Algorithms and methods
Working with multisets provides always more accurate and reliable results
than analyzing the individual images one at a time. Advantages are linked to
the use of more diverse information that allows a better definition of the image
constituents and, as a consequence, a reduction in the ambiguity associated
with the resolved maps and spectral signatures [58]. Below, some comments
on examples of multisets formed by images from the same platform and im-
ages from different platforms are provided.
4.1 Image multisets formed by images coming from the same
platform
As mentioned above, the only requirement for multisets formed by imagesfrom the same platform is a common spectral mode. This simple condition
makes this kind of multiset the most commonly found in research studies.
There are scientific problems particularly suitable for this kind of multiset.
Clear examples are formed by images that come from the same sample
collected at different depths, as can be done in confocal Raman imaging [3,4].
This strategy provides a clear description of the sample in the three dimensions
and helps solving interesting problems, such as knowing the sequence of use of
inks in forensic document studies (see Fig. 7) [59].
FIGURE 7 Multivariate curve resolution results (maps and spectral signatures) obtained from a
multiset analysis of ink images obtained at different depths in a document. The sequence of use of
inks can be seen from the distribution maps (Pilot BPG is more dominant in the upper layers in the
ink intersection and crosses over Pilot BAB).
Multivariate curve resolution Chapter j 2.5 131
Another example refers to images collected during process monitoring
[60,61]. In these situations, having a bilinear model with a single set of
spectral signatures provides consistency to the final solution, since maps at
different depths or maps from the evolution of a constituent in a process are
always related to the same spectral signature. Besides, the complementary
compositional information in the different layers (or process stages) helps to
model all compounds more easily, since minor compounds in a particular
image may have a more dominant presence in a related image of the multiset
structure.
Sometimes multisets with common spectral information are formed by
images of related samples and it is relevant to find the link among all of them.
This would be the example of multisets acquired on individuals of the same
biological population, where common resolved spectral signatures are useful
to define more clearly the fingerprint of tissues and compounds appearing in
all individuals (useful to define general trends of the population) and can be
distinguished from compounds of specific individuals (associated with natural
biological variability) (see Fig. 2) [38,62]. Another paradigmatic example of
multisets of related images refers to the use of HSI for quantitative purposes,
where calibration and test images can be analyzed in the same multiset
structure [38]. This last example will be studied in more detail in the next
section.
4.2 Image multisets coming from different platforms
Often the expression image fusion is preserved for those situations in which
the images analyzed together come from different platforms. This scenario is
way more challenging than coupling images acquired with the same image
acquisition system because spectral and spatial differences among the different
images need to be handled [5].
The major complexity linked to image fusion from different platforms
comes because the pixel mode among different techniques needs to be com-
mon. Achieving this condition implies surmounting problems linked to dif-
ferences in spatial orientation and spatial resolution among images.
When the spatial resolution of the images to be fused is the same, there are
different algorithms oriented to do coregistering of images, and most of them
lay on the selection and use of some reference points in the images to be
aligned. Once these pixels are selected, suitable transformations of translation
and rotation are performed to obtain spatially congruent pixels among images
[64]. The only drawback in this process is the delicate step of selection of
reference pixels, which is simple in structured images with clear landmarks,
such as environmental landscapes or some kinds of biological tissues, but can
be less obvious when images have a poor spatial structure, e.g., mixtures of
pharmaceutical powders. To overcome this problem, other procedures have
been proposed that work with all pixels in the images. This strategy avoids the
132 SECTION j II Algorithms and methods
possible bias in the selection of reference pixels and provides more robust
results in the optimization of shift and rotation parameters because much more
information is used [65]. A possible way to optimize the rotation and trans-
lation parameters among images is via a simplex-based algorithm that mini-
mizes the cost function:
ssqðQ; dx; dyÞ ¼
XX�
Ar
i; j ðx; y;aÞ � As
i; jðxþdx; yþdy;aþQÞði; jÞ
�2
(10)
where A(i,j) represents any single image measurement (intensity, singular
value, concentration, etc.) associated with a particular pixel with Cartesian
coordinates i,j. Ar (i,j) refers to the image taken as reference and As (i,j) to the
image to be spatially matched (dx, dy, and q are the translation in x and y
directions and rotation angle needed to achieve the optimal image matching,
respectively). There are many possible options in terms of spatial information
used to match images. When the sample has a clear contour, binarized sample
contour maps may be a good reference. When this is not the case, binarized
versions of score maps or unmixed distribution maps particularly comparable
among images are also suitable. Once images are appropriately matched,
MCR-ALS can be applied to a multiset structure that will have the pixel mode
in common and different spectral modes for each of the platforms appended.
Nevertheless, most imaging platforms present different spatial resolutions.
An obvious solution is binning (downsampling) the images with the highest
resolution to match the one with lowest resolution and build a multiset as the
one shown in Fig. 6. However, the ultimate aim would be performing image
fusion preserving the natural spatial resolution of each particular image to
obtain the maximum spectral and spatial detail about the samples.
Recently, a solution for this problem has been found in the multiset
analysis world by using the so-called incomplete multiset structures [5,66].
These structures are row- and column-wise augmented matrices with some
missing data blocks and were originally used to address environmental
problems. The translation of this concept to work with images with different
spatial resolution is represented in Fig. 8 [67].
For the example of two images, X1HR, with high spatial resolution, and
X2LR, with low spatial resolution, a first regular multiset structure is built by
appending X2LR with a downsampled version of the first image, X1LR. These
two images with the same spatial resolution are first spatially matched and
used to build a complete multiset with a common pixel dimension [X1LR
X2LR]. Afterward, the original image with highest resolution (X1HR) is
appended below its lowest spatial resolution version [X1LR;X1HR]. The result
is an incomplete multiset structure with three blocks because the image with
lower spatial detail (X2LR) does not have an equivalent with high spatial
resolution.
To resolve this multiset structure, an adapted version of the MCR-ALS
algorithm is employed that is based on the idea that an incomplete multiset
Multivariate curve resolution Chapter j 2.5 133
can be defined as a group of intersecting complete multisets with information
in common. For the example in Fig. 8, the algorithm used optimizes simul-
taneously the profiles in the two complete multiset structures, expressed as
follows:
½X1LRX2LR� ¼ CLR½S1S2�T (11)
½X1LR;X1HR�[ ½C1LR;C1HR�ST1 (12)
After each iteration, an objective function including the two optimizations is
used to drive the global model, defined as:
min
�
k ½X1LRX2LR� � CLR½S1S2�T k þ k ½X1LR;X1HR� � ½CLR;CHR�ST1 k
�
(13)
The outcome of the algorithm is a set of pure extended spectral signatures
including information of all connected platforms, [S1 S2]
T, associated with a
related set of high spatial resolution maps CHR. The only limitation of this
approach appears when there are some image constituents that are only present
in the image with the lowest spatial resolution. In this case, maps with high
spatial resolution cannot be retrieved for these constituents [67].
Amore detailed description of this algorithm can be encountered in
Ref. [67], where simulated examples and image fusion structures including
MS/IR and Raman/IR images are presented. Fig. 9 shows the incomplete
FIGURE 8 Incomplete multiset used to couple images obtained from different spectroscopic
platforms with different spatial resolutions.
134 SECTION j II Algorithms and methods
structure used in the study of the fusion of an IR image (spatial resolution
44 � 44 mm2) and a Raman image (spatial resolution 100 � 100 mm2) of a
tonsil tissue sample. The final results obtained are the signatures of the
different tissue and subtissue components of the sample and the distribution
maps at the highest possible resolution.
When the spectroscopic direction is considered, different platforms can
provide spectra that may show important differences in terms of number of
spectral channels. In such a case, the information of the techniques with higher
number of spectral readings will dominate the analysis. Tackling this problem
may involve binning of some of the techniques, or compression by variable
selection or by using scores provided by auxiliary methods, such as PCA or
even MCR scores obtained on the different individual images. Another com-
mon operation to fuse information of different techniques is the rescaling of
FIGURE 9 Multivariate curve resolution results obtained from the analysis of an incomplete
multiset formed by Raman and FT-IR images from a sample of tonsil tissue. FT-IR, Fourier-
transform infrared.
Multivariate curve resolution Chapter j 2.5 135
the spectroscopic measurement so that signal intensities from the different
blocks are comparable. This operation implies dividing the full blocks by a
suitable scaling factor that can be established visually or can be obtained
otherwise, e.g., the norm of each matrix block [5].
Although the problems associated with the spatial mode are the most
challenging and relevant, there exists a situation that may cause difficulties in
data fusion that is linked to the characteristics of the spectroscopic techniques
used. Indeed, in the first section, techniques providing 3D images, e.g., Raman,
IR, and 4D images, e.g., EEM fluorescence, were presented. Coupling images
that present a different number of spectroscopic dimensions per pixel is also a
challenge. To build a multiset structure joining a 3D image (obeying a bilinear
model) and a 4D image (obeying a trilinear model), both images need to be
unfolded to form a data matrix (sized nr pixels x nr. spectral channels). In the
case of a 3D image, pixel spectra are simply located one on top of each other,
as in Fig. 1; in the case of the 4D EEM image, unfolding takes place as in
Fig. 2B (see Fig. 10). The analysis of the multiset in Fig. 10 by MCR-ALS
would provide a bilinear model. To preserve the natural trilinear behavior of
the 4D EEM image and knowing that constraints can be applied differently in
the Si
T blocks of the multiset structure, trilinearity will be applied as a
constraint only to the blocks of the emission spectra related to the EEM image.
In this way, MCR-ALS will solve the image fusion problem of 3D and 4D
images by using a hybrid bilinear/trilinear model [5,63].
5. Use of resolved maps and spectral signatures: going
beyond MCR
The main purpose of MCR when applied to hyperspectral image analysis is
recovering the underlying BeereLambert law of the image measurement and
providing concentration maps and spectral signatures of the image constitu-
ents. However, the MCR scores (C profiles) and loadings (ST profiles) have
very desirable properties that make them excellent starting information
for other data analysis purposes. Indeed, MCR scores and loadings are
FIGURE 10 (A) Image fusion of 3D and 4D excitation-emission fluorescence measurement
fluorescence images.
136 SECTION j II Algorithms and methods
noise-filtered compressed representations of the compositional and structural
information of the image constituents, respectively. Besides, each of these
profiles is chemically meaningful and contains constituent-specific informa-
tion. The use of MCR scores and loadings increases the performance and
flexibility of data analysis tasks when compared to the straight use of raw
image spectra as initial information [3,4]. Below, some outstanding examples
of further use of MCR concentration profiles and spectral signatures in
different data analysis applications are described.
5.1 Use of MCR scores (concentration profiles or maps)
The matrix C of concentration profiles retrieved by MCR provides two
different kinds of information: on the one hand, the rows of the matrix provide
compressed interpretable information of the composition of each particular
pixel and, on the other hand, every column shows the relative variation of
abundance of a particular constituent along the whole image. When each
concentration profile is refolded into the related 2D map, the information of
pixel relative abundance and spatial distribution of a particular constituent is
obtained. This diversity of information makes that different data analysis tasks
focused on the compositional information (segmentation), on the relative
abundance of the image constituents in pixels (quantitative analysis), or on the
spatial distribution of constituents (heterogeneity studies and superresolution
applications) may work very efficiently when using MCR scores as starting
information.
Segmentation is a common task in hyperspectral image analysis and in-
cludes all unsupervised data analysis tools oriented to find classes of similar
pixels, i.e., pixels with similar composition [3]. The outcome of this analysis is
a segmentation map, where the pixel classes can be displayed, and the class
centroids, which represent the average pixel for each class. Traditionally, raw
spectra were used to perform image segmentation because the shape and in-
tensity of spectra is directly related to chemical composition. Class centroids
were the mean spectra of all pixels belonging to the same class. The use of
MCR scores for image segmentation offers a series of advantages. On the one
hand, the compressed information speeds up the segmentation analysis and the
classes are more accurately defined because the concentration profiles are
noise-filtered, in contrast with the raw spectra that contain the experimental
error incorporated. The interpretation of the characteristics of the class cen-
troids becomes also easier because the information defining every pixel is
formed by relative abundances of image constituents, i.e., straight composition
information. Therefore, the centroids obtained offer the average composition
of every class. Fig. 11A shows the MCR maps and spectral signatures of the
constituents of a kidney stone image; Fig. 11B shows the related segmentation
maps and centroids when raw image spectra (top plot) and MCR scores
(bottom plots) are used, respectively. The segmentation maps are similar using
Multivariate curve resolution Chapter j 2.5 137
both kinds of information, the centroid spectra are very similar to each other
and make difficult defining the characteristics of each class, whereas the MCR
centroids provide clear information on the composition of every class,
expressed as relative concentration of the different image constituents [37].
There are additional advantages of using MCR scores in segmentation
linked to the fact that every profile in C contains compound-specific infor-
mation. This allows omitting certain profiles for segmentation tasks, e.g., those
related to modeled background contributions, or selecting only some of the
chemical concentration profiles for segmentation if pixel similarities want to
be expressed on the basis of only some particular image constituents. Pre-
processing can also be used when relative concentrations of different image
constituents in the image are very unbalanced, e.g., autoscaling or normali-
zation of each concentration profile before segmentation can be doneto
enhance the relevance of minor compounds in the image. All the strategies
above are unthinkable when raw pixel spectra with mixed information of all
image constituents are used [37].
To end up the use of MCR scores for segmentation, it is relevant to mention
that segmentation can be done on a single image or on image multisets. When
done on image multisets formed by images collected on different samples (see
Fig. 6A and Eqs. 7 and 9), segmentation is performed taking altogether the
MCR scores from the augmented C matrix containing the Ci scores of every
particular image. Such a strategy is very valuable when classes common to all
FIGURE 11 (A) Maps and resolved spectra for a kidney stone Raman image, (B) segmentation
maps and centroids obtained from raw image spectra and from multivariate curve resolution
(MCR) scores.
138 SECTION j II Algorithms and methods
images need to be distinguished from classes specific from a particular image.
Such an idea is interesting in multisets formed by images from samples of
individuals belonging to the same biological population. Classes in all samples
refer to population trends, whereas specific classes for an individual are related
to the natural biological variability within a population [68].
The most known use of MCR scores is related to quantitative analysis of
image constituents [3,37]. To do that, an initial column-wise augmented
multiset (see Fig. 6A) is built by appending together calibration and unknown
images of samples containing the constituents of interest. Every concentration
profile contains information associated with a particular image constituent, and
this information will be used to build the related calibration model and do the
suitable predictions. A different calibration model will be built per each image
constituent.
At this point, it is relevant to mention that quantitative analysis can be
performed at a bulk image level or at a local pixel level. Both tasks can be
done using the information contained in the MCR scores, as shown sche-
matically in Fig. 12. First the MCR analysis is performed on the multiset
containing the calibration and test samples, and compound-specific informa-
tion is obtained in the concentration profiles. For a particular image constituent
represented by an augmented concentration profile, the average concentration
value of each image map (coming from the elements in the profile of the
suitable Ci block) is computed. The MCR average concentration values for the
calibration samples (in arbitrary units) are regressed against the real reference
concentration values of the samples, and the calibration line is obtained. The
prediction step can be done at two levels: (1) bulk image concentrations can be
predicted for the test samples by submitting the average MCR concentration
value of the related image maps to the calibration model and (2) for any image,
the real pixel concentration of an image constituent can be found by sub-
mitting the MCR pixel concentration value to the calibration model.
FIGURE 12 Use of multivariate curve resolution scores for quantitative image analysis at a bulk
image and local pixel level.
Multivariate curve resolution Chapter j 2.5 139
This approach allows performing quantitative analysis on images with a
different number of pixels and geometry, since calibration lines and bulk
image predictions are done based on the average image concentration values
and not on total integrated areas under concentration profiles, as in other MCR
applications.
In the analysis of many products, e.g., pharmaceutical formulations or feed
products, the information on the amount of the different constituents in the
product needs to be complemented by information on the heterogeneity of the
mixture that can be obtained from the sample images. Heterogeneity studies
can also be performed at an individual constituent level using MCR scores.
The definition of heterogeneity incorporates two different aspects, the so-
called constitutional heterogeneity and the distributional heterogeneity [68].
Constitutional heterogeneity is the term that defines the scatter in pixel con-
centration values within an image and looks upon the characteristics of each
pixel individually, disregarding the properties of the pixel neighborhood. Such
a heterogeneity contribution is easily described by histograms built with the
different concentration values obtained in the resolved MCR profiles. The
higher the standard deviation linked to the histogram, the higher the consti-
tutional heterogeneity. Equally important is the distributional heterogeneity
that takes into account how uniformly distributed the different constituents in
the sample surface are. Such a concept needs to be defined taking into account
the properties of the pixel neighborhood. To do so, the starting information
in the concentration profile of a particular constituent needs to be refolded into
the concentration map to recover the spatial information. Indicators of image
constituent heterogeneity can be obtained by using approaches such as mac-
ropixel analysis, which analyzes properties of small pixel concentration win-
dows that contain a pixel and the immediate concentric neighbors.
Heterogeneity curves are obtained showing the change in the average variance
of pixel neighborhood concentration values as a function of the size of the
pixel neighborhood selected. Steeper decreases of the heterogeneity curves are
related to lower distributional heterogeneities, i.e., to material more uniformly
distributed. Fig. 13 shows the maps for three components of a pharmaceutical
