A practical design method for reinforced concrete structures with viscous dampers
Ying Zhou ⇑, Xilin Lu, Dagen Weng, Ruifu Zhang
State Key Laboratory of Disaster Reduction in Civil Engineering, Tongji University, 1239 Siping Road, Shanghai 200092, China
a r t i c l e i n f o a b s t r a c t
Article history:
Received 19 July 2011
Revised 7 February 2012
Accepted 9 February 2012
Available online 22 March 2012
Keywords:
Viscous damper
Design method
Reinforced concrete structure
Wenchuan Earthquake
0141-0296/$ - see front matter � 2012 Elsevier Ltd. A
doi:10.1016/j.engstruct.2012.02.014
⇑ Corresponding author. Tel.: +86 21 6598 6157; fa
E-mail addresses: yingzhou@tongji.edu.cn (Y. Zhou
wdg@tongji.edu.cn (D. Weng), zhangruifu@gmail.com
As a result of the 2008 Wenchuan Earthquake, the Chinese government issued a modified seismic code
with increased protection categories and seismic intensities. According to the new code, a lot of school
and industrial buildings need to be seismically retrofitted to satisfy the new seismic requirements. Com-
pared to the retrofitting technology of seismic isolation, the installation of viscous dampers to those
existing buildings is more realistic because of easy construction. However, the design of viscous dampers,
which provides a high level of damping in a structure, is a relatively new application in China for a well-
established and proven technology in other seismically active regions in the world. Only general informa-
tion on the usage of viscous damper is given in Chinese code, which would potentially confuse engineers
and researchers. Thus, the intent of this paper is to propose a practical design method for reinforced con-
crete (RC) structures with viscous dampers. The proposed design process is divided into two stages. In the
preliminary stage, the quantity, mechanical parameters and configurations of the viscous dampers are
determined. In the next stage, the reduction of deformations, additional damping ratio, and connection
of the dampers to the structure are examined. An example is also given to demonstrate the application
of the proposed method to retrofit a RC frame structure by viscous dampers. It is concluded that the pro-
posed design method satisfies the urgent requirement of design and pushes the further development of
research on viscous dampers.
� 2012 Elsevier Ltd. All rights reserved.
1. Introduction
1.1. Background
On May 12th, 2008, a magnitude of MW 8.0 earthquake hit
Wenchuan in China. The earthquake had a shallow focal depth of
approximately 19 km, with the epicenter located 80km WNW of
Chengdu, capital of Sichuan province. The entire country was dev-
astated by the mega earthquake. The death toll of the earthquake
was of over 69,000 killed people, with over 374,000 people injured
and nearly 5 million homeless; the total lost was estimated at
US$130 billion.
After the Wenchuan Earthquake, new Chinese seismic design
codes were issued with the modifications in attempt to increase
protection categories and seismic intensities. In Chinese code, the
protection categories of buildings specified in the Standard for Clas-
sification of Seismic Protection of Building Constructions (GB50223,
2008) [1] are classified into four categories: moderate protection
(MP), standard protection (SP), emphasized protection (EP), and
particular protection (PP), in the order of the increasing protection
requirement. The design requirements for the four building types
ll rights reserved.
x: +86 21 6598 2668.
), lxlst@tongji.edu.cn (X. Lu),
(R. Zhang).
of protection categories are different in structural details and seis-
mic forces [2]. After the quake, protection categories for all class
buildings, dormitories, and dining halls in kindergartens, primary
schools, and middle schools are increased from standard seismic
protection buildings to emphasized seismic protection buildings.
This modification means that the seismic forces of those school
buildings will be calculated commensurate with the design inten-
sity while the structural details will be checked one degree higher
than the design intensity. The purpose of this modification is to
protect young and valuable students in earthquakes. On the other
hand, the seismic intensities of cities are specified in the Code for
Seismic Design of Buildings (GB50011-2008) [3]. After Wenchuan
Earthquake, the seismic intensities of many cities in China are
increased by half degree or more. Lots of school buildings and
industrial buildings in those cities are not complied with new seis-
mic code requirements and thus need to be retrofitted.
Comparing to traditional retrofitting practices, such as enlarg-
ing cross sections or adding steel plates to structural elements
[4], the application of supplementary viscous dampers to buildings
enables easier construction, and reduced labor and downtime.
1.2. Existing research on viscous dampers
Viscous dampers themselves are old technology, dating back
to more than a century ago to full-scale usage on US large cali-
