TIP42/TIP42A
/TIP42B
/TIP42C
 —
 PN
P Epitaxial Silicon Transistor
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIP42/TIP42A/TIP42B/TIP42C Rev. B0 1
December 2009
TIP42/TIP42A/TIP42B/TIP42C
PNP Epitaxial Silicon Transistor
Features
• Medium Power Linear Switching Applications
• Complement to TIP41/TIP41A/TIP41B/TIP41C
Absolute Maximum Ratings TA=25°C unless otherwise noted
Symbol Parameter Value Units
 VCBO Collector-Base Voltage : TIP42
 : TIP42A
 : TIP42B
 : TIP42C
 - 40
 - 60
 - 80
- 100
V
V
V
V
 VCEO Collector-Emitter Voltage : TIP42
 : TIP42A
 : TIP42B
 : TIP42C
 - 40
 - 60
 - 80
- 100
V
V
V
V
 VEBO Emitter-Base Voltage - 5 V
 IC Collector Current (DC) - 6 A
 ICP Collector Current (Pulse) -10 A
 IB Base Current -2 A
 PC Collector Dissipation (TC=25°C) 65 W
 Collector Dissipation (TA=25°C) 2 W
 TJ Junction Temperature 150 °C
 TSTG Storage Temperature - 65 to 150 °C
1.Base 2.Collector 3.Emitter
1 TO-220
TIP42/TIP42A
/TIP42B
/TIP42C
 —
 PN
P Epitaxial Silicon Transistor
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIP42/TIP42A/TIP42B/TIP42C Rev. B0 2
Electrical Characteristics TA=25°C unless otherwise noted
* Pulse Test: PW≤300μs, Duty Cycle≤2%
Symbol Parameter Test Condition Min. Max. Units
 VCEO(sus) * Collector-Emitter Sustaining Voltage
: TIP42
: TIP42A
: TIP42B
: TIP42C
 IC = -30mA, IB = 0 -40
 -60
 -80
-100
V
V
V
V
 ICEO Collector Cut-off Current
: TIP42/42A
: TIP42B/42C
 VCE = -30V, IB = 0
 VCE = -60V, IB = 0
-0.7
-0.7
mA
mA
 ICES Collector Cut-off Current
: TIP42
: TIP42A
: TIP42B
: TIP42C
 VCE = -40V, VEB = 0
 VCE = -60V, VEB = 0
 VCE = -80V, VEB = 0
 VCE = -100V, VEB = 0
-400
-400
-400
-400
μA
μA
μA
μA
 IEBO Emitter Cut-off Current VEB = -5V, IC = 0 -1 mA
 hFE * DC Current Gain VCE = -4V, IC = -0.3A
 VCE = -4V, IC = -3A
 30
 15

75
 VCE(sat) * Collector-Emitter Saturation Voltage IC = -6A, IB = -600mA -1.5 V
 VBE(sat) * Base-Emitter Saturation Voltage VCE = -4V, IC = -6A -2.0 V
 fT Current Gain Bandwidth Product VCE = -10V, IC = -500mA,
 f = 1MHz
3.0 MHz
TIP42/TIP42A
/TIP42B
/TIP42C
 —
 PN
P Epitaxial Silicon Transistor
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIP42/TIP42A/TIP42B/TIP42C Rev. B0 3
Typical Performance Characteristics
Figure 1. DC current Gain Figure 2. Base-Emitter Saturation Voltage
Collector-Emitter Saturation Voltage
Figure 3. Safe Operating Area Figure 4. Power derating
-0.01 -0.1 -1 -10
1
10
100
1000
VCE = -4V


h F
E,
 D
C
 C
U
R
R
E
N
T
G
A
IN
IC[A], COLLECTOR CURRENT
-0.01 -0.1 -1 -10 -100
-0.0
-0.4
-0.8
-1.2
-1.6
-2.0
IC/IB = 10
VCE(sat)
VBE(sat)


V B
E(
sa
t),
 V
C
E(
sa
t)[
V]
, S
A
TU
R
A
TI
O
N
 V
O
LT
AG
E
IC[A], COLLECTOR CURRENT
-1 -10 -100
-0.1
-1
-10
-100
TIP42C
TIP42B
TIP42A
TIP42
IC(MAX) (DC)
IC(MAX) (PULSE)
5m
s
1m
s
0.5m
s


I C
[A
],
C
O
LL
E
C
TO
R
 C
U
R
R
E
N
T
VCE[V], COLLECTOR-EMITTER VOLTAGE
0 25 50 75 100 125 150 175
0
20
40
60
80
100


P C
[W
],
P
O
W
ER
 D
IS
S
IP
A
TI
O
N
TC[oC], CASE TEMPERATURE
TIP42/TIP42A
/TIP42B
/TIP42C
 —
 PN
P Epitaxial Silicon Transistor
© 2009 Fairchild Semiconductor Corporation www.fairchildsemi.com
TIP42/TIP42A/TIP42B/TIP42C Rev. B0 4
Mechanical Dimensions
TO-220
Dimensions in Millimeters
