950106-00967950106-00967
CEBBECEBBE - - 12121212
N DE REFERENCDE REFERENCE : :
Filter Interval(hr) Under carriage
E/g oil filter 65.05510-5028A 250 Idler 200102-00082
E/g fuel filter 65.12503-5026A 500 Upper roller 200105-00043
Element-inner(air cleaner) 400504-00092 2000 Lower roller 200104-00053
Element-outer(air cleaner) 400504-00091 2000 Track spring 200101-00046
Suction filter-oil tank 2474-9016A 2000 Sprocket 200108-00095
Filter-oil tank 400504-00131 1000 Track link-without shoe 200103-00125
Element-pilot filter 2471-1154 1000 Track shoe-link+shoe 200106-00385 600G
Aircon filter K1002210 1000 Shoe (only) 200106-00467 600G
Breaker filter(opt) 474-00046 250
Element-Air Breather K1029257 1000
Belt Seal kit
Aircon Belt 2106-1019D10 990L Seal kit-boom K9001878
Fan Belt 130205-00251 1230L Seal kit-arm K9001901
Seal kit-bucket 2.9m K9001892
Seal kit-center joint 401107-01330
Bulb Main pump K9001902A
Bulb 24V 2W 515-00012A Swing motor K9008336A
Bulb-halogen 24V 75/70W 2515-1016D4 Travel motor K9008310
Bulb 24V 10W 2515-1021D1 Control valve 420-00295KT
DOOSAN Excavator DX225LCA
Battery / fuse / relay
Battery 300101-00199 Engine Gasket kit
Fuse 10A 2527-1016 Top overhaul gasket kit 65.99605-8020
Fuse 15A 2527-1017 All overhaul gasket kit 65.99601-8027
Fuse 20A 2527-1018
Fuse 30A 2527-1025
Fusible link 27A 2527-1023A
Relay 2544-9033
Battery relay 2544-9024
Teeth / adapter / side cutter Manual
Teeth 713-00024A Parts book 950106-00967
Adpater 2713-1218A Operation Manual 950106-00968PT
Side cutter(RH) 2713-1059A Shop manual 950106-00969PT
Side cutter(LH) 2713-1060A

FOREWORD
● This parts list is shown the equipment components parts of 「DOOSAN EXCAVATOR DX225LCA」.
1. HOW TO ORDER PARTS.
When ordering parts, please specify the follwing items as shown in the following example.
Ex. 1) Model of Machine : DX225LCA (Shown on name plate on the side cover)
2) Machine Serial No : CEBBE-○○○○○ (Shown on nameplate on the bed frame)
3) Engine Serial No : ECOEN - ○○○○ (Shown on Engine cylinder block)
4) Part No. : 400914-00212
5) Description : PUMP,MAIN
6) Q'ty : 1
2. HOW TO USE THIS PARTS LIST.
Key No. : It shows the reference no. on the illustration.
Part No. : It shows the part number of the parts which are included in an illustration.
Description : It shows the name of part. Components of an assembly part are shown with [●] marks and are shown
on the line, or lines, below the assembly part.
Also if the components with [●] mark is consists of further components part.
These further components are shown with the marks [●●].
Q'ty : It shows the quantity use for one machine. quantity of components show the quantity for one assembly part.
Service code : Abbreviations in this column have their own meaning as show below.
B : The parts with this abbreviation shows that the part requires some work on it before installing in the machine.
D : These parts are not serviceable, In case of the part with this abbreviation is a component of an assembly
and is not available independently. The assembly part containing this part should be ordered.
K : This means that the part is contained in the service part kit.
R : The part with this abbreviation shows that the quantity of the part
is changed depending on the machine, such as an adjusting shim etc.
S : This part is specially provided as a service part, which was not
provided in the machine before shipping from the factory.
OP : Optional parts.OS : Over-sized parts. US : Under-sized parts.
(Part with abbreviation "OS" or "US" is described on the line below the standard sized part.)
# : The part with this mark is newly added on that page of the equipment.
Serial no. : Serial No. shows the machine serial number which the parts were applied.
As to the engine Serial No. shows only engine serial number which the parts were applied.
Parts without any applicable serial number are used in every machine.
ICA : ICA shows the interchangeability between the original and the improved parts.
Abbreviations used in this column are as follows;
I : Part No. in the column of "Replaceable part" can be used instead of this part but not vice versa.
P : This must not be used for machine. The part No. in the column "Replaceable part" should be used instead.
T : Parts No. those in the column of "Replaceable part" can be used as an assembly instead of this part.
Y : This part and the part in the column of "Replaceable part" are interchangeable with each other.
Blank : This part has no "Repleaceable part"
Replaceable part : Interchangeable parts nos. and their required quantity are shown in this column.
If interchangeable improved parts are provided for the parts which you may order, the improved parts
classified as "I", "P","T" or "Y" may be supplied.
● When repairing, it is recommended to use our standard part.
● Researching the assembling parts from Part No., see the 「Parts Index」 of this parts list.
 Dec. 2012
PREFÁCIO
●●●● Esta lista de peças apresenta os componentes e partes do equipamento 「「「「EXCAVADEIRA EXCAVADEIRA EXCAVADEIRA EXCAVADEIRA DOOSAN DX225LCA」」」」.
1. COMO SOLICITAR PEÇAS
Quando solicitar as peças, por favor, especifique os items abaixo conforme exemplo.
Ex. 1) Modelo do equipamento : DX225LCA (Mostrado em placa de identificação na tampa lateral)
2) Número de série do equipamento: CEBBE-○○○○ (Mostrado na placa de identificação do chassi)
3) Número de série do motor: ECOEN - ○○○○ (Mostrado no bloco de cilindros do motor)
4) Part No. : 400914-00212
5) Descrição : PUMP,MAIN
6) Quantidade : 1
2. COMO UTILIZAR ESSA LISTA DE PEÇAS.
Número chave : Mostra o número de referência no desenho.
Código Material : Mostrao código dos materiais que estão inclusos no desenho.
Descrição : Mostra o nome da peça. Os componentes de montagem da peça são mostrados com a marca [ ●] e são mostrados
na linha, ou linhas abaixo do código do conjunto.
Além disso, se os componentes com a marca [●] é composto de mais componentes
Esses componentes adicionais são mostrados com a marca [ ●●].
Quantidade : Mostra a quantidade usada em um equipamento. A quantidade de componentes mostra a quantidade para um
conjunto montado.
Código de Serviço : As abreviações dessa coluna têm seu próprio significado conforme abaixo:
B : As peças com essa abreviação mostram que a peça requer algum trabalho antes de ser instalado no equipamento.
D : Essas peças não são comercializadas, a peça com essa abreviação é parte da montagem de um conjunto
e não é vendida separadamente. O conjunto que contém essa peça é que deve ser solicitado neste caso.
K : Significa que a peça está contida no kit de serviços de peças.
R : A peça com essa abreviação está mostrando que a quantidade da peça
muda dependendo do equipamento, tal como um calço de ajuste etc.
S : Esta peça é especialmente fornecida como uma peça de serviço, que não tenha sido
fornecida na máquina previamento entregue pela fábrica.
OP : Peças opicionais.OS : Peças de tamanho excedente. US : Peças de tamanho inferior.
(Peças com abreviação "OS" ou "US" são descritas na linha abaixo dos itens de tamanho padrão)
# : As peças com essa marca, são peças que foram recentemente inseridas na pagina do equipamento.
Número de série : Número de série mostra a partir de que número de série cada peça é aplicada ao equipamento.
Em relação ao número de série do motor, este mostra apenas a que número de série de motor cada peça é aplicada.
Peças sem nenhum númerp de série informado podem ser usadas em todos os equipamentos.
ICA : ICA mostra a intercambialidade entre a peça original e peça aperfeiçoada.
Abreviações mostradas nesta coluna têm os seguintes significados;
I : O código constante na coluna de "Item Substituto" mostra que esse item pode ser usado ao invés da peça original
 mas não vice versa.
P : Não deve ser usado para o equipamento. O Código na coluna "Item Substituto" deve ser usado ao invés deste.
T : Códigos que estão na coluna "Item Substituto" podem ser usados em conjunto ao invés desteitem.
Y : Este item e o item na coluna "Item Substituto" são intercambiáveis entre si.
Vazio : Este item não apresenta "Item Substituto"
Item Substituto : Códigos Intercambiáveis e suas requeridas quantidades são mostrados nesta coluna.
Se um item substituto aperfeiçoado for fornecido para as peças que você quer solicitar, os itens substitutos
classificados como "I", "P","T" or "Y" devem ser fornecidos.
●●●● Quando num reparo, é recomndado usar nossas peças originais.
●●●● Buscando por conjuntos de montagem pelo código do item, veja o 「「「「Índice de PeçasÍndice de PeçasÍndice de PeçasÍndice de Peças 」」」」 desta lista de materiais.
 Dez. 2012
CONTENTSCONTENTS
● ENGINE PARTS
Fig. 001 CYLINDER BLOCK BLOCO DE CILINDROS 001-1
002 TIMING GEAR CASE CAIXA DE ENGRENAGEM DO SINCRONISMO 002-1
003 FLYWHEEL HOUSING CARCACA DO VOLANTE 003-1
004 CRANK SHAFT CAMBOTA 004-1
005 CYLINDER HEAD CABEÇOTE DO MOTOR 005-1
006 VALVE MECHANISM MÊCANISMO DE VÁLVULA 006-1
007 BREATHER PIPE TUBO DE RESPIRO 007-1
008 OIL PUMP BOMBA DE ÓLEO 008-1
009 OIL FILTER FILTRO DE ÓLEO 009-1
010 OIL COOLER REFRIGERADOR DE OLEO 010-1
011 OIL PAN CARTER DE OLEO 011-1
012 THERMOSTAT TERMOSTATO 012-1
013 WATER PUMP & COOLING FAN BOMBA D'ÁGUA & VENTILADOR DE RESFRIAMENTO013-1
014 INTAKE & EXHAUST MANIFOLD COLETOR DE ADMISSÃO & EXAUSTÃO 014-1
015 TURBO CHARGER & OIL PIPE CARREGADOR TURBO & BOMBA DE ÓLEO 015-1
016 FUEL SYSTEM SISTEMA DE COMBUSTÍVEL 016-1
017 FUEL FILTER FILTRO DE COMBUSTÍVEL 017-1
018 ALTERNATOR MOUNTING Suporte DE ALTERNADOR 018-1
019 STARTER MOTOR DE ARRANQUE 019-1
020 OVER HAUL GASKET KIT-TOP KIT JUNTA DE VEDAÇÃO - TOPO 020-1
021 OVER HAUL GASKET KIT-ALL KIT JUNTA DE VEDAÇÃO - INTEIRO 021-1
● BODY PARTS
Fig. 1100 MAIN FRAME QUADRO PRINCIPAL 1100-1
1110 COUNTER WEIGHT - 4.1 TON CONTRAPESO - 4.1 TON 1110-1
1120 ENGINE MOUNTING SUPORTE DO MOTOR 1120-1
1130 RADIATOR MOUNTING SUPORTE DE RADIADOR 1130-1
1140 RADIATOR RADIADOR 1140-1
1150 MUFFLER SILENCIADOR 1150-1
1160 CAC PIPING TUBULAÇÃO CAC 1160-1
1 DX225LCA
1170 AIR CLEANER PURIFICADOR DE AR 1170-1
1180 PUMP MOUNTING SUPORTE Da BOMBA 1180-1
1190 SWING MOTOR MOTOR DE GIRO 1190-1
1200 FUEL TANK TANQUE DE COMBUSTÍVEL 1200-1
1210 FUEL PIPING TUBULAÇÃO DE COMBUSTÍVEL 1210-1
1220 FUEL FILLER PUMP BOMBA DE ALIMENTAÇÃO DE COMBUSTÍVEL 1220-1
1230 OIL TANK TANQUE DE ÓLEO 1230-1
1240 OIL COOLER PIPING(1) BOMBA DE REFRIGERAÇÃO DE ÓLEO (1) 1240-1
1250 OIL COOLER PIPING(2) BOMBA DE REFRIGERAÇÃO DE ÓLEO (2) 1250-1
1260 OIL COOLER PIPING(3) BOMBA DE REFRIGERAÇÃO DE ÓLEO (3) 1260-1
1270 ENGINE CONTROL CONTROLE DE MOTOR 1270-1
1280 MAIN PIPING(1) - PUMP TUBULAÇÃO PRINCIPAL(1) - BOMBA 1280-1
1290 MAIN PIPING(2) - BOOM TUBULAÇÃO PRINCIPAL(2) - LANÇA 1290-1
1300 MAIN PIPING(3) - ARM, BUCKET TUBULAÇÃO PRINCIPAL(3) - BRAÇO DA PÁ 1300-1
1310 MAIN PIPING(4) - SWING TUBULAÇÃO PRINCIPAL(4) - BALANÇO 1310-1
1320 MAIN PIPING(5) - CENTER JOINT TUBULAÇÃO PRINCIPAL(5) - JUNTA CENTRAL 1320-1
1330 PILOT PIPING(1) TUBULAÇÃO PILOTO(1) 1330-1
1340 PILOT PIPING(2) TUBULAÇÃO PILOTO(2) 1340-1
1350 PILOT PIPING(3) TUBULAÇÃO PILOTO(3) 1350-1
1360 PILOT PIPING(4) TUBULAÇÃO PILOTO(4) 1360-1
1370 PILOT PIPING(5) TUBULAÇÃO PILOTO(5) 1370-1
1380 PILOT PIPING(6) TUBULAÇÃO PILOTO(6) 1380-1
1390 PILOT PIPING(7) TUBULAÇÃO PILOTO(7) 1390-1
1400 PILOT PIPING(8) TUBULAÇÃO PILOTO(8) 1400-1
1410 CONTROL STAND - L.H. CONSOLE DE CONTROLE - L.H. 1410-1
1420 CONTROL STAND - R.H. CONSOLE DE CONTROLE - R.H. 1420-1
1430 SEAT SLIDING PLATE CORREDIÇA DE ASSENTO 1430-1
1440 SEAT PLATE PLACA DE ASSENTO 1440-1
1450 SEAT MOUNTING Suporte DE ASSENTO 1450-1
1460 SEAT ASSENTO 1460-1
1470 DUCT COVER TAMPA DO DUTO 1470-1
1480 HEATER COVER TAMPA DO AQUECEDOR 1480-1
1490 CABIN MOUNTING Suporte DE CABINE 1490-1
1500 CABIN(1) CABINE(1) 1500-1
1510 CABIN(2) CABINE(2) 1510-1
1520 CABIN(3) CABINE(3) 1520-1
DX225LCA 2
1530 CABIN(4) CABINE(4) 1530-1
1540 HANDLE - CABIN ALÇA - CABINE 1540-1
1550 FLOOR MAT TAPETE DE ASSOALHO 1550-1
1560 FLOOR PLATE PLACA DO ASSOALHO 1560-1
1570 HANDLE ASS'Y CONJUNTO DE ALÇA 1570-1
1580 ROOF COVER TETO 1580-1
1590 FOOT REST - L.H. DESCANÇO DE PÉ - L.E. 1590-1
1600 FOOT REST - R.H. DESCANÇO DE PÉ - L.D. 1600-1
1610 SUPPORT SUPORTE 1610-1
1620 BAFFLE DEFLECTOR 1620-1
1630 SIDE DOOR - L.H PORTA LATERAL - L.E. 1630-1
1640 SIDE DOOR - R.H PORTA LATERAL - L.D. 1640-1
1650 BATTERY COVER TAMPA DE BATERIA 1650-1
1660 COVER TAMPA 1660-1
1670 ENGINE COVER TAMPA DE MOTOR 1670-1
1680 ACOUSTIC FOAM ESPUMA DE ISOLAMENTO ACÚSTICO 1680-1
1690 UNDER COVER ABRIGO 1690-1
1700 LUBRICATION PIPING TUBULAÇÃO DE LUBRIFICAÇÃO 1700-1
1710 ELECTRIC BOX ASS'Y CONJUNTO DE CAIXA ELÉTRICA 1710-1
1720 ELECTRIC PARTS - CABIN PARTES ELÉTRICAS - CABINE 1720-1
1730 ELECTRIC PARTS - CONTROL STAND PARTES ELÉTRICAS - CONSOLE DE CONTROLE 1730-1
1740 ELECTRIC PARTS - RELATED PARTES ELÉTRICAS - RELACIONADOS 1740-1
1750 ELECTRIC PARTS - ENGINE PARTES ELÉTRICAS - MOTOR 1750-1
1760 ALTERNATOR MOUNTING Suporte DE ALTERNADOR 1760-1
1770 ELECTRIC PARTS - WORKING LAMP PARTES ELÉTRICAS - FAROL 1770-1
1780 ELECTRIC WIRING FIAÇÃO ELÉTRICA 1780-1
1790 HEATER PIPING(1) TUBULAÇÃO DE AQUECIMENTO (1) 1790-1
1800 HEATER PIPING(2) TUBULAÇÃO DE AQUECIMENTO (2) 1800-1
1810 AIRCON UNIT UNIDADE DE AR-CONDICIONADO 1810-1
1820 AIRCONDITIONER AIR-CONDICIONADO 1820-1
1830 WORKING LAMP(2-LAMP) FAROL (2 LÂMPADAS) 1830-1
1840 WORKING LAMP - REAR FAROL TRASEIRO 1840-1
1850 ROTATING BEACON FAROL ROTATIVO 1850-1
1860 TRAVEL ALARM ALARME DE DESLOCAÇÃO 1860-1
● TRACK PARTS
3 DX225LCA
Fig. 2100 TRACK FRAME ESTEIRA 2100-1
2110 TRAVEL DEVICE DISPOSITIVO DE CURSO 2110-1
2120 IDLER RODA GUIA 2120-1
2130 TRACK SPRING ROLETE 2130-1
2140 UPPER ROLLER RODANTE SUPERIOR 2140-1
2150 LOWER ROLLER RODANTE INFERIOR 2150-1
2160 CENTER JOINT JUNTA CENTRAL 2160-1
2170 TRACK SHOE ASS'Y - 600G Sapata - 600G 2170-1
2180 TRAVEL PIPING TUBUAÇÃO DE CIRCULAÇÃO 2180-1
● FRONT PARTS
Fig. 3100 BOOM MOUNTING Suporte Da LANÇA 3100-1
3110 BOOM - 5.7m LANÇA - 5.7M 3110-1
3120 ARM - 2.9m BRAÇO - 2.9M 3120-1
3130 BUCKET ASS'Y - 1.24m³(54") - SIDE PIN Caçamba - 1,24M³(54") - LADO PINO 3130-1
3140 BOOM PIPING TUBULAÇÃO DE LANÇA 3140-1
3150 LUBRICATION PIPING - BOOM TUBULAÇÃO DE LUBRIFICAÇÃO - LANÇA 3150-1
3160 ARM PIPING TUBULAÇÃO DE BRAÇO 3160-1
3170 LUBRICATION PIPING - ARM TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 3170-1
● HYDRAULIC PARTS
Fig. 4100 MAIN PUMP BOMBA PRINCIPAL 4100-1
4110 REGULATOR REGULADOR 4110-1
4120 GEAR PUMP BOMBA DE ENGRENAGEM 4120-1
4130 SWING MOTOR MOTOR DE GIRO 4130-1
4140 SWING REDUCTION GEAR ENGRENAGEM DE REDUÇÃO DE GIRO 4140-1
4150 TRAVEL MOTOR MOTOR DE DESLOCAMENTO 4150-1
4160 TRAVEL REDUCTION GEAR ENGRENAGEM DE REDUÇÃO DE VELOCIDADE 4160-1
4170 CONTROL VALVE(1) VÁLVULA DE CONTROLE(1) 4170-1
4180 CONTROL VALVE(2) VÁLVULA DE CONTROLE(2) 4180-1
4190 CONTROL VALVE(3) VÁLVULA DE CONTROLE(3) 4190-1
4200 REMOTE CONTROL VALVE VÁLVULA DE CONTROLE REMOTO 4200-1
4210 PEDAL VALVE VÁLVULA DE PEDAL 4210-1
4220 SOLENOID VALVE Solenóide 4220-1
4230 BOOM CYLINDER - L.H. CILÍNDRO DE LANÇA - L.E. 4230-1
4240 BOOM CYLINDER - R.H. CILÍNDRO DE LANÇA - L.D. 4240-1
DX225LCA 4
4250 ARM CYLINDER CILÍNDRO DE BRAÇO 4250-1
4260 BUCKET CYLINDER - ARM 2.9m CILÍNDRO Da Caçamba - BRAÇO 2.9M 4260-1
4270 BUCKET CYLINDER - ARM 2.4m CILÍNDRO Da Caçamba - BRAÇO 2.4M 4270-1
4280 BUCKET CYLINDER - ARM 3.5m CILÍNDRO Da Caçamba - BRAÇO 3.5M 4280-1
4290 BUCKET CYLINDER - ARM 6.2m CILÍNDRO Da Caçamba - BRAÇO 6.2M 4290-1
● OTHER PARTS
Fig. 5100 TOOLS FERRAMENTAS 5100-1
5110 SPARE PARTS PEÇAS SOBRESSALENTES 5110-1
5120 NAME PLATE - CABIN(EXPORT) PLACA DE NOME - CABINE(EXPORTADO) 5120-1
5130 NAME PLATE - EXPORT PLACA DE NOME - EXPORTADO 5130-1
5140 DECAL - SPEC DECALQUE - ESPECÍFICO 5140-1
5150 DECAL - FUSE BOX DECALQUE - CAIXA DE FUSO 5150-1
5160 DECAL - MACHINE NAME DECALQUE - NOME DA MÁQUINA 5160-1
5170 DECAL - LUBRICATION(EXPORT) DECALQUE - LUBRIFICAÇÃO(EXPORTADO) 5170-1
5180 DECAL - SERIAL DECALQUE - SÉRIE 5180-1
5190 DECAL - LIFTING CAPA DECALQUE - CAPA DE LEVANTAMENTO 5190-1
● OPTION PARTS
Fig. 6100 MAIN PIPING - ONE WAY TUBULAÇÃO PRINCIPAL - CANAL ÚNICO 6100-1
6110 ONE WAY PIPING - WITH FILTER TUBULAÇÃO DE CANAL ÚNICO - COM FILTRO 6110-1
6120 PILOT PIPING - ONE WAY TUBULAÇÃO PILOTO - CANAL ÚNICO 6120-1
6130 BOOM PIPING - BOOM 5.7m(ONE & TWO WAY) TUBULAÇÃO DE LANÇA - BRAÇO 5.7M (CANAL DUPLO)6130-1
6140 ARM PIPING - ARM 2.9m(ONE & TWO WAY) TUBULAÇÃO DE LANÇA - BRAÇO 2.9M (CANAL DUPLO)6140-1
6150 MAIN PIPING - QUICK FIT TUBULAÇÃO PRINCIPAL - ENCAIXE RÁPIDO 6150-1
6160 ELECTRIC PARTS - QUICK CLAMP PARTES ELÉTRICAS - ENGATE RÁPIDO 6160-1
6170 BOOM PIPING - BOOM 5.7m(QUICK CLAMP) TUBULAÇÃO DE LANÇA - LANÇA 5.7M (ENGATE RÁPIDO)6170-1
6180 ARM PIPING - ARM 2.9m(QUICK CLAMP) TUBULAÇÃO DE BRAÇO - BRAÇO 2.9M (ENGATE RÁPIDO)6180-1
6190 ALTERNATOR - 80A ALTERNADOR - 80A 6190-1
6200 TRACK SHOE ASS'Y - 700G Sapata- 700G 6200-1
6210 TRACK SHOE ASS'Y - 800G Sapata - 800G 6210-1
6220 TRACK SHOE ASS'Y - 900G Sapata - 900G 6220-1
6230 BOOM - 5.7M - H.D TYPE LANÇA - 5.7M - TIPO H.D 6230-1
6240 ARM - 2.9m(HEAVY DUTY) BRAÇO - 2.9M (TRABALHO PESADO) 6240-1
6250 BOOM PIPING - 5.7m(H.D) TUBULAÇÃO DE LANÇA - 5.7M (H.D) 6250-1
6260 BOOM PIPING - ONE & TWO WAY(H.D) TUBULAÇÃO DE LANÇA - CANAL DUPLO (H.D) 6260-1
5 DX225LCA
6270 BUCKET ASS'Y - 0.92m³ Caçamba - 0.92M³ 6270-1
6280 BUCKET ASS'Y - 0.51m³ Caçamba- 0.51M³ 6280-1
6290 BUCKET ASS'Y - 0.81m³ Caçamba - 0.81M³ 6290-1
6300 BUCKET ASS'Y - 1.05m³ Caçamba - 1.052M³ 6300-1
6310 BUCKET ASS'Y - 1.17m³ Caçamba - 1.17M³ 6310-1
6320 BUCKET ASS'Y - 1.28m³ Caçamba - 1.28M³ 6320-1
6330 BUCKET ASS'Y - 0.73m³(36") - SIDE PIN Caçamba - 0.73M³(36") - LADO PINO 6330-1
6340 BUCKET ASS'Y - 0.90m³(42") - SIDE PIN Caçamba - 0.90M³(42") - LADO PINO 6340-1
6350 BUCKET ASS'Y - 1.07m³(48") - SIDE PIN Caçamba - 1.07M³(48") - LADO PINO 6350-1
6360 BUCKET ASS'Y - 1.32m³(57") - SIDE PIN Caçamba - 1.32M³(57") - LADO PINO 6360-1
6370 BUCKET ASS'Y - 1.49m³(63") - SIDE PIN Caçamba - 1.49M³(63") - LADO PINO 6370-1
6380 ARM - 2.4m BRAÇO - 2.4M 6380-1
6390 ARM PIPING - ARM 2.4m TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M 6390-1
6400 LUBRICATION PIPING - ARM 2.4m TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 2.4M 6400-1
6410 ARM PIPING - ARM 2.4m(ONE & TWO WAY) TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (CANAL DUPLO)6410-1
6420 ARM PIPING - ARM 2.4m(QUICK CLAMP) TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (ENGATE RÁPIDO)6420-1
6430 ARM - 3.5m BRAÇO - 3.5M 6430-1
6440 ARM PIPING - ARM 3.5m TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M 6440-1
6450 LUBRICATION PIPING - ARM 3.5m TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 3.5M 6450-1
6460 ARM PIPING - ARM 3.5m(ONE & TWO WAY) TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (CANAL DUPLO)6460-1
6470 ARM PIPING - ARM 3.5m(QUICK CLAMP) TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (ENGATE RÁPIDO)6470-1
6480 BOOM - 8.5m LANÇA - 8.5M 6480-1
6490 ARM - 6.2m BRAÇO - 6.2M 6490-1
6500 COUNTER WEIGHT - SUPER LONG CONTRAPESO - SUPER LONGO 6500-1
6510 BUCKET ASS'Y - 0.39m³ CONJUNTO DE PÁ - 0.39M³ 6510-1
6520 BUCKET ASS'Y - 0.45m³ - DITCH CLEANING CONJUNTO DE PÁ - 0.45M³ - BALDE DE LIMPEZA 6520-1
6530 BOOM PIPING - BOOM 8.5m TUBULAÇÃO DE LANÇA - LANÇA 8.5M 6530-1
6540 LUBRICATION PIPING - BOOM 8.5m TUBULAÇÃO DE LUBRIFICAÇÃO -LANÇA 8.5M 6540-1
6550 ARM PIPING - ARM 6.2m TUBULAÇÃO DE BRAÇO - BRAÇO 6.2M 6550-1
6560 LUBRICATION PIPING - ARM 6.2m TUBULAÇÃO DE LUBRIFICAÇÃO -BRAÇO 6.2M 6560-1
6570 SUN ROOF COVER QUEBRA SOL 6570-1
6580 RAIN SHIELD PROTEÇÃO CONTRA CHUVA 6580-1
6590 RAIN SHIELD & LAMP MOUNTING PROTEÇÃO CONTRA CHUVA & SUPORTE LAMPADA6590-1
6600 FOGS GUARD ASS'Y PROTEÇÃO CONTRA NEBLIMA 6600-1
 WORLDWIDE NETWORK●
DX225LCA 6
Serial No. ;
CYLINDER BLOCK
BLOCO DE CILINDROS
DATE DEC. 21, 2012
1st EDITION Fig. 001
001 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CYLINDER BLOCK
BLOCO DE CILINDROS
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 001
001 -1 65.01101-6079D CYLINDER BLOCK ASS'Y BLOCO CONJ,CILINDRO;DB58TIS FINAL1
2 65.01101-0030I BLOCK;CYLINDER BLOCO,CILINDRO 1 D
3 65.01105-1048A CAP;BEARING(F.M.R) CAPA 6 D
5 65.01105-1047A CAP;BEARING(NO.4) CAPA 1 D
7 65.91710-0001 RING;STOPPER ANEL;CYL,CORPO À BRG,CAPA2
8 65.90020-0066A BOLT;BRG CAP PARAFUSO,ROLAMENTO CAPA14
9 65.04410-0007C BUSH;CAM SHAFT BUCHA;EIXO DE CAM 1 B
10 65.04410-0006C BUSH;CAM SHAFT BUCHA;EIXO DE CAM 5 B
11 65.90302-0009 PLUG;CORE BUJAO,CORDEL 2
12 65.90302-0041 PLUG;CORE BUJAO,CORDEL;CILINDRO BLOCO2
13 65.90302-0042 PLUG;CORE BUJAO,CORDEL;CILINDRO CABEÇA3
15 65.90310-0030 SCREW;PLUG M12X1.25 BUJAO,ROSCA 1
16 06.56190-0704 RING;SEAL ANEL DE SELO 1
17 65.90320-0019 PLUG SCREW PT3/8 ROSCA,BUJAO 1
18 06.15091-0313 PLUG;CORE BUJAO,CORDEL 2
19 65.90320-0022 PLUG SCREW PT1/8 ROSCA,BUJAO 10
20 65.90201-0058 BOLT;STUD M14X12.5X45 PARAFUSO,TACHÃO 1
21 65.91605-0001E COVER TAMPA;CORDEL FURO 1
22 06.01913-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 2
23 65.01112-0021A COVER;PUSH ROD CHAMBER TAMPA;EMPURRE HASTE CÂMARA2
24 65.01112-5018 COVER;PUSH ROD CHAMBER TAMPA;EMPURRE HASTE CÂMARA1
25 65.90020-0049 BOLT;HEX. PARAFUSO,HEX;EMPURRE HASTE CÂMARA 6
26 65.96507-0007 PACKING;PUSH ROD CHAMBER ANEL DE SELO;LIGAÇÃO PARAFUSO6
27 65.01110-6090B METAL;CRANK STD ROLAMENTO,METAL;MANIVELA EIXO7
65.01110-6091B METAL;CRANK 0.25 ROLAMENTO,PRINCIPAL;MANIVELA EIXO7 US
65.01110-6092B METAL;CRANK 0.50 ROLAMENTO,PRINCIPAL;MANIVELA EIXO7 US
28 65.01150-6008 WASHER;THRUST ARRUELA,IMPULSO 2
65.01150-6034A WASHER;THRUST 0.25 ARRUELA,IMPULSO;SUPERIOR & BAIXAR2 OS
65.01150-6035A WASHER;THRUST 0.50 ARRUELA,IMPULSO;SUPERIOR & BAIXAR2 OS
29 65.91615-0011 COVER;BLIND TAMPA;CILINDRO BLOCO 1
30 06.01913-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 2
31 65.01201-0067 LINER;CYLINDER (ALTV.) FORRADOR,CILINDRO 6 D
65.01201-0068 LINER;CYLINDER(1A) FORRADOR,CILINDRO 6
65.01201-0069 LINER;CYLINDER(1B) FORRADOR,CILINDRO 6
65.01201-0070 LINER;CYLINDER(2A) FORRADOR,CILINDRO 6
65.01201-0071 LINER;CYLINDER(2B) FORRADOR,CILINDRO 6
36 65.01901-0020 GASKET;PUSH ROD CHAMBER VEDAÇÃO;EMPURRE HASTE CÂMARA TAMPA3
37 06.56021-0106 O-RING;O/P DRIVE FLANGE ANEL,O 1
DX225LCA 001 - 2
Serial No. ;
CYLINDER BLOCK
BLOCO DE CILINDROS
DATE DEC. 21, 2012
1st EDITION Fig. 001
001 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CYLINDER BLOCK
BLOCO DE CILINDROS
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 001
001 -38 65.90310-0135 PLUG;SCREW ROSCA,BUJAO 1
39 06.56190-0706 SEAL RING A14X20 ANEL DE SELO 1
40 65.05903A0013 GASKET;FLANGE VEDAÇÃO,ÓLEO TUBO;TC ÓLEO RETORNO1
42 65.90310-0122 PLUG;DRAIN ROSCA,BUJAO;CILINDRO CABEÇA1
45 06.56190-0713 RING;SEAL A18X24 ANEL DE SELO 2
46 65.01601-5010A OIL JET PIPE BOCAL CONJ,ÓLEO SPRAY;PISTÃO ARREF6
47 65.05401-5023 RELIEF VALVE ASS'Y VÁLVULA CONJ,ALÍVIO;PISTÃO ARREFEC6
48 06.56021-0102 O-RING ANEL,O 1
52 65.05401-5002F RELIEF VALVE ASS'Y VÁLVULA CONJ,ALÍVIO 1
53 65.27441-7006 SWITCH;OIL PRESS. INTERRUPTOR,ÓLEO PRESSÃO1
54 65.90201-0182 BOLT;STUD PARAFUSO,TACHÃO;MTG BKT1
DX225LCA 001 - 4
Serial No. ;
TIMING GEAR CASE
CAIXA DE ENGRENAGEM DO SINCRONISMO
DATE DEC. 21, 2012
1st EDITION Fig. 002
002 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TIMING GEAR CASE
CAIXA DE ENGRENAGEM DO SINCRONISMO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 002
002 -1 65.01304-0003C CASE;TIMING GEAR CRONOMETRAGEM ENGRENAGEM CASO1
4 06.22022-3119 PIN PINO,PARALELO 1
5 06.01913-3120BOLT ASS`Y M8X45 PARAFUSO CONJ 2
6 06.01913-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 4
7 65.01305-5074A COVER;TIMING GEAR CASE TAMPA,TGC;CRONOMETRAGEM ENGRENAGEM1
10 06.22022-3111 PIN PINO,PARALELO 1
12 06.01913-3115 BOLT ASS'Y M8X25 PARAFUSO CONJ 7
15 06.01913-3122 BOLT ASS'Y M8X55 PARAFUSO CONJ 5
17 65.01307-0002B COVER;TIMING CHECK HOLE TAMPA,TGC;CHECAR FURO 2
19 06.01913-2911 BOLT ASS'Y M6X16 PARAFUSO CONJ 4
29 65.01510-0001 SEAL;OIL(FRONT) SELO,ÓLEO 1
31 65.01903-0002C GASKET VEDAÇÃO,TGC TAMPA;CHECAR FURO TAMP2
33 65.01903B0003 GASKET;TIMING GEAR CASE COVER VEDAÇÃO,TGC 1
34 65.01903B0004 GASKET;TIMING GEAR CASE(BLOCK) VEDAÇÃO,TGC 1
DX225LCA 002 - 2
Serial No. ;
FLYWHEEL HOUSING
CARCACA DO VOLANTE
DATE DEC. 21, 2012
1st EDITION Fig. 003
003 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FLYWHEEL HOUSING
CARCACA DO VOLANTE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 003
003 -1 65.01401-0119A HOUSING;FLYWHEEL HABITAÇÃO,RODA DE VOAR 1
5 06.01494-4407 BOLT;HEX. M14X1.5X40 PARAFUSO,HEX 1
6 06.01494-4409 BOLT;HEX. M14X1.5X50 PARAFUSO,HEX 6
8 06.16731-2110 WASHER;SPRING ARRUELA,MOLA 8
9 06.11063-9217 NUT PORCA,HEX 1
10 06.22022-3111 PIN PINO,PARALELO 2
11 65.96401-0007 CAP;RUBBER CAPA,BORRACHA;CRONOMETRAGEM PONTO 1
15 65.01510-0101 SEAL;OIL(REAR) SELO,ÓLEO;RR 1
16 65.01904-0021 GASKET;FLYWHEEL HOUSING VEDAÇÃO,RODA DE VOAR HABITAÇÃO1
DX225LCA 003 - 2
Serial No. ;
CRANK SHAFT
CAMBOTA
DATE DEC. 21, 2012
1st EDITION Fig. 004
004 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CRANK SHAFT
CAMBOTA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 004
004 -101 65.02101-6018A CRANK SHAFT ASS'Y VIRABREQUIM 1
103 65.02101-0045A SHAFT;CRANK VIRABREQUIM 1
105 06.22022-3212 PIN;PARALLEL PINO,PARALELO 1
104 65.02115-0009 GEAR;CRANK SHAFT ENGRENAGEM,VIRABREQUIM1
106 65.93020-0015 BUSH;TAPER BUCHA 1
108 65.02120-0002 RING;OIL THROWER ANEL,ÓLEO LANÇADOR;ANEL LANÇADOR Ó1
109 65.90501-0006 NUT PORCA,HEX 1
110 65.91501-0006 KEY;SLIDING CHAVE;VIRABREQUIM 1
201 65.02301-5099A FLYWHEEL ASS'Y RODA DE VOAR CONJ 1
202 65.02310-0006 GEAR;RING ENGRENAGEM,ANEL;RODA DE VOAR1
204 65.02301-0245A FLY WHEEL RODA DE VOAR 1
207 06.01494-4506 BOLT M16X1.5X35 PARAFUSO,HEX 6
208 06.16731-2111 WASHER;SPRING ARRUELA,MOLA 6
301 65.02401-6021 CONNECTING ROD ASS'Y HASTE,CONEXÃO 6
305 65.02411-0006A BOLT PARAFUSO,HEX;CONEXÃO HASTE2
306 65.02401-0163D ROD;CONNECTING HASTE,CONEXÃO 1 D
307 65.02405-0006 BUSH BUCHA;CONEXÃO HASTE 1 B
308 65.02410-6083B METAL;CON-ROD STD ROLAMENTO,CONEXÃO HASTE6
65.02410-6124B METAL;CON-ROD 0.125mm ROLAMENTO,CONEXÃO HASTE6 US
65.02410-6125B METAL;CON-ROD 0.25mm ROLAMENTO,CONEXÃO HASTE6 US
400 65.02501-0440 PISTON(ALTV.) PISTÃO 6 D
401 65.02501-0416 PISTON(ALTV.) PISTÃO 6 D
65.02501-0443 PISTON(ALTV.-2) PISTÃO 6 D
402 65.02501-0417 PISTON-1;A GRADE PISTÃO 6
65.02501-0444 PISTON-2;A GRADE PISTÃO 6
403 65.02501-0418 PISTON-1;B GRADE PISTÃO 6
65.02501-0445 PISTON-2;B GRADE PISTÃO 6
404 65.02503-8058 PISTON RING KIT ANEL KIT,PISTÃO 1
404A - . RING;TOP . ANEL,PISTÃO 6 K
404B - . RING,SECOND . ANEL,SECUNDÁRIO 6 K
404C - . RING;OIL . ANEL,PISTÃO 6 K
412 65.02502-0082A PIN;PISTON PINO,PISTÃO 6
413 65.90815-0007 RING;RETAINING ANEL,FECHADURA;PISTÃO 12
501 65.02601-5019 PULLEY;DAMPER POLIA,VIRABREQUIM 1
503 65.02122-0001 COVER;DUST TAMPA;POEIRA 1
DX225LCA 004 - 2
Serial No. ;
CYLINDER HEAD
CABEÇOTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 005
005 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CYLINDER HEAD
CABEÇOTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 005
005 -101 65.03101-6071B CYLINDER HEAD ASS'Y CABEÇA CONJ,CILINDRO 1
102 65.03101-1043C HEAD;CYLINDER CABEÇA;CILINDRO 1 D
104 65.03201-1013A GUIDE;VALVE GUIA,VÁLVULA 12 B
105 65.03203-1054 SEAT;EXHAUST VALVE LUGAR,VÁLVULA;ESCAPAMENTO VÁLVULA6 B
106 65.03203-1053 SEAT;INLET VALVE LUGAR,VÁLVULA;ENTRADA VÁLVULA6 B
107 65.90302-0015 PLUG;CORE(NEAR FACE) BUJAO,CORDEL;CILINDRO CABEÇA1
108 65.90302-0030 PLUG;CORE(EXHAUST MAIN) BUJAO,CORDEL 6
109 65.90302-0019B PLUG;CORE BUJAO,CORDEL 11
110 65.90302-0045 PLUG;CORE BUJAO,CORDEL;CILINDRO CABEÇA3
111 65.90302-0027 PLUG;CORE BUJAO,CORDEL 6
112 65.90302-0011 PLUG;DRILLED PASS BUJAO;FURADEIRA PASSAGEM,CYL CABEÇ6
113 65.90302-0017 PLUG;WATER JET CORE BUJAO,CORDEL;CYL CABEÇA ÁGUA JET6
116 06.06225-0706 BOLT;STUD M8X25 PARAFUSO,TACHÃO 3
117 06.06125-8717 BOLT;STUD PARAFUSO,TACHÃO 9
118 06.06125-8709 BOLT;STUD M8X35 PARAFUSO,TACHÃO 1
119 65.91710-0004 RING;STOPPER ANEL,PARE;CYL,BLOCO À CYL,CABEÇA2
120 65.90021-0002 BOLT;CYLINDER HEAD PARAFUSO,COLAR HEX DUO;CYL.CABEÇA18
121 65.90021-0003 BOLT;CYLINDER HEAD PARAFUSO,COLAR HEX DUO;CYL.CABEÇA6
122 65.90021-0004 BOLT;CYLINDER HEAD PARAFUSO,COLAR HEX DUO;CYL.CABEÇA2
123 06.06125-8723 BOLT;STUD M8X110 PARAFUSO,TACHÃO 2
124 65.19202-5005 HOOK;LIFTING ANZOL,ELEVADOR 1
125 65.03901-0066A GASKET;CYLINDER HEAD VEDAÇÃO,CILINDRO CABEÇA;CILINDRO C1
128 06.16731-2110 WASHER;SPRING ARRUELA,MOLA 1
129 06.01733-4409 BOLT;HEX M14X1.5X25 PARAFUSO,HEX 1
130 06.16731-2108 WASHER;SPRING ARRUELA,MOLA 1
131 06.01733-4208 BOLT M10X1.25X22 PARAFUSO,HEX 1
132 65.26815-0002 PLUG;DUMMY BUJAO;MANEQUIM 6
133 65.19202-0005 HOOK;LIFTING ANZOL,ELEVADOR 1
134 06.01943-3213 BOLT ASS'Y M10X1.25X20 PARAFUSO CONJ 2
200 65.03401-6097B CYLINDER HEAD COVER ASS'Y TAMPA,CILINDRO CABEÇA 1
201 65.03401-6094 COVER;CYL. HEAD TAMPA,CILINDRO CABEÇA 1
202 06.04190-8808 BOLT M5X16 ROSCA KIT 6
203 06.16731-2104 WASHER;SPRING ARRUELA,MOLA 6
204 06.15010-0308 WASHER;PLAIN ARRUELA,PLANÍCIE 6
205 65.03903-0001 PACKING;BREATHER PIPE EMPANQUE,TAMPA;PCV VÁLVULA TAMPA1
206 65.01801-0011 CASE;BREATHER CASO;RESPIRO 1
207 65.03905-0002C GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA(1
209 65.90501-0028 NUT;CYLINDER HEAD COVER PORCA,HEX 4
DX225LCA 005 - 2
Serial No. ;
CYLINDER HEAD
CABEÇOTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 005
005 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CYLINDER HEAD
CABEÇOTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 005
005 -210 65.90701-0202 WASHER;PLATE ARRUELA,PLANÍCIE;CYL.CABEÇA TAMPA4
211 65.03905-0023A GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA4
220 65.01810-5011 CAP;OIL FILLER CAPA CONJ,ÓLEO ENCHEDOR1
223 65.01801-5035A BREATHER PIPE ASS'Y HABITAÇÃO,RESPIRO 1
224 65.96501-0032B O-RING;BREATHER ANEL,O;ÓLEO SEPARADOR VÁLVULA1
DX225LCA 005 - 4
Serial No. ;
VALVE MECHANISM
MÊCANISMO DE VÁLVULA
DATE DEC. 21, 2012
1st EDITION Fig. 006
006 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
VALVE MECHANISM
MÊCANISMO DE VÁLVULA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 006
006 -101 65.04101-0032 VALVE;INLET VÁLVULA,ADMISSÃO 6
102 65.04101-0025A VALVE;EXHAUST VÁLVULA,ESCAPAMENTO 6
103 65.04102-0005 SPRING;VALVE MOLA,VÁLVULA 12
104 65.04103-0001B RETAINER;VALVE SPRING PLACA,VÁLVULA MOLA 12
105 65.04103-0002 PLATE;SPRING PLACA,VÁLVULAMOLA 12
106 65.04104-0001 SPLIT;COLLAR CHAVETA,VÁLVULA 24
107 65.04902-0015 SEAL;VALVE STEM SELO,ÓLEO;VÁLVULA STEM 12
201 65.04200-6019D ROCKER ARM & SHAFT ASS'Y BALANCIM BRAÇO EIXO CONJ1
202 65.04201-5002C ROCKER ARM ASS'Y BRAÇO,BALANCIM;IN EX 12
206 65.04205-0001 SCREW;ADJUST ROSCA,AJUSTADOR 12
207 65.90501-0013 NUT;HEX. PORCA,HEX 12
208 65.04203-5008C ROCKER ARM SHAFT ASS'Y BALANCIM BRAÇO EIXO CONJ1
210 65.04202-0009 BRACKET(FRONT) SUPORTE,BALANCIM BRAÇO 1
211 65.04202-0003C BRACKET(ROCKER ARM) SUPORTE,BALANCIM BRAÇO 6
212 65.97601-0048 SPRING;ROCKER ARM MOLA;BALANCIM BRAÇO EIXO5
213 06.29010-0116 RING;SNAP ANEL,ESTALO 1
214 06.01013-9118 BOLT;HEX. M8X65 PARAFUSO,HEX 10
215 06.15010-2311 WASHER ARRUELA,PLANÍCIE 10
216 65.90201-0081 BOLT;STUD PARAFUSO,TACHÃO;CYL.CABEÇA TAMPA4
301 65.04301-0009 TAPPET TUCHO,VÁLVULA 12
302 65.04302-5006 ROD;PUSH PUSHROD 12
401 65.04401-0018B SHAFT;CAM EIXO DE CAM 1
402 06.29151-4608 KEY CHAVE,DESLIZAMENTO 1
403 65.98112-0009A FLANGE FLANGE;EIXO DE CAM 1
404 06.01913-3115 BOLT ASS'Y M8X25 PARAFUSO CONJ 2
501 65.04501-0004 GEAR;CAM SHAFT ENGRENAGEM,EIXO DE CAM 1
503 65.90701-0059 WASHER;PLAIN ARRUELA;CAM ENGRENAGEM1
504 06.01733-4410 BOLT M14X1.5X28 PARAFUSO,HEX 1
505 65.04505-5012 IDLE GEAR ASS'Y ENGRENAGEM CONJ,INATIVO1
510 65.04506-0011 SHAFT;IDLE GEAR EIXO,INATIVO ENGRENAGEM 1
511 65.90720-0016 WASHER;THRUST ARRUELA,IMPULSO;INATIVO ENGRENAGEM1
512 06.01943-3222 BOLT ASS'Y M10X1.25X55 PARAFUSO CONJ 2
DX225LCA 006 - 2
Serial No. ;
BREATHER PIPE
TUBO DE RESPIRO
DATE DEC. 21, 2012
1st EDITION Fig. 007
007 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BREATHER PIPE
TUBO DE RESPIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 007
007 -1 65.01801-5100 HOUSING;BREATHER HABITAÇÃO,RESPIRO 1
2 06.01923-3114 BOLT ASS'Y M8X22 PARAFUSO CONJ 4
3 65.01840-0008A BRACKET;BREATHER PIPE SUPORTE,RESPIRO;CCV SISTEMA1
4 65.90001-0139 BOLT;HEX. M8X150 PARAFUSO,HEX 4
5 06.16731-2107 WASHER ARRUELA,MOLA 4
6 65.91701-0197 SPACER ESPAÇADOR;BREATHR HOUSING SUPORTE2
7 65.91701-0199 SPACER ESPAÇADOR;BREATHR HOUSING SUPORTE1
8 65.91701-0233 SPACER ESPAÇADOR;RESPIRO HABITAÇÃO SUPORT1
9 65.96301-0421 HOSE;RUBBER MANGUEIRA,BORRACHA;RESPIRO TUBO1
10 06.67020-0105 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
11 65.97460-0002 CABLE TIA CINTA;LAÇO,CABO 2
16 65.05701-5541 PIPE;OIL TUBO,SUCÇÃO;À BLOCO DE TUBO1
17 06.01923-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 3
18 65.96301-0422A HOSE;RUBBER MANGUEIRA,BORRACHA;CCV SISTEMA1
19 06.67020-0101 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
20 65.96301-0386 HOSE;RUBBER MANGUEIRA,BORRACHA;CCV SISTEMA1
21 06.67020-0101 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
22 65.98131-0119 NIPPLE BICO;AR COMP. ÁGUA ENTRADA1
23 06.56190-0719 RING;SEAL ANEL DE SELO 1
DX225LCA 007 - 2
Serial No. ;
OIL PUMP
BOMBA DE ÓLEO
DATE DEC. 21, 2012
1st EDITION Fig. 008
008 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL PUMP
BOMBA DE ÓLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 008
008 -101 65.05101-7025 OIL PUMP ASS'Y BOMBA CONJ,ÓLEO 1
102 65.05102-0018 HOUSING;OIL PUMP CORPO;ÓLEO BOMBA 1 D
103 65.05104-6065 GEAR ASS'Y;OIL PUMP ENGRENAGEM,ÓLEO BOMBA;ÓLEO BOMBA1
106 65.05105-0044 SHAFT;OIL PUMP EIXO,ÓLEO BOMBA;ÓLEO BOMBA1
107 65.05104-0177 GEAR;OIL PUMP ENGRENAGEM,ÓLEO BOMBA;ÓLEO BOMBA1
108 65.05705-6023 STRAINER ASS'Y COADOR;ÓLEO BOMBA 1
109 06.01013-9117 BOLT M8X65 PARAFUSO,HEX 4
110 06.16731-2107 WASHER ARRUELA,MOLA 4
111 65.05103-0051 COVER;OIL PUMP TAMPA;ÓLEO BOMBA 1 D
112 65.91710-0012 RING;STOPPER ANEL,PARE 1
113 06.22070-0913 PIN;SPLIT 4X30 PINO,CISÃO 1
114 65.91305-0007 SEAT;SPRING LUGAR,MOLA 1
115 65.97601-0090 SPRING;COMPRESSION MOLA,COMPRESSÃO 1
116 06.31641-0222 BALL;STEEL BOLA,AÇO 1
117 06.01913-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 2
118 65.96601-0058 GASKET VEDAÇÃO,ÓLEO BOMBA 1
119 65.05701-5636A OIL PIPE ASS'Y TUBO,ÓLEO;ÓLEO FILTRO 1
120 06.01923-3120 BOLT ASS'Y M8X45 PARAFUSO CONJ 4
121 65.05903A0002 GASKET VEDAÇÃO,ÓLEO TUBO 2
122 06.01944-3215 BOLT ASS'Y M10X1.25X25 PARAFUSO CONJ 2
202 65.05201-0065 GEAR;OIL PUMP DRIVE ENGRENAGEM,ÓLEO BOMBA;ÓLEO BOMBA1
203 65.05207-0006 COUPLING;SLEEVE MANGA;ACOPLAMENTO 1
204 65.05202-0001B BUSH;DRIVE GEAR BUCHA 1
DX225LCA 008 - 2
Serial No. ;
OIL FILTER
FILTRO DE ÓLEO
DATE DEC. 21, 2012
1st EDITION Fig. 009
009 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL FILTER
FILTRO DE ÓLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 009
009 -10 65.05501-7084A OIL FILTER ASS'Y FILTRO CONJ,ENGINE ÓLEO 1
20 65.05510-5028A CARTRIDGE,OIL FILTER CARTUCHO,ÓLEO FILTRO 1
30 65.05503-5053 HEAD;OIL FILTER CABEÇA,ÓLEO FILTRO 1
40 65.90310-0036A PLUG;SCREW ROSCA,BUJAO;ÓLEO FILTRO 1
50 06.56190-0709 SEAL;RING ANEL DE SELO 1
60 06.31641-0222 BALL;STEEL BOLA,AÇO 1
70 65.97601-0045 SPRING;COMPRESS MOLA,COMPRESSÃO;COMBUSTÍVEL FILTRO1
80 65.90350-0005 SCREW;PLUG PT 3/8 BUJAO 1
100 65.05520-5001 FLANGE;INTERMEDIATE FLANGE,INTERMEDIÁRIA;ÓLEO FILTRO1
110 65.05901C0004 GASKET;OIL FILTER VEDAÇÃO,ÓLEO FILTRO 1
120 06.01953-3219 BOLT ASS'Y M10X1.25X40 PARAFUSO CONJ 3
130 65.90001-6013 BOLT;HEX. PARAFUSO,HEX 1
140 06.01923-3228 BOLT ASS'Y M10X85 PARAFUSO CONJ 2
150 06.01923-3225 BOLT ASS'Y M10X70 PARAFUSO CONJ 1
160 06.01923-3222 BOLT ASS`Y PARAFUSO CONJ 1
DX225LCA 009 - 2
Serial No. ;
OIL COOLER
REFRIGERADOR DE OLEO
DATE DEC. 21, 2012
1st EDITION Fig. 010
010 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL COOLER
REFRIGERADOR DE OLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 010
010 -10 65.05601-7056E OIL COOLER ASS'Y ARREFECEDOR CONJ,ÓLEO 1
11 65.05902-0025 GASKET;ELEMENT VEDAÇÃO,ÓLEO ARREFECEDOR2
15 65.05606-5024 ELEMENT;OIL COOLER ELEMENTOS,ÓLEO ARREFECEDOR1
20 65.05604-0013B HOUSING;OIL COOLER HABITAÇÃO,ÓLEO ARREFECEDOR1
25 65.05902A0005 GASKET;OIL COOLER VEDAÇÃO,ÓLEO ARREFECEDOR1
30 06.01923-3120 BOLT ASS'Y M8X45 PARAFUSO CONJ 12
40 06.01923-3115 BOLT ASS'Y M8X25 PARAFUSO CONJ 14
50 06.01923-3113 BOLT ASS'Y M8X20 PARAFUSO CONJ 2
60 65.90201-0103 BOLT;STUD PARAFUSO,TACHÃO;ÓLEO ARREFECEDOR2
61 06.15010-2311 WASHER ARRUELA,PLANÍCIE 2
62 06.16731-2107 WASHER ARRUELA,MOLA 2
70 65.05701-5531 OIL PIPE ASS'Y TUBO,ÓLEO;ÓLEO PRESSÃO UNIDADE1
80 06.01913-3114 BOLT ASS'Y M8X22 PARAFUSO CONJ 8
90 65.05701-5530 PIPE ASS'Y;OIL TUBO,ÓLEO;TURBO CARREGADOR1
100 65.05903A0001 GASKET VEDAÇÃO,ÓLEO TUBO 4
DX225LCA 010 - 2
Serial No. ;
OIL PAN
CARTER DE OLEO
DATE DEC. 21, 2012
1st EDITION Fig. 011
011 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL PAN
CARTER DE OLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 011
011 -1 65.05801-5247 PAN;OIL PANELA,ÓLEO 1
3 65.98125-5022A JOINT;DRAIN TORNEIRA,DRENO 1
4 06.56190-0732 SEAL;RING ANEL DE SELO 1
9 06.01913-3119 BOLT ASS'Y M8X40 PARAFUSO CONJ 21
10 06.01913-3123 BOLT;HEX. M8X60 PARAFUSO,HEX 2
11 65.05740-5007 BRACKET SUPORTE,ÓLEO TUBO;CCVSISTEMA1
20 65.05805-5222A GAUGE;OIL LEVEL BITOLA,ÓLEO NÍVEL 1
30 65.05806-5102A TUBE;GUIDE TUBO,ÓLEO NÍVEL BITOLA;ÓLEO PANELA1
40 06.56017-0303 O-RING ANEL,O 2
50 65.91701-0086 SPACER ESPAÇADOR 2
60 65.05904A0002 GASKET;OIL PAN VEDAÇÃO,ÓLEO PANELA 1
DX225LCA 011 - 2
Serial No. ;
THERMOSTAT
TERMOSTATO
DATE DEC. 21, 2012
1st EDITION Fig. 012
012 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
THERMOSTAT
TERMOSTATO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 012
012 -1 65.06404-5032 HOUSING ASS'Y HABITAÇÃO CONJ,TERMÓSTATO1
4 65.06402-5015 THERMOSTAT TERMÓSTATO 1
5 65.06405-0039 OUTLET;WATER TUBO,ÁGUA ESCOAMENTO;TERMÓSTATO1
6 06.01923-3114 BOLT ASS'Y M8X22 PARAFUSO CONJ 2
7 65.90201-0037 BOLT;SPACER PARAFUSO,TACHÃO 1
8 06.16731-2107 WASHER ARRUELA,MOLA 1
9 06.15010-2311 WASHER ARRUELA,PLANÍCIE 1
10 06.01493-4217 BOLT M10X1.25X90 PARAFUSO,HEX 2
11 06.01493-4216 BOLT M10X1.25X85 PARAFUSO,HEX 1
12 06.01943-3217 BOLT M10X1.25X30 PARAFUSO,HEX 3
13 06.16044-0211 WASHER;SPRING ARRUELA,ONDA 6
17 65.06904A0004 GASKET;THERMOSTAT HSG VEDAÇÃO,TERMÓSTATO;TERMÓSTATO1
18 65.06904-0003 GASKET;THERMOSTAT VEDAÇÃO,TERMÓSTATO 1
19 65.96301-0045C HOSE;RUBBER MANGUEIRA,BORRACHA;TERMÓSTATO1
20 06.67020-0106 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
DX225LCA 012 - 2
Serial No. ;
WATER PUMP & COOLING FAN
BOMBA D'ÁGUA & VENTILADOR DE RESFRIAMENTO
DATE DEC. 21, 2012
1st EDITION Fig. 013
013 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
WATER PUMP & COOLING FAN
BOMBA D'ÁGUA & VENTILADOR DE RESFRIAMENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 013
013 -101 65.06500-6144A WATER PUMP ASS'Y BOMBA CONJ,ÁGUA 1
102 65.06501-0214 HOUSING HABITAÇÃO 1 D
103 65.06520-6007 SEAL;MECHANICAL SELO,MECANICO;ÁGUA BOMBA1
104 65.93410-0027 BEARING ROLAMENTO,BOLA 1
105 06.29020-0132 SNAP RING 55X2 ANEL,ESTALO 1
106 65.06504-0033 HUB;V-BELT PULLEY CUBO;ÁGUA BOMBA POLIA 1
107 65.06506-0085 IMPELLER IMPULSOR;ÁGUA BOMBA 1
108 65.06512-0016 COVER TAMPA,ÁGUA BOMBA 1
109 65.06901-0035A GASKET VEDAÇÃO,ÁGUA BOMBA;ÁGUA BOMBA1
110 06.04200-9009 SCREW;CROSS M8X20 ROSCA,TRANSVERSAL 3
111 06.01493-4215 BOLT M10X1.25X80 PARAFUSO,HEX 1
112 06.01493-4212 BOLT M10X1.25X65 PARAFUSO,HEX 2
113 06.01943-3218 BOLT ASS'Y M10X1.25X35 PARAFUSO CONJ 1
114 06.16731-2108 WASHER;SPRING ARRUELA,MOLA 3
115 K1052729 PULLEY;BELT POLIA,VENTILADOR;ÁGUA BOMBA1
116 65.06901B0002 GASKET;WATER PUMP VEDAÇÃO;ÁGUA BOMBA 1
201 65.06601-5070 FAN;COOLING VENTILADOR,ARREFECEDOR1
203 65.06611-0132 FLANGE;FAN FLANGE,VENTILADOR;VENTILADOR ACION1
204 06.01013-9130 BOLT M8X150 PARAFUSO,HEX 4
207 06.16731-2107 WASHER ARRUELA,MOLA 4
209 130205-00251 BELT,V CINTO,V 1
DX225LCA 013 - 2
Serial No. ;
INTAKE & EXHAUST MANIFOLD
COLETOR DE ADMISSÃO & EXAUSTÃO
DATE DEC. 21, 2012
1st EDITION Fig. 014
014 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
INTAKE & EXHAUST MANIFOLD
COLETOR DE ADMISSÃO & EXAUSTÃO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 014
014 -101 65.08101-0274 MANIFOLD;EXHAUST MANIFOLD,ESCAPAMENTO 1
103 06.06175-8208 BOLT;STUD M10X1.25X30 PARAFUSO,TACHÃO 4
104 06.16731-2107 WASHER ARRUELA,MOLA 12
105 06.15010-2311 WASHER ARRUELA,PLANÍCIE 12
106 06.11063-8214 NUT PORCA,HEX 12
107 65.08901-0028 GASKET;EXHAUST MANIFOLD VEDAÇÃO,ESCAPAMENTO MANIFOLD3
201 65.08201-5062 MANIFOLD;INTAKE MANIFOLD,ENTRADA 1
202 65.08202-0175 STAKE;INTAKE ESTACA,ENTRADA 1
203 65.26803-7028B AIR HEATER AQUECEDOR,AR 1
204 65.09904-0008 GASKET;AIR HEATER VEDAÇÃO,AR TUBO 2
205 06.01923-3124 BOLT ASS'Y M8X65 PARAFUSO CONJ 4
207 06.16731-2107 WASHER ARRUELA,MOLA 4
208 06.15010-2311 WASHER ARRUELA,PLANÍCIE 4
212 65.90020-0142 BOLT ASS'Y PARAFUSO,COLAR HEX 7
213 06.01013-9127 BOLT M8X120 PARAFUSO,HEX 1
214 06.11063-8214 NUT PORCA,HEX 3
215 06.16731-2107 WASHER ARRUELA,MOLA 3
216 06.15010-2311 WASHER ARRUELA,PLANÍCIE 3
219 65.08902-0034 GASKET;INTAKE MANIFOLD VEDAÇÃO,ENTRADA MANIFOLD;IN.MANIFO1
220 65.08120-0026 HEAT;SCREEN TELA,CALOR;ESCAPAMENTO MANIFOLD1
221 06.01913-3111 BOLT ASS'Y M8X16 PARAFUSO CONJ 3
222 65.91701-0029 SPACER ESPAÇADOR;INATIVO POLIA SUPORTE1
DX225LCA 014 - 2
Serial No. ;
TURBO CHARGER & OIL PIPE
CARREGADOR TURBO & BOMBA DE ÓLEO
DATE DEC. 21, 2012
1st EDITION Fig. 015
015 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TURBO CHARGER & OIL PIPE
CARREGADOR TURBO & BOMBA DE ÓLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 015
015 -101 65.09100-7080A TURBO CHARGER ASS'Y CARREGADOR CONJ,TURBO1
102 65.09901-0018A GASKET VEDAÇÃO,TURBO CARREGADOR1
103 06.11024-9202 NUT M10X1.25 PORCA,HEX 4
104 06.16731-2108 WASHER;SPRING ARRUELA,MOLA 4
105 65.09901-0020 GASKET;TURBO CHARGER VEDAÇÃO,TURBO CARREGADOR1
106 65.90201-0096 BOLT;STUD M8X30 PARAFUSO,TACHÃO;TURBO CARREGADOR4
107 06.11063-8214 NUT PORCA,HEX 4
108 06.16731-2107 WASHER ARRUELA,MOLA 4
109 65.98130-0200A ADAPTER ADAPTADOR 1
110 65.05701-5342 OIL PIPE ASS'Y TUBO,ÓLEO;CYL,BLOCO À INJ,BOMBA CO1
111 06.78144-2403 HOLLOW SCREW M12X1.5 ROSCA,CAVIDADE 1
112 06.56190-0709 SEAL;RING ANEL DE SELO 1
113 06.56190-0704 RING;SEAL ANEL DE SELO 2
114 65.98155-0011 UNION;HOLLOW UNIÃO,CAVIDADE 1
115 06.56180-0714 RING;SEAL ANEL DE SELO 2
116 06.12172-9314 NUT;CAP PORCA,CAPA 1
117 65.97480-0135 HOLDER TITULAR;TURBO CARREGADOR ÓLEO ENTR1
118 06.01913-3110 BOLT ASS'Y M8X12 PARAFUSO CONJ 1
119 65.05701-5343 OIL PIPE ASS'Y TUBO,ÓLEO;CYL,BLOCO À TURBO CARREG1
120 65.96601-0067 GASKET;T/C OIL RETURN VEDAÇÃO,FLANGE;TC ÓLEO RETORNO TUB1
121 06.01913-3115 BOLT ASS'Y M8X25 PARAFUSO CONJ 2
122 65.96301-0280A HOSE;RUBBER MANGUEIRA,BORRACHA;TURBO CARREGADO1
123 06.67020-0106 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
201 65.09411-5054 PIPE;INLET TUBO,AR;T/C À CAC 1
202 65.96301-0279 HOSE;RUBBER MANGUEIRA,BORRACHA 1
203 06.67020-0109 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 2
204 65.09440-0016 BRACKET SUPORTE,AR ENTRADA 1
205 06.01923-3215 BOLT ASS'Y M10X25 PARAFUSO CONJ 2
DX225LCA 015 - 2
Serial No. ;
FUEL SYSTEM
SISTEMA DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 016
016 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL SYSTEM
SISTEMA DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 016
016 -101 65.10101-7099A NOZZLE HOLDER ASS'Y TITULAR CONJ,BOCAL 6
102 65.10102-6069 NOZZLE BOCAL,INJEÇÃO 1
104 65.96507-0044B RING;SEAL ANEL DE SELO;BOCAL TITULAR6
106 65.96507-0050 SEAL;RING ANEL DE SELO;BOCAL TITULAR6
108 65.90201-0099 BOLT;STUD PARAFUSO,TACHÃO;BOCAL TITULAR CONJ12
109 06.11063-8214 NUT PORCA,HEX 12
110 06.16731-2107 WASHER ARRUELA,MOLA 12
201 65.10301-6088 PRESSURE PIPE ASS'Y TUBO CONJ,INJEÇÃO 1
202 65.10301-6089 PRESSURE PIPE ASS'Y TUBO CONJ,INJEÇÃO 1
301 400912-00071 PUMP ASSY,INJECTION BOMBA CONJ,INJEÇÃO 1
301A 105220-649A . PUMP,FEED . BOMBA,ALIMENTADOR 1
301AA400908-00004 .. HAND PRIMING PUMP .. BOMBA,ALIMENTADOR 1
301B 131150-2620 . PLUNGER . ÊMBOLO 6
301C 65.11108-6006S . VALVE,DELIVERY . VÁLVULA 1
301D 131424-1520 . VALVE;OVERFLOW. VÁLVULA CONJ,ALAGAMENTO1
301E 156639-8820 . COUPLING . ACOPLAMENTO,BOMBA,INJEÇÃO1
304 06.67020-0101 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
305 65.08301-6008 HOSE;AIR MANGUEIRA CONJ,AR;I/P IMPULSIONAR 1
306 65.98131-0050 CONN SCREW CONEXÃO,ROSCA 1
307 06.56180-0714 RING;SEAL ANEL DE SELO 1
308 65.05701-5200 PIPE;OIL TUBO CONJ,ÓLEO;CYL,BLOCO À I/BOMBA1
309 65.98155-0011 UNION;HOLLOW UNIÃO,CAVIDADE 1
310 06.12172-9314 NUT;CAP PORCA,CAPA 1
311 06.56180-0714 RING;SEAL ANEL DE SELO 2
320 65.11596-0001 WIRE;SEAL SELO,ARAME 3
321 65.11596-0002 WIRE;SEAL SELO,ARAME 1
401 06.01913-3122 BOLT ASS'Y M8X55 PARAFUSO CONJ 1
402 06.01913-3124 BOLT ASS'Y M8X65 PARAFUSO CONJ 4
404 06.01283-7128 BOLT;HEX. M8X85 PARAFUSO,HEX 2
405 06.16731-2107 WASHER ARRUELA,MOLA 1
406 65.11401-0002C BRACKET;REAR SUPORTE,INJEÇÃO BOMBA;TRASEIRA1
407 06.01953-3213 BOLT ASS'Y M10X1.25X20 PARAFUSO CONJ 2
408 06.15010-2312 WASHER;PLAIN ARRUELA,PLANÍCIE 1
409 06.11063-9215 NUT M10X1.25 PORCA,HEX 1
410 06.16731-2108 WASHER;SPRING ARRUELA,MOLA 1
411 65.11902A0001 GASKET;INJECTION PUMP MOUNTING VEDAÇÃO;INJEÇÃO BOMBA MONTAGEM1
501 65.12301-5022 PIPE;FUEL(RETURN) TUBO,COMBUSTÍVEL 1
502 65.96341-0100 HOSE;FUEL MANGUEIRA,COMBUSTÍVEL 1
DX225LCA 016 - 2
Serial No. ;
FUEL SYSTEM
SISTEMA DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 016
016 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL SYSTEM
SISTEMA DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 016
016 -503 06.78144-2204 SCREW;HOLLOW ROSCA,CAVIDADE 1
504 65.96507-0043 RING;SEAL A14X20 ANEL DE SELO 2
505 06.78144-2204 SCREW;HOLLOW ROSCA,CAVIDADE 1
506 65.96507-0043 RING;SEAL A14X20 ANEL DE SELO 2
507 65.12301-5824 PIPE;FUEL TUBO,COMBUSTÍVEL;SOBRE FLUXO1
508 65.98150-0015B SCREW;HOLLOW ROSCA,CAVIDADE;BOCAL TITULAR6
509 06.56180-0712 RING;SEAL ANEL DE SELO 12
510 65.12301-5825 PIPE;FUEL(RETURN) TUBO CONJ,COMBUSTÍVEL;INJ BOMBA CO1
511 65.96301-0176 HOSE;RUBBER MANGUEIRA,BORRACHA;COMBUSTÍVEL RET1
512 65.97401-0089 CLIP GRAMPO;COMBUSTÍVEL RETORNO MANGUEI2
513 65.97460-0002 CABLE TIA CINTA;LAÇO,CABO 1
515 65.96341-0100 HOSE;FUEL MANGUEIRA,COMBUSTÍVEL 1
DX225LCA 016 - 4
Serial No. ;
FUEL FILTER
FILTRO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 017
017 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL FILTER
FILTRO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 017
017 -1 65.12501-7023B FUEL FILTER ASS`Y FILTRO CONJ,COMBUSTÍVEL 1
2 65.12504-5013A HEAD;FUEL FILTER CABEÇA,COMBUSTÍVEL FILTRO1
4 65.12503-5016B ELEMENT;E/G FUEL FILTER ELEMENTOS,COMBUSTÍVEL FILTRO1
5 65.90310-0143 SCREW;PLUG ROSCA,BUJAO 1
6 06.56180-0716 RING;SEAL ANEL DE SELO 1
7 06.01953-3318 BOLT ASS'Y M12X1.5X35 PARAFUSO CONJ 2
DX225LCA 017 - 2
Serial No. ;
ALTERNATOR MOUNTING
Suporte DE ALTERNADOR
DATE DEC. 21, 2012
1st EDITION Fig. 018
018 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ALTERNATOR MOUNTING
Suporte DE ALTERNADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 018
018 -1 65.19102-0013B BRACKET SUPORTE,ALTERNADOR 1
2 06.01944-3215 BOLT ASS'Y M10X1.25X25 PARAFUSO CONJ 1
3 06.01943-3218 BOLT ASS'Y M10X1.25X35 PARAFUSO CONJ 2
5 65.19103-6010A EYE BOLT ASS'Y PARAFUSO CONJ,OLHAL;ALTERNADOR MON1
10 65.90441-0009A EYE BOLT PARAFUSO,OLHAL;ALTERNADOR1 D
11 65.19107-0001A PIECE;GUIDE PEDAÇO,GUIA;ALTERNADOR AJUSTADOR1 D
12 65.93020-0055 BUSH BUCHA 1 D
13 06.11063-9217 NUT PORCA,HEX 3 D
14 06.01943-3319 BOLT ASS'Y M12X1.5X40 PARAFUSO CONJ 1
15 65.08120-0027 SCREEN;HEAT TELA,CALOR 1
DX225LCA 018 - 2
Serial No. ;
STARTER
MOTOR DE ARRANQUE
DATE DEC. 21, 2012
1st EDITION Fig. 019
019 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
STARTER
MOTOR DE ARRANQUE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 019
019 -1 300516-00041 STARTER ASSY INICIADOR CONJ 1
1A 65.26212-0006 . RELAY;MAGNETIC . RETRANSMITIR 1
2 06.01943-3318 BOLT ASS'Y M12X1.5X35 PARAFUSO CONJ 3
3 65.29101-5001 WIRE;ELECTRIC ARAME,ELÉTRICO 1
4 65.97480-0223 HOLDER TITULAR;RETRANSMITIR 1
5 06.01943-3213 BOLT ASS'Y M10X1.25X20 PARAFUSO CONJ 1
6 65.90201-0168 BOLT;STUD PARAFUSO,TACHÃO 1
7 06.16731-2108 WASHER;SPRING ARRUELA,MOLA 1
DX225LCA 019 - 2
Serial No. ;
OVER HAUL GASKET KIT-TOP
KIT JUNTA DE VEDAÇÃO - TOPO
DATE DEC. 21, 2012
1st EDITION Fig. 020
020 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OVER HAUL GASKET KIT-TOP
KIT JUNTA DE VEDAÇÃO - TOPO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 020
020 -- 65.99605-8020 OVER HAUL GASKET KIT-TOP VEDAÇÃO KIT,TOPO EXAMINAR1
1 65.03901-0066A GASKET;CYLINDER HEAD VEDAÇÃO,CILINDRO CABEÇA;CILINDRO C1
2 65.04902-0011A SEAL;VALVE STEM SELO 12
3 65.03905-0023A GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA4
4 65.03905-0002B GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA(1
5 65.03903-0001 PACKING;BREATHER PIPE EMPANQUE,TAMPA;PCV VÁLVULA TAMPA1
6 65.06904-0003 GASKET;THERMOSTAT VEDAÇÃO,TERMÓSTATO 1
7 65.06904A0004 GASKET;THERMOSTAT HSG VEDAÇÃO,TERMÓSTATO;TERMÓSTATO1
8 65.08901-0028 GASKET;EXHAUST MANIFOLD VEDAÇÃO,ESCAPAMENTO MANIFOLD3
9 65.08902-0034 GASKET;INTAKE MANIFOLD VEDAÇÃO,ENTRADA MANIFOLD;IN.MANIFO1
10 65.09904-0008 GASKET;AIR HEATER VEDAÇÃO,AR TUBO 2
11 65.96507-0044B RING;SEAL ANEL DE SELO;BOCAL TITULAR6
12 65.96507-0050 SEAL;RING ANEL DE SELO;BOCAL TITULAR6
13 06.56180-0712 RING;SEAL ANEL DE SELO 12
14 65.96501-0032B O-RING;BREATHER ANEL,O;ÓLEO SEPARADOR VÁLVULA1
15 65.09901-0018A GASKET VEDAÇÃO,TURBO CARREGADOR1
16 65.09901-0020 GASKET;TURBO CHARGER VEDAÇÃO,TURBO CARREGADOR1
17 65.96601-0067 GASKET;T/C OIL RETURN VEDAÇÃO,FLANGE;TC ÓLEO RETORNO TUB1
DX225LCA 020 - 2
Serial No. ;
OVER HAUL GASKET KIT-ALL
KIT JUNTA DE VEDAÇÃO - INTEIRO
DATE DEC. 21, 2012
1st EDITION Fig. 021
021 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OVER HAUL GASKET KIT-ALL
KIT JUNTA DE VEDAÇÃO - INTEIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 021
021 -- 65.99601-8027 OVER HAUL GASKET KIT-ALL VEDAÇÃO KIT,TODO EXAMINAR1
1 06.56021-0106 O-RING;O/P DRIVE FLANGE ANEL,O 1
2 65.01901-0020 GASKET;PUSH ROD CHAMBER VEDAÇÃO;EMPURRE HASTE CÂMARA TAMPA3
3 65.05903A0013 GASKET;FLANGE VEDAÇÃO,ÓLEO TUBO;TC ÓLEO RETORNO1
4 06.56021-0102 O-RING ANEL,O 1
5 65.01510-0001 SEAL;OIL(FRONT) SELO,ÓLEO 1
6 65.01903-0002C GASKET VEDAÇÃO,TGC TAMPA;CHECAR FURO TAMP2
7 65.01903B0003 GASKET;TIMING GEAR CASE COVER VEDAÇÃO,TGC 1
8 65.01903B0004 GASKET;TIMING GEAR CASE(BLOCK) VEDAÇÃO,TGC 1
9 65.01510-0101 SEAL;OIL(REAR) SELO,ÓLEO;RR 1
10 65.01904-0021 GASKET;FLYWHEEL HOUSING VEDAÇÃO,RODA DE VOAR HABITAÇÃO1
11 65.03901-0066A GASKET;CYLINDER HEAD VEDAÇÃO,CILINDRO CABEÇA;CILINDRO C1
12 65.04902-0015 SEAL;VALVE STEM SELO,ÓLEO;VÁLVULA STEM 12
13 65.03905-0023A GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA4
14 65.03905-0002B GASKET;CYLINDER HEAD COVER VEDAÇÃO,CILINDRO CABEÇA TAMPA(1
15 65.03903-0001 PACKING;BREATHER PIPE EMPANQUE,TAMPA;PCV VÁLVULA TAMPA1
16 65.05903A0002GASKET VEDAÇÃO,ÓLEO TUBO 2
17 65.05901C0004 GASKET;OIL FILTER VEDAÇÃO,ÓLEO FILTRO 1
18 65.05902A0005 GASKET;OIL COOLER VEDAÇÃO,ÓLEO ARREFECEDOR1
19 65.05903A0001 GASKET VEDAÇÃO,ÓLEO TUBO 2
20 65.05904A0002 GASKET;OIL PAN VEDAÇÃO,ÓLEO PANELA 1
21 65.06904-0003 GASKET;THERMOSTAT VEDAÇÃO,TERMÓSTATO 1
22 65.06904A0004 GASKET;THERMOSTAT HSG VEDAÇÃO,TERMÓSTATO;TERMÓSTATO1
23 65.06901B0002 GASKET;WATER PUMP VEDAÇÃO;ÁGUA BOMBA 1
24 65.08901-0028 GASKET;EXHAUST MANIFOLD VEDAÇÃO,ESCAPAMENTO MANIFOLD3
25 65.08902-0034 GASKET;INTAKE MANIFOLD VEDAÇÃO,ENTRADA MANIFOLD;IN.MANIFO1
26 65.09904-0008 GASKET;AIR HEATER VEDAÇÃO,AR TUBO 2
27 65.96507-0044B RING;SEAL ANEL DE SELO;BOCAL TITULAR6
28 65.96507-0050 SEAL;RING ANEL DE SELO;BOCAL TITULAR6
29 65.11902A0001 GASKET;INJECTION PUMP MOUNTING VEDAÇÃO;INJEÇÃO BOMBA MONTAGEM1
30 06.56180-0712 RING;SEAL ANEL DE SELO 12
31 65.96507-0007 PACKING;PUSH ROD CHAMBER ANEL DE SELO;LIGAÇÃO PARAFUSO6
32 65.96501-0032B O-RING;BREATHER ANEL,O;ÓLEO SEPARADOR VÁLVULA1
33 65.09901-0018A GASKET VEDAÇÃO,TURBO CARREGADOR1
34 65.09901-0020 GASKET;TURBO CHARGER VEDAÇÃO,TURBO CARREGADOR1
35 65.96601-0067 GASKET;T/C OIL RETURN VEDAÇÃO,FLANGE;TC ÓLEO RETORNO TUB1
DX225LCA 021 - 2
Serial No. ;
MAIN FRAME
QUADRO PRINCIPAL
DATE DEC. 21, 2012
1st EDITION Fig. 1100
1100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN FRAME
QUADRO PRINCIPAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1100
1100 -- 160620-00347 FRAME,MAIN QUADRO, PRINCIPAL - D
1 160620-00348A FRAME,MAIN QUADRO, PRINCIPAL 1
5 S0571266 BOLT PARAFUSO,HEX 36
6 160-00068A COVER;RUBBER TAMPA,BORRACHA 1
7 180-00463 PACKING EMPANQUE 1
8 621-02938B COVER TAMPA 1
9 DS0025023 BOLT;SET PARAFUSO 2
13 S0571866 BOLT M20X2.5X170 PARAFUSO,HEX 1
14 2123-1107D7 PIN;KNOCK PINO,BATIDA 2
15 2160-1004D48 BUSHING;RUBBER BUCHA,BORRACHA 1
16 2160-1004D39 BUSHING;RUBBER BUCHA,BORRACHA 1
17 2160-1201D11 BUSHING;RUBBER BUCHA,BORRACHA 1
21 2114-9012A WASHER ARRUELA,RÍGIDO 36
25 2160-1201D13 BUSHING;RUBBER BUCHA,BORRACHA 2
26 2160-1201D12 BUSHING;RUBBER BUCHA,BORRACHA 1
27 2160-1004D55 BUSHING;RUBBER BUCHA,BORRACHA 2
28 191-02990C PLATE PLACA 2
29 K1049858 BOLT PARAFUSO 6
31 195-02623B BRACKET SUPORTE 1
32 DS0025015 BOLT;SET PARAFUSO 1
33 160-00081 CAP CAPA,BORRACHA 1
36 DS7601027 BUSHING;RUBBER BUCHA,BORRACHA 2
37 DS7601028 BUSHING;RUBBER BUCHA,BORRACHA 2
38 2160-1004D31 BUSHING;RUBBER BUCHA,BORRACHA 1
39 S4013133 NUT PORCA 1
40 S8470165 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
41 DS7601046 BUSHING;RUBBER BUCHA,BORRACHA 1
91 K1039519 WASHER;HARD ARRUELA,RÍGIDO;CONTADOR PESO MONTA4
92 K1039520 BOLT PARAFUSO,HEX 4
DX225LCA 1100 - 2
Serial No. ;
COUNTER WEIGHT - 4.1 TON
CONTRAPESO - 4.1 TON
DATE DEC. 21, 2012
1st EDITION Fig. 1110
1110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
COUNTER WEIGHT - 4.1 TON
CONTRAPESO - 4.1 TON
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1110
1110 -- 160702-00637 WEIGHT ASSY,COUNTER;4.1TON PESO CONJ,CONTADOR;4.1TON1
1 160702-00638 WEIGHT,COUNTER PESO,CONTADOR 1
2 K1014698 BRACKET SUPORTE 1
3 DS0025015 BOLT;SET PARAFUSO 2
DX225LCA 1110 - 2
Serial No. ;
ENGINE MOUNTING
SUPORTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 1120
1120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ENGINE MOUNTING
SUPORTE DO MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1120
1120 -- 150109-00736 ENGINE ASSY MONTAGEM DE MOTOR - D
3 110427-00210 BRACKET,ENGINE MOUNTING SUPORTE,ENGINE MONTAGEM1
4 110427-00212 BRACKET,ENGINE MOUNTING SUPORTE,ENGINE MONTAGEM1
5 110427-00211 BRACKET,ENGINE MOUNTING SUPORTE,ENGINE MONTAGEM1
6 110427-00213 BRACKET,ENGINE MOUNTING SUPORTE,ENGINE MONTAGEM1
14 195-02465 BRACKET SUPORTE 1
17 2114-1929 WASHER ARRUELA 4
18 161-00548 RUBBER BORRACHA,ENGINE MONTAGEM4
19 161-00550 RUBBER BORRACHA,ENGINE MONTAGEM4
21 K1004487 BRACKET SUPORTE 2
24 K1007551 HOSE;AIR MANGUEIRA,AR 1
25 2114-9012A WASHER ARRUELA,RÍGIDO 8
26 110958-01083 SUPPORT;NUT APOIO,PORCA 4
27 S0771466 BOLT PARAFUSO,HEX 4
32 124-00208D6 CLIP GRAMPO 2
34 K1001029 BOLT PARAFUSO 2
36 S0515366 BOLT PARAFUSO,HEX 2
37 S5010713 WASHER;PLAIN ARRUELA,PLANÍCIE 2
38 DS0025015 BOLT;SET PARAFUSO 2
39 S5102603 WASHER,SPRING ARRUELA,MOLA 10
40 S0712366 BOLT PARAFUSO,HEX 7
41 S0786366 BOLT PARAFUSO,HEX 8
42 S5102703 WASHER;SPRING ARRUELA,MOLA 8
48 S4032633 NUT M10X1.25 PORCA 1
49 S0711866 BOLT PARAFUSO,HEX 1
50 S8510044 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
53 S0511866 BOLT PARAFUSO,HEX 1
101 ECOEN ENGINE ASS'Y;TIER-2(TROPICAL) MONTAGEM DE MOTOR 1
DX225LCA 1120 - 2
Serial No. ;
RADIATOR MOUNTING
SUPORTE DE RADIADOR
DATE DEC. 21, 2012
1st EDITION Fig. 1130
1130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
RADIATOR MOUNTING
SUPORTE DE RADIADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1130
1130 -- 150109-00736 ENGINE ASSY MONTAGEM DE MOTOR - D
2 440211-00386A RADIATOR ASSY RADIADOR CONJ 1
7 K1006781 HOSE;WATER MANGUEIRA,ÁGUA 1
8 K1006780 HOSE;WATER MANGUEIRA,ÁGUA 1
13 K1038409 TANK;RESERVE TANQUE,RESERVA 1
15 K1000563B STAY ESTADA 1
22 K1004515 HOSE MANGUEIRA,ÁGUA 1
28 2114-1816A WASHER ARRUELA,RÍGIDO 4
29 S0512466 BOLT PARAFUSO,HEX 8
30 S5102903 WASHER,SPRING ARRUELA,MOLA 4
31 124-00208D2 CLIP GRAMPO 2
34 K1001029 BOLT PARAFUSO 2
35 DS0025016 BOLT;SET PARAFUSO 2
45 S8450012 CLAMP BRAÇADEIRA,MANGUEIRA 1
46 S8500079 CLAMP;HOSE BRAÇADEIRA,CONSTANTE TORQUE5
47 S5010913 WASHER,PLAIN ARRUELA,PLANÍCIE 4
54 K1040048 BRACKET SUPORTE 1
55 K1047774 STAY ESTADA,RADIADOR 1
DX225LCA 1130 - 2
Serial No. ;
RADIATOR
RADIADOR
DATE DEC. 21, 2012
1st EDITION Fig. 1140
1140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
RADIATOR
RADIADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1140
1140 -- 440211-00386A RADIATOR ASSY RADIADOR CONJ 1
1 440211-00517 RADIATOR RADIADOR 1
2 400206-00455 COOLER,OIL ARREFECEDOR, ÓLEO 1
3 440301-00038 CHARGE,AIR COOLER CARREGADOR,AR ARREFECEDOR1
13 110948-00134 SHROUD ASSY SUDÁRIO,FABRICAÇÃO 1
13A 110921-02339 . GUARD,FAN . GUARDA, VENTILADOR 1
14 101551-00064 NET,WIRE;RADIATOR NET, FIO;RADIADOR 1
15 101551-00065 NET,WIRE;OIL COOLER NET, FIO, RADIADOR DE ÓLEO1
16 101551-00066 NET,WIRE;CAC NET, FIO;CAC 1
24 110910-00918 CAP CAPA 1
30 410202-00025 COCK,DRAIN TORNEIRA,DRENO 1
DX225LCA 1140 - 2
Serial No. ;
MUFFLER
SILENCIADOR
DATE DEC. 21, 2012
1st EDITION Fig. 1150
1150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MUFFLER
SILENCIADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1150
1150 -- 150109-00736 ENGINE ASSY MONTAGEM DE MOTOR - D
9 K1006245 COVER TAMPA 1
10 K1016432 BRACKET SUPORTE;TURBO CARREGADORR TAMPA1
11 K1016430 COVER TAMPA,TURBO CARREGADOR1
12 240103-00325 MUFFLER ASSY SILENCIADOR CONJ 1
12-1 240103-00326 . MUFFLER . SILENCIADOR 1
12-2 110421-00052 . BRACKET,MUFFLER . SUPORTE,SILENCIADOR 1
12-3 120119-00022 . BOLT,U . PARAFUSO,U 2
12-4 S5010613 . WASHER;PLAIN . ARRUELA,PLANÍCIE 4
12-5S4012633 . NUT . PORCA,HEX 8
16 K1045900 PIPE;EXHAUST TUBO,ESCAPAMENTO 1
33 124-00310A CLAMP BRAÇADEIRA 1
34 K1001029 BOLT PARAFUSO 6
37 S5010713 WASHER;PLAIN ARRUELA,PLANÍCIE 2
43 S4012733 NUT PORCA 2
44 S0515866 BOLT PARAFUSO,HEX 2
52 DS0025021 BOLT;SET PARAFUSO 2
DX225LCA 1150 - 2
Serial No. ;
CAC PIPING
TUBULAÇÃO CAC
DATE DEC. 21, 2012
1st EDITION Fig. 1160
1160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CAC PIPING
TUBULAÇÃO CAC
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1160
1160 -- K1046072 CAC PIPING CARREGADOR,AR ARREFECEDOR- D
1 420202-00141 PIPE TUBO 1
2 420101-00296 HOSE,AIR MANGUEIRA,AR 2
3 124-00194 CLAMP BRAÇADEIRA 4
4 420202-00142 PIPE TUBO 1
5 K1045910 HOSE;CAC MANGUEIRA,AR 2
6 DS0025014 BOLT;SET PARAFUSO 4
7 K1000663 BRACKET SUPORTE 1
8 K1000704A CLAMP BRAÇADEIRA 4
9 DS0025023 BOLT;SET PARAFUSO 4
10 K1012143 BRACKET SUPORTE 1
DX225LCA 1160 - 2
Serial No. ;
AIR CLEANER
PURIFICADOR DE AR
DATE DEC. 21, 2012
1st EDITION Fig. 1170
1170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
AIR CLEANER
PURIFICADOR DE AR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1170
1170 -- 400414-00198 CLEANER ASSY,AIR ASPIRADOR, AR - D
1 400414-00226 CLEANER,AIR ASPIRADOR, AR 1
1A 400504-00092 . ELEMENT,INNER(AIR) . ELEMENTO, INTERNO 1
1B 400504-00091 . ELEMENT,OUTER(AIR) . ELEMENTO, EXTERIOR 1
1C 110902-00211 . BAND,AIR CLEANER . CINTA,TUBO 2
1D A213589 . EJECTOR,DUST . EJETOR, POEIRA 1
3 DS0025015 BOLT;SET PARAFUSO 4
4 193-00913A PIPE;AIR TUBO,AR 1
5 420101-00600 HOSE,AIR MANGUEIRA,AR 1
6 S8510118 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 4
7 193-00912 PIPE;AIR TUBO,AR 1
8 K1000562 HOSE;AIR MANGUEIRA,AR 1
9 S8510092 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
10 185-00410C HOSE;AIR MANGUEIRA 1
11 170-00004 INDICATOR;DUST INDICADOR,POEIRA;AR LIMPADOR1
12 2120-2165 BOLT PARAFUSO,TACHÃO 2
13 S4012633 NUT PORCA,HEX 2
14 S5102603 WASHER,SPRING ARRUELA,MOLA 2
15 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 2
17 S8510143 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
18 K1003618 CAP;RAIN CAPA,CHUVA 1
DX225LCA 1170 - 2
Serial No. ;
PUMP MOUNTING
SUPORTE Da BOMBA
DATE DEC. 21, 2012
1st EDITION Fig. 1180
1180 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PUMP MOUNTING
SUPORTE Da BOMBA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1180
1180 -- 400911-00005 PUMP INSTALLATION INSTALAÇÃO DA BOMBA - D
1 400914-00212 PUMP,MAIN BOMBA,PRINCIPAL 1
2 229-00025C COVER;PUMP TAMPA,BOMBA 1
3 K1013825 COUPLING ACOPLAMENTO,BOMBA 1
3A - . HUB . CUBO 1 D
3B 2474-7009 . ELEMENT . ELEMENTOS 1
3C - . INSERT(A) . INSERIR 4 D
3D - . INSERT(R) . INSERIR 4 D
3E K9000422 . SET;SOCKET BOLT . PARAFUSO,HEX SOQUETE 1
3F - . BOLT;CLAMPING . PARAFUSO,HEX 2 D
3G - . PIN;SPRING . PINO,MOLA 12 D
3H 2474-7009K . ELEMENT KIT . ELEMENTOS KIT,ACOPLAMENTO1
4 S0512266 BOLT PARAFUSO,HEX 9
5 S0512366 BOLT PARAFUSO,HEX 3
6 S5102603 WASHER,SPRING ARRUELA,MOLA 12
7 S2227866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
8 S5111103 WASHER;SPRING ARRUELA,MOLA 4
DX225LCA 1180 - 2
Serial No. ;
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION Fig. 1190
1190 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1190
1190 -- 401-00477J SWING DEVICE ASS'Y DISPOSITIVO CONJ,OSCILANTE- D
1 170301-00111B DEVICE,SWING;SUB DISPOSITIVO,OSCILANTE;SUB1
1A 170303-00049B . MOTOR,SWING . MOTOR,OSCILANTE 1
1B 130426-00010 . GEAR ASSY,REDUCTION . ENGRENAGEM CONJ,REDUÇÃO1
1C 2181-1110D3 . ADAPTER . ADAPTADOR,S 1
1D 181-00698 . REDUCER . REDUTOR 1
1E 121-00010D3 . NUT . PORCA 1
1F S8000181 . O-RING . ANEL,O 1
1G 2181-1950D7 . PLUG . BUJAO 1
1H 2181-1913D24 . REDUCER . REDUTOR 1
1I K1000266 . PIPE . TUBO 1
1J 2119-1063B . CAP . CAPA 1
1K 2184-1036D43 . HOSE PF1/2-550L . MANGUEIRA 1
1L S5011113 . WASHER;PLAIN . ARRUELA,PLANÍCIE 1
2 2184-1046D50 HOSE MANGUEIRA 1
3 DS2214051 ADAPTER ADAPTADOR 1
4 181-00103 REDUCER REDUTOR 1
5 S6710041 NIPPLE;GREASE APROPRIADO 1
6 121-00006 NUT PORCA 1
7 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 1
8 124-00208D2 CLIP GRAMPO 2
9 K1001029 BOLT PARAFUSO 2
10 2114-9012A WASHER ARRUELA,RÍGIDO 11
11 S0570166 BOLT M20X2.5X65 PARAFUSO,HEX 11
12 160-00027 CAP CAPA,BORRACHA 2
13 2123-4030 PIN;LOCK PINO,BATIDA 1
14 S0511666 BOLT PARAFUSO,HEX 2
DX225LCA 1190 - 2
Serial No. ;
FUEL TANK
TANQUE DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 1200
1200 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL TANK
TANQUE DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1200
1200 -- 450103-00269 TANK ASSY,FUEL TANQUE,COMBUSTÍVEL - D
1 450103-00270 TANK,FUEL TANQUE,COMBUSTÍVEL 1
2 473-00033 COVER TAMPA 1
3 S8011450 O-RING ANEL,O 1
4 471-00105A FILTER;FUEL STRAINER FILTRO,COMBUSTÍVEL COADOR1
5 110911-00126 CAP,FUEL CAPA,COMBUSTÍVEL;CHAVE 1
5A 400504-00045 . ELEMENT(FUEL CAP) . ELEMENTOS,FILTRO;COMBUSTÍVEL CAPA1
6 119-00014AD1 GAUGE;LEVEL BITOLA,NÍVEL 1
7 DS2802021 CLIP GRAMPO 2
8 S8000111 O-RING ANEL,O 2
9 186-00017A COCK;DRAIN TORNEIRA,DRENO 1
10 S0512066 BOLT M10X1.5X25 PARAFUSO,HEX 6
11 S5102603 WASHER,SPRING ARRUELA,MOLA 6
12 K1001029 BOLT PARAFUSO 2
13 S0565466 BOLT PARAFUSO,HEX 6
14 2114-1813 SHIM CALÇO 3
15 2114-1814 SHIM CALÇO 3
16 114-00425 SPACER ESPAÇADOR 6
18 301316-00016 SENDER,FUEL SENSOR,COMBUSTÍVEL 1
19 S3450833 SCREW ROSCA,MÁQUINA;R/CABEÇA 6
20 S5100203 WASHER;SPRING ARRUELA,MOLA 6
21 2181-1890D2 PLUG BUJAO 2
22 DS2105053 HOSE MANGUEIRA,COMBUSTÍVEL 1
23 S8450012 CLAMP BRAÇADEIRA,MANGUEIRA 1
DX225LCA 1200 - 2
Serial No. ;
FUEL PIPING
TUBULAÇÃO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 1210
1210 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL PIPING
TUBULAÇÃO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1210
1210 -- K1007631B FUEL PIPING TUBULAÇÃO DE COMBUSTÍVEL- D
1 K1013251 SEPARATOR;WATER SEPARADOR,ÁGUA 1
1A K9002044 . ELEMENT . ELEMENTOS;ÁGUA SEPARADOR1
1B S8010751 . O-RING . ANEL,O 1
5 DS2105022 HOSE;FUEL MANGUEIRA,COMBUSTÍVEL 1
6 DS2105026 HOSE MANGUEIRA,COMBUSTÍVEL 1
7 DS2105018 HOSE MANGUEIRA,COMBUSTÍVEL 1
8 2124-1509D2 CLIP GRAMPO 2
9 124-00209D1 CLIP GRAMPO 5
10 S8470014 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 7
11 S0512266 BOLT PARAFUSO,HEX 2
13 K1001029 BOLT PARAFUSO 9
15 DS2105011 HOSE;FUEL MANGUEIRA,COMBUSTÍVEL 1
16 S5102603 WASHER,SPRING ARRUELA,MOLA 2
17 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 2
DX225LCA 1210 - 2
Serial No. ;
FUEL FILLER PUMP
BOMBA DE ALIMENTAÇÃO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION Fig. 1220
1220 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FUEL FILLER PUMP
BOMBA DE ALIMENTAÇÃO DE COMBUSTÍVEL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1220
1220 -- 400909-00073 FUEL FILLER PUMP ASS'Y CONJUNTO DE BOMBA DE ENCHIMENTO- D
1 401-00449 PUMP;FUEL FILLER BOMBA,COMBUSTÍVEL TRANSFERÊNCI1
1A 2181-2755B . ADAPTER . ADAPTADOR1
1B S8180321 . RING;SEAL . ANEL DE SELO 2
1C 181-00809 . ADAPTER . ADAPTADOR 1
1D 181-00810 . ELBOW . COTOVELO;COMBUSTÍVEL BOMBA1
1E 121-00085 . NUT . PORCA 1
1F 407-00001 . VANE KIT . VENTOINHA KIT 1
1G 2401-1276KT . SEAL KIT . SELO KIT;COMBUSTÍVEL TRANSFERÊNCIA1
1H 523-00012 . MOTOR;FUEL TRANS. PUMP . MOTOR,COMBUSTÍVEL BOMBA1
2 195-02662B BRACKET SUPORTE,COMBUSTÍVEL BOMBA1
3 621-02739B COVER TAMPA,COMBUSTÍVEL BOMBA1
4 K1001029 BOLT PARAFUSO 11
5 2114-1058D72 WASHER;PLAIN ARRUELA,PLANÍCIE 2
6 DS0025021 BOLT;SET PARAFUSO 2
7 S8470014 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 1
8 DS2105146 HOSE MANGUEIRA 1
9 2181-2104D6 ADAPTER ADAPTADOR,S 1
10 S8000181 O-RING ANEL,O 1
11 DS2079171 HOSE MANGUEIRA 1
12 185-00167D3 HOSE ASS`Y MANGUEIRA,COMBUSTÍVEL 1
12A 2420-1258 . VALVE;CHECK . VÁLVULA,CHECAR 1
12B 2471-1152 . STRAINER . COADOR;COMBUSTÍVEL BOMBA1
12C 2160-1336 . CAP;STRAINER . CAPA;COADOR 1
13 K1011080 BRACKET SUPORTE 1
14 K1011081 BRACKET SUPORTE 1
15 DS0025019 BOLT;SET PARAFUSO 4
16 S8470032 CLAMP;HOSE BRAÇADEIRA,MANGUEIRA 3
19 190-01172 PLATE;NAME(FUEL PUMP) PLACA,NOME 1
20 124-00208D6 CLIP GRAMPO 2
21 124-00208D5 CLIP GRAMPO 3
22 K1024144 SWITCH;TOGGLE INTERRUPTOR;COMBUSTÍVEL BOMBA1
22-1 549-00093 . SWITCH . INTERRUPTOR,TOGGLE;MIL SPEC1
22-2 530-00214A . HARNESS;JOINT . ARNÊS;COMBUSTÍVEL BOMBA1
DX225LCA 1220 - 2
Serial No. ;
OIL TANK
TANQUE DE ÓLEO
DATE DEC. 21, 2012
1st EDITION Fig. 1230
1230 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL TANK
TANQUE DE ÓLEO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1230
1230 -- 450105-00361 TANK ASSY,OIL TANQUE,ÓLEO - D
1 450105-00362 TANK,OIL TANQUE,ÓLEO 1
2 K1011675A COVER TAMPA 1
3 S8011850 O-RING ANEL,O 1
4 2129-1393 SPRING MOLA 1
5 400504-00131 ELEMENT,FILTER ELEMENTO, FILTRO 1
6 2426-1175 VALVE;BY-PASS VÁLVULA,IGNORAR 1
7 473-00052 COVER TAMPA 1
8 S8011650 O-RING ANEL,O 1
9 K1000269A PIPE;SUCTION TUBO,SUCÇÃO 1
10 2474-9016A FILTER;SUCTION FILTRO,SUCÇÃO 1
11 136-00002 ROD HASTE 1
12 2129-1008 SPRING;COMPRESS MOLA,COMPRESSÃO 1
13 119-00025B GAUGE;LEVEL BITOLA,NÍVEL 1
14 K1012685A BREATHER;AIR RESPIRO,AR 1
14A K9005662 . GASKET . VEDAÇÃO,FLANGE 1
14B K1029257 . ELEMENT;AIR BREATHER . ELEMENTOS 1
15 S8011200 O-RING ANEL,O 1
16 S0565466 BOLT PARAFUSO,HEX 6
17 2114-1813 SHIM CALÇO 3
18 2114-1814 SHIM CALÇO 3
19 114-00425 SPACER ESPAÇADOR 6
20 DS0025024 BOLT;SET PARAFUSO 6
21 400411-00001A STRAINER;BY-PASS COADOR;IGNORAR 1
22 2120-2166D41 BOLT;SOCKET M5X0.8X8 PARAFUSO,HEX SOQUETE 6
23 S8000181 O-RING ANEL,O 1
24 2181-1950D7 PLUG BUJAO 1
25 S4012733 NUT PORCA 1
26 S8000111 O-RING ANEL,O 2
27 2181-1890D2 PLUG BUJAO 2
28 K1003296 SENSOR;HYD OIL TEMP SENSOR,TEMPERATURA;ÓLEO1
29 S0514666 BOLT M12X1.75X16 PARAFUSO,HEX 2
30 S5102703 WASHER;SPRING ARRUELA,MOLA 2
31 K1007957 BOLT;SET PARAFUSO,HEX 12
DX225LCA 1230 - 2
Serial No. ;
OIL COOLER PIPING(1)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (1)
DATE DEC. 21, 2012
1st EDITION Fig. 1240
1240 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL COOLER PIPING(1)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1240
1240 -- 420212-06964 PIPING,OIL COOLER TUBULAÇÕES, REFRIGERADOR DE ÓLEO- D
9 420218-00104A PIPE,SUCTION TUBO,SUCÇÃO 1
16 2185-1737D8 HOSE MANGUEIRA 1
19 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
20 2181-1950D9 PLUG BUJAO,VERIFIQUE NOVAMENTE1
21 2181-1950D3 PLUG BUJAO,VERIFIQUE NOVAMENTE1
22 2181-1126D6 ADAPTER ADAPTADOR 1
23 2181-4133D5 ADAPTER ADAPTADOR 1
25 2181-2627D5 ADAPTER ADAPTADOR,ORIFÍCIO 1
26 2181-1126D115 ADAPTER ADAPTADOR,S 1
27 2181-2294D2 ELBOW COTOVELO 1
31 S8500118 CLAMP;HOSE BRAÇADEIRA,CONSTANTE TORQUE4
35 S2215366 BOLT;SOCKET M12X35 PARAFUSO,HEX SOQUETE 4
37 DS2020128 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO1
41 DS2058331 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO1
42 DS2012070 HOSE MANGUEIRA 1
43 S8000111 O-RING ANEL,O 1
44 S8000181 O-RING ANEL,O 2
45 S8000231 O-RING ANEL,O 1
46 S8000241 O-RING ANEL,O 2
47 S8000291 O-RING ANEL,O 1
48 S8030121 O-RING ANEL,O 4
52 2180-1026D31 O-RING ANEL,O 1
DX225LCA 1240 - 2
Serial No. ;
OIL COOLER PIPING(2)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (2)
DATE DEC. 21, 2012
1st EDITION Fig. 1250
1250 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL COOLER PIPING(2)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1250
1250 -- 420212-06964 PIPING,OIL COOLER TUBULAÇÕES, REFRIGERADOR DE ÓLEO- D
1 420202-00015 PIPE TUBO 1
3 K1036303B PIPE TUBO 1
4 140-01604C PIPE TUBO 1
5 K1036302B PIPE TUBO 1
6 K1036143A PIPE TUBO 1
7 K1036299A PIPE TUBO 1
8 K1000644B PIPE TUBO,SUCÇÃO 1
10 K1044617 PLATE PLACA,FRENTE 1
11 110406-00039 BRACKET SUPORTE 2
12 K1002341 VALVE;BYPASS VÁLVULA,IGNORAR 1
13 K1007197 VALVE;BYPASS VÁLVULA,IGNORAR 1
14 549-00095 SWITCH;PRESSURE INTERRUPTOR,PRESSÃO 1
15 2185-1776D2 HOSE MANGUEIRA 3
17 120-00317 BOLT;U PARAFUSO,U 1
18 2120-1413D12 U-BOLT PARAFUSO,U 4
19 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE3
30 S8500079 CLAMP;HOSE BRAÇADEIRA,CONSTANTE TORQUE12
32 S4012733 NUT PORCA 10
33 S5102703 WASHER;SPRING ARRUELA,MOLA 10
34 2114-1058D72 WASHER;PLAIN ARRUELA,PLANÍCIE 10
35 S2215366 BOLT;SOCKET M12X35 PARAFUSO,HEX SOQUETE 24
36 DS0025018 BOLT;SET PARAFUSO 6
43 S8000111 O-RING ANEL,O 3
49 2180-1026D24 O-RING ANEL,O 1
50 2180-1026D27 O-RING ANEL,O 3
51 2180-1026D28 O-RING ANEL,O 2
52 2180-1026D31 O-RING ANEL,O 1
91 2181-1950D9 PLUG BUJAO,VERIFIQUE NOVAMENTE1
92 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
93 S8000291 O-RING ANEL,O 1
94 S8000111 O-RING ANEL,O 1
DX225LCA 1250 - 2
Serial No. ;
OIL COOLER PIPING(3)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (3)
DATE DEC. 21, 2012
1st EDITION Fig. 1260
1260 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
OIL COOLER PIPING(3)
BOMBA DE REFRIGERAÇÃO DE ÓLEO (3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1260
1260 -- 420212-06964 PIPING,OIL COOLER TUBULAÇÕES, REFRIGERADOR DE ÓLEO- D
2 140-02009A PIPE TUBO 1
22 2181-1126D6 ADAPTER ADAPTADOR 1
24 DS2213167 ADAPTER ADAPTADOR 1
28 2181-1702D73 ELBOW COTOVELO 1
29 2181-1951D5 TEE T 1
35 S2215366 BOLT;SOCKET M12X35 PARAFUSO,HEX SOQUETE 4
38 2184-1036D293 HOSE PF1/2-600L MANGUEIRA 1
39 DS20551024 HOSE MANGUEIRA,ÓLEO 1
40 DS2055976 HOSE MANGUEIRA 1
44 S8000181 O-RING ANEL,O 3
47 S8000291 O-RING ANEL,O 1
49 2180-1026D24 O-RING ANEL,O 1
DX225LCA 1260 - 2
Serial No. ;
ENGINE CONTROL
CONTROLE DE MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 1270
1270 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ENGINE CONTROL
CONTROLE DE MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1270
1270 -- K1046113A ENGINE CONTROL ASS'Y CONTROLE DE MOTOR ASS ' Y- D
1 2197-1777A BRACKET SUPORTE 1
2 S0711866 BOLT PARAFUSO,HEX 2
3 S5102603 WASHER,SPRING ARRUELA,MOLA 2
4 S0504566 BOLT M6X1.0X14 PARAFUSO,HEX 3
5 S5102303 WASHER;SPRING ARRUELA,MOLA 2
6 2150-1122 HOOK;CABLE ANZOL,CABO 1
7 133-00172 LEVER ALAVANCA1
8 S4012533 NUT PORCA,HEX 3
9 S5102503 WASHER,SPRING ARRUELA,MOLA 9
10 195-02079 BRACKET SUPORTE 1
12 300513-00006 MOTOR,ENGINE CONTROL MOTOR,ENGINE CONTROLE 1
13 2523-9016 MOTOR;E/G STOP MOTOR,PARE 1
14 159-00227 COVER PLACA,TAMPA 1
15 S0508966 BOLT PARAFUSO,HEX 6
16 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 2
18 160-00040 BUSHING;RUBBER BUCHA,BORRACHA 1
19 2197-1802A BRACKET SUPORTE 1
20 K1001029 BOLT PARAFUSO 3
21 2124-1509D10 CLIP GRAMPO 2
22 DS0025019 BOLT;SET PARAFUSO 4
25 2124-1509D1 CLIP GRAMPO 1
28 195-02157 BRACKET SUPORTE 1
29 S0509366 BOLT PARAFUSO,HEX 2
30 120810-00145 WASHER,PLAIN ARRUELA,PLANÍCIE 1
71 K1007835 CABLE;CONTROL CABO,ENGINE CONTROLE 1
72 K1003118 BRACKET SUPORTE 1
73 2138-9006B JOINT;BALL LIGAÇÃO,BOLA 1
74 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 2
75 2120-2166D5 BOLT PARAFUSO,HEX 2
76 S4012233 NUT PORCA 1
77 S5102203 WASHER;SPRING ARRUELA,MOLA 1
DX225LCA 1270 - 2
Serial No. ;
MAIN PIPING(1) - PUMP
TUBULAÇÃO PRINCIPAL(1) - BOMBA
DATE DEC. 21, 2012
1st EDITION Fig. 1280
1280 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING(1) - PUMP
TUBULAÇÃO PRINCIPAL(1) - BOMBA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1280
1280 -- 420212-06958 PIPING,MAIN TUBULAÇÃO, PRINCIPAL - D
1 K1025391 VALVE;CONTROL VÁLVULA,CONTROLE 1
2 140-01484B PIPE TUBO 1
3 140-01485B PIPE TUBO 1
9 K1006396B BLOCK BLOCO 1
10 K1007164B BLOCK BLOCO 1
11 161-00281 RUBBER BORRACHA;1" TUBO 2
14 124-00218 CLAMP BRAÇADEIRA,TUBO 4
15 K1048145 SENSOR;PRESSURE SENSOR,PRESSÃO 2
16 2181-9081 FLANGE;SPLIT FLANGE,CISÃO 8
17 2181-9078 FLANGE FLANGE 4
20 2181-2218D6 PLUG BUJAO 2
21 2181-1950D9 PLUG BUJAO,VERIFIQUE NOVAMENTE1
22 DS2242029 REDUCER ADAPTADOR 2
25 114-00425 SPACER ESPAÇADOR 4
28 S5102803 WASHER;SPRING ARRUELA,MOLA 4
31 S0562766 BOLT PARAFUSO,HEX 4
32 S0565466 BOLT PARAFUSO,HEX 4
33 S2215466 BOLT;SOCKET M12X1.75X40 PARAFUSO,HEX SOQUETE 8
35 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 8
36 S2215766 BOLT;SOCKET M12X55 PARAFUSO,HEX SOQUETE 8
38 S2217066 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
43 DS2018100 HOSE MANGUEIRA 2
44 DS2097013 HOSE MANGUEIRA,ÓLEO 1
45 DS2097014 HOSE MANGUEIRA,ÓLEO 1
55 2180-1026D19 O-RING ANEL,O 10
58 S8030161 O-RING ANEL,O 2
59 S8000291 O-RING ANEL,O 1
60 S8000141 O-RING ANEL,O 2
DX225LCA 1280 - 2
Serial No. ;
MAIN PIPING(2) - BOOM
TUBULAÇÃO PRINCIPAL(2) - LANÇA
DATE DEC. 21, 2012
1st EDITION Fig. 1290
1290 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING(2) - BOOM
TUBULAÇÃO PRINCIPAL(2) - LANÇA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1290
1290 -- 420212-06958 PIPING,MAIN TUBULAÇÃO, PRINCIPAL - D
4 140-01601C PIPE;BOOM UP TUBO;LANÇA SUPERIOR 1
5 140-01602C PIPE;BOOM DOWN TUBO 1
6 195-02883B PLATE SUPORTE 1
7 195-02884B PLATE SUPORTE 1
12 2124-1025D6 CLAMP;PIPE BRAÇADEIRA,TUBO 1
13 2124-1025D5 CLAMP;PIPE BRAÇADEIRA,TUBO 1
18 2181-9079 FLANGE FLANGE 16
26 S5102703 WASHER;SPRING ARRUELA,MOLA 2
27 S5010713 WASHER;PLAIN ARRUELA,PLANÍCIE 1
29 DS0025020 BOLT;SET PARAFUSO 4
30 S0561066 BOLT M12X1.75X65 PARAFUSO,HEX 1
34 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 24
35 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
41 DS2038222 HOSE MANGUEIRA 2
42 DS2038144 HOSE MANGUEIRA 2
54 2180-1026D2 O-RING ANEL,O 8
55 2180-1026D19 O-RING ANEL,O 2
61 S0560866 BOLT;SET PARAFUSO,HEX 1
DX225LCA 1290 - 2
Serial No. ;
MAIN PIPING(3) - ARM, BUCKET
TUBULAÇÃO PRINCIPAL(3) - BRAÇO DA PÁ
DATE DEC. 21, 2012
1st EDITION Fig. 1300
1300 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING(3) - ARM, BUCKET
TUBULAÇÃO PRINCIPAL(3) - BRAÇO DA PÁ
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1300
1300 -- 420212-06958 PIPING,MAIN TUBULAÇÃO, PRINCIPAL - D
17 2181-9078 FLANGE FLANGE 6
19 2181-9083 FLANGE;SPLIT FLANGE,CISÃO 3
35 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
50 DS2040683 HOSE MANGUEIRA 1
51 DS2040684 HOSE MANGUEIRA 1
52 DS2040685 HOSE MANGUEIRA 1
53 DS2040686 HOSE MANGUEIRA 1
55 2180-1026D19 O-RING ANEL,O 4
DX225LCA 1300 - 2
Serial No. ;
MAIN PIPING(4) - SWING
TUBULAÇÃO PRINCIPAL(4) - BALANÇO
DATE DEC. 21, 2012
1st EDITION Fig. 1310
1310 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING(4) - SWING
TUBULAÇÃO PRINCIPAL(4) - BALANÇO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1310
1310 -- 420212-06958 PIPING,MAIN TUBULAÇÃO, PRINCIPAL - D
8 423-00202 BLOCK BLOCO 2
17 2181-9078 FLANGE FLANGE 3
18 2181-9079 FLANGE FLANGE 4
19 2181-9083 FLANGE;SPLIT FLANGE,CISÃO 1
35 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
37 S2213166 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
39 DS2045337 HOSE MANGUEIRA 1
40 DS2045338 HOSE MANGUEIRA 1
54 2180-1026D2 O-RING ANEL,O 4
55 2180-1026D19 O-RING ANEL,O 2
DX225LCA 1310 - 2
Serial No. ;
MAIN PIPING(5) - CENTER JOINT
TUBULAÇÃO PRINCIPAL(5) - JUNTA CENTRAL
DATE DEC. 21, 2012
1st EDITION Fig. 1320
1320 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING(5) - CENTER JOINT
TUBULAÇÃO PRINCIPAL(5) - JUNTA CENTRAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1320
1320 -- 420212-06958 PIPING,MAIN TUBULAÇÃO, PRINCIPAL - D
17 2181-9078 FLANGE FLANGE 8
23 2181-2627D1 ADAPTER ADAPTADOR,ORIFÍCIO 2
24 2181-2627D3 ADAPTER ADAPTADOR,ORIFÍCIO 2
35 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
46 DS2026146 HOSE MANGUEIRA 1
47 DS2026129 HOSE MANGUEIRA 1
48 DS2026145 HOSE MANGUEIRA 1
49 DS2026127 HOSE MANGUEIRA 1
55 2180-1026D19 O-RING ANEL,O 4
56 S8030121 O-RING ANEL,O 4
57 S8000231 O-RING ANEL,O 4
DX225LCA 1320 - 2
Serial No. ;
PILOT PIPING(1)
TUBULAÇÃO PILOTO(1)
DATE DEC. 21, 2012
1st EDITION Fig. 1330
1330 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(1)
TUBULAÇÃO PILOTO(1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1330
1330 -- 420212-06961 PIPING,PILOT TUBULAÇÃO, PILOTO - D
1 471-00075A FILTER;PILOT FILTRO,PILOTO 1
1A - . HEAD . CABEÇA 1 D
1B 2472-7003 . CASE . CASO 1
1C 2471-1154 . ELEMENT;FILTER(PILOT) . ELEMENTOS;PILOTO FILTRO1
1D 2426-1237 . VALVE;BY-PASS . VÁLVULA,IGNORAR 1
1E 2471-1155A . INDICATOR . INDICADOR 1
1F Y-3738-04 . O-RING . ANEL,BACKUP 1
1G Y-3738-05 . RING;BACK UP . ANEL,O 1
1H 530-00236 . HARNESS;PILOT FILTER . ARNÊS 1
1I 2197-1661 . BRACKET . SUPORTE,HABITAÇÃO 1
1J S0508653 . BOLT . PARAFUSO,HEX 1
1K S5102503 . WASHER,SPRING . ARRUELA,MOLA 1
4 195-02716C BRACKET;FILTER SUPORTE,FILTRO;PILOTO FILTRO1
5 198-00016 RUBBER BORRACHA 2
7 124-00208D3 CLIP GRAMPO 1
11 124-00208D6 CLIP GRAMPO 1
17 2181-1126D6 ADAPTER ADAPTADOR 1
19 2181-1126D14 ADAPTER ADAPTADOR,S 3
26 2181-1702D4 ELBOW COTOVELO 1
27 2181-1702D2 ELBOW COTOVELO 1
31 2181-1951D6 TEE T 1
36 S5102303 WASHER;SPRING ARRUELA,MOLA 2
37 2114-1058D10 WASHER ARRUELA,PLANÍCIE 2
40 S0553766 BOLT PARAFUSO,HEX 2
41 S0512266 BOLT PARAFUSO,HEX 2
42 K1001029 BOLT PARAFUSO 2
58 DS2094053 HOSE MANGUEIRA 1
62 2184-1046D94 HOSE PF1/4-780LMANGUEIRA 1
63 2184-1046D120 HOSE PF1/4-1950L MANGUEIRA 1
64 DS2093003 HOSE PF3/8-1350L MANGUEIRA 1
65 DS2054133 HOSE MANGUEIRA 1
72 S8000141 O-RING ANEL,O 1
73 S8000111 O-RING ANEL,O 2
74 S8000181 O-RING ANEL,O 2
DX225LCA 1330 - 2
Serial No. ;
PILOT PIPING(2)
TUBULAÇÃO PILOTO(2)
DATE DEC. 21, 2012
1st EDITION Fig. 1340
1340 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(2)
TUBULAÇÃO PILOTO(2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1340
1340 -- 420212-06961 PIPING,PILOT TUBULAÇÃO, PILOTO - D
2 2460-9057A ACCUMULATOR ACUMULADOR;PILOTO 1
3 K1039014A BRACKET SUPORTE 1
8 124-00208D7 CLIP GRAMPO 4
9 124-00208D9 CLIP GRAMPO 1
17 2181-1126D6 ADAPTER ADAPTADOR 1
19 2181-1126D14 ADAPTER ADAPTADOR,S 4
21 2181-1126D38 ADAPTER ADAPTADOR 1
26 2181-1702D4 ELBOW COTOVELO 4
30 K1038032 TEE T,FILTRO 1
34 2181-1951D19 TEE T 1
35 S5110503 WASHER;SPRING ARRUELA,MOLA 2
38 DS0025017 BOLT PARAFUSO 4
39 S2209666 BOLT;SOCKET PARAFUSO,HEX SOQUETE 2
42 K1001029 BOLT PARAFUSO 5
43 2184-1060D70 HOSE PF1/2-1700L MANGUEIRA 1
56 DS2093193 HOSE MANGUEIRA 1
59 DS2093080 HOSE MANGUEIRA 1
60 DS2093212 HOSE MANGUEIRA 1
61 DS2093017 HOSE MANGUEIRA 1
71 DS2093034 HOSE MANGUEIRA 1
73 S8000111 O-RING ANEL,O 10
74 S8000181 O-RING ANEL,O 3
131 K1047557 VALVE;SOLENOID VÁLVULA,SOLENÓIDE 1
132 2184-1046D187 HOSE PF1/4-2600L MANGUEIRA 1
133 2181-1126D14 ADAPTER ADAPTADOR,S 1
134 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
135 S8000111 O-RING ANEL,O 2
DX225LCA 1340 - 2
Serial No. ;
PILOT PIPING(3)
TUBULAÇÃO PILOTO(3)
DATE DEC. 21, 2012
1st EDITION Fig. 1350
1350 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(3)
TUBULAÇÃO PILOTO(3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1350
1350 -- 420212-06961 PIPING,PILOT TUBULAÇÃO, PILOTO - D
6 2549-9112 SWITCH;PRESSURE INTERRUPTOR,PRESSÃO 2
12 2181-1951D1 TEE T 1
13 2181-1950D2 PLUG BUJAO,VERIFIQUE NOVAMENTE2
14 430223-00011A REDUCER REDUTOR 2
16 2181-2635 TEE ADAPTADOR 1
18 2181-1126D7 ADAPTER ADAPTADOR 2
23 181-00144D5 ADAPTER ADAPTADOR,ORIFÍCIO 2
24 2181-1702D3 ELBOW PFO1/4XPF3/8 COTOVELO 1
26 2181-1702D4 ELBOW COTOVELO 1
32 2181-1951D16 TEE T 2
38 DS0025017 BOLT PARAFUSO 2
44 DS2093155 HOSE MANGUEIRA 1
45 DS2093184 HOSE MANGUEIRA 1
46 DS2093178 HOSE MANGUEIRA 1
47 DS2093134 HOSE MANGUEIRA 2
48 DS2093174 HOSE MANGUEIRA 1
49 DS2093175 HOSE MANGUEIRA 1
55 DS2093090 HOSE MANGUEIRA 1
72 S8000141 O-RING ANEL,O 8
73 S8000111 O-RING ANEL,O 7
177 430216-00004 JOINT PLATE SUB ASS`Y LIGAÇÃO SUB CONJ;PILOTO LIGAÇÃO PL1
177-1 K1000354 . BRACKET;JOINT . PLACA 1
177-2 181-00078D1 . ADAPTER . ADAPTADOR 1
177-3 121-00010D1 . NUT . PORCA 8
177-4 420-00352D1 . VALVE;SHOCKLESS . VÁLVULA,SEM CHOQUE 1
177-5 DS2410009 . ADAPTER . ADAPTADOR 3
177-6 181-00086D1 . TEE . T 1
177-7 181-00086D2 . TEE . T 2
DX225LCA 1350 - 2
Serial No. ;
PILOT PIPING(4)
TUBULAÇÃO PILOTO(4)
DATE DEC. 21, 2012
1st EDITION Fig. 1360
1360 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(4)
TUBULAÇÃO PILOTO(4)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1360
1360 -- 420212-06961 PIPING,PILOT TUBULAÇÃO, PILOTO - D
10 124-00208D8 CLIP GRAMPO 1
15 K1003664D1 VALVE;SHOCKLESS VÁLVULA,SEM CHOQUE 1
18 2181-1126D7 ADAPTER ADAPTADOR 2
24 2181-1702D3 ELBOW PFO1/4XPF3/8 COTOVELO 1
26 2181-1702D4 ELBOW COTOVELO 1
32 2181-1951D16 TEE T 1
42 K1001029 BOLT PARAFUSO 1
46 DS2093178 HOSE MANGUEIRA 1
50 DS2093139 HOSE MANGUEIRA,ÓLEO 1
51 DS2093222 HOSE MANGUEIRA 1
52 DS2093022 HOSE MANGUEIRA 1
53 DS2093173 HOSE MANGUEIRA 1
54 DS2093026 HOSE MANGUEIRA 1
72 S8000141 O-RING ANEL,O 4
73 S8000111 O-RING ANEL,O 2
DX225LCA 1360 - 2
Serial No. ;
PILOT PIPING(5)
TUBULAÇÃO PILOTO(5)
DATE DEC. 21, 2012
1st EDITION Fig. 1370
1370 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(5)
TUBULAÇÃO PILOTO(5)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1370
1370 -- 420212-06961 PIPING,PILOT TUBULAÇÃO, PILOTO - D
17 2181-1126D6 ADAPTER ADAPTADOR 1
18 2181-1126D7 ADAPTER ADAPTADOR 4
19 2181-1126D14 ADAPTER ADAPTADOR,S 2
20 2181-1126D27 ADAPTER ADAPTADOR 1
22 2181-1126D103 ADAPTER ADAPTADOR 1
25 2181-1702D10 ELBOW COTOVELO 4
28 2181-1702D34 ELBOW COTOVELO 1
29 2181-1702D9 ELBOW COTOVELO 1
31 2181-1951D6 TEE T 1
33 2181-2281D21 TEE T 1
57 DS2094004 HOSE MANGUEIRA 1
66 DS2094055 HOSE MANGUEIRA 1
67 DS2093185 HOSE MANGUEIRA 1
68 DS2093130 HOSE MANGUEIRA 1
69 DS2094037 HOSE MANGUEIRA 1
70 DS2093030 HOSE MANGUEIRA 1
72 S8000141 O-RING ANEL,O 10
73 S8000111 O-RING ANEL,O 4
74 S8000181 O-RING ANEL,O 3
DX225LCA 1370 - 2
Serial No. ;
PILOT PIPING(6)
TUBULAÇÃO PILOTO(6)
DATE DEC. 21, 2012
1st EDITION Fig. 1380
1380 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(6)
TUBULAÇÃO PILOTO(6)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1380
1380 -- 420212-06965 PIPING,PILOT TUBULAÇÃO, PILOTO - D
1 410113-00022A VALVE,JOYSTICK(L.H) VÁLVULA,JOYSTICK;L.H 1
10 K1003945 PROTECTOR PROTETOR 1
12 430201-00113 ADAPTER,FILTER ADAPTADOR,FILTRO 1
13 DS2213165 ADAPTER ADAPTADOR 2
14 2181-1126D27 ADAPTER ADAPTADOR 2
15 2181-1126D28 ADAPTER ADAPTADOR 1
17 2181-1126D7 ADAPTER ADAPTADOR 1
18 2181-1126D36 ADAPTER ADAPTADOR 1
20 2181-1702D5 ELBOW COTOVELO 1
28 S2205066 BOLT;SOCKET M6X1.0X25 PARAFUSO,HEX SOQUETE 4
30 DS2094006 HOSE MANGUEIRA 1
32 DS2095003 HOSE MANGUEIRA 1
33 DS2095001 HOSE MANGUEIRA 4
35 DS2095004 HOSE MANGUEIRA 1
40 S8000141 O-RING ANEL,O 9
DX225LCA 1380 - 2
Serial No. ;
PILOT PIPING(7)
TUBULAÇÃO PILOTO(7)
DATE DEC. 21, 2012
1st EDITION Fig. 1390
1390 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(7)
TUBULAÇÃO PILOTO(7)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1390
1390 -- 420212-06965 PIPING,PILOT TUBULAÇÃO, PILOTO - D
2 410113-00021A VALVE,JOYSTICK(R.H) VÁLVULA,JOYSTICK;R.H 1
10 K1003945 PROTECTOR PROTETOR 1
12 430201-00113 ADAPTER,FILTER ADAPTADOR,FILTRO 1
13 DS2213165 ADAPTER ADAPTADOR 2
14 2181-1126D27 ADAPTER ADAPTADOR 2
15 2181-1126D28 ADAPTER ADAPTADOR 1
17 2181-1126D7 ADAPTER ADAPTADOR 1
20 2181-1702D5 ELBOW COTOVELO 1
28 S2205066 BOLT;SOCKET M6X1.0X25 PARAFUSO,HEX SOQUETE 4
32 DS2095003 HOSE MANGUEIRA 1
33 DS2095001 HOSE MANGUEIRA 4
34 DS2095002 HOSE PF3/8-1750L MANGUEIRA 1
40 S8000141 O-RING ANEL,O 8
DX225LCA 1390 - 2
Serial No. ;
PILOT PIPING(8)
TUBULAÇÃO PILOTO(8)
DATE DEC. 21, 2012
1st EDITION Fig. 1400
1400 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING(8)
TUBULAÇÃO PILOTO(8)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1400
1400 -- 420212-06965 PIPING,PILOT TUBULAÇÃO, PILOTO - D
3 420-00467A VALVE;PEDAL VÁLVULA,PEDAL 1
4 2423-1470 BLOCK BLOCO 2
5 621-02151 PLATE PLACA 1
6 198-00016 RUBBER BORRACHA 2
7 124-00209D2 CLIP GRAMPO 1
8 124-00209D3 CLIP GRAMPO 2
9 124-00209D8 CLIP GRAMPO1
11 2471-1135 FILTER;ADAPTER ADAPTADOR,FILTRO 1
16 2181-1126D14 ADAPTER ADAPTADOR,S 6
18 2181-1126D36 ADAPTER ADAPTADOR 1
19 2181-1126D6 ADAPTER ADAPTADOR 1
21 2114-2031D5 WASHER;SPRING ARRUELA,MOLA 4
22 2114-1058D10 WASHER ARRUELA,PLANÍCIE 2
23 S0558666 BOLT PARAFUSO,HEX 2
24 S0512266 BOLT PARAFUSO,HEX 2
25 K1001029 BOLT PARAFUSO 4
26 S0558766 BOLT PARAFUSO,HEX 2
27 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 4
29 DS2054356 HOSE MANGUEIRA 1
30 DS2094006 HOSE MANGUEIRA 1
31 DS2053833 HOSE MANGUEIRA 1
36 DS2093189 HOSE MANGUEIRA 1
37 DS2093191 HOSE PF1/4-2880L MANGUEIRA 1
38 DS2093190 HOSE MANGUEIRA 1
39 DS2093192 HOSE MANGUEIRA 1
40 S8000141 O-RING ANEL,O 1
41 S8000181 O-RING ANEL,O 2
42 S8000111 O-RING ANEL,O 6
DX225LCA 1400 - 2
Serial No. ;
CONTROL STAND - L.H.
CONSOLE DE CONTROLE - L.H.
DATE DEC. 21, 2012
1st EDITION Fig. 1410
1410 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL STAND - L.H.
CONSOLE DE CONTROLE - L.H.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1410
1410 -- 220111-00022 STAND ASSY,CONTROL CARRINHO ASSY, CONTROLE- D
1 195-02753C BRACKET;STAND LH SUPORTE,LEVANTE 1
2 621-02901B COVER;STAND LH LOWER TAMPA,LEVANTE;LH,BAIXAR 1
3 220204-00099 COVER,STAND TAMPA,LEVANTE 1
4 621-03014B COVER;STAND LOW TAMPA,LEVANTE 1
5 195-02868C BRACKET;SAFETY SUPORTE CONJ;SEGURANÇA1
5A 549-00089 . SWITCH;MICRO . INTERRUPTOR;MICRO 1
6 621-02957B PLATE;STAND MOUNT PLACA;LEVANTE MONTAGEM1
9 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO3
10 2120-2166D10 SCREW ROSCA 10
11 K1001023 STRIP;WEATHER TIRA,TEMPO 1
12 621-03733C COVER TAMPA 1
13 K1000840 LEVER ALAVANCA 1
14 K1000842A COVER TAMPA 1
15 S3450823 SCREW ROSCA 2
16 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 2
17 621-02801 COVER;SWITCH TAMPA,INTERRUPTOR 8
18 S2202966 BOLT;SOCKET PARAFUSO,HEX SOQUETE 1
19 2114-1898D4 WASHER ARRUELA,PLANÍCIE 1
20 K1010466 FOAM ESPUMA 2
DX225LCA 1410 - 2
Serial No. ;
CONTROL STAND - R.H.
CONSOLE DE CONTROLE - R.H.
DATE DEC. 21, 2012
1st EDITION Fig. 1420
1420 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL STAND - R.H.
CONSOLE DE CONTROLE - R.H.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1420
1420 -- 220111-00023 STAND ASSY,CONTROL CARRINHO ASSY, CONTROLE- D
1 195-02755C BRACKET;R.H. SUPORTE,LEVANTE 1
2 621-02926E COVER;SWITCH TAMPA,INTERRUPTOR 1
3 621-02900B COVER;STAND LOWER TAMPA,LEVANTE;RH,BAIXAR 1
4 220204-00100 COVER,STAND TAMPA,LEVANTE 1
5 621-03014B COVER;STAND LOW TAMPA,LEVANTE 1
6 621-02957B PLATE;STAND MOUNT PLACA;LEVANTE MONTAGEM1
10 2120-2166D10 SCREW ROSCA 10
11 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 2
12 K1001023 STRIP;WEATHER TIRA,TEMPO 1
13 621-03733C COVER TAMPA 1
14 621-02801 COVER;SWITCH TAMPA,INTERRUPTOR 2
15 K1006995 CAP CAPA 1
16 K1010466 FOAM ESPUMA 2
DX225LCA 1420 - 2
Serial No. ;
SEAT SLIDING PLATE
CORREDIÇA DE ASSENTO
DATE DEC. 21, 2012
1st EDITION Fig. 1430
1430 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SEAT SLIDING PLATE
CORREDIÇA DE ASSENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1430
1430 -- K1052181 SEAT PLATE ASS'Y PLACA CONJ,LUGAR - D
1 621-03011E SEAT PLATE ASS'Y PLACA CONJ,LUGAR 1
1-1 621-02895C . PLATE;SEAT MOUNT . PLACA,LUGAR 1
1-2 195-02904C . STAND TILT BRACKET ASS'Y . SUPORTE CONJ,LEVANTE;INCLINAÇÃO1
1-3 2120-2166D5 . BOLT . PARAFUSO,HEX 8
1-4 621-02925A . PLATE . PLACA 2
1-5 2114-1898D14 . WASHER;PLAIN . ARRUELA,PLANÍCIE 8
2 123-00524B PIN;TILT STAND PINO;INCLINAÇÃO LEVANTE 2
3 K1040096 RAIL TRILHO 1
4 621-03005A PLATE PLACA 2
5 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 8
6 2114-2031D4 WASHER;SPRING ARRUELA,MOLA 4
7 2121-1311D2 NUT PORCA 4
8 2114-1898D17 WASHER M12 ARRUELA,PLANÍCIE 2
9 2121-1311D1 NUT PORCA 4
10 2120-2166D5 BOLT PARAFUSO,HEX 4
11 2114-1898D18 WASHER ARRUELA,PLANÍCIE 2
12 S2208866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
13 114-00590 WASHER ARRUELA 2
DX225LCA 1430 - 2
Serial No. ;
SEAT PLATE
PLACA DE ASSENTO
DATE DEC. 21, 2012
1st EDITION Fig. 1440
1440 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SEAT PLATE
PLACA DE ASSENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1440
1440 -- K1002229A SEAT PLATE PLACA CONJ,LUGAR;BASE ALTA- D
1 K1002230A BRACKET;SEAT LOWER PLACA 1
2 K1002231A PLATE;COVER PLACA 1
3 2120-2166D10 SCREW ROSCA 4
4 2114-1898D15 WASHER;PLAIN ARRUELA,PLANÍCIE 4
5 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO4
DX225LCA 1440 - 2
Serial No. ;
SEAT MOUNTING
Suporte DE ASSENTO
DATE DEC. 21, 2012
1st EDITION Fig. 1450
1450 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SEAT MOUNTING
Suporte DE ASSENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1450
1450 -- 220110-00086A SEAT ASSY,OPERATER LUGAR - D
1 220110-00087A SEAT,OPERATOR LUGAR 1
2 S2208866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
DX225LCA 1450 - 2
Serial No. ;
SEAT
ASSENTO
DATE DEC. 21, 2012
1st EDITION Fig. 1460
1460 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SEAT
ASSENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1460
1460 -- 220110-00087A SEAT,OPERATOR LUGAR 1
4 430205-00038 BELLOWS FOLES 1
11 220106-00040 REST,ARM;R.H REST,BRAÇO;DIREITO 1
16 220108-00012 REST,HEAD REST,CABEÇA 1
18 220106-00041 REST,ARM;L.H REST,BRAÇO;ESQUERDA 1
23 220213-00023 BELT,SEAT CINTO 1
29 190112-00021 SUSPENSION SUSPENSÃO 1
30 110925-00241 HANDLE;WEIGHT ADJ PUNHO;AJUSTE DE PESO 1
DX225LCA 1460 - 2
Serial No. ;
DUCT COVER
TAMPA DO DUTO
DATE DEC. 21, 2012
1st EDITION Fig. 1470
1470 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DUCT COVER
TAMPA DO DUTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1470
1470 -- 110517-00370 COVER ASSY,SIDE TAMPA - D
1 621-02903C COVER;SIDE FRONT TAMPA,LATERAL;FRENTE 1
2 110517-00364 COVER,SIDE;MID UPPER TAMPA,LATERAL;MÉDIA SUPERIOR1
3 621-02904C COVER;SIDE MID LOWER TAMPA,LATERAL;MÉDIA BAIXAR1
4 621-02909G COVER;SWITCH TAMPA,INTERRUPTOR 1
5 906-00002A ASHTRAY ASM CINZEIRO 1
6 621-02908B HOLDER;CUP TITULAR,COPO 1
7 213-00035B DUCT;DEFROSTER SIDE DUTO,DESEMBAÇADOR;LATERAL1
8 213-00030B DUCT;FACE MID DUTO,MÉDIA 1
9 213-00031E DUCT;FACE REAR DUTO,ROSTO;TRASEIRA 1
10 213-00032B DUCT;DEFROSTER FRONT DUTO,DESEMBAÇADOR;FRENTE1
11 213-00033B DUCT;DEFROSTER MID DUTO,DESEMBAÇADOR;MÉDIA1
12 213-00034E DUCT;DEFROSTER REAR DUTO,DESEMBAÇADOR;TRASEIRA1
13 213-00029C DUCT;FACE FRONT DUTO,FRENTE 1
14 195-02768E BRACKET;SWITCH TAMPA,SUPORTE;INTERRUPTOR TAMPA FR1
15 195-02769E BRACKET;SWITCH SUPORTE;INTERRUPTOR TAMPA TRASEIRA1
16 415-00046B LOUVER DEF SIDE TRAPEIRA;LATERAL 1
17 415-00045B LOUVER DEF FRONT TRAPEIRA;FRENTE 1
18 195-02770E BRACKET;CUP SUPORTE;COPO TITULAR 1
19 415-00044B LOUVER FACE TRAPEIRA;ROSTO 1
20 K1001068 FOAM ESPUMA 1
21 K1048689 FOAM ESPUMA 1
22 K1039212C PLATE PLACA,FRENTE 1
23 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 22
24 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO4
25 S3654523 SCREW ROSCA 4
26 2120-2166D23 SCREW ROSCA 3
27 621-02801 COVER;SWITCHTAMPA,INTERRUPTOR 3
28 621-03734A COVER TAMPA;FURO 6
30 K1005007A PLATE PLACA 1
31 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 3
32 2120-2166D5 BOLT PARAFUSO,HEX 3
33 2114-2031D4 WASHER;SPRING ARRUELA,MOLA 3
34 K1009627 PLATE PLACA 1
35 2120-2166D36 BOLT PARAFUSO,HEX 4
36 2114-1898D5 WASHER M6 ARRUELA,PLANÍCIE 4
37 K1010304 BOLT;FLANGE PARAFUSO,HEX;FLANGE 8
38 2120-2166D57 BOLT;GREEN PARAFUSO,HEX;VERDE PARAFUSO2
DX225LCA 1470 - 2
Serial No. ;
DUCT COVER
TAMPA DO DUTO
DATE DEC. 21, 2012
1st EDITION Fig. 1470
1470 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DUCT COVER
TAMPA DO DUTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1470
1470 -39 110910-00265 CAP CAPA 1
DX225LCA 1470 - 4
Serial No. ;
HEATER COVER
TAMPA DO AQUECEDOR
DATE DEC. 21, 2012
1st EDITION Fig. 1480
1480 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
HEATER COVER
TAMPA DO AQUECEDOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1480
1480 -- 650103-00002A REAR ASSY;COVER TRASEIRA ASSY;CAPA - D
1 621-02894G COVER;REAR LOWER TAMPA;TRASEIRA BAIXAR 1
2 460103-00039 DUCT,FOOT DUTO,PE 1
3 213-00037B DUCT;REAR(L.H.) DUTO,TRASEIRA;LH 1
4 213-00038B DUCT;REAR(R.H.) DUTO,TRASEIRA;RH 1
5 213-00039B DUCT;AIR INLET DUTO,AR ENTRADA 1
6 415-00043B NOZZLE;REAR TRAPEIRA;TRASEIRA 2
7 621-02913C COVER;REAR(L.H.) TAMPA;TRASEIRA 1
8 621-02914C COVER;REAR(R.H.) TAMPA;TRASEIRA 1
9 621-02915B COVER;REAR CENTER TAMPA;TRASEIRA CENTRAL 1
10 621-02907B COVER;SIDE REAR(L.H.) TAMPA,LATERAL;TRASEIRA 1
11 621-02917C COVER;STEREO UP TAMPA;ESTÉREO 1
12 K1001295B PLATE PLACA 1
13 621-02919B COVER;FUSE TAMPA;FUSÍVEL 1
14 195-02771C BRACKET;FUSE BOX SUPORTE 1
15 110406-02099 BRACKET;STEREO SUPORTE 1
16 2125-1095A CATCH;MAGNETIC PEGADOR;MAGNETICO 1
17 K1005344A COVER TAMPA 1
18 K1005345A COVER;HOLE TAMPA 1
19 621-02920C COVER;BOX TAMPA;CAIXA 1
20 K1001310 FOAM ESPUMA 4
21 213-00040A DUCT;AIR BOX DUTO,AR CAIXA 1
22 195-02774A BRACKET;AIR DUCT MOUNT SUPORTE,MONTAGEM;AR DUTO1
23 161-00622 FOAM;AIR SEAL ESPUMA 1
24 195-02785E BRACKET;CROSS BAR SUPORTE 1
26 2120-2166D10 SCREW ROSCA 19
27 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO2
28 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 5
29 2120-2166D12 BOLT;HEX PARAFUSO 3
30 2120-2166D36 BOLT PARAFUSO,HEX 19
31 2114-1898D5 WASHER M6 ARRUELA,PLANÍCIE 19
32 S3644163 SCREW ROSCA,CÍRIO 4
33 K1002385 STOPPER ROLHA 2
34 161-00624 PAD;FOAM ALMOFADA;ESPUMA 1
35 2120-2166D5 BOLT PARAFUSO,HEX 2
36 2120-2166D58 BOLT PARAFUSO,HEX;VERDE PARAFUSO1
38 K1043726 NOZZLE;REAR TRAPEIRA 2
DX225LCA 1480 - 2
Serial No. ;
CABIN MOUNTING
Suporte DE CABINE
DATE DEC. 21, 2012
1st EDITION Fig. 1490
1490 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN MOUNTING
Suporte DE CABINE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1490
1490 -- 160626-00058 MOUNT ASSY,CABIN MONTAGEM DE CABINE ASSY- D
1 161-00010 RUBBER;MOUNT(FRONT) BORRACHA,CABINE MONTAGEM;FRENTE2
2 161-00011 RUBBER;MOUNT(REAR) BORRACHA,CABINE MONTAGEM;TRASEIRA2
4 2114-1058D2 WAHSER ARRUELA,PLANÍCIE 4
5 2121-9007 NUT PORCA 4
6 2120-2166D2 BOLT PARAFUSO,HEX 16
7 2114-1898D1 WASHER ARRUELA,PLANÍCIE 16
DX225LCA 1490 - 2
Serial No. ;
CABIN(1)
CABINE(1)
DATE DEC. 21, 2012
1st EDITION Fig. 1500
1500 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(1)
CABINE(1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1500
1500 -- 220101-00192K CABIN ASSY CABINE CONJ 1
1 - BODY;CABIN CORPO,CILINDRO 1 D
2 903-00072A GLASS;RH VIDRO;RH 1
3 903-00073A GLASS;LH REAR VIDRO;LH 1
4 903-00075 GLASS;REAR VIDRO,TRASEIRA;ANTENA PADRÃO1
5 198-00054A TRIM;REAR GLASS BORRACHA,H;TRASEIRA VIDRO1
6 220214-00023B STRIP,WEATHER TIRA,TEMPO 1
8 162-00039A STRIP;BODY TIRA 1
9 162-00038 TRIM;ROOF TIRA,TEMPO 1
12 621-02864 COVER;FRESH AIR ASM TAMPA;FRESH AR 1
13 471-00119 FILTER;FRESH AIR FILTRO,FRESH AR 1
18 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 15
19 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 2
20 2120-2166D28 BOLT;HEX PARAFUSO,HEX 2
21 2160-1310 BUSHING;RUBBER BUCHA,BORRACHA 5
24 S2208561 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA4
25 2120-2166D12 BOLT;HEX PARAFUSO 4
30 161-00640A SPONGE ESPONJA 1
31 2120-2166D7 SCREW ROSCA 2
47 2120-2166D5 BOLT PARAFUSO,HEX 2
58 195-02729 BRACKET;BLADE SUPORTE;FRENTE LIMPADOR BRAÇO DESL1
59 161-00598A RUBBER;WASHER NOZZLE BORRACHA;ARRUELA BOCAL1
60 554-00005 NOZZLE;WASHER ARRUELA;INTERMEDIÁRIA 1
61 621-02837A COVER;WASHER NOZZLE TAMPA;ARRUELA BOCAL 1
66 123-00523 PIN;GAS-SPRING PINO;GÁS MOLA 2
73 300512-00010 MOTOR,WIPER MOTOR,LIMPADOR 1
76 2114-1898D13 WASHER;PLAIN ARRUELA,PLANÍCIE 2
77 2120-2166D26 SCREW ROSCA 2
89 K1003427 BOLT;KNOB PARAFUSO,CALOMBO 1
101 541-00015 ARM;WIPER BRAÇO,LIMPADOR;FRENTE 1
102 507-00006 BLADE;WIPER LÂMINA,LIMPADOR 1
104 K1002635 DAMPER AMORTECEDOR 1
105 K1002636 DAMPER AMORTECEDOR 1
106 2185-1660 HOSE MANGUEIRA 1
108 K1004061 FOAM ESPUMA 1
109 K1003522 STOPPER ROLHA 5
110 S2208466 BOLT;SOCKET PARAFUSO,HEX SOQUETE 3
111 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO1
DX225LCA 1500 - 2
Serial No. ;
CABIN(1)
CABINE(1)
DATE DEC. 21, 2012
1st EDITION Fig. 1500
1500 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(1)
CABINE(1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1500
1500 -121 110910-00038A CAP,PLASTIC CAPA,PLÁSTICO;M10 2
122 110910-00077 CAP,PLASTIC CAPA,PLÁSTICO;M12 13
DX225LCA 1500 - 4
Serial No. ;
CABIN(2)
CABINE(2)
DATE DEC. 21, 2012
1st EDITION Fig. 1510
1510 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(2)
CABINE(2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1510
1510 -- 220101-00192K CABIN ASSY CABINE CONJ 1
7 162-00034B STRIP;WEATHER TIRA,TEMPO 1
18 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 4
19 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 8
20 2120-2166D28 BOLT;HEX PARAFUSO,HEX 4
25 2120-2166D12 BOLT;HEX PARAFUSO 4
26 2114-1898D6 WASHER;PLAIN ARRUELA,PLANÍCIE 2
29 416-00019B STOPPER;LOWER ROLHA,PISTÃO 2
34 161-00195 STOPPER ROLHA,BORRACHA 2
39 2121-1311D4 NUT PORCA 2
49 220205-00024B DOOR ASSY,SLIDE PORTA CONJ,DESLIZANTE 1
49-1 K1033991 . PANEL ASS'Y . PORTA,DESLIZANTE 1
49-2 195-02739C . BRACKET;RH LOWER ROLLER . SUPORTE;INFERIOR ROLETE1
49-3 195-02740E . BRACKET;RH ROLLER UPPER . SUPORTE,ROLETE;SUPERIOR1
49-4 100601-00023 . CATCH ASS'Y;SLIDE(L.H) . PEGADOR CONJ;DESLIZANTE,LH1
49-5 100601-00024 . CATCH ASS'Y;SLIDE(R.H) . PEGADOR CONJ;DESLIZANTE,RH1
49-6 900131-00014A . ROLLER;SLIDE DOOR . ROLETE;DESLIZANTE PORTA4
49-7 K1036331 . BAR . BARRA;DESLIZANTE PORTA 1
49-8 K1033880 . GLASS;FRONT UPPER . VIDRO,FRENTE;SUPERIOR 1
49-10 2114-1898D3 . WASHER;PLAIN . ARRUELA,PLANÍCIE 6
49-11 2120-2166D28 . BOLT;HEX . PARAFUSO,HEX 6
49-12 2120-2166D12 . BOLT;HEX . PARAFUSO 4
49-15 2120-2166D52 . BOLT M6X1.0X12 . PARAFUSO,HEX 2
49-16 474-00044A . SUN SCREEN;FRONT . PALA DE SOL CONJ 1
49-17 K1036967 . DAMPER . AMORTECEDOR 1
49-19 K1056987 . PLATE . PLACA 2
49-20 K1006368 . RUBBER . BORRACHA 2
50 903-00074A GLASS;FRONTLOWER VIDRO,FRENTE;BAIXA 1
51 142-00128B STRIKER;RH GREVISTA;DESLIZANTE PORTA FRENTE1
52 142-00127C STRIKER;SLIDE DOOR REAR GREVISTA;DESLIZANTE PORTA TRASEIRA2
53 110956-00328 STOPPER,FRONT(L.H) ROLHA;DESLIZANTE PORTA ABERTURA1
54 110956-00329 STOPPER,FRONT(R.H) ROLHA;DESLIZANTE PORTA ABERTURA1
55 2140-1338 PIPE;SPACER TUBO;ESPAÇADOR 4
57 549-00086 SWITCH;SLIDE INTERRUPTOR,LIMPADOR;CORTADOR OFF1
63 161-00618B STOPPER;SLIDE DOOR OPEN(L.H) ROLHA;DESLIZANTE PORTA ABERTURA1
64 161-00619B STOPPER;SLIDE DOOR OPEN(R.H) ROLHA;DESLIZANTE PORTA ABERTURA1
78 S3450993 SCREW ROSCA 4
80 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 4
DX225LCA 1510 - 2
Serial No. ;
CABIN(2)
CABINE(2)
DATE DEC. 21, 2012
1st EDITION Fig. 1510
1510 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(2)
CABINE(2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1510
1510 -88 K1003284 STRIKER;LH GREVISTA 1
103 S4034833 NUT PORCA 1
118 180102-00744 FOAM ESPUMA 2
119 180102-00743 FOAM ESPUMA 2
123 198-00036A STRIP;WEATHER TRIM,BORRACHA 1
DX225LCA 1510 - 4
Serial No. ;
CABIN(3)
CABINE(3)
DATE DEC. 21, 2012
1st EDITION Fig. 1520
1520 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(3)
CABINE(3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1520
1520 -- 220101-00192K CABIN ASSY CABINE CONJ 1
14 2120-2166D10 SCREW ROSCA 4
17 191-03166C STRIKER PLATE ROOF PLACA;GREVISTA,TELHADO 1
19 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 4
20 2120-2166D28 BOLT;HEX PARAFUSO,HEX 2
31 2120-2166D7 SCREW ROSCA 1
55 2140-1338 PIPE;SPACER TUBO;ESPAÇADOR 2
56 K1000794 STOPPER;RUBBER ROLHA 2
62 530-00417B HARNESS;CABIN ARNÊS;CABINE 1
65 S3458843 SCREW ROSCA 2
67 621-03113B PLATE;STOPPER (R.H) PLACA,ROLHA 1
68 621-03114B PLATE;STOPPER (L.H) PLACA,ROLHA 1
70 125-00077 LOCK;REAR GLASS (L.H) FECHADURA,JANELA 1
71 125-00078 LOCK;REAR GLASS (R.H) FECHADURA,JANELA 1
72 2161-2212 STOPPER;RUBBER ROLHA,BORRACHA 2
75 534-00079 ROOM LAMP LÂMPADA;SALA 1
75A 2515-1021D1 . BULB . BULBO 1
76 2114-1898D13 WASHER;PLAIN ARRUELA,PLANÍCIE 2
77 2120-2166D26 SCREW ROSCA 2
78 S3450993 SCREW ROSCA 4
79 S3452853 SCREW ROSCA 4
80 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 20
81 2541-9020 SPEAKER FALANTE 2
82 S3450833 SCREW ROSCA,MÁQUINA;R/CABEÇA 8
84 161-00609E PAD;ROOF REAR ALMOFADA,TELHADO;TRASEIRA1
85 161-00610E PAD;ROOF CENTER ALMOFADA,TELHADO;FRENTE1
86 150120-00035 RAIL,ROOF(R.H) TRILHO,COMUM;TELHADO,R.H1
87 150120-00034 RAIL,ROOF(L.H) TRILHO,COMUM;TELHADO,L.H1
90 161-00613C PAD;ROOF FRONT ALMOFADA 1
91 172-00055A HANDLE;ROOF MAÇANETA;TELHADO TAMPA2
92 2199-9058 HAMMER MARTELO;EMERGÊNCIA 1
93 2150-1133 HOOK;COAT ANZOL 1
94 621-02910C COVER;PILLAR LH TAMPA;PILAR 1
95 621-02911C COVER;PILLAR RH TAMPA;PILAR 1
96 621-02912B COVER;REAR UPPER TAMPA,FALANTE 1
97 2114-2031D1 WASHER;SPRING ARRUELA,MOLA 2
98 K1006936 SCRIVET GRAMPO;SCRIPET 12
99 2120-2166D18 SCREW ROSCA 2
DX225LCA 1520 - 2
Serial No. ;
CABIN(3)
CABINE(3)
DATE DEC. 21, 2012
1st EDITION Fig. 1520
1520 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(3)
CABINE(3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1520
1520 -100 K1002641 MODULE ASS'Y ANTENA MÓDULO,VIDRO 1
107 K1003676B PLATE PLACA 1
111 2120-2166D53 SCREW PARAFUSO,HEX;VERDE PARAFUSO4
113 2114-1898D5 WASHER M6 ARRUELA,PLANÍCIE 4
114 K1006933 SCRIVET GRAMPO;SCRIPET 3
115 S5010313 WASHER ARRUELA,PLANÍCIE 2
116 K1010839 FORM ESPUMA 1
DX225LCA 1520 - 4
Serial No. ;
CABIN(4)
CABINE(4)
DATE DEC. 21, 2012
1st EDITION Fig. 1530
1530 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(4)
CABINE(4)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1530
1530 -- 220101-00192K CABIN ASSY CABINE CONJ 1
11 625-00159B STEP;CABIN DOOR PASSO;CABINE PORTA 1
18 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 1
19 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 4
20 2120-2166D28 BOLT;HEX PARAFUSO,HEX 4
23 2114-1898D15 WASHER;PLAIN ARRUELA,PLANÍCIE 6
25 2120-2166D12 BOLT;HEX PARAFUSO 1
28 2120-2150D3 SCREW PARAFUSO,PLANO CABEÇA 4
32 622-00353K DOOR ASS'Y PORTA CONJ 1
32-1 - . DOOR;BODY . ARREFECEDOR, ÓLEO 1 D
32-2 903-00069A . GLASS;DOOR LOWER . VIDRO,PORTA;BAIXA 1
32-3 622-00355A . SASH ASS'Y . CAIXILHO CONJ,PORTA 1
32-3A 622-00356 .. FRAME ASS'Y;SASH .. QUADRO CONJ,CHASSIS 1
32-3B 2123-6119 .. LOCK;SASH .. FECHADURA,PORTA;CAIXILHO1
32-3C162-00033A .. BAR;CENTER .. BARRA;CENTRAL 1
32-4 903-00070B . GLASS;SASH FRONT . VIDRO;FRENTE 1
32-5 903-00071B . GLASS;SASH REAR . VIDRO;TRASEIRA 1
32-6 161-00623 . TRIM . ARREMATADOR;CAIXILHO PORTA1
32-7 621-02869C . COVER;LOCK . TAMPA,LATERAL 1
32-8 198-00053A . RUBBER TRIM;DOOR INNER . TRIM,BORRACHA;PORTA 1
32-9 133-00221 . LEVER ASS'Y;INNER HANDLE . ALAVANCA CONJ;MAÇANETA,INTERNA1
32-10 137-00092 . LINK;DOOR INNER . TIRANTE;PORTA INTERNA 1
32-11 125-00072 . CATCH ASS'Y;DOOR INNER . PEGADOR 1
32-12 136-00055A . ROD;OUTER HANDLE . HASTE;PORTA EXTERIOR MAÇANETA1
32-13 K1002637 . DAMPER . AMORTECEDOR 1
32-14 2150-1132A . HOOK;CATCH DOOR . ANZOL,PEGADOR PORTA 1
32-15 K1027765 . HINGE ASS'Y;DOOR . DOBRADIÇAS,PORTA 2
32-16 K1003900 . KEY ASS`Y;DOOR . CILINDRO,PORTA CHAVE;F9001
32-17 2172-9021 . HANDLE;OUTER . MAÇANETA;EXTERIOR 1
32-18 145-00124A . STAY . ESTADA;PORTA INTERNA 1
32-19 2123-2247 . PIN . PINO 2
32-20 2124-1689A . SNAP . GRAMPO 2
32-21 621-02867A . COVER;DOOR INNER . CAPA;MANGUEIRA 1
32-22 2114-1898D15 . WASHER;PLAIN . ARRUELA,PLANÍCIE 6
32-23 2120-2166D1 . BOLT . PARAFUSO,HEX 6
32-24 2120-2166D5 . BOLT . PARAFUSO,HEX 2
32-25 2114-1898D2 . WASHER . ARRUELA,PLANÍCIE 2
32-26 2891-1311 . PLATE . PLACA 4
DX225LCA 1530 - 2
Serial No. ;
CABIN(4)
CABINE(4)
DATE DEC. 21, 2012
1st EDITION Fig. 1530
1530 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CABIN(4)
CABINE(4)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1530
1530 -32-27 S4012533 . NUT . PORCA,HEX 2
32-28 161-00621B . STOPPER;RUBBER . ROLHA,BORRACHA 1
32-28A191-03283 .. PLATE;STOPPER .. PLACA,ROLHA 1
32-28B4132-1138 .. KNOB .. CALOMBO 1
32-28C161-00620 .. RUBBER;STOPPER .. BORRACHA;ROLHA 1
32-28D116-00092A .. STOPPER .. ROLHA 1
32-29 2114-1898D3 . WASHER;PLAIN . ARRUELA,PLANÍCIE 2
32-30 2120-2166D28 . BOLT;HEX . PARAFUSO,HEX 2
32-31 2120-2166D52 . BOLT M6X1.0X12 . PARAFUSO,HEX 5
32-32 S4012333 . NUT . PORCA 2
32-33 2120-2150D3 . SCREW . PARAFUSO,PLANO CABEÇA 3
32-34 S5210303 . WASHER;TOOTHED . ARRUELA 3
32-35 124-00010 . CLIP;ROD . GRAMPO;HASTE 2
32-36 124-00344 . CLIP;ROD . GRAMPO;HASTE 1
32-37 2120-2166D53 . SCREW . PARAFUSO,HEX;VERDE PARAFUSO8
32-38 K1006370 . FOAM . ESPUMA 1
33 2142-9005 STRIKER;DOOR GREVISTA;PORTA FECHADURA1
34 161-00195 STOPPER ROLHA,BORRACHA 2
35 2125-9055 LOCK;BACK PEGADOR;TRASEIRO FECHADURA1
36 621-02849B COVER;BACK LOCK INNER TAMPA;TRASEIRO FECHADURA1
37 133-00220E LEVER;BACK LOCK ALAVANCA,TRASEIRO FECHADURA1
38 195-02719C BRACKET;BACK LOCK SUPORTE 1
39 2121-1311D4 NUT PORCA 2
41 2120-2166D1 BOLT PARAFUSO,HEX 6
42 2114-1856 SHIM;STRIKER CALÇO;GREVISTA 1
43 2120-2150D1 BOLT PARAFUSO,PLANO CABEÇA 2
46 2114-1898D2 WASHERARRUELA,PLANÍCIE 4
47 2120-2166D5 BOLT PARAFUSO,HEX 4
48 2127-1002A CABLE;BACK LOCK ARAME;PEGADOR LIBERADOR1
117 2129-1446 SPRING MOLA 1
DX225LCA 1530 - 4
Serial No. ;
HANDLE - CABIN
ALÇA - CABINE
DATE DEC. 21, 2012
1st EDITION Fig. 1540
1540 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
HANDLE - CABIN
ALÇA - CABINE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1540
1540 -- K1038240 HANDLE ASS'Y PUNHO ASS ' Y - D
1 K1038247 HANDLE MAÇANETA,CABINE;INTERNA1
2 2120-2166D4 BOLT M10X1.5X20 PARAFUSO,HEX 4
3 2114-1898D15 WASHER;PLAIN ARRUELA,PLANÍCIE 4
DX225LCA 1540 - 2
Serial No. ;
FLOOR MAT
TAPETE DE ASSOALHO
DATE DEC. 21, 2012
1st EDITION Fig. 1550
1550 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FLOOR MAT
TAPETE DE ASSOALHO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1550
1550 -1 110935-00069 MAT;FLOOR MAT,ASSOALHO 1
DX225LCA 1550 - 2
Serial No. ;
FLOOR PLATE
PLACA DO ASSOALHO
DATE DEC. 21, 2012
1st EDITION Fig. 1560
1560 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FLOOR PLATE
PLACA DO ASSOALHO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1560
1560 -- 250106-00125A PLATE ASSY,FLOOR PLACA - D
1 2120-2166D55 BOLT PARAFUSO,HEX 4
2 2114-1898D17 WASHER M12 ARRUELA,PLANÍCIE 4
3 2120-2166D1 BOLT PARAFUSO,HEX 2
4 2114-1898D1 WASHER ARRUELA,PLANÍCIE 8
5 160-00071 BUSHING;RUBBER BUCHA,BORRACHA 1
6 160-00072 BUSHING;RUBBER BUCHA,BORRACHA 4
7 160-00080B BUSHING;RUBBER BUCHA,BORRACHA 2
8 S2208866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 6
9 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 6
10 133-00229A LEVER;TRAVEL (L.H) ALAVANCA,VIAGEM;LH 1
11 133-00230A LEVER;TRAVEL (R.H) ALAVANCA,VIAGEM 1
12 250106-00126A PLATE,FLOOR PLACA,ASSOALHO 1
13 621-01507A PLATE PLACA 1
14 161-00381 RUBBER;PEDAL(R.H) BORRACHA,PEDAL;DIREITO,PROPELLING1
15 161-00382 RUBBER;PEDAL(L.H) BORRACHA,PEDAL;ESQUERDA1
16 2120-2166D4 BOLT M10X1.5X20 PARAFUSO,HEX 6
17 S2211866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
18 S5110603 WASHER;SPRING ARRUELA,MOLA 4
19 K1039515 BRACKET;PEDAL(R.H) PEDAL,VIAGEM;RH 1
20 K1039514 BRACKET;PEDAL(L.H) PEDAL,VIAGEM;LH 1
21 2132-1134B GRIP;LEVER(R.H) PUNHO,ALAVANCA;DIREITO 1
22 2132-1133B GRIP;LEVER(L.H) PUNHO,ALAVANCA;ESQUERDA1
23 S2201766 BOLT;SOCKET PARAFUSO,HEX SOQUETE 2
24 S5000113 WASHER;PLAIN ARRUELA,PLANÍCIE 2
25 2161-2487 CAP;RUBBER CAPA,BORRACHA 1
26 160-00073A CAP CAPA,PLÁSTICO 2
DX225LCA 1560 - 2
Serial No. ;
HANDLE ASS'Y
CONJUNTO DE ALÇA
DATE DEC. 21, 2012
1st EDITION Fig. 1570
1570 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
HANDLE ASS'Y
CONJUNTO DE ALÇA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1570
1570 -1 110925-00007 HANDLE ASS'Y;OUTER MAÇANETA CONJ;EXTERIOR 1
1-1 172-00053B . HANDLE;OUTER . MAÇANETA;EXTERIOR 1
1-2 2120-2166D2 . BOLT . PARAFUSO,HEX 4
1-3 2114-1898D15 . WASHER;PLAIN . ARRUELA,PLANÍCIE 4
3 K1004272 STAY;MIRROR ESTADA,ESPELHO 1
11 K1040606 MIRROR;SIDE ESPELHO,TRASEIRA VISTA 1
DX225LCA 1570 - 2
Serial No. ;
ROOF COVER
TETO
DATE DEC. 21, 2012
1st EDITION Fig. 1580
1580 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ROOF COVER
TETO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1580
1580 -- 621-03732C ROOF COVER ASS'Y TAMPA CONJ,TELHADO - D
16 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 1
19 123-00516B LOCK ASS'Y;ROOF COVER FECHADURA CONJ;TELHADO TAMPA1
123-00523 PIN;GAS-SPRING PINO;GÁS MOLA 2
2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 1
2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 1
2120-2166D9 SCREW ROSCA 1
621-03727B COVER;ROOF TAMPA,TELHADO 1
DS1003009 GAS-SPRING MOLA,GÁS 2
21 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 1
2120-2166D9 SCREW ROSCA 1
DX225LCA 1580 - 2
Serial No. ;
FOOT REST - L.H.
DESCANÇO DE PÉ - L.E.
DATE DEC. 21, 2012
1st EDITION Fig. 1590
1590 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FOOT REST - L.H.
DESCANÇO DE PÉ - L.E.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1590
1590 -- K1002082 FOOT REST(L.H) REST,PE;ESQUERDA - D
1 195-02949A BRACKET;FOOT REST(L.H) SUPORTE,PE REST;LH 1
2 2120-2166D1 BOLT PARAFUSO,HEX 2
3 2114-1898D1 WASHER ARRUELA,PLANÍCIE 2
4 2160-1345 COVER;FOOT REST TAMPA;PÉ REST 1
DX225LCA 1590 - 2
Serial No. ;
FOOT REST - R.H.
DESCANÇO DE PÉ - L.D.
DATE DEC. 21, 2012
1st EDITION Fig. 1600
1600 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FOOT REST - R.H.
DESCANÇO DE PÉ - L.D.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1600
1600 -- K1002083 FOOT REST(R.H) REST,PE;DIREITO - D
1 195-02948A BRACKET;FOOT REST(R.H) SUPORTE,PE REST 1
2 2120-2166D1 BOLT PARAFUSO,HEX 2
3 2114-1898D1 WASHER ARRUELA,PLANÍCIE 2
4 2160-1346 COVER;FOOT REST TAMPA;PÉ REST 1
DX225LCA 1600 - 2
Serial No. ;
SUPPORT
SUPORTE
DATE DEC. 21, 2012
1st EDITION Fig. 1610
1610 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SUPPORT
SUPORTE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1610
1610 -- 110958-01518 SUPPORT & BAFFLE ASSY APOIO - D
1 K1038954B SUPPORT APOIO 1
2 110958-00097 SUPPORT APOIO 1
4 K1030750A SUPPORT APOIO 1
6 110958-01055 SUPPORT APOIO 1
7 K1030506B SUPPORT APOIO 1
8 110958-01541 SUPPORT APOIO 1
10 110502-00025 COVER,BAFFLE TAMPA,DEFLETOR 1
18 DS0025015 BOLT;SET PARAFUSO 25
19 110502-00524 COVER,BAFFLE TAMPA,DEFLETOR 2
22 DS0025022 BOLT;SET PARAFUSO 4
25 DS0025017 BOLT PARAFUSO 4
26 S4012633 NUT PORCA,HEX 4
DX225LCA 1610 - 2
Serial No. ;
BAFFLE
DEFLECTOR
DATE DEC. 21, 2012
1st EDITION Fig. 1620
1620 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BAFFLE
DEFLECTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1620
1620 -- 110958-01518 SUPPORT & BAFFLE ASSY APOIO - D
5 K1049826 SUPPORT APOIO 1
11 K1049011 COVER;BAFFLE TAMPA,DEFLETOR 1
13 K1045908 COVER;BAFFLE TAMPA,DEFLETOR 1
14 K1030731 COVER;BAFFLE TAMPA,DEFLETOR 1
15 K1030732A COVER;BAFFLE TAMPA,DEFLETOR 1
16 K1030735A COVER;BAFFLE TAMPA,DEFLETOR 1
17 K1030734A COVER;BAFFLE TAMPA,DEFLETOR 1
18 DS0025015 BOLT;SET PARAFUSO 43
23 K1038966 COVER;BAFFLE TAMPA,DEFLETOR 1
DX225LCA 1620 - 2
Serial No. ;
SIDE DOOR - L.H
PORTA LATERAL - L.E.
DATE DEC. 21, 2012
1st EDITION Fig. 1630
1630 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SIDE DOOR - L.H
PORTA LATERAL - L.E.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1630
1630 -- 110508-08513 COVER ASSY TAMPA - D
3 110982-00132A DOOR ASSY,SIDE;TROPICAL(L.H) PORTA CONJ,LATERAL;TROPICAL,LH1
3-1 110958-00230 . SUPPORT . APOIO 1
3-2 110982-00133 . DOOR,SIDE . PORTA,LATERAL 1
3-2A 125-00034A .. LOCK .. FECHADURA;DIREITO 1
3-3 110982-00131 . DOOR,SIDE(L.H) . PORTA,LATERAL;ESQUERDA1
3-4 250201-00028 . PLATE;STOPPER . PLACA,ROLHA 2
3-5 110956-00002A . STOPPER,RUBBER . ROLHA,BORRACHA 2
3-7 K1038920 . PLATE;LOCK . PLACA,FRENTE;FECHADURA1
3-8 K1001260A . STOPPER;RUBBER . ROLHA,BORRACHA 1
3-9 2114-1058D45 . WASHER . ARRUELA,PLANÍCIE 2
3-10 S0511853 . BOLT . PARAFUSO,HEX2
3-11 2114-1058D30 . WASHER;PLAIN . ARRUELA,PLANÍCIE 8
3-12 S4012733 . NUT . PORCA 8
3-13 S5010313 . WASHER . ARRUELA,PLANÍCIE 10
3-14 S0504553 . BOLT M6X1.0X14 . PARAFUSO,HEX 8
3-15 S0504453 . BOLT M6X1.0X12 . PARAFUSO,HEX 2
3-18 S4012633 . NUT . PORCA,HEX 1
3-19 - . FOAM . ESPUMA 1 D
3-20 K1000602 . BUSHING . BUCHA 2
3-21 K1048085 . STOPPER;RUBBER . ROLHA 1
3-22 K1039869B . PLATE;LOCK . PLACA,FRENTE;FECHADURA1
3-23 623-00074B . STAY . ESTADA CONJ 1
3-24 623-00075B . STAY . ESTADA CONJ 1
3-25 K1008335 . BUSHING . BUCHA 2
3-26 2705-9002 . PIN;LOCK . PINO,FECHADURA 4
3-27 S4012533 . NUT . PORCA,HEX 1
3-28 110947-00027 . SHIM . CALÇO 2
26 DS0025015 BOLT;SET PARAFUSO 10
44 K1004630 KEY;CYLINDER CILINDRO,CHAVE 1
47 K1045909 PLATE PLACA,FRENTE 1
DX225LCA 1630 - 2
Serial No. ;
SIDE DOOR - R.H
PORTA LATERAL - L.D.
DATE DEC. 21, 2012
1st EDITION Fig. 1640
1640 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SIDE DOOR - R.H
PORTA LATERAL - L.D.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1640
1640 -- 110508-08513 COVER ASSY TAMPA - D
2 110982-00103C DOOR ASSY,SIDE;(R.H) PORTA CONJ,LATERAL;R.H 1
2-1 110958-00181A . SUPPORT . APOIO 1
2-2 110982-00128A . DOOR,SIDE . PORTA,LATERAL 1
2-2A 125-00035A .. LOCK .. FECHADURA;ESQUERDA 1
2-3 250201-00028 . PLATE;STOPPER . PLACA,ROLHA 1
2-4 110956-00002A . STOPPER,RUBBER . ROLHA,BORRACHA 1
2-6 621-02726A . PLATE;LOCK . PLACA,FECHADURA 1
2-7 K1001260A . STOPPER;RUBBER . ROLHA,BORRACHA 2
2-8 623-00075B . STAY . ESTADA CONJ 1
2-9 2705-9002 . PIN;LOCK . PINO,FECHADURA 2
2-10 2114-1058D45 . WASHER . ARRUELA,PLANÍCIE 3
2-11 S0511853 . BOLT . PARAFUSO,HEX 2
2-12 2114-1058D30 . WASHER;PLAIN . ARRUELA,PLANÍCIE 4
2-13 S4012733 . NUT . PORCA 4
2-14 S5010313 . WASHER . ARRUELA,PLANÍCIE 4
2-15 S0504553 . BOLT M6X1.0X14 . PARAFUSO,HEX 4
2-19 S4012633 . NUT . PORCA,HEX 2
2-20 K1000602 . BUSHING . BUCHA 1
2-21 K1008335 . BUSHING . BUCHA 1
2-22 110947-00027 . SHIM . CALÇO 1
5 621-03642C COVER;TANK TAMPA,TANQUE 1
26 DS0025015 BOLT;SET PARAFUSO 8
44 K1004630 KEY;CYLINDER CILINDRO,CHAVE 1
DX225LCA 1640 - 2
Serial No. ;
BATTERY COVER
TAMPA DE BATERIA
DATE DEC. 21, 2012
1st EDITION Fig. 1650
1650 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BATTERY COVER
TAMPA DE BATERIA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1650
1650 -- 110508-08513 COVER ASSY TAMPA - D
4 110503-00016C COVER ASSY,BATTERY TAMPA CONJ,BATERIA 1
4-1 - . BATTERY COVER . TAMPA CONJ,BATERIA 1 D
4-2 110503-00008A . COVER,BATTERY . TAMPA,BATERIA 1
4-2A 125-00071B .. LATCH;FRONT .. FECHADURA;FRENTE 1
4-3 S0512066 . BOLT M10X1.5X25 . PARAFUSO,HEX 4
4-4 S5010613 . WASHER;PLAIN . ARRUELA,PLANÍCIE 4
4-5 - . RUBBER . BUCHA 1 D
4-6 - . RUBBER . BUCHA 1 D
4-7 400315-00026 . CYLINDER,GAS . CILINDRO,GÁS 1
4-8 S5102503 . WASHER,SPRING . ARRUELA,MOLA 4
4-9 S4012533 . NUT . PORCA,HEX 4
4-10 K1005305A . STOPPER;RUBBER . ROLHA,BORRACHA 2
4-11 DS1001061 . CYLINDER;GAS . CILINDRO,GÁS 1
4-12 S4012333 . NUT . PORCA 4
4-13 S5102303 . WASHER;SPRING . ARRUELA,MOLA 4
11 621-03657B COVER;TANK TAMPA,TANQUE 1
15 K1013266B STAY TRILHO,MÃO 1
17 K1038110A STAY;MIRROR ESTADA,ESPELHO 1
18 K1038107A STAY;MIRROR ESTADA,ESPELHO 1
19 2114-1058D68 WASHER ARRUELA,PLANÍCIE 4
25 DS0025014 BOLT;SET PARAFUSO 4
26 DS0025015 BOLT;SET PARAFUSO 4
27 195-02706C BRACKET SUPORTE 1
29 161-00580 CAP;RUBBER CAPA,BORRACHA 2
30 S0561066 BOLT M12X1.75X65 PARAFUSO,HEX 2
31 S0560666 BOLT PARAFUSO,HEX 4
32 S5102703 WASHER;SPRING ARRUELA,MOLA 10
33 S0560566 BOLT M12X1.75X40 PARAFUSO,HEX 4
37 2114-1154 WASHER ARRUELA 6
40 S4012733 NUT PORCA 4
41 195-02624C BRACKET SUPORTE 1
42 DS0025025 BOLT;SET PARAFUSO 2
43 S5010713 WASHER;PLAIN ARRUELA,PLANÍCIE 4
44 K1004630 KEY;CYLINDER CILINDRO,CHAVE 1
49 S0515166 BOLT M12X1.75X28 PARAFUSO,HEX 2
52 2114-1058D54 WASHER ARRUELA,PLANÍCIE 2
81 K1040606 MIRROR;SIDE ESPELHO,TRASEIRA VISTA 2
DX225LCA 1650 - 2
Serial No. ;
COVER
TAMPA
DATE DEC. 21, 2012
1st EDITION Fig. 1660
1660 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
COVER
TAMPA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1660
1660 -- 110508-08513 COVER ASSY TAMPA - D
8 K1039208A COVER TAMPA 1
9 K1039209A COVER TAMPA 1
10 110508-08802 COVER TAMPA 1
26 DS0025015 BOLT;SET PARAFUSO 21
34 114-00529 SPACER ESPAÇADOR 2
38 K1002943 RUBBER BUCHA 2
39 S0515266 BOLT PARAFUSO,HEX 2
51 DS0025022 BOLT;SET PARAFUSO 5
58 K1052808 COVER;MUFFLER TAMPA 1
DX225LCA 1660 - 2
Serial No. ;
ENGINE COVER
TAMPA DE MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 1670
1670 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ENGINE COVER
TAMPA DE MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1670
1670 -- 110508-08513 COVER ASSY TAMPA - D
1 110506-00047 COVER,ENGINE TAMPA,ENGINE 1
1A 1.162-00001 . RUBBER;CUSHION . ALMOFADA,BORRACHA 1
6 K1038870B COVER TAMPA 1
12 K1039430C STAY ESTADA 1
13 125-00075A CATCH PEGADOR 2
22 S5102503 WASHER,SPRING ARRUELA,MOLA 10
23 2114-1058D56 WASHER ARRUELA,PLANÍCIE 4
24 S0508866 BOLT PARAFUSO,HEX 8
26 DS0025015 BOLT;SET PARAFUSO 5
36 2705-9002 PIN;LOCK PINO,FECHADURA 2
44 K1004630 KEY;CYLINDER CILINDRO,CHAVE 2
46 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 4
48 DS0025019 BOLT;SET PARAFUSO 6
52 2114-1058D54 WASHER ARRUELA,PLANÍCIE 2
53 K1013812 BUSHING BUCHA;MOTOR TAMPA 1
56 S4012533 NUT PORCA,HEX 2
57 DS1001088 SPRING;GAS MOLA,GÁS 1
DX225LCA 1670 - 2
Serial No. ;
ACOUSTIC FOAM
ESPUMA DE ISOLAMENTO ACÚSTICO
DATE DEC. 21, 2012
1st EDITION Fig. 1680
1680 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ACOUSTIC FOAM
ESPUMA DE ISOLAMENTO ACÚSTICO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1680
1680 -- K1045987A FOAM ASS'Y ESPUMA - D
2 K1000485A FOAM;POLYURETHANE ESPUMA 1
4 K1000488A FOAM;POLYURETHANE ESPUMA 1
5 K1000489A COVER TAMPA,DEFLETOR 1
6 K1000490A FOAM;POLYURETHANE ESPUMA 1
7 K1000491 FOAM;POLYURETHANE ESPUMA 1
8 K1000492A COVER TAMPA,DEFLETOR 1
9 K1045902A COVER TAMPA,DEFLETOR 1
10 K1000500 RUBBER TIRA,TEMPO 1
11 124-00070 CLIP;TREE ROSCA;ÁRVORE GRAMPO 12
12 K1000504 RUBBER TIRA,TEMPO 1
13 K1000852A RUBBER TIRA,TEMPO 1
14 K1001029 BOLT PARAFUSO 12
15 161-00614 FOAM ESPUMA,POLIURETANO 1
16 K1007044 BUSHING BUCHA 1
17 K1038009 FOAM ESPUMA 1
18 K1038010 FOAM ESPUMA 1
19 K1038011 FOAM ESPUMA 2
DX225LCA 1680 - 2
Serial No. ;
UNDER COVER
ABRIGO
DATE DEC. 21, 2012
1st EDITION Fig. 1690
1690 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
UNDER COVER
ABRIGO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1690
1690 -- K1045932 UNDER COVER ASS'Y SOB CAPA ASS ' Y - D
1 K1000591A COVER;UNDER TAMPA,INTERNA 1
2 K1000592A COVER;UNDER TAMPA,INTERNA 1
3 K1024692 COVER;UNDER TAMPA,INTERNA 1
4 K1039134 COVER;UNDER TAMPA,INTERNA 1
5 K1045929 COVER;UNDER TAMPA,INTERNA 1
6 K1039137 COVER;UNDER TAMPA,INTERNA 1
7 K1041250 COVER;UNDER TAMPA,INTERNA 1
8 K1041251 COVER;UNDER TAMPA,INTERNA 1
9 K1041252COVER;UNDER TAMPA,INTERNA 1
10 K1000600B COVER;UNDER TAMPA,INTERNA 1
11 S0560466 BOLT M12X1.75X35 PARAFUSO,HEX 49
12 S5102703 WASHER;SPRING ARRUELA,MOLA 49
13 DS0401188 WASHER;PLAIN ARRUELA,PLANÍCIE 49
DX225LCA 1690 - 2
Serial No. ;
LUBRICATION PIPING
TUBULAÇÃO DE LUBRIFICAÇÃO
DATE DEC. 21, 2012
1st EDITION Fig. 1700
1700 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING
TUBULAÇÃO DE LUBRIFICAÇÃO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1700
1700 -- 420212-06987 PIPING,LUBRICATION TUBULAÇÃO, LUBRIFICAÇÃO - D
1 K1007665B PIPE;GREASE TUBO 1
2 2181-1925 ELBOW COTOVELO 1
4 S0504366 BOLT PARAFUSO,HEX 1
5 S5102303 WASHER;SPRING ARRUELA,MOLA 1
6 2181-2527 TEE T 1
7 S6710041 NIPPLE;GREASE APROPRIADO 2
8 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 2
DX225LCA 1700 - 2
Serial No. ;
ELECTRIC BOX ASS'Y
CONJUNTO DE CAIXA ELÉTRICA
DATE DEC. 21, 2012
1st EDITION Fig. 1710
1710 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC BOX ASS'Y
CONJUNTO DE CAIXA ELÉTRICA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1710
1710 -- 300619-00514B ELECTRIC ASSY;EBOX ELÉTRICO CONJ;E CAIXA 1
1 250201-00795A PLATE,ELECTRIC BOX PLACA,ELÉTRICO CAIXA 1
2 D913109 NUT,FLANGE PORCA,FLANGE 4
3 2543-9015 CONTROLLER;STARTER CONTROLADOR,INICIADOR 1
4 300611-00271 CONTROLLER;WIPER MOTOR CONTROLADOR 1
5 300612-00001A CONVERTER;DC CONVERSOR,DC 1
6 S3450953 SCREW M6X12 ROSCA 6
7 S5102303 WASHER;SPRING ARRUELA,MOLA 8
8 545-00011 RESISTOR;AUXILIARY RESISTOR;AUXILIAR 1
9 S3450863 SCREW ROSCA,MÁQUINA;R/CABEÇA 2
10 S5100203 WASHER;SPRING ARRUELA,MOLA 6
11 2544-9033 RELAY RETRANSMITIR 7
12 301202-00042 RELAY RETRANSMITIR 2
13 S3450833 SCREW ROSCA,MÁQUINA;R/CABEÇA 4
14 190-01192D24 PLATE,NAME;RELAY PLACA,NOME;RETRANSMITIR1
15 310207-00425A HARNESS,ELECTRIC BOX ARNÊS,ELÉTRICO CAIXA 1
16 124-00208D3 CLIP GRAMPO 2
17 124-00208D2 CLIP GRAMPO 1
18 K1001029 BOLT PARAFUSO 3
19 S3450983 SCREW M16X20 ROSCA 2
20 190-01192D29 PLATE,NAME;RELAY PLACA,NOME;RETRANSMITIR1
21 190-01192D26 PLATE,NAME;RELAY PLACA,NOME;RETRANSMITIR1
DX225LCA 1710 - 2
Serial No. ;
ELECTRIC PARTS - CABIN
PARTES ELÉTRICAS - CABINE
DATE DEC. 21, 2012
1st EDITION Fig. 1720
1720 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - CABIN
PARTES ELÉTRICAS - CABINE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1720
1720 -- 300619-00056E ELECTRIC ASSY ELÉTRICO CONJ - D
1 300426-00012A PANEL,GAUGE;3.8INCH PAINEL,BITOLA;3.8INCH 1
1A 515-00012A . BULB . BULBO 6
2 S3450863 SCREW ROSCA,MÁQUINA;R/CABEÇA 4
3 S5100203 WASHER;SPRING ARRUELA,MOLA 4
4 S5000213 WASHER;PLAIN M5 ARRUELA,PLANÍCIE 4
5 K1001263A BOX;FUSE CAIXA,FUSÍVEL 1
5A 2527-1016 . FUSE;BLADE 10A . FUSÍVEL 8
5B 2527-1017 . FUSE;BLADE 15A . FUSÍVEL 3
5C 2527-1018 . FUSE;BLADE 20A . FUSÍVEL,LÂMINA 2
5D 2527-1025 . FUSE;BLADE 30A . FUSÍVEL,LÂMINA 1
6 K1001263A BOX;FUSE CAIXA,FUSÍVEL 1
6A 2527-1016 . FUSE;BLADE 10A . FUSÍVEL 8
6B 2527-1017 . FUSE;BLADE 15A . FUSÍVEL 3
6C 2527-1018 . FUSE;BLADE 20A . FUSÍVEL,LÂMINA 2
6D 2527-1025 . FUSE;BLADE 30A . FUSÍVEL,LÂMINA 1
7 S3450983 SCREW M16X20 ROSCA 4
8 S5102303 WASHER;SPRING ARRUELA,MOLA 4
12 S3450833 SCREW ROSCA,MÁQUINA;R/CABEÇA 4
13 S5100203 WASHER;SPRING ARRUELA,MOLA 4
14 543-00095 PANEL ASS'Y;WIPER CONTROL PAINEL CONJ;LIMPADOR CONTROLE1
15 543-00096 RADIO CONTROL PANEL ASS'Y PAINEL CONJ;RÁDIO CONTROLE1
16 300730-00006 LIGHTER,CIGAR ISQUEIRO,CHARUTO 1
17 K1053423 SOCKET;12V POWER SOQUETE;12V PODER 1
18 2528-9040 METER;HOUR MEDIDOR,HORAS 1
19 549-00103 SWITCH;ROCKER(2STEP) INTERRUPTOR,BALANCIM 1
20 K1002406D11 ACTUATOR;SWITCH ATUADOR,INTERRUPTOR;LÂMPADA1
21 549-00103 SWITCH;ROCKER(2STEP) INTERRUPTOR,BALANCIM 1
22 K1002406D12 ACTUATOR;SWITCH ATUADOR,INTERRUPTOR;ALTA VELOCIDAD1
23 K1006572 SWITCH;BREAKER/SHEAR;2 LED INTERRUPTOR,BALANCIM 1
24 K1002406D21 ACTUATOR;SWITCH ATUADOR,INTERRUPTOR;MARTELO&TOSQUI1
25 310207-00417B HARNESS,CABIN ARNÊS,CABINE;DX-MECANICO1
27 530-00434B HARNESS;HOUR METER JOINT ARNÊS;HORAS MEDIDOR 1
28 310207-00708 HARNESS;CHECK CONNECTOR ARNÊS,LIGAÇÃO;CHECAR CONEXÃO1
29 S5100003 WASHER;SPRING ARRUELA,MOLA 4
30 S3450343 SCREW ROSCA 4
32 2516-1116 BUZZER;PILOT SIRENE,PILOTO 1
33 S5102303 WASHER;SPRING ARRUELA,MOLA 2
DX225LCA 1720 - 2
Serial No. ;
ELECTRIC PARTS - CABIN
PARTES ELÉTRICAS - CABINE
DATE DEC. 21, 2012
1st EDITION Fig. 1720
1720 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - CABIN
PARTES ELÉTRICAS - CABINE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1720
1720 -34 S3450943 SCREW ROSCA 2
36 124-00208D3 CLIP GRAMPO 3
38 124-00208D4 CLIP GRAMPO 4
39 124-00208D5 CLIP GRAMPO 2
40 K1001029 BOLT PARAFUSO 5
41 S5102303 WASHER;SPRING ARRUELA,MOLA 1
42 S3450953 SCREW M6X12 ROSCA 1
43 S0508653 BOLT PARAFUSO,HEX 4
44 S5102503 WASHER,SPRING ARRUELA,MOLA 4
51 547-00023 SENSOR;SUN SENSOR 1
52 S0508653 BOLT PARAFUSO,HEX 1
53 S5102503 WASHER,SPRING ARRUELA,MOLA 1
54 300611-00138 CONTROLLER,ENGINE THROTTLE CONTROLADOR,ENGINE ACELERADOR1
55 S4012333 NUT PORCA 4
56 S5102303 WASHER;SPRING ARRUELA,MOLA 4
57 S5010313 WASHER ARRUELA,PLANÍCIE 4
58 K1003113D4 PLATE;NAME PLACA,NOME 1
59 2121-1305 NUT PORCA 5
91 300637-00009 PLAYER,CD(24V) LEITOR,CD 1
101 300611-00042B CONTROLLER,EPOS CONTROLADOR,EPOS 1
DX225LCA 1720 - 4
Serial No. ;
ELECTRIC PARTS - CONTROL STAND
PARTES ELÉTRICAS - CONSOLE DE CONTROLE
DATE DEC. 21, 2012
1st EDITION Fig. 1730
1730 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - CONTROL STAND
PARTES ELÉTRICAS - CONSOLE DE CONTROLE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1730
1730 -- 300619-00793A ELECTRIC ASSY,STAND ELÉTRICO CONJ - D
1 K1001858A SWITCH;STARTER INTERRUPTOR,INICIADOR 1
1A K1009605B . KEY;STARTER . CHAVE,INICIADOR INTERRUPTOR2
3 300661-00004 DIAL,ENGINE CONTROL DISQUE,ENGINE CONTROLE 1
4 S3450583 SCREW ROSCA,MÁQUINA;R/CABEÇA 2
5 S5100103 WASHER;SPRING ARRUELA,MOLA 2
6 549-00090A SWITCH;TOGGLE INTERRUPTOR,TOGGLE 1
7 K1004427 PLATE;NAME PLACA,NOME 1
8 K1002534A HARNESS;STAND(L.H) ARNÊS;LH CONTROLE LEVANTE1
9 310207-01182 HARNESS,STAND(R.H) ARNÊS,CONTROLE LEVANTE;R.H1
10 K1004426 PLATE;NAME PLACA,NOME 1
DX225LCA 1730 - 2
Serial No. ;
ELECTRIC PARTS - RELATED
PARTES ELÉTRICAS - RELACIONADOS
DATE DEC. 21, 2012
1st EDITION Fig. 1740
1740 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - RELATED
PARTES ELÉTRICAS - RELACIONADOS
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1740
1740 -- 300619-01604 ELECTRIC ASSY;CHASSIS ELÉTRICO CONJ - D
1 300101-00199 BATTERY BATERIA 2
2 110420-00566 BRACKET,BATTERY MOUNTING SUPORTE,BATERIA MONTAGEM1
3 S5102603 WASHER,SPRING ARRUELA,MOLA 2
4 DS0001079 BOLT PARAFUSO,HEX 2
5 K1039068 COVER TAMPA,BATERIA 1
7 K1018595 BOLT;KNOB PARAFUSO,CALOMBO 4
8 2544-9024 RELAY;BATTERY RETRANSMITIR;BATERIA 1
9 DS0025039 BOLT;SET PARAFUSO 2
12 2527-9004 BREAKER;CIRCUIT QUEBRADOR,CIRCUITO 1
13 2120-1354 SCREW ROSCA 2
14 2527-1023A LINK;FUSIBLE TIRANTE,FUSÍVEL 1
18 K1007668BRACKET SUPORTE 1
19 S0508666 BOLT PARAFUSO,HEX 2
20 S5102503 WASHER,SPRING ARRUELA,MOLA 2
21 K1000789 TANK;RESERVE TANQUE,RESERVA;JANELA ARRUELA1
22 2195-1534 BRACKET SUPORTE 1
23 S0504453 BOLT M6X1.0X12 PARAFUSO,HEX 2
24 S5102303 WASHER;SPRING ARRUELA,MOLA 2
25 K1055454 LAMP;HEAD LÂMPADA CONJ,CABEÇA 2
25A 2515-1016D4 . BULB;HALOGEN . BULBO 1
26 300726-00002 HORN;HIGH CHIFRE;ALTA 1
27 300726-00003 HORN;LOW CHIFRE;BAIXA 1
28 S0508666 BOLT PARAFUSO,HEX 2
29 S5102503 WASHER,SPRING ARRUELA,MOLA 2
30 110406-01352 BRACKET SUPORTE;LÂMPADA 1
31 DS0025019 BOLT;SET PARAFUSO 2
32 621-02643C PLATE PLACA 1
33 DS0025013 BOLT;SET PARAFUSO 2
34 4185-1777 HOSE;WATER MANGUEIRA,ÁGUA 1
35 2415-1018 ADAPTER;HOSE ADAPTADOR,MANGUEIRA 1
36 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 4
37 110508-04839 COVER,RELAY TAMPA,RETRANSMITIR 1
39 110406-00608 BRACKET SUPORTE 1
40 K1057605 SWITCH;DISCONNECTOR INTERRUPTOR CONJ 1
41 DS0025015 BOLT;SET PARAFUSO 2
42 600105-00002 NAME PLATE;SWITCH PLATE,NAME;DESLIGADOR INTERRUPTOR1
DX225LCA 1740 - 2
Serial No. ;
ELECTRIC PARTS - ENGINE
PARTES ELÉTRICAS - MOTOR
DATE DEC. 21, 2012
1st EDITION Fig. 1750
1750 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - ENGINE
PARTES ELÉTRICAS - MOTOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1750
1750 -- 300619-01605 ELECTRIC ASSY;ENGINE ELÉTRICO CONJ;MOTOR - D
1 301202-00067 RELAY RETRANSMITIR 1
8 2547-9038B SENSOR;WATER TEMP SENSOR,TEMPERATURA;ÁGUA1
9 S8180251 PACKING EMPANQUE 1
10 2547-1015 SENSOR;ENG SPEED SENSOR,VELOCIDADE;MOTOR1
11 2197-1793 BRACKET;SPEED SENSOR SUPORTE;VELOCIDADE SENSOR1
12 S0512066 BOLT M10X1.5X25 PARAFUSO,HEX 2
13 S5102603 WASHER,SPRING ARRUELA,MOLA 3
14 310207-01044A HARNESS,ENGINE ARNÊS CONJ 1
14A 300803-00086 . FUSE;200A . FUSÍVEL;200A 1
15 DS0026006 BOLT,STUD PARAFUSO,TACHÃO 3
16 S5102603 WASHER,SPRING ARRUELA,MOLA 3
17 310101-00035 TIE,CABLE LAÇO,CABO;T150R 7
20 553-00001D4 CABLE;E/G EARTH CABO,ENGINE ENCALHE 1
21 S0511653 BOLT PARAFUSO,HEX 1
22 S5102603 WASHER,SPRING ARRUELA,MOLA 1
23 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 1
24 2121-1305 NUT PORCA 2
25 DS0025049 BOLT PARAFUSO 5
26 K1010584 BLOCK BLOCO 1
27 S0759166 BOLT PARAFUSO,HEX 2
28 S5102603 WASHER,SPRING ARRUELA,MOLA 2
31 DS0025033 BOLT;SET PARAFUSO 2
32 S3450573 SCREW M4X0.7X10 ROSCA 2
33 110420-00330 BRACKET SUPORTE,MONTAGEM;CABO7
34 120117-00071 BOLT,STUD PARAFUSO,TACHÃO 1
35 S4012533 NUT PORCA,HEX 2
36 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 2
37 S5102503 WASHER,SPRING ARRUELA,MOLA 2
DX225LCA 1750 - 2
Serial No. ;
ALTERNATOR MOUNTING
Suporte DE ALTERNADOR
DATE DEC. 21, 2012
1st EDITION Fig. 1760
1760 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ALTERNATOR MOUNTING
Suporte DE ALTERNADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1760
1760 -- K1007371 ALTERNATOR MOUNTING ALTERNADOR CONJ - D
1 S0760853 BOLT PARAFUSO,HEX 1
2 S5102703 WASHER;SPRING ARRUELA,MOLA 2
3 2114-1058D54 WASHER ARRUELA,PLANÍCIE 1
4 S0562653 BOLT M12X1.75X160 PARAFUSO,HEX 1
5 S5010713 WASHER;PLAIN ARRUELA,PLANÍCIE 2
6 S4012733 NUT PORCA 1
21 300901-00034 ALTERNATOR;60A ALTERNADOR;60A 1
21A 130707-00042 . PULLEY,ALTERNATOR . POLIA,ALTERNADOR 1
DX225LCA 1760 - 2
Serial No. ;
ELECTRIC PARTS - WORKING LAMP
PARTES ELÉTRICAS - FAROL
DATE DEC. 21, 2012
1st EDITION Fig. 1770
1770 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - WORKING LAMP
PARTES ELÉTRICAS - FAROL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1770
1770 -- K1044917 ELECTRIC PARTS;WORKING LAMP ELÉTRICO CONJ - D
1 301005-00132 LAMP;WORKING LÂMPADA CONJ,TRABALHO 2
1A 2515-1016D4 . BULB;HALOGEN . BULBO 1
3 DS0025019 BOLT;SET PARAFUSO 4
6 310207-00539 HARNESS;WORKING LAMP CHICOTE DE FIOS;LÂMPADA DE TRABALHO1
7 124-00208D2 CLIP GRAMPO 1
8 2124-1509D1 CLIP GRAMPO 6
9 K1001029 BOLT PARAFUSO 7
10 2197-1660 BRACKET SUPORTE,HABITAÇÃO 1
13 110921-00091 GUARD;LAMP GUARDA,LÂMPADA 2
DX225LCA 1770 - 2
Serial No. ;
ELECTRIC WIRING
FIAÇÃO ELÉTRICA
DATE DEC. 21, 2012
1st EDITION Fig. 1780
1780 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC WIRING
FIAÇÃO ELÉTRICA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1780
1780 -- 300619-01634 ELECTRIC ASSY;WIRING ELÉTRICO CONJ - D
1 310207-01176A HARNESS,MAIN CHICOTE DE FIOS, PRINCIPAL1
1A 2548-1027 . DIODE . DIODO CONJ 4
1B 548-00003A . DIODE . DIODO 1
1C K1000814 . DIODE;4 PIN . DIODO;ARRAY 1
1D K1000815 . DIODE;8 PIN . DIODO;ARRAY 1
2 2550-1014D1 TERMINAL;BATTERY(+) TERMINAL;BATERIA 2
3 2550-1014D2 TERMINAL;BATTERY(-) TERMINAL;BATERIA 2
4 2160-1212 CAP;BATT. TML (+) CAPA,BATERIA TERMINAL 2
5 2160-1213 CAP;BATT. TML (-) CAPA,BATERIA TERMINAL 2
7 S0511653 BOLT PARAFUSO,HEX 2
8 S5102603 WASHER,SPRING ARRUELA,MOLA 2
9 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 2
10 2553-1275D39 CABLE;EARTH CABO,BATERIA ENCALHE 1
11 S0511653 BOLT PARAFUSO,HEX 2
12 S5102603 WASHER,SPRING ARRUELA,MOLA 2
13 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 2
16 2553-1275D81 CABLE;BATT RY-STARTER CABO,BATERIA RETRANSMITIR1
17 2195-3500 BRACKET SUPORTE,HABITAÇÃO 6
18 S0504453 BOLT M6X1.0X12 PARAFUSO,HEX 6
19 S5102303 WASHER;SPRING ARRUELA,MOLA 6
20 2197-1660 BRACKET SUPORTE,HABITAÇÃO 1
21 2197-1661 BRACKET SUPORTE,HABITAÇÃO 11
24 2124-1509D1 CLIP GRAMPO 9
26 124-00208D2 CLIP GRAMPO 9
27 124-00208D3 CLIP GRAMPO 31
28 124-00208D4 CLIP GRAMPO 9
29 124-00208D5 CLIP GRAMPO 2
30 K1001029 BOLT PARAFUSO 64
31 310203-00020 CABLE,EARTH CABO,ENCALHE 1
32 2553-1275D6 CABLE;BATT-BATT CABO,BATERIA 1
33 2553-1275D138 CABLE,BATTERY RELAY CABO,ELÉTRICO;BATERIA 1
34 2553-1275D113 CABLE;BATTERY CABO,ELÉTRICO;BATERIA 1
DX225LCA 1780 - 2
Serial No. ;
HEATER PIPING(1)
TUBULAÇÃO DE AQUECIMENTO (1)
DATE DEC. 21, 2012
1st EDITION Fig. 1790
1790 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
HEATER PIPING(1)
TUBULAÇÃO DE AQUECIMENTO (1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1790
1790 -- K1001331E AIR CONDITIONER CONDICIONADOR DE AR - D
1 920-00127A UNIT;AIR CON. & HEATING CONDICIONADOR,AR 1
2 S0508653 BOLT PARAFUSO,HEX 6
3 S5102503 WASHER,SPRING ARRUELA,MOLA 6
4 2114-1058D29 WASHER ARRUELA,PLANÍCIE 6
5 S3450833 SCREW ROSCA,MÁQUINA;R/CABEÇA 4
6 S5000213 WASHER;PLAIN M5 ARRUELA,PLANÍCIE 4
7 2185-1308D5 HOSE;RUBBER MANGUEIRA,BORRACHA;AQUECEDOR1
8 2185-1308D5 HOSE;RUBBER MANGUEIRA,BORRACHA;AQUECEDOR1
10 S8450016 CLAMP BRAÇADEIRA,MANGUEIRA 2
DX225LCA 1790 - 2
Serial No. ;
HEATER PIPING(2)
TUBULAÇÃO DE AQUECIMENTO (2)
DATE DEC. 21, 2012
1st EDITION Fig. 1800
1800 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
HEATER PIPING(2)
TUBULAÇÃO DE AQUECIMENTO (2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1800
1800 -- K1045898 AIR CONDITIONER CONDICIONADOR DE AR - D
1 2181-2774 NIPPLE;HOSE BICO,MANGUEIRA 2
2 S8450016 CLAMP BRAÇADEIRA,MANGUEIRA 2
3 2181-1159 ADAPTER ADAPTADOR 1
4 2181-1160A ADAPTER ADAPTADOR 1
5 2181-1161A ADAPTER ADAPTADOR 1
6 S8180411 SEAL;COPPER SELO 1
7 124-00208D7 CLIP GRAMPO2
8 K1001029 BOLT PARAFUSO 2
9 547-00024A SENSOR;AMBENT SENSOR,TEMPERATURA;AMBIENTE1
DX225LCA 1800 - 2
Serial No. ;
AIRCON UNIT
UNIDADE DE AR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION Fig. 1810
1810 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
AIRCON UNIT
UNIDADE DE AR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1810
1810 -- 920-00127A UNIT;AIR CON. & HEATING CONDICIONADOR,AR 1
1 K1002206 MOTOR;BLOWER;24V MOTOR,SOPRADOR 1
2 K1002207 POWER FET CONTROLADOR;SOPRADOR VELOCIDADE1
3 K1002208 RELAY;BLOWER 24V RETRANSMITIR 1
4 K1002209 RELAY;AIRCON 24V RETRANSMITIR 1
5 K1002210 FILTER;AIR CON. FILTRO,AR CONDICIONADOR1
6 K1002211 SENSOR;TEMP EVAPORATOR SENSOR,TEMPERATURA 1
7 K1002212 SENSOR;TEMPERATURE SENSOR,TEMPERATURA 1
8 K1002213 SENSOR;WATER TEMP SENSOR,TEMPERATURA 1
9 K1002214 CORE;HEATER CORDEL;AQUECEDOR 1
10 K1002215 EVAPORATOR EVAPORADOR 1
11 K1002216 HARNESS;AIR CONDITIONER ARNÊS;AR CONDICIONADOR1
12 K1002217 ACTUATOR;INTAKE ATUADOR;ENTRADA 1
13 K1002218 ACTUATOR;AIR MIX ATUADOR;AR MIX 1
14 K1002219 ACTUATOR;MODE ATUADOR;MODO 1
DX225LCA 1810 - 2
Serial No. ;
AIRCONDITIONER
AIR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION Fig. 1820
1820 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
AIRCONDITIONER
AIR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1820
1820 -- 440213-00333 VENTILATION ASSY;AIR CON VENTILAÇÃO CONJ;AR CON - D
2 2204-6039A RECEIVER DRIER SECADOR,RECEPTOR 1
3 S0508666 BOLT PARAFUSO,HEX 2
4 S5102503 WASHER,SPRING ARRUELA,MOLA 2
5 2197-1798C BRACKET;COMPRESSOR SUPORTE,COMPRESSOR 1
6 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 4
7 S5102503 WASHER,SPRING ARRUELA,MOLA 4
8 S0557166 BOLT PARAFUSO,HEX 4
9 2208-6013B COMPRESSOR COMPRESSOR,AR 1
10 S0712153 BOLT M10X1.25X28 PARAFUSO,HEX 1
11 S5102603 WASHER,SPRING ARRUELA,MOLA 1
12 S5010613 WASHER;PLAIN ARRUELA,PLANÍCIE 1
13 2107-6006 PULLEY ASS'Y;IDLE POLIA CONJ,INATIVO 1
14 S0759853 BOLT M10X1.25X115 PARAFUSO,HEX 2
15 S5102603 WASHER,SPRING ARRUELA,MOLA 2
16 520-00004 CONDENSER;AIR CON CONDENSADOR,AR CONDICIONADOR1
17 S0509366 BOLT PARAFUSO,HEX 4
18 S5102503 WASHER,SPRING ARRUELA,MOLA 4
19 2114-1058D29 WASHER ARRUELA,PLANÍCIE 4
20 K1001277C HOSE;DISCHARGE MANGUEIRA,DESCARREGAR1
20A 2180-6088 . O-RING;DISCHARGE . ANEL,O;DESCARREGAR 1
20B K1011384 . O-RING;CONDENSER . ANEL,O 1
20C 1.161-00018 . CAP;CHECK PORT(H) . CAPA;AR CONDICIONADOR 1
22 420102-00239 HOSE;LIQUID(1) MANGUEIRA,AR CONDICIONADOR1
22A K1011388 . O-RING . ANEL,O 2
24 124-00208D3 CLIP GRAMPO 3
25 124-00209D1 CLIP GRAMPO 4
26 K1001029 BOLT PARAFUSO 7
27 S0504666 BOLT M6X1.0X16 PARAFUSO,HEX 1
28 S5010303 WASHER ARRUELA,PLANÍCIE 1
29 2114-1058D52 WASHER ARRUELA,PLANÍCIE 1
30 2106-1019D10 V-BELT 4PK 990L CINTO,V 1
31 2120-2187 BOLT;STUD PARAFUSO,TACHÃO 1
32 S5102503 WASHER,SPRING ARRUELA,MOLA 1
33 S4012303 NUT PORCA 2
34 S5102303 WASHER;SPRING ARRUELA,MOLA 2
35 S5000313 WASHER;PLAIN ARRUELA,PLANÍCIE 2
91 543-00107 CONTROL PANEL;AIR CON PAINEL,CONTROLE;AR CONDICIONADOR1
DX225LCA 1820 - 2
Serial No. ;
AIRCONDITIONER
AIR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION Fig. 1820
1820 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
AIRCONDITIONER
AIR-CONDICIONADO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1820
1820 -92 K1001278C HOSE;SUCTION MANGUEIRA,AR CONDICIONADOR;SUCÇÃO1
92A 2180-6086 . O-RING;SUCTION . ANEL,O;SUCÇÃO 1
92B K1011385 . O-RING;EVAPORATOR . ANEL,O 1
92C 1.161-00019 . CAP;CHECK PORT(L) . CAPA 1
93 K1001280C HOSE;LIQUID(2) MANGUEIRA,LÍQUIDO 1
93A K1011388 . O-RING . ANEL,O 2
DX225LCA 1820 - 4
Serial No. ;
WORKING LAMP(2-LAMP)
FAROL (2 LÂMPADAS)
DATE DEC. 21, 2012
1st EDITION Fig. 1830
1830 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
WORKING LAMP(2-LAMP)
FAROL (2 LÂMPADAS)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1830
1830 -- K1007403B WORKING LAMP-2 LAMP LÂMPADA CONJ,TRABALHO;ADICIONAL- D
1 534-00085 LAMP;HEAD LÂMPADA,CABEÇA 2
1A 2515-1016D4 . BULB;HALOGEN . BULBO 1
2 530-00430A HARNESS;FRONT CABIN LAMP ARNÊS,LÂMPADA;FRENTE CABINE1
3 195-02908E BRACKET;FRONT LAMP SUPORTE,LÂMPADA 1
4 2120-2166D54 BOLT;GREEN M12X1.75X20 PARAFUSO,HEX 2
5 2114-1898D6 WASHER;PLAIN ARRUELA,PLANÍCIE 2
10 549-00103 SWITCH;ROCKER(2STEP) INTERRUPTOR,BALANCIM 1
11 K1002406D13 ACTUATOR;SWITCH ATUADOR,INTERRUPTOR 1
DX225LCA 1830 - 2
Serial No. ;
WORKING LAMP - REAR
FAROL TRASEIRO
DATE DEC. 21, 2012
1st EDITION Fig. 1840
1840 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
WORKING LAMP - REAR
FAROL TRASEIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1840
1840 -- K1007405 WORKING LAMP-REAR LAMP LÂMPADA CONJ,TRABALHO;ADICIONAL- D
1 530-00431 HARNESS;REAR LAMP ARNÊS,LIGAÇÃO;TRASEIRA TRABALHO LÂ1
2 195-02775A PLATE SUPORTE 1
3 S0508853 BOLT PARAFUSO,HEX 2
4 S5102503 WASHER,SPRING ARRUELA,MOLA 2
5 2197-1661 BRACKET SUPORTE,HABITAÇÃO 1
6 2124-1509D1 CLIP GRAMPO 3
7 534-00085 LAMP;HEAD LÂMPADA,CABEÇA 1
7A 2515-1016D4 . BULB;HALOGEN . BULBO 1
8 K1001029 BOLT PARAFUSO 3
DX225LCA 1840 - 2
Serial No. ;
ROTATING BEACON
FAROL ROTATIVO
DATE DEC. 21, 2012
1st EDITION Fig. 1850
1850 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ROTATING BEACON
FAROL ROTATIVO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1850
1850 -- 300705-00013C BEACON ASSY,ROTATING SINAL LUMINOSO CONJ,ROTATIVO;LAMPADA 6- D
1 131002-00085A BUSHING ASSY BUCHA CONJ 1
2 S5102503 WASHER,SPRING ARRUELA,MOLA 1
3 S0508853 BOLT PARAFUSO,HEX 1
4 530-00464 HARNESS;ROTATING BEACON ARNÊS;ROTATIVO SINAL TABULEIRO LUM1
5 300705-00037 LAMP;ROTATING BEACON SINAL LUMINOSO,ROTATIVO 1
5A 300710-00023 . BULB;STROBE . BULBO;STROBE 1
20 549-00101 SWITCH;ROCKER(1STEP) INTERRUPTOR,BALANCIM 1
21 K1002406D3 ACTUATOR ATUADOR,INTERRUPTOR;SINAL LUMINOSO1
DX225LCA 1850 - 2
Serial No. ;
TRAVEL ALARM
ALARME DE DESLOCAÇÃO
DATE DEC. 21, 2012
1st EDITION Fig. 1860
1860 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL ALARM
ALARME DE DESLOCAÇÃO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 1860
1860 -- 300619-01069 ELECTRIC ASSY;ALARM ELÉTRICO CONJ - D
1 549-00103 SWITCH;ROCKER(2STEP) INTERRUPTOR,BALANCIM 1
2 K1002406D14 ACTUATOR;SWITCH ATUADOR,INTERRUPTOR;ALARME1
3 516-00011 BUZZER;ALARM SIRENE 1
4 S0508653 BOLT PARAFUSO,HEX 2
5 S5010513 WASHER,PLAIN ARRUELA,PLANÍCIE 2
6 S5102503 WASHER,SPRING ARRUELA,MOLA 2
7 2544-9033 RELAY RETRANSMITIR 1
DX225LCA 1860 - 2
Serial No. ;
TRACK FRAME
ESTEIRA
DATE DEC. 21, 2012
1st EDITION Fig. 2100
2100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK FRAME
ESTEIRA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2100
2100 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
2 140109-00048 BEARING,SWING ROLAMENTO,OSCILANTE 1
2A 401107-00751 . SEAL,SWING BEARING . SELO,OSCILANTE ROLAMENTO2
9 200112-00076 GUARD,TRACK GUARDA, FAIXA 4
10 621-02938B COVER TAMPA 1
11 180-00463 PACKING EMPANQUE 1
12 621-03166COVER TAMPA,INTERNA;C/F 1
13 621-03167 COVER;MOTOR TAMPA,MOTOR;ESQUERDA 2
14 422-00055 VALVE;GREASE VÁLVULA,GRAXA 2
15 S0515366 BOLT PARAFUSO,HEX 4
17 S0571166 BOLT PARAFUSO,HEX 4
18 S0721466 BOLT M16X1.5X40 PARAFUSO,HEX 16
19 S0766066 BOLT M16X1.5X90 PARAFUSO,HEX 72
20 S0770266 BOLT M20X1.5X70 PARAFUSO,HEX 36
22 DS0025016 BOLT;SET PARAFUSO 2
23 DS0025019 BOLT;SET PARAFUSO 12
25 S5102903 WASHER,SPRING ARRUELA,MOLA 16
27 2114-9012A WASHER ARRUELA,RÍGIDO 44
28 S4013133 NUT PORCA 4
101 160617-00231A FRAME ASSY,TRACK QUADRO,FAIXA 1
DX225LCA 2100 - 2
Serial No. ;
TRAVEL DEVICE
DISPOSITIVO DE CURSO
DATE DEC. 21, 2012
1st EDITION Fig. 2110
2110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL DEVICE
DISPOSITIVO DE CURSO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2110
2110 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
3 170401-00039B DEVICE,TRAVEL DISPOSITIVO,VIAGEM 2
4 200108-00095 SPROCKET DENTE DE RODA 2
16 S0565666 BOLT M16X2.0X70 PARAFUSO,HEX 60
21 120-00050B BOLT;FLANGE PARAFUSO,HEX 60
26 2114-1816A WASHER ARRUELA,RÍGIDO 60
DX225LCA 2110 - 2
Serial No. ;
IDLER
RODA GUIA
DATE DEC. 21, 2012
1st EDITION Fig. 2120
2120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
IDLER
RODA GUIA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2120
2120 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
5 200101-00045 ADJUSTER ASSY,TRACK AJUSTADOR CONJ,FAIXA 2
5-1 200101-00046 . SPRING ASSY,TRACK . MOLA CONJ,FAIXA 1
5-2 200102-00082 . IDLER ASSY . TENSOR ASSY 1
5-2A - .. BODY .. CORPO,CILINDRO 1 D
5-2B 110958-02139 .. SUPPORT .. APOIO 2
5-2C 130712-01144 .. SHAFT .. EIXO 1
5-2D 130702-00152 .. BUSHING,SHAFT .. BUCHA 2
5-2E 401107-00632 .. SEAL;GROUP .. SELO,FLUTUANTE 2
5-2F S8010700 .. O-RING .. ANEL,O 2
5-2G 2123-1011 .. PIN .. PINO 2
5-2H 2181-1116D9 .. PLUG PT1/4 .. BUJAO 2
5-3 S0565466 . BOLT . PARAFUSO,HEX 4
5-4 S5102903 . WASHER,SPRING . ARRUELA,MOLA 4
DX225LCA 2120 - 2
Serial No. ;
TRACK SPRING
ROLETE
DATE DEC. 21, 2012
1st EDITION Fig. 2130
2130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK SPRING
ROLETE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2130
2130 -- 200101-00046 SPRING ASSY,TRACK MOLA CONJ,FAIXA 1
2 110406-02589 BRACKET SUPORTE 1
3 160601-00903 BODY,CYLINDER CORPO,CILINDRO 1
4 400337-00478 ROD,CYLINDER HASTE,CILINDRO 1
5 120311-00145 NUT,LOCK PORCA 1
6 110951-00998 SPACER ESPAÇADOR 1
7 111601-00588 SPRING MOLA 1
8 - RING;GUIDE ANEL,POEIRA 2 D
9 - U-PACKING EMPANQUE,U 1 D
10 - RING;WEAR ANEL,DESGASTE 1 D
11 400337-00479 ROD,PISTON HASTE,CILINDRO 1
12 120501-02552 PIN,SPRING PINO 1
13 - O-RING ANEL,O 1 D
DX225LCA 2130 - 2
Serial No. ;
UPPER ROLLER
RODANTE SUPERIOR
DATE DEC. 21, 2012
1st EDITION Fig. 2140
2140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
UPPER ROLLER
RODANTE SUPERIOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2140
2140 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
6 200105-00043 ROLLER,UPPER ROLETE,SUPERIOR 4
6-1 - . BODY . CORPO,CILINDRO 1 D
6-2 130712-01145 . SHAFT,UPPER ROLLER . EIXO 1
6-3 140107-00508 . BEARING,TAPER ROLLER . ROLAMENTO,ROLETE 2
6-4 110508-14220 . COVER . TAMPA 1
6-5 S8010755 . O-RING 1BG-75 . ANEL,O 1
6-6 401111-00035 . SEAL GROUP . SELO,FLUTUANTE 1
6-8 120312-00429 . NUT . PORCA 1
6-9 401003-00516 . RING,LOCKING . ANEL 1
6-10 401003-00517 . RING,THRUST . ANEL, IMPULSO 1
6-11 S0512066 . BOLT M10X1.5X25 . PARAFUSO,HEX 3
6-12 2181-1116D1 . PLUG . BUJAO,VERIFIQUE NOVAMENTE1
DX225LCA 2140 - 2
Serial No. ;
LOWER ROLLER
RODANTE INFERIOR
DATE DEC. 21, 2012
1st EDITION Fig. 2150
2150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LOWER ROLLER
RODANTE INFERIOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2150
2150 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
7 200104-00053 ROLLER,LOWER ROLETE,BAIXAR 18
7-1 - . BODY . CORPO,CILINDRO 1 D
7-2 110917-00477 . COLLAR;EXTERNAL . COLAR 1
7-3 110917-00478 . COLLAR;INTERNAL . COLAR 1
7-4 130712-01146 . SHAFT . EIXO 1
7-5 K1013713A . BUSHING . BUCHA 2
7-6 120501-02553 . PIN . PINO 2
7-7 2181-1116D1 . PLUG . BUJAO,VERIFIQUE NOVAMENTE1
7-8 S8010600 . O-RING . ANEL,O 2
7-9 401111-00036 . SEAL GROUP . SELO,FLUTUANTE 2
DX225LCA 2150 - 2
Serial No. ;
CENTER JOINT
JUNTA CENTRAL
DATE DEC. 21, 2012
1st EDITION Fig. 2160
2160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CENTER JOINT
JUNTA CENTRAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2160
2160 -- 650105-00104 UNDERCARRIAGE ASSY CONJUNTO DO TREM DE POUSO- D
8 400826-00011A JOINT,CENTER ARTICULAÇÃO, CENTRO 1
8-1 K1038791 . HUB . CUBO 1
8-2 K1038792 . SPINDLE . FUSO 1
8-3 K1038793 . COVER . TAMPA 1
8-4 K1038794 . SPACER . ESPAÇADOR 1
8-5 S6500600 . RING;RETAINER . ANEL,RETENÇÃO 1
8-6 S8000801 . O-RING . ANEL,O 1 K
8-7 - . SEAL;DUST . SELO,POEIRA 1 K
8-8 - . SEAL;SLIPPER . SELO,PANTUFA 7 K
8-9 S8011000 . O-RING . ANEL,O 1 K
8-10 S8001050 . O-RING . ANEL,O 1 K
8-11 K9006884 . SHIM . CALÇO 1
8-12 K9006883 . SHIM . CALÇO 1
8-13 S0515253 . BOLT M12X1.75X30 . PARAFUSO,HEX 4
8-14 S5102703 . WASHER;SPRING . ARRUELA,MOLA 4
8-15 2181-1116D2 . PLUG . BUJAO,VERIFIQUE NOVAMENTE1
* 401107-01330 SEAL KIT,CENTER JOINT SELO 1
DX225LCA 2160 - 2
Serial No. ;
TRACK SHOE ASS'Y - 600G
Sapata - 600G
DATE DEC. 21, 2012
1st EDITION Fig. 2170
2170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK SHOE ASS'Y - 600G
Sapata - 600G
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2170
2170 -- 200106-00385 SHOE ASSY,TRACK;600MM SAPATA CONJ,FAIXA 2
1 200103-00125 LINK ASSY,TRACK LINK ASSY, FAIXA 1
1A 101539-00255 . LINK;R.H . TIRANTE,GUIA;DIREITO 49
1B 101539-00256 . LINK;L.H . TIRANTE,GUIA;ESQUERDA 49
1E 120501-02554 . PIN . PINO 48
1F 120501-02555 . PIN,MASTER . PINO 1
1G 131002-00517 . BUSHING . BUCHA 48
1H 131002-00518 . BUSHING MASTER . BUCHA 1
1I 401103-00120 . SEAL,DUST . SELO,POEIRA 96
1J K1038374 . SPACER . ESPAÇADOR 2
2 120112-01199 BOLT,TRACK PARAFUSO,HEX 196
3 120312-00430 NUT,TRACK PORCA 196
4 200106-00467 SHOE,TRACK;600G SAPATA,FAIXA 49
DX225LCA 2170 - 2
Serial No. ;
TRAVEL PIPING
TUBUAÇÃO DE CIRCULAÇÃO
DATE DEC. 21, 2012
1st EDITION Fig. 2180
2180 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL PIPING
TUBUAÇÃO DE CIRCULAÇÃO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 2180
2180 -- 420212-06994 PIPING,UNDERCARRIAGE TUBULAÇÃO, TREM DE POUSO- D
1 DS2112002 HOSE MANGUEIRA 4
3 DS2092177 HOSE MANGUEIRA 2
4 DS2054217 HOSE MANGUEIRA 2
5 2181-9078 FLANGE FLANGE 8
6 2181-9081 FLANGE;SPLIT FLANGE,CISÃO 8
7 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
8 S2215466 BOLT;SOCKET M12X1.75X40 PARAFUSO,HEX SOQUETE 16
9 2180-1026D19 O-RING ANEL,O 8
10 S8000181 O-RING ANEL,O 3
11 2181-2281D10 TEE T 1
12 2181-1126D6 ADAPTER ADAPTADOR 2
13 2181-1126D14 ADAPTERADAPTADOR,S 1
14 S8000111 O-RING ANEL,O 3
15 2181-4125 TEE T 1
16 160-00069 BUSHING;RUBBER BUCHA,BORRACHA 2
17 2181-1702D56 ELBOW COTOVELO 2
DX225LCA 2180 - 2
Serial No. ;
BOOM MOUNTING
Suporte Da LANÇA
DATE DEC. 21, 2012
1st EDITION Fig. 3100
3100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM MOUNTING
Suporte Da LANÇA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3100
3100 -- 650102-00122 FRONT ASSY,GENERAL FRENTE ASSY, GERAL - D
2 120501-01812 PIN,BOOM FOOT PINO,BOOM PE 1
3 120501-01061 PIN PINO;LANÇA CYL CABEÇA 2
11 2180-1106BD24 SEAL;DUST SELO,POEIRA 4
12 DS7752018 SHIM CALÇO,POLÍMERO 2
13 DS7752012 SHIM CALÇO,POLÍMERO 4
14 621-03710A PLATE;STOPPER PLACA,ROLHA 1
16 2116-1060D6 STOPPER ROLHA 2
17 S0521366 BOLT PARAFUSO,HEX 4
18 S5102903 WASHER,SPRING ARRUELA,MOLA 4
22 DS7752093 SHIM CALÇO,POLÍMERO 2
23 DS7752013 SHIM CALÇO,POLÍMERO 4
24 DS7752028 SHIM CALÇO,POLÍMERO 2
DX225LCA 3100 - 2
Serial No. ;
BOOM - 5.7m
LANÇA - 5.7M
DATE DEC. 21, 2012
1st EDITION Fig. 3110
3110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM - 5.7m
LANÇA - 5.7M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3110
3110 -- 230207-00238 BOOM ASSY LANÇA,MÁQUINA - D
1 230211-00168 BOOM,MACHINE;(5.7M) LANÇA,MÁQUINA 1
1A 131008-00140 . BUSHING,SINTERING . BUCHA 4
1B 2180-1106BD6 . SEAL;DUST . SELO,POEIRA 2
4 K1007253B PIN PINO,CENTRAL;BOOM 1
5 2123-2185G PIN PINO;LANÇA FINAL,LANÇA À BRAÇO1
6 120501-01062 PIN PINO;BRAÇO CYL CABEÇA/HASTE1
7 2116-1531A STOPPER ROLHA 2
8 S0567066 BOLT PARAFUSO,HEX 2
9 S4012933 NUT PORCA 4
10 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
11 2180-1106BD24 SEAL;DUST SELO,POEIRA 6
12 DS7752018 SHIM CALÇO,POLÍMERO 2
13 DS7752012 SHIM CALÇO,POLÍMERO 2
14 621-03710A PLATE;STOPPER PLACA,ROLHA 1
16 2116-1060D6 STOPPER ROLHA 1
17 S0521366 BOLT PARAFUSO,HEX 3
18 S5102903 WASHER,SPRING ARRUELA,MOLA 3
23 DS7752013 SHIM CALÇO,POLÍMERO 2
24 DS7752026 SHIM CALÇO,POLÍMERO 2
25 DS7752027 SHIM CALÇO,POLÍMERO 2
26 DS7752025 SHIM CALÇO,POLÍMERO;POLÍMERO4
27 DS7752017 SHIM CALÇO,POLÍMERO 2
28 DS7752093 SHIM CALÇO,POLÍMERO 2
DX225LCA 3110 - 2
Serial No. ;
ARM - 2.9m
BRAÇO - 2.9M
DATE DEC. 21, 2012
1st EDITION Fig. 3120
3120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM - 2.9m
BRAÇO - 2.9M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3120
3120 -- 230201-00104 ARM ASS'Y BRAÇO,MÁQUINA - D
1 230204-00083G ARM,MACHINE;2.9M BRAÇO,MÁQUINA 1
1A 131008-00064A . BUSHING . BUCHA;BRAÇO TIRANTE 2
1B 131004-00023A . BUSHING,CARBURIZING . BUCHA 2
1C 131004-00024A . BUSHING,CARBURIZING . BUCHA 2
2 101541-00021B LINK ASSY,PUSH TIRANTE,EMPURRE 1
2A 131004-00026A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
2B 131004-00025A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
3 101540-00056 LINK;GUIDE(R.H) TIRANTE,GUIA;DIREITO 1
4 2155-1300B LINK;GUIDE(L.H) TIRANTE,GUIA 1
7 120501-01063 PIN PINO;BRAÇO CYL HASTE 1
8 120501-01064 PIN PINO;CAÇAMBA CYL CABEÇA1
9 120501-01065 PIN PINO;BRAÇO TIRANTE RESSALTO1
10 120501-01052 PIN PINO;BRAÇO TIRANTE À CAÇAMBA2
11 120501-02429 PIN;BUCKET CYL ROD PINO;CAÇAMBA CYL HASTE 1
12 2180-1106BD4 SEAL;DUST SELO,POEIRA 2
13 2180-1106BD24 SEAL;DUST SELO,POEIRA 14
14 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
15 DS7752012 SHIM CALÇO,POLÍMERO 8
16 DS7752013 SHIM CALÇO,POLÍMERO 8
17 DS7752006 SHIM CALÇO,POLÍMERO 2
18 DS7752007 SHIM CALÇO,POLÍMERO 2
19 2116-1060D6 STOPPER ROLHA 2
20 S0521366 BOLT PARAFUSO,HEX 2
21 S5102903 WASHER,SPRING ARRUELA,MOLA 2
22 S4012933 NUT PORCA 8
23 DS0001084 BOLT PARAFUSO,HEX 3
24 DS0001083 BOLT PARAFUSO,HEX 1
25 S6710041 NIPPLE;GREASE APROPRIADO 7
26 180-00077D5 O-RING ANEL,O 2
27 K1000911 SPACER ESPAÇADOR 2
29 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 7
30 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
31 S0712066 BOLT PARAFUSO,HEX 12
34 180-00077D3 O-RING ANEL,O 2
DX225LCA 3120 - 2
Serial No. ;
BUCKET ASS'Y - 1.24m³(54") - SIDE PIN
Caçamba - 1,24M³(54") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 3130
3130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.24m³(54") - SIDE PIN
Caçamba - 1,24M³(54") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3130
3130 -- 230104-01269 BUCKET ASS'Y-1.24m³(H.D) CAÇAMBA CONJ 1
1 K1013111A BUCKET;WITH TOOTH-1.24㎥ CAÇAMBA;COM DENTE 1 D
1A 230104-01271 . BUCKET;WELD-1.24㎥ . CAÇAMBA,SOLDE;54" 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 5
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 5
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 5
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 5
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 3130 - 2
Serial No. ;
BOOM PIPING
TUBULAÇÃO DE LANÇA
DATE DEC. 21, 2012
1st EDITION Fig. 3140
3140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING
TUBULAÇÃO DE LANÇA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3140
3140 -- K1041795 BOOM PIPING TUBULAÇÃO DE BOOM - D
4 K1033273 PIPE TUBO 1
5 K1033274 PIPE TUBO 1
6 K1033265 PIPE TUBO 1
7 K1033267 PIPE TUBO 1
8 K1033266 PIPE TUBO 1
9 K1033268 PIPE TUBO 1
10 DS2040610 HOSE MANGUEIRA,ÓLEO 1
11 DS2038190 HOSE MANGUEIRA 1
12 124-00367 CLAMP;PIPE BRAÇADEIRA,TUBO 4
13 124-00300 CLAMP;PIPE BRAÇADEIRA,TUBO 2
15 124-00368 CLAMP;PIPE BRAÇADEIRA,TUBO 2
17 S0562766 BOLT PARAFUSO,HEX 24
18 S5102803 WASHER;SPRING ARRUELA,MOLA 24
19 161-00574 RUBBER BORRACHA;3/4" TUBO 9
20 161-00281 RUBBER BORRACHA;1" TUBO 1
21 S2212566 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
22 2180-1026D2 O-RING ANEL,O 6
23 2181-9078 FLANGE FLANGE 8
24 2180-1026D19 O-RING ANEL,O 4
25 2181-9079 FLANGE FLANGE 8
26 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 20
28 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 12
51 S0562766 BOLT PARAFUSO,HEX 4
52 S5102803 WASHER;SPRING ARRUELA,MOLA 4
61 124-00302 CLAMP;PIPE BRAÇADEIRA,TUBO 16
62 124-00303 CLAMP;PIPE BRAÇADEIRA,TUBO 4
71 400309-00341A CYLINDER,BOOM;(L.H) CILINDRO,LANÇA;LH 1
72 400309-00343A CYLINDER,BOOM;(R.H) CILINDRO,LANÇA;RH 1
81 400305-00219 CYLINDER,ARM CILINDRO,BRAÇO 1
DX225LCA 3140 - 2
Serial No. ;
LUBRICATION PIPING - BOOM
TUBULAÇÃO DE LUBRIFICAÇÃO - LANÇA
DATE DEC. 21, 2012
1st EDITION Fig. 3150
3150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - BOOM
TUBULAÇÃO DE LUBRIFICAÇÃO - LANÇA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3150
3150 -- 420212-02750 PIPING,BOOM;LUBRICATION TUBULAÇÃO, BOOM - D
1 K1038814 PIPE TUBO 1
2 K1038815 PIPE TUBO 1
3 DS2053864 HOSE MANGUEIRA 1
4 2184-1045D126 HOSE MANGUEIRA 1
5 2184-1045D254 HOSE MANGUEIRA 1
6 2181-1925 ELBOW COTOVELO 2
7 S3524403 PLUG ROSCA 1
11 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 5
13 2181-4112 ADAPTER ADAPTADOR 3
14 124-00199D4 CLIP GRAMPO 2
15 2124-1353D2 CLIP GRAMPO 3
16 K1001029BOLT PARAFUSO 5
18 K1038003 GREASE PLATE ASS'Y PLACA,FRENTE 1
18-1 K1037887 . PLATE . PLACA,FRENTE 1
18-2 181-00525 . REDUCER . REDUTOR 2
18-3 S4032833 . NUT . PORCA 2
18-4 181-00103 . REDUCER . REDUTOR 3
18-5 121-00006 . NUT . PORCA 3
18-6 S6710041 . NIPPLE;GREASE . APROPRIADO 5
19 S0511866 BOLT PARAFUSO,HEX 2
20 S5102603 WASHER,SPRING ARRUELA,MOLA 2
DX225LCA 3150 - 2
Serial No. ;
ARM PIPING
TUBULAÇÃO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION Fig. 3160
3160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING
TUBULAÇÃO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3160
3160 -- 420212-08004 PIPING,ARM TUBULAÇÃO, BRAÇO - D
1 400310-00214 CYLINDER;BUCKET CILINDRO,CAÇAMBA;2.9 BRAÇO1
3 2181-9079 FLANGE FLANGE 8
4 2180-1026D2 O-RING ANEL,O 4
5 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 8
6 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 8
11 DS2130014 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO2
DX225LCA 3160 - 2
Serial No. ;
LUBRICATION PIPING - ARM
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO
DATE DEC. 21, 2012
1st EDITION Fig. 3170
3170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - ARM
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 3170
3170 -- 420212-08037 PIPING,LUBRICATION;2.9M TUBULAÇÃO, LUBRIFICAÇÃO - D
1 DS2055849 HOSE MANGUEIRA 1
2 DS2059595 HOSE PF1/4-310L MANGUEIRA CONJ,HIDRÁULICO1
3 DS2225009 ADAPTER ADAPTADOR 1
4 2181-1184 ADAPTER ADAPTADOR 4
5 K1001029 BOLT PARAFUSO 7
6 DS2802023 CLIP GRAMPO 5
7 S6710041 NIPPLE;GREASE APROPRIADO 4
8 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 4
9 K1010730 ELBOW COTOVELO 2
11 DS2805007 CLIP GRAMPO 1
12 S4032833 NUT PORCA 3
13 2181-1923D12 ADAPTER ADAPTADOR 2
14 420205-00241A PIPE TUBO 1
15 K1047302 PIPE TUBO 1
16 420205-00393 PIPE,LUBRICATION TUBO 1
17 K1047304 PIPE TUBO 1
18 420207-02037 PIPE TUBO 1
19 DS2805008 CLIP GRAMPO 1
20 2181-4112 ADAPTER ADAPTADOR 2
DX225LCA 3170 - 2
Serial No. ;
MAIN PUMP
BOMBA PRINCIPAL
DATE DEC. 21, 2012
1st EDITION Fig. 4100
4100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PUMP
BOMBA PRINCIPAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4100
4100 -- 400914-00212 PUMP,MAIN BOMBA,PRINCIPAL 1
11 1.409-00167 PISTON & SHOE ASS`Y PISTÃO&SAPATA CONJ 2
13 1.451-00063 CYLINDER ASS'Y(R) BLOCO CONJ;CILINDRO 1
14 1.451-00060 CYLINDER ASS'Y(L) BLOCO CONJ;CILINDRO 1
30 284-00005 SWASH PLATE ASS`Y PLACA,SWASH 2
41 K9001849 CHECK 1 ASS`Y VÁLVULA CONJ,CHECAR 2
42 K9001850 CHECK 2 ASS`Y VÁLVULA,CHECAR 2
79 420-00127 VALVE;PROPORTIONAL VÁLVULA,EPPR 1
111 1.405-00060 SHAFT;DRIVING(F) EIXO,ACIONAMENTO 1
113 405-00008 SHAFT;DRIVING(R) EIXO,ACIONAMENTO 1
114 101-00006 GEAR ENGRENAGEM,SOL;NO.1 1
123 109-00097 BEARING;ROLLER ROLAMENTO,ROLETE 2
124 109-00098 BEARING;SPACER ROLAMENTO,AGULHA 2
127 1.109-00124 SPACER;BEARING ESPAÇADOR,ROLAMENTO 4
153 1.412-00083 PLATE;PUSH PLACA,EMPURRE 2
156 408-00013 BUSH;SPHERICAL BUCHA,ESFÉRICA 2
157 129-00044 SPRING;CYLINDER MOLA 18
158 114-00228 SPACER ESPAÇADOR 2
211 412-00006 PLATE;SHOE PLACA,SAPATA 2
250 1.197-00005 SUPPORT KIT APOIO KIT 1
251 195-00463 SUPPORT APOIO;SWASH 2
261 1.430-00212 COVER;SEAL(F) TAMPA;SELO,FRENTE 1
271 402-00026A CASING;PUMP CASO;BOMBA 2
312 100201-00158 BLOCK,VALVE BLOCO,VÁLVULA 1
401 S2229071 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA8
406 S2208871 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
466 2181-1950D5 PLUG PF3/4 BUJAO,VERIFIQUE NOVAMENTE4
467 2181-1950D2 PLUG BUJAO,VERIFIQUE NOVAMENTE2
468 2181-1890D2 PLUG BUJAO 2
490 181-00519 PLUG BUJAO 18 D
530 123-00150 TILTING PIN ASS`Y PINO;INCLINAÇÃO 2
532 409-00003 PISTON;SERVO PISTÃO,SERVO 2
534 416-00004 STOPPER(L) ROLHA 2
535 416-00005 STOPPER(S) ROLHA 2
702 S8010355 O-RING ANEL,O 2 K
710 S8010951 O-RING ANEL,O 3 K
717 S8011451 O-RING ANEL,O 4 K
724 S8000081 O-RING ANEL,O 16 K
DX225LCA 4100 - 2
Serial No. ;
MAIN PUMP
BOMBA PRINCIPAL
DATE DEC. 21, 2012
1st EDITION Fig. 4100
4100 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PUMP
BOMBA PRINCIPAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4100
4100 -725 S8000111 O-RING ANEL,O 2 K
727 S8000141 O-RING ANEL,O 2 K
728 S8000241 O-RING ANEL,O 4 K
732 S8000185 O-RING ANEL,O 2 K
774 401106-00179 SEAL,OIL SELO,ÓLEO 1 K
789 S8060181 RING;BACKUP ANEL,BACKUP 2 K
792 S8090350 RING;BACK-UP ANEL,BACKUP 2 K
806 S4012933 NUT PORCA 2
808 S4013133 NUT PORCA 2
824 S6500400 RING;RETAINING ANEL,RETENÇÃO;EIXO,C TIPO2
885 123-00151 PIN D8X12L PINO 2
886 S5740870 PIN;SPRING PINO,MOLA 4
901 S3140025 BOLT;EYE PARAFUSO,OLHAL 2
953 S3527808 SCREW;SET M16X30L ROSCA 2
954 120-00130 SCREW;ADJUST ROSCA,AJUSTADOR 2
985 K9001852 COVER TAMPA 1
986 S2212061 BOLT;SOCKET M10X1.5X25 PARAFUSO,HEX SOQUETE 4
* K9001902A SEAL KIT;MAIN PUMP SELO KIT;PRINCIPAL BOMBA 1
DX225LCA 4100 - 4
Serial No. ;
REGULATOR
REGULADOR
DATE DEC. 21, 2012
1st EDITION Fig. 4110
4110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
REGULATOR
REGULADOR
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4110
4110 -- K9001833 REGULATOR ASS`Y REGULADOR CONJ 2
412 S2209661 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA2
413 S2210071 BOLT;SOCKET PARAFUSO,HEX SOQUETE 2
436 S2205261 BOLT;SOCKET M6X1.0X30 PARAFUSO,HEX SOQUETE CABEÇA2
438 S2204861 BOLT;SOCKER PARAFUSO,HEX SOQUETE CABEÇA10
496 181-00318 PLUG BUJAO 5
601 1.402-00055 CASING(A) CASO 1 D
611 1.357-00014 LEVER;FEEDBACK(A) ALAVANCA 1 D
612 1.357-00005 LEVER 1(A) ALAVANCA 1 D
613 1.357-00008 LEVER 2(B) ALAVANCA 1 D
614 1.181-00136 PLUG;CENTER(A) BUJAO,APOIO 1 D
615 1.181-00090 PLUG;ADJUST(A) BUJAO 1 D
621 1.409-00189 PISTON;COMPEN PISTÃO;COMPENSAÇÃO 1 D
622 1.402-00036 CASE;PISTON CASO,PISTÃO 1 D
623 1.428-00208 ROD;COMPEN HASTE;COMPEN 1 D
624 1.131-00165 SEAT;SPRING(C) MOLA,LUGAR 1 D
625 1.131-00143 SPRING;OUTER PRIMAVERA; EXTERIOR 1 D
626 1.131-00139 SPRING;INNER PRIMAVERA; INTERNA 1 D
627 K9001834 RING;ADJUST(C) ANEL,AJUSTADOR 1 D
628 K9001835 SCREW;ADJUST(C) ROSCA,AJUSTADOR 1 D
629 K9001836 COVER C(A) TAMPA 1 D
630 1.121-00044 NUT;LOCK PORCA,FECHADURA 1 D
631 K9001837 SLEEVE;PF MANGA 1 D
641 K9001838 COVER;PILOT TAMPA;PILOTO 1 D
643 1.409-00204 PISTON;PILOT PISTÃO,PILOTO 1 D
644 1.131-00170 SEAT;SPRING(Q) MOLA,LUGAR 1 D
645 1.115-00171 RING;ADJUST(Q) ANEL,AJUSTADOR 1 D
646 1.131-00157 SPRING;PILOT PRIMAVERA;PILOTO 1 D
651 1.425-00001 SLEEVE MANGA 1 D
652 1.424-00038 SPOOL(A) CANILHA 1 D
653 1.131-00166 SEAT;SPRING MOLA,LUGAR 1 D
654 1.131-00160 SPRING;RETURN PRIMAVERA;RETORNO 1 D
655 1.131-00172 SPRING;SET PRIMAVERA;CONJUNTO 1 D
656 1.430-00017 COVER TAMPA 1 D
708 S8010755 O-RING 1BG-75 ANEL,O 1 K
722 S8000061 O-RING ANEL,O 3 K
724 S8000085 O-RING ANEL,O 9 K
725 S8000111 O-RING ANEL,O 1 K
DX225LCA 4110 - 2
Serial No. ;
REGULATOR
REGULADOR
DATE DEC. 21, 2012
1st EDITION Fig. 4110
4110 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
REGULATOR
REGULADOR
DATEDEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4110
4110 -728 S8000181 O-RING ANEL,O 1 K
730 S8000221 O-RING ANEL,O 1 K
732 S8000161 O-RING ANEL,O 1 K
733 S8000201 O-RING ANEL,O 1 K
734 S8010251 O-RING ANEL,O 1 K
735 S8002721 O-RING ANEL,O 1 K
755 S8000111 O-RING ANEL,O 2 K
756 S8000261 O-RING ANEL,O 1 K
763 S8010351 O-RING ANEL,O 1 K
801 S4012533 NUT PORCA,HEX 2
814 S6500100 RING;SNAP ANEL,RETENÇÃO 1
836 1.115-00366 RING;STOP ANEL,PARE 1 D
858 S6510150 RING;SNAP ANEL,RETENÇÃO 2
874 1.123-00007 PIN PINO 1
875 1.123-00012 PIN(A) PINO 2 D
876 1.123-00014 PIN(A) PINO 2 D
887 1.123-00009 PIN PINO 1 D
897 1.123-00016 PIN(A) PINO 1 D
898 K9001839 PIN PINO 1 D
924 S3524008 SCREW;SET ROSCA 1
925 120-00199 SCREW;ADJUST(Qi) ROSCA,AJUSTADOR 1
DX225LCA 4110 - 4
Serial No. ;
GEAR PUMP
BOMBA DE ENGRENAGEM
DATE DEC. 21, 2012
1st EDITION Fig. 4120
4120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
GEAR PUMP
BOMBA DE ENGRENAGEM
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4120
4120 -- K9001811 PUMP;GEAR BOMBA CONJ,ENGRENAGEM1
307 1.426-00005 POPPET BONECA 1
308 1.427-00002 SEAT LUGAR 1
309 180-00211 RING ANEL 1
310 129-00045 SPRING MOLA 1
311 120-00131 SCREW;ADJUSTING ROSCA,AJUSTADOR 1
312 121-00038 NUT;LOCK PORCA,FECHADURA 1
351 - CASE;GEAR CASO 1 D
353 1.403-00037 GEAR;DRIVE ENGRENAGEM,ACIONAMENTO1 D
354 1.403-00040 GEAR;DRIVEN ENGRENAGEM,ACIONAMENTO1 D
355 471-00030 FILTER FILTRO;ENGRENAGEM BOMBA1
361 1.402-00017 CASE;FRONT CASO,FRENTE 1 D
433 S2209666 BOLT;SOCKET PARAFUSO,HEX SOQUETE 2
434 S2209961 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA2
435 S2208871 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
466 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
700 115-00043 RING ANEL,QUADRADO 1 K
710 S8010951 O-RING ANEL,O 1 K
725 S8000111 O-RING ANEL,O 1 K
732 S8000161 O-RING ANEL,O 1 K
850 S6510180 RING;SNAP ANEL,RETENÇÃO 1
* 719212KT SEAL KIT;GEAR PUMP SELO KIT;ENGRENAGEM BOMBA1
DX225LCA 4120 - 2
Serial No. ;
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION Fig. 4130
4130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4130
4130 -- 170303-00049B MOTOR,SWING MOTOR,OSCILANTE 1
101 - CASING;VALVE CASO 1 D
102 2.121-00009 PLUG BUJAO 2
103 K9001840 SPRING MOLA 2
104 K9001841 PLUNGER ÊMBOLO 2
105 410116-00410 VALVE;SWING REACTIONLESS VÁLVULA 1
106 S8000341 O-RING ANEL,O 2 K
107 410127-00095 VALVE,RELIEF VÁLVULA,ALÍVIO 2
108 S6005050 BEARING;BALL ROLAMENTO,BOLA 1
109 S2227561 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA4
110 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE2
111 S8000111 O-RING ANEL,O 2 K
112 K9001842 O-RING ANEL,O 1 K
113 S5741162 PIN;SPRING PINO,MOLA 2
201 K9001843 SHAFT;DRIVE EIXO,ACIONAMENTO 1
202 412-00011 PLATE;SHOE PLACA,SAPATA 1
203 K9001845 PISTON & SHOE ASS`Y PISTÃO&SAPATA CONJ 1
205 150102-00439 BLOCK,CYLINDER BLOCO 1
206 1.148-00015 BALL;THRUST BOLA,IMPULSO 1
207 1.412-00092 PLATE;RETAINER PLACA,RETENTOR 1
208 1.114-00009 COLLAR COLAR,ARRUELA 1
209 1.109-00134 ROLLER ROLAMENTO,ROLETE 5
210 1.114-00286 WASHER ARRUELA 2
211 1.131-00048 SPRING MOLA 1
212 S6510620 RING;SNAP ANEL,RETENÇÃO 1
213 250201-01934 PLATE;TIMING PLACA 1
301 K9008334A CASE CASO 1
302 401106-00181 SEAL,OIL SELO,ÓLEO 1 K
303 K9008335 BEARING;ROLLER ROLAMENTO,ROLETE 1
305 352-00014 PLATE;SEPARATION PLACA,SEPARADOR 3
306 412-00013 PLATE;FRICTION PLACA,FRICÇÃO 2
307 180-00220 O-RING ANEL,O 1 K
308 180-00221 O-RING ANEL,O 1 K
309 452-00020 PISTON;BRAKE PISTÃO,FREIO 1
310 129-00062 SPRING;BRAKE MOLA 18
311 2181-1116D4 PLUG BUJAO,VERIFIQUE NOVAMENTE1
312 2181-1116D2 PLUG BUJAO,VERIFIQUE NOVAMENTE1
400 410102-00024 VALVE,BRAKE VÁLVULA,FREIO 1
DX225LCA 4130 - 2
Serial No. ;
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION Fig. 4130
4130 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SWING MOTOR
MOTOR DE GIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4130
4130 -* K9008336A SEAL KIT;SWING MOTOR SELO KIT 1
DX225LCA 4130 - 4
Serial No. ;
SWING REDUCTION GEAR
ENGRENAGEM DE REDUÇÃO DE GIRO
DATE DEC. 21, 2012
1st EDITION Fig. 4140
4140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SWING REDUCTION GEAR
ENGRENAGEM DE REDUÇÃO DE GIRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4140
4140 -- 130426-00010 GEAR ASSY,REDUCTION ENGRENAGEM CONJ,REDUÇÃO1
1 K1038206 CASING CASO 1
2 K1038207 SHAFT;DRIVE EIXO,ACIONAMENTO 1
3 2412-1040 PLATE ANEL,NILOS 1
4 2109-9033 BEARING;ROLLER ROLAMENTO,ROLETE;ESFÉRICA1
5 K1038685 PLATE;COVER PLACA 1
6 S6500380 RING;SNAP ANEL,RETENÇÃO 4
7 2180-1254 SEAL;OIL SELO,ÓLEO 1
8 109-00174 BEARING;ROLLER ROLAMENTO,CILINDRO 1
9 130422-00001A GEAR,RING ENGRENAGEM,ANEL 1
10 K1038205 CARRIER NO.2 VEÍCULO;NO2 1
11 2114-1901A WASHER;THRUST NO.2 ARRUELA,IMPULSO 4
12 104-00050 GEAR;PLANET NO.2 ENGRENAGEM,PLANETÁRIO;NO24
13 110-00219 BUSH NO.2 BUCHA 4
14 K1038208 PIN NO.2 PINO 4
15 S5741200 PIN;SPRING PINO,MOLA 4
16 S0121061 BOLT PARAFUSO,HEX 1
17 114-00548 WASHER;THRUST NO.3 ARRUELA,IMPULSO 1
18 104-00048 GEAR;SUN NO.2 ENGRENAGEM,SOL;NO2 1
19 2705-1030 PIN;KNOCK PINO,BATIDA 4
20 100502-00001 CARRIER NO.1 VEÍCULO 1
21 114-00527 WASHER;THRUST NO.1 ARRUELA,IMPULSO 4
22 130424-00001 GEAR;PLANET NO.1 ENGRENAGEM;NO1 4
23 120501-00009 PIN ASS'Y;NO1 PINO CONJ;NO1 4
24 120107-00002 BOLT,HEX SOCKET PARAFUSO,HEX SOQUETE 16
25 130425-00001 GEAR,SUN;NO1 ENGRENAGEM,SOL;NO1 1
26 S6500450 RING;SNAP ANEL,PARE 1
27 2181-1116D2 PLUG BUJAO,VERIFIQUE NOVAMENTE2
28 2181-1116D4 PLUG BUJAO,VERIFIQUE NOVAMENTE1
29 2140-1406 PIPE;LEVEL GAUGE TUBO;NÍVEL BITOLA 1
30 2119-1065 GAUGE;LEVEL BITOLA,NÍVEL 1
31 120811-00001 WASHER,DOUBLE TAB ARRUELA,REDUÇÃO ENGRENAGEM1
32 120-00144 BOLT PARAFUSO,HEX 8
33 120816-00001 WASHER,THRUST ARRUELA,IMPULSO;NO4 1
51 100502-00022 CARRIER ASS'Y;NO.1 VEÍCULO CONJ;NO.1 1
52 K9008338 CARRIER NO2 ASS`Y VEÍCULO CONJ 1
DX225LCA 4140 - 2
Serial No. ;
TRAVEL MOTOR
MOTOR DE DESLOCAMENTO
DATE DEC. 21, 2012
1st EDITION Fig. 4150
4150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL MOTOR
MOTOR DE DESLOCAMENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4150
4150 -C 300609-00069 CONTROL PART ASSY CONTROLE CONJ,ELETRONICO1
C-1 430215-00552 . FLANGE ASS'Y;REAR . FLANGE CONJ 1
C-2 K9007409A . FLANGE KIT;REAR . FLANGE KIT;TRASEIRA 1
C-3 110956-00060 . STOPPER . ROLHA 2
1 - REAR FLANGE FLANGE TRASEIRO 1 D
23 410207-00307 SPOOL,MAIN CANILHA,PRINCIPAL 1
24 1.181-00059 PLUG;FOR MAIN BUJAO 2
26 1.181-00067 PLUG;CHECK BUJAO 2
27 1.420-00013 VALVE;CHECK VÁLVULA,CHECAR 2
28 1.131-00058 SPRING;FOR MAIN MOLA 2
30 1.129-00006 SPRING;CHECK MOLA 2
36 S8000321 O-RING ANEL,O 2 K
37 S8002731 O-RING ANEL,O 2 K
41 S5700891 PIN;PARALLEL PINO,PARALELO 1
43 S2221471 BOLT;SOCKET PARAFUSO,HEX SOQUETE 12
46 S8000181 O-RING ANEL,O 2 K
52 2181-1890D2 PLUG BUJAO 4
54 2181-1116D10 PLUG BUJAO 5
63 2181-1890D4 PLUG BUJAO,VERIFIQUE NOVAMENTE2
65 1.424-00041 SPOOL;2SPEED CANILHA 1
66 111601-00354 SPRING MOLA 1
68 S6250182 BALL;STEEL BOLA,AÇO 2
71 1.415-00005 ORIFICE ORIFÍCIO 1
74 S8000111 O-RING ANEL,O 4 K
79 1.471-00001A FILTER FILTRO 1
91 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE2
- 170403-00134 MOTOR,TRAVEL MOTOR,VIAGEM 1
200 400701-00004 CYL BLOCK & PISTON KIT CILINDRO BLOCO&PISTÃO CONJ1
205 K9007406A PISTON ASSY PISTÃO CONJ 1
204 K9007397 BLOCK;CYLINDER BLOCO,CILINDRO 1
207 K9004447 PLATE;RETAINER PLACA,FRENTE 1
208 K9004448 BALL;THRUST BOLA,IMPULSO 1
202 K9007415A SHAFT,DRIVE EIXO,ACIONAMENTO 1
203 K9007382 PLATE;SWASH PLACA,SWASH 1
209 K9007398A PLATE,TIMING PLACA,CRONOMETRAGEM 1
212 K9004453 PISTON;PARKING PISTÃO,ESTACIONAMENTO 1
213 1.131-00049A SPRING MOLA 12
214 K9004449 SPRING MOLA 1
DX225LCA 4150 - 2
Serial No. ;
TRAVEL MOTOR
MOTOR DE DESLOCAMENTO
DATE DEC. 21, 2012
1st EDITION Fig. 4150
4150 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL MOTOR
MOTOR DE DESLOCAMENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4150
4150 -215 412-00013 PLATE;FRICTION PLACA,FRICÇÃO 2
216 352-00014 PLATE;SEPARATION PLACA,SEPARADOR 2
232 K9007401 SEAL;OIL SELO,ÓLEO 1 K
235 S8001801 O-RING ANEL,O 1 K
239 S8002101 O-RING ANEL,O 1 K
242 1.123-00053 PIN;PARALLEL PINO,PARALELO 4
247 S8061800 RING;BACK UP ANEL,BACKUP 1 K
248 S8062100 RING;BACK UP ANEL,BACKUP 1 K
249 K9007400 BEARING;BALL ROLAMENTO,BOLA 1
250 1.109-00026 BEARING;BALL ROLAMENTO,BOLA 1
260 130602-00200 PISTON KIT;2 SPEED PISTÃO KIT 1
261 111601-00117 SPRING,SPEED-ADJUSTING MOLA,VELOCIDADE AJUSTADOR1
267 1.540-00006 PIVOT PIVÔ 2
275 S8000081 O-RING ANEL,O 2 K
400 410127-00190 VALVE ASSY,RELIEF VÁLVULA CONJ,ALÍVIO 2
401 - PLUNGER ÊMBOLO 1 D
402 1.180-00527 SEAL;PISTON SELO,PISTÃO 1
403 - BODY CORPO,CILINDRO 1 D
404 S8060161 RING;BACK-UP ANEL,BACKUP 2
405 S8000161 O-RING ANEL,O 3
406 S8010291 O-RING ANEL,O 1
407 - RETAINER;SPRING RETENTOR;PRIMAVERA 1 D
408 - SPRING MOLA 1 D
409 - PISTON PISTÃO 1 D
410 S8000221 O-RING ANEL,O 2
411 S8060221 RING;BACK UP ANEL,BACKUP 3
412 - PLUG;ADJUST BUJAO 1 D
413 - NUT;LOCK PORCA,FECHADURA 1 D
* K9008310 SEAL KIT;TRAVEL MOTOR SELO KIT;VIAGEM MOTOR 1
DX225LCA 4150 - 4
Serial No. ;
TRAVEL REDUCTION GEAR
ENGRENAGEM DE REDUÇÃO DE VELOCIDADE
DATE DEC. 21, 2012
1st EDITION Fig. 4160
4160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRAVEL REDUCTION GEAR
ENGRENAGEM DE REDUÇÃO DE VELOCIDADE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4160
4160 -- 170402-00028 REDUCTION GEAR ENGRENAGEM CONJ,REDUÇÃO,VIAGEM1
38 S8000181 O-RING ANEL,O 3 K
101 K9007383A SPINDLE FUSO 1
102 1.180-00512 SEAL;FLOATING SELO,FLUTUANTE 1
105 900122-00079 HUB CUBO 1
106 1.540-00003 PIECE;DISTANCE PEDAÇO,DISTANCIA;DISTANCIA1
104 K9007412 CARRIER NO 2 ASSY VEÍCULO CONJ 1
103 - CARRIER NO2 VEÍCULO 1 D
108 K9007393 GEAR;PLANETARY ENGRENAGEM;PLANETÁRIO 4
109 K9007394 WASHER;THRUST ARRUELA,IMPULSO 8
110 S5740960 PIN;SPRING PINO,MOLA 4
111 K9007402 BEARING;NEEDLE ROLAMENTO,AGULHA 4
112 K9007396 BUSH;FLOATING BUCHA 4
113 K9007392 SHAFT EIXO 4
114 K9007391 GEAR;SUN ENGRENAGEM,SOL 1
115 S6500750 RING;RETAINING ANEL,RETENÇÃO 1
116 K9007411 CARRIER NO 1 ASSY VEÍCULO CONJ 1
107 K9007388 BEARING;SHAFT ROLAMENTO 3
117 K9007387 GEAR;PLANETARY ENGRENAGEM;PLANETÁRIO 3
118 1.216-00017 CAGE;NEEDLE GAIOLA,AGULHA 3
122 S5740770 PIN;SPRING PINO,MOLA 3
131 K9007389 WASHER;THRUST ARRUELA,IMPULSO 6
134 - CARRIER NO1. VEÍCULO 1 D
121 K9007390 GEAR;DRIVE ENGRENAGEM,ACIONAMENTO1
123 110508-09675 COVER TAMPA 1
124 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 16
125 K9007403 BEARING;ANGULAR BALL ROLAMENTO,BOLA 2
126 S8012300 O-RING ANEL,O 1 K
128 2181-1890D4 PLUG BUJAO,VERIFIQUE NOVAMENTE3
129 K9007386A RING;SEAL ANEL;SELO 1
130 1.180-00144 O-RING ANEL,O 1 K
132 K9004304 WASHER;THRUST ARRUELA,IMPULSO 1
133 1.412-00157 PLATE;THRUST PLACA,IMPULSO 1
136 K9007395A SHIM CALÇO 2
137 401002-00739 RING,O ANEL 1
DX225LCA 4160 - 2
Serial No. ;
CONTROL VALVE(1)
VÁLVULA DE CONTROLE(1)
DATE DEC. 21, 2012
1st EDITION Fig. 4170
4170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL VALVE(1)
VÁLVULA DE CONTROLE(1)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4170
4170 -- K1025391 VALVE;CONTROL VÁLVULA,CONTROLE 1
32 426-00168 POPET BONECA;LANÇA PRIORITÁRIO2
33 129-00126 SPRING MOLA,CHECAR 2
57 114-00414 SPACER ESPAÇADOR 1
60 181-00633 PLUG ASS'Y BUJAO CONJ 1
61 2181-2337D13 REDUCER REDUTOR 1
62 S8000141 O-RING ANEL,O 1 K
68 K9001804 VALVE;MAIN RELIEF VÁLVULA,PRINCIPAL ALÍVIO 1
69 420-00258 VALVE;OVERLOAD RELIEF VÁLVULA CONJ,SOBRECARGA ALÍVIO6
71 181-00565 PLUG ASS`Y BUJAO 1
72 181-00701 PLUG ASS`Y BUJAO 12
75 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 8
77 S2223266 BOLT;SOCKET M16X130L PARAFUSO,HEX SOQUETE 8
81 S5010913 WASHER,PLAIN ARRUELA,PLANÍCIE 8
88 2181-2434 FLANGE FLANGE 2
89 2180-1217D109 O-RING ANEL,O;DX CONTROLE VÁLVULA2 K
92 181-00647 PLUG ASS'Y BUJAO CONJ 1
93 181-00649 PLUG ASS'Y BUJAO CONJ 1
106 K9001805 VALVE;OVERLOAD RELIEF VÁLVULA,SOBRECARGA ALÍVIO2
* 420-00295KT SEAL KIT;CONTROL VALVE SELO KIT;CONTROLE VÁLVULA1
DX225LCA 4170 - 2
Serial No. ;
CONTROL VALVE(2)
VÁLVULA DE CONTROLE(2)
DATE DEC. 21, 2012
1st EDITION Fig. 4180
4180 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL VALVE(2)
VÁLVULA DE CONTROLE(2)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4180
4180 -- K1025391 VALVE;CONTROL VÁLVULA,CONTROLE 1
1 423-00096 HOUSING;VALVE HABITAÇÃO;DIREITO 1 D
2 424-00185 SPOOL ASS`Y-ARM2 ÊMBOLO CONJ;KVMG-S260 1
3 K9003671 SPOOL ASS'Y-BOOM1 CANILHA CONJ,LANÇA 1
4 424-00199 SPOOL ASS`Y-BUCKET ÊMBOLO CONJ;KVMG-S225 1
5 K9001807 SPOOL ASS`Y-TRAVEL BOBINA CONJ,VIAGEM 2
6 424-00115 SPOOL ASS`Y-T/S ÊMBOLO CONJ;KVMG270 1
7 S8010451 O-RING ANEL,O 20 K
8 430-00033 CAP CAPA,VÁLVULA 10
12 430-00035 CAP CAPA,VÁLVULA 10
13 423-00097 HOUSING;VALVE HABITAÇÃO;LH 1 D
14 K9003672 SPOOL ASS'Y-ARM1 CANILHA CONJ,BRAÇO 1
15 K9003673 SPOOL ASS'Y-BOOM2 CANILHA CONJ,LANÇA 1
16 K9001809 SPOOL ASS`Y-SWING BOBINA CONJ,OSCILANTE 1
17 K9001810 SPOOL ASS`Y-OPTION CANILHA CONJ,OPÇÃO 1
50 K9001199 PLUG BUJAO 1
62 S8000141 O-RING ANEL,O 1 K
63 415-00037 PLUG;ORIFICE ORIFÍCIO 1
65 180-00403 O-RING ANEL,O 14 K
66 180-00402 O-RING ANEL,O 7 K
70 420-00259 FOOT RELIFE VALVE VÁLVULA CONJ,PE ALÍVIO 2
72 181-00701 PLUG ASS`Y BUJAO 2
74 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 40
91 181-00646 PLUG BUJAO 1
105 181-00701 PLUG ASS`Y BUJAO 1
DX225LCA 4180 - 2
Serial No. ;
CONTROL VALVE(3)
VÁLVULA DE CONTROLE(3)
DATE DEC. 21, 2012
1st EDITION Fig. 4190
4190 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL VALVE(3)
VÁLVULA DE CONTROLE(3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4190
4190 -- K1025391 VALVE;CONTROL VÁLVULA,CONTROLE 1
18 430-00038 CAP CAPA 1
19 - SPOOL CANILHA 1 D
20 429-00024 SEAT;SPRING GUIA 2
21 129-00124 SPRING MOLA 1
22 430-00040 SPOOL END ROSCA,LUGAR 1
23 S8000261 O-RING ANEL,O 1 K
24A 420-00314. ARM REGEN ASS'Y . VÁLVULA,REGENERAÇÃO 1
24 430-00041 PLUG BUJAO;REGENERAÇÃO 1
25 S8000241 O-RING ANEL,O 1 K
26 129-00125 SPRING MOLA;REGENERAÇÃO 1
27 - SPOOL CANILHA 1 D
28 - SLEEVE MANGA 1 D
29 - PISTON PISTÃO 1 D
30 S8000161 O-RING ANEL,O 1 K
31 S8060161 RING;BACK-UP ANEL,BACKUP 2 K
34 426-00169 POPET BONECA,CARGA CHECAR 6
35 129-00127 SPRING MOLA;CARGA CHECAR 7
36 S8000321 O-RING ANEL,O 9 K
37 181-00628 FLANGE FLANGE 6
38 426-00170 POPET BONECA;TITULAR VÁLVULA 2
39 129-00128 SPRING MOLA 2
40 114-00411 SPACER ASS`Y ESPAÇADOR CONJ 2
41 S8000061 O-RING ANEL,O 2 K
42 S8000041 O-RING ANEL,O 2 K
43 181-00630 FLANGE FLANGE 1
44 426-00171 POPPET,LOAD CHECK BONECA,CARGA CHECAR 1
45 129-00130 SPRING MOLA;CARGA CHECAR 1
46 430-00042 PLUG BUJAO;TS ORIFÍCIO 1
47 180-00398 O-RING ANEL,O 1 K
48 129-00129 SPRING MOLA;ORIFÍCIO 1
49 426-00172 POPET BONECA;ORIFÍCIO 1
51 426-00173 POPET BONECA,CARGA CHECAR 1
52 181-00631 FLANGE FLANGE;M/R 2
53 114-00413 SPACER ESPAÇADOR 2
54 S8010250 O-RING ANEL,O 2 K
55 180-00445 RING;BACK-UP ANEL,BACKUP 2 K
67 420-00246 ANTI-DRIFT VALVE ASS'Y VÁLVULA,TITULAR;LANÇA&BRAÇO2
DX225LCA 4190 - 2
Serial No. ;
CONTROL VALVE(3)
VÁLVULA DE CONTROLE(3)
DATE DEC. 21, 2012
1st EDITION Fig. 4190
4190 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
CONTROL VALVE(3)
VÁLVULA DE CONTROLE(3)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4190
4190 -73 S2212766 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
75 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 28
76 S2213066 BOLT;SOCKET M10X1.5X70 PARAFUSO,HEX SOQUETE 8
78 S2204866 BOLT;SOCKET PARAFUSO,HEX SOQUETE 2
92 181-00647 PLUG ASS'Y BUJAO CONJ 1
94A 420-00309 . BOOM PRIORITY VALVE . VÁLVULA,BOOM PRIORITÁRIO2
94 430-00045 PLUG BUJAO;LANÇA PRIORITÁRIO 2
95 409-00049 PISTON PISTÃO;BM PRIORITÁRIO KVMG2702
96 - BODY CORPO,CILINDRO 2 D
97 409-00050 PISTON PISTÃO;BM PRIORITÁRIO KVMG2702
98 129-00139 SPRING MOLA;BM PRIORITÁRIO 2
99 - SLEEVE MANGA 2 D
100 426-00182 POPET ASS`Y BONECA CONJ 2
102 180-00400 O-RING ANEL,O 2 K
103 S8060121 RING;BACK UP ANEL,BACKUP 2 K
104 S8000121 O-RING ANEL,O 2 K
101 S2213466 BOLT;SOCKET M10X90 PARAFUSO,HEX SOQUETE 8
DX225LCA 4190 - 4
Serial No. ;
REMOTE CONTROL VALVE
VÁLVULA DE CONTROLE REMOTO
DATE DEC. 21, 2012
1st EDITION Fig. 4200
4200 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
REMOTE CONTROL VALVE
VÁLVULA DE CONTROLE REMOTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4200
4200 -- 410113-00022A VALVE,JOYSTICK(L.H) VÁLVULA,JOYSTICK;L.H 1
410113-00021A VALVE,JOYSTICK(R.H) VÁLVULA,JOYSTICK;R.H 1
1 K9001114 CASE CASO 1 D
2 2181-1116D2 PLUG BUJAO,VERIFIQUE NOVAMENTE4
3 K9001115 BUSHING BUCHA 1
4 K9001116 SPOOL CANILHA 4 D
5 1.114-00012 SHIM CALÇO;S290LC-V 1 D
6 K9001117 SPRING MOLA 2 D
7 K9001762 SEAT;SPRING MOLA,LUGAR 2 D
8 K9001763 STOPPER ROLHA 4 D
9 K9001119 SPRING MOLA 4
10 1.416-00017 STOPPER ROLHA 2 D
11 K9001121 SPRING MOLA 4 D
12 K9001766 ROD;PUSH PUSHROD 4 D
13 K9001123 SPRING MOLA 2 D
14 K9001767 SEAT;SPRING MOLA,LUGAR 2 D
15 1.416-00018 STOPPER ROLHA 2 D
16 K9001768 PLUG BUJAO 4 D
17 S8000205 O-RING ANEL,O 4
18 180-00198 SEAL;ROD SELO,HASTE 4
19 1.412-00017 PLATE PLACA 1
20 K9001128 BOOT BOTA 1
21 1.138-00004 JOINT ASS`Y LIGAÇÃO 1
22 K9001129A PLATE;SWASH PLACA,SWASH 1
23 1.121-00028 NUT PORCA,HEX 1
24 S4012833 NUT PORCA 1
25 K9001130 HANDLE ASS`Y(L.H) MAÇANETA CONJ;ESQUERDA1
K9001131 HANDLE ASS`Y(R.H) MAÇANETA CONJ;DIREITO 1
25A 1.161-00021 . CAP;PEANUT . CAPA;AMENDOIM 1
26 1.178-00004 BAR;HANDLE BARRA;MAÇANETA 1
27 S5740800 PIN;SPRING PINO,MOLA 1
28 K9001132 BELLOWS FOLES 1
29 1.110-00169 BUSHING BUCHA 1
30 K9001133 CONNECTOR ASS`Y CONECTOR 1
32 K9001001 SWITCH ASS`Y INTERRUPTOR 1
33 410207-00175 SPOOL KIT;(1,3) CANILHA KIT;1,3 1
34 410207-00176 SPOOL KIT;(2,4) CANILHA KIT;2,4 1
35 K9004000 KIT;PLUG(1,3) BUJAO KIT 1
DX225LCA 4200 - 2
Serial No. ;
REMOTE CONTROL VALVE
VÁLVULA DE CONTROLE REMOTO
DATE DEC. 21, 2012
1st EDITION Fig. 4200
4200 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
REMOTE CONTROL VALVE
VÁLVULA DE CONTROLE REMOTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4200
4200 -36 K9004001 KIT;PLUG(2,4) BUJAO KIT 1
37 K9001139 KIT;HANDLE(R.H) MAÇANETA KIT;DIREITO 1
K9001140 KIT;HANDLE(L.H) MAÇANETA KIT;ESQUERDA 1
DX225LCA 4200 - 4
Serial No. ;
PEDAL VALVE
VÁLVULA DE PEDAL
DATE DEC. 21, 2012
1st EDITION Fig. 4210
4210 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PEDAL VALVE
VÁLVULA DE PEDAL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4210
4210 -- 420-00467A VALVE;PEDAL VÁLVULA,PEDAL 1
1 - BODY CORPO,CILINDRO 1 D
2 - BODY CORPO,CILINDRO 1 D
3 420-00112 PLUG BUJAO 1
4 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE3
51 K9006863 KIT;SPOOL CANILHA KIT 4
5 429-00004 SEAT;SPRING MOLA,LUGAR 4
6 K9001141 SPRING MOLA 4
7 429-00005 SEAT;SPRING MOLA,LUGAR 4
8 424-00042 SPOOL CANILHA 4
9 161-00080 STOPPER ROLHA 4
10 K9006860 SPRING MOLA 4
11 S5740600 PIN;SPRING PINO,MOLA 4
12 S8000261 O-RING ANEL,O 4
52 K9006864 KIT;PLUG BUJAO KIT 4
13 - ROD;PUSH PUSHROD 4 D
14 S5740480 PIN;SPRING PINO,MOLA 4
15 - SEAL SELO 4 D
16 148-00012 BALL;STEEL BOLA,AÇO 4
17 129-00043 SPRING MOLA 4
18 159-00017 PLATE PLACA 4
19 115-00042 RING;SNAP ANEL,ESTALO 4
20 - PLUG BUJAO 4 D
21 S8010251 O-RING ANEL,O 4
22 180-00198 SEAL;ROD SELO,HASTE 4
23 180-00199 SEAL;DUST SELO,POEIRA 4
33 1.409-00225 PISTON PISTÃO 4
24 K9006865 KIT;COVER TAMPA 1
27 2110-1184D7 BUSH;DU 10X10 BUCHA,DU 4
25 S2210071 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
26 K9006866 KIT;CAM CAM KIT 2
28 K9006861 SHAFT;CAM EIXO DE CAM 2
32 K9006862 BELLOWS FOLES 2
34 S8000081 O-RING ANEL,O 1
35 S8000111 O-RING ANEL,O 1
DX225LCA 4210 - 2
Serial No. ;
SOLENOID VALVE
Solenóide
DATE DEC. 21, 2012
1st EDITION Fig. 4220
4220 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SOLENOID VALVE
Solenóide
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4220
4220 -- K1047557 VALVE;SOLENOID VÁLVULA,SOLENÓIDE 1
1 - BLOCK BLOCO 1 D
2 K9007363 SPOOL;SOLENOID CANILHA;SOLENÓIDE 3
3 1.519-00001 COIL 24V BOBINA 3
4 K9002065 VALVE;CHECK VÁLVULA,CHECAR 1
4A 1.180-00447 . KIT;SEAL . SELO KIT 1
5 2181-1950D1 PLUG BUJAO,VERIFIQUE NOVAMENTE4
DX225LCA 4220 - 2
Serial No. ;
BOOM CYLINDER - L.H.
CILÍNDRO DE LANÇA - L.E.
DATE DEC. 21, 2012
1st EDITION Fig. 4230
4230 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM CYLINDER - L.H.
CILÍNDRO DE LANÇA - L.E.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4230
4230 -- 400309-00341A CYLINDER,BOOM;(L.H) CILINDRO,LANÇA;LH 1
1 420406-01077 TUBE ASS'Y MANGUEIRA,CILINDRO 1
2 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
3 400337-00454 ROD ASS'Y HASTE,CILINDRO 1
4 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
5 K9001856 ROD;COVER TAMPA;HASTE 1
6 110-00079 DD-BUSH BUCHA,DU 1
7 115-00050 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001857 SEAL;BUFFER SELO;BUFFER1 K
9 K9001858 U-PACKING EMPANQUE,U 1 K
10 K9001877 RING;BACK UP ANEL,BACKUP 1 K
11 115-00059 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00051 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011201 O-RING ANEL,O 1 K
14 K9001859 RING;BACK UP ANEL,BACKUP 1 K
15 S8011251 O-RING ANEL,O 1 K
16 1.115-00204 RING;CUSHION ANEL,ALMOFADA 1
17 K9001860 PISTON PISTÃO;CILINDRO 1
18 K9001890 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00087 RING;WEAR ANEL,DESGASTE 2 K
20 K9001861 RING;DUST ANEL,POEIRA 1 K
21 S8010651 O-RING ANEL,O 1 K
22 1.180-00277 RING;BACK UP ANEL,BACKUP 2 K
23 K9001862 NUT;PISTON PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2222272 BOLT;SOCKET PARAFUSO,HEX SOQUETE 10
26 K9007358A BAND ASSY,PIPE CINTA CONJ,TUBO 1
27 124-00088 BAND;PIPE CINTA,TUBO 1
28 S5100603 WASHER;SPRING ARRUELA,MOLA 2
29 S0558153 BOLT PARAFUSO,HEX 2
30 K9007360A PIPE ASSY;H(L.H) TUBO CONJ;H(LH) 1
31 S8000281 O-RING ANEL,O 1
32 S5100603 WASHER;SPRING ARRUELA,MOLA 4
33 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
34 K9007368A PIPE ASSY;R(L.H) TUBO CONJ;R(LH) 1
35 S8000281 O-RING ANEL,O 1
36 S5100603 WASHER;SPRING ARRUELA,MOLA 4
37 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
DX225LCA 4230 - 2
Serial No. ;
BOOM CYLINDER - L.H.
CILÍNDRO DE LANÇA - L.E.
DATE DEC. 21, 2012
1st EDITION Fig. 4230
4230 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM CYLINDER - L.H.
CILÍNDRO DE LANÇA - L.E.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4230
4230 -38 1.124-00157 CLAMP;PIPE BRAÇADEIRA,TUBO 1
39 S5100703 WASHER;SPRING ARRUELA,MOLA 1
40 S0561053 BOLT M12X1.75X65 PARAFUSO,HEX 1
* K9001878 SEAL KIT;BOOM CYLINDER SELO CONJ;LANÇA CILINDRO1
DX225LCA 4230 - 4
Serial No. ;
BOOM CYLINDER - R.H.
CILÍNDRO DE LANÇA - L.D.
DATE DEC. 21, 2012
1st EDITION Fig. 4240
4240 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM CYLINDER - R.H.
CILÍNDRO DE LANÇA - L.D.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4240
4240 -- 400309-00343A CYLINDER,BOOM;(R.H) CILINDRO,LANÇA;RH 1
1 420406-01077 TUBE ASS'Y MANGUEIRA,CILINDRO 1
2 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
3 400337-00454 ROD ASS'Y HASTE,CILINDRO 1
4 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
5 K9001856 ROD;COVER TAMPA;HASTE 1
6 110-00079 DD-BUSH BUCHA,DU 1
7 115-00050 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001857 SEAL;BUFFER SELO;BUFFER 1 K
9 K9001858 U-PACKING EMPANQUE,U 1 K
10 K9001877 RING;BACK UP ANEL,BACKUP 1 K
11 115-00059 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00051 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011201 O-RING ANEL,O 1 K
14 K9001859 RING;BACK UP ANEL,BACKUP 1 K
15 S8011251 O-RING ANEL,O 1 K
16 1.115-00204 RING;CUSHION ANEL,ALMOFADA 1
17 K9001860 PISTON PISTÃO;CILINDRO 1
18 K9001890 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00087 RING;WEAR ANEL,DESGASTE 2 K
20 K9001861 RING;DUST ANEL,POEIRA 1 K
21 S8010651 O-RING ANEL,O 1 K
22 1.180-00277 RING;BACK UP ANEL,BACKUP 2 K
23 K9001862 NUT;PISTON PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2222272 BOLT;SOCKET PARAFUSO,HEX SOQUETE 10
26 K9007358A BAND ASSY,PIPE CINTA CONJ,TUBO 1
27 124-00088 BAND;PIPE CINTA,TUBO 1
28 S5100603 WASHER;SPRING ARRUELA,MOLA 2
29 S0558153 BOLT PARAFUSO,HEX 2
30 K9007359A PIPE ASSY;H(R.H) TUBO CONJ;H(RH) 1
31 S8000281 O-RING ANEL,O 1
32 S5100603 WASHER;SPRING ARRUELA,MOLA 4
33 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
34 K9007367A PIPE ASSY;R(R.H) TUBO CONJ;R(RH) 1
35 S8000281 O-RING ANEL,O 1
36 S5100603 WASHER;SPRING ARRUELA,MOLA 4
37 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
DX225LCA 4240 - 2
Serial No. ;
BOOM CYLINDER - R.H.
CILÍNDRO DE LANÇA - L.D.
DATE DEC. 21, 2012
1st EDITION Fig. 4240
4240 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM CYLINDER - R.H.
CILÍNDRO DE LANÇA - L.D.
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4240
4240 -38 1.124-00157 CLAMP;PIPE BRAÇADEIRA,TUBO 1
39 S5100703 WASHER;SPRING ARRUELA,MOLA 1
40 S0561053 BOLT M12X1.75X65 PARAFUSO,HEX 1
* K9001878 SEAL KIT;BOOM CYLINDER SELO CONJ;LANÇA CILINDRO1
DX225LCA 4240 - 4
Serial No. ;
ARM CYLINDER
CILÍNDRO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION Fig. 4250
4250 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM CYLINDER
CILÍNDRO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4250
4250 -- 400305-00219 CYLINDER,ARM CILINDRO,BRAÇO 1
1 420406-01072 TUBE ASS'Y MANGUEIRA,CILINDRO 1
2 131008-00130 BUSH BUCHA 1
3 400337-00452 ROD ASS`Y HASTE,CILINDRO 1
4 131008-00130 BUSH BUCHA 1
5 K9001881 ROD;COVER TAMPA;HASTE 1
6 110-00081 DD-BUSH BUCHA,DU 1
7 115-00073 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001882 SEAL;BUFFER SELO;BUFFER 1 K
9 K9001883 U-PACKING EMPANQUE,U 1 K
10 K9001884 RING;BACK UP ANEL,BACKUP 1 K
11 115-00077 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00078 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011351 O-RING ANEL,O 1 K
14 1.180-00662 RING;BACK UP ANEL,BACKUP 1 K
15 2180-1217D96 O-RING ANEL,O 1 K
16 K9001893 RING;CUSHION ANEL,ALMOFADA 1
17 K9001894 PISTON PISTÃO;BRAÇO CILINDRO 1
18 K9001148 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00079 RING;WEAR ANEL,DESGASTE 2 K
20 K9001149 RING;DUST ANEL,POEIRA 2 K
21 S8010801 O-RING ANEL,O 1 K
22 K9001895 RING;BACK UP ANEL,BACKUP 2 K
23 K9001896 NUT;RISTON PORCA,PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 K9001897 PLUNGER;CUSHION ÊMBOLO 1
26 115-00081 RING;STOP ROLHA 1
27 S2222272 BOLT;SOCKET PARAFUSO,HEX SOQUETE 14
28 1.420-00050 VALVE;CHECK VÁLVULA,CHECAR 1
29 129-00071 SPRING MOLA 1
30 1.195-00022 SUPPORT;SPRING APOIO;MOLA 1
31 2181-1116D3 PLUG;HEX. SOCKET BUJAO 1
32 K9001898 PIPE BAND ASS'Y-B CINTA CONJ,TUBO 1
33 124-00052 BAND;PIPE CINTA,TUBO 1
34 S5100703 WASHER;SPRING ARRUELA,MOLA 2
35 S0560563 BOLT;HEX PARAFUSO,HEX 2
36 K9001900 PIPE ASS`Y-R TUBO CONJ 1
37 S8000341 O-RING ANEL,O 1
DX225LCA 4250 - 2
Serial No. ;
ARM CYLINDER
CILÍNDRO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION Fig. 4250
4250 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM CYLINDER
CILÍNDRO DE BRAÇO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4250
4250 -38 S5100703 WASHER;SPRING ARRUELA,MOLA 4
39 S2215961 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA4
40 K9001158 U-BOLT PARAFUSO,U 1
41 S5100603 WASHER;SPRING ARRUELA,MOLA 2
42 S4012633 NUT PORCA,HEX 2
* K9001901 SEAL KIT;ARM CYLINDER SELO CONJ;BRAÇO CILINDROINDER1
DX225LCA 4250 - 4
Serial No. ;
BUCKET CYLINDER - ARM 2.9m
CILÍNDRO Da Caçamba - BRAÇO 2.9M
DATE DEC. 21, 2012
1st EDITION Fig. 4260
4260 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 2.9m
CILÍNDRO Da Caçamba - BRAÇO 2.9M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4260
4260 -- 400310-00214 CYLINDER;BUCKET CILINDRO,CAÇAMBA;2.9 BRAÇO1
1 420406-01074 TUBE ASS`Y MANGUEIRA,CILINDRO 1
2 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
3 400337-00453 ROD ASSY,CYLINDER HASTE,CILINDRO 1
4 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
5 K9001870 COVER;ROD TAMPA;HASTE 1
6 110-00097 DD-BUSH BUCHA,DU;BRAÇO 1
7 K9001401 RING;RETAINING ANEL,RETENÇÃO1
8 K9001402 SEAL;BUFFER SELO 1 K
9 K9001403 U-PACKING EMPANQUE,U 1 K
10 K9001404 RING;BACK UP ANEL,BACKUP 1 K
11 115-00084 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00063 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011151 O-RING ANEL,O 1 K
14 1.180-00278 RING;BACK UP ANEL,BACKUP 1 K
15 S8011201 O-RING ANEL,O 1 K
16 K9001406 RING;CUSHION ANEL,ALMOFADA 1
17 K9001871 PISTON PISTÃO 1
18 K9001891 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00055 RING;WEAR ANEL,DESGASTE 2 K
20 K9001872 RING;DUST ANEL,POEIRA 2 K
21 180-00276 O-RING ANEL,O 1 K
22 K9001410 RING;BACK UP ANEL,BACKUP 2 K
23 K9001862 NUT;PISTON PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2222171 BOLT;SOCKET M16X2.0X75 PARAFUSO,HEX SOQUETE 10
26 K9001873 PIPE BAND ASS`Y CINTA CONJ,TUBO 1
27 K9001874 BAND;PIPE CINTA,TUBO 1
28 S5100703 WASHER;SPRING ARRUELA,MOLA 2
29 S0560563 BOLT;HEX PARAFUSO,HEX 2
30 K9001875 PIPE ASS`Y-R TUBO CONJ 1
31 S8000281 O-RING ANEL,O 1
32 S5100603 WASHER;SPRING ARRUELA,MOLA 4
33 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
34 K9001413 CLAMP;PIPE BRAÇADEIRA,TUBO 1
35 S5100603 WASHER;SPRING ARRUELA,MOLA 1
36 S2221873 BOLT PARAFUSO,HEX SOQUETE 1
37 K9001876 PIPE ASS`Y-H TUBO CONJ 1
DX225LCA 4260 - 2
Serial No. ;
BUCKET CYLINDER - ARM 2.9m
CILÍNDRO Da Caçamba - BRAÇO 2.9M
DATE DEC. 21, 2012
1st EDITION Fig. 4260
4260 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 2.9m
CILÍNDRO Da Caçamba - BRAÇO 2.9M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4260
4260 -38 S8000281 O-RING ANEL,O 1
39 S5100603 WASHER;SPRING ARRUELA,MOLA 4
40 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
* K9001892 SEAL KIT;BUCKET CYLINDER SELO CONJ;CAÇAMBA CILINDRO1
DX225LCA 4260 - 4
Serial No. ;
BUCKET CYLINDER - ARM 2.4m
CILÍNDRO Da Caçamba - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION Fig. 4270
4270 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 2.4m
CILÍNDRO Da Caçamba - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4270
4270 -- 400310-00215 CYLINDER,BUCKET CILINDRO,CAÇAMBA 1
1 420406-01075 TUBE ASS'Y MANGUEIRA,CILINDRO 1
2 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
3 400337-00453 ROD ASSY,CYLINDER HASTE,CILINDRO 1
4 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
5 K9001870 COVER;ROD TAMPA;HASTE 1
6 110-00097 DD-BUSH BUCHA,DU;BRAÇO 1
7 K9001401 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001402 SEAL;BUFFER SELO 1 K
9 K9001403 U-PACKING EMPANQUE,U 1 K
10 K9001404 RING;BACK UP ANEL,BACKUP 1 K
11 115-00084 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00063 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011151 O-RING ANEL,O 1 K
14 1.180-00278 RING;BACK UP ANEL,BACKUP 1 K
15 S8011201 O-RING ANEL,O 1 K
16 K9001406 RING;CUSHION ANEL,ALMOFADA 1
17 K9001871 PISTON PISTÃO 1
18 K9001891 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00055 RING;WEAR ANEL,DESGASTE 2 K
20 K9001872 RING;DUST ANEL,POEIRA 2 K
21 180-00276 O-RING ANEL,O 1 K
22 K9001410 RING;BACK UP ANEL,BACKUP 2 K
23 K9001862 NUT;PISTON PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2222171 BOLT;SOCKET M16X2.0X75 PARAFUSO,HEX SOQUETE 10
26 K9001873 PIPE BAND ASS`Y CINTA CONJ,TUBO 1
27 K9001874 BAND;PIPE CINTA,TUBO 1
28 S5100703 WASHER;SPRING ARRUELA,MOLA 2
29 S0560563 BOLT;HEX PARAFUSO,HEX 2
30 K9003467 PIPE ASS'Y-R TUBO CONJ 1
31 S8000281 O-RING ANEL,O 1
32 S5100603 WASHER;SPRING ARRUELA,MOLA 4
33 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
34 K9001413 CLAMP;PIPE BRAÇADEIRA,TUBO 1
35 S5100603 WASHER;SPRING ARRUELA,MOLA 1
36 S2221873 BOLT PARAFUSO,HEX SOQUETE 1
37 K9003468 PIPE ASS'Y-H TUBO CONJ 1
DX225LCA 4270 - 2
Serial No. ;
BUCKET CYLINDER - ARM 2.4m
CILÍNDRO Da Caçamba - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION Fig. 4270
4270 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 2.4m
CILÍNDRO Da Caçamba - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4270
4270 -38 S8000281 O-RING ANEL,O 1
39 S5100603 WASHER;SPRING ARRUELA,MOLA 4
40 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
* K9001892 SEAL KIT;BUCKET CYLINDER SELO CONJ;CAÇAMBA CILINDRO1
DX225LCA 4270 - 4
Serial No. ;
BUCKET CYLINDER - ARM 3.5m
CILÍNDRO Da Caçamba - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION Fig. 4280
4280 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 3.5m
CILÍNDRO Da Caçamba - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4280
4280 -- 400310-00216 BUCKET CYLINDER CILINDRO,CAÇAMBA 1
1 420406-01076 TUBE ASS'Y MANGUEIRA,CILINDRO 1
2 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
3 400337-00453 ROD ASSY,CYLINDER HASTE,CILINDRO 1
4 131008-00067A BUSH BUCHA,SINTERIZAÇÃO 1
5 K9001870 COVER;ROD TAMPA;HASTE 1
6 110-00097 DD-BUSH BUCHA,DU;BRAÇO 1
7 K9001401 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001402 SEAL;BUFFER SELO 1 K
9 K9001403 U-PACKING EMPANQUE,U 1 K
10 K9001404 RING;BACK UP ANEL,BACKUP 1 K
11 115-00084 WIPER;DUST LIMPADOR,POEIRA 1 K
12 115-00063 RING;RETAINING ANEL,RETENÇÃO 1
13 S8011151 O-RING ANEL,O 1 K
14 1.180-00278 RING;BACK UP ANEL,BACKUP 1 K
15 S8011201 O-RING ANEL,O 1 K
16 K9001406 RING;CUSHION ANEL,ALMOFADA 1
17 K9001871 PISTON PISTÃO 1
18 K9001891 SEAL;SLIPPER SELO,PANTUFA 1 K
19 115-00055 RING;WEAR ANEL,DESGASTE 2 K
20 K9001872 RING;DUST ANEL,POEIRA 2 K
21 180-00276 O-RING ANEL,O 1 K
22 K9001410 RING;BACK UP ANEL,BACKUP 2 K
23 K9001862 NUT;PISTON PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2222171 BOLT;SOCKET M16X2.0X75 PARAFUSO,HEX SOQUETE 10
26 K9001873 PIPE BAND ASS`Y CINTA CONJ,TUBO 2
27 K9001874 BAND;PIPE CINTA,TUBO 2
28 S5100703 WASHER;SPRING ARRUELA,MOLA 4
29 S0560563 BOLT;HEX PARAFUSO,HEX 4
30 K9003470 PIPE ASS'Y-R TUBO CONJ 1
31 S8000281 O-RING ANEL,O 1
32 S5100603 WASHER;SPRING ARRUELA,MOLA 4
33 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
34 K9001413 CLAMP;PIPE BRAÇADEIRA,TUBO 2
35 S5100603 WASHER;SPRING ARRUELA,MOLA 2
36 S2221873 BOLT PARAFUSO,HEX SOQUETE 2
37 K9003471 PIPE ASS'Y-H TUBO CONJ 1
DX225LCA 4280 - 2
Serial No. ;
BUCKET CYLINDER - ARM 3.5m
CILÍNDRO Da Caçamba - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION Fig. 4280
4280 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 3.5m
CILÍNDRO Da Caçamba - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4280
4280 -38 S8000281 O-RING ANEL,O 1
39 S5100603 WASHER;SPRING ARRUELA,MOLA 4
40 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
* K9001892 SEAL KIT;BUCKET CYLINDER SELO CONJ;CAÇAMBA CILINDRO1
DX225LCA 4280 - 4
Serial No. ;
BUCKET CYLINDER - ARM 6.2m
CILÍNDRO Da Caçamba - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION Fig. 4290
4290 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 6.2m
CILÍNDRO Da Caçamba - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4290
4290 -- K1011434A BUCKET CYLINDER CILINDRO,CAÇAMBA 1
1 K9001753 TUBE ASS`Y MANGUEIRA CONJ 1
2 K1004106 BUSH;ROLLED BUCHA;CAÇAMBA CILINDRO CABEÇA1
3 K9001754A ROD ASS`Y HASTE,CILINDRO 1
4 K1004106BUSH;ROLLED BUCHA;CAÇAMBA CILINDRO CABEÇA1
5 110508-00989 COVER,ROD TAMPA,HASTE 1
6 1.110-00068 DD-BUSH BUCHA;DD 1
7 1.115-00032 RING;RETAINING ANEL,RETENÇÃO 1
8 K9001424 SEAL;BUFFER SELO,BUFFER 1 K
9 K9001425 U-PACKING EMPANQUE,U 1 K
10 K9001426 RING;BACK UP ANEL,BACKUP 1 K
11 1.180-00496 WIPER;DUST SELO,POEIRA LIMPADOR 1 K
12 115-00052 RING;RETAINING ANEL,RETENÇÃO 1
13 S8010901 O-RING ANEL,O 1 K
14 K9001427 RING;BACK UP ANEL,BACKUP 1 K
15 S8010951 O-RING ANEL,O 1 K
16 K9001428 RING;CUSHION ANEL,ALMOFADA 1
17 K9001429 PISTON PISTÃO 1
18 K9001430 SEAL;SLIPPER SELO,PANTUFA 1 K
19 1.180-00415 RING;WEAR ANEL,DESGASTE 2 K
20 K9001431 RING;DUST ANEL,POEIRA 2 K
21 1.180-00117 O-RING ANEL,O 1 K
22 K9001374 BACK UP RING ANEL,BACKUP 2 K
23 K9001375 NUT;PISTION PORCA;PISTÃO 1
24 1.120-00219 SCREW;SET ROSCA 1
25 S2218961 BOLT PARAFUSO,HEX SOQUETE CABEÇA8
26 K9001755 PIPE BAND ASS`Y CINTA CONJ,TUBO 2
27 S5100703 WASHER;SPRING ARRUELA,MOLA 4
28 S0560563 BOLT;HEX PARAFUSO,HEX 4
29 K9001756 PIPE ASS`Y-H TUBO CONJ 1
30 S8000251 O-RING SELO,O-ANEL 1
31 S5100703 WASHER;SPRING ARRUELA,MOLA 4
32 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
33 K9001757 PIPE ASS`Y-R TUBO CONJ 1
34 S8000251 O-RING SELO,O-ANEL 1
35 S5100703 WASHER;SPRING ARRUELA,MOLA 4
36 S2212761 BOLT;SOCKET M10X1.5X55 PARAFUSO,HEX SOQUETE 4
37 K9001158 U-BOLT PARAFUSO,U 2
DX225LCA 4290 - 2
Serial No. ;
BUCKET CYLINDER - ARM 6.2m
CILÍNDRO Da Caçamba - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION Fig. 4290
4290 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET CYLINDER - ARM 6.2m
CILÍNDRO Da Caçamba - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 4290
4290 -38 S5100603 WASHER;SPRING ARRUELA,MOLA 4
39 S4012633 NUT PORCA,HEX 4
40 S6710032 NIPPLE;GREASE BICO,GRAXA 2
* K9001752 SEAL KIT;BUCKET CYL. SELO CONJ;CAÇAMBA_T30_OPÇÃO1
DX225LCA 4290 - 4
Serial No. ;
TOOLS
FERRAMENTAS
DATE DEC. 21, 2012
1st EDITION Fig. 5100
5100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TOOLS
FERRAMENTAS
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5100
5100 -- K1007832 TOOL ASS'Y FERRAMENTA CONJ - D
1 2199-1063F34C TOOL ASSY FERRAMENTA CONJ 1
1-1 2199-9043 . BOX;TOOL . CAIXA,FERRAMENTA 1 D
1-2 T6580008 . WRENCH;ADJUSTABLE 6' . REPELÃO,AJUSTADOR ÂNGULO1 D
1-3 T6580020 . WRENCH;ADJUST . REPELÃO,AJUSTADOR ÂNGULO1 D
1-4 T7050003 . DRIVER(-) . CHAVE DE FENDAS,ROSCA 1 D
1-5 T7050013 . DRIVER . CHAVE DE FENDAS 1 D
1-6 T7050021 . DRIVER . CHAVE DE FENDAS,ROSCA 1 D
1-7 T7050022 . DRIVER . CHAVE DE FENDAS 1 D
1-8 T7500004 . PILER;COMBI . ALICATE;COMBINAÇÃO 1 D
1-10 2199-1004 . BAR . BARRA 1
1-11 2199-1005 . PIPE . TUBO 1
1-12 T6690012 . BAR;EXTENSION . BARRA,EXTENSÃO 1 D
1-13 T6690013 . BAR;EXTENSION . BARRA,EXTENSÃO 1 D
1-14 T6750003 . HANDLE;RATCHET . REPELÃO,CATRACA 1 D
1-15 2199-9009 . CLIP;DRIVER . GRAMPO 1 D
1-16 K1008167 . WRENCH;FILTER . REPELÃO,FILTRO 1
1-17 T6550005 . L-WRENCH . REPELÃO,L 1 D
1-18 T6550006 . L-WRENCH . REPELÃO,L 1 D
1-19 T6550007 . L-WRENCH . REPELÃO,L 1 D
1-20 T6550009 . L-WRENCH . REPELÃO,L 1 D
1-21 T6550011 . L-WRENCH . REPELÃO,L 1 D
1-22 T6550018 . L-WRENCH 17 . REPELÃO,L 1 D
1-23 T6510062 . SPANNER . CHAVE INGLESA 1 D
1-24 T6510066 . SPANNER 10x13 . CHAVE INGLESA 1 D
1-25 T6510070 . SPANNER . CHAVE INGLESA 1 D
1-26 T6510072 . SPANNER . CHAVE INGLESA 1 D
1-27 T6510075 . SPANNER 19x22 . CHAVE INGLESA 1 D
1-28 T6510081 . SPANNER 24X27 . CHAVE INGLESA 1 D
1-29 T6510085 . SPANNER 27X30 . CHAVE INGLESA 1 D
1-30 T6510089 . SPANNER 32X36 . CHAVE INGLESA 1 D
1-31 T6510091 . SPANNER 36X41 . CHAVE INGLESA 1 D
1-32 T6510018 . SPANNER 24 . CHAVE INGLESA 1 D
1-33 T6510027 . SPANNER 41 . CHAVE INGLESA 1 D
1-40 T6510079 . SPANNER 22x24 . CHAVE INGLESA 1
1-43 T6510087 . SPANNER 30x32 . CHAVE INGLESA 1
1-55 T6600183 . SOCKET M6 . REPELÃO 1 D
1-56 T6600189 . SOCKET M8 . REPELÃO,SOQUETE 1 D
DX225LCA 5100 - 2
Serial No. ;
TOOLS
FERRAMENTAS
DATE DEC. 21, 2012
1st EDITION Fig. 5100
5100 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TOOLS
FERRAMENTAS
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5100
5100 -1-57 T6600197 . SOCKET;WRENCH . REPELÃO,SOQUETE 1 D
1-58 T6600201 . SOCKET;WRENCH . REPELÃO,SOQUETE 1 D
1-59 T6600211 . SOCKET;WRENCH . REPELÃO,SOQUETE 1 D
1-60 T6600223 . SOCKET;WRENCH . REPELÃO,SOQUETE 1 D
1-78 T6600217 . SOCKET;WRENCH . REPELÃO,SOQUETE 1 D
1-82 T6510069 . SPANNER 12X14 . CHAVE INGLESA 1
1-84 850315-00029 . HAMMER . MARTELO 1
1-85 850334-00008 . WRENCH,L . REPELÃO,L 1
1-86 T6600191 . SOCKET;WRENCH . REPELÃO,SOQUETE 1
2 2199-9008 GREASE GUN PISTOLA,GRAXA 1
3 2199-9007 BOX CAIXA,FERRAMENTA 1
4 K1007669 HOSE;OIL DRAIN MANGUEIRA;DRENO 1
DX225LCA 5100 - 4
Serial No. ;
SPARE PARTS
PEÇAS SOBRESSALENTES
DATE DEC. 21, 2012
1st EDITION Fig. 5110
5110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SPARE PARTS
PEÇAS SOBRESSALENTES
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5110
5110 -- 101594-00300 SPARE PARTS ASSY CONJUNTO DE PEÇAS DE REPOSIÇÃO- D
1 400504-00131 ELEMENT,FILTER ELEMENTO, FILTRO 1
2 2471-1154 ELEMENT;FILTER(PILOT) ELEMENTOS;PILOTO FILTRO 1
3 400504-00091 ELEMENT,OUTER(AIR) ELEMENTO, EXTERIOR 1
4 400504-00092 ELEMENT,INNER(AIR) ELEMENTO, INTERNO 1
5 65.05510-5028A CARTRIDGE,OIL FILTER CARTUCHO,ÓLEO FILTRO 1
6 65.12503-5016B ELEMENT;E/G FUEL FILTER ELEMENTOS,COMBUSTÍVEL FILTRO1
8 2106-1019D10 V-BELT 4PK 990L CINTO,V 1
10 2512-1095D1 BOX;SPARE PARTS CAIXA,PEÇAS DE REPOSIÇÃO1
11 2180-9153 O-RING KIT ANEL KIT,O 1
15 515-00012A BULB BULBO 2
17 2515-1016D4 BULB;HALOGEN BULBO 2
19 2527-1016 FUSE;BLADE 10A FUSÍVEL 2
20 2527-1017 FUSE;BLADE 15A FUSÍVEL 2
21 2527-1018 FUSE;BLADE 20A FUSÍVEL,LÂMINA 1
22 2527-1025 FUSE;BLADE 30A FUSÍVEL,LÂMINA 1
23 2527-1023A LINK;FUSIBLE TIRANTE,FUSÍVEL 1
24 300803-00086 FUSE;200A FUSÍVEL;200A 1
25 K1029257 ELEMENT;AIR BREATHER ELEMENTOS 1
26 130205-00251 BELT,V CINTO,V 1
41 950106-00967 PARTS BOOK PEÇAS LIVRO 1
42 950106-00968PT MANUAL,OPERATION MANUAL DE OPERAÇÃO, 1
DX225LCA 5110 - 2
Serial No. ;
NAME PLATE - CABIN(EXPORT)
PLACA DE NOME - CABINE(EXPORTADO)
DATE DEC. 21, 2012
1st EDITION Fig. 5120
5120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
NAME PLATE - CABIN(EXPORT)
PLACA DE NOME - CABINE(EXPORTADO)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5120
5120 -- 950209-01718 NAME PLATE ASSY;CABIN DECALQUE - D
1 950205-01466C DECAL DECALQUE 1
2 950205-01461A DECAL DECALQUE 1
3 950205-01456A DECAL DECALQUE 1
4 950205-01462A DECAL(EMR EXIT) DECALQUE 1
9 950205-01460B DECAL;FRONT WINDOW DECALQUE;EMERGÊNCIA SAIDA1
10 950205-01451 DECAL;WARNING(MAINTEN) DECALQUE;ALERTA,MANUTENÇÃO1
13 K1011743D6 PLATE;NAME DECALQUE 1
14 950205-00862A DECAL;VISIBILITY DECALQUE;VISIBILIDADE 1
15 950205-01680 DECAL;CABIN INTERFERENCE DECALQUE;CABINE INTERFERÊNCIA1
DX225LCA 5120 - 2
Serial No. ;
NAME PLATE - EXPORT
PLACA DE NOME - EXPORTADO
DATE DEC. 21, 2012
1st EDITION Fig. 5130
5130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable partPart No. Q'ty
NAME PLATE - EXPORT
PLACA DE NOME - EXPORTADO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5130
5130 -- 950205-00668 DECAL ASSY;EXPORT DECALQUE - D
2 950205-00662 DECAL(DOOSAN) DECALQUE 1
3 950205-01455B DECAL;WARNING(SWING AREA) DECALQUE;ALERTA,OSCILANTE ÁREA2
4 950205-01464A DECAL;WARNING(BOOM) DECALQUE;ALERTA,LANÇA 2
7 950205-01448 DECAL;WARNING(BATTERY) DECALQUE;ALERTA,BATERIA 1
10 950205-01463A DECAL;TRACK ADJUSTER DECALQUE 2
11 950205-01467B DECAL;WARNING(FAN AND BELT) DECALQUE 1
12 950205-01450B DECAL;SAFETY(ROTATING) DECALQUE;SEGURANÇA,ROTATIVO PEÇAS1
13 950205-01453 DECAL;WARNING(RADI CAP) DECALQUE;ALERTA,RADIADOR CAPA1
14 950205-01454A DECAL;WARNING(ACC) DECALQUE 1
16 190-00648A PLATE;NAME PLACA,NOME 1
17 2122-1002D4 RIVET REBITE 4
19 K1042074A PLATE;NAME DECALQUE 4
20 K1011000 DECAL DECALQUE 1
22 K1011002 DECAL DECALQUE 1
27 950205-01468A DECAL;PRESSURIZED OIL DECALQUE 1
30 K1039697 DECAL DECALQUE 2
31 950205-00663 DECAL(DOOSAN) DECALQUE 2
33 950205-01763 DECAL DECALQUE 2
DX225LCA 5130 - 2
Serial No. ;
DECAL - SPEC
DECALQUE - ESPECÍFICO
DATE DEC. 21, 2012
1st EDITION Fig. 5140
5140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - SPEC
DECALQUE - ESPECÍFICO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5140
5140 -- K1049177 NAME PLATE ASS'Y PLACA,NOME - D
1 2190-2556D179 PLATE;NAME PLACA,NOME 1
DX225LCA 5140 - 2
Serial No. ;
DECAL - FUSE BOX
DECALQUE - CAIXA DE FUSO
DATE DEC. 21, 2012
1st EDITION Fig. 5150
5150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - FUSE BOX
DECALQUE - CAIXA DE FUSO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5150
5150 -- K1049168 NAME PLATE ASS'Y PLACA,NOME - D
1 K1008019D21 PLATE;NAME DECALQUE 1
2 K1008019D22 PLATE;NAME DECALQUE 1
DX225LCA 5150 - 2
Serial No. ;
DECAL - MACHINE NAME
DECALQUE - NOME DA MÁQUINA
DATE DEC. 21, 2012
1st EDITION Fig. 5160
5160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - MACHINE NAME
DECALQUE - NOME DA MÁQUINA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5160
5160 -- K1049182 NAME PLATE ASS'Y DECALQUE - D
1 K1049184 PLATE;NAME DECALQUE 2
DX225LCA 5160 - 2
Serial No. ;
DECAL - LUBRICATION(EXPORT)
DECALQUE - LUBRIFICAÇÃO (EXPORTADO)
DATE DEC. 21, 2012
1st EDITION Fig. 5170
5170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - LUBRICATION(EXPORT)
DECALQUE - LUBRIFICAÇÃO (EXPORTADO)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5170
5170 -- 950209-03552 PLATE ASSY,NAME PLACA,NOME - D
1 950209-03553 PLATE,NAME PLACA,NOME 1
DX225LCA 5170 - 2
Serial No. ;
DECAL - SERIAL
DECALQUE - SÉRIE
DATE DEC. 21, 2012
1st EDITION Fig. 5180
5180 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - SERIAL
DECALQUE - SÉRIE
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5180
5180 -- 950209-02978 NAME PLATE ASS`Y PLACA,NOME - D
1 950209-02977 PLATE,NAME PLACA,NOME 1
2 2122-1002D2 RIVET REBITE 4
DX225LCA 5180 - 2
Serial No. ;
DECAL - LIFTING CAPA
DECALQUE - CAPA DE LEVANTAMENTO
DATE DEC. 21, 2012
1st EDITION Fig. 5190
5190 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
DECAL - LIFTING CAPA
DECALQUE - CAPA DE LEVANTAMENTO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 5190
5190 -- 950209-00501 PLATE ASSY,NAME;LIFTING CAPA. PLACA,NOME - D
1 950209-00487 PLATE,NAME;LIFTING CAPA. PLACA,NOME;ELEVADOR CAPACIDADE1
DX225LCA 5190 - 2
Serial No. ;
MAIN PIPING - ONE WAY
TUBULAÇÃO PRINCIPAL - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION Fig. 6100
6100 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING - ONE WAY
TUBULAÇÃO PRINCIPAL - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6100
6100 -- 420212-06960 PIPING,MAIN;ONE WAY TUBULAÇÃO, PRINCIPAL - D
1 426-00267B VALVE;RELIEF VÁLVULA,ALÍVIO 1
1A 410127-00078 . VALVE;RELIEF . VÁLVULA,ALÍVIO 1
2 423-00193B BLOCK BLOCO 1
3 2181-2170 BLOCK;SPACER BLOCO,ESPAÇADOR 1
4 2181-9078 FLANGE FLANGE 2
5 195-03435B BRACKET SUPORTE 1
6 195-03436B BRACKET SUPORTE 1
7 2181-4133D6 ADAPTER ADAPTADOR 2
8 DS2232107 ADAPTER ADAPTADOR 1
9 2181-2293D4 TEE T 1
10 S5102703 WASHER;SPRING ARRUELA,MOLA 4
11 S0561266 BOLT PARAFUSO,HEX 2
12 S0561066 BOLT M12X1.75X65 PARAFUSO,HEX 2
13 S2213466 BOLT;SOCKET M10X90 PARAFUSO,HEX SOQUETE 4
14 DS0025020 BOLT;SET PARAFUSO 4
15 DS2012300 HOSE MANGUEIRA 1
16 DS2026201 HOSE MANGUEIRA 1
17 DS2016055 HOSE MANGUEIRA 2
18 2180-1026D19 O-RING ANEL,O 2
19 S8030161 O-RING ANEL,O 5
20 S8000291 O-RING ANEL,O 5
41 DS2013834 HOSE MANGUEIRA 1
42 K1000358B BRACKET SUPORTE 1
43 DS0025019 BOLT;SET PARAFUSO 4
44 2181-2293D4 TEE T 1
45 S8030161 O-RING ANEL,O 2
DX225LCA 6100 - 2
Serial No. ;
ONE WAY PIPING - WITH FILTER
TUBULAÇÃO DE CANAL ÚNICO - COM FILTRO
DATE DEC. 21, 2012
1st EDITION Fig. 6110
6110 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ONE WAY PIPING - WITH FILTER
TUBULAÇÃO DE CANAL ÚNICO - COM FILTRO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6110
6110 -- 400406-00308 FILTER ASSY,BREAKER;ONE WAY FILTRO ASSY, DISJUNTOR - D
1 471-00114 FILTER;BREAKER FILTRO,HIDRÁULICO ÓLEO 1
1A 474-00046 . ELEMENT;BREAKER FILTER . ELEMENTOS,FILTRO 1
1B 2180-1026D19 . O-RING . ANEL,O 1
1C S8010751 . O-RING . ANEL,O 1
1D 401003-00260 . RING,SUPPORT . ANEL,APOIO 1
2 195-03437E BRACKET SUPORTE 1
3 2181-2815D1 ELBOW COTOVELO 2
4 2181-2293D4 TEE T 1
5 DS2012217 HOSE MANGUEIRA 1
6 DS2013220 HOSE MANGUEIRA 1
7 DS0025021 BOLT;SET PARAFUSO 4
8 DS0025018 BOLT;SET PARAFUSO 4
9 S8030161 O-RING ANEL,O 4
10 S8000291 O-RING ANEL,O 2
DX225LCA 6110 - 2
Serial No. ;
PILOT PIPING - ONE WAY
TUBULAÇÃO PILOTO - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION Fig. 6120
6120 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING - ONE WAY
TUBULAÇÃO PILOTO - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6120
6120 -- 420212-06962 PIPING,PILOT;ONE WAY TUBULAÇÃO, PILOTO - D
1 K1047556 VALVE;SOLENOID VÁLVULA,SOLENÓIDE 1
2 426-00266 VALVE;EPPR VÁLVULA,EPPR 1
2A K9001362 . VALVE;E.P.P.R . VÁLVULA,EPPR 1
3 110425-00065 BRACKET,EPPR VALVE SUPORTE,EPPR VÁLVULA 1
4 549-00010 SWITCH;PRESSURE INTERRUPTOR,PRESSÃO 1
5 530-00067 HARNESS ARNÊS;PRESSÃO INTERRUPTOR1
6 DS2242017 REDUCER ADAPTADOR 1
7 2471-1133 ADAPTER;FILTER ADAPTADOR,FILTRO 1
8 2181-1126D36 ADAPTER ADAPTADOR 2
9 2181-1702D4 ELBOW COTOVELO 2
10 181-00779 TEE;SHUTTLE T,LANÇADEIRA VÁLVULA 1
11 2181-1951D1 TEE T 2
12 124-00208D6 CLIP GRAMPO 1
13 110951-00128 SPACER ESPAÇADOR 2
14 S5102503 WASHER,SPRING ARRUELA,MOLA 2
15 K1001029 BOLT PARAFUSO 1
16 S0508766 BOLT PARAFUSO,HEX 2
17 S0560866 BOLT;SET PARAFUSO,HEX 2
18 DS2093391 HOSE MANGUEIRA 1
19 2184-1045D177 HOSE PF1/4-510 MANGUEIRA 1
20 DS2093040 HOSE MANGUEIRA 1
21 DS2093021 HOSE MANGUEIRA 1
22 DS2093044 HOSE MANGUEIRA 1
23 2184-1046D169 HOSE PF1/4-1600L MANGUEIRA 1
24 DS2055788 HOSE PF1/4-2050L MANGUEIRA 125 2184-1046D68 HOSE PF1/4-600L MANGUEIRA 1
27 S8000141 O-RING ANEL,O 2
28 S8000111 O-RING ANEL,O 7
29 430216-00006 JOINT PLATE SUB ASS`Y LIGAÇÃO SUB CONJ;PILOTO LIGAÇÃO PL1
29-1 K1000354 . BRACKET;JOINT . PLACA 1
29-2 181-00078D1 . ADAPTER . ADAPTADOR 1
29-3 121-00010D1 . NUT . PORCA 8
29-4 420-00352D1 . VALVE;SHOCKLESS . VÁLVULA,SEM CHOQUE 1
29-5 DS2410009 . ADAPTER . ADAPTADOR 3
29-6 181-00086D1 . TEE . T 1
29-7 181-00086D2 . TEE . T 2
29-8 420-00476 . VALVE;SHUTTLE . VÁLVULA,LANÇADEIRA 1
DX225LCA 6120 - 2
Serial No. ;
PILOT PIPING - ONE WAY
TUBULAÇÃO PILOTO - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION Fig. 6120
6120 - 3 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
PILOT PIPING - ONE WAY
TUBULAÇÃO PILOTO - CANAL ÚNICO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6120
6120 -29-9 121-00010D7 . NUT . PORCA 2
DX225LCA 6120 - 4
Serial No. ;
BOOM PIPING - BOOM 5.7m(ONE & TWO WAY)
TUBULAÇÃO DE LANÇA - BRAÇO 5.7M (CANAL DUPLO
DATE DEC. 21, 2012
1st EDITION Fig. 6130
6130 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING - BOOM 5.7m(ONE & TWO WAY)
TUBULAÇÃO DE LANÇA - BRAÇO 5.7M (CANAL DUPL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6130
6130 -- 420212-06762 PIPING,BOOM;ONE OR TWO WAY TUBULAÇÃO, BOOM - D
1 K1033269 PIPE TUBO 1
2 K1033270 PIPE TUBO 1
3 420207-01840 PIPE ASSY,HYDRAULIC TUBO 1
4 420207-01841 PIPE ASSY,HYDRAULIC TUBO 1
5 2180-1026D19 O-RING ANEL,O 6
6 S2212666 BOLT PARAFUSO,HEX SOQUETE 16
7 124-00368 CLAMP;PIPE BRAÇADEIRA,TUBO 16
8 161-00281 RUBBER BORRACHA;1" TUBO 8
9 124-00367 CLAMP;PIPE BRAÇADEIRA,TUBO 4
10 2181-9078 FLANGE FLANGE 4
11 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 8
12 S8000291 O-RING ANEL,O 2
13 2181-1950D9 PLUG BUJAO,VERIFIQUE NOVAMENTE2
14 420207-01842 PIPE ASSY,HYDRAULIC TUBO 2
DX225LCA 6130 - 2
Serial No. ;
ARM PIPING - ARM 2.9m(ONE & TWO WAY)
TUBULAÇÃO DE LANÇA - BRAÇO 2.9M (CANAL DUPLO
DATE DEC. 21, 2012
1st EDITION Fig. 6140
6140 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 2.9m(ONE & TWO WAY)
TUBULAÇÃO DE LANÇA - BRAÇO 2.9M (CANAL DUPL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6140
6140 -- 420212-08011 PIPING,ONE & TWO WAY,ARM TUBULAÇÃO, BRAÇO - D
1 420207-00514A PIPE ASSY,HYDRAULIC TUBO 2
2 DS20401232 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO2
3 2181-9078 FLANGE FLANGE 8
4 2180-1026D19 O-RING ANEL,O 6
5 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 16
6 K1004057 CLAMP;PIPE BRAÇADEIRA,TUBO 4
10 S2215966 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
13 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 8
17 S5102803 WASHER;SPRING ARRUELA,MOLA 4
18 S0562766 BOLT PARAFUSO,HEX 4
19 S5110703 WASHER;SPRING ARRUELA,MOLA 4
41 410137-00032B VALVE ASS'Y,STOP;(L.H) VÁLVULA CONJ,PARE;L.H 1
41-1 410137-00067A . VALVE,STOP;1"(LH) . VÁLVULA,PARE;ESQUERDA 1
41-2 S8000291 . O-RING . ANEL,O 1
41-3 2181-4133D6 . ADAPTER . ADAPTADOR 1
41-4 2181-2817D2 . CAP . CAPA,ORS 1
41-5 S8030161 . O-RING . ANEL,O 1
41-6 2181-1950D7 . PLUG . BUJAO 1
41-7 S8000181 . O-RING . ANEL,O 1
42 410137-00033B VALVE ASS'Y,STOP;(R.H) VÁLVULA CONJ,PARE;R.H 1
42-1 410137-00069A . VALVE,STOP;1"(RH) . VÁLVULA,PARE;DIREITO 1
42-2 S8000291 . O-RING . ANEL,O 1
42-3 2181-4133D6 . ADAPTER . ADAPTADOR 1
42-4 2181-2817D2 . CAP . CAPA,ORS 1
42-5 S8030161 . O-RING . ANEL,O 1
42-6 2181-1950D7 . PLUG . BUJAO 1
42-7 S8000181 . O-RING . ANEL,O 1
DX225LCA 6140 - 2
Serial No. ;
MAIN PIPING - QUICK FIT
TUBULAÇÃO PRINCIPAL - ENCAIXE RÁPIDO
DATE DEC. 21, 2012
1st EDITION Fig. 6150
6150 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
MAIN PIPING - QUICK FIT
TUBULAÇÃO PRINCIPAL - ENCAIXE RÁPIDO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6150
6150 -- 420212-06969 PIPING,MAIN;QUICK CLAMP TUBULAÇÃO, PRINCIPAL - D
1 426-00287B VALVE;QUICK-FIT VÁLVULA;RÁPIDA FIXAÇÃO 1
1A 410135-00109 . VALVE;SOLENOID . VÁLVULA,SOLENÓIDE 1
1B 410126-00019 . VALVE;REDUCING . VÁLVULA,REDUÇÃO 1
1C 300715-00036 . COIL . BOBINA 1
2 195-03123E BRACKET SUPORTE,RÁPIDA FIXAÇÃO VÁLVULA1
3 K1000351A PLATE PLACA,LIGAÇÃO 1
4 181-00078D1 ADAPTER ADAPTADOR 2
5 2181-1126D7 ADAPTER ADAPTADOR 1
6 2181-1126D85 ADAPTER ADAPTADOR 1
7 DS2404024 ADAPTER ADAPTADOR 1
8 2181-1702D3 ELBOW PFO1/4XPF3/8 COTOVELO 2
9 DS2338029 ELBOW COTOVELO 1
10 121-00010D1 NUT PORCA 2
11 S5102503 WASHER,SPRING ARRUELA,MOLA 2
12 DS0025019 BOLT;SET PARAFUSO 4
13 S0556466 BOLT PARAFUSO,HEX 2
14 DS2013515 HOSE MANGUEIRA 1
15 DS2054293 HOSE MANGUEIRA 1
16 DS2054394 HOSE MANGUEIRA,ÓLEO 1
17 DS2093300 HOSE MANGUEIRA 1
18 DS2053868 HOSE MANGUEIRA 1
19 DS2053869 HOSE MANGUEIRA 1
20 S8000231 O-RING ANEL,O 1
21 S8000141 O-RING ANEL,O 1
22 S8000111 O-RING ANEL,O 4
23 S8030061 O-RING ANEL,O 2
DX225LCA 6150 - 2
Serial No. ;
ELECTRIC PARTS - QUICK CLAMP
PARTES ELÉTRICAS - ENGATE RÁPIDO
DATE DEC. 21, 2012
1st EDITION Fig. 6160
6160 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ELECTRIC PARTS - QUICK CLAMP
PARTES ELÉTRICAS - ENGATE RÁPIDO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6160
6160 -- K1007413 QUICK CLAMP PIPING TUBULAÇÃO,RÁPIDA BRAÇADEIRA- D
1 549-00092 SWITCH;LOCKOUT TOGGLE INTERRUPTOR,TOGGLE;FECHADURA FORA1
2 530-00432A HARNESS;JOINT ARNÊS;RÁPIDA BRAÇADEIRA1
3 K1005776 PLATE;NAME DECALQUE 1
DX225LCA 6160 - 2
Serial No. ;
BOOM PIPING - BOOM 5.7m(QUICK CLAMP)
TUBULAÇÃO DE LANÇA - LANÇA 5.7M (ENGATE RÁPID
DATE DEC. 21, 2012
1st EDITION Fig. 6170
6170 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING - BOOM 5.7m(QUICK CLAMP)
TUBULAÇÃO DE LANÇA - LANÇA 5.7M (ENGATE RÁPI
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6170
6170 -- K1041837 BOOM PIPING-QUICK FIT BOOM TUBULAÇÃO-QUICK FIT- D
1 DS2053849 HOSE MANGUEIRA 1
2 DS2053953 HOSE MANGUEIRA,ÓLEO 1
3 181-00078D5 ADAPTER ADAPTADOR 2
4 195-00163 BRACKET SUPORTE 1
5 S0563366 BOLT PARAFUSO,HEX 4
6 S5102803 WASHER;SPRING ARRUELA,MOLA 4
7 K1004006 PLATE PLACA 2
8 121-00010D1 NUT PORCA 2
9 K1010847 BRACKET SUPORTE 1
10 K1001029 BOLT PARAFUSO 8
11 DS2805009 CLIP GRAMPO 8
12 K1000356 ADAPTER ADAPTADOR 2
13 121-00010D7 NUT PORCA 2
DX225LCA 6170 - 2
Serial No. ;
ARM PIPING - ARM 2.9m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.9M (ENGATE RÁPI
DATE DEC. 21, 2012
1st EDITION Fig. 6180
6180 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 2.9m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.9M (ENGATE RÁP
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6180
6180 -- 420212-08035 PIPING,QUICK CLAMP;(2.9M) TUBULAÇÃO, BRAÇO - D
1 K1001052 PIPE TUBO 1
2 K1001053 PIPE TUBO 1
3 DS2055866 HOSE MANGUEIRA 2
4 2181-2820D1 PLUG BUJAO 2
5 S0508866 BOLT PARAFUSO,HEX 5
6 S5102503 WASHER,SPRING ARRUELA,MOLA 5
7 K1004011 CLAMP;PIPE BRAÇADEIRA,TUBO 5
DX225LCA 6180 - 2
Serial No. ;
ALTERNATOR - 80A
ALTERNADOR - 80A
DATE DEC. 21, 2012
1st EDITION Fig. 6190
6190 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'tyALTERNATOR - 80A
ALTERNADOR - 80A
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6190
6190 -- 300901-00042 ALTERNATOR ASSY;80A ALTERNADOR CONJ - D
1 300901-00033 ALTERNATOR;80A ALTERNADOR;80A 1
1A 130707-00042 . PULLEY,ALTERNATOR . POLIA,ALTERNADOR 1
DX225LCA 6190 - 2
Serial No. ;
TRACK SHOE ASS'Y - 700G
Sapata- 700G
DATE DEC. 21, 2012
1st EDITION Fig. 6200
6200 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK SHOE ASS'Y - 700G
Sapata- 700G
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6200
6200 -- 200106-00382 SHOE ASSY,TRACK SAPATA CONJ,FAIXA - D
1 200106-00386 SHOE ASSY,TRACK;700MM SAPATA CONJ,FAIXA 2
1-1 200103-00125 . LINK ASSY,TRACK . LINK ASSY, FAIXA 1
1-1A 101539-00255 .. LINK;R.H .. TIRANTE,GUIA;DIREITO 49
1-1B 101539-00256 .. LINK;L.H .. TIRANTE,GUIA;ESQUERDA49
1-1E 120501-02554 .. PIN .. PINO 48
1-1F 120501-02555 .. PIN,MASTER .. PINO 1
1-1G 131002-00517 .. BUSHING .. BUCHA 48
1-1H 131002-00518 .. BUSHING MASTER .. BUCHA 1
1-1I 401103-00120 .. SEAL,DUST .. SELO,POEIRA 96
1-1J K1038374 .. SPACER .. ESPAÇADOR 2
1-2 120112-01199 . BOLT,TRACK . PARAFUSO,HEX 196
1-3 120312-00430 . NUT,TRACK . PORCA 196
1-4 200106-00468 . SHOE,TRACK;700G . SAPATA,FAIXA 49
2 110955-00106B STEP PASSO 4
4 S0560466 BOLT M12X1.75X35 PARAFUSO,HEX 16
5 S5102703 WASHER;SPRING ARRUELA,MOLA 16
DX225LCA 6200 - 2
Serial No. ;
TRACK SHOE ASS'Y - 800G
Sapata - 800G
DATE DEC. 21, 2012
1st EDITION Fig. 6210
6210 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK SHOE ASS'Y - 800G
Sapata - 800G
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6210
6210 -- 200106-00383 SHOE ASSY,TRACK SAPATA CONJ,FAIXA - D
1 200106-00387 SHOE ASSY,TRACK;800MM SAPATA CONJ,FAIXA 2
1-1 200103-00125 . LINK ASSY,TRACK . LINK ASSY, FAIXA 1
1-1A 101539-00255 .. LINK;R.H .. TIRANTE,GUIA;DIREITO 49
1-1B 101539-00256 .. LINK;L.H .. TIRANTE,GUIA;ESQUERDA49
1-1E 120501-02554 .. PIN .. PINO 48
1-1F 120501-02555 .. PIN,MASTER .. PINO 1
1-1G 131002-00517 .. BUSHING .. BUCHA 48
1-1H 131002-00518 .. BUSHING MASTER .. BUCHA 1
1-1I 401103-00120 .. SEAL,DUST .. SELO,POEIRA 96
1-1J K1038374 .. SPACER .. ESPAÇADOR 2
1-2 120112-01199 . BOLT,TRACK . PARAFUSO,HEX 196
1-3 120312-00430 . NUT,TRACK . PORCA 196
1-4 200106-00469 . SHOE,TRACK;800G . SAPATA,FAIXA 49
2 110955-00107B STEP PASSO 4
4 S0560466 BOLT M12X1.75X35 PARAFUSO,HEX 16
5 S5102703 WASHER;SPRING ARRUELA,MOLA 16
DX225LCA 6210 - 2
Serial No. ;
TRACK SHOE ASS'Y - 900G
Sapata - 900G
DATE DEC. 21, 2012
1st EDITION Fig. 6220
6220 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
TRACK SHOE ASS'Y - 900G
Sapata - 900G
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6220
6220 -- 200106-00384 SHOE ASSY,TRACK SAPATA CONJ,FAIXA - D
1 200106-00388 SHOE ASSY,TRACK;900MM SAPATA CONJ,FAIXA 2
1-1 200103-00125 . LINK ASSY,TRACK . LINK ASSY, FAIXA 1
1-1A 101539-00255 .. LINK;R.H .. TIRANTE,GUIA;DIREITO 49
1-1B 101539-00256 .. LINK;L.H .. TIRANTE,GUIA;ESQUERDA49
1-1E 120501-02554 .. PIN .. PINO 48
1-1F 120501-02555 .. PIN,MASTER .. PINO 1
1-1G 131002-00517 .. BUSHING .. BUCHA 48
1-1H 131002-00518 .. BUSHING MASTER .. BUCHA 1
1-1I 401103-00120 .. SEAL,DUST .. SELO,POEIRA 96
1-1J K1038374 .. SPACER .. ESPAÇADOR 2
1-2 120112-01199 . BOLT,TRACK . PARAFUSO,HEX 196
1-3 120312-00430 . NUT,TRACK . PORCA 196
1-4 200106-00470 . SHOE,TRACK;900G . SAPATA,FAIXA 49
2 110955-00108C STEP PASSO 4
4 S0560466 BOLT M12X1.75X35 PARAFUSO,HEX 16
5 S5102703 WASHER;SPRING ARRUELA,MOLA 16
DX225LCA 6220 - 2
Serial No. ;
BOOM - 5.7M - H.D TYPE
LANÇA - 5.7M - TIPO H.D
DATE DEC. 21, 2012
1st EDITION Fig. 6230
6230 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM - 5.7M - H.D TYPE
LANÇA - 5.7M - TIPO H.D
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6230
6230 -- 230207-00231 BOOM ASSY LANÇA,MÁQUINA - D
1 230211-00162A BOOM 5.7m H.D LANÇA,MÁQUINA 1
1A 131008-00140 . BUSHING,SINTERING . BUCHA 4
1B DS5502006 . SEAL,DUST . SELO,POEIRA 2
2 K1007253B PIN PINO,CENTRAL;BOOM 1
3 2123-2185G PIN PINO;LANÇA FINAL,LANÇA À BRAÇO1
4 120501-01062 PIN PINO;BRAÇO CYL CABEÇA/HASTE1
5 2116-1531A STOPPER ROLHA 2
6 S0567066 BOLT PARAFUSO,HEX 2
7 S4012933 NUT PORCA 4
8 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
9 2180-1106BD24 SEAL;DUST SELO,POEIRA 6
10 DS7752018 SHIM CALÇO,POLÍMERO 2
11 DS7752012 SHIM CALÇO,POLÍMERO 2
12 621-03710A PLATE;STOPPER PLACA,ROLHA 1
13 2116-1060D6 STOPPER ROLHA 1
14 S0521366 BOLT PARAFUSO,HEX 3
15 S5102903 WASHER,SPRING ARRUELA,MOLA 3
16 DS7752013 SHIM CALÇO,POLÍMERO 2
17 DS7752026 SHIM CALÇO,POLÍMERO 2
18 DS7752027 SHIM CALÇO,POLÍMERO 2
19 DS7752025 SHIM CALÇO,POLÍMERO;POLÍMERO4
20 DS7752017 SHIM CALÇO,POLÍMERO 2
21 DS7752093 SHIM CALÇO,POLÍMERO 2
DX225LCA 6230 - 2
Serial No. ;
ARM - 2.9m(HEAVY DUTY)
BRAÇO - 2.9M (TRABALHO PESADO)
DATE DEC. 21, 2012
1st EDITION Fig. 6240
6240 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM - 2.9m(HEAVY DUTY)
BRAÇO - 2.9M (TRABALHO PESADO)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6240
6240 -- 230201-00645 ARM ASSY BRAÇO,MÁQUINA - D
1 230204-00283 ARM,MACHINE;2.9M H.D BRAÇO,MÁQUINA 1
1A 131008-00064A . BUSHING . BUCHA;BRAÇO TIRANTE 2
1B 131004-00023A . BUSHING,CARBURIZING . BUCHA 2
1C 131004-00024A . BUSHING,CARBURIZING . BUCHA 2
2 101541-00114 LINK ASSY,PUSH;(H.D) TIRANTE,EMPURRE 1
2A 131004-00026A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
2B 131004-00025A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
3 101540-00055 LINK;GUIDE(R.H) TIRANTE,GUIA;DIREITO 1
4 K1010025A LINK;GUIDE(L.H) TIRANTE,GUIA;ESQUERDA 1
5 120501-01063 PIN PINO;BRAÇO CYL HASTE 1
6 120501-01064 PIN PINO;CAÇAMBA CYL CABEÇA1
7 120501-01065 PIN PINO;BRAÇO TIRANTE RESSALTO1
8 120501-01052 PIN PINO;BRAÇO TIRANTE À CAÇAMBA2
9 120501-02429 PIN;BUCKET CYL ROD PINO;CAÇAMBA CYL HASTE 1
10 2180-1106BD4 SEAL;DUST SELO,POEIRA 2
11 2180-1106BD24 SEAL;DUST SELO,POEIRA 14
12 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
13 DS7752012 SHIM CALÇO,POLÍMERO 8
14 DS7752013 SHIM CALÇO,POLÍMERO 8
15 DS7752006 SHIM CALÇO,POLÍMERO 2
16 DS7752007 SHIM CALÇO,POLÍMERO 2
17 2116-1060D6 STOPPER ROLHA 2
18 S0521366 BOLT PARAFUSO,HEX 2
19 S5102903 WASHER,SPRING ARRUELA,MOLA 2
20 S4012933 NUT PORCA 8
21 DS0001084 BOLT PARAFUSO,HEX 3
22 DS0001083 BOLT PARAFUSO,HEX 1
23 S6710041 NIPPLE;GREASE APROPRIADO 5
24 180-00077D5 O-RING ANEL,O 2
25 K1000911 SPACER ESPAÇADOR 2
26 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 5
27 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
28 S0712066 BOLT PARAFUSO,HEX 12
29 180-00077D3 O-RING ANEL,O 2
DX225LCA 6240 - 2
Serial No. ;
BOOM PIPING - 5.7m(H.D)
TUBULAÇÃO DE LANÇA - 5.7M (H.D)
DATE DEC. 21, 2012
1st EDITION Fig. 6250
6250 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING - 5.7m(H.D)
TUBULAÇÃO DE LANÇA - 5.7M (H.D)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6250
6250 -- 420212-07897 PIPING,BOOM(5.7M) TUBULAÇÃO, BOOM - D
4 420207-02224 PIPE ASSY,HYDRAULIC TUBO 1
5 420207-02225 PIPE ASSY,HYDRAULIC TUBO 1
6 420207-02226 PIPE ASSY,HYDRAULICTUBO 1
7 K1033267 PIPE TUBO 1
8 420207-02227 PIPE ASSY,HYDRAULIC TUBO 1
9 K1033268 PIPE TUBO 1
10 DS2040610 HOSE MANGUEIRA,ÓLEO 1
11 DS2038190 HOSE MANGUEIRA 1
12 124-00367 CLAMP;PIPE BRAÇADEIRA,TUBO 4
13 124-00300 CLAMP;PIPE BRAÇADEIRA,TUBO 2
15 124-00368 CLAMP;PIPE BRAÇADEIRA,TUBO 2
17 S0562766 BOLT PARAFUSO,HEX 24
18 S5102803 WASHER;SPRING ARRUELA,MOLA 24
19 180308-00411 RUBBER BUCHA 9
20 180308-00235 RUBBER BUCHA 1
21 S2212566 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
22 2180-1026D2 O-RING ANEL,O 6
23 2181-9078 FLANGE FLANGE 8
24 2180-1026D19 O-RING ANEL,O 4
25 2181-9079 FLANGE FLANGE 8
26 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 20
28 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 12
51 S0562766 BOLT PARAFUSO,HEX 4
52 S5102803 WASHER;SPRING ARRUELA,MOLA 4
61 124-00302 CLAMP;PIPE BRAÇADEIRA,TUBO 16
62 124-00303 CLAMP;PIPE BRAÇADEIRA,TUBO 4
71 400309-00341A CYLINDER,BOOM;(L.H) CILINDRO,LANÇA;LH 1
72 400309-00343A CYLINDER,BOOM;(R.H) CILINDRO,LANÇA;RH 1
81 400305-00219 CYLINDER,ARM CILINDRO,BRAÇO 1
DX225LCA 6250 - 2
Serial No. ;
BOOM PIPING - ONE & TWO WAY(H.D)
TUBULAÇÃO DE LANÇA - CANAL DUPLO (H.D)
DATE DEC. 21, 2012
1st EDITION Fig. 6260
6260 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING - ONE & TWO WAY(H.D)
TUBULAÇÃO DE LANÇA - CANAL DUPLO (H.D)
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6260
6260 -- 420212-07903 PIPING,BOOM;1&2 WAY(5.7M) TUBULAÇÃO, BOOM - D
1 420207-02229 PIPE ASSY,HYDRAULIC TUBO 1
2 420207-02230 PIPE ASSY,HYDRAULIC TUBO 1
5 2180-1026D19 O-RING ANEL,O 4
6 S2212666 BOLT PARAFUSO,HEX SOQUETE 8
7 124-00368 CLAMP;PIPE BRAÇADEIRA,TUBO 16
8 180308-00235 RUBBER BUCHA 8
9 124-00367 CLAMP;PIPE BRAÇADEIRA,TUBO 4
10 2181-9078 FLANGE FLANGE 4
11 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 8
12 S8000291 O-RING ANEL,O 2
13 2181-1950D9 PLUG BUJAO,VERIFIQUE NOVAMENTE2
14 420207-01842 PIPE ASSY,HYDRAULIC TUBO 2
DX225LCA 6260 - 2
Serial No. ;
BUCKET ASS'Y - 0.92m³
Caçamba - 0.92M³
DATE DEC. 21, 2012
1st EDITION Fig. 6270
6270 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.92m³
Caçamba - 0.92M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6270
6270 -- 230104-01245 BUCKET ASS'Y-0.92㎥ CAÇAMBA CONJ 1
1 230104-01246 BUCKET-0.92㎥ CAÇAMBA,SOLDE 1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 5
2 K1038006A TOOTH PONTO,DENTE 5
3 2705-1020 PIN;LOCKING PINO,FECHADURA 5
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 5
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6270 - 2
Serial No. ;
BUCKET ASS'Y - 0.51m³
Caçamba- 0.51M³
DATE DEC. 21, 2012
1st EDITION Fig. 6280
6280 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.51m³
Caçamba- 0.51M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6280
6280 -- 230104-01249 BUCKET ASS'Y-0.51㎥ CAÇAMBA CONJ 1
1 230104-01250 BUCKET-0.51㎥ CAÇAMBA,SOLDE;0.51M3(SAE)1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 3
2 K1038006A TOOTH PONTO,DENTE 3
3 2705-1020 PIN;LOCKING PINO,FECHADURA 3
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 3
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6280 - 2
Serial No. ;
BUCKET ASS'Y - 0.81m³
Caçamba - 0.81M³
DATE DEC. 21, 2012
1st EDITION Fig. 6290
6290 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.81m³
Caçamba - 0.81M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6290
6290 -- 230104-01251 BUCKET ASS'Y-0.81㎥ CAÇAMBA CONJ 1
1 230104-01252 BUCKET-0.81㎥ CAÇAMBA,SOLDE 1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 5
2 K1038006A TOOTH PONTO,DENTE 5
3 2705-1020 PIN;LOCKING PINO,FECHADURA 5
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 5
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6290 - 2
Serial No. ;
BUCKET ASS'Y - 1.05m³
Caçamba - 1.052M³
DATE DEC. 21, 2012
1st EDITION Fig. 6300
6300 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.05m³
Caçamba - 1.052M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6300
6300 -- 230104-01253 BUCKET ASS'Y-1.05㎥ CAÇAMBA CONJ 1
1 230104-01254 BUCKET-1.05㎥ CAÇAMBA,SOLDE;1.05M3 1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 5
2 K1038006A TOOTH PONTO,DENTE 5
3 2705-1020 PIN;LOCKING PINO,FECHADURA 5
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 5
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6300 - 2
Serial No. ;
BUCKET ASS'Y - 1.17m³
Caçamba - 1.17M³
DATE DEC. 21, 2012
1st EDITION Fig. 6310
6310 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.17m³
Caçamba - 1.17M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6310
6310 -- 230104-01255 BUCKET ASS'Y-1.17㎥ CAÇAMBA CONJ 1
1 230104-01256 BUCKET-1.17㎥ CAÇAMBA,SOLDE;1.17M3 1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 6
2 K1038006A TOOTH PONTO,DENTE 6
3 2705-1020 PIN;LOCKING PINO,FECHADURA 6
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 6
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6310 - 2
Serial No. ;
BUCKET ASS'Y - 1.28m³
Caçamba - 1.28M³
DATE DEC. 21, 2012
1st EDITION Fig. 6320
6320 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.28m³
Caçamba - 1.28M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6320
6320 -- 230104-01257 BUCKET ASS'Y-1.28㎥ CAÇAMBA CONJ 1
1 230104-01258 BUCKET-1.28㎥ CAÇAMBA,SOLDE 1
1A 2713-1218A . ADAPTER;TOOTH . ADAPTADOR,DENTE 6
2 K1038006A TOOTH PONTO,DENTE 6
3 2705-1020 PIN;LOCKING PINO,FECHADURA 6
4 2114-1848A WASHER;LOCKING ARRUELA,FECHADURA 6
5 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
6 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
7 S0574661 BOLT M24X3.0X65 PARAFUSO,HEX 10
8 S4013333 NUT PORCA 10
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6320 - 2
Serial No. ;
BUCKET ASS'Y - 0.73m³(36") - SIDE PIN
Caçamba - 0.73M³(36") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 6330
6330 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.73m³(36") - SIDE PIN
Caçamba - 0.73M³(36") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig.6330
6330 -- 230104-01259 BUCKET ASS'Y-0.73m³(H.D) CAÇAMBA CONJ 1
1 K1013101A BUCKET;WITH TOOTH-0.73㎥ CAÇAMBA,SOLDE 1 D
1A 230104-01261 . BUCKET;WELD-0.73㎥ . CAÇAMBA,SOLDE 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 4
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 4
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 4
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 4
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6330 - 2
Serial No. ;
BUCKET ASS'Y - 0.90m³(42") - SIDE PIN
Caçamba - 0.90M³(42") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 6340
6340 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.90m³(42") - SIDE PIN
Caçamba - 0.90M³(42") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6340
6340 -- 230104-01262 BUCKET ASS'Y-0.90m³(H.D) CAÇAMBA CONJ 1
1 K1013104A BUCKET;WITH TOOTH-0.9㎥ CAÇAMBA,SOLDE 1 D
1A 230104-01264 . BUCKET;WELD-0.9㎥ . CAÇAMBA,SOLDE 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 5
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 5
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 5
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 5
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6340 - 2
Serial No. ;
BUCKET ASS'Y - 1.07m³(48") - SIDE PIN
Caçamba - 1.07M³(48") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 6350
6350 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.07m³(48") - SIDE PIN
Caçamba - 1.07M³(48") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6350
6350 -- 230104-01266 BUCKET ASS'Y-1.07㎥ CAÇAMBA CONJ 1
1 K1013108A BUCKET;WITH TOOTH-1.07m³ CAÇAMBA;COM DENTE 48" 1 D
1A 230104-01268 . BUCKET;WELD (48") . CAÇAMBA,SOLDE;48" 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 5
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 5
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 5
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 5
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6350 - 2
Serial No. ;
BUCKET ASS'Y - 1.32m³(57") - SIDE PIN
Caçamba - 1.32M³(57") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 6360
6360 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.32m³(57") - SIDE PIN
Caçamba - 1.32M³(57") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6360
6360 -- 230104-01272 BUCKET ASS'Y-1.32m³(H.D) CAÇAMBA CONJ 1
1 K1013114A BUCKET;WITH TOOTH-1.32㎥ CAÇAMBA;COM DENTE 1 D
1A 230104-01274 . BUCKET;WELD-1.32㎥ . CAÇAMBA,SOLDE 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 6
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 6
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 6
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 6
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6360 - 2
Serial No. ;
BUCKET ASS'Y - 1.49m³(63") - SIDE PIN
Caçamba - 1.49M³(63") - LADO PINO
DATE DEC. 21, 2012
1st EDITION Fig. 6370
6370 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 1.49m³(63") - SIDE PIN
Caçamba - 1.49M³(63") - LADO PINO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6370
6370 -- 230104-01275 BUCKET ASS'Y-1.49m³(H.D) CAÇAMBA CONJ 1
1 K1013118A BUCKET;WITH TOOTH-1.49㎥ CAÇAMBA;COM DENTE 1 D
1A 230104-01277 . BUCKET;WELD-1.49㎥ . CAÇAMBA,SOLDE 1
1AA 2713-1218A .. ADAPTER;TOOTH .. ADAPTADOR,DENTE 7
1B 713-00024A . TOOTH;POINT . PONTO,DENTE 7
1C 2705-1020 . PIN;LOCKING . PINO,FECHADURA 7
1D 2114-1848A . WASHER;LOCKING . ARRUELA,FECHADURA 7
2 2713-1059A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
3 2713-1060A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
4 S0574861 BOLT M24X3.0X75 PARAFUSO,HEX 10
5 S4013333 NUT PORCA 10
6 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 10
DX225LCA 6370 - 2
Serial No. ;
ARM - 2.4m
BRAÇO - 2.4M
DATE DEC. 21, 2012
1st EDITION Fig. 6380
6380 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM - 2.4m
BRAÇO - 2.4M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6380
6380 -- 230201-00105 ARM ASS'Y BRAÇO,MÁQUINA - D
1 230204-00084C ARM,MACHINE;2.4M BRAÇO,MÁQUINA 1
1A 131008-00064A . BUSHING . BUCHA;BRAÇO TIRANTE 2
1B K1000733 . BUSHING . BUCHA;BRAÇO FINAL RESSALTO2
1C K1000734 . BUSHING . BUCHA;BRAÇO TIRANTE 2
2 101541-00021B LINK ASSY,PUSH TIRANTE,EMPURRE 1
2A 131004-00026A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
2B 131004-00025A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
3 2155-1300B LINK;GUIDE(L.H) TIRANTE,GUIA 1
4 101540-00056 LINK;GUIDE(R.H) TIRANTE,GUIA;DIREITO 1
7 120501-01063 PIN PINO;BRAÇO CYL HASTE 1
8 120501-01064 PIN PINO;CAÇAMBA CYL CABEÇA1
9 120501-01065 PIN PINO;BRAÇO TIRANTE RESSALTO1
10 120501-01052 PIN PINO;BRAÇO TIRANTE À CAÇAMBA2
11 120501-02429 PIN;BUCKET CYL ROD PINO;CAÇAMBA CYL HASTE 1
12 2180-1106BD4 SEAL;DUST SELO,POEIRA 2
13 2180-1106BD24 SEAL;DUST SELO,POEIRA 14
14 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
15 DS7752012 SHIM CALÇO,POLÍMERO 8
16 DS7752013 SHIM CALÇO,POLÍMERO 8
17 DS7752006 SHIM CALÇO,POLÍMERO 2
18 DS7752007 SHIM CALÇO,POLÍMERO 2
19 2116-1060D6 STOPPER ROLHA 2
20 S0521366 BOLT PARAFUSO,HEX 2
21 S5102903 WASHER,SPRING ARRUELA,MOLA 2
22 S4012933 NUT PORCA 8
23 DS0001084 BOLT PARAFUSO,HEX 3
24 DS0001083 BOLT PARAFUSO,HEX 1
25 S6710041 NIPPLE;GREASE APROPRIADO 7
26 180-00077D5 O-RING ANEL,O 2
27 K1000911 SPACER ESPAÇADOR 2
29 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 7
30 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
31 S0712066 BOLT PARAFUSO,HEX 12
34 180-00077D3 O-RING ANEL,O 2
DX225LCA 6380 - 2
Serial No. ;
ARM PIPING - ARM 2.4m
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION Fig. 6390
6390 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 2.4m
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6390
6390 -- 420212-05429 ARM PIPING TUBULAÇÃO - D
1 400310-00215 CYLINDER,BUCKET CILINDRO,CAÇAMBA 1
3 2181-9079 FLANGE FLANGE 8
4 2180-1026D2 O-RING ANEL,O 4
5 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 8
6 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 8
11 DS20401141 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO2
DX225LCA 6390 - 2
Serial No. ;
LUBRICATION PIPING - ARM 2.4m
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 2.4M
DATE DEC. 21, 2012
1st EDITION Fig. 6400
6400 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - ARM 2.4m
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 2.4M
DATE DEC.21, 2012
1st EDITION
Serial No. ;
Fig. 6400
6400 -- 420212-05311 PIPING,LUBRICATION;2.4M TUBULAÇÃO, LUBRIFICAÇÃO - D
1 DS2055920 HOSE MANGUEIRA 1
2 DS2059600 HOSE PF1/4-330L MANGUEIRA CONJ,HIDRÁULICO1
3 DS2225009 ADAPTER ADAPTADOR 1
4 2181-1184 ADAPTER ADAPTADOR 4
5 K1001029 BOLT PARAFUSO 3
6 DS2802023 CLIP GRAMPO 1
7 S6710041 NIPPLE;GREASE APROPRIADO 4
8 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 4
9 K1010730 ELBOW COTOVELO 2
11 DS2805007 CLIP GRAMPO 1
12 S4032833 NUT PORCA 3
13 2181-1923D12 ADAPTER ADAPTADOR 2
14 K1025464 PIPE TUBO 1
15 K1025465 PIPE TUBO 1
16 K1025466 PIPE TUBO 1
18 K1025467 PIPE TUBO 1
19 DS2805008 CLIP GRAMPO 1
20 2181-4112 ADAPTER ADAPTADOR 2
21 420205-00283 PIPE TUBO 1
DX225LCA 6400 - 2
Serial No. ;
ARM PIPING - ARM 2.4m(ONE & TWO WAY)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (CANAL DUPLO
DATE DEC. 21, 2012
1st EDITION Fig. 6410
6410 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 2.4m(ONE & TWO WAY)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (CANAL DUPL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6410
6410 -- 420212-01717 ARM PIPING,ONE & TWO WAY TUBULAÇÃO - D
1 K1025246 PIPE TUBO 2
2 2184-1100D90 HOSE MANGUEIRA 2
3 2181-9078 FLANGE FLANGE 8
4 2180-1026D19 O-RING ANEL,O 6
5 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 16
6 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 8
10 S2215966 BOLT;SOCKET PARAFUSO,HEX SOQUETE 4
11 S5102803 WASHER;SPRING ARRUELA,MOLA 4
12 S0562766 BOLT PARAFUSO,HEX 4
13 K1004057 CLAMP;PIPE BRAÇADEIRA,TUBO 4
14 S5110703 WASHER;SPRING ARRUELA,MOLA 4
41 410137-00032B VALVE ASS'Y,STOP;(L.H) VÁLVULA CONJ,PARE;L.H 1
41-1 410137-00067A . VALVE,STOP;1"(LH) . VÁLVULA,PARE;ESQUERDA 1
41-2 S8000291 . O-RING . ANEL,O 1
41-3 2181-4133D6 . ADAPTER . ADAPTADOR 1
41-4 2181-2817D2 . CAP . CAPA,ORS 1
41-5 S8030161 . O-RING . ANEL,O 1
41-6 2181-1950D7 . PLUG . BUJAO 1
41-7 S8000181 . O-RING . ANEL,O 1
42 410137-00033B VALVE ASS'Y,STOP;(R.H) VÁLVULA CONJ,PARE;R.H 1
42-1 410137-00069A . VALVE,STOP;1"(RH) . VÁLVULA,PARE;DIREITO 1
42-2 S8000291 . O-RING . ANEL,O 1
42-3 2181-4133D6 . ADAPTER . ADAPTADOR 1
42-4 2181-2817D2 . CAP . CAPA,ORS 1
42-5 S8030161 . O-RING . ANEL,O 1
42-6 2181-1950D7 . PLUG . BUJAO 1
42-7 S8000181 . O-RING . ANEL,O 1
DX225LCA 6410 - 2
Serial No. ;
ARM PIPING - ARM 2.4m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (ENGATE RÁPI
DATE DEC. 21, 2012
1st EDITION Fig. 6420
6420 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 2.4m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 2.4M (ENGATE RÁP
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6420
6420 -- K1013434A ARM PIPING-QUICK CLAMP TUBULAÇÃO,RÁPIDA BRAÇADEIRA;2.4M B- D
1 K1025462 PIPE TUBO 1
2 K1025463 PIPE TUBO 1
3 DS2055867 HOSE MANGUEIRA 2
4 2181-2820D1 PLUG BUJAO 2
5 S0508866 BOLT PARAFUSO,HEX 6
6 S5102503 WASHER,SPRING ARRUELA,MOLA 6
7 K1004011 CLAMP;PIPE BRAÇADEIRA,TUBO 6
DX225LCA 6420 - 2
Serial No. ;
ARM - 3.5m
BRAÇO - 3.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6430
6430 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM - 3.5m
BRAÇO - 3.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6430
6430 -- 230201-00107 ARM ASSY BRAÇO,MÁQUINA - D
1 230204-00086C ARM ASS'Y-3.5M BRAÇO,MÁQUINA 1
1A 131008-00064A . BUSHING . BUCHA;BRAÇO TIRANTE 2
1B K1000733 . BUSHING . BUCHA;BRAÇO FINAL RESSALTO2
1C K1000734 . BUSHING . BUCHA;BRAÇO TIRANTE 2
2 101541-00021B LINK ASSY,PUSH TIRANTE,EMPURRE 1
2A 131004-00026A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
2B 131004-00025A . BUSHING,CARBURIZING . BUCHA;BRAÇO TIRANTE 2
3 101540-00056 LINK;GUIDE(R.H) TIRANTE,GUIA;DIREITO 1
4 2155-1300B LINK;GUIDE(L.H) TIRANTE,GUIA 1
7 120501-01063 PIN PINO;BRAÇO CYL HASTE 1
8 120501-01064 PIN PINO;CAÇAMBA CYL CABEÇA1
9 120501-01065 PIN PINO;BRAÇO TIRANTE RESSALTO1
10 120501-01052 PIN PINO;BRAÇO TIRANTE À CAÇAMBA2
11 120501-02429 PIN;BUCKET CYL ROD PINO;CAÇAMBA CYL HASTE 1
12 2180-1106BD4 SEAL;DUST SELO,POEIRA 2
13 2180-1106BD24 SEAL;DUST SELO,POEIRA 14
14 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
15 DS7752012 SHIM CALÇO,POLÍMERO 8
16 DS7752013 SHIM CALÇO,POLÍMERO 8
17 DS7752006 SHIM CALÇO,POLÍMERO 2
18 DS7752007 SHIM CALÇO,POLÍMERO 2
19 2116-1060D6 STOPPER ROLHA 2
20 S0521366 BOLT PARAFUSO,HEX 2
21 S5102903 WASHER,SPRING ARRUELA,MOLA 2
22 S4012933 NUT PORCA 8
23 DS0001084 BOLT PARAFUSO,HEX 3
24 DS0001083 BOLT PARAFUSO,HEX 1
25 S6710041 NIPPLE;GREASE APROPRIADO 7
26 180-00077D5 O-RING ANEL,O 2
27 K1000911 SPACER ESPAÇADOR 2
29 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 7
30 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
31 S0712066 BOLT PARAFUSO,HEX 12
34 180-00077D3 O-RING ANEL,O 2
DX225LCA 6430 - 2
Serial No. ;
ARM PIPING - ARM 3.5m
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6440
6440 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 3.5m
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6440
6440 -- 420212-05430 ARM PIPING TUBULAÇÃO - D
1 400310-00216 BUCKET CYLINDER CILINDRO,CAÇAMBA 1
3 2181-9079 FLANGE FLANGE 8
4 2180-1026D2 O-RING ANEL,O 4
5 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 8
6 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 8
11 DS2130012 HOSE ASSY,HYDRAULIC MANGUEIRA CONJ,HIDRÁULICO2
DX225LCA 6440 - 2
Serial No. ;
LUBRICATION PIPING - ARM 3.5m
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6450
6450 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - ARM 3.5m
TUBULAÇÃO DE LUBRIFICAÇÃO - BRAÇO 3.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6450
6450 -- 420212-05312 PIPING,LUBRICATION;3.5M TUBULAÇÃO, LUBRIFICAÇÃO - D
1 DS2055849 HOSE MANGUEIRA 1
2 DS2059598 HOSE PF1/4-360L MANGUEIRA CONJ,HIDRÁULICO1
3 DS2225009 ADAPTER ADAPTADOR 1
4 2181-1184 ADAPTER ADAPTADOR 4
5 K1001029 BOLT PARAFUSO 9
6 DS2802023 CLIP GRAMPO 6
7 S6710041 NIPPLE;GREASE APROPRIADO 4
8 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 4
9 K1000057 ELBOW COTOVELO,ADAPTADOR 2
11 DS2805007 CLIP GRAMPO 2
12 S4032833 NUT PORCA 3
13 2181-1923D12 ADAPTER ADAPTADOR 2
14 K1010218 PIPE TUBO 1
15 K1013684 PIPE TUBO 1
16 K1013685 PIPE TUBO 1
18 K1013686 PIPE TUBO 1
19 DS2805008 CLIP GRAMPO 1
20 2181-4112 ADAPTER ADAPTADOR 2
21 420205-00284 PIPE TUBO 1
DX225LCA 6450 - 2
Serial No. ;
ARM PIPING - ARM 3.5m(ONE & TWO WAY)
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (CANAL DUPLO
DATE DEC. 21, 2012
1st EDITION Fig. 6460
6460 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 3.5m(ONE & TWO WAY)
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (CANAL DUPL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6460
6460 -- 420212-01719 ARM PIPING,ONE & TWO WAY TUBULAÇÃO - D
1 K1008100 PIPE TUBO 2
2 DS2040489 HOSE MANGUEIRA 2
3 2181-9078 FLANGE FLANGE 8
4 2180-1026D19 O-RING ANEL,O 6
5 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 16
6 K1004057 CLAMP;PIPE BRAÇADEIRA,TUBO 8
10 S2215966 BOLT;SOCKETPARAFUSO,HEX SOQUETE 4
11 S5102803 WASHER;SPRING ARRUELA,MOLA 8
12 S0562766 BOLT PARAFUSO,HEX 8
13 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 8
14 S5110703 WASHER;SPRING ARRUELA,MOLA 4
41 410137-00030B VALVE ASSY,STOP;(L.H) VÁLVULA CONJ,PARE;L.H 1
41-1 410137-00067A . VALVE,STOP;1"(LH) . VÁLVULA,PARE;ESQUERDA 1
41-2 S8000291 . O-RING . ANEL,O 1
41-3 2181-2816D2 . ELBOW . COTOVELO 1
41-4 2181-2817D2 . CAP . CAPA,ORS 1
41-5 S8030161 . O-RING . ANEL,O 1
41-6 2181-1950D7 . PLUG . BUJAO 1
41-7 S8000181 . O-RING . ANEL,O 1
42 410137-00031B VALVE ASSY,STOP;(R.H) VÁLVULA CONJ,PARE;R.H 1
42-1 410137-00069A . VALVE,STOP;1"(RH) . VÁLVULA,PARE;DIREITO 1
42-2 S8000291 . O-RING . ANEL,O 1
42-3 2181-2816D2 . ELBOW . COTOVELO 1
42-4 2181-2817D2 . CAP . CAPA,ORS 1
42-5 S8030161 . O-RING . ANEL,O 1
42-6 2181-1950D7 . PLUG . BUJAO 1
42-7 S8000181 . O-RING . ANEL,O 1
DX225LCA 6460 - 2
Serial No. ;
ARM PIPING - ARM 3.5m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (ENGATE RÁPI
DATE DEC. 21, 2012
1st EDITION Fig. 6470
6470 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 3.5m(QUICK CLAMP)
TUBULAÇÃO DE BRAÇO - BRAÇO 3.5M (ENGATE RÁP
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6470
6470 -- K1013389 ARM PIPING-QUICK CLAMP TUBULAÇÃO,RÁPIDA BRAÇADEIRA- D
1 K1008111 PIPE TUBO 1
2 K1008112 PIPE TUBO 1
3 DS2055921 HOSE MANGUEIRA 2
4 2181-2820D1 PLUG BUJAO 2
5 S0508866 BOLT PARAFUSO,HEX 5
6 S5102503 WASHER,SPRING ARRUELA,MOLA 5
7 K1004011 CLAMP;PIPE BRAÇADEIRA,TUBO 5
DX225LCA 6470 - 2
Serial No. ;
BOOM - 8.5m
LANÇA - 8.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6480
6480 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM - 8.5m
LANÇA - 8.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6480
6480 -- 230207-00127 BOOM ASSY LANÇA,MÁQUINA - D
1 230211-00144A BOOM,MACHINE 8.5m LANÇA,MÁQUINA 1
1A 131008-00074A . BUSHING . BUCHA 2
1B 2180-1106BD6 . SEAL;DUST . SELO,POEIRA 2
4 K1007253B PIN PINO,CENTRAL;BOOM 1
5 2123-2185G PIN PINO;LANÇA FINAL,LANÇA À BRAÇO1
6 120501-01062 PIN PINO;BRAÇO CYL CABEÇA/HASTE1
7 2116-1531A STOPPER ROLHA 2
8 S0567066 BOLT PARAFUSO,HEX 2
9 S4012933 NUT PORCA 4
10 2180-1106BD6 SEAL;DUST SELO,POEIRA 2
11 2180-1106BD24 SEAL;DUST SELO,POEIRA 6
12 DS7752018 SHIM CALÇO,POLÍMERO 2
13 DS7752012 SHIM CALÇO,POLÍMERO 2
15 621-03710A PLATE;STOPPER PLACA,ROLHA 1
16 2116-1060D6 STOPPER ROLHA 1
17 S0521366 BOLT PARAFUSO,HEX 3
18 S5102903 WASHER,SPRING ARRUELA,MOLA 3
23 DS7752013 SHIM CALÇO,POLÍMERO 2
24 DS7752026 SHIM CALÇO,POLÍMERO 2
25 DS7752027 SHIM CALÇO,POLÍMERO 2
26 DS7752025 SHIM CALÇO,POLÍMERO;POLÍMERO4
27 DS7752017 SHIM CALÇO,POLÍMERO 2
28 K1017764 ROD;TIE HASTE,LAÇO 1
29 2123-1915A PIN PINO 2
30 2116-1472A PLATE;STOPPER PLACA,ROLHA 4
31 S5102703 WASHER;SPRING ARRUELA,MOLA 4
32 S0515053 BOLT M12X1.75X25 PARAFUSO,HEX 4
33 DS7752093 SHIM CALÇO,POLÍMERO 2
DX225LCA 6480 - 2
Serial No. ;
ARM - 6.2m
BRAÇO - 6.2M
DATE DEC. 21, 2012
1st EDITION Fig. 6490
6490 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM - 6.2m
BRAÇO - 6.2M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6490
6490 -- 230201-00137 ARM ASSY;(6.2M) BRAÇO,MÁQUINA - D
1 230204-00168B ARM,MACHINE;(6.2M) BRAÇO,MÁQUINA 1
1A 131008-00064A . BUSHING . BUCHA;BRAÇO TIRANTE 2
1B 131004-00020A . BUSHING . BUCHA,CEMENTAÇÃO 2
1C 131004-00021A . BUSHING . BUCHA,CEMENTAÇÃO 2
2 101541-00012 LINK;PUSH ASS`Y TIRANTE,EMPURRE 1
2A 2110-1366A . BUSHING . BUCHA;CAÇAMBA CYL./CAÇAMBA À P.TIR4
3 2155-1306B LINK;GUIDE(R.H) TIRANTE,GUIA;DIREITO 1
4 2155-1307B LINK;GUIDE(L.H) TIRANTE,GUIA;ESQUERDA 1
6 120501-01063 PIN PINO;BRAÇO CYL HASTE 1
7 120501-01066 PIN PINO;BUC CYL CABEÇA 1
8 120501-01041 PIN PINO;BRAÇO TIRANTE&BUC CYL HASTE2
9 120501-01042 PIN PINO;BRAÇO,TIRANTE À CAÇAMBA2
10 2180-1106BD24 SEAL;DUST SELO,POEIRA 2
11 2180-1106BD3 SEAL;DUST SELO,POEIRA 14
12 DS7752012 SHIM CALÇO,POLÍMERO 2
13 DS7752013 SHIM CALÇO,POLÍMERO 2
14 2116-1060D6 STOPPER ROLHA 1
15 S0521366 BOLT PARAFUSO,HEX 2
16 S5102903 WASHER,SPRING ARRUELA,MOLA 2
17 S4012933 NUT PORCA 8
18 S0566766 BOLT PARAFUSO,HEX 4
19 S6710041 NIPPLE;GREASE APROPRIADO 7
20 180-00077D3 O-RING ANEL,O 2
21 2180-1106BD14 SEAL;DUST SELO,POEIRA 2
22 DS7752001 SHIM CALÇO;POLÍMERO 8
23 DS7752002 SHIM CALÇO;POLÍMERO 8
24 2114-1994B SPACER ESPAÇADOR 2
25 2114-1995B SPACER ESPAÇADOR 2
26 2116-1060D6 STOPPER ROLHA 1
27 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 7
28 2181-1116D1 PLUG BUJAO,VERIFIQUE NOVAMENTE1
29 DS2854017 RING,O ANEL 2
DX225LCA 6490 - 2
Serial No. ;
COUNTER WEIGHT - SUPER LONG
CONTRAPESO - SUPER LONGO
DATE DEC. 21, 2012
1st EDITION Fig. 6500
6500 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
COUNTER WEIGHT - SUPER LONG
CONTRAPESO - SUPER LONGO
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6500
6500 -- 160702-00673 WEIGHT ASSY,COUNTER;5.3TON PESO,CONTADOR 1
1 160702-00674 WEIGHT,COUNTER;5.3TON PESO,CONTADOR 1
2 K1002454B BRACKET SUPORTE 1
3 DS0025015 BOLT;SET PARAFUSO 2
DX225LCA 6500 - 2
Serial No. ;
BUCKET ASS'Y - 0.39m³
CONJUNTO DE PÁ - 0.39M³
DATE DEC. 21, 2012
1st EDITION Fig. 6510
6510 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.39m³
CONJUNTO DE PÁ - 0.39M³
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6510
6510 -- 230104-01198 BUCKET ASS'Y- 0.39㎥ CAÇAMBA CONJ 1
1 230104-01199 BUCKET - 0.39㎥ CAÇAMBA,SOLDE 1
1A 2713-1222B . ADAPTER;TOOTH . ADAPTADOR,DENTE 4
2 713-00057C POINT;TOOTH PONTO,DENTE 4
3 2705-1022 PIN;LOCKING PINO,FECHADURA 4
4 2114-1859 WASHER;LOCKING ARRUELA,FECHADURA 4
5 2713-1229A CUTTER;SIDE(L.H) CORTADOR,LATERAL;ESQUERDA1
6 2713-1228A CUTTER;SIDE(R.H) CORTADOR,LATERAL;DIREITO1
7 S0574561 BOLT M24X3.0X60 PARAFUSO,HEX 8
8 S4013333 NUT PORCA 8
9 2114-1831A WASHER;HARDEN ARRUELA,RÍGIDO 8
DX225LCA 6510 - 2
Serial No. ;
BUCKET ASS'Y - 0.45m³ - DITCH CLEANING
CONJUNTO DE PÁ - 0.45M³ - BALDE DE LIMPEZA
DATE DEC. 21, 2012
1st EDITION Fig. 6520
6520 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BUCKET ASS'Y - 0.45m³ - DITCH CLEANING
CONJUNTO DE PÁ - 0.45M³ - BALDE DE LIMPEZA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6520
6520 -- K1010821B BUCKET ASS`Y-0.45㎥ CAÇAMBA CONJ;SUB 0.45M3DC1
1 K1010822B BUCKET-0.45㎥ CAÇAMBA;0.45M3 1
2 4713-4004B TOOTH PONTO,DENTE 7
3 S0565466 BOLT PARAFUSO,HEX 14
4 S4012933 NUT PORCA 14
DX225LCA 6520 - 2
Serial No. ;
BOOM PIPING - BOOM 8.5m
TUBULAÇÃO DE LANÇA - LANÇA 8.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6530
6530 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
BOOM PIPING - BOOM 8.5m
TUBULAÇÃO DE LANÇA - LANÇA 8.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6530
6530 -- K1045837 BOOM PIPING TUBULAÇÃO DE BOOM - D
1 K1045852 PIPE TUBO 1
2 K1045853 PIPE TUBO 1
3 K1045854 PIPE TUBO 1
4 K1045855 PIPE TUBO 1
5 K1018659 PIPE TUBO 1
6 K1018660 PIPE TUBO 1
7 K1018706 PIPE TUBO 1
8 K1045856 PIPE TUBO 3
9 K1045857 PIPE TUBO 110 K1018109 PIPE TUBO 1
11 K1018709 PIPE TUBO 1
12 K1018710 PIPE TUBO 1
13 DS2040637 HOSE MANGUEIRA,ÓLEO 1
14 DS2038226 HOSE MANGUEIRA,ÓLEO 1
15 124-00367 CLAMP;PIPE BRAÇADEIRA,TUBO 2
16 124-00300 CLAMP;PIPE BRAÇADEIRA,TUBO 2
17 124-00368 CLAMP;PIPE BRAÇADEIRA,TUBO 8
18 K1011211 CLAMP BRAÇADEIRA,TUBO 8
19 124-00302 CLAMP;PIPE BRAÇADEIRA,TUBO 8
20 124-00303 CLAMP;PIPE BRAÇADEIRA,TUBO 4
21 S0562766 BOLT PARAFUSO,HEX 18
22 S5102803 WASHER;SPRING ARRUELA,MOLA 18
23 161-00574 RUBBER BORRACHA;3/4" TUBO 16
24 161-00281 RUBBER BORRACHA;1" TUBO 4
25 S2212566 BOLT;SOCKET PARAFUSO,HEX SOQUETE 32
26 S2212666 BOLT PARAFUSO,HEX SOQUETE 8
27 2180-1026D2 O-RING ANEL,O 12
28 2181-9078 FLANGE FLANGE 8
29 2180-1026D19 O-RING ANEL,O 6
30 2181-9079 FLANGE FLANGE 8
31 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 16
32 S2212466 BOLT;SOCKET M10X1.5X40 PARAFUSO,HEX SOQUETE 16
51 400309-00341A CYLINDER,BOOM;(L.H) CILINDRO,LANÇA;LH 1
52 400309-00343A CYLINDER,BOOM;(R.H) CILINDRO,LANÇA;RH 1
61 400305-00219 CYLINDER,ARM CILINDRO,BRAÇO 1
62 S0562766 BOLT PARAFUSO,HEX 2
63 S5102803 WASHER;SPRING ARRUELA,MOLA 2
DX225LCA 6530 - 2
Serial No. ;
LUBRICATION PIPING - BOOM 8.5m
TUBULAÇÃO DE LUBRIFICAÇÃO -LANÇA 8.5M
DATE DEC. 21, 2012
1st EDITION Fig. 6540
6540 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - BOOM 8.5m
TUBULAÇÃO DE LUBRIFICAÇÃO -LANÇA 8.5M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6540
6540 -- K1045838 LUBRICATION PIPING(8.5M BOOM) TUBULAÇÃO DE LUBRIFICAÇÃO- D
1 K1038814 PIPE TUBO 1
2 K1038815 PIPE TUBO 1
3 DS2053864 HOSE MANGUEIRA 1
4 DS2053884 HOSE MANGUEIRA 1
5 2184-1045D254 HOSE MANGUEIRA 1
6 2181-1925 ELBOW COTOVELO 2
7 S3524403 PLUG ROSCA 1
8 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 5
9 2181-4112 ADAPTER ADAPTADOR 3
10 124-00199D4 CLIP GRAMPO 2
11 2124-1353D2 CLIP GRAMPO 7
12 K1001029 BOLT PARAFUSO 9
13 K1038003 GREASE PLATE ASS'Y PLACA,FRENTE 1
13-1 K1037887 . PLATE . PLACA,FRENTE 1
13-2 181-00525 . REDUCER . REDUTOR 2
13-3 S4032833 . NUT . PORCA 2
13-4 181-00103 . REDUCER . REDUTOR 3
13-5 121-00006 . NUT . PORCA 3
13-6 S6710041 . NIPPLE;GREASE . APROPRIADO 5
14 S0511866 BOLT PARAFUSO,HEX 2
15 S5102603 WASHER,SPRING ARRUELA,MOLA 2
DX225LCA 6540 - 2
Serial No. ;
ARM PIPING - ARM 6.2m
TUBULAÇÃO DE BRAÇO - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION Fig. 6550
6550 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
ARM PIPING - ARM 6.2m
TUBULAÇÃO DE BRAÇO - BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6550
6550 -- 420212-08378 PIPING,ARM(6.2M) TUBULAÇÃO, BRAÇO - D
1 K1011434A BUCKET CYLINDER CILINDRO,CAÇAMBA 1
2 K1018712 PIPE TUBO 2
3 K1018713 PIPE TUBO 2
4 DS2040543 HOSE MANGUEIRA,ÓLEO 2
5 DS2040544 HOSE MANGUEIRA,ÓLEO 2
6 124-00302 CLAMP;PIPE BRAÇADEIRA,TUBO 16
7 S2212366 BOLT;SOCKET M10X1.5X35 PARAFUSO,HEX SOQUETE 24
9 S2212566 BOLT;SOCKET PARAFUSO,HEX SOQUETE 8
10 2180-1026D19 O-RING ANEL,O 2
11 2180-1026D2 O-RING ANEL,O 8
12 2181-9078 FLANGE FLANGE 4
13 2181-9079 FLANGE FLANGE 12
14 S0562766 BOLT PARAFUSO,HEX 16
15 S5102803 WASHER;SPRING ARRUELA,MOLA 16
16 161-00574 RUBBER BORRACHA;3/4" TUBO 8
17 S2212266 BOLT;SOCKET M10X1.5X30 PARAFUSO,HEX SOQUETE 8
DX225LCA 6550 - 2
Serial No. ;
LUBRICATION PIPING - ARM 6.2m
TUBULAÇÃO DE LUBRIFICAÇÃO -BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION Fig. 6560
6560 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
LUBRICATION PIPING - ARM 6.2m
TUBULAÇÃO DE LUBRIFICAÇÃO -BRAÇO 6.2M
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6560
6560 -- 420212-05313 PIPING,LUBRICATION;6.2M TUBULAÇÃO, LUBRIFICAÇÃO - D
1 K1011522 PIPE TUBO 1
2 K1018714 PIPE TUBO 1
3 K1018715 PIPE TUBO 1
4 K1018762 PIPE TUBO 1
5 K1011527 PIPE TUBO 1
6 K1018763 PIPE TUBO 1
7 K1018764 PIPE TUBO 1
8 K1018765 PIPE TUBO 1
9 K1018766 PIPE TUBO 1
10 DS2059607 HOSE PF1/4-350L MANGUEIRA CONJ,HIDRÁULICO1
11 2184-1036D199 HOSE MANGUEIRA 1
12 2181-1184 ADAPTER ADAPTADOR 4
13 S6710041 NIPPLE;GREASE APROPRIADO 4
14 160-00020 CAP;GREASE NIPPLE CAPA,GRAXA;BICO 4
15 DS2805008 CLIP GRAMPO 2
16 K1001029 BOLT PARAFUSO 10
17 DS2225009 ADAPTER ADAPTADOR 5
18 S4032833 NUT PORCA 7
19 DS2805007 CLIP GRAMPO 3
20 K1010730 ELBOW COTOVELO 2
21 2181-1923D12 ADAPTER ADAPTADOR 2
22 2181-4112 ADAPTER ADAPTADOR 2
23 DS2802023 CLIP GRAMPO 5
DX225LCA 6560 - 2
Serial No. ;
SUN ROOF COVER
QUEBRA SOL
DATE DEC. 21, 2012
1st EDITION Fig. 6570
6570 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
SUN ROOF COVER
QUEBRA SOL
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6570
6570 -- 621-02870C SUN ROOF COVER TAMPA;SOL TELHADO - D
1 621-02871B COVER;SUN ROOF TAMPA,TELHADO 1
2 621-02872 COVER;ROOF HINGE TAMPA;TELHADO DOBRADIÇAS2
3 171-00060A HINGE;ROOF COVER DOBRADIÇAS;TELHADO TAMPA2
4 161-00599 PAD;RUBBER ALMOFADA,BORRACHA 2
5 123-00523 PIN;GAS-SPRING PINO;GÁS MOLA 2
6 123-00516B LOCK ASS'Y;ROOF COVER FECHADURA CONJ;TELHADO TAMPA1
7 621-02873 COVER;ROOF GAS-CYLINDER TAMPA,TELHADO 2
8 161-00600 PAD;RUBBER ALMOFADA,BORRACHA 2
9 191-03279A PLATE;ROOF GAS-SPRING RH PLACA;RH 1
10 191-03280A PLATE;ROOF GAS-SPRING LH PLACA;LH 1
11 DS1003008 GAS-SPRING MOLA,GÁS 2
12 621-03103 COVER;ROOF HANDLE TAMPA,TELHADO;MAÇANETA2
13 161-00639 RUBBER;ROOF HANDLE BORRACHA;TELHADO MAÇANETA2
14 2114-1898D3 WASHER;PLAIN ARRUELA,PLANÍCIE 6
15 S3450943 SCREW ROSCA 4
16 2120-2166D7 SCREW ROSCA 2
17 2114-1898D14 WASHER;PLAIN ARRUELA,PLANÍCIE 6
18 S2208561 BOLT;SOCKET PARAFUSO,HEX SOQUETE CABEÇA4
DX225LCA 6570 - 2
Serial No. ;
RAIN SHIELD
PROTEÇÃO CONTRA CHUVA
DATE DEC. 21, 2012
1st EDITION Fig. 6580
6580 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
RAIN SHIELD
PROTEÇÃO CONTRA CHUVA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6580
6580 -- K1002561B RAIN SHIELD PROTETOR DE CHUVA - D
1 159-00294C COVER;RAIN SHIELD TAMPA;CHUVA ISOLADOR 1
2 162-00040A STRIP;WEATHER TIRA,TEMPO 1
3 K1002574A BRACKET(L.H) SUPORTE 1
4 K1002575A BRACKET(R.H) SUPORTE 1
5 195-03374C BRACKET;RAIN SHIELD SUPORTE 2
6 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 4
7 621-03103 COVER;ROOF HANDLE TAMPA,TELHADO;MAÇANETA4
8 161-00639 RUBBER;ROOF HANDLE BORRACHA;TELHADO MAÇANETA6
9 2114-1898D5 WASHER M6 ARRUELA,PLANÍCIE 4
10 2114-1898D6 WASHER;PLAIN ARRUELA,PLANÍCIE 2
11 2120-2166D37 BOLT PARAFUSO,HEX 2
DX225LCA 6580 - 2
Serial No. ;
RAIN SHIELD & LAMP MOUNTING
PROTEÇÃO CONTRA CHUVA & SUPORTE LAMPADA
DATE DEC. 21, 2012
1st EDITION Fig. 6590
6590 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
RAIN SHIELD & LAMP MOUNTING
PROTEÇÃO CONTRA CHUVA & SUPORTE LAMPADA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6590
6590 -- 534-00117B RAIN SHIELD & LAMP ASS'Y PROTETOR DE CHUVA - D
1 159-00294C COVER;RAIN SHIELD TAMPA;CHUVA ISOLADOR 1
2 162-00040A STRIP;WEATHER TIRA,TEMPO 1
4 K1002574A BRACKET(L.H) SUPORTE 1
5 K1002575A BRACKET(R.H) SUPORTE 1
6 161-00639 RUBBER;ROOF HANDLE BORRACHA;TELHADO MAÇANETA8
7 621-03103 COVER;ROOF HANDLE TAMPA,TELHADO;MAÇANETA48 2114-1898D5 WASHER M6 ARRUELA,PLANÍCIE 4
9 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 2
10 2120-2166D10 SCREW ROSCA 2
11 2114-1898D6 WASHER;PLAIN ARRUELA,PLANÍCIE 2
12 2120-2166D37 BOLT PARAFUSO,HEX 2
DX225LCA 6590 - 2
Serial No. ;
FOGS GUARD ASS'Y
PROTEÇÃO CONTRA NEBLIMA
DATE DEC. 21, 2012
1st EDITION Fig. 6600
6600 - 1 DX225LCA
Key No. Part No. Description Description Q'ty S.C Serial No.ICA
Replaceable part
Part No. Q'ty
FOGS GUARD ASS'Y
PROTEÇÃO CONTRA NEBLIMA
DATE DEC. 21, 2012
1st EDITION
Serial No. ;
Fig. 6600
6600 -- 110921-01181 GUARD ASSY;FOGS GUARDA ASSY;NEVOEIROS - D
1 110921-01182 GUARD;FOGS GUARDA;FOGS 1
2 K1002846 GUARD;FRONT GUARDA,FOGS;FRENTE 1
3 K1002842A BRACKET SUPORTE 1
4 K1002838 BRACKET(L.H) SUPORTE 1
5 K1002839A BRACKET(R.H) SUPORTE 1
6 K1002840 BRACKET(L.H) SUPORTE 1
7 K1002841 BRACKET(R.H) SUPORTE 1
8 161-00195 STOPPER ROLHA,BORRACHA 2
9 2114-1898D17 WASHER M12 ARRUELA,PLANÍCIE 19
10 2120-2166D27 BOLT PARAFUSO,HEX 17
11 2121-1311D4 NUT PORCA 2
12 2114-1898D1 WASHER ARRUELA,PLANÍCIE 2
13 2114-1898D2 WASHER ARRUELA,PLANÍCIE 8
14 2121-1311D2 NUT PORCA 4
15 2114-1058D31 WASHER ARRUELA,PLANÍCIE 2
16 2114-1898D10 WASHER M12 ARRUELA,PLANÍCIE 2
17 2114-1898D6 WASHER;PLAIN ARRUELA,PLANÍCIE 2
18 2121-1311D1 NUT PORCA 2
19 S0515766 BOLT M12X1.75X55 PARAFUSO,HEX 2
20 K1005823 CYLINDER;GAS CILINDRO,GÁS 1
21 K1005822 CYLINDER;GAS CILINDRO,GÁS 1
22 2120-2166D5 BOLT PARAFUSO,HEX 4
23 2120-2166D32 BOLT PARAFUSO,HEX 2
24 K1007231A NAME;PLATE PLACA,NOME 1
25 2120-2166D52 BOLT M6X1.0X12 PARAFUSO,HEX 2
DX225LCA 6600 - 2
Fig No. Key No.Part No.
06.01013-9117 008 109
06.01013-9118 006 214
06.01013-9127 014 213
06.01013-9130 013 204
06.01283-7128 016 404
06.01493-4212 013 112
06.01493-4215 013 111
06.01493-4216 012 11
06.01493-4217 012 10
06.01494-4407 003 5
06.01494-4409 003 6
06.01494-4506 004 207
06.01733-4208 005 131
06.01733-4409 005 129
06.01733-4410 006 504
06.01913-2911 002 19
06.01913-3110 015 118
06.01913-3111 014 221
06.01913-3113 001 22
 001 30
 002 6
 008 117
06.01913-3114 010 80
06.01913-3115 002 12
 006 404
 015 121
06.01913-3119 011 9
06.01913-3120 002 5
06.01913-3122 002 15
 016 401
06.01913-3123 011 10
06.01913-3124 016 402
06.01923-3113 007 17
 010 50
06.01923-3114 007 2
 012 6
06.01923-3115 010 40
06.01923-3120 008 120
 010 30
06.01923-3124 014 205
06.01923-3215 015 205
06.01923-3222 009 160
06.01923-3225 009 150
06.01923-3228 009 140
06.01943-3213 005 134
 019 5
06.01943-3217 012 12
06.01943-3218 013 113
 018 3
06.01943-3222 006 512
Fig No. Key No.Part No.
06.01943-3318 019 2
06.01943-3319 018 14
06.01944-3215 008 122
 018 2
06.01953-3213 016 407
06.01953-3219 009 120
06.01953-3318 017 7
06.04190-8808 005 202
06.04200-9009 013 110
06.06125-8709 005 118
06.06125-8717 005 117
06.06125-8723 005 123
06.06175-8208 014 103
06.06225-0706 005 116
06.11024-9202 015 103
06.11063-8214 014 106
 014 214
 015 107
 016 109
06.11063-9215 016 409
06.11063-9217 003 9
 018 13
06.12172-9314 015 116
 016 310
06.15010-0308 005 204
06.15010-2311 006 215
 010 61
 012 9
 014 105
 014 208
 014 216
06.15010-2312 016 408
06.15091-0313 001 18
06.16044-0211 012 13
06.16731-2104 005 203
06.16731-2107 007 5
 008 110
 010 62
 012 8
 013 207
 014 104
 014 207
 014 215
 015 108
 016 110
 016 405
06.16731-2108 005 130
 013 114
 015 104
 016 410
Fig No. Key No.Part No.
06.16731-2108 019 7
06.16731-2110 003 8
 005 128
06.16731-2111 004 208
06.22022-3111 002 10
 003 10
06.22022-3119 002 4
06.22022-3212 004 105
06.22070-0913 008 113
06.29010-0116 006 213
06.29020-0132 013 105
06.29151-4608 006 402
06.31641-0222 008 116
 009 60
06.56017-0303 011 40
06.56021-0102 001 48
 021 4
06.56021-0106 001 37
 021 1
06.56180-0712 016 509
 020 13
 021 30
06.56180-0714 015 115
 016 307
 016 311
06.56180-0716 017 6
06.56190-0704 001 16
 015 113
06.56190-0706 001 39
06.56190-0709 009 50
 015 112
06.56190-0713 001 45
06.56190-0719 007 23
06.56190-0732 011 4
06.67020-0101 007 19
 007 21
 016 304
06.67020-0105 007 10
06.67020-0106 012 20
 015 123
06.67020-0109 015 203
06.78144-2204 016 503
 016 505
06.78144-2403 015 111
1.109-00026 4150 250
1.109-00124 4100 127
1.109-00134 4130 209
1.110-00068 4290 6
1.110-00169 4200 29
1.114-00009 4130 208
1
Fig No. Key No.Part No.
1.114-00012 4200 5
1.114-00286 4130 210
1.115-00032 4290 7
1.115-00171 4110 645
1.115-00204 4230 16
 4240 16
1.115-00366 4110 836
1.120-00219 4230 24
 4240 24
 4250 24
 4260 24
 4270 24
 4280 24
 4290 24
1.121-00028 4200 23
1.121-00044 4110 630
1.123-00007 4110 874
1.123-00009 4110 887
1.123-00012 4110 875
1.123-00014 4110 876
1.123-00016 4110 897
1.123-00053 4150 242
1.124-00157 4230 38
 4240 38
1.129-00006 4150 30
1.131-00048 4130 211
1.131-00049A 4150 213
1.131-00058 4150 28
1.131-00139 4110 626
1.131-00143 4110 625
1.131-00157 4110 646
1.131-00160 4110 654
1.131-00165 4110 624
1.131-00166 4110 653
1.131-00170 4110 644
1.131-00172 4110 655
1.138-00004 4200 21
1.148-00015 4130 206
1.161-00018 1820 20C
1.161-00019 1820 92C
1.161-00021 4200 25A
1.162-00001 1670 1A
1.178-00004 4200 26
1.180-00117 4290 21
1.180-00144 4160 130
1.180-00277 4230 22
 4240 22
1.180-00278 4260 14
 4270 14
 4280 14
Fig No. Key No.Part No.
1.180-00415 4290 19
1.180-00447 4220 4A
1.180-00496 4290 11
1.180-00512 4160 102
1.180-00527 4150 402
1.180-00662 4250 14
1.181-00059 4150 24
1.181-00067 4150 26
1.181-00090 4110 615
1.181-00136 4110 614
1.195-00022 4250 30
1.197-00005 4100 250
1.216-00017 4160 118
1.357-00005 4110 612
1.357-00008 4110 613
1.357-00014 4110 611
1.402-00017 4120 361
1.402-00036 4110 622
1.402-00055 4110 601
1.403-00037 4120 353
1.403-00040 4120 354
1.405-00060 4100 111
1.409-00167 4100 11
1.409-00189 4110 621
1.409-00204 4110 643
1.409-00225 4210 33
1.412-00017 4200 19
1.412-00083 4100 153
1.412-00092 4130 207
1.412-00157 4160 133
1.415-00005 4150 71
1.416-00017 4200 10
1.416-00018 4200 15
1.420-00013 4150 27
1.420-00050 4250 28
1.424-00038 4110 652
1.424-00041 4150 65
1.425-00001 4110 651
1.426-00005 4120 307
1.427-00002 4120 308
1.428-00208 4110 623
1.430-00017 4110 656
1.430-00212 4100 261
1.451-00060 4100 14
1.451-00063 4100 13
1.471-00001A 4150 79
1.519-00001 4220 3
1.540-00003 4160 106
1.540-00006 4150 267
100201-00158 4100 312
Fig No. Key No.Part No.
100502-00001 4140 20
100502-00022 4140 51
100601-00023 1510 49-4
100601-00024 1510 49-5
101-00006 4100 114
101539-00255 2170 1A
 6200 1-1A
 6210 1-1A
 6220 1-1A
101539-00256 2170 1B
 6200 1-1B
 6210 1-1B
 6220 1-1B
101540-00055 6240 3
101540-00056 3120 3
 6380 4
 6430 3
101541-00012 6490 2
101541-00021B 3120 2
 6380 2
 6430 2
101541-00114 6240 2
101551-00064 1140 14
101551-00065 1140 15
101551-00066 1140 16
101594-00300 5110 -
104-00048 4140 18
104-00050 4140 12
105220-649A 016 301A
109-00097 4100 123
109-00098 4100 124
109-00174 4140 8
110-00079 4230 6
 4240 6
110-00081 4250 6
110-00097 4260 6
 4270 6
 4280 6
110-00219 4140 13
110406-00039 1250 11
110406-00608 1740 39
110406-01352 1740 30
110406-02099 1480 15
110406-02589 2130 2
110420-00330 1750 33
110420-00566 1740 2
110421-00052 1150 12-2
110425-00065 6120 3
110427-00210 1120 3
110427-00211 1120 5
2
Fig No. Key No.Part No.
110427-00212 1120 4
110427-00213 1120 6
110502-00025 1610 10
110502-00524 1610 19
110503-00008A 1650 4-2
110503-00016C 1650 4
110506-00047 1670 1
110508-00989 4290 5
110508-04839 1740 37
110508-08513 1630 -
 1640 -
 1650 -
 1660 -
 1670 -
110508-08802 1660 10
110508-09675 4160 123
110508-14220 2140 6-4
110517-00364 1470 2
110517-00370 1470 -
110902-00211 1170 1C
110910-00038A 1500 121
110910-00077 1500 122
110910-002651470 39
110910-00918 1140 24
110911-00126 1200 5
110917-00477 2150 7-2
110917-00478 2150 7-3
110921-00091 1770 13
110921-01181 6600 -
110921-01182 6600 1
110921-02339 1140 13A
110925-00007 1570 1
110925-00241 1460 30
110935-00069 1550 1
110947-00027 1630 3-28
 1640 2-22
110948-00134 1140 13
110951-00128 6120 13
110951-00998 2130 6
110955-00106B 6200 2
110955-00107B 6210 2
110955-00108C 6220 2
110956-00002A 1630 3-5
 1640 2-4
110956-00060 4150 C-3
110956-00328 1510 53
110956-00329 1510 54
110958-00097 1610 2
110958-00181A 1640 2-1
110958-00230 1630 3-1
Fig No. Key No.Part No.
110958-01055 1610 6
110958-01083 1120 26
110958-01518 1610 -
 1620 -
110958-01541 1610 8
110958-02139 2120 5-2B
110982-00103C 1640 2
110982-00128A 1640 2-2
110982-00131 1630 3-3
110982-00132A 1630 3
110982-00133 1630 3-2
111601-00117 4150 261
111601-00354 4150 66
111601-00588 2130 7
114-00228 4100 158
114-00411 4190 40
114-00413 4190 53
114-00414 4170 57
114-00425 1200 16
 1230 19
 1280 25
114-00527 4140 21
114-00529 1660 34
114-00548 4140 17
114-00590 1430 13
115-00042 4210 19
115-00043 4120 700
115-00050 4230 7
 4240 7
115-00051 4230 12
 4240 12
115-00052 4290 12
115-00055 4260 19
 4270 19
 4280 19
115-00059 4230 11
 4240 11
115-00063 4260 12
 4270 12
 4280 12
115-00073 4250 7
115-00077 4250 11
115-00078 4250 12
115-00079 4250 19
115-00081 4250 26
115-00084 4260 11
 4270 11
 4280 11
115-00087 4230 19
 4240 19
Fig No. Key No.Part No.
116-00092A 1530 32-28D
119-00014AD1 1200 6
119-00025B 1230 13
120-00050B 2110 21
120-00130 4100 954
120-00131 4120 311
120-00144 4140 32
120-00199 4110 925
120-00317 1250 17
120107-00002 4140 24
120112-01199 2170 2
 6200 1-2
 6210 1-2
 6220 1-2
120117-00071 1750 34
120119-00022 1150 12-3
120311-00145 2130 5
120312-00429 2140 6-8
120312-00430 2170 3
 6200 1-3
 6210 1-3
 6220 1-3
120501-00009 4140 23
120501-01041 6490 8
120501-01042 6490 9
120501-01052 3120 10
 6240 8
 6380 10
 6430 10
120501-01061 3100 3
120501-01062 3110 6
 6230 4
 6480 6
120501-01063 3120 7
 6240 5
 6380 7
 6430 7
 6490 6
120501-01064 3120 8
 6240 6
 6380 8
 6430 8
120501-01065 3120 9
 6240 7
 6380 9
 6430 9
120501-01066 6490 7
120501-01812 3100 2
120501-02429 3120 11
 6240 9
3
Fig No. Key No.Part No.
120501-02429 6380 11
 6430 11
120501-02552 2130 12
120501-02553 2150 7-6
120501-02554 2170 1E
 6200 1-1E
 6210 1-1E
 6220 1-1E
120501-02555 2170 1F
 6200 1-1F
 6210 1-1F
 6220 1-1F
120810-00145 1270 30
120811-00001 4140 31
120816-00001 4140 33
121-00006 1190 6
 3150 18-5
 6540 13-5
121-00010D1 1350 177-3
 6120 29-3
 6150 10
 6170 8
121-00010D3 1190 1E
121-00010D7 6120 29-9
 6170 13
121-00038 4120 312
121-00085 1220 1E
123-00150 4100 530
123-00151 4100 885
123-00516B 1580 19
 6570 6
123-00523 1500 66
 1580 19
 6570 5
123-00524B 1430 2
124-00010 1530 32-35
124-00052 4250 33
124-00070 1680 11
124-00088 4230 27
 4240 27
124-00194 1160 3
124-00199D4 3150 14
 6540 10
124-00208D2 1130 31
 1190 8
 1710 17
 1770 7
 1780 26
124-00208D3 1330 7
 1710 16
Fig No. Key No.Part No.
124-00208D3 1720 36
 1780 27
 1820 24
124-00208D4 1720 38
 1780 28
124-00208D5 1220 21
 1720 39
 1780 29
124-00208D6 1120 32
 1220 20
 1330 11
 6120 12
124-00208D7 1340 8
 1800 7
124-00208D8 1360 10
124-00208D9 1340 9
124-00209D1 1210 9
 1820 25
124-00209D2 1400 7
124-00209D3 1400 8
124-00209D8 1400 9
124-00218 1280 14
124-00300 3140 13
 6250 13
 6530 16
124-00302 3140 61
 6250 61
 6530 19
 6550 6
124-00303 3140 62
 6250 62
 6530 20
124-00310A 1150 33
124-00344 1530 32-36
124-00367 3140 12
 6130 9
 6250 12
 6260 9
 6530 15
124-00368 3140 15
 6130 7
 6250 15
 6260 7
 6530 17
125-00034A 1630 3-2A
125-00035A 1640 2-2A
125-00071B 1650 4-2A
125-00072 1530 32-11
125-00075A 1670 13
125-00077 1520 70
Fig No. Key No.Part No.
125-00078 1520 71
129-00043 4210 17
129-00044 4100 157
129-00045 4120 310
129-00062 4130 310
129-00071 4250 29
129-00124 4190 21
129-00125 4190 26
129-00126 4170 33
129-00127 4190 35
129-00128 4190 39
129-00129 4190 48
129-00130 4190 45
129-00139 4190 98
130205-00251 013 209
 5110 26
130422-00001A 4140 9
130424-00001 4140 22
130425-00001 4140 25
130426-00010 1190 1B
 4140 -
130602-00200 4150 260
130702-00152 2120 5-2D
130707-00042 1760 21A
 6190 1A
130712-01144 2120 5-2C
130712-01145 2140 6-2
130712-01146 2150 7-4
131002-00085A 1850 1
131002-00517 2170 1G
 6200 1-1G
 6210 1-1G
 6220 1-1G
131002-00518 2170 1H
 6200 1-1H
 6210 1-1H
 6220 1-1H
131004-00020A 6490 1B
131004-00021A 6490 1C
131004-00023A 3120 1B
 6240 1B
131004-00024A 3120 1C
 6240 1C
131004-00025A 3120 2B
 6240 2B
 6380 2B
 6430 2B
131004-00026A 3120 2A
 6240 2A
 6380 2A
4
Fig No. Key No.Part No.
131004-00026A 6430 2A
131008-00064A 3120 1A
 6240 1A
 6380 1A
 6430 1A
 6490 1A
131008-00067A 4230 2
 4230 4
 4240 2
 4240 4
 4260 2
 4260 4
 4270 2
 4270 4
 4280 2
 4280 4
131008-00074A 6480 1A
131008-00130 4250 2
 4250 4
131008-00140 3110 1A
 6230 1A
131150-2620 016 301B
131424-1520 016 301D
133-00172 1270 7
133-00220E 1530 37
133-00221 1530 32-9
133-00229A 1560 10
133-00230A 1560 11
136-00002 1230 11
136-00055A 1530 32-12
137-00092 1530 32-10
140-01484B 1280 2
140-01485B 1280 3
140-01601C 1290 4
140-01602C 1290 5
140-01604C 1250 4
140-02009A 1260 2
140107-00508 2140 6-3
140109-00048 2100 2
142-00127C 1510 52
142-00128B 1510 51
145-00124A 1530 32-18
148-00012 4210 16
150102-00439 4130 205
150109-00736 1120 -
 1130 -
 1150 -
150120-00034 1520 87
150120-00035 1520 86
156639-8820 016 301E
Fig No. Key No.Part No.
159-00017 4210 18
159-00227 1270 14
159-00294C 6580 1
 6590 1
160-00020 1190 7
 1700 8
 3120 29
 3150 11
 3170 8
 6240 26
 6380 29
 6400 8
 6430 29
 6450 8
 6490 27
 6540 8
 6560 14
160-00027 1190 12
160-00040 1270 18
160-00068A 1100 6
160-00069 2180 16
160-00071 1560 5
160-00072 1560 6
160-00073A 1560 26
160-00080B 1560 7
160-00081 1100 33
160601-00903 2130 3
160617-00231A 2100 101
160620-00347 1100 -
160620-00348A 1100 1
160626-00058 1490 -
160702-00637 1110 -
160702-00638 1110 1
160702-00673 6500 -
160702-00674 6500 1
161-00010 1490 1
161-00011 1490 2
161-00080 4210 9
161-00195 1510 34
 1530 34
 6600 8
161-00281 1280 11
 3140 20
 6130 8
 6530 24
161-00381 1560 14
161-00382 1560 15
161-00548 1120 18
161-00550 1120 19
161-00574 3140 19
Fig No. Key No.Part No.
161-00574 6530 23
 6550 16
161-00580 1650 29
161-00598A 1500 59
161-00599 6570 4
161-00600 6570 8
161-00609E 1520 84
161-00610E 1520 85
161-00613C 1520 90
161-00614 1680 15
161-00618B 1510 63
161-00619B 1510 64
161-00620 1530 32-28C
161-00621B 1530 32-28
161-00622 1480 23
161-00623 1530 32-6
161-00624 1480 34
161-00639 6570 13
 6580 8
 6590 6
161-00640A 1500 30
162-00033A 1530 32-3C
162-00034B 1510 7
162-00038 1500 9
162-00039A 1500 8
162-00040A 6580 2
 6590 2
170-00004 1170 11
170301-00111B 1190 1
170303-00049B 1190 1A
 4130 -
170401-00039B 2110 3
170402-00028 4160 -
170403-00134 4150 -
171-00060A 6570 3
172-00053B 1570 1-1
172-00055A 1520 91
180-00077D3 3120 34
 6240 29
 6380 34
 6430 34
 6490 20
180-00077D5 3120 26
 6240 24
 6380 26
 6430 26
180-00198 4200 18
 4210 22
180-00199 4210 23
180-00211 4120 309
5
Fig No. Key No.Part No.
180-00220 4130 307
180-00221 4130 308
180-00276 4260 21
 4270 21
 4280 21
180-00398 4190 47
180-00400 4190 102
180-00402 4180 66
180-00403 4180 65
180-00445 4190 55
180-00463 1100 7
 2100 11
180102-00743 1510 119
180102-00744 1510 118
180308-00235 6250 20
 6260 8
180308-00411 6250 19
181-00078D1 1350 177-2
 6120 29-2
 6150 4
181-00078D5 6170 3
181-00086D1 1350 177-6
 6120 29-6
181-00086D2 1350 177-7
 6120 29-7
181-00103 1190 4
 3150 18-4
 6540 13-4
181-00144D5 1350 23
181-00318 4110 496
181-00519 4100 490
181-00525 3150 18-2
 6540 13-2
181-005654170 71
181-00628 4190 37
181-00630 4190 43
181-00631 4190 52
181-00633 4170 60
181-00646 4180 91
181-00647 4170 92
 4190 92
181-00649 4170 93
181-00698 1190 1D
181-00701 4170 72
 4180 105
 4180 72
181-00779 6120 10
181-00809 1220 1C
181-00810 1220 1D
185-00167D3 1220 12
Fig No. Key No.Part No.
185-00410C 1170 10
186-00017A 1200 9
190-00648A 5130 16
190-01172 1220 19
190-01192D24 1710 14
190-01192D26 1710 21
190-01192D29 1710 20
190112-00021 1460 29
191-02990C 1100 28
191-03166C 1520 17
191-03279A 6570 9
191-03280A 6570 10
191-03283 1530 32-28A
193-00912 1170 7
193-00913A 1170 4
195-00163 6170 4
195-00463 4100 251
195-02079 1270 10
195-02157 1270 28
195-02465 1120 14
195-02623B 1100 31
195-02624C 1650 41
195-02662B 1220 2
195-02706C 1650 27
195-02716C 1330 4
195-02719C 1530 38
195-02729 1500 58
195-02739C 1510 49-2
195-02740E 1510 49-3
195-02753C 1410 1
195-02755C 1420 1
195-02768E 1470 14
195-02769E 1470 15
195-02770E 1470 18
195-02771C 1480 14
195-02774A 1480 22
195-02775A 1840 2
195-02785E 1480 24
195-02868C 1410 5
195-02883B 1290 6
195-02884B 1290 7
195-02904C 1430 1-2
195-02908E 1830 3
195-02948A 1600 1
195-02949A 1590 1
195-03123E 6150 2
195-03374C 6580 5
195-03435B 6100 5
195-03436B 6100 6
195-03437E 6110 2
Fig No. Key No.Part No.
198-00016 1330 5
 1400 6
198-00036A 1510 123
198-00053A 1530 32-8
198-00054A 1500 5
2.121-00009 4130 102
200101-00045 2120 5
200101-00046 2120 5-1
 2130 -
200102-00082 2120 5-2
200103-00125 2170 1
 6200 1-1
 6210 1-1
 6220 1-1
200104-00053 2150 7
200105-00043 2140 6
200106-00382 6200 -
200106-00383 6210 -
200106-00384 6220 -
200106-00385 2170 -
200106-00386 6200 1
200106-00387 6210 1
200106-00388 6220 1
200106-00467 2170 4
200106-00468 6200 1-4
200106-00469 6210 1-4
200106-00470 6220 1-4
200108-00095 2110 4
200112-00076 2100 9
2106-1019D10 1820 30
 5110 8
2107-6006 1820 13
2109-9033 4140 4
2110-1184D7 4210 27
2110-1366A 6490 2A
2114-1058D10 1330 37
 1400 22
2114-1058D2 1490 4
2114-1058D29 1790 4
 1820 19
2114-1058D30 1630 3-11
 1640 2-12
2114-1058D31 6600 15
2114-1058D45 1630 3-9
 1640 2-10
2114-1058D52 1820 29
2114-1058D54 1650 52
 1670 52
 1760 3
2114-1058D56 1670 23
6
Fig No. Key No.Part No.
2114-1058D68 1650 19
2114-1058D72 1220 5
 1250 34
2114-1154 1650 37
2114-1813 1200 14
 1230 17
2114-1814 1200 15
 1230 18
2114-1816A 1130 28
 2110 26
2114-1831A 3130 6
 6270 9
 6280 9
 6290 9
 6300 9
 6310 9
 6320 9
 6330 6
 6340 6
 6350 6
 6360 6
 6370 6
 6510 9
2114-1848A 3130 1D
 6270 4
 6280 4
 6290 4
 6300 4
 6310 4
 6320 4
 6330 1D
 6340 1D
 6350 1D
 6360 1D
 6370 1D
2114-1856 1530 42
2114-1859 6510 4
2114-1898D1 1490 7
 1560 4
 1590 3
 1600 3
 6600 12
2114-1898D10 6600 16
2114-1898D13 1500 76
 1520 76
2114-1898D14 1270 74
 1430 1-5
 1430 5
 1470 31
 1480 28
Fig No. Key No.Part No.
2114-1898D14 1500 18
 1510 18
 1530 18
 1560 9
 1580 19
 1580 21
 6570 17
2114-1898D15 1440 4
 1530 23
 1530 32-22
 1540 3
 1570 1-3
2114-1898D17 1430 8
 1560 2
 6600 9
2114-1898D18 1430 11
2114-1898D2 1530 32-25
 1530 46
 6600 13
2114-1898D3 1500 19
 1510 19
 1510 49-10
 1520 19
 1530 19
 1530 32-29
 1580 16
 1580 19
 6570 14
2114-1898D4 1410 19
2114-1898D5 1470 36
 1480 31
 1520 113
 6580 9
 6590 8
2114-1898D6 1510 26
 1830 5
 6580 10
 6590 11
 6600 17
2114-1901A 4140 11
2114-1929 1120 17
2114-1994B 6490 24
2114-1995B 6490 25
2114-2031D1 1520 97
2114-2031D4 1430 6
 1470 33
2114-2031D5 1400 21
2114-9012A 1100 21
 1120 25
 1190 10
Fig No. Key No.Part No.
2114-9012A 2100 27
2116-1060D6 3100 16
 3110 16
 3120 19
 6230 13
 6240 17
 6380 19
 6430 19
 6480 16
 6490 14
 6490 26
2116-1472A 6480 30
2116-1531A 3110 7
 6230 5
 6480 7
2119-1063B 1190 1J
2119-1065 4140 30
2120-1354 1740 13
2120-1413D12 1250 18
2120-2150D1 1530 43
2120-2150D3 1530 28
 1530 32-33
2120-2165 1170 12
2120-2166D1 1530 32-23
 1530 41
 1560 3
 1590 2
 1600 2
2120-2166D10 1410 10
 1420 10
 1440 3
 1480 26
 1520 14
 6590 10
2120-2166D12 1480 29
 1500 25
 1510 25
 1510 49-12
 1530 25
2120-2166D18 1520 99
2120-2166D2 1490 6
 1570 1-2
2120-2166D23 1470 26
2120-2166D26 1500 77
 1520 77
2120-2166D27 6600 10
2120-2166D28 1500 20
 1510 20
 1510 49-11
 1520 20
7
Fig No. Key No.Part No.
2120-2166D28 1530 20
 1530 32-30
2120-2166D32 6600 23
2120-2166D36 1470 35
 1480 30
2120-2166D37 6580 11
 6590 12
2120-2166D4 1540 2
 1560 16
2120-2166D41 1230 22
2120-2166D5 1270 75
 1430 1-3
 1430 10
 1470 32
 1480 35
 1500 47
 1530 32-24
 1530 47
 6600 22
2120-2166D52 1410 16
 1420 11
 1470 23
 1510 49-15
 1510 80
 1520 80
 1530 32-31
 6580 6
 6590 9
 6600 25
2120-2166D53 1410 9
 1440 5
 1470 24
 1480 27
 1500 111
 1520 111
 1530 32-37
2120-2166D54 1830 4
2120-2166D55 1560 1
2120-2166D57 1470 38
2120-2166D58 1480 36
2120-2166D7 1500 31
 1520 31
 6570 16
2120-2166D9 1580 19
 1580 21
2120-2187 1820 31
2121-1305 1720 59
 1750 24
2121-1311D1 1430 9
 6600 18
Fig No. Key No.Part No.
2121-1311D2 1430 7
 6600 14
2121-1311D4 1510 39
 1530 39
 6600 11
2121-9007 1490 5
2122-1002D2 5180 2
2122-1002D4 5130 17
2123-1011 2120 5-2G
2123-1107D7 1100 14
2123-1915A 6480 29
2123-2185G 3110 5
 6230 3
 6480 5
2123-2247 1530 32-19
2123-4030 1190 13
2123-6119 1530 32-3B
2124-1025D5 1290 13
2124-1025D6 1290 12
2124-1353D2 3150 15
 6540 11
2124-1509D1 1270 25
 1770 8
 1780 24
 1840 6
2124-1509D10 1270 21
2124-1509D2 1210 8
2124-1689A 1530 32-20
2125-1095A 1480 16
2125-9055 1530 35
2127-1002A 1530 48
2129-1008 1230 12
2129-1393 1230 4
2129-1446 1530 117
213-00029C 1470 13
213-00030B 1470 8
213-00031E 1470 9
213-00032B 1470 10
213-00033B 1470 11
213-00034E 1470 12
213-00035B 1470 7
213-00037B 1480 3
213-00038B 1480 4
213-00039B 1480 5
213-00040A 1480 21
2132-1133B 1560 22
2132-1134B 1560 21
2138-9006B 1270 73
2140-1338 1510 55
 1520 55
Fig No. Key No.Part No.
2140-1406 4140 29
2142-9005 1530 33
2150-1122 1270 6
2150-1132A 1530 32-14
2150-1133 1520 93
2155-1300B 3120 4
 6380 3
 6430 4
2155-1306B 6490 3
2155-1307B 6490 4
2160-1004D31 1100 38
2160-1004D39 1100 16
2160-1004D48 1100 15
2160-1004D55 1100 27
2160-1201D11 1100 17
2160-1201D12 1100 26
2160-1201D13 1100 25
2160-1212 1780 4
2160-1213 1780 5
2160-1310 1500 21
2160-1336 1220 12C
2160-1345 1590 4
2160-1346 1600 4
2161-2212 1520 72
2161-2487 1560 25
2172-9021 1530 32-17
2180-1026D19 1280 55
 1290 55
 1300 55
 1310 55
 1320 55
 2180 9
 3140 24
 6100 18
 6110 1B
 6130 5
 6140 4
 6250 24
 6260 5
 6410 4
 6460 4
 6530 29
 6550 10
2180-1026D2 1290 54
 1310 54
 3140 22
 3160 4
 6250 22
 6390 4
 6440 4
8
Fig No. Key No.Part No.
2180-1026D2 6530 27
 6550 11
2180-1026D24 1250 49
 1260 49
2180-1026D27 1250 50
2180-1026D28 1250 51
2180-1026D31 1240 52
 1250 52
2180-1106BD14 6490 21
2180-1106BD24 3100 11
 3110 11
 3120 13
 6230 9
 6240 11
 6380 13
 6430 13
 6480 11
 6490 10
2180-1106BD3 6490 11
2180-1106BD4 3120 12
 6240 10
 6380 12
 6430 12
2180-1106BD6 3110 10
 3110 1B
 3120 14
 6230 8
 6240 12
 6380 14
 6430 14
 6480 10
 6480 1B
2180-1217D109 4170 89
2180-1217D96 4250 15
2180-1254 4140 7
2180-6086 1820 92A
2180-6088 1820 20A
2180-9153 5110 11
2181-1110D3 1190 1C
2181-1116D1 2140 6-12
 2150 7-7
 3120 30
 4150 91
 4210 4
 6240 27
 6380 30
 6430 30
 6490 28
2181-1116D10 4150 54
2181-1116D2 2160 8-15
Fig No. Key No.Part No.
2181-1116D2 4130 312
 4140 27
 4200 2
2181-1116D3 4250 31
2181-1116D4 4130 311
 4140 28
2181-1116D9 2120 5-2H
2181-1126D103 1370 22
2181-1126D115 1240 26
2181-1126D14 1330 19
 1340 133
 1340 19
 1370 19
 1400 16
 2180 13
2181-1126D27 1370 20
 1380 14
 1390 14
2181-1126D28 1380 15
 1390 15
2181-1126D36 1380 18
 1400 18
 6120 8
2181-1126D38 1340 21
2181-1126D6 1240 22
 1260 22
 1330 17
 1340 17
 1370 17
 1400 192180 12
2181-1126D7 1350 18
 1360 18
 1370 18
 1380 17
 1390 17
 6150 5
2181-1126D85 6150 6
2181-1159 1800 3
2181-1160A 1800 4
2181-1161A 1800 5
2181-1184 3170 4
 6400 4
 6450 4
 6560 12
2181-1702D10 1370 25
2181-1702D2 1330 27
2181-1702D3 1350 24
 1360 24
 6150 8
Fig No. Key No.Part No.
2181-1702D34 1370 28
2181-1702D4 1330 26
 1340 26
 1350 26
 1360 26
 6120 9
2181-1702D5 1380 20
 1390 20
2181-1702D56 2180 17
2181-1702D73 1260 28
2181-1702D9 1370 29
2181-1890D2 1200 21
 1230 27
 4100 468
 4150 52
2181-1890D4 4150 63
 4160 128
2181-1913D24 1190 1H
2181-1923D12 3170 13
 6400 13
 6450 13
 6560 21
2181-1925 1700 2
 3150 6
 6540 6
2181-1950D1 1240 19
 1250 19
 1250 92
 1340 134
 4120 466
 4130 110
 4220 5
2181-1950D2 1350 13
 4100 467
2181-1950D3 1240 21
2181-1950D5 4100 466
2181-1950D7 1190 1G
 1230 24
 6140 41-6
 6140 42-6
 6410 41-6
 6410 42-6
 6460 41-6
 6460 42-6
2181-1950D9 1240 20
 1250 91
 1280 21
 6130 13
 6260 13
2181-1951D1 1350 12
9
Fig No. Key No.Part No.
2181-1951D1 6120 11
2181-1951D16 1350 32
 1360 32
2181-1951D19 1340 34
2181-1951D5 1260 29
2181-1951D6 1330 31
 1370 31
2181-2104D6 1220 9
2181-2170 6100 3
2181-2218D6 1280 20
2181-2281D10 2180 11
2181-2281D21 1370 33
2181-2293D4 6100 44
 6100 9
 6110 4
2181-2294D2 1240 27
2181-2337D13 4170 61
2181-2434 4170 88
2181-2527 1700 6
2181-2627D1 1320 23
2181-2627D3 1320 24
2181-2627D5 1240 25
2181-2635 1350 16
2181-2755B 1220 1A
2181-2774 1800 1
2181-2815D1 6110 3
2181-2816D2 6460 41-3
 6460 42-3
2181-2817D2 6140 41-4
 6140 42-4
 6410 41-4
 6410 42-4
 6460 41-4
 6460 42-4
2181-2820D1 6180 4
 6420 4
 6470 4
2181-4112 3150 13
 3170 20
 6400 20
 6450 20
 6540 9
 6560 22
2181-4125 2180 15
2181-4133D5 1240 23
2181-4133D6 6100 7
 6140 41-3
 6140 42-3
 6410 41-3
 6410 42-3
Fig No. Key No.Part No.
2181-9078 1280 17
 1300 17
 1310 17
 1320 17
 2180 5
 3140 23
 6100 4
 6130 10
 6140 3
 6250 23
 6260 10
 6410 3
 6460 3
 6530 28
 6550 12
2181-9079 1290 18
 1310 18
 3140 25
 3160 3
 6250 25
 6390 3
 6440 3
 6530 30
 6550 13
2181-9081 1280 16
 2180 6
2181-9083 1300 19
 1310 19
2184-1036D199 6560 11
2184-1036D293 1260 38
2184-1036D43 1190 1K
2184-1045D126 3150 4
2184-1045D177 6120 19
2184-1045D254 3150 5
 6540 5
2184-1046D120 1330 63
2184-1046D169 6120 23
2184-1046D187 1340 132
2184-1046D50 1190 2
2184-1046D68 6120 25
2184-1046D94 1330 62
2184-1060D70 1340 43
2184-1100D90 6410 2
2185-1308D5 1790 7
 1790 8
2185-1660 1500 106
2185-1737D8 1240 16
2185-1776D2 1250 15
2190-2556D179 5140 1
2195-1534 1740 22
Fig No. Key No.Part No.
2195-3500 1780 17
2197-1660 1770 10
 1780 20
2197-1661 1330 1I
 1780 21
 1840 5
2197-1777A 1270 1
2197-1793 1750 11
2197-1798C 1820 5
2197-1802A 1270 19
2199-1004 5100 1-10
2199-1005 5100 1-11
2199-1063F34C 5100 1
2199-9007 5100 3
2199-9008 5100 2
2199-9009 5100 1-15
2199-9043 5100 1-1
2199-9058 1520 92
220101-00192K 1500 -
 1510 -
 1520 -
 1530 -
220106-00040 1460 11
220106-00041 1460 18
220108-00012 1460 16
220110-00086A 1450 -
220110-00087A 1450 1
 1460 -
220111-00022 1410 -
220111-00023 1420 -
220204-00099 1410 3
220204-00100 1420 4
220205-00024B 1510 49
220213-00023 1460 23
220214-00023B 1500 6
2204-6039A 1820 2
2208-6013B 1820 9
229-00025C 1180 2
230104-01198 6510 -
230104-01199 6510 1
230104-01245 6270 -
230104-01246 6270 1
230104-01249 6280 -
230104-01250 6280 1
230104-01251 6290 -
230104-01252 6290 1
230104-01253 6300 -
230104-01254 6300 1
230104-01255 6310 -
230104-01256 6310 1
10
Fig No. Key No.Part No.
230104-01257 6320 -
230104-01258 6320 1
230104-01259 6330 -
230104-01261 6330 1A
230104-01262 6340 -
230104-01264 6340 1A
230104-01266 6350 -
230104-01268 6350 1A
230104-01269 3130 -
230104-01271 3130 1A
230104-01272 6360 -
230104-01274 6360 1A
230104-01275 6370 -
230104-01277 6370 1A
230201-00104 3120 -
230201-00105 6380 -
230201-00107 6430 -
230201-00137 6490 -
230201-00645 6240 -
230204-00083G 3120 1
230204-00084C 6380 1
230204-00086C 6430 1
230204-00168B 6490 1
230204-00283 6240 1
230207-00127 6480 -
230207-00231 6230 -
230207-00238 3110 -
230211-00144A 6480 1
230211-00162A 6230 1
230211-00168 3110 1
2401-1276KT 1220 1G
240103-00325 1150 12
240103-00326 1150 12-1
2412-1040 4140 3
2415-1018 1740 35
2420-1258 1220 12A
2423-1470 1400 4
2426-1175 1230 6
2426-1237 1330 1D
2460-9057A 1340 2
2471-1133 6120 7
2471-1135 1400 11
2471-1152 1220 12B
2471-1154 1330 1C
 5110 2
2471-1155A 1330 1E
2472-7003 1330 1B
2474-7009 1180 3B
2474-7009K 1180 3H
2474-9016A 1230 10
Fig No. Key No.Part No.
250106-00125A 1560 -
250106-00126A 1560 12
250201-00028 1630 3-4
 1640 2-3
250201-00795A 1710 1
250201-01934 4130 213
2512-1095D1 5110 10
2515-1016D4 1740 25A
 1770 1A
 1830 1A
 1840 7A
 5110 17
2515-1021D1 1520 75A
2516-1116 1720 32
2523-9016 1270 13
2527-1016 1720 5A
 1720 6A
 5110 19
2527-1017 1720 5B
 1720 6B
 5110 20
2527-1018 1720 5C
 1720 6C
 5110 21
2527-1023A 1740 14
 5110 23
2527-1025 1720 5D
 1720 6D
 5110 22
2527-9004 1740 12
2528-9040 1720 18
2541-9020 1520 81
2543-9015 1710 3
2544-9024 1740 8
2544-9033 1710 11
 1860 7
2547-1015 1750 10
2547-9038B 1750 8
2548-1027 1780 1A
2549-9112 1350 6
2550-1014D1 1780 2
2550-1014D2 1780 3
2553-1275D113 1780 34
2553-1275D138 1780 33
2553-1275D39 1780 10
2553-1275D6 1780 32
2553-1275D81 1780 16
2705-1020 3130 1C
 6270 3
 6280 3
Fig No. Key No.Part No.
2705-1020 6290 3
 6300 3
 6310 3
 6320 3
 6330 1C
 6340 1C
 6350 1C
 6360 1C
 6370 1C
2705-1022 6510 3
2705-1030 4140 19
2705-9002 1630 3-26
 1640 2-9
 1670 36
2713-1059A 3130 2
 6270 5
 6280 5
 6290 5
 6300 5
 6310 5
 6320 5
 6330 2
 6340 2
 6350 2
 6360 2
 6370 2
2713-1060A 3130 3
 6270 6
 6280 6
 6290 6
 6300 6
 6310 6
 6320 6
 6330 3
 6340 3
 6350 3
 6360 3
 6370 3
2713-1218A 3130 1AA
 6270 1A
 6280 1A
 6290 1A
 6300 1A
 6310 1A
 6320 1A
 6330 1AA
 6340 1AA
 6350 1AA
 6360 1AA
 6370 1AA
11
Fig No. Key No.Part No.
2713-1222B 6510 1A
2713-1228A 6510 6
2713-1229A 6510 5
284-00005 4100 30
2891-1311 1530 32-26
300101-00199 1740 1
300426-00012A 1720 1
300512-00010 1500 73
300513-00006 1270 12
300516-00041 019 1
300609-00069 4150 C
300611-00042B 1720 101
300611-00138 1720 54
300611-00271 1710 4
300612-00001A 1710 5
300619-00056E 1720 -
300619-00514B 1710 -
300619-00793A 1730 -
300619-01069 1860 -
300619-01604 1740 -
300619-01605 1750 -
300619-01634 1780 -
300637-00009 1720 91
300661-00004 1730 3
300705-00013C 1850 -
300705-00037 1850 5
300710-00023 1850 5A
300715-00036 6150 1C
300726-00002 1740 26
300726-00003 1740 27
300730-00006 1720 16
300803-00086 1750 14A
 5110 24
300901-00033 6190 1
300901-00034 1760 21
300901-00042 6190 -
301005-00132 1770 1
301202-00042 1710 12
301202-00067 1750 1
301316-00016 1200 18
310101-00035 1750 17
310203-00020 1780 31
310207-00417B 1720 25
310207-00425A 1710 15
310207-00539 1770 6
310207-00708 1720 28
310207-01044A 1750 14
310207-01176A 1780 1
310207-01182 1730 9
352-00014 4130 305
Fig No. Key No.Part No.
352-00014 4150 216
400206-00455 1140 2
400305-00219 3140 81
 4250 -
 6250 81
 6530 61
400309-00341A 3140 71
 4230 -
 6250 71
 6530 51
400309-00343A 3140 72
 4240 -
 6250 72
 6530 52
400310-00214 3160 1
 4260 -
400310-00215 4270 -
 6390 1
400310-00216 4280 -
 6440 1
400315-00026 1650 4-7
400337-00452 4250 3
400337-00453 4260 3
 4270 3
 4280 3
400337-00454 4230 3
 4240 3
400337-00478 2130 4
400337-00479 2130 11
400406-00308 6110 -
400411-00001A 1230 21
400414-00198 1170 -
400414-00226 1170 1
400504-00045 1200 5A
400504-00091 1170 1B
 5110 3
400504-00092 1170 1A
 5110 4
400504-00131 1230 5
 5110 1
400701-00004 4150 200
400826-00011A 2160 8
400908-00004 016 301AA
400909-00073 1220 -
400911-00005 1180 -
400912-00071 016 301
400914-00212 1180 1
 4100-
401-00449 1220 1
401-00477J 1190 -
Fig No. Key No.Part No.
401002-00739 4160 137
401003-00260 6110 1D
401003-00516 2140 6-9
401003-00517 2140 6-10
401103-00120 2170 1I
 6200 1-1I
 6210 1-1I
 6220 1-1I
401106-00179 4100 774
401106-00181 4130 302
401107-00632 2120 5-2E
401107-00751 2100 2A
401107-01330 2160 *
401111-00035 2140 6-6
401111-00036 2150 7-9
402-00026A 4100 271
405-00008 4100 113
407-00001 1220 1F
408-00013 4100 156
409-00003 4100 532
409-00049 4190 95
409-00050 4190 97
410102-00024 4130 400
410113-00021A 1390 2
 4200 -
410113-00022A 1380 1
 4200 -
410116-00410 4130 105
410126-00019 6150 1B
410127-00078 6100 1A
410127-00095 4130 107
410127-00190 4150 400
410135-00109 6150 1A
410137-00030B 6460 41
410137-00031B 6460 42
410137-00032B 6140 41
 6410 41
410137-00033B 6140 42
 6410 42
410137-00067A 6140 41-1
 6410 41-1
 6460 41-1
410137-00069A 6140 42-1
 6410 42-1
 6460 42-1
410202-00025 1140 30
410207-00175 4200 33
410207-00176 4200 34
410207-00307 4150 23
412-00006 4100 211
12
Fig No. Key No.Part No.
412-00011 4130 202
412-00013 4130 306
 4150 215
4132-1138 1530 32-28B
415-00037 4180 63
415-00043B 1480 6
415-00044B 1470 19
415-00045B 1470 17
415-00046B 1470 16
416-00004 4100 534
416-00005 4100 535
416-00019B 1510 29
4185-1777 1740 34
420-00112 4210 3
420-00127 4100 79
420-00246 4190 67
420-00258 4170 69
420-00259 4180 70
420-00295KT 4170 *
420-00309 4190 94A
420-00314 4190 24A
420-00352D1 1350 177-4
 6120 29-4
420-00467A 1400 3
 4210 -
420-00476 6120 29-8
420101-00296 1160 2
420101-00600 1170 5
420102-00239 1820 22
420202-00015 1250 1
420202-00141 1160 1
420202-00142 1160 4
420205-00241A 3170 14
420205-00283 6400 21
420205-00284 6450 21
420205-00393 3170 16
420207-00514A 6140 1
420207-01840 6130 3
420207-01841 6130 4
420207-01842 6130 14
 6260 14
420207-02037 3170 18
420207-02224 6250 4
420207-02225 6250 5
420207-02226 6250 6
420207-02227 6250 8
420207-02229 6260 1
420207-02230 6260 2
420212-01717 6410 -
420212-01719 6460 -
Fig No. Key No.Part No.
420212-02750 3150 -
420212-05311 6400 -
420212-05312 6450 -
420212-05313 6560 -
420212-05429 6390 -
420212-05430 6440 -
420212-06762 6130 -
420212-06958 1280 -
 1290 -
 1300 -
 1310 -
 1320 -
420212-06960 6100 -
420212-06961 1330 -
 1340 -
 1350 -
 1360 -
 1370 -
420212-06962 6120 -
420212-06964 1240 -
 1250 -
 1260 -
420212-06965 1380 -
 1390 -
 1400 -
420212-06969 6150 -
420212-06987 1700 -
420212-06994 2180 -
420212-07897 6250 -
420212-07903 6260 -
420212-08004 3160 -
420212-08011 6140 -
420212-08035 6180 -
420212-08037 3170 -
420212-08378 6550 -
420218-00104A 1240 9
420406-01072 4250 1
420406-01074 4260 1
420406-01075 4270 1
420406-01076 4280 1
420406-01077 4230 1
 4240 1
422-00055 2100 14
423-00096 4180 1
423-00097 4180 13
423-00193B 6100 2
423-00202 1310 8
424-00042 4210 8
424-00115 4180 6
424-00185 4180 2
Fig No. Key No.Part No.
424-00199 4180 4
426-00168 4170 32
426-00169 4190 34
426-00170 4190 38
426-00171 4190 44
426-00172 4190 49
426-00173 4190 51
426-00182 4190 100
426-00266 6120 2
426-00267B 6100 1
426-00287B 6150 1
429-00004 4210 5
429-00005 4210 7
429-00024 4190 20
430-00033 4180 8
430-00035 4180 12
430-00038 4190 18
430-00040 4190 22
430-00041 4190 24
430-00042 4190 46
430-00045 4190 94
430201-00113 1380 12
 1390 12
430205-00038 1460 4
430215-00552 4150 C-1
430216-00004 1350 177
430216-00006 6120 29
430223-00011A 1350 14
440211-00386A 1130 2
 1140 -
440211-00517 1140 1
440213-00333 1820 -
440301-00038 1140 3
450103-00269 1200 -
450103-00270 1200 1
450105-00361 1230 -
450105-00362 1230 1
452-00020 4130 309
460103-00039 1480 2
471-00030 4120 355
471-00075A 1330 1
471-00105A 1200 4
471-00114 6110 1
471-00119 1500 13
4713-4004B 6520 2
473-00033 1200 2
473-00052 1230 7
474-00044A 1510 49-16
474-00046 6110 1A
507-00006 1500 102
13
Fig No. Key No.Part No.
515-00012A 1720 1A
 5110 15
516-00011 1860 3
520-00004 1820 16
523-00012 1220 1H
530-00067 6120 5
530-00214A 1220 22-2
530-00236 1330 1H
530-00417B 1520 62
530-00430A 1830 2
530-00431 1840 1
530-00432A 6160 2
530-00434B 1720 27
530-00464 1850 4
534-00079 1520 75
534-00085 1830 1
 1840 7
534-00117B 6590 -
541-00015 1500 101
543-00095 1720 14
543-00096 1720 15
543-00107 1820 91
545-00011 1710 8
547-00023 1720 51
547-00024A 1800 9
548-00003A 1780 1B
549-00010 6120 4
549-00086 1510 57
549-00089 1410 5A
549-00090A 1730 6
549-00092 6160 1
549-00093 1220 22-1
549-00095 1250 14
549-00101 1850 20
549-00103 1720 19
 1720 21
 1830 10
 1860 1
553-00001D4 1750 20
554-00005 1500 60
600105-00002 1740 42
621-01507A 1560 13
621-02151 1400 5
621-02643C 1740 32
621-02726A 1640 2-6
621-02739B 1220 3
621-02801 1410 17
 1420 14
 1470 27
621-02837A 1500 61
Fig No. Key No.Part No.
621-02849B 1530 36
621-02864 1500 12
621-02867A 1530 32-21
621-02869C 1530 32-7
621-02870C 6570 -
621-02871B 6570 1
621-02872 6570 2
621-02873 6570 7
621-02894G 1480 1
621-02895C 1430 1-1
621-02900B 1420 3
621-02901B 1410 2
621-02903C 1470 1
621-02904C 1470 3
621-02907B 1480 10
621-02908B 1470 6
621-02909G 1470 4
621-02910C 1520 94
621-02911C 1520 95
621-02912B 1520 96
621-02913C 1480 7
621-02914C 1480 8
621-02915B 1480 9
621-02917C 1480 11
621-02919B 1480 13
621-02920C 1480 19
621-02925A 1430 1-4
621-02926E 1420 2
621-02938B 1100 8
 2100 10
621-02957B 1410 6
 1420 6
621-03005A 1430 4
621-03011E 1430 1
621-03014B 1410 4
 1420 5
621-03103 6570 12
 6580 7
 6590 7
621-03113B 1520 67
621-03114B 1520 68
621-03166 2100 12
621-03167 2100 13
621-03642C 1640 5
621-03657B 1650 11
621-03710A 3100 14
 3110 14
 6230 12
 6480 15
621-03727B 1580 19
Fig No. Key No.Part No.
621-03732C 1580 -
621-03733C 1410 12
 1420 13
621-03734A 1470 28
622-00353K 1530 32
622-00355A 1530 32-3
622-00356 1530 32-3A
623-00074B 1630 3-23
623-00075B 1630 3-24
 1640 2-8
625-00159B 1530 11
65.01101-0030I 001 2
65.01101-6079D 001 1
65.01105-1047A 001 5
65.01105-1048A 001 3
65.01110-6090B 001 27
65.01110-6091B 001 27
65.01110-6092B 001 27
65.01112-0021A 001 23
65.01112-5018 001 24
65.01150-6008 001 28
65.01150-6034A 001 28
65.01150-6035A 001 28
65.01201-0067 001 31
65.01201-0068 001 31
65.01201-0069 001 31
65.01201-0070 001 31
65.01201-0071 001 31
65.01304-0003C 002 1
65.01305-5074A 002 7
65.01307-0002B 002 17
65.01401-0119A 003 1
65.01510-0001 002 29
 021 5
65.01510-0101 003 15
 021 9
65.01601-5010A 001 46
65.01801-0011 005 206
65.01801-5035A 005 223
65.01801-5100 007 1
65.01810-5011 005 220
65.01840-0008A 007 3
65.01901-0020 001 36
 021 2
65.01903-0002C 002 31
 021 6
65.01903B0003 002 33
 021 7
65.01903B0004 002 34
 021 8
14
Fig No. Key No.Part No.
65.01904-0021 003 16
 021 10
65.02101-0045A 004 103
65.02101-6018A 004 101
65.02115-0009 004 104
65.02120-0002 004 108
65.02122-0001 004 503
65.02301-0245A 004 204
65.02301-5099A 004 201
65.02310-0006 004 202
65.02401-0163D 004 306
65.02401-6021 004 301
65.02405-0006 004 307
65.02410-6083B 004 308
65.02410-6124B 004 308
65.02410-6125B 004 308
65.02411-0006A 004 305
65.02501-0416 004 401
65.02501-0417 004 402
65.02501-0418 004 403
65.02501-0440 004 400
65.02501-0443 004 401
65.02501-0444 004 402
65.02501-0445 004 403
65.02502-0082A 004 412
65.02503-8058 004 404
65.02601-5019 004 501
65.03101-1043C 005 102
65.03101-6071B 005 101
65.03201-1013A 005 104
65.03203-1053 005 106
65.03203-1054 005 105
65.03401-6094 005 201
65.03401-6097B 005 200
65.03901-0066A 005 125
 020 1
 021 11
65.03903-0001 005 205
 020 5
 021 15
65.03905-0002B 020 4
 021 14
65.03905-0002C 005 207
65.03905-0023A 005 211
 020 3
 021 13
65.04101-0025A 006 102
65.04101-0032 006 101
65.04102-0005 006 103
65.04103-0001B 006 104
Fig No. Key No.Part No.
65.04103-0002 006 105
65.04104-0001 006 106
65.04200-6019D 006 201
65.04201-5002C 006 202
65.04202-0003C006 211
65.04202-0009 006 210
65.04203-5008C 006 208
65.04205-0001 006 206
65.04301-0009 006 301
65.04302-5006 006 302
65.04401-0018B 006 401
65.04410-0006C 001 10
65.04410-0007C 001 9
65.04501-0004 006 501
65.04505-5012 006 505
65.04506-0011 006 510
65.04902-0011A 020 2
65.04902-0015 006 107
 021 12
65.05101-7025 008 101
65.05102-0018 008 102
65.05103-0051 008 111
65.05104-0177 008 107
65.05104-6065 008 103
65.05105-0044 008 106
65.05201-0065 008 202
65.05202-0001B 008 204
65.05207-0006 008 203
65.05401-5002F 001 52
65.05401-5023 001 47
65.05501-7084A 009 10
65.05503-5053 009 30
65.05510-5028A 009 20
 5110 5
65.05520-5001 009 100
65.05601-7056E 010 10
65.05604-0013B 010 20
65.05606-5024 010 15
65.05701-5200 016 308
65.05701-5342 015 110
65.05701-5343 015 119
65.05701-5530 010 90
65.05701-5531 010 70
65.05701-5541 007 16
65.05701-5636A 008 119
65.05705-6023 008 108
65.05740-5007 011 11
65.05801-5247 011 1
65.05805-5222A 011 20
65.05806-5102A 011 30
Fig No. Key No.Part No.
65.05901C0004 009 110
 021 17
65.05902-0025 010 11
65.05902A0005 010 25
 021 18
65.05903A0001 010 100
 021 19
65.05903A0002 008 121
 021 16
65.05903A0013 001 40
 021 3
65.05904A0002 011 60
 021 20
65.06402-5015 012 4
65.06404-5032 012 1
65.06405-0039 012 5
65.06500-6144A 013 101
65.06501-0214 013 102
65.06504-0033 013 106
65.06506-0085 013 107
65.06512-0016 013 108
65.06520-6007 013 103
65.06601-5070 013 201
65.06611-0132 013 203
65.06901-0035A 013 109
65.06901B0002 013 116
 021 23
65.06904-0003 012 18
 020 6
 021 21
65.06904A0004 012 17
 020 7
 021 22
65.08101-0274 014 101
65.08120-0026 014 220
65.08120-0027 018 15
65.08201-5062 014 201
65.08202-0175 014 202
65.08301-6008 016 305
65.08901-0028 014 107
 020 8
 021 24
65.08902-0034 014 219
 020 9
 021 25
65.09100-7080A 015 101
65.09411-5054 015 201
65.09440-0016 015 204
65.09901-0018A 015 102
 020 15
15
Fig No. Key No.Part No.
65.09901-0018A 021 33
65.09901-0020 015 105
 020 16
 021 34
65.09904-0008 014 204
 020 10
 021 26
65.10101-7099A 016 101
65.10102-6069 016 102
65.10301-6088 016 201
65.10301-6089 016 202
65.11108-6006S 016 301C
65.11401-0002C 016 406
65.11596-0001 016 320
65.11596-0002 016 321
65.11902A0001 016 411
 021 29
65.12301-5022 016 501
65.12301-5824 016 507
65.12301-5825 016 510
65.12501-7023B 017 1
65.12503-5016B 017 4
 5110 6
65.12504-5013A 017 2
65.19102-0013B 018 1
65.19103-6010A 018 5
65.19107-0001A 018 11
65.19202-0005 005 133
65.19202-5005 005 124
65.26212-0006 019 1A
65.26803-7028B 014 203
65.26815-0002 005 132
65.27441-7006 001 53
65.29101-5001 019 3
65.90001-0139 007 4
65.90001-6013 009 130
65.90020-0049 001 25
65.90020-0066A 001 8
65.90020-0142 014 212
65.90021-0002 005 120
65.90021-0003 005 121
65.90021-0004 005 122
65.90201-0037 012 7
65.90201-0058 001 20
65.90201-0081 006 216
65.90201-0096 015 106
65.90201-0099 016 108
65.90201-0103 010 60
65.90201-0168 019 6
65.90201-0182 001 54
Fig No. Key No.Part No.
65.90302-0009 001 11
65.90302-0011 005 112
65.90302-0015 005 107
65.90302-0017 005 113
65.90302-0019B 005 109
65.90302-0027 005 111
65.90302-0030 005 108
65.90302-0041 001 12
65.90302-0042 001 13
65.90302-0045 005 110
65.90310-0030 001 15
65.90310-0036A 009 40
65.90310-0122 001 42
65.90310-0135 001 38
65.90310-0143 017 5
65.90320-0019 001 17
65.90320-0022 001 19
65.90350-0005 009 80
65.90441-0009A 018 10
65.90501-0006 004 109
65.90501-0013 006 207
65.90501-0028 005 209
65.90701-0059 006 503
65.90701-0202 005 210
65.90720-0016 006 511
65.90815-0007 004 413
65.91305-0007 008 114
65.91501-0006 004 110
65.91605-0001E 001 21
65.91615-0011 001 29
65.91701-0029 014 222
65.91701-0086 011 50
65.91701-0197 007 6
65.91701-0199 007 7
65.91701-0233 007 8
65.91710-0001 001 7
65.91710-0004 005 119
65.91710-0012 008 112
65.93020-0015 004 106
65.93020-0055 018 12
65.93410-0027 013 104
65.96301-0045C 012 19
65.96301-0176 016 511
65.96301-0279 015 202
65.96301-0280A 015 122
65.96301-0386 007 20
65.96301-0421 007 9
65.96301-0422A 007 18
65.96341-0100 016 502
 016 515
Fig No. Key No.Part No.
65.96401-0007 003 11
65.96501-0032B 005 224
 020 14
 021 32
65.96507-0007 001 26
 021 31
65.96507-0043 016 504
 016 506
65.96507-0044B 016 104
 020 11
 021 27
65.96507-0050 016 106
 020 12
 021 28
65.96601-0058 008 118
65.96601-0067 015 120
 020 17
 021 35
65.97401-0089 016 512
65.97460-0002 007 11
 016 513
65.97480-0135 015 117
65.97480-0223 019 4
65.97601-0045 009 70
65.97601-0048 006 212
65.97601-0090 008 115
65.98112-0009A 006 403
65.98125-5022A 011 3
65.98130-0200A 015 109
65.98131-0050 016 306
65.98131-0119 007 22
65.98150-0015B 016 508
65.98155-0011 015 114
 016 309
65.99601-8027 021 -
65.99605-8020 020 -
650102-00122 3100 -
650103-00002A 1480 -
650105-00104 2100 -
 2110 -
 2120 -
 2140 -
 2150 -
 2160 -
713-00024A 3130 1B
 6330 1B
 6340 1B
 6350 1B
 6360 1B
 6370 1B
16
Fig No. Key No.Part No.
713-00057C 6510 2
719212KT 4120 *
850315-00029 5100 1-84
850334-00008 5100 1-85
900122-00079 4160 105
900131-00014A 1510 49-6
903-00069A 1530 32-2
903-00070B 1530 32-4
903-00071B 1530 32-5
903-00072A 1500 2
903-00073A 1500 3
903-00074A 1510 50
903-00075 1500 4
906-00002A 1470 5
920-00127A 1790 1
 1810 -
950106-00967 5110 41
950106-00968PT 5110 42
950205-00662 5130 2
950205-00663 5130 31
950205-00668 5130 -
950205-00862A 5120 14
950205-01448 5130 7
950205-01450B 5130 12
950205-01451 5120 10
950205-01453 5130 13
950205-01454A 5130 14
950205-01455B 5130 3
950205-01456A 5120 3
950205-01460B 5120 9
950205-01461A 5120 2
950205-01462A 5120 4
950205-01463A 5130 10
950205-01464A 5130 4
950205-01466C 5120 1
950205-01467B 5130 11
950205-01468A 5130 27
950205-01680 5120 15
950205-01763 5130 33
950209-00487 5190 1
950209-00501 5190 -
950209-01718 5120 -
950209-02977 5180 1
950209-02978 5180 -
950209-03552 5170 -
950209-03553 5170 1
A213589 1170 1D
D913109 1710 2
DS0001079 1740 4
DS0001083 3120 24
Fig No. Key No.Part No.
DS0001083 6240 22
 6380 24
 6430 24
DS0001084 3120 23
 6240 21
 6380 23
 6430 23
DS0025013 1740 33
DS0025014 1160 6
 1650 25
DS0025015 1100 32
 1110 3
 1120 38
 1170 3
 1610 18
 1620 18
 1630 26
 1640 26
 1650 26
 1660 26
 1670 26
 1740 41
 6500 3
DS0025016 1130 35
 2100 22
DS0025017 1340 38
 1350 38
 1610 25
DS0025018 1250 36
 6110 8
DS0025019 1220 15
 1270 22
 1670 48
 1740 31
 1770 3
 2100 23
 6100 43
 6150 12
DS0025020 1290 29
 6100 14
DS0025021 1150 52
 1220 6
 6110 7
DS0025022 1610 22
 1660 51
DS0025023 1100 9
 1160 9
DS0025024 1230 20
DS0025025 1650 42
DS0025033 1750 31
Fig No. Key No.Part No.
DS0025039 1740 9
DS0025049 1750 25
DS0026006 1750 15
DS0401188 1690 13
DS1001061 1650 4-11
DS1001088 1670 57
DS1003008 6570 11
DS1003009 1580 19
DS2012070 1240 42
DS2012217 6110 5
DS2012300 6100 15
DS2013220 6110 6
DS2013515 6150 14
DS2013834 6100 41
DS2016055 6100 17
DS2018100 1280 43
DS2020128 1240 37
DS2026127 1320 49
DS2026129 1320 47
DS2026145 1320 48
DS2026146 1320 46
DS2026201 6100 16
DS2038144 1290 42
DS2038190 3140 11
 6250 11
DS2038222 1290 41
DS2038226 6530 14
DS20401141 6390 11
DS20401232 6140 2
DS2040489 6460 2
DS2040543 6550 4
DS2040544 6550 5
DS2040610 3140 10
 6250 10
DS2040637 6530 13
DS2040683 1300 50
DS2040684 1300 51
DS2040685 1300 52
DS2040686 1300 53
DS2045337 1310 39
DS2045338 1310 40
DS2053833 1400 31
DS2053849 6170 1
DS2053864 3150 3
 6540 3
DS2053868 6150 18
DS2053869 6150 19
DS2053884 6540 4
DS2053953 6170 2
DS2054133 1330 65
17
Fig No. Key No.Part No.
DS2054217 2180 4
DS2054293 6150 15
DS2054356 1400 29
DS2054394 6150 16
DS20551024 1260 39
DS2055788 6120 24
DS2055849 3170 1
 6450 1
DS2055866 6180 3
DS2055867 6420 3
DS2055920 6400 1
DS2055921 6470 3
DS2055976 1260 40
DS2058331 1240 41
DS2059595 3170 2
DS2059598 6450 2
DS2059600 6400 2
DS20596076560 10
DS2079171 1220 11
DS2092177 2180 3
DS2093003 1330 64
DS2093017 1340 61
DS2093021 6120 21
DS2093022 1360 52
DS2093026 1360 54
DS2093030 1370 70
DS2093034 1340 71
DS2093040 6120 20
DS2093044 6120 22
DS2093080 1340 59
DS2093090 1350 55
DS2093130 1370 68
DS2093134 1350 47
DS2093139 1360 50
DS2093155 1350 44
DS2093173 1360 53
DS2093174 1350 48
DS2093175 1350 49
DS2093178 1350 46
 1360 46
DS2093184 1350 45
DS2093185 1370 67
DS2093189 1400 36
DS2093190 1400 38
DS2093191 1400 37
DS2093192 1400 39
DS2093193 1340 56
DS2093212 1340 60
DS2093222 1360 51
DS2093300 6150 17
Fig No. Key No.Part No.
DS2093391 6120 18
DS2094004 1370 57
DS2094006 1380 30
 1400 30
DS2094037 1370 69
DS2094053 1330 58
DS2094055 1370 66
DS2095001 1380 33
 1390 33
DS2095002 1390 34
DS2095003 1380 32
 1390 32
DS2095004 1380 35
DS2097013 1280 44
DS2097014 1280 45
DS2105011 1210 15
DS2105018 1210 7
DS2105022 1210 5
DS2105026 1210 6
DS2105053 1200 22
DS2105146 1220 8
DS2112002 2180 1
DS2130012 6440 11
DS2130014 3160 11
DS2213165 1380 13
 1390 13
DS2213167 1260 24
DS2214051 1190 3
DS2225009 3170 3
 6400 3
 6450 3
 6560 17
DS2232107 6100 8
DS2242017 6120 6
DS2242029 1280 22
DS2338029 6150 9
DS2404024 6150 7
DS2410009 1350 177-5
 6120 29-5
DS2802021 1200 7
DS2802023 3170 6
 6400 6
 6450 6
 6560 23
DS2805007 3170 11
 6400 11
 6450 11
 6560 19
DS2805008 3170 19
 6400 19
Fig No. Key No.Part No.
DS2805008 6450 19
 6560 15
DS2805009 6170 11
DS2854017 6490 29
DS5502006 6230 1B
DS7601027 1100 36
DS7601028 1100 37
DS7601046 1100 41
DS7752001 6490 22
DS7752002 6490 23
DS7752006 3120 17
 6240 15
 6380 17
 6430 17
DS7752007 3120 18
 6240 16
 6380 18
 6430 18
DS7752012 3100 13
 3110 13
 3120 15
 6230 11
 6240 13
 6380 15
 6430 15
 6480 13
 6490 12
DS7752013 3100 23
 3110 23
 3120 16
 6230 16
 6240 14
 6380 16
 6430 16
 6480 23
 6490 13
DS7752017 3110 27
 6230 20
 6480 27
DS7752018 3100 12
 3110 12
 6230 10
 6480 12
DS7752025 3110 26
 6230 19
 6480 26
DS7752026 3110 24
 6230 17
 6480 24
DS7752027 3110 25
18
Fig No. Key No.Part No.
DS7752027 6230 18
 6480 25
DS7752028 3100 24
DS7752093 3100 22
 3110 28
 6230 21
 6480 33
ECOEN 1120 101
K1000057 6450 9
K1000266 1190 1I
K1000269A 1230 9
K1000351A 6150 3
K1000354 1350 177-1
 6120 29-1
K1000356 6170 12
K1000358B 6100 42
K1000485A 1680 2
K1000488A 1680 4
K1000489A 1680 5
K1000490A 1680 6
K1000491 1680 7
K1000492A 1680 8
K1000500 1680 10
K1000504 1680 12
K1000562 1170 8
K1000563B 1130 15
K1000591A 1690 1
K1000592A 1690 2
K1000600B 1690 10
K1000602 1630 3-20
 1640 2-20
K1000644B 1250 8
K1000663 1160 7
K1000704A 1160 8
K1000733 6380 1B
 6430 1B
K1000734 6380 1C
 6430 1C
K1000789 1740 21
K1000794 1520 56
K1000814 1780 1C
K1000815 1780 1D
K1000840 1410 13
K1000842A 1410 14
K1000852A 1680 13
K1000911 3120 27
 6240 25
 6380 27
 6430 27
K1001023 1410 11
Fig No. Key No.Part No.
K1001023 1420 12
K1001029 1120 34
 1130 34
 1150 34
 1190 9
 1200 12
 1210 13
 1220 4
 1270 20
 1330 42
 1340 42
 1360 42
 1400 25
 1680 14
 1710 18
 1720 40
 1770 9
 1780 30
 1800 8
 1820 26
 1840 8
 3150 16
 3170 5
 6120 15
 6170 10
 6400 5
 6450 5
 6540 12
 6560 16
K1001052 6180 1
K1001053 6180 2
K1001068 1470 20
K1001260A 1630 3-8
 1640 2-7
K1001263A 1720 5
 1720 6
K1001277C 1820 20
K1001278C 1820 92
K1001280C 1820 93
K1001295B 1480 12
K1001310 1480 20
K1001331E 1790 -
K1001858A 1730 1
K1002082 1590 -
K1002083 1600 -
K1002206 1810 1
K1002207 1810 2
K1002208 1810 3
K1002209 1810 4
K1002210 1810 5
Fig No. Key No.Part No.
K1002211 1810 6
K1002212 1810 7
K1002213 1810 8
K1002214 1810 9
K1002215 1810 10
K1002216 1810 11
K1002217 1810 12
K1002218 1810 13
K1002219 1810 14
K1002229A 1440 -
K1002230A 1440 1
K1002231A 1440 2
K1002341 1250 12
K1002385 1480 33
K1002406D11 1720 20
K1002406D12 1720 22
K1002406D13 1830 11
K1002406D14 1860 2
K1002406D21 1720 24
K1002406D3 1850 21
K1002454B 6500 2
K1002534A 1730 8
K1002561B 6580 -
K1002574A 6580 3
 6590 4
K1002575A 6580 4
 6590 5
K1002635 1500 104
K1002636 1500 105
K1002637 1530 32-13
K1002641 1520 100
K1002838 6600 4
K1002839A 6600 5
K1002840 6600 6
K1002841 6600 7
K1002842A 6600 3
K1002846 6600 2
K1002943 1660 38
K1003113D4 1720 58
K1003118 1270 72
K1003284 1510 88
K1003296 1230 28
K1003427 1500 89
K1003522 1500 109
K1003618 1170 18
K1003664D1 1360 15
K1003676B 1520 107
K1003900 1530 32-16
K1003945 1380 10
 1390 10
19
Fig No. Key No.Part No.
K1004006 6170 7
K1004011 6180 7
 6420 7
 6470 7
K1004057 6140 6
 6410 13
 6460 6
K1004061 1500 108
K1004106 4290 2
 4290 4
K1004272 1570 3
K1004426 1730 10
K1004427 1730 7
K1004487 1120 21
K1004515 1130 22
K1004630 1630 44
 1640 44
 1650 44
 1670 44
K1005007A 1470 30
K1005305A 1650 4-10
K1005344A 1480 17
K1005345A 1480 18
K1005776 6160 3
K1005822 6600 21
K1005823 6600 20
K1006245 1150 9
K1006368 1510 49-20
K1006370 1530 32-38
K1006396B 1280 9
K1006572 1720 23
K1006780 1130 8
K1006781 1130 7
K1006933 1520 114
K1006936 1520 98
K1006995 1420 15
K1007044 1680 16
K1007164B 1280 10
K1007197 1250 13
K1007231A 6600 24
K1007253B 3110 4
 6230 2
 6480 4
K1007371 1760 -
K1007403B 1830 -
K1007405 1840 -
K1007413 6160 -
K1007551 1120 24
K1007631B 1210 -
K1007665B 1700 1
Fig No. Key No.Part No.
K1007668 1740 18
K1007669 5100 4
K1007832 5100 -
K1007835 1270 71
K1007957 1230 31
K1008019D21 5150 1
K1008019D22 5150 2
K1008100 6460 1
K1008111 6470 1
K1008112 6470 2
K1008167 5100 1-16
K1008335 1630 3-25
 1640 2-21
K1009605B 1730 1A
K1009627 1470 34
K1010025A 6240 4
K1010218 6450 14
K1010304 1470 37
K1010466 1410 20
 1420 16
K1010584 1750 26
K1010730 3170 9
 6400 9
 6560 20
K1010821B 6520 -
K1010822B 6520 1
K1010839 1520 116
K1010847 6170 9
K1011000 5130 20
K1011002 5130 22
K1011080 1220 13
K1011081 1220 14
K1011211 6530 18
K1011384 1820 20B
K1011385 1820 92B
K1011388 1820 22A
 1820 93A
K1011434A 4290 -
 6550 1
K1011522 6560 1
K1011527 6560 5
K1011675A 1230 2
K1011743D6 5120 13
K1012143 1160 10
K1012685A 1230 14
K1013101A 6330 1
K1013104A 6340 1
K1013108A 6350 1
K1013111A 3130 1
K1013114A 6360 1
Fig No. Key No.Part No.
K1013118A 6370 1
K1013251 1210 1
K1013266B 1650 15
K1013389 6470 -
K1013434A 6420 -
K1013684 6450 15
K1013685 6450 16
K1013686 6450 18
K1013713A 2150 7-5
K1013812 1670 53
K1013825 1180 3
K1014698 1110 2
K1016430 1150 11
K1016432 1150 10
K1017764 6480 28
K1018109 6530 10
K1018595 1740 7
K1018659 6530 5
K1018660 6530 6
K1018706 6530 7
K1018709 6530 11
K1018710 6530 12
K1018712 6550 2
K1018713 6550 3
K1018714 6560 2
K1018715 6560 3
K1018762 6560 4
K1018763 6560 6
K1018764 6560 7
K1018765 6560 8
K1018766 6560 9
K1024144 1220 22
K1024692 1690 3
K1025246 6410 1
K1025391 1280 1
 4170 -
 4180 -
 4190 -
K1025462 6420 1
K1025463 6420 2
K1025464 6400 14
K1025465 6400 15
K1025466 6400 16
K1025467 6400 18
K1027765 1530 32-15
K1029257 1230 14B
 5110 25
K1030506B 1610 7
K1030731 1620 14
K1030732A 1620 15
20
Fig No. Key No.Part No.
K1030734A 1620 17
K1030735A 1620 16
K1030750A 1610 4
K1033265 3140 6
K1033266 3140 8
K1033267 3140 7
 6250 7
K1033268 3140 9
 6250 9
K1033269 6130 1
K1033270 6130 2
K1033273 3140 4
K1033274 3140 5
K1033880 1510 49-8
K1033991 1510 49-1
K1036143A 1250 6
K1036299A 1250 7
K1036302B 1250 5
K1036303B 1250 3
K1036331 1510 49-7
K1036967 1510 49-17
K1037887 3150 18-1
 6540 13-1
K1038003 3150 18
 6540 13
K1038006A 6270 2
 6280 2
 6290 2
 6300 2
 6310 2
 6320 2
K1038009 1680 17
K1038010 1680 18
K1038011 1680 19
K1038032 1340 30
K1038107A 1650 18
K1038110A 1650 17
K1038205 4140 10
K1038206 4140 1
K1038207 4140 2
K1038208 4140 14
K1038240 1540 -
K1038247 1540 1
K1038374 2170 1J
 6200 1-1J
 6210 1-1J
 6220 1-1J
K1038409 1130 13
K1038685 4140 5
K1038791 2160 8-1
Fig No. Key No.PartNo.
K1038792 2160 8-2
K1038793 2160 8-3
K1038794 2160 8-4
K1038814 3150 1
 6540 1
K1038815 3150 2
 6540 2
K1038870B 1670 6
K1038920 1630 3-7
K1038954B 1610 1
K1038966 1620 23
K1039014A 1340 3
K1039068 1740 5
K1039134 1690 4
K1039137 1690 6
K1039208A 1660 8
K1039209A 1660 9
K1039212C 1470 22
K1039430C 1670 12
K1039514 1560 20
K1039515 1560 19
K1039519 1100 91
K1039520 1100 92
K1039697 5130 30
K1039869B 1630 3-22
K1040048 1130 54
K1040096 1430 3
K1040606 1570 11
 1650 81
K1041250 1690 7
K1041251 1690 8
K1041252 1690 9
K1041795 3140 -
K1041837 6170 -
K1042074A 5130 19
K1043726 1480 38
K1044617 1250 10
K1044917 1770 -
K1045837 6530 -
K1045838 6540 -
K1045852 6530 1
K1045853 6530 2
K1045854 6530 3
K1045855 6530 4
K1045856 6530 8
K1045857 6530 9
K1045898 1800 -
K1045900 1150 16
K1045902A 1680 9
K1045908 1620 13
Fig No. Key No.Part No.
K1045909 1630 47
K1045910 1160 5
K1045929 1690 5
K1045932 1690 -
K1045987A 1680 -
K1046072 1160 -
K1046113A 1270 -
K1047302 3170 15
K1047304 3170 17
K1047556 6120 1
K1047557 1340 131
 4220 -
K1047774 1130 55
K1048085 1630 3-21
K1048145 1280 15
K1048689 1470 21
K1049011 1620 11
K1049168 5150 -
K1049177 5140 -
K1049182 5160 -
K1049184 5160 1
K1049826 1620 5
K1049858 1100 29
K1052181 1430 -
K1052729 013 115
K1052808 1660 58
K1053423 1720 17
K1055454 1740 25
K1056987 1510 49-19
K1057605 1740 40
K9000422 1180 3E
K9001001 4200 32
K9001114 4200 1
K9001115 4200 3
K9001116 4200 4
K9001117 4200 6
K9001119 4200 9
K9001121 4200 11
K9001123 4200 13
K9001128 4200 20
K9001129A 4200 22
K9001130 4200 25
K9001131 4200 25
K9001132 4200 28
K9001133 4200 30
K9001139 4200 37
K9001140 4200 37
K9001141 4210 6
K9001148 4250 18
K9001149 4250 20
21
Fig No. Key No.Part No.
K9001158 4250 40
 4290 37
K9001199 4180 50
K9001362 6120 2A
K9001374 4290 22
K9001375 4290 23
K9001401 4260 7
 4270 7
 4280 7
K9001402 4260 8
 4270 8
 4280 8
K9001403 4260 9
 4270 9
 4280 9
K9001404 4260 10
 4270 10
 4280 10
K9001406 4260 16
 4270 16
 4280 16
K9001410 4260 22
 4270 22
 4280 22
K9001413 4260 34
 4270 34
 4280 34
K9001424 4290 8
K9001425 4290 9
K9001426 4290 10
K9001427 4290 14
K9001428 4290 16
K9001429 4290 17
K9001430 4290 18
K9001431 4290 20
K9001752 4290 *
K9001753 4290 1
K9001754A 4290 3
K9001755 4290 26
K9001756 4290 29
K9001757 4290 33
K9001762 4200 7
K9001763 4200 8
K9001766 4200 12
K9001767 4200 14
K9001768 4200 16
K9001804 4170 68
K9001805 4170 106
K9001807 4180 5
K9001809 4180 16
Fig No. Key No.Part No.
K9001810 4180 17
K9001811 4120 -
K9001833 4110 -
K9001834 4110 627
K9001835 4110 628
K9001836 4110 629
K9001837 4110 631
K9001838 4110 641
K9001839 4110 898
K9001840 4130 103
K9001841 4130 104
K9001842 4130 112
K9001843 4130 201
K9001845 4130 203
K9001849 4100 41
K9001850 4100 42
K9001852 4100 985
K9001856 4230 5
 4240 5
K9001857 4230 8
 4240 8
K9001858 4230 9
 4240 9
K9001859 4230 14
 4240 14
K9001860 4230 17
 4240 17
K9001861 4230 20
 4240 20
K9001862 4230 23
 4240 23
 4260 23
 4270 23
 4280 23
K9001870 4260 5
 4270 5
 4280 5
K9001871 4260 17
 4270 17
 4280 17
K9001872 4260 20
 4270 20
 4280 20
K9001873 4260 26
 4270 26
 4280 26
K9001874 4260 27
 4270 27
 4280 27
K9001875 4260 30
Fig No. Key No.Part No.
K9001876 4260 37
K9001877 4230 10
 4240 10
K9001878 4230 *
 4240 *
K9001881 4250 5
K9001882 4250 8
K9001883 4250 9
K9001884 4250 10
K9001890 4230 18
 4240 18
K9001891 4260 18
 4270 18
 4280 18
K9001892 4260 *
 4270 *
 4280 *
K9001893 4250 16
K9001894 4250 17
K9001895 4250 22
K9001896 4250 23
K9001897 4250 25
K9001898 4250 32
K9001900 4250 36
K9001901 4250 *
K9001902A 4100 *
K9002044 1210 1A
K9002065 4220 4
K9003467 4270 30
K9003468 4270 37
K9003470 4280 30
K9003471 4280 37
K9003671 4180 3
K9003672 4180 14
K9003673 4180 15
K9004000 4200 35
K9004001 4200 36
K9004304 4160 132
K9004447 4150 207
K9004448 4150 208
K9004449 4150 214
K9004453 4150 212
K9005662 1230 14A
K9006860 4210 10
K9006861 4210 28
K9006862 4210 32
K9006863 4210 51
K9006864 4210 52
K9006865 4210 24
K9006866 4210 26
22
Fig No. Key No.Part No.
K9006883 2160 8-12
K9006884 2160 8-11
K9007358A 4230 26
 4240 26
K9007359A 4240 30
K9007360A 4230 30
K9007363 4220 2
K9007367A 4240 34
K9007368A 4230 34
K9007382 4150 203
K9007383A 4160 101
K9007386A 4160 129
K9007387 4160 117
K9007388 4160 107
K9007389 4160 131
K9007390 4160 121
K9007391 4160 114
K9007392 4160 113
K9007393 4160 108
K9007394 4160 109
K9007395A 4160 136
K9007396 4160 112
K9007397 4150 204
K9007398A 4150 209
K9007400 4150 249
K9007401 4150 232
K9007402 4160 111
K9007403 4160 125
K9007406A 4150 205
K9007409A 4150 C-2
K9007411 4160 116
K9007412 4160 104
K9007415A 4150 202
K9008310 4150 *
K9008334A 4130 301
K9008335 4130 303
K9008336A 4130 *
K9008338 4140 52
S0121061 4140 16
S0504366 1700 4
S0504453 1630 3-15
 1740 23
 1780 18
S0504553 1630 3-14
 1640 2-15
S0504566 1270 4
S0504666 1820 27
S0508653 1330 1J
 1720 43
 1720 52
Fig No. Key No.Part No.
S0508653 1790 2
 1860 4
S0508666 1740 19
 1740 28
 1820 3
S0508766 6120 16
S0508853 1840 3
 1850 3
S0508866 1670 24
 6180 5
 6420 5
 6470 5
S0508966 1270 15
S0509366 1270 29
 1820 17
S0511653 1750 21
 1780 11
 1780 7
S0511666 1190 14
S0511853 1630 3-10
 1640 2-11
S0511866 1120 53
 3150 19
 6540 14
S0512066 1200 10
 1650 4-3
 1750 12
 2140 6-11
S0512266 1180 4
 1210 11
 1330 41
 1400 24
S0512366 1180 5
S0512466 1130 29
S0514666 1230 29
S0515053 6480 32
S0515166 1650 49
S0515253 2160 8-13
S0515266 1660 39
S0515366 1120 36
 2100 15
S0515766 6600 19
S0515866 1150 44
S0521366 3100 17
 3110 17
 3120 20
 6230 14
 6240 18
 6380 20
 6430 20
Fig No. Key No.Part No.
S0521366 6480 17
 6490 15
S0553766 1330 40
S0556466 6150 13
S0557166 1820 8
S0558153 4230 29
 4240 29
S0558666 1400 23
S0558766 1400 26
S0560466 1690 11
 6200 4
 6210 4
 6220 4
S0560563 4250 35
 4260 29
 4270 29
 4280 29
 4290 28
S0560566 1650 33
S0560666 1650 31
S0560866 1290 61
 6120 17
S0561053 4230 40
 4240 40
S0561066 1290 30
 1650 30
 6100 12
S0561266 6100 11
S0562653 1760 4
S0562766 1280 31
 3140 17
 3140 51
 6140 18
 6250 17
 6250 51
 6410 12
 6460 12
 6530 21
 6530 62
 6550 14
S0563366 6170 5
S0565466 1200 13
 1230 16
 1280 32
 2120 5-3
 6520 3
S0565666 2110 16
S0566766 6490 18
S0567066 3110 8
 6230 6
23
Fig No. Key No.Part No.
S0567066 6480 8
S0570166 1190 11
S0571166 2100 17
S0571266 1100 5
S0571866 1100 13
S0574561 6510 7
S0574661 6270 7
 6280 7
 6290 7
 6300 7
 6310 7
 6320 7
S0574861 3130 4
 6330 4
 6340 4
 6350 4
 6360 4
 6370 4
S0711866 1120 49
 1270 2
S0712066 3120 31
 6240 28
 6380 31
 6430 31
S0712153 1820 10
S0712366 1120 40
S0721466 2100 18
S0759166 1750 27
S0759853 1820 14
S0760853 1760 1
S0766066 2100 19
S0770266 2100 20
S0771466 1120 27
S0786366 1120 41
S2201766 1560 23
S2202966 1410 18
S2204861 4110 438
S2204866 4190 78
S2205066 1380 28
 1390 28
S2205261 4110 436
S2208466 1500 110
S2208561 1500 24
 6570 18
S2208866 1430 12
 1450 2
 1560 8
S2208871 4100 406
 4120 435
S2209661 4110 412
Fig No. Key No.Part No.
S2209666 1340 39
 4120 433
S2209961 4120 434
S2210071 4110 413
 4210 25
S2211866 1560 17
S2212061 4100 986
S2212266 1280 35
 1290 35
 1300 35
 1310 35
 1320 35
 1400 27
 2180 7
 3160 6
 4160 124
 4180 74
 6390 6
 6440 6
 6550 17
S2212366 3140 26
 3160 5
 6250 26
 6390 5
 6410 6
 6440 5
 6460 13
 6530 31
 6550 7
S2212466 1290 34
 3140 28
 4170 75
 4190 75
 6130 11
 6140 13
 6140 5
 6250 28
 6260 11
 6410 5
 6460 5
 6530 32
S2212566 3140 21
 6250 21
 6530 25
 6550 9
S2212666 6130 6
 6260 6
 6530 26
S2212761 4230 33
 4230 37
Fig No. Key No.Part No.
S2212761 4240 33
 4240 37
 4260 33
 4260 40
 4270 33
 4270 40
 4280 33
 4280 40
 4290 32
 4290 36
S22127664190 73
S2213066 4190 76
S2213166 1310 37
S2213466 4190 101
 6100 13
S2215366 1240 35
 1250 35
 1260 35
S2215466 1280 33
 2180 8
S2215766 1280 36
S2215961 4250 39
S2215966 6140 10
 6410 10
 6460 10
S2217066 1280 38
S2218961 4290 25
S2221471 4150 43
S2221873 4260 36
 4270 36
 4280 36
S2222171 4260 25
 4270 25
 4280 25
S2222272 4230 25
 4240 25
 4250 27
S2223266 4170 77
S2227561 4130 109
S2227866 1180 7
S2229071 4100 401
S3140025 4100 901
S3450343 1720 30
S3450573 1750 32
S3450583 1730 4
S3450823 1410 15
S3450833 1200 19
 1520 82
 1710 13
 1720 12
24
Fig No. Key No.Part No.
S3450833 1790 5
S3450863 1710 9
 1720 2
S3450943 1720 34
 6570 15
S3450953 1710 6
 1720 42
S3450983 1710 19
 1720 7
S3450993 1510 78
 1520 78
S3452853 1520 79
S3458843 1520 65
S3524008 4110 924
S3524403 3150 7
 6540 7
S3527808 4100 953
S3644163 1480 32
S3654523 1470 25
S4012233 1270 76
S4012303 1820 33
S4012333 1530 32-32
 1650 4-12
 1720 55
S4012533 1270 8
 1530 32-27
 1630 3-27
 1650 4-9
 1670 56
 1750 35
 4110 801
S4012633 1150 12-5
 1170 13
 1610 26
 1630 3-18
 1640 2-19
 4250 42
 4290 39
S4012733 1150 43
 1230 25
 1250 32
 1630 3-12
 1640 2-13
 1650 40
 1760 6
S4012833 4200 24
S4012933 3110 9
 3120 22
 4100 806
 6230 7
Fig No. Key No.Part No.
S4012933 6240 20
 6380 22
 6430 22
 6480 9
 6490 17
 6520 4
S4013133 1100 39
 2100 28
 4100 808
S4013333 3130 5
 6270 8
 6280 8
 6290 8
 6300 8
 6310 8
 6320 8
 6330 5
 6340 5
 6350 5
 6360 5
 6370 5
 6510 8
S4032633 1120 48
S4032833 3150 18-3
 3170 12
 6400 12
 6450 12
 6540 13-3
 6560 18
S4034833 1510 103
S5000113 1560 24
S5000213 1720 4
 1790 6
S5000313 1820 35
S5010303 1820 28
S5010313 1520 115
 1630 3-13
 1640 2-14
 1720 57
S5010513 1270 16
 1670 46
 1740 36
 1750 36
 1820 6
 1860 5
S5010613 1150 12-4
 1170 15
 1210 17
 1650 4-4
 1750 23
Fig No. Key No.Part No.
S5010613 1780 13
 1780 9
 1820 12
S5010713 1120 37
 1150 37
 1290 27
 1650 43
 1760 5
S5010913 1130 47
 4170 81
S5011113 1190 1L
S5100003 1720 29
S5100103 1730 5
S5100203 1200 20
 1710 10
 1720 13
 1720 3
S5100603 4230 28
 4230 32
 4230 36
 4240 28
 4240 32
 4240 36
 4250 41
 4260 32
 4260 35
 4260 39
 4270 32
 4270 35
 4270 39
 4280 32
 4280 35
 4280 39
 4290 38
S5100703 4230 39
 4240 39
 4250 34
 4250 38
 4260 28
 4270 28
 4280 28
 4290 27
 4290 31
 4290 35
S5102203 1270 77
S5102303 1270 5
 1330 36
 1650 4-13
 1700 5
 1710 7
25
Fig No. Key No.Part No.
S5102303 1720 33
 1720 41
 1720 56
 1720 8
 1740 24
 1780 19
 1820 34
S5102503 1270 9
 1330 1K
 1650 4-8
 1670 22
 1720 44
 1720 53
 1740 20
 1740 29
 1750 37
 1790 3
 1820 18
 1820 32
 1820 4
 1820 7
 1840 4
 1850 2
 1860 6
 6120 14
 6150 11
 6180 6
 6420 6
 6470 6
S5102603 1120 39
 1170 14
 1180 6
 1200 11
 1210 16
 1270 3
 1740 3
 1750 13
 1750 16
 1750 22
 1750 28
 1780 12
 1780 8
 1820 11
 1820 15
 3150 20
 6540 15
S5102703 1120 42
 1230 30
 1250 33
 1290 26
Fig No. Key No.Part No.
S5102703 1650 32
 1690 12
 1760 2
 2160 8-14
 6100 10
 6200 5
 6210 5
 6220 5
 6480 31
S5102803 1280 28
 3140 18
 3140 52
 6140 17
 6170 6
 6250 18
 6250 52
 6410 11
 6460 11
 6530 22
 6530 63
 6550 15
S5102903 1130 30
 2100 25
 2120 5-4
 3100 18
 3110 18
 3120 21
 6230 15
 6240 19
 6380 21
 6430 21
 6480 18
 6490 16
S5110503 1340 35
S5110603 1560 18
S5110703 6140 19
 6410 14
 6460 14
S5111103 1180 8
S5210303 1530 32-34
S5700891 4150 41
S5740480 4210 14
S5740600 4210 11
S5740770 4160 122
S5740800 4200 27
S5740870 4100 886
S5740960 4160 110
S5741162 4130 113
S5741200 4140 15
S6005050 4130 108
Fig No. Key No.Part No.
S6250182 4150 68
S6500100 4110 814
S6500380 4140 6
S6500400 4100 824
S6500450 4140 26
S6500600 2160 8-5
S6500750 4160 115
S6510150 4110 858
S6510180 4120 850
S6510620 4130 212
S6710032 4290 40
S6710041 1190 5
 1700 7
 3120 25
 3150 18-6
 3170 7
 6240 23
 6380 25
 6400 7
 6430 25
 6450 7
 6490 19
 6540 13-6
 6560 13
S8000041 4190 42
S8000061 4110 722
 4190 41
S8000081 4100 724
 4150 275
 4210 34
S8000085 4110 724
S8000111 1200 8
 1230 26
 1240 43
 1250 43
 1250 94
 1330 73
 1340 135
 1340 73
 1350 73
 1360 73
 1370 73
 1400 42
 2180 14
 4100 725
 4110 725
 4110 755
 4120 725
 4130 111
 4150 74
26
Fig No. Key No.Part No.
S8000111 4210 35
 6120 28
 6150 22
S8000121 4190 104
S8000141 1280 60
 1330 72
 1350 72
 1360 72
 1370 72
 1380 40
 1390 40
 1400 40
 4100 727
 4170 62
 4180 62
 6120 27
 6150 21
S8000161 4110 732
 4120 732
 4150 405
 4190 30
S8000181 1190 1F
 1220 10
 1230 23
 1240 44
 1260 44
 1330 74
 1340 74
 1370 74
 1400 41
 2180 10
 4110 728
 4150 46
 4160 38
 6140 41-7
 6140 42-7
 6410 41-7
 6410 42-7
 6460 41-7
 6460 42-7
S8000185 4100 732
S8000201 4110 733
S8000205 4200 17
S8000221 4110 730
 4150 410
S8000231 1240 45
 1320 57
 6150 20
S8000241 1240 46
 4100 728
Fig No. Key No.Part No.
S8000241 4190 25
S8000251 4290 30
 4290 34
S8000261 4110 756
 4190 23
 4210 12
S8000281 4230 31
 4230 35
 4240 31
 4240 35
 4260 31
 4260 38
 4270 31
 4270 38
 4280 31
 4280 38
S8000291 1240 47
 1250 93
 1260 47
 1280 59
 6100 20
 6110 10
 6130 12
 6140 41-2
 6140 42-2
 6260 12
 6410 41-2
 6410 42-2
 6460 41-2
 6460 42-2
S8000321 4150 36
 4190 36
S8000341 4130 106
 4250 37
S8000801 2160 8-6
S8001050 2160 8-10
S8001801 4150 235
S8002101 4150 239
S8002721 4110 735
S8002731 4150 37
S8010250 4190 54
S8010251 4110 734
 4210 21
S8010291 4150 406
S8010351 4110 763
S8010355 4100 702
S8010451 4180 7
S8010600 2150 7-8
S8010651 4230 21
 4240 21
Fig No. Key No.Part No.
S8010700 2120 5-2F
S8010751 1210 1B
 6110 1C
S8010755 2140 6-5
 4110 708
S8010801 4250 21
S8010901 4290 13
S8010951 4100 710
 4120 710
 4290 15
S8011000 2160 8-9
S8011151 4260 13
 4270 13
 4280 13
S8011200 1230 15
S8011201 4230 13
 4240 13
 4260 15
 4270 15
 4280 15
S8011251 4230 15
 4240 15
S8011351 4250 13
S8011450 1200 3
S8011451 4100 717
S8011650 1230 8
S8011850 1230 3
S8012300 4160 126
S8030061 6150 23
S8030121 1240 48
 1320 56
S8030161 1280 58
 6100 19
 6100 45
 6110 9
 6140 41-5
 6140 42-5
 6410 41-5
 6410 42-5
 6460 41-5
 6460 42-5
S8060121 4190 103
S8060161 4150 404
 4190 31
S8060181 4100 789
S8060221 4150 411
S8061800 4150 247
S8062100 4150 248
S8090350 4100 792
S8180251 1750 9
27
Fig No. Key No.Part No.
S8180321 1220 1B
S8180411 1800 6
S8450012 1130 45
 1200 23
S8450016 1790 10
 1800 2
S8470014 1210 10
 1220 7
S8470032 1220 16
S8470165 1100 40
S8500079 1130 46
 1250 30
S8500118 1240 31
S8510044 1120 50
S8510092 1170 9
S8510118 1170 6
S8510143 1170 17
T6510018 5100 1-32
T6510027 5100 1-33
T6510062 5100 1-23
T6510066 5100 1-24
T6510069 5100 1-82
T6510070 5100 1-25
T6510072 5100 1-26
T6510075 5100 1-27
T6510079 5100 1-40
T6510081 5100 1-28
T6510085 5100 1-29
T6510087 5100 1-43
T6510089 5100 1-30
T6510091 5100 1-31
T6550005 5100 1-17
T6550006 5100 1-18
T6550007 5100 1-19
T6550009 5100 1-20
T6550011 5100 1-21
T6550018 5100 1-22
T6580008 5100 1-2
T6580020 5100 1-3
T6600183 5100 1-55
T6600189 5100 1-56
T6600191 5100 1-86
T6600197 5100 1-57
T6600201 5100 1-58
T6600211 5100 1-59
T6600217 5100 1-78
T6600223 5100 1-60
T6690012 5100 1-12
T6690013 5100 1-13
T6750003 5100 1-14
Fig No. Key No.Part No.
T7050003 5100 1-4
T7050013 5100 1-5
T7050021 5100 1-6
T7050022 5100 1-7
T7500004 5100 1-8
Y-3738-04 1330 1F
Y-3738-05 1330 1G











































Fig No. Key No.Part No.28
Head Office
Hwasu-Dong 7-11, Dong-Gu, Incheon, Korea.
Tel : +82-32-211-1114 Fax : +82-32-211-1231
Seoul Office
Doosan Tower 26TH FL. 18-12, Euljiro-6Ga,
Jung-Gu, Seoul, korea 100-730
Tel : +82-2-3389-8114 Fax : +82-2-3389-8117
ASIA & OCEANIA
Doosan Infracore Machine Tools Yantai Co.,Ltd.
1, Dayu Road 1, ETDZ, Yantai, Shandong, China
Tel : +86-0535-693-5060 , Fax : +86-0535-693-5619
Doosan Infracore Liaoning Machinery Co.,Ltd.
No.32 DongLing Road, DongLing District, ShenYang,
Liaoning, China
Tel : +86-24-8841-1407, Fax : +86-24-8841-1404
Doosan Infracore Xinjiang Machinery Co.,Ltd.
No. 178, Hetanbei Road, Wurumuqi, Xinjiang, China
Tel : +86-991-469-7217 , Fax : +86-991-469-8641
Dajian(Tianjin) Mechanical Construction Co., Ltd
No.87 Gongxing Road, Tanggu, Tianjin, china
Tel : +86-22-2521-0540 Fax : +86-22-2521-0714
Doosan Infracore (China) Co., Ltd.
#28, Wuzhishan Road, Eco. & Tech, Development Zone,
Yantai, Shandong, China
Tel : +86-535-638-2000 Fax : +86-535-638-2004
Doosan Infracore Japan Corporation
3rd Floor, k-1 Bld.,19-4, Nishi-shinbashi 2-Chome,
Minato-Ku, Tokyo, Japan
Phone : +81-3-3434-2547 Fax : +81-3-3434-2548
Doosan Infracore Middle East Center(Dubai)
183127, AI-Serkal Building, Air Port Road, Dubai, U.A.E
Phone : +971-4-295-2781, 2782 Fax : +971-4-295-2783
NORTH AMERICA
Doosan Infracore America Corporation
2905 Shawnee Industrial Way, Suwanee,
Georgia 30024, U. S. A
Tel : +1-770-831-2200 Fax : +1-770-831-0480
Doosan Infracore America Corporation N.J. Office
8 York Avenue, West Caldwell, N.J. 07006, U.S.A
 Tel : +1-973-618-2500 Fax : +1-973-618-2501
Doosan Infracore America Corporation Cleveland Office
4530 Renaissance Parkway, Warrensville Heights, OH 44128, U.S.A
Tel : +1-216-595-1212 Fax : +1-216-595-1214
EUROPE
Doosan Infracore U.K., Ltd.
Doosan House, Unit 6.3, Nantgarw Park, Cardiff
CF47QU, U.K.
Tel : +44-1443-84-2273 Fax : +44-1443-84-1933
Doosan Infracore Germany GmbH
Hans-Boeckler strasse 27-29, D-40764, Langenfeld-Fuhrkamp,
Germany / Tel : +49-2173-8509-20 Fax : +49-2173-8509-60
Doosan Infracore Europe S.A. (Europe Head Office)
1A, Rue Achille Degrace, 7080 Frameries, Belgium
Tel : +32-65-61-3231 Fax : +32-65-61-3238
Doosan Infracore France SARL
2Eme Etage, 1/3 Avenue Pavlov, Z.A.I. Des Bruyeres, 78190 Trappes France
Tel : +33-1-3016-2140 Fax : +33-1-3016-2144
SOUTH AMERICA
Colombia Liaison Office
Diagonal127 A No. 17-34 Oficina 302
Bogota, Colombia
Tel : +57-1-625-3470 Fax : 57-1 -625-3883
AFRICA
Doosan Infracore South Africa (PTY)Ltd.
60C Electron Road, Isando 1600, Johannesburg, South Africa
Tel : +27-11-974-2095 Fax : +27-11 -974-2778
TRAPPES
(France)
YANTAI
(China)
TIANJIN
(China)
XINJIANG
(China)
DUBAI
(U.A.E)
TOKYO
(Japan)
SEOUL(Korea) CLEVELAND
(U.S.A)
NEW JERSEY
(U.S.A)
ATLANTA
(U.S.A)
BOGOTA
(Colombia)
FRAMERIES
(Belgium)CARDIFF
(U.K.)
DUSSELDORF
(Germany)
JOHANNESBURG
(South Africa)
TRAPPES
(France)
YANTAI
(China)
TIANJIN
(China)
XINJIANG
(China)
DUBAI
(U.A.E)
TOKYO
(Japan)
SEOUL(Korea) CLEVELAND
(U.S.A)
NEW JERSEY
(U.S.A)
ATLANTA
(U.S.A)
BOGOTA
(Colombia)
FRAMERIES
(Belgium)CARDIFF
(U.K.)
DUSSELDORF
(Germany)
JOHANNESBURG
(South Africa)
TRAPPES
(France)
YANTAI
(China)
TIANJIN
(China)
XINJIANG
(China)
DUBAI
(U.A.E)
TOKYO
(Japan)
SEOUL(Korea) CLEVELAND
(U.S.A)
NEW JERSEY
(U.S.A)
ATLANTA
(U.S.A)
BOGOTA
(Colombia)
FRAMERIES
(Belgium)CARDIFF
(U.K.)
DUSSELDORF
(Germany)
JOHANNESBURG
(South Africa)
TRAPPES
(France)
YANTAI
(China)
TIANJIN
(China)
XINJIANG
(China)
DUBAI
(U.A.E)
TOKYO
(Japan)
SEOUL(Korea) CLEVELAND
(U.S.A)
NEW JERSEY
(U.S.A)
ATLANTA
(U.S.A)
BOGOTA
(Colombia)
FRAMERIES
(Belgium)CARDIFF
(U.K.)
DUSSELDORF
(Germany)
JOHANNESBURG
(South Africa)
 (Doosan Infracore Europe S.A. France Office)
Doosan Infracore Europe S.A. Italy Office
Via Monfalcone 41, 20090 Cinisello B.mo (MI)
Tel : +39-2-612-0565 Fax : +39-2-612-6322
DOOSAN INFRACORE CO., LTD.
AROUND THE WORLD
