LIS MANUAL
Technical support
2020.11
LIS MANUAL
A laboratory information system (LIS) is computer software that processes, stores and
manages data from all stages of medical processes and tests.
LIS MANUAL: ICHROMA II
Device Protocol Interface Connection type
Data Transmission
method
Setting on device Note SW ver.
RS232 mini USB cable print serial data
LAN cable/WIFI dongle HTTP method receiver/server needs setting
LAN cable/WIFI dongle TCP/IP method IR2.01.06.06~
RS232 mini USB cable print serial data
LAN cable/WIFI dongle HTTP method receiver/server needs setting
LAN cable/WIFI dongle TCP/IP method IR2.01.06.06~
RS232 mini USB cable print serial data IR2.01.06.16~
Network LAN cable/WIFI dongle HTTP method receiver/server needs setting IR2.01.06.16~
Network LAN cable/WIFI dongle TCP/IP method IR2.01.06.16~
HL7
Boditech
ichroma II
POCcelerator
Network
Network
Choose Protocol and Interface at PC Connection
LIS MANUAL: ICHROMA II DEVICE SETTING
LIS MANUAL: ICHROMA II DEVICE SETTING
WI-FI DONGLE
LIS MANUAL: ICHROMA II DEVICE SETTING
ETHERNET
LIS MANUAL: ICHROMA II DEVICE SETTING
TCP/IP
TCP/IP, or the Transmission Control Protocol/Internet Protocol, is a suite of communication protocols
used to interconnect network devices on the internet. TCP/IP can also be used as a communications
protocol in a private computer network (an intranet or an extranet).
AVAILABLE WI-FI DONGLE
Product
name
Standard Certification manufact
urer
Accessibility Note
1 N100MINI IEEE 802.11b, 802.11g, 802.11n KCC ipTIME Can be bought in South
Korea
Able to use no
w
2 TL-WN725N IEEE 802.11b, 802.11g, 802.11n FCC, CE, IC, Ro
HS
TP-LINK Can be bought in South
Korea, Europe, India
Additional test
needed
3 EW-7811Un IEEE 802.11b, 802.11g, 802.11n FCC, CE, WIFI Edimax Can be bought in China
, Europe, India
Additional test
needed
4 EW-7611ULB IEEE 802.11b, 802.11g, 802.11n
Bluetooth 4.0 BLE/4.0 Dual Mode
Bluetooth 3.0+HS
Bluetooth 2.1 & 3.0
FCC, CE, BQB Edimax Can be bought in China
, Europe, India
Additional test
needed
