9. Which of the given losses are directly proportional to square of speed?
a) Windage loss
b) Eddy current loss
c) Both Windage and eddy current loss
d) Hysteresis loss and brush loss
View Answer
Answer: c
Explanation: The windage loss includes the power required to circulate air through the machine
and ventilating ducts, and is approximately proportional to the square of speed. Also, eddy
current losses are proportional to square of speed.
10. Consider the following statements regarding efficiency of electrical machines:
(i) efficiency should be calculated by measuring output and input
(ii) efficiency is maximum when constant losses = variable losses
(iii) electrical machines are designed to have maximum efficiency at full load
(iv) electrical machines are designed to have maximum efficiency at near about full load
(v) efficiency should be calculated by measuring their losses
(vi) efficiency is maximum when constant losses = x times of (variable losses)
Which of the above statements are correct?
a) (i),(iii),(vi)
b) (ii),(iv),(v)
c) (i),(ii),(iii)
d) (iv),(v),(vi)
View Answer
Answer: b
Explanation: The machine efficiency rises with load. but at a particular load, efficiency is
maximum and beyond this load, efficiency diminishes. Also, for both motors and generators,
machine efficiency is maximum when variable loss = constant loss.
11. The electromechanical energy conversion devices used in power systems are never
operated to deliver maximum power output, because at maximum power output,
_____________
a) Efficiency is less than 50%
b) Temperature of the power devices is much more than the specified allowable temperature
rise
c) Half of the power input appears as losses
d) Any of the mentioned
View Answer
Answer: b
Explanation: In practice, devices are operated at a load somewhat less than rated load, at which
the efficiency is maximum.
12. For the same rating machines, which of the following statement is correct regarding the
efficiency (η)?
a) η of low speed machine > η of high speed machine
b) η of low speed machine
