·IEC61215 / · IEC61730
ODA-120MHD
610W~640W
210*105mm
POWER RANGE
CELL SIZE
JUNCTION BOX
Waterproof protection grade:IP68
Safety Level: Class II
Maximum System Voltage: 1500V
outstanding waterproof level、
Effectively resist harsh environments
Frame
Strong mechanical load
resistance up to 5400Pa
Anodic oxidation layer resistant to
chemical corrosion available
OSDA�Solar�established� in�2008,� is�a�high-tech�enterprise� integrating�R&D,�production�and�sales�of�solar�
energy�products.� It� is�committed�to�the�overall�solution�of�distributed�photovoltaic�system�and�provides�
services�from�consulting,�design,�construction,�financing�to�intelligent�operation�and�maintenance.
OSDA has 3 production sites in China and branches and representative offices in more than 10 countries
overseas. Products include solar cells, modules, On/Off grid solar system, solar pump and other solar related
applications. Our products have passed many international certifications such as TUV, MCS, CEC, IEC, ISO,
CE, CQC and so on. With excellent quality, our products are exported to more than 100 countries of the world.
Since its establishment, OSDA has always followed the idea of "Smart energy，Lightening future". It has
followed the steps of” the Belt and Road Initiative”, we bring bright light to the countries and people who are
short of electricity. Sharing the concept of modern civilization, and building a green home together.
99%
87.4%
30
5
30
Guarantee on product material and workmanship
Linear Power output warranty
Higher Power Output
Module power increases 5-25% generally, bringing
significantly lower LCOE and higher IRR.
SMBB Technology
Better light trapping and current collection to improve
module power output and reliability.
Certified to withstand: wind load (2400 Pascal) and snow
load (5400 Pascal).
Enhanced Mechanical Load
2400 Pa
5400 Pa
PID Resistance
Excellent Anti-PID performance guarantee via
optimized mass-production process and materials
control.
18BB
ODA-120MHD
Cell�Type
No.�of�Cells
Dimensions
Weight
Front�Glass
Back�Glass
Frame
Junction�box
Output�cables
MaxWind�Load/Snow�Load
1500�
30
0~+3%
-0.290%
-0.250%
+0.041%
45±2
-40~+85
Maximum�System�Voltage（V）
Maximum�Series�Fuse�Rating（A）
Power�Tolerance（W）
Pmax�Temperature�Coefficient（s W/℃）
Voc�Temperature�Coefficient（s V/℃）
Isc�Temperature�Coefficient（s A/℃）
NMOT�Nominal�Module�Operating�Temperature（℃）
Operating�and�Storage�Temperature（℃）
(640W)
ELECTRICAL�DATA(STC)
ELECTRICAL�DATA(NMOT)
210*105�N�Type�Bifacial�Mono
120（12*10）
2172*1303*30mm
34.50kg
2.0mm�AR�coating�tempered�glass
2.0mm�Glazed�Glass
Anodized�Aluminium�Alloy
IP68�3diodes
4mm²�cable�35cm（Including�MC4�connector)�
2400Pa/5400Pa
*STC:irradiance�1000W/m²，AM1.5，and�cell�temperature�of�25℃
NMOT
CHARACTERISTICS
Tel�:�86-574-87915068
Call:�86-13566302808
E-mail�:�sales@osdasol.com
The company reserves the right of final interpretation
ADD:1-1,No.136,Haichuan Road,Jiangbei Area,Ningbo
 City,Zhejiang Province,P.R.China
ODA625-30V-MHD ODA630-30V-MHD ODA635-30V-MHD
474.00
34.41
13.75
41.49±3%
14.22±3%
478.00
34.60
13.78
44.71±3%
14.25±3%
482.00
34.79
13.82
41.94±3%
14.30±3%
40HQ�container 18�Packages/666pcs
625.00
36.58
17.09
43.90±3%
17.85±3%
22.09
630.00
36.78
17.13
44.14±3%
17.89±3%
22.27
635.00
36.98
17.18
44.38±3%
17.95±3%
22.44
ODA620-30V-MHDODA615-30V-MHDODA610-30V-MHD
620.00
36.38
17.05
43.66±3%
17.81±3%
21.91
615.00
36.18
17.00
43.42±3%
17.76±3%
21.74
610.00
35.98
16.96
43.18±3%
17.72±3%
21.56
ELECTRICAL�DATA(BNPI)
*BNPI:back�irradiance�135W/m²，AM1.5，and�cell�temperature�of�25℃
470.00
34.22
13.72
41.26±3%
14.19±3%
467.00
34.04
13.68
41.03±3%
14.15±3%
463.00
33.85
13.65
40.81±3%
14.12±3%
693.00
36.58
18.94
43.90±3%
19.78±3%
698.00
36.78
18.98
44.14±3%
19.82±3%
704.00
36.98
19.04
44.38±3%
19.89±3%
687.00
36.38
18.89
43.66±3%
19.73±3%
681.00
36.18
18.84
43.42±3%
19.68±3%
676.00
35.98
18.79
43.18±3%
19.63±3%
ODA640-30V-MHD
640.00
37.18
17.22
44.62±3%
17.99±3%
22.62
486.00
34.98
13.86
42.17±3%
14.33±3%
709.00
37.18
19.08
44.62±3%
19.93±3%
ODA625-30V-MHD ODA630-30V-MHD ODA635-30V-MHDODA620-30V-MHDODA615-30V-MHDODA610-30V-MHD ODA640-30V-MHD
ODA625-30V-MHD ODA630-30V-MHD ODA635-30V-MHDODA620-30V-MHDODA615-30V-MHDODA610-30V-MHD ODA640-30V-MHD
