Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
www.PRSJournal.com 1277e
Hyaluronic acid rejuvenation therapy can
offer an improvement for patients who
present too early for aesthetic surgery,
those who do not want surgery, or those who
have undergone surgery but would benefit from
further subtle facial enhancements. Fat compart-
ments of the face deflate gradually like a slow-
leaking tire, often without the patient noticing.1,2
“Reflation” of these areas, as opposed to “infla-
tion,” reinforces the concept that volume has been
diminished with age, and is now being restored
with hyaluronic acid filler. Stiffer hyaluronic acid
fillers can add support and lift features that have
descended, including the nasal tip or eyebrows,
for example, and restore tissue resistance. Softer
hyaluronic acid fillers can change the contour
and shape of facial features, such as the jawline or
forehead. Modern hyaluronic acid rejuvenation is
more than just chasing lines and folds. With more
sophisticated treatments and finer sculpting tools,
it becomes increasingly necessary for the clinician
to perform a detailed facial analysis for each indi-
vidual patient.
As surgeons, we tend to focus on a problem
and the solution, but can at times miss the oppor-
tunity for full facial rejuvenation. As in restoring
a painting or a car, one does not just restore the
front third and leave the rest unfinished—this
would appear peculiar. Also as in restoring a
painting, the project is outlined and can require
several stages, and smaller maintenance enhance-
ments in perpetuity (Fig. 1). For a comprehen-
sive facial analysis, younger patient photographs
in various facial poses can offer an abundance of
helpful information. For example, if the patients
Disclosure: Dr. Swift is a consultant/clinical in-
vestigator for Allergan, Merz, and Galderma. Dr.
Remington is a consultant and advisory board
member for Galderma and Allergan. Dr. Comstock
is a consultant and advisory board member for Al-
lergan, Galderma, Colorescience, Skinceuticals, Re-
vance, and skinbetter science. Drs. Mckee, Lambros,
and Lalonde have no financial interest in any of the
products mentioned in this article.
Copyright © 2019 by the American Society of Plastic Surgeons
DOI: 10.1097/PRS.0000000000005607
Daniel Mckee, M.D.
Kent Remington, M.D.
Arthur Swift, M.D.
Val Lambros, M.D.
Jody Comstock, M.D.
Don Lalonde, M.D.
Vancouver, British Columbia; Calgary,
Alberta; Montreal, Quebec; and Saint
John, New Brunswick, Canada; New-
port Beach, Calif.; and Tucson, Ariz.
Learning Objectives: After studying this article, the participant should be able
to: 1. Process several patient-specific factors before reaching an optimal treat-
ment strategy with appreciation for facial balance. 2. Define the advantages
and disadvantages of various hyaluronic acid preparations and delivery tech-
niques, to achieve a specific goal. 3. Perform advanced facial rejuvenation
techniques adapted to each facial zone, combining safety considerations. 4.
Prevent and treat complications caused by inadvertent intraarterial injections
of hyaluronic acid.
Summary: The growing sophistication and diversity of modern hyaluronic acid
fillers combined with an increased understanding of various delivery tech-
niques has allowed injectable filler rejuvenation to become a customizable
instrument offering a variety of different ways to improve the face: volume
restoration, contouring, balancing, and feature positioning/shaping—beyond
simply fading skin creases. As more advanced applications for hyaluronic acid
facial rejuvenation are incorporated into practice, an increased understanding
of injection anatomy is important to optimize patient safety. (Plast. Reconstr.
Surg. 143: 1277e, 2019.)
From the University of British Columbia; Remington Laser;
McGill University; private practice; Skin Spectrum; and
Dalhousie University.
Received for publication August 29, 2018; accepted Janu-
ary 11, 2019.
Effective Rejuvenation with Hyaluronic Acid
Fillers: Current Advanced Concepts
Related Video content is available for this ar-
ticle. The videos can be found under the “Re-
lated Videos” section of the full-text article, or,
for Ovid users, using the URL citations pub-
lished in the article.
RELATED VIDEO CONTENT IS AVAILABLE
ONLINE.
CME
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
1278e
Plastic and Reconstructive Surgery • June 2019
never had a full upper lip, a pronounced Cupid’s
bow, a peaked eyebrow, or full upper eyelids in
their youth, they would not benefit from any of
these enhancements at a later age. Respect their
genetics (Fig. 2). In older faces, the changeable
features such as lip size, eyebrow position, and
cheek volume should be only partly restored in a
subtle nature to their youthful proportions, limit-
ing the restoration to comply with the surround-
ing irreversible effects of age.3 Do not attempt to
return older faces to appear the way they did in
their twenties. Instead, make them appear the
best for their age. Some patients young and old
are not wired for aesthetics, so do not let them
pull you in to distorted results.
Traditionally, surgeons define their aesthetic
surgical treatment endpoints (e.g., brow position)
using a discrete measurement based on an aver-
age obtained from the literature, or their own
experience. Symmetry is often a goal. However,
the pinpoint nature of hyaluronic acid rejuvena-
tion has allowed further refinement toward more
ideal treatment endpoints, which are more often
based on facial proportions.4,5 When it comes to
treatment endpoints, one size fits none. Recog-
nizably beautiful faces all have a convergence of
beauty and facial proportions that appear quite
similar within all races, in addition to similar facial
shape, delicacy of features, balance, and symme-
try.6–8 One goal of syringe therapy is to make the
patients more blended toward their ideal propor-
tion, but also limiting changes by their relatively
constant features (e.g., intercanthal distance,
forehead height, anterior nasal spine position)
and their genetics, age, and ethnic features.9
Everyone’s facial muscles and features age
differently, at different rates, with different com-
pensatory effects from neighboring supporting
structures. Some facial muscles become stronger
in time because of a lifetime of overactivation.
Accordingly, the brow can elevate or descend with
age. The aperture of the eye can widen or constrict.
Facial muscles of expression (especially in overly
animated patients) with time can overpower the
surrounding tissue resistance, creating unwanted
creases and wrinkles. This is called dynamic dis-
cord and is observed mostly in the periorbital and
perioral zones. Focused individualized treatment
Fig. 1. Top 25 facial aesthetic zones for comprehensive analysis and hyaluronic acid rejuvenation.
Zones can overlap and are often affected by treatment of adjacent zones.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
Volume 143, Number 6 • Rejuvenation with Hyaluronic Acid Filler
1279e
to restore balance by using neuromodulator and
hyaluronic acid combination maintenance ther-
apy may partially prevent this regression. Injected
hyaluronic acid product lasts 1 to 2years, depend-
ing on patient and treatment variables. However,
facial restoration effects can be long lasting, as
hyaluronic acid stimulates neocollagenesis, elas-
tin, and ground substance, through tension and
direct stimulation to fibroblasts.10 There may also
be persistent positive effects on surrounding mus-
cle efficiency and soft-tissue elasticity.
PREPARATION AND TECHNIQUE
An advanced injector should be comfortable
with using both microcannulas and needles, as
both have their advantages and disadvantages—
often specific to facial location. In anatomical
danger zones, a blunt-tip microcannula is safer
in the subcutaneous plane but must still be used
with caution. Long microcannulas can be used to
contour large surface areas, or gently break up
creases and scars, with little discomfort, trauma, or
bruising. Microcannulas require a needle for skin
entry and often a second pair of hands to assist, so
there is a learning curve. The needle is typically
one or two gauges larger than the microcannula
(e.g., a 25-gauge ½-inch trocar for a 27-gauge 1.5-
inch microcannula). The 30-gauge microcannu-
las are especially useful for delicate areas such as
the tear trough or upper lip. Microcannulas can
be difficult to maneuver around dense tissues or
retaining ligaments. Where lift is desired, needles
are better for creating structural pillars on bone.
Transferring product under sterile technique into
smaller 3-cc syringes can offer better tactile feed-
back and control of injected volume—like a finer
paint brush (off-label). (See Video, Supplemental
Digital Content 1, which displays how to decrease
Fig. 2. This 54-year-old patient of Dr. K. Remington who presents with an old photograph at age 23 (left), bringing attention to her
underlying genetics—mild lip volume, subtle Cupid’s peaks, and blunted upper eyebrow peaks. (Center) Before treatment, the patient
has supraorbital hollowing, deflated midface, deflated earlobes (yellow line), downturned unsupported oral commissures, retruded
upper lip, deflated vermillion lips, obscured jawline, and weak chin (white line). (Right) Three weeks after full facial rejuvenation with
hyaluronic acid and neuromodulator, the above age-related changes are improved. The injector is careful not to overtreat the upper
vermillion lip and philtral columns, matching her native lip genetics. The upper eyebrow peak remains gradual, as in her youth.
Video 1. Supplemental Digital Content 1, which displays how to
decrease the discomfort of the needle with filler injections, can
be found in the “Related Videos” section of the full-text article at
PRSJournal.com or at http://links.lww.com/PRS/D495.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D495
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
1280e
Plastic and Reconstructive Surgery • June 2019
the pain of the needle with filler injections. This
video can be found in the “Related Videos” sec-
tion of the full-text article at PRSJournal.com or
at http://links.lww.com/PRS/D495.)
There are technical ways to reduce the pain of
injection in addition to merely decreasing the size
of the injection needle, or using microcannulas
for contouring of large surface areas. As with the
principles of local anesthesia infiltration,11 inject-
ing any fluid very slowly allows the tissue to equili-
brate, resulting in less injury, swelling, and pain.
Prevent the needle from wobbling, and inject per-
pendicular to the skin. Sensory noise with vibra-
tion or a flick movement distracts the brain from
registering the pain signals. Similarly, allowing the
skin to fall into the needle, rather than pushing
the needle into the skin, reduces pain. Pretreat-
ment with a cooling mechanism may reduce pain.
Knowing the characteristics and personalities of
each hyaluronic acid product will help the injector
decide where and how to use each product to its maxi-
mal effect. Some basic hyaluronic acid characteristics
include the following: (1) stiffness G′ (stiffer products
have a tendency to lift, but are also more prone to skin
irregularities, especially when applied to thin skin), (2)
cohesivity (optimal for smooth contouring), (3) lon-
gevity, (4) water absorption (highly absorptive prod-
ucts are prone to edema issues around the orbit), (5)
crosslinking variations, and (6) response to hyaluroni-
dase (higher doses of hyaluronidase are required to
dissolve more robust crosslinking technology).
Under sterile technique, filler can be mixed
with normal saline or dilute lidocaine/epineph-
rine using a female-to-female Luer-Lock connector
(Becton, Dickinson & Co., Franklin Lakes, N.J.) (off-
label). Ratios include 2:1 and 1:1 mixtures. Inject-
ing blended filler promotes a thin film of product to
be layered smoothly in an area of desired contour.
Blended hyaluronic acid is especially useful in areas
with thin skin that are prone to irregularities (e.g.,
lips, orbit, temple, and forehead).12
After the injections are complete, a lubricat-
ing gel can be used to lightly and briefly mold and
massage over the skin to help reduce lumps and
irregularities. Some areas only require subtle mold-
ing (such as the lips) compared to other areas
which require more assertive massaging (such as the
cheeks). Also, have the patient animate their face to
further expose any irregularities. Ice packs can be
applied to areas prone to swelling, such as the lips.
UPPER FACE
Signs of forehead aging include slight concav-
ity in the lower third of the forehead, increased
forehead lines throughout, and flattening of the
brow and glabella. Placing hyaluronic acid on
periosteum to contour the lower third of the fore-
head improves contour and also tents up the skin
to fade creases.13 This technique can also elevate
the eyebrows through improved efficiency of the
frontalis muscle, given the restoration of the pivot
support for its lever arm.14 An attractive forehead
has a very mild prominence at the glabella and
supraorbital rim where the eyebrows perch. An
attractive female eyebrow starts medially at the
orbital rim in line with the medial canthus, and
slants upwards at 10 to 20 degrees. The intercan-
thal distance is measured, and the eyebrow peak is
typically situated the same distance from the head
of the brow. The eyebrows may either descend
or become elevated with age (elevation can be
due to the effects of dynamic discord). Microcan-
nulas inserted from the lateral side of the brow
can restore volume on the supraorbital rim to
improve contour, and help support the eyebrow.
This technique does not work if the eyebrows
have fallen below the rim, as volume placed on
the rim in this case will only push the eyebrows
lower—similar to a waterfall breast deformity with
high implant placement. With this microcannula
technique, one hand props the brow up, and the
other hand directs the hyaluronic acid to support
the desired position of the brow. An assistant can
place a finger under the supraorbital rim to block
dispersion of hyaluronic acid into the upper eye-
lid. The brow peak can be defined by depositing
extra hyaluronic acid at the peak. At the level of
the supraorbital rim and glabella, the supraorbital
and supratrochlear arteries course on periosteum
and are therefore vulnerable to hyaluronic acid
injections even when the needle is directly on
bone. The supratrochlear artery courses just deep
to the medial corrugator crease; thus, if a perioste-
ally placed needle is necessary to restore the gla-
bella, injecting medial to this crease is safer.
Temporal hollowing should be restored in
female patients only to a subtle concavity com-
pared to male temples, which are more flator
slightly convex.15 By reflating the temple, the lat-
eral eyebrows swing back into plain sight. The
temporal zone is fraught with vessels. Supraperi-
osteal placement of hyaluronic acid on bone
with a needle or subcutaneous placement of
hyaluronic acid using a microcannula are safer
techniques (Fig. 3). When injecting on bone, the
hyaluronic acid tends to spread upward along the
needle track and into the subcutaneous hollow-
ing. (See Video, Supplemental Digital Content 2,
which displays temple contouring with periosteal
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D495
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
Volume 143, Number 6 • Rejuvenation with Hyaluronic Acid Filler
1281e
placement of hyaluronic acid. This video can be
found in the “Related Videos” section of the full-
text article at PRSJournal.com or at http://links.
lww.com/PRS/D496.)
In the infrabrow region, subcutaneous tissue
can deflate with age, causing a degree of orbital
hollowing, especially medially.16 Redundant skin
is the symptom, but the cause can be partially
treated with low-G′ hyaluronic acid that lightly
coats the plane between skin and orbicularis
muscle. Use of a 27-gauge microcannula with an
approach from the lateral position is among the
safest approaches. Similarly, crow’s feet can be
faded with a similar approach and plane, which
can also include a light subcision using the micro-
cannula directed perpendicular to the creases.
MIDFACE
Although partially contained by relatively
fixed facial retaining ligaments, soft-tissue com-
partments of the face deflate, descend, and/or
wrinkle with time.17 The troughs and creases from
the retaining ligaments become more prominent
as an indicator of slow deflation of the immedi-
ately adjacent soft tissue.
The cheek has several overlapping aesthetic
zones for consideration, at times concurrent with
known fat compartments.18 The malar mound is
often one of the first areas treated, as surround-
ing areas are frequently improved after restoring
this area. Treatment of the cheek can be done
efficiently by using stiff hyaluronic acid pillars
positioned on bone, which tent up a fanned-out
subcutaneous layer of soft hyaluronic acid—like a
canopy’s frame holding up the lighter top (Fig. 4).
The shadow inferior to the malar mound (form
shadow) narrows the face by contrasting the lesser
fullness of the cheek’s form shadow, found just
inferior to the malar mound and mostly within
the submalar zone. A well-contrasted form shadow
is slightly concave relative to the malar mound.
The shadow is often accented with makeup and
is a sign of youth. The extent of contrast is less
tolerated by Asian faces, aged faces, or postsurgi-
cal faces.19 In these exceptions, the submalar zone
Fig. 3. Images showing a patient of Dr. V. Lambros who received hyaluronic acid rejuvenation injections to the temples.
(Left) Before injection, the patient demonstrates significant hollowing over the temples. Each side received 1.5 cc of hyal-
uronic acid diluted in 5 cc of normal saline. (Right) After injection, there is only subtle youthful concavity over the temples.
The lateral tail of the eyebrows are brought back into plain view. A 25-gauge microcannula was used to infiltrate blended
hyaluronic acid into the subcutaneous plane.
Video 2. Supplemental Digital Content 2, which displays temple
contouring with periosteal placement of hyaluronic acid, can be
found in the “Related Videos” section of the full-text article at
PRSJournal.com or at http://links.lww.com/PRS/D496.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D496
http://links.lww.com/PRS/D496
http://links.lww.com/PRS/D496
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
1282e
Plastic and Reconstructive Surgery • June 2019
(especially medially) requires less contrast with
the malar mound. The malar mound itself should
be gradual, smooth, and rounded—accenting the
natural ogee curve on the oblique facial view.4
The position of the mound varies from face to
face depending on the position of other facial
features. The apex of the malar mound is eccen-
tric, and sits slightly superior and medial on the
mound. Compared with a Caucasian female malar
apex, the male and female Asian apex is broader
and sits more inferior and medial. The male malar
mound itself is also broader. (See Video, Supple-
mental Digital Content 3, which displays cheek
analysis and volume restoration with hyaluronic
acid. This video can be found in the “Related Vid-
eos” section of the full-text article at PRSJournal.
com or at http://links.lww.com/PRS/D497.)
The medial cheek deflates earlier in male sub-
jects, Asians, and patients with negative vectors.
Fig. 4. Cross-sectional anatomy demonstrating deflation of the cheek with age, and “reflation” of
the cheek with hyaluronic acid. (Left) The young cheek skin is supported by thick deep fat and the
zygomatic cutaneous retaining ligaments, and a full superficial fat layer. (Center) The aged cheek
shows deflation of the deep fat and ptosis of the retaining ligaments. The unsupported superficial
soft tissue of the cheek droops over the nasolabial fold ligamentous structure. (Right) Restoring
volume to the superficial fat compartment using soft hyaluronic acid causes the cheek skin and
cutaneous ligaments to plump up. Stiffer hyaluronic acid placed on malar bone restores volume
to the deep compartment and acts like poles or pillars to support and lift the canopy top.
Video 3. Supplemental Digital Content 3, which displays cheek
analysis and volume restoration with hyaluronic acid, can be
found in the “Related Videos” section of the full-text article at
PRSJournal.com or at http://links.lww.com/PRS/D497.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D497
http://links.lww.com/PRS/D497
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
Volume 143, Number 6 • Rejuvenation with Hyaluronic Acid Filler
1283e
Restoring volume to the medial cheek and
 sub–orbicularis oculi fat in a deep plane can
support the lower eyelid structures. The medial
cheek should be treated before treating the tear
trough, or else the negative vector will be exac-
erbated. Use of a blunt-tip microcannula and
approaching from the lateral aspect of the face
are favored to avoid piercing the infraorbital and
angular vessels. (See Video, Supplemental Digital
Content 4, which displays the medial cheek using
a microcannula injecting in the deep subcutane-
ous layer. This video can be found in the “Related
Videos” section of the full-text article at PRSJour-
nal.com or at http://links.lww.com/PRS/D498.)
Restoring volume under the thin delicate skin
of the tear trough can lead to skin irregularities and
a bluish hue from the Tyndall effect.20,21 The Tyndall
effect can be caused by too much hyaluronic acid
injected into the subdermal plane or in the der-
mis—especially superficial dermis. Hyaluronidase
may be used to reverse deformities caused by hyal-
uronic acid. (See Video, Supplemental Digital Con-
tent 5, which displays using hyaluronidase to treat
the Tyndall effectin the tear troughs. This video
can be found in the “Related Videos” section of
the full-text article at PRSJournal.com or at http://
links.lww.com/PRS/D499.) Medially, the orbicularis
retaining ligaments have multiple attachments to
bone, so a periosteal placement of hyaluronic acid
using a microcannula is difficult. Microdeposit of
hyaluronic acid on the rim using a needle has been
described. Blended soft hyaluronic acid can be
used to thinly coat the layer between skin and orbi-
cularis with a 30-gauge microcannula.22 It is safest to
undertreat the tear troughs, as hyaluronic acid will
absorb water over time. The more hydrophilic the
hyaluronic acid molecule is, the more problematic
it can be in this area. The lower lateral eyelid crease
can be softened with an identical approach. The
lateral orbicularis is not as fixed to bone; therefore,
a bilayer approach can be achieved with a micro-
cannula. When examining more laterally on the
cheek, a flattened preauricular cheek is often a tell-
tale sign of a previous face lift and can be corrected
with fanning subcutaneous hyaluronic acid but
should not be overcorrected because of the risk of
masculinizing the face.23 (See Video, Supplemen-
tal Digital Content 6, which displays tear trough
Video 4. Supplemental Digital Content 4, which displays the
medial cheek using a microcannula injecting in the deep sub-
cutaneous layer, can be found in the “Related Videos” section
of the full-text article at PRSJournal.com or at http://links.lww.
com/PRS/D498.
Video 5. Supplemental Digital Content 5, which displays using
hyaluronidase to treat the Tyndall effect in the tear troughs, can
be found in the “Related Videos” section of the full-text article at
PRSJournal.com or at http://links.lww.com/PRS/D499.
Video 6. Supplemental Digital Content 6, which displays tear
trough rejuvenation with hyaluronic acid, can be found in the
“Related Videos” section of the full-text article at PRSJournal.
com or at http://links.lww.com/PRS/D500.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D498
http://links.lww.com/PRS/D499
http://links.lww.com/PRS/D499
http://links.lww.com/PRS/D498
http://links.lww.com/PRS/D498
http://links.lww.com/PRS/D499
http://links.lww.com/PRS/D500
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
1284e
Plastic and Reconstructive Surgery • June 2019
rejuvenation with hyaluronic acid. This video can
be found in the “Related Videos” section of the full-
text article at PRSJournal.com or at http://links.lww.
com/PRS/D500.)
Nasal rejuvenation with hyaluronic acid filler
is very risky.24 It is safest to remain exactly midline
and on periosteum/perichondrium when redefin-
ing the radix or nasal dorsum.25 Caudal support
decreases with age because of deflation of caudal
soft tissues and retrusion of the piriform fossa. The
nasal tip drops, the nasolabial angle decreases, the
nasal length appears longer, and the nasal bases
splay, resulting in larger nares. A high-G′ hyal-
uronic acid can be used to correct these deformi-
ties by structurally reinforcing the columella base
at the anterior nasal spine, in addition to filler
placement under the nasal bases, directly on bone.
(See Video, Supplemental Digital Content 7, which
displays nasal rejuvenation with hyaluronic acid.
This video can be found in the “Related Videos”
section of the full-text article at PRSJournal.com
or at http://links.lww.com/PRS/D501.)
High-G′ filler injected in the aged earlobe can
improve firmness of the earlobe and counteract
descent with age. A pixie ear deformity following
face lift can be improved by injecting hyaluronic
acid filler into the preauricular cheek just adja-
cent to the earlobe. Injecting the adjacent skin
with stiff filler can add support to the skin and
prevent it from pulling down on the earlobe. (See
Video, Supplemental Digital Content 8, which dis-
plays earlobe rejuvenation with hyaluronic acid.
This video can be found in the “Related Videos”
section of the full-text article at PRSJournal.com
or at http://links.lww.com/PRS/D502.)
LOWER FACE
The nasolabial fold becomes more defined
with age.26 This is a partly caused by descent of
the midface as it droops over a relatively perma-
nent facial ligament. The nasolabial fold benefits
when the deflated midface is propped up with
structural hyaluronic acid filler. Obliterating
this anatomical structure should not be the goal.
Adjunct techniques to soften the fold include
(1) gentle subcision with a microcannula run-
ning longitudinally with the fold and then a light
sheeting of cohesive filler, or (2) multiple needle
deposits along the fold aimed at the superficial
subcutaneous layer in the lower two-thirds of the
fold, and the subdermal layer in the upper third.
The tortuous facial artery runs parallel to the
Video 7. Supplemental Digital Content 7, which displays nasal
rejuvenation with hyaluronic acid, can be found in the “Related
Videos” section of the full-text article at PRSJournal.com or at
http://links.lww.com/PRS/D501.
Video 8. Supplemental Digital Content 8, which displays ear-
lobe rejuvenation with hyaluronic acid, can be found in the
“Related Videos” section of the full-text article at PRSJournal.
com or at http://links.lww.com/PRS/D502.
Video 9. Supplemental Digital Content 9, which displays naso-
labial fold rejuvenation with hyaluronic acid, can be found in
the “Related Videos” section of the full-text article at PRSJournal.
com or at http://links.lww.com/PRS/D503.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D500
http://links.lww.com/PRS/D500
http://links.lww.com/PRS/D501
http://links.lww.com/PRS/D502
http://links.lww.com/PRS/D501
http://links.lww.com/PRS/D502
http://links.lww.com/PRS/D503
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
Volume 143, Number 6 • Rejuvenation with Hyaluronic Acid Filler
1285e
fold and becomes more superficial in the upper
third of the crease as the skin thins. (See Video,
Supplemental Digital Content 9, which displays
nasolabial fold rejuvenation with hyaluronic acid.
This video can be found in the “Related Videos”
section of the full-text article at PRSJournal.com
or at http://links.lww.com/PRS/D503.)
Like the nasolabial fold, most signs of aging in
the lower face are partly influenced by soft-tissue
deflation and skeletal resorption of the midface27
(Fig. 5). The jowl is partly caused by descent of fat
and skin relative to the fixed prejowl sulcus. The
jowl is also partly caused by tissue deflation of adja-
cent supporting zones including the prejowl sulcus,
the marionette zone, and the lateral oral commis-
sure. With age, the skin and subcutaneous tissue
surrounding the perioral region lose elasticity and
resistance compared to the surrounding facial
muscles. Several consequences of this dynamic
discord include increased lateral teeth show with
smiling (which becomes a grin), down-turned oral
commissures, and increased perioral skin creases.
Hyaluronic acid treatment can restore volume, tis-
sue resistance, and balance to the cutaneous lips,
modiolus region, marionette zone, and prejowl
sulcus. (See Video, Supplemental Digital Content
10, which displays age-related retrusion of the
lateral oral commissure, jowl, and marionette zone
requiring hyaluronic acid rejuvenation therapy.
This video can be found in the “Related Videos”
section of the full-text articleat PRSJournal.com
or at http://links.lww.com/PRS/D504.) Chin projec-
tion should not be restored without also addressing
the other lower facial zones—at the risk of causing
Fig. 5. (Left) This 67-year-old patient has midface and lower face retrusion from multizone soft-tissue deflation, and
maxillary and mandibular bony resorption. Resulting signs of aging include fixed cheek creases, prominent nasola-
bial fold, jowls, labiomandibular creases, and obscured jawline. The jowl is amplified by the tethering effect of the
osteocutaneous mandibular ligament, and deflation of the zones immediately adjacent. (Right) The patient is shown
10 months after injection with hyaluronic acid by Dr. K. Remington, without surgery. Restoring structure and vol-
ume to the malar mound and medial cheek (marked in blue) improves all of the above-mentioned deformities by
providing projection/lift. The cheek form shadow (marked in purple) becomes slightly more contrasted and concave
relative to the restored malar cheek. The medial cheek droops less over the nasolabial fold, lightening the crease’s
shadow. Injecting the lower facial zones (i.e., nasolabial fold, prejowl sulcus, marionette zone, lateral oral commissure,
postjowl jawline, and chin) improves the above-mentioned lower face deformities. Jawline definition is restored,
along with its shadow underneath (white line). The restoration project returns youthful shadow to the jawline and the
cheek’s form shadow, and removes shadows from creases, folds, and hollows.
Video 10. Supplemental Digital Content 10, which displays age-
related retrusion of the lateral oral commissure, jowl, and mari-
onette zone requiring hyaluronic acid rejuvenation therapy, can
be found in the “Related Videos” section of the full-text article at
PRSJournal.com or at http://links.lww.com/PRS/D504.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D503
http://links.lww.com/PRS/D504
http://links.lww.com/PRS/D504
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
1286e
Plastic and Reconstructive Surgery • June 2019
an overprojected central chin in proportion to the
rest of the lower face. Deep hyaluronic acid depos-
its using a needle can address a retruded chin.
Hyaluronic acid therapy is more customizable than
using a surgical chin implant. However, hyaluronic
acid does not replace the need for chin implants
for patients with significant micrognathia. The pos-
terior jawline can be contoured using a microcan-
nula aimed posteriorly. A soft jawline and rounded
projected chin is more feminine, whereas a square
jawline and wider chin are more masculine.28
The vermillion lips are particularly sensitive to
symmetry and balance, and it does not take much to
achieve a noticeably unnatural result. The white roll
border can be partly restored by adding extra prod-
uct to the vermillion peak if necessary, using a 27- or
25-gauge microcannula. In a balanced lip, the dis-
tance between the philtral columns is equal to the
height of the lower lip. The lower lip height is larger
than the upper lip height in Caucasians by a factor
of 1.618:1 (phi), but closer to 1:1 in Asians.4 With
age, the lower lip vermillion deflates quicker than
its counterpart. Restoration of volume should focus
on the middle 80 percent of the lower vermillion lip
(equal to the intercanthal distance). The thin skin
of the lip is prone to lumps; therefore, a blended
soft hyaluronic acid is often preferred. Injections
at the wet-dry junction are typically performed in
a plane between skin and superficial orbicularis
muscle (subvermillion). The tortuous labial arteries
have variable anatomy but are typically situated in
deep orbicularis and oral mucosa (approximately
4 mm deep to skin) adjacent to the vermillion bor-
der. (See Video, Supplemental Digital Content 11,
which displays lip rejuvenation with hyaluronic acid.
This video can be found in the “Related Videos” sec-
tion of the full-text article at PRSJournal.com or at
http://links.lww.com/PRS/D505.)
SAFETY
Hyaluronic acid rejuvenation is reversible and
therefore the safest currently available injectable
filler.29 Acute complications are rare but can include
pain from nerve injury, venous and lymphatic com-
promise, severe bruising from vessel injury, local
skin pressure necrosis, and distal soft-tissue necro-
sis.30–33 Inadvertent intravascular injection of filler
is responsible for distal soft-tissue necrosis affecting
distant skin or the eye. If the arterial flow connects
with the ophthalmic system, ophthalmoplegia or
blindness can occur.34 Depositing filler external to
vessels does not cause distal soft-tissue necrosis but
can cause local temporary blanching of the skin
that is responsive to massage and hyaluronidase.
Subdermal injections are safe from major
intraarterial complications but can still cause local
skin necrosis from increased pressure in areas with
less elastic skin such as scarred tissue, or areas that
have native terminal end-arteries such as the nose
and glabella. If the needle inadvertently slips deep
to the dermis, the plunger resistance decreases as
a warning if using a small 3-cc syringe.
Supraperiosteal injections are typically the
next safest plane, but have the added risk of (1)
piercing nerves and vessels on the way down,
and (2) intraarterial injections in select loca-
tions where major vessel are on bone. Piercing
vital structures on the pathway down to bone can
be minimized by choosing the shortest distance
to bone: needle perpendicular to the skin. The
supraorbital, infraorbital, and supratrochlear
arteries all initially course on periosteum. The
facial artery courses on periosteum as it crosses
the mandible 1 cm medial to the medial edge of
the masseter. All these vessels connect with the
ophthalmic artery system as well (Fig. 6).
The injection plane between skin and bone
(subcutaneous and muscle layer) is where the
majority of arteries course, and where the major-
ity of risk lies. Advanced knowledge of injection
anatomy is required to prevent complications.
This knowledge must include location and depth
of target tissue and vital structures as they relate
to surface landmarks.33 (See Video, Supplemen-
tal Digital Content 12, which displays injection
anatomy and safety techniques. This video can be
found in the “Related Videos” section of the full-
text article at PRSJournal.com or at http://links.
lww.com/PRS/D506.)
Video 11. Supplemental Digital Content 11, which displays lip
rejuvenation with hyaluronic acid, can be found in the “Related
Videos” section of the full-text article at PRSJournal.com or at
http://links.lww.com/PRS/D505.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
http://links.lww.com/PRS/D505
http://links.lww.com/PRS/D506
http://links.lww.com/PRS/D506
http://links.lww.com/PRS/D505
Copyright © 2019 American Society of Plastic Surgeons. Unauthorized reproduction of this article is prohibited.
Volume 143, Number 6 • Rejuvenation with Hyaluronic Acid Filler
1287e
In high-risk areas or planes, consider aspirat-
ing before injection, using a microcannula brought
in perpendicular to the known course of the sur-
rounding artery, and avoid injecting in areas that
are vasodilated (e.g., from earlier injection trauma).
If a needle must be used, inject the hyaluronic acid
directly on periosteum, or at a depth well away from
the known vital structures in the area.
Regardless of injection depth, hyaluronic acid
should be injectedin small aliquots (injections. Plast
Reconstr Surg. 2017;139:1103–1108.
 32. Scheuer JF III, Sieber DA, Pezeshk RA, Campbell CF,
Gassman AA, Rohrich RJ. Anatomy of the facial danger
zones: Maximizing safety during soft-tissue filler injections.
Plast Reconstr Surg. 2017;139:50e–58e.
 33. Swift A, Remington K. S.A.F.E.R. Technique. Fort Lauderdale,
Fla: The Aesthetic Blueprint Seminar; 2016.
 34. Beleznay K, Carruthers JD, Humphrey S, Jones D. Avoiding
and treating blindness from fillers: A review of the world lit-
erature. Dermatol Surg. 2015;41:1097–1117.
 35. Pessa JE, Nguyen H, John GB, Scherer PE. The anatomical
basis for wrinkles. Aesthet Surg J. 2014;34:227–234.
 36. DeLorenzi C. Transarterial degradation of hyaluronic acid
filler by hyaluronidase. Dermatol Surg. 2014;40:832–841.
 37. DeLorenzi C. New high dose pulsed hyaluronidase protocol
for hyaluronic acid filler vascular adverse events. Aesthet Surg
J. 2017;37:814–825.
 38. Cohen JL, Biesman BS, Dayan SH, et al. Treatment of hyal-
uronic acid filler-induced impending necrosis with hyal-
uronidase: Consensus recommendations. Aesthet Surg J.
2015;35:844–849.
 39. DeLorenzi C. Complications of injectable fillers, part 2:
Vascular complications. Aesthet Surg J. 2014;34:584–600.
D
ow
nloaded from
 http://journals.lw
w
.com
/plasreconsurg by B
hD
M
f5eP
H
K
av1zE
oum
1tQ
fN
4a+
kJLhE
Z
gbsIH
o4X
M
i0
hC
yw
C
X
1A
W
nY
Q
p/IlQ
rH
D
3i3D
0O
dR
yi7T
vS
F
l4C
f3V
C
4/O
A
V
pD
D
a8K
2+
Y
a6H
515kE
=
 on 11/01/2023
