Food Hydrocolloids 151 (2024) 109832
Available online 2 February 2024
0268-005X/© 2024 The Authors. Published by Elsevier Ltd. This is an open access article under the CC BY license (http://creativecommons.org/licenses/by/4.0/).
Renewable methanol utilizing bacteria as future meat analogue: An
explorative study on the physicochemical and texturing properties of
Methylobacillus flagellatus biomass and fractions
Wanqing Jia a,d, Laurice Pouvreau b, Atze Jan van der Goot a, Timotheus Y. Althuis c,
David Virant e, Aleksander J. Kruis e, Gregor Kosec e, Nico J. Claassens c, Julia K. Keppler a,*
a Laboratory of Food Process Engineering, Wageningen University, P.O. Box 17, 6700 AA, Wageningen, the Netherlands
b Wageningen Food and Biobased Research, Wageningen University, P.O. Box 17, 6700 AA, Wageningen, the Netherlands
c Laboratory of Microbiology, Wageningen University, 6708 WE, Wageningen, the Netherlands
d Farmless, 1068KL, Amsterdam, the Netherlands
e Acies Bio d.o.o., Tehnološki Park 21, SI-1000 Ljubljana, Slovenia
A R T I C L E I N F O
Keywords:
Single cell protein
Gram-negative bacteria
Meat analogue
Shear cell
Functional properties
Future food
A B S T R A C T
There is an ongoing search for sustainable and functional alternative protein sources to animal proteins. Meth-
ylobacillus flagellatus (grown on renewable methanol) is known to give high protein yields with low resource
requirements. However, the techno-functionality for food applications has not yet been explored. In this study,
the biomass was processed by microfluidizer, centrifugation and acid precipitation. Unprocessed biomass (UB:
protein content of 73 %) and processed biomass fractions were investigated on their composition, physico-
chemical and rheological properties. All the biomass fractions had comparable composition, a pink, meat-like
colour and umami smell. Differences were observed in the rheological and structuring properties using shear
cell: UB yielded layered but crumbly structure, while the acid precipitated fraction resulted in a firm consistent
product. From a functional point of view, M. flagellatus is a promising protein source that can be used for meat
analogues without extensive prior fractionation.
1. Introduction
Due to the increasing global demand for high-quality protein and the
simultaneous growing awareness among consumers that the dispro-
portionate consumption of meat proteins is not sustainable, there is
growing interest in the search for alternative protein sources. Plant
proteins are promising, but often have deficiencies in functionality and
sensory characteristics that limit their application for imitating the meat
and dairy products (Kyriakopoulou et al., 2021). Recently, so-called
single cell protein or cellular protein have been described as potential
alternatives for plant proteins. In this category, fungi (e.g. Quorn™),
yeast and bacteria are investigated, and some cases already commer-
cialized for their protein yield, composition, and functional properties as
food ingredient (Kyriakopoulou et al., 2021; Nyyssölä et al., 2022; Ritala
et al., 2017). However, while these are usually grown on glucose (for
example from maize or sugar beet), growing bacteria on renewable
methanol could be an alternative approach avoiding the dependence on
crops as substrate (Cotton et al., 2020; Leger et al., 2021; Sakarika et al.,
2022). Methanol is a promising feedstock that can be made renewable
from CO2, water, and electricity. Energy-efficient processes for pro-
duction of e-methanol, using hydrogen from water electrolysis as in-
termediate, are already developed and currently being scaled-up
industrially (IRENA and Methanol Institute, 2021). In addition, meth-
anol can be renewably made from residual waste biomass and municipal
solid waste, as these waste streams can be gasified and the generated
syngas can be converted into bio-methanol.
M. flagellatus is a promising obligate methylotroph Gram-negative
strain with high protein content. It was selected as a prospective in-
dustrial strain due to its high growth rates and yields (Kruis et al., 2022).
However, its compositional and functional properties for food applica-
tions have not been explored yet. One of the challenges of using mi-
crobial biomass for food is their high nucleic acid content. This is a
concern because the ingestion of purine compounds derived from RNA
degradation increases plasma uric acid concentrations, which can cause
gout and kidney stones (Anaizi, 2023).
* Corresponding author.
E-mail address: julia.keppler@wur.nl (J.K. Keppler).
Contents lists available at ScienceDirect
Food Hydrocolloids
journal homepage: www.elsevier.com/locate/foodhyd
https://doi.org/10.1016/j.foodhyd.2024.109832
Received 19 November 2023; Received in revised form 20 January 2024; Accepted 29 January 2024
mailto:julia.keppler@wur.nl
www.sciencedirect.com/science/journal/0268005X
https://www.elsevier.com/locate/foodhyd
https://doi.org/10.1016/j.foodhyd.2024.109832
https://doi.org/10.1016/j.foodhyd.2024.109832
https://doi.org/10.1016/j.foodhyd.2024.109832
http://crossmark.crossref.org/dialog/?doi=10.1016/j.foodhyd.2024.109832&domain=pdf
http://creativecommons.org/licenses/by/4.0/
Food Hydrocolloids 151 (2024) 109832
2
The aim of the present study is to screen the composition, physico-
chemical, rheological, and texturing properties of unprocessed
M. flagellatus biomass and its derived fractions. We hypothesize that
these properties of the unprocessed microbial biomass and its derived
fractions are influenced by the different processing steps and thus have
different potential for food applications. Besides the above-mentioned
analysis, microbial safety assessment for human consumption is also
one of the main challenges for the food application, which is not part of
this study. M. flagellatus is not known to be pathogenic, but it has not
been tested and approved for food application yet. In this study we
focussed on the compositional and techno-functional characterization of
this bacterium for food applications.
The Gram-negative bacteria cell wall is mainly composed of a lipo-
polysaccharide membrane (Kim et al., 2005). The cell wall can be
fractured by high-pressure homogenization (Gomes et al., 2020),
yielding disrupted biomass (DB) displaying potentially different prop-
erties than the reference “unprocessed” (washed, frozen and thawed)
biomass (UB). High speed centrifugation is overall capable of generate
an insoluble pellet fraction (IF) which is rich in bacteria cells and a
soluble supernatant fraction (SF), which have different properties
potentially. Finally, isoelectric precipitation (using acid) is often used as
a method to recover soluble protein from plant and microalgae (la Cour
et al., 2019; Veide Vilg & Undeland, 2017), and it is of interest to test if
this also holds true for microbial protein. Thus, the acid-insoluble
fraction (AIF) was produced by acid precipitation of the soluble frac-
tion SF.
All fractions will be characterized with respect to composition
including nucleic acid content, amino acid profile, nitrogen conversion
factor, physicochemical-, and rheological properties. The results of the
latter will be discussed comparatively with results from similar analyses
reported in literature for various plant protein fractions to give a rough
estimation on similarities and difference. Then the UB and the most-
intensively processed fraction AIF, as well as soy protein concentrate,
being an often used bulk ingredient for meat analogues as reference, are
treated in the shear cell to test their ability to form a fibrous texture to
understand the potential of those biomasses for use in meat analogue-
like products.
2. Material and methods
2.1. Materials
HCl and NaOH were obtained from Sigma-Aldrich (St Louis, MO,
USA). Ultrapure water was obtained by purifying tap water with a Milli-
Q Lab Water System (Milli-QM., Keppler, J. K., & van der Goot, A. J. (2021).
Assessing functional properties of rapeseed protein concentrate versus isolate for
food applications. Innovative Food Science & Emerging Technologies, 68(February),
Article 102636. https://doi.org/10.1016/j.ifset.2021.102636
Jia, W., Sethi, D. S., van der Goot, A. J., & Keppler, J. K. (2022). Covalent and non-
covalent modification of sunflower protein with chlorogenic acid: Identifying the
critical ratios that affect techno-functionality. Food Hydrocolloids, 131(May), Article
107800. https://doi.org/10.1016/j.foodhyd.2022.107800
Jiang, W., Saxena, A., Song, B., Ward, B. B., Beveridge, T. J., & Myneni, S. C. B. (2004).
Elucidation of functional groups on gram-positive and gram-negative bacterial surfaces
using infrared spectroscopy. https://doi.org/10.1021/LA049043
Kalyuzhnaya, M. G., C Beck, D. A., Vorobev, A., Smalley, N., Kunkel, D. D.,
Lidstrom, M. E., & Chistoserdova, L. (2012). Novel methylotrophic isolates from lake
sediment, description of Methylotenera versatilis sp. nov. and emended description
of the genus Methylotenera. International Journal of Systematic and Evolutionary
Microbiology, 62, 106–111. https://doi.org/10.1099/ijs.0.029165-0
Kim, S., Reuhs, B. L., & Mauer, L. J. (2005). Use of Fourier transform infrared spectra of
crude bacterial lipopolysaccharides and chemometrics for differentiation of
Salmonella enterica serotypes. Journal of Applied Microbiology, 99(2), 411–417.
https://doi.org/10.1111/j.1365-2672.2005.02621.x
Kornet, R., Veenemans, J., Venema, P., van der Goot, A. J., Meinders, M., Sagis, L., & van
der Linden, E. (2021). Less is more: Limited fractionation yields stronger gels for pea
proteins. Food Hydrocolloids, 112, Article 106285. https://doi.org/10.1016/j.
foodhyd.2020.106285
Kornet, C., Venema, P., Nijsse, J., van der Linden, E., van der Goot, A. J., & Meinders, M.
(2020). Yellow pea aqueous fractionation increases the specific volume fraction and
viscosity of its dispersions. Food Hydrocolloids, 99. https://doi.org/10.1016/j.
foodhyd.2019.105332
Kruis, A. J., Virant, D., Horvat, J., Nagode, T., & Fujs, S. (2022). Genetically modified
methylobacillus bacteria having improving properties.
Kyriakopoulou, K., Keppler, J. K., & Van Der Goot, A. J. (2021). Functionality of
ingredients and additives in plant-based meat analogues. Foods, 10, 9147. https://
doi.org/10.3390/foods10030600. https://www.avebe.com/vegan-meat-ana
logues-2/
laCour, R., Schjoerring, J. K., & Jørgensen, H. (2019). Enhancing protein recovery in
green biorefineries by lignosulfonate-assisted precipitation. Frontiers in Sustainable
Food Systems, 3. https://doi.org/10.3389/fsufs.2019.00112
Leger, D., Matassa, S., Noor, E., Shepon, A., Milo, R., & Bar-Even, A. (2021).
Photovoltaic-driven microbial protein production can use land and sunlight more
efficiently than conventional crops. Proceedings of the National Academy of Sciences of
the United States of America, 118(26). https://doi.org/10.1073/pnas.2015025118
Liu, C., Teng, Z., Lu, Q. Y., Zhao, R. Y., Yang, X. Q., Tang, C. H., & Liao, J. M. (2011).
Aggregation kinetics and ζ-potential of soy protein during fractionation. Food
Research International, 44(5), 1392–1400. https://doi.org/10.1016/J.
FOODRES.2011.01.054
Lorv, J. S. H., Rose, D. R., & Glick, B. R. (2014). Bacterial ice crystal controlling proteins.
https://doi.org/10.1155/2014/976895.
Mackey, B. M., Miles, C. A., Parsons, S E, & Seymour, D. A. (1991). Thermal denaturation
of whole cells and cell components of Escherichia coli examined by differential
scanning calorimetry. Journal of General Microbiology, 137, 2361–2374.
Mahapatra, S., Banerjee, D., & Banerjee, M. (2013). Fungal exopolysaccharide:
Production, composition and applications. Microbiology Insights, 6. https://doi.org/
10.4137/MBI.S10957. –7.
Möller, A. C., van der Padt, A., & van der Goot, A. J. (2021). From raw material to mildly
refined ingredient – linking structure to composition to understand fractionation
processes. Journal of Food Engineering, 291. https://doi.org/10.1016/j.
jfoodeng.2020.110321
Moreno, H. M., Domínguez-Timón, F., Díaz, M. T., Pedrosa, M. M., Borderías, A. J., &
Tovar, C. A. (2020). Evaluation of gels made with different commercial pea protein
isolate: Rheological, structural and functional properties. Food Hydrocolloids, 99.
https://doi.org/10.1016/J.FOODHYD.2019.105375
Mosharaf, M. K., Tanvir, M. Z. H., Haque, M. M., Haque, M. A., Khan, M. A. A.,
Molla, A. H., Alam, M. Z., Islam, M. S., & Talukder, M. R. (2018). Metal-adapted
bacteria isolated from wastewaters produce biofilms by expressing proteinaceous
curli fimbriae and cellulose nanofibers. Frontiers in Microbiology, 9(JUN), 1–17.
https://doi.org/10.3389/fmicb.2018.01334
Nicolaou, N., Xu, Y., & Goodacre, R. (2010). Fourier transform infrared spectroscopy and
multivariate analysis for the detection and quantification of different milk species.
W. Jia et al.
https://doi.org/10.1016/j.foodhyd.2024.109832
https://doi.org/10.1016/j.foodhyd.2024.109832
https://doi.org/10.1055/S-0043-1770929
https://doi.org/10.1055/S-0043-1770929
https://doi.org/10.3390/NU12041115
https://doi.org/10.1016/j.copbio.2019.10.002
https://doi.org/10.2166/wst.2016.473
https://doi.org/10.1016/J.WATRES.2017.12.058
https://doi.org/10.1016/J.WATRES.2017.12.058
https://doi.org/10.1016/j.foodhyd.2022.108059
https://doi.org/10.1080/10826068.2020.1728696
https://doi.org/10.3390/MD20040227
https://doi.org/10.1016/j.jfoodeng.2016.05.010
https://doi.org/10.1016/j.jfoodeng.2016.05.010
https://doi.org/10.1016/J.FOODCHEM.2022.135069
https://doi.org/10.1186/s40064-015-1476-7
https://doi.org/10.1186/s40064-015-1476-7
https://doi.org/10.1007/s11483-021-09686-8
https://doi.org/10.1007/s11483-021-09686-8
https://doi.org/10.1128/JB.00512-10
https://doi.org/10.1016/J.FOODHYD.2013.07.017
https://doi.org/10.1016/J.FOODHYD.2013.07.017
https://www.irena.org/publications/2021/Jan/Innovation-Outlook-Renewable-Methanol
https://www.irena.org/publications/2021/Jan/Innovation-Outlook-Renewable-Methanol
https://doi.org/10.1016/j.ifset.2021.102636
https://doi.org/10.1016/j.foodhyd.2022.107800
https://doi.org/10.1021/LA049043
https://doi.org/10.1099/ijs.0.029165-0
https://doi.org/10.1111/j.1365-2672.2005.02621.x
https://doi.org/10.1016/j.foodhyd.2020.106285
https://doi.org/10.1016/j.foodhyd.2020.106285
https://doi.org/10.1016/j.foodhyd.2019.105332
https://doi.org/10.1016/j.foodhyd.2019.105332
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref22
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref22
https://doi.org/10.3390/foods10030600
https://doi.org/10.3390/foods10030600
https://www.avebe.com/vegan-meat-analogues-2/
https://www.avebe.com/vegan-meat-analogues-2/
https://doi.org/10.3389/fsufs.2019.00112
https://doi.org/10.1073/pnas.2015025118
https://doi.org/10.1016/J.FOODRES.2011.01.054
https://doi.org/10.1016/J.FOODRES.2011.01.054
https://doi.org/10.1155/2014/976895
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref28
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref28
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref28
https://doi.org/10.4137/MBI.S10957
https://doi.org/10.4137/MBI.S10957
https://doi.org/10.1016/j.jfoodeng.2020.110321
https://doi.org/10.1016/j.jfoodeng.2020.110321
https://doi.org/10.1016/J.FOODHYD.2019.105375
https://doi.org/10.3389/fmicb.2018.01334
Food Hydrocolloids 151 (2024) 109832
15
Journal of Dairy Science, 93(12), 5651–5660. https://doi.org/10.3168/jds.2010-
3619
Nyyssölä, A., Suhonen, A., Ritala, A., & Oksman-Caldentey, K. M. (2022). The role of
single cell protein in cellular agriculture. Current Opinion in Biotechnology, 75, 1–7.
https://doi.org/10.1016/j.copbio.2022.102686
Pace, C. N., Grimsley,G. R., & Scholtz, J. M. (2009). Protein ionizable groups: pK values and
their contribution to protein stability and solubility *. https://doi.org/10.1074/jbc.
R800080200
Peng, Y. (2021). Soy fractionation pathways for food applications.
Peng, Y., Kersten, N., Kyriakopoulou, K., & van der Goot, A. J. (2020). Functional
properties of mildly fractionated soy protein as influenced by the processing pH.
Journal of Food Engineering, 275, Article 109875. https://doi.org/10.1016/j.
jfoodeng.2019.109875
Peters, J. (2016a). Water-binding of protein particles. In PhD thesis. https://doi.org/
10.1017/CBO9781107415324.004
Peters, J. (2016b). Water-binding of protein particles. In PhD thesis. https://doi.org/
10.1017/CBO9781107415324.004
Ritala, A., Häkkinen, S. T., Toivari, M., & Wiebe, M. G. (2017). Single cell protein-state-
of-the-art, industrial landscape and patents 2001-2016. Frontiers in Microbiology, 8
(OCT). https://doi.org/10.3389/fmicb.2017.02009
Sakarika, M., Ganigué, R., & Rabaey, K. (2022). Methylotrophs: From C1 compounds to
food. Current Opinion in Biotechnology, 75, 1–8. https://doi.org/10.1016/j.
copbio.2022.102685
Schröder, A., Sprakel, J., Schroën, K., & Berton-Carabin, C. C. (2017). Tailored
microstructure of colloidal lipid particles for Pickering emulsions with tunable
properties. Soft Matter, 13(17), 3190–3198. https://doi.org/10.1039/c6sm02432g
Tanger, C., Müller, M., Andlinger, D., & Kulozik, U. (2022). Influence of pH and ionic
strength on the thermal gelation behaviour of pea protein. Food Hydrocolloids, 123.
https://doi.org/10.1016/J.FOODHYD.2021.106903
Van De Velde, F., De Hoog, E. H. A., Oosterveld, A., & Tromp, R. H. (2015). Protein-
polysaccharide interactions to alter texture. Annual Review of Food Science and
Technology, 6, 371–388. https://doi.org/10.1146/annurev-food-022814-015558
Veide Vilg, J., & Undeland, I. (2017). pH-driven solubilization and isoelectric
precipitation of proteins from the brown seaweed Saccharina latissima—effects of
osmotic shock, water volume and temperature. Journal of Applied Phycology, 29(1),
585–593. https://doi.org/10.1007/s10811-016-0957-6
Volova, T. G., & Barashkov, V. A. (2010). Characteristics of proteins synthesized by
hydrogen-oxidizing microorganisms. Applied Biochemistry and Microbiology, 46(6),
574–579. https://doi.org/10.1134/S0003683810060037
Waghmare, A. G., Salve, M. K., LeBlanc, J. G., & Arya, S. S. (2016). Concentration and
characterization of microalgae proteins from Chlorella pyrenoidosa. Bioresources and
Bioprocessing, 3(1), 1–11. https://doi.org/10.1186/S40643-016-0094-8/FIGURES/8
Yang, J., Zamani, S., Liang, L., & Chen, L. (2021). Extraction methods significantly
impact pea protein composition, structure and gelling properties. Food Hydrocolloids,
117. https://doi.org/10.1016/J.FOODHYD.2021.106678
Zając, M., Kotyńska, J., Zambrowski, G., Breczko, J., Deptuła, P., Cieśluk, M.,
Zambrzycka, M., Święcicka, I., Bucki, R., & Naumowicz, M. (2023). Exposure to
polystyrene nanoparticles leads to changes in the zeta potential of bacterial cells.
Scientific Reports, 13(1). https://doi.org/10.1038/s41598-023-36603-5
W. Jia et al.
https://doi.org/10.3168/jds.2010-3619
https://doi.org/10.3168/jds.2010-3619
https://doi.org/10.1016/j.copbio.2022.102686
https://doi.org/10.1074/jbc.R800080200
https://doi.org/10.1074/jbc.R800080200
http://refhub.elsevier.com/S0268-005X(24)00106-1/sref36
https://doi.org/10.1016/j.jfoodeng.2019.109875
https://doi.org/10.1016/j.jfoodeng.2019.109875
https://doi.org/10.1017/CBO9781107415324.004
https://doi.org/10.1017/CBO9781107415324.004
https://doi.org/10.1017/CBO9781107415324.004
https://doi.org/10.1017/CBO9781107415324.004
https://doi.org/10.3389/fmicb.2017.02009
https://doi.org/10.1016/j.copbio.2022.102685
https://doi.org/10.1016/j.copbio.2022.102685
https://doi.org/10.1039/c6sm02432g
https://doi.org/10.1016/J.FOODHYD.2021.106903
https://doi.org/10.1146/annurev-food-022814-015558
https://doi.org/10.1007/s10811-016-0957-6
https://doi.org/10.1134/S0003683810060037
https://doi.org/10.1186/S40643-016-0094-8/FIGURES/8
https://doi.org/10.1016/J.FOODHYD.2021.106678
https://doi.org/10.1038/s41598-023-36603-5
	Renewable methanol utilizing bacteria as future meat analogue: An explorative study on the physicochemical and texturing pr ...
	1 Introduction
	2 Material and methods
	2.1 Materials
	2.2 Methods
	2.2.1 Biomass generation
	2.2.2 Fractionation and sample preparation
	2.2.3 Compositional analysis
	2.2.4 Biomass cell integrity
	2.2.5 Protein characterization
	2.2.5.1 Molecular weight distribution
	2.2.5.2 Protein secondary structure
	2.2.5.3 Thermograms
	2.2.5.4 Zeta potential and conductivity
	2.2.5.5 Water holding capacity and biomass solubility
	2.2.5.6 Colour
	2.3 Structuring properties
	2.3.1 Rheological properties
	2.3.2 Rheological properties with closed cavity rheometer
	2.3.3 Structure formation
	3 Result and discussion
	3.1 Appearance and colour
	3.2 Composition analysis
	3.2.1 Composition and amino acid profile
	3.2.2 Protein molecular weight profile
	3.2.3 Fraction composition and protein secondary structure
	3.3 Physico-chemical properties
	3.3.1 Thermograms by differential scanning calorimetry (DSC)
	3.3.2 Zeta potential and conductivity
	3.3.3 Water holding capacity
	3.4 Structuring properties
	3.4.1 Rheological properties with Discovery Hybrid Rheometer
	3.4.2 Rheological properties by closed cavity rheometer (CCR)
	4 The potential of using M. flagellatus for making meat analogue product
	5 Conclusion
	CRediT authorship contribution statement
	Declaration of competing interest
	Data availability
	Acknowledgement
	Appendix A Supplementary data
	ReferencesIQ 7000 Ultrapure Lab Water System,
Merck KGaA, Darmstadt, Germany).
2.2. Methods
2.2.1. Biomass generation
M. flagellatus OCB6 was modified to reduce the viscosity of the broth
by deleting the genes responsible for exopolysaccharide formation
(Kruis et al., 2022) using methods described by Hendrickson et al.
(2010).
The biomass of M. flagellatus was prepared by Acies Bio (Ljubljana,
Slovenia) in 5 L lab-scale bioreactors (Sartorius) in fed-batch mode. A
mineral medium containing KH2PO4, Na2HPO4, MgSO4, NH4SO4 and a
trace element mixture was used. Methanol concentration was dynami-
cally maintained at 4–5 g/L throughout the cultivations via a feedback
loop using an online methanol sensor. The pH was kept at 7 by automatic
addition of ammonium hydroxide, which also served as source of ni-
trogen. The aeration rate was contolled at 2.0 VVM (volume air per
volume of liquid per minute) with ambient air. The stirring speed was
automatic regulated to maintain dissolved oxygen at 30 % during the
first 10 h of growth, with a max speed of 1500 rpm. Once dry cell weight
reached around 5 g/L, oxygen became limiting and max stirring was
maintained till the end of the process. After the culture reached the
stationary phase, the biomass was harvested by centrifugation, and
washed twice with distilled water. The final wet pellet obtained after
washing was stored at − 80 ◦C.
2.2.2. Fractionation and sample preparation
The fractionation process of the biomass was performed in two
batches and is depicted in Fig. 1. The so called ‘unprocessed’ thawed
biomass (UB) was taken as starting material, which was treated by ho-
mogenization, centrifugation, acid precipitation, and neutralization. For
this, the 300 g UB was evenly distributed into four centrifugal bottles
(1L) and Milli-Q water was added to reach a dilution factor of 10. To
mitigate the viscous nature of the biomass, it was dispersed in water
using a rotor-stator homogenizer (Ultra-Turrax IKA T18 basic, Germany)
at a high speed of 10,000 rpm for approximately 30s. The method was
adapted from a previous method reported by (Schröder et al., 2017).
To stress the bacterial cell wall for a better release of protein, the
dispersion was homogenized at 600 bar with a high-pressure homoge-
nizer to produce the so called ‘disrupted biomass’ (DB) (Microfluidizer®
Processor MF 110Y with Y-shaped interaction chamber, F12Y; min. in-
ternal channel: 75 μm), (Microfluidics, Newton, Massachusetts, USA).
DB was further centrifuged at 20,000 g for 30 min and the soluble su-
pernatant was collected and named as ‘soluble fraction’ (SF), while the
pellet fraction was denoted as ‘insoluble fraction’ (IF).
To test if the proteins can be further concentrated, acid precipitation
was conducted with the SF. The highest protein recovery yield was
achieved by acid precipitation at pH 4 (pH values between 2 and 6 were
tested). Thus, acid precipitation was performed at pH 4 by adding 1M of
HCl to the supernatant and the dispersion was mixed with a magnetic
stirrer at 700 rpm. Afterward, the dispersion was centrifuged at 10,000 g
for 10 min and the supernatant was freeze-dried for a mass balance
calculation. The recovered pellet was redispersed into Milli-Q water to
create a solution, which was stirred with a magnet at 700 rpm for 1 h and
the pH was readjusted to 7 by adding 1 M NaOH. The solution named
acid-insoluble fraction (AIF). All fractions (UB, DB, SF, IF and AIF) were
collected and freeze-dried for a mass balance calculation and further
analysis.
Abbreviation
AA Amino acid
AIF Acid insoluble fraction
ATR-FTIR Attenuated-total-reflection Fourier Transform Infrared
C1 One carbon
CCR Closed cavity rheometer
CLSM Confocal laser scanning microscope
DB Disrupted biomass
DHR Discovery Hybrid Rheometer
DSC Differential scanning calorimetry
IF Insoluble fraction
MW Molecular weight
NCF Nitrogen conversion factor
PPI Pea protein isolate
SDS-PAGE Sodium dodecyl sulphate polyacrylamide gel
electrophoresis
SF Soluble fraction
SPC Soy protein concentrate
UB Unprocessed biomass
WHC Water holding capacity
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
3
2.2.3. Compositional analysis
The fat content of freeze-dried UB, DB, SF, IF and AIF was deter-
mined with the AACC 30–25.01 method, and ash content was measured
with the AACC 08-01 method. The soluble and the total nucleotides were
analysed by NovoCIB (France).
The full amino acid profile of the UB, IF and AIF including cysteine
and tryptophan was analysed by Eurofins (The Netherlands): with the
ISO 13903:2005; EU 152/2009 (F) method. The total amino acid content
corresponds to the protein content of the sample. The nitrogen conver-
sion factor (NCF) for UB, IF and AIF was calculated as 5.35, 5.17 and
5.06 based on the results of full amino acid profile. The same NCF of UB
(5.35) was assumed for DB as there is no composition change expected
during high-pressure homogenization. This NCF was also used for pro-
tein determination in SF, although it is expected to have a slightly higher
NCF value than 5.35.
Further, the total nitrogen content of the freeze-dried biomass frac-
tions was determined with the Dumas combustion method using a Ni-
trogen Analyzer (Flash EA 1112 Series, Thermo Scientific, The
Netherlands), and protein concentrations were derived by the above
mentioned NCF. The carbohydrate content of the biomass was calcu-
lated by the difference of ash, fat, protein, and nucleotides content.
2.2.4. Biomass cell integrity
To study the effect of freeze-drying on the biomass, a confocal laser
scanning microscope (CLSM) (type 510; Zeiss, Oberkochen, Germany)
was used to visualize the original as well as the freeze-dried UB. A
mixture of 2 different staining dyes was used: 0.2 wt % Rhodamine-B
(Rh-b) and 0.2 wt % of Bodipy for protein and fat staining respec-
tively. Excitation light in CLSM was provided by two lasers: a HeNe laser
at 501 nm for Rhodamine B and 580 nm for Bodipy. Stained samples
were mixed with a toothpick and left at 4 ◦C for about 2h prior to im-
aging. A 10 × EC Plan-Neofluar/0.5 objective lens was used to take the
images. The ZEN software (Carl Zeiss Microscopy, Jena, Germany) was
used to analyse the images.
2.2.5. Protein characterization
2.2.5.1. Molecular weight distribution. The protein molecular weight
distribution of the freeze-dried UB, DB, SF, IF and AIF was determined
using sodium dodecyl sulphate polyacrylamide gel electrophoresis (SDS-
PAGE) as previously described (Jia et al., 2021). A protein solution of
approximately 2 mg/mL was prepared in a falcon tube. The sample
buffer (0.125M Tris/HCL buffer pH 6.8 containing 4 % w/v SDS, 40 %
w/v glycerol, 0.02 % bromophenol blue) was diluted in a ratio of 1:1
with 0.9 % NaCl-solution for the non-reduced samples and for the
reduced samples β-mercaptoethanol was added in a concentration of 5
%. The samples were suspended in sample buffer in a concentration of
2.75 mg/ml sample buffer, vortexed and then heated for 30 min at 95 ◦C.
In total 20 μL clear supernatant after centrifugation (15,000 g, 15 min)
was loaded onto the gel. The experiment was performed at 200 V for 30
min. Subsequently, the gels were stained with Coomassie Blue solution.
Destaining was performed overnight using a water-methanol-acetic acid
solution with an 80/10/10 % v/v ratio. The gel was scanned with a gel
scanner (Biorad-GS900, Netherlands).
2.2.5.2. Protein secondary structure. The protein secondary structure of
the freeze-dried UB, DB, SF, IF and AIF was measured using a Fourier
Transform Infrared (FTIR) spectrometer with a thermally controlled Bio
ATR2 unit at 25 ◦C and a nitrogen cooled MCT detector (Confocheck™
system, BrukerOptics, Ettlingen, Germany) (Jia et al., 2022). A 2 % w/w
protein solution was prepared by adding the freeze-dried powder to 5
mL Milli-Q water, followed by vortexing to allow full hydration. In-
terferograms were accumulated over the spectral range 4000-400 cm− 1,
with a resolution of 4 cm− 1. In total 60 scans at a resolution of 0.7 cm− 1
were conducted. Independent duplicates with 20 μL of the sample were
loaded into the cell for measurements. For evaluation of protein sec-
ondary structure, the measured spectra of the amide band І region
(1580-1700 cm− 1) were vector-normalized using the Bruker OPUS
software system (8.25, Ettlingen, Germany). The second derivative was
calculated using 9 smoothing points. Besides, the whole spectra without
normalization between 4000 and 900 cm− 1 were compared for each
fraction.
2.2.5.3. Thermograms. The thermal stability of freeze-dried UB, DB, SF,
IF and AIF were analysed with differential scanning calorimetry (DSC)
(TA instrument 250; TA Instruments, Newcastle, DE, USA). Approxi-
mately 8 mg of the sample was weighed in a high-volume pan and 32 μL
of Milli-Q water was added. The pan was sealed and heated from 25 to
130 ◦C using a heating rate of 5 ◦C/min. After 1 min, the pan was cooled
down to 25 ◦C using a cooling rate of 20 ◦C/min. This heating and
cooling process was repeated for a second time to make sure the peak
indicated protein denaturation. Duplicates were measured for each
sample. The onset denaturation temperature (onset Td), the peak tem-
perature of denaturation (Td), and the denaturation enthalpy (J/g
Fig. 1. The scheme of biomass fractionation, including total and protein mass balance. UB, raw biomass; DB, disrupted biomass; SF, soluble fraction; IF, Pellet
insoluble fraction; AIF, acid insoluble fraction. The mass balance was also expressed as total mass by dry matter (g DM/100g UB in DM), and total protein (g protein
DM/100g UB in DM). The mass balance of each fraction was all originated from the initial raw material UB.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
4
biomass) were collected by Trios data analysis software (TA
Instruments).
2.2.5.4. Zeta potential and conductivity. The zeta potential of the freeze-
dried biomass UB, DB, SF, IF and AIF was measured as described by
(Narong & James, 2006) using Zetasizer Nano ZS (Malvern Instruments
Ltd., Malvern, Worcestershire, UK). The 2 % w/w solutions of the
biomass were diluted approximately 100 times. The measurements were
performed at 25 ◦C and the results were expressed as the average from
measurements of two independent samples. The pH and conductivity
were measured after overnight mixing using the Multi-Parameter Meter
(HQ440D laboratory Dual Input, the Netherlands).
2.2.5.5. Water holding capacity and biomass solubility. The amount of
soluble dry matter and the water holding capacity (WHC) of the insol-
uble matter was measured based on an adapted method reported earlier
(Möller et al., 2021). A 4 % w/w dispersion of the freeze-dried fractions
UB, DB, SF, IF and AIF was made in a falcon tube by adding 0.4 g of the
powder into 10 g of Milli-Q water. The samples were vortexed for 1 min
and rotated overnight with a roller table. The pH value of all the frac-
tions was in between 6.2 and 6.3. Afterward, the samples were centri-
fuged at 4000 g for 30 min. The supernatant and the pellet were
transferred into an aluminum tray and dried in an oven at 105 ◦C (Model
E28, Binder, Germany) for at least 16 h. The weight of the pellet before
(Mwet pellet) and after freeze drying (Mdry pellet) was measured. The dry
masses of the original sample Moriginal and of the supernatant Msupernatant
were measured. The WHC of the dry pellet and the solubility were
calculated according to equations (1) and (2), respectively:
WHC
(
g water
g dry pellet
)
=
Mwet pellet − Mdry pellet
Mdry pellet
(1)
Solubility (%)=
Msupernatant
Moriginal
(2)
2.2.5.6. Colour. The colour of UB, DB, SF, IF and AIF was measured
with ColourFlexEZ (HunterLab) and the software of Easymatch QC for
the data analysis. Approximately 5g of the sample were loaded onto the
colour meter, and all measurements were performed in duplicates.
2.3. Structuring properties
2.3.1. Rheological properties
Dispersions of 15 wt % concentration (dry matter) were prepared
from the freeze-dried UB, DB, SF, IF and AIF. The viscosity was deter-
mined by a Discovery Hybrid Rheometer (DHR) (TA instrument, The
Netherlands) combined with a Peltier Concentric Cylinders and a solvent
trap (grooved bob with 14 mm diameter). A flow sweep was applied to
the dispersions at 20 ◦C from 0.1 to 100 s− 1 to measure the viscosity.
Afterward, a temperature sweep was performed by increasing the
temperature from 20 to 95 ◦C at a rate of 5 ◦C/min, followed by a
holding time of 5 min at 95 ◦C before cooling down to 20 ◦C at a rate of
3 ◦C/min. The storage (G′) and loss modulus (G″) were recorded as a
function of time. Subsequently, the heated samples were further exposed
to an amplitude sweep from 0.1 to 100 % (at a frequency of 1 Hz). The
storage (G′) and loss modulus (G″) dependency on strain were recorded.
2.3.2. Rheological properties with closed cavity rheometer
Viscoelastic properties were measured with a Closed Cavity
Rheometer device (CCR) (RPA elite, TA instruments, USA). Approxi-
mately 2 g of the sample powder was mixed with Milli-Q water and a
total mass of 5 g sample (40 % DM) was made. Besides, a comparison
was made for UB, SF and AIF by adding 1 % salt to the Milli-Q water
before mixing with the sample to understand the effect of salt on the
rheological properties. After 30 min hydration time, the samples were
then placed in between two plastic foils in the closed cavity (disk
geometry). A pressure of 4 bars was applied to prevent water evapora-
tion. The complex modulus (G*) was calculated by the software based on
the measured storage modulus (G′) and loss modulus (G″). Due to the
limitation of the sample availability, the measurement was performed
only once.
2.3.3. Structure formation
Structure formation was only tested for freeze-dried UB and AIF
fractions (60 g for each fraction) because they represent the lowest and
the highest processed fractions. A high-temperature conical shear cell
(HTSC) (Wageningen University, Wageningen, the Netherlands) was
used for the structuring experiments (Grabowska et al., 2016). Heating
and cooling were performed using an external oil bath. A biomass
mixture of 40 wt % concentration was prepared by firstly mixing 0.9 g
sodium chloride and 53.1 g demineralized water. Then the 36 g sample
(dry matter) was mixed with water, and subsequently hydrated for 30
min. Afterward, the hydrated sample was transferred to the preheated
HTSC and then sheared at 30 rpm at 140 ◦C for 15 min.
3. Result and discussion
Unprocessed biomass of M. flagellatus and the various fractions
derived from it were characterized with respect to their physicochemical
and rheological properties, to evaluate their potential use for food
applications.
3.1. Appearance and colour
To assess whether freezing and freeze-drying already affected the
integrity of the cell wall, the wet unprocessed biomass (UB) was
compared before and after freeze-drying: the protein (red colour) and fat
(yellow colour) distribution for the untreated biomass and freeze-dried
UB was investigated using CLSM (Fig. 2).
Large numbers of rod-like particles can be identified for the un-
treated biomaterial at 10 μm scale (Fig. 2 A2, B2), which are most likely
the bacteria cells, since the methylotrophic bacteria have a rod-shape
(Kalyuzhnaya et al., 2012). However, it is hard to distinguish between
protein and fat, because thecolour of the particles was in between red
and yellow. This indicates that both protein and lipids are present in
these particles and likely still located within the cell. After freeze-drying,
the individual rod-like particles were less visible, and the CLSM image
was dominated with red colour (proteins) and some yellow particles
(fat). This suggests that some of the individual cells in UB are broken
after freezing, freeze-drying or resuspension, which released the protein
and fat from the rod-like bacteria. The fat coalesced after release and
formed domains that were larger than the original microbe. It is known
that the freezing and thawing rate without cryoprotectants can affect
bacteria cells, because intracellular ice crystals being formed upon
freezing can rupture cells either physically or through osmotic pressure
changes (Lorv et al., 2014). Because all samples obtained during frac-
tionation were similarly frozen, freeze-dried, and resuspended, it can be
assumed that this will have influenced the cell wall integrity of all
samples similarly and that differences can be ascribed to their individual
processing history.
Next to the cell wall integrity, also the colour of the samples was
analysed: The colour intensities of all fractions were similar except for
the lowest lightness with AIF fraction (Supplementary Fig. S1). All
fractions had a pinkish hue. The results confirmed that the difference in
appearance between the fractions was small and not significantly
affected by fractionation. This means that the colour was not caused by
pigments with specific properties that might have accumulated specif-
ically in the soluble or the insoluble fraction.
W. Jia et al.
https://www.hach.com/hq440d-laboratory-dual-input-multi-parameter-meter-ph-conductivity-optical-dissolved-oxygen-orp-and-ise/product?id=7640513839
Food Hydrocolloids 151 (2024) 109832
5
3.2. Composition analysis
3.2.1. Composition and amino acid profile
Table 1 shows the true protein content based on amino acid analysis,
ash, fat, total nucleotides, and rest (potentially carbohydrate) contents
of UB, DB, SF, IF and AIF. The corresponding amino acid analysis of the
protein fraction, which was also used to calculate the nitrogen conver-
sion factor for further analyses with Dumas, is shown in Table 2.
UB contained 73 % protein, 2 % fat, 5 % ash, 5 % soluble nucleotides
and 14 % others (potentially carbohydrates). A high protein content of
approximately 74 % dry mass has been reported for hydrogen-oxidizing
bacteria (Volova & Barashkov, 2010). However, in that study, a higher
lipid concentration of 6–9 % was observed, a lower carbohydrate con-
centration of 5–6 % and a higher DNA/RNA content of 12–13 %. These
differences could be caused by using different types of bacteria, but it is
also possible that different analysis methods were used. The protein
content in the biomass based on amino acid analysis (approx. 73 %
protein with NCF of 5.06 due to the presence of nucleotides) is com-
parable to commercial plant protein fractions, such as soy protein
concentrate (approx. 62 % with NCF of 5.7) and pea protein isolate
(approx. 69 % with NCF of 5.45) (Moreno et al., 2020; Peng, 2021).
Thus, further protein fractionation is likely not required for many food
applications that require a high protein content. However, different
processing methods were still applied to the UB to understand the
Fig. 2. CLSM micrographs of the biomass before freeze-drying at a scale of 40 μm (A1) and 10 μm (A2) and the freeze-dried UB at a scale of 40 μm (B1) and 10 μm
(B2). Red: proteins, Yellow: lipids. of freeze-dried powder from UB, DB, SF, IF and AIF fractions.
Table 1
The biomass composition with protein, carbohydrate, ash, and fat for UB, DB, SF, IF and AIF in dry matter (g/100g powder). The nitrogen to protein conversion factor
(NCF) was derived by amino acid analysis (Table 2) for UB, IF and AIF.
Composition Total Nitrogen g/
100g
Proteina g/
100g
Non-Protein Nitrogen g/
100g
NCF Fat g/
100g
Ash g/
100g
Total nucleotides g/100g
b
Carbohydrates g/
100gc
UB 13.7 ± 0.1 73.1 ± 0.3 1.6 5.35 2.0 ± 0.2 5.5 ± 0.4 5.0 14.4
DB 13.2 ± 0.3 69.8 ± 1.2 N.A 5.35 1.8 ±
0.01
5.4 ± 0.1 4.8 18.2
SF 13.4 ± 0.03 71.7 ± 0.8 N.A 5.35 2.1 ±
0.04
5.7 ± 0.3 5.3 15.4
IF 13.3 ± 0.3 67.0 ± 2.4 2.2 5.17 1.2 ±
0.01
4.7 ± 0.5 3.8 23.3
AIF 14.0 ± 0.2 70.9 ± 0.9 2.3 5.06 0.7 ± 0.1 5.0 ± 1.3 5.0 18.5
a Protein content of UB, IF and AIF was obtained from total amino acid analysis, thus it is true protein content.
b The soluble nucleotides were also measured for the fractions UB, DB, SF, AIF and IF as follows: 0.08, 0.08, 0.99, 0.11, 0.05 g/100g powder (dry matter). Due to the
sample limitation, only one measurement was obtained, thus no standard deviation was obtained.
c The carbohydrate content was calculated by the difference (mean value of each component was used).
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
6
influence of the processing steps on the composition (e.g. carbohydrates
and nucleotides) and on the functional properties of the biomass.
The various processing steps (Fig. 1) did not have a large effect on the
overall composition of the biomass. The protein content was around 70
g/100g for all fractions. The centrifugation of disrupted biomass (DB)
yielded two fractions: the insoluble fraction (IF) and the supernatant
fraction (SF). The lowest protein content of 67.0 g/100g was found for
the IF, whereas this fraction also had the highest carbohydrate content
(23.3 g/100g). Since the SF had a lower carbohydrate content of 15.4 g/
100g, it can be concluded that the centrifugation process removed 28 %
of carbohydrates from the DB (18.2 g/100g) into the IF (23.3 g/100g).
Since the supernatant fraction was slightly turbid, this large decrease
might have been caused by phase separation phenomena between the
different polymers present (Van De Velde et al., 2015), which could be
interesting to explore in future studies.
The slightly lower nucleotide content in the IF (3.8 g/100g) corre-
lates with the higher amount in the SF (5.7 g/100g). The fat content of
DB and SF was similar with approx. 2 g/100g, and acid precipitation of
SF resulted in a lower fat content of 0.7 g/100g in acid precipitated
fraction (AIF), which indicates that fat could be removed to a certain
extent by the acid precipitation process. The ash content was similar in
all samples.
Acid precipitation is a common method to purify protein from plant-
based materials, such as soy protein or pea protein (Peng, 2021; Yang
et al., 2021). Bacterial biomasses contain mainly ribosomal proteins and
enzymes, while plant seeds contain storage proteins (Hendrickson et al.,
2010). The remaining carbohydrates (or others) are most likely
composed of polysaccharides, even though this strain was modified to
reduce exopolysaccharide formation. Hower some exopolysaccharides
may still be attached to the cell material and may lead to higher viscosity
and are difficult to separate from the proteins just by acid precipitation
(Mahapatra et al., 2013). Identification of the type of carbohydrates
present could help to develop strategies for effective removal of (exo)
polysaccharide (in case their removal is necessary from a functional
point of view). Polysaccharides were reported to be extracted by ultra-
sound in combination with formamide and NaOH or various combina-
tions of ultrasound and heat (Dai et al., 2016).
The average amino acid(AA) composition for UB, IF and AIF is
shown in Table 2 alongside the composition of soy protein concentrate
(SPC), pea protein isolate (PPI) and casein for comparison. Overall, the
analysis revealed that all fractions had a well-balanced amino acid
profile, though they are somewhat low in cysteine, which was in line
with previous findings for other hydrogen-oxidizing, Gram-negative
bacteria (Nyyssölä et al., 2022; Volova & Barashkov, 2010). The nucleic
acid content varied slightly between 3.8 and 5 g/100 g. In the case of
mycoprotein, which is already used commercially for food, a reduction
from 10 to 2 g/100 g dry matter is achieved through post-processing, to
reach the 18 yrs
Amino acid (AA) g/100g protein g/100g protein g/100g protein g/100g protein g/100g protein g/100 g protein g/100g
protein
Essential AA
Threonine 5.1 5.4 5.0 3.9 3.7 4.2 2.3
Methionine 2.1 1.9 1.9 1.3 1.1 2.5 2.2
Phenylalanine 4.6 4.7 4.7 5.0 5.5 4.6 3.8
Histidine 2.2 2.0 2.3 2.4 2.5 3.3 1.5
Lysine 7.2 7.1 7.3 6.4 7.5 7.3 4.5
Valine 6.3 6.2 6.6 4.8 5.3 5.7 3.9
Isoleucine 5.0 5.0 5.4 4.5 4.9 2.2 3.0
Leucine 8.6 8.4 8.9 7.9 8.4 9.4 5.9
Total Essential AA 41.1 40.8 42.2 36.1 38.9 39.3 27.1
Non-essential AA
Alanine 7.9 8.0 8.0 4.5 4.4 3.0 N.A
Arginine 6.2 5.8 6.2 7.4 8.7 3.2 N.A
Aspartic Acid 11.3 11.6 11.2 11.4 11.7 7.1 N.A
Glutamic Acid 12.5 11.7 12.1 19.9 17.4 22.2 N.A
Glycine 6.3 6.7 6.1 4.2 4.1 1.9 N.A
Proline 4.0 3.7 4.0 5.2 4.5 10.4 N.A
Serine 3.9 4.2 3.9 5.2 5.1 5.7 N.A
Tyrosine 3.8 4.6 4.0 3.6 4.1 4.8 N.A
Cysteine + Cystine 0.8 0.5 0.4 1.48a 1.1 0.4 N.A
Tryptophan 2.1 2.5 2.0 1.2 0.7 1.3 N.A
Total non-essential AA 58.9 59.2 57.9 62.5 61.1 60.0 N.A
a Only cysteine was analysed for SPC and PPI.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
7
3.2.3. Fraction composition and protein secondary structure
The complete ATR-FTIR spectra give an overview of the sample
fraction composition (Fig. 4A). The interaction of infrared light with
molecular bonds represents typically the following components: carbo-
hydrates (C–O bond at 900-1150 cm− 1), lipids (CH2 bond at 2800-3000
cm− 1), proteins (C–O and NH at 1400-1700 cm− 1) and nucleotides
(1650 cm− 1) (Mosharaf et al., 2018; Nicolaou et al., 2010), although
multicomponent samples result in superpositions of different signals.
The spectra confirmed the composition of the fractions described in
Table 2, except for the acid precipitated sample (AIF). AIF has signifi-
cantly less signal intensity in the amide I (1600-1800 cm− 1) and amide II
(1470-1570 cm− 1) region (primarily protein) than the other fractions,
whereas the protein content of all samples (Table 2) is approximately the
same. It can be assumed that the strong signal of the other fractions is
caused by the substances with similar absorption to proteins. For
example, nucleotides have an overlapping absorption at 1650 cm− 1 and
cell wall fragments not only consist of carbohydrates but also have a
distinct absorption at 1640 cm− 1 and 1540 cm− 1 due to the presence of
amides (Jiang et al., 2004). A similar effect was observed for the CH2
signal, where lipids but also cell wall insoluble lipopolysaccharides give
a signal (Kim et al., 2005).
The secondary derivative of the amide I band (Fig. 4B) can be used to
understand if the protein conformation was altered by the fractionation
process. Since the protein composition did not change (Fig. 3), these
variations only reflect the mechanical or chemical treatment of the
sample. The results show a strong α-helix signal and a low intensity for
β-sheets for all samples. An absorption intensity shift is seen in the
intramolecular β-sheets: UB shows a strong signal at 1630 cm− 1,
whereas all the other signals of the samples were shifted towards a
higher wavelength (1635 cm− 1). This indicates changes in the hydrogen
bonds stabilizing the β-sheets, which could be caused by the homoge-
nization treatment applied to all the fractions except UB (i.e. confor-
mational changes caused by the high pressure). No significant protein-
protein aggregates (intermolecular β-sheets at 1620 cm− 1) are seen for
the fractions, except for IF (signal at 1625 and 1610 cm− 1), but we
cannot exclude the occurrence of complexes between proteins and
polysaccharides or other types of aggregates with FTIR. Probably any
aggregates with a low solubility end up in the pellet (IF) after centri-
fugation, but we also observed some turbidity in the soluble fraction
(SF). However, no further analysis of protein aggregates was conducted
in the current study and their presence cannot be confirmed or excluded
at this stage. Finally, minor changes were found in the α-helix region,
with AIF having the lowest signal intensity at 1655 cm− 1. However, the
α-helix is known to overlap with superimposed signals from, for
example, nucleotides at 1650 cm− 1. Thus, there were only minor
conformational differences between the different samples, suggesting a
limited effect of the processing history on the protein structure.
3.3. Physico-chemical properties
3.3.1. Thermograms by differential scanning calorimetry (DSC)
Thermograms of the different biomass fractions were recorded to
understand their melting behaviour. The term melting refers to protein
denaturation as well as to the melting of cell wall components. The heat
flow changes of UB, DB, SF, IF and AIF fraction are shown in Fig. 5, and
the melting temperatures (Tm) as well as enthalpies are listed in Table 3.
Three different, albeit weak endothermic peaks were observed for all
fractions during heating for the first run.The melting temperature (Tm)
of the first peak was detected between 70 and 76 ◦C, and 89–98 ◦C for
the second peak, and 124–126 ◦C for the third peak. Thermograms of
Gram-negative bacteria report melting of ribosomal proteins between 47
and 85 ◦C (Mackey et al., 1991). But next to proteins, also the individual
melting of different cell components might cause some of these peaks:
the Tm around 95 ◦C and higher could be linked to the melting of cellular
DNA combined with dehydration and depolymerization of cell wall
components. It is noteworthy that the observed enthalpies were mostly
far below 0.8 J/g biomass, which would correspond to less than 1 J/g
protein and is lower than values found for other processed proteins.
Depending on the processing history, soy protein isolates with a similar
protein content gave an enthalpy of 1.3–6.9 J/g protein (Peng et al.,
2020). For pea protein a total enthalpy of 2.2 J/g protein was found
(Tanger et al., 2022).
Fig. 3. Protein molecular weight (MW) distribution by SDS-PAGE without reducing agent (A) and with reducing agent (B) for the freeze-dried samples of UB, DB, SF,
IF and AIF.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
8
Fig. 4. A) ATR-FTIR spectra of the sample fractions UB, DB, SF, IF and AIF and B) second derivative of the amide I band of the same samples.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
9
Enthalpy changes could be caused by variances in the overall cell
material composition, given that the enthalpy is strongly dependent on
the concentration of the individual component. The decreasing of the Tm
of almost all samples relative to the UB could be caused by either further
damaging the cell wall components and proteins by the microfluidizer
treatment (as hypothesized based on the FTIR analysis Fig. 4), or by
liberating the proteins from the cell wall material. A second temperature
run was performed with each sample and the first and the third peak
both disappeared during this second run, indicating that these were
irreversibly damaged by the heat treatment during the first run.
3.3.2. Zeta potential and conductivity
The absolute zeta potential (Fig. 6 A) of all samples is ranging be-
tween |50| and |40| mV. Based on the amino acid composition, the
charge at neutral pH for free ionizable groups were roughly estimated to
be around |10| mV and |20| mV (Pace et al., 2009), which is far lower
than the measured values. Dependent on the carbohydrate composition,
some bacterial polysaccharides or cells can be strongly negatively
charged (e.g. |35| mV for Paenibacillus (Boukhelata et al., 2019), |44|
mV for E.coli bacterial cells (Halder et al., 2015), or in a range of |30|
and |35| mV for an K. pneumaniae strain (Zając et al., 2023).
Gram-negative bacteria were found to be more highly charged than
Gram-positive bacteria probably because of the highly charged lipo-
polysaccharides in the outer membrane layer (Zając et al., 2023). We
thus assumed that the carbohydrates (e.g. lipopolysaccharides from the
cell wall) of all samples contributed towards the high negative zeta
potential.
The lowest absolute zeta potential (|40| mV) was found for the su-
pernatant (SF) among all the fractions. An explanation could be the
minor compositional changes of the fractions, as SF had the lowest
carbohydrate content, and at the same time the highest ash content (6 g/
100g) (including salts as counter ions) and the highest fat content (2 g/
100g) (i.e., uncharged molecules). Also, the conductivity of SF (8 μS/
cm) is significantly higher than for all the other fractions (Fig. 6 B),
likewise reflecting a higher salt concentration.
Besides, all the fractions have a higher zeta potential compared to
various plant proteins, although such results are highly dependent on
the composition and processing history of the fractions. For plant pro-
tein, soy protein concentrate (SPC) was reported to have a zeta potential
between |20| and |30| at pH 7 and pea protein isolate (PPI) had a zeta
potential value between |17| and |25| at pH 7. Besides, it was also found
that the amount and type of salt added during SPC and PPI fractionation
directly influenced the zeta potential of the fraction (Gravel et al., 2023;
Helmick et al., 2021; Liu et al., 2011; Peng, 2021).
3.3.3. Water holding capacity
The water holding capacity (WHC) of the different fractions is shown
in Fig. 6 C. WHC is an important parameter for meat analogue appli-
cation, which links to the juiciness of the structure (Cornet et al., 2021).
Again, the unprocessed UB fraction has the highest WHC of approxi-
mately 20 g/g dry pellet. Interestingly, a lower WHC was observed for all
the processed biomass of DB, SF and IF. The WHC of all the biomass
fractions is in general much higher compared to plant protein sources
such as rapeseed, soy and lupine protein (less than 10 g/g dry pellet) (Jia
et al., 2021; Peng, 2021; Peters, 2016a,b) or microalgae (3.1 g/g sample)
(Waghmare et al., 2016). Specifically, commercial SPC and PPI were
Fig. 5. A) Heat flow of the sample fractions UB, DB, SF, AIF and IF by heating
from 20 to 130 ◦C for the first run, and B) heat flow of the sample fractions for
the second run.
Table 3
The onset of melting temperature (onset Tm), melting peak temperature (Tm) and
melting enthalpy (J/g) with respect to the different fractions of UB, DB, SF, AIF,
and IF. Values are listed as mean and standard deviation of two independent
measurements.
Peak Fractions UB DB SF IFb AIFa
1st run
Peak 1
Onset Tm,1
(◦C)
66.9 ±
0.8
65.1 ±
0.8
64.8 ±
0.7
62.3 ±
1.3
72.6 ±
1.1
Tm,1 (◦C) 75.8 ±
0.5
70.4 ±
0.1
70.8 ±
0.2
70.0 ±
1.7
75.9 ±
1.1
Enthalpy
(J/g)
0.5 ±
0.2
0.2 ±
0.03
0.2 ±
0.01
0.8 ±
0.02
0.06 ±
0.001
1st run
Peak 2
Onset Tm,2
(◦C)
90.8 ±
0.6
89.7 ±
0.01
89.9 ±
0.1
88.6 ±
0.4
83.1 ±
2.4
Tm,1 (◦C) 97.6 ±
0.3
94.5 ±
0.4
94.3 ±
0.1
93.3 ±
0.1
89.7 ±
0.9
Enthalpy
(J/g)
0.3 ±
0.01
0.3 ±
0.02
0.4 ±
0.01
0.2 ±
0.01
0.4 ±
0.05
1st run
Peak 3
Onset Tm,3
(◦C)
123.7
± 1.9
121.0
± 0.7
118.6
± 0.1
120.0
± 0.2
119.5
± 0.4
Tm,1 (◦C) 125.7
± 0.4
124.9
± 0.01
123.6
± 0.03
124.8
± 0.1
124.0
± 0.4
Enthalpy
(J/g)
0.1 ±
0.02
0.2 ±
0.02
0.2 ±
0.01
0.3 ±
0.01
0.3 ±
0.01
2nd run
Peak 4
Onset Tm,1
(◦C)
79.9 ±
0.1
78.7 ±
0.9
79.9 ±
0.4
78.2 78.0 ±
0.1
Tm,1 (◦C) 83.4 ±
0.1
83.6 ±
0.2
83.9 ±
0.04
82.5 83.6 ±
0.01
Enthalpy
(J/g)
0.04 ±
0.01
0.1 ±
0.06
0.04 ±
0.004
0.05 0.1 ±
0.05
2nd run
Peak 5
Onset Tm,1
(◦C)
89.6 ±
0.5
89.0 ±
0.7
88.4 ±
0.1
90.0 N.D
Tm,1 (◦C) 94.4 ±
0.2
92.9 ±
1.2
91.9 ±
0.2
90.3 N.D
Enthalpy
(J/g)
0.1 ±
0.01
0.2 ±
0.1
0.03 ±
0.01
0.1 N.D
a For AIF fraction in the first run, an additional peak was found with the onset Tm
(61.0 ± 1.0 ◦C), Tm (65.5 ± 1.3 ◦C) and enthalpy (0.1 ± 0.01 J/g).
b During the second run of IF fraction, only a single measurement was per-
formed, thus no standard deviation is known.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
10
reported to have a WHC of approximately 4 g/g sample. Besides, the
extraction methods were reported to have a big impact on the WHC, e.g.
PPI extracted by alkali-isoelectric precipitationis reported to result in a
lower WHC of 2.4–2.6 g/g sample compared to the commercial PPI.
The complexity of the biomass composition makes it hard to explain
the high WHC and the differences between the fractions. The WHC is
affected by the material composition as well as the mechanic processing
history. Polysaccharides from cyanobacteria were reported to have a
comparable high WHC of 20–25 g/g (Gongi et al., 2022, p. 227). Thus, it
is likely that the high WHC is mainly derived from both the protein and
polysaccharides. However, other factors play into the decrease of the
WHC between the UB and all the other fractions as well, for example
mechanical processing also affects the integrity of the bacterial cell wall
and further research is recommended to elucidate this. Furthermore, the
structure of the resulting pellet also influences the amount of water that
the pellet can hold (Jia et al., 2021; Peters, 2016a,b). Here, a gel like
pellet was observed after centrifugation, and water was trapped inside
the gel-like structure. In addition, a high solubility of the biomass was
observed for all fractions (above 80 %) (in supplementary data Fig. S2).
3.4. Structuring properties
3.4.1. Rheological properties with Discovery Hybrid Rheometer
The viscosity of the different fractions (UB, DB, SF, IF and AIF) are
shown in Fig. 7A. All fractions appeared as fluid under 15 % DM. The
viscosity decreased with an increased shear rate, which indicates a
shear-thinning behaviour under room temperature. Besides, the viscos-
ity of the different fractions are all higher compared to commercial spray
dried soy protein concentrate (was not highest compared to the other
fractions, the longest LVE regime indicates that it has the resistant gel
against deformation upon oscillation. Commercial SPC had a γc of
slightly higher than 1 % (Peng, 2021). Pea protein fractions prepared by
two aqueous purification processes were had a γc of 1–10 % (Kornet
et al., 2021).
3.4.2. Rheological properties by closed cavity rheometer (CCR)
CCR is suggested as a tool to understand the rheology behaviour of
plant protein during thermo-mechanical processing, such as inside an
extruder (Cornet et al., 2022; Pietsch, 2019). Here the oscillation at 1 %
strain and 1 Hz frequency was measured for all the freeze-dried biomass
fractions in CCR. In addition, soy protein concentrate (SPC) with a
similar protein content of 67 % was used as a reference (denominated as
“reference”). The complex modulus G* was measured by heating
(40–150 ◦C) was measured (Fig. 7D) by cooling (150–50 ◦C) (Fig. 7E).
In general, the heating of all the fractions resulted in a constant re-
gion of a G*-value from 40 to 70 ◦C, followed by an increase from 70 to
100 ◦C, followed by a decrease from 100 to 135 ◦C and stabilized from
135 to 150 ◦C. An increase of the G*-value from ~10,000 Pa (70 ◦C) to
20,000 Pa (100 ◦C) further confirmed heat-induced gelation as indicated
in Fig. 7B and the denaturation as suggested by the DSC peak 1 and 2 at
approximately 70 and 90 ◦C (Fig. 5). The G*-value decreased after
reaching the maximum value at 100 ◦C though the DSC peak was
observed at 120 ◦C. The decrease of the G*-value at high temperature
was known to be associated with the degradation of crosslinked struc-
tures (Emin et al., 2017), for example cell wall material. Thus, the
depolymerization effect was most likely most important in determining
the rheological behavior. The AIF fraction showed a similar trend, but
this dispersion had a much higher G*-value compared to the other
fractions. The result suggest that the acid precipitation enhanced the
rheological properties, although the composition of this fraction
remained roughly similar to the other samples. The commercial SPC
showed a different trend, which started with a steady decrease from 40
to 120 ◦C, and then largely decreased from 120 to 150 ◦C. Besides, SPC
showed highest G*-value throughout the whole heating ramp, indicating
the highest mechanical strength. This value is similar to the reported
data (Jia et al., 2021).
Though the SPC showed the highest G*-value during the whole
heating ramp, the G*-value of SPC during cooling enhanced only to 100
kPa at the end of cooling (50 ◦C), which was much less compared to AIF
(250 kPa) as well as DB, SF, and IF (165 kPa). Again, the lowest G*-value
was found for UB (57 kPa). As previously discussed, this could be due to
the lower mechanical processing of this fraction, and thus lower initial
accessibility of the proteins.
4. The potential of using M. flagellatus for making meat
analogue product
The macrostructure of the sheared and heated UB, AIF, and SPC
samples at 40 % DM using shear cell are shown in Fig. 8. Both UB and
AIF formed intact pancakes with an umami smell, which had some
similarities with meat. Some water was found on the surface of the AIF
sample, whereas hardly any water was found on the UB sample’s sur-
face. The UB sample formed a layered structure broken into pieces when
taken from the shear cell. For the AIF sample, a pancake like structure
was formed, which was porous with many holes. Hardly any fine fibrous
structure was present with the UB and AIF sample, which might be
associated with the low cysteine content (Table 2). Cysteine is a sulfur-
containing amino acid, which is known to be associated with the
network structure formation due to the S–S group crosslinking between
proteins (Dinani, van der Harst, Boom, & van der Goot, 2023). The SPC
showed more fibrous structure after the same treatment in shear cell.
This result is not surprising since SPC has a much higher cysteine content
(approximately two times more than UB and nearly four times more than
AIF). Furthermore, SPC is known to contain two immiscible components
of protein and polysaccharides, which is important for the fibrous
structure formation (Grabowska et al., 2016). The differences in the
structure formed for UB and AIF fractions might be explained by the
differences between their composition, techno-functional properties,
and processing history. It is noticed that the AIF had a higher carbo-
hydrate and lower protein content compared to UB (Table 1), as well as
higher viscosity and a higher viscoelastic property (Fig. 7). The microbe
cells might still be intact for UB due to less strong mechanical treatment
Table 4
The G’-, G″-value and Tan δ at the onset of heating, holding regions and end of cooling region by the temperature ramp is recorded for the different fractions (the last
data point of each region). The critical strain γc during amplitude sweep is determined at the end of the LVE region.
Fractions Onset heating 20 ◦C (T = 0 min) Holding (95 ◦C)
(T = 20 min)
End of cooling 20 ◦C (T = 50 min) Critical strain γc
G’ (Pa) G’’ (Pa) Tan δ G’ (Pa) G’’ (Pa) Tan δ G’ (Pa) G’’ (Pa) Tan δ %
UB 315.2 201.8 0.6 825.8 214.2 0.3 9951.9 3563.3 0.4 8.4
DB 76.3 49.5 0.6 1501.6 313.7 0.2 17816.3 5525.5 0.3 38.7
SF 7.2 7.2 1.0 1492.0 142.9 0.1 13752.7 3190.9 0.2 44.5
IF 460.7 273.1 0.6 2066.2 531.9 0.3 16411.0 5662.8 0.3 8.4
AIF 546.1 201.3 0.4 2974.8 417.5 0.1 19923.0 5179.0 0.3 10.7
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
13
compared to intensively processed AIF fraction, hindering a continuous
homogenous protein network.
While the solid appearance of AIF and the layered and crumbly
texture of UB certainly needs further process optimization steps to
improve the final texture towards a more stable and fibrous texture, it is
still promising that some structure can already be formed based on the
unprocessed biomass. Furthermore, although similar in composition, UB
and AIF differ in their appearance, which gives them a different appli-
cation range (e.g. UB potentially for meat analogue production and AIF
as more homogenous gelling agent). It remains to be tested if plant
protein blends (e.g. from soy or wheat) with the bacterial biomass can
further improve the texture towards forming meat analogues, by for
example introducing another phase and/or a higher cysteine
concentration.
From a food safety point of view, a meat analogue with the presented
bacterial biomass and 40 % dry matter would contain 2 g nucleotides/
100 g meat analogue (based on Table 1), which is within the 2 g/day (w/
w) upper limit recommended by WHO for novel foods from single cell
protein. But further reduction steps should be evaluated in the future
(Coelho et al., 2020, p. 1115). Besides, from the consumer acceptance
point of view, the pinkish colour of the biomass (that turned brown on
the surface after heating in the shear cell), as well as the umami flavour
(sausage smell), suits the target product, lessening the need for colour-
ants or artificial flavourings. Nevertheless, a more in-depth analysis of
the involved pigments needs to be conducted to better understand their
nature.
5. Conclusion
We screened the physicochemical- and rheological properties of
M. flagellatus unprocessed biomass and different fractions. Overall, a
high protein content of 73 %, very high zeta-potential and high-water
holding capacity was evident. Thus, we observed promising structural
and rheological properties for food applications, further supported by
the pleasant smell and colour of the biomass fractions. In particular, the
unprocessed biomass of M. flagellatus showed properties suitablefor
meat analogues and should be further investigated.
Interestingly, the various processing steps applied for protein frac-
tionation and removal of nucleotides had a significant effect on the
rheological properties and structure formation of the unprocessed
biomass versus acid precipitated fraction. However, there were only
minor changes in the overall composition (such as protein and nucleo-
tides), primarily with respect to carbohydrate content. Since we could
not find a clear correlation between the rheological properties and the
carbohydrate content, we thus assume that either the individual car-
bohydrate composition and/or the fractionation and mechanical/
chemical treatment modified the rheological properties of the fractions.
Next to that, a negative effect of salt on the rheological properties
seemed evident. The presented results were an explorative study to
assess the functional potential of microbial biomass M. flagellatus for
future applications. Further research is still required to better explain
the underlying phenomena and modulate the material and composition.
Future research should also address food safety aspects, including
confirmation that no traces of methanol feedstock is left in the biomass.
We note that we do not expect any methanol in the biomass because it is
probably all consumed during cultivation, and possible traces can be
easily removed due to its volatility. While it is not known as a pathogen,
studies are needed to confirm the safety of this promising microbial
protein source for food application as well as its taste. In addition,
regulatory approval is needed to apply M. flagellatus as a food ingredient.
CRediT authorship contribution statement
Wanqing Jia: Writing – original draft, Methodology, Formal anal-
ysis, Data curation, Conceptualization. Laurice Pouvreau: Writing –
review & editing, Supervision, Funding acquisition, Conceptualization.
Fig. 8. Structuring properties of freeze-dried UB (A1, A2 and A3), AIF (B1, B2 and B3) and SPC (C1 and C2) (dry matter of 40 %), corresponding to a protein
concentration of approximately 28 % in the shear cell.
W. Jia et al.
Food Hydrocolloids 151 (2024) 109832
14
Atze Jan van der Goot: Writing – review & editing. Timotheus Y.
Althuis: Writing – review & editing, Investigation. David Virant:
Writing – review & editing. Aleksander J. Kruis: Writing – review &
editing. Gregor Kosec: Writing – review & editing. Nico J. Claassens:
Writing – review & editing, Supervision, Funding acquisition, Concep-
tualization. Julia K. Keppler: Writing – original draft, Supervision,
Funding acquisition, Formal analysis, Conceptualization.
Declaration of competing interest
The authors declare that they have no known competing financial
interests or personal relationships that could have appeared to influence
the work reported in this paper.
Data availability
Data will be made available on request.
Acknowledgement
This project was funded by the Protein Transition Investment Theme
of Wageningen University. Bacterial biomass was kindly provided by
Acies Bio (Ljubljana, Slovenia). The authors would like to thank Pan-
agiotis Voudouris (WFBR) for the support for the CLSM images. The
authors also would like to thank Frederique Catsman and Aleksandra
Pawlik (WFBR) for the support of the rheology measurements. The
graphical abstract was made in BioRender.com.
Appendix A. Supplementary data
Supplementary data to this article can be found online at https://doi.
org/10.1016/j.foodhyd.2024.109832.
References
Anaizi, N. (2023). The impact of uric acid on human health: Beyond gout and kidney
stones. Ibnosina Journal of Medicine and Biomedical Sciences, 15(3), 110–116. https://
doi.org/10.1055/S-0043-1770929
Coelho, M. O. C., Monteyne, A. J., Kamalanathan, I. D., Najdanovic-Visak, V.,
Finnigan, T. J. A., Stephens, F. B., & Wall, B. T. (2020). Short-Communication:
Ingestion of a nucleotide-rich mixed meal increases serum uric acid concentrations
but does not affect postprandial blood glucose or serum insulin responses in young
adults. Nutrients 2020, 12(4), 1115. https://doi.org/10.3390/NU12041115. 12, Page
1115.
Cotton, C. A., Claassens, N. J., Benito-Vaquerizo, S., & Bar-Even, A. (2020). Renewable
methanol and formate as microbial feedstocks. Current Opinion in Biotechnology, 62,
168–180. https://doi.org/10.1016/j.copbio.2019.10.002
Dai, Y.-F., Xiao, Y., Zhang, E.-H., Liu, L.-D., Qiu, L., You, L.-X., Mahadevan, G. D.,
Chen, B.-L., Zhao, F., Le-Xing, L. Q., Gurumurthy, Y., & Mahadevan, D. (2016).
Effective methods for extracting extracellular polymeric substances from Shewanella
oneidensis MR-1. https://doi.org/10.2166/wst.2016.473
Desmond, P., Best, J. P., Morgenroth, E., & Derlon, N. (2018). Linking composition of
extracellular polymeric substances (EPS) to the physical structure and hydraulic
resistance of membrane biofilms. Water Research, 132, 211–221. https://doi.org/
10.1016/J.WATRES.2017.12.058
Dinani, S. T., van der Harst, J. P., Boom, R., & van der Goot, A-J. (2023). Effect of l-
cysteine and l-ascorbic acid addition on properties of meat analogues. Food
Hydrocolloids, 134, 108059. https://doi.org/10.1016/j.foodhyd.2022.108059.
Gomes, T. A., Zanette, C. M., & Spier, M. R. (2020). An overview of cell disruption
methods for intracellular biomolecules recovery. Preparative Biochemistry &
Biotechnology, 50(7), 635–654. https://doi.org/10.1080/10826068.2020.1728696
Gongi, W., Pinchetti, J. L. G., Cordeiro, N., & Ouada, H. B. (2022). Extracellular
polymeric substances produced by the thermophilic cyanobacterium gloeocapsa
gelatinosa: Characterization and assessment of their antioxidant and metal-chelating
activities. Marine Drugs 2022, 20(4), 227. https://doi.org/10.3390/MD20040227.
20, Page 227.
Grabowska, K. J., Zhu, S., Dekkers, B. L., De Ruijter, N. C. A., Gieteling, J., & van der
Goot, A. J. (2016). Shear-induced structuring as a tool to make anisotropic materials
using soy protein concentrate. Journal of Food Engineering, 188, 77–86. https://doi.
org/10.1016/j.jfoodeng.2016.05.010
Gravel, A., Dubois-Laurin, F., & Doyen, A. (2023). Effects of hexane on protein profile
and techno-functional properties of pea protein isolates. Food Chemistry, 406, Article
135069. https://doi.org/10.1016/J.FOODCHEM.2022.135069
Halder, S., Yadav, K. K., Sarkar, R., Mukherjee, S., Saha, P., Haldar, S., Karmakar, S., &
Sen, T. (2015). Alteration of zeta potential and membrane permeability in bacteria:
A study with cationic agents. SpringerPlus, 4(1), 1–14. https://doi.org/10.1186/
s40064-015-1476-7
Helmick, H., Hartanto, C., Bhunia, A., Liceaga, A., & Kokini, J. L. (2021). Validation of
bioinformatic modeling for the zeta potential of vicilin, legumin, and commercial
pea protein isolate. Food Biophysics, 16, 474–483. https://doi.org/10.1007/s11483-
021-09686-8
Hendrickson, E. L., Beck, D. A. C., Wang, T., Lidstrom, M. E., Hackett, M., &
Chistoserdova, L. (2010). Expressed genome of Methylobacillus flagellatus as
defined through comprehensive proteomics and new insights into methylotrophy.
Journal of Bacteriology, 192(19), 4859–4867. https://doi.org/10.1128/JB.00512-10
Hesarinejad, M. A., Koocheki, A., & Razavi, S. M. A. (2014). Dynamic rheological
properties of Lepidium perfoliatum seed gum: Effect of concentration, temperature
and heating/cooling rate. Food Hydrocolloids, 35, 583–589. https://doi.org/
10.1016/J.FOODHYD.2013.07.017
IRENA, Methanol Institute. (2021). ISBN: 978-92-9260-320-5. Innovation outlook:
Renewable methanol. International Renewable Energy Agency, Abu Dhabi https://
www.irena.org/publications/2021/Jan/Innovation-Outlook-Renewable-Methanol.
Jia, W., Rodriguez-Alonso, E., Bianeis,
