Building an Android App
from the Command Line
(4 January 2017)
Update 2024-03-01: Updated the article to use newer SDK, NDK, etc. and target Android
API level 34.
I have been learning a bit of Android programming recently (late to the party, I know). One
thing that frustrated me was figuring out how to actually build an Android application.
Things are simple enough with C. As explained in the first section of K&R, one might write
this as a first program:
#include
int main()
{
printf("Hello, world!\n");
return 0;
}
and turn it into an executable by simply invoking the system compiler as below.
$ cc hello.c
$ ./a.out
Hello, world!
This diagram illustrates the full process:
For Android, however, the official way to write Hello World is to fire up Android Studio, use
its wizard to create a new project, and the application will then be generated and built
https://www.hanshq.net/
https://www.hanshq.net/
https://en.wikipedia.org/wiki/The_C_Programming_Language
https://en.wikipedia.org/wiki/The_C_Programming_Language
https://developer.android.com/training/basics/firstapp/creating-project.html
https://developer.android.com/training/basics/firstapp/creating-project.html
https://developer.android.com/studio/intro/index.html
https://developer.android.com/studio/intro/index.html
automagically in a few minutes.
This is of course intended as a convenience for the developer, but for someone who wants to
know what's going on, it makes things difficult instead. What actually happened? Which of all
these files are really necessary for Hello World?
Others have expressed similar concerns:
(For me, it generated a 50 MB directory containing 1,348 files spread across 630
subdirectories.)
Perhaps it is the control freak in me speaking (a good trait for programmers about their
programs), but I simply don't feel comfortable not understanding how to build my own
program.
Below are my notes on how to build an Android application by hand from the command line.
The instructions are for Linux, but they should be easy to adapt to Mac or Windows. The full
source code and a build script is available in command_line_android.tar.gz.
Table of Contents
▪ Installing the Development Tools
▪ The Hello World Program
▪ Building
▪ Running
▪ Using Native Code
Installing the Development Tools
Android applications are usually written in Java (or Kotlin these days), so building them
requires having a Java Development Kit (JDK) installed. I downloaded the latest version from
here, extracted and put it on my PATH like so:
$ curl -LO https://download.oracle.com/java/17/archive/jdk-17.0.10_linux-x64_bin.tar.gz
$ tar zxf jdk-17.0.10_linux-x64_bin.tar.gz
$ export JAVA_HOME="$PWD/jdk-17.0.10"
$ export PATH="$JAVA_HOME/bin:$PATH"
https://twitter.com/ID_AA_Carmack/status/771749108780523520
https://twitter.com/ID_AA_Carmack/status/771749108780523520
https://www.hanshq.net/files/android_files.txt
https://www.hanshq.net/files/android_files.txt
https://www.hanshq.net/files/command_line_android.tar.gz
https://www.hanshq.net/files/command_line_android.tar.gz
https://www.hanshq.net/files/command_line_android.tar.gz
https://www.hanshq.net/command-line-android.html#sdk
https://www.hanshq.net/command-line-android.html#sdk
https://www.hanshq.net/command-line-android.html#source
https://www.hanshq.net/command-line-android.html#source
https://www.hanshq.net/command-line-android.html#building
https://www.hanshq.net/command-line-android.html#building
https://www.hanshq.net/command-line-android.html#running
https://www.hanshq.net/command-line-android.html#running
https://www.hanshq.net/command-line-android.html#native
https://www.hanshq.net/command-line-android.html#native
https://www.oracle.com/java/technologies/downloads/
https://www.oracle.com/java/technologies/downloads/
We create a directory for the Android software development kit, and set a variable to refer to
it:
$ mkdir android_sdk
$ SDK="$PWD/android_sdk"
One way to get what we need is by using the Android Commandline Tools that can be found
on the Android Studio download page. They provide the sdkmanager which can be used to fetch
all the components we need:
$ curl -LO https://dl.google.com/android/repository/commandlinetools-linux-11076708_latest.zip
$ unzip -q commandlinetools-linux-11076708_latest.zip -d "$SDK"
$ "$SDK/cmdline-tools/bin/sdkmanager" --sdk_root="$SDK" --install \
"platforms;android-34" "build-tools;34.0.0" "platform-tools" "ndk;26.2.11394342"
Or, we can fetch the components we need manually. What we need is build-tools (for aapt, d8,
and apksigner), an Android Platform to target, and platform-tools (for adb).
$ curl -LO https://dl.google.com/android/repository/build-tools_r34-linux.zip
$ mkdir "$SDK/build-tools"
$ unzip -q build-tools_r34-linux.zip -d "$SDK/build-tools"
$ mv "$SDK/build-tools/android-14" "$SDK/build-tools/34.0.0"
$ curl -LO https://dl.google.com/android/repository/platform-34-ext7_r02.zip
$ mkdir "$SDK/platforms"
$ unzip -q platform-34-ext7_r02.zip -d "$SDK/platforms"
$ curl -LO https://dl.google.com/android/repository/platform-tools_r34.0.5-linux.zip
$ unzip -q platform-tools_r34.0.5-linux.zip -d "$SDK"
$ BUILD_TOOLS="$SDK/build-tools/34.0.0"
$ PLATFORM="$SDK/platforms/android-34"
The Hello World Program
Our Hello World program consists of three files: an application manifest, a layout and an
Activity.
The app manifest is shown below (AndroidManifest.xml). It specifies the name of the app, which
Android API it targets, etc. The intent-filter element sets up MainActivity as the main entry
point of the program.









Below is the layout file (res/layout/activity_main.xml). It defines UI elements to be used in our
program.
https://developer.android.com/studio/index.html#command-line-tools-only
https://developer.android.com/studio/index.html#command-line-tools-only
https://developer.android.com/guide/topics/manifest/manifest-intro.html
https://developer.android.com/guide/topics/manifest/manifest-intro.html
https://developer.android.com/guide/topics/ui/declaring-layout.html
https://developer.android.com/guide/topics/ui/declaring-layout.html

Finally, the Activity is implemented like this: (java/net/hanshq/hello/MainActivity.java)
package net.hanshq.hello;
import android.app.Activity;
import android.os.Bundle;
import android.widget.TextView;
public class MainActivity extends Activity {
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
TextView text = (TextView)findViewById(R.id.my_text);
text.setText("Hello, world!");
 }
}
Building
All build artifacts will be put in subdirectories of the build directory which we create here.
$ mkdir -p build/gen build/obj build/apk
The first build step is to generate the R.java file, which is used for referring to resources
(such as R.id.my_text above). This is done using the Android Asset Packaging Tool, aapt:
$ "$BUILD_TOOLS/aapt" package -f -m -J build/gen/ -S res \
 -M AndroidManifest.xml -I "$PLATFORM/android.jar"
whichcreates build/gen/net/hanshq/hello/R.java.
The -f flag causes aapt to overwrite any existing output file, -m causes it to create package
directories under the output directory, and -J makes it generate the R.java file and sets the
output directory. -S points out the resource directory, -M specifies the manifest, and -I adds
the platform .jar as an "include file".
Now that all the Java code is ready, we can compile it using javac:
$ javac --release 11 -classpath "$PLATFORM/android.jar" -d build/obj \
 build/gen/net/hanshq/hello/R.java java/net/hanshq/hello/MainActivity.java
The Java compiler created .class files containing byte code for the Java Virtual Machine. That
then has to be translated to Dalvik byte code using the d8 tool:
$ "$BUILD_TOOLS/d8" --release --lib "$PLATFORM/android.jar" \
 --output build/apk/ build/obj/net/hanshq/hello/*.class
https://developer.android.com/reference/android/app/Activity.html
https://developer.android.com/reference/android/app/Activity.html
https://en.wikipedia.org/wiki/Dalvik_%28software%29
https://en.wikipedia.org/wiki/Dalvik_%28software%29
We then package the contents of the build/apk/ directory together with the manifest and
resources into an Android Application Package (APK) file, again using the aapt tool:
$ "$BUILD_TOOLS/aapt" package -f -M AndroidManifest.xml -S res/ \
 -I "$PLATFORM/android.jar" \
 -F build/Hello.unsigned.apk build/apk/
The application has now been built, but the APK file needs to be signed before any device
will allow running it, even in debug mode, and zipaligned if we ever want to publish it in the
Play Store.
First, we run the zipalign tool, which aligns uncompressed files in the APK on 4-byte
boundaries, and any shared objects on page boundaries, for easier memory mapping:
$ "$BUILD_TOOLS/zipalign" -f -p 4 \
 build/Hello.unsigned.apk build/Hello.aligned.apk
Then we use the Java keytool to create a key store and key for signing:
$ keytool -genkeypair -keystore keystore.jks -alias androidkey \
 -validity 10000 -keyalg RSA -keysize 2048 \
 -storepass android -keypass android
What is your first and last name?
 [Unknown]:
What is the name of your organizational unit?
 [Unknown]:
What is the name of your organization?
 [Unknown]:
What is the name of your City or Locality?
 [Unknown]:
What is the name of your State or Province?
 [Unknown]:
What is the two-letter country code for this unit?
 [Unknown]:
Is CN=Unknown, OU=Unknown, O=Unknown, L=Unknown, ST=Unknown, C=Unknown correct?
 [no]: yes
(you may want to put in more proper values of course.)
and use that key to sign our application with apksigner:
$ "$BUILD_TOOLS/apksigner" sign --ks keystore.jks \
 --ks-key-alias androidkey --ks-pass pass:android \
 --key-pass pass:android --out build/Hello.apk \
 build/Hello.aligned.apk
Et voilà, we have successfully built an Android application by hand from the command line!
The diagram below illustrates the whole process.
https://developer.android.com/studio/publish/app-signing.html#signing-manually
https://developer.android.com/studio/publish/app-signing.html#signing-manually
https://docs.oracle.com/en/java/javase/11/tools/keytool.html
https://docs.oracle.com/en/java/javase/11/tools/keytool.html
https://docs.oracle.com/en/java/javase/11/tools/keytool.html
(We skipped some common steps that aren't strictly necessary: linting and ProGuard.)
Running
We can install our freshly built APK on a device (which must have USB debugging enabled)
using the Android Debug Bridge:
$ "$SDK/platform-tools/adb" install -r build/Hello.apk
and run it, either by starting it manually from the Launcher, or with adb:
https://developer.android.com/studio/write/lint.html
https://developer.android.com/studio/write/lint.html
https://developer.android.com/studio/build/shrink-code.html
https://developer.android.com/studio/build/shrink-code.html
https://developer.android.com/studio/command-line/adb.html#Enabling
https://developer.android.com/studio/command-line/adb.html#Enabling
$ "$SDK/platform-tools/adb" shell am start -n net.hanshq.hello/.MainActivity
Using Native Code
While Android applications are usually written in Java, they can also contain native code,
that is, machine code to be run directly by the device's processor. This is useful for
performance, as it removes the overhead from running Java code, and for portability, as it
opens the platform to code written in other languages.
Adding native code to our program makes it a little harder to build, but it turns out not to be
too bad.
The Android Native Development Kit (NDK) provides compilers and libraries for building C
and C++ code for Android. It can be installed with the sdkmanager, or manually like this:
$ curl -LO https://dl.google.com/android/repository/android-ndk-r26c-linux.zip
$ mkdir "$SDK/ndk"
$ unzip -q android-ndk-r26c-linux.zip -d "$SDK/ndk"
$ NDK="$SDK/ndk/26.2.11394342"
$ mv "$SDK/ndk/android-ndk-r26c" "$NDK"
We set more shell variables to point at the specific toolchains we'll use: (if you're not using
Linux, you'll want one of the other prebuilt directories)
$ ARM_CLANG="$NDK/toolchains/llvm/prebuilt/linux-x86_64/bin/armv7a-linux-androideabi33-clang"
$ ARM64_CLANG="$NDK/toolchains/llvm/prebuilt/linux-x86_64/bin/aarch64-linux-android33-clang"
$ X86_CLANG="$NDK/toolchains/llvm/prebuilt/linux-x86_64/bin/x86_64-linux-android33-clang"
We will update our Activity to use the Java Native Interface (see also Android JNI Tips) to call
a new method, getMessage(), and use that method to set the text of the TextView. The method
will be implemented in native code by a library called hello, which we load with
System.loadLibrary in a static initializer block:
package net.hanshq.hello;
import android.app.Activity;
import android.os.Bundle;
import android.widget.TextView;
public class MainActivity extends Activity {
static {
System.loadLibrary("hello");
 }
public native String getMessage();
@Override
protected void onCreate(Bundle savedInstanceState) {
super.onCreate(savedInstanceState);
setContentView(R.layout.activity_main);
TextView text = (TextView)findViewById(R.id.my_text);
text.setText(getMessage());
 }
}
The hello library must provide a native implementation of the getMessage method. To figure
out what C function signature corresponds to the Java method, we invoke javac with the -h
 flag to generate a header:
https://developer.android.com/ndk/index.html
https://developer.android.com/ndk/index.html
https://developer.android.com/training/articles/perf-jni.html
https://developer.android.com/training/articles/perf-jni.html
$ javac -h /tmp --release 11 -classpath "$PLATFORM/android.jar" -d build/obj \
 build/gen/net/hanshq/hello/R.java java/net/hanshq/hello/MainActivity.java
$ grep -A1 _getMessage /tmp/net_hanshq_hello_MainActivity.h
JNIEXPORT jstring JNICALL Java_net_hanshq_hello_MainActivity_getMessage
 (JNIEnv *, jobject);
We implement it like this, in hello.c:
#include
#include
static const char *const messages[] = {
"Hello, world!",
"Hej världen!",
"Bonjour, monde!",
"Hallo Welt!"
};
JNIEXPORT jstring JNICALL
Java_net_hanshq_hello_MainActivity_getMessage(JNIEnv *env, jobject obj)
{
int i;
i = rand() % (sizeof(messages) / sizeof(messages[0]));
return (*env)->NewStringUTF(env, messages[i]);
}
The C file is compiled into the shared library libhello.so (note the extra lib prefix). We build
one for ARMv7, one for AArch64, and one for X86-64, to support most devices and
emulators, and put them in the APK's lib/ directory:
$ mkdir -p build/apk/lib/armeabi-v7a build/apk/lib/arm64-v8a \
 build/apk/lib/x86_64
$ "$ARM_CLANG" -fpic -shared -o build/apk/lib/armeabi-v7a/libhello.so \
 jni/hello.c
$ "$ARM64_CLANG" -fpic -shared -o build/apk/lib/arm64-v8a/libhello.so \
 jni/hello.c
$ "$X86_CLANG" -fPIC -shared -o build/apk/lib/x86_64/libhello.so \
 jni/hello.c
(See the ABI Management doc for which ABIs can be targeted with the NDK,and under
which lib/ directory to put the .so file.)
To build the APK, we repeat the build steps from above (aapt all the way to apksigner). The
contents of the APK can be inspected with the jar tool:
$ jar tf build/Hello.apk
AndroidManifest.xml
classes.dex
lib/arm64-v8a/libhello.so
lib/armeabi-v7a/libhello.so
lib/x86_64/libhello.so
res/layout/activity_main.xml
resources.arsc
META-INF/ANDROIDK.SF
META-INF/ANDROIDK.RSA
META-INF/MANIFEST.MF
The file should contain the manifest, the Java classes converted to DEX format, our three
native .so files, Application resources in raw (activity_main.xml) and binary (resources.arsc)
form. The META-INF directory contains the JAR file manifest and cryptographic signatures.
When run, the application looks like this:
https://developer.android.com/ndk/guides/abis.html
https://developer.android.com/ndk/guides/abis.html
For a larger example, see the Othello project.
Hans Wennborg | www.hanshq.net | hans (at) hanshq.net | Twitter | Mastodon | RSS
https://www.hanshq.net/othello.html
https://www.hanshq.net/othello.html
https://www.hanshq.net/
https://www.hanshq.net/
https://twitter.com/hansw2000
https://twitter.com/hansw2000
https://mastodon.social/@hansw2000
https://mastodon.social/@hansw2000
https://www.hanshq.net/feed.rss
https://www.hanshq.net/feed.rss
