Foreword
Please read and understand the service manual carefully to ensure correct servicing of the
Analyzer.
After reading, please keep the service manual properly and place it at an accessible position for
lookup at any time.
Product name: Auto-Chemistry Analyzer
 Model: CS-T180
Date of preparation: August 2018; Rev. No.: REV.2018-08.
Intellectual Property
Dirui Industrial Co., Ltd. (hereinafter referred to as Dirui Company) reserves the intellectual
property of the service manual and related products.
© 2017 All rights reserved
Without the written approval of Dirui Company, any individuals or organizations shall not copy,
alter or translate any parts of the manual.
Statement
Dirui Company has the final interpretation right of the manual.
Dirui Company declares that it will be responsible for the safety, reliability and performances
of the product only if all following requirements are met.
1) The assembly, readjustment, improvement and repair of the Analyzer are undertaken by
personnel approved by Dirui Company.
2) Relevant electrical equipment complies with national standards.
3) Product repair is carried out according to the service manual.

Repair Service
Charge-free services:
Products within the scope of warranty of Dirui Company can enjoy charge-free services.
Chargeable services:
1) Services for products beyond the range of the warranty of Dirui Company.
2) Repair of products caused by following factors, even within the warranty period.
Artificial damages, improper use, network voltage beyond the regulated range, irresistible
natural disasters, accessories or consumables not approved by Dirui Company, or repair of the
product by personnel not authorized by Dirui Company.
Change/ Refund
Please follow steps below for change/ refund from Dirui Company.
(1) Get the right of change/ refund: Contact the after-sales service personnel of Dirui Company,
inform the serial number of the product, indicate the product model and describe the reason of
refund in brief.
(2) Transportation expense: The user shall bear the transportation expenses (including customs
fees) to Dirui Company.
After-sales Service Provider
After-sales Service Unit: Dirui Industrial Co., Ltd.
Address: 3333 Yiju Road, New & High Tech. Development Zone, Changchun Post Code:
130103
International Customer Service Hotline: +86 400 808 7597
International Customer Service E-mail: service@dirui.com.cn
Domestic Customer Service Hotline: 400 811 6695 400 811 6605

Domestic Fax: 0431-85100405
Domestic Customer Service E-mail: service.ch@dirui.com.cn
Readers
The readers of the maintenance manual are Dirui Company and the maintenance personnel
authorized by Dirui Company.
Symbols
1. Symbols
Symbol Meaning

Biological hazards which warn the operator of biological infectivity.

Laser, dangerous symbol

AC
 Medical apparatus and instruments for in vitro diagnosis
 Lot code

Service life
 Serial number

Manufacturing date

Protective earthing

Manufacturer

The equipment complies with the requirements of European Union for in vitro diagnostic medical
devices.

Attention, refer to accompanying document or mark specific warning or attention conditions
 Classification No.

On (power)

Symbol Meaning

Off (power)

Transportation and storage temperature limit (temperature limit)

Transportation and storage humidity limit (humidity limit)

Atmospheric pressure limit (atmospheric pressure limit)

Be careful, burns

Mark indicating the use of restricted hazardous substances in electronic and electrical products. It
means the product contains some substances whose use is restricted (but the content is within the
allowable range), the product can be used without hazards in an environment-friendly use period (7
years) but it shall be put to recycling system after the expiry of environment-friendly use period.
2. Signs
(1)
(2)
(3)
(4)

(5)
(6)
Safety Precautions

● If the hospital or organization in charge of the instrument can not formulate a satisfactory
servicing/ repair plan, the instrument may not operate normally and personal health may be
affected.
● Combustible gas (such as anesthetic) or combustible liquid (such as ethyl alcohol) shall not
be used near the product to prevent explosion.
● Power supply shall be cut off when the product is repaired. Repair of the instrument when
it is turned on may cause electric shock and damages of electrical components.
● Please connect the Analyzer to a socket with an independent fuse and protective switch. If
the Analyzer shares a fuse and protective switch with other equipment (such as life support
equipment), trip may occur in case of a fault, over current or impact current at the moment of
startup.
● The clothes, hair and hands of the servicing personnel shall be away from moving
components such as sampling probe to prevent pinching or piercing.
● As the part with warning signs may have mechanical action, human body injuries such as
pinching and stabbing may be caused in normal operation, disassembly or servicing.
● The operator is obligated to follow national and local regulations on discharge and
treatment of expired reagent, waste liquid, waste sample and consumables.
● The reagent will irritate eyes, skin and mucosa. The operator shall abide by laboratory
operation safety regulations and wear personal protective appliances (such as laboratory
clothes and gloves) when touching reagent related articles in the laboratory.
● Once the reagent touches with skin, use a large amount of water to flush the skin, or send
the injured to a doctor if necessary. Once the reagent touches with eyes, use a large amount of
water to flush the eyes and send the injured to a doctor.
● The Analyzer shall be used by professional medical examination personnel or trained
doctors, nurses or testers.

● The samples, quality control objects, calibration objects and waste liquid have potential
biological infectivity. The servicing person shall abide by laboratory operation safety
regulations and wear personal protective appliances (such as laboratory clothes and gloves)
when touching and handling relevant articles in the laboratory.
● As all components and surface of the Analyzer have potential infectivity, safety protection
measures shall be taken in operation and servicing.
● Do not touch the tip of the sampling probe as the tip is sharp and it may have blood sample,
quality control object and calibration object that have potential biological infectivity.
I

Contents
Chapter 1 Overview of the Analyzer .................................................................................................. 1
1.1 System overview ............................................................................................................................................. 1
1.2 Structure and introduction of the Analyzer ................................................................................................... 1
1.2.1 Structure of the Analyzer................................................................................................................................................ 1
1.2.2 Front view (without shield) of the Analyzer ................................................................................................................... 2
1.2.3 Rear view (without shield) of the Analyzer .................................................................................................................... 2
1.2.4 Left view (without shield) of the Analyzer ..................................................................................................................... 3
1.2.5 Right view (without shield) of the Analyzer .................................................................................................................. 4
1.3 Working principle ..........................................................................................................................................4
1.3.1 Analysis process ............................................................................................................................................................. 4
1.3.2 Characteristics of photometry ......................................................................................................................................... 5
Chapter 2 Installation of the Analyzer ............................................................................................... 6
2.1 Installation requirements ............................................................................................................................... 6
2.1.1 Space requirements......................................................................................................................................................... 6
2.1.2 Environmental requirements .......................................................................................................................................... 6
2.1.3 Power requirements ........................................................................................................................................................ 7
2.1.4 Requirements for pure water device ............................................................................................................................... 7
2.2 Unpacking ....................................................................................................................................................... 7
2.2.1 Unpacking steps ............................................................................................................................................................. 7
2.2.2 Handling method ............................................................................................................................................................ 7
2.3 Installation process ......................................................................................................................................... 8
2.3.1 Installation of the Analyzer ............................................................................................................................................ 8
2.3.2 Power connection ......................................................................................................................................................... 12
2.3.3 Connection of peripheral equipment ............................................................................................................................ 12
2.3.4 Software installation and uninstallation ........................................................................................................................ 12
2.3.5 Pure water filling .......................................................................................................................................................... 16
2.3.6 Discharge of waste liquid ............................................................................................................................................. 16
2.3.7 System login ................................................................................................................................................................. 17
2.3.8 Debugging of the Analyzer ........................................................................................................................................ 19
2.3.9 Test of clinical items .................................................................................................................................................... 20
2.3.10 Training for medical personnel ................................................................................................................................... 20
2.3.11 Fill-in of installation acceptance report ...................................................................................................................... 20
2.4 Bar code reader of sample/ reagent disk ...................................................................................................... 20
2.4.1 Scanning range of bar code reader................................................................................................................................ 20
2.4.2 Requirements for sample container .............................................................................................................................. 20
2.4.3 Requirements of reagent bottle ..................................................................................................................................... 20
2.4.4 Requirements for sample bar codes use ........................................................................................................................ 20
2.4.5 Requirements for reagent bar codes use ....................................................................................................................... 21
2.4.6 Requirements for pasting bar code labels ..................................................................................................................... 21
2.4.7 Use of bar code reader .................................................................................................................................................. 22
2.4.8 Rule of reagent bar codes ............................................................................................................................................. 22
Chapter 3 Introduction to unit modules .......................................................................................... 24
3.1 Optical unit ................................................................................................................................................. 24
3.1.1 Description of functions ............................................................................................................................................... 24
3.1.2 Diagram ........................................................................................................................................................................ 24
3.2 Probe unit ..................................................................................................................................................... 24
3.2.1 Description of functions ............................................................................................................................................... 24
3.2.2 Diagram ........................................................................................................................................................................ 25
3.2.3 Work process ................................................................................................................................................................ 25
3.3 Rinsing unit ................................................................................................................................................. 26
3.3.1 Description of functions ............................................................................................................................................... 26
3.3.2 Diagram ........................................................................................................................................................................ 26
3.3.3 Work process ................................................................................................................................................................ 26
3.4 Mixing unit ................................................................................................................................................. 28
3.4.1 Description of functions ............................................................................................................................................... 28
3.4.2 Diagram ........................................................................................................................................................................28
3.4.3 Work process ................................................................................................................................................................ 28
3.5 Reaction disk unit ......................................................................................................................................... 29
3.5.1 Description of functions ............................................................................................................................................... 29
3.5.2 Diagram ........................................................................................................................................................................ 29
3.6 Sample/ reagent disk driving mechanism ..................................................................................................... 30
3.6.1 Description of functions ............................................................................................................................................... 30
3.6.2 Diagram ........................................................................................................................................................................ 30
II

3.7 Refrigeration chamber ................................................................................................................................. 31
3.7.1 Description of functions ............................................................................................................................................... 31
3.7.2 Diagram ........................................................................................................................................................................ 31
3.7.3 Work process ................................................................................................................................................................ 31
Chapter 4 Fluid circuit and gas circuit of the Analyzer ................................................................. 32
4.1 Description of functions of fluid system ....................................................................................................... 32
4.2 Schematic diagram of integral fluid circuit and gas circuit ......................................................................... 33
4.3 Description of work process of gas circuit and fluid circuit system of the Analyzer ................................... 34
4.3.1 Liquid aspirating, dispensing and rinsing functions ................................................................................................... 34
4.3.2 Waste liquid collection and discharge of the Analyzer ............................................................................................... 35
Chapter 5 Electric circuit of the Analyzer ....................................................................................... 36
5.1 Electrical wiring diagram of the Analyzer ................................................................................................... 36
5.2 Functions of circuit boards ........................................................................................................................... 36
5.3 Electrical wiring diagram of circuit boards ................................................................................................. 38
5.3.1 Probe control board ...................................................................................................................................................... 38
5.3.2 Reaction disk control board .......................................................................................................................................... 38
5.3.3 AC control board ........................................................................................................................................................ 39
5.3.4 AC drive board ........................................................................................................................................................... 40
5.3.5 ISE control board (optional) ....................................................................................................................................... 41
Chapter 6 Components replacement and debugging ................................................................... 42
6.1 Replacement and debugging of commonly used components ...................................................................... 42
6.1.1 Halogen lamp replacement ........................................................................................................................................... 42
6.1.2 Replacement of optical unit ........................................................................................................................................ 43
6.1.3 Replacement and debugging of mixing bar ................................................................................................................ 47
6.1.4 Replacement and debugging of probe assembly ......................................................................................................... 49
6.1.5 Replacement of constant-temperature degassing system ............................................................................................ 50
6.1.6 Electrode replacement .................................................................................................................................................. 51
6.1.7 Replacement of tube for pinch valve .......................................................................................................................... 53
6.1.8 Replacement of Peltier of reagent disk ....................................................................................................................... 53
6.1.9 Replacement of heating window of sample reagent disk ............................................................................................ 54
6.1.10 Replacement of driving component motor ............................................................................................................... 55
6.1.11 Replacement of driving component optocoupler ...................................................................................................... 55
Chapter 7 Maintenance ..................................................................................................................... 56
7.1 System maintenance preparation ............................................................................................................... 56
7.1.1 Tools and instruments .................................................................................................................................................. 56
7.1.2 Pure water ..................................................................................................................................................................... 56
7.1.3 Detergent ...................................................................................................................................................................... 56
7.2 Application of "System Maintenance" window ........................................................................................... 57
7.2.1 Reset Analyzer ............................................................................................................................................................. 57
7.2.2 Check cuvette blank and light intensity ........................................................................................................................ 58
7.2.3 Exhaust air .................................................................................................................................................................... 60
7.2.4 Rinsing .........................................................................................................................................................................61
7.2.5 Mechanism check ......................................................................................................................................................... 63
7.2.6 Water quality check .................................................................................................................................................... 67
7.2.7 Bar code ....................................................................................................................................................................... 67
7.2.8 ISE ................................................................................................................................................................................ 68
7.3 System maintenance position and parts ....................................................................................................... 72
7.3.1 Clean, check and replace parts regularly .................................................................................................................... 72
7.3.2 Spare parts for regular replacement and maintenance .................................................................................................. 73
7.4 Maintenance methods ................................................................................................................................... 74
7.4.1 Probe ............................................................................................................................................................................ 74
7.4.2 Reaction disk ................................................................................................................................................................ 79
7.4.3 Light source lamp ......................................................................................................................................................... 84
7.4.4 Nozzles of rinsing mechanism ...................................................................................................................................... 84
7.4.5 Mixing bar .................................................................................................................................................................... 84
7.4.6 Cleaning refrigeration chamber .................................................................................................................................. 85
7.4.7 Syringe pump ............................................................................................................................................................. 86
7.4.8 Maintenance of the Analyzer before stop ..................................................................................................................... 86
7.4.9 Cleaning and maintenance of the Analyzer ................................................................................................................ 86
7.4.10 Waste liquid treatment .............................................................................................................................................. 87
7.4.11 Cleaning of pure water tank and filter ...................................................................................................................... 87
7.5 Maintenance of electrolyte device ................................................................................................................ 88
7.5.1 Clean, check and replace parts regularly .................................................................................................................... 88
7.5.2 Rinsing of ISE matching cuvette .................................................................................................................................. 89
7.5.3 Rinsing of ISE reagent tubing ...................................................................................................................................... 89
III

7.5.4 Rinse flow cell .............................................................................................................................................................. 89
7.5.5 Maintenance of CI electrode ...................................................................................................................................... 89
7.5.6 Rinsing of ISE waste liquid part ................................................................................................................................. 90
7.6 Scrapped analyzer ...................................................................................................................................... 91
Chapter 8 Fault analysis .................................................................................................................... 92
8.1 Causes and analysis of faults with alarm code ............................................................................................. 92
8.1.1 Main control module .................................................................................................................................................... 92
8.1.2 Reaction disk unit module ............................................................................................................................................ 99
8.1.3 Probe unit module ...................................................................................................................................................... 105
8.1.4 ISE unit module .......................................................................................................................................................... 135
8.1.5 AC unit module .......................................................................................................................................................... 136
Chapter 9 List of spare parts .......................................................................................................... 140
9.1 List of Easily-worn Parts and Consumables .............................................................................................. 140
9.1.1 List of Easily-worn Parts ............................................................................................................................................ 140
9.1.2 List of Consumables ................................................................................................................................................... 140
9.2 List of Maintenance Case ........................................................................................................................... 140
9.2.1 List of Small Maintenance Case ................................................................................................................................. 140
9.2.2 List of Big Maintenance Case .................................................................................................................................... 141
9.2.3 List of ISE Maintenance Case .................................................................................................................................... 142
9.3 List of frequently-used spare parts ............................................................................................................ 142
9.3.1 List of assembly spare parts ....................................................................................................................................... 142
9.3.2 List of switching power supply spare parts ................................................................................................................ 143
9.3.3 List of circuit board spare parts .................................................................................................................................. 143
9.3.4 List of sensor spare parts ............................................................................................................................................144
9.3.5 List of pump spare parts ............................................................................................................................................. 144
9.3.6 List of optocoupler spare parts ................................................................................................................................... 144
9.3.7 List of timing belt spare parts ..................................................................................................................................... 145
9.3.8 List of motor spare parts ............................................................................................................................................. 145
9.3.9 List of valve spare parts .............................................................................................................................................. 145
9.3.10 List of other spare parts ............................................................................................................................................ 145
9.4 Unit exploded drawing and spare parts list ............................................................................................... 146
9.4.1 Optical unit ................................................................................................................................................................. 146
9.4.2 Probe unit ................................................................................................................................................................... 148
9.4.3 Rinsing unit ................................................................................................................................................................ 152
9.4.4 Mixing unit ............................................................................................................................................................... 154
9.4.5 Reaction disk and driving mechanism ........................................................................................................................ 156
9.4.6 Sample/ reagent disk unit ......................................................................................................................................... 162
9.4.7 Constant-temperature degassing assembly ............................................................................................................... 170
9.4.8 Syringe pump unit ...................................................................................................................................................... 172
9.4.9 Valve group assembly .............................................................................................................................................. 174
9.4.10 Waste liquid assembly .............................................................................................................................................. 176
9.4.11 Waste liquid tank assembly .................................................................................................................................... 178
9.4.12 Pure water unit ....................................................................................................................................................... 180
9.4.13 Detergent tank assembly ......................................................................................................................................... 182
9.4.14 Cover plate assembly ................................................................................................................................................ 184
9.4.15 ISE unit..................................................................................................................................................................... 192
9.5 Pipeline diagram and spare part codes list ............................................................................................... 208
9.6 Accessories case exploded drawing and spare parts list ............................................................................ 212
9.6.1 Accessory case ........................................................................................................................................................... 212
9.6.2 Accessory case Layer 2 .............................................................................................................................................. 214
9.6.3 Accessory case Layer 3 .............................................................................................................................................. 216
9.6.4 Accessory case Layer 4 .............................................................................................................................................. 218
Chapter 10 Manual revision and change record ........................................................................... 220

Service Manual of Auto-Chemistry Analyzer


Chapter 1 Overview of the Analyzer
1.1 System overview
 The Auto-Chemistry Analyzer (model: CS-T180) is a discrete type modular analyzer with an external computer and it
is used for emergency treatment with priority.
The Analyzer has functions including automatic sample dispensing, reagent dispensing, interference shielding, mixing,
preheating, reaction monitoring, rinsing and results calculation, display and printing. It fully imitates and substitutes
manual operation, which not only improves work efficiency, but also reduces test error and improves the accuracy and
precision of test results.
Scope of application: Quantitative analysis of clinical chemical components such as serum, plasma, urine and cerebrospinal
fluid.

1.2 Structure and introduction of the Analyzer
1.2.1 Structure of the Analyzer
3
5 1
24
6

Fig. 1-2-1 Structure of the Analyzer
No. Name No. Name
1 Probe Unit 4 Rinsing Unit
2 ISE Module (Optional) 5 Mixing Unit
3 Sample /Reagent Disk 6 Reaction Disk

1
Service Manual of Auto-Chemistry Analyzer


1.2.2 Front view (without shield) of the instrument
4
1
2
3
5
6
7
9
8
10

Fig. 1-2-2 Front view (without shield) of the Analyzer
No. Name No. Name
1 Mixing Unit 6 ISE Reagent Tank Assembly (Optional)
2 Bar Code Reader Assembly (Optional) 7 Alkaline Detergent Bottle
3 Power Drive Board 8 Rinsing Unit
4 Reaction Disk Control Board 9 Observation Window of Syringe Pump
5 Group Valve Assembly 10 Probe Unit

1.2.3 Rear view (without shield) of the instrument
8
13
1
2
3
4
5
7
6
9
12
10
11
14
15

Fig. 1-2-3 Rear view (without shield) of the instrument

2
Service Manual of Auto-Chemistry Analyzer


No. Name No. Name
1 Syringe Pump Unit 9 ISE Control Board (Optional)
2 Pump Assembly (ISE Optional) 10 Waste Liquid Float Socket
3 ISE Reagent Tank Assembly (Optional) 11 Pure Water Float Socket
4
Constant-temperature Degassing
Assembly
12 Network Interface
5 Valve Assembly (ISE Optional) 13 Switch Power Supply Assembly
6 Water Outlet Connector Assembly 14 AC Control Board
7 Waste Liquid Tank Assembly 15 Probe Control Board
8
Amplification Board Assembly (ISE
Optional)


1.2.4 Left view (without shield) of the Analyzer
1
2
3
4

Fig. 1-2-4 Left view (without shield) of the Analyzer
No. Name No. Name
1 Halogen Lamp Assembly 3 AD Board Assembly
2 Alkaline Detergent Bottle Assembly 4 Fan of the Analyzer

3
Service Manual of Auto-Chemistry Analyzer


1.2.5 Right view (without shield) of the Analyzer
5 466
1
3
2

Fig. 1-2-5 Right view (without shield) of the Analyzer
No. Name No. Name
1 Fan of the Analyzer 4 Power Switch of Analyzing Module
2 Power Indicator Lamp 5 Test System Assembly (ISE Optional)
3 General Power Switch 6 Refrigeration Fan

1.3 Working principle
1.3.1 Analysis process
The test flow is shown in the figure below:Fig. 1-3-1 Analysis process
Notes:
Taking reaction time as 13.5min as an example.
4
Service Manual of Auto-Chemistry Analyzer


1.3.2 Characteristics of photometry
The Analyzer applies the whole-process photometry method. That is, the absorbance of reaction solution is
continuously measured in the 13.5min reaction time. The absorbance of 56 cuvettes will be measured one by one
when they pass the optical axis of photometer. The absorbance of each cuvette will be measured for 40 times (40 test
points) in the 13.5min reaction time. The polychromatic light from the light source will be focused by the lens and
then pass the cuvette used for photometry. The wavelength after light split will be absorbed simultaneously by 12
fixed photoelectric sensors and amplified by 12 amplifiers respectively. Then, the absorbance or absorbance change
rate will be calculated. When dual-wavelength test is applied, as the difference of the absorbance or the difference of
absorbance change rate of main wavelength and complementary wavelength is used to calculate the concentration,
dual-wavelength test not only makes compensation to the sample test of lipemia, hemolysis and icterus but also
compensates the effects caused by voltage variation, making the test values more accurate and stable. The test
principle is shown in figure below:

Fig. 1-3-2 Diagram of photometer
Detector
Concave
diffraction
grating
12 fixed
wavelengths
Cuvette
Light source
lamp
5
Service Manual of Auto-Chemistry Analyzer

Chapter 2 Analyzer Installation

The Analyzer and bundled software can only be installed by Dirui or its authorized personnel.
2.1 Installation requirements

Please install the Analyzer at places meeting following requirements, or its performance may not be
guaranteed.
2.1.1 Space requirements
The installation and use of the Analyzer shall meet following requirements,
(Dimensions( mm)：744×703×530(L×W×H)):

Fig. 2-1-1 Top view of installation space

Do not put the Analyzer at a place where the disconnecting device is hard to be operated.
2.1.2 Environmental requirements
(1)Environmental temperature: 15℃~32℃.
(2)Relative humidity: not greater than 75%.
(3)Atmospheric pressure: 75kPa~106kPa.
(4)The Analyzer shall be put in a dust-free environment with good ventilation but no mechanical vibration, no source
of large noise or power interference.
(5)Do not put the Analyzer near brush motor, scintillant fluorescent lamp and electrical contact equipment often used.
(6)The Analyzer shall be prevented from direct sunlight exposure and not be placed near heat and wind sources.
(7)The maximum volume of the area 1m away from the Analyzer shall be at 70dB.
(8)The worktable shall be flat and able to bear a weight of greater than 150kg. (The Analyzer shall not be
disassembled into several independent parts and weight of major components are not shown)

● If the temperature and the humidity cannot meet requirements above, air conditioner shall be used.
● In the operating process, the Analyzer will generate heat and exhaust the heat at the back. The working
6
Service Manual of Auto-Chemistry Analyzer

environment should be kept well ventilated, and ventilating device should be used if necessary. But the
Analyzer should be protected from the direct airflow, otherwise, the test accuracy may be affected.
2.1.3 Power requirements
(1)Power voltage: 100V-240V~ 50/60Hz.
(2)Power consumption: 600VA.
Notes:
During normal operation, the Analyzer has power consumption smaller than the rated maximum power
consumption because:
● the refrigeration and heating systems do not work continuously after the Analyzer becomes stable. Thus the
power consumption will decrease.
● the power components of the Analyzer work at a different time rather than work simultaneously.
(3)Fuse: F6.3AL250V 5mm×20mm.
(4)To ensure the reliable operation of the Analyzer, a 20A switchboard shall be used for the Analyzer and three 5A
receptacles shall be used for the display, and printer; the equipment with a heavy load such as air conditioners and
refrigerators shall not be plugged into the same socket.

● The power source shall be properly grounded, otherwise, operators may get an electric shock and the
system may get damaged.
● The receptacle connected with power cable shall be placed near the Analyzer and easily disconnected.
● Input voltage of the Analyzer shall meet the requirement. It is recommended that the hospital prepares a
3kVA or 6kVA online UPS power source.
2.1.4Requirements for pure water
The peak water consumption of the Analyzer is about 3L per hour. Pure water and pure water tank shall meet the
following conditions:
(1)The electric conductivity of the pure water shall be smaller than 1μs/cm.
(2)Pure water temperature is 15℃~30℃.
(3)The pure water tank provided with the Analyzer shall be placed on the ground and the tubing connected with the
Analyzer shall be within 1.5m.
(4)The water supply capacity of the pure water tank shall be above 5L/h.
2.2 Unpacking
2.2.1 Unpacking steps
After the arrival of the Analyzer, please carefully check the package of the Analyzer. If it is damaged, please contact
Dirui or the local distributor. If the package is intact, please unpack the Analyzer by following the steps below.
(1)Put the box in the direction pointed by the arrow.
(2)Open the box of accessories and check objects in the box according to the packing list. In case of items missing,
please fill it in the Installation Acceptance Report and contact Dirui or the local distributor.
(3)Open the Analyzer with appropriate tools in the accessory box, inspect the appearance of the Analyzer carefully,
and then check according to the packing list. In case of damages in carrying or shortage of parts, please fill it in the
Installation Acceptance Report and contact Dirui or the local distributor.
2.2.2 Way of carrying
(1)Push directly during a stable transportation in short distance.
(2)The Analyzer should be maintained upright when handling and transporting.
(3)Try to avoid vibration when handling.

7
Service Manual of Auto-Chemistry Analyzer

As the Analyzer is stationary equipment, it shall not be moved in a normal working process and no supporting
device for lifting and carrying is provided.
2.3 Installation process
2.3.1 Installation of the Analyzer
(1)Put the Analyzer at an appropriate position and adjust the levelness of the Analyzer.
(2)Install a probe and check whether the probe mechanism is able to move flexibly.
(3)Install the cuvette.
(4)Dispense 1000mL alkaline detergent to the alkaline detergent bottle, open the alkaline detergent replacement
window at the left side of the Analyzer, put the alkaline detergent bottle inside the Analyzer and install the tubing and
float.
(5)Connection of pure water tubes
Dispense 10L pure water with conductivity less than 1μs/cm in pure water tank, use the pure water supply tube
(within 1.5m) to connect the outlet connector of the pure water tank with the pure water dispensing port (1 in Fig.
2-3-1) on the rear cover of the Analyzer, and then use the pure water float switch to connect the pure water tank with
the pure water liquid level switch (5 in Fig. 2-3-1) on the rear cover of the Analyzer.

Fig. 2-3-1
(6)Connection of waste liquid tubes
a)High-concentration waste liquid outlet tubing: connect one end of waste liquid connecting tube with the
connector of "high-concentration waste liquid outlet" (3 in Fig. 2-3-1) on the rear cover of the Analyzer (with
another end inserted on the connector of the waste liquid tank).
b)Low-concentration waste liquid outlet tubing: connect the other end of waste liquid connecting tube with the
connector of "low-concentration waste liquid outlet" (2 in Fig. 2-3-1) on the rear cover of the Analyzer (with
another end inserted on the connector of the waste liquid tank or the drainage system.
c)Liquid level sensor connection:insert one end of the waste liquid level sensor to the "Waste liquid level sensor
port" (6 in Fig. 2-3-1) on the rear cover of the Analyzer and install the other end in two waste liquid tanks. SW4 is
a high-concentration waste liquid level sensor and SW7 is a low-concentration waste liquid level sensor.

● Low-concentration waste liquid tube outlet shall not be immersed below the liquid level.
● The low-concentration waste liquid tubing must not be bent or swung. It should be flat like a parabola.
● The waste liquid tank should be 0.8m~1m lower than the host.
● Don't combine high and low concentration waste liquid tubing.
● The discharge of the high-concentration waste liquid shall observe the local medical waste treatment
8
Service Manual of Auto-Chemistry Analyzer

regulations.
● The drainage system shall be in compliance with the local regulations with regard to sewage discharge and
treatment of medical institutions.
(7)Install ISE electrode (optional)

Make sure that the storage temperature of the electrode is at 1℃~51℃.
a)Open ISE maintenance window on the right cover:

Fig. 2-3-2
b)Screw off the flow cell set screws on electrode assembly to lift up electrode assembly as shown in the figure
above.
c)Screw off nuts K, Cl, Na and NaREF on the flow cell (as shown in Fig. 2-3-3), take off the matching seal plugs
and seal rings; nuts K, Cl, Na and NaREF are kept for installing electrodes Cl, K, Na and NaREF, and the matching
seal rings are for no other uses and can be handled by users themselves. (See Fig. 2-3-4 for removed seal plugs and
matching seal rings):

If the seal ring on the seal plug falls into flow cell by accident, please take it out with a cotton swab (do not use
the hard material to take it out directly).

1 K-nut, K-seal plug, seal ring 2 Cl-nut, Cl-seal plug, seal ring 3 Flow cell
4 Na-nut, Na-seal plug, seal ring 5 NaREF-nut, NaREF-seal plug, seal ring
Fig. 2-3-3
3
2
1 5
4
9
Service Manual of Auto-Chemistry Analyzer


 1 Seal ring 2 Seal plug 3 Nut
Fig. 2-3-4
d)The packages of electrodes Cl, K, Na and NaREF are as shown in the figure below. The electrodes shall be
installed in accordance with the instruction on the package box of each electrode to prevent any installation faults.

1 The packaging of Na electrode (NaREF electrode) 2 The packaging of CI electrode
3 The packaging of K electrode tip 4 The packaging of K electrode
Fig. 2-3-5
e)Install electrodes Cl, K, Na and NaREF (same as electrode Na) on the flow cell according to following steps:

Place O-seal ring properly during the installation (#4 in Fig. 2-3-6) to prevent the loss.
Unpack the package of K electrode tip and K electrode wire, and take out the electrode and related accessories
in the package.
Install O-seal ring (#4 in Fig. 2-3-7) on the K electrode wire smoothly, wring K electrode tip (#10 in Fig. 2-3-7)
on K electrode wire, and then install the seal ring of the electrode (#9 in Fig. 2-3-7) on the K electrode tip
smoothly to compose electrode K (the installation method as shown in Fig. 2-3-7).
Wipe the liquid in electrode holes on the flow cell clean with a cotton swab; wipe the electrode clean with a
cotton swab as well.
Put the electrode K through nuts (as shown in Fig. 2-3-7), ensure that the seal ring of the electrode is installed
on the K electrode tip smoothly, and wring the installed electrode assembly on the flow cell.

Lock nuts by hands with moderate strength during electrode installation.
1 2 3
10
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-6

Fig. 2-3-7
1 K nut 2 Cl nut 3 Cl electrode 4 O-seal ring 5 Na electrode 6 Na nut
7 Na nut 8 Na electrode seal 9 the electrode seal ring 10 K electrode tip 11 K electrode wire
Install electrodes Cl, Na and NaREF on flow cell at the corresponding positions as per the method above.
f)Connect the other end of the flow cell with electrodes Cl, K, Na and NaREF installed on one end and the
preamplifier board connector as shown in the figure below:

1 NaREF electrode connector 2 Cl electrode connector
3 K electrode connector 4 Na electrode connector
Fig. 2-3-8
Note:
Differences between the electrodes are as follows:
 1 11 4 10 9
1 11
2 3
4
5 6
7 8 9 10
11
Service Manual of Auto-Chemistry Analyzer

● K electrode tip is removable;
● The surface of electrode Na is made of glass;
● The surface of electrode CI is made of metal.
g)Push the electrode assembly back to original position and install it with the set screws.
h)Install the ISE electrode on the platform and replace the cover plate and set screw.
2.3.2 Power connection

Before power connection, ensure the main power switch (circuit breaker) of the Analyzer is at OFF position.
The Analyzer is accompanied with three-core power cable, wherein the red one is the live cable, the blue one is the
neutral cable and the yellowish green is the ground cable, and the rated temperature of the three-core power cable is
70℃.
2.3.3 Connection of peripheral equipment
(1)Install and connect the computer, display and printer and check:
a)Whether the printer driver is installed.
b)Specification of printing papers used in the printer.
(2)One end of the cable that is carried along with the computer is plugged onto the network interface of the Analyzer
and the other end is plugged onto the network interface of the host computer.
2.3.4 Software installation and uninstallation
2.3.4.1 Software installation
Put the Analyzer installation disk in computer CD driver, and run the setup.exe file, and the interface is as shown
below:

Fig. 2-3-9
Select the installation program language, then click "OK" and the display is as shown below:
12
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-10
Click "Next", and the display is as shown below:

Fig. 2-3-11
To change the installation path, click "Browse" in the figure above to select the installation path; click "Next" to use
the default installation path and the display is as shown below:
13
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-12
Click "Finish" to finish the software installation, and the icon of the application software will be generated on the
desktop automatically.
2.3.4.2 Software uninstallation
Method I: select "Automatic test analyzer" in "Programs and Features" on computer control panel, click to select "
", and the figure below pops up:

Fig. 2-3-13
14
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-14
Click "Next", and the display is as shown below:

Fig. 2-3-15
Click "Yes", and the display is as shown below:
15
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-16
Click "Finish" to finish uninstalling the Analyzer software.
Method II: click "Start", find out "Auto-Chemistry Analyzer" in "Programs" and then click "Uninstall CS-T180
Auto-Chemistry Analyzer", and an uninstallation confirmation window appears. The uninstallation process is the
same as Method I.
2.3.5 Pure water filling

Fig. 2-3-17
1
2
1
3
4
5
16
Service Manual of Auto-Chemistry Analyzer

If it is necessary to use the pure water tank to take away the pure water for filling, from the pure water tank take out
the pure water float switch (#3 as shown in Fig. 2-3-17), remove the water tube (#2 as shown in Fig. 2-3-17) and tank
cover (#4 as shown in Fig. 2-3-17) and place them on somewhere clean to use the pure water tank (#5 as shown in Fig.
2-3-17) to take away the pure water for filling and install the parts above successively on the pure water tank after the
filling; if it is unnecessary to use the pure water tank to take away the pure water for filling, remove the tank cover (#4
as shown in Fig. 2-3-17) directly and place the tank on somewhere clean to fill pure water in the pure water tank.● Every month as pure water is filled, when removing the water pipe (Fig. 2-3-17, No. 2), observe whether
there is any hair, wire, and other debris in the filter of the end of observation part 2. If there is, the filter
should be removed and rinsed. If it cannot be rinsed clean, replace the new filter.
● The removed immersed tube shall not be thrown with force to prevent a large volume of air from entering in
the tube or the thrown liquid from injuring personal safety.
2.3.6 Discharge of waste liquid
See "2.3.1 Analyzer installation" for specific discharge of waste liquid in waste liquid tank.

● Low-concentration waste liquid tube outlet shall not be immersed in liquid level.
● The low-concentration waste liquid pipeline must not be bent or swung. It should be flat like a parabola.
● Don't combine high and low concentration waste liquid tubing.
● The discharge of the high-concentration waste liquid shall observe the local medical waste treatment
regulations.
● The drainage system shall be in compliance with the local regulations with regard to sewage discharge and
treatment of medical institutions.
2.3.7 System login
Connect the power sources of the water purifier, computer host, computer display and printer and analyzing module
(at the front right side) of the Analyzer as well as the main power source of the Analyzer (at the rear right lower side
of the Analyzer).
Double click the icon " " of Analyzer application software (hereinafter referred to as software); or click "Start",
find the Analyzer software on "Program" window and click it to enter the "System login" window, and the display is
as shown below:

Fig. 2-3-18
17
Service Manual of Auto-Chemistry Analyzer


Fig. 2-3-19
Input correct user name and password (the initial user name of the Analyzer software is 1 and the initial password is
1), click "Login" or Enter key on the keyboard to enter the main window of the software, and the display is as shown
below:

Fig. 2-3-20
After the software is logged in successfully, the offline status is displayed. Then you can browse the function
window, check the alarm information, and execute logout and exit.
On the interface as shown in Fig. 2-3-19, if the wrong user name and password are input, a login failure prompt will
be given on the screen and the display is as shown below:

Fig. 2-3-21
If wrong user name or password is input for three continuous times, a prompt of "Login failure for 3 times and the
program will be terminated" will be given. Exit the program after the confirmation.
18
Service Manual of Auto-Chemistry Analyzer

The function keys in the interface as shown in Fig. 2-3-20 are as follows:
(1)Online: click " " and after successful network connection, " " will be
displayed on the status bar at the upper left corner. Now all the operations are available.
If after software login, power source of the analyzing module of the Analyzer is disconnected or the analyzing
module is not correctly connected with the operation unit, click "Online", "Connecting" is displayed on the status bar
and "Online failure" (on the lower left corner of the screen) is displayed a few seconds later.
If above prompt is given, connect the analyzing module and operation unit of the Analyzer correctly, connect power
source of the analyzing module and then connect the network.
(2)Exit the system: click " " in the shortcut keys area to enter the window of "Exit the system" as shown in the
figure below:

Fig. 2-3-22
Click " " to exit the software system.
The exit can only be carried out under the offline status, and if the Analyzer is online, click " " first to go offline
and then exit the system.
(3)Switch the user: click " " to switch users and the display is as shown below:

Fig. 2-3-23

●When the testing doctor is having a rest, it is recommended to exit the software to prevent nonusers from
destroying the software or modifying data. Users are recommended to back up the database regularly to
prevent accidental data loss.
● After the initial user name and password are input for the first-time login, set the user name, password and
access right in the "User information" of "System management" for the next login.
The Analyzer will be under the standby status 40 minutes after the power source connection (waiting for the
temperature and the light source to be stabilized).
19
Service Manual of Auto-Chemistry Analyzer

2.3.8 Commissioning of the Analyzer
Conduct following operations on the System maintenance interface in the sequence below.
(1)ISE syringe pump exhaust
Execute ISE syringe pump exhausts to exhaust the air in the tubing.
(2)Probe horizontal check
Confirm that the probe is at the correct position above the cuvette, rinsing bath, sample reagent disk outer circle,
sample reagent disk middle circle, sample reagent disk inner circle, ISE adding position (with ISE module).
(3)Mixing bar horizontal check
Confirm that the mixing bar is at the upper position of the cuvette and the rinsing bath by the mixing bar horizontal
check.
(4)Mechanical motions check
Execute 20 mechanical motions checks to confirm if the wiping block on the nozzle of the rinsing mechanism abrades
the cuvette and if each mechanism operates normally.
(5)Rinsing cuvettes and ISE
Rinse cuvettes via the window of "System maintenance". To configure ISE device, carry out rinsing ISE tubing and
rinsing ISE cuvette maintenance operations on ISE maintenance interface.
(6)Light intensity check
Execute the light intensity check and attach the result in the acceptance report. The light check value shall be less than
or equal to 18000.
(7)Cuvette blank test
Execute the cuvette blank test, and the cuvette blank test value of Cuvette 1 shall be in the range of 8000-18000, and
the difference between other cuvettes and Cuvette 1 in blank shall be in the range of -1500~1500.
(8)ISE check
Execute 50 ISE checks on the "System Maintenance" window. The difference between two adjacent values of the test
results shall not be more than 0.2 mV.
2.3.9 Test of clinical items
Edit chemical parameters, register reagent information, test rate assay ALT and endpoint assay TP and two-point rate
assay UREA, calculate coefficient of variation and fill the test results in Installation Acceptance Report.
2.3.10 Training for medical personnel
Conduct training on the operation and maintenance of the Analyzer for medical personnel and record the training in
Installation Acceptance Report.
2.3.11 Fill-in of installation acceptance report
Fill in the Installation Acceptance Report completely and send one copy to Dirui or the local distributor.
2.4 Barcode reader of the sample reagent disk
2.4.1 Scanning range of barcode reader
The internal barcode reader (optional) can simultaneously scan the outer circle and inner circle of the sample reagent
disk. When scanning the inner circle, the inner circle reagent disk or tube needs to be removed.
2.4.2 Requirements for sample container
(1)Specifications:
Test tube: Φ12mm×75mm, Φ12mm×100mm, Φ13mm×75mm, Φ13mm×100mm(±1 mm)
Standard cup: Φ14mm×37mm(±1 mm)
(2)The tube mouth shall be regular without extrusion or deformation.
20
Service Manual of Auto-Chemistry Analyzer

2.4.3 Requirements of reagent bottle
Specification: 70mL, 35mL and 20mL.
2.4.4 Requirements for sample barcodes use
(1)Barcode type: Code 128, Code 39, Code 93, Codebar, I2 of 5.
(2)Size of barcode label:
It is required the width of the barcode should be 8mm~12mm and its effective length should not be greater than
40mm. During the cutting, the start blank and end blank of the barcode shall not be smaller than 3mm as shown in the
figure below:
Barcode width
Start blank
Effective length of
barcode End blank
Fig. 2-4-1
(3)See Table 2-4-1 for number of digits of different barcodes.
Table 2-4-1
Type of sample barcodes Number of identification digits
Code39 3~18
Code93 3~18
Code128 3~18
I2of53~18
Codebar 3~18
2.4.5 Requirements for reagent barcodes use
(1)Barcode type: code 128 (17 bit).
(2)Size of barcode label: it is required the width of the barcode should be 12mm~25mm and its effective length
should not be greater than 40mm (as shown in Fig. 2-4-1).
(3)During the cutting, the start blank and end blank of the barcode shall not be smaller than 3mm (as shown in Fig.
2-4-1).

● Codebar must be prefixed and suffixed with A, B, C or D and the barcode shall not have characters such as
' ', " " and ( ), or it cannot be normally identified.
● The length of barcode suffixed with NR shall not be less than 5.
2.4.6 Requirements for pasting barcode labels
(1)Barcode label shall be pasted in a flat manner without crumple and pollution and the print of barcode lines cannot
be incomplete as this may lead to incorrect reading.
(2)Pasting of barcodes
The lower edge of the barcode shall be 15mm~20mm from the tube bottom to ensure correct reading of the barcode.
21
Service Manual of Auto-Chemistry Analyzer

When the test tube is inserted in the sample, reagent disk test tube rack, it shall be ensured the barcode faces the
opening of the sample position. The pasting method of sample barcodes is shown in the figure below:

Fig. 2-4-2 Pasting of sample barcodes

The ID number on the screen after the scanning or on the report shall be added with "+" before the
corresponding capital letters if the barcodes are small in Code 39.
2.4.7 Use of barcode reader
If "Sample barcode number" is selected under sample test mode on "Other information" interface of the "System
Setting" window before the analysis, the sample, reagent disk will stop rotating at the position of the barcode reader
after the test is started and the barcode reader will read the barcode according to the set sample position. The reader
will scan for three times if the barcode cannot be read during the scanning. Sample tests cannot be conducted during
barcode scanning and the tests can only be conducted after the scanning. The sample, reagent disk will turn to the
reading position of the barcode reader to conduct barcode scanning after the probe finishes dispensing samples. After
scanning barcodes, the sample, reagent disk will return to the dispensing position to continue the sample dispensing.
The scanned information will display on the windows of "Sample registration" and "Test result".
During the sample reagent disk barcode reader check on the "System maintenance" window, the barcode reader
identifies barcode information of samples at reagent disk position 1, outer 1, and inner 2, and a prompt of success or
failure is then given after the scanning.
Only after the barcode is pasted at the opening of the sample, reagent disk for the test tube to be pasted with barcode
can the barcode be identified.
2.4.8 Rule of reagent barcodes
Users may prepare the barcode numbers as the case may be. The rule is as shown in Table 2-4-2:
Table 2-4-2
Barcode
digit
Barcode
information
Scope of barcode
value Detailed explanations of barcodes Note
1~2 Item name
0~94 Item code of biochemical reagent (representing different item names)
95 ISE Internal Standard Solution
96 ISE Diluent
97 ISE Reference Solution
98 CS series anti-bacterial phosphor-free detergent
99 CS-alkaline detergent
3 Bottle specification
1 20mL
2 70mL
3 100mL
4 500mL
5 2000mL
6 5000mL
7 150mL
8 40mL(CS-T300B) 35mL(CS-T180)
22
Service Manual of Auto-Chemistry Analyzer

Barcode
digit
Barcode
information
Scope of barcode
value Detailed explanations of barcodes Note
4 Reagent types
1 R1
2 R2
3 R3
4 R4
5 None
The reagent type must be 5 if
the item code is ISE reagent or
CS series detergent.
5~9
Date of
manufacturer
(Lot No.)
0~9 Year
01~12 Month
01~31 Day
10 Validity
1 2 weeks
2 1 month
3 3 months
4 6 months
5 12 months
6 18 months
7 2 years
8 3 years
9 5 years
11~14 Bottle code 0001~9999 Bottle No. (bottle XXXXX)
15~17 Check bit
Number or letters
(automatically
generated)

The reagent barcode information is read by the barcode reader, and coupled with parameters of all analysis items
already saved by the Analyzer. This process is called reagent automatic registration. That is to say, the relevant
reagent information can be determined by barcode scanning.
The information which has already been read will display on "Reagent information" window in forms of "Disk No.",
"Position", "Reagent name" and "Type".
Reagent name: the chemical names of analysis items.
Reagent position: there are outer 01~40 positions on sample reagent disk middle circle (when executing system
maintenance, outer position 01 defaults to CS-anti-bacterial phosphor-free detergent; when executing
cross-contamination avoidance, it’s required to register the detergent position in the “Reagent Registration” window )
to place reagent for automatic barcode scanning. There are 01~40 positions on the inner circle. Automatic barcode
scanning is not available for reagents on sample reagent disk inner circle under the condition that the middle circle is
filled with reagent and the reagent information can only be manually registered.

The reading window of the barcode readers of sample and reagent disks shall be regularly cleaned.

23
Service Manual of Auto-Chemistry Analyzer

Chapter 3 Introduction to unit modules
3.1 Optical unit
3.1.1 Description of functions
 The halogen lamp, after light convergence by lens, shines the cuvette with sample and then to the optical grating after
light convergence by lens. The optical grating divides the light of halogen lamp of full spectrum into monochromatic light
of different wavelength necessary for the test and then has signal conversion and testing with a photocell.
3.1.2 Diagram
1
2
5
3
6
7
4

Fig. 3-1-1 Structure of optical unit
No. Name No. Name
1 Raster Box 5 Data Collection Board
2
Front Microscope Base Assembly of
Reflector
6 Wire P514
3 Halogen Lamp Assembly 7 Wire B06-P4
4 Fan

3.2 Probe unit
3.2.1 Description of functions
Probe unit can realize basic functions of aspirating samples from the sample test tube and aspirating reagent
from the reagent bottle, as well as the function of adding samples and reagent into the cuvette.
Other auxiliary functions include liquid level detection, collision detection in the moving process, automatic
recovery, mechanical limit, self-locking and interlocking control.
24
Service Manual of Auto-Chemistry Analyzer

3.2.2 Diagram
1
2
3
4
5
7
6

Fig. 3-2-1 Structure of probe unit
No. Name No. Name
1
Positioning Optocoupler for Probe
Swinging
5
Positioning Optocoupler for Probe
Lifting and Descending
2 Stepper Motor for Probe Rotation 6 Probe
3
Stepper Motor for Probe Lifting and
Descending
7 Probe Rotary Arm
4
Gear Toothed Belt for Probe Lifting and
Descending

3.2.3 Work process
(1) Pump zeroing and rinsing of inner and outer walls;
(2) Aspirate 3ul air;
(3) Rotate to the position above the reagent/sample disk;
(4) Descend and insert into the reagent bottle for about 2mm lower than the liquid level;
(5) Aspirate samples of set volume + excessive volume and withdraw;
(6) Lift from the reagent bottle and rotate to the position above rinsing bath to rinse outer wall;
(7) Aspirate 3ul air;
(8) Rotate to the position above the reagent/sample disk;
(9) Aspirate sample of set volume;
(10) Lift from the sample cuvette or tube and rotate to the position above reaction disk;
(11) Dispense the sample or reagent into the cuvette;
(12) Rotate from the position above the cuvette to the position above rinsing bath.

25
Service Manual of Auto-Chemistry Analyzer

3.3 Rinsing unit
3.3.1 Description of functions
Rinsing unit mainly performs to rinse the cuvette to make the cuvette can be cycled.
3.3.2 Diagram1
23
4
5
6

Fig. 3-3-1 Structure of rinsing unit
No. Name No. Name
1 Rinsing Probe 4 Rinsing Probe Support
2 Lifting Assembly 5 Wiping Probe
3 Lifting Motor 6 Rinsing Probe Fixing Rack
3.3.3 Work process
Cuvette rinsing process:
Step 1: Probe 1 aspirates reaction mixture, and then dispenses detergent to the cuvette;
Step 2: Probe 1 aspirates detergent solution, and then dispenses detergent solution to the cuvette;
Step 3: Probe 2 aspirates detergent solution, and then dispenses pure water to the cuvette;
Step 4: Probe 2 aspirates pure water, and then dispenses pure water to the cuvette;
Step 5: Probe 3 aspirates pure water, and then dispenses pure water to the cuvette, and execute this step;
Step 6: Wiping probe aspirates pure water;
Step 7: Wiping probe wipes the cuvette.
26
Service Manual of Auto-Chemistry Analyzer


Fig. 3-3-2 Rinsing probe arrangement of rinsing unit

Fig. 3-3-3 Work flow of rinsing unit

Wiping
Probe
Rinsing
Probe 3
Rotating direction of reaction disk
Rinsing
Probe 2
Rinsing
Probe 1
27
Service Manual of Auto-Chemistry Analyzer

3.4 Mixing unit
3.4.1 Description of functions
After sample and reagent injection and filling, it is used to mix them.
3.4.2 Diagram
1
2
3
4
11 7
10
6
8
9
5

Fig. 3-4-1 Structure of mixing unit
No. Name No. Name
1 Mixing Support Arm 7 Flange Bearing
2 Mixing Bar 8 Sliding Block
3 Mixing Supporting Shaft 9 Bearing
4 Encoding Disk Motor Cover 10 Base
5 Swinging Motor 11 Lifting Motor
6 Support Rod
3.4.3 Work process
(1) Rotate to the position above the reaction disk;
(2) Descend and insert into cuvette;
(3) Mix the reaction solution;
(4) Lift from the cuvette and rotate to the position above rinsing bath;
(5) Descend to rinsing bath;
(6) Rinse the mixing bar;
(7) Lift from the rinsing bath.

28
Service Manual of Auto-Chemistry Analyzer

3.5 Reaction disk unit
3.5.1 Description of functions
The cuvette unit is mainly used to support the fixed cuvette and drive the rotary movement of cuvette in
incubation bath.
3.5.2 Diagram
3
1
4 2

Fig. 3-5-1 Structure of incubation bath assembly
No. Name No. Name
1 Fan 3 Overflow Connector
2 Optocoupler 4 Disk Cover Pin

1
2
3
4
5
6

Fig. 3-5-2 Structure of driving mechanism
No. Name No. Name
1 Motor Gear 4 Damping Device Assembly
2 Disk Drive Support 5 Gear Disk
3 Stepper Motor 6 Support Column
29
Service Manual of Auto-Chemistry Analyzer

3.6 Sample/ reagent disk driving mechanism
3.6.1 Description of functions
 The sample/ reagent disk rotating mechanism mainly performs to support the sample/ reagent disk rack and
transmits the power to the sample rack through the central shaft and timing belt and synchronous pulley to realize the
rotating of reagent/ sample rack. The reagent is sent to a designated position to coordinate to finish sampling, mixing
and rinsing.
3.6.2 Diagram
2
3
8
5
6
7
1
4

Fig. 3-6-1 Structure of sample/ reagent disk driving mechanism
No. Name No. Name
1 Reagent Disk Connecting Sleeve 5 Drive Motor
2 Insulation Cover 6 Disk Rotation Support
3 Connection Fixing Column 7 Belt Pulley
4 Sample Timing Encoding Disk 8 Timing Belt

123

Fig. 3-6-2 Structure of driving mechanism coded disc
No. Name No. Name
1 Sample Timing Encoding Disk 3 Original Point Optocoupler
2 Position Optocoupler


30
Service Manual of Auto-Chemistry Analyzer

3.7 Refrigeration chamber
3.7.1 Description of functions
 Refrigeration chamber is the main body of sample/ reagent disk unit. Semiconductor is used for refrigeration and
the temperature is held at 2 ~12 . Each reagent disk has 40 reagent and 40 sample positions on its circumference ℃ ℃
(CS series anti-bacterial phosphor-free detergent is put at No. 1 position).
3.7.2 Diagram
2
5
4
1
3

Fig. 3-7-1 Structure of refrigeration bin
No. Name No. Name
1 Disk Body 4 Radiator
2
Sample/ Reagent Disk Drive
Mechanism
5
Scanning Window of Sample Bar Code
Reader
3 Cooling Fan
3.7.3 Work process
 The refrigeration disk includes the reagent/ sample rack inside to form an enclosed environment. Heat
preservation cotton is set at outer circle and temperature in disk is kept unchanged. The radiator exports the outside
heat from Peltier to make the Peltier temperature will not be too high, so as to realize temperature reduction of the
reagent. The fan exports the heat from radiator through the front and rear ventilation shield and exhausts it to outer
instrument.
31
Service Manual of Auto-Chemistry Analyzer


Chapter 4 Fluid circuit and gas circuit of the Analyzer
4.1 Description of functions of fluid circuit system
The fluid circuit system of the Analyzer is composed of the waste liquid assembly, constant-temperature
degassing assembly, syringe pump unit, waste liquid tank assembly, valve group assembly, pure water unit, test
system assembly, amplification board assembly, pump assembly, valve assembly, ISE reagent tank assembly,
detergent tank assembly and other structural unit assemblies, with the function of each unit shown in the table below:
Name Function
Waste Liquid Tank Assembly
To supply a vacuum for the testing of the Analyzer, and collect the
waste liquid generated when the cuvette is rinsed by the rinsing
probe, and finally discharge out of the machine in the form of
positive pressure
Constant-temperature Degassing
Assembly
To realize the heating of deionized water of the Analyzer and the
removal of free gas in the deionized water
Syringe Pump Unit
To realize the supply of deionized water for the Analyzer and the
sample aspirating and dispensing
Waste Liquid Tank Assembly
To recycle the high-concentration and low-concentration waste
liquid produced by the Analyzer
Group Valve Assembly
To integrate control valves for the rinsing probe, rinsing bath,
detergent and waste liquid
Pure Water Unit To provide deionized water for the Analyzer
Test System Assembly ISE test and detection part
Amplifier Board Assembly Part of electrical control board for ISE test
Pump Assembly
Dispensing and aspirating actuators and waste liquid vacuum
integration for ISE test
Valve Assembly
Control valve integration and degassing tank and transit tank
integration for ISE test
ISE Reagent Tank Assembly To provide the corresponding reagent for the ISE test
Detergent Tank Assembly To provide concentrated detergent for testing of the Analyzer
32
Service Manual of Auto-Chemistry Analyzer


4.2 Schematic diagram of fluid circuit and gas circuit of the Analyzer

Fig. 4-2-1 Fluid circuit and gas circuit of the Analyzer

Reaction disk  Reagent refrigeration chamber
Connector a
No.1
Check valve
Probe
rinsing
bath
R
in
si
ng
 b
at
h
of
 m
ix
in
g
m
ec
ha
ni
sm

Alkaline detergent
N
o.
 1
 p
ro
be

N
o.
 2
pr
ob
e
N
o.
 3
 p
ro
be

N
o.
 4
 p
ro
be

No.2 No.3 No.4 No.8 No.7 No.6 No.5
High-concentr
ation waste
liquid tank
Deionized
water
Low-concent
ration waste
liquid tank
Connector b
Pressure sensor
Up
Down
33
Service Manual of Auto-Chemistry Analyzer


4.3 Description of work process of the gas circuit and fluid circuit of the Analyzer
4.3.1 Liquid aspirating, dispensing and rinsing functions
4.3.1.1 Fluid circuit diagram

Fig. 4-3-1 Schematic diagram of liquid aspirating, dispensing and rinsing functions
4.3.1.2 Work process
 The syringe pump unit is mainly to achieve the supply of deionized water for the Analyzer, sample and reagent
aspirating and dispensing, and alkaline detergent aspirating and dispensing, with the working order of the fluid circuit
shown below:
(1) Power on and switch on SV1, then syringe pump P1 will descend to aspirate pure water; then switch off SV1, and power
on and switch on SV6 and SV9, and then syringe pump P1 will descend to aspirate detergent; switch offSV6 and SV9 and
prepare to test;
(2) Syringe pump P2 descends and the probe aspirates the sample, and then syringe pump P2 ascends to dispense the
sample to the cuvette, and the probe returns to be above the rinsing bath and descends to the designated position; then
power on and switch on SV2, and then syringe pump P1 will ascend and pump pure water to achieve the rinsing of the inner
wall of probe with pure water; then switch off SV2 and power on and switch on SV8, and then syringe pump P1 will ascend
to achieve the rinsing of the outer wall of probe with pure water; then switch off SV8;
(3) Syringe pump P2 descends and the probe aspirates the reagent, and then syringe pump P2 ascends to dispense the
reagent to the cuvette, and the probe returns to be above the rinsing bath and descends to the designated position; then
power on and switch on SV2, and then syringe pump P1 will ascend and pump pure water to achieve the rinsing of the inner
wall of probe with pure water; then switch off SV2 and power on and switch on SV8, and then syringe pump P1 will ascend
to achieve the rinsing of the outer wall of probe with pure water; then switch off SV8;
(4) Power on and switch on SV7, and then syringe pump P1 will ascend and pump pure water to achieve the rinsing of the
outer wall of mixing bar with pure water; then switch off SV7;
(5) Power on and switch on SV6 and SV9, and then syringe pump P1 will descend to aspirate detergent; switch off SV6 and
SV9, and power on and switch on SV4, and then syringe pump P1 will ascend to achieve the rinsing of cuvette; switch off
SV4, and power on and switch on SV5, and then syringe pump P1 will ascend to achieve the rinsing of cuvette; then switch
off SV5, and power on and switch on SV6, and then syringe pump P1 will ascend to achieve the rinsing of cuvette; then
switch off SV6.

No.1
Probe
rinsing
bath
R
in
si
ng
 b
at
h
of
 m
ix
in
g
m
ec
ha
ni
sm

Alkaline detergent
No.2 No.3 No.4 No.8 No.7 No.6 No.5
N
o.
 1
 p
ro
be

N
o.
 2
pr
ob
e
N
o.
 3
 p
ro
be

N
o.
 4
 p
ro
be

34
Service Manual of Auto-Chemistry Analyzer


4.3.2 Waste liquid collection and discharge of the Analyzer
4.3.2.1 Fluid circuit diagram


Fig. 4-3-2 Schematic diagram of waste liquid collection and discharge of the Analyzer
4.3.2.2 Work process
 The waste liquid assembly is mainly to provide a vacuum for the constant-temperature degassing assembly,
remove the free gas in the deionized water inside the degassing assembly, collect the waste liquid generated when the
cuvette is rinsed by the rinsing probe and the waste liquid generated by the rinsing bath of mixing mechanism, probe
rinsing bath, reaction disk and reagent refrigeration chamber, and finally discharge the waste liquid into the
high-concentration waste liquid tank and low-concentration waste liquid tank outside the machine, with the working
order of the fluid circuit shown below:
(1) P3 is powered on to operate to provide negative pressure for the vacuum tank and supply a vacuum for the testing
of the Analyzer; then SV10 is powered on and switched on to collect the waste liquid generated when the cuvette is
rinsed by the rinsing probe, and discharge the waste liquid into the high-concentration waste liquid tank outside the
machine;
(2) The waste liquid produced by the rinsing bath of mixing mechanism, probe rinsing bath, reaction disk and reagent
refrigeration chamber is discharged into the low-concentration waste liquid tank by self-weight.

Reaction disk  Reagent refrigeration chamber
No.1
Check valve
Probe
rinsing
bath
R
in
si
ng
 b
at
h
of
 m
ix
in
g
m
ec
ha
ni
sm

N
o.
 1
 p
ro
be

N
o.
 2
pr
ob
e
N
o.
 3
 p
ro
be

N
o.
 4
 p
ro
be

No.2 No.3 No.4 No.8 No.7 No.6 No.5
High-concentration
waste liquid tank
Low-concentration
waste liquid tank
Pressure sensor
Up
Down
35
Service Manual of Auto-Chemistry Analyzer


Chapter 5 Electric circuit of the Analyzer
5.1 Electrical wiring diagram of the Analyzer
J15
B02 main control board B04 reaction disk control board
B03 probe control board
B05 AC control board
B06 data collection board
B17ISE control board
2 black EGND
4 black EGND
1 red CANL
3 white CANH
4 black EGND
1 redCANL
3 white CANH2 black EGND
3 redCANL
1 white CANH
4 black EGND
1 red CANL
3 white CANH
4 black EGND
1 red CANL
3 white CANH
4 black EGND
1 red CANL
3 white CANH
4 black EGND
1 red CANL
3 white CANH
J8
J9
J12 J13
B04-P12 B04-P13
B05-P15 B05-P14
J4
B03-P8
B03-P9
B02-P5
B17-P10
3 white CANH 127cm
J14
B02-P2
1031112 CAT5E standard jumper
Network connector
1 black
2 screen
3 red
1 red
2 screen
3 black
B06-P4
B02-P3
J3
J21
2004079 CS-6400CAB\CS6400 P514 wire (outsourced)
J3
1 red CANL
J18J20 J16
B08 AC drive board
J21
3 red
4 yellow
1 brown
J22
2 red
3 orange
1 brow
n
5 green
6 blue
4 yellow
8 grey
9 w
hite
7 purple
11 brow
n
12 red
10 black
14 yellow
15 green
13 orange
17 purple
18 grey
16 blue
FAN
3_O
U
T
FAN
2_O
U
T
FAN
1_O
U
T
PE
LTIE
R
_FAN
1_24V
_O
U
T
LIG
H
T SO
U
R
C
E_FAN
_24V
_O
U
T
PE
LTIE
R
_FAN
2_24V
_O
U
T
BA
TH
_H
EATE
R
3_O
U
T
BA
TH
_H
EATE
R
2_O
U
T
BA
TH
_H
EATE
R
1_O
U
T
R
ESE
R
VE_H
EATE
R
_O
U
T
W
ASH
_H
EATE
R
_O
U
T
D
C
24_PU
M
P2_O
U
T
D
C
24_PU
M
P1_O
U
T
R
ELAY_O
U
T
PE
LTIE
R
_C
TRL1_O
U
T
G
N
D
G
N
D
5V
_H
EATE
R
_O
U
T
2 red
3 orange
5 green
6 blue
4 yellow
8 grey
9 w
hite
7 purple
11 brow
n
12 red
10 black
14 yellow
15 green
13 orange
17 purple
18 grey
16 blue
J23
2 red G
N
D
3 orange 5V
1 brow
n 5V
5 green 5V
6 blue GN
D
4 yellow
 PELT
IER
_V
IN
2 red G
N
D
3 orange 5V
1 brow
n 5V
5 green 5V
6 blue GN
D
4 yellow
 PELT
IER
_V
IN
B05-P21
B05-P22
B05-P23
B08-P16
B08-P18
B08-P20
3 red
4 yellow
1 brow
n
24V switching power supply
RV0.75 green
RV0.75 black
RV0.75 green
RV0.75 black
DC1802+24V-01
DC1802-GND-01
DC1802+24V-01
DC1802-GND-01
1
2
3
4
B05-P12
26cm
29cm
26cm
29cm
RV1.0 green
RV1.0 black
RV1.0 green
RV1.0 black
DC1802+24V-02
DC1802-GND-02
DC1802+24V-02
DC1802-GND-02
1
2
3
4
B08-P11
Fan
1 red
2 black
2 black
1 red
JFan05
JFan08
Fan08
Fan05
DC1802+24V-03
DC1802+24V-04
DC1802-GND-03
DC1802-GND-04
2 black
1 green
2 black
1 green
PFan05
PFan08
Fan
General power switch
Wiring
terminal
block of
halogen lamp
L1802
N1802
L1801N1801
DC1801+12V
DC1801-GND
12
L0102
N0102
102cm
DC0205+12V
DC0205-GND
G0102
G1801
G1802
G1801-1
12V switching power supply
Switch
RV2.5 black
RV2.5 green
DC1802+24V
DC1802-GND
DC0103+24V
DC0103-GND
J14
J16
J12
B01-P2
2 green
1 black
1 green
2 black
B04-P16
B03-P14
1 green
2 black
B17-P9
2 green
1 black
4 blue 3 red
2 blue 1 red
J0203
J3
J11
J9 J10
Optical unit
G0204
G0205
G0204-1
G0205-1
Filter
Fig. 5-1-1 Electrical wiring diagram of the Analyzer

5.2 Functions of circuit boards
Circuit board Functional description
Main control board (1) Communicate with upper computer (2) Communicate with other control boards
Data collection board (1) Data gathering
Probe control board
(1) Control the swinging drive motor of probe
(2) Check the status of probe swinging and zeroing optocoupler
(3) Control the probe lifting driving motor
(4) Check the status of probe lifting optocoupler
(5) Check the liquid level detection signal and touch signal of probe
(6) Control the dispensing pump driving motor
(7) Check the status of dispensing pump zeroing optocoupler
(8) Control the rinsing pump driving motor
(9) Check the status of rinsing pump zeroing optocoupler
(10) Control the sample/ reagent disk driving motor
(11) Check the status of zero-point optocoupler and positioning
optocoupler of sample/ reagent disk
(12) Control V1, V2 and V8 solenoid valves
(13) Bar code reading
36
Service Manual of Auto-Chemistry Analyzer


Circuitboard Functional description
Reaction disk control board
(1) Control the reaction disk mechanism driving motor
(2) Check the status of zero-point optocoupler and counting optocoupler of
reaction disk
(3) Control the rinsing mechanism driving motor
(4) Check the rinsing mechanism zeroing optocoupler
(5) Control the mixing mechanism swinging driving motor
(6) Check the status of swinging optocoupler of mechanism
(7) Control the lifting motor of mixing mechanism
(8) Check the lifting optocoupler of mixing mechanism
(9) Control and check the mixing motor of mixing mechanism
(10) Control V4, V5, V6, V7, V9 and V10 solenoid valves
(11) Supply power and trigger signals for the data collection board
AC control board
(1) Communicate with the main control board or reaction disk control
board
(2) Read the pressure of the vacuum diaphragm pump
(3) Collect the temperature of reaction disk, constant-temperature
degassing assembly, sample/reagent disk and light source system and
the ambient temperature
(4) Control the power signal lamp board
(5) Control the sample dispensing indicator lamp board
(6) Control 2 Peltier radiation fans
(7) Control the heat circulating fan of 3 incubation bathes
(8) Control 2 Peltiers
(9) Control 1 light source lamp radiator fan
(10) Control the heating strip of heating window
(11) Control the heating strip of reaction disk
(12) Control the heating strip of constant-temperature degassing tank
(13) Control 2 vacuum diaphragm pumps
(14) Control the optical power supply
(15) Collect the liquid level information of pure water tank,
high-concentration waste liquid tank, low-concentration waste liquid
tank and detergent tank
(16) Supply 5V power to the AC drive board
(17) Collect the current information of Peltier
AC drive control board
(1) Drive 2 Peltier radiation fans, 1 light source fan and 3 incubation bath
heat circulating fans
(2) Drive the heating strip of heating window
(3) Drive the switch of control relay of 12V light source power supply
(4) Drive the heating strip of constant-temperature degassing tank
(5) Drive the heating strip of reaction disk
(6) Drive 2 diaphragm pumps
(7) Drive 2 Peltiers
ISE control board (optional)
(1) Check the status of zero-point optocoupler of dilution pump
(2) Control the internal standard peristaltic pump motor
(3) Control the matching peristaltic pump motor
(4) Control the dilution pump motor
(5) Control V11, V12, V13, V14 and V15 solenoid valves
(6) Control the M9 mixing motor
(7) Control P16 and P17 vacuum pumps
(8) Read the AD data of electrode potential
(9) Check the vacuum pressure
Switching power supply
(1) The 12V switching power supply is light source power supply.
(2) The 24V switching power supply provides power to the Analyzer
except the light source.


37
Service Manual of Auto-Chemistry Analyzer


5.3 Electrical wiring diagram of circuit boards
5.3.1 Probe control board

B03 sample/ reagent board
J1
J7
J4
J13
J10
Rinsing pump motor
Dispensing pump motor
J6
J3
P1
D
B9 m
ale
connector
6 blue
5 red
3 black
4 green
12 blue
11 red
9 black
10 green
Probe swinging motor
Probe lifting motor
CS-T240\CS-T240 J102 wire (outsourced)

3 purple A-
4 grey A+
2 blue B+
1 green B-
4 red
3 brown
5 orange
6 yellow
9 green
10 blue
11 purple
12 grey
2 blue
1 green
3 purple
1 green
2 blue
3 purple
4 grey
5 white
6 black
Probe swinging and
zeroing optocoupler
2 red
1 brown
3 orange
2 green
1 yellow
3 blue
1 brown
2 red
3 orange
4 yellow
5 green
6 blue
Zero-point
optocoupler of disk
Positioning
optocoupler of disk
8 red-SUR
9 orange-TOU
10 yellow-GND
5 yellow
4 black
3 red
For reagent disk motor
3
orange 4
yellow
2 red
1 brown
10
black11
brown
6 blue
5 green
2 red
1 brown
3 orange
4 yellow
5 green
6 blue
1 black
2 brown
3 red
4 orange
5 yellow
6 green
7 blue
8 purple
9 grey
14
yellow15
green
13
orange
12 red
18 grey
17
purple
16 blue
3 green A-
4 blue B+
2 yellow 24V
1 orange A+
4 orange
3 blue
5 yellow
6 green
3 green
2 yellow
4 red
5 white
2 red 24V
1 brown A+
3 orange A-
4 yellow B+
2 red
1 brown
3 orange
4 yellow
1 green
2 blue
4 grey
3 purple
2 blue
1 green
3 purple
4 grey
2 black
1 brown
3 orange
4 red
2 black
1 white
3 brown
4 red
6 yellow
5 orange 2 black
1 white
3 brown
4 red
6 yellow
5 orange
Dispensing pump
zeroing optocouplerB12 optocoupler
adapter board
CS-400-10-0707.PCBDOC
J4
J3
J2
2 red
1
white
3
blue5
green6
black
2 red
1
white
3
blue5
green6
black
Rinsing pump zeroing
optocoupler
1 white
2 black
4 red
3 brown
1 white
2 black
4 red
3 brown
1 purple
2 grey
4 black
3 white
D
B9 fem
ale
connector
CS-400 bar code reader cable (outsourced)
J2
Valve for water
supply
Inner arm valve
B10 bar code board
14115022 CS-6400 bar code reader board (with burned program)
J3 Bar code reader
2 red
1 brown
3 orange
4 yellow
6 blue
5 green 2 red
1 brown
3 orange
4 blue
6 yellow
5 green
J2
B03-P1
B03-P7
B03-P4
B03-P2
B03-P3
B03-P6
B03-P13
B03-P10
B12-P4
P102
J0303 P0303
PPS1
J1102 P1102PPS8
PPS9
PPS10
J1402P1402
B12-P3-PPS
B12-P2-PPS
J1403P1403
P4
P3
J1401P1401
V1
V2
7 brown-5V
11 green-TXD
12 blue-RXD
6 brown
2 ora nge
4 yel low
1 gre en
5 blue
3 red
TXD
TOUCH
SURFACE
GND
RXD
+5V
B11 liquid level detection board
2
3
4
5
6
1
1
2
3
4
5
6
J4
J7
J1
1 white
2 black
5 purple
4 blue
6 yellow
7 yellow-5V
8 green-SUR
9 blue-TOU
10 red - ground
1
brown-
TXD
2 red-
地
3
orange-
RXD
4
yellow-
5V
FPC adapter board (bare board)
of lifting mechanism
FPC1.0-DIP-6P vertical\ connector
2 white
1 grey
3 black
Probe lif ting
optocoupler
PPS2
9 orange A-
10 yellow A+
8 red B+
7 brown B-
P223
6 blue
1 black
2 purple
1 grey
5 purple 24V
6 grey B-
5 green
6 blue
5 white
6 black
5
green-
SUR
6 blue-
TOU
11 orange-RXD
12 brown-TXD
1 red
2 shielding layer
1 blue
6 green
2 white
5 green 24V
6 blue -B
5 white
6 black 5 white 6 yellow
1 orange
2 yellow
1 orange
2 yellow
1 orange
2 yellow
V8
Probe rinsing bath valve
P1603 J1603J12
B03-P12
B11-P1
B10-P2
CS6400CAB\CS6400 J223 wire
J0901
 red
 black
Optional
Fig. 5-3-1 Electrical wiring diagram of probe control board

5.3.2 Reaction disk control board

B04 reaction disk board
J5
J6
J2
J4
J17
J7
J10
J25
6 blue
5 red
3 black
4 green
Rinsing motor
For reaction
disk motor
3 orange A-
4 yellow A+
2 red B+
1 brown B-
4 red
3 brown
5 orange
6 yellow
6 blue
5 red
3 black
4 green
3 purple A-
4 grey A+
2 blue B+
1 green B-
6 grey
5 purple
3 green
4 blue
J8
3 purple
7 brown
2 blue
1 green
9 orange
8 red
Rinsing zeroing
optocoupler 3 purple
2 blue
1 green
3 purple
2 blue
1 green
3 purple
2 blue
1 green
4 grey
6 black
5 white
 grey
 black
 white



CS-400 optocoupler board
(OPB815L)
GND
+5V
C
GND
+5V
C
 brown
 orange
 red
4 brown
6 orange
5 red
1 grey
3 black
2 white



4 yellow
6 blue
5 green
1 brown
3 orange
2 red
9 white
10 black
8 grey
7 purple
4 yellow
6 blue
5 green
1 brown
3 orange
2 red
9 white
10 black
8 grey
7 purple
4 yellow
6 blue
5 green
1 brown
3 orange
2 red
8 grey
7 purple
4 red
1 white
3 brown
2 black
V5 solenoid valve for
No. 2 probe rinsing
V7 solenoid valve of rinsing bath of
mixing mechanism
V4 solenoid valve for
No. 3 probe rinsing
V9 detergent
valve
V10 waste
liquid valve
Lifting motor of mixing
mechanism
Swinging motor of mixing
mechanism
2 black
1 red
2 grey
1 purple
3 white
4 black
2 blue
1 green
6 grey
7 white
8 black
11 brown
13 orange
12 red
2 red
1 brown
3 orange
4 yellow
12 green
13 red
14 blue
2 blue
1 green
5 purple
14 yellow
2 black
1 blue
2 black
1 red Mixing motor of mixing
mechanism
2 blue
1 green
3 purple
4 grey
6 black
5 white
5 blue
4 green
6 purple
7 grey9 black
8 white
4 red
7 grey
9 black
8 white
2 green
1 red
3 black
1 grey
3 black
2 white
Swinging optocoupler of mixing mechanism
Lifting optocoupler for mixing mechanism
B04-P5
B04-P8
B04-P6
B04-P10
B04-P25
B04-P7
B04-P4
B04-P2
B04-P17P434
P441
J0502 P0502PPS5
J0402 P0402
Reaction disk
counting optocoupler
Reaction disk
zeroing
optocoupler
J1604 P1604
J1609 P1609
P0602
P0604 J0604 PPS7
PPS6
2 brown
1 red
2 red
1 black
V6 solenoid valve for
No. 1 probe rinsing
J0602
M7
M6
J441
6 green
7 red
8 blue
5 black
11 black
 green
 red
 blue
 black
5 green
6 black
CS-T240/J440C wire
4 brown
6 orange
5 red
1 grey
3 black
2 white
Fig. 5-3-2 Electrical wiring diagram of reaction disk control board

38
Service Manual of Auto-Chemistry Analyzer


5.3.3 AC control board
AC control board B05
J24
2 screen
3 white (GND)
1 red
J2
J4
3 orange TP-
1 blue TP+
B05-P4 JS07PS07
2 screen
3 white
1 red
Sensor
1 blue TP+
2 orange TP-
Temperature sensor of constant-
temperature degass ing tank
2 black(GND)
3 yellow(IIC_SDA1)
4 green(IIC_SCL1)
1 red(5V)
B05-P2 DF1B-4DS-2.5RC B13-P2
2 black(GND)
3 yellow(IIC_SDA1)
4 green(IIC_SCL1)
1 red(5V)
Sensor
Temperature sensor
of reaction disk
J3
B05-P3 JS03PS03
3 white (-TP1)
4 screen
1 red(+TP1)
 5 screen
J5
B05-P5
2 screen
3 white
1 red
8 screen
9 white
7 red
PS05
2 screen
3 white
1 red
2 screen
3 white
1 red
PS01
J11
2 yellow
1 orange
6 grey
5 purple
10 black
9 white
2 yellow
1 black
High-concentration waste liquid
float CS-T180-15-02
2 yellow
1 black
Pure water float CS-T180-19-03
2 yellow
1 black
Detergent float CS-T180-23-02
PSW05JSW05
PSW04-1JSW04
PSW06JSW06
2 yellow
1 orange
2 grey
1 purple
2 black
1 white
B05-P24
B05-P11
2 red GND
3 green LED_OUT2
1 brown 5V
4 blue LED_OUT1
1 green
LED_OUT2
2 brown 5V
1 red GND
2 blue
LED_OUT1
B16-P1
B16-P2
CS-400\ power signal lamp
board B16
J2
J1
J25
2 black GND
3 green LED_OUT4
1 red 5V
4 blue LED_OUT3
B05-P25
1 red 5V
2 black GND
3 green LED_OUT4
4 blue LED_OUT3
B09-P1
4 blue
3 green
4 blue
3 green
Light-concentration waste liquid float
CS-T180-15-02
3 black
4 yellow
Sample dispensing indicator
lamp board (green and blue) B09J1
5 screen
 S3
S7
S5
S1
SW4
SW7
SW5
SW6
2 shield
1 red(+TP1)
3 white (-TP1)
1 red
3 white
6 shield
2 red(+TP1)
 6 screen
4 white (-TP1)
2 red
5 shield
4 white A
 red
 white

screen
 white
 screenA
3 orange TP-
1 blue TP+
1 black
3 black
1 blue TP+
3 orange TP-
JS01
Sample reagent disk
temperature sensor
Sensor
1 blue TP+
2 orange TP-
Optical temperature sensor
Sensor
1 black
2 black
Ambient temperature sensor
Sensor
1 blue TP+
2 orange TP-
5 screen
6 white
4 red
2 screen
3 white
1 red
PS02
JS05
JS02
MPXV pressure sensor module
version B13J2
S2
Pressure sensor of air
collector
Fig. 5-3-3 Electrical wiring diagram of AC control board

39
Service Manual of Auto-Chemistry Analyzer


5.3.4 AC drive board

 AC drive board B08
J1
B08-P1
2 yellow GND
3 green
1 orangePELTIER_FAN2_OUT
5 purple
6 grey GND
4 blue GND
LIGHT SOURCE_FAN_OUT
PELTIER_FAN1_OUT
1 red
2 black
2 black
1 red
JFan06PFan06
JFan02PFan02
2 yellow
1 green
2 blue
1 orange
 Refrigeration and
cooling fan
Fan
2 black
1 red
JFan07PFan07
Light source radiation fan
1 purple
2 grey
J21
2 yellow
3 green
4 blue
1 orange
6 grey
5 purple
8 black
7 white
9 brown
6 grey
7 white
8 black
5 purple
2 yellow
3 green
4 blue
1 orange
9 brown
2 yellow
3 black
4 red
1 red
6 black
5 yellow
9 black
8 yellow
7 red
J0405P0405
FAN1_OUT
FAN1_Detection
GND
FAN2_OUT
FAN2_Detection
GND
FAN3_OUT
FAN3_Detection
GND
J23 2 blackGND
1 green5V
2 black
1 green
Heater
2 black
2 red
1 green
J4
2 black GND
1 green 24V 2 black
1 green
Heater
2 white
Incubation bath
heating strip
JHeating01PHeating01
JHeating05
J5 2 black GND
1 green 24V
2 black
1 green
PHeating05
Heater
2 black 2 black
1 black
Heating5
J6
2 yellow
2 yellow1 orange
1 orange
Pump
2 black 2 black
1 red 1 red
Diaphragm pump
JP1PP1
4 grey
3 purple
2 grey
1 purple
PP2
Pump
2 black 2 black
1 red 1 red
Diaphragm pump
JP2
2 green
1 green
4 black
3 black
Peltier
2 black
1 green
JCooling01PCooling01
B08-P7
2 black
1 green
J7
J17
2 green
1 green
4 black
3 black
PCooling02 JCooling02
2 black
1 green
B08-P17
B08-P6
B08-P5
B08-P4
B08-P23
B08-P21
PHeating04 JHeating04
Fan6
Fan7
Fan2
Fan3
Fan4
Fan5
Heating4
Heating1
P1
P2
Cooling1
Cooling2
Circulating fan of incubation bath
Temperature relay
1 white 1 white
2 white
A
A
1 red
2 black
Peltier
2 black
1 green 1 red
2 black
1 red
5 yellow
3 black
4 red
2 yellow
6 black
9 black
8 yellow
7 red
A
A
A
A
A
A
A
A
A
R
R
R
R
R
R
R
R
R
Heater
1 red
2
red
Temperature relay
A A
A
 Refrigeration and cooling fan
C ircula ti ng fan of
inc ubat ion bath
1 red
Heating strip of
heating window
Constant-temperature
degassing heating strip
Peltier
Peltier
Heating strip of
heating window
Fig. 5-3-4 Electrical wiring diagram of AC drive board

40
Service Manual of Auto-Chemistry Analyzer


5.3.5 ISE control board (optional)

B17 ISE control board
J12
J6
J65
TO
_IS
E_AM
P
J41
B18 ISE pre-amplification
board
R
E
F
N
A
K
C
L
RE
F
el
ec
tro
de

N
a e
le
ctr
od
e K
 el
ec
tro
de
CI
 el
ec
tro
de
1 white
2 red
3 blue
5 gre en
J4
Proportioning pump motor
Internal standard pump motor
1 red
2 gre en
3 yel low
4 blue
PM06
JM07
JM06
B19 pum
p optocoupler
adapter board
B17-P6
B19-P41
B17-P65
J1
B18-P1
B17-P4
2 yel low
1 ora nge
3 gre en
1 brown
2 red
3 ora nge
4 yel low
7 gre en
8 blue
9 purple
10 gre y
1 brown
2 red
3 ora nge
4 yel low
1 gre en
2 blue
3 purple
4 gre y
B17-P12
1 brown
2 red
3 ora nge
4 yel low
5 gre en
6 blue
7 purple
8 gre y
9 white
10 bla ck
15 brown2
16 red2
1 brown
2 red
Mixing motor
1 yel low
2 ora nge
LTK wire
J3
J5
PM05JM05
B17-P5
1 white
2 bla ck
3 brown
4 red
1 white
2 bla ck
3 brown
4 red
Plunger pump
142cm
1 red
2 yel low
3 brown
4 ora nge
PM07
P387
PV13 JV13
V13
6 bla ck
1 yel low
2 yel low
V14
V15
V11
V12
P6
P7
M9
P5
1 gre en
2 blue
PV14 JV14
1 yel low
2 yel low
1 purple
2 gre y
PV15 JV15
1 red
2 bla ck
1 white
2 bla ck
PV11 JV11
1 brown 2
2 red 2
PV12 JV12
1 red
2 bla ck
1 red
2 bla ck
21
21
21
B19-P3-PPS
CS-6400 J387 wire 14102551
2 red
1 brown
Pump
2 black 2 black
1 red 1 red
JP16PP16
B17-P13J13
2 black
3 yellow
4 green
1 red
B20-P2
2 yellow
3 green
4 black
1 red MPXV pressure sensor module
version B20J2
5 black（ screen）
J1 B17-P1
P16
Pump
2 black 2 black
1 red 1 red
P17
JP17PP17
4 yellow
3 orange
1 brown
2 red
3 ora nge
4 yel low
Fig. 5-3-5 Electrical wiring diagram of ISE control board (optional)

41
Service Manual of Auto-Chemistry Analyzer


Chapter 6 Components replacement and debugging

6.1 Replacement and debugging of commonly used components
6.1.1 Halogen lamp replacement
The precision of the Analyzer will decline as the light power will be weaker due to the aging light source lamp.
Check quantity of light, if the check value is larger than 18000, replace halogen lamp in time.
6.1.1.1 Inspection of quantity of light
Select "Light Check" in the "System Maintenance" window, and click "Execute" button so that the instrument
automatically executes the light source energy test. The test results are displayed in AD value or printed by the
pressing down the print key. Generally, the value will reach its highest point at 340nm.
6.1.1.2 Replacement of light source lamp
(1) Prepare a new halogen lamp, as shown in Fig. 6-1-1.

Fig. 6-1-1

Do not touch the surface of the halogen lamp, otherwise, the light intensity value will be affected.If there are
stains such as fingerprints on the surface, wipe it witha piece of gauze dipped with ethanol.
(2) Turn off the power of the Analyzer to completely cool down the lamphouse (about 30 minutes), so as to prevent
ambustion.
(3) Screw off the fixing screws of the side doors of the instrument and open the small door as shown in Fig. 6-1-2.

Fig. 6-1-2
(4) Screw off the terminal blocks (two screws) of the halogen lamp on the terminal strip and take off the leads, as
shown in Fig. 6-1-3.
Replacement
of halogen
lamp
Replacement of
alkaline detergent
42
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-3
(5) Screw off the two fixing screws of light source holder and take out the halogen lamp, shown as in Fig. 6-1-4.

Fig. 6-1-4
(6) Replace with a new halogen lamp according to the reverse steps of above, tighten the screws, and do not contact
other leads. Leads should not be loose or up warping.
(7) Close the small door and tighten the fixing screws, power on the analyzer. In the stand-by state, execute "Light
Quantity Check" function, and after the light quantity meets the requirement, carry out the test.

6.1.2 Replacement of optical unit
 If there is any trouble in the test process, it is recommended to remove the whole optical unit for maintenance
and replacement.
(1) Turn off the power of the Analyzer to completely cool down the lamphouse (about 30 minutes), so as to prevent
ambustion.
(2) Unscrew the fixing screw of the rinsing mechanism , remove the rinsing mechanism of cuvette, place the rinsing
mechanism on a flat place aside, without causing damage to the rinsing probe, and lift the reaction disk cover up and
put aside.
(3) As shown in Fig. 6-1-5, loosen but not remove the screw of Cover 4, and then remove Cover 1, 2 and 3 in
sequence. Pay attention to the position of mixing and rinsing baths when removing Cover 2.
Two terminal
blocks
Fixing screw
43
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-5
(4) As shown in Fig. 6-1-6, unscrew three screws in the middle as circled in red color and lift up the reaction disk.

Place the reaction disk in a dry and clean place, and prevent water on the wall of cuvette drip into the
analyzer.

Fig. 6-1-6
(5) Remove the incubation bath, as shown in Figure 6-1-7, and unplug four terminal blocks selected. Unscrew off five
fixing screws of the incubation bath, as shown in Figure 6-1-8, upwarp the incubation bath, and pay attention to the
tubing under the incubation bath.
1
2
3
4
Rinsing bath
Mixing bar
Screw of rinsing
mechanism
44
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-7


Fig. 6-1-8
(6) Remove the optical unit connecting wire. First remove the ground wire G0205 as shown in Figure 6-1-9, and
check whether the screw washer gets lost. Unscrew the cover screw that fixes AD box, remove the cover, pull out the
connection wires P514 and B06-P4 on the circuit board, as shown in Figure 6-1-10, pull out the temperature sensor,
and remove the two DC0205 wires on the iconic terminal block with a screwdriver.
Terminal
block
45
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-9


Fig. 6-1-10

(7) Remove the optical unit, as shown in Fig. 6-1-11. There is a screw on the back of the optical unit. Hold the optical
unit by hand and screw down the screw at the same time. Hold up the incubation bath and lift the optical unit up
obliquely and take it out.
Ground wire
G0205
AD box
cover
DC0205+12V DC0205-GND
Temperature
Sensor
46
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-11
(8) Install the new optical unit in accordance with the reverse steps mentioned above. Since the incubation bath and
the optical unit are fixed with screws, do not lock the screws in Fig. 6-1-11. After the incubation bath is fixed, lock the
above-mentioned screws, and then install in step (8)-(2).
(9) After installation, the following operations are carried out to verify that the instrument can work normally.
 a) "Reset" operation: in the "System Maintenance" interface, select the "Instrument Reset" and then click the
"Execute" button;
 b) Mechanical motions check: in the "System Maintenance" interface, select "Mechanical Motions Check";
 c) Execute "AD Normalization", "cuvette Blank", "Reaction Disk Optical Couple Test", "Original AD Value
Check", and "Cuvette Blank Injection Volume Check".
 d) Execute "stray light", "linear range of absorbance", "absorbance repeatability", "absorbance accuracy" and
"absorbance stability" tests.

6.1.3 Replacement and debugging of mixing bar
(1) Turn off the power of the analyzer.
(2) Loosen two fixing screws for about 1 circle, as shown in the figure: pull out mixing bar from the bottom.

Fig. 6-1-12
(3) Prepare a new mixing bar, and wipe the front of the new mixing bar with a piece of gauze dipped in ethanol.
(4) When installing the new mixing bar, insert the mixing bar at the heel of the motor and fix it with M2 screws as
shown in the figure:
Screw
47
Service Manual of Auto-Chemistry Analyzer



Fig. 6-1-13
(5) Put the adjusting block of the mixing bar on the bracket of the cuvette and move the cuvette above the adjusting
block as shown in the figure:

Fig. 6-1-14
(6) Screw off M2 screw, and adjust the mixing bar until its point touches the upper surface of adjusting block as
shown in the figure: fasten M2 screw.

Fig. 6-1-15
(7) Select "Mixing Mechanism Check" from "Mechanism Check" in the "System Maintenance" window, and click "
" and “ " to confirm whether the position of mixing bar is correct.
(8) If not in the center of the cuvette, use CS-T180 debugging and maintenance program to adjust. After getting
online, select the lower computer debugging, mixing unit and position compensation in turn.
 (9) Click "Position" to show a drop-down symbol and select the cuvette, click "Read". When the reading of position
information is complete, fill in the number of compensation step in the position information box, in the range of
-15~15, set the compensation step and then click "Settings".
Mixing motor
Mixing bar M2 screw
Mixing mechanism
Place the adjusting block here
Adjusting block
Height adjusting screw
Cuvette bracket
Mixing bar
Cuvette bracket
Upper end of adjusting block
48
Service Manual of Auto-Chemistry Analyzer


(10) When resetting the mixing unit, adjust the mixing bar to the position of the cuvette, and observe whether the
mixing bar is in the center of the cuvette. If the mixing bar is not in the center, the compensation settings should be
made again according to the specific circumstances.
(11) Execute "Mechanical action check" for 10 times in "Mechanism Check" in the "System Maintenance" window
and confirm whether or not the mechanical action is normal.

6.1.4 Replacement and debugging of probe assembly
(1) Power off the analyzer.
(2) Hold the shell of the probe with fingers and then pick it up and take it off as shown in the figure:

Fig. 6-1-17
(3) Unscrew tubing connector as shown in the figure:

Fig. 6-1-18
(4) Remove the probe.
(5) Replace with a new probe and screw down the tubing connectors in reverse order.
(6) Turn on the power switch of the analyzer.
(7) Click "System Maintenance" button in functions navigation area.
(8) Select "Horizontal Check of Probe" and "Mixing Mechanism" in the "Mechanism Check" list, and then click "
" button and single click " " button to move on the next action.
(9) Execute "Horizontal Check of Probe". When the probe stops above the cuvette, check whether the point of probe
aims at the center of cuvette, as shown in the figure.

Fig. 6-1-19
(10) If not in the center, use CS-T180 debugging and maintenance program to adjust the probe mechanism. After
Probe front
Cuvette
49
Service Manual of Auto-Chemistry Analyzer


getting online, select the lower computer debugging, probe unit and swing compensation.
(11) Click "Position" to show a drop-down symboland select the cuvette, click "Read". When the reading of position
information is complete, fill in the number of compensation step in the position information box, in the range of
-15~15, set the compensation step and then click "Settings".
(12) When resetting the probe, adjust the probe to the position of the cuvette, and observe whether the probe is in the
center of the cuvette. If the probe is not in the center, the compensation settings should be made again according to the
specific circumstances.

6.1.5 Replacement of constant-temperature degassing system
(1) Shut down the power switch on the lower right side of the analyzer, remove the back cover of the analyzer, and
disconnect the tubing XR78-80 (No. 2 tube) between the V1 solenoid valve in the analyzer and the
constant-temperature degassing tank.
(2) One minute later, disconnect the intake pipe XR78-500 (No. 1 tube) and the degassing tube XR78-200 (No 28
tube) at the bottom of the constant-temperature degassing tank, and disconnect the three wire plugs on the
constant-temperature degassing tank. As shown in figure below:


Fig. 6-1-21

Fig. 6-1-22
(3) Loosen the two fixing screws of the constant-temperature degassing tank, remove the constant-temperature
degassing tank from the analyzer and place it on a clean desk.
(4) Install the new constant-temperature degassing tank to the original position and connect the tubing and wire plug
one by one accurately.
Caution:
● When replacing the constant-temperature degassing tank, pull out No. 1, No. 2 and No. 28 tubes and wire plugs
before replacing the components.
● During the replacement process, there will be an overflow at the outlet of No. 1 tube. The water container should
be prepared before pulling off the tube, or the nylon bandage and plug should be used to seal.
(5) Turn on the power switch on the lower right side of the analyzer. In the process of power-on resetting of the
XR78-80 (No. 2
tube)
Wire plug
Tube 28
Tube 1
50
Service Manual of Auto-Chemistry Analyzer


analyzer,conduct spitting test of the rinsing probe. Because the tubing becomes empty after replacing the degassing
tank, the water in the tubing can not be replenished in time, the analyzer will stop because of alarming "abnormal
spitting of 3-11-2 rinsing mechanism rinsing probe". After tubing is reset repeatedly and filled up with water, enter
the standby mode. If the alarm still sounds after repeated reset, please check the tubing.

When there are bubbles in the tubing, there may be water spraying in the probe rinsing bath, which should be
cleared in time.
(6) Execute the "Syringe Pump Exhausts" operation to ensure that there are no bubbles in the sample dispensing
injection pump (500μL) and the water supply injection pump (10mL).

6.1.6 Electrode replacement

● Generally, it is prohibited to open ISE cover.Otherwise, the results may be inaccurate caused by poor
temperature control.
● Keep the replacement of electrode and checks of equipment within 1 hour.
● The service life of ISE electrode is 6 months or being tested for 15000 times.
● Make sure that the storage temperature of the electrode is at 1℃~51℃.

Fig. 6-1-23 Diagram of Electrode Arrangement
6.1.6.1 Replacement of Na, K and CI electrodes
Electric potential of electrode will gradually decrease after long time of using, which leads to poor responding. Thus
the electrode should be replaced for a new one.
(1) Time to replace electrode
An alarm sounds when the slope value of the calibration is abnormal, as shown in the table below:
Slope value
Alarm information
Na K Cl
40mV~70mV 40mV~70mV -70mV~-40mV Normal range
35mV~40mV 35mV~40mV -40mV~-35mV Abnormal ISE preparation
Below 35mV Below 35mV Above -35mV Abnormal ISE slope rate
When abnormal ISE preparation warning occurs, the analysis at that day can be executed as usual, and new
electrode shall be replaced with on the second day. When abnormal ISE slope rate alarm sounds, replace with a new
electrode in time.
If the alarm sounds or QC test fails while the slope rate is still within the normal range, it indicates that the
response of electrode is poor. The situation is usually caused by tubing pollution, and can be solved by rinsing the
tubing.
One of the reasons causing dramatic change of slope value of that day but normal calibration value of the former
day may be electrode. Check whether there is leakage or blocking and bubble in tubing.
(2) Replacement method of electrode
a) Open the maintenance opening on the right side of the analyzer, and unscrew the fixing screw on electrode
components, and lift up electrode components.
b) Select the electrode to be replaced, and screw off the electrode with hands holding protecting jacket, as shown
51
Service Manual of Auto-Chemistry Analyzer


in the figure:

Fig. 6-1-24
c) Pull out the wire of electrode as shown in the figure:

Fig. 6-1-25
d) After removing the electrode, wipe out the liquid with the cotton swab in the position on flow cell for
electrode installation, as shown in the figure:

Fig. 6-1-26
e) Assemble and install the new corresponding electrodes at the proper position of the flow cell, and then
connect the other end of the electrode with the connector of the front zoom plate.
(3) Finishing of electrode
After the new electrode was installed, the electrode shall be repaired and maintained before being analyzed in
accordance with the following order:
a) Execute all ISE tubing once in "ISE" window of "System maintenance".
b) After 10 minutes, execute ISE check for 10 times in "ISE" window of "System Maintenance". The results of
ISE check will be displayed on the system maintenance working area.
c) Execute ISE calibration for once to confirm that whether the slope is within the reference range.
6.1.6.2 Replacement of reference electrode
(1) Time to replace
Replace with new electrode when all slope value of Na, K, Ci electrode is low or unstable.
(2) Replacement method
Select reference electrode (NA REF), and refer to (2) Replacement method of electrode under the "Replacement
of Na, K and Cl electrodes" for the replacement method and precautions for replacement.
(3) Confirmation after replacement
a) Execute all ISE tubing once in "ISE" window of "System maintenance".
b) After 10 minutes, execute ISE check for 10 times in "ISE" window of "System Maintenance". The results of
52
Service Manual of Auto-Chemistry Analyzer


ISE check will be displayed on the system maintenance working area. The difference of two successive check values
of the same electrode shall not be more than 0.2mv.
c) Execute ISE calibration for once to confirm that whether the slope is within the reference range.

6.1.7 Replacement of tube for pinch valve
(1) Open ISE cover plate of analysis unit of the Analyzer.
(2) Replace the tube with a new one. Prevent the hose from loosening and falling when inserting, as shown in the
figure:

Fig. 6-1-27
(3) Wipe with a piece of gauze dipped in pure water if there is liquid dripping from the tube.
(4) Install the ISE cover.
6.1.8 Replacement of Peltier of reagent disk

Power off the whole machine for at least three minutes before operation.


Tube for pinch valve
53
Service Manual of Auto-Chemistry Analyzer






(1) Remove the side cover and the front cover;
(2) Pull out both the male and female connectors of the wire socket, and pull it out after loosening the screw of the
front ventilation hood and lower ventilation hood.
(3) Unscrew radiator screws and remove radiator.
(4) Replace Peltier PCooLing01/ PCooLing02;
(5) After replacement, install according to the reverse steps.
6.1.9 Replacement of heating window of sample reagent disk

(1) Turn the sample reagent probe away from the sample reagent disk, remove the chamber cover, take out the sample
reagent disk holder, and remove the heat insulation cover;
(2) Remove the side cover,upper cover and front cover;
(3) Pull out both the male and female connectors of the wire socket, and pull it out after loosening the screw of the
front ventilation hood and lower ventilation hood.
(4) Unscrew three mounting screws in the refrigeration chamber, pull down the overflow pipe and take out the
components of refrigeration chamber.
(5) Remove the screws of the bar code scanning window and heat the replaced window.
(6) After replacement, install according to the reverse steps.
Mounting
screw
Insertion direction Insertion direction Screw Screw
Front Ventilation Hood Lower Ventilation Hood
54
Service Manual of Auto-Chemistry Analyzer


6.1.10 Replacement of driving component motor

(1) Turn the sample reagent probe away from the sample reagent disk, remove the chamber cover, take out the sample
reagent disk holder, and remove the heat insulation cover;
(2) Remove the side cover, upper cover and front cover;
(3) Pull out both the male and female connectors of the wire socket, and pull it out after loosening the screw of the
front ventilation hood and lower ventilation hood.
(4) Unscrew three mounting screws in the refrigeration chamber, pull down the overflow pipe and take out the
components of refrigeration chamber.
(5) Remove the mounting screws of driving component and remove the driving component.
(6) Remove the motor wire socket, loosen the mounting screws and replace the motor.
(7) After replacement, install according to the reverse steps.
6.1.11 Replacement of driving component optocoupler
(1) Execute 6.1.10 (1) ~ (5)
(2) Pull out the optocoupler wire, blow the thermoplastic on the back of the optocoupler with a heat gun until it melts,
remove the optocoupler, and clean the residual thermoplastic with a screwdriver.
(3) Place a new optocoupler into the mounting hole and fix it with thermoplastic.
(4) After replacement, install according to the reverse steps.


Position of
screw
55
Service Manual of Auto-Chemistry Analyzer

Chapter 7 Maintenance
7.1 System maintenance preparation
To guarantee the accuracy and precision of the Analyzer, operators shall strictly follow User Manual of
Auto-Chemistry Analyzer (Type: CS-T180) and regularly provide maintenance for the Analyzer so as to get reliable
test results and ensure the Analyzer with planned service life.
Before maintenance of the Analyzer, please prepare the following tools:
7.1.1 Tools and instruments
(1)Accessory (accompanying)
Tool Name Use
Cross screwdriver To remove and install cover
Probe unblocking needle To clean probe
Probe unblocking tool To clean when probe blocked
Fixing block To adjust the height of mixing bar
(2)Objects prepared by users
Tool Name Use
Clean gauze To clean all parts
Cotton swab To clean probe
Dust collector To clean the cooling fan
Water tanks (two) To drain waste liquid
Brush of test tube To clean rinsing bath
7.1.2 Pure water
During routine operation and system maintenance, the Analyzer shall be filled with pure water with conductivity
lower than 1μs/cm. Don't forget to maintain and check the pure water unit regularly during using pure water unit.
Refer to the User Manual of the pure water unit for details to contact with the manufacturer or seller.
7.1.3 Detergent
Various detergents, used for rinsing all parts of the Analyzer, shall be purchased from Dirui Company. If the
detergents are replaced with any other detergent, cuvette, probe, mixing bar and tubing may be not rinsed fully,
leading to the impact on the accuracy and precision of testing result. The Company will not be responsible for any
inaccuracy due to failure to use detergent specified.
3 kinds of CS series detergent in total:
(1)CS series anti-bacterial phosphor-free detergent: Put CS-anti-bacterial phosphor-free detergent in the specified
position according to the prompt. 2% of CS series anti-bacterial phosphor-free detergent shall be adopted for
scrubbing parts of the Analyzer or soaking cuvette.
(2)CS-alkaline detergent: place CS-alkaline detergent in the detergent bottle in front of the Analyzer for rinsing
cuvette
(3)CS-ISE detergent: Place standard cup of CS-ISE detergent at position outer 1 on sample reagent disk for rinsing
ISE matching cuvette, flow cell and ISE tubing.
56
Service Manual of Auto-Chemistry Analyzer

7.2 Application of "System Maintenance" window
Click " " in the functions area to enter maintenance window, and then set the daily maintenance
as per the demand. The interface is as shown:

Fig. 7-2-1
During the maintenance operation of the Analyzer, click " " in the window to stop maintenance
operation that can be stopped halfway, or execute other operation until maintenance operation is finished when some
maintenance operation cannot be stopped halfway. The Analyzer will reset first before executing any maintenance
item. In case of any abnormal mechanism during maintenance, an alarm prompt will be displayed in the "Alarm
Information" window.
Click " " to exit some maintenance window.
7.2.1 Reset analyzer
Click the icon on "System Maintenance" as shown below:
57
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-2
Click " ", and the mechanism of the Analyzer will automatically return to the reset point. It is not
allowed to suddenly suspend the reset process. Other operations are allowable only under standby mode.
Please execute reset if the alarm information gives prompts, or the Analyzer is suddenly suspended, or single-step
adjustment of probe, or mixing mechanism is executed.
7.2.2 Check cuvette blank and light intensity
Click the " " icon on the "System Maintenance" window to execute test of cuvette blank and light
intensity.
(1)Cuvette blank test
Select " " on the "Cuvette Blank and Light Intensity" window, and click "
", then the Analyzer will execute cuvette blank test of 160 cuvettes and display the test results on the cuvette blank
test window as shown below:
58
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-3
Click the " " button to preview and print the cuvette blank value if needed. During the check of
cuvette blank, click the " " button to end cuvette blank test.
Normally, the user is suggested to execute cuvette blank test once a week. User shall execute cuvette blank test after
replacing cuvette only if the value is qualified. Operator is not suggested to continue sample test if the cuvette blank
value is abnormal, otherwise, it may affect the accuracy of test result.
a)"cuvette No." column: display the number of 1~56 cuvettes.
b)"340~380" column: separately display the cuvette blank test of 56 cuvettes of different cuvette No.
corresponding to wavelength of 340nm, 380nm, 405nm, 450nm, 480nm, 505nm, 546nm, 570nm, 600nm, 660nm,
700nm, 750nm, or 800nm.
c)"1" (cuvette) line: display the cuvette blank value of No. 1 cuvette under 12wavelengths, which is qualified if the
value is in the range of 8000~18000.
d)"2~56" (cuvette) line: display the difference between cuvettes of No. 2~56, which is the difference between
cuvette blank of No. 1 cuvette and cuvette blank of No. 2~56 cuvette, and the difference is only qualified within the
range of -1500~1500.
(2)Check quantity of light
Select " " on "Cuvette Blank and Light Intensity" window, and the display is shown as below:
59
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-4
Click the " " button, and the Analyzer will automatically execute the check of light source energy,
and display the check value of this time and before, and the difference value automatically calculated can be printed
as needed. The check value of quantity of light shall be less than or equal to 18000. Click the " "
button to end the check of light intensity.
Normally, users are suggested to check quantity of light once a month. Check light intensity first after replacing
halogen lamp, and only when the value of light intensity is qualified can the testbe carried out.
7.2.3 Exhaust air
Click the " " icon on the "System Maintenance" window to execute air exhaust of syringe pump as shown
below:
60
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-5
Select " " on the "Air Exhaust" window, and select " " or "
" as needed. If to select "Detergent aspirating", place CS-anti-bacterial phosphor-free detergent
in position outer 1 on the sample reagent disk. Click " ", the syringe pump piston will twitch up
and down repeatedly to exhaust the air in syringe pump or tubing. Emergency stops are not allowed during this
function operation, and any other operation shall be carried out under the standby status.
Exhaust air from syringe pump for several times when replacing syringe pump or its tubing or firstly install the
Analyzer.
7.2.4 Rinsing
Click the " " icon on the "System Maintenance" window to rinse cuvette, and drain the whole machine, as
shown below:
(1)Rinse cuvette
Click " " on the "Rinsing" window as shown below:
61
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-6
Click" ", and the Analyzer will automatically rinse 56 cuvettes. During rinsing cuvette, click "
" to end the operation.
In case that the cuvette blank value is abnormal, execute "Rinse cuvette" first; the user is suggested to rinse cuvette
once a week to protect the test result from being affected by polluted cuvette.
(2)Drain whole machine
Click " " on the "Rinsing" window as shown below:

Fig. 7-2-7
Click the " " button, operate according to the prompt, and wait for standby before executing other
operation.
62
Service Manual of Auto-Chemistry Analyzer

When executing "complete machine dewatering", the pure water in the water feeding tubing of the rinsing
mechanism, the probe inner wall, the probe outer wall, the rinsing bath, and the degassing tank will be drained, and
the detergent in the alkaline detergent tubing will be drained. Detergent will be discharged from the inlet. Before
executing the function, prepare a container to hold the discharged detergent. Pure water will be discharged directly to
the low-concentration waste liquid tube.
(3)Probe rinsing
In the "rinsing" window, select " ", and the interface is as shown below:

Fig. 7-2-7(a)
Click the " " button. Operate according to the prompt. Wait for standby before executing other
operation.
It’s suggested that the user execute probe rinsing once a week.
7.2.5 Mechanism check
Click " " in the "System maintenance" window to execute the vertical check and horizontal check of probe
and check mixing mechanism, mechanical action and rinsing mechanism. Please execute corresponding maintenance
action to check or adjust the mechanism.
(1)Vertical check of probe
Select " " on the "Mechanism check" window as shown in the figure:
63
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-8
Click the " " button, and the Analyzer starts the single-step vertical action of lifting mechanism
of probe, then click the " " button to execute the next action, and click " "
button to stop the maintenance action.
Vertical check of "5mL", "50mL", "Empty Bottle", "Check out" or "Return to Zero" can be selected.
Please refer to "7.4.1 (4) Adjustment and confirmation of the position of probe" for the action of vertical check of
probe.
(2)Horizontal check of probe
Select " " on the "Mechanism check" window as shown in the figure:

Fig. 7-2-9
64
Service Manual of Auto-Chemistry Analyzer

Click the " " button, and the Analyzer starts the single-step horizontal action of lifting
mechanism of probe, then click the " " button to execute the next action, and click the "
" button to stop the maintenance action.
Please refer to "7.4.1 (4) Adjustment and confirmation of the position of probe" for the detailed specification of
horizontal check of probe.
Please execute the action when adjusting or checking the position of probe.
(3)Check of mixing mechanism
Select " " on the "Mechanism check" window as shown in the figure:

Fig. 7-2-10
Click the " " button, and the Analyzer starts the single-step action check of mixing mechanism,
then click the " " button to execute the next action, and click the " " button
to stop the maintenance action.
Execute when adjusting the position of mixing mechanism (at cuvette side and above the rinsing bath).
(4)Mechanical motions check
Select " " on the "Mechanism check" window as shown in the figure:
65
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-11
Input the number of check within the range of 1~65535, and click the " " button to execute action
check of all mechanisms. Click the " " button to stop the maintenance action.
(5)Mechanical motions check
Select " " on the "Mechanism check" window as shown in the figure:

Fig. 7-2-12
Click the " " button and the Analyzer executes the reset automatically, then the rinsing
mechanism goes off (failing distance: upon the rinsing probe enters into the cuvette); click "Next", the rinsing
mechanism goes up to zero; then click "Next", the rinsing mechanism goes down. Click the " "
button to stop the maintenance action.
66
Service Manual of Auto-Chemistry Analyzer

7.2.6 Water quality check
On the "System Maintenance" window click the " " icon to check the water quality, and the interface is as
shown below:

Fig. 7-2-13
Select "cal." and click the " " button, and according to the prompt put a 20mL reagent bottle
holding 20mL normal saline in position outer 1.
After calibration, put a 20mL reagent bottle holding 20mL water to be tested in position outer 1 accoding to the
prompt. After testing, the test result will be displayed on the software interface.
7.2.7 Barcode
Click the " " button on the "System maintenance" window to check the barcode of sample and reagent.
Select " " on the "Barcode" window as shown in the figure:
67
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-14
Click the " " button, the Analyzer will scan the barcode at position 1, outer 1 and inner 2 of the
sample reagent disk, and display the check result.

Before testing, put a test tube with barcode respectively at position 1 and outer 1 of the sample reagent disk;
after the scanning, put a test tube with barcode at position 1, and a 20mL reagent bottle with barcode at
position outer 1; and after scanning, put a test tube with barcode at position 1, and a 35mL reagent bottle
with barcode at position inner 2 for scanning.
7.2.8 ISE
Click the " " icon on the "System maintenance" window to enter the ISE window, as shown in the figure:
68
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-15
(1)ISE check
Click and select " " on the "ISE" window, and set the number of checks in the input bar "Check
Times" within the range of 1-999. Click the " " button to display the check value on the working
area of the check result. Click the " " button to end the action.
Execute ISE check after ISE warning occurs, rinsing ISE or replacing electrode.

● The normal value range of ISE check:
Item name Range of normal value (unit: mV)
Na+ -200~200
K+ -300~100
Cl- -200~200
● The difference of two successive check values of the same electrode shall be no more than 0.2mV.
(2)Rinse ISE tubing
Select " " on the "ISE" window as shown in the figure:
69
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-16
Select the type of tube needed to be rinsed as per the actual situation in the ISE tubing rinsing area, and click the "
" button, the Analyzer will automatically rinse the tubing, the action can be ended by clicking the
" " button.
Users are suggested to rinse all ISE tubes once a month.
(3)Rinse ISE matching cuvette
Select " " on the "ISE" window as shown in the figure:

70
Service Manual of Auto-Chemistry Analyzer

Fig. 7-2-17
Place CS-IES detergent at position outer 1 of the sample reagent disk, and click the " " button,the Analyzer will automatically rinse ISE cuvette, and the action can be ended by clicking the "
" button.
User is suggested to rinse ISE matching cuvette once a week, and execute ISE calibration after rinsing.
(4)Exhaust air from ISE diluent tubing
Select " " on the "ISE" window as shown in the figure:

Fig. 7-2-18
When bubbles exist inside ISE tubing and ISE syringe pump, click the " " button to execute
tubing exhaust. Emergency stops are not allowed during this function operation, and any other operation shall be
carried out in standby status.
(5)Rinse ISE flow cell
Select " " on the "ISE" window as shown in the figure:
71
Service Manual of Auto-Chemistry Analyzer


Fig. 7-2-19
Place CS-ISE detergent at position outer 1 of the sample reagent disk, and click the " " button,
the Analyzer will automatically rinse ISE flow cell, and the action can be ended by clicking the "
" button.
User is suggested to rinse ISE flow cell once a month.
7.3 System maintenance position and parts

If the Analyzer is installed with accessories which are not provided or recommended by the manufacturer or
the Analyzer is used otherwise specified by the manufacturer, the relating protection may be weakened.
7.3.1 Clean, check and replace parts regularly
Maintain, check and replace parts regularly as shown in Table 7-3-1 (providing the Analyzer is used for 5 hours per
day):
(○: Clean and check regularly ●: Replace and add regularly)
Table 7-3-1 List of Parts to be Cleaned, Checked and Replaced Regularly
No. Items
Necessary
amount for
1 time
Annual
consumption
Periodic
Reference
Daily
Appro
priate
time
Weekly Monthly Yearly
1 Standard cup ● ——
2 Manual-rinsing probe ○ 7.4.1
3 Probe rinsing tank Rinsing bath of mixing bar ○ 7.4.1
72
Service Manual of Auto-Chemistry Analyzer

No. Items
Necessary
amount for
1 time
Annual
consumption
Periodic
Reference
Daily
Appro
priate
time
Weekly Monthly Yearly
4
(Note a) Cuvette (7/set) 8 groups 32 sets ● ○ 7.4.2
5 Incubation bath and axial fan ○ 7.4.2
6
(Note b)
Halogen lamp (light source
lamp) 1 2 ● 7.4.3
7 Rinse nozzles of mechanism ○ 7.4.4
8 Mixing bar ○ 7.4.5
9
Rinsing of syringe pump
Sample dispensing in syringe
pump
 ● 7.4.7
10 Water supply filter and detergent filter ○ 7.4.11
11
CS series anti-bacterial
phosphor-free detergent
CS-alkaline detergent
 ● 7.1.3
12 Vacuum bottle body ○ ——
13 Refrigeration chamber ○ 7.4.6
14 Cooling Fans ○ ——
15
(Note c)
Confirmation of cuvette
blank ○ 7.2.2
16 Drainage of waste liquid ○ ——
17 Detergent bottle ○ 7.4.2
Note:
a)Statistic about the maximum consumption is made in the list, if the cuvette blank value is qualified, it can be
used continually. Replace with a new cuvette if the cuvette blank value is still abnormal after rinsing cuvette.
b)Halogen lamp, whose average service time is 2000 hours, needs to be replaced when the value of quantity of
light is tested with 340nm wavelength to be larger than 18000 hours, and to ensure the accuracy and precision
of test result, halogen lamp with service time of 750 hours are recommended for the replacement.
c)Execute cuvette blank test once a week, otherwise, warning of abnormal cuvette blank value may occur.
d)The Analyzer can be equipped with stylus, ink-jet or laser printer, and user can select consumables as per
the type of printer.
7.3.2 Spare parts for regular replacement and maintenance
Please prepare the following parts all the time for repairing the Analyzer at any time in case of faults. The parts are
shown in Table 7-3-2:
Table 7-3-2 List of Spare Parts
No. Part name Note Suggested qty./year
1 Halogen lamp 12V20W 2
2 Cuvette (7/set×8 sets) 32 sets
3 Axial fan F251RF05LC5V 3
73
Service Manual of Auto-Chemistry Analyzer

No. Part name Note Suggested qty./year
4 LMT55 ethylene tube 1/4×3/8 (unit: inch)
5 LMT55 ethylene tube 1/8 inch×1/4 inch 5m
6 LMT55 ethylene tube 1/16 inch×1/8 inch 5m
7 Teflon FEP hard pipe 1mm×2mm 5m
8 Teflon FEP hard pipe 1.5mm×2.5mm 5m
9 Teflon FEP hard pipe 2.1mm×3.2mm 3m
10 Silicone tube 8mm×14mm 3m
11 Water supply filter and detergent filter For tubing 1 piece for each
12 Probe For sample-aspirating 1
13 Mixing bar For mixing 2
14 Wiping white block of rinsing mechanism For rinsing cuvette Two for each spec.
15 Rinsing of syringe pump For water supply during rinsing 1
16 Sample dispensing in syringe pump For dispensing sample and reagent 1
7.4 Maintenance methods

● Don't spill water, reagent detergent or other solutions on the machine or electric parts of the Analyzer in
case of any damages.
● Do not touch probe mechanism, mixing mechanism or cuvette-rinsing mechanism during operation of the
Analyzer in case of infection or injury.
● During operation, the operators shall take preventive measures like wear protective gloves, glasses, working
suits in case of infection due to touch with polluted area or solution or skin injury due to contacting with
corrosive liquid. The operator shall rinse with water and take disinfection measures after contacting the
polluted or corrosive liquid due to carelessness.
● During maintenance process, please check whether there are hazards caused by inefficiency of hoses or
parts filled with solution.
7.4.1 Probe
The inner/outer wall of the probe may have serum, reagent or drops attached, or is easy to be blocked if being polluted,
as a result the test results of the Analyzer may be affected. Therefore, regular check and rinsing or cleaning are
needed.
(1)Daily automatic rinsing of the Analyzer
Place a reagent bottle (70mL bottle) with CS-anti-bacterial phosphor-free detergent at position outer 1 of the sample
reagent disk, as shown in the figure:
74
Service Manual of Auto-Chemistry Analyzer


Fig. 7-4-1
When the filling finishes, the probe will automatically aspirate CS-anti-bacterial phosphor-free detergent or
CS-alkaline detergent for rinsing.

Place detergent at stipulated position to avoid cross contamination of cuvette and probe during rinsing.
(2)Cleaning of probe tip surface
a)Turn off the power of the Analyzer.
b)Remove the cover of reagent disk, and move rotary arm of probe on the disk by hands, as shown in the figure:

Fig. 7-4-2
c)Wipe the surface of the probe with cotton swab dipped in alcohol, as shown in the figure:

Fig. 7-4-3
75
Service Manual of Auto-Chemistry Analyzer


Don't put a large amount of alcohol near the Analyzer during use providing the alcohol is inflammable.
d)After powering-on again, the probe will automatically swing to resetting position.
(3)Cleaning of blocked probe and serious cross contamination
a)Turn off the power of the Analyzer.
b)Hold the cope shell of the probe with fingers and then pick up to take it off as shown in the figure:

Fig. 7-4-4
Unscrew tubing connector as shown in the figure:

Fig. 7-4-5
c)Remove the probe.
d)Connect the connector at the end of the probe unblocking tool with the that on the probe, as shown in the figure:
Take a clean cuvette and inject sodium hypochlorite detergent; then put the probe into the detergent in the cuvette
and pull the piston of the syringe to absorb the detergent; finally eject the detergent after 5 min.

Fig. 7-4-6
76
Service Manual of Auto-Chemistry Analyzer

If failed to unblock the probe, soak the probe in hot water for 5 min, and pull/push the syringe piston repeatedly.
e)After step d), if the probe still cannot discharge liquid, the blockage is very serious, then the needle shall be
penetrated from the probe tip for cleaning again, as shown in the figure:

Fig. 7-4-7
Afterwards, repeat step d) with probe unblocking needle.
f)Ensure that the probe is properly installed and then turn on the Analyzer power switch to reset the entireunit. After the Analyzer enters the standby state, if the test is performed, the power of the Analyzer needs to
be turned off again, and the power switch is turned on again after 10 seconds to prevent the liquid level
detection function from malfunctioning.
(4)Adjustment and confirmation of probe position
a)Turn on the power source of the Analyzer.
b)Click the "Maintain" button in the functions area.
c)Select "horizontal check of probe" and "mixing mechanism" on the "Mechanism check" list, then click the "
" button and the " " button to move on the next action.
d)Conduct "horizontal check of probe", and when probe stops above the cuvette, check whether the point of probe
is at the center of cuvette, as shown in Fig. 7-4-8. If not, contact the maintenance personnel.
Cuvette
Probe front

Fig. 7-4-8
e)Execute "mixing mechanism check", when mixing bar stops above the cuvette, check whether the point of
mixing bar is at the center of cuvette. If not, contact the maintenance personnel.
Overlook the position of probe and mixing bar relative to cuvette, as shown in the figure:
77
Service Manual of Auto-Chemistry Analyzer

R1+R2 mixing position
R1 mixing position
Re
act
ion

dis
k
Dispensing
position

Fig. 7-4-9
Click the " " button to end the maintenance process.
Horizontal check process of lifting mechanism of probe:
Probe reset→upper part of cuvette→rinsing bath (with a pause)→sample reagent disk outer 1 reagent bottle
position (going downward)→rinsing bath above the cuvette (with a pause)→sample reagent disk position inner 2
reagent bottle (going downward)→rinsing bath (with a pause)→repeat above steps.
Check process of mixing mechanism:
Mixing bar reset→above the cuvette→rinsing bath→above the cuvette→repeat the action process.
f)Vertical check of probe
Select "vertical check of sample probe" from "Mechanism check" on the "System maintenance" window, and click
the " " button, the probe will descend until its point touches the bottom of standard cup.
g)Vertical check of probe
During the vertical check of reagent probe, take three 70mL reagent bottles and fill 5mL and 50mL normal saline
into the 1st and 2nd bottle respectively, then place the reagent bottle with 5mL of normal saline in position outer 1
of the sample reagent disk, select corresponding reagent volume on the window, and click the "
" button. During test, the Analyzer will remember the height as the benchmark value for
calculating reagent left.

The normal saline must be used for the vertical check of probe, if the volume of liquid is not correct, alarm
prompt "wrong placing of reagent bottle for vertical check" will be sent.
(5)Cleaning of rinsing bath
78
Service Manual of Auto-Chemistry Analyzer

a)If rinsing bath is polluted, use the tube brush or cotton swab dipped in 2% CS series anti-bacterial phosphor-free
detergent for cleaning as shown in the figure:

Fig. 7-4-10
b)Fill about 10mL of 2% CS series anti-bacterial phosphor-free detergent in the rinsing bath as shown in the figure:

Fig. 7-4-11
c)Fill about 100mL of water in rinsing for washing.
After flushing, the dirt in the rinsing tank can be removed, and the bacteria can be inhibited to grow and breed.
Generally, the cleaning process shall be conducted once every month. The dirt of the Analyzer discovered during use
shall be cleared promptly.
7.4.2 Reaction disk
Polluted cuvette or incubation bath may lead to inaccurate test result. In addition, clean the cuvette regularly and
check the cuvette blank value as it is going aging after long time of using; when warning of abnormal cuvette blank
value is given, clean cuvette in time.
(1)Dirt confirmation of cuvette
a)Turn on the power source of the Analyzer.
b)Execute cuvette blank test in "Cuvette blank and quantity of light" on the "System maintenance" window.
c)The cuvette blank value of Cuvette 1 shall be in the range of 8000-18000, and the test value of Cuvette 2~56 shall
be within the range of -1500～1500, which is the difference with cuvette blank value of No.1 cuvette.
d)If the cuvette blank value is not qualified, execute the test after rinsing cuvette, if cuvette blank value still
exceeds the standard, the cuvette shall be replaced.

The cuvette blank value can be displayed and printed. But the Analyzer will not store cuvette blank value
tested.
79
Service Manual of Auto-Chemistry Analyzer

(2)Rinsing of cuvette
The difference between cuvettes out of the range of -1500～1500 may be caused by polluted cuvette, and in this
condition the cuvette shall be rinsed. However, if cuvette cannot meet the demands after rinsing, it shall be replaced
in time.
a)Rinse cuvette through selecting "Rinse" from the "System maintenance" window.
b)After rinsing, execute cuvette blank test again. If the difference between cuvettes remains out of range
of-1500~1500, replace them with new ones.

To avoid being polluted after long time of using, soak cuvettes in 2% CS series anti-bacterial phosphor-free
detergent for 8 hours every month, then wash the residual detergent on cuvette surface with clean water, and
wash the water with pure water . After the outer surface of the cuvettes is dry, install them on the reaction
disk. Test can only be executed until cuvette blank is checked to be qualified.
(3)Clean outer wall of cuvette
It is recommended to clean the outer wall of the cuvettes with lens paper once a week. Care should be taken not to
leave scratches on the outer wall of the cuvettes during cleaning.
(4)Replace cuvette
Please replace with new cuvette if cuvette blank value is unqualified after rinsing.

New cuvette shall be soaked in 2% CS series anti-bacterial phosphor-free detergent for over 8 hours before
using, and installed on reaction disk after rinsing, and the test can only be executed until cuvette blank is
checked to be qualified.
a)Turn off the power of the Analyzer.
b)Wear the protective gloves, take down the rinsing tip, then hold the reaction disk cover handle and lift it up
forcibly (do not shake it to left and right in a large range in case of damaging the pin), next take down the reaction
disk cover and put it at a clean place as shown in the figure:

Fig. 7-4-12
c)Remove the fixing screw as shown in the figure:
80
Service Manual of Auto-Chemistry Analyzer


Fig. 7-4-13
d)Remove the cuvette as shown in the figure:

Fig. 7-4-14
e)Remove other cuvettes, then installed the new soaked cuvettes on the reaction disk. The 8 sets of cuvettes shall be
replaced at the same time.
f)Turn on the power source of the Analyzer.
g)Execute cuvette blank test in "Cuvette blank and quantity of light" on the "System Maintenance" window.
Cuvette blank test must be executed after replacement of cuvette every time. The test can only be executed when
cuvette blank value is qualified.

● There will be contaminants on the cuvette wall if the used cuvette is exposed in the air for a long time.Thus
the cuvette shall be immersed in the pure water. In addition, take off the cuvette to soak it in pure water if the
Analyzer has not been used for more than 3 days in a row. If there is the emergency stop during testing, rinse
the unrinsed cuvette with pure water to prevent the reaction solution remaining on the cuvette for a long time.
● Do not wipe the cuvette with or soak it in organic solvents (benzenes or ethanol).
Fixing screw
Cuvette installation
disk fixing screw Screw of cuvette
installation disk
handle
81
Service Manual of Auto-Chemistry Analyzer

(5)Cleaning of incubation bath, dust screen and axial fan
As the test result may be inaccurate if the incubation batch and axial fan are seriously polluted by downy or silky dust,
cleaning shall be executed every month.
a)Follow the "Replace cuvette" process of the above section, remove the reaction disk cover, then loosen the fixing
screw of cuvette installation disk, rotatethe screw of cuvette installation disk handle in anti-clockwise direction to
a limited height, and lift and take down the cuvette installation disk and put it at a clean position.
b)Loosen the fan fixing screw, then take out the fan fixing rack and the fan, and clear the dust in the incubation
batch, dust screen and fan blade with brush and wet gauze as shown in the figure below:

Fig. 7-4-15

Prevent the water on the inner wall of the cuvette from dripping into the Analyzer. Otherwise, it may cause
faults of the Analyzer.
c)Wipe the metering window of incubation bath with clean and wet gauze, as shown in the figure:

Fig. 7-4-16

Do not scratch or let sundries attached on metering window.
d)After cleaning, reinstall the fan, dust screen, cuvette installation disk and reaction disk cover.
e)Reinstall the rinsing head of the Analyzer on the original position and fix it.
f)Execute cuvette blank test in "Cuvette blank and quantity of light" of the "System maintenance" window, and the
test can only be executed when the cuvette blank value is qualified.

Screw the fixed knob of reaction disk tightly when installing reaction disk to ensure a reliable installation and
82
Service Manual of Auto-Chemistry Analyzer

no loosening.
(6)Cleaning of detergent bottle
As CS-alkaline detergent is added at proper time into detergent bottle to maintain the daily usage, cleaning is
suggested to be executed every month because dust or crystal may exist after long time of using.
a)Turn off the Analyzer main power or perform this maintenance in standby mode.
b)Push the detergent replacing window forward slightly and stop once hearing the sound, then the window is
available to be opened as shown in Fig. 7-4-17: first turn on the detergent float switch, then tilt the detergent bottle
in the direction of the arrow and take it out and open the cover of detergent bottle. Please clear the bottle when there
is a little detergent.

Fig. 7-4-17
c)Clean the detergent bottle cover with a rag.
d)Take down the detergent bottle, and rinse the inner/outer wall of the box with detergent, wash it with tap water,
then clear it with pure water.
e)Pull out the filter assembly on the top of the detergent pipeline, use a cotton swab to push part 9 out from the hole
of installation part 6, use tap water to rinse the front and back of part 9 until there is no debris on it, and then put it
back in the original position after rinsing.
f)Wipe the water drips on the bottle surface with dry cloth, then fill the detergent bottle with 1LCS-alkaline
detergent and reinstall it.

The detergent tubing shall be free of right-angle bending after the detergent bottle is installed or it will cause
blocking.
g)Connect the float switch again, and close the detergent replacing window.
h)Execute "Filling and flushing detergent tubing exhaust" in "Exhaust" menu on the "System maintenance"
window.
Detergent bottle
Detergent float Detergent connector
Detergent replacing
window
83
Service Manual of Auto-Chemistry Analyzer

7.4.3 Light source lamp
The precision of the Analyzer will decline as the light power will be weaker due to the aging light source lamp. Check
quantity of light, if the check value is larger than 18000, replace halogen lamp in time. See "6.1.1 Halogen lamp
replacement " for specific operation method.
7.4.4 Nozzles of rinsing mechanism
Unable to rinse cuvette or water overflow out of the cuvette due to the blocked nozzle of the Analyzer may lead to the
failure of the Analyzer or inaccurate test data.
(1)Anticlockwise screw out fixing screws on the rinsing mechanism to remove the cuvette rinsing mechanism.
(2)Wipe the outer wall of the nozzle with swab dipped in 2% CS series anti-bacterial phosphor-free detergent, as
shown in the figure:

Fig. 7-4-20

Do not bend the nozzle, or replace with severely polluted or worn swabbing block during operation.
(3)Slightly rotate the swabbing block to pull it out. Install the swabbing block as shown in the figure: do not install at
wrong direction, and the bottom of swabbing block shall be parallel to the cuvette.
Pr
es
s
Cuvette
Rinse nozzle
Wiping block

Fig. 7-4-21
(4)Install the rinsing mechanism on its original position.
(5)Execute "Mechanical action check" for 10 times in "Mechanism check" of the "System maintenance" window.
The swabbing block shall not touch the cuvette. The rinsing water shall be near to the cuvette rim and not spill out of
the cuvette.
7.4.5 Mixing bar
Cross contamination caused by polluted mixing bar may affect the accuracy and precision of test result. Thus, regular
Rinse nozzles of
mechanism Wiping block of
rinsing mechanism
Fixing screw of
rinsing mechanism
84
Service Manual of Auto-Chemistry Analyzer

cleaning is necessary. In addition, replace mixing bar if it is bent.
(1)Cleaning of mixing bar
Wipe mixing bar with gauze dipped in ethanol, then wipe out the liquid on its surface with that dipped in pure water,
as shown in the figure: do not bend mixing bar during wiping.

Fig. 7-4-22
(2)Replacement of mixing bar, See "6.1.3 Replacement and debugging of mixing bar " for specific operation method.
7.4.6 Cleaning refrigeration chamber
As the refrigeration chamber may be polluted by sample, reagent or dust, cleaning shall be executed once a month.
(1)Take out the sample disk, and wipe the part inside the refrigeration chamber with gauze:

Fig. 7-4-27
(2)Wipe the reader window of barcode reader with lens paper, as shown in the figure:

Fig. 7-4-28
85
Service Manual of Auto-Chemistry Analyzer


As laser barcode reader is adopted for the Analyzer, do not directly look at the reader window of barcode
reader under non-shutdown status.
7.4.7 Syringe pump
(1)Syringe pump includes detergent syringe pump and dispensing syringe pump, and also ISE dilution syringe pump
if it is connected with ISE device. Syringe pump can be generally used for about 1 million times, and needs to be
replaced after the 15 months of using. Please contact consumer-service staff for replacement.
(2)Check the syringe pump observation in front of the Analyzer and whether the dispensing syringe pump has
bubbles, if so, conduct exhausting and maintenance according to 7.2.3, as shown in the figure:

Fig. 7-4-29

Use pure water to clean surface of syringe pump instead of alcohol or other organic solution.
7.4.8 Maintenance of the Analyzer before stop
Take the following measures to maintain the Analyzer before maintenance or treatment:
(1)Take out all reagent bottles, and sample tubes and standard cups containing sample, calibrator and QC solution
from the sample reagent disk.
(2)Remove the tubing and cables connected with the pure water tank and the waste liquid tank by the method detailed
in "7.4.11 Cleaning of tanks and filters".
(3)Completely exhaust the liquid in the syringe pump and other tubes.
(4)Push directly during a stable transport in short distance.
(5)Keep the Analyzer vertical during carrying and transport process.
(6)Avoid vibration during carrying, and check and adjust the Analyzer after carrying to make sure it is normal before
use.
7.4.9 Cleaning and maintenance of the Analyzer
Clean the surface of analyzer regularly to keep it tidy. Wipe the surface with a wet and soft cloth or gauze, or those
dipped in pure water of small amount if necessary. But don't wipe it with any organic solvent in case of damages to
the shell.
The operator shall pay attention to the following matters during cleaning:
(1)Take proper disinfection measures in case of hazardous substance leaked on the surface or inside the equipment.
(Carry out disinfection through wiping with 84 disinfectant that is diluted with the ratio of 1:200).
Rinsing syringe
pump
ISE dilution
syringe pump
Observation window
of syringe pump
Sample dispensing
syringe pump
86
Service Manual of Auto-ChemistryAnalyzer

(2)Don't use the detergent or sanitizer with possibility of danger due to chemical reaction with parts or materials in
equipment.
(3)In case of doubts about the compatibility between sanitizer or detergent and parts or materials in equipment, please
consult the manufacturer or its agencies.
7.4.10 Waste liquid treatment
Two kinds of waste liquid will be produced during the normal operation of the Analyzer:
(1)High-concentration waste liquid: generated during the test, and the waste liquid contains serum and various
biochemistry reagent.
(2)Low-concentration waste liquid: composed of pure water for rinsing the cuvette of the Analyzer, that for rinsing
all probe mechanism, overflowing water and condensate water.
According to the national laws and regulations, the waste liquid shall be discharged only after disinfection, and the
waste liquid generated from the Analyzer shall be disposed as per the following principles:
(1)High-concentration waste liquid: drain the waste liquid after mixing with "84 disinfectant" as the proportion of 1:
50.
(2)Low-concentration waste liquid: it can be directly discharged only if the PH concentration is in compliance with
the Level-one standard of maximum discharging concentration.

● Please handle the waste fluid of the Analyzer to prevent potential biological and chemical pollution.
● High-concentration waste liquid cannot be discharged after mixing with low-concentration waste liquid.
7.4.11 Cleaning of pure water tank and filter
In case of operation duration of the Analyzer over 1 month under normal status, the pure water tank may have
impurities which will affect the measurement accuracy and instrument stability, so the regular cleaning shall be
conducted to the pure water tank and the filter:
87
Service Manual of Auto-Chemistry Analyzer


Fig. 7-4-30
(1)Take out pure water float switch from the pure water tank (No. 3 of Fig. 7-4-30), remove the inlet tube (No. 2 of
Fig. 7-4-30) and put it at a clean position, then separate Tube 2 from Part 6, and push out the Part 6 from the mounting
part 6 with a swab, next wash the Part 9 with tap water at its front and back faces, and finally reinstall the part.
(2)Rinse the pure water tank with clean water at least for 3 times till there are no visible impurities on the inner wall.
(3)Assemble the parts of the pure water tank and connect it with the Analyzer correctly.
(4)Enter the "Exhaust" window under the "System Maintenance" interface, select "Not suck detergent", click the "
" button to carry out syringe pump exhaust to avoid bubbles in the tubing.
7.5 Maintenance of electrolyte device
7.5.1 Clean, check and replace parts regularly
See the parts to be cleaned or replaced in the Table 7-5-1 (calculate as 5 using hours per day of the Analyzer):
(○: Clean and check regularly ●: Replace parts regularly)
Table 7-5-1
No. Items
Periodic
Reference
Daily Appropriate time Weekly Monthly
Every 2
months
Every 3
months
Every 6
months
1 Syringe pump (diluent, sample) ● 7.4.11
2 Rinsing of the matching cuvette ○ 7.5.2
3 Rinsing of reagent tubing ○ 7.5.3
1
2
1
3
4
5
88
Service Manual of Auto-Chemistry Analyzer

No. Items
Periodic
Reference
Daily Appropriate time Weekly Monthly
Every 2
months
Every 3
months
Every 6
months
4 Na electrode ● 7.5.4
5 K electrode ● 7.5.4
6 CI electrode ● 7.5.4
7 Reference electrode ● 7.5.4
8 Tube for pinch valve ● 7.5.5
9 Rinse flow cell ○ 7.5.6
7.5.2 Rinsing of ISE matching cuvette
After electrolyte test, matching cuvette may be polluted by protein, fat or bacteria. The cup shall be rinsed after a
certain time of testing to ensure normal usage.
(1)Place a standard cup of CS-ISE Detergent at position 01 (outer circle position 01) of the sample reagent
disk.
(2)After testing every week, execute and select "Rinse ISE matching cuvette" from the "ISE" window of "System
maintenance".
7.5.3 Rinsing of ISE reagent tubing
ISE tubing may be polluted after long time of using, which may further lead to inaccurate data. Rinse once a month as
the steps below.
(1)The implementation of rinsing ISE reagent tubing
a)Dilute CS-ISE detergent with pure water to 20 times, and take 200mL of the solution into an open vessel for
backup.
b)Take out the reagent suck of reference solution, diluent and standard solution from reagent bottle, and plug them
into container with diluted detergent, then execute "Rinse all ISE tubing" for 3 times in the "ISE" window of
"System maintenance".
c)After rinsing, take out the reagent sucking tube of reference solution, diluent and standard solution from
detergent container, and wash the CS-ISE detergent attached on the suckers with pure water, then wipe them with
gauze, and finally put back the reagent bottles with reference solution, diluent and standard solution.
d)Execute "Rinse all ISE tubing" three times in the "ISE" window of "System maintenance".
e)Execute ISE calibration after rinsing all tubing.
(2)The implementation of ISE check
Execute "ISE check" for 30 times in "ISE" window of "System maintenance". The check result will be displayed.

The result difference of successive 2 checks of the same electrode shall be no more than 0.2mV.
7.5.4 Rinse flow cell
(1)Place a standard cup with fresh CS-ISE detergent at position outer 1 of the sample reagent disk.
(2)After testing every week, execute and select "Rinse ISE flow cell" from "ISE" window in "System maintenance".
7.5.5 Maintenance of Cl electrode
(1)To remove the Cl electrode to be maintained.
89
Service Manual of Auto-Chemistry Analyzer

(2)Lay down the sanding paper on the table (as shown in the figure below), and drip 3-5 drops of pure water on the
sanding paper; remove the electrode seal ring at the front of electrode, and hold the electrode head with hands to make
the head perpendicular to sanding paper with its surface touching the paper. Draw "8" with electrode to polish the
electrode head for 5-10 times in the area dripped with pure water until the electrode head is glossy.

Fig. 7-5-1

● Electrode head shall be perpendicular to the sanding paper during polishing.
● Do not press electrode head hard, the head shall only slightly touch the sanding paper during polishing.
(3)Slightly wipe the electrode head with cotton swab dipped in pure water to wipe residual matters and dry the
electrode.
(4)Drip a little drop of silicone mixture at the surface of electrode head, and evenly smear the mixture on the surface,
then wipe out residual silicone with dry cotton swab until only a slim layer left on the surface.
(5)It can be used after electrode is reinstalled.

● Maintain Cl electrode every month.
● If the seal ring cannot be well installed on the electrode head after several maintenance times of Cl electrode,
replace with new electrode in time.
7.5.6 Rinsing of ISE waste liquid part
If crystal attaches on ISE waste liquid part, it may lead to inaccurate test result due to the generation of poor insulation
performance, thus cleaning is suggested to be executed once a week.
(1)Rinsing bottle with pure water will wash the crystal and pollutant from the interface of waste liquid part to the
waste liquid container. Then wash the internal of waste liquid container with pure water, as shown in the figure:
90
Service Manual of Auto-Chemistry Analyzer


Fig. 7-5-2
(2)Wipe with gauze dipped in pure water to prevent residual conductive component on waste liquid interface and the
outer side of waste liquid water container.

Noise interference may be caused by the touch of waste liquid hose during testing.
7.6 Scrapped analyzer
Do not abandon the Analyzer randomly after its service life but inform of the manufacturer for recycle.


91
Service Manual of Auto-Chemistry Analyzer

Chapter 8 Fault analysis
8.1 Causes and analysisof faults with alarm code
8.1.1 Main control module
Fault code Fault description Fault cause analysis Solution
1-1-1 Incubation bath pre-heating timeout
Temperature in incubation bath does not reach constant 37°C in
regulated time during resetting.
(1) Check if the CAN cable connection of main control board and AC
control board is normal;
(2) Check if the operation indicator lamp of AC control board flickers;
(3) Check if the wiring of temperature sensor of incubation bath of AC
control board is normal;
(4) Check if the wiring of heating device of incubation bath of AC control
board is normal;
(5) Check other alarms of the AC control board
1-1-2 Abnormal can bus of reaction disk can heartbeat response timeout of reaction disk control board and abnormal can bus
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-3 Abnormal can bus of probe can heartbeat response timeout of probe control board and abnormal can bus
(1) Check if the CAN cable connection of main control board and probe
control board is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-4 Abnormal can bus of AC board can heartbeat response timeout of AC control board and abnormal can bus
(1) Check if the CAN cable connection of main control board and AC
control board is normal;
(2) Check if the operation indicator lamp of AC control board flickers;
(3) Check other alarms of the AC control board
1-1-6 Data receiving of data collection board timeout
Data has not been received from data collection board in 20
seconds during test
(1) Check if the serial port cable connection of main control board and data
collection board is normal;
(2) Check if the operation indicator lamp of data collection board flickers;
1-1-7 Sample dispensing of probe timeout
The Finish command is not replied in regulated time after probe
dispenses sample.
(1) Check if the CAN cable connection of main control board and probe
control board is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-8 R1 dispensing of probe timeout The Finish command is not replied in regulated time after probe dispenses R1.
(1) Check if the CAN cable connection of main control board and probe
control board is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
92
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-9 R2 dispensing of probe timeout The Finish command is not replied in regulated time after probe dispenses R2.
(1) Check if the CAN cable connection of main control board and probe
control board is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-10 ISE dispensing of probe timeout The Finish command is not replied in regulated time after probe dispenses ISE.
(1) Check if the CAN cable connection of main control board and probe
control board is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-13 Abnormal communication of data collection board No response of data collection board during resetting
(1) Check if the serial port cable connection of main control board and data
collection board is normal;
(2) Check if the operation indicator lamp of data collection board flickers;
1-1-15 Communication and data collection timeout
Communication and data collection is not finished in regulated
time
(1) Check if the serial port cable of main control board and data collection
board is normal;
(2) Check if the CAN cable of main control board and reaction disk control
board is normal;
(3) Check if the operation indicator lamp of data collection board flickers;
(4) Check if the operation indicator lamp of reaction disk control board
flickers;
(5) Check other alarms
1-1-16 Probe maintenance action: vertical inspection of reaction disk timeout
Execute probe maintenance action: no maintenance completion
command received when it comes to vertical inspection of
reaction disk
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-17 Probe maintenance action: vertical inspection of reagent disk timeout
Execute probe maintenance action: no maintenance completion
command received when it comes to vertical inspection of
reagent disk
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-18 Maintenance action: horizontal inspection of probe timeout
Execute probe maintenance action: no maintenance completion
command received when it comes to horizontal inspection of
probe
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-19 Maintenance action: syringe pump air exhausting timeout
No maintenance completion command received when executing
air exhausting action of syringe pump
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-20 Maintenance action: rinsing mechanism inspection timeout
No maintenance completion command received when executing
inspection action of rinsing mechanism
(1) Check if the CAN cable of main control board and reaction disk control
board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
93
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-21 Maintenance action: mixing mechanism inspection timeout
No maintenance completion command received when executing
inspection action of rinsing mechanism
(1) Check if the CAN cable of main control board and reaction disk control
board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-22 Residual reagent volume scanning timeout under standby mode
Residual reagent volume scanning not finished in regulated time
under standby mode
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-23 Bar code scanning timeout under standby mode
Bar code scanning not finished in regulated time under standby
mode
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-24 Maintenance action: water drainage timeout
Execute maintenance action: no maintenance completion
command received in regulated time during water drainage of
machine
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-25 Maintenance action: bar code position inspection timeout
Executemaintenance action: no maintenance completion
command received in regulated time during bar code position
inspection
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-26 Maintenance action: ISE inspection timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE inspection
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-27 Maintenance action: ISE internal standard tubing rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE internal
standard tubing rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-28 Maintenance action: ISE reference tubing rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE reference
tubing rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-29 Maintenance action: ISE dilution tubing rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE dilution tubing
rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-30 Maintenance action: ISE all tubing rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE all tubing
rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
94
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-31 Maintenance action: ISE dilution pump air exhausting timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE dilution pump
air exhausting
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-32 Maintenance action: ISE flow cell rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE flow cell
rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-33 Maintenance action: ISE proportioning cup rinsing timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE proportioning
cup rinsing
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
(3) Check other alarms of the ISE control board
1-1-34 Sample skip Skip all tests of the sample if the sample volume is insufficient.
(1) Check the residual sample volume
(2) Check if the liquid level detection board works normally
(3) Check if the sample is put at a wrong place
1-1-35 R1 reagent skip Skip all tests with this reagent if the R1 reagent volume is insufficient.
(1) Check the residual reagent volume
(2) Check if the liquid level detection board works normally
(3) Check if the reagent is put at a wrong place
1-1-36 R2 reagent skip Skip all tests with this reagent if the R2 reagent volume is insufficient.
(1) Check the residual reagent volume
(2) Check if the liquid level detection board works normally
(3) Check if the reagent is put at a wrong place
1-1-37 Cuvettes stained continuously 5 continuously stained cuvettes in test
(1) Check if the cuvette is cleaned
(2) Check if the rinsing mechanism works normally
(3) Check if the voltage of light source is lower than the threshold value
(4) Check if the light source is blocked
(5) Check other alarms
1-1-38 Cuvettes stained Cuvette blank value exceeds the set upper and lower limit in test
(1) Check if the cuvette is cleaned
(2) Check if the rinsing mechanism works normally
(3) Check if the voltage of light source is lower than the threshold value
(4) Check if the light source is blocked
(5) Check other alarms
1-1-39 Reaction disk control board resetting failed
Reaction disk resetting failed when executing resetting action of
the machine (1) Check the alarms of reaction disk
1-1-40 Probe control board resetting failed Probe resetting failed when executing resetting action of the machine (1) Check the alarms of probe
1-1-41 AC control board resetting failed AC control board resetting failed when executing resetting action of the machine (1) Check AC alarms
1-1-42 ISE control board resetting failed ISE resetting failed when executing resetting action of the machine (1) Check ISE alarms
1-1-43 Little white block rinsing failed Little white block rinsing failed after executing resetting action of the machine (1) Check the alarms of reaction disk
95
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-44 Reagent is used up Residual reagent volume in R1 or R2 bottle is less than minimum residual volume
(1) Check the residual reagent volume
(2) Check if the liquid level detection board works normally
(3) Check if the reagent is put at a wrong place
1-1-45
Waiting for sample dispensing
timeout under sample dispensing
suspension state
Under the sample dispensing suspension state, sample
dispensing is not continued in regulated time
(1) Check if it is to click to continue sample dispensing
(2) Check if it is to click to determine or cancel disk change
1-1-46 Basic value gaining failed The cuvette blank of the cuvette for first test exceeds the range 8000-18000
(1) Check if the serial port cable connection of main control board and data
collection board is normal;
(2) Check if the operation indicator lamp of data collection board flickers;
(3) Check if the light source is turned on
1-1-47 Probe detects bubbles Membrane or bubbles are found at bottle mouth when the probe aspirates sample or reagent
(1) Check if there are membranes or air bubbles at the mouth of test tube or
reagent bottle
(2) Check if the probe control board works normally
(3) Check if the liquid level detection board works normally
1-1-48 Liquid surface detection failure. The probe fails to descend more.
The probe fails to descend more as the liquid detection signal is
disturbed above the bottle mouth when the probe aspirates
sample or reagent
(1) Check if the probe control board works normally
(2) Check if the liquid level detection board works normally
1-1-49 Maintenance action: water quality inspection timeout
Execute maintenance action: no maintenance completion
command received in regulated time during ISE all tubing
rinsing
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-50 Maintenance action: vertical inspection of probe timeout
Execute probe maintenance action: no maintenance completion
command received when it comes to verticalinspection of probe
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-51 Reaction disk triggering sequence error Reaction disk received is not the first one triggered 10 start
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-52 Reaction disk triggering sequence error Reaction disk received is not the first one triggered 10 stop
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-53 Reaction disk triggering sequence error Reaction disk received is not the one triggered 30 start
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
96
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-54 Reaction disk triggering sequence error Reaction disk received is not the one triggered 30 stop
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-55 Reaction disk triggering sequence error Reaction disk received is not the second one triggered 10 start
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-56 Reaction disk triggering sequence error Reaction disk received is not the second one triggered 10 start
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-57 Reaction disk triggering sequence error Reaction disk received is not the one triggered 35 start
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-58 Reaction disk triggering sequence error Reaction disk received is not the one triggered 35 stop
(1) Check if the CAN cable connection of main control board and reaction
disk control board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
(3) Check other alarms of the reaction disk control board
1-1-59 Abnormal disconnection of test software
Abnormal disconnection of network occurs when the test
software does not click to disconnect the network
(1) Check if network connection is normal;
(2) Check if network operation is normal;
1-1-60 Water quality check failed Abnormal structure in water quality check
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-61 Reagent/ sample disk resetting failed Reagent/ sample disk resetting failed during testing
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-62 Reagent/ sample disk zeroing failed Reagent/ sample disk zeroing failed after the completion of test
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
97
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
1-1-63 Instrument status reading timeout Instrument status not returned in specified time when reading the instrument status
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-64 Residual reagent volume scanning failed during testing Faults found in residual reagent volume scanning during the test
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-65 Residual reagent volume scanning timeout during testing
Scanning not completed in specified time in residual reagent
volume scanning during the test
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-66 Test adding abnormality when reaction disk is to stop
When the test is to be completed and test is to be added when the
reaction disk is to stop, the instrument does not process and has
alarm prompt.

1-1-67 Probe control board resetting timeout
Reply of probe control board not received in regulated time
during resetting
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
1-1-68 Reaction disk control board resetting timeout
Reply of reaction disk control board not received in regulated
time during resetting
(1) Check if the CAN cable of main control board and reaction disk control
board is normal;
(2) Check if the operation indicator lamp of reaction disk control board
flickers;
1-1-69 AC control board resetting timeout Reply of reaction disk control board not received in regulated time during resetting
(1) Check if the CAN cable of main control board and AC control board is
normal;
(2) Check if the operation indicator lamp of AC control board flickers;
1-1-70 ISE control board resetting timeout Reply of ISE control board not received in regulated time during resetting
(1) Check if the CAN cable of main control board and ISE control board is
normal;
(2) Check if the operation indicator lamp of ISE control board flickers;
1-1-71 Little white block rinsing timeout Reply of little white block rinsing completion not received in regulated time during resetting
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board
1-1-72 Probe rinsing timeout Probe rinsing completion command not received in regulated time when executing the probe rinsing action
(1) Check if the CAN cable of main control board and probe control board
is normal;
(2) Check if the operation indicator lamp of probe control board flickers;
(3) Check other alarms of the probe control board


98
Service Manual of Auto-Chemistry Analyzer

8.1.2 Reaction disk unit module
Fault code Fault description Fault cause analysis Solution
4-11-1 Process fault
When an action is executed, the alarm is triggered when it
exceeds the preset time. For example, if the time set for the
startup of mixing mechanism is 1s, the alarm will be triggeredif
the program is modified to change the time for startup to 2s.
(1) Feed it back to the engineer
4-11-2
Abnormal water dispensing of
rinsing probe of rinsing
mechanism
The probe detects the water volume of rinsing probe in cuvette.
When the deviation of water volume in No. 1, No. 3 and No. 5
cuvettes is not within the allowable range, this alarm is
triggered.
(1) Check if there is water in water tank;
(2) Check if the rinsing probe is blocked;
(3) Check if solenoid valve V9 V6 V5 V4 have crystallization and
blockage;
(4) Check if the tubing has leakage and if the constant-temperature
degassing tank has air leakage.
4-11-3
Abnormal water aspirating of
rinsing probe of rinsing
mechanism
The probe detects the residual water volume in cuvette after
water aspirating of the probe. When the residual water volume
in No. 1, No. 3, No. 5 and No. 7 cuvettes is greater than the set
value, this alarm is triggered.
(1) Check if the rinsing probe is blocked;
(2) Check if solenoid valve V10 has crystallization and blockage;
(3) Check if the tubing has leakage
4-21-1 Sample probe unlocking reaction disk timeout
In the dispensing process of probe, the command to lock the
reaction disk is transmitted through the CAN bus before
descending is executed at the reaction disk side. The lock of the
reaction disk is released after the completion of ascending and
zeroing. This alarm is triggered if it is detected the reaction disk
is still locked before the reaction disk rotates.
(1) Check other alarm codes if it is caused by human factors;
(2) Feed it back to engineer if it is caused by non-human factors.
4-21-2 Reagent probe R1 unlocking reaction disk timeout
In the dispensing process of probe, the command to lock the
reaction disk is transmitted through the CAN bus before
descending is executed at the reaction disk side. The lock of the
reaction disk is released after the completion of ascending and
zeroing. This alarm is triggered if it is detected the reaction disk
is still locked before the reaction disk rotates.
(1) Check other alarm codes if it is caused by human factors;
(2) Feed it back to engineer if it is caused by non-human factors.
4-21-3 Reagent probe R2 unlocking reaction disk timeout
In the dispensing process of probe, the command to lock the
reaction disk is transmitted through the CAN bus before
descending is executed at the reaction disk side. The lock of the
reaction disk is released after the completion of ascending and
zeroing. This alarm is triggered if it is detected the reaction disk
is still locked before the reaction disk rotates.
(1) Check other alarm codes if it is caused by human factors;
(2) Feed it back to engineer if it is caused by non-human factors.
4-21-4 Mixing mechanism waiting stop of reaction disk mechanism timeout
When the reaction disk mechanism stops rotating, it will trigger
descending of the mixing mechanism. If the trigger time
exceeds the preset allowable range, this alarm is triggered.
(1) Feed it back to the engineer
4-21-5
Rinsing or mixing mechanism
reaction disk is not at the highest
position when the reaction disk is
to rotate.
The reaction disk is locked when the mixing mechanism mixes
in the cuvette. This alarm is triggered when it is detected the
lock of reaction disk mechanism is not released by the mixing
mechanism when the reaction disk mechanism rotates.
(1) Check relevant alarms of the mixing mechanism;
(2) Check relevant alarms of the rinsing mechanism;
99
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-101-1
Driver configuration failure of
mixing mechanism swinging
motor.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the reaction disk control board.
4-101-2 Driver configuration failure of mixing mechanism lifting motor.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the reaction disk control board.
4-101-3 Driver configuration failure of rinsing mechanism motor.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the reaction disk control board.
4-101-4
Driver configuration failure of
reaction disk mechanism lifting
motor.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the reaction disk control board.
4-102-1 Mixing mechanism swinging motor has short circuit. Mixing mechanism swinging motor has short circuit. (1) Replace the reaction disk control board.
4-102-2 Mixing mechanism lifting motor has short circuit. Mixing mechanism lifting motor has short circuit. (1) Replace the reaction disk control board.
4-102-3 Rinsing mechanism motor has short circuit. Rinsing mechanism motor has short circuit. (1) Replace the reaction disk control board.
4-102-4 Reaction disk mechanism lifting motor has short circuit. Reaction disk mechanism lifting motor has short circuit. (1) Replace the reaction disk control board.
4-103-1 Mixing mechanism swinging motor has open circuit. Mixing mechanism swinging motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
4-103-2 Mixing mechanism lifting motor has open circuit. Mixing mechanism lifting motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
4-103-3 Rinsing mechanism motor has open circuit. Rinsing mechanism motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
4-103-4 Reaction disk mechanism lifting motor has open circuit. Reaction disk mechanism lifting motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
4-103-5 Mixing motor has open circuit or faults.
Control board has open circuit inside and mixing motor has
open circuit.
 Back output low level signal triggers the alarm.
(1) Check the cable;
(2) Check the mixing motor;
(3) Replace the probe control board.
4-104-1
Swinging and zeroing of mixing
mechanism fail to reach the zero
point.
After the mixing mechanism finishes the swinging and zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the mixing and swinging optocoupler signal is disturbed.
4-104-2
Lifting and zeroing of mixing
mechanism fail to reach the zero
point.
After the mixing mechanism finishes the lifting and zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if the mixing and lifting optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the mixing and lifting optocoupler signal is disturbed.
4-104-3 Lifting and zeroing of rinsing pump fail to reach the zero point.
After the rinsing mechanism finishes the lifting and zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if the rinsing mechanism lifting optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the rinsing mechanism lifting optocoupler signal is
disturbed.
100
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-104-4 Zeroing of reaction disk fails to reach the zero point.
After the reaction disk mechanism finishes the zeroing action,
the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if thereaction disk zeroing optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the optocoupler signal is disturbed.
4-105-1
Swinging and positioning of
mixing mechanism fail to reach the
preset position.
After the mixing mechanism finishes the swinging and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the mixing and swinging optocoupler signal is disturbed.
4-105-4 Positioning of reaction disk fails to reach the preset position.
After the reaction disk mechanism finishes the rotating and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the reaction disk zeroing optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the optocoupler signal is disturbed.
4-106-1
Abnormal initial position of
swinging and positioning of
mixing mechanism.
Before the mixing mechanism is started to have swinging and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the swinging optocoupler signal is disturbed.
4-106-4 Abnormal initial position of positioning of reaction disk.
Before the reaction disk mechanism is started to have rotating
and positioning action, the alarm is triggered when the level
status of positioning optocoupler is different from the preset
status.
(1) Check if the reaction disk positioning optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the optocoupler signal is disturbed.
4-107-1 Swinging and zeroing failure of mixing mechanism.
When the mixing mechanism is started up to have swinging and
zeroing action, the alarm is triggered when the level status of
zeroing optocoupler is different from the preset status in a
specified time.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and swinging motor is normal;
(4) Check if the cable connection of motor is normal;
4-107-2 Lifting and zeroing failure of mixing mechanism.
When the mixing mechanism is started up to have lifting and
zeroing action, the alarm is triggered when the level status of
zeroing optocoupler is different from the preset status in a
specified time.
(1) Check if the mixing and lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and lifting motor is normal;
(4) Check if the cable connection of motor is normal;
4-107-3 Lifting and zeroing failure of rinsing mechanism.
When the rinsing mechanism is started up to have lifting and
zeroing action, the alarm is triggered when the level status of
zeroing optocoupler is different from the preset status in a
specified time.
(1) Check if the rinsing mechanism lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the rinsing mechanism lifting motor is normal;
(4) Check if the cable connection of motor is normal;
4-107-4 Zeroing failure of reaction disk mechanism
When the reaction disk is started up to have zeroing action, the
alarm is triggered when the level status of zeroing optocoupler is
different from the preset status in a specified time.
(1) Check if the reaction disk mechanism optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reaction disk mechanism motor is normal;
(4) Check if the cable connection of motor is normal;
4-108-1 Swinging of mixing mechanism fails to leave the zero point.
The fault of mixing mechanism swinging and zeroing
optocoupler leads to that the control board misjudges it is at the
zero position. The alarm is triggered when the zeroing
optocoupler level status does not change after a certain steps of
swinging.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and swinging motor is normal;
(4) Check if the cable connection of motor is normal;
4-108-2 Lifting of mixing mechanism fails to leave the zero point.
The fault of mixing mechanism lifting and zeroing optocoupler
leads to that the control board misjudges it is at the zero
position. The alarm is triggered when the zeroing optocoupler
level status does not change after a certain steps of descending.
(1) Check if the mixing and lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and lifting motor is normal;
(4) Check if the cable connection of motor is normal;
101
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-108-3 Rinsing mechanism fails to leave the zero point.
The fault of rinsing mechanism lifting and zeroing optocoupler
leads to that the control board misjudges it is at the zero
position. The alarm is triggered when the zeroing optocoupler
level status does not change after a certain steps of descending.
(1) Check if the rinsing mechanism lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the rinsing mechanism lifting motor is normal;
(4) Check if the cable connection of motor is normal;
4-108-4 Reaction disk mechanism fails to leave the zero point.
The fault of reaction disk mechanism zeroing optocoupler leads
to that the control board misjudges it is at the zero position. The
alarm is triggered when the zeroing optocoupler level status
does not change after a certain steps of rotating.
(1) Check if the reaction disk mechanism optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reaction disk mechanism motor is normal;
(4) Check if the cable connection of motor is normal;
4-109-1 Swinging and positioning failure of mixing mechanism.
When the mixing mechanism has swinging and positioning
action, the alarm is triggered when the level signal change times
of positioning optocoupler is not equal to the preset times in a
specified time.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and swinging motor is normal;
(4) Check if the cable connection of motor is normal;
4-109-4 Positioning failure of reaction disk
When the reaction disk mechanism has rotating and positioning
action, the alarm is triggered when the level signal change times
of positioning optocoupler is not equal to the preset times in a
specified time.
(1) Check if the reaction disk mechanism optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reaction disk mechanism motor is normal;
(4) Check if the cable connection of motor is normal;
4-110-1 Fixed-angle swinging failure of mixing mechanism.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
4-110-2
Fixed-distance lifting or
descending failure of mixing
mechanism.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
4-110-3
Fixed-distance lifting or
descending failure of rinsing
mechanism.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
4-110-4 Fixed-angle rotation failure of reaction disk mechanism
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
4-111-1 Swinging andcoded disc scanning failure of mixing mechanism.
When the mixing mechanism swings to scan the coded disc, the
alarm will be triggered if it fails to swing and the scanned
number of slots (optocoupler level change times) does not reach
the preset number in specified time.
(1) Check if the swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the swinging motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
4-111-4 Coded disc scanning failure of reaction disk mechanism
When the reaction disk mechanism swings to scan the coded
disc, the alarm will be triggered if the positioning optocoupler is
pulled out and the scanned number of slots (optocoupler level
change times) does not reach the preset number in specified
time.
(1) Check if the optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
4-113-1
Abnormal swinging and
positioning verification of mixing
mechanism.
The alarm is triggered when the steps for hindering the mixing
and swinging mechanism to a specific position increase and the
difference between it and the scanned steps of the slots is
beyond the limited range.
(1) Check if the mixing and swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the mixing and swinging motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
(6) Check if the mechanism arm and motor are loose.
102
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-114-1 Abnormal swinging and coded disc verification of mixing mechanism.
The alarm is triggered if the deviation between the scanned
coded disc information due to optocoupler fault or coded disc
abnormality and the theoretical coded disc information is
beyond the allowable range.
(1) Check if the optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
4-114-4 Abnormal coded disc verification of reaction disk mechanism.
The alarm is triggered if the deviation between the scanned
coded disc information due to optocoupler fault or coded disc
abnormality and the theoretical coded disc information is
beyond the allowable range.
(1) Check if the positioning optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
(6) Check if the mechanism motor is loose.
4-115-1
Abnormal swinging and
positioning information
calculation of mixing mechanism.
The alarm is triggered if the mixing mechanism swinging and
positioning information are wrongly set. (1) Feed it back to the engineer
4-116-1 Probe does not swing at the highest point during swinging.
Before the mixing mechanism is started up to have swinging
action, the control board will judge if it is at the highest point
according to the level status of the lifting optocoupler of the
mechanism. If the probe is not at the highest position, the alarm
is triggered.
(1) Check the harness connection;
4-118-2 Abnormal lifting and zeroing verification of mixing mechanism.
Taking the highest point of the mixing mechanism as the zero
point, the coordinates will decrease automatically if it moves
downwards and increase automatically if it moves upwards.
When the mechanism moves from the zero point and then
returns to the zero points, the coordinates are checked and if
they are found beyond the allowable range, the alarm will be
triggered.
(1) Check other alarm information;
4-118-3 Abnormal lifting and zeroing verification of rinsing mechanism.
Taking the highest point of the rinsing mechanism as the zero
point, the coordinates will decrease automatically if it moves
downwards and increase automatically if it moves upwards.
When the mechanism moves from the zero point and then
returns to the zero points, the coordinates are checked and if
they are found beyond the allowable range, the alarm will be
triggered.
(1) Check other alarm information;
4-119-4
Rinsing mechanism is not at the
highest point and reaction disk
mechanism does not rotate.
When the reaction disk mechanism is started up to have rotating
action, the alarm is triggered if it is found not at the highest point
according to the level status of the rinsing mechanism zeroing
optocoupler.
(1) Check the harness connection;
4-120-4 Positioning optocoupler failure of reaction disk.
In the resetting process, the level status of reaction disk
positioning optocoupler will change. If it does not change, the
alarm is triggered.
(1) Check if the circuit connection of reaction disk positioning
optocoupler is normal;
(2) Check if the positioning optocoupler is normal;
103
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-121-4
Positioning optocoupler is not at
the present position after zeroing of
reaction disk.
After the reaction disk finishes the zeroing action, the alarm is
triggered when the level status of positioning optocoupler is
different from the preset status.
(1) Check if the circuit connection of reaction disk positioning
optocoupler is normal;
(2) Check if the positioning optocoupler is normal;
4-131-7 Fault of V7 at rinsing bath of mixing mechanism
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-131-6 Fault of needle valve V6 of rinsing mechanism 1
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-131-5 Fault of needle valve V5 of rinsing mechanism 2
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-131-4 Fault of needle valve V4 of rinsing mechanism 3
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-131-10 Fault of vacuum valve V10
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-131-9 Fault of detergent valve V9
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
4-132-7 Open circuit of V7 at rinsing bath of mixing mechanism
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-132-6 Open circuit of needle valve V6 of rinsing mechanism 1
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-132-5 Open circuit of needle valve V5 of rinsing mechanism 2
The solenoid valve driver chip has the function. When the driver
chip has fault
 andit is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-132-4 Open circuit of needle valve V4 of rinsing mechanism 3
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-132-10 Open circuit of vacuum valve V10
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-132-9 Open circuit of detergent valve V9
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-134-7
Driver configuration failure of V7
at rinsing bath of mixing
mechanism
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
104
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
4-134-6
Driver configuration failure of
needle valve V6 of rinsing
mechanism 1
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-134-5
Driver configuration failure of
needle valve V5 of rinsing
mechanism 2
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-134-4
Driver configuration failure of
needle valve V4 of rinsing
mechanism 3
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-134-10 Driver configuration failure of vacuum valve V10
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-134-9 Driver configuration failure of detergent valve V9
Abnormal communication in SPI between AC256 and
NCV7708
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
4-22-2 Data storage sector erase and failure Data storage sector damaged (1) Replace the probe control board.
4-22-3 Data storage sector data read-in invalid Data storage sector damaged
(1) Read in compensation data to control board. If it continues to alarm,
replace the probe control board.

8.1.3 Probe unit module
Fault code Fault description Fault cause analysis Solution
3-11-1 Process fault
When an action is executed, the alarm is triggered when it
exceeds the preset time. For example, if the time set for the
startup of probe dispensing is 1s, the alarm will be triggered if
the program is modified to change the time for startup to 2s.
(1) Feed it back to the engineer
3-21-7
Abnormal communication of probe
control board and liquid level
detection board during resetting
During resetting, the probe control board has serial port
communication with the liquid level detection board and the
communication circuit is disconnected. The alarm is triggered if
the probe control board does not receive the reply command of
liquid level detection board in specified time.
(1) Check if the wiring of the flexible circuit board at probe control
board end and liquid detection board end is normal;
(2) Replace the liquid level detection board.
(3) Replace the probe control board.
3-21-9
Probe control board waiting for
ISE control board triggering ISE
sample dispensing timeout during
ISE test
In ISE test process, the probe dispenses ISE sample and the
command is triggered by the ISE control board. The alarm is
triggered if the probe control board does not receive the ISE
control board triggering command in unit time.
(1) The alarm is caused as ISE control board fails to send touch
command in a specified time. Check other alarms.
3-32-1
Touch occurs when the probe
detects No.1 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
105
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-2
Touch occurs when the probe
detects No.2 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-3
Touch occurs when the probe
detects No.3 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-4
Touch occurs when the probe
detects No.4 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-5
Touch occurs when the probe
detects No.5 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-6
Touch occurs when the probe
detects No.6 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-7
Touch occurs when the probe
detects No.7 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-8
Touch occurs when the probe
detects No.8 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-9
Touch occurs when the probe
detects No.9 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sampleor reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-10
Touch occurs when the probe
detects No.10 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-11
Touch occurs when the probe
detects No.11 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-12
Touch occurs when the probe
detects No.12 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-13
Touch occurs when the probe
detects No.13 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-14
Touch occurs when the probe
detects No.14 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-15
Touch occurs when the probe
detects No.15 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
106
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-16
Touch occurs when the probe
detects No.16 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-17
Touch occurs when the probe
detects No.17 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-18
Touch occurs when the probe
detects No.18 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-19
Touch occurs when the probe
detects No.19 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-20
Touch occurs when the probe
detects No.20 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-21
Touch occurs when the probe
detects No.21 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-22
Touch occurs when the probe
detects No.22 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-23
Touch occurs when the probe
detects No.23 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-24
Touch occurs when the probe
detects No.24 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-25
Touch occurs when the probe
detects No.25 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-26
Touch occurs when the probe
detects No.26 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-27
Touch occurs when the probe
detects No.27 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-28
Touch occurs when the probe
detects No.28 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-29
Touch occurs when the probe
detects No.29 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
107
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-30
Touch occurs when the probe
detects No.30 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-31
Touch occurs when the probe
detects No.31 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggeredwhen the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-32
Touch occurs when the probe
detects No.32 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-33
Touch occurs when the probe
detects No.33 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-34
Touch occurs when the probe
detects No.34 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-35
Touch occurs when the probe
detects No.35 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-36
Touch occurs when the probe
detects No.36 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-37
Touch occurs when the probe
detects No.37 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-38
Touch occurs when the probe
detects No.38 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-39
Touch occurs when the probe
detects No.39 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-40
Touch occurs when the probe
detects No.40 position of sample/
reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-41
Touch occurs when the probe
detects outer No.1 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-42
Touch occurs when the probe
detects outer No.2 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-43
Touch occurs when the probe
detects outer No.3 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
108
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-44
Touch occurs when the probe
detects outer No.4 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-45
Touch occurs when the probe
detects outer No.5 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-46
Touch occurs when the probe
detects outer No.6 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-47
Touch occurs when the probe
detects outer No.7 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-48
Touch occurs when the probe
detects outer No.8 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-49
Touch occurs when the probe
detects outer No.9 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-50
Touch occurs when the probe
detects outer No.10 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-51
Touch occurs when the probe
detects outer No.11 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-52
Touch occurs when the probe
detects outer No.12 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-53
Touch occurs when the probe
detects outer No.13 position of
sample/ reagent disk
When the probedispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-54
Touch occurs when the probe
detects outer No.14 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-55
Touch occurs when the probe
detects outer No.15 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-56
Touch occurs when the probe
detects outer No.16 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-57
Touch occurs when the probe
detects outer No.17 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
109
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-58
Touch occurs when the probe
detects outer No.18 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-59
Touch occurs when the probe
detects outer No.19 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-60
Touch occurs when the probe
detects outer No.20 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-61
Touch occurs when the probe
detects outer No.21 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-62
Touch occurs when the probe
detects outer No.22 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-63
Touch occurs when the probe
detects outer No.23 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-64
Touch occurs when the probe
detects outer No.24 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-65
Touch occurs when the probe
detects outer No.25 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-66
Touch occurs when the probe
detects outer No.26 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-67
Touch occurs when the probe
detects outer No.27 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-68
Touch occurs when the probe
detects outer No.28 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-69
Touch occurs when the probe
detects outer No.29 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-70
Touch occurs when the probe
detects outer No.30 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-71
Touch occurs when the probe
detects outer No.31 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
110
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-72
Touch occurs when the probe
detects outer No.32 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-73
Touch occurs when the probe
detects outer No.33 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-74
Touch occurs when the probe
detects outer No.34 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-75
Touch occurs when the probe
detects outer No.35 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-76
Touch occurs when the probe
detects outer No.36 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-77
Touch occurs when the probe
detects outer No.37 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-78
Touch occurs when the probe
detects outer No.38 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-79
Touch occurs when the probe
detects outer No.39 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-80
Touch occurs when the probe
detects outer No.40 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-81
Touch occurs when the probe
detects inner No.2 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-82
Touch occurs when the probe
detects inner No.3 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-83
Touch occurs when the probe
detects inner No.4 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-84
Touch occurs when the probe
detects inner No.5 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-85
Touch occurs when the probe
detects inner No.6 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
111
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-86
Touch occurs when the probe
detects inner No.7 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-87
Touch occurs when the probe
detects inner No.8 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-88
Touch occurs when the probe
detects inner No.9 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-89
Touch occurs when the probe
detects inner No.10 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-90
Touch occurs when the probe
detects inner No.11 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-91
Touch occurs when the probe
detects inner No.12 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-92
Touch occurs when the probe
detects inner No.13 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-93
Touch occurs when the probe
detects inner No.14 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-94
Touch occurs when the probe
detects inner No.15 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-95
Touch occurs when the probe
detects inner No.16 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-96
Touch occurs when the probe
detects inner No.17 position of
sample/ reagent disk
When the probe dispenses sample or reagent,the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-97
Touch occurs when the probe
detects inner No.18 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-98
Touch occurs when the probe
detects inner No.19 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-99
Touch occurs when the probe
detects inner No.20 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
112
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-100
Touch occurs when the probe
detects inner No.21 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-101
Touch occurs when the probe
detects inner No.22 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-102
Touch occurs when the probe
detects inner No.23 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-103
Touch occurs when the probe
detects inner No.24 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-104
Touch occurs when the probe
detects inner No.25 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-105
Touch occurs when the probe
detects inner No.26 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-106
Touch occurs when the probe
detects inner No.27 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-107
Touch occurs when the probe
detects inner No.28 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-108
Touch occurs when the probe
detects inner No.29 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-109
Touch occurs when the probe
detects inner No.30 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-110
Touch occurs when the probe
detects inner No.31 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-111
Touch occurs when the probe
detects inner No.32 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-112
Touch occurs when the probe
detects inner No.33 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-113
Touch occurs when the probe
detects inner No.34 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
113
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-32-114
Touch occurs when the probe
detects inner No.35 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-115
Touch occurs when the probe
detects inner No.36 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-116
Touch occurs when the probe
detects inner No.37 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-117
Touch occurs when the probe
detects inner No.38 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1)Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-118
Touch occurs when the probe
detects inner No.39 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-119
Touch occurs when the probe
detects inner No.40 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-120
Touch occurs when the probe
detects inner No.1 position of
sample/ reagent disk
When the probe dispenses sample or reagent, the alarm is
triggered when the probe descends and has collision and then
causes touch optocoupler signal.
(1) Sample or reagent is used up;
(2) Signal detection failure or poor contact;
(3) Touch signal is disturbed.
3-32-200
Alarm caused by failure of lifting
and zeroing optocoupler at zeroing
position by default when the probe
rises to zeroing position
When the probe mechanism lifting and zeroing optocoupler has
a fault, the control board misjudges the probe is at the highest
point. The alarm is triggered when the probe descends and
detects the touch signal.
(1) Check if the probe lifting and zeroing optocoupler and its
connection are normal;
3-33-1
The probe does not detect sample
at No.1 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-2
The probe does not detect sample
at No.2 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-3
The probe does not detect sample
at No.3 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-4
The probe does not detect sample
at No.4 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
114
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-5
The probe does not detect sample
at No.5 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-6
The probe does not detect sample
at No.6 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-7
The probe does not detect sample
at No.7 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-8
The probe does not detect sample
at No.8 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-9
The probe does not detect sample
at No.9 position of sample/ reagent
disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-10
The probe does not detect sample
at No.10 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-11
The probe does not detect sample
at No.11 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-12
The probe does not detect sample
at No.12 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-13
The probe does not detect sample
at No.13 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-14
The probe does not detect sample
at No.14 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
115
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-15
The probe does not detect sample
at No.15 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-16
The probe does not detect sample
at No.16 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-17
The probe does not detect sample
at No.17 positionof sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-18
The probe does not detect sample
at No.18 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-19
The probe does not detect sample
at No.19 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-20
The probe does not detect sample
at No.20 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-21
The probe does not detect sample
at No.21 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-22
The probe does not detect sample
at No.22 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-23
The probe does not detect sample
at No.23 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-24
The probe does not detect sample
at No.24 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
116
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-25
The probe does not detect sample
at No.25 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-26
The probe does not detect sample
at No.26 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-27
The probe does not detect sample
at No.27 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-28
The probe does not detect sample
at No.28 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-29
The probe does not detect sample
at No.29 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-30
The probe does not detect sample
at No.30 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-31
The probe does not detect sample
at No.31 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-32
The probe does not detect sample
at No.32 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-33
The probe does not detect sample
at No.33 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-34
The probe does not detect sample
at No.34 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
117
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-35
The probe does not detect sample
at No.35 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-36
The probe does not detect sample
at No.36 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-37
The probe does not detect sample
at No.37 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specifiedtime is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-38
The probe does not detect sample
at No.38 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-39
The probe does not detect sample
at No.39 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-40
The probe does not detect sample
at No.40 position of sample/
reagent disk after descending to the
maximum distance
When the process time is limited, the maximum descending
steps of the probe to this position in a specified time is 2100. The
alarm is triggered when the probe does not detect the sample
after descending for 2100 steps.
(1) Sample is used up;
3-33-41
The probe does not detect sample
or reagent at outer No.1 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-42
The probe does not detect sample
or reagent at outer No.2 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-43
The probe does not detect sample
or reagent at outer No.3 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
118
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-44
The probe does not detect sample
or reagent at outer No.4 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-45
The probe does not detect sample
or reagent at outer No.5 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-46
The probe does not detect sample
or reagent at outer No.6 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-47
The probe does not detect sample
or reagent at outer No.7 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-48
The probe does not detect sample
or reagent at outer No.8 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-49
The probe does not detect sample
or reagent at outer No.9 position of
sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-50
The probe does not detect sample
or reagent at outer No.10 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-51
The probe does not detect sample
or reagent at outer No.11 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
119
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-52
The probe does not detect sample
or reagent at outer No.12 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-53
The probe does not detect sample
or reagent at outer No.13 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-54
The probe does not detect sample
or reagent at outer No.14 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-55
The probe does not detect sample
or reagent at outer No.15 position
of sample/reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-56
The probe does not detect sample
or reagent at outer No.16 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-57
The probe does not detect sample
or reagent at outer No.17 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-58
The probe does not detect sample
or reagent at outer No.18 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-59
The probe does not detect sample
or reagent at outer No.19 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
120
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-60
The probe does not detect sample
or reagent at outer No.20 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-61
The probe does not detect sample
or reagent at outer No.21 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-62
The probe does not detect sample
or reagent at outer No.22 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-63
The probe does not detect sample
or reagent at outer No.23 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-64
The probe does not detect sample
or reagent at outer No.24 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-65
The probe does not detect sample
or reagent at outer No.25 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-66
The probe does not detect sample
or reagent at outer No.26 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-67
The probe does not detect sample
or reagent at outer No.27 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
121
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-68
The probe does not detect sample
or reagent at outer No.28 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-69
The probe does not detect sample
or reagent at outer No.29 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-70
The probe does not detect sample
or reagent at outer No.30 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-71
The probe does not detect sample
or reagent at outer No.31 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-72
The probe does not detect sample
or reagent at outer No.32 positionof sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-73
The probe does not detect sample
or reagent at outer No.33 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-74
The probe does not detect sample
or reagent at outer No.34 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-75
The probe does not detect sample
or reagent at outer No.35 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
122
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-76
The probe does not detect sample
or reagent at outer No.36 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-77
The probe does not detect sample
or reagent at outer No.37 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-78
The probe does not detect sample
or reagent at outer No.38 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-79
The probe does not detect sample
or reagent at outer No.39 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-80
The probe does not detect sample
or reagent at outer No.40 position
of sample/ reagent disk after
descending to the maximum
distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the sample or reagent after it descends for the
maximum steps.
(1) Sample or reagent is used up;
3-33-81
The probe does not detect reagent
at inner No.2 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-82
The probe does not detect reagent
at inner No.3 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-83
The probe does not detect reagent
at inner No.4 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
123
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-84
The probe does not detect reagent
at inner No.5 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-85
The probe does not detect reagent
at inner No.6 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-86
The probe does not detect reagent
at inner No.7 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-87
The probe does not detect reagent
at inner No.8 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-88
The probe does not detect reagent
at inner No.9 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-89
The probe does not detect reagent
at inner No.10 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggeredif the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-90
The probe does not detect reagent
at inner No.11 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-91
The probe does not detect reagent
at inner No.12 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
124
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-92
The probe does not detect reagent
at inner No.13 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-93
The probe does not detect reagent
at inner No.14 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-94
The probe does not detect reagent
at inner No.15 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-95
The probe does not detect reagent
at inner No.16 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-96
The probe does not detect reagent
at inner No.17 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-97
The probe does not detect reagent
at inner No.18 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-98
The probe does not detect reagent
at inner No.19 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-99
The probe does not detect reagent
at inner No.20 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
125
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-100
The probe does not detect reagent
at inner No.21 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-101
The probe does not detect reagent
at inner No.22 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-102
The probe does not detect reagent
at inner No.23 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-103
The probe does not detect reagent
at inner No.24 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-104
The probe does not detect reagent
at inner No.25 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-105
The probe does not detect reagent
at inner No.26 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-106
The probe does not detect reagent
at inner No.27 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-107
The probe does not detect reagent
at inner No.28 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximumsteps.
(1) Reagent is used up;
126
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-108
The probe does not detect reagent
at inner No.29 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-109
The probe does not detect reagent
at inner No.30 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-110
The probe does not detect reagent
at inner No.31 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-111
The probe does not detect reagent
at inner No.32 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-112
The probe does not detect reagent
at inner No.33 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-113
The probe does not detect reagent
at inner No.34 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-114
The probe does not detect reagent
at inner No.35 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-115
The probe does not detect reagent
at inner No.36 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
127
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-33-116
The probe does not detect reagent
at inner No.37 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-117
The probe does not detect reagent
at inner No.38 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-118
The probe does not detect reagent
at inner No.39 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-119
The probe does not detect reagent
at inner No.40 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-33-120
The probe does not detect reagent
at inner No.1 position of sample/
reagent disk after descending to the
maximum distance
After the probe vertical inspection and empty bottle inspection,
the maximum steps for descending of the probe mechanism to
this position are determined. The alarm is triggered if the probe
does not detect the reagent after it descends for the maximum
steps.
(1) Reagent is used up;
3-31-1
In test process, water volume in
rinsing pump reaches the upper
limit.
In the test process, the alarm is triggered if the maximum
volume of the rinsing pump is changed to 5mL from 9.85mL.
(1) For alarms caused by other faults, check if there are other alarm
codes.
3-31-2 In test process, water volume in rinsing pump is insufficient.
The alarm is triggered if the water volume in the rinsing pump is
less than the water volume to be used. The program is modified
to change the water dispensing volume to inner wall of the probe
to 3mL from 2.2mL.
(1) For alarms caused by other faults, check if there are other alarm
codes.
3-31-3
In the test process, the residual
volume in rinsing pump during
zeroing is greater than the
allowable maximum residual
volume during zeroing.
In the test process, the alarm is triggered if the residual volume
in rinsing pump is greater than 250uL during zeroing. The
program is modified to zero the residual volume 300uL during
zeroing.
(1) For alarms caused by other faults, check if there are other alarm
codes.
3-81-1
Receiving R1 reagent volume
dispensing information error.
Dispensing action converts to
probe rinsing action.
Modify the main control board program, the alarm is triggered if
the modified R1 volume is beyond 10-300uL. (1) Feed it back to the engineer
128
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-81-2
Receiving R2 reagent volume
dispensing information error.
Dispensing action converts to
probe rinsing action.
Modify the main control board program, the alarm is triggered if
the modified R2 volume is beyond 10-150uL. (1) Feed it back to the engineer
3-81-3
Receiving colorimetric sample
volume dispensing information
error. Dispensing action converts
to probe rinsing action.
Modify the main control board program, the alarm is triggered if
the modified S volume is beyond 2-35uL. (1) Feed it back to the engineer
3-81-4
Receiving ISE sample volume
dispensing information error.
Dispensing action converts to
probe rinsing action.
Modify the main control boardprogram, the alarm is triggered if
the modified ISE sample volume is beyond 30-100uL. (1) Feed it back to the engineer
3-81-5
Invalid receiving of dispensing
position information. Dispensing
action converts to probe rinsing
action.
Modify the main control board program, the alarm is triggered if
the modified aspirating position is beyond 1-120. (1) Feed it back to the engineer
3-81-6
Asynchronous validity of received
dispensing position information
and dispensing volume
information. Dispensing action
converts to probe rinsing action.
Modify the main control board program, the alarm is triggered if
the modified aspirating position is 0 and the volume information
is 100uL.
(1) Feed it back to the engineer
3-101-6
Driver of probe mechanism
swinging motor has configuration
failure. Reading driver information
failed.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the probe control board.
3-101-7
Driver of probe mechanism lifting
motor has configuration failure.
Reading driver information failed.
After the motor driver chip is welded, the alarm will be triggered
if control chip AC256 and motor driver chip 30521 have
communication fault.
(1) Replace the probe control board.
3-102-6 Probe mechanism swinging motor has short circuit. Probe mechanism swinging motor has short circuit. (1) Replace the probe control board.
3-102-7 Probe mechanism lifting motor has short circuit. Probe mechanism lifting motor has short circuit. (1) Replace the probe control board.
3-103-6 Probe mechanism swinging motor has open circuit. Probe mechanism swinging motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
3-103-7 Probe mechanism lifting motor has open circuit. Probe mechanism lifting motor has open circuit.
(1) Check the circuit.
(2) Replace the probe control board.
3-104-6
Swinging and zeroing of probe fail
to reach the zero point.
Optocoupler is in abnormal status
after motor stops operating.
After the probe mechanism finishes the swinging and zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the probe swinging optocoupler signal is disturbed.
129
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-104-7
Lifting and zeroing of probe fail to
reach the zero point. Optocoupler
is in abnormal status after motor
stops operating.
After the probe mechanism finishes the lifting and zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler is different from the preset status.
(1) Check if the probe lifting optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the probe lifting optocoupler signal is disturbed.
3-104-8
Zeroing of syringe pump fails to
reach the zero point. Optocoupler
is in abnormal status after motor
stops operating.
After the dispensing pump finishes the zeroing action, the alarm
is triggered when the level status of zeroing optocoupler is
different from the preset status.
(1) Check if the dispensing pump optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the dispensing pump optocoupler signal is disturbed.
3-104-9
Zeroing of rinsing pump fails to
reach the zero point. Optocoupler
is in abnormal status after motor
stops operating.
After the rinsing pump finishes the zeroing action, the alarm is
triggered when the level status of zeroing optocoupler is
different from the preset status.
(1) Check if the rinsing pump optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the rinsing pump optocoupler signal is disturbed.
3-104-10
Zeroing of reagent disk fails to
reach the zero point. Optocoupler
is in abnormal status after motor
stops operating.
After the reagent disk finishes the zeroing action, the alarm is
triggered when the level status of zeroing optocoupler is
different from the preset status.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the reagent disk zeroing optocoupler signal is disturbed.
3-105-6
Swinging and positioning of probe
fail to reach the preset position.
Optocoupler is in abnormal status
after motor stops operating.
After the probe mechanism finishes the swinging and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the probe swinging optocoupler signal is disturbed.
3-105-10
Positioning of reagent disk fails to
reach the preset position.
Optocoupler is in abnormal status
after motor stops operating.
After the reagent disk mechanism finishes the swinging and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the reagent disk zeroing optocoupler signal is disturbed.
3-106-6
Abnormal initial position of
swinging and positioning of probe.
Optocoupler is in abnormal status
before motor starts operating.
Before the probe mechanism is started to have swinging and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the probe swinging optocoupler signal is disturbed.
3-106-10
Abnormal initial position of
positioning of reagent disk.
Optocoupler is in abnormal status
before motor starts operating.
Before the reagent disk is started to have rotating and
positioning action, the alarm is triggered when the level status of
positioning optocoupler is different from the preset status.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the circuit connection is normal;
(3) Check if the reagent disk zeroing optocoupler signal is disturbed.
3-107-6
Swinging and zeroing failure of
probe. Motor operating timeout or
out of step.
When the probe mechanism is started up to have swinging and
zeroing action, the alarm is triggered when the level status of
probe swinging and zeroing optocoupler is different from the
preset status in a specified time.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
3-107-7
Lifting and zeroing failure of
probe. Motor operating timeout or
out of step.
When the probe mechanism is started up to have lifting and
zeroing action, the alarm is triggered when the level status of
probe lifting and zeroing optocoupler is different from the preset
status in a specified time.
(1) Check if the probe lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe lifting motor is normal;
(4) Check if the cable connection of motor is normal;
130
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-107-8
Zeroing failure of syringe pump.
Motor operating timeout or out of
step.
When the dispensing pump mechanism is started up to have
zeroing action, the alarm is triggered when the level status of
zeroing optocoupler of the dispensing pump is different from the
preset status in a specified time.
(1) Check if the dispensingpump optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the dispensing pump motor is normal;
(4) Check if the cable connection of motor is normal;
3-107-9
Zeroing failure of rinsing pump.
Motor operating timeout or out of
step.
When the rinsing pump mechanism is started up to have zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler of the rinsing pump is different from the preset
status in a specified time.
(1) Check if the rinsing pump optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the rinsing pump motor is normal;
(4) Check if the cable connection of motor is normal;
3-107-10
Zeroing failure of reagent disk.
Motor operating timeout or out of
step.
When the reagent disk mechanism is started up to have zeroing
action, the alarm is triggered when the level status of zeroing
optocoupler of the reagent disk is different from the preset status
in a specified time.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
3-108-6 Swinging of probe fails to leave the zero point.
The fault of probe swinging and zeroing optocoupler leads to
that the control board misjudges it is at the zero position. The
alarm is triggered when the zeroing optocoupler level status
does not change after a certain steps of swinging.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
3-108-7 Descending of probe fails to leave the zero point.
The fault of probe swinging, lifting and zeroing optocoupler
leads to that the control board misjudges it is at the zero
position. The alarm is triggered when the zeroing optocoupler
level status does not change after a certain steps of descending.
(1) Check if the probe lifting optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe lifting motor is normal;
(4) Check if the cable connection of motor is normal;
3-108-8 Syringe pump fails to leave the zero point.
The fault of dispensing pump zeroing optocoupler leads to that
the control board misjudges it is at the zero position. The alarm
is triggered when the zeroing optocoupler level status does not
change after aspiration of a certain volume.
(1) Check if the dispensing pump optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the dispensing pump motor is normal;
(4) Check if the cable connection of motor is normal;
3-108-9 Rinsing pump fails to leave the zero point.
The fault of rinsing pump zeroing optocoupler leads to that the
control board misjudges it is at the zero position. The alarm is
triggered when the zeroing optocoupler level status does not
change after aspiration of a certain volume.
(1) Check if the rinsing pump optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the rinsing pump motor is normal;
(4) Check if the cable connection of motor is normal;
3-108-10 Reagent disk fails to leave the zero point.
The fault of reagent disk zeroing optocoupler leads to that the
control board misjudges it is at the zero position. The alarm is
triggered when the zeroing optocoupler level status does not
change after a certain steps of rotating.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
3-109-6
Swinging and positioning failure
of probe. Motor operating timeout
or out of step.
When the probe mechanism has swinging and positioning
action, the alarm is triggered when the level signal change times
of positioning optocoupler is not equal to the preset times in a
specified time.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
3-109-10
Positioning failure of reagent disk.
Motor operating timeout or out of
step.
When the reagent disk mechanism has rotating and positioning
action, the alarm is triggered when the level signal change times
of positioning optocoupler is not equal to the preset times in a
specified time.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
3-110-6 Probe swinging for fixed steps timeout.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
131
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-110-7 Probe lifting for fixed steps timeout.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
3-110-8 Syringe pump operating for fixed steps timeout.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
3-110-9 Rinsing pump operating for fixed steps timeout.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
3-110-10 Reagent disk operating for fixed steps timeout.
The alarm is triggered in case of insufficient setting time of
known actions. (1) Feed it back to the engineer
3-111-6
Probe swinging and coded disc
scanning timeout or out of steps or
exceeding the number of scanning
When the probe mechanism swings to scan the coded disc, the
alarm will be triggered if it fails to swing and the scanned
number of slots (optocoupler level change times) does not reach
the preset number in specified time.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
3-111-10
Reagent disk coded disc scanning
timeout or out of steps or
exceeding the number of scanning
When the reagent disk mechanism swings to scan the coded
disc, the alarm will be triggered if the positioning optocoupler is
pulled out and the scanned number of slots (optocoupler level
change times) does not reach the preset number in specified
time.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
3-112-10 Bar code scanning and reagent disk operating timeout or out of steps.
When the reagent disk mechanism has rotating and coordinates
to have bar code scanning, the alarm is triggered when the level
signal change times of positioning optocoupler is not equal to
the preset times in a specified time.
(1) Check if the reagent disk zeroing optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
3-113-6 Abnormal swinging and positioning verification of probe.
The alarm is triggered when the steps for hindering the probe
swinging mechanism to a specific position increase and the
difference between it and the scanned steps of the slots is
beyond the limited range.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connectionof optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
(6) Check if the mechanism arm and motor are loose.
3-114-6 Abnormal swinging and coded disc verification of probe.
The alarm is triggered if the deviation between the scanned
coded disc information due to optocoupler fault or coded disc
abnormality and the theoretical coded disc information is
beyond the allowable range.
(1) Check if the probe swinging optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the probe swinging motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
(6) Check if the mechanism arm and motor are loose.
3-114-10 Abnormal coded disc verification of reagent disk.
The alarm is triggered if the deviation between the scanned
coded disc information due to optocoupler fault or coded disc
abnormality and the theoretical coded disc information is
beyond the allowable range.
(1) Check if the reagent disk positioning optocoupler is normal;
(2) Check if the cable connection of optocoupler is normal;
(3) Check if the reagent disk motor is normal;
(4) Check if the cable connection of motor is normal;
(5) Check if the coded disc is normal.
(6) Check if the mechanism motor is loose.
132
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-115-6
Abnormal swinging and
positioning information
calculation of probe.
The alarm is triggered if the probe swinging and positioning
information are wrongly set. (1) Feed it back to the engineer
3-116-6 Probe does not swing at the highest point.
Before the probe mechanism is started up to have swinging
action, the control board will judge if it is at the highest point
according to the level status of the lifting optocoupler of the
mechanism. If the probe is not at the highest position, the alarm
is triggered.
(1) Check the harness connection;
3-117-8 Aspirating and dispensing volume of syringe pump out of limit.
The alarm is triggered if the aspirating and dispensing volume
exceeds the maximum aspirating and dispensing volume. (1) Feed it back to the engineer
3-117-9 Aspirating and dispensing volume of rinsing pump out of limit.
The alarm is triggered if the aspirating and dispensing volume
exceeds the maximum aspirating and dispensing volume. (1) Feed it back to the engineer
3-118-7 Abnormal lifting and zeroing verification of probe.
Taking the highest point of the probe as the zero point, the
coordinates will decrease automatically if it moves downwards
and increase automatically if it moves upwards. When the
mechanism moves from the zero point and then returns to the
zero points, the coordinates are checked and if they are found
beyond the allowable range, the alarm will be triggered.
(1) Check other alarm information;
3-118-8
Abnormal zeroing verification of
syringe pump. Motor operating
steps from zero point to one point
and the motor operating steps from
the position to zero point.
Taking the zero point of the pump as the zero point, the
coordinates will decrease automatically for aspirating and
increase automatically for dispensing. When the mechanism
moves from the zero point and then returns to the zero points,
the coordinates are checked and if they are found beyond the
allowable range, the alarm will be triggered.
(1) Check other alarm information;
3-118-9 Abnormal zeroing verification of syringe pump.
Taking the zero point of the pump as the zero point, the
coordinates will decrease automatically for aspirating and
increase automatically for dispensing. When the mechanism
moves from the zero point and then returns to the zero points,
the coordinates are checked and if they are found beyond the
allowable range, the alarm will be triggered.
(1) Check other alarm information;
3-120-10 Positioning optocoupler failure of reagent disk during resetting.
In the resetting process, the level status of reagent disk
positioning optocoupler will change. If it does not change, the
alarm is triggered.
(1) Check if the circuit connection of reagent disk positioning
optocoupler is normal;
(2) Check if the positioning optocoupler is normal;
3-121-10
Positioning optocoupler is not at
the present position after zeroing of
reagent disk.
After the reagent disk finishes the zeroing action, the alarm is
triggered when the level status of positioning optocoupler is
different from the preset status.
(1) Check if the circuit connection of reagent disk positioning
optocoupler is normal;
(2) Check if the positioning optocoupler is normal;
3-131-1 Failure of water supply valve V1
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
3-131-2 Failure of inner wall valve V2
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
133
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-131-8 Failure of outer wall valve V8
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Replace the circuit board.
3-132-1 Open circuit of water supply valve V1
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
3-132-2 Open circuit of inner wall valve V2
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
3-132-8 Open circuit of outer wall valve V8
The solenoid valve driver chip has the function. When the driver
chip has fault
 and it is fed back to the control board, the alarm is triggered.
(1) Check if the solenoid valve is normal;
(2) Check if the circuit connection is normal;
(3) Check if the driver chip has poor welding.
3-133-11 Mutually exclusive solenoid valves are opened simultaneously.
For the rinsing mechanism water valve, rinsing bath valve of
mixing mechanism, probe inner wall valve, probe outer wall
valve and water supply valve of the machine, only one time of
them can be opened at one time. At one time, the alarm will be
triggered if the program is changed to make two types of the
solenoid valve are opened.
(1) Feed it back to the engineer
3-134-1 Driver configuration failure of water supply valve V1
Abnormal communication in SPI between AC256 and
NCV7708 (1) Replace the circuit board.
3-134-2 Driver configuration failure of inner wall valve V2
Abnormal communication in SPI between AC256 and
NCV7708 (1) Replace the circuit board.
3-134-8 Driver configuration failure of outer wall valve V8
Abnormal communication in SPI between AC256 and
NCV7708 (1) Replace the circuit board.
3-141-1
Probe has collision in
proportioning cup when dispensing
ISE sample
The alarm is triggered when the probe mechanism descends at
the ISE matching cuvette position and detects a touch signal.
(1) Check ISE module alarm information;
(2) Check if the probe mechanism is normal;
3-141-2
Probe does not detect the liquid
surface in proportioning cup when
dispensing ISE sample
The ISE sample shall be dispensed below the liquid level if
dispensing of it is required. The alarm is triggered if theprobe
does not touch anything or detect the liquid surface after
descending to the maximum distance.
(1) Check the alarm of ISE unit.
3-141-3
Probe does not detect the liquid
surface when aspirating sample in
cuvette
In the liquid detection process, the sample in cuvette should be
aspirated in dilution process or saccharification process. The
alarm is triggered if the probe does not detect the liquid surface
after descending for fixed steps (calculated based on the data of
main control board).
(1) Check if the liquid level detection is normal;
(2) Check other alarms.
3-141-4 Touch occurs when the probe aspirates diluted sample in cuvette
During the dilution or saccharification process of probe
mechanism, the alarm is triggered if the probe detects touch
signal when descending to aspirate sample.
(1) Check if the liquid level detection is normal;
(2) Check if the touch signal is normal.
3-141-6
Probe tip detects the liquid surface
when dispensing sample or reagent
in cuvette
When the probe dispenses sample or reagent, it will enter a
cuvette and not touch the liquid surface. The alarm is triggered if
it detects the liquid surface detection signal.
(1) Check if the liquid level detection is normal;
134
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
3-141-7
Detection distance out of limit in
vertical inspection and detection of
5mL liquid surface
The alarm is triggered if the deviation between the descending
distance for 5mL detection and the theoretical distance exceeds
the allowable range.
(1) Conduct standard operation;
(2) Check if the liquid level detection is normal;
3-141-8
Detection distance out of limit in
vertical inspection and detection of
50mL liquid surface
The alarm is triggered if the deviation between the descending
distance for 50mL detection and the theoretical distance exceeds
the allowable range.
(1) Check if the liquid level detection is normal;
3-141-11 Abnormal sensitivity of liquid surface detection board.
The probe control board and liquid surface detection board have
serial port communication. The alarm is triggered if the
detection sensitivity of the device is different from the read
sensitivity of liquid surface detection board.
(1) Replace the liquid level detection board.
3-141-12
Detection distance out of limit in
vertical inspection and detection of
70mL empty bottle
The alarm is triggered if the deviation between the descending
distance for 70mL detection and the theoretical distance exceeds
the allowable range.
(1) Check if the empty bottle has liquid inside and if the position is
normal.
3-141-13
The probe will have collision when
descending to the cuvette to have
dispensing.
When the probe dispenses sample or reagent, it will descend
from the mouth of cuvette and the alarm is triggered if it detects
the touch signal.
(1) Check the probe tip position relative to the position of cuvette;
(2) Check if the probe mechanism is normal;
3-141-14
Automatic adjustment fault in
vertical inspection and empty
bottle inspection.
The alarm is triggered if touch occurs before it descends for less
than 2500 steps and reaches the theoretical steps in empty bottle
inspection.
(1) Check if the probe mechanism is normal;
3-161-1 Bar code setting failure The alarm is triggered in case of abnormal serial port communication between the probe board and bar code reader.
(1) Check if the circuit connection is normal;
(2) Replace the bar code assembly;
(3) Replace the probe control board.
3-161-2 Invalid bar code The alarm is triggered in case of invalid bar code.
(1) Check if there is bar code or if the bar code is damaged;
(2) Check if the circuit connection is normal;
(3) Replace the bar code assembly;
(4) Replace the probe control board.
3-22-2 Data storage sector erase and failure Data storage sector damaged (1) Replace the probe control board.
3-22-3 Data storage sector data read-in invalid Data storage sector damaged
(1) Read in compensation data to control board. If it continues to alarm,
replace the probe control board.

8.1.4 ISE unit module
Fault code Fault description Fault cause analysis Solution
17-1-1 Zeroing of dilution pump failed Dilution pump fails to reach the zero point when executing zeroing action
(1) Check if the optocoupler is connected;
(2) Read the optocoupler status and check if it changes;
(3) Replace the optocoupler;
(4) Replace the circuit board.
135
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
17-1-2 Dilution pump fails to leave the zero point Dilution pump fails to leave the zero point when having action
(1) Check if the optocoupler is connected;
(2) Read the optocoupler status and check if it changes;
(3) Replace the optocoupler;
(4) Replace the circuit board.
17-1-3 Dilution pump is not at the zero point during ISE test Dilution pump is not at the zero point during ISE test
(1) Check if the optocoupler is connected;
(2) Read the optocoupler status and check if it changes;
(3) Replace the optocoupler;
(4) Replace the circuit board.
17-1-4 Abnormal pressure of vacuum pump Abnormal vacuum pump or vacuum tubing
(1) Check if vacuum pump and wiring are normal;
(2) Check the vacuum tubing;
(3) Replace the circuit board.
17-1-5 Abnormal pressure relief of vacuum pump
Abnormal pressure relief is caused by blockage of vacuum
pump tubing or solenoid valve
(1) Check if ISE vacuum tubing and solenoid valve in tubing are
blocked
17-1-6 Waiting for sample timeout Sample mechanism fails to finish sample dispensing in regulated time period during ISE test
(1) Check if there are relevant alarms of sample probe;
(2) Monitor the main control board information and feed it back to
engineer

8.1.5 AC unit module
Fault code Fault description Fault cause analysis Solution
5-1-1 Abnormal ambient temperature sensor Short circuit of ambient temperature sensor
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-1-2 Abnormal ambient temperature sensor Open circuit of ambient temperature sensor
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-1-3 Abnormal ambient temperature Ambient temperature is loo high
(1) Check if the ambient temperature of the machine is 15℃-32℃;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-1-4 Abnormal ambient temperature The ambient temperature is too low
(1) Check if the ambient temperature of the machine is 15℃-32℃;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-2-1 Abnormal optical temperature sensor Short circuit of optical temperature sensor
(1) Check if optical temperature sensor connection cable is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-2-2 Abnormal optical temperature sensor Open circuit of optical temperature sensor
(1) Check if optical temperature sensor connection cable is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-2-3 Optical system light source use timeout Optical system light source is used for over 2000 hours (1) Replace the light source
136
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
5-2-4 Abnormal optical system temperature Too high optical system temperature
(1) Check if light source radiation fan connection cable is normal;
(2) Check if optical fan is normal;
(3) Replace the AC control board;
5-4-2 Abnormal incubation bath temperature sensor Incubation bath temperature sensor is short or open circuited.
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-4-3Incubation bath heating timeout After the incubation bath is continuously heated for 180s, the temperature rise is less than 1℃.
(1) Check if incubation bath heating strip and its connection cable are
normal;
(2) Check if the temperature sensor is normal.
(3) Replace the AC control board;
5-4-4 Abnormal incubation bath fan Circulating fan of incubation bath stops working (1) Check if incubation bath circulating fan and its connection cable are normal;
5-4-5 Abnormal temperature of incubation bath Temperature of incubation bath beyond the lower limit
(1) Check if incubation bath heating strip and its connection cable are
normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-4-6 Abnormal temperature of incubation bath Incubation bath temperature beyond 40℃
(1) Confirm if the room temperature is within the range of 15-32°C.
(2) Confirm if the cooling system radiation fan of the instrument
rotates normally;
(3) Check if the temperature sensor is normal.
5-4-7 Abnormal temperature of incubation bath Incubation bath temperature beyond the range of (37±0.5)℃
(1) Confirm if the room temperature is within the range of 15-32°C.
(2) Confirm if the cooling system radiation fan of the instrument
rotates normally;
(3) Check if the temperature sensor is normal.
5-10-1 Abnormal pressure sensor of diaphragm pump Open circuit of pressure sensor of diaphragm pump
(1) Check if the diaphragm pump pressure sensor and its connection
cable are normal;
(2) Replace the pressure detection circuit board
5-10-2 Abnormal pressure sensor of vacuum negative pressure pump
Communication error of pressure sensor of vacuum negative
pressure pump
(1) Check if the diaphragm pump pressure sensor and its connection
cable are normal;
(2) Replace the pressure detection circuit board
5-10-3 Read atmospheric pressure out of limit
Atmospheric pressure beyond limit read by pressure sensor of
vacuum negative pressure pump
(1) Check if the diaphragm pump pressure sensor and its connection
cable are normal;
(2) Check if the pressure detection circuit board and vacuum pressure
tank connection tubing is normal;
(3) Replace the pressure detection circuit board
5-10-4 Abnormal vacuum negative pressure
Insufficient negative pressure of vacuum negative pressure
pump in resetting for self-inspection
(1) Check if vacuum diaphragm pump and wiring are normal;
(2) Check if vacuum diaphragm tubing is normal;
(3) Replace the vacuum diaphragm pump.
137
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
5-10-5 Abnormal vacuum negative pressure
Insufficient negative pressure before use of vacuum negative
pressure pump
(1) Check if diaphragm pump and wiring are normal;
(2) Check if diaphragm tubing is normal;
(3) Replace the diaphragm pump.
5-10-6 Abnormal vacuum negative pressure resetting
Vacuum gas exhaust completion command not received from
reaction disk control board during resetting
(1) Check if the reaction disk control board is normal;
(2) Check if communication CAN bus of reaction disk control board
and AC control board is normal.
5-11-1 Abnormal reagent disk temperature sensor Short circuit of reagent disk temperature sensor
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-11-2 Abnormal reagent disk temperature sensor Open circuit of reagent disk temperature sensor
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-11-3 Reagent disk refrigeration timeout
Temperature exceeding upper refrigeration limit after
refrigeration of reagent disk for 6h
(1) Check if Peltier and wiring are normal;
(2) Check if the reagent disk fan wiring is normal;
5-11-4 Abnormal Peltier current of reagent disk
Peltier current of reagent disk out of normal range under
initiation or resetting status
(1) Check if Peltier and wiring are normal;
(2) Check if the reagent disk fan wiring is normal;
5-11-5 Too high reagent disk Peltier Reagent disk Peltier reversely connected or reverse wiring sequence
(1) Check if Peltier and wiring are normal;
(2) Replace the temperature sensor;
(3) Check if the reagent disk fan wiring is normal;
5-11-6 Abnormal Peltier current of reagent disk Peltier current of reagent disk out of normal range
(1) Check if Peltier and wiring are normal;
(2) Check if the reagent disk fan wiring is normal;
5-13-1
Abnormal temperature sensor of
constant-temperature degassing
assembly
Short circuit of temperature sensor of constant-temperature
degassing assembly
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-13-2
Abnormal temperature sensor of
constant-temperature degassing
assembly
Open circuit of temperature sensor of constant-temperature
degassing assembly
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-13-3
Heating timeout of
constant-temperature degassing
assembly
After the constant-temperature degassing assembly is
continuously heated for 5min, the temperature rise is less than
1℃ in heating process.
(1) Check if constant-temperature degassing heating strip and its
connection cable are normal;
(2) Check if AC drive board is normal.
5-13-4
Too high temperature of
constant-temperature degassing
assembly
Temperature over 50oC of constant-temperature degassing
assembly
(1) Check if sensor connection is normal;
(2) Replace the temperature sensor;
(3) Replace the AC control board;
5-15-1 High-concentration waste liquid tank full of waste liquid
Too much waste liquid in high-concentration waste liquid tank
during resetting
(1) Empty the high-concentration waste liquid tank;
(2) Check if the waste liquid sensor interface and wiring are normal;
(3) Check if high-concentration waste liquid float ball falls off.
5-15-2 High-concentration waste liquid tank full of waste liquid
Too much waste liquid in high-concentration waste liquid tank
under standby or test status
(1) Empty the high-concentration waste liquid tank;
(2) Check if the waste liquid sensor interface and wiring are normal;
(3) Check if high-concentration waste liquid float ball falls off.
138
Service Manual of Auto-Chemistry Analyzer

Fault code Fault description Fault cause analysis Solution
5-15-3 Low-concentration waste liquid tank full of waste liquid
Too much waste liquid in low-concentration waste liquid tank
under standby or test status
(1) Empty the low-concentration waste liquid tank;
(2) Check if the waste liquid float interface and wiring are normal;
(3) Check if low-concentration waste liquid float ball falls off.
5-15-4 Low-concentration waste liquid tank full of waste liquid
Too much waste liquid in low-concentration waste liquid tank
during resetting
(1) Empty the low-concentration waste liquid tank;
(2) Check if the waste liquid float interface and wiring are normal;
(3) Check if low-concentration waste liquid float ball falls off.
5-19-1 Insufficient pure water Insufficient pure water in pure water tank during resetting
(1) Add pure water to tank;
(2) Check if the pure water float interface and wiring are normal;
(3) Check if pure water float ball falls off.
5-19-2 Pure water in serious lack Insufficient pure water in pure water tank, pure water not added in 20min
(1) Add pure water to tank;
(2) Check if the pure water float interface and wiring are normal;
(3) Check if pure water float ball falls off.
5-19-3 Insufficient pure water Insufficient pure water in pure water tank under standby or test status
(1) Add pure water to tank;
(2) Check if the pure water float interface and wiring are normal;
(3) Check if pure water float ball falls off.
5-23-6 Insufficient alkaline detergentInsufficient alkaline detergent
(1) Add alkaline detergent to alkaline detergent bottle
(2) Check if detergent float wiring is normal;
(3) Check if detergent float ball falls off.

139


Chapter 9 List of Spare Parts

9.1 List of Easily-worn Parts and Consumables
9.1.1 List of Easily-worn Parts
No. Name SAP Code Remarks
1 Probe Assembly 1024850
2 Mixing Bar 1008016
3 Wiping Head 1028046
4 Wire J1401\ Rinsing Syringe Pump 2011692
5
Wire J1402\ Sample Dispensing
Syringe Pump
2011693
6 Wire JM05\ ISE Syringe Pump 2011715

9.1.2 List of Consumables
No. Name SAP Code Replacement Cycle
1 Halogen Lamp Assembly 2001897 Half a year
2 Cuvette 1027510 Half a year
3 Peristaltic Pump Tube Assembly 2001439 3 months
4
GR74- Tube 140 (Tube 82) \ Tube
for Pinch Valve
2012987 3 months
5 Tube GR75-200 (Tube 87) 2012992 3 months
6 Na Electrode 1013580 Half a year
7 K Electrode Head 1013582 Half a year
8 CI Electrode 1013581 Half a year
9 ISE Filter 200 1008102 Half a year
● The Analyzer is regarded being used for 5 hours per day during calculation.

9.2 List of Maintenance Case
9.2.1 List of Small Maintenance Case (SAP Code:——)
(Recommended Replaced Period:1year)
No. Name SAP Code Qty.
1 SCV06265\ Check Valve 1009867 1
2 H322-3-2\ Lock Nut 1006955 4
3 H323-3-1-2\ Lock Bolt 1006956 4
4 CS400-02-03-05 GRB1\ Insulated Glass 1000064 1
5 CS-T180-03-06\ Probe Housing 1027949 1
140


6 CS-T180-08-01(PPO)\ Rinsing Bath 1025933 1
7 CS-T180-07-00\ Mixing and Rinsing Bath Unit 2009893 1
8 CS-T180-06-08\ Shell of Support Arm for Mixing 1025202 1
9 CS-400(ISE)\ ISE Filter 200 1008102 4
10 5*20 6.3A 250V\ Fuse 1013297 4
11 CS400-08-01(CS-400-06-20 Japan)\ Mixing Bar 1008016 2
12 CS-T180-FBO4-700\ Flanging Tube\ Tube 46 1036834 1
13 CS-T180-FD11-120\ Flanging Tube\ Tube 3 1036829 1
14 CS-T180-FD11-350\ Flanging Tube\ Tube 5 1036830 1
15 CS-T180-FD11-1020\ Flanging Tube\ Tube 6 1038196 1
16 CS-T180-FD06-250\ Flanging Tube\ Tube 7 1036832 1

9.2.2 List of Big Maintenance Case (SAP Code:——)
(Recommended Replaced Period:2years)
No. Name SAP Code Qty.
1 SCV06265\ Check Valve 1009867 1
2 H322-3-2\ Lock Nut 1006955 4
3 H323-3-1-2\ Lock Bolt 1006956 4
4 CS400-02-03-05 GRB1\ Insulated Glass 1000064 1
5 CS-T180-03-06\ Probe Housing 1027949 1
6 CS-T180-08-01(PPO)\ Rinsing Bath 1025933 1
7 CS-T180-07-00\ Mixing and Rinsing Bath Unit 2009893 1
8 CS-T180-06-08\ Shell of Support Arm for Mixing 1025202 1
9 CS-400(ISE)\ ISE Filter 200 1008102 4
10 5*20 6.3A 250V\ Fuse 1013297 4
11 CS400-08-01(CS-400-06-20 Japan)\ Mixing Bar 1008016 2
12 CS-T180-FBO4-700\ Flanging Tube\ Tube 46 1036834 1
13 CS-T180-FD11-120\ Flanging Tube\ Tube 3 1036829 1
14 CS-T180-FD11-350\ Flanging Tube\ Tube 5 1036830 1
15 CS-T180-FD11-1020\ Flanging Tube\ Tube 6 1038196 1
16 CS-T180-FD06-250\ Flanging Tube\ Tube 7 1036832 1
17 JCooling01\ Peltier 2011767 1
18 JCooling02\ Peltier 2011769 1
141


9.2.3 List of ISE Maintenance Case (SAP Code:——)
(Recommended Replaced Period:1years)
No. Name SAP Code Qty.
1 SCV06265\ Check Valve 1009867 1
2 H322-3-2\ Lock Nut 1006955 4
3 H323-3-1-2\ Lock Bolt 1006956 4
4 CS400-02-03-05 GRB1\ Insulated Glass 1000064 1
5 CS-T180-03-06\ Probe Housing 1027949 1
6 CS-T180-08-01(PPO)\ Rinsing Bath 1025933 1
7 CS-T180-07-00\ Mixing and Rinsing Bath Unit 2009893 1
8 CS-T180-06-08\ Shell of Support Arm for Mixing 1025202 1
9 CS-400(ISE)\ ISE Filter 200 1008102 4
10 5*20 6.3A 250V\ Fuse 1013297 4
11 CS400-08-01(CS-400-06-20 Japan)\ Mixing Bar 1008016 2
12 CS-T180-FBO4-700\ Flanging Tube\ Tube 46 1036834 1
13 CS-T180-FD11-120\ Flanging Tube\ Tube 3 1036829 1
14 CS-T180-FD11-350\ Flanging Tube\ Tube 5 1036830 1
15 CS-T180-FD11-1020\ Flanging Tube\ Tube 6 1038196 1
16 CS-T180-FD06-250\ Flanging Tube\ Tube 7 1036832 1
17 JCooling01\ Peltier 2011767 1
18 JCooling02\ Peltier 2011769 1
19 CS6400ISE\ Peristaltic Pump Tube Assembly 2001439 8 (annual consumption)
20 GR74-140\ Tube 82\ for Pinch Valve 2012987 4 (annual consumption)
21 GR75-200\ Tube 87\ for Pinch Valve 2012992 4 (annual consumption)
22 CS-T180ISE-FBO6-40\ Tube 93\ Flanging Tube 1038195 1

9.3 List of Frequently-used Spare Parts
9.3.1 List of Assembly Spare Parts
No. Name SAP Code Remarks
1 Optical Detection Unit 2015065
2 Probe Unit 2015064
3 Rinsing Unit 2015062
4 Mixing Unit 2015063
5 Constant-temperature Degassing Assembly 2009924
142


6 Syringe Pump Unit 2015066
7 Drive Mechanism 2015419
8 Incubation Bath Assembly 2015420
9 Sample/ Reagent Disk Drive Mechanism 2015421
10 CS-T180 Refrigeration Chamber 2010237
11 Sample/ Reagent Disk Rack Assembly 2014996
12 Waste Liquid Tank Assembly 2015067
13 Group Valve Assembly 2015422
14 Detergent Tank Assembly 2015423
15 Bar Code Reader Assembly 2009905 Optional
16 Pure Water Unit 2016056
17 Waste Liquid Tank Assembly 2016057
18 Test System Assembly 2016232 Optional ISE
19 Amplifier Board Assembly 2016236 Optional ISE
20 Pump Assembly 2016235 Optional ISE
21 Valve Assembly 2016234 Optional ISE

9.3.2 List of Switching Power Supply Spare Parts
No. Name SAP Code Remarks
1 24V Switching Power Supply 1033147 LCM600Q-T-N
2 12V Switching Power Supply 1030473 HWS50A-12

9.3.3 List of Circuit Board Spare Parts
No. Name SAP Code Remarks
1 CS-T180\ Main Control Board (with Burned Program) 2014281
2 CS-T180\ Probe Control Board (with Burned Program) 2014282
3 CS-T180\ Reaction Disk Control Board (with Burned Program) 2014283
4 CS-T180\ AC Control Board (with Burned Program) 2014284
5 CS-T180\ Data Collection Board (with Burned Program) 2014285
6 CS-T180\ Liquid Level Detecting Board (with Burned Program) 2014286
7 CS-T180\ Data Collection Board 1037989
143


8 CS-T180\ Sample Dispensing Indicator Lamp Board 1037991
9
CS6400ISE MPXV Pressure Sensor
Module Board (with Burned
Program)
2001534 Vacuum Tank
10 CS-400\ Power Signal Lamp Board (Assembly) 2000383
11 CS-400-17\ Pump Optocoupler Adapter Board (Assembly) 2000381
12
CS-6400\CS-6400 Bar Code
Reader Board (with Burned
Program)
2001508
13 CS-T180\ ISE Control Board (with Burned Program) 2014287 ISE
14 CS-6400\CS-6400 ISE Front Amplifier Board 2006448 ISE
15 CS-6400ISE\ Pump Adapter Board Assembly 2000405

9.3.4 List of Sensor Spare Parts
No. Name SAP Code Remarks
1 Wire JS01 2011735 Ambient Temperature Sensor
2 Wire JS02 2011734 Optical Temperature Sensor
3 Wire JS03 2011729 Incubation Bath Temperature Sensor
4 Wire JS05 2011733 Sample Reagent Disk Temperature Sensor
5 Wire JS07 2011731
Temperature Sensor of
Constant-temperature Degassing

6 Wire PSW04-1 2011745 High- and Low-concentration Waste Liquid Float
7 Wire PSW05 2011747 Pure Water Float
8 Wire PSW06 2011748 Detergent Float

9.3.5 List of Pump Spare Parts
No. Name SAP Code Remarks
1 Wire JP1 2011764 Diaphragm Pump 1026470
2 Wire JP2 2011765 Diaphragm Pump 1026470

9.3.6 List of Optocoupler Spare Parts
No. Name SAP Code Remarks
1 Groove Optocoupler 1023766 KI3781, 7 pcs.
2 Wire J0402 for Optocoupler 2011702 Optocoupler wire of reaction disk


144


9.3.7 List of Timing Belt Spare Parts
No. Name SAP Code Remarks
1 Timing Belt 1008957 363-3M
2 Timing Belt 1008955 100XL-10
3 Timing Belt 1008956 240XL-10

9.3.8 List of Motor Spare Parts
No. Name SAP Code Remarks
1 Wire J102 2003848 Probe Swinging Arm and Lifting Motor
2 Wire J434 2003383 Rinsing Mechanism Lifting Motor
3 Wire J441 2003479 For reaction disk motor
4 Wire J223 2000165 For reagent disk motor
5 Wire J0602 2015056 Motor of Mixing Lifting Mechanism
6 Wire J440C 2004870 For mixing motor

9.3.9 List of Valve Spare Parts
No. Name SAP Code Remarks
1 Wire J1603 2015060 For two-way solenoid valve 1023461 (1 pc.)
2 Wire J1403 2015058 For two-way solenoid valve1023461 (2 pcs.)
3 Wire J1604 2015059
For two-way solenoid valve
1023461 (4 pcs.)
For two-way solenoid valve
1023462 (1 pc.)
4 Wire J1609 2015057 For three-way solenoid valve 1022794 (1 pc.)

9.3.10 List of Other Spare Parts
No. Name SAP Code Remarks
1 Fuse 1013297 5×20 6.3A 250V
2 EMI Filter 1013214
3 Power Switch 1013253
4 T-reducer 1009655 RT6-2.5, optional for ISE
5 Diluent Tank Assembly 2009937 Optional ISE
6 Internal Standard Solution Tank Assembly 2009936 Optional ISE
7 Reference Solution Tank Assembly 2014348 Optional ISE

145
9.4 Unit Exploded Drawing and Spare Parts List
9.4.1 Optical Detection Unit (CS-T180-02-00)
SAP Code: 2015065

No. Name SAP Code Remarks
1 Raster Box ——
2 Front Microscope Base Assembly of Reflector 2014704
3 Halogen Lamp Assembly 2001904
4 Fan 1030718
5 Data Collection Board 08+09 (with Burned Program) 2001932
5-01 Data Collection Board-08 2006382 Finished products need to be delivered with 09
5-02 Data Collection Board-09 2006383 Finished products need to be delivered with 09
6 CS6400 Wire P514 2004079 Connecting wire of AD board and main control board
7 Wire B06-P4 2012199
8 Wire JFan02 2011753 Connecting wire of fan
9 Wire JS02 2011734 Connecting wire of thermistor
146
1
2
5-02
5-01
3
6
7
4
8
9
CS-T180-02-00
147
9.4.2 Probe Unit
9.4.2.1 Probe Unit (Upper Part) (CS-T180-03-01-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Probe Housing 1027949
2 Compression Screw 1003883
3 Guide Pin 1007278
4 Reagent Probe Compression Spring 1007847
5 Anti-rotation Block 1007280
6 Reagent Probe Rack 1007633
7 Guide Sleeve 1025478
8 Sample Probe Arm 1004827
9 Cross Recessed Pan-head Combined Screw M3×8 1008288
10 Cross Recessed Pan-head Combined Screw M3×6 1008287
11 Probe Arm Cardboard 1007736
12 Flat-head Cross Screw M3×5 1008302
13 Probe Arm Connection Piece 1027474
14 Hexagon Socket Set Screw with Cup Point M4×8 1008520
15 Hexagon Socket Cap Screw M3×8 1008310
16 Circuit Board Washer 1007684
17 CS-T180 Liquid Level Detecting Board (with Burned Program) 2014286
18 Inner Pressing Plate of Probe Arm 1007474
19 Syringe Pump Tube Connector 1009527
20 Cross Recessed Pan-head Combined Screw M3×18 1008519
21 Seal Ferrule 1008074
22 Reagent Box Connector 1009685
23 CS400 Tube 148 (Assembly) 2005156
24 Cross Recessed Pan-head Screw M3×8 2011686
25 Probe Tube 1029226
26 Probe Protective Tube T180 1029227
27 Wire B11-P 2011686
148
1
2
3
4
6
7
8
5
9
10
1211 13 14
15
16
17
24
18
1920212223
27
2526

CS-T180-03-01-00
149
9.4.2.2 Probe Unit (Lower Part) (CS-T180-03-02-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Timing Belt 1008957
2 Hexagon Socket Set Screws with Cup Point M4×5 1008300
3 Linear Bearing 1008778
4 Flange Bearing 1008805
5 Timing Belt 1008955
6 Wire J102 2003848 Probe Swinging Arm and Lifting Motor
6-01 Wire J102 - Arm Swing Motor 1011871
6-02 Wire J102 - Lifting Motor 1011872
7 Groove Optocoupler 1023766
8 Deep Groove Ball Bearing 1008804
9 Deep Groove Ball Bearing 1008803
10 FPC Soft Circuit Board 1014524 Soft circuit board passing through the spline
11 Timing Pulley 3M-20 1009084
12 Timing Pulley 12XL 1009085
13 Timing Pulley 20-3M 1009086
14 Timing Pulley 34-XL 1009094
15 Wire J0303 2011684
150
7
5
113 9
15
14
12
6-01
7
1
2
6-02
6
8
4
15
2
10
13
CS-T180-03-02-00
151
9.4.3 Rinsing Unit (CS-T180-05-00)
SAP Code: ——

No. Name SAP Code Remarks
1 Spring Holder 1007469 Qty.: 4
2 Pressure Spring 1007846 Qty.: 4
3 Rinsing Probe 3 (Made in China) 1006007 Qty.: 3
4 Wiping Probe 2 1008033
5 Spring Fixing Base 1027447 Qty.: 4
6 Rinsing Probe Rack 1024694
7 Fixing Screw 1004331
8 O-ring 21.2×2.65 1008719
9 Rinsing Probe Support 1007471
10 Circlip for Shaft 10 1008596
11 Hexagon Socket Cap Screw M4X10 1008317
12 Connecting Plate 1004332
13 Spring Washer 4 1008586 Qty.:2
14 Hexagon Socket Combined Screw

1008561
15 Support Shaft 1003150
16 Hexagon Socket Set Screws with

1008330 Qty.: 5
17 Sliding Block 1004261
18 Shaft Bearing 1003164
19 Rolling Ball Bearing 1008781 Qty.:2
20 Split Washer 3 1008594 Qty.:2
21 Cross Recessed Pan-head Combined

1008287 Qty.: 7
22 Pressure Sheeting 1003295 Qty.:2
23 Base 2006128
24 Wire J434 2003383 Rinsing Mechanism Lifting Motor

24-01 Stepper Motor 1011921
25 Cross Recessed Pan-head Combined

1008293 Qty.: 3
26 Wire J0502 2011701
26-01 Groove Optocoupler 1023766
27 Optocoupler Fixing Plate 3 1003162
28 Rinsing Bath Cable Plugboard

1000626
29 Oscillating Bar Assembly 1003160
152
4
1
2
3
10
11
12
15
23
16
17
1319 1821 2022
14
9
8
7
6
5
13
21 21 22 21
19
20
16
24
CS-T180-05-00
24-01
25
26
26-01
27 28
29
153
9.4.4 Mixing Unit (CS-T180-06-00)
SAP Code: ——

No. Name SAP Code Remarks
1 Upper Cover of Swinging Motor 1007487
2 Encoding Disk Motor Cover 1007484
3 Encoding Disk Combination 1024699
4 Cross Pan-head Screw M3×40 1008280
5 Wire J0602 2015056
5-01 Stepper Motor 1011907
5-02 Stepper Motor 1011873
6 Fixing Sheeting 1003159
7 Pin Fixing Plate 1003158
8 Sliding Block 1004261
9 Shaft Bearing 1003164
10 Arm Swing Motor Fixing Base Assembly 2006193
11 Rolling Ball Bearing 1008781
12 Pressure Sheeting 1004261
13 Oscillating Bar Assembly 1003160
14 Base 2006128
15 Optocoupler Fixing Plate 1 1003161
16 Wire J0604 2011711
16-01 Groove Optocoupler 1023766
17 Optocoupler Fixing Plate 3 1003162
18 Cable plugboard fixing plate 1003163
19 Mixing Bearing Assembly 1001311
20 Mixing Bar 1008016
21 Swing Arm for Mixing 1024700
22 Shell of Support Arm for Mixing 1025202
23 Connecting Block for Mixing 1004818
24 Mixing Motor Installation Piece 1003938
25 Locating Block 1007210
26 Wire J440C 2004870
26-01 Hollow Cuvette Motor 1011890
154
3
10
2
15
1
5-01
16-01
8913 12
5-02
2423
19
17
26-01
16
7
6
14 11
20
18
4
22
21
26
16
5
5
25
CS-T180-06-00
155
9.4.5 Reaction Disk and Drive Mechanism
9.4.5.1 Overall Unit (CS-T180-04-00)
SAP Code: 2008800



No. Name SAP Code Remarks
1 Installation Baseplate Assembly 2009917
2 Drive Mechanism 2009914 Refer to 9.4.5.2
3 Incubation Bath Assembly 2009915 Refer to 9.4.5.3
4 Cuvette Installation Disk Assembly 2009916
4-01 Cuvette 1027510
4-02 Cuvette Fixing Screw 1027509
156
CS-T180-04-00
4-01
4
3
2
1
4-02
157
9.4.5.2 Drive Mechanism (CS-T180-04-01-00)
SAP Code: 2009914



No. Name SAP Code Remarks
1 Bearing Fixing Sleeve 1004262
2 Set Pin for Disk 1003315
3 Waterproof Plug 1007975
4 Motor Gear 1009080
5 Hexagon Socket Set Screw with Cup Point M4×6 1008377
6 Waterproof Hood of Motor Gear 1007022
7 Disk Drive Support 1007767
8 CS400 Wire J441 (Assembly) 2003479
8-01 Stepper Motor 1011874
9 Damping Device Assembly 2000436
10 Rolling Ball Bearing 1008783
11 Support Column 1027499
12 300-Gear Disk 1009076
158
CS-T180-04-01-00
11
2
1
3
5
4
6
7
8
9
10
12
8-01
159
9.4.5.3 Incubation Bath Assembly (CS-T180-04-02-00)
SAP Code: 2009915



No. Name SAP Code Remarks
1 Incubation Bath 1027500
2 Wire J0405 2011755
2-01 Fan 1027755 3 pcs. in total
3 Fan Partition 1030726
4 Fan Pressure Sheeting 1030727
5 Wire J0402 2011702
5-01 Optocoupler 1013345 2 pcs. in total
6 Wire JHeating01 2011760
6-01 Heating Belt 1030730
6-02 Temperature Switch 1030806 On the bottom of incubation bath
7 Socket Rack 1030729
8 Wire JS03 2011729
8-01 Temperature Sensor 1023727
9 Overflow Connector 1027506 3 pcs. in total
10 Disk Cover Pin 1029217
11 Fan Protective Piece 1030728
12 Outer Window Pressure Sheeting 1027502
160
CS-T180-04-02-00
5
5-01
12
3
1
42-01
6
8-01
11
10
7
9
8
2
6-01
6-02
161
9.4.6 Sample/ Reagent Disk Unit
9.4.6.1 Overall Unit (CS-T180-11-00)
SAP Code: 2009898



No. Name SAP Code Remarks
1 Chamber Cover Assembly 2010243
2 Sample/ Reagent Disk Rack Assembly 2014996 Refer to 9.4.6.2
3 Refrigeration Chamber 2010237 Refer to 9.4.6.3
4 Sample/ Reagent Disk Drive Mechanism 2010238 Refer to 9.4.6.4
5 Waterproof Pad 1007974
162
5
1
4
2
3
CS-T180-11-00



163
9.4.6.2 Sample/ Reagent Disk Rack Assembly (CS-T180-11-10-00)
SAP Code: 2014996



No. Name SAP Code Remarks
1 Lock Bolt 1006956
2 Lock Nut 1006955
3 Rubber Mat 1037918
4 Sample/ Reagent Disk Rack 1037917
164
2
4
1
1
3
2
CS-T180-11-10-00



165
9.4.6.3 Refrigeration Chamber (CS-T180-11-09-00)
SAP Code: 2010237



No. Name SAP Code Remarks
1 Rubber Foaming Seal Strip 1008756
2 Plastic Circlip 1027633
3 Disk Body 1027630
4 Insulation Cover 2 1027632
5 Radiator 1027635
6 Lower Ventilation Hood 1027637
7 JFan06 2011751
8 JCooling01 2011767
8-01 Peltier 1025290
9 Front Ventilation Hood 1027636
10 JFan07 2011752
11 JCooling02 2011769
12 JS05 2011733 Required to be assembled (with
thermal silicone grease
and glue 460) 12-01 Refrigeration Temperature Block 1004519
13 Insulation Pad 2 1037922
14 Glass Slide 1000081
15 Wire JHeating04 2011757
16 Heating Window Rack 1003172
17 Insulation Pad 1 1037921
166
CS-T180-11-09-00
12
12-01
13
9
14
2
8
16
17
15
11
6
3
10
8-01
1
4
5
5
7
8-01



167
9.4.6.4 Sample Reagent Disk Drive Mechanism (CS-T180-11-08-00)
SAP Code: 2015061



No. Name SAP Code Remarks
1 Timing Belt 1008956
2 Hexagon Socket Set Screws with Cup Point M4×6 1008377
3 Reagent Disk Joint Sleeve 1006917
4 Insulation Cover 1027629
5 Deep Groove Ball Bearing 1008783
6 Connection Fixing Column 1007489
7 Sample Timing Encoding Disk 1007488
8 Waterproof Plug 1007975
9 Timing Pulley 1009081
10 Motor Waterproof Hood 1007490
11 Disk Drive Support 1007475
12 Wire J223 2000165 Drive Motor
12-01 Wire J223 for stepper motor 1011934
13 Damping Device Assembly 2000436
14 Wire J1102 2011687 For zeroing and counting optocoupler
15 Groove Optocoupler 1023766
168
7
8
1
4
2
2
12
13
3
2
10
6
5
11
12-01
9
2
5
2
15
14
CS-T180 -11-08 -00




169
9.4.7 Constant-temperature Degassing Assembly (CS-T180-13-00)
SAP Code: 2009924

No. Name SAP Code Remarks
1 Cross Recessed Pan-head Combined Screw 1008467
2 Tank Support Plate 1025675
3 Installation Column 1025694
4 Lower Insulation Cover 1025709
5 Connector G18-4 1009534
6 Cross Recessed Pan-head Combined Screw 1008288
7 Seal Joint 1025692
8 Constant-temperature Degassing Upper Cover 1025691
9 Water Block 1025693
10 Wire JS07 2011731
10-01 Temperature Sensor 1026128
11 Cross Recessed Pan-head Combined Screw 1008287
12 Wire JHeating05 2011762
12-01 Heating Belt 1025710
12-02 Temperature Switch 1030310
13 Constant-temperature Degassing Rack 1025674
14 Upper Insulation Cover 1025708
15 Insulated Cotton of Tank 1025707
16 Constant-temperature Degassing Tank 1025690
17 O-ring 1033917
170
CS-T180-13-00
7
5
6
8
2
3
1
4
13
16
12
17
15
14 12-02
9
11
12-01
10
10-01
171
9.4.8 Syringe Pump Unit (CS-T180-14-00)
SAP Code: 2015066

No. Name SAP Code Remarks
1 Syringe Pump Installation Plate 1025676
2 Pump Optocoupler Adapter Board (Assembly) 2000381
3 Cross Recessed Pan-head Combined Screw 1008288
4 Cross Recessed Pan-head Combined Screw 1008465
5 Single Valve Fixing Plate 1025679
6 Cross Recessed Pan-head Combined Screw 1008288
7 Single Valve Plate -X225 1025695
8 Wire J1403 2015058
8-01 Two-way Solenoid Valve 1023461
9 Solenoid Valve Connector 1009525
10 Pan-head Cross Screw 1008297
11 Cross Recessed Small Pan-head Screw 1008399
12 Exhaust Block 1 1032079
13 O-ring 1008764
14 Exhaust Block 2 1032080
15 Wire J1402 2011693
15-01 Motor 1030805
16 Wire J1401 2011692
172
2
3
4
1
7
8-01
6
5
8-01
10
15-01
8
9
11
15
16-01
16
CS-T180-14-00
14
12
13
173
9.4.9 Group Valve Assembly (CS-T180-16-00)
SAP Code: 2015422

No. Name SAP Code Remarks
1 Wire J1604 2015059
1-01 Two-way Solenoid Valve 1023461
1-02 Two-way Solenoid Valve 1023462
2 Solenoid Valve Connector 1009560
3 Five Valve Plate 1025698
4 Group Valve Rack 1025681
5 Cross Recessed Pan-head Combined Screw 1008291
6 Cross Recessed Pan-head Combined Screw 1008288
7 Internal Thread Connector G14-4 1024018
8 Wire J1609 2015057
8-01 3-way Solenoid Valve 1022794
9 Cross Pan-head Screw 1008267
10 Plug 1025714
11 Solenoid Valve Connector 1009525
12 Wire J1603 2015060
12-01 Two-way Solenoid Valve 1023461
174
CS-T180-16-00
8-01
10
6
12-01
11
1
4
3
5
1-01
9
7
8
1-02
2
12
175
9.4.10 Waste Liquid Assembly (CS-T180-10-00)
SAP Code: 2015067

No. Name SAP Code Remarks
1 Cross Recessed Pan-head Combined Screw 1008291
2 Check Valve 1009867
3 Cross Recessed Pan-head Combined Screw 1008287
4 Pressure Sensor Module Plate (with Burned Program) 2001534
5 Y-Connector 1009549
6 Pump Rack 1027460
7 Cross Recessed Pan-head Combined Screw 1008348
8 Liquid Collection Vacuum Tank Assembly (Semi-finished Product) 2002037
9 Hexagon Socket Combined Screw 1008560
10 Waste Liquid Tank Rack 1025673
11 Wire JP2 2011765
11-01 Diaphragm Pump 1026470
12 Wire JP1 2011764
12-01 Diaphragm Pump 1026470
176
CS-T180-10-00
1
8
5
10 6
3
12
11
12-01
4
9
7
2
11-01
177
9.4.11 Waste Liquid Tank Assembly (CS-T180-15-00)
SAP Code: 2016057

No. Name SAP Code Remarks
1 Bulkhead Connector 1025720
2 Float Pressure Cap 1007180
3 Low-concentration Waste Liquid Cover 1025697
4 Set Pin 1007297
5 Float Fixing Base 1004607
6 Water Tank 2009900
7 Wire PSW04-1 2011745
7-01 Float Pressure Cap 1007180
7-02 Float Pressing Plate 1007186
7-03 Float of Waste Liquid Tank 1025711
8 Bulkhead Connector 1025721
178
CS-T180-15-00
2
5
6
4
1
3
7
7-03
8
7-02
7-01
179
9.4.12 Pure Water Assembly (CS-T180-19-00)
SAP Code: 2016056

No. Name SAP Code Remarks
1 Float Pressure Cap 1007180
2 Wire PSW05 2011747
2-01 Float Pressing Plate 1007186
2-02 Water Tank Float 1025712
3 Float Fixing Base 1004607
4 Water Tank 2009900
5 ISE Filter 200 1008102
6 Detergent Filter Connector 1007202
7 XR78-305\ Tube 2013012
8 Set Pin 1007297
9 Water Outlet Cover 1025700
10 Panel Installation Connector 1/4-28 UNF 1009564
180
2-02
4
2
10
8
7
9
6
1
3
2-01
5
CS-T180-19-00
181
9.4.13 Detergent Tank Assembly (CS-T180-23-00)
SAP Code: 2015423

No. Name SAP Code Remarks
1 Wire PSW06 2011748
1-01 Detergent Tank Cap Pad 1025706
1-02 Detergent Float 1025713
2 Bottle Body (with Cover) 2006185
3 ISE Filter 200 1008102
4 Detergent Filter Connector 1007202
5 FR22-167\ Tube 2013006
6 O-ring 1018605
7 Flanging Connector 1020420
182
CS-T180-23-00
4
5
6 1
1-01
1-02
2
3
7
183
9.4.14 Cover Assembly
9.4.14.1 Cover Overall Unit (CS-T180-12-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Upper Cover Assembly 2011623 Refer to 9.4.14.2
2 Beam Welding Assembly of Upper Cover 1029228
3 Screw Cap 1036330
4 Rear Connecting Piece 1029086
5 Set Pin 1030776
6 Nitrogen Spring 1029180
7 Left Cover 1036480
8 Lower Pivot Point of Gas Strut 1029232
9 Cover Assembly —— Refer to 9.4.14.3
10 Front Cover 1029075
11 Locating Pin 1029089
12 Front Side Coaming 1029088
13 Side Coaming 1029087
14 Tank Bottom Foot (Large) 1007961
15 Sample Dispensing Indicator Lamp Board CS-T180 1037991
16 Power Switch 1013253
17 Right Cover 1036481
18 EMI Filter, Fuse 1013214/101329719 Rear Cover 1025756
20 Rear Upper Cover 1029076
21 Hinge Assembly —— Refer to 9.4.14.4
22 Locating Pin 1030776
184
4
3
2
CS T180 12 00- - -
1
5
6
7
8
9
5
22
10
11
12
21
20
4
19
6
5
5
18
17
16
15
14
13
185
9.4.14.2 Upper Cover Assembly (CS-T180-12-08-00)
SAP Code: 2011623



No. Name SAP Code Remarks
1 Front Fixing Plate of Upper Cover 1029082
2 Front Connecting Piece of Upper Cover 1029083
3 Upper Cover 1029080
4 Inspection Window 1029081
186
4
3
2
1
CS T180 12 08 00- - - -
187
9.4.14.3 Cover Assembly (CS-T180-12-07-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Left Upper Cover 1029077
2 Left Middle Cover 1029090
3 Induction Disk Cover 1036728
4 Left Lower Cover 1029078
5 Rinsing Tube Fixing Sleeve 1041802
6 Screw Cap 1036330
7 Reagent Disk Cover 1027644
8 Right Cover 1029079
9 Rubber Jacket 1007495
10 Knob 1007496
188
4
3
2
1
5
6
7
8
9
10
CS T180 12 07 00- - - -
189
9.4.14.4 Hinge Assembly (CS-T180-12-21-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Self-lubricating Bearing 1008835
2 Hinge Shaft 1029229
3 Split Washer 5 1008595
4 Hinge Support 1029231
5 Hinge for Upper Cover 1029230
190
4
3
2
1
5
CS T180 12 21 00- - - -
191
9.4.15 ISE Unit
9.4.15.1 Test System Assembly (CS-T180-20-01-00)
SAP Code: 2016232

No. Name SAP Code Remarks
1 Wire J351 2000269 Flow Cell
2 Flow Cell Retaining Clip 1025701
3 Cross Recessed Pan-head Combined Screw 1008288
4 Seal Ring 1013583
5 K Electrode Head 1013582
6 K Electrode Wire 1014486
7 CI Electrode 1013581
8 K Nut 1013584
9 Cl Nut 1013586
10 Wire JV14 2011723
10-01 Pinch Valve 1009857
11 Cross Recessed Pan-head Combined Screw 1008484
12 Cross Recessed Pan-head Combined Screw 1008465
13 Cross Recessed Pan-head Combined Screw 1008292
14 Test System Base 1025683
15 Annular Fixer 1003554
16 Proportioning Cup Assembly 2002108
17 Cross Recessed Pan-head Combined Screw 1008295
18 Wire JV13 2011722
18-01 Solenoid Valve 1036697
19 Installation Ring 1009174
20 Cross Recessed Pan-head Combined Screw 1008287
21 Solenoid Valve Connector 1009560
22 Wire JV15 2011724
22-01 Pinch Valve 1009866
23 Electrode Mounting Plate 1025682
24 Na Nut 1013585
25 Ca Seal Plug 1007327
26 Na Electrode 1013580
192
CS-T180-20-01-00
1
13
17
4
2
8
10
15
5
3
22
23
11
20
19
24
12
18-01
10-01
18
14
7
25
26
16
22-01
21
9
6
193
9.4.15.2 Amplifier Board Assembly (CS-T180-20-02-00)
SAP Code: 2016236

No. Name SAP Code Remarks
1 Electrode Rack 1001352
2 Electrode Fixing Plate 1004980
3 Cross Recessed Countersunk Head Screw 1008303
4 Cross Recessed Pan-head Combined Screw 1008287
5 Cross Recessed Pan-head Combined Screw 1008288
6 Amplifier Board Box 1025684
7 Pre-amplification Board (Assembly) 2000408
8 Amplifier Board Hood 1025685
194
CS-T180-20-02-00
1
4
3
5
6
7
2
8
195
9.4.15.3 Pump Assembly (CS-T180-20-03-00)
SAP Code: 2016235

No. Name SAP Code Remarks
1 Pump Assembly Fixing Plate 1025686
2 Wire JM06 2011719
2-01 Peristaltic Pump 1009797
3 Wire JM07 2011720
3-01 Peristaltic Pump 1009797
4 Cross Recessed Pan-head Combined Screw 1008288
5 Wire JP16 2014320
5-01 Diaphragm Pump 1026470
6 Wire JM05 2011715
6-01 Syringe Pump 1025722
7 Cross Recessed Pan-head Combined Screw 1008288
8 Pump Adapter Assembly 2000405
196
CS-T180-20-03-00
1
6-01
3-01
4
8
3
5
6
2-01
2
7
5-01
197
9.4.15.4 Valve Assembly (CS-T180-20-04-00)
SAP Code: 2016234

No. Name SAP Code Remarks
1 Adapter 1/4"-16 1009707
2 Electrode Waste Liquid Tank Connector 1025703
3 Cross Recessed Pan-head Combined Screw 1008288
4 Electrode Waste Liquid Tank Fixing Plate 1025689
5 Reagent Bottle Cap 1007613
6 Thread Cap 1 1007096
7 O-ring 1008740
8 Reagent Bottle 1007615
9 Degassing Tank CS400ISE 2002240
10 Wire JV11 2011725
10-01 Solenoid Valve 1036697
11 Valve Assembly Mounting Plate 1025687
12 Cross Recessed Pan-head Combined Screw 1008484
13 Pressure Sensor Module Plate (with Burned Program) 2001534
14 Cross Recessed Pan-head Combined Screw 1008287
15 Cross Recessed Pan-head Combined Screw 1008291
16 Electrode Waste Liquid Tank Fixing Pillar 1025702
17 Wire JV12 2011726
17-01 Solenoid Valve 1036697
18 Electrode Waste Liquid Tank Upper Cap 1025704
198
12
17-01
14
15
17
16
18
13
11
7
10
5
8
9
10-01
6
1
2
3
4
CS-T180-20-04-00
199
9.4.15.5 Internal Standard Solution Tank Assembly (CS-T180-22-01-00)
SAP Code: 2009936

No. Name SAP Code Remarks
1 Flanging Connector 1020420
2 Internal Standard Solution Tank Cap 2006237
3 O-ring 1018605
4 ISE Tank Cap Pad 1025705
5 Tube FR22-180-02 2014293
6 Detergent Filter Connector 1007202
7 ISE Filter 200 1008102
8 Internal Standard Solution Tank 1011767
200
CS-T180-22-01-00
2
1
3
7
4
8
6
5
201
9.4.15.6 Reference Solution Tank Assembly (CS-T180-22-04-00)
SAP Code: 2014348

No. Name SAP Code Remarks
1 Flanging Connector 1020420
2 Internal Standard Solution Tank Cap 2006237
3 O-ring 1018605
4 ISE Tank Cap Pad 1025705
5 Tube FR22-180-01 2014292
6 Detergent Filter Connector 1007202
7 ISE Filter 200 1008102
8 Internal Standard Solution Tank 1011767
202
CS-T180-22-04-00
1
4
7
8
5
6
2
3
203
9.4.15.7 Alkene Dispensing Tank Assembly (CS-T180-22-02-00)
SAP Code: 2009937

No. Name SAP Code Remarks
1 Flanging Connector 1020420
2 O-ring 1018605
3 Alkene Dispensing Tank Cap 2006238
4 ISE Tank Cap Pad 1025705
5 Tube FR22-160-01 2012999
6 Detergent Filter Connector 1007202
7 ISE Filter 200 1008102
8 Alkene Dispensing Tank 1011761
204
5
8
4
3
2
1
7
6
CS-T180-22-02-00
205
9.4.15.8 ISE Reagent Tank Assembly (CS-T180-22-00)
SAP Code: 2009933

No. Name SAP Code Remarks
1 Internal Standard Solution Tank Assembly 2009936
2 Reference Solution Tank Assembly 2014348
3 Alkene Dispensing Tank Assembly 2009937
4 Tank Rack 1027461
206
3
1
2
4
CS-T180-22-00
207
9.5 Pipeline Diagram and Spare Part Codes List
(1) List of Tubing Spare Parts
No. Name SAP Code Remarks
1 Tube 1 2012963
2 Tube 2 2012633
3 Tube 4 2011964
4 Tube 9 2012964
5 Tube 10 2012936
6 Tube 11 2011604
7 Tube 12 2016720
8 Tube 13 2016721
9 Tube 15 2016722
10 Tube 17 2013006
11 Tube 18 2015021
12 Tube 19 2015022
13 Tube 20 2013007
14 Tube 21 2013008
15 Tube 22 2011995
16 Tube 24 2015323
17 Tube 25 2015324
18 Tube 26 2015025
19 Tube 27 2012944
20 Tube 28 2015325
21 Tube 29 2015019
22 Tube 30 2015023
23 Tube 32 2012947
24 Tube 33 2012948
25 Tube 34 2012949
26 Tube 35 2012950
27 Tube 36 2015020
28 Tube 37 2015046
29 Tube 38 2012953
208
No. Name SAP Code Remarks
30 Tube 39 2012954
31 Tube 40 2013012
32 Tube 41 2013013
33 Tube 42 2012626
34 Tube 43 2015024
35 Tube 44 2012957
36 Tube 45 2012628
37 Tube 47 2012629
38 Tube 48 2012956
39 Tube 49 2012630
40 Tube 50 2012642
41 Tube 51 2012625
42 Tube 52 2013014
43 Tube 54 2012959
44 Tube 55 2012960
45 Tube 56 2012961
46 Tube 57 2012962

(2) List of Connector and Function Parts
No. Code Name SAP Code Remarks
1 F1 3/8 T-Connector T670-6005\ T-Connector 1009530
2 F2 SCV06265\ Check Valve 1009867
3 F4 1/8 Y-Connector (Y230-1)\Y-Connector 1009549
4 F5 BHU2202\ Bulkhead Connector 1025719
5 F6 BHU2204\ Bulkhead Connector 1025720
6 F7 CS-T180-16-04\ Bore Through Connector 1031967
7 F8 BHU2206\ Bulkhead Connector 1025721
8 F9 CS-6400CAB-02-27 P-606\ Square Connector 1009713
9 F10 PMS230-1\ Tube Connector 1009564
10 F11 N8S8\ Thread Reverse Clasp Joint 1025717
11 F12 N8E8\ Right-angle Thread Adapter 1025718
209
12U1 CS-T180-10-00 Waste Liquid Assembly 2015067
13 U2
CS-T180-13-00
Constant-temperature Degassing
Assembly
2009924
14 U3 CS-T180-14-00 Syringe Pump Unit 2015066
15 U4 CS-T180-15-00 Waste Liquid Tank Assembly 2016057
16 U5 CS-T180-16-00 Group Valve Assembly 2015422
17 U6 CS-T180-19-00 Pure Water Unit 2016056
18 U7 CS-T180-23-00 Detergent Tank Assembly 2015423

210
Low-concentration
Waste Liquid Tank
High-concentration
Waste Liquid Tank
Deionized Water
Pressure
Sensor
Check Valve
Alkaline Detergent
Probe 4 Probe 2Probe 3 Probe 1
Reaction Disk Reagent Refrigeration Chamber
M
ixing R
insing B
ath
P
robe R
insing B
ath
211
9.6 Accessories Case Exploded Drawing and Spare Parts List
9.6.1 Accessories Case (CS-T180-BZ-06-00)
SAP Code: ——



No. Name SAP Code Remarks
1 Accessories Case Upper Cover 1040844
2 Accessories Case 2nd Layer Refer to 9.6.2
3 Accessories Case 3rd Layer Refer to 9.6.3
4 Accessories Case 4th Layer Refer to 9.6.4
5 Accessories Case Cardboard Box 1040843
212
2
5
4
3
1
CS-T180-BZ-06-00
213
9.6.2 Accessories Case 2nd Layer (CS-T180-BZ-10)
SAP Code: ——
 Note: a copy of Operation Procedure (1038114) and a copy of Maintenance Procedure (1038116) shall be
prepared on accessories case lining-3.


No. Name SAP Code Remarks
1
CS-T180 Accessory Case
Comparison Diagram 1037891
Inspection Certificate for Instrument
Products 1011550
Maintenance & Repair Service Card
of Instrument Products 1011549
CS-T180 User Manual 1038110
Installation Acceptance Report 1038112 2 volumes
Installation CD of Auto-Chemistry
Analyzer (General) 1011782
CD Bag 1011783
Zippered Bag 1011746
2 10A/220V\ Flexible Power Cable 1011743
3 S6500-GY\ Category 5 Cable 1030645
4 CS-T180-BZ-10 Accessories Case Lining-3 1040847
5
CS-400-03-04 Spring Clip 1007469 2 pcs.
CS-400-03-03 Pressure Spring 1007846 2 pcs.
Pressure Spring 1026457
Cross Recessed Pan-head Combined
Screw M4×16 1008295 5 pcs.
Cross Recessed Pan-head Combined
Screw M4×8 1008291 8 pcs.
6
Fuse 5×20 / 6.3A/250V 1013297 2 pcs.
Probe Unblocking Needle 1029683 1 No.
7 None Standby
8 Probe Unblocking Tool (Optional) 2000426
9 Allen Wrench 1.5mm 1011734
10 Allen Wrench 2mm 1011735
214
7
8
9
1
2
3
4
5 6
10
CS-T180-BZ-10
215
9.6.3 Accessories Case 3rd Layer (CS-T180-BZ-09)
SAP Code: ——


No. Name SAP Code Remarks
1 Reagent Bottle 1011819 90 pcs. (35ml)
2 CS-T180-BZ-09 Accessories Case Lining-2 1040846
3 Standard Cup 1011733 500 pcs./bag
4 Cross Screwdriver 1011736
216
2
3
1
4
CS-T180-BZ-09
217
9.6.4 Accessories Case 4th Layer (CS-T180-BZ-08)
SAP Code: ——


No. Name SAP Code Remarks
1 Optional ISE Assembly —— 1 set
2 None —— Standby
3 Reagent Bottle (70ml) 1011766 3 sets
4 Reagent Bottle (20ml) 1011762 20 pcs.
5 CS-T180-BZ-08 Accessories Case Lining-1 1040845
6
CS-T180 Tube 38 2012953
CS-T180 Tube 37 2012944
CS-T180 Tube 27 2015046
218
CS-T180-BZ-08
4
5
1
2
3
6
219
Service Manual of Auto-Chemistry Analyzer

Chapter 10 Manual revision and change record


No. Revision No. Date of Revision Contents of Revision
Chapter of
Revision
1 REV.2018-08 2018-08 First edition
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25

220
