7.1   Introduction
Rapid improvements in high- resolution mass spectrometry (HRMS) instru-
mentation since the early 2000s have led to equally dramatic develop-
ments in the fields of targeted and untargeted metabolomics.1 However,
the MS instrument vendors initially lagged behind in software devel-
opment, and the gap in raw MS data processing tools for metabolomics
has been primarily filled by efforts from academia. The MZmine project
was originally started in 2005 by Matej Orešic's group at VTT Biotechnol-
ogy in Finland.2 It received a major overhaul towards modularity, spear-
headed mainly by Tomáš Pluskal at the Okinawa Institute of Science and
technology in Japan, and its second version, MZmine 2, was introduced in
CHaPTeR 7
Metabolomics Data Analysis
Using MZmine
TOMáš PluSkal*a, anSgaR kORFb, alekSandR SMIRnOVc,
ROBIn SCHMIdb, TIMOTHy R. FallOna,d, XIuXIa duc and
JIng- ke Weng*a,d
aWhitehead Institute for Biomedical Research, 455 Main Street, Cambridge,
Ma 02142, uSa; buniversity of Münster, Institute of Inorganic and analytical
Chemistry, department of analytical Chemistry, Corrensstraße 28/30,
Münster, 48149, germany; cuniversity of north Carolina at Charlotte,
department of Bioinformatics and genomics, 9331 Robert d. Snyder Rd,
Charlotte, nC 28223, uSa; dMassachusetts Institute of Technology,
department of Biology, 77 Massachusetts ave, Cambridge, Ma 02139, uSa
*e- mail: pluskal@wi.mit.edu, wengj@wi.mit.edu
D
ow
nl
oa
de
d
by
 M
IT
 L
ib
ra
ry
 o
n
3/
17
/2
02
0
3:
26
:5
2
A
M
.
Pu
bl
ishe
d
on
 1
6
M
ar
ch
 2
02
0
on
 h
ttp
s:
//p
ub
s.
rs
c.
or
g
| d
oi
:1
0.
10
39
/9
78
17
88
01
98
80
-0
02
32
233Metabolomics Data Analysis Using MZmine
2010.3 Since then, MZmine has grown into a worldwide collaborative proj-
ect with many research labs and companies having contributed new code
and data- processing modules. as of 2019, the project contains over 180 000
lines of Java source code. gitHub statistics indicate that the software has
been downloaded over 56 000 times over the last four years, and our inter-
nal tracking system shows that over 4.3 million individual module runs
have been performed in 2018 alone. In the last three years, MZmine has
also been participating in the “google Summer of Code” program, offering
opportunities to computer science students to receive funding from google
for their contributions to the development of MZmine.4
MZmine is implemented in Java and can, therefore, be readily used on many
different computer platforms. It has been designed as a modular system and
a particular emphasis has been given to its powerful visualization modules
(Figure 7.1a), which distinguish MZmine from other MS data- processing
tools such as XCMS or OpenMS.5,6 Raw mass spectra can be imported into
MZmine in common file formats, including netcdf, mzMl, mzXMl, and
mzdata.7 When running on Microsoft Windows, MZmine can also directly
import the native .raw files of Thermo and Waters instruments using ven-
dor libraries. MZmine assumes the input data comes from MS experiments
coupled to liquid chromatography (lC- MS) or gas chromatography (gC- MS).
although there are no specific modules in MZmine for processing direct
infusion data, the existing modules can perform feature detection, deiso-
toping, and metabolite identification based on such data simply by ignoring
the retention time values.
