Accepted Manuscript
Title: Stability indicating HPLC-DAD method for analysis of
Ketorolac binary and ternary mixtures in eye drops:
Quantitative analysis in rabbit aqueous humor
Authors: Fawzy A. El Yazbi, Ekram M. Hassan, Essam F.
Khamis, Marwa A.A. Ragab, Mohamed M.A. Hamdy
PII: S1570-0232(17)31761-0
DOI: https://doi.org/10.1016/j.jchromb.2017.10.024
Reference: CHROMB 20854
To appear in: Journal of Chromatography B
Received date: 28-11-2016
Revised date: 2-9-2017
Accepted date: 11-10-2017
Please cite this article as: Fawzy A.El Yazbi, Ekram M.Hassan, Essam
F.Khamis, Marwa A.A.Ragab, Mohamed M.A.Hamdy, Stability indicating HPLC-
DAD method for analysis of Ketorolac binary and ternary mixtures in eye
drops: Quantitative analysis in rabbit aqueous humor, Journal of Chromatography
B https://doi.org/10.1016/j.jchromb.2017.10.024
This is a PDF file of an unedited manuscript that has been accepted for publication.
As a service to our customers we are providing this early version of the manuscript.
The manuscript will undergo copyediting, typesetting, and review of the resulting proof
before it is published in its final form. Please note that during the production process
errors may be discovered which could affect the content, and all legal disclaimers that
apply to the journal pertain.
https://doi.org/10.1016/j.jchromb.2017.10.024
https://doi.org/10.1016/j.jchromb.2017.10.024
Stability indicating HPLC-DAD method for analysis of
Ketorolac binary and ternary mixtures in eye drops:
Quantitative analysis in rabbit aqueous humor


Fawzy A. El Yazbi1, Ekram M. Hassan1, Essam F. Khamis1, Marwa A.A. Ragab1, and
Mohamed M.A. Hamdy2

1Department of Pharmaceutical Analytical Chemistry, Faculty of Pharmacy, University of
Alexandria, Elmessalah, Alexandria 21521, Egypt.
2Analytical and Pharmaceutical Chemistry Department, Faculty of Pharmacy and Drug
Manufacturing, Pharos University in Alexandria, Canal El-Mahmoudia Street, Smouha,
Alexandria, Egypt.

Highlights
 HPLC-DAD method for assay of Ketorolac tromethamine binary and ternary mixtures.
 Analysis in-vitro was stability indicating in presence of possible degradations.
 Internal standard method was used for assay in rabbit aqueous humor.
 Validation according to FDA regulation for in-vivo and ICH for in-vitro assays.
 Assay of drugs with degradations, eye drops excipients and biological interference.


Abstract
Ketorolac tromethamine (KTC) with phenylephrine hydrochloride (PHE) binary mixture
(mixture 1) and their ternary mixture with chlorpheniramine maleate (CPM) (mixture 2) were
analyzed using a validated HPLC-DAD method. The developed method was suitable for the in
vitro as well as quantitative analysis of the targeted mixtures in rabbit aqueous humor. The
analysis in dosage form (eye drops) was a stability indicating one at which drugs were
separated from possible degradation products arising from different stress conditions (in vitro
analysis). For analysis in aqueous humor, Guaifenesin (GUF) was used as internal standard
and the method was validated according to FDA regulation for analysis in biological fluids.
Agilent 5 HC-C18(2) 150 x 4.6mm was used as stationary phase with a gradient eluting
solvent of 20 mM phosphate buffer pH 4.6 containing 0.2% triethylamine and acetonitrile.
The drugs were resolved with retention times of 2.41, 5.26, 7.92 and 9.64 min for PHE, GUF,
KTC and CPM, respectively. The method was sensitive and selective to analyze
simultaneously the three drugs in presence of possible forced degradation products and dosage
form excipients (in vitro analysis) and also with the internal standard, in presence of aqueous
humor interferences (analysis in biological fluid), at a single wavelength (261 nm). No
extraction procedure was required for analysis in aqueous humor. The simplicity of the
method emphasizes its capability to analyze the drugs in vivo (in rabbit aqueous humor) and in
vitro (in pharmaceutical formulations).
Keywords: Stability indicating HPLC-DAD; Ketorolac tromethamine; phenylephrine
hydrochloride; chlorpheniramine maleate; eye drops; Quantitative analysis in rabbit aqueous
humor, FDA regulation for validation in-vivo.
Key words: HPLC-DAD, stability-indicating, eye drops, aqueous humor, ketorolac
tromethamine

1 Introduction
Being a non-steroidal anti-inflammatory drug, ketorolac tromethamine (KTC) (fig. S1) is used
in eye drops to decrease ocular itching [2]. The United States Pharmacopeia (USP) describes a
HPLC-UV method for its assay [1]. Several methods have been described in literature for its
determination including: spectrophotometric and spectrofluorometric [3], HPLC-UV [4],
HPTLC [5] and capillary chromatographic [6] methods. Few articles reported the
determination of mixtures containing KTC with sparfloxacin using HPLC [8] and gatifloxacin
using HPTLC [9] methods.
In ophthalmology, the decongestant phenylephrine hydrochloride (PHE) (fig. S1) is used to
treat conjunctivitis [2]. Different titrimetric methods are described for its assay in bulk form
according to USP [1] and British Pharmacopoeia (BP) [10]. While HPLC-UV methods are
described by USP and BP for its dosage forms analysis [1, 10]. Scientific literature includes a
wide variety of methods for its assay in pharmaceuticals using HPLC [11, 12], capillary
electrophoresis [13], HPTLC [14], spectrophotometry [15], spectrofluorometry [16] and
UPLC [17].
The antihistaminic chlorpheniramine maleate (CPM) (fig. S1) is used for the symptomatic
relief of different allergic conditions. It is official in both USP and BP, at which non-aqueous
titrations are used for its determination [1, 10]. Spectrophotometric methods are described by
the USP and BP for its analysis in different dosage forms [1, 10]. Numerous reports can be
found in the scientific literature for its determination. Example of published reports for its
analysis in different pharmaceuticals is HPLC [18], while in human plasma there are different
examples as HPLC-Electrospray Ionization-Tandem Mass Spectrometry (HPLC-ESI-MS/MS)
[19] and HPLC-Mass Spectrometry (HPLC-MS) [20]. Several articles reported the
determination of CPM in mixtures using HPLC [11, 12, 21], HPLC-Tandem Mass
Spectrometry (HPLC-MS/MS) [22] and Spectrophotometry [15].
Both PHE and CPM are assayed together in combined pharmaceutical mixtures using HPLC
[11, 12] and spectrophotometry [15]. An HPTLC method was used for analysis of KTC and
PHE binary mixture in eye vials [23].
A fixed-dose combination vial which is manufactured with strict conditions of GMP to contain
only the active ingredients: KTC (0.3%) and PHE (1%) [24] with the absence of any inactive
components in the formulation is indicated to be used during intraocular lens replacement or
cataract surgery. Also it is indicated for prevention of intraoperative miosis and reduction of
postoperative ocular pain. Moreover, it is added to the ophthalmic irrigation solution used
during such surgeries. Similarly, PHE (0.12%), CPM (0.2%) and KTC (0.5%) eye drops [25]
is used to maintain pupil size, reduce ocular pain and to treat any eye irritation after eye
surgeries. No report is found in literature dealing with their analysis either in dosage form as a
stability indicating method or in aqueous humor.
The aim of this work is the development of a simple, rapid and sensitive HPLC method for the
in vitro and in vivo (quantitation in aqueous humor) analysis of KTC/PHE binary mixture and
KTC/PHE/CPM ternary mixture in their dosage forms and rabbit aqueous humor. The method
is a stability indicating which is able to analyze the drugs in presence of different stress
degradation products and dosage form excipient, moreover, it is a bio-analytical method which
is able to analyze the drugs in presence of aqueous humor interferences. Confirmation of the
peak purity and identity was done using DAD.The proposed method is suitable for their
analysis in rabbit aqueous humor without extraction procedure using guaifenesin (GUF) as
internal standard.
2 Experimental
2.1 Instrumentation
The HPLC-DAD system consisted of Agilent 1200 series (Agilent Technologies, Santa Clara,
CA, USA) (automatic injector, quaternary pump, vacuum degasser and multiple wavelength
diode array detector G1315 C/D and G1365 C/D) connected to a computer loaded with
Agilent ChemStation Software. The column used was Agilent 5 HC-C18 (2) 150 x 4.6mm
2.2 Materials and Reagents
Pharmaceutical grades of KTC, PHE, CPM and internal standard (IS) Guaifenesin (GUF)
were kindly supplied by Pharonia Pharmaceuticals (New Borg El-Arab City, Alexandria,
Egypt) and were certified to contain 99.98%, 99.99%, 99.90% and 99.95% of the drugs,
respectively. HPLC-grade acetonitrile (Scharlau Chemie S.A., Sentmenat, Spain), analytical
grade of ortho-phosphoric acid, hydrochloric acid, sodium hydroxide, 5% hydrogen peroxide
and high purity distilled water were used.
2.3 Chromatographic conditions
A mobile phase system consisting of 20 mM phosphate buffer pH 4.6 and acetonitrile was
used. The separation was achieved with gradient elution using 20 mM phosphate buffer
containing 0.2% triethylamine (A) and acetonitrile (B), the elution started with 95:5 A: B till 1
min, then changed to 75:25 A: B till 1.1 min and continued in this ratio till 9 min After that the
mobile phase returns back to the starting ratio 95:5, A: B till 10 min. The flow rate was 1.0
mL/min. The injection volume was 20 µL. The chromatograms were extracted at the
wavelength of 261 nm. All determinations were performed at 25ºC. Triplicate injections were
made for each concentration.
2.4 Preparation of stock standard solutions
Standard solutions containing 1000, 1000, 500 and 1000 µg.mL–1 of KTC, PHE, CPM and
GUF (internal standard for analysis in aqueous humor) were prepared separately by dissolving
the reference materials in distilled water. Regarding the stability of solutions of the drugs,
stock solutions were stored at 4°C in amber glass vessels and were found to be stable for at
least 10 days.
2.5 Analysis of eye drops (in vitro)
2.5.1 Preparation of calibration standards
The working solutions were prepared by dilution of the corresponding standard solution with
acetonitrile. Different volumes from each drug standard solution were diluted with acetonitrile
in 10-mL volumetric flasks to prepare calibration standards solutions at 10, 20, 30, 50, 60, 75,
90, 95 and 100 µg.mL–1 for KTC, 7.5, 25, 50, 75, 100, 125, 150, 175 and 200 µg.mL–1 for
PHE and 9, 10, 12, 15, 18, 21, 24, 27, 30 µg.mL–1 for CPM. External standard method was
used for analysis of drugs in eye drops.
2.5.2 Forced degradation and stability-indicating study
The ICH guidelines demand conducting forced decomposition studies using a variable
parameters; this was followed by separation of drug from degradation products [26].
According to the stress conditions described below, final dilutions in acetonitrile of 60, 30, 30
µg.mL-1 for KTC, PHE and CPM, respectively were prepared, filtered using a 0.45 µm
filtration disk and chromatographed under the previously described LC conditions.
The conditions for basic, acidic and oxidative hydrolysis with photolytic and dry heat
degradation were summarized in Table 1. For Dry heat degradation, an amount of each drug
powder (100 mg) was used, after the specified time, each powder was dissolved in distilled
water, and aliquots of these stocks were diluted to volume with acetonitrile.
All solutions except for photolytic degradation were cooled. After that all the degraded
solutions were diluted to volume with acetonitrile to obtain the stated final concentrations of
each drug.
2.5.3 Preparation of Laboratory Prepared Pharmaceutical Preparations
OMIDRIA ™ eye vial and KETO-PC ™ eye drops are available in the USA and Indian
markets, respectively [27, 28]. However, due to the unavailability of the commercial dosage
form in the local (Egyptian) market, laboratory prepared preparations were used in the study.
For preparing eye vial OMIDRIA ™ (mixture 1) [29], a volume of 5 mL solution containing
1% PHE and 0.3% KTC was prepared by dissolving 50 and 15 mg PHE and KTC,
respectively, in water for injection containing citric acid and sodium citrate (previously
prepared by dissolving 100 mg citric acid and 100 mg sodium citrate in 1000 mL water for
injection) in a 5-mL volumetric flask. The solution was sonicated for 30 min. For preparing
eye drops KETO-PC ™ (mixture 2), a volume of 10 mL solution containing 0.5% KTC,
0.12% PHE and 0.2% CPM was prepared by dissolving 50, 12 and 20 mg KTC, PHE and
CPM, respectively, in water for injection containing citric acid and sodium citrate in a 10-mL
volumetric flask. The solution was sonicated for 30 min.
2.6. Analysis in rabbit aqueous humor
2.6.1 Preparation of calibration and quality control standards
The calibration and quality control (QC) standards were prepared by spiking control aqueous
humor with standard solutions at 5% of the aqueous humor volume. Calibration standards
were prepared at 10, 20, 30, 50, 60, 75, 90, 95 and 100 µg.mL–1 for KTC, 7.5, 25, 50, 75, 100,
125, 150, 175 and 200 µg.mL–1 for PHE and 9, 10, 12, 15, 18, 21, 24, 27, 30 µg.mL–1 for
CPM. QC standards were prepared at 10 ( lower limit of quantification, LLOQ), 20 (low
quality control, LQC), 60 (medium quality control, MQC) and 90 µg.mL–1 (high quality
control, HQC) for KTC, while for PHE, 7.5 (LLOQ), 25 (LQC), 100 (MQC) and 175 µg.mL–1
(HQC) and for CPM, the following standards were prepared: 9 (LLOQ), 12 (LQC), 21 (MQC)
and 27 µg.mL–1 (HQC). All the spiked solutions were kept frozen at - 20° C. All frozen
calibration and QC standards were thawed at room temperature prior to analysis. Aliquots (2
mL) of each spiked solutions were dispensed into test tubes where 50 µL (equivalent to 50 µg)
of IS solution is added and then transferred into autosampler vials and 20 µL was injected into
the HPLC system. Internal standard method was used to analyze drugs in aqueous humor.
2.6.2 Administration Protocol
Twenty Baladi rabbits, breed synonym is El-Baladi El-Mohassan and the strain is Baladi Red,
(approximately 2 – 2.5 Kg) were obtained from the local market and were housed in the
research animal house. All rabbits were housed individually in a temperature-controlled
animal housing facility, with a 12 h light/night cycle and with free access to food and water.
The laboratory-made pharmaceutical vials similar to OMIDRIA ™ were instilled with a
calibrated adjustable micropipette fitted with disposable tips into the lower conjunctival sac of
the eyes of 2 rabbits by pulling the lower eye lid away from the eyeball, similarly the
laboratory-made pharmaceutical drops similar to KETO-PC ™ were instilled to another 2
rabbits. After instillation, the upper and lower lids were held together for few seconds to avoid
rapid removal of the eye drops from the ocular surface.
2.6.3 Sampling Protocol
After dissection, the eyeballs were removed from the 20 slaughtered rabbits. The aqueous
humor was collected using a syringe needle at the back of the eyeballs. About 2 mL aqueous
humor was extracted from each eye. The extraction procedure from the 4 rabbits instilled with
the eye drops of both preparations were done after one hour of instillation. The aqueous humor
from the instilled 4 rabbits containing the pharmaceutical preparations or the drug-free
aqueous humor from the non-instilled 16 rabbits was frozen under – 20 °C until thawed prior
to analysis.
2.6.4 Analysis of Laboratory Prepared Pharmaceutical Preparations in rabbit aqueous
humor
After the frozen samples were thawed, a volume of 2mL of the aqueous humor was dispensed
into test tubes where 50 µL of IS solution was added afterthat 10 folds dilution with done
with a mixture of 1:1 aqueous humor: acetonitrile and then transferred into autosampler vials
and 20 µL was injected into the HPLC system.
3. Results and discussion
3.1 LC method optimization for either in vitro analysis or in aqueous humor analysis
The work aimed to develop a high-throughput assay with considerable sensitivity for the
simultaneous determination of KTC binary mixture with PHE and its ternary mixture with
PHE and CPM. To attain this objective, different method parameters were assessed in order to
optimize the chromatographic parameters to resolve analytes peaks from each other, from
degradation products, dosage form excipients and from any foreign peaks from aqueous
humor. The method offers advantage of injecting larger number of samples in a short time
period (10 min). The separation was investigated using different ratios of acetonitrile and
buffer on various types of columns such as Hypersil C18, Symmetry C8 and Agilent 5 HC-
C18(2) 150 x 4.6mm at varying flow rates so as to identify optimal chromatographic
condition. The Agilent 5 HC-C18 (2) 150 x 4.6mm fulfilled the desired requirement for both
the analytes and IS peaks and responses. Isocratic elution was unsuccessful as it caused PHE
to elute early (at 1.55 min), therefore gradient elution was used for the separation.
Triethylamine (TEA) was crucial to decrease peak tailing of KTC and CPM. The pH 4.6 was
chosen as it yielded symmetrical peak and in the same time, it is away from the pKa values of
drugs. The mobile phase consisting of 20 mM phosphate buffer containing 0.2% triethylamine
and acetonitrile in the stated gradient elution mode in section 2.3 was found to be the most
suitable for fast elution, good reproducibility and peak shape, (fig. 1). The selected wavelength
(261 nm) provides the desired sensitivity and selectivity of the analysis. The chromatographic
conditions described gave good peaks separation (resolution > 19 and selectivity > 1.2). For
efficiency, the number of theoretical plates values were > 9000.
3.2 Stability indicating aspects (in vitro analysis)
Forced-degradation experiments were carried out on each of the three drugs in order to
produce the possible relevant degradation products and test their chromatographic behavior
using the developed method (table 1)
KTC is susceptible to degradation under the stated acidic and basic conditions. A decrease in
its peak area which reached 12%and 9%of the expected area upon acidic and basic conditions,
respectively with the appearance of different degradation peaks. It was more susceptible to
oxidative degradation (decrease of 72% in its peak area) and four degradation peaks were
eluted. While under photolytic conditions, no sign of degradation was observed. Degradation
of 17% and one degradation product appeared under dry heat degradation conditions (fig. 2).
PHE degradation behavior was nearly similar to KTC under acidic, basic and oxidative
conditions. Unlike KTC, PHE showed one degradation product under photolytic conditions
and did not show any under dry heat degradation conditions, (fig. 2).
CPM was stable under all the stated degradation conditions except for the oxidative stress
conditions as it showed 18% degradation eluting one degradation product, (fig. 2).
3.3 Method validation
For the in vitro analysis, the method was validated according to ICH [30] guidelines while the
quantitation of drugs in aqueous humor, validation was done according to the FDA 2001
Guidance for Industry on Bioanalytical Method Validation [31].
3.3.1 In vitro analysis
3.3.1.1 Linearity and Limits of Detection and Quantification
Regression analysis shows good linearity as correlation coefficient values were higher than
0.999. The statistical regression equations and parameters are shown in supplementary
information file.
Based on signal-to-noise ratio method, LOD values of 1.49, 0.68 and 0.81 and LOQ values of
4.97, 2.27 and 2.70 µg.mL-1, for KTC, PHE and CPM, respectively, were obtained.
3.3.1.2 Accuracy and Precision
Accuracy either with intra-day or inter-day precision were evaluated using three concentration
levels (n=3) within the same day or on 3 consecutive days, respectively. The percentage
relative standard deviation (RSD %) and percentage relative error (Er %) did not exceed 2.0 %
proving the high repeatability and accuracy of the developed method for the estimation of the
analytes in their bulk form, Tables (S2 and S3).
3.3.1.3 Specificity
Method specificity was demonstrated by the successful resolution of the intact drugs from
each other using varied ratios of ten synthetic mixtures (tables S4 and S5) and from their
forced degradation products. No foreign peaks were observed from any of the inactive
ingredients in the dosage form taking into consideration that OMIDRIA ™ [29] lacks any
inactive constituents while for KETO-PC ™, the suspected inactive components that could be
present in eye drops are: benzalkonium chloride, sodium chloride, boric acid, potassium
chloride, sorbitol, hydrochloric acid and/or sodium hydroxide to adjust pH. They were tested
and didn’t interfere in the analysis as the DAD enables peak purity verification, where no co-
elution from the inactive components was detected.
3.3.1.4 Robustness
Robustness was examined by making small changes (Table S6) in acetonitrile content in the
mobile phase (±2 %), the time of gradient program (± 0.1 minute), TEA concentration
(±0.05%), pH value (±0.2), flow rate (±0.05 mL.min-1), or working wavelengths (±2 nm) and
recording the chromatograms of standard mixture of target compounds. These variations did
not have any significant effect on the measured responses (peak area) or retention times of the
drugs.
3.3.1.5 Stability of solutions
The stability of KTC, PHE and CPM working solutions as well as the sample solutions in
acetonitrile was examined. Within 6 h at room temperature, no chromatographic changes were
observed. Also, the stock solutions which prepared in distilled water and stored under
refrigeration at 4 ºC, were found to be stable for at least 2 weeks. No observed changes were
found in the retention times or peak areas of the drugs.
3.3.2 Analysis in rabbit aqueous humor
3.3.2.1 Linearity and LLOQ
The calibration curves of the drugs were constructed from a blank sample (an aqueous humor
sample processed without an IS) (fig. 3a), a zero sample (an aqueous humor sample processed
with IS) and nine non-zero calibration standards covering the entire range including LLOQ.
Linearity was assessed by internal standard method. The ten-point calibration curve was linear
and the data of regression analysis shows good linearity as the correlation coefficient values
were higher than 0.999. Regression equations were: Y= -0.25+0.77X, Y= 0.26+0.26X and Y=
-0.03+0.22X, for KTC, PHE and CPM, respectively (Y is the peak area ratio of drug; X is the
drug concentration in μg.mL-1). The LLOQ samples showed adequate sensitivity for the three
drugs determination in aqueous humor samples (Fig. 3b). The RSD % for six LLOQs was
below 1.47% and the accuracy was between 98.68 and 101.47% for all three analytes.
3.3.2.2 Accuracy and precision
The validation batch used consisted of one set of calibration standards and six replicates (n =
6) of quality control samples at four levels (LLOQ, LQC, MQC and HQC). The accuracy and
precision were evaluated as described under in vitro analysis. The intra-day precision (
RSD%) at LLOQ, LQC, MQC and HQC levels ranged from 0.99 to 1.51% for KTC, 0.74 to
1.95% for PHE and 0.59 to 2.00% for CPM. Inter-day precision ranged from 0.58 to 1.99%
for KTC, 0.81 to 2.00% for PHE and 0.87 to 2.78% for CPM. For accuracy, recoveries values
were from 98-102%, Table (2).
3.3.2.3 Specificity
The specificity of the proposed analytical method demonstrates thelack of chromatographic
interference from endogenous aqueous humor components and the optimum separation of the
drugs from each other. It was evaluated by processing control aqueous humor from six
different rabbits. The aqueous humor samples were spiked with lower limit of quantification
(LLOQ) working solutions along with IS to confirm the lack of interference at their retention
time and absence of rabbit-to-rabbit variation. No interfering peak from endogenous aqueous
humor compounds was observed in blank aqueous humor at the retention times of analytes
and IS. Typical chromatograms for the blank aqueous humor and aqueous humor spiked with
KTC, PHE and CPM at LLOQ in presence of the IS with working concentration are shown in
figs. 3a and 4b. The chromatographic peak purity was assessed using the peak profiles
obtained from DAD.
3.3.2.4 Stability studies
Stability experiments were performed to evaluate the analyte stability in aqueous humor
samples (LQC and HQC, n = 6) under different sample analysis conditions. Long-term
stability was evaluated after storage of the samples at - 70° C for 45 days. Short-term stability
was assessed after storage of spiked QC samples at ambient temperature for 6 h. Post-
preparative stability was assessed after storage at 5° C for 24 h. Freeze–thaw stability was
assessed by analyzing spiked QC samples after five freeze–thaw cycles. For all the stability
experiments of analytes and IS in control aqueous humor, excellent % recovery (98 – 102%)
and RSD % ( less than 2%) values were achieved indicating their stability in different
conditions, (table 3).
3.4. Analysis of laboratory prepared pharmaceutical dosage form (in vitro)
The active ingredients KTC, PHE and CPM eluted at their specific retention times. No
interfering peaks were observed from any of the inactive ingredients. Peak purity was verified
through the peak purity profiling.
Three independently prepared solutions each repeated five times were analyzed and the assay
results revealed satisfactory accuracy and precision as the RSD % and Er % values did not
exceed 2.0 %. Furthermore, reference RP-HPLC methods [11, 32] were statistically compared
with the proposed method using the Student’s t test and the variance ratio F test. The reference
method used for the PHE and CPM [11] comparison utilized C18 column, mobile phase of
16:22:62, acetonitrile: methanol: buffer and quantitation with DAD at 280 nm. While the
reference method used for KTC [32] comparison, utilized C18 column, mobile phase of 60:40,
buffer: acetonitrile and quantitation with DAD at 255 nm. In both tests (t and F tests), there
were no significant differences detected as the calculated values did not exceed the theoretical
ones at the 95 % confidence level (Table 4).
3.5 Analysis of Laboratory Prepared Pharmaceutical Preparations in rabbit aqueous
humor
KTC, PHE, CPM and GUF in rabbits’ aqueous humor eluted at their specific retention times
as shown in fig. 4. No interfering peaks were observed neither from the inactive ingredients
nor the aqueous humor. The purity of chromatographic peaks was ascertained using peak
profiles obtained from DAD (Fig. S7). Ten folds dilution on the extracted aqueous humor
were made before analysis by mixture of 1:1 aqueous humor: acetonitrile till reaching the
linearity range of the three drugs. For mixture 1, the mean found concentrations ± % RSD
were 63.56 µg.mL–1 ± 1.43% and 176.45 µg.mL–1 ± 1.76% for KTC and PHE,
respectively (n=4). While for mixture 2, the mean found concentrations ± % RSD were 72.22
µg.mL–1 ± 1.19%, 19.98 µg.mL–1 ± 2.25% and 27.70 µg.mL–1 ± 2.09% for KTC, PHE and
CPM, respectively (n=4).
4. Conclusions
For the simultaneous determination of PHE/KTC and PHE/KTC/CPM mixtures in their
pharmaceutical combinations and rabbits’ aqueous humor, a HPLC-DAD method was
successfully adopted. The method reveals high throughput ability as a result of the short time
needed for analysis. Reproducible recoveries for the analytes were produced, as the need of no
extraction procedure of the three drugs from aqueous humor was required. Moreover, the three
analytes were exposed to forced degradation using several stress conditions, and the proposed
method achieved considerable resolution of the analytes’ peaks from those of the forced
degradation products. Absence of interferences either from endogenous aqueous humor
components or from degradation products was confirmed by DAD. No such specific
procedure has been reported for the assay of both the binary and ternary drug mixtures in
rabbits’ aqueous humor, in vivo, or in their dosage form (eye drops), in vitro. From the results
of all of the validation parameters, we can deduce that the presented method of analysis can be
applied for conducting bioequivalence studies with considerable sensitivity, precision and
accuracy. At the same time, for checking drugs quality during routine analysis or stability
studies, the proposed method is highly recommended.
Conflict of Interest
The authors declare no conflict of interest.


References
[1] The United States Pharmacopeia, Thirty-fifth edition, The National Formulary, Thirty edition,
United States Pharmacopeial Convention, Inc. , Asian Edition , Washington, D.C.,2012.
[2] S.C. Sweetman, Martindale-The Complete Drug Reference, Thirty -sixth edition, The
Pharmaceutical press, London, 2009.

[3] A. A. Gouda, M. I. K. El-Sayed, A. S. Amin and R. El Sheikh, Arab. J. Chem. 6 (2013) 145-163.

[4] G. Sunil, M. Jambulingam, S. A. Thangadurai, D. Kamalakannan, R. Sundaraganapathy and C.
Jothimanivannan, Arab. J. Chem. (2013) available online (last accesses 10/4/2017)
http://dx.doi.org/10.1016/j.arabjc.2012.12.031

[5] P. V. Devarajan, S. P. Gore and S. V. Chavan, J. Pharm. Biomed. Anal. 22 (2000) 679-683.
[6] S. Orlandini, S. Furlanetto, S. Pinzauti, G. D’Orazio and S. Fanali, J. Chromatogr. A. 1044 (2004)
295-303.
[7] S. Orlandini, S. Fanali, S. Furlanetto, A. M. Marras and S. Pinzauti, J. Chromatogr. A. 1032
(2004) 253-263.
[8]  P. A. Singh R, Chawla P, Indian J. Pharma. Biol. Res. 1 (2013) 95-101.
[9] P. Vandana, P. Shital, K. Suwarna, P. Rushikesh and V. Smita, J. Chem. Pharm. Res. 5 (2013)
135-141.

[10] The British Pharmacopoeia, Her Majesty’s Stationery Office, London, 2013.

[11] A. Dewani, B. Barik, V. Chipade, R. Bakal, A. Chandewar and S. Kanungo, Arab. J. Chem. 7
(2014) 811-816.

[12] A. Marın, E. Garcıa, A. Garcıa and C. Barbas, J. Pharm. Biomed. Anal. 29 (2002) 701-714.

http://dx.doi.org/10.1016/j.arabjc.2012.12.031
[13] A. Marchesini, M. Williner, V. Mantovani, J. Robles and H. Goicoechea, J. Pharm. Biomed.
Anal. 31 (2003) 39-46.

[14] P. V. Devarajan, M. H. Adani and A. S. Gandhi, J. Pharm. Biomed. Anal. 22 (2000) 685-690.

[15] N. Erk, J. Pharm. Biomed. Anal. 23 (2000) 1023-1031.
[16] A. J. Nepote and A. C. Olivieri, Anal. Chim. Acta. 439(2001) 87-94.
[17] E. Deconinck, P.-Y. Sacre, S. Baudewyns, P. Courselle and J. De Beer, J. Pharm. Biomed. Anal.
56 (2011) 200-209.

[18] O. Al-Deeb, N. Foda, F. El Shafie and A. Al-Afifi, J. Liq. Chromatogr. Relat. Technol. 20 (1997)
2221-2231.
[19] R. A. Moreno, D. Oliveira‐Silva, C. E. Sverdloff, B. C. Borges, P. A. Rebelo Galvinas, R. B.
Astigarraga and N. C. Borges, Biomed. Chromatogr. 24 (2010) 774-781.
[20] T. Takagaki, M. Matsuda, Y. Mizuki and Y. Terauchi, J. Chromatogr. B. 776 (2002) 169-176.

[21] M. Qi, P. Wang, Y. Leng, J. Gu and R. Fu, Chromatographia. 56 (2002) 295-298.
[22] Q. Liao, Z. Xie, B. Pan, C. Zhu, M. Yao, X. Xu and J. Wan, Chromatographia. 67 (2008) 687-694.
[23] F. A. El-Yazbi, E. M. Hassan, E. F. Khamis, M. A. A. Ragab and M. M. A. Hamdy, J.
Chromatogr. Sci. 54 (2016) 819-828.


[24]


[25]


[26]



http://www.omidria.com/ (last access on line 10/4/2017)

http://www.healthplus24.com/drugs/ketorolac/keto-pc-05--eye-drops.aspx(last access on line 10/4/2017)

ICH, Stability Testing of New Drug Substances and Products, International Conference on
Harmonization, IFPMA, Geneva. (1993).
http://www.ich.org/fileadmin/Public_Web_Site/ICH_Products/Guidelines/Quality/Q1A_R2/Step4/Q1A_R2__Guideline.pdf
(last access on line 10/4/2017)
http://www.omidria.com/
http://www.healthplus24.com/drugs/ketorolac/keto-pc-05--eye-drops.aspx
http://www.ich.org/fileadmin/Public_Web_Site/ICH_Products/Guidelines/Quality/Q1A_R2/Step4/Q1A_R2__Guideline.pdf





[27]

[28]

[29]

http://www.omeros.com/about/about.htm (last access on line 16/6/2017)

http://www.dawabazar.in/keto_pc/laborate_pharmaceutical_india/15759587 (last access on line
16/6/2017)

R. H. Osher, I. K. Ahmed & G. A. Demopulos, Expert Rev. Ophthalmol. 10 (2015) 91-103. DOI:
10.1586/17469899.2015.1026806
[30] ICH, Harmonized Tripartite Guideline: Validation of Analytical Procedures: Text and
Methodology, Q2 (R1), 2005.
http://www.ich.org/fileadmin/Public_Web_Site/ICH_Products/Guidelines/Quality/Q2_R1/Step4/Q2_R1__Guideline.pdf
(last access on line 10/4/2017)

[31] Guidance for Industry, Bioanalytical Method Validation, US Department of Health and Human
Services, FDA, CDER and CVM: Washington, DC, 2001.
 http://www.fda.gov/downloads/Drugs/Guidance/ucm070107.pdf
(last access on line 10/4/2017)

[32] B. Prathap, A. Dey, G. Srinivaso Rao, Indo Am. J. Pharma. Res. 4 (2014) 1717-1729.
http://www.omeros.com/about/about.htm
http://www.dawabazar.in/keto_pc/laborate_pharmaceutical_india/15759587
http://www.ich.org/fileadmin/Public_Web_Site/ICH_Products/Guidelines/Quality/Q2_R1/Step4/Q2_R1__Guideline.pdf
http://www.fda.gov/downloads/Drugs/Guidance/ucm070107.pdf


Figures Captions:

Figure 1: HPLC chromatogram of 48, 12 and 18 μg mL–1 of KTC, PHE and CPM
standard solutions, respectively


Figure 2: HPLC chromatograms of KTC after exposure to base (a), acid (b), oxidative
(c), thermal dry heat (d) and PHE after base (e), acid (f), oxidative (g) and photolytic UV
degradation (h) with oxidative degradation of CPM (i).










Figure 3: HPLC chromatogram of (a) unspiked aqueous humor and (b) LLOQ of KTC,
PHE and CPM with GUF (IS) in aqueous humor


Figure 4: HPLC chromatogram of (a) KTC (63.56 µg.mL–1) and PHE (176.45 µg.mL–1)
and (b) KTC (72.22 µg.mL–1), PHE (19.98 µg.mL–1) and CPM (27.70 µg.mL–1) both
extracted from rabbits’ aqueous humor after application of preparation mixtures 1 and
2, respectively, using GUF as internal standard




Tables Captions:
Table 1: Summary of degradation studies of KTC, PHE and CPM using the proposed
HPLC method (in vitro analysis).
Table 2: Intra-day and inter-day precision and accuracy (n = 6) for the determination of
KTC, PHE and CPM in rabbits’ aqueous humor using the proposed HPLC method
(analysis in aqueous humor).
Table 3: Stability summary of KTC, PHE and CPM in aqueous humor (n = 6) (analysis
in aqueous humor)
Table 4: Analysis of the laboratory-made pharmaceutical dosage form using the external
standard method and the reference method (in vitro analysis)

Table 1
Summary of degradation studies of KTC, PHE and CPM using the proposed
HPLC method (in vitro analysis).
Analyte
Degradation
conditions
Degradation %
Retention times of
degradation
products (min)
1- Basic Degradation
KTC
3mL,1M NaOHa
90º C for 4 h
9% 3.24, 3.41
PHE 7% 3.97, 4.53
CPM - -
2- Acidic Degradation
KTC
3mL,1M HCla
90º C for 4 h
12% 2.85, 3.22
PHE 9% 4.53
CPM - -
3- Oxidative Degradation
KTC
0.5 mL,5% H2O2
90º C for 15 min
28% 2.81, 3.20, 3.34, 3.54
PHE 22% 4.55
CPM 18% 5.06
4- Photolytic Degradation
KTC
UV 254 nm
10 h
- -
PHE 6% 3.96
CPM - -
5- Dry Heat Degradation
KTC
100º C for 10 h
17% 8.79
PHE - -
CPM - -
a. For the basic and acidic and oxidative hydrolysis, neutralization was done by adding either
1M NaOH or 1M HCl.

Table 2
Intra-day and inter-day precision and accuracy (n = 6) for the determination of KTC,
PHE and CPM in rabbits’ aqueous humor using the proposed HPLC method (analysis in
aqueous humor).
Level
Theoretical
concentration
(µg.mL–1)
Intra-day Inter-day
Calculated
concentration
(µg.mL–1)
%
Recovery
RSD%
Calculated
concentration
(µg.mL–1)
%
Recovery
RSD%
KTC
LLOQ 10 9.89 98.90 1.47 10.12 101.20 1.99
LQC 20 20.17 100.85 1.29 20.02 100.10 0.58
MQC 60 61.10 101.83 1.51 59.74 99.57 1.71
HQC 90 89.84 99.82 0.99 90.66 100.73 1.28
PHE
LLOQ 7.5 7.61 101.47 0.74 7.58 101.07 1.19
LQC 25 25.47 101.88 1.95 24.88 99.52 0.81
MQC 100 101.24 101.24 1.00 99.58 99.58 1.91
HQC 175 178.17 101.81 1.63 172.78 98.73 2.00
CPM
LLOQ 9 9.10 101.11 0.87 9.35 103.89 2.24
LQC 12 12.24 102.00 0.59 12.28 102.33 1.11
MQC 21 20.78 98.95 1.27 21.14 100.67 2.78
HQC 27 26.74 99.04 2.00 27.40 101.48 0.87


Table 3
Stability summary of KTC, PHE and CPM in aqueous humor (n = 6) (analysis in aqueous humor)



Stability
Storage
Condition
KTC PHE CPM
QC
samples
(µg.mL–1)
Mean
RSD
%
%
Recovery
QC
samples
(µg.mL–1)
Mean
RSD
%
%
Recovery
QC
samples
(µg.mL–1)
Mean
RSD
%
%
Recovery
Short-term
Room
temperature
(6h)
20 20.17 1.74 100.85 25 25.14 0.22 100.54 12 12.40 2.00 103.33
90 90.84 1.14 100.93 175 177.29 1.47 101.31 27 26.51 2.14 98.19
Freeze-thaw
After 5 cycles
at -
70°C
20 20.08 0.78 100.40 25 24.58 1.54 98.32 12 12.28 0.22 102.33
90 89.87 1.05 99.86 175 175.80 0.84 100.46 27 27.13 0.81 100.48
Post
preparative
5°C for 24 h
20 19.78 1.12 98.90 25 24.51 0.39 98.04 12 12.23 2.74 101.92
90 89.74 2.00 99.71 175 176.27 0.88 100.73 27 27.74 1.08 102.74
 Long-term
45 days at -
70°C
20 20.36 0.87 101.80 25 25.73 2.87 102.92 12 11.85 1.26 98.75
90 90.28 0.39 100.31 175 174.08 1.32 99.47 27 27.11 0.69 100.41
30

Table 4
Analysis of the laboratory-made pharmaceutical dosage form using the external
standard method and the reference method (in vitro analysis)

Mixture 1
(KTC/PHE)
Recovery % ± RSDa
KTC PHE
Proposed
HPLC
method
Reference
method
[32]
Proposed
HPLC
method
Reference
method
[11]
100.78 ±
1.47
100.12 ±
1.02
101.10 ±
0.95
101.23 ±
1.41
tb 0.82 0.17
Fb 2.08 2.20

Mixture 2
(KTC/PHE/CPM)
Recovery % ± RSDa
KTC PHE CPM
Proposed
HPLC
method
Reference
method
[32]
Proposed
HPLC
method
Reference
method
[11]
Proposed
HPLC
method
Reference
method
[11]
101.12 ±
0.91
100.74 ±
1.47
100.09 ±
1.18
100.64 ±
1.25
100.92 ±
1.20
100.39 ±
0.79
tb 0.49 0.72 0.82
Fb 2.61 1.12 2.31

a. Mean ± relative standard deviation of five determinations.
b. Theoretical values of t and F are 2.31 and 6.39, respectively, at 95% confidence limit
