Nokia Flexi Cabinets Description

DN09247917
Issue 12
Approved on 2023-11-17
Single RAN BTS Site Solutions
Rel. 24R2-SR
Operating Documentation, Issue 02
© 2024 Nokia. Nokia Condential Information. Use subject to agreed restrictions on disclosure and use.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
2 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Nokia is committed to diversity and inclusion. We are continuously reviewing our customer
documentation and consulting with standards bodies to ensure that terminology is inclusive
and aligned with the industry. Our future customer documentation will be updated
accordingly.
This document includes Nokia proprietary and condential information, which may not be
distributed or disclosed to any third parties without the prior written consent of Nokia. This
document is intended for use by Nokia’s customers (“You”/”Your”) in connection with a
product purchased or licensed from any company within Nokia Group of Companies. Use this
document as agreed. You agree to notify Nokia of any errors you may nd in this document;
however, should you elect to use this document for any purpose(s) for which it is not
intended, You understand and warrant that any determinations You may make or actions
You may take will be based upon Your independent judgment and analysis of the content of
this document.
Nokia reserves the right to make changes to this document without notice. At all times, the
controlling version is the one available on Nokia’s site.
No part of this document may be modied.
NO WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO
ANY WARRANTY OF AVAILABILITY, ACCURACY, RELIABILITY, TITLE, NON-INFRINGEMENT,
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, IS MADE IN RELATION TO THE
CONTENT OF THIS DOCUMENT. IN NO EVENT WILL NOKIA BE LIABLE FOR ANY DAMAGES,
INCLUDING BUT NOT LIMITED TO SPECIAL, DIRECT, INDIRECT, INCIDENTAL OR
CONSEQUENTIAL OR ANY LOSSES, SUCH AS BUT NOT LIMITED TO LOSS OF PROFIT,
REVENUE, BUSINESS INTERRUPTION, BUSINESS OPPORTUNITY OR DATA THAT MAY ARISE
FROM THE USE OF THIS DOCUMENT OR THE INFORMATION IN IT, EVEN IN THE CASE OF
ERRORS IN OR OMISSIONS FROM THIS DOCUMENT OR ITS CONTENT.
Copyright and trademark: Nokia is a registered trademark of Nokia Corporation. Other
product names mentioned in this document may be trademarks of their respective owners.
© 2024 Nokia.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
3
Table of Contents
 Summary of changes 6 ....................................................................................................................
1 EU compliance 8 ...............................................................................................................................
2 FCC Part 15 compliance 10 ............................................................................................................
3 Overview of Nokia Flexi Cabinets 11 .............................................................................................
4 Flexi Cabinet for Indoor (FCIA) 12 .................................................................................................
4.1 FCIA description 12 ..............................................................................................................
4.1.1 FCIA contents of delivery 13 ...................................................................................
4.1.2 FCIA dimensions and weight 14 ..............................................................................
4.2 FCIA optional items 15 ........................................................................................................
5 Flexi Cabinet for Outdoor (FCOA) 18 ............................................................................................
5.1 FCOA description 18 ............................................................................................................
5.1.1 FCOA contents of delivery 19 .................................................................................
5.1.2 FCOA dimensions and weight 20 ............................................................................
5.2 FCOA optional items 21 ......................................................................................................
6 Flexi Cabinet Outdoor (FCOB) 24 ..................................................................................................
6.1 FCOB description 24 ............................................................................................................
6.1.1 FCOB contents of delivery 29 .................................................................................
6.1.2 FCOB dimensions and weight 30 ............................................................................
6.1.3 FCOB interfaces 31 ...................................................................................................
6.1.4 FCOB LED indications 33 .........................................................................................
6.2 FCOB optional items 34 ......................................................................................................
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
4 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
List of Figures
Figure 1 CE marking (EU R&TTE Directive 1999/5/EC) 8 ...........................................................
Figure 2 CE marking 8 ......................................................................................................................
Figure 3 RED Article 10.10-marking 9 ...........................................................................................
Figure 4 FCIA overview 13 ..............................................................................................................
Figure 5 FCIA contents of delivery 14 ..........................................................................................
Figure 6 FMBB overview 16 ............................................................................................................
Figure 7 FSEE overview 16 ..............................................................................................................
Figure 8 FCOA overview 19 ............................................................................................................
Figure 9 FCOA contents of delivery 19 ........................................................................................
Figure 10 FPMA overview 22 ..........................................................................................................
Figure 11 FSEE overview 22 ...........................................................................................................
Figure 12 FSES overview 23 ...........................................................................................................
Figure 13 Lock – version A 27 ........................................................................................................
Figure 14 Lock - version B 27 ........................................................................................................
Figure 15 FCOB cabinetversions 28 .............................................................................................
Figure 16 FCOB contents of delivery 29 ......................................................................................
Figure 17 FCOB PDU interfaces 32 ...............................................................................................
Figure 18 FYGG overview 34 ..........................................................................................................
Figure 19 Flexi enhanced external GPS box (FYGE) 34 ...............................................................
Figure 20 Slotpack AC/DC power solution for FCOB 35 ............................................................
Figure 21 Interfaces in the Slotpack AC/DC power solution 36 ...............................................
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
5
List of Tables
Table 1 Contents of FCIA delivery 14 ...........................................................................................
Table 2 FCIA dimensions and weight 15 .......................................................................................
Table 3 Contents of FCOA delivery 20 .........................................................................................
Table 4 FCOA dimensions and weight 21 .....................................................................................
Table 5 Contents of FCOB delivery 30 .........................................................................................
Table 6 FCOB dimensions and weight 31 .....................................................................................
Table 7 FCOB PDU box interfaces 32 ...........................................................................................
Table 8 FCOB cabinet interfaces 33 .............................................................................................
Table 9 FCOB LED indications 33 ..................................................................................................
Table 10 Slotpack AC/DC power solution dimensions and weight 35 .....................................
Table 11 Slotpack AC/DC power solution interfaces 37 ............................................................
Table 12 Slotpack LED indications in the Rectifiers part 38 .....................................................
Table 13 Slotpack LED indications in the Smartpack part 38 ...................................................
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
6 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Summary of changes
Changes between document issues are cumulative. Therefore, the latest document issue
contains all changes made to previous issues.
Changes between document issues are cumulative. Therefore, the latest document issue contains
all changes made to previous issues.
Changes between issues 11 (2023-09-06) and 12 (2023-11-17)
General changes
Power consumption has been changed to power draw.
Changes between issues 10 (2023-02-22) and 11 (2023-09-06)
General changes
The document has been renamed to Nokia Flexi Cabinet Description.
Information about ACOC has been moved to Nokia AirScale System Module Product
Description.
FCFA, FCSA, and FSEB have been removed.
The Power consumption of Outdoor Cabinet fans chapter has been removed and the applicable
information has been moved to FCOB description.
FCIA description
FCIA description has been extended with new information.
FCIA optional items
More information about FMBB has been added.
FCOA description
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
7
Benefits of FCOA have been added.
FCOB description
FCOB benefits and external alarms have been added.
Information on fan power draw has been added.
Changes between issues 09 (2023-02-02) and 10 (2023-02-22)
ACOC description
Information on cabinet cooling has been added.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
8 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
1. EU compliance
EU RoHS statement, CE marking, Directive 2014/53/EU (RED) Article 10.10 compliance
EU RoHS statement
This equipment complies with the European Union RoHS Directive 2011/65/EU on the restriction
of the use of certain hazardous substances in electrical and electronic equipment. The directive
applies to the use of lead, mercury, cadmium, hexavalent chromium, Polybrominated Biphenyls
(PBB), and Polybrominated Diphenyl Ethers (PBDE) in electrical and electronic equipment.
CE marking
The equipment described in this document complies with either:
The relevant provisions of the European Union R&TTE Directive 1999/5/EC for some products
shipped prior to June 30, 2017
Figure 1: CE marking (EU R&TTE Directive 1999/5/EC)

Hereby, Nokia declares that one or more of these base stations is compliant with the essential
requirements and other relevant provisions of Directive: 1999/5/EC.
or
European Union Radio Equipment Directive (RED) 2014/53/EU for some current products and all
products shipped after June 30, 2017.
Figure 2: CE marking

Hereby, Nokia declares that radio equipment type Flexi Multiradio 10 BTS and Nokia AirScale
BTS is compliant with Directive 2014/53/EC. For the full text of the EU declaration of
conformity, see Single RAN/Reference documentation/Declaration of Conformities (DoCs).
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
9
These declarations are only valid for configurations (combinations of software, firmware, and
hardware) provided and/or supported by Nokia.
Directive 2014/53/EU (RED) Article 10.10 compliance
The radio frequency usage in EU is restricted and before you use the radio equipment in the
commercial network you must apply for the band license from the local regulator.
As an evidence for the restriction, the packaging is to have the RED Article 10.10-marking
describing the impacted countries.
Figure 3: RED Article 10.10-marking

C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
10 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
2. FCC Part 15 compliance
Note:
This equipment has been tested and is compliant with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction,may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment causes harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from the one to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Class A (not Class B) of FCC Part 15 may be met when using specific SFPs in some product
configurations. For more details, see List of Supported Nokia BTS SFPs.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
Note:
This compliance statement is not applicable to all hardware units described in this
document.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
11
3. Overview of Nokia Flexi Cabinets
Information about supported products
This document provides an overview of Nokia Flexi Cabinets, including general descriptions,
dimensions and weights, contents of deliveries, and optional items.
The following products are covered in this document:
Flexi Cabinet for Indoor (FCIA)
Flexi Cabinet for Outdoor (FCOA)
Flexi Cabinet Outdoor (FCOB)
Tip:
Graphics included in the document are representations and should only be considered as
examples.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
12 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
4. Flexi Cabinet for Indoor (FCIA)
Information on Flexi Cabinet for Indoor (FCIA) 470152A specification, contents of delivery,
dimensions and weight, and optional items
Related documents:
For information on installing FCIA, see Installing Flexi Cabinet for Indoor FCIA.
For information on installing Nokia BTS Modules in FCIA, see Installing Flexi Multiradio 10 BTS
Modules in Cabinets.
For more information on installing FCIA, see also Flexi Cabinet for Indoor (FCIA) Quick Guide.
For more information about maintaining, see Maintaining Flexi Cabinet for Indoor FCIA.
4.1 FCIA description
Flexi Cabinet for Indoor (FCIA) (470152A) is available for Flexi Multiradio 10 BTS installations where
additional protection is needed or where the number of modules prevents installation in a stack.
FCIA provides 36U space and 19-inch free space for installing Flexi Multiradio 10 BTS modules and
for optional site support. The cabinet is made of a hot-dip galvanizing steel plate and is used for
indoor installations requiring a secure cabinet, including large indoor configurations exceeding 22U
that need earthquake protection. The FCIA cabinet doesn't carry any electrical functionality, as it
doesn't have traditional backplanes or electronics. The cable entries are located at the top of the
cabinet. External cables are connected directly to the Flexi modules inside the cabinet.
The main advantages of FCIA include:
several hours of shared battery backup for a single cabinet with one or two BTSs.
additional space for other 19-inch units.
earthquake protection for configurations with more than six modules.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
13
Figure 4: FCIA overview

FCIA locking
The cabinet doors have padlockable cam locks. You can use a padlock for more protection. The
cabinet doesn't support customer-specific BTS locks.
4.1.1 FCIA contents of delivery
Delivery contents of Flexi Cabinet for Indoor (FCIA) 470152A
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
14 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Figure 5: FCIA contents of delivery

Table 1: Contents of FCIA delivery
Property Code Content
FCIA 470152A 1 x cabinet
Site bag 1 822083 30 x guide shelve
Site bag 2 6338845 62 x loose cage nut
6401026 and 6150886 2 x cable clamp with 4 x K30x24 torx screw
4.1.2 FCIA dimensions and weight
FCIA holds 36U of free space for modules.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
15
Table 2: FCIA dimensions and weight
Property Value
Height 1800 mm (70.87 in.)
Depth 600 mm (23.62 in.)
Width 597 mm (23.50 in.)
Weight (empty cabinet) 60 kg (132 lb)
4.2 FCIA optional items
List of optional items supported by Flexi Cabinet for Indoor (FCIA) (470152A)
List of optional items supported by FCIA:
Flexi battery mounting kit for FCIA (FMBB) (471459A), including the indoor long-term multi-
integrated battery backup solution (MIBBU)—62 Ah or 92 Ah battery with an indoor installation
cable kit
Flexi power rectifier (FPRB) (CS7000030)
Flexi system external alarm module (FSEE) (473751A)
Flexi system external OVP (FSES/FSEP) (472285A/473246A)
FMBB
FMBB (471459A) is needed when using batteries in FCIA. The mounting kit is installed at the
bottom of the cabinet.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
16 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Figure 6: FMBB overview

FPRB
FPRB (CS7000030) is a modular 6 kW output power AC rectifier consisting of three individual 2 kW
and 3 kW AC/DC power modules operating in parallel mode. FPRB outputs a positive earthed –54
VDC (V48N) as a BTS operational supply voltage rail and for site battery charging. It supports Flexi
Multiradio 10 BTS configurations in indoor and outdoor cabinets, as well as stack, pole, and wall
configurations.
For more information on the FPRB, see FPRB Flexi Power Rectifier in Nokia BTS Optional Items
Description.
FSEE
You can install FSEE (473751A.101) on the cabinet roof and use it to extend the Flexi BTS alarm
connector up to 24 alarms.
Figure 7: FSEE overview

For more information on FSEE, see FSEE Flexi System External Alarm Module in Nokia BTS
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
17
Optional Items Description.
FSES/FSEP
FSES/FSEP (472285A/473246A) is an IP-protected enclosure for overvoltage protection and power
terminals. You can install FSES/FSEP on the cabinet roof.
For more information on the OVP enclosures, see FSEP/FSES Flexi System External OVP in the
Nokia BTS Optional Items Description document.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
18 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
5. Flexi Cabinet for Outdoor (FCOA)
Flexi Cabinet for Outdoor (FCOA) 470142A specification, contents of delivery, dimensions, and
weight, and optional items
Related documents:
For information on installing FCOA, see Installing Flexi Cabinet for Outdoor FCOA.
For information on installing Nokia BTS Modules in FCOA, see Installing Flexi Multiradio 10
BTS Modules in Cabinets.
For more information on installing FCOA, see also Flexi Cabinet for Outdoor (FCOA) Quick
Guide.
For more information about maintaining FCOA, see Maintaining Flexi Cabinet for Outdoor
FCOA.
5.1 FCOA description
Flexi Cabinet for Outdoor (FCOA) (470142A) is available for Flexi Multiradio 10 BTS installations
where additional protection is needed or where the number of modules prevents installation in a
stack.
FCOA provides additional shielding for the BTS site and space for auxiliary devices. FCOA provides
19-inch wide free space for installing BTS modules. It has an aluminum chassis enclosed with
aluminum sides and door. You can lock the cabinet door with a triangle door-open key. For
additional protection, you can also lock the cabinet with a padlock using the provided padlock
fastener. FCOA doesn't have any electrical functionality and doesn't increase BTS site power draw.
The cabinet protects the BTS and cables against external damage and foreign objects.
Configurations exceeding 22U require earthquake protection.
The Flexi Multiradio 10 BTS system and RF modules are IP65 weather-protected. FCOA is an
option for sites where further protection is needed. The main benefits of FCOA include:
module and cable protection against severe weather conditions, such as wind-driven rain.
earthquake protection for Flexi Multiradio 10 BTS configurations with more than six modules
(WCDMA, EDGE, WiMax, or LTE).
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
19
Figure 8: FCOA overview

5.1.1 FCOA contents of delivery
Delivery contents of Flexi Cabinet for Outdoor (FCOA) 470142A
Figure 9: FCOA contents of delivery

C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
20 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Table 3: Contents of FCOA delivery
Property Code Content
FCOA 470142A 1 x cabinet
6490006/6490809 1 x triangle key
Site bag 1 6497988 1 x latch
6332594 62 x M5 cage nut
825362 24 x support rail AI
6150287 2 x M5x12 torx screw
6401026 and 6150747 2 x cable clamp, 4 x K30x24 torx screw
824774 2 x FCOA knock-out plate
6331075 1 x lock nut
6607940 1 x strap flexi 164.5 mm hook
Site bag 2 822546 10 x dummy panel
00049229 1 x instruction sheet (FCOA Cabinet Quick
Guide)
5.1.2 FCOA dimensions and weight
FCOA holds 40U (30U horizontally + 5U + 5U vertically) of free space for modules.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
21
Table 4: FCOA dimensions and weight
Property Value
Height 1550 mm (61.02 in.)
Depth 770 mm (30.31 in.)
Depth with air filter 930 mm (36.61 in.)
Depth with air filter and wind plate 1020 mm (40.16 in.)
Width 770 mm (30.31 in.)
Weight (empty cabinet) 60.8 kg (134 lb)
Weight (with air filter and wind plate) 97.2 kg (214 lb)
Total weight (fully equipped with batteries) 358 kg (789 lb)
5.2 FCOA optional items
Optional items used with Flexi Cabinet for Outdoor (FCOA) 470142A
The following optional items can be mounted to the FCOA cabinet:
Flexi power rectifier (FPRB) (CS7000030)
Flexi system external alarm module (FSEE) (473751A)
Flexi system external OVP (FSES/FSEP) (472285A/473246A)
FPMA
FPMA (470139A) is a casing for the AC input and DC output cable connector box. FPMA can house
up to three AC/DC rectifiers, each of which has an output power of 1 kW 48 V DC power.
Additionally, FPMA can house up to three battery submodules, which can provide up to one hour
of battery backup time when the AC power mains is down on a typical 1+1+1 Flexi Multiradio 10
BTS site. You can connect two hardware alarms from FPMA directly to the Flexi Multiradio 10 BTS
system module using an Ethernet RJ-45 cable.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
22 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Figure 10: FPMA overview

FPRB
FPRB (CS7000030) is a modular 6 kW output power AC rectifier package consisting of three
individual 2 kW/3 kW AC/DC power modules operating in parallel mode. FPRB outputs a positive
earthed –54 VDC (V48N) as a respective BTS operational supply voltage rail and for site battery
charging. It supports Flexi 10 Multiradio BTS configurations in indoor and outdoor cabinets, as well
as stack, pole, and wall configurations.
For more information on the FPRB, see FPRB Flexi Power Rectifier in Nokia BTS Optional Items
Description.
FSEE
You can install FSEE (473751A.101) on the cabinet roof and use it to extend the Flexi BTS alarm
connector up to 24 alarms. FCOA includes a lock and a door alarm switch.
Figure 11: FSEE overview

For more information on FSEE, see FSEE Flexi System External Alarm Module in Nokia BTS
Optional Items Description.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
23
FSES/FSEP
FSES/FSEP (472285A/473246A) is an IP-protected enclosure for overvoltage protection and power
terminals. You can install FSES/FSEP on the cabinet roof.
Figure 12: FSES overview
For more information on the OVP enclosures, see FSEP/FSES Flexi System External OVP in
Nokia BTS Optional Items Description.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
24 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
6. Flexi Cabinet Outdoor (FCOB)
Flexi Cabinet Outdoor (FCOB) (473240A/473240B) specification, contents of delivery, dimensions,
and weight, and optional items
Related documents:
For information on installing FCOB, see Installing Flexi Cabinet for Outdoor FCOB.
For more information on installing FCOB, see also Flexi Cabinet Outdoor (FCOB) Quick Guide.
For more information about maintaining, see Maintaining Flexi Cabinet for Outdoor FCOB.
6.1 FCOB description
FCOB Flexi Cabinet Outdoor (473240A/473240B) is designed to house indoor system modules
and enable their deployment in an outdoor environment. FCOB is introduced by the 5GC000416
feature.
The cabinet can accommodate one Flexi Multiradio 10 system module indoor (FSIH) or one Nokia
AirScale system module indoor. FCOB provides IP55-protected installation spacefor indoor
system modules. FCOB enables installing indoor system module in similar outdoor locations as
Flexi outdoor modules.
FCOB provides an internal space of 4U for the following types of configurations:
FSIH + 1U optional unit (for example, FYGG/FYGE GPS module)
4U optional units (no batteries)
FCOB provides the following types of configurations:
FSIH full configuration (FSIH + 2x FBIH) + FYGG/FYGE or another optional unit
AMIA full configuration (2x AirScale control plug-in unit + 6x AirScale capacity plug-in unit) +
FYGG/FYGE or another optional unit
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
25
Note:
For NR-ready capacity plug-in units, Nokia recommends using AMOD outdoor subrack or
ACOC outdoor cabinet.
Due to FCOB thermal load limitation, the maximum configurations with ABIO/ABIN/ABIL
are:
2x ASIL /2x ASIB + 3x ABIN + 3x ABIA (the maximum ambient temperature is 50°C
(122°F))
2x ASIL /2x ASIB + 2x ABIO/ABIL + 2x ABIA (the maximum ambient operating
temperature is 45°C (113°F))
2x ASIL /2x ASIB + 1x ABIO/ABIL + 3x ABIA (the maximum ambient operating
temperature is 45°C (113°F))
Note:
Consult local Nokia support on your optional unit configuration.
The main benefits of FCOB include:
IP55 protection for indoor system module deployment in outdoor environment
Environment operating temperature from –40°C to 50°C (–40°F to 122°F) (with solar radiation)
and operating temperature for devices installed inside FCOB from –5°C to 55°C (23°F to 131°F)
Operating relative humidity from 5% to 85%
4U internal space
Operational status of components in the cabinet monitored and collected via the system
module EAC interface
Flexible installation options
The maximum allowed heat load produced by the 4U of units installed inside FCOB is 1500 W.
FCOB has four external alarms:
Door alarm
Internal fans alarm
External fans alarm
High-temperature alarm
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
26 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Benefits of FCOB
Field-replaceable PDU box (for power delivery and fan control)
Support for a total of eight customer external alarms, and additionally four alarm lines
reserved for cabinet own internal alarms
Field-replaceable internal and external fan submodule
Heater
Installation options
Wall installation (using either side of FCOB, vertical installation only)
Pole installation (using either side of FCOB, vertical installation only)
Floor installation:
Stand-alone on the floor (either vertically or horizontally)
Two FCOBs stacked (horizontal installation only)
3U casings stacked on top of FCOB (horizontal installation only):
up to three 3U casings for earthquake Zone 4
up to five 3U casings for earthquake Zone 2
FCOB installed on top of a 3U casing (horizontal installation only, not allowed for earthquake
Zone 4)
Note:
The maximum number of 3U casings in a stack with a FCOB installed on top is three.
Versions of FCOB
FCOB can have two locking options:
Lock with triangle cylinder – version A (473240A)
Tip:
The lock and key aren't replaceable, but you can add a padlock for more security.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
27
Figure 13: Lock – version A

Swing handle lock with cylinder – version B (473240B)
IP55 according to DIN EN 60529
Resistance-Class II according to DIN EN 1630:2011-09/RC2
Vibration Resistance according to DIN EN 61373 2011
Cylinder profile according to standard DIN 18252
Figure 14: Lock - version B

Tip:
You should exchange the cylinder for own cabinet security needs and responsibility.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
28 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Figure 15: FCOB cabinet versions

Power draw of FCOB fan
Values of FCOB fan power draw:
30 W idle
50 W typical
150 W max. ambient
500 W cold start (heater active)
The total power draw of a Flexi cabinet site support module depends on the installed third-party
configuration in the line terminal equipment space. The estimated maximum heat load can be
assumed to be the same as the power draw values.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
29
6.1.1 FCOB contents of delivery
Delivery contents of Flexi Cabinet Outdoor (FCOB) 473240A/473240B
Figure 16: FCOB contents of delivery

Note:
Version B.101 cabinet does not include a separate code for key in the accessory bag. The
key is delivered with the swing handle lock.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
30 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Table 5: Contents of FCOB delivery
Property Code Content
FCOB 473240A/473240B 1 x cabinet
Site bag 830028 2 x lifting part
087670A 2 x mounting bracket
829933 2 x guide plate
830137 1 x cable entry cover
995816 and 995817 2 x power cable (1 x positive, 1 x negative)
995864 1 x EAC cable
6401142 10 x cable tie
P305124 1 x drilling jig
830470 4 x connecting stud
P206180 20 x M5 screw
6490006 1 x key
P353858 1 x instruction sheet (Flexi Cabinet Outdoor
(FCOB) Quick Guide)
6.1.2 FCOB dimensions and weight
FCOB holds 4U of free space for modules.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
31
Table 6: FCOB dimensions and weight
Property Value
Height (cabinet) 600 mm (23.62 in.)
Height (mounting bracket) 160 mm (6.30 in.)
Depth 600 mm (23.62 in.)
Width 380 mm (14.96 in.)
Weight (empty cabinet without mounting kits) 473240A.102 weight 29 kg (63.9 lb) max
473240B.101 weight 30 kg (66.1 lb) max
Volume 137 L (36.19 gal.)
Free space for modules 4U (177.8 mm)
6.1.3 FCOB interfaces
FCOB has two power outputs for internal units: maximum 42 A for output 1 and maximum 5 A for
output 2. The cabinet also has four external alarms: door alarm, internal fans alarm, external fans
alarm, and high temperature alarm.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
32 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Table 7: FCOB PDU box interfaces
Interface Connector Description
Power supply (DC IN –/DC IN +) 2-pole connector DC input, max. 50 A
Power supply (DC OUT +/DC
OUT –)
2-pole connector DC output1, max. 1500 W
Breaker – For DC output 1
Power supply (terminal block) Terminal block connector DC output 2, max. 180 W
Fuse – DC output 2, 5 A port
protection
Switch Rotary switch 1500 W high performance
1500 W low noise
1000 W lower noise
700 W lower noise
EAC 19PIN connector EAC to SM
TEST 19PIN connector Debugging and testing
Figure 17: FCOB PDU interfaces
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
33
Table 8: FCOB cabinet interfaces
Interface Connector Description
Grounding 1 x M8 screw or 2 x M5 screw
(NEBS)
–
ESD ESD stud –
External alarm Terminal block connector Alarm input connector
6.1.4 FCOB LED indications
LED indications of Flexi Cabinet Outdoor (FCOB) 473240A/473240B
Table 9: FCOB LED indications
Status Condition Color Description
Internal fans (INT FAN) Normal Green, stable Normal fan operation
Fault Red, stable Fan speed differs 30%
or more from the
reference
External fans (EXT
FAN)
Normal Green, stable Normal fan operation
Fault Red, stable Fan speed differs 30%
or more from the
reference
Board running status
(RUN)
Normal Green, stable PDU box powered and
no fault
Fault Red, stable PDU box in
malfunction status
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
34 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
6.2 FCOB optional items
Optional items used with Flexi Cabinet Outdoor (FCOB) 473240A/473240B
You can use the following optional items with the FCOB cabinet:
OD external GNSS enhanced holdover (FYGG)
Flexi enhanced external GPS box (FYGE)
Slotpack AC/DC power solution for FCOB
FYGG
FYGG (473185A) provides an IP65-rated solution for RF GNSS signal to 1PPs+ToD conversion and
extended holdover performance using existing GNSS infrastructure. It supports the two global
positioning systems GPS and GLONASS.
Figure 18: FYGG overview

For more information on the FYGG, see FYGG Outdoor External GNSS Enhanced Holdover in
Nokia BTS Optional Items Description.
Flexi enhanced external GPS box (FYGE)
FYGE (472978A) provides synchronization for one Flexi BTS from a GNSS system.
Figure 19: Flexi enhanced external GPS box (FYGE)

C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
35
For more information on the FYGE, see FYGE Flexi Enhanced External GPS Box in Nokia BTS
Optional Items Description.
Slotpack AC/DC power solution for FCOB
Slotpack AC/DC power solution is a standalone 5.4 kW/48 VDC rectifier system prepared for
integration into 1U/19” slot. Its AC input range is 100–250 V AC with typical efficiency of > 95% at
25–80% load. The Smartpack S control unit offers easy control and comprehensive monitoring of
the power system.
All the building blocks combined make it an effective and safe power system, suitable for a wide
range of indoor and outdoor applications.
This power system consists of:
Smartpack S controller
Up to three 1800 W rectifiers for total power of 5.4 kW
Battery breaker: 1 x 80 A with LVBD
Load breakers: 1 x 60 A, 2 x 80 A
Figure 20: Slotpack AC/DC power solution for FCOB

Table 10: Slotpack AC/DC power solution dimensions and weight
Property Value
Height 44 mm (1.75 in.)
Depth 262 mm (10.31 in.)
Width 482 mm (18.98 in.)
Weight 5.2 kg (11.5 lb)
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
36 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Figure 21: Interfaces in the Slotpack AC/DC power solution

C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
Issue 12. © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
37
Table 11: Slotpack AC/DC power solution interfaces
Property Value
Mains feed interface 1 phase 230 V AC or 3 phase (Δ) 230/400 V AC, 3 phase
(Y)
Max. 4 mm2 (AWG12)
Battery distribution 1 x 80 A, max. 25 mm2 (2AWG)
M6 cable lug
Load distribution 1x 60 A, 2 x 80 A, max. 25 mm2 (2 AWG)
M6 cable lug
Inputs/Outputs 6 x digital inputs, max. 0.5 mm2 (20 AWG), spring terminals
6 x relay alarm outputs, max. 0.5 mm2 (20 AWG), spring
terminals
Serial port (RS-232 or RS-485
connect)
RJ-11, 6 pins
Ethernet port RJ-45, 8 pins
10/100 BASE-T HP
Auto MDI/MDI-X
The Enter or Left arrow key When entering numbers, a short press of this key
navigates to the left
A long press of this key enters and saves data
The Cancel or Right arrow key When entering numbers, a short press of this key
navigates to the right
A long press of this key cancels or aborts data
The Up and Down arrow keys To navigate up or downwards the menu icons, point at
options and increase and decrease values
The Slotpack solution has LED indicators placed in the Smartpack as well as in the Rectifiers part
of the set. LED indications in the Smartpack help to operate the DC power system from the
controller’s front panel.
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
Nokia Flexi Cabinets Description
38 © 2024 Nokia. Nokia Confidential Information
Use subject to agreed restrictions on disclosure and use.
Issue 12
Table 12: Slotpack LED indications in the Rectifiers part
LED color Description
Red, alarm Alarms:
• Low /high input voltage shutdown
• High /low temperature shutdown
• Rectifier Failure
• Overvoltage shutdown on output
• Fan failure
• Low output voltage alarm
• CAN bus failure
Yellow, warning Warnings:
• Rectifier in power de-rate mode
• Remote output current limit activated
• Input voltage out of range, flashing at
overvoltage
• Loss of CAN communication with controller
Green Normal operation
Table 13: Slotpack LED indications in the Smartpack part
LED color Description
Green
Power: OFF
Power: ON
The controller has NO supply
The supply is healthy
Green
Warning: OFF
Warning: ON
No Warning
Warning (Minor alarm, Non-critical alarm)
Green
Alarm: OFF
Alarm: ON
No Alarm
Alarm (Major alarm, Critical Alarm)
C
opyrighted m
aterial licensed to rodrigo.c.braganca@
nokia.com
 on 20-06-2024.
N
o further reproduction or netw
orking is perm
itted. D
istributed by N
okia.
